Delta Electronics LMWM860A 802.11 bgn RF Module User Manual
Delta Networks, Inc. 802.11 bgn RF Module
User Manual
LM-WM860A-R
Preliminary Product Specification
IEEE802.11n 2.4GHz WLAN Mini-PCI Adapter
Note: This document contains proprietary technical information in which is the property of the Delta Networks
Inc. and shall not be disclosed to others in whole or in part, reproduced, copied, or used as the basis for
design, manufacturing, or sale of apparatus without written permission of Delta Networks Inc.
Delta Networks Inc. ii
Table Of Contents
1.
REVISION HISTORY...................................................................................................................................................... 1
1.1.
D
OCUMENT
R
EVISION
H
ISTORY
................................................................................................................................... 1
2.
GENERAL DESCRIPTION ............................................................................................................................................ 2
2.1.
F
EATURES
.................................................................................................................................................................... 2
2.2.
M
ECHANICAL
D
ESIGN
.................................................................................................................................................. 3
2.3.
IC
S
OLUTION
............................................................................................................................................................... 4
2.4.
VID,
DID,
SVID
AND
SPID
ASSIGNMENT
................................................................................................................... 5
3.
TECHNICAL SPECIFICATIONS .................................................................................................................................. 6
4.
DELIVERY PACKAGE ................................................................................................................................................... 8
Delta Networks Inc. 1
1. Revision History
Revision Date Remark
1.00 2009/0213 Product Initial
1.1. Document Revision History
Revision Date Remark
1.00 2009/02/13 Preliminary product spec
Delta Networks Inc. 2
2. General Description
LM-WM860A-R is compliant with mini PCI standard Adapter. The Atheros 802.11b/g/n IEEE802.11n technique
delivers up to 54Mbps (802.11g) or 300Mbps 11n data rate, the bandwidth support 20MHz and 40MHz for legacy
WLAN standard and also fulfilled high throughput data rate requirement on IEEE802.11n, it uses 2 sets of 2.4GHz
Tx / Rx antenna’s combinations, since the IEEE802.11b/g is CCK & OFDM modulation scheme and used CCK
modulation to follow backward compatible with IEEE802.11b, up to 54Mbps on single 2.4GHz frequency band. It
supports the Quality of Service for 802.11e. (WMM) feature to enable robust wireless streaming of audio and video
content while remaining compatible with any 802.11b/g devices.
2.1. Features
Form Factor – a compatible with Mini-PCI Adapter
32-bit 33 and 66MHz PCI v2.3 interface
Support for IEEE 802.11g standard, IEEE802.11b and IEEE802.11n compliant
Support 802.11e-compatible bursting, 802.11h, 802.11j and 802.11i
Security Cypher text WEP, TKIP and AES hardware encryption
2x2 MIMO technology improves effective throughput and range over existing 802.11b/g/n products
Frame aggregation with A-MPDU
Wake-on-Wireless feature supported
Supports spatial multiplexing, cyclic-delay diversity (CDD) and Maximal Ratio Combining (MRC)
Data rate 802.11b/g: 1,2,5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54-Mbps
and Atheros IEEE802.11n rate at 150Mbps (HT20MHz channel bandwidth; 300Mbps (for HT40MHz
channel bandwidth)
Drivers - Microsoft
®
Windows
®
2000, XP and Vista and Linux
Delta Networks Inc. 3
2.2. Mechanical Design
To be defined as standard Mini-PCI TypeIIIA form factor
Delta Networks Inc. 4
2.3. IC Solution
The IC solution for LM-WM860A-R:based on Atheros MB91 chipset
P/N Functionality Description
AR9223 IEEE802.11n MIMO MAC/BB/RF
for 2.4 GHz WLANs
The Atheros AR9223 is a highly integrated single-chip solution
for 2.4GHz 802.11n-ready wireless local area networks (WLANs)
that enable high-performance 2x2 MIMO configurations for
wireless station applications demanding robust link quality and
maximum throughput and range. The AR9223 integrates a
multi-protocol MAC, baseband processor, analog to digital and
digital to analog (ADC/DAC) converters, 2x2 MIMO radio
tranceiver, and PCI interface in an all CMOS device for low
power and small form factor applications.
Delta Networks Inc. 5
2.4. VID, DID, SVID and SPID assignment
1. Vendor ID (VID): use Chip’s vendor ID = 0x168C
2. Device ID (DID): use Chip’s device ID = 0x??
3. Sub-Vendor ID (SVID): use manufacture’s ID = 0x4033
4. Sub-Product ID (SPID): use manufacture’s product ID = 0x7827
Delta Networks Inc. 6
3. Technical Specifications
LM-WM860A-R Specification
Specification Wireless LAN PC Card
WLAN Standard IEEE802.11b, IEEE 802.11g; IEEE802.11e, IEEE802.11h; IEEE802.11i;
IEEE802.11j; IEEE802.11n standard
Data Rate IEEE802.11b/g: 1/2/5.5/6/9/11/12/18/24/36/48 and 54Mbps
And with IEEE802.11n data rate up to 150Mbps (HT20MHz) and
300Mbps( HT40MHz)
Wireless Medium Complementary code keying (CCK) and Orthogonal Frequency Division
Multiplexing (OFDM); MIMO-OFDM
Frequency Band 2.4GHzband:ISM band 2.412 – 2.484GHz and FCC band
2.412-2.462GHz
Modulation Technique OFDM: BPSK@6/9 Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps
64-QAM@48/54Mbps
DSSS: DBPSK @1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM and 64QAM
Wired Equivalent Privacy
64-bit, 128-bit data encryption
Antenna 2X Tx and 2X Rx
Delta Networks Inc. 7
LM-WM860A-R specification (continued)
Specification Wireless LAN PC Card
Receive Sensitivity TBD
Max output power TBD
Power consumption
Measured for 2xTx / 2x Rx:
TBD
Drivers Windows 2000, XP, Vista and Linux version
Security WPA, 802.1x, TKIP
Certification Certified with embedded product as radio module for pre-scan on FCC
Part 15 (North America) Compliant
Form Factor Mini-PCI TypeIIIA
Operating Environment Temperature: 0~40℃ (operating)
-40~85℃ (storage)
Humidity (non-condensing): 10~95% RH
Dimension (L x W) 60mmx50mm
Delta Networks Inc. 8
4. Delivery Package
IEEE802.11n 2.4GHz WLAN Mini-PCI TypeIIIA Adapter
Driver CD
The product Spec and Datasheets are based on Atheros reference design from MB91
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
This device is intended only for OEM integrators under the following
conditions:
1) The antenna must be installed such that 20 cm is maintained between the
antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or
antenna,
3) For all products market in US, OEM has to limit the operation channels in CH1 to
CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply
any tool or info to the end-user regarding to Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed.
IMPORTANT NOTE: In the event that these conditions can not be met (for example
certain laptop configurations or co-location with another transmitter), then the FCC
authorization is no longer considered valid and the FCC ID can not be used on the
final product. In these circumstances, the OEM integrator will be responsible for
re-evaluating the end product (including the transmitter) and obtaining a separate
FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may
be installed such that 20 cm may be maintained between the antenna and users. The
final end product must be labeled in a visible area with the following: “Contains FCC
ID: PD5‐LMWM860A”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user
regarding how to install or remove this RF module in the user’s manual of the end
product which integrates this module.
The end user manual shall include all required regulatory information/warning as
show in this manual.
