Dimplex North America 300032 Remote Controller User Manual DF3215 INSTRUCTIONS
Dimplex North America LTD Remote Controller DF3215 INSTRUCTIONS
Users Manual
FEDERAL COMMUNICATIONS COMMISSION
INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this
device could void
the user's authority to operate the equipment.
Remote display
U
p
button
Left Button
Flame ON/OFF button
FLAME ON/OFF BUTTON
Press the Flame On/Off button to turn the flame ON.
HEATER ON/OFF BUTTON
Press the Heater On/Off button to turn the heater
NOTE
A red indicator light will illuminate on the fireplace to indicate that the heater is ON.
NOTE
When the flame and/or the heater are ON, the unit will turn OFF when both control buttons
are pressed at the same time.
SLEEP TIMER
1. Set the sleep timer to the length of time you want the unit to operate by pressing the
sleep timer button.
NOTE
The sleep timer can be set from 30 minutes to 8 hours.
2. Pressing the sleep timer button repeatedly will increase the sleep timer by 30 minute
increments.
3. Press the flame button and/or the heater button to turn the unit ON.
4. The fireplace will automatically turn OFF when the sleep timer reaches 0 minutes.
5. The sleep timer can be reset by pressing the sleep timer button repeatedly until the
sleep timer display disappears and the room temperature display is shown.
SET CLOCK
1. Press the ENTER button until the middle display flashes.
2. Use the direction buttons on the hand held remote to move the cursor to the clock
and press the ENTER button.
3. A day of the week will flash.
4. Use the left or right button to set the day of the week.
Right
button
Down
button
Sleep timer
button
Heater ON/OFF button
Enter button
Occupancy
Sensor
Set temperature
Day of week
Room temperature Time of da
y
Ambient Light
Sensor
Batteries
5. Press the up button and the hour display will flash.
6. Use the left or right button to set the hour.
7. Press the up button and the minute display will flash.
8. Use the left or right button to set the minute.
9. Press ENTER to return to the main menu.
SET °F OR °C
1. Press the ENTER button until the middle display flashes.
2. Use the direction buttons on the hand held remote to move the cursor to and press
ENTER.
3. Use the left or right button to toggle between °F and °C.
4. Press ENTER to select °F or °C.
FLICKERING FIRELIGHT
1. Press the flame button to turn the flame ON.
2. Press the ENTER button until the middle display flashes.
3. Use the direction buttons on the hand held remote to move the cursor to and press
ENTER.
4. Press the up button to turn the flickering top lights ON.
5. Press ENTER to return to the main menu.
NOTE
To turn the flickering lights OFF repeat steps 1 to 3 and then press the down button.
FLAME SPEED
1. Press the flame button to turn the flame ON.
2. Press the ENTER button until the middle display flashes.
3. Use the direction buttons on the hand held remote to move the cursor to and press
ENTER.
4. Repeatedly press the left or right arrow keys to change the flame speed.
NOTE
The bar graph located on the top of the screen displays the speed range of the flame
motor.
5. Press ENTER to return to the main menu.
LIGHT DIMMER
1. Press the flame button to turn the flame ON.
2. Press the ENTER button until the middle display flashes.
3. Use the direction buttons on the hand held remote to move the cursor to and press
ENTER.
4. Repeatedly press the left or right arrow keys to change the brightness of the upper
lights.
NOTE
The bar graph located on the top of the screen displays the upper light brightness range.
AMBIENT LIGHT SENSOR
When the room gets darker the upper lights dim allowing for a more intense and realistic
flame effect.
1. Press the flame button to turn the flame ON.
2. Press the ENTER button until the middle display flashes.
3. Use the direction buttons on the hand held remote to move the cursor to and press
ENTER.
4. Press the up button to turn the ambient light sensor ON.
5. Press ENTER to return to the main menu.
NOTE
To turn the ambient light sensor OFF repeat steps 1 to 3 and then press the down button.
SLOW START/FADING EMBERS
If the slow start function is being used at start up then the fading embers function will
automatically be programmed at shut down.
1. Press the ENTER button until the middle display flashes.
2. Use the direction buttons on the hand held remote to move the cursor to and press
ENTER.
3. Press the left or right button to select 1, 5, or 10 minutes.
NOTE
When the timer is set to 1, 5, or 10 minutes it determines the length of time over which the
embers will fade upon turning the unit OFF.
NOTE
The slow start function timer is automatically programmed for 1 minute. This timer setting
cannot be changed.
4. Press the up button to turn the slow start/fading embers function ON.
5. Press ENTER to return to the main menu.
6. Press the flame on/off button to activate slow start.
NOTE
When turning the unit OFF and the slow start/fading ember function is ON, the slow
start/fading ember indicator will flash.
OCCUPANCY SENSOR
The occupancy sensor function can be programmed to turn the fireplace ON when it
detects movement. The occupancy sensor is programmed to turn the fireplace OFF when
it doesn’t detect movement in 5, 10, or 20 minutes. The occupancy sensor has a range of
10 feet.
1. Press the ENTER button until the middle display flashes.
2. Use the direction buttons on the hand held remote to move the cursor to and press
ENTER.
3. Press the left or right button to 5, 10, 0r 20 minutes.
4. Press the up button to turn the occupancy sensor ON.
5. Press ENTER to return to the main menu.
NOTE
To turn the occupancy sensor OFF repeat steps 1 to 3 and then press the down button.
CHILD LOCK
1. Press the ENTER button until the middle display flashes.
2. Use the direction buttons on the hand held remote to move the cursor to and press
ENTER.
3. Press and hold the up button for 4 – 5 seconds. The will flash when the child lock
function has been turned ON.
4. To turn the child proof function OFF, hold the down arrow key for 4 – 5 seconds.
PURIFIRE
1. Press the ENTER button until the middle display flashes.
2. Press the ENTER button on the purifire function.
3. Press the left of right button to select LOW or HIGH.
4. Press the up button to turn the purifire ON.
5. Press ENTER to return to the main menu.
NOTE
To turn the purifire OFF repeat steps 1 to 3 and then press the down button.
