Manual Requirement of FCC / IC
Our product (DNMWR001) is one of vehicle parts incorporated into the vehicle as the original equipment.
Therefore we will not supply the user’s manual and service manual of the product.
Although, we will request to describe on the vehicle user’s manual and service manual as following
statement accordance with FCC and IC requirement to the vehicle manufacturer.
1. Requirement to User Manual
1.1. FCC Requirement
1.1.1. Accordance with 15.21 of FCC rule, we will describe on the user’s manual as following
statement.
1.1.2. Accordance with FCC RF exposure of requirement, we will describe on the user’s manual as
following statement.
1.2. IC Requirement
1.2.1. Accordance with RSS-210 of requirement, we will describe on the user’s manual as following
statement.
2. Service manual
Accordance with SAR requirement of FCC rule, we will describe on the service manual as following
statement.
Operation is subject to the following two conditions;
(1) this device may not cause interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation of the device.
(3)
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC RF exposure Information
This device complies with the FCC RF exposure requirements.
Caution : Radio Frequency Exposure
This device comply with applicable FCC radio frequency exposure
regulations, must be adjusted with a distance of at least 20cm (7.9
inches) between the RF aperture of device and the body of any person
at all time during adjustment.
To : XXXXXXXXXXXXXXX
The following statements are FCC and IC requirement for user’s manual and service manual.
Therefore, the following statements must be described on user’s manual and service manual.
Please describe the following statements on your user’s manual and service manual.
1. Requirement statement for user’s manual requirement
1.1. FCC Requirement
1.2. IC Requirement
2. Requirement statement for service manual
Note ;
Above sheet is translated to English. In general, we will use Japanese version.
Above sheet is draft version, so some changes may be occurred. But information contents are not
changed.
Operation is subject to the following two conditions;
(1) this device may not cause interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation of the device.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC RF exposure Information
This device complies with the FCC RF exposure requirements.
Caution : Radio Frequency Exposure
This device comply with applicable FCC radio frequency exposure
regulations, must be adjusted with a distance of at least 20cm (7.9 inches)
between the RF aperture of device and the body of any person at all time
during adjustment.
3. Outline of operation and Service manual
Our product is one of vehicle parts incorporated into the vehicle as the original equipment. Therefore we
will not supply the user’s manual and service manual of the product.
We describe the operation and service method as followings.
- Operation
Our product will be stand-by radiating the radio frequency by vehicle ignition ON.
And the product will radiate radio wave by stepping on the vehicle’s accelerator.
- Service
Our product is adjusted the axis of RF beam as following steps.
1. For the adjustment of vertical RF beam axis
- The screw for vertical adjustment of Milli-wave radar sensor is turned by the wrench,
and the vertical angle of RF beam is adjusted.
2. For the adjustment of Horizontal RF beam axis
- The Ignition of vehicles is turned ON.
- The inspection equipment is connected to vehicle.
- Gap of a horizontal axis is checked according to the work procedure displayed on the
screen of inspection equipment.
- Based on an inspection result, a wrench turns and adjusts the right-and-left adjustment
screw of Milli-wave radar sensor.
