VC130-1
DIGITAL MULTIMETER VERSION 09/14
Nº 1090519
Robust upcoming unit with manual Measuring range selection. VOLTCRAFT offers something for every user and scope of
the appropriate device. From beginners up to the professional model, always on the current state of the art and the usual
price. The VC100 series is designed for all measurement tasks in the household and the leisure sector. Even professional
tasks can be performed up to 250 V.
HIGHLIGHTS
CAT III 250 V //
2000 counts //
Standard measurement ranges
V/DC, V/AC, A/DC //
Resistance //
Diode tester //
Acoustic continuity checker //
Contactless AC voltage checker //
hFE-transistor test (with optional adapter) //
Hold function //
Low battery display //
Sturdy housing with soft
rubber protection //
VOLTCRAFT® - TOP PERFORMANCE IN EVERY WAY
“For more than 25 years, our product range has been dynamically adapting to the constant changes in the industry. We
commit to offering first-class quality to our customers while delivering an excellent cost-performance ratio. This philosophy
remains the cornerstone of Voltcraft’s success.”
TECHNICAL DATA
Display 2000 counts (4000 counts with the VC170-1)
Measuring frequency approx. 2-3 measuring operations/second
Measuring lead length about 75 cm each
Measuring impedance >10MΩ (V range)
Operating voltage 9 V block battery
Working conditions g 0°C to 40°C max. 75% rF, non-condensin
Operating altitude max. 2,000 m
Storage temperature -10°C to +50°C
Weight ca. 200 g
Dimensions (LxWxH) 137 x 72 x 35 (mm)
Measuring category CAT III 250 V
Degree of contamination 2
Direct voltage, overload protection 250 V
Range
VC130-1/150-1
Accuracy Resolution Range
VC170-1
Accuracy Resolution
200 mV
±(0.5 % + 8)
0.1 mV 400 mV* ±(0.8% + 8) 0.1 mV
2000 mV 1 mV 4000 mV
±(0.8% + 8)
1 mV
20 V 0.01 V 40 V 0.01 V
200 V 0.1 V 250 V 0.1 V
250 V ±(0,8 % + 8) 1 V * With the VC170-1, the 400 mV measuring range is only
available via the manual measuring range selection.
Alternating voltage (40 – 400 Hz), overload protection 250 V, Average recording for sinus signal.
Range
VC130-1/150-1
Accuracy Resolution Range VC170-
1
Accuracy Resolution
200 V ±(1.5 % + 8) 0.1 V 400 mV* ±(2.0% + 10) 0.1 mV
250 V 1 V 4000 mV
±(1.6% + 4)
1 mV
40 V 0.01 V
250 V 0.1 V
* With the VC170-1, the 400 mV measuring range is only
available via the manual measuring range selection.
Direct current, overload protection 1A/250V + 10 A/250 V
Range
VC130-1/150-1
Accuracy Resolution Range
VC170-1
Accuracy Resolution
200 µA*
±(1.3 % + 2)
0.1 µA 400 µA±(1.3 % + 2) 0.1 µA
2000 µA 1 µA 4000 µA 1 µA
20 mA 0.01 mA 40 mA ±(1.6 % + 2) 0.01 mA
200 mA ±(1.5 % + 8) 0.1 mA 400 mA 0.1 mA
10 A ±(2.5 % + 10) 0.01 A 4 A ±(2.0 % + 10) 0.01 A
* only with the VC130-1 10 A 0.1 A
Alternating current (only with VC170-1), overload protection 1A/250V + 10 A/250 V, Average recording for sinus signal.
Range (40 - 400 Hz) Accuracy Resolution
400 µA±(1.6 % + 5) 0,1 µA
4,000 µA 1 µA
40 mA ±(2.0 % + 8) 0.01 mA
400 mA 0.1 mA
4 A ±(2.6 % + 4) 0.001 A
10 A 0.01 A
Resistance, overload protection 250 V, test voltage ca. 0.5 V
Range
VC130-1/150-1
Accuracy Resolution Range VC170-1 Accuracy Resolution
200 Ω
±(1.0 % + 10)
0.1 Ω400 Ω ±(1.6 % + 3) 0,1 Ω
2000 Ω1 Ω4 kΩ
±(1.3 % + 2)
0.001 kΩ
20 kΩ0.01 kΩ40 kΩ0.01 kΩ
200 kΩ0.1 kΩ400 kΩ0.1 kΩ
20 MΩ ±(1.3 % + 7) 0.01 MΩ4 / 40 MΩ ±(2.0 % + 8) 0.001 / 0.01 MΩ
Temperature (only VC150-1)
Range Accuracy Resolution
-40 to 0 °C ±(10.4 % + 7)
1 °C>0 to 400 °C ±(3.3 % + 4)
>400 to 1000 °C ±(3.9 % + 4)
Frequency/duty cycle (only with VC170-1), overload protection 250 V
Range Accuracy Resolution
10 Hz - 10 MHz
max. 10 Vrms ±(0.7% + 4)
0.01 Hz - 0.01 MHz
Sensitivity:
< 100 kHz = 300 mV
> 100 kHz = 600 mV
0.1 – 99.9% 0.1%
Acoustic continuity tester <10 Ω Permanent sound
Diode test test voltage Uo 3.0 V
Diode overload protection/continuity tester: 250 V
Transistor test “hFE” 0 – 1000ß, test voltage Uce 3 V, test current Ibo 10 µA
NCV voltage test 230 V/AC
PACKAGE CONTENT
Digital multimeter // Measurement lines // Battery // Operating instructfions
