Configureable Multi-tuner
• Dual AM/FM tuners pre-installed
• 6 independent audio outputs
• Independent 56 stations memory for each tuner
• Independent control for all six tuners
• Auto preset function
• Preset skip
• Station rename
• Front panel and IR lock mode
Plug n’ Play upgrade
• 4 expandable slots
• Simple plug n’ play upgrade
• Optional tuner cards will be available
Ethernet IP control
• WEB remote control and setup
• Firmware update capability
System control
• RS-232C port
• Remote in / out IR control
• Six +12V, 250mA trigger outputs and master
output
TU-604CI
Multi-Tuner
New model preliminary information
Expandable 6 Source Multi-Tuner
Dual Independent AM/FM tuners pre-installed with expansion slots for
up to 4 optional tuner cards.
Bullet points
ACD-AMFM
FM/AM Tuner Module
ACD-XM
XM Ready Module
ACD-HD
HD Radio Module
Optional Tuner Card
16940707 A
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
4
4
3
5
.
4
7
x
a
m
0
1
5
.
4
4
2
5
7
3
3
6
5
4
4
3
0
3
1
1
4
3
4
7
1
Denon Electronics (USA), LLC
100 Corporate Drive
Mahwah, NJ 07430, U.S.A.
www.usa.denon.com
FM Coax 75 ohms antenna
AM antenna
Optional tuner slot (Tuner 3 to 6)
2
2
4
Analog audio (Tuner 1 and 2)
Optional analog audio (Tuner 3 to 6)
Ethernet
RS-232C
Remote in/out
Trigger Out
(Tuner 1 to 6 and Master)
2
4
1
1
1
7
Tuner
OUT
Input / Output terminals
Specifications
General
Power supply AC 120 V, 60 Hz
Dimensions (WxHxD) 434 x 147 x 398 mm
17-3/32” x 5-25/32” x 15-21/32”
Weight 9.7 kg, 21.38 lbs
Control
• Design and specifications are subject to change without notice.
