datasheet
epaper for retail
¢ Dynamic price, promotion and
product information
¢ Instant response to competitor
activity
¢ Unlimited consumer information
¢ Brand logos and messaging
¢ Synchronize pricing and
promotions with web channels
¢ Cross-sell and up-sell capability
¢ Improved store operational
efciencies
¢ Provision of staff information –
planograms; replenishment
instructions
¢ No maintenance of paper price
tags or sticky paper labels
epaper for retail
ZBD’s epaper solution combines
high-denition zero-power, bistable
LCD displays with a communications
capability that can wirelessly update
individual displays, a store oor, or an
entire retail enterprise, without impact
on existing infrastructure.
The epop 50 is the smallest display in
ZBD’s product range at just 70mm x
32mm (2.75” x 1.26”) and is designed
for mass-market and fmcg installations:
convenience store, large-scale grocery,
pharmaceutical and small-ticket
products throughout specialty.
¢ Simple to install, integrate
and maintain
¢ Unrivaled contrast and visibility:
super-bright, paper-like
¢ Low touch communications
¢ Low total cost of ownership
¢ Self-installation capability
The epop 50 is part of ZBD’s
total store solution and really is
‘plug and go’.
The ease of use and extraordinary
reliability of ZBD’s technology provides
retailers with a solution to automate
customer communication, prices and
promotions: virtually maintenance-free
and without the need for expensive and
unreliable infrastructure.
The epop 50’s wireless capability
puts a fantastic tool into retailers’
hands: the ability to change any
product-related information anywhere,
any time.
“ ZBD’s solution was the
natural choice for our new
‘ON’ store… the system
has been extremely easy
to implement and it’s very
easy to use.”
Matt Ranta
Marketing Manager, Vann’s Inc.
External: 70mm x 32mm (2.75” x 1.26”)
Visible screen area: 53mm x 24mm (2.1” x 0.94”)
Full graphic epaper image
20,160 pixels @ 111 dpi
Bistable (no power required to retain image indenitely)
High-contrast black/white
Landscape or Portrait
Supports scannable barcodes
3 pages/display screens in memory
Multi-Page switching. At least 95% of an entire
store can switch pages in less than 10 seconds
Update throughput: c.6000 updates per hour,
per Bounce Communicator (depending on
image density).
10,000 – 20,000 updates per hour with multiple
Bounce Communicators.
Background update mode:
Any page can be updated at any time
Standard operating temperature range
32 to 104°F (0 to 40°C)
Storage temperature range -4 to 158°F
(-20 to 70°C)
Water-resistant
5 year battery life
(up to 10 years with extended options)
Supported by multiple shelf-edge ranges –
individual clips and long-length strip options
Range of additional specialized ttings available.
Full ZBD Catalog on request.
Standard unit is available with transparent front
and gray rear. White, color and graphic print
options on application
Unit identier barcode on rear and on front
(vertical orientation)
868Mhz or 915MHz ISM Band 2-way wireless
Standard ZBD Bounce Communications
The ZBD architecture couldn’t be
simpler. Data is managed by the Bounce
Processor taking feeds from any
combination of local or remote sources.
Data can be hosted or managed locally.
Formatted images are sent wirelessly to
epops via the Bounce Communicator,
a single, small transmitter/receiver (for
a typical store), positioned in the store
or back ofce.
ZBD also supports integration via XML
or API interface toolset.
The epop 50 has been designed to
provide all the features required for
complete in-store automation, handling
multiple sets of information on
different pages with the capability to
switch instantly between them
as required.
Formed in 2000 out of QinetiQ, the
inventors of LCD technology in the
1970’s, ZBD is a pioneering company
with its own R & D, full IPR and scalable
manufacturing processes that enable
it to deliver an epaper solution with
practical commercial advantages for
retailers.
ZBD is a leader in the design and supply
of electronic shelf labels and associated
software solutions for the retail industry.
The company has developed the
next generation of LCD, creating
high-contrast bistability that requires
no battery power to retain its image.
Its epaper product portfolio provides
retailers with a total store solution
and the ability to manage and update
pricing, product and promotional
information at point of purchase,
dynamically.
ZBD Displays Ltd, 10024 Skokie Blvd, Suite 205, Skokie, IL 60077 USA
+1 (888) ZBD-4-EPOP contact@zbdsolutions.com www.zbdsolutions.com
© 2011 ZBD Displays Ltd. ZBD and Bounce are registered trademarks of ZBD Displays Ltd
ZBD-EPOP-50-v1e-050111
Bounce
Communicator
Data from current IT
systems including:
Merchandising and
category management
Marketing, CRM,
affinity analysis
Retail management system
Inventory management
Operations
Pricing
Pricing promotions
Procurement
Retail systems Deployment
epop 500
epop 300
epop 50 epop 55
“We found that the ZBD system was not only the best
looking product, but its light touch infrastructure and
low total cost of ownership made it the only choice
for us.” Dr Maurizio Cattaruzza
IT Manager
Coop Nordest
