Denso DECS001 Electrostatic Capacity sensor User Manual Users manual
Denso Corporation Electrostatic Capacity sensor Users manual
Denso >
Users manual
Manual Requirement of FCC
Our product (DECS001) is one of vehicle parts, which is installed in the passenger seat.
We will supply the user’s manual that include statements and instructions in accordance with FCC requirements.
NOTE
This device compiles with Part 18 of the FCC Rules.
This device may cause interference.
If this device causes interference,
please consult the nearest
SUBARU dealer for maintenance of the system.
Black plate (65,1)
北米Model "A1120BE-A" EDITED: 2011/ 6/ 16
&SUBARU advanced frontal
airbag system
S01AH02
Your vehicle is equipped with a SUBARU
advanced frontal airbag system that com-
plies with the new advanced frontal airbag
requirements in the amended Federal
Motor Vehicle Safety Standard (FMVSS)
No. 208.
The SUBARU advanced frontal airbag
system automatically determines the de-
ployment force of the driver’s SRS frontal
airbag at the time of deployment as well as
whether or not to activate the front
passenger’s SRS frontal airbag and, if
activated, the deployment force of the
SRS frontal airbag at the time of deploy-
ment.
Your vehicle has warning labels on the
driver’s and front passenger’s sun visors
beginning with the phrase “EVEN WITH
ADVANCED AIR BAGS”and a tag
attached to the glove box lid beginning
with the phrase “Even with Advanced Air
Bags”. Make sure that you carefully read
the instructions on the warning labels and
tag.
Always wear your seatbelt. The SUBARU
advanced frontal airbag system is a
supplemental restraint system and must
be used in combination with a seatbelt. All
occupants should wear a seatbelt or be
seated in an appropriate child restraint
system.
The driver’s SRS frontal airbag is stowed
in the center portion of the steering wheel.
The front passenger’s SRS frontal airbag
is stowed near the top of the dashboard
under an “SRS AIRBAG”mark. Also, the
driver’s knee airbag is stowed in the
bottom of the steering column.
In a moderate to severe frontal collision,
the following components deploy.
.SRS frontal airbag for driver
.SRS frontal airbag for front passenger
.Knee airbag for driver
These components supplement the seat-
belts by reducing the impact to the
occupant’s head, chest and knees.
WARNING
NEVER INSTALL A REARWARD FA-
CING CHILD SEAT IN THE FRONT
SEAT. DOING SO RISKS SERIOUS
INJURY OR DEATH TO THE CHILD
BY PLACING THE CHILD’S HEAD
TOO CLOSE TO THE SRS AIRBAG.
WARNING
Never allow a child to stand up, or to
kneel on the front passenger’s seat.
The SRS airbag deploys with con-
siderable force and can injure or
even kill the child.
Seat, seatbelt and SRS airbags 1-39
–CONTINUED –
1
Black plate (66,1)
北米Model "A1120BE-A" EDITED: 2011/ 6/ 16
1-40 Seat, seatbelt and SRS airbags
WARNING
Never hold a child on your lap or in
your arms. The SRS airbag deploys
with considerable force and can
injure or even kill the child.
WARNING
The SRS airbag deploys with con-
siderable speed and force. Occu-
pants who are out of proper position
when the SRS airbag deploys could
suffer very serious injuries. Be-
cause the SRS airbag needs enough
space for deployment, the driver
should always sit upright and well
back in the seat as far from the
steering wheel as practical while
still maintaining full vehicle control
and the front passenger should
move the seat as far back as
possible and sit upright and well
back in the seat.
It is also important to wear your
seatbelt to help avoid injuries that
can result when the SRS airbag
contacts an occupant not in proper
position such as one thrown toward
the front of the vehicle during pre-
accident braking.
WARNING
.Do not put any objects over the
steering wheel pad and dash-
board. If the SRS frontal airbag
deploys, these objects could in-
terfere with its proper operation
and could be propelled inside the
vehicle, causing injury.
.Do not put any objects under the
driver’s side of the instrument
Black plate (67,1)
北米Model "A1120BE-A" EDITED: 2011/ 6/ 21
panel. If the knee airbag deploys,
those objects could interfere with
its proper operation and could be
propelled inside the vehicle,
causing injury.
.The key must not be attached to
heavy, sharp or hard acces-
sories, or another key. If the knee
airbag deploys, those objects
could interfere with its proper
operation and could be propelled
inside the vehicle and cause
injury.
WARNING
Do not attach accessories to the
windshield, or fit an extra-wide mir-
ror over the rear view mirror. If the
SRS airbag deploys, those objects
could become projectiles that could
seriously injure vehicle occupants.
!Driver’s SRS frontal airbag
S01AH0201
The driver’s SRS frontal airbag uses a
dual stage inflator. The inflator operates in
different ways depending on the severity
of impact.
Have the system inspected by your
SUBARU dealer immediately if the SRS
airbag system warning light illuminates.
NOTE
The driver’s SRS side airbag and SRS
curtain airbag are not controlled by the
SUBARU advanced frontal airbag sys-
tem.
!Front passenger’s SRS frontal air-
bag
S01AH0202
The front passenger’s SRS frontal airbag
uses a dual stage inflator. The inflator
operates in different ways depending on
the severity of impact.
The occupant detection system sensor is
installed under the seat upholstery and
monitors the position and posture of the
front passenger. Using this information,
the occupant detection system determines
whether the front passenger’s SRS frontal
impact airbag should be deployed or not.
The occupant detection system may not
inflate the front passenger’s SRS frontal
airbag even when the driver’s SRS frontal
airbag deploys. This is normal. In this
case, although the front passenger’s SRS
frontal airbag does not operate, the front
passenger’s seatbelt pretensioner oper-
ates with the driver’s seatbelt preten-
sioner. For details about the seatbelt
pretensioner, refer to “s01afFront seatbelt
pretensioners”F1-20.
Observe the following precautions. Failure
to do so may prevent the SUBARU
advanced frontal airbag system from
functioning correctly or cause the system
to fail.
.Do not apply any strong impact to the
front passenger’s seat.
.Do not spill liquid on the front passen-
ger’s seat. If liquid is spilled, wipe it off
immediately.
.Do not remove or disassemble the front
passenger’s seat.
.Do not install any accessory (such as
an audio amplifier) other than a genuine
SUBARU accessory under the front pas-
senger’s seat.
.Do not place anything (shoes, umbrel-
la, etc.) under the front passenger’s seat.
Seat, seatbelt and SRS airbags 1-41
–CONTINUED –
1
Black plate (68,1)
北米Model "A1120BE-A" EDITED: 2011/ 6/ 21
1-42 Seat, seatbelt and SRS airbags
.Do not place a magnet near the
seatbelt buckle.
If the seatbelt buckle switch and/or front
passenger’s occupant detection system
have failed, the SRS airbag system
warning light will illuminate. Have the
system inspected by your SUBARU deal-
er immediately if the SRS airbag system
warning light illuminates.
If your vehicle has sustained impact, this
may affect the proper function of the
SUBARU advanced frontal airbag system.
Have your vehicle inspected at your
SUBARU dealer. Do not use the front
passenger’s seat while driving the vehicle
to your SUBARU dealer.
NOTE
The front passenger’s SRS side airbag
and SRS curtain airbag are not con-
trolled by the SUBARU advanced fron-
tal airbag system.
!Passenger’s frontal airbag ON and
OFF indicators
S01AH0203
Refer to “s03ae03Front passenger’s frontal
airbag ON and OFF indicators”F3-11.
!Occupant detection system
S01AH0209
The occupant detection system sensor is
installed under the seat upholstery and
monitors the position and posture of the
front passenger. Using this information,
the occupant detection system determines
whether the front passenger’s SRS frontal
impact airbag should be deployed or not.
If the front passenger’s seat cushion is
wet, this may adversely affect the ability of
the system to determine deployment. If
the seat cushion is wet, the front passen-
ger should stop sitting on the front
passenger’s seat. Wipe off water from
the seat immediately, let the seat dry
naturally and then check the airbag warn-
ing light as follows.
.If the airbag warning light illuminates,
keep the seat dry until the warning light
turns off. If the airbag warning light stays
on even when the seat has dried, do not
allow anyone to sit on the front passen-
ger’s seat and have the system checked
by your SUBARU dealer.
.If the airbag warning light does not
illuminate, check that the airbag ON/OFF
indicator light works properly. If the in-
dicator light does not work properly, do not
allow anyone to sit on the front passen-
ger’s seat and have the system checked
by your SUBARU dealer.
Also, if luggage or electronic devices are
placed on the front passenger’s seat, this
may adversely affect the ability of the
system to determine deployment. This
may prevent the airbag ON/OFF indicator
light from working properly. Check that the
airbag ON/OFF indicator light works prop-
erly.
When the OFF indicator light turns off and
the ON indicator light illuminates, the front
passenger’s airbag may deploy during a
collision. Remove luggage and electronic
devices from the front passenger’s seat.
NOTE
This device compiles with Part 18 of
the FCC Rules. This device may cause
interference. If this device causes inter-
ference, please consult the nearest
SUBARU dealer for maintenance of
the system.
A copy of the original declaration of
conformity can be found in chapter 13.
!Conditions in which front passen-
ger’s SRS frontal airbag is not
activated
S01AH0204
The front passenger’s SRS frontal airbag
will not be activated when any of the
following conditions are met regarding the
front passenger’s seat:
.The seat is empty.
.The seat is equipped with a rearward
facing child restraint system and an infant
is restrained with it. (See WARNING that
follows.)
.The seat is equipped with a forward
Black plate (69,1)
北米Model "A1120BE-A" EDITED: 2011/ 6/ 16
facing child restraint system and a small
child is restrained with it. (See WARNING
that follows.)
.The seat is equipped with a booster
seat and a small child is in the booster
seat. (See WARNING that follows.)
.The seat is relieved of the occupant
load for a time exceeding the predeter-
mined monitoring time period.
.The seat is occupied by a child who
has outgrown a child restraint system
(See WARNING that follows.) or by a
small adult.
.The front passenger’s occupant detec-
tion system is malfunctioning.
WARNING
NEVER INSTALL A REARWARD FA-
CING CHILD SEAT IN THE FRONT
PASSENGER’S SEAT EVEN IF THE
FRONT PASSENGER’S SRS FRON-
TAL AIRBAG IS DEACTIVATED. Be
sure to install it in the REAR seat in
a correct manner. Also, it is strongly
recommended that any forward fa-
cing child seat or booster seat be
installed in the REAR seat, and that
even children who have outgrown a
child restraint system be also
seated in the REAR seat. This is
because children sitting in the front
passenger’s seat may be killed or
severely injured should the front
passenger’s SRS frontal airbag de-
ploy. REAR seats are the safest
place for children.
When the front passenger’s seat is occu-
pied by a child, observe the following
precautions. Failure to do so may increase
the load on the front passenger’s seat,
activating the front passenger’sSRS
frontal airbag even though that seat is
occupied by a child.
.Do not place any article on the seat
other than the child occupant and a child
restraint system.
.Do not place more than one child on
the seat.
!If the front passenger’s frontal air-
bag ON indicator illuminates and the
OFF indicator turns off even when
an infant or a small child is in a child
restraint system (including booster
seat)
S01AH020401
Turn the ignition switch to the “LOCK”
position if the front passenger’s frontal
airbag ON indicator illuminates and the
OFF indicator turns off even when an
infant or a small child is in a child restraint
system (including booster seat). Remove
the child restraint system from the seat. By
referring to the child restraint manufac-
turer’s recommendations as well as the
child restraint system installation proce-
dures in “s01agChild restraint systems”F1-
23, correctly install the child restraint
system. Turn the ignition switch to the
“ON”position and make sure that the front
passenger’s frontal airbag ON indicator
turns off and the OFF indicator illuminates.
If still the ON indicator remains illuminated
while the OFF indicator turns off, take the
following actions.
.Ensure that no article is placed on the
seat other than the child restraint system
and the child occupant.
.Ensure that the backward-forward po-
sition and seatback of front passenger’s
seat are locked into place securely by
moving the seat back and forth.
If the ON indicator still remains illuminated
while the OFF indicator turns off after
taking relevant corrective actions de-
scribed above, relocate the child restraint
system to the rear seat and immediately
contact your SUBARU dealer for an
inspection.
NOTE
When a child who has outgrown a child
restraint system or a small adult is
seated in the front passenger’s seat,
Seat, seatbelt and SRS airbags 1-43
–CONTINUED –
1
Black plate (70,1)
北米Model "A1120BE-A" EDITED: 2011/ 6/ 16
1-44 Seat, seatbelt and SRS airbags
the SUBARU advanced frontal airbag
system may or may not activate the
front passenger’s SRS frontal airbag
depending on the occupant’s seating
posture. If the front passenger’s SRS
frontal airbag is activated (the ON
indicator remains illuminated while
the OFF indicator turns off), take the
following actions.
.Ensure that no article is placed on
the seat other than the occupant.
If the ON indicator still remains illumi-
nated while the OFF indicator turns off
despite the fact that the actions noted
above have been taken, seat the child/
small adult in the rear seat and im-
mediately contact your SUBARU dealer
for an inspection. Even if the system
has passed the dealer inspection, it is
recommended that on subsequent trips
the child/small adult always take the
rear seat.
Children who have outgrown a child
restraint system should always wear the
seatbelt irrespective of whether the airbag
is deactivated or activated.
!Conditions in which front passen-
ger’s SRS frontal airbag is activated
S01AH0205
The front passenger’s SRS frontal airbag
will be activated for deployment upon
impact when any of the following condi-
tions are met regarding the front passen-
ger’s seat.
.When the seat is occupied by an adult.
.When a heavy article is placed on the
seat.
!If the passenger’s frontal airbag OFF
indicator illuminates and the ON
indicator turns off even when the
front passenger’s seat is occupied
by an adult
S01AH020501
This can be caused by the adult incor-
rectly sitting in the front passenger’s seat.
Turn the ignition switch to the “LOCK”
position. Ask the front passenger to set
the seatback to the upright position, sit up
straight in the center of the seat cushion,
correctly fasten the seatbelt, position his/
her legs out forward, and adjust the seat to
the rearmost position. Turn the ignition
switch to the “ON”position. If the OFF
indicator remains illuminated while the ON
indicator remains off, take the following
actions.
.Turn the ignition switch to the “LOCK”
position.
.Make sure that you do not use a
blanket, seat cushion, seat cover, seat
heater or massager, etc.
.If wearing excessive layers of clothing,
the front passenger should remove any
unnecessary items before sitting in the
front passenger seat, or should sit in a
rear seat.
.Next, turn the ignition switch to the
“ON”position and wait 6 seconds to allow
the system to complete self-checking.
Following the system check, both indica-
tors turn off for 2 seconds. Now, the ON
indicator should illuminate while the OFF
indicator remains off.
If the OFF indicator still remains illumi-
nated while the ON indicator remains off,
ask the occupant to move to the rear seat
and immediately contact your SUBARU
dealer for an inspection.
!How to contact the vehicle manu-
facturer concerning modifications
for persons with disabilities that
may affect the advanced air bag
system (U.S. only)
S01AH0208
Changing or moving any parts of the front
seats, rear seat, seatbelts, front bumper,
front side frame, radiator panel, instrument
panel, combination meter, steering wheel,
steering column, tire, suspension or floor
panel can affect the operation of the
SUBARU advanced airbag system. If
you have any questions, you may contact
the following SUBARU distributors.
<Continental U.S., Alaska and the District
of Columbia>
Black plate (71,1)
北米Model "A1120BE-A" EDITED: 2011/ 6/ 16
Subaru of America, Inc.
Customer Dealer Services Department
P.O. Box 6000
Cherry Hill, NJ 08034-6000
1-800-SUBARU3 (1-800-782-2783)
<Hawaii>
Servco Subaru Inc., dba Subaru Hawaii
2850 Pukoloa Street, Suite 202, Honolulu,
HI 96819
808-839-2273
<Guam>
Shen’s Corporation dba Prestige Automo-
bile
491, East Marine Drive, Route 1 Dededo,
Guam
671-633-2698
<Puerto Rico>
Trebol Motors
P.O. Box 11204, San Juan, Puerto Rico
00910
787-793-2828
There are currently no SUBARU distribu-
tors in any other U.S. territories. If you are
in such an area, please contact the
SUBARU distributor or dealer from which
you bought your vehicle.
!Operation
S01AH0207
A) Driver’s side
B) Passenger’s side
1) SRS AIRBAGs deploy as soon as a collision occurs.
2) After deployment, SRS AIRBAGs start to deflate immediately so that the driver’s vision is not
obstructed.
Seat, seatbelt and SRS airbags 1-45
–CONTINUED –
1
