CASEVision™/ClearCase
Quick Reference Guide
Document Number 007-2395-001
CONTRIBUTORS
Written by John Posner
Production by Gloria Ackley
Engineering contributions by Atria Software, Inc.
© Copyright 1994, Silicon Graphics, Inc.— All Rights Reserved
© Copyright 1994, Atria Software, Inc.— All Rights Reserved
This document contains proprietary and confidential information of
Silicon Graphics, Inc. The contents of this document may not be
disclosed to third parties, copied, or duplicated in any form, in whole
or in part, without the prior written permission of Silicon Graphics,
Inc.
RESTRICTED RIGHTS LEGEND
Use, duplication, or disclosure of the technical data contained in this
document by the Government is subject to restrictions as set forth in
subdivision (c) (1) (ii) of the Rights in Technical Data and Computer
Software clause at DFARS 52.227-7013 and/or in similar or successor
clauses in the FAR, or in the DOD or NASA FAR Supplement.
Unpublished rights reserved under the Copyright Laws of the
United States. Contractor/manufacturer is Silicon Graphics, Inc.,
2011 N. Shoreline Blvd., Mountain View, CA 94039-7311.
Silicon Graphics and IRIS are registered trademarks and IRIX is a
trademark of Silicon Graphics, Inc. ClearCase and Atria are
registered trademarks of Atria Software, Inc. OPEN LOOK is a
trademark of AT&T. UNIX is a trademark of AT&T Bell
Laboratories. Sun, SunOS, Solaris, SunSoft, SunPro, SPARCworks,
NFS, and ToolTalk are trademarks or registered trademarks of Sun
Microsystems, Inc. OSF and Motif are trademarks of the The Open
Software Foundation, Inc.FrameMaker is a registered trademark of
Frame Technology Corporation. Hewlett-Packard, HP, Apollo,
Domain/OS, DSEE, and HP-UX are trademarks or registered
trademarks of Hewlett-Packard Company. PostScript is a trademark
of Adobe Systems, Inc. X Window System is a trademark of the
Massachusetts Institute of Technology.
iii
Contents
cleartool Subcommands............................................................... 1
ClearCase Commands................................................................... 3
Non-Command Manual Pages...................................................... 4
Basic cleartool Commands........................................................... 5
Building Software with clearmake ............................................... 7
Configuring Views with Config Specs......................................... 9
ClearCase Query Language........................................................ 10
Report-Writing with –fmt............................................................. 11
ClearCase Graphical Interface.................................................... 13
Group File Syntax................................................................. 14
xclearcase Preselectors and Macros.................................. 15
xclearcase Built-In Function Calls...................................... 18
cleartool Subcommand Syntax.................................................. 19
Non-cleartool Command Syntax................................................ 25
ClearCase Directory Tree Structure........................................... 26
Basic System Administration Commands ................................ 27
Glossary ....................................................................................... 29
Customer Information................................................................ 30
CASEVision/ClearCase Quick Reference Guide 1
cleartool Subcommands
*command appears in Basic cleartool Commands section
✝command appears in Basic System Administration Commands section
See page 19 for syntax summaries of these commands.
*✝annotate annotate lines of text file with timestamps
* apropos extract manual page summaries, glossary definitions
* catcr display configuration record
* catcs display config spec
* cd change current working directory
* checkin create permanent new version of an element
* checkout create view-private, modifiable copy of a version
chevent modify comment string in existing event record
✝chpool change the storage pool to which an element is assigned
✝chtype change the type of an element / rename a branch
*✝describe describe an object
* diff compare files or versions of an element
* diffcr compare configuration records
* edcs edit config spec
* find select objects from a directory hierarchy
* findmerge determine what files require a merge (and perform merge)
* help help on cleartool command usage
ln create VOB hard link or VOB symbolic link
✝lock lock an object
*ls list VOB-resident objects and view-private objects
* lscheckout list checkouts of an element
* lsdo list derived objects
* lshistory list history of an element or other object
✝lslock list locks
✝lspool list storage pools
* lsprivate list view-private objects
✝lsreplica list VOB replicas
✝lstype list type objects
*✝lsview list view registry entries
*✝lsvob list VOB registry entries
* lsvtree list version tree of an element
* man display a ClearCase manual page
* merge merge versions of an element
*✝mkattr attach an attribute to an object
✝mkattype create an attribute type object
✝mkbranch create a new branch in the version tree of an element
✝mkbrtype create a branch type object
* mkdir create a directory element
*✝mkelem create a file or directory element
✝mkeltype create an element type object
✝mkhlink attach a hyperlink to an object
✝mkhltype create a hyperlink type object
*✝mklabel attach a version label to a version
✝mklbtype create a label type object
✝mkpool create a storage pool or modify its scrubbing parameters
2 CASEVision/ClearCase Quick Reference Guide
✝mktag create a view-tag or VOB-tag
mktrigger attach a trigger to an element
mktrtype create a trigger type object
*✝mkview create and register a view
*✝mkvob create and register a versioned object base (VOB)
*✝mount activate a VOB
mv move or rename an element or VOB link
✝protect change permissions or ownership of an object
✝protectvob change owner or groups of a VOB
pwd print working directory
pwv print working view
quit quit interactive cleartool session
✝recoverview recover a view database
✝reformatview update the format of a view database
✝reformatvob update the format of a VOB database
✝register create an entry in the VOB or view registry
reserve convert a checkout to reserved status
✝rmattr remove an attribute from an object
✝rmbranch remove a branch from the version tree of an element
rmdo remove a derived object from a VOB
✝rmelem remove an element from a VOB
✝rmhlink remove a hyperlink from an object
✝rmlabel remove a version label from a version
rmmerge remove a merge arrow from versions
*✝rmname remove the name of an element or VOB symbolic link from
a directory
✝rmpool remove a storage pool from a VOB
✝rmtag remove a VOB-tag or view-tag from the tag registry
rmtrigger remove a trigger from an element
✝rmtype remove a type object from a VOB
✝rmver remove a version from the version tree of an element
✝rmview remove a view storage directory
✝rmvob remove a VOB storage directory
rnpool rename a VOB storage pool
rntype rename a type object
* setcs set the config spec of a view
* setview create a process that is set to a view
shell create a subprocess to run a shell or other program
space report on VOB disk space usage
*✝startview start or connect to a view_server process
✝umount deactivate a VOB
* uncheckout cancel a checkout of an element
✝unlock unlock an object
✝unregister remove a VOB or view from the object registry
unreserve change a checkout to unreserved status
* winkin wink-in a derived object
* xdiff compare files or versions of an element graphically
* xlsvtree display an element’s version tree graphically
* xmerge merge versions of an element graphically
CASEVision/ClearCase Quick Reference Guide 3
ClearCase Commands
clearaudit audited shell facility; create derived objects without
clearmake
clearbug create problem report for Atria Customer Support
clearcvt_ccase copy or move ClearCase data to a different VOB
clearcvt_dsee convert dsee files/elements to ClearCase
clearcvt_rcs convert rcs files to ClearCase
clearcvt_sccs convert sccs files to ClearCase
clearcvt_unix convert unix files to ClearCase
cleardiff compare or merge files
clearlicense report on status of Atria product licenses
clearmake maintain, update, and rebuild groups of programs
clearprompt prompt for user input
cleartool ClearCase user-level commands (character interface)
export_mvfs export/unexport MVFS file systems to NFS clients
init.d/atria ClearCase start/stop script (IRIX-5, SunOS-5, OSF/1)
mvfscache control and monitor MVFS caches
mvfslog set or display MVFS console error logging level
mvfsstat list MVFS statistics
mvfsstorage list data container pathname for MVFS file
mvfstime list MVFS timing statistics for a command
mvfsversion list MVFS version string
rc.atria ClearCase start/stop script (HPUX-9, SunOS-4)
rgy_passwd set the VOB-tag registry password
scrubber clean VOB storage pools; run from root crontab
view_scrubber delete DO data containers from view storage
vob_scrubber clean events in VOB database; run weekly by root
crontab
xclearcase ClearCase graphical user interface
xcleardiff compare or merge files graphically
xlsvtree display an element’s version tree graphically
4 CASEVision/ClearCase Quick Reference Guide
Non-Command Manual Pages
General
Building Software
System Administration
Graphical Interface (xclearcase)
ClearCase Servers
config_record bill-of-materials for clearmake build or audited shell
config_spec rules to filter element versions for a view
ct_funcref summary of cleartool commands
ct_permissions access permissions for cleartool commands
derived_object file built by clearmake; has an associated CR
env_ccase ClearCase environment variables
errorlogs_ccase ClearCase error log files
events_ccase ClearCase operations and event records
fmt_ccase format strings for cleartool command output
makefile_ccase target description file for clearmake builds
pathnames_ccase pathname resolution and extended namespace
query_language ClearCase query language syntax and usage
type_manager programs for managing element data
user_profile cleartool user profile
version_selector ClearCase version selector syntax
view view storage directory description
vob VOB storage directory description
wildcards_ccase pattern-matching characters for pathnames
bldhost build hosts file; lists hosts for use by clearmake –J
bldserver.control controls a host’s use as a distributed build server
clearmake.options build options specification file
makefile_ccase target description file for clearmake builds
bldhost build hosts file; lists hosts for use by clearmake –J
bldserver.control controls a host’s use as a distributed build server
cc.magic ClearCase file typing rules
config_ccase ClearCase configuration files
crontab_ccase ClearCase crontab scripts
ct_permissions access permissions for cleartool commands
env_ccase ClearCase environment variables
errorlogs_ccase ClearCase error log files
exports_ccase list of VOBs for access by non-ClearCase hosts
license.db ClearCase network-wide license database
registry_ccase ClearCase registries for VOBs and views
softbench_ccase ClearCase Encapsulation for SoftBench
tooltalk_ccase ClearCase Encapsulation for ToolTalk
type_manager programs for managing element data
cc.icon ClearCase icon database
cc.magic ClearCase file typing rules
schemes X Window System resources
abe audited build executor (started as req’d by clearmake)
albd_server
db_server
vob_server
vobrpc_server
location broker daemon; starts other servers
VOB database server
VOB data storage server
VOB database server
promote_server derived object data storage server
view_server server process for a view
db_dumper dump VOB database (invoked by reformatvob)
db_loader load VOB database (invoked by reformatvob)
lockmgr database access arbitrator
CASEVision/ClearCase Quick Reference Guide 5
Basic cleartool Commands
Getting On-Line Help
Creating a Private VOB
Working with Views and Config Specs
Working with File and Directory Elements
display ClearCase
manual page cleartool man command
extract data from whatis
database for ClearCase cleartool apropos [–glossary]string | 'regexp'
display cleartool
subcommand syntax cleartool help cleartool-command
1) create VOB mount point
2) create the VOB
3) mount the VOB
mkdir mount-over-dir
cleartool mkvob –tag VOB-tag VOB-storage-dir
cleartool mount VOB-tag
list registered views cleartool lsview "pattern"
create a new view cleartool mkview –tag view-tag storage-dir
set an existing view cleartool setview view-tag
check the working view cleartool pwv
activate a view cleartool startview view-tag
display the current config
spec cleartool catcs
set config spec to default cleartool setcs –default
set config spec to a file cleartool setcs file-of-config-rules
edit current config spec cleartool edcs
checkout a file cleartool checkout element-pathname
cleartool co element-pathname
checkin a file cleartool checkin element-pathname
cleartool ci element-pathname
cancel a checkout cleartool uncheckout element-pathname
cleartool unco element-pathname
list checked-out files cleartool lsco [–all][–long][–cview]pathname
convert a file
to an element
1) cleartool co .
2) cleartool mkelem view-private-file
3) cleartool ci .
create a directory element 1) cleartool co .
2) cleartool mkdir newdir
3) cleartool ci .
copy data from another
view to current directory cp /view/view-tag/full-pathname .
list files and directories cleartool ls [–short][pathname ]
display an element’s
version tree cleartool lsvtree element-pathname
cleartool xlsvtree element-pathname
remove an element name
from a directory version
1) cleartool co /vobs/src
2) cleartool rmname /vobs/src/foo.c
3) cleartool ci /vobs/src
create a branch cleartool mkbranch branch1 foo.c
label a version cleartool mklabel LABEL1 foo.c
attach an attribute to an
object cleartool mkattr Tested '"Yes" ' foo.c
cleartool mkattr TestLevel 3 foo.c
change checkin comment cleartool chevent –c "add lib.h" \
foo.c@@/main/23
6 CASEVision/ClearCase Quick Reference Guide
Comparing and Merging Elements
Working with Derived Objects (DOs)
and Configuration Records (CRs)
Examining and Describing ClearCase Objects
Using View-Extended Pathnames
(see pathnames_ccase manual page)
Use a view-extended pathname to access a version that is visible in another
active view.
Using VOB-Extended Pathnames
(see pathnames_ccase and version_selector manual pages)
Use extended naming to access a version of an element that is not visible in
your current view. Use a VOB-extended name to access any specific branch
or version of any element.
compare version with
preceding version cleartool [x]diff –pred pathname
find elements that
need to be merged
into versions in
your view
cleartool findmerge dir-names [ –whynot ] \
{ –ftag view-tag | –fver version-selector | –flatest } \
–print
merge changes
cleartool [x]merge –to target-version other-versions
cleartool findmerge dir-name
{–ftag view-tag | –fver version-selector | –flatest } \
{–[x]merge | –[x]okmerge | –exec cmd | –ok cmd }
DO-ID format: lib.o@@14–Sep.09:54.418
/vobs/proj/src/util.o@@03–Jan.23.33.8989
display CR contents cleartool catcr [–flat][–recurse] lib.o
compare CRs cleartool diffcr lib.o \
lib.o@@14–Apr.10:43.7465
list DOs cleartool lsdo [–stime][–me]
cleartool lsdo [–zero][–long] lib.o
display an element’s
version tree cleartool [x]lsvtree element-pname
list event history cleartool lshistory [–minor][–all][element-pname]
list DOs cleartool lsdo DO-IDs
describe an object cleartool describe [–long]objects
list view-private
objects cleartool lsprivate [–tag view-tag]
examine annotated
version of a text file cleartool annotate –out – –rm –long filename
list registered views cleartool lsview 'pattern'
list registered views cleartool lsvob [–host hostname]
/view/view-tag/full-pathname
/view/mainview/vobs/src/util.c
element util.c@@
branch util.c@@/main/rel_3.2_branch
version util.c@@/main/4 version-ID
util.c@@/REL3 version label
util.c@@/main/gopher_port/LATEST special label
derived object util.o@@14–May.16:10.3546 DO-ID
hyperlink Merge@1234@/vobs/src hyperlink-ID
CASEVision/ClearCase Quick Reference Guide 7
Building Software with clearmake
clearmake Command-Line Syntax
Command-Line Options (see clearmake manual page)
Environment variables read by clearmake
(see clearmake and env_ccase manual pages)
clearmake [ –f makefile ... ] [ –ukinservdp ] [ –OTFUVMN ]
[–C mode ] [ –J num ] [ –A BOS-file ] ... [ macro=value ] ...
[target_name ] ...
–f file without –f, search for makefile, then Makefile
–u unconditionally rebuild all targets on command line
–k quit failed entry; continue on targets that don’t depend on it
–i ignore error codes returned by commands
–n no execute; just list scripts for targets that need rebuilding
–s silent
–e environment variables override macros in makefile
–r ignore built-in rules in /usr/atria/etc/builtin.mk
–v verbose
–d debug
–p list all target descriptions and all macro definitions
–C mode compatibility mode: sgismake,sgipmake,sun,gnu,std
–O compare only names and versions (not build scripts or build
options)
–T disable configuration lookup; rebuild based on time-modified
stamps
–F like –T, but also suppress CR creation
–U unconditional build for goal targets, but not subtargets
–V disable wink-ins from other views; restrict configuration lookup
to this view
–M check makefile dependencies only
–J num set maximum concurrency level;
num=1 means “distributed, but serial”
–N disable default BOS file processing per clearmake.options
–A spec-file add to or replace (combine with –N) default BOS files; see also
clearcase_bld_options_specs and clearmake.options
makeflags clearmake command options with no
arguments
clearcase_bld_audit_tmpdir temporary workspace (default: /tmp)
clearcase_bld_conc concurrency level; overridden by –J
clearcase_bld_host_type build hosts file in home directory:
.bldhost.$clearcase_bld_host_type
clearcase_bld_options_specs colon-separated list of BOS files
(use with –A)
clearcase_bld_shell_flags options passed to build script subshell
clearcase_bld_verbosity umask for newly created DOs
clearcase_bld_umask 0=default 1=–v2=–d;
clearcase_make_compat compatibility mode; overridden by –C
8 CASEVision/ClearCase Quick Reference Guide
Parallel Building
(see bldhost and bldserver.control manual pages)
Makefile Usage (see makefile_ccase manual page)
Build Options Spec (BOS) Files
(see clearmake.options manual page)
Configuration Records (see config_record manual page)
Internal Macros (see clearmake manual page)
Other Important Macros (see clearmake manual page)
start parallel build 1. Set clearcase_bld_host_type
2. Create build hosts file in your home directory
3. Use –J to set maximum concurrency level
target/
dependency line
target ... : [dependency ... ][ar-lib(object-module) ... ]
NOTE: VOB-extended and view-extended
pathnames are not allowed; wildcards are allowed in
targets and dependencies
make macro definition macro=string
make macro
expansion:
$(macro) or $(macro:str1=str2)
NOTE: Macros are allowed anywhere in makefile;
EVs are allowed in build scripts only
macro assignment macro_name = string
target-list := macro_name = string
macro_name :sh= shell-command
special targets
.no_config_rec: tgts
.no_cmp_script: tgts
.no_wink_in: tgts
.no_cmp_non_mf_deps: tgts
include file facility include BOS-file
sinclude BOS-file
examine derived
object’s config rec cleartool catcr options derived-object-identifier ...
$* (inference rule only) filename (no suffix) of inferred dependency
$@ full target name of current target
$< (inference rule only) filename of implicit dependency
$? (explicit makefile rule only) out-of-date dependencies list
$$@ (target/ dependency line only) filename of current target
$% (library target only) target object module in library
makefile (top-level makefile only) current makefile or most recently
parsed makefile
vpath colon-separated list of directory search paths for
targets
clearcase_bld_umask set DO permissions (“002” recommended)
CASEVision/ClearCase Quick Reference Guide 9
Configuring Views with Config Specs
Standard Config Spec Rule
Standard Rule (see config_spec manual page)
Special Rules
Sample Config Spec
scope pattern version-selector [optional-clause ]
NOTE: Rule must occupy a single physical line (no backslash continuation).
scope
element
element –file
element –directory
element –eltype element-type
pattern
* *.c *[0–5].h any ClearCase wildcard; see
wildcards_ccase man page)
src/util.c any util.c element in any directory
named src
/vobs/incl/util.h full pathname of an element
src/.../util.c any util.c element under any src directory
src/.../*.[ch] any .c or .h element under any src directory
src/... all file/dir elements in any src subtree
Restrictions: No view-extended pathnames; relative pathname
must start below VOB-tag; full pathname must be in some VOB.
version-
selector
CHECKEDOUT checked-out version in your view
.../bugfix/3 version-ID (branch/version-number)
.../bugfix/REL2 branch pathname and version label
REL3 version label
/main/LATEST most recent version on element’s
principal branch
{QA_level>3} query
{Tested == "Yes"} query
Special version-selectors:
–config do-pathname [ –select do-leaf-pattern ] [ –ci ]
–none
–error
optional-
clause
–nocheckout
–mkbranch branch-type
–time date-time (affects latest versions only)
date-time:= date.time |date |time | now
date:= day-of-week |long-date
day-of-week:= today | yesterday | Sun | ... | Sat
long-date:= d[d]–month[–[yy]yy]
month:= January | ... | December | Jan | ... | Dec
time:= h[h]:m[m][:s[s]] (24–hour format)
time date-time (see –time above)
include config-spec-pathname
work on bugfix branch, based on
rel2 version label
element * CHECKEDOUT
element * .../bugfix/LATEST
element * REL2 –mkbranch bugfix
10 CASEVision/ClearCase Quick Reference Guide
ClearCase Query Language
Aquery reports names of elements, branches, versions, and/or VOB links.
Query in Version-Selector
Query in find and findmerge subcommands
Query Primitives
Logical Operators
A version-selector query must be enclosed in braces { ... }. It matches the
most recent version on the specified branch. If no branch is specified, it
matches a most recent version on any branch.
cleartool
subcommand with
–version option
cleartool describe –version \
'/main/{attype(QAlvl)}' util.c
config spec rule .../rel2.1/{QAlvl==5}
version-extended
pathname
cat util.c@@/{hltype(published_article.12,<–)}
NOTE: A branch pathname and a query cannot both
be used in a version-extended pathname.
find:
–element, –branch,
and –version options
cleartool find –avobs –version 'QAlvl==5’ –print
cleartool find . –ver \
'created_by(ann) && hltype(spec,<–)' –ok \
'cleartool mklabel –nc SPEC $clearcase_xpn'
findmerge:
–element option cleartool findmerge /vobs/src \
-element 'created_by(drp)' -merge
attribute with specified value on objectattr-type compare-op value
compare-op:== != < <= > >=
attribute with specified value on object
or subobject attr_sub(attr-type,compare-op,value)
attribute on object attype(attr-type)
attribute on object or subobject attype_sub(attr-type)
object associated with branch of
particular type brtype(branch-type)
user who created object created_by(login-name)
creation time created_since(date-time)
(see page 9 for date-time syntax)
element of particular type eltype(element-type)
has hyperlink of particular type hltype(hlink-type)
hltype(hlink-type, –>)
hltype(hlink-type, <–)
has particular version label lbtype(label-type)
version label on object or subobject lbtype_sub(label-type)
select elements with merge arrow merge(from-location,to-location)
select elements assigned to pool pool(pool-name)
select elements with particular
attached triggers trtype(trigger-type)
select version(s) version(version-selector)
() !<<=>>= =!= && ||
higher precedence lower precedence
CASEVision/ClearCase Quick Reference Guide 11
Report-Writing with –fmt
Conversion Specification Syntax
Keyletters and Modifiers
Escape Sequences
%[min][.max][modifier-chars]keyletter
%n name of object
%En
%Ln
%Sn
%Vn
%Xn
%PVn
%PS
element name
leaf name
short name
version-ID
extended name
predecessor’s version-ID
predecessor’s short name
%c comment string from object’s event record
%Nc comment string without trailing <nl>
%d date-time
%Sd
%Vd
%DAd
%MAd
%BAd
%OAd
(short) date only
(very long) day of week, date, and time
age in days
age in months
age as a bar graph (longer bar = more recent)
age as a bar graph (longer bar = older)
%h hostname, as reported by uname -n
%l (“el”) labels: parenthesized, comma-separated list
%Cl
%Nl field width spec = max number of labels to display
space-separated list — no commas or parentheses
%a attributes: comma-separated list of attr=value pairs
%Sa
%Na
%[attype]a
value only (instead of attr=value)
space-separated list — no commas or parentheses
attribute name only — no value
%m object kind (element, branch, version, label type, etc.)
%e event kind (“create version”, “destroy element”, etc.)
%u user login name
%Fu
%Gu
%Lu
user’s full name
user’s group name
user-ID.group-ID
%o operation kind (see events_ccase manual page)
%% percent character
\t
\n
\nnn
\’
\\
tab
newline
octal character code
single-quote character
backslash character
12 CASEVision/ClearCase Quick Reference Guide
Field-Width Specifier Rules
Examples
A single number is interpreted as a minimum width (for example, %8En)
To supply only a maximum width, precede the number with a decimal point
(%.10En) or with a zero and decimal point (%0.10En).
To specify a constant display width, set the minimum and maximum widths
to the same value (%20.20c).
Values shorter than the specified minimum width are right justified. A
negative minimum width value (%–20.20c) left justifies short values.
Values longer than the specified maximum width are truncated from the
right. A negative maximum width value (%15.–15Sn) truncates long values
from the left.
A maximum width specifier has special meaning when used with %Cl. For
example, %.5Cl prints a version's first five labels only, followed by ... .
cleartool lshistory \
–fmt "OBJ–NAME: %–20.20n\tCOMMENT: %c\n" foo.c
cleartool annotate –fmt "%Sd %–8.8u | " foo.c
cleartool lshistory \
–fmt '%d %Fu (%u@%h)\n %e "%n"\n "%Nc”\n’ util.c
CASEVision/ClearCase Quick Reference Guide 13
ClearCase Graphical Interface
Commands
Configuration
Basic Pointer Actions
Menu Navigation
xclearcase start ClearCase graphical user interface
xcleardiff compare or merge files graphically
xlsvtree compare or merge files graphically
clearprompt prompt for user input
cc.icon ClearCase icon database
cc.magic ClearCase file typing rules
schemes X Window System resources
select item click leftMouse
select region drag leftMouse
extend-select
(discontiguous) <Ctrl>-leftMouse
extend-select (range)
(for textual, not
graphical, dir list) <Shift>-leftMouse
display “pop-up help”
for an enabled menu
item
Toolbar: rightMouse on button
other menus: click leftMouse to post menu, then
rightMouse over item
change working
directory
doubleClick on directory icon
or
edit directory text input box
List directory history press
display pop-up menu rightMouse in browser
exit xclearcase Exit option on File menu
post (“pin up”) a pull-
down menu;
...using mnemonic
(underlined char)
click leftMouse on menu
or
AltKey-mnemonicChar
cycle through posted
menu options upArrow
downArrow
post submenu mnemonicChar
or
rightArrow
cycle through menus
left-to-right rightArrow
leftArrow
Invoke highlighted
menu item
<Return>
or
<Space>
14 CASEVision/ClearCase Quick Reference Guide
Group File Syntax
scope-declaration
RootMenu menu-name
{
item-definition
item-definition
}
Menu submenu-name
{
item-definition
item-definition
}
Scope browserClass [,browserClass ]... :menuType [,menuType]...
pulldown |popup |toolbar
List
Pool
*
String
Username
Viewtag
Vob
File Attype
Brtype
Eltype
Hltype
Lbtype
Trtype
Vtree
Fast
listBrowserClass
label [bitmaps ][mnemonic ][preselect-clause ][&]function [f.help "text"]
f.exec %QUOTE% script %QUOTE%
f.menu submenu-name
f.separator
@unarmed [,armed [,insensitive ]]
_character
%PNAME[](restrictions)
%ATTYPE[](restrictions)
%VOBTAG[](restrictions)
%VIEWTAG[](restrictions)
f.call "built-in-function"
Run in background
no brackets: select exactly one
[] select one or more
[n]select exactly n
[n+]select n or more
[n-m]select between n and m
f.alias "aliased-menu-item"
...
Scope File:pulldown
Scope Vtree:toolbar
Scope Fast:pulldown
Scope *:popup
if toolbar
button
not
pushed
one or
more
submenus
optional
if toolbar
button
pushed
if toolbar
button
greyed-
out
see page 18 ☛
see page 15
CASEVision/ClearCase Quick Reference Guide 15
xclearcase Preselectors and Macros
For preselect-count syntax, see page 14. Arguments lines include argument
name, set of possible values, and default (if any).
%ATTYPE[ preselect-count ]( restrictions ) preselector
%ATTYPE[]( prompt,restrictions,pname-in-VOB,keyboard ) macro
(also: %BRTYPE, %ELTYPE, %HLTYPE, %LBTYPE, %TRTYPE)
Prompt for one or more attribute, branch, element, hyperlink, label, or
trigger types
prompt character string for user prompt Select xxx type(s)
restrictions active or lock or obsolete any type object
pname-in-vob pathname in any VOB VOB containing working dir
keyboard enable not enabled
%DIR( ) macro
Return the pathname of the current browser’s directory
no arguments
%ELEMENT( pathnames ) macro
Strip any ClearCase annotations from pathnames, leaving standard
pathname
pathnames any pathname(s)
(non-element pathnames are returned unchanged)
%ELEMSUFFIX( pathnames ) macro
Append extended naming symbol (@@) to pathnames
pathnames any pathname(s)
(non-element pathnames are returned unchanged)
%HYPERLINK[ preselect-count ]( ) preselector
%HYPERLINK[]( prompt,browser ) macro
Prompt for one or more hyperlink objects
prompt character string for user prompt
browser vtree or vtree element-pname
%LIST[ preselect-count ]( ) preselector
%LIST[]( prompt,title ) macro
Prompt for data from a named list browser
prompt character string for user prompt
title title of list browser to use
%LISTOUT( title,class,persistence,width,height ) macro
Redirect output to a list browser (named or unnamed)
title character string
class character string class of active browser
when macro invoked
persistence transient browser stays up
until user closes it
width 1-32 (window width in inches) 8
height 1-32 (window height in inches) 4
%MOUNT( pathnames ) macro
Return the VOB mount points (VOB-tags) of specified pathnames
pathnames any pathname(s) within one or more VOBs
16 CASEVision/ClearCase Quick Reference Guide
%NAME( ) macro
Return the name associated with the current browser
no arguments
%PNAME[ preselect-count ]( restrictions ) preselector
%PNAME[]( prompt,restrictions,browser,keyboard ) macro
Prompt (with file or vtree browser) for one or more pathnames
prompt character string for user prompt Select pathname(s)
restrictions dir or ndir don’t care
elem or nelem don’t care
dobj or ndobj don’t care
invob or ninvob don’t care
checkout or ncheckout don’t care
reserved or nreserved don’t care
browser file or file dir-pname file browser prompts for
or file in current directory
vtree or vtree element-pname
keyboard enable not enabled
%POOL[ preselect-count ]( ) preselector
%POOL[]( prompt,pname-in-vob,keyboard ) macro
Prompt for one or more storage pool names
prompt character string for user prompt
pname-in-vob pathname in any VOB VOB containing working dir
keyboard enable not enabled
%RELATIVE( pathnames,dir ) macro
Convert full or relative pathnames into pathnames relative to directory
pathnames any pathname(s)
dir directory to which the converted pathnames are to be relative
%REMOVE( var-name ) macro
Delete a persistent temporary variable created with %SAVE
var-name name of temporary variable
%RESTORE( var-name ) macro
Retrieve the value of a temporary variable created with %SAVE
var-name name of temporary variable
%SAVE( var-name,string,persistence ) macro
Save string into named temporary variable (see also %RESTORE)
var-name name of temporary variable
string character string to be stored in variable
persistence keep variable removed afte
this f.exec completes
%SELECTION( ) macro
Return the current data selection(s) from the current browser
no arguments
%SETVIEW( pathnames ) macro
Convert pathnames to view-extended pathnames, based on the
current set view
pathnames any pathname(s)
%SORT( pathnames ) macro
Sort pathnames
pathnames any pathname(s)
CASEVision/ClearCase Quick Reference Guide 17
%STRING[ preselect-count ]( ) preselector
%STRING[]( prompt,default ) macro
Prompt for one or more text lines
prompt character string for user prompt Enter string
default character string; pre-fills text input area
%TEXTOUT( title,default-text,width,height ) macro
Redirect standard output to read-only text-display window
title title of text browser
default-text character string
width 1-32 (window width in inches) 8
height 1-32 (window height in inches) 4
%TMPFILE( ) macro
Create a temporary file and return its pathname
no arguments
%USERNAME[ preselect-count ]( ) preselector
%USERNAME[]( prompt,keyboard ) macro
Prompt for one or more usernames
prompt character string for user prompt Select user name(s)
keyboard enable not enabled
%VERMOD( pathnames ) macro
Convert standard pathnames to version-extended pathnames
pathname any pathname(s)
(non-element pathnames are returned unchanged)
%VIEWTAG[ preselect-count ]( restrictions ) preselector
%VIEWTAG[]( prompt,restrictions,keyboard ) macro
Prompt for one or more view-tags
prompt character string for user prompt Select viewtag(s)
restrictions active or inactive don’t care
keyboard enable not enabled
%VOBTAG[ preselect-count ]( restrictions ) preselector
%VOBTAG[]( prompt,restrictions,keyboard ) macro
Prompt for one or more VOB-tags
prompt character string for user prompt Select vobtag(s)
restrictions mounted or nmounted don’t care
keyboard enable not enabled
%WHICH( path-ev,filename ) macro
Search specified path for the first occurrence of filename
path-EV any environment variable that stores a directory search path
(typically, grp_path)
filename Any valid file name (a shell script or executable)
%WILD( pathnames ) macro
Expand wildcards in pathnames
path-expr pathname with one or more of these wildcard characters:
~ *?
18 CASEVision/ClearCase Quick Reference Guide
xclearcase Built-In Function Calls
xxtype pname bring up type browser for VOB identified by pname
close close current browser
file directory-pname bring up file browser on directory-pname
file_disp_date enable/disable size and date modified display
file_disp_owner enable/disable owner and permissions display
file_disp_rule enable/disable config spec rule display
file_disp_type enable/disable object type information display
file_disp_version enable/disable version information display
file_sort_by_checkout enable (disable by-rule and by-type)/disable sort-
by-checkout for file system objects in file browser
file_sort_by_rule enable (disable by-checkout and by-type)/disable
sort-by-rule for file system objects in file browser
file_sort_by_time enable/disable “minor” sort-by-time
file_sort_by_type enable (disable by-rule and by-checkout)/disable
sort-by-type for file system objects in file browser
force force update of current browser
graphic disable/enable graphic (icon) display mode
keyboard enable/disable the keyboard input box for the
current browser
list_delete_selected delete selected items from current list browser
pool pname bring up pool browser on VOB identified by
pname
print output-pname
[ pagesize ] [ scale ]
send PostScript image of vtree to output-pname
pagesize :=
a0 | a1 | a2 | a3 | a4 | a5 | letter | legal
scale := scale_to_page | percentScalingFactor
percentScalingFactor := integer; default = 100
quit quit xclearcase
setview view-tag set process’s current working view to view-tag
showtrans bring up the transcript pad
type_disp_active enable/disable display of active objects
type_disp_locked enable/disable display of locked objects
type_disp_obsolete enable/disable display of obsolete objects
update
update any browsers marked for update — by
default, browsers are updated when a GUI
command completes, or whenever 15 seconds
elapse without any GUI activity
username bring up username browser
viewtag bring up view-tag browser
vobtag bring up VOB-tag browser
vtree element-pname bring up vtree browser on element-pname
vtree_disp_all_label enable/disable all labels display
(if disabled: max=5)
vtree_disp_all_ver
enable/disable display of all versions
(if disabled: show “significant” versions only —
branch points, labeled versions, and hyperlink
endpoints)
vtree_disp_checkout enable/disable display of checked-out versions
vtree_disp_merge enable/disable merge arrow display
CASEVision/ClearCase Quick Reference Guide 19
cleartool Subcommand Syntax
annotate [–all | –rm][–rmfmt format][–nco][–out [dir–]pname]
[–short | –long | –fmt format[,hdr-format[,elide-format]]]
[–nheader][–ndata | –force]pname ...
catcr [–recurse | –flat | –union | –check [–union]| –makefile]
[–select do-leaf-pattern][–ci][–type {f|d|l}...]
[–element_only][–view_only][–name tail-pattern]
[–zero][–wd][–nxname][–long | –short]do-pname ...
catcs [–tag view-tag]
cd [dir-pname]
checkin | ci [–keep | –rm][–from source-pname][–cr][–ptime]
[–identical][–c comment | –cq | –cqe | –nc]pname ...
checkout | co [–reserved | –unreserved][–branch branch-pname]
[[–out dest-pname]| –ndata]
[–c comment | –cq | –cqe | –nc]pname ...
chevent [–c comment |–cq |–cqe |–nc][–append |–insert |–replace]
{–event [–vob pname–in–vob]event-selector ...
|–eltype | –brtype |–attype | –hltype | –lbtype | –trtype |
–rptype}[–vob pname-in-vob]type-name ...
|–pool [–vob pname-in-vob]pool-name ...
|–vreplica [–vob pname-in-vob] replica-name ...
|–hlink hlink-selector ...
|–vob pname-in-vob
|pname ... }
chpool [–force][–c comment | –cq | –cqe | –nc]pool-name pname ...
chtype [–force][–c comment | –cq | –cqe | –nc]type-name pname ...
describe [–long | –short | –fmt format]
{[–cview][–version version-selector |–ancestor]
[–aattr {attr-type-name[, ...] | –all}]
[–ahlink {hlink-type-name[, ...] | –all}]
[–alabel {label-type-name[, ...] | –all}]
[–predecessor]pname ...
|–type [–vob pname-in-vob]type-name ...
|–pool [–vob pname-in-vob]pool-name ...
|–vreplica [–vob pname-in-vob] replica-name ...
|–hlink hlink-selector ...
|–vob pname-in-vob
}
diff [–tiny | –window][–serial_format | –diff_format | –columns n]
[–options "pass-through-opts"][–predecessor]pname ...
diffcr [–recurse | –flat][–select do-leaf-pattern][–ci]
[–type {f | d | l }...][–element_only][–view_only][–wd]
[–name tail-pattern][–nxname][–long | –short]do-pname do-pname
edcs [–tag view-tag][pname]
find pname ... [–name 'pattern'][–depth][–follow][–nrecurse][–cview]
[–user login-name][–group group-name][–type { f | d | l}...]
[–nxname][–element query][–branch query][–version query]
{–print | –exec command-invocation | –ok command-invocation } ...
find [pname ...] –all [–visible | –nvisible]find-options
find –avobs [–visible | –nvisible]find-options
Environment variables set by find (for use in –exec or –ok commands):
CLEARCASE_PN element pathname
CLEARCASE_PN element pathname
CLEARCASE_XN_SFX extended naming symbol (@@ by default)
CLEARCASE_ID_STR pathname of branch, or version ID (no @@)
CLEARCASE_XPN version-extended pname of branch or version
20 CASEVision/ClearCase Quick Reference Guide
findmerge {–avobs | pname ... | [pname ...] –all}
{–ftag view-tag | –fversion version-selector | –flatest}
[–depth][–follow][–nrecurse][–name 'pattern']
[–type { f | d | fd }][–user login-name][–group group-name]
[–visible][–element query][–nzero][–nback][–whynot]
[–c checkout_comment | –cq | –cqe | –nc]
[–abort | –qall][–serial][–log log_pname]
{ –print [–long | –short | –nxname] |
{–merge | –okmerge} | {–xmerge | –okxmerge} |
–exec command-invocation | –ok command-invocation } ...
Environment variables set by findmerge (for use in –exec or –ok commands):
CLEARCASE_PN element pathname
CLEARCASE_XN_SFX extended naming symbol (@@ by default)
CLEARCASE_ID_STR version-ID of "to" version
CLEARCASE_XPN version-extended pathname of "to" version
CLEARCASE_F_ID_STR version-ID of "from" version
CLEARCASE_FXPN version-extended pathname of "from" version
CLEARCASE_B_ID_STR version-ID of base contributor version
help [command-name]
ln [–slink][–c comment | –cq | –cqe | –nc]pname target-pname
ln [–slink][–c comment | –cq | –cqe | –nc]pname [pname ...]target-dir-pname
lock [–replace][–nusers login-name[,...] | –obsolete]
[–c comment | –cq | –cqe | –nc]
{ {–eltype | –brtype | –attype | –hltype | –lbtype | –trtype |–rptype }
[–vob pname-in-vob]type-name ...
|–pool [–vob pname-in-vob]pool-name ...
|–vob {pname-in-vob | vob-storage-dir-pname }
|pname ... }
ls [–recurse | –directory][–long | –short][–vob_only | –view_only]
[–nxname][–visible][pname ...]
lscheckout | lsco [–long | –short | –fmt format][–cview]
[–brtype branch–type][–me | –user login-name]
[–recurse |–directory | –all | –avobs |–areplicas][pname ...]
lsdo [–recurse][–me][–long | –short | –fmt format][–zero]
[–stime | –sname][pname ...]
lshistory [–long | –short | –fmt format][–eventid]
[–minor][–nco][–since date-time][–user login-name]
[[–recurse | –directory | –all | –avobs][–branch branch-type]
pname ...
| {–eltype | –brtype | –attype | –hltype | –lbtype | –trtype
|–rptype}[–vob pname-in-vob]type-name ...
|–vreplica [–vob pname-in-vob] replica-name ...
|–pool [–vob pname-in-vob]pool-name ...
|–hlink hlink-selector ...
|–vob pname-in-vob
]
lslock [–long | –short | –fmt format][–obsolete]
[{–eltype | –brtype | –attype | –hltype | –lbtype | –trtype |–rptype}
[–vob pname-in-vob]type-name ...
|–pool [–vob pname-in-vob]pool-name ...
|–vob {pname-in-vob | vob-storage-dir-pname}
|[–all]pname ...
]
lspool [–long | –short | –fmt format][–obsolete]
[–vob pname-in-vob][pool-name ...]
lsprivate [–tag view-tag][–vob pname-in-vob][–long | –short][–co]
lstype {–eltype | –brtype | –lbtype | –attype | –hltype | –trtype |–rptype}
[–long | –short | –fmt format]
[–obsolete][–vob pname-in-vob][type-name ...]
lsview [–short | –long][–host hostname][–region ’region-pattern’]
[’view-tag-pattern’ ... | –storage view-storage-dir-pname ...]
lsvob [–short | –long][–host hostname][–region ’region-pattern’]
[’vob-tag-pattern’ ... |–storage vob-storage-dir-pname ...]
lsvtree [–nrecurse][–short][–all][–merge][–nco]
[–branch branch-pname]pname ...
CASEVision/ClearCase Quick Reference Guide 21
man [command-name]
merge {–out output-pname | –to contrib-and-result-pname}
[–base pname | –insert | –delete][–ndata | –narrows][–replace]
[–abort | –qall][–c comment | –cq | –cqe | –nc]
[–tiny | –window][–serial_format | –diff_format | –col n]
[–options "pass-through-options"]
{–version contrib-version-selector ... | contrib-pname ...}
mkattr [–replace][–recurse][–version version-selector]
[–c comment | –cq | –cqe | –nc]
{attribute-type-name value | –default attribute-type-name}pname ...
mkattr –hlink [–replace][–c comment | –cq | –cqe | –nc]
{attribute-type-name value | –default attribute-type-name }
hlink-selector ...
mkattr [–replace][–c comment | –cq | –cqe | –nc]
[–select do-leaf-pattern][–ci][–type {f|d } ...]
[–name tail-pattern] –config do-pname
{attribute-type-name value | –default attribute-type-name }
mkattype [–replace][–vpelement | –vpbranch | –vpversion][–omaster]
[–vtype {integer | real | time | string |opaque}]
[[–gt low-value |–ge low-value]
[–lt high-value | –le high-value] |–enum value[,...]]
[–default default-value][–c comment | –cq | –cqe | –nc]
[–vob pname-in-vob]type-name ...
mkbranch [–version version-selector][–nco]
[–c comment | –cq | –cqe | –nc]branch-type-name pname ...
mkbrtype [–replace][–pelement][–vob pname-in-vob]
[–c comment | –cq | –cqe | –nc]type-name ...
mkdir [–nco][–c comment | –cq | –cqe | –nc]dir-pname ...
mkelem [–eltype elem-type-name][–nco | –ci]
[–c comment | –cq | –cqe | –nc]element-pname ...
mkeltype [–replace] –supertype elem-type-name [–manager mgr-name]
[–ptime][–attype attr-type-name[, ...]] [–vob pname-in-vob]
[–c comment | –cq | –cqe | –nc]type-name ...
mkhlink [–unidir][–ttext to-text][–ftext from-text] [–c comment | –cq | –cqe | –nc]
hlink-type-name from-obj-pname [to-obj-pname]
mkhltype [–replace][–attype attr-type[,...]] [–vob pname-in-vob]
[–omaster][–c comment | –cq | –cqe | –nc]type-name ...
mklabel [–replace][–recurse][–version version-selector]
[–c comment | –cq | –cqe | –nc]label-type-name pname ...
mklabel [–replace][–c comment | –cq | –cqe | –nc]
[–select do-leaf-pattern][–ci][–type {f | d } ...]
[–name tail-pattern] –config do-pname label-type-name
mklbtype [–replace][–pbranch][–omaster][–vob pname-in-vob]
[–c comment | –cq | –cqe | –nc]type-name ...
mkpool –source [–ln pool-dir-pname][–vob pname-in-vob]
[–c comment | –cq | –cqe | –nc]pool-name ...
mkpool {–derived | –cleartext}[–ln pool-dir-pname]
[–size max-kbytes reclaim-kbytes [–age hours][–alert command]]
[–vob pname-in-vob][–c comment | –cq | –cqe | –nc]pool-name ...
mkpool –update [–size max-kbytes reclaim-kbytes][–age hours]
[–alert command][–vob pname-in-vob]
[–c comment | –cq |–cqe | –nc]pool-name ...
mktag –view –tag view-tag [–tcomment tag-comment][–replace]
[–region network-region][–nstart]
[–host hostname –hpath local-stg-path –gpath global-stg-path ]
view-storage-pname
mktag –vob –tag vob-tag [–tcomment tag-comment][–replace]
[–region network-region][–options mount-options]
[–public [–password tag-reg-password]]
[–host hostname –hpath local-stg-path –gpath global-stg-path ]
vob-storage-pname
mktrigger [–ninherit | –nattach][–recurse][–force]
[–c comment | –cq | –cqe | –nc]trigger-type-name element ...
22 CASEVision/ClearCase Quick Reference Guide
See also Trigger-Related Environment Variables on page 24.
mktrtype –element [–global][–replace]{–preop | –postop } opkind[,...]
[restriction-list ][–nusers login-name[,...]]
{ –exec command | –mklabel label-type | –mkattr attr-type=value
| –mkhlink hltype,to=pname | –mkhlink hltype,from=pname } ...
[–print ][–c comment | –cq | –cqe | –nc ]
[–vob pname-in-vob ]type-name ...
restriction-list := one or more of:
–attype attr-type[,...]or –attype –all
–brtype branch-type[,...]or –brtype –all
–eltype elem-type[,...]or –eltype –all
–hltype hlink-type[,...]or –hltype –all
–lbtype label-type[,...]or –lbtype –all
–trtype trigger-type[,...]or –trtype –all
On this opkind... These restrictions are checked before firing...
MODIFY_ELEM
checkout element type, branch type
uncheckout element type, branch type
reserve element type, branch type
unreserve element type, branch type
MODIFY_DATA
chevent element type, branch type
mkelem element type
mkbranch element type, branch type
checkin element type, branch type
rmelem element type
rmbranch element type, branch type
rmver element type, branch type
rmname N/A
chtype all type objects
lock element type, branch type
unlock element type, branch type
MODIFY_MD
chevent restrictions on type of affected object
mklabel element type, label type, branch type
mkattr element type, attribute type, branch type
mkhlink element type, hyperlink type, branch type
mktrigger element type, hyperlink type, branch type
rmlabel element type, label type
rmattr element type, attribute type, branch type
rmhlink element type, hyperlink type, branch type
rmtrigger element type, trigger type
See also Trigger-Related Environment Variables on page 24.
mktrtype –type [–replace ]{–preop | –postop } opkind[,...]inclusion-list
[–nusers login-name[,...]] –exec command [–print ]
[–c comment | –cq | –cqe | –nc ][–vob pname-in-vob ]type-name ...
inclusion-list := one or more of:
–attype attr-type[,...]
–brtype branch-type[,...]
–eltype elem-type[,...]
–hltype hlink-type[,...]
–lbtype label-type[,...]
–trtype trigger-type[,...]
Type trigger opkinds:
MODIFY_TYPE
mktype,rmtype,rntype,lock,unlock,chevent
mkview –tag view-tag [–tcomment tag-comment][–tmode {unix | msdos} ]
[–region network-region][–ln link-storage-to-dir-pname]
[ –host hostname –hpath host-stg-path –gpath global-stg-path ]
view-storage-pname
mkvob –tag vob-tag [–c comment | –cq | –cqe | –nc][–tcomment tag-comment]
[–region network-region][–public [–password tag-reg-password]]
[–options mount-options]
[–host hostname –hpath host-stg-path –gpath global-stg-path ]
vob-storage-dir-pname
mount {[–options mount-options]vob-mount-tag | –all }
CASEVision/ClearCase Quick Reference Guide 23
mv [–c comment | –cq | –cqe | –nc]pname target-pname
mv [–c comment | –cq | –cqe | –nc]pname [pname ...]target-dir-pname
protect [–chown login-name][–chgrp group-name][–chmod permissions]
[–file | –directory ][–recurse]
[–c comment | –cq | –cqe | –nc]pname ...
protectvob [–force][–chown login-name][–chgrp group-name]
[–add_group group-name[,...]] [–delete_group group-name[,...]] vob_stor-
age_pname ...
pwd
pwv [–short][–wdview | –setview]
quit
recoverview [–force][–vob vob_uuid | –dir dir_object_id ]
{ –tag view-tag | view-storage-pname }
reformatview [ –dump | –load ]{ –tag view-tag | view-storage-pname }
reformatvob [–dump | –load][–rm][–force][–to dumpfile_directory ]
[–host hostname –hpath host-stg-path –gpath global-stg-path ]
vob-storage-dir-pname
register –view [–replace][–host hostname –hpath host-stg-path –gpath global-stg-path ]
view-storage-pname
register –vob [–replace] [–host hostname –hpath host-stg-path –gpath global-stg-path ]
vob-storage-pname
reserve [–c comment | –cq | –cqe | –nc]pname ...
rmattr [–version version-selector][–c comment | –cq | –cqe | –nc]
attribute-type-name pname ...
rmattr [–c comment | –cq | –cqe | –nc] { [–version version-selector]
{ attribute-type-name pname ... |–hlink attribute-type-name hlink-selector ... }
rmbranch [–force][–c comment | –cq | –cqe | –nc]pname ...
rmdo do-pname ...
rmdo {–all | –zero}[pname ...]
rmelem [–force][–c comment | –cq | –cqe | –nc]pname ...
rmhlink [–c comment | –cq | –cqe | –nc]hlink-selector ...
rmlabel [–version version-selector][–c comment | –cq | –cqe | –nc]
label-type-name pname ...
rmmerge [–c comment | –cq | –cqe | –nc]from-pname to-pname
rmname [–c comment | –cq | –cqe | –nc]pname ...
rmpool [–c comment | –cq | –cqe | –nc][–vob pname-in-vob]pool-name ...
rmtag { –view | –vob }[–region network-region | –all ]view-or-vob-tag ...
rmtrigger [–ninherit | –nattach][–recurse]
[–c comment | –cq | –cqe | –nc]trigger-type-name pname ...
rmtype {–eltype | –brtype | –lbtype | –attype | –hltype |–rptype
|–trtype [–ignore] } [–rmall [–force]]
[–c comment | –cq | –cqe | –nc][–vob pname-in-vob]type-name ...
rmver [–force][–xbranch][–xlabel][–xattr][–xhlink][–data]
[–version version-selector | –vrange low-version high-version]
[–c comment | –cq | –cqe | –nc]pname ...
rmview [–force]{–tag view-tag | view-storage-pname }
rmview [–force][–vob pname-in-vob] –uuid view_uuid
rmvob [–force]vob-storage-dir-pname ...
rnpool [–vob pname-in-vob][–c comment | –cq | –cqe | –nc]
old-pool-name new-pool-name
rntype {–eltype | –brtype | –lbtype | –attype | –hltype | –trtype |–rptype}
[–vob pname-in-vob][–c comment | –cq | –cqe | –nc]
old-type-name new-type-name
setcs [–tag view-tag]{–current | –default | pname }
setview [–login][–exec command-invocation]view-tag
shell [command [args ...]]
space [–all] { pname-in-vob ... | vob-storage-dir-pname ... |–avobs
| –directory dir-pname ... }
startview view-tag ...
umount {vob-mount-tag | –all }
uncheckout | unco [–keep | –rm]pname ...
24 CASEVision/ClearCase Quick Reference Guide
Trigger-Related Environment Variables
This environment variable... Is set by... (see also mktrtype manual page)
unlock [–c comment | –cq | –cqe | –nc]
{{–eltype | –brtype | –attype | –hltype | –lbtype | –trtype | –rptype}
[–vob pname-in-vob]type-name ...
|–pool [–vob pname-in-vob]pool-name ...
|–vob {pname-in-vob | vob-storage-dir-pname }
|pname ... }
unregister –vob {–uuid uuid | vob-storage-dir-pname }
unregister –view {–uuid uuid | view-storage-dir-pname }
unreserve [–view [hostname:]view-storage-dir-pname]
[–c comment | –cq | –cqe | –nc]pname ...
winkin [–out output-pname]do-pname ...
xdiff [–tiny][–hstack | –vstack][–pred ] [–options "pass-thru-options"]pname ...
xlsvtree [–all][–nmerge][–nco][–options "pass-through-options"]pname ...
xmerge {–out output-pname | –to contrib-and-result-pname }
[–base pname |–insert | –delete][–ndata | –narrows][–replace]
[–abort | –qall][–c comment | –cq | –cqe | –nc][–hstack | –vstack]
[–tiny][–options "pass-through-options"]
{–version contrib-version-selector ... | contrib-pname ...}
clearcase_attach mktrigger, rmtrigger
clearcase_attype all operations restrictable by attr type
clearcase_brtype all operations restrictable by branch type
clearcase_ci_fpn checkin
clearcase_comment all operations that support comments
clearcase_eltype all operations restrictable by element type
clearcase_ftext mkhlink, rmhlink
clearcase_fvob_pn mkhlink, rmhlink
clearcase_fxpn mkhlink, rmhlink
clearcase_hltype all operations restrictable by hlink type
clearcase_id_str ci, co, mk/rmattr, mr/rmhlink, mk/rmlabel,
mkbranch, rmver
clearcase_is_from mkhlink, rmhlink
clearcase_lbtype all operations restrictable by label type
clearcase_mtype all
clearcase_new_type rntype
clearcase_op_kind all
clearcase_out_pn checkout
clearcase_pn all (element triggers only)
clearcase_pn2 lnname
clearcase_pop_kind mkelem, mkslink, lnname
clearcase_ppid all
clearcase_slnktxt mkslink
clearcase_trtype all operations restrictable by trigger type
clearcase_ttext mkhlink, rmhlink
clearcase_tvob_pn mkhlink, rmhlink
clearcase_txpn mkhlink, rmhlink
clearcase_user all
clearcase_val all
clearcase_view_tag all
clearcase_vob_pn all
clearcase_vtype mkattr
clearcase_xn_sfx all
clearcase_xpn all (element triggers only)
CASEVision/ClearCase Quick Reference Guide 25
Non-cleartool Command Syntax
etc = command lives in ${atriahome}/etc, not ${atriahome}/bin
clearaudit [shell_cmd ]
clearbug [ –short | –s ]
clearcvt_ccase [ –I date-time | –s date-time ][ –r ][ –n ][ –o script-dir-pname ]
[ –p file-pname ][ –e file-pname ][source-name ... ]
clearcvt_dsee [ –I date-time | –s date-time ][ –r ][ –n ]
[ –o script-dir-pname ][ –p file-pname ][ –e file-pname ]
[ –T translation-file ][source-name ... ]
clearcvt_rcs [ –I date-time | –s date-time ][ –r ][–n ]
[ –o script-dir-pname ] –p file-pname ][ –e file-pname ][ –V ]
[ –T translation-file ][ –S ][source-name ... ]
clearcvt_sccs [ –I date-time | –s date-time ][ –r ][ –n ]
[ –o script-dir-pname ][ –p file-pname ][ –e file-pname ]
[ –B branch-id ][ –V ][ –T translation-file ][source-name ... ]
clearcvt_unix [ –s date-time ][ –r ][ –n ][ –L ][ –i ]
[ –o script-dir-pname ][ –t temp-dir-pname ][ –p file-pname ]
[ –e file-pname ][ –b target-branch [ –v version-id ]][source-name ... ]
diff:
cleardiff [ –window | –tiny ]
[ –diff_format | –serial_format | –columns n]
[ –headers_only | –quiet | –status_only ]
[ –blank_ignore ]pname1 pname2 ...
merge:
cleardiff –out output-pname [ –base pname ]
[ –qall | –abort ][ –window | –tiny ]
[–diff_format | –serial_format | –columns n]
[ –headers_only | –quiet | –status_only ][ –blank_ignore ]pname1
pname2 ...
clearlicense [ –product product-name ][ –hostid | –release {username |user-ID }... ]
clearmake [ –f makefile ... ][ –ukinservdp ][ –OTFUVMN ]
[ –C mode ][ –J num ][ –A BOS-file ]... [macro=value ... ]
[target_name ... ]
prompt for text:
clearprompt text –prompt prompt_string –outfile pname
[ –multi_line ][ –default string |–dfile pname]
[ –prefer_gui ]
prompt for pathname:
clearprompt file –prompt prompt_string –outfile pname
[ –pattern match_pattern ][ –default filename |–dfile pname]
[ –directory dir_path ][ –prefer_gui ]
prompt for continue-processing choice:
clearprompt proceed –prompt prompt_string [ –type type ]
[ –default choice ][ –mask choice[,choice]][ –prefer_gui ]
choice := proceed |abort
prompt for yes/no choice:
clearprompt yes_no –prompt prompt_string [ –type type ]
[ –default choice ][ –mask choice[,choice]][ –prefer_gui ]
type := ok |warning |error
choice := yes |no |abort
cleartool subcommand [options/args ]
determine cache status:
etc mvfscache [cache_name ]
control cache operation:
etc mvfscache { –e cache_list | –d cache_list | –f cache_list }
etc mvfslog [ none | error | warn | info | stale | debug ]
etc mvfsstat [–i ][–c ][–r ][–v ][–V ][–l ][–h ][time ][count ]
etc mvfsstorage pname ...
etc mvfstime [–i ][–c ][–r ][–v ][–V ][–l ][–h ]command [args ]
mvfsversion [–r ][–s ]
etc rgy_passwd [ –password tag-registry-password ]
26 CASEVision/ClearCase Quick Reference Guide
ClearCase Directory Tree Structure
etc scrubber [ –e | –f | –o ][ –p pool[,...]| –k kind[,...]]
[ –a |vob-storage-dir-pname ... ]
etc view_scrubber [–p ][–k ][–n ][DO-pname ... ]
etc vob_scrubber [–stats_only ][ –long ][ –nlog ]
{ –lvobs |vob-storage-dir-pname ... }
xclearcase [–file |–attype |–brtype |–eltype |–hltype |–lbtype |–trtype |
–vtree [–all ][–nmerge ][–nco ]pname ... ][X-options ]
diff:
xcleardiff [–tiny ][–hstack |–vstack ][X-options ]pname1 pname2 ...
merge:
xcleardiff –out output-pname [–force ][–base pname ][–tiny ]
[–hstack |–vstack ] [ –qall ][–pause ][X-options ]
contrib-pname ...
xlsvtree [–all ][–nco ][–nmerge ][X-options ]pname ...
/usr/atria/ default install dir (atriahome overrides it)
bin/ symbolic link to $arch/bin
config/ configuration files
clearmake/ C++ and miscellaneous build support
cron/ crontab(1) scripts, scrubber scripts
magic/ file-typing config file, default.magic
services/ Clearcase server configuration file
softbench/ SoftBench configuration files
tooltalk/ ToolTalk configuration files
ui/ graphical user interface utilities
Schemes/ X resource configuration files
bitmaps/ xclearcase browser icons
grp/ xclearcase group files (menu, toolbar defs)
icon/ default file type-to-bitmap mappings file
lib/ misc GUI libs (X11)
vob/ vob_scrubber_params file
default_config_spec default configuration spec for all new views
doc ClearCase documentation
man/ manual pages (nroff source format)
tutorial/ scripts and data files for ClearCase tutorial
etc/ symbolic link to $arch/etc (admin tools)
examples/ ClearCase usage examples
install/ ClearCase installation scripts
lib/ symbolic link to $arch/lib
$arch architecture-specific programs and data
bin/ user programs (cleartool,clearmake, etc.)
etc/ server-level (daemon) programs
sysgen/ kernel configuration files
lib/ additional server-level programs
mgrs/ element type managers
/usr/adm/atria/
or
/var/adm/atria/ main ClearCase administration directory
log/ ClearCase log files (*_log)
rgy/ registry directory (VOB and view registries)
cache/ run-time cache information
config/ license_host and other host configuration files
CASEVision/ClearCase Quick Reference Guide 27
Basic System Administration Commands
VOBs
Storage Pools
Elements
create and register a VOB cleartool mkvob –tag vob-tag [ –public ] \
vob-storage-dir
list registered VOBs cleartool lsvob [–long][–host hostname]
describe a VOB in detail cleartool describe –long –vob pname-in-vob
mount a VOB cleartool mount vob-tag
show VOB disk usage cleartool space pname-in-vob
chown/chmod an object cleartool protect –chown admin foo.c
cleartool protect –chmod +r foo.c
set VOB owner or group(s)
cleartool protectvob –{add|delete}_group \
vob-storage-dir
cleartool protectvob –chown/chgrp \
vob-storage-dir
lock a VOB or an individual
object cleartool lock [–obs][–nusers]name
list all locks in a VOB cleartool lslock –all –obsolete pname-in-vob
unlock a VOB cleartool unlock –vob pname-in-vob
1) create a new VOB-tag
2) private ➝public tag
3) new network region
cleartool mktag –vob vob-tag vob-storage-dir
mktag –vob tag –public –replace vob-stg-dir
mktag –vob tag –region region vob-stg-dir
reformat (dump/load) VOB
database cleartool reformatvob vobtag-or-storage-dir
take VOB out of service
reregister the VOB cleartool unregister –vob vob-storage-dir
cleartool register –vob vob-storage-dir
remove a VOB-tag cleartool rmtag –vob vob-tag
remove a VOB 1) cleartool umount vob-tag
2) cleartool rmvob vob-storage-dir
list storage pools cleartool lspool [–long][–vob pname-in-vob]
list element’s
assigned pools cleartool describe –long element-pathname
lock/unlock a
storage pool cleartool {lock|unlock} –pool pool-name
create a new
storage pool
cleartool mkpool –source pool-name
cleartool mkpool –derived –size 10000 8000 pool-name
cleartool mkpool –cleartext –upd –age 48 pool-name
remove a storage
pool cleartool rmpool pool-name
change pool
assignment cleartool chpool new-pool-name element-pathname
lock/unlock elements cleartool {lock|unlock}element-pathname
lock branch type for all
users except rkd,lea cleartool lock –nusers rkd,lea –brtype beta2
list existing element types cleartool lstype [–long] –eltype
change an element’s type cleartool chtype eltype element-pname
change assigned storage
pool cleartool chpool pool-name element-pathname
remove an element name
from a directory cleartool rmname element-pathname
remove a version cleartool rmver version-specifier
28 CASEVision/ClearCase Quick Reference Guide
Meta-Data
Views
Starting/Stopping ClearCase Processing
list existing types cleartool lstype –xxtype [–long]\
[–vob pname-in-vob]
create an attribute type
object; then attach
attributes
1) cleartool mkattype Tested
2) cleartool mkattr Tested ’"no" ’ foo.c
3) cleartool mkattr –config lib.o –def Tested
create a branch type object;
then make a branch 1) cleartool mkbrtype branch1
2) cleartool mkbranch branch1 foo.c
create an element type
object; then create an
element of that type
1) cleartool mkeltype –super text_file c_src
2) cleartool mkelem –eltype c_src foo.c
create a hyperlink type
object; then connect two
objects with a hyperlink
1) cleartool mkhltype HLINK1
2) cleartool mkhlink HLINK1 foo.c bar.c
create a label type object,
and then attach a version
label
1) cleartool mklbtype LABEL1
2) cleartool mklabel LABEL1 foo.c
create a trigger type object;
then attach a trigger to an
element
1) cleartool mktrtype –element –global \
–postop checkin –nc –exec \
’/vobs/scripts/test $clearcase_pn’ \
checkin_trigger
2) cleartool mktrigger TRIG1 *.[ch]
delete a type object cleartool rmtype –xxtype type-name(s)
delete a meta-data instancecleartool rmtype –attype attr-type-names
cleartool rmhlink hlink-selector
change an event comment cleartool chevent –c "Fix #324" foo.c
change an event comment
using event-ID
1) cleartool lshistory –long –eventid util.c
2) cleartool chevent –c "for patch g12" \
–append –event 45678
list registered views cleartool lsview [–long][–host hostname ]
cleartool lsview ’*_integ’
create a new view cleartool mkview –tag view-tag view-storage-dir
enable view-extended
pathname access to view cleartool startview view-tag
remove a view-tag cleartool rmtag –view view-tag
remove a view cleartool rmview { –tag view-tag | view-stg-dir }
reformat for new release cleartool reformatview \
{ –tag view-tag | view-stg-dir }
recover view database cleartool recoverview \
{ –tag view-tag | view-stg-dir }
take a view out of service;
reregister the view cleartool unregister –view view-storage-dir
cleartool register –view view-storage-dir
SunOS 4
HP-UX 9 /etc/rc.atria {start | stop }
SunOS 5
IRIX 5 /etc/init.d/atria {start | stop }
OSF/1 Ver. 2 /sbin/init.d/atria {start | stop }
CASEVision/ClearCase Quick Reference Guide 29
Glossary
Element A version-controlled file or directory-that is, a
file or directory for which ClearCase maintains
a version tree.
Version A specific instance of a file or directory ele-
ment.
Merge The combining of the contents of two or more
files into a single new file. Typically, all the files
involved are versions of a single file element.
VOB
Versioned Object Base. A VOB is a data
repository that can be mounted as a file sys-
tem of type MVFS. A VOB’s mount point is
called its VOB-tag.
View
Required to access a VOB. A view is a lens, or
filter, which makes visible a version of each
VOB element, yielding a work environment for
a single developer or a closely coordinated
group. Each view has a unique name, its view-
tag.
Config Spec A set of rules that specify which VOB element
versions are visible in the view. Every view
has a config spec.
Derived Object (DO) A file created in a ClearCase build.
Configuration Record
(CR)
An audit of the software build process. A con-
figuration record uniquely identifies a derived
object; it stores the file versions and build
flags necessary to create the derived object.
The build audit happens transparently.
Wink-in To import, into a view, a derived object that
was built in another view (by the current user
or a different one).
Meta-Data Data associated with VOB-resident objects-for
example, event records, attributes, hyperlinks,
labels, and triggers.
Type Object A meta-data prototype object created with
mkattype, mkbrtype, mkeltype, mkhltype, mkl-
btype, or mktrtype.
Trigger
A user-defined procedure that fires before or
after a specific ClearCase operation. Triggers
are used primarily to define and control the
software engineering process.
VOB Database Object
An object with an entry in the VOB database:
element
branch
version
VOB symbolic link
hyperlink
derived object
VOB storage pool
replica
type object:
attribute type, branch type,
element type, hyperlink type, label type,
trigger type
30 CASEVision/ClearCase Quick Reference Guide
Customer Information
WE WOULD LIKE TO HEAR FROM YOU
As a user of Silicon Graphics documentation, your comments are
important to us. They help us to better understand your needs and
to improve the quality of our documentation.
Any information that you provide will be useful. Here is a list
of suggested topics to comment on:
•General impression of the document
•Omission of material that you expected to find
•Technical errors
•Relevance of the material to the job you had to do
•Quality of the printing and binding
Please include the title and part number of the document you
are commenting on. The part number for this document is
007-2395-001.
Thank you!
Three Ways to Reach Us
Write your comments and mail them to this address:
ATTN: TECHNICAL PUBLICATIONS M/S 9L-935
SILICON GRAPHICS, INC.
2011 Norht Shoreline Blvd
Mt View CA 94043-9640
UNITED STATES OF AMERICA
If electronic mail is available to you, write your comments in
an e-mail message and mail it to either of these addresses:
•If you are on the Internet, use the address:
techpubs@sgi.com
•For UUCP mail, use this address through any backbone
site: [your_site]!sgi!techpubs
You can forward your comments (or annotated copies of
manual pages) to Technical Publications at this FAX number:
415-965-0964
