DATA SHEET
![](/img.php?id=1183429&img=bg2.png)
THE LATEST EPOP
IN THE RANGE –
PROVIDING COMPLETE
CONTROL THROUGHOUT
THE STORE
EPOP 300
DATA SHEET
EPOP FUNCTIONALITY:
• Compact size enables wide usage throughout a retail environment
• Provides truly dynamic content at the point of purchase
• Wireless communication requires no infrastructure to implement
• Patented bistable e-paper display uses zero power between updates
• Based on typical usage of five updates a day the EPOP has a
five year battery life
• Excellent viewing angle
• Multiple page storage
• Strong visual impact under all lighting conditions
• Durable and hygienic
• Plastics all approved for food use
• Water resistant with an IP64 rating
• Shock resistant and tamper proof
• Provides 100% accurate price and promotional content
• Optional promotional colour available
TECHNICAL DATA EPOP 300:
DIMENSIONS
Overall Size (WxHxD) 112 x 57 x 9 (15) mm
Display
Viewable Area (WxH) 94 x 30mm
Presentation Monochrome
Pixel Dimensions 0.211 x 0.211mm
Pixel Shape Square
Pixel Pitch 0.231 x 0.231mm
Pixel Density 110dpi
Aspect Ratio 5:2
Aperture Ratio 84.9%
Contrast Ratio >25:1 typical
Reflectance 40% typical
Viewing Angle
- Vertical 110° typical
- Horizontal 110° typical
Display Update Time 750ms@25°C
typical
Multiple Page
storage capability 3 pages
COMMUNICATIONS
Frequency Band 868-915Mhz
unlicensed ISM band
Modulation GFSK modulation
Encoding Manchester encoding
Tx Power 10dBm (5mW ERP)
Rx Sensitivity -100dBm@0.1%BER
Data Rate 25kbps
Antenna Internal 1/4 wave
dipole (0db gain)
Range
- Free air >200m typical
- In building >100m typical
(100,000 sq feet)
POWER
Supply Voltage 2.7 to 3.3v
Standby Current 3µA typical
Active Current 30mA typical
Battery Type Lithium Manganese
Dioxide
Battery Life >5 years typical
ENVIRONMENT
Operating Temperature 0 to +40°C
Storage Temperature -20 to +70°C
