DF1 Manual
Description:
DF1 is a remote sensor device measuring 3-axis accelerations and communicating data via a
wireless connection to a base station.
It is intended as a development platform for a technical user, or someone who wants to learn more
about this technology. The user can read, record, and process data produced by the device via a
wireless connection. This connection can be made though any computer which supports the
Bluetooth 4.0 protocol.
Demo applications are available and can be installed on a iOS device supporting Bluetooth 4.0.
For more information please go to: http://devicefactory.com
Warning: This device is intended for adult use only, keep out of reach of children and pets.
Contents:
DF1 device
CR2032 Battery
Operation:
Install Battery:
Place device face down on a flat surface, FCC ID should be visible
Unscrew the Philips head fastener securing the battery door with a #1 driver
Do not remove any of the other Torx fasteners
Swing battery door open
Place CR2032 battery into the battery tray with positive (+) side facing up
Swing battery door closed
Secure battery door with Philips head fastener, do not over tighten fastener
Note: If the device is not going to be used for an extended period of time, please remove the
battery.
Connecting via iOS or Android device:
Demo application will be made available App stores
Search for Device Factory for available Apps
App source code is also available at http://github.com/devicefactory
Connecting via Linux or Mac OSX:
Standard programming techniques can be used to access the device
Your computer must support the Bluetooth 4.0 protocol
A Bluetooth 4.0 USB adapter can also be used
To list available devices use the following software tool: hcitool
To connect to the device you can use the following software tool : gattool
For more information please go to the following sites:
http://devicefactory.com
http://github.com/devicefactory
http://developer.apple.com
http://developer.android.com
Specifications:
Range: 160 feet (50 meters), line of sight
Battery: CR2032 3.0 volts
Battery Life: Up to 1 year, application dependent
Communication Protocol: Bluetooth Low Energy (Bluetooth Smart)
Operating Frequency: 2.400 GHz - 2.4835 GHz ISM band
Operating Temperature: 5F (-15C) to 150F (65C)
Safety:
Important safety instructions: Read and follow all instructions in this manual.
Do not attempt to open or tamper with the device.
Do not expose the device to any liquids.
Do not expose the device to extreme temperatures, high or low.
Do not allow children or pets to handle the device.
Components may present a choking hazard.
Device may contain substances that can damage the environment if handled and/or disposed
of improperly.
Device may contain substances that can damage human health if handled and/or disposed of
improperly.
Disposal:
Be kind to our environment. It is your responsibility to dispose of the device properly at its end of
life. Please contact your local government's waste management authority to locate a recycling drop
off point for electronic equipment and batteries.
Do not dispose of the device with household waste.
Device may contain a Lithium-Ion battery which may not be disposed of with household
waste.
Follow all local laws pertaining to waste disposal
Regulatory:
Federal Communications Commission (FCC) Statement
This device complies with FCC part 15 FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference and
2. This device must accept any interference, including interference that may cause undesired
operation of the device.
FCC Warning: Changes or modifications to the device could void the user’s authority to operate
the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver.
Consult the an experienced radio technician for help.
This device meets the FCC and IC requirements for RF exposure in public or uncontrolled
environments.
Cet appareil est conforme aux conditions de la FCC et IC en matière de RF dans des
environnements publics ou incontrôlée.
Canada: Industry Canada (IC) Statement
IC Notice to Users English/French in accordance with RSS GEN Issue 3:
This device complies with Industry Canada license exempt RSS standard(s).
Operation is subject to the following two conditions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operation of the device.
Cet appareil est conforme avec Industrie Canada RSS standard exempts de licence(s).
Son utilisation est soumise à Les deux conditions suivantes:
1. cet appareil ne peut pas provoquer d’interférences et
2. cet appareil doit accepter Toute interférence, y compris les interférences qui peuvent causer
un mauvais fonctionnement du dispositive
CAN ICES - 3 (B)/NMB – 3(B)
IC: 11777A-DF1
FCC ID: 2ABTJ-DF1
Device Ideas
Model: DF1
