DewertOkin P105820 RF1058 User Manual 1
DewertOkin GmbH RF1058 1
User Manual
Quick guide RF1058
08.07.2016 Id-Nr. 84624(-) 1 / 1
GB
For wireless operation of your motorized comfort bed system
Wireless, ergonomic, reliable, easy handling, elegant design
Activate the pairing mode at the CU170.
Example for a Pairing method:
1. Press the pairing button (a) at the CU170 2x until the LED turns on. You now have 20s for the pairing process.
2. Press button (1) and (19) of the RF1058 simultaneously. If the pairing LED or the LED set flashes 2x and a "Peep"
signal sounds the programming has been completed.
3. According to this method you can pair a second CU170 by using button (3) and (19).
Note: The distance between transmitter and receiver should be less than two meters for pairing.
Button Function
LED Function of massage
1 Drive M1 up (head)
2 Drive M3 up (lift)
3 Drive M2 up (foot)
4 Drive M1 down (head)
5 Drive M3 down (lift)
6 Drive M2 down (foot)
7 Drive M4 up (tilt)
9 Drive M4 down (tilt)
10 Head massage higher level
11 Massage on/off
12 Foot massage higher level
13 Head massage lower level
14 Massage wave
15 Foot massage lower level
16 Set memory
17 Under Bed Light on/off
18 Child safety lock on/off
19 Position Flat
20 Memory position Zero G
21 Memory position TV
1 + 19 Pairing System 1
3 + 19 Pairing System 2
13 + 15 Press + Release
16 + 19 Press + Hold
16 + 19 Reset memory position
a Slow
b Medium
c Fast
a
RF1058
CU170
11
2
19
5
7
10
13
16
1
4
17
3
6
9 14
12
15
18
20
21
a
b
c
