6.User’s manual requirement
6.1.Operation manual
(1) Registration of the cellular phone
Transmits the registration signal from the cellular phone to the navigation system and register the
cellular phone at the navigation system.
(2) Selection of the cellular phone
Transmits the selection signal from the navigation system to the cellular phone and connect the
navigation system with the cellular phone.
(3) Call
Call by inputting the phone number with the touch sensitive panel installed in the navigation
system. Get the phone by operating the touch sensitive panel installed in the navigation system.
Bluetooth
RF signal
Bluetooth
RF signal
Bluetooth
RF signal
Cellular
RF signal
6.2.User’s Manual Requirement of FCC rule
BTA-01A is installed in the navigation system, so BTA-01A has no manual for user.
FCC user’s manual requirements that are FCC rule Part 15.21 and 15.105 are described on
user’s manual of the vehicle.
Fig 6.2. FCC rule requirement for user’s manual
FCC and RSS-210 Regulations
This device complies with Part 15of the FCC Rules and RSS-210 Rules
Operation is subject to the following two conditions :
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
FCC WARNING
: Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
