AV SURROUND RECEIVER

AVR-787

OPERATING INSTRUCTIONS

¢SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

1. Read Instructions – All the safety and operating instructions should be read

before the product is operated.

2. Retain Instructions – The safety and operating instructions should be

retained for future reference.

3. Heed Warnings – All warnings on the product and in the operating

instructions should be adhered to.

4. Follow Instructions – All operating and use instructions should be followed.

5. Cleaning – Unplug this product from the wall outlet before cleaning. Do not

use liquid cleaners or aerosol cleaners.

6. Attachments – Do not use attachments not recommended by the product

manufacturer as they may cause hazards.

7. Water and Moisture – Do not use this product near water – for example,

near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement;

or near a swimming pool; and the like.

8. Accessories – Do not place this product on an unstable cart, stand, tripod,

bracket, or table. The product may fall, causing serious injury to a child or

adult, and serious damage to the product. Use only with a cart, stand,

tripod, bracket, or table recommended by the manufacturer, or sold with

the product. Any mounting of the product should

follow the manufacturer’s instructions, and should

use a mounting accessory recommended by the

manufacturer.

9. A product and cart combination should be moved

with care. Quick stops, excessive force, and

uneven surfaces may cause the product and cart

combination to overturn.

10. Ventilation – Slots and openings in the cabinet are provided for ventilation

and to ensure reliable operation of the product and to protect it from

overheating, and these openings must not be blocked or covered. The

openings should never be blocked by placing the product on a bed, sofa,

rug, or other similar surface. This product should not be placed in a built-in

installation such as a bookcase or rack unless proper ventilation is provided

or the manufacturer’s instructions have been adhered to.

11. Power Sources – This product should be operated only from the type of

power source indicated on the marking label. If you are not sure of the type

of power supply to your home, consult your product dealer or local power

company. For products intended to operate from battery power, or other

sources, refer to the operating instructions.

12. Grounding or Polarization – This product may be equipped with a polarized

alternating-current line plug (a plug having one blade wider than the other).

This plug will fit into the power outlet only one way. This is a safety feature.

If you are unable to insert the plug fully into the outlet, try reversing the

plug. If the plug should still fail to fit, contact your electrician to replace

your obsolete outlet. Do not defeat the safety purpose of the polarized

plug.

13. Power-Cord Protection – Power-supply cords should be routed so that they

are not likely to be walked on or pinched by items placed upon or against

them, paying particular attention to cords at plugs, convenience

receptacles, and the point where they exit from the product.

15. Outdoor Antenna Grounding – If an outside antenna or cable system is

connected to the product, be sure the antenna or cable system is grounded

so as to provide some protection against voltage surges and built-up static

charges. Article 810 of the National Electrical Code, ANSI/NFPA 70,

provides information with regard to proper grounding of the mast and

supporting structure, grounding of the lead-in wire to an antenna discharge

unit, size of grounding conductors, location of antenna-discharge unit,

connection to grounding electrodes, and requirements for the grounding

electrode. See Figure A.

16. Lightning – For added protection for this product during a lightning storm,

or when it is left unattended and unused for long periods of time, unplug it

from the wall outlet and disconnect the antenna or cable system. This will

prevent damage to the product due to lightning and power-line surges.

17. Power Lines – An outside antenna system should not be located in the

vicinity of overhead power lines or other electric light or power circuits, or

where it can fall into such power lines or circuits. When installing an

outside antenna system, extreme care should be taken to keep from

touching such power lines or circuits as contact with them might be fatal.

18. Overloading – Do not overload wall outlets, extension cords, or integral

convenience receptacles as this can result in a risk of fire or electric shock.

19. Object and Liquid Entry – Never push objects of any kind into this product

through openings as they may touch dangerous voltage points or short-out

parts that could result in a fire or electric shock. Never spill liquid of any

kind on the product.

20. Servicing – Do not attempt to service this product yourself as opening or

removing covers may expose you to dangerous voltage or other hazards.

Refer all servicing to qualified service personnel.

21. Damage Requiring Service – Unplug this product from the wall outlet and

refer servicing to qualified service personnel under the following

conditions:

a) When the power-supply cord or plug is damaged,

b) If liquid has been spilled, or objects have fallen into the product,

c) If the product has been exposed to rain or water,

d) If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the

operating instructions as an improper adjustment of other controls may

result in damage and will often require extensive work by a qualified

technician to restore the product to its normal operation,

e) If the product has been dropped or damaged in any way, and

f) When the product exhibits a distinct change in performance – this

indicates a need for service.

22. Replacement Parts – When replacement parts are required, be sure the

service technician has used replacement parts specified by the

manufacturer or have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock, or other

hazards.

23. Safety Check – Upon completion of any service or repairs to this product,

ask the service technician to perform safety checks to determine that the

product is in proper operating condition.

24. Wall or Ceiling Mounting – The product should be mounted to a wall or

ceiling only as recommended by the manufacturer.

25. Heat – The product should be situated away from heat sources such as

radiators, heat registers, stoves, or other products (including amplifiers)

that produce heat.

SAFETY INSTRUCTIONS

FIGURE A

EXAMPLE OF ANTENNA GROUNDING

AS PER NATIONAL

ELECTRICAL CODE

ENGLISH

FCC INFORMATION (For US customers)

1. PRODUCT

This product complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this product may not cause harmful

interference, and (2) this product must accept any interference received,

including interference that may cause undesired operation.

2. IMPORTANT NOTICE: DO NOT MODIFY THIS PRODUCT

This product, when installed as indicated in the instructions contained in this

manual, meets FCC requirements. Modification not expressly approved by

DENON may void your authority, granted by the FCC, to use the product.

3. NOTE

This product has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation.

This product generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

product does cause harmful interference to radio or television reception,

which can be determined by turning the product OFF and ON, the user is

encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the product into an outlet on a circuit different from that to

which the receiver is connected.

•Consult the local retailer authorized to distribute this type of product or

an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du

Canada.

¢NOTE ON USE

•Avoid high temperatures.

Allow for sufficient heat dispersion when installed

in a rack.

•Handle the power cord carefully.

Hold the plug when unplugging the cord.

•Keep the apparatus free from moisture, water, and

dust.

•Unplug the power cord when not using the

apparatus for long periods of time.

* (For apparatuses with ventilation holes)

•Do not obstruct the ventilation holes.

•Do not let foreign objects into the apparatus.

•Do not let insecticides, benzene, and thinner come

in contact with the apparatus.

•Never disassemble or modify the apparatus in any

way.

ENGLISH

Contents

Thank you for choosing the DENON AVR-787 AV Surround Receiver. This remarkable component has been engineered to provide superb surround sound listening with home theater sources such as DVD, as well as

providing outstanding high fidelity reproduction of your favorite music sources.

As this product is provided with an immense array of features, we recommend that before you begin hookup and operation that you review the contents of this manual before proceeding.

Accessories······················································································2

Before using ····················································································2

Cautions on installation·································································3

About the remote control unit······················································3

Inserting the batteries····································································3

Operating range of the remote control unit································3

Part names and functions

Front panel ·····················································································4

Display····························································································4

Rear panel ······················································································5

Remote control unit ···································································5, 6

Easy to setup flow··········································································7

Speaker layout [Basic layout]························································7

Speaker connections······································································8

Connecting a DVD player and monitor ········································9

Auto Setup

qConnecting a microphone ·······················································10

wBefore performing the Auto Setup procedure ························10

ePerform the Auto Setup procedure·········································11

rAssigning power amplifiers ·····················································11

tSwitching the front speaker ····················································11

yStarting Auto Setup ·································································11

uChecking and storing the measurement results ·····················12

Error messages ············································································12

Check the parameter····································································13

Cable indications ··········································································13

The video conversion function····················································14

On screen display signals ····························································14

Connecting a TV/DBS tuner························································15

Connecting a video camera or video game ··································15

Connecting the external inputs (EXT. IN) terminals ·················15

Connecting a CD player ·······························································16

Connecting a tape deck ·······························································16

Connecting a VCR·········································································16

Connecting a CD recorder or MD recorder ································17

Connecting the antenna terminals·······································17, 18

Connecting the XM terminal·······················································18

Connecting the iPod®··································································18

Connecting the MULTI ZONE terminals

ZONE2 out connections ·······························································19

ZONE2 speaker out connections ·················································19

Connecting the PRE OUT terminals············································20

Connecting the power supply cord ············································20

Playing the input source······························································21

Turning the sound off temporarily (MUTING)·······························22

Listening over headphones ··························································22

Switching the front speakers ·······················································22

Checking the currently playing program source, etc. ··················22

Switching the brightness of the display·······································22

Using the surround modes

Types of surround modes and their features·························22, 23

Selecting the play mode (DIRECT/STEREO) ································23

Selecting the Dolby Digital and DTS Surround mode

(only with digital input) ·································································24

Selecting the Dolby Pro Logic IIx (Pro Logic II) mode·················25

Selecting the DTS NEO:6 mode ··················································26

Selecting the NEURAL SURROUND mode ·································26

Checking the input signals ···························································26

Surround modes and parameters········································27 ~ 29

Basic Operation

Getting Started

Easy Setup Procedure

Connecting Other Sources Using the DENON original surround modes

Types of surround modes and their features·······························30

Selecting the DSP surround simulation ·······································31

Setting the tone control ·······························································32

Adjusting the speaker volume ·····················································32

Using the fader function ······························································32

Listening to the radio

Auto preset memory ····································································33

Auto tuning···················································································33

Manual tuning ··············································································33

Preset memory ············································································34

Checking the preset stations ·······················································34

Recalling preset stations ······························································34

XM Satellite Radio········································································34

Checking the XM signal strength and Radio ID ···························35

Channel selection·········································································35

Category search ···········································································35

Night mode ···················································································36

User mode function

Storing the settings in the memory ·············································36

Calling the settings out ································································36

Combining the currently playing sound

with the desired image (VIDEO SELECT function)····················36

Personal memory plus function··················································36

Playing the iPod®·········································································37

Listening to music········································································38

Viewing still pictures and videos

(only for iPods equipped with the slideshow / video function)····38

Disconnecting the iPod ································································38

Multi zone music entertainment system·····························39, 40

Outputting a program source to amplifier, etc.,

in the ZONE2 room (ZONE2 SELECT mode) ·······························41

Remote control unit operations during multi-source playback·····41

Recording (audio and/or video) ··················································42

About the memory functions······················································42

Initialization of the microprocessor (Reset) ·································42

Advanced Operation

ENGLISH

Speaker Setup

Setting the Speaker Configuration ·········································54, 55

Setting the Subwoofer Setup ······················································55

Setting the Distance ······························································55, 56

Setting the Channel Level······················································56, 57

Setting the Crossover Frequency ················································57

Troubleshooting······································································65, 66

Additional Information···························································63, 64

Specifications················································································66

List of preset codes············································End of this manual

Operating DENON audio components ·······································58

Setting the preset memory function··········································58

Operating a component stored in the preset memory····59 ~ 61

Setting the punch through function···········································62

Advanced Setup – Part 2

Operating the remote control unit

System setup items and default values ····························43 ~ 45

Navigating through the System Setup Menu ···························46

About the on screen display and front display ·························47

Audio Input Setup

Setting the Digital In Assignment ················································47

Setting the EXT IN Subwoofer Level ···········································48

Setting the iPod Assignment ·······················································48

Setting the Input Function Level··················································48

Setting the Function Rename ······················································49

Setting the Tuner Presets ······················································49, 50

Video Setup

Setting the Component In Assignment ·······································51

Setting the Video Convert····························································51

Setting the Audio Delay ·······························································51

Setting the On Screen Display (OSD) ··········································52

Advanced Playback

Setting the 2ch Direct/Stereo ······················································52

Setting the Auto Surround Mode·················································52

Option Setup

Setting the Power Amplifier Assignment ····································53

Setting the Volume Control··························································53

Setting the Setup Lock ································································54

Advanced Setup – Part 1

Accessories

Check that the following parts are attached in addition to the main

unit:

qOperating instructions ..............................................................1

wWarranty (for North America model only).....................................1

eService station list ....................................................................1

rRemote control unit (RC-1046).................................................1

tR6P/AA batteries ......................................................................2

yAM loop antenna ......................................................................1

uFM indoor antenna ...................................................................1

iSetup microphone (DM-S205) (Approx. 20 ft / 6 m) ................1

Getting Started

Before using

Pay attention to the following before using this unit:

•Moving the unit.

To prevent short-circuits or damaged wires in the connection cables,

always unplug the power supply cord and disconnect the connection

cables between all other audio components when moving the unit.

•Cautions on using mobile phones.

Using a mobile phone near this unit may result in noise. If so, move

the mobile phone away from this unit when it is in use.

•Before turning the power operation button on.

Check once again that all connections are correct and that there are

not problems with the connection cables. Always set the power

operation button to the standby position before connecting and

disconnecting connection cables.

•Store these instructions in a safe place.

After reading, store this instructions along with the warranty card in

a safe place.

•Whenever the power operation button is in the STANDBY state,

the unit is still connected to AC line voltage.

Please be sure to turn off the power operation button or unplug

the cord when you leave home for, say, a vacation.

•Note that the illustrations in these instructions may differ from

the actual unit for explanation purposes.

Getting Started Getting Started

ENGLISH

About the remote control unit

In addition to controlling the AVR-787, the attached remote control

unit (RC-1046) can also be used to control the following products:

qDENON component products

wComponent products other than DENON:

•Set using the preset memory function ( page 58).

Inserting the batteries

qRemove the remote control

unit’s rear cover.

wSet two R6P/AA batteries in

the battery compartment in

the indicated direction.

ePut the rear cover back on.

Notes on batteries:

•Replace the batteries with new ones if the set does not operate

even when the remote control unit is operated nearby the unit.

(The attached batteries are only for verifying operation.)

•When inserting the batteries, be sure to do so in the proper

direction, following the “<” and “>” marks in the battery

compartment.

•To prevent damage or leakage of battery fluid:

•Do not use a new battery together with an old one.

•Do not use two different types of batteries.

•Do not short-circuit, disassemble, heat or dispose of batteries

in flames.

•Remove the batteries from the remote if it will not be in use for

long periods.

•If the battery fluid should leak, carefully wipe the fluid off the

inside of the battery compartment and insert new batteries.

•When replacing the batteries, have the new batteries ready and

insert them as quickly as possible.

Operating range of the remote control unit

30°

Approx. 23 feet/7 m

•Point the remote control unit at the remote sensor when operating

it.

•The remote control unit can be used from a distance of approximately

23 feet/7 meters, at a horizontal angle of up to 30° with respect to

the sensor.

NOTE:

•It may be difficult to operate the remote control unit if the remote

sensor is exposed to direct sunlight or strong artificial light.

Cautions on installation

Wall

Note

Note:

For heat dispersal, do not install this unit in a confined space such

as a bookcase or similar enclosure.

Getting Started Getting Started

ENGLISH

Display

qInput signal indicators

wInput signal channel indicators

•The audio channel(s) included in the input signal

light(s).

•This lights when the digital signal is inputted.

eInformation display

rOutput signal channel indicators

The audio channels that can be output light.

tSpeaker indicators

This lights corresponding to the settings of the

front speakers of the various surround modes.

yZONE2 output indicator

uMaster volume indicator

This displays the volume level.

The Setup item number is displayed in System

Setup.

iZONE2/REC SELECT indicators

Lights while selecting the ZONE2 or REC

SELECT mode. (Off when the “SOURCE” is

selected.)

oInput mode indicators

!0 AUTO indicator

This lights when the broadcast station is selected

in the AUTO tuning mode.

!1 STEREO indicator

This lights when an FM stereo broadcast has

been received.

!2 TUNED indicator

This lights when an FM/AM broadcast has been

received.

Part names and functions

Front panel

For details on the functions of these parts, refer to the pages given in parentheses ( ).

qPower operation button

(ON/STANDBY)··········································(10)

wPower indicator ·········································(10)

ePower switch·······································(10, 42)

rHeadphones jack (PHONES)·····················(22)

tANALOG button ········································(21)

ySPEAKER buttons································(22, 42)

uZONE2 button············································(40)

iSHIFT button··············································(34)

oUSER MODE buttons ································(36)

!0 PRESET buttons·········································(33)

!1 V. AUX INPUT terminals

Remove the cap covering the terminals when

you want to use them.

!2 SETUP MIC jack·········································(10)

!3 SYSTEM SETUP button····························(11)

!4 SURR. MODE/SURR. PARA button····(21, 31)

!5 SELECT/ENTER knob··························(11, 31)

@8@9 @7 @3@6 @4 @2@5 !9 !7@1

@0 !8

r y i o !1 !4!2 !5 !6

eu !0

u y

!0!2 !1

er t

!6 Cursor buttons (DD, HH)·······························(11)

!7 MASTER VOLUME control knob··············(21)

!8 TUNING buttons (•, ª)·····························(33)

!9 STATUS button··········································(22)

@0 DIMMER button·········································(22)

@1 VIDEO SELECT button ······························(36)

@2 Display

@3 BAND button··············································(33)

@4 EXT. IN button············································(22)

@5 Remote control sensor································(3)

@6 INPUT MODE button·································(21)

@7 ZONE2/REC SELECT button·····················(41)

@8 FUNCTION knob ········································(21)

@9 MAIN button ··············································(21)

•The SELECT/ENTER knob on the main unit operates

in the same way as the CURSOR FFand GGbuttons

on the remote control unit.

•The control functions in the same way as the

CURSOR FFbutton when turned counterclockwise,

as the CURSOR GGbutton when turned clockwise.

•The control functions in the same way as the ENTER

button when pressed the knob.

Getting Started Getting Started

ENGLISH

Remote control unit

Remote control signal

transmitter························(3)

Power buttons················(10)

Master volume control

buttons····························(21)

CH SELECT/ENTER

button························(11, 32)

NIGHT/AUDIO

button························(36, 59)

MUTING button··············(22)

STATUS/RETURN

button························(22, 59)

Tuner system/System

buttons······················(33, 59)

Rear panel

qEXT. IN terminals·······································(15)

wDIGITAL terminals

(Optical/Coaxial) ·······································(9, 16)

eAUDIO OUT terminals·······························(14)

rSpeaker terminals ·······································(8)

tPower supply cord·····································(20)

yAC outlets···················································(20)

uPRE OUT terminals······························(19, 20)

iCOMPONENT VIDEO terminals··················(9)

oVIDEO/S-VIDEO terminals··························(9)

!0 DOCK CONTROL jack································(18)

!1 AUDIO IN terminals·····································(9)

!2 XM terminal ···············································(18)

!3 ANTENNA terminals ·································(17)

!4 REMOTE CONTROL jacks ·························(19)

VIDEO SELECT/SETUP

button························(36, 59)

Function buttons············(21)

Indicator··························(58)

Cursor buttons

(DD, HH, FF, GG)····················(11)

ON SCREEN/

DISPLAY button········(22, 59)

DIMMER/MENU

button························(22, 59) Mode selector

switches····················(10, 58)

System buttons ·····(59 ~ 61)

!2!3 !1 !0 o i u y t

w e r

[ Front ]

NOTE:

•If buttons on the front or rear are pressed strongly, the button on the opposite side will be activated

too.

Getting Started Getting Started

ENGLISH

MAIN buttons·················(41)

Function/

Number buttons·············(21)

SURROUND PARAMETER/

AUDIO button···········(21, 59)

ENTER button·················(11)

Cursor buttons

(DD, HH, FF, GG)····················(11)

INPUT MODE/RETURN

button························(21, 59)

SURROUND MODE

buttons····························(23)

TEST TONE/DISPLAY

button························(57, 59)

Tuner system/System

buttons······················(33, 61)

ZONE2 buttons···············(41)

SYSTEM SETUP/SETUP

button························(11, 59)

[ Rear ]

NOTE:

•If buttons on the front or rear are pressed strongly, the button on the opposite side will be activated

too.

Easy Setup Procedure

ENGLISH

Speaker layout [Basic layout]

Example of basic layout with eight speakers and a monitor.

Subwoofer Center speaker

Surround speaker

Surround back speaker

Front speaker

Set these at the sides of the

monitor or screen with their front

surfaces as flush with the front of

the screen as possible.

•This section contains the basic steps necessary to configure the AVR-787 according to your listening

room environment and the source equipment and loudspeakers you are using.

•To set the sound field manually ( page 54 ~ 57).

Easy to setup flow

Easy Setup Procedure

Auto setup flow

1) Speaker Configuration

2) Distance

3) Channel Level

Connecting a microphone ( page 10).

The measurement of the speakers in the

listening position.

Check of the measurement result.

Placing the speakers.

Connecting the speakers.

Connect the DVD player to

the AVR-787.

Connect the AVR-787’s

monitor output terminal to

the TV’s video input

terminal ( page 9). Store the measurement result in the memory.

Play a DVD.

•Do not plug in the power supply cord until all connections have been completed.

><<>><<>

><><

(L) (R)

(L) (R) (L) (R)

Easy Setup Procedure Easy Setup Procedure

ENGLISH

¢Connections

•With the AVR-787, up to ten speakers can be connected for surround playback.

•When making connections, also refer to the operating instructions of the other components.

When using only one surround back

speaker, connect it to the left channel.

Connection terminal for

subwoofer with built-in

amplifier.

Front speakers

(A)

Surround

speakers

Front speakers

(B)

Subwoofer

Surround back

speakers

Center

speaker

ImpedanceSpeaker

Connecting the speaker cables

Speaker connections

Connect the speaker terminals with the speakers

making sure that like polarities are matched (<

with <, >with >).

¢Speaker impedance

Note on speaker impedance

When using speakers with an impedance

below the designated value (for example 4

Ω/ohms), playing for long periods of time with

the volume high could cause the temperature

to rise, activating the protection circuit.

When the protection circuit is activated, the

output to the speakers is cut off and the power

indicator blinks. If this happens, unplug the

power cord, wait for the set to cool off and

improve ventilation around the unit. Also check

the wiring of the input cables and the speaker

cables. After doing this, plug the power cord

back in and turn the unit’s power back on.

If the protection circuit is activated again even

though there are no problems with the wiring or

the ventilation around the unit, switch off the

power and contact a DENON service center.

NOTE:

When making connections, take care that

none of the individual conductors of the

speaker cable come in contact with adjacent

terminals, with other speaker cable

conductors, or with the rear panel and

screws.

NEVER touch the speaker terminals when

the power is on. Doing so could result in

electric shocks.

1. Loosen by turning

counterclockwise.

Either tightly twist or terminate the core

wires.

2. Insert the cable.

3. Tighten by turning clockwise.

6 ~ 16 Ω/ohms

Center

Surround

Surround back / ZONE2

6 ~ 16 Ω/ohmsFront A, B

12 ~ 16 Ω/ohmsFront A+B

Connecting banana plugs

Turn clockwise to tighten, then

insert the banana plug.

Easy Setup Procedure Easy Setup Procedure

ENGLISH

•For best picture quality (especially with progressive DVD and other high definition sources), choose the

component video connection to your monitor. S-Video and composite video outputs are also provided if

your monitor does not have component video inputs.

Connecting a DVD player and monitor

•To connect the video output from the DVD player to the AVR-787, you only need to choose one

connection type. For more information about the video up conversion function ( page 14).

•To connect the digital audio output from the DVD player, you can choose from either the coaxial or

optical connections. If you choose to use the coaxial connection, it needs to be assigned. For more

information about Digital Input Assignment ( page 47).

Audio signal flow is shown with white arrows, video signal flow is shown with gray arrows.

•The AVR-787 is equipped with another set of input terminals for a non-DVD video disc player (such as

laser disc, VCD/SVCD, or future high definition disc player). The above connection guidelines for DVD

also apply to the VDP input.

•The component video input and/or output terminals may be labelled differently on some monitors or

video components. Check the owner’s manuals for other components for further information.

DVD player

S VIDEO

OUT

AUDIO OUT

VIDEO

OUT

COMPONENT VIDEO OUT

OPTICAL

OUT

S VIDEO

VIDEO

Monitor

COMPONENT VIDEO IN

Easy Setup Procedure Easy Setup Procedure

ENGLISH

Auto Setup

The AVR-787’s auto setup use the attached microphone to measure

the acoustic properties in the room and automatically make the

optimum settings.

•To make the sound field settings manually ( page 54 ~ 57).

qConnecting a microphone

Connect the attached setup microphone to <SETUP

MIC>.

Mount the setup microphone on a camera tripod, etc.,

and set with the receptor pointing towards the ceiling.

Microphone

Place the setup microphone’s sound receptor at the height of the

ears in the listening position.

It is not possible to measure properly if there are any obstacles

between the speakers and microphone. Check that there are no

obstacles.

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

Sound receptor

Press <ON/STANDBY>or [ON/SOURCE].

•The power indicator blinks green and the power turns on.

Press <POWER>.

£OFF:

The power turns off and the indicator is off.

¢ON:

The power indicator lights red.

Turn on your subwoofer.

Set the volume to halfway and set the crossover frequency to

the maximum or Low pass filter off if your subwoofer can adjust

the output volume and the crossover frequency.

Some subwoofers have a standby mode. Be sure to turn this

function off before performing the Auto Setup procedure.

Turn on your monitor.

wBefore performing the Auto Setup procedure

Set [MODE SELECTOR 1] to “AUDIO”.

SYSTEM SETUP

[ON/SOURCE]

ENTER

D H F G

[MODE SELECTOR 1]

D H F G

ENTER

SYSTEM SETUP

<POWER> SYSTEM SETUP

F G

, ENTER

D H

NOTE:

•Once the settings are completed, disconnect the setup microphone.

Easy Setup Procedure Easy Setup Procedure

ENGLISH

rAssigning power amplifiers

Press DDHHto select “Power Amp Assign”, then press FF

GGto set.

The surround back output can be assigned to the “Front” or “ZONE2”

output.

Front A, Front B:

Assign to use the “Front A” or “Front B” speakers with bi-amp

connections.

Surround Back:

Assign to use as surround back speaker.

When assigned to “Front” or “ZONE2”, skip the surround back

channel measurement.

During the auto setup procedure, test tones are not output to

“ZONE2”.

ZONE2:

Assign to use as “ZONE2” speakers.

tSwitching the front speaker

Press DDHHto select “Front Sp”, then press FFGGto select

the speaker.

Front A Front B Front A+B

yStarting Auto Setup

Press DDHHto select “Start”, then press FF.

•Start the measurements.

Measurement of each channel is performed as follows:

FL FR C SW SL SR

SBL SBR

1 2

1: The subwoofer speaker is measured twice.

2: Not displayed when “ZONE2” and “FRONT” are set at

“Setting the Power Amplifier Assignment” ( page 53).

•After each channel is measured, “Calculating” appears.

•The display switches to the Auto Setup check screen

automatically.

NOTE:

•Do not change the speaker connections or subwoofer volume

after making the measurements.

•Do not turn off the power while the data is being stored.

Cautions during measurements:

•Loud test tones are output during the measurements. Be careful

for example when small children are nearby.

•Proper measurements may not be possible if there are obstacles

between the speaker and the setup microphone.

•During the measurements, do not stand between or near the

speakers and setup microphone.

•To avoid influencing the measurements, turn off the power of air-

conditioners or any other equipment producing sound in the

room. Perform the measurements with the room as quiet as

possible.

•Measurement is cancelled when VOLUME is operated while the

Auto Setup is performed.

ePerform the Auto Setup procedure

Press DDHHto select “Auto Setup”, then press ENTER.

Press SYSTEM SETUP.

Press DDHHto select “Auto Setup”, then press ENTER.

The message “Connect Microphone” is displayed if no

microphone is connected. If so, connect the auto setup

microphone.

•“System Setup” menu is not displayed when using headphones.

¢About automatic retry

To confirm the results of the measurements, remeasurement is

automatically performed.

Remeasurement is performed up to two times. During this time,

“Retry1” or “Retry2” is displayed on the screen.

MeasuresCauseExample

qThis screen will be displayed when the speakers required

for producing suitable reproduction have not been detected.

•Check that the pertinent speakers are properly connected.

wThis screen will be displayed when the speaker polarity is

connected in reverse.

•Check the polarity of the pertinent speakers. For some

speakers, this screen may be displayed even though the

speakers are properly connected.

If so, select “Skip

”.

eThis screen will be displayed when accurate measurements

cannot be made due to the input level of the microphone being

too high.

•Set up the speakers so that their position is farther away

from the listening position.

•Lower the volume of the subwoofer speaker.

Easy Setup Procedure Easy Setup Procedure

ENGLISH

Error messages

•These error screens may be displayed when performing Auto Setup measurement and the automatic measurements can not be completed

because of the speaker arrangement, measurement environment, or other factors. Please check the following matters, reset the pertinent

items, and measure again.

•When there is too much noise in the room, the speakers may not be detected properly. Should this happen, perform the measurements when

the noise level is low, or switch off the power of the equipment that is producing the noise for the duration of the measurements.

Press DDHHto select the items, then press FF.

rThis screen will be displayed when the measurement

microphone is not connected.

•Connect the measurement microphone to the microphone

connector.

uChecking and storing the measurement

results

Press DDHHto select an item, then press ENTER.

The measurement results of each item can be checked here.

After checking, press ENTER, then press DDHHto set.

When “Store” is selected:

Press ENTER.

•When measurements have been made using the measurement

microphone, speakers with a built-in filter such as subwoofers might

be set with a value that differs from the physical distance because

of the internal electrical delay.

Retry:

Perform the measurement again.

Measurement is repeated.

Store:

All the settings are stored in the memory.

Cancel:

Cancel the auto setup settings.

Easy Setup Procedure

ENGLISH

Cable indications

Signal direction

The hookup diagrams on the subsequent pages assume the use of the following optional connection cables (not supplied).

Video cableAudio cable

NOTE:

•Do not plug in the power supply cord until all connections have been completed.

•When making connections, also refer to the operating instructions of the other components.

•Be sure to connect the left and right channels properly (left with left, right with right).

•Do not bundle power cords together with speaker cables. Doing so could result in humming or noise.

Analog connections (Stereo)

(Orange)

Pin-plug cable

Analog connections (Monaural, for subwoofer)

Pin-plug cable

Digital connections (Coaxial)

Coaxial cable (75 Ω/ohms pin-plug cable)

(Yellow)

Digital connections (Optical)

Optical fiber cable

Speaker connections

Speaker cable

Video connections

Video cable (75 Ω/ohms video pin-plug cable)

S-Video connections

S-Video cable

Audio signal

Video signal

(White)

(Red)

Component video connections

Component video cable

(Y)

(PB/CB)

(PR/CR)

(Green)

(Blue)

(Red)

IN OUT OUT IN

Connecting Other Sources

Check the parameter

1Press DDHHto select “Parameter Check”, then press

ENTER.

Press DDHHto select the item, then press ENTER.

Press ENTER.

•To reset:

Press DDHHto select “Restore” at the “Parameter Check” screen,

then press FF.

Example: Speaker Configuration Check

hh(Press ENTER.)

•The results of the measured items can be checked.

•This item is displayed, after the measurement result of the “Auto

Setup” is decided.

Connecting Other Sources Connecting Other Sources

ENGLISH

Signals input to the AVR-787

VIDEO signal

input terminal

(yellow)

S-Video signal

input terminal

Video signal output to

VIDEO MONITOR OUT

terminal (yellow)

On screen display signal output

(C: Signal E: No signal) (C: On screen signals output E: On screen signals not output)

Video signal output to

S-Video MONITOR OUT

terminal

On screen display signals

Video signal output to Component

(Color Difference) Video MONITOR

OUT terminal

With the AVR-787, the Video signal and the S-Video signal which were

inputted are mutually converted. And also the Video signal and the S-

Video signal which were inputted are converted into a higher quality.

The flow of the video signals.

AVR-787’s input

terminals

AVR-787’s output

terminals

(Component Video

terminals)

(Component Video

terminals)

(S-Video terminal)

(Video terminal)

The video conversion function

(S-Video terminal)

(Video terminal)

Cautions on the video conversion function:

•When the component video terminals are used to connect the

AVR-787 with a TV (or monitor, projector, etc.) and the video

(yellow) or S-Video terminals are used to connect the AVR-787

with a VCR, depending on the combination of the TV and VCR the

picture may flicker in the horizontal direction, be distorted, be out

of sync not display at all when playing video tapes.

If this happens, connect a commercially available video stabilizer,

etc., with a TBC (time base corrector) function between the AVR-

787 and the VCR, or if your VCR has a TBC function, turn it on.

Connecting Other Sources Connecting Other Sources

ENGLISH

Connecting a TV/DBS tuner

•For best picture quality choose the component video connection to your TV or DBS tuner. S-Video and

composite video outputs are also provided.

•To connect the digital audio output from the TV or DBS tuner, you can choose from either the coaxial or

optical connections. If you choose to use the coaxial connection, it needs to be assigned. For more

information about Digital Input Assignment ( page 47).

TV/DBS tuner

S VIDEO

OUT

AUDIO OUT

VIDEO

OUT

COMPONENT VIDEO OUT

OPTICAL

OUT

Connecting the external inputs (EXT. IN) terminals

•These terminals are for inputting multi-channel audio signals from an outboard decoder, or a component

with a different type of multi-channel decoder, such as a DVD-Audio player, or a multi-channel Super

Audio CD player, or other future multi-channel sound format decoder.

•The video signal connection is the same as that for a DVD player ( page 9).

•For instructions on playback using the external input (EXT. IN) terminals ( page 21).

•With discs on which special copyright protection measures have been taken, however, the digital signals

may not be output from the DVD player. In this case, connect the DVD player’s analog multi-channel

output to the AVR-787’s EXT. IN terminals for playback. Also refer to your DVD player’s operating

instructions.

DVD Audio-Video /

Super Audio CD player /

External decoder

FRONT

7.1ch AUDIO OUT

CENTER

SURROUND

BACK

SUB-

WOOFER

Connecting a video camera or video game

Video camera /

Video game

AUDIO OUT

OPTICAL

OUT

VIDEO

OUT

Connecting Other Sources Connecting Other Sources

ENGLISH

Connecting a VCR

•For best picture quality choose the component video connection to your VCR. S-Video and composite

video outputs are also provided.

•If you wish to perform analog dubbing from a digital source, such as a DVD recorder to an analog

recorder such as a cassette deck, you will need to connect the analog inputs and outputs as shown

below, in addition to the digital audio connections.

•The digital inputs and outputs connection is the same as that for a CD (MD) recorder.

•If you choose to use the coaxial or optical connection, it needs to be assigned. For more information

about Digital Input Assignment ( page 47).

•When recording to a VCR, it is necessary that the type of cable used with the playback source equipment

be the same type that is connected to the AVR-787 VCR OUT terminal.

Example: TV IN →S-Video cable : VCR OUT →S-Video cable

TV IN →Video cable : VCR OUT →Video cable

Video deck

S VIDEO

OUT

S VIDEO

AUDIO IN

AUDIO OUT

VIDEO

OUT

VIDEO

COMPONENT VIDEO OUT

Connecting a tape deck

AUDIO OUT

AUDIO IN

Tape deck

Connecting a CD player

To connect the digital audio output from the CD player, you can choose from either the coaxial or optical

connections. If you choose to use the optical connection, it needs to be assigned. For more information

about Digital Input Assignment ( page 47).

AUDIO OUT

CD player

COAXIAL

OUT

Connecting Other Sources Connecting Other Sources

ENGLISH

Connecting a CD recorder or MD recorder

•If you wish to perform analog dubbing from a digital source, such as a CD or MD recorder to an analog

recorder such as a tape deck, you will need to connect the analog inputs and outputs as shown below,

in addition to the digital audio connections.

•If you choose to use the coaxial or optical connection, it needs to be assigned. For more information

about Digital Input Assignment ( page 47).

AUDIO IN

AUDIO OUT

CD recorder /

MD recorder

OPTICAL

OUT

OPTICAL

NOTE:

•Do not connect the output of the component connected to the OPTICAL 2 OUT terminal on the AVR-

787’s rear panel to any terminal other than the OPTICAL 2 IN terminal.

¢AM loop antenna assembly

Connect to the AM

antenna terminals.

Remove the vinyl tie

and take out the

connection line.

Bend in the reverse

direction.

a. With the antenna on

top any stable

surface.

b. With the antenna

attached to a wall.

Mount

Installation hole Mount on wall, etc.

An F-type FM antenna cable plug can be connected directly.

Connecting the antenna terminals

Direction of broadcasting station

75 Ω/ohms Coaxial cable

FM antenna

FM indoor antenna (Supplied)

AM loop antenna

(Supplied)

AM outdoor antenna

Ground

Connection of AM antennas

1. Push the lever.

2. Insert the conductor.

3. Return the lever.

•The source selected for MAIN ZONE is output from the digital output terminal (OPT-2).

The source selected in the REC SELECT mode is not associated with the output from the digital output

terminal (OPT-2).

Connecting Other Sources Connecting Other Sources

ENGLISH

Connecting the XM terminal

•AVR-787 is the XM Ready®receiver. You can receive XM®Satellite Radio by connecting to the XM

Passport System (sold separately) and subscribing to the XM service.

•Plug the XM Passport System into XM terminal on the rear panel.

•Position the XM Passport System near a south-facing window to receive the best signal.

For details, see “XM Satellite Radio” ( page 34, 35).

When making connections, also refer to the operating instructions of the XM Passport System.

NOTE:

•Keep the power supply cord unplugged until the XM Passport System connection has been completed.

AUX OUT

XM Passport System

NOTE:

•Do not connect two FM antennas

simultaneously.

•Even if an external AM antenna is used, do

not disconnect the AM loop antenna.

•Make sure the AM loop antenna lead

terminals do not touch metal parts of the

panel.

Note to CATV system installer:

This reminder is provided to call the CATV

system installer’s attention to Article 820-40 of

the NEC which provides guidelines for proper

grounding and, in particular, specifies that the

cable ground shall be connected to the

grounding system of the building, as close to

the point of cable entry as practical.

Connecting the iPod®

iPod

ASD-1R

AUDIO OUT

S-VIDEO OUT

When using an iPod, you must connect the Control Dock for iPod (ASD-1R, sold separately) and the DOCK

CONTROL jack on the AVR-787 with a mini-jack and assign the iPod to any AUDIO and/or S-VIDEO

terminal(s).

The diagram below shows an example of connections for when the iPod is assigned to the DVD/VDP

terminal.

For instructions on assigning the iPod to a specific terminal, see “Setting the iPod Assignment” (

page 48).

For instructions on playing the iPod, see “Playing the iPod” ( page 37).

•The optional standard Control Dock for iPod is DENON ASD-1R sold separately.

><<>><<>

><><

(L) (R)

(L) (R) (L) (R)

Connecting Other Sources Connecting Other Sources

ENGLISH

For instructions on operations using the MULTI ZONE functions ( page 39 ~ 41).

Connecting the MULTI ZONE terminals

ZONE2 out connections

NOTE:

•For instructions on installation and operation of separately sold devices, refer to the devices’

operating instructions.

OUTPUT

INPUT

AUX OUT

RC-616 INFRARED

RETRANSMITTER

RC-617 INFRARED SENSOR

Extension terminal for future use.

•When the power amplifier is assigned to the ZONE2 output channel at “Power Amp Assignment” in the

“System Setup” menu, the surround back speaker terminals can be used as the ZONE2 speaker out

terminals ( page 53).

•The connections diagram below is an example for when the surround back speaker is assigned to the

ZONE2 stereo 2 channel.

In this case, surround back speaker out can not be used for MAIN ZONE.

ZONE2 speaker out connections

ZONE2

Connection terminal for

subwoofer with built-in

amplifier.

Front speakers

(A)

Surround

speakers

Front speakers

(B)

Subwoofer

ZONE2

Front speakers

Center

speaker

The settings must be changed

to use this speaker for ZONE2

(page 53).

•When the power amplifier is assigned to the ZONE2 output channel at “Power Amp Assignment” in the

“System Setup” menu, the surround back pre-out terminals can be used as the ZONE2 pre-out out

terminals ( page 53).

•If another power amplifier or pre-main (integrated) amplifier is connected, the ZONE2 out (variable level)

terminals can be used to play a different program source in ZONE2 the same time ( page 39, 40).

•When a sold separately room-to-room remote control unit (DENON RC-616, 617 or 618) is wired and

connected between the MAIN ZONE and ZONE2, the remote-controllable devices in the MAIN ZONE

can be controlled from ZONE2 using the remote control unit.

Power amplifier

(ZONE2)

(Variable)

Connecting Other Sources Connecting Other Sources

ENGLISH

Connecting the power supply cord

AC 120 V, 60 Hz

AC outlet

(wall)

NOTE:

•Insert the plugs securely. Incomplete connections will result in the generation of noise.

•Only use the AC OUTLETS for audio equipment. Never use it for hair driers, monitors or other electrical

appliances.

AC OUTLETS

•SWITCHED (total capacity – 120 W (1 A))

The power to the outlet is turned on and off in

conjunction with the POWER switch on the

main unit, and when the power is switched

between on and standby from the remote

control unit.

No power is supplied from this outlet when

this unit’s power is at standby. Never connect

equipment whose total power consumption

exceeds 120 W (1 A).

•Use these terminals if you wish to connect external power amplifier(s) to increase the power of the

front, center, surround and surround back sound channels, or for connection to powered loudspeakers.

•When using only one surround back speaker, connect it to the left channel.

Connecting the PRE OUT terminals

Power amplifier

SURROUND

BACK

SURROUND

FRONT

CENTER

SUB-

WOOFER

ENGLISH

Basic Operation

Playing the input source

Use FUNCTION to select the input source you want to

play.

To select the input source when ZONE2/REC SELECT is

selected, press <MAIN>then operate <FUNCTION>.

Start playback on the selected component.

For operating instructions, refer to the component’s manual.

Press INPUT MODE.

•The input mode indicator lights.

AUTO (All auto mode):

The type of input signal is detected and the AVR-787’s surround

mode is switched automatically. Can be selected for sources for

which the “Digital In Assignment” (page 47) is made.

The mode switches automatically to DTS / Dolby Digital / PCM.

The input switches to the analog input terminals is no digital signals

are being input.

ANALOG (exclusive analog audio signal playback mode) and

EXT. IN (External decoder input terminal selection mode):

The signals input to the various input terminals are played.

PCM (exclusive PCM signal playback mode) and

DTS (exclusive DTS signal playback mode):

Played when the various signals are input. Noise may be generated

when a mode different from the input signal is set.

AUTO

EXT. IN ANALOG

PCM DTS

Use VOLUME to adjust the volume.

•The volume level is displayed on the master volume level display.

The volume can be adjusted between the range of –80 ~ 0 ~ 18

dB. Depending on the channel level settings and the different

surround mode settings and when in the down-mix mode, it may

not be possible to adjust the volume to 18 dB.

NOTE:

•When the input mode is set to the external input (EXT. IN), the

surround mode cannot be set.

•In play modes other than the external input mode, the signals

connected to these terminals cannot be played.

Cautions when playing DTS sources:

•For DTS sources, be sure to connect the device to the digital

input terminal and set “AUTO” or “DTS” for the input source.

Noise will be generated if you play in the “ANALOG” or “PCM”

mode.

•When playing DTS signals in the “AUTO” mode, noise may be

generated when you first start playing and during searching. If so,

play in the “DTS” mode.

•Canceling the EXT. IN mode:

Press INPUT MODE or <ANALOG>to switch to the desired input mode.

•To use the EXT. IN mode together with a picture, select the input source

to which the video signal is connected first, then set the input mode.

•The “DIGITAL” indicator lights when digital signals are being input

properly. If the “DIGITAL” indicator does not light, check whether

the “Digital In Assignment” ( page 47) and connections are correct.

Press <ANALOG>to select “ANALOG”, <EXT. IN>to select “EXT.

IN”.

To lower the subwoofer channel level in the EXT. IN mode, press

SURROUND PARAMETER and select “SW. ATT”.

For some players the playback level of the SW channel may seen

strong. If so, set to “ON”.

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

[MUTING]

STATUS

DIMMER

FUNCTION

[ON SCREEN]

VOLUME

INPUT MODE

FUNCTION

SURROUND

PARAMETER

FUNCTION <ANALOG> DIMMER

INPUT MODE <EXT. IN> STATUS

VOLUME

SURROUND PARAMETER<PHONES>

Basic Operation Basic Operation

ENGLISH

Turning the sound off temporarily (MUTING)

Press [MUTING].

You can adjust the muting level ( page 53).

•Canceling MUTING mode:

To cancel the muting mode, either press [MUTING] or adjust the volume.

Connect the headphones to <PHONES>.

•No sound is produced from the speakers automatically.

NOTE:

•To prevent hearing loss, be careful not to raise the volume level

excessively when using headphones.

Listening over headphones

Switching the front speakers

Press <SPEAKER>to turn the corresponding speaker pair

on.

Switching the brightness of the display

Press DIMMER.

The brightness of the display can be adjusted in three steps. The

display can also be turned off.

Checking the currently playing program source,

etc.

Press STATUS.

•The current program source and various settings are indicated on

the display.

Using the surround modes

Types of surround modes and their features

The AVR-787 is equipped with many surround modes. We

recommend using the surround modes as described below in order to

achieve the maximum effect for the specific signal source.

is a 6.1-channel/7.1-channel surround mode.

Sources recorded in Dolby Digital EX

DOLBY DIGITAL EX / +PLIIx*(page 24)

•This mode is optimized for playing sources recorded in Dolby

Digital EX.

Sources recorded in DTS-ES

DTS-ES DSCRT 6.1 / MTRX 6.1, +PLIIx*(page 24)

•This is the optimum mode for playing sources recorded in

DTS-ES.

Dolby Digital or DTS Surround (5.1 ch sources)

2 ch sources recorded in Dolby Surround

DOLBY DIGITAL / DOLBY DIGITAL+PLIIx*/

DTS SURROUND / DTS 96/24 / DTS+PLIIx*/

DTS+NEO:6 (page 24)

•This mode is optimized for playing 5.1-channel or 7.1-channel

music.

•For Dolby Surround recording sources, Dolby Pro Logic II

playback is conducted.

2-channel sources recorded in XM HD Surround

NEURAL SURROUND (page 26)

•This is the optimum mode for playing sources recorded in XM

HD Surround.

¢On screen display

Press [ON SCREEN].

•The current program source and various settings are displayed on

the monitor screen.

¢Front panel display

ENGLISH

Sources recorded in stereo

Sources recorded in monaural

DIRECT / STEREO

•Effective for achieving pure playback.

•If there is no need for tone control or distribution of the low

frequencies in function of the speaker configuration, select

the DIRECT mode to achieve the best sound quality.

DENON Original Surround Modes (page 30, 31)

•Select these for 7.1-channel playback with sources recorded

in stereo or monaural.

•The effects are different for each of the surround modes.

Select the one most suited for the source being used.

DTS NEO:6 (page 26)

•This is a surround mode for playing 6.1- or 7.1-channel stereo

sources developed by Digital Theater Systems.

•One of two playing modes, MUSIC (for music sources) or

CINEMA (for movie sources), can be selected according to

your preferences.

DOLBY PRO LOGIC IIx*(page 25)

•Developed by Dolby Laboratories, this surround mode

provides 7.1-channel surround sound with conventional stereo

(2-channel) sources.

•Select CINEMA mode for movie surround soundtracks,

MUSIC for music sources, and GAME for 2-channel game

box audio sources.

Basic Operation Basic Operation

•Surround modes marked with an asterisk (*) cannot be used when

the surround back speaker is set to “NONE”.

•The “+PLIIx Cinema” mode cannot be selected when only one

surround back speaker is being used.

¢DIRECT mode

This mode is for playing with high quality sound. The audio signals are

transmitted directly, without passing through the tone circuits, etc.

Selecting the play mode (DIRECT/STEREO)

The AVR-787 is equipped with two 2-channel playback modes exclusively

for music. Select the mode to suit your tastes.

Press [DIRECT/STEREO]to select “DIRECT”.

STEREODIRECT

¢STEREO mode

Use this mode to adjust the tone and achieve the desired sound.

Press [DIRECT/STEREO]to select “STEREO”.

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

STATUS

ENTER

D H F G

INPUT MODE

[STANDARD]

SURROUND

PARAMETER

[DIRECT/STEREO]

D H F G

ENTER

INPUT MODE STATUS

SURROUND PARAMETER

F G, ENTER

D H

Basic Operation Basic Operation

ENGLISH

Selecting the Dolby Digital and DTS Surround

mode (only with digital input)

Play a program source with the , mark.

•“ ” or “ ” lights, depending on the source.

Press SURROUND PARAMETER.

Press DDHHto select the item, then press FFGGto set.

Press [STANDARD] to select “STANDARD (Dolby/DTS

Surround)”.

Select an input source for which digital (COAXIAL or

OPTICAL) is set ( page 47).

Press INPUT MODE to select “AUTO”.

D.COMP.:

The dynamic range is compressed. Select one of four modes: “OFF”,

“LOW”, “MID” (middle) or “HIGH”.

Effective source mode

Dolby Digital /

DTS (For DTS sources, only displayed for compatible software.)

LFE:

To play the various types of software properly, we recommend

setting to the values shown below.

•To play Dolby Digital software: “0 dB”

•To play DTS movie software: “0 dB”

•To play DTS music software: “–10 dB”

SB CH OUT:

Select the play mode or surround back channel playback method.

•The “ ” or “ ” indicator lights.

(1) For multi-channel sources

•SB OFF (OFF):

Not played.

•NON MTRX:

Surround channel signal played.

•MTRX ON:

Surround channel signal played with digital matrix processing.

•ES MTRX:

DTS signal played with digital matrix processing.

•ES DSCRT:

Signal included in DTS-ES discrete 6.1-channel sources played.

•PLIIx CINEMA:

Decoded in Dolby Pro Logic IIxCinema mode, surround back signal

played.

Set the surround back speaker to “2sp” at “Speaker

Configuration” ( page 54, 55).

•PLIIx MUSIC:

Decoded in Dolby Pro Logic IIxMusic mode, surround back signal

played.

Set the surround back speaker to “1sp” or “2sp” at “Speaker

Configuration” ( page 54, 55).

(2) For 2-channel sources

•OFF: Not played.

•ON: Surround channel signal played.

CINEMA EQ.:

Use this if movie dialogues sound harsh to lower the treble sound.

Effective source mode

Dolby Pro Logic IIx / Dolby Pro Logic / Dolby Digital /

DTS Surround / DTS NEO:6

•Select “Default Yes” and press FFto reset all the settings.

¢Dialog normalization function

This operates automatically when playing Dolby Digital sources.

This is a function for automatically correcting the standard signal level

for different program sources. The correction value can be checked by

pressing STATUS.

The numbers are the correction value when corrected to the standard level.

TONE:

Adjust the tone control.

Can be set in surround modes other than direct mode.

Can be set separately for the different surround modes. (Adjusted

together for the Dolby/DTS SURROUND modes.)

Press ENTER or SURROUND PARAMETER.

Example: Dolby Digital Example: DTS

Basic Operation Basic Operation

ENGLISH

Selecting the Dolby Pro Logic IIx (Pro Logic II)

mode

Press [STANDARD] to select “DOLBY PLIIx”.

Play a program source.

DOLBY PLIIx

NEURAL SURROUND

DTS NEO:6

Press SURROUND PARAMETER.

It is possible to play analog input signals and digital input signals (2-

channels) in the surround mode.

This mode is optimal for playing program sources recorded in Dolby

Surround.

Press DDHHto select the item, then press FFGGto set.

When “MUSIC” mode is selected:

PANORAMA:

This is effective when the surround effect seems weak.

DIMENSION:

This shifts the center of the sound field image to the front or surround

side. This compensates for when the sound field image seems

unbalanced. (0 to 6, default : 3)

CENTER WIDTH:

A natural expansion to the front can be achieved by adjusting the

center signal’s output balance between the center and front channels.

(0 to 7, default : 3)

Press ENTER or SURROUND PARAMETER.

Press FFGGto select the play mode.

CINEMA:

This mode is suited for playing movie sources recorded in Dolby

Surround and general sources recorded in stereo.

MUSIC:

This mode is suited for playing stereo music signals in the surround

mode. With music signals, the sound field expansion differs according

to the type of music, the recording conditions (live/studio), etc..

Because of this, the MUSIC mode offers a number of optional

parameters for further adjusting the sound field.

GAME:

This mode is optimum for games. The GAME mode can only be

used for 2-channel audio sources.

PL:

This mode is compatible with conventional Dolby Pro Logic sources.

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

ENTER

D H F G

[ON SCREEN]

[STANDARD]

SURROUND

PARAMETER

D H F G

ENTER

F G, ENTER

SURROUND PARAMETER D H

(When “MUSIC” is selected)

Basic Operation Basic Operation

ENGLISH

Selecting the DTS NEO:6 mode

It is possible to play analog input signals and digital input signals (2-

channels) in the surround mode.

Press SURROUND PARAMETER.

Play a program source.

Press FFGGto select the play mode.

Press [STANDARD] to select “DTS NEO:6”.

DOLBY PLIIx

NEURAL SURROUND

DTS NEO:6

CINEMA:

This mode is optimum for playing movies. Decoding is performed

with emphasis on separation performance to achieve the same

atmosphere with 2-channel sources as with 6.1-channel sources.

MUSIC:

This mode is suited mainly for playing music.

Selecting the NEURAL SURROUND mode

It is possible to play analog input signals and digital input signals (2-

channels) in the surround mode.

This is the optimum mode for playing sources recorded in XM HD

Surround ( page 34, 35).

Play a program source.

Press SURROUND PARAMETER.

Press [STANDARD] to select “NEURALSURROUND”.

Press DDHHto select the item, then press FFGGto set.

Press ENTER or SURROUND PARAMETER.

DOLBY PLIIx

NEURAL SURROUND

DTS NEO:6

Press DDHHto select the item, then press FFGGto set.

When “MUSIC” mode is selected:

Press ENTER or SURROUND PARAMETER.

CNTR. IMAGE:

The expansion of the center channel can be adjusted. (0.0 to 1.0,

default : 0.3)

(When “MUSIC” is selected)

OFFSET:

Displays the dialog normalization offset value.

FLAG:

“MATRIX” is displayed if the input signal has undergone matrix

processing, “DISCRETE” is displayed if the input signal has undergone

discrete processing.

SIGNAL:

Displays the type of input signal.

fs:

Displays the input signal’s sampling frequency.

Checking the input signals

Press [ON SCREEN].

Press [ON SCREEN] again.

OSD-1 : Input signal

OSD-2 : Input/output settings

OSD-3 : Auto surround mode

OSD-4 ~ 6 : USER MODE 1 ~ 3

OSD-7 ~ 13 : Tuner preset stations

•“OSD-1”-“FLAG” is not displayed if there is no FLAG identification

signal in the input signal.

•OSD-3:

This is displayed when the auto surround mode is set to “ON” (

page 52) and the input mode is set to “AUTO”.

It is not displayed when the input mode is set to “ANALOG” or

“EXT. IN”.

Example: Dolby Digital Example: DTS

FORMAT:

Displays the input signal’s number of channels (front / surround /

LFE on/off).

“SURROUND” is displayed for 2-channel signal sources recorded

in Dolby Surround.

Basic Operation Basic Operation

ENGLISH

Surround Mode

Surround modes and parameters

CC(CINEMA)

CC(NOTE 2)

CC(NOTE 3)

CC(NOTE 2)

CC(OFF)

CC(0 dB)

CC(NOTE 1)

CC(0 dB)

CC(OFF)

SURROUND

L/R

Channel output Parameter (default values are shown in parentheses)

SUB-

WOOFER

D. COMP

*1 NIGHT

mode

LFE

SB CH

OUT TONE CONTROL CINEMA EQ. MODE ROOM

SIZE

CC(Medium)

Dolby

Digital

CC(10)

FRONT

L/R CENTER

SURROUND

BACK

L/R

CC(OFF)

CC(0.3)

CC(3)

CC(30 msec)

DELAY TIME

PANORAMA DIMENSION CENTER

WIDTH CENTER IMAGE SW ATT

CC(OFF)

PRO LOGIC II/IIx MUSIC MODE only NEO:6 MUSIC

MODE only

EXT. IN

only

EFFECT

LEVEL

CC:Adjustable

EE:Not adjustable

NOTE 1 : BASS +6 dB, TREBLE +4 dB

NOTE 2 : This parameter is available when the “MODE” is set to “CINEMA”.

NOTE 3 : This parameter is available when the “MODE” is set to “CINEMA” or “PL”.

*1: When playing Dolby Digital and DTS signals.

*2: When playing Dolby Digital, DTS, DVD-Audio and Super Audio CD.

CC: Signal

EE:No signal

CC:Adjustable

EE:Not adjustable

CC: Signal

EE:No signal

BB:Turned on or off by speaker

configuration setting

STEREO

EXT. IN

DOLBY PRO LOGIC IIx

DOLBY PRO LOGIC II

DTS NEO:6

DOLBY DIGITAL

DTS SURROUND

NEURAL SURROUND

5CH/7CH STEREO

MONO MOVIE

ROCK ARENA

JAZZ CLUB

VIDEO GAME

MATRIX

VIRTUAL

Signals and adjustability in the different modes

NEURAL SURROUND

Basic Operation Basic Operation

ENGLISH

Surround Mode

Button

Note DTS ES DSCRT

(With Flag)

Input signals

DTS DOLBY DIGITAL

STANDARD

DTS SURROUND

DTS ES DSCRT6.1

DTS ES MTRX6.1

DTS SURROUND

DTS 96/24

DTS + PLIIx CINEMA

DTS + PLIIx MUSIC

DTS + NEO:6

DTS NEO:6 CINEMA

DTS NEO:6 MUSIC

DOLBY SURROUND

DOLBY DIGITAL EX

DOLBY DIGITAL

DOLBY DIGITAL+PLIIx CINEMA

DOLBY DIGITAL+PLIIx MUSIC

DOLBY PRO LOGIC IIx CINEMA

DOLBY PRO LOGIC IIx MUSIC

DOLBY PRO LOGIC IIx GAME

DOLBY PRO LOGIC II CINEMA

DOLBY PRO LOGIC II MUSIC

DOLBY PRO LOGIC II GAME

DOLBY PRO LOGIC

ANALOG LINEAR PCM DTS ES MTRX

(With Flag)

DTS

(5.1ch)

DTS

96/24

DOLBY DIGITAL EX

(With Flag)

DOLBY DIGITAL EX

(With no Flag)

DOLBY

DIGITAL

(5.1ch)

DOLBY

DIGITAL

(3, 4, 5ch)

DOLBY

DIGITAL

(2ch)

DVD-AUDIO

DVD-Audio

(multi ch)

DVD-Audio

(2ch)

176.4/

192kHz

4:Mode selectable in default status

CC:Selectable mode

EE:Non-selectable mode

NOTE :

*1: This mode is not available when the Surround Back speaker setup is set to “None”.

*2: This mode is not available when the Surround Back speaker setup is set to “1sp” or “None”.

¢Differences in surround mode names depending on the input signals

Basic Operation Basic Operation

ENGLISH

Surround Mode

Button

Note DTS ES DSCRT

(With Flag)

Input signals

DTS DOLBY DIGITAL

ANALOG LINEAR PCM DTS ES MTRX

(With Flag)

DTS

(5.1ch)

DTS

96/24

DOLBY DIGITAL EX

(With Flag)

DOLBY DIGITAL EX

(With no Flag)

DOLBY

DIGITAL

(5.1ch)

DOLBY

DIGITAL

(3, 4, 5ch)

DOLBY

DIGITAL

(2ch)

DVD-AUDIO

DVD-Audio

(multi ch)

DVD-Audio

(2ch)

176.4/

192kHz

DIRECT

DSP SIMULATION

5CH/7CH STEREO

MONO MOVIE

ROCK ARENA

JAZZ CLUB

VIDEO GAME

MATRIX

VIRTUAL

STEREO

4:Mode selectable in default status

CC:Selectable mode

EE:Non-selectable mode

NOTE :

*1: If the Surround Back speaker setup is set to “None”, then “5CH STEREO” is displayed.

STEREO

5CH/7CH STEREO

(NOTE 1)

Basic Operation Basic Operation

ENGLISH

VIRTUAL

MATRIX

VIDEO GAME

MONO MOVIE

(NOTE 2)

JAZZ CLUB

ROCK ARENA

Using the DENON original surround modes

The AVR-787 is equipped with a high performance digital signal processor (DSP) that uses digital signal processing to recreate sound fields

artificially. One of seven surround modes can be selected according to the program source and parameters can be further adjusted to achieve

even more realistic sound fields.

Types of surround modes and their features

This mode recreates the atmosphere of a live concert in an arena.

This mode recreates the atmosphere of a live concert in a club with low ceilings, hard walls and the artist just in

front of you.

This mode provides a rich sense of presence for video games.

This mode recreates the atmosphere of an expansive sound field for movie sources recorded in monaural.

This mode recreates music sources recorded in stereo with an enhanced sense of expansion.

This mode can be used to enjoy surround sound with only front speakers or when using headphones.

NOTE 1: “5CH STEREO” is displayed when “SB CH OUT” is set to “OFF”.

NOTE 2: When playing sources recorded in monaural, the sound will be one-sided if signals are only input to one channel (left or right), so input

signals to both channels. If you have a source component with only one audio output (monophonic camcorder, etc.) obtain a “Y”

adapter cable to split the mono output to two outputs, and connect to the L and R inputs.

•Depending on the program source being played, the effect may not be very noticeable. In this case, try other surround modes, without

worrying about their names, to create a sound field suited to your tastes.

This mode lets you enjoy stereo sound with seven speakers. The front L (R) channel signals are played from the

surround and surround back L (R) channels and only the in-phase component of the L and R channels is played on

the center channel.

Basic Operation Basic Operation

ENGLISH

•Select “Default Yes” and press FFto reset all the settings.

Press DDHHto select the item, then press FFGGto set.

Selecting the DSP surround simulation

Press SURROUND PARAMETER.

Press [DSP SIMULATION].

5CH/7CH STEREO MONO MOVIE

JAZZ CLUB

ROCK ARENA

MATRIX VIDEO GAME

VIRTUAL

The 5CH/7CH STEREO mode can be selected directly by pressing

[5CH/7CH STEREO].

¢To operate the surround mode and the surround

parameters from the remote control unit ¢Operating the surround mode and the surround

parameters from the main unit’s panel

Use <SELECT/ENTER>to select the surround mode.

DIRECT STEREO

MONO MOVIE

DTS NEO:6

5CH/7CH STEREO NEURAL SURROUND

MATRIXVIRTUAL SURROUND

DOLBY PRO LOGIC

ROCK ARENA JAZZ CLUB

VIDEO GAME

To select the surround mode while adjusting the surround

parameters, tone defeat or tone control, press <SURROUND MODE>,

then operate the selector.

Perform steps 2 to 4 under “Selecting the DSPsurround

simulation”.

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

[CH SELECT],

ENTER

D H F G

[DSP SIMULATION]

SURROUND

PARAMETER

D H F G

ENTER

[5CH/7CH STEREO]

F G, SELECT/ENTER

<SURROUND MODE>,

SURROUND PARAMETER

D H

Press ENTER or SURROUND PARAMETER.

ROOM SIZE:

Adjust the imaginary size of the recreated sound field space. (Does

not express size of room in which played.)

There are five parameters: “small”, “med.s”, “medium”, “med.l”

and “large”.

SB CH OUT

•ON:

Surround back channel played.

•OFF:

Surround back channel not played.

EFFECT LEVEL:

Adjust the strength of the surround effect.

DELAY TIME: (MATRIX mode only)

Adjust the delay time between “0 ms” and “110 ms”.

Basic Operation Basic Operation

ENGLISH

Press ENTER or SURROUND PARAMETER.

Press GGto select “OFF”.

Press DDHHto select “Bass” or “Treble”, then press FF

GGto set the level.

Can be adjusted within the range of –10 dB to +10 dB.

Set “Tone Defeat” to “ON” at step 3 in “Adjusting the

tone”.

Adjusting the speaker volume

Press [CH SELECT].

Press [CH SELECT] to select the speaker.

The settable speaker switches each time this button is pressed.

Press [FF GG]to adjust the volume.

The SW channel level can be turned off by decreasing it one step

from –12.0 dB.

OFF ´–12.0 dB ´+12.0 dB

Setting the tone control

Adjust the bass and treble to suit your tastes.

Press SURROUND PARAMETER.

Press DDHHto select “TONE DEFEAT”.

In the direct mode, “TONE” cannot be selected.

¢Adjusting the tone

¢When you do not want to adjust the tone

“S. Back” when surround back

speaker set to “1sp”.

Using the fader function

With this function, the volume of all the front side speakers or all the

rear side speakers can be adjusted (attenuated) at once.

Press [CH SELECT].

Press DDHHor [CH SELECT] to select “Fader”.

Press FFto attenuate the volume of all the front side

speakers, GGto attenuate the volume of all the rear

side speakers.

The fader function does not affect the subwoofer.

It is possible to adjust so that the volume of the speaker whose

volume is the lowest is –12 dB.

Basic Operation Basic Operation

ENGLISH

Listening to the radio

Check that the remote control unit is set to “AUDIO”.

Hold <PRESET •>and press <POWER>.

•The unit automatically begins searching for FM broadcast

stations.

When the first FM broadcast station is found, that station is

stored in the preset memory at channel A1.

Subsequent stations are automatically stored in order at preset

channels A1 to A8, B1 to B8, C1 to C8, D1 to D8, E1 to E8, F1 to

F8 and G1 to G8 for a maximum of 56 stations.

Channel A1 is tuned in after the auto preset memory operation is

completed.

Auto preset memory

This unit is equipped with a function for automatically searching for

FM broadcast stations and storing them in the preset memory.

•If an FM station cannot be preset automatically due to poor reception,

use the “Manual tuning” operation to tune in the station, then preset

it using the manual “Preset memory” operation.

•To interrupt this function, press <ON/STANDBY>.

Switch off the unit using <POWER>.

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

CHANNEL

[FM/AM]

SHIFT

[ON SCREEN]

[TUNER]

TUNING

[MODE]

BAND

[MEMORY]

<POWER> CHANNEL

SHIFT <PRESET •>

<FUNCTION> TUNING

BAND

Use <FUNCTION>to select “TUNER” or press

[TUNER].

Auto tuning

Manual tuning

Press [MODE] to set the auto tuning mode.

•The “AUTO” indicator lights.

Press TUNING.

•Automatic searching begins.

•If tuning does not stop at the desired station, use to the “Manual

tuning” operation.

•“AM” or “FM” can be selected directly by pressing [FM/AM].

Use <FUNCTION>to select “TUNER” or press

[TUNER].

Press [MODE] to set the manual tuning mode.

Check that the display’s “AUTO” indicator turns off.

Press BAND to select “AM”, “FM” or “XM”.

When listening to the XM Satellite Radio ( page 34, 35).

Press BAND to select “AM”, “FM” or “XM”.

When listening to the XM Satellite Radio ( page 34, 35).

Press TUNING.

The frequency changes continuously when the button is held in.

•When the manual tuning mode is set, FM stereo broadcasts are

received in monaural and the “STEREO” indicator turns off.

•“AM” or “FM” can be selected directly by pressing [FM/AM].

Basic Operation Basic Operation

ENGLISH

Use the “Auto tuning” or “Manual tuning” operation

to tune in the station to be preset in the memory.

Press [MEMORY].

Press CHANNEL to select the desired preset channel

(1 to 8).

Preset memory

Press SHIFT to select the desired memory block (A to

G).

Press [MEMORY] again.

•Store the station in the preset memory.

•To preset other channels, repeat steps 2 to 5.

A total of 56 broadcast stations can be preset — 8 stations (channels

1 to 8) in each of blocks A to G.

•The memory block can also be selected by pressing SHIFT.

Recalling preset stations

Press SHIFT to select the memory block.

Press CHANNEL to select the desired preset channel.

Press [ON SCREEN] repeatedly until the “Tuner Preset

Stations” screen appears on the on screen display.

Checking the preset stations

XM Satellite Radio

¢Introducing XM Satellite Radio

There’s a world of audio listening pleasure beyond AM and FM. XM

Satellite Radio. Select from over 170 channels of music, news, sports,

comedy, talk, and entertainment. Coast-to-coast coverage. Digital

quality sound. With all music channels 100% commercial free.

Questions?: Visit www.xmradio.com.

AVR-787 is the XM Ready receiver. You can receive XM®Satellite

Radio by connecting to the XM Passport System (sold separately) and

subscribing to the XM service.

¢How to Subscribe

Listeners can subscribe by visiting XM on the Web at www.xmradio.com

or by calling XM’s Listener Care at (800) 967-2346.

Customers should have their Radio ID and credit card ready. The

Radio ID can be found by selecting channel 0 on the radio.

¢A Warning Against Reverse Engineering

It is prohibited to copy, decompile, disassemble, reverse engineer, or

manipulate any technology incorporated in receivers compatible with

the XM Satellite Radio system.

Furthermore, the AMBE®voice compression software included in

this product is protected by intellectual property rights including

patent rights, copyrights, and trade secrets of Digital Voice Systems,

Inc. The user of this or any other software contained in an XM Radio

is explicitly prohibited from attempting to copy, decompile, reverse

engineer, or disassemble the object code, or in any other way convert

the object code into human-readable form. The software is licensed

solely for use within this product.

Hardware and required $12.95 monthly service subscription sold

separately. Other fees and taxes, including a one-time activation

fee may apply. Subscription fee is consumer only. All fees and

programming subject to change. Channels with frequent explicit

language are indicated with an XL. Channel blocking is available for

XM radio receivers by calling 1-800-XMRADIO. Subscriptions subject

to Customer Agreement available at xmradio.com. XM service only

Basic Operation Basic Operation

ENGLISH

Checking the XM signal strength and Radio ID

Use <FUNCTION>to select “TUNER” or press

[TUNER].

Press STATUS until “SIGNAL” is displayed.

•The display changes as shown below according to the receiving

condition.

Press BAND to select “XM”.

Adjust the antenna location until “SIGNAL:GOOD”

is displayed.

Press STATUS until the XM channel (ex.XM001) is

displayed.

Press TUNING to select channel 0 (XM000).

ConditionDisplay

GOOD Signal strength is good

MARGINAL Signal strength is marginal

WEAK Signal strength is poor

Loss of the signal Category search

Channel selection

Press TUNING to reach the desired channel.

The channel changes continuously when you press and hold TUNING.

When the artist name and song title are received, they are displayed.

Use <FUNCTION>to select “TUNER” or press

[TUNER].

Press BAND to select “XM”.

Press FFGGto select the category, and press DDHHto

select the channel within the selected category.

Press FFGGin the XM mode.

•The current category name is displayed.

•“LOADING” is displayed while receiving the channel or information.

•“UPDATING” is displayed while updating encryption code.

•When the selected channel is not available, “XM – – –” is displayed.

•Information on the artist name, song title, category and signal level

can be checked using STATUS.

•The XM Satellite Radio channels can be preset in the same way as

AM/FM band ( page 34).

•“XM” can be selected directly by pressing [XM RADIO].

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

D H F G

STATUS

[XM RADIO]

[NIGHT]

VIDEO SELECT

[TUNER]

D H F G

TUNING

BAND

F G

TUNING

BAND STATUS

VIDEO SELECT

D H

Radio ID

Channel name

Song title / Artist name

Channel number

Channel category

ENGLISH

Advanced Operation

The night mode can be set when playing Dolby Digital sources. The

dialogues are easier to hear at night and when listening with the

volume low.

Press [NIGHT].

Night mode

•Canceling night mode:

Press [NIGHT] again.

•When the night mode is set to “ON”, the “D.COMP” surround

parameter can not be selected.

User mode function

The AVR-787 is equipped with a function for storing the selected input

source, the auto surround mode and input mode in the memory and

selecting these settings when you want to use them.

The following are stored in the memory:

qqCurrently set input source

wwCurrently set surround mode

eeCurrently set input mode

Press <USER MODE>until “Memory” is displayed.

Press VIDEO SELECT until the desired image appears on

the monitor.

Combining the currently playing sound with the

desired image (VIDEO SELECT function)

•To cancel, press VIDEO SELECT to select “SOURCE”.

•The video source selected with the video select function is stored in

the memory for the different input sources.

The surround mode last selected and the input mode setting are stored

individually for the different input sources.

The surround parameters, tone control settings and playback level

balance for the different output channels are memorized for each

surround mode.

Personal memory plus function

Storing the settings in the memory

Press <USER MODE>at which the settings you want to

call out are stored.

Calling the settings out

Advanced Operation Advanced Operation

ENGLISH

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

[ENTER]

[D H F G]

STATUS

[OFF]

FUNCTION

[MODE]

[MEMORY]

[D H F G]

[ENTER]

FUNCTION

STATUS

NOTE:

•DENON will accept no responsibility whatsoever for loss or damage

of data on an iPod occurring when the iPod is used connected to

the AVR-787.

•Some of the functions may not operate, depending on the type

of iPod and the software version.

•The optional standard Control Dock for iPod is DENON ASD-1R sold

separately.

If the screens above are not displayed, the iPod may not be properly

connected. Check the connections and settings.

Connect the AVR-787 and iPod using the Control

Dock for iPod (ASD-1R) ( page 18).

Use FUNCTION to select the function assigned in step 2.

Assign the input terminal at “Setting the iPod

Assignment” ( page 48).

Playing the iPod®

iPod is a trademark of Apple Computer, Inc., registered

in the U.S. and other countries.

With the iPod, non-copyrighted contents and contents that may be

legally reproduced or played may be reproduced and played by

individuals for their personal use. Violating copyrights is prohibited

by law.

The music recorded on the iPod can be played when using a Control

Dock for iPod (ASD-1R, sold separately). The iPod can be controlled

using the buttons on the main unit and the remote control unit.

(iPod screen)

Advanced Operation Advanced Operation

ENGLISH

•When STATUS is pressed during playback, the front panel display

switches between the title name, artist name and album name.

•Depending on the iPod’s software version, it may not be possible to

operate the iPod from the AVR-787. Use the latest version of the

software. Information on the latest version of the software can be

obtained on the Apple Computer website.

•If you do not want the on screen display to be displayed while

playing the iPod, set “Function/Mode Status” at “Setting the On

Screen Display” to “OFF” ( page 52).

•With the AVR-787 it is possible to display folder names and file

names on the screen like titles. The AVR-787 can display up to 64

characters, consisting of numbers, capital letters and small letters.

A “?” mark is displayed in place of non-compatible characters.

Viewing still pictures and videos

(only for iPods equipped with the slideshow /

video function)

Press [MODE] for at least 2 seconds to switch from the

Browse mode to the Remote mode.

•“Remote iPod” is displayed on the AVR-787’s display.

Watching the iPod’s screen, press [DDHH]to select

“Photos” or “Video”, then press [ENTER] or [GG].

•The iPod’s photo and video data are displayed on the monitor.

Use this procedure to view photo and video data stored on the iPod

on a monitor.

•To output photo or video data recorded on the iPod to the monitor,

the iPod’s “TV Out” setting (under “Video Settings”) must be set to

“ON”.

For details, refer to the iPod’s operating instructions.

Disconnecting the iPod

Press <ON/STANDBY>or [OFF] and set the AVR-787’s

power to the standby mode.

The iPod can be disconnected after switching to a function other

than the one to which the iPod input is assigned.

Listening to music

Press [DDHH]to select the music file, then press [ENTER]

or [GG].

Press [FF]to return to the music menu screen.

Press [ENTER] or [GG].

•Playback starts.

Manual search:

Press and hold in [DDHH]during playback.

•DD:Fast reverse

•HH:Fast forward

Track search:

Press [DDHH]during playback.

•DD:Move to beginning of previous track

•HH:Move to beginning of next track

Repeat play:

Press [MODE].

The mode switches as follows each time [MODE] is pressed.

•RPT One: Single track repeat

•RPT All: All track repeat

Pause:

Press [ENTER] during playback.

Press again to resume.

Stop:

Press [ENTER] for at least 2 seconds during playback.

Shuffle play:

Press [MEMORY].

The mode switches as follows each time [MEMORY] is pressed.

•SFL Songs: Single track shuffle

•SFL Albums: Album shuffle

The mode switches between the Browse mode and the Remote

mode if [MODE] is pressed for at least 2 seconds.

In the Remote mode, only [DDHHFFGG]and [ENTER] can be used.

Advanced Operation Advanced Operation

ENGLISH

¢When using the SURR.BACK/ZONE2 amplifier as the ZONE2

•The SPEAKER OUT and PRE OUT terminals can be used simultaneously in ZONE2.

•To use the ZONE2, turn on ZONE2.

•The output of the ZONE2 SPEAKER OUT terminals can be adjusted with [VOLUME] (ZONE2).

[System configuration and connections example 1]

Using this unit’s internal amplifier as the ZONE2.

AVR-787

DVD player

Input

RC-616

Monitor

MAIN ZONE 5.1-channel systems

ZONE2 speaker out

System remote

control unit (RC-1046)

FL FR

RC-617

Programmable

remote control unit

ZONE2

:Speaker cable

:Room-to-room remote control system (separately sold)

control line

Refer to “Connections” ( page 19).

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

VOLUME

ZONE2

Multi zone music entertainment system

•When the outputs of the ZONE2 OUT terminals are wired and connected to integrated amplifiers installed in other rooms, different sources can

be played in rooms other than the MAIN ZONE in which this unit and the playback devices are installed. (Refer to ZONE2 on the diagram below)

•ZONE2 speaker out and pre-out can be used when “ZONE2” is selected at “Power Amp Assignment” in the “System Setup” menu. In this

case, surround back speaker out cannot be used for MAIN ZONE.

•When a sold separately room-to-room remote control unit (DENON RC-616, 617 or 618) is wired and connected between the MAIN ZONE

and ZONE2, the remote-controllable devices in the MAIN ZONE can be controlled from ZONE2 using the remote control unit.

•For the AUDIO outputs, use high quality pin-plug cables and wire in such a way that there is no humming or noise.

•For instructions on installation and operation of separately sold devices, refer to the devices’ operating instructions.

•When the main unit is set to the recording output mode, ZONE2 remote control button cannot be operated.

Advanced Operation Advanced Operation

ENGLISH

[System configuration and connections example 2]

Using external amplifier.

RC-617

AVR-787

Premain amplifier

or Power amplifier

ZONE2 Audio out

(Variable out)

DVD player

Input

FL FR

SL SR

Programmable

remote control unit

System remote control unit

(RC-1046)

RC-616

MAIN ZONE 5.1-channel systems

ZONE2

Monitor

:Multi source audio signal cable

:Room-to-room remote control system (separately sold)

control line

Refer to “Connections” ( page 19).

ENGLISH

Advanced Operation Advanced Operation

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

[CHANNEL]

[MODE SELECTOR 2]

[MODE SELECTOR 1]

[VOLUME]

[FUNCTION]

[MAIN ON/OFF]

[ZONE2 OFF ]

[ZONE2 ON ]

[FUNCTION]

When the ZONE2 SOURCE function is set to

“TUNER”, the preset channel can be selected pressing

[CHANNEL].

Press [FUNCTION].

•The “ -2” indicator and the indicator for the selected

source light.

The ZONE2 source switches directly.

The output level of the ZONE2 SPEAKER OUT

terminals can be controlled pressing [VOLUME].

Default setting (ZONE2 volume level):

– – – dB (Minimum)

Set [MODE SELECTOR 1] to the “AUDIO”.

Press [ZONE2 ON].

•The “ ” indicator lights.

To cancel the ZONE2 mode:

Press [ZONE2 OFF].

Remote control unit operations during multi-

source playback

This is only possible when the main unit in the ZONE2 mode ( page

53).

Set [MODE SELECTOR 2] to the “ZONE2”.

With “ZONE2 SOURCE” displayed, turn <FUNCTION>

to select the source you want to output appears on the

display.

•The “ -2” indicator and the indicator for the selected

source light.

Outputting a program source to amplifier, etc.,

in the ZONE2 room (ZONE2 SELECT mode)

•The signals of the source selected in the ZONE2 mode are also

output from the VCR and CD-R/TAPE recording output terminals.

•Digital signals are not output from the ZONE2 audio output terminals.

•About the MULTI ZONE connections ( page 39, 40).

•The source selected for MAIN ZONE is output from the digital

output terminal (OPT-2).

The source selected in the REC SELECT mode is not associated

with the output from the digital output terminal (OPT-2).

Press <ZONE2/REC SELECT>to display the “ZONE2

SOURCE” on the display.

Start playing the source to be output.

For operating instructions, refer to the manuals of the respective

components.

RECOUT

ZONE2

•When using ZONE2, it is possible to turn the power for the MAIN

ZONE only on or off by pressing [MAIN ON/OFF].

Advanced Operation Advanced Operation

ENGLISH

¢Last function memory

The various settings set when the AVR-787’s power is switched to

standby are stored in the memory. When the power is turned back on,

the settings made when the power was switched to standby are

recalled.

About the memory functions

¢Backup memory

The various settings are stored in the memory for about 1 week, even

when the power is turned off or the power cord is unplugged.

Initialization of the microprocessor (Reset)

Use the procedure described below to reset the microprocessor if the

display is abnormal or if the buttons on the main unit or the remote

control unit do not operate.

Switch off the unit using <POWER>.

Check that the entire display is blinking with an interval

of about 1 second, and release your fingers from the 2

buttons.

•The microprocessor will be initialized.

Hold the following <SPEAKER>(Aand B) and press

<POWER>.

•If step 3 does not work, start over from step 1.

•If the microprocessor has been reset, all the settings are reset to the

default values.

Recording (audio and/or video)

Press <ZONE2/REC SELECT>until “RECOUT” appears

on the display.

Use <FUNCTION>to select the source to be recorded

(audio and/or video).

•The “ ” indicator and the indicator for the selected

source light.

Record (the audio or video signals).

For operations, see the operating instructions of the device from

which you are recording (audio or video signals).

•To cancel, press <ZONE2/REC SELECT>and set the function to “ZONE2”.

NOTE:

•When the REC OUT mode is selected, [ZONE2] and [FUNCTION]

(ZONE2) cannot be operated.

•Digital signals are not output from the analog REC OUT terminal.

RECOUT

ZONE2

ENGLISH

Advanced Setup – Part 1

System setup items and default values

PageDefault settingsItems

1. Auto Setup

1Auto Setup –9 ~ 12

2. Speaker Setup

Speaker

Configuration

Channel Level

Front Sp.

Large

Center Sp. Surround Sp.Subwoofer

Small SmallYes

Surround

L & R

Center

Front

L & R Subwoofer

10 ft12 ft12 ft 12 ft

Front

RCenter Surround R Subwoofer

0 dB 0 dB 0 dB 0 dB 0 dB

Surround Back

Sp.

Small / 2sp

Distance

Surround L

0 dB

Crossover

Frequency

580 Hz

54, 55

2Subwoofer

Setup LFE (Normal) 55

55, 56

56, 57

Surround

Back

10 ft

Surround

Back R

0 dB

Surround

Back L

0 dB

The AVR-787 performs an analysis of the speaker system and measures

the acoustic characteristics of your room to permit an appropriate

automatic setting.

Automatically set the output component and properties for the various

channels according to the combination of speakers to be actually used for

surround playback.

This parameter is for optimizing the timing with which the audio signals

are produced from the speakers and subwoofer according to the listening

position.

Set the volume of the various speakers so that the sound output from the

speakers and the subwoofer seems to have the same volume level.

Select the method of playback of the subwoofer for playing the low bass

signals.

Set the frequency (Hz) below which the bass sound of the various speakers

is to be output from the subwoofer.

ENGLISH

Advanced Setup – Part 1 Advanced Setup – Part 1

PageDefault settingsItems

4. Video Setup

1Component In

Assignment DVD / VDP TV / DBS VCR 51

2Video Convert ON 51

COMP1 COMP2 COMP3

Audio Delay30 ms 51

On Screen

Display

4Function/Mode = ON

Master Volume = ON

Mode = Mode 1

3. Audio Input Setup

Digital In

Assignment Input

Function

Digital

Inputs

CD AUX DVD / VDP TV / DBS

COAX 1 COAX 2 OPT 1 OPT 2

V. AUX

OPT 3

2EXT. IN

Subwoofer

Level SW Level = +15 dB

Input Function

Level

TUNER AUXCD CDR /

TAPE

DVD /

VDP TV / DBS

0 dB 0 dB0 dB 0 dB 0 dB 0 dB

4VCR

0 dB

V. AUX

0 dB

5Function

Rename 49

6Tuner Presets

A1 ~ A8

B1 ~ B8

C1 ~ C8

D1 ~ D8

E1 ~ E8

87.5/89.1/98.1/107.9/90.1/90.1/90.1/90.1 MHz

520/600/1000/1400/1500/1710 kHz, 90.1/90.1 MHz

90.1 MHz

Auto Preset

Memory

F1 ~ F8

G1 ~ G8

90.1 MHz

Preset Skip

Preset

Name

All preset channels = ON 49

–50

TUNER AUXCD CDR /

TAPE

DVD /

VDP TV / DBS VCR V. AUX

iPod

Assignment

It is possible to assign the Control Dock for iPod’s (ASD-1R, sold separately)

audio and/or video signals to any input terminals on the AVR-787 and play

them.

iPod Function = OFF 48

This assigns the different input function for the digital input

terminals.

Sets the playback level of the analog signal that was input to the EXT. IN

subwoofer terminal.

Up to 56 FM stations can be preset automatically.

The playback level is corrected individually for the different input sources.

The name of the input function that is displayed can be changed.

Preset channels that are not used often can be skipped.

The preset channels can be given the names you want.

This assigns the different input sources for the component video input

terminals.

This sets whether or not to use the video conversion function.

Adjust the time delay between the video and audio signals.

Set whether or not to display the on screen display for indications other

than the menu screens.

PageDefault settingsItems

Advanced Setup – Part 1 Advanced Setup – Part 1

ENGLISH

PageDefault settingsItems

5. Advanced Playback

12ch

Direct/Stereo

Auto Surround

Mode

Basic

Auto Surround Mode = ON

6. Option Setup

1Power Amp

Assign 53

S. Back

2Volume Control

Setup Lock

Vol.Limit = OFF

P. On Lev. = LAST

Mute Lev. = FULL

Setup Lock = OFF

Main

Make the 2-channel direct mode and stereo mode speaker settings.

Set whether or not to store the surround mode last played for the input

signal.

To suit your preference, a surround back channel’s power amplifier can be

assigned to the front channel (“Front A” or “Front B”) for bi-amp

playback, ZONE2.

This sets the volume level of output.

This sets whether or not to lock the system setup settings so that they

cannot be changed.

ENGLISH

Advanced Setup – Part 1 Advanced Setup – Part 1

Navigating through the System Setup Menu

Use System Setup to customize a variety of settings to suit your listening environment.

For the contents of a system menu and the initial setting of this unit ( page 44, 45).

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

ENTER

D H F G

SYSTEM SETUP

D H F G

ENTER

F G, ENTER

D HSYSTEM SETUP

Press SYSTEM SETUP.

•The “System Setup” menu appears.

Press DDHHagain to select the item you want to set, then

press ENTER.

Press DDHHto select the item you want to set, then press

ENTER.

Press ENTER and set a new item.

Press SYSTEM SETUP to return to the “System Setup”

menu or the main menu.

To change the setting:

Press DDHHto select the item you want to change, then

press FFGGto change the setting.

Select “Default Yes”, then press FFto reset to the default setting.

* S Y S T E M S E T U P

A u d i o I n S e t u p

[ On screen display ] [ Display ]

* A u d i o I n S e t u p

D i g i t a l I n

* D i g i t a l I n

C O A X 1 < C D >

* S Y S T E M S E T U P

E x i t

Advanced Setup – Part 1 Advanced Setup – Part 1

ENGLISH

The AVR-787 is equipped with an intuitive and easy-to-understand on screen display, and is equipped with an alphanumeric front panel display

that can also be used to check and adjust settings. We recommend that you use the on screen display when you make system adjustments.

Some representative front display and on screen display examples are shown below.

About the on screen display and front display

[ On screen display ]

Top menu

Main menu

[ Front display ]

A u t o S e t u p

Top menu

Screen title

No.

Sub-menu title

S p e a k e r S e t u p

To select a menu, press DDor HH.

D i g i t a l I n

Main menu Screen title

No.

Sub-menu title

* A u t o S e t u p

S t a r t <

Press FFto execute.

Currently selected line

C O A X 1 < C D >

Current setting

Currently selected line

Audio Input Setup

Setting the Digital In Assignment

This assigns the different input function for the digital input terminals.

Press DDHHto select “Audio Input Setup”, then press

ENTER.

Press DDHHto select “Digital In Assign”, then press

ENTER.

Press ENTER.

Press DDHHto select the input terminals, then press FF

GGto set.

•“TUNER” cannot be selected on the “Digital In Assign” screen.

•It is not possible to make the “Digital In Assignment” settings for

the function assigned at “iPod Assignment”.

CD, AUX, DVD, TV, VCR, V. AUX, CDR:

Assign the different function according to the devices connected

to the AVR-787’s input terminals.

ENGLISH

Advanced Setup – Part 1 Advanced Setup – Part 1

Press FFGG to set.

Setting the EXT. IN Subwoofer Level

Press DDHHto select “EXT IN SW Level”, then press

ENTER.

Press FFGGto set.

Press ENTER.

Sets the playback level of the analog signal that was input to the EXT.

IN subwoofer terminal.

Setting the iPod Assignment

It is possible to assign the Control Dock for iPod’s (ASD-1R, sold

separately) audio and/or video signals to any input terminals on the

AVR-787 and play them.

1Press DDHHto select “iPod Assign”, then press ENTER.

OFF:

This is the factory default setting.

CD, AUX, CDR/TAPE:

When using a Control Dock for iPod, it is possible to connect with

the audio input terminal of the assigned function.

DVD/VDP, TV/DBS, VCR, V. AUX:

When using a Control Dock for iPod, it is possible to connect with

the audio and video input terminals of the assigned function.

Press ENTER.

(When “CDR/TAPE” is selected)

Setting the Input Function Level

Press DDHHto select “Input Function Level”, then press

ENTER.

•After completing this setting, check that the playback levels for the

different sources are the same.

Press DDHHto select the input source, then press FFGG

to set.

The volume can be adjusted within the range –12 dB to +12 dB.

Press ENTER.

The playback level is corrected individually for the different input

sources.

Advanced Setup – Part 1 Advanced Setup – Part 1

ENGLISH

Setting the Function Rename

Press DDHHto select “Function Rename”, then press

ENTER.

Press DDHHto select the input function, then press FF

GG to set.

Press FFGGto move the cursor (

) to the desired

position, then press DDHHto select the character.

Up to 8 characters can be input.

The characters that can be input are shown below.

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

a b c d e f g h i j k l m n o p q r s t u v w x y z 0 1 2 3 4

5 6 7 8 9

! ” # % & ’ ( ) *+ , – . / : ; < = > ? @ [ \ ] (space)

Repeat step 3 to input the input source name.

To set the input function name back to how it was:

qPress FFGGto highlight the input function name, then press DD

HH.

wPress DD HHto select “Default Yes”, then press FF.

Once all the characters have been input, press ENTER.

The name of the input function that is displayed can be changed.

Setting the Tuner Presets

¢Auto Preset Memory

Up to 56 FM stations can be preset automatically.

Press DDHHto select “Tuner Presets”, then press ENTER.

Press DDHHto select “Auto Preset Memory”, then press

ENTER.

Press FFto select “Yes”.

•“Search” blinks on the screen and searching begins.

•“Completed” appears once searching is completed.

•If an FM station cannot be preset automatically due to poor

reception, use the “Manual tuning” operation ( page 33) to tune

in the station, then preset it using the manual “Preset memory”

operation ( page 34).

¢Preset Skip

Preset channels that are not used often can be skipped.

Press DDHHto select “Preset Skip”, then press ENTER.

Press FFGGto select the preset memory block.

Press DDHHto select the preset channel, then press FF

GGto set.

Press ENTER.

Repeat steps 2 and 3.

ON, OFF:

Select “OFF” to skip the preset channel, “ON” if you do not want

to skip.

When HHis pressed at the very bottom of the screen, then the

next preset memory block appears.

Advanced Setup – Part 1 Advanced Setup – Part 1

ENGLISH

¢Preset Name

The preset channels can be given the names you want. (Except the

XM channels.)

Press DDHHto select “Preset Name”, then press ENTER.

Press DDHHto select the preset channel, then press FF

GGto set.

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

a b c d e f g h i j k l m n o p q r s t u v w x y z 0 1 2 3 4

5 6 7 8 9

! ” # % & ’ ( ) *+ , – . / : ; < = > ? @ [ \ ] (space)

Once all the characters have been input, press ENTER.

Press FFGGto move the cursor (

) to the desired position,

then press DDHHto select the character.

Up to 8 characters can be input.

The characters that can be input are shown below.

Repeat step 3 to input the preset channel name.

To set the preset channel name back to how it was:

qPress FFGGto highlight the preset channel, then press DD HH.

wPress DD HHto select “Default Yes”, then press FF.

Press ENTER.

Advanced Setup – Part 1 Advanced Setup – Part 1

ENGLISH

•Down-converting from the component video signal to the S-Video

and composite video signal is not possible, so when not using the

component video monitor output terminal connect the player using

the S-Video or composite video input terminal ( page 14).

•When a non-standard video signal from a game machine or some

other source is input, the video conversion function might not

operate. If this happens, please set the conversion mode to “OFF”.

•When the video conversion function has been used, information

such as that of text broadcasts which has been added to the video

signal might not be output. If this happens, please set the conversion

mode to “OFF”.

Setting the Video Convert

Press DDHHto select “Video Convert”, then press ENTER.

Press DDHHto select the input source, then press FFGG

to set.

ON, OFF:

Select “ON” to use the video conversion function, “OFF” if you do

not want to use it.

Press ENTER.

This sets whether or not to use the video conversion function.

Setting the Audio Delay

Adjust the time delay between the video and audio signals.

Press DDHHto select “Audio Delay”, then press ENTER.

Press FFGGto set.

Press ENTER.

0 ms ~ 200 ms:

Adjust the time delay.

With a movie source, for example, adjust so that the movement

of the actors’ lips is synchronized with the sound.

•By default, this menu is not displayed when no digital signals are

being input.

•To make this setting for the component video signal, select the

delay time and turn the on screen display off, then check that the

timing of the component video and audio match.

•The audio delay setting does not apply when playing in the EXT. IN

mode or in the analog input direct mode or stereo mode (Front

speaker setting “Large” and TONE DEFEAT “ON”).

Video Setup

Setting the Component In Assignment

This assigns the different input sources for the component video input

terminals.

Press DDHHto select “Component In Assign”, then

press ENTER.

Press ENTER.

•It is not possible to make the “Component In Assignment” settings

for the function assigned at “iPod Assignment”.

Press DDHHto select the input terminals, then press FF

GGto set.

DVD/VDP, TV/DBS, VCR, V.AUX:

Assign the different input sources to “COMP1”, “COMP2” or

“COMP3”.

Press DDHHto select “Video Setup”, then press ENTER.

Advanced Setup – Part 1 Advanced Setup – Part 1

ENGLISH

Advanced Playback

Setting the 2ch Direct/Stereo

Make the 2-channel direct mode and stereo mode speaker settings.

Press DDHHto select “Advanced Playback”, then press

ENTER.

Press DDHHto select “2ch Direct / Stereo”, then press

ENTER.

Press DDHHto select the item, then press FFGGto set.

For a description of the settings for the different items, see pages

54 ~ 57.

Basic:

The “Speaker Setup” settings are displayed.

Custom:

The speaker settings for the 2-channel direct and stereo modes can

be changed.

Press ENTER.

Press FFGGto select “Basic” or “Custom”.

Setting the Auto Surround Mode

Set whether or not to store the surround mode last played for the

input signal.

The surround mode used at last for the three types of input signals

shown below is stored in the memory, and the signal is automatically

played with that surround mode the next time it is input.

qAnalog and PCM 2-channel signals (STEREO)

w2-channel signals of Dolby Digital, DTS or other multi-channel

format (DOLBY PLIIx Cinema)

eMulti-channel signals of Dolby Digital, DTS or other multi-

channel format (DOLBY/DTS SURROUND)

Default settings are indicated in ( ).

Press DDHHto select “Auto Surround Mode”, then

press ENTER.

Press FFGGto set.

Press ENTER.

Setting the On Screen Display (OSD)

Set whether or not to display the on screen display for indications

other than the menu screens.

Press DDHHto select “On Screen Display”, then press

ENTER.

Press DDHHto select the item, then press FFGGto set.

Function/Mode Status:

•ON, OFF:

Select “ON” to display the on screen display when the input source

is selected, “OFF” if you do not want to display it.

Master Volume Status:

•ON, OFF:

Select “ON” to display the on screen display when the main volume

is adjusted, “OFF” if you do not want to display it.

Display Mode:

•MODE1:

Flickering is not prevented.

•MODE2:

Prevents flickering of the on screen display when there is no video

signal.

Use this mode if the on screen display is not displayed in “MODE1”.

Press ENTER.

Advanced Setup – Part 1 Advanced Setup – Part 1

ENGLISH

Setting the Power Amplifier Assignment

To suit your preference, a surround back channel’s power amplifier

can be assigned to the front channel (“Front A” or “Front B”) for bi-

amp playback, ZONE2.

Press DDHHto select “Option Setup”, then press ENTER.

Option Setup

Press DDHHto select “Power Amp Assign”, then press

ENTER.

Press FFGGto set.

S. Back:

The surround back speakers are used in MAIN ZONE.

Front A, Front B:

This provides a bi-amp mode for the two main front speakers,

replicating the front A or front B amplifier channel’s outputs.

ZONE2:

This mode assigns the surround back amplifier channels to provide

ZONE2 speaker-level outputs from the surround back speaker

terminals.

Press ENTER.

Front Bi-Amp connections

Dynamic sound with a range wider than that of full range

systems can be played by connecting bi-amp compatible

speakers to the AVR-787. Be sure to consult the owner’s

manual of your bi-amp-capable speakers for further

information before proceeding.

NOTE:

•When making bi-amp connections, be sure to remove the

short-circuiting bar included with the speaker.

Speaker [R]

AVR-787

Speaker [L]

Setting the Volume Control

This sets the volume level of output.

Press DDHHto select “Volume Control”, then press

ENTER.

Press DDHHto select the item, then press FFGGto set.

Volume Limit:

Set the volume’s upper limit.

•OFF:

If you do not want to set a volume limit, select “OFF”.

In this case, the volume can be set to the AVR-787’s maximum

volume (output) level of +18 dB, which is extremely loud.

•–20 dB, –10 dB, 0 dB:

The volume cannot be increased above the selected levels.

Mute Level:

Set the level of volume attenuation in the mute mode.

•FULL:

The volume is fully muted.

•–20 dB, –40 dB:

The volume is lowered 20 dB or 40 dB from the current level.

Power On Level:

Set the volume level when the power is turned on.

You can adjust the MAIN ZONE volume level within the range of

–80 to +18 dB.

•LAST:

The volume set when the AVR-787 was last used is stored in the

memory and set when the power is turned on.

•– – – (Mute):

The volume is always muted when the power is turned on.

Press ENTER.

MAIN ZONE

Surround Back 7.1ch system

ZONE2 5.1ch system

Bi-Amp 5.1ch system

Power Amplifier

Assignment ZONE2

–

2ch system

–

PRE-OUT

S.BACK/ZONE2

Surround back

ZONE2

–

SPEAKER OUT

ENGLISH

Advanced Setup – Part 1

Setting the Setup Lock

This sets whether or not to lock the system setup settings so that

they cannot be changed.

Press DDHHto select “Setup Lock”, then press ENTER.

Press FFto select “ON”, then press ENTER.

•When the setup lock function is activated, the settings listed below

cannot be changed, and “SETUP LOCKED” is displayed when

related buttons are operated.

•System setup settings

•Surround parameter settings

•Tone control settings

•Channel level settings (including test tones)

•To unlock, press SYSTEM SETUP again and display the “Setup Lock”

screen, then select “OFF” and press ENTER.

Advanced Setup – Part 2

•If the “Auto Setup” procedure has already been performed, there is

no need to make this setting.

•Perform this setting if you wish to make the settings for your

speaker systems manually.

Speaker Setup

Setting the Speaker Configuration

Automatically set the output component and properties for the

various channels according to the combination of speakers to be

actually used for surround playback.

About the button names in this explanation

<>: Buttons on the main unit

[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

ENTER

D H F G

[TEST TONE]

D H F G

ENTER

F G, ENTER

D H

Press DDHHto select “Speaker Setup”, then press

ENTER.

Press DDHHto select “Speaker Config.”, then press

ENTER.

Press DDHHto select the speaker, then press FFGGto set.

Large:

Select this when using large speakers with ample low frequency

reproduction capabilities.

Small:

Select this when using small speakers without ample low frequency

reproduction capabilities.

Yes / No:

Select “Yes” when a subwoofer is connected, “No” when no

subwoofer is connected.

None:

Select this when no speaker is connected.

2sp / 1sp:

Select the number of surround back speakers.

ENGLISH

Advanced Setup – Part 2 Advanced Setup – Part 2

Press ENTER.

A subwoofer with sufficient low frequency playback capability can

better handle deep bass than most main and surround speakers,

and the system’s overall performance will be greatly enhanced

when “Small” is set for the main (front) and surround speakers.

When “Front” is set to “Small”, “Subwoofer” is automatically set

to “Yes”, and when “Subwoofer” is set to “No”, “Front” is

automatically set to “Large”.

•Select “Large” or “Small” not according to the actual size of the speaker

but according to the speaker’s capacity for playing low frequency

(bass sound below the frequency set for the Crossover Frequency)

signals. If you do not know, try comparing the sound at both settings

(setting the volume to a level low enough so as not to damage the

speakers) to determine the proper setting.

Setting the Subwoofer Setup

Select the method of playback of the subwoofer for playing the low

bass signals.

Press DDHHto select “Subwoofer Setup”, then press

ENTER.

Press FFGGto set.

LFE (Normal):

For any channel(s) that are set to “Large”, low frequencies in that

channel’s corresponding source are directed to that loudspeaker

only. The low frequencies played from the subwoofer are only the

LFE signals and the low frequencies of channels set to “Small”.

LFE+Main:

Low frequencies from speaker channels that have been set to

“Large” are reproduced from those speakers as well as from the

subwoofer(s).

•The subwoofer mode setting is only valid when and “Yes” is set for

the subwoofer in the “Setting the Speaker Configuration”.

•Select the “LFE+Main” mode if you want low frequency signals to

always be played from the subwoofer channel.

•Select the mode achieving a voluminous bass sound when playing

music or movie sources.

Press ENTER.

Setting the Distance

This parameter is for optimizing the timing with which the audio

signals are produced from the speakers and subwoofer according to

the listening position.

Preparations:

Measure the distances between the listening position and the

speakers (L1 to L8 on the diagram at the below).

Press DDHHto select “Distance”, then press ENTER.

L1 L2

L4 L5

L6 L7

CFRFL

Listening position

SL SR

SBL SBR

Press DDHHto select the speaker, then press FFGGto set.

Press ENTER.

Center speaker

Front speaker

Subwoofer

Surround speaker

Surround back speaker

ENGLISH

Advanced Setup – Part 2 Advanced Setup – Part 2

•The distance changes in units of 0.5 foot each time the button is

pressed. Select the value closest to the measured distance.

•Please note that the difference of distance for every speaker

should be 20 ft or less.

12..... L1

..... L2

..... L3

..... L4

..... L5

..... L6

..... L7

..... L8

Set the volume of the various speakers so that the sound output from

the speakers and the subwoofer seems to have the same volume

level.

Press DDHHto select “Channel Level”, then press ENTER.

Press DDHHto select “Test Tone Start”, then press FFto

select “Yes”.

Press FFGGto set.

When “Auto” mode is selected:

Press FFGGto adjust the volume.

•Test tones are output automatically, in the order shown below.

Auto:

Adjust the level while listening to the test tones produced

automatically from each speaker.

Test tones are automatically emitted from each speaker.

Manual:

Adjust with the speaker from which the test tone is output switched

manually.

CFR SR

SBL

SBR

Setting the Channel Level

The volume can be adjusted within the range –12 dB to +12 dB.

When “Manual” mode is selected:

Press DDHHto select the speaker, then press FFGGto

adjust the volume.

Press ENTER.

-1

-2

(2 speakers)

(1 speaker)

•To cancel the setting, press HHand select “Level Clear”, then press

FFand select “Yes”.

•To adjust the channel level separately for the different play modes

after setting the channel level, perform the operation on page 32.

-1

ENGLISH

Advanced Setup – Part 2Advanced Setup – Part 2

¢Adjusting the test tone using the remote control

unit

Adjustment of the test tones using the remote control unit is only

possible in the “Auto” mode and only valid in the STANDARD (Dolby/

DTS Surround) mode. The adjusted levels are automatically stored for

the different surround modes.

Press [TEST TONE].

•Test tones are output from the different speakers.

Press [TEST TONE].

Press FFGGto adjust the volume.

Setting the Crossover Frequency

Set the frequency (Hz) below which the bass sound of the various

speakers is to be output from the subwoofer.

For speakers that are set to “Small”, frequencies under the crossover

frequency are cut before the signal is output, and the low frequency

component that was cut is output from the subwoofer or the

speakers that are set to “Large”.

Press DDHHto select “Crossover Frequency”, then

press ENTER.

Press FFGGto set.

40, 60, 80, 90, 100, 110, 120, 150, 200, 250 Hz:

Set as desired according to your speakers’ bass playback ability.

Press ENTER.

•The crossover frequency mode is valid only when subwoofer is set

to “ON”, and when one or more speakers are set to “Small”, as

described in section “Setting the Speaker Configuration” ( page

54, 55).

•If “LFE+Main” is set at “Subwoofer Setup”, “SW:LFE+Main” (

page 55) is displayed at the top right of the screen.

•Set to “80 Hz” when using regular speakers. When using small

speakers, we recommend setting to a higher frequency.

ENGLISH

Operating the remote control unit

Operating DENON audio components

Set [MODE SELECTOR 1] to “AUDIO”.

Operate the audio component.

For details, refer to the component’s operating instructions.

While this remote control is compatible with a wide range of

infrared controlled components, it may be the case that some

component models cannot be operated with this remote control.

Set [MODE SELECTOR 2] to the position for the

component to be operated (CD, CD-R/MD or TAPE).

Press [ZONE2 OFF] and [MAIN ON] at the same time.

•The indicator starts flashing.

Referring to the included list of preset codes, press

[NUMBER] to input the preset code (a 3-digit number)

for the manufacturer of the component whose signals

you want to store in the memory.

To store the codes of another component in the memory,

repeat steps 1 to 4.

•The signals for the pressed buttons are emitted while setting the

preset memory. To avoid accidental operation, cover the remote

control unit’s transmitting window while setting the preset memory.

•Depending on the model and year of manufacture, this function

cannot be used for some models, even if they are of makes listed in

the list of preset codes.

•Some manufacturers use more than one type of remote control

code. Refer to the included list of preset codes to change the

number and verify correct operation.

•The preset memory can be set for one component only among the

following: CD-R/MD, DVD/VDP and DBS/CABLE.

Setting the preset memory function

•DENON and other makes of components can be operated by setting

the preset memory.

•This remote control unit can be used to operate components of

other manufacturers without using the learning function by

registering the manufacturer of the component as shown in the list

of preset codes ( End of this manual).

•Operation is not possible for some models.

Set [MODE SELECTOR 2] to the component to be

registered.

Set [MODE SELECTOR 1] to “AUDIO” or “VIDEO”.

Set to the AUDIO side for the CD, TAPE or CD-R/MD position, and

to the VIDEO side for the DVD/VDP, DBS/CABLE, VCR or TV

position.

[MODE SELECTOR 2]

[MODE SELECTOR 1]

[MAIN ON]

[ZONE2 OFF]

[NUMBER]

Operating the remote control unit Operating the remote control unit

ENGLISH

Operating a component stored in the preset

memory

Operate the component.

For details, refer to the component’s operating instructions.

Some models cannot be operated with this remote control unit.

Set [MODE SELECTOR 1] to “AUDIO” or “VIDEO”.

Set to the AUDIO side for the CD, TAPE or CD-R/MD position, and

to the VIDEO side for the DVD/VDP, DBS/CABLE, VCR or TV

position.

Set [MODE SELECTOR 2] to the component you want

to operate.

[MODE SELECTOR 2]

[MODE SELECTOR 1]

[

]

[

]

[

[A/B]

[

], [DISC SKIP +]

[

6 7

[

8 9

]

[VCR CH + –]

[SETUP]

[D H

F G],

[AUDIO]

[ENTER]

[DISPLAY], [RETURN]

[MENU]

[ON/SOURCE]

[OFF]

[SHIFT] [CHANNEL + –]

[NUMBER] (0~9, +10)

[TV/VCR]

[TUNING + – ]

[TV VOL. + – ]

[

MODE/MENU

]

[

BAND/PICTURE ADJUST

]

[MEMORY/SUBTITLE]

[SETUP]

[D H

F G],

[

AUDIO

]

[ENTER]

[DISPLAY]

[

RETURN

]

(Monitor)

Cable TVSatellite tuner Video deckVideo disc playerDVD playerTape deckMD recorderCD recorderCD player

RETURN

DISPLAY

ENTER

AUDIO

DDHHFFGG

SETUP

9, VCR CH +

8, VCR CH –

0, DISC SKIP +

3, A/B

CHANNEL +

CHANNEL –

SHIFT

ON / SOURCE

OFF

MODE SELECTOR 2

MODE SELECTOR 1

Device operated

ENGLISH

Operating the remote control unit Operating the remote control unit

¢Functions of buttons for the different devices

Play Forward play Play PlayPlay

Punch through

Pause

Skip (reverse)

Search (reverse)

CD-R / MD

Preset channel selection

–

Skip (forward)

–

A/B switching

–

Rewind

TAPE

Preset channel selection

–

Reverse play

Pause

Skip (reverse)

Search (reverse)

–

Power on /Standby

Skip (forward)

–

Pause

Channels –

Search (reverse)

VCR

–

Power on /Standby

Channels +

–

Power on /Standby

Pause

Skip (reverse)

Search (reverse)

DVD / VDP

–

Power off

Audio

Power on

Skip (forward)

Disc skip

DBS / CABLE

–

Power on /Standby

Preset channel selection

–

Preset channel selection

–

Channels –

Channels +

–

Channels –

Channels +

–

Channels –

Channels +

Return

Enter

Display selection

Channels –

Channels +

Return

Enter

Display selection

Channels –

Channels +

Return

Enter

Display selection

VIDEO

Stop Stop Stop StopStop

–––––

Setup –

Search (forward) Fast forward Search (forward) Search (forward)Search (forward)

––––

Cursor operationCursor operation Cursor operation

–

Power on /Standby

Channels –

Channels +

Return

Enter

Display selection

–

Cursor operation

Play

Pause

Skip (reverse)

Search (reverse)

Preset channel selection

–

Skip (forward)

–

Preset channel selection

–

Stop

–

Search (forward)

–

Play

Pause

Skip (reverse)

Search (reverse)

Preset channel selection

–

Skip (forward)

Disc skip +

AUDIO

Preset channel selection

–

Stop

–

Search (forward)

–

–––– MenuMenu Menu Menu

––

[Front]

Punch through Punch through

(Monitor)

Cable TVSatellite tuner Video deckVideo disc playerDVD playerTape deckMD recorderCD recorderCD player

Special remarks

Default setting

(Preset code)

RETURN

DISPLAY

MEMORY / SUBTITLE

ENTER

BAND /

PICTURE ADJUST

AUDIO

DDHHFFGG

SETUP

MODE / MENU

TUNING – / TV VOL –

TUNING + / TV VOL +

TV/ VCR

NUMBER (0 ~ 9, +10)

MODE SELECTOR 2

MODE SELECTOR 1

Device operated

Operating the remote control unit Operating the remote control unit

ENGLISH

––––Setup –

–

CD-R / MD

Tuning

–

AM/FM/XM switching

–

TAPE

Tuning

–

AM/FM/XM switching

–

Volume control +

Number input /

Track selection

Input mode selection

–

VCR

Volume control +

–

Input mode selection

–

Volume control +

Channels

Input mode selection

Audio

Display selection

Enter

DVD / VDP

Volume control +

Number input /

Track selection

Input mode selection

Return

Picture adjust

DBS / CABLE

Volume control +

Channels

Input mode selection

Tuning

Auto/Manual switching

Tuning

Auto/Manual switching

Volume control –

–

Volume control –

–

Volume control –

VIDEO

––––

Cursor operation

DENON

(111)

DENON

(111) –HITACHI

(108)

ABC

(007)

DENON

(111) –

Preset memory Preset memory – –

Subtitle

Volume control +

Channels

Input mode selection

Volume control –

HITACHI

(134)

–

Tuning

–

AM/FM/XM switching

Tuning

Auto/Manual switching

–

Preset memory

–

Tuning

–

AM/FM/XM switching

AUDIO

Tuning

Auto/Manual switching

–

DENON

(111)

Preset memory

[Rear]

––

Enter

Cursor operationCursor operation

–

Cursor operation

–

Enter Enter

––

Display selection

Return

Display selection

Return

–

Display selection

Return

Special remarks:

qIt is only possible to set the preset memory for one device per mode. When a new code is preset, the previous code is automatically deleted.

wNote that the function names of the DVD buttons on the remote control unit may differ for some brands. Check beforehand.

eThe CD, CD-R/MD, TAPE, VCR or DVD/VDP buttons can be assigned to a TV or satellite tuner (or cable TV) ( page 62).

qq qq,wq,eq,eq

ENGLISH

Operating the remote control unit Operating the remote control unit

Setting the punch through function

Set [MODE SELECTOR 1] to “VIDEO”.

Press [MEMORY] and [INPUT MODE] at the same time.

•The indicator starts flashing.

Set [MODE SELECTOR 2] to the component to be

registered (DBS/CABLE or TV).

“Punch Through” is a function allowing you to operate 1, 2, 6,

7, 8and 9on CD, TAPE, CD-R/MD, DVD/VDP or VCR

components when in the DBS/CABLE or TV mode. By default, nothing

is set.

Input the number of the component you want to set.

4No.

CD 1

TAPE 2

CD-R/MD 3

DVD/VDP 4

VCR 5

No setting 0

[MEMORY] [INPUT MODE]

[MODE SELECTOR 2]

[MODE SELECTOR 1]

ENGLISH

Examples of speaker layouts

Below we introduce examples of speaker layouts. Refer to these to

arrange your speakers according to their type and how you want to

use them.

[1] Using surround back speaker(s)

qWhen mainly playing movies

Recommended when your surround speakers are single or 2-way

speakers.

Subwoofer

Surround back speakers

Front speakers

60°

Monitor

Center speaker

[As seen from above]

Surround

speakers

Surround speaker

Front speaker

2 to 3 feet

[As seen from the side]

Surround back

speaker

Point slightly

downwards

Additional Information

About the speakers

Surround back speakers

Sound position directly to the rear can be achieved easily by adding a

surround back speaker to a 5.1-channel system.

In addition, the acoustic image extending between the sides and the

rear is narrowed, thus greatly improving the expression of the

surround signals for sounds moving from the sides to the back and

from the front to the point directly behind the listening position.

FL C

SR chSL ch

Change of positioning and acoustic image

with 5.1-channel systems

Movement of acoustic

image from SR to SL

FL C

SL ch SR ch

SB ch

Change of positioning and acoustic image

with 6.1-channel systems

Movement of acoustic

image from SR to SB to

In addition to sources recorded in 6.1-channels, the surround effect of

conventional 2- to 5.1-channel sources can also be enhanced.

¢Number of surround back speakers

We recommend using two speakers.

When using dipolar speakers in particular, be sure to use two speakers.

¢Placement of the surround left and right channels

when using surround back speakers

We recommend installing the speakers for the surround “L” and “R”

channels a bit forward.

wWhen playing movies and musics

Surround back

[As seen from above]

Surround

speaker

Front speaker

2 to 3 feet

[ As seen from the side ]

Surround back

speaker

Point slightly

downwards

45° ~ 60°

Surround

speakers

Subwoofer

Front speakers

Monitor

Center speaker

Surround speakers

[ As seen from above ]

[ As seen from the side ]

Front speaker

2 to 3 feet

Surround speaker

60°

[2] When not using surround back speakers

Subwoofer

Monitor

Front speakers

Center speaker

speakers

120°

ENGLISH

Additional Information Additional Information

¢Sources recorded in Dolby Surround

Sources recorded in Dolby Surround are indicated with the following

logo marks.

Dolby Surround support mark:

Manufactured under license from Dolby Laboratories. “Dolby”,

“Pro Logic” and the double-D symbol are trademarks of Dolby

Laboratories.

The AVR-787 is equipped with a digital signal processing circuit that

lets you play program sources in the surround mode to achieve the

same sense of presence as in a movie theater.

Surround

Dolby Surround

[1] Dolby Digital

Dolby Digital is the multi-channel digital signal format developed by

Dolby Laboratories.

A total of 5.1-channels are played: three front channels (“FL”, “FR”

and “C”), two surround channels (“SL” and “SR”) and the “LFE”

channel for low frequencies.

Because of this, there is no crosstalk between channels and a realistic

sound field with a “three-dimensional” feeling (sense of distance,

movement and positioning) is achieved.

A real, overpowering sense of presence is achieved when playing

movie sources in AV rooms as well.

[2] Dolby Pro Logic II

Dolby Pro Logic II is a matrix decoding technology developed by Dolby

Laboratories. Regular music such as that on CDs is encoded into 5

channels to achieve an excellent surround effect.

The surround channel signals are converted into stereo and full band

signals (with a frequency response of 20 Hz to 20 kHz or greater) to

create a “three-dimensional” sound image offering a rich sense of

presence for all stereo sources.

[3] Dolby Pro Logic II x

Dolby Pro Logic IIx is a further improved version of the Dolby Pro

Logic II matrix decoding technology.

Audio signals recorded in 2 channels are decoded to achieve a natural

sound with up to 7.1-channels.

There are three modes: “Music” suited for playing music, “Cinema”

suited for playing movies, and “Game” which is optimum for playing

games.

MANUFACTURED UNDER LICENSE FROM DIGITAL THEATER

SYSTEMS, INC.

U.S. PAT. NO’S. 5,451,942; 5,956,674; 5,974,380; 5,978,762;

6,226,616; 6,487,535 AND OTHER U.S. AND WORLD–WIDE

PATENTS ISSUED AND PENDING.

“DTS”, “DTS–ES”, “Neo:6”, AND “DTS 96/24” ARE

DTS Digital Surround

DTS Digital Surround is a digital surround format developed by Digital

Theater Systems of the United States.

The number of playback channels and the playing band is the same as

for Dolby Digital (5.1-channels).

The compression rate of the audio data when it was recorded on the

medium is lower than for Dolby Digital, so there is more information

when the data is decoded, resulting in richer, clearer sound quality.

DTS-ES™

DTS-ES is a new surround format developed by Digital Theater

Systems.

A sound image and sense of positioning can be achieved by adding a

surround back (“SB”) channel to the conventional 5.1-channels.

DTS-ES™ Discrete 6.1:

This is the latest format, in which all 6.1-channels, including the

“SB” channel, are recorded independently. Since the different

channels are independent, the sound can be designed with total

freedom.

DTS-ES™ Matrix 6.1:

With this format, the “SB” channel is matrix-encoded and inserted

into the “SL” and “SR” channels, then decoded for the “SL”, “SR”

and “SB” channels upon playback. This achieves a surround sound

more faithful to the artist’s sound design intentions than with

conventional 5.1- or 6.1-channel systems.

DTS NEO:6 surround

This is a matrix decoding technology for 6.1-channel surround playback

of 2-channel sources.

The optimum decoding for the type of signal source to be played can

be selected. There are two modes.

DTS NEO:6 CINEMA:

This mode is suited for playing movies. It achieves the same type of

sound as in a movie theater, even with 2 channels.

DTS NEO:6 MUSIC:

This mode is suited for playing music. A natural sense of expansion

is added to the sound field.

DTS 96/24

DTS 96/24 is a multi-channel digital signal format developed by Digital

Theater Systems.

The sampling frequency is raised to achieve 5.1-channel playback with

high quality sound (sampling frequency: 96 kHz, quantization: 24 bits).

Neural Surround

Neural Surround™, a breakthrough in audio technology, will bring the

excitement of surround music to more of America’s listening

audience. It provides the rich envelopment and discrete image detail

of surround sound in a format 100 % compatible with stereo. With

superior spectral resolution and channel separation, Neural

Surround™ draws the brain’s attention to sonic details in musical

instruments, vocals, and ambience that are typically masked by other

playback systems. This allows the listener to fully experience the

richness and subtleties in recorded performance as never before. As

the chosen format for XM Satellite Radio’s new XM HD surround

programming, Neural Surround will help deliver more surround music

to more listeners than any other broadcast format. XM Satellite Radio

will be the first radio company -to broadcast surround sound on the

radio 24 hours a day and will offer three channels fully dedicated to

Neural Surround™ music. This alone will amount to more than 25,000

hours of Neural Surround™ music each year.

•This product is manufactured under license from Neural Audio

Corporation.

D&M Holdings Inc. hereby grants the user a non-exclusive, non-

transferable, limited license right exercisable to use the NA

SURROUND Technology and other US and World Wide Patents

Pending technology.

“Neural” and “Neural Audio” and “Neural Surround” Are

Page

ENGLISH

PageMeasuresCauseSymptom

MeasuresCauseSymptom

Troubleshooting

ENGLISH

Troubleshooting

If a problem should arise, first check the following.

1. Are the connections correct?

2. Have you operated the receiver according to the Operating Instructions?

3. Are the speakers and other components operating properly?

If this unit is not operating properly, check the items listed in the table below. Should the problem persist,

there may be a malfunction. Disconnect the power immediately and contact your store of purchase.

Display not lit and sound

not produced when

POWER switch set to

on.

•Power supply cord not plugged in

securely.

•Check the insertion of the power

supply cord plug.

Display lit but sound not

produced.

•Speaker cables not securely

connected.

•FUNCTION knob position is not

appropriate.

•Volume control set to minimum.

•MUTING is on.

•No digital signal is being input.

•Connect securely.

•Switch to the proper position.

•Turn volume up to suitable level.

•Switch off MUTING.

•Properly select a digital signal input

source.

Nothing is displayed on

monitor.

•AVR-787’s video output terminals and

monitor’s input terminals are not

properly connected.

•Monitor’s input setting is wrong.

•Player connected with component

terminal, TV connected with video

terminal (yellow) or S-Video terminal.

•Check that the connections are

correct.

•Set the monitor’s input selector to

the terminals to which video signals

are connected.

•Down-conversion is not possible for

progressive video signals.

Make the interlace settings on the

player.

13 ~ 20

—

No DTS sound is

produced.

•DVD player’s audio output setting is

not set to bit stream.

•DVD player is not DTS-compatible.

•AVR-787’s input setting is set to

analog.

•Make the DVD player’s default

settings.

•Use a DTS-compatible player.

•Set to “AUTO” or “DTS”.

—

Copying from DVD to

VCR is not possible.

•Copying between a source such as

DVD and a VCR is not usually

possible, as DVDs are often encoded

with copy-protection signals that

prevent VCR recording.

•Copying is not possible. —

This unit does not

operate properly when

remote control unit is

used.

•Batteries dead.

•Remote control unit too far from this

unit.

•Obstacle between this unit and

remote control unit.

•Different button is being pressed.

•<and >ends of batteries inserted

in reverse.

•Replace with new batteries.

•Move closer.

•Remove obstacle.

•Press the proper button.

•Insert batteries properly.

—

Power has turned off

and the power indicator

is blinking red.

•The set’s internal temperature has

risen and the protection circuit has

been activated.

•The core wires of the speaker cables

are touching each other or the AVR-

787’s rear panel, activating the

protection circuit.

•AVR-787 is malfunctioning.

•Put the AVR-787 in a well-ventilated

place.

•Turn off the power, then wait for the

set to fully cool off before turning the

power back on.

•Check the connections of all the

speaker cables.

•Turn off the power and contact a

DENON customer service center.

No test tones are

produced.

•Surround mode is set to a mode

other than STANDARD (Dolby/DTS

Surround).

•Set to STANDARD (Dolby/DTS

Surround).

—

No sound is produced

from surround speakers.

•Surround mode is set to “STEREO”. • Set to a mode other than “STEREO”. —

Sound is only produced

from the center speaker.

•You are playing a monaural source

(TV, AM radio broadcast, etc.) in the

STANDARD (Dolby/DTS Surround)

mode.

•When playing monaural sources,

select a surround mode other than

STANDARD (Dolby/DTS Surround)

mode.

30, 31

“DOLBY DIGITAL” is not

displayed.

•DVD player’s digital audio output

setting is not proper.

•Check the DVD player’s audio output

setting.

For details, see the DVD player’s

operating instructions.

—

35“CHECK ANTENNA” is

displayed in the XM

mode.

•AVR-787’s XM connectors and the

XM Passport System is not properly

connected.

•Check that the connection are

correct.

No sound is produced

from subwoofer.

•Subwoofer’s power is not on.

•Subwoofer’s initial setting is set to

“NO”.

•Subwoofer’s output is not connected.

•The subwoofer’s channel volume

level is set to “OFF”.

•Turn on the power.

•Set the setting to “YES”.

•Connect properly.

•Turn the subwoofer’s channel volume

level up.

—

54, 55

35“NO SIGNAL” is

displayed in the XM

mode.

•The signal cannot be received. • Reposition your XM Passport System.

ENGLISH

Symptom Cause Measures Page

Troubleshooting Troubleshooting

Specifications

¢Audio section

•Power amplifier

Rated output: Front (A, B):

85 W + 85 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)

120 W + 120 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)

Center:

85 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)

120 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)

Surround:

85 W + 85 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)

120 W + 120 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)

Surround Back:

85 W + 85 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)

120 W + 120 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)

Output terminals: Front: A or B 06 ~ 16 Ω/ohms

A + B 12 ~ 16 Ω/ohms

Center, Surround, Surround. Back: 06 ~ 16 Ω/ohms

•Analog

Input sensitivity / input impedance: 200 mV / 47 kΩ/kohms

Frequency response: 10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)

S/N: 98 dB (DIRECT mode)

¢Video section

•Standard video terminals

Input / output level and impedance: 1 Vp-p, 75 Ω/ohms

Frequency response: 5 Hz ~ 10 MHz — +1, –3 dB

•S-Video terminals

Input / output level and impedance: Y (brightness) signal — 1 Vp-p, 75 Ω/ohms

C (color) signal — 0.286 Vp-p, 75 Ω/ohms

Frequency response: 5 Hz ~ 10 MHz — +1, –3 dB

•Color component video terminal

Input / output level and impedance: Y (brightness) signal — 1 Vp-p, 75 Ω/ohms

PB/CBsignal — 0.7 Vp-p, 75 Ω/ohms

PR/CRsignal — 0.7 Vp-p, 75 Ω/ohms

Frequency response: DC ~ 100 MHz — +0, –3 dB

¢Tuner section [FM] [AM]

(note: µV at 75 Ω/ohms, 0 dBf = 1 x 10–15 W)

Receiving Range: 87.5 MHz ~ 107.9 MHz 520 kHz ~ 1710 kHz

Usable Sensitivity: 1.0 µV (11.2 dBf) 18 µV

50 dB Quieting Sensitivity: MONO 1.6 µV (15.3 dBf)

STEREO 23 µV (38.5 dBf)

S/N (IHF-A): MONO 77 dB

STEREO 72 dB

Total Harmonic Distortion (at 1 kHz): MONO 0.15 %

STEREO 0.3 %

¢General

Power supply: AC 120 V, 60 Hz

Power consumption: 5.1 A

1 W Max (Standby)

Maximum external dimensions: 434 (W) x 147 (H) x 417 (D) mm (17-3/32” x 5-25/32” x 16-27/64”)

Mass: 11.8 kg (26 lbs)

¢Remote control unit (RC-1046)

Batteries: R6P/AA Type (Two batteries)

External dimensions: 52 (W) x 243 (H) x 21 (D) mm (2-3/64” x 9-9/16” x 53/64”)

Mass: 175 g (Approx. 6.2 oz) (included batteries)

* For purposes of improvement, specifications and design are subject to change without notice.

“OFF AIR” is displayed

in the XM mode.

•The selected channel is not currently

broadcasting.

•Select the another channel.

Receiving only XM

channels 0 and 1.

•The XM Tuner is not activated. • Contact XM Radio.

PRESET CODE

Go Video 047, 048

Goldstar 000, 006, 012, 062, 088

Gradiente 094

Grundig 042

Harley Davidson 094

Harman Kardon 040, 062

Hi-Q 091

Hitachi 009, 013, 023, 026, 058,

*[108], 109, 110, 111

JC Penny 004, 005, 007, 023, 028,

049, 062, 085, 087, 088

Jensen 013, 026

JVC 004, 005, 006, 026, 029,

043, 044, 045, 046, 085

Kenwood 004, 005, 006, 026, 029,

033, 045, 085, 090

Kodak 088

Lloyd 009, 094

LXI 088

Magnavox 015, 016, 042, 049, 063,

106

Magnin 087

Marantz 004, 005, 006, 015, 042,

049, 085, 090

Marta 088

MEI 049

Memorex 009, 033, 049, 053, 060,

081, 087, 088, 091, 094,

115

Metz 123, 124, 125, 126, 127,

128

MGA 001, 017, 027, 041, 097

MGN Technology 087

Midland 011

DVD

Denon 014, *[111]

Aiwa 009

Hitachi 010

JVC 006, 011

Konka 012, 013

Magnavox 005

Mitsubishi 004

Panasonic 014

Philips 005, 015, 016, 017

Pioneer 003, 008

Sanyo 018

Sony 002, 019, 020

Toshiba 001, 021, 022

Zenith 023

VDP

Denon 028, 029, 112

Magnavox 026

Mitsubishi 028

Panasonic 029, 030

Philips 026

Pioneer 028, 031

RCA 032

Sony 033, 034, 035, 036

VCR

Admiral 081

Aiko 095

Aiwa 009

Akai 026, 027, 070, 072, 082,

083, 084

Alba 055

Amstrad 009

ASA 042

Asha 087

Audio Dynamic 005, 085

Audiovox 088

Beaumark 087

Broksonic 086, 093

Calix 088

Candle 006, 087, 088, 089, 090

Canon 049, 057

Capehart 025, 055, 056, 071

Carver 015

CCE 095

Citizen 006, 007, 087, 088, 089,

090, 095

Craig 007, 087, 088, 091, 115

Curtis Mathes 006, 049, 073, 080, 087,

090, 092

Cybernex 087

Daewoo 025, 055, 059, 074, 089,

093, 095, 096

Daytron 025, 055

DBX 005, 085

Dumont 053

Dynatech 009

Electrohome 001, 088, 097

Electrophonic 088

Emerson 001, 009, 017, 027, 086,

088, 089, 092, 093, 097,

100, 101, 102, 103, 104,

117

Fisher 009, 028, 031, 053, 054,

091, 099, 115

GE 007, 011, 049, 050, 051,

052, 073, 080, 087

¢List of preset codes

Minolta 013, 023

Mitsubishi 001, 003, 008, 013, 014,

017, 027, 029, 039, 040,

041, 045, 097

Motorola 081

Montgomery Ward

001, 002, 007, 009, 049,

063, 081, 115, 117

MTC 009, 087, 094

Multitech 007, 009, 011, 087, 090,

094

NAD 038

NEC 004, 005, 006, 018, 026,

029, 045, 061, 062, 085

Nikko 088

Noblex 087

Optimus 081, 088

Optonica 021

Panasonic 024, 049, 064, 066, 067,

068, 069, 107

Perdio 009

Pentax 009, 013, 023, 058, 090

Philco 015, 016, 049

Philips 015, 021, 042, 049, 105

Pilot 088

Pioneer 005, 013, 029, 036, 037,

038, 045, 085

Portland 025, 055, 090

Proscan 063, 080

Pulsar 060

Quartz 033

Quasar 034, 035, 049

Radio Shack 001, 002, 021, 081, 087,

088, 091, 094, 097, 098,

115

ENGLISH

PRESET CODE

Radix 088

Randex 088

RCA 007, 013, 019, 023, 058,

063, 064, 065, 073, 080,

082, 087

Realistic 009, 021, 031, 033, 049,

053, 081, 087, 088, 091,

094, 097, 098

Ricoh 055

Salora 033, 041

Samsung 007, 011, 051, 059, 070,

083, 087, 089, 113

Sanky 081

Sansui 005, 026, 029, 045, 061,

085, 114

Sanyo 032, 033, 053, 087, 091,

115, 116

SBR 042

Scott 017, 020, 086, 089, 093,

117

Sears 013, 023, 028, 031, 033,

053, 054, 088, 091, 098,

099, 115

Sentra 055

Sharp 001, 002, 021, 097

Shogun 087

Sony 075, 076, 077, 078, 079,

121, 122

STS 023

Sylvania 009, 015, 016, 017, 041,

049, 094

Symphonic 009, 094

Tandy 009

Tashiko 009, 088

Tatung 004, 026, 030

Teac 004, 009, 026, 094

Technics 024, 049

Teknika 009, 010, 022, 049, 088,

094

TMK 087, 092

Toshiba 013, 017, 020, 041, 059,

089, 098, 099, 117

Totevision 007, 087, 088

Unirech 087

Vecrtor Research 005, 062, 085, 089, 090

Victor 005, 045, 046, 085

Video Concepts 005, 027, 085, 089, 090

Videosonic 007, 087

Wards 013, 021, 023, 087, 088,

089, 091, 094, 097, 118,

119, 120

XR-1000 094

Yamaha 004, 005, 006, 026, 062,

085

Zenith 060, 078, 079

Admiral 045, 121

Adventura 122

Aiko 054

Akai 016, 027, 046

Alleron 062

A-Mark 007

Amtron 061

Anam 006, 007, 036

Anam National 061, 147

AOC 003, 007, 033, 038, 039,

047, 048, 049, 133

Archer 007

Audiovox 007, 061

Bauer 155

Belcor 047

Bell & Howell 045, 118

Bradford 061

Brockwood 003, 047

Candle 003, 030, 031, 032, 038,

047, 049, 050, 122

Capehart 003

Celebrity 046

Circuit City 003

Citizen 029, 030, 031, 032, 034,

038, 047, 049, 050, 054,

061, 095, 122, 123

Concerto 031, 047, 049

Colortyme 003, 047, 049, 135

Contec 013, 051, 052, 061

Cony 051, 052, 061

Craig 004, 061

Crown 029

Curtis Mathes 029, 034, 038, 044, 047,

049, 053, 095, 118

Daewoo 027, 029, 039, 048, 049,

054, 055, 106, 107, 137

Daytron 003, 049

Dimensia 044

Dixi 007, 015, 027

Electroband 046

Electrohome 029, 056, 057, 058, 147

Elta 027

Emerson 029, 051, 059, 060, 061,

062, 118, 123, 124, 139,

148

Envision 038

Etron 027

Fisher 014, 021, 063, 064, 065,

118

Formenti 155

Fortress 012

Fujitsu 004, 062

Funai 004, 062

Futuretech 004

GE 020, 036, 037, 040, 044,

058, 066, 088, 119, 120,

125, 147

Goldstar 000, 015, 029, 031, 039,

048, 051, 056, 057, 067,

068, 069, 116

Grundy 062

Hitachi 029, 031, 051, 052, 070,

111, 112, 113, 124,

*[134]

Hitachi Pay TV 151

Infinity 017, 071

Janeil 122

JBL 017, 071

JC Penny 020, 034, 039, 040, 041,

044, 048, 050, 058, 066,

069, 076, 088, 090, 095,

125, 136, 159

JCB 046

JVC 019, 051, 052, 072, 073,

091, 117, 126

Kawasho 018, 046

Kenwood 038, 056, 057

Kloss 010, 032

Kloss Novabeam 005, 122, 127, 131

KTV 074, 123

Loewe 071

Logik 144

Luxman 031

LXI 008, 014, 017, 024, 040,

044, 063, 071, 075, 076,

077, 118, 125

ENGLISH

PRESET CODE

Magnavox 005, 010, 017, 030, 033,

038, 050, 056, 071, 078,

079, 085, 089, 108, 109,

110, 127, 131, 132, 145

Marantz 015, 017, 071, 080

Matsui 027

Memorex 014, 027, 045, 083, 118,

144

Metz 160, 161, 162, 163

MGA 001, 039, 048, 056, 057,

058, 065, 081, 083

Midland 125

Minutz 066

Mitsubishi 001, 016, 039, 048, 056,

057, 058, 065, 081, 082,

083, 105

Montgomery Ward

011, 020, 144, 145, 146

Motorola 121, 147

MTC 031, 034, 039, 048, 095

NAD 008, 075, 076, 128

National 002, 036, 061, 147

National Quenties

002

NEC 031, 038, 039, 048, 057,

084, 086, 135, 147

Nikko 054

NTC 054

Optimus 128

Optonica 011, 012, 093, 121

Orion 004, 139

Panasonic 002, 009, 017, 036, 037,

071, 141, 143, 147

Philco 005, 010, 030, 050, 051,

056, 079, 085, 127, 131,

132, 145, 147

Philips 005, 015, 017, 050, 051,

056, 078, 087, 088, 089,

131, 132, 147

Pioneer 124, 128, 142

Portland 054

Price Club 095

Proscan 040, 044, 125

Proton 035, 051, 092, 129

Pulsar 042

Quasar 036, 037, 074, 141

Radio Shack 011, 044, 063, 093, 118

RCA 040, 044, 125, 130, 137,

151, 152

Realistic 014, 063, 093, 118

Saisho 027

Samsung 003, 015, 034, 053, 055,

057, 094, 095, 136, 153

Sansui 139

Sanyo 013, 014, 021, 022, 063,

064, 081, 096

SBR 015

Schneider 015

Scott 062

Sears 008, 014, 021, 022, 023,

024, 025, 040, 052, 057,

062, 063, 064, 065, 073,

075, 076, 097, 098, 125,

159

Sharp 011, 012, 013, 026, 093,

099, 100, 104, 121

Siemens 013

Signature 045, 144

Simpson 050

Sony 043, 046, 138, 146, 150

Soundesign 030, 050, 062

Spectricon 007, 033

Squareview 004

Supre-Macy 032, 122

Supreme 046

Sylvania 005, 010, 017, 030, 078,

079, 085, 089, 101, 127,

131, 132, 145, 155

Symphonic 004, 148

Tandy 012, 121

Tatung 036, 124

Technics 037

Teknika 001, 030, 032, 034, 052,

054, 078, 083, 095, 144,

156, 157

Tera 035, 129

THOMSON 165, 166

Toshiba 008, 014, 034, 063, 075,

076, 095, 097, 136, 158,

159

Universal 020, 066, 088

Victor 019, 073, 126

Video Concepts 016

Viking 032, 122

Wards 005, 045, 066, 078, 085,

088, 089, 093, 102, 103,

131, 132, 148

Zenith 042, 114, 115, 140, 144,

149

Zonda 007

CABLE

ABC 006, *[007], 008, 009

Archer 010, 011

Century 011

Citizen 011

Colour Voice 012, 013

Comtronic 014

Eastern 015

Garrard 011

Gemini 030, 033, 034

General Instrument

030, 031, 032

Hytex 006

Jasco 011

Jerrold 009, 016, 017, 026, 032

Magnavox 018

Movie Time 019

NSC 019

Oak 000, 006, 020

Panasonic 001, 005

Philips 011, 012, 013, 018, 021

Pioneer 002, 003, 022

RCA 029

Regency 015

Samsung 014, 023

Scientific Atlanta 004, 024, 025

Signal 014

SL Marx 014

Starcom 009

Stargate 014

Teleview 014

Tocom 007, 016

TV86 019

Unika 011

United Artists 006

Universal 010, 011

Viewstar 018, 019

Zenith 027, 028

DBS (SATELLITE)

Alphastar 054

Chaparral 035, 036

Dishnet 053

Drake 037, 038

ENGLISH

PRESET CODE

Echostar Dish 062, 066

GE 048, 055, 056

General Instruments

039, 040, 041

Grundig 070, 071, 072, 073

Hitachi 058, 059

Hughes Network 063, 064, 065, 069

JVC 057

Kathrein 074, 075, 076, 083

Magnavox 060

Nokia 070, 080, 084, 085, 086

Philips 060

Primestar 051

Proscan 048, 055, 056

RCA 048, 055, 056, 068

Realistic 042

Sierra I036

Sierra II 036

Sierra III 036

Sony 049, 067

STS1 043

STS2 044

STS3 045

SRS4 046

Technisat 077, 078, 079, 081, 082

Toshiba 047, 050

Uniden 061

Denon *[111], 044

Aiwa 001, 035, 043

Burmster 002

Carver 003, 035

Emerson 004, 005, 006, 007

Fisher 003, 008, 009, 010

JVC 018, 019

Kenwood 011, 012, 013, 014, 017

Magnavox 006, 015, 035

Marantz 016, 028, 035

MCS 016, 024

Onkyo 025, 027

Optimus 017, 020, 021, 022, 023

Philips 014, 032, 033, 035

Pioneer 006, 022, 030

Sears 006

Sony 023, 031

Teac 002, 009, 028

Technics 016, 029, 036

Wards 035, 037

Yamaha 038, 039, 040, 041

Zenith 042

CDR

Denon *[111], 112

Philips 112

Denon 113

Kenwood 003, 004

Onkyo 007

Sharp 005

Sony 006

TAPE

Denon *[111]

Aiwa 001, 002

Carver 002

Harman/Kardon 002, 003

JVC 004, 005

Kenwood 006

Magnavox 002

Marantz 002

Onkyo 016, 018

Optimus 007, 008

Panasonic 012

Philips 002

Pioneer 007, 008, 009

Sony 013, 014, 015

Technics 012

Victor 004

Wards 007

Yamaha 010, 011

014111 (default)

DVD preset codes

DENON Model No.

DVD-555

DVD-755

DVD-900

DVD-910

DVD-955

DVD-1000

DVD-1200

DVD-1500

DVD-1710

DVD-1910

DVD-2200

DVD-2800

DVD-2800II

DVD-800

DVD-1600

DVD-2000

DVD-2500

DVD-3000

DVD-3300

DVD-2900

DVD-2910

DVD-3800

DVD-3910

DVD-5900

DVD-5910

DVD-9000

DVM-715

DVM-1800

DVM-1805

DVM-1815

DVM-2815

DVM-4800

*[ ] :Preset codes set upon shipment from the

factory.

ENGLISH

Denon Brand Company, D&M Holdings Inc.

Printed in China 00D 511 4494 002

TOKYO, JAPAN

www.denon.com

Denon Avr 787 Users Manual 1. AVR787E3_ENG 3rd

AVR-787 to the manual 3b44d8a3-17e5-95d4-8132-8d983d2a27cc

Navigation menu

Versions of this User Manual:

Views

Navigation
