Diasonic Technology Co DL-60ISH LED DESK LAMP User Manual 60iSH60iS Cover Eng ai
Diasonic Technology Co Ltd LED DESK LAMP 60iSH60iS Cover Eng ai
Users Manual
DIASONIC TECHNOLOGY CO., LTD
#321-43, Suksu-dong, Manan-ku, An Yang-City, Kyung Ki-Do, Korea.
TEL : +82-(0)31-474-0852 FAX : +82-(0)31-474-0856
Audio Play & Charging
5V/500mA
USB mini B - Female (iPhone/iPod charging & USB 2.0)
Approx 1,100 Lux ·100 Lux
Longer than 40,000Hour
AC/DC adaptor : AC 100~240V to DC 12V/1.5A
9W for Lighting, 4W for Charging
180(W:Base) x 172(D:Base) x 455(H) x 328(L)
-10~40
MODEL
iPod & iPhone Application
Charging Current
USB Port
Audio
Color temp
CRI
Brightness
Life Time
Power
Power consumption
Dimension
Weight
Operating Temperature
DL-60iSH DL-60iS
L 1.2W + R 1.2W, Rotary Volume Control, Line in / Earphone Jack
1,160g 1,130g
Over 90 Over 75
SPECIFICATION
ඖ
G
For Repair or Service
If the product stops working correctly, discontinue its use and contact the listed service center in the manual or
DIASONIC Technology at 82-31-474-0852.
ඖ
G
Repair Policy
1. This product has passed strict quality control and testing process.
2. Failure of the product under normal operating conditions, during the warranty period may be repaired by Diasonic or our authorized
service organization free of charge. Some shipping or handling charges may be involved.
3. For the following cases, some service fees will be charged.
1) When the product is damaged due to user's mishandling, abuse, or improper operation.
2) When the product is damaged due to user's modification, attempted repair, or otherwise access to sealed/non-user serviceable items.
3) When the product is damaged due to fires, pollution, earthquakes and any other natural or unnatural conditions, accidents, etc.
4. It will be at the sole discretion of Diasonic or the authorized service center to determine the qualification of the warranty service.
Original purchase invoice and other documentation may be required to verify qualification of service.
Product : LED Desk Lamp
Model : DL-60iSH/60iS
Warranty Period : 1year
Purchase Date:
Purchaser
Name
Address
Telephone
Name
Address
Telephone
Seller
WARRANTY CARD
Study 6,000~7,000K
Reading 4,500~5,500K
Relaxation/Sleep 2,300~3,300K
5,800~6,800K
DESK
LAMP
DL-60iSH/DL-60iS
USER MANUAL
Thank you for purchasing DL-60iSH/60iS.
Please read instructions with care and operate DL-60iSH/60iS safely before use.
We'd like to recommend you to keep instructions to use DL-60iSH/60iS well.
̻G
Caution : Any changes or modifications in construction of this device which are not expressly approved by the
party responsible for compliance could void the user's authority to operate the equipment.
̻GNote :
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications,
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio / TV technician for help.
FCC (Federal Communications Commission)
Press the power button.
(60iSH Srzhu#Exwwrq)
Press the power button.
(60iS Srzhu#Exwwrq)
A. Light Stand including light
D. AC Adaptor
B. iPod cradle
E. Light Base
C. Control Button
INSTRUCTIONS
MULTI-PIVOT-FLEXIBLE POSITIONING
PRODUCT BOX CONTAINS
ADVANTAGE OF LED DESK LAMP
DL-60iSH (Operational Mode & Docking System)
Do not place at slanting place. Adjust height appropriately.
90¶
90¶
90¶
50¶
ඖG5 Step Brightness Control Function.
ඖGAppropriate color temperature for each subjects.
- Reading Mode (4,500K~5,500K) - Study Mode (6,000K~7,000K)
- Relaxation Mode (2,300K~3,300K) - Bedtime Mode (2,300K~3,300K)
ඖGTimer & Power Control Function.
ඖGBuilt in docking interface for Charging&Audio Play.
ඖGCompatible with all iphone and ipods.
ඖG1.2w X 2 output.
ECO-friendly light
It provides a safe, comfortable, consistent light that stimulates
concentration without eye strain. It contains no mercury or
environmentally harmful substances.
Low power consumption
It consumes 75% LESS power than a typical
fluorescent light.
Extraordinary Long lifetime
Lasting 40 TIMES LONGER than a typical incandescent bulb.
(Used 5 hours per day it will last up to 22 years)
Flicker Free Light
Reduced eye strain without the flickering present in
both incandescent and florescent lights.
ඖ USB ␜㣄㜄㉐ 5V(1A) 㢌 㤸㠄㡸 ḩἽ䚌㜠, 䚬☐䔤㢨⇌
MP3 ☥ 㜠⤠㦹⪌㢌 ὤὤ☘㡸 㻝㤸䀴㢨⽈⦐ 㻝㤸䚔 ㍌
㢼㏩⏼␘.
ඖ iPhone, iPod 㥐䖼㡸 ㏘䈔☐㜄 ⓸䇭䚐 ㇵ䈐㜄㉐ PC㝴
⒤㢨䇴 㤸㋕ ⵃ 㻝㤸㡸 䚔 ㍌ 㢼㏩⏼␘.
DL-60iS (Docking System)
ඖGTimer & Power Control Function.
ඖGBuilt in docking interface for Charging&Audio Play.
ඖGCompatible with all iphone and ipods.
ඖG1.2w X 2 output.
ඖ USB ␜㣄㜄㉐ 5V(1A) 㢌 㤸㠄㡸 ḩἽ䚌㜠, 䚬☐䔤㢨⇌
MP3 ☥ 㜠⤠㦹⪌㢌 ὤὤ☘㡸 㻝㤸䀴㢨⽈⦐ 㻝㤸䚔 ㍌
㢼㏩⏼␘.
ඖ iPhone, iPod 㥐䖼㡸 ㏘䈔☐㜄 ⓸䇭䚐 ㇵ䈐㜄㉐ PC㝴
⒤㢨䇴 㤸㋕ ⵃ 㻝㤸㡸 䚔 ㍌ 㢼㏩⏼␘.
