Kurzanleitung RF-TOUCHLINE / Quick guide RF-TOUCHLINE
12.09.2018 90855 1.0 1 / 2
Pairing RF-TOUCHLINE Pairing RF-TOUCHLINE
D
GB
Zur kabellosen Bedienung Ihres motorisierten Komfortbettes
Kabellos, ergonomisch, zuverlässig, einfache Bedienung, elegantes Design.
Aktivieren Sie den Pairing-Modus.
Pairing Methode
1. Verbinden Sie alle Komponenten mit dem Antriebssystem.
2. Stecken Sie den Stecker in die Steckdose.
3. Drücken Sie 2x die Pairing-Taste (a) bis die LED leuchtet. Der Pairing-Prozess ist
aktiv.
4. Drücken Sie gleichzeitig die Tasten (1) und (3) am Handsender, bis die LED
erlischt und die LED im Handsender dauerhaft leuchtet. Der Lernprozess ist
abgeschlossen.
5. Mit den Tasten (4) und (6) können Sie nach der gleichen Methode ein zweites
Antriebssystem zur Parallelfahrt von zwei Applikationen pairen.
Hinweis: Für den Pairing-Prozess sollte der Abstand zwischen Sender und
Empfänger weniger als zwei Meter betragen.
For wireless operation of your motorized comfort bed system
Wireless, ergonomic, reliable, easy handling, elegant design.
Activate the pairing mode.
Pairing method
1. Connect all components to the drive system.
2. Insert the plug into the socket.
3. Press the pairing button (a) 2x until the LED lights up. The pairing process is
active.
4. Press button (1) and (3) of the handset simultaneously until the LED switches off
and the LED on the handset glows constantly. The learning process is completed.
5. With buttons (4) and (6) you can pair a second drive system for parallel operation
of two applications using the same method.
Note: The distance between transmitter and receiver should be less than two
meters for pairing.
RF-TOUCLINE
Taste / Button Funktion Function
1 - 21 Kundenspezifisch Customer specific
1 + 3 Pairing (System 1) Pairing (System 1)
4 + 6 Pairing (System 2) Pairing (System 2)
FCC Warning / IC Warning
FCC: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: Any changes or modifications not approved by the party responsible for compliance could void the user's authority to operate the
equipment.
IC: This device complies with Industry Canada RSS-210 standard(s). Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device."
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio Exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement."
![](/img.php?id=4092232&img=bg2.png)
Kurzanleitung RF-TOUCHLINE / Quick guide RF-TOUCHLINE
13.09.2018 90855 1.0 2 / 2
Position der Pairing Taste / Position of the Pairing button
OKIMAT 2
HE150
Remote Control ECO / RF ECO BT
OKIMAT 4
HE-300
HE-300 SMPS
a a
a a
a
a
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
IC Warning
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le fonctionnement
