SOURCE 1
REPLACEMENT PARTS
DM240 DM300
Part Number Description Notes or code on wiring diagram 230V 460V 575V 230V 460V 575V 230V 460V 575V
025-37467-000 ACTUATOR, BELIMO AF24 BAS Only XXXXXX X X X
029-20424-000 BEARING,BALL PILLOW BLOCK R:A X X X
029-22145-000 BEARING,BALL,4 BOLT FLG R:A XXX
029-22144-000 BEARING,BALL,4-BOLT FLG R:A XX X
028-13333-000 BELT V 5VX860 R:A XX X
028-10382-000 BELT V BX68 69.8 R:A HIGH SPEED X X X
028-12027-000 BELT V BX70 71.8 R:A STD SPEED X X X
028-12017-000 BELT V BX81 82.8 R:A HIGH SPEED X X X
028-12080-000 BELT V BX83 84.8 R:A STD SPEED X X X
026-35494-000 BRACKET,BEARING R:A XXXXXX
029-18431-000 BURNER,GAS R:F XXXXXX X X X
028-13332-000 BUSHING,B1X1.438 BORE R:A XX X
024-21219-000 CAP,RUN,12.5/ MFD,370V R:B POWER EXHAUST FAN XXXXXX X X X
031-01956-000 CAPACITOR,100UF 50WVDC R:A BAS Only, CAP XXXXXX X X X
024-31976-000 CIRCUIT BREAKER 3.2A 250V CB2 XXXXXX X X X
024-27583-000 CIRCUIT BREAKER 6.0A 250V CB1 XXXXXX X X X
024-27517-000 CIRCUIT BREAKER 20A 250V CB4 XXXXXX X X X
024-25989-000 CIRCUIT BREAKER,100A 240V DS1*
024-27675-000 CIRCUIT BREAKER,100A 480V DS1*
024-27514-000 CIRCUIT BREAKER,110A 600V DS1*
024-27513-000 CIRCUIT BREAKER,125A 600V DS1*
024-27512-000 CIRCUIT BREAKER,150A,600V DS1*
024-27510-000 CIRCUIT BREAKER,200A 600V DS1*
024-27509-000 CIRCUIT BREAKER,225A 600V DS1*
024-27574-000 CIRCUIT BREAKER,35A,600V DS1*
024-27652-000 CIRCUIT BREAKER,40A 600V DS1*
024-27643-000 CIRCUIT BREAKER,45A 480V DS1*
024-27573-000 CIRCUIT BREAKER,45A 600V DS1*
024-26063-000 CIRCUIT BREAKER,50A 480V DS1*
024-27647-000 CIRCUIT BREAKER,50A 600V DS1*
024-27572-000 CIRCUIT BREAKER,60A 600V DS1*
024-26059-000 CIRCUIT BREAKER,60A,480V DS1*
024-27508-000 CIRCUIT BREAKER,70A 480V DS1*
024-27571-000 CIRCUIT BREAKER,70A 600V DS1*
024-27503-000 CIRCUIT BREAKER,80A 240V DS1*
024-27644-000 CIRCUIT BREAKER,80A 480V DS1*
024-32037-000 CIRCUIT BREAKER,80A 600V DS1*
024-27507-000 CIRCUIT BREAKER,90A 480V DS1*
024-27570-000 CIRCUIT BREAKER,90A 600V DS1*
373-06404-000 COIL COND DM180 F R:F FRONT X X X
373-06404-150 COIL COND DM180 F TC R:A FRONT, TECHNICOAT X X X
373-06405-000 COIL COND DM180 R R:G REAR X X X
373-06405-150 COIL COND DM180 R TC R:A REAR, TECHNICOAT X X X
373-06295-000 COIL COND DM240 F R:E FRONT X X X
373-06295-150 COIL COND DM240 F TC R:A FRONT, TECHNICOAT X X X
373-06296-000 COIL COND DM240 R R:F REAR X X X
373-06296-150 COIL COND DM240 R TC R:A REAR, TECHNICOAT X X X
373-21391-101 COIL COND DM300/DH240 F R:B FRONT X X X
373-21391-150 COIL COND DM300/DH240 F TCR:A FRONT, TECHNICOAT X X X
373-21390-101 COIL COND DM300/DH240 R R:A REAR X X X
373-21390-150 COIL COND DM300/DH240 R TCR:A REAR, TECHNICOAT X X X
373-06227-000 COIL EVAP DM180 R:H X X X
373-06227-200 COIL EVAP DM180 TC R:A TECHNICOAT X X X
373-06228-000 COIL EVAP DM240 R:J XXX
373-21474-001 COIL EVAP DM300 LOWER R:B LOWER X X X
373-21473-001 COIL EVAP DM300 UPPER R:A UPPER X X X
026-31432-001 COIL GUARD 15T R:A X X X
026-31432-002 COIL GUARD 20-25T R:A XXX X X X
028-12342-000 COMPRESSOR, GROMMET COMPR XXXXXX
028-07772-000 COMPRESSOR, SPRING COMPR X X X
015-02095-005 COMPRESSOR,H23A563DBEA COMPR X
015-01643-005 COMPRESSOR,H23A563DBFA COMPR X
015-02094-005 COMPRESSOR,H23A563DBLA COMPR X
015-02053-001 COMPRESSOR,H2DA114DBEH COMPR X X
015-02054-001 COMPRESSOR,H2DA114DBFH COMPR X X
015-02052-001 COMPRESSOR,H2DA114DBLH COMPR X X
015-02707-004 COMPRESSOR,ZRT144KC-TF5 COMPR X
015-02708-004 COMPRESSOR,ZRT144KC-TFD COMPR X
015-02709-004 COMPRESSOR,ZRT144KC-TFE COMPR X
025-17620-014 CONT,PRESS,RFG380/300 O/C R:C HPS XXXXXX
024-24101-000 CONTACTOR,ELEC, R:A M4 & M5 XXXXXX
Model and Voltage
DM180
DM180, 240 & 300
York Sunline 2000
Supercedes: Nothing 035-19036-000 Rev. A(0802)
Note: This is a non-comprehensive parts lists intended for stocking purposes for first production (style A) units. It is not intended to
replace the complete, comprehensive list with subsequent changes.
* See UNIT NAMEPLATE or TECHNICAL LITERATURE for the required breaker/max fuse size.
DM240 DM300
Part Number Description Notes or code on wiring diagram 230V 460V 575V 230V 460V 575V 230V 460V 575V
Model and Voltage
DM180
024-25955-000 CONTACTOR,ELEC,30 AMP R:A M1 X X X X X X X
M2 XXX XX X X X
M3 XXXXXX X X
M4 & M5 X X X
024-25844-000 CONTACTOR,ELEC,40 AMP R:A M3 X
024-25846-000 CONTACTOR,ELEC,50 AMP R:A M1 X X
M2 X
025-29012-004 CONTROL SPARK R:A IC1 & IC2 XXXXXX X X X
031-01940-000 CONTROL,CPC 810-3060 R:A BAS Only XXXXXX X X X
031-00863-000 CONTROL,ENTHALPY SINGLE ECONOMIZER / BAS XXXXXX X X X
031-01938-000 CONTROL,HONEYWELL W7750 R:A BAS Only XXXXXX X X X
031-01937-000 CONTROL,JOHNSON UNIT 1126 R:A BAS Only XXXXXX X X X
031-01939-000 CONTROL,NOVAR ETC-3 R:A BAS Only XXXXXX X X X
031-01934-000 CONTROL,SIMPLICITY LOCKOUTR:A SIMPLICITY XXXXXX X X X
025-26366-009 CONTROL,TEMP R:A LIMIT SWITCH XXXXXX X X X
025-27733-002 CONTROL,TEMP R:A ROLLOUT SWITCH XXXXXX X X X
025-32655-000 CONTROL,TEMP R:A AUX. LIMIT SWITCH XXXXXX X X X
025-27723-001 CONTROL,TEMP R:A LAS2 XXXXXX
025-27727-002 CONTROL,TEMP R:D FS1 & FS2 XXXXXX X X X
025-35355-001 CONTROL,TEMP SPST 30F R:A LAS3 XXXXXX X X X
025-32675-000 COVER,SWITCH DISC/BRKR DS1* XXXXXX X X X
029-22116-000 CRANKARM, BELIMO ACTUATOR BAS Only XXXXXX X X X
024-32007-000 DIRTY FLTR.SWITCH XXXXXX X X X
026-35506-000 DISTR,14T,#10,.187X30S R:A XX X
026-25558-000 FAN,PROP,24DIA,4BL,32DEG POWER EXHAUST FAN XXXXXX X X X
026-25579-000 FAN,PROP,30DIA,3BL,18DEG R:B CONDENSER FAN XXXXXX X X X
026-25532-000 FILTER AIR 2 X 12 X 24 XX X
026-25534-000 FILTER AIR 2 X 18 X 24 X X X
026-28050-024 FILTER METAL 2 X 18 X 24 McDonald's X X X
026-28050-029 FILTER METAL 2 X 24 X 34 McDonald's X X X
026-32670-005 FILTER, MEDIA POLYESTER 24X18X2 McDonald's X X X
026-32670-008 FILTER, MEDIA POLYESTER 24X34X2 McDonald's X X X
026-38487-000 FILTER, PLEATED 2 X 12 X 24 XX X
026-35528-000 FILTER, PLEATED 2 X 16 X 20 XXX
026-35529-000 FILTER, PLEATED 2 X 16 X 25 XXX
026-35530-000 FILTER, PLEATED 2 X 18 X 24 X X X
026-38555-000 FILTER, PLEATED 2 X 20 X 24 XX X
026-38553-000 FILTER, PLEATED 2 X 24 X 24 XX X
026-38029-000 FILTER, PLEATED 4 X 16 X 20 XXX
026-38030-000 FILTER, PLEATED 4 X 16 X 25 XXX
026-38031-000 FILTER, PLEATED 4 X 18 X 24 X X X
026-03617-000 FILTER,AIR 2 X 16 X 20 XXX
026-03616-000 FILTER,AIR 2 X 16 X 25 XXX
026-35464-000 FILTER DRIER,SOLID CORE XXXXXX X X X
025-04649-000 FU,DUAL,250V 30A, 9X16X2 R:D FUSE 7 - 9 X
025-15491-000 FU,DUAL,250V 35A,13X16X3 R:C FUSE 7 - 9 X
025-13292-000 FU,DUAL,250V 60A,13X16X3 R:E FUSE 1 - 6 X X X
025-13292-000 FU,DUAL,250V 60A,13X16X3 R:E FUSE 7 - 9 X
025-06079-000 FU,DUAL,600V 12A,13X16X5 R:C FUSE 7 - 9 X
025-05741-000 FU,DUAL,600V 15A,13Z16X5 R:C FUSE 7 - 9 X
025-04650-000 FU,DUAL,600V 30A,13X16X5 R:C FUSE 1 - 3 X X X X
025-04650-000 FU,DUAL,600V 30A,13X16X5 R:C FUSE 7 - 9 X X X
025-17407-000 FUHLR,# 1,600V, 30A,1P R:A FUSE 16 - 17 XXXXXX X X X
025-17407-000 FUHLR,# 1,600V, 30A,1P R:A 120V GFCI OUTLET XXXXXX X X X
025-18281-000 FUHLR,#19,250V, 30A,3P R:1 FUSE 7 - 9 X
025-18283-000 FUHLR,#20,250V, 60A,3P R:1 FUSE 7 - 9 X X X
025-18283-000 FUHLR,#20,250V, 60A,3P R:1 FUSE 7 - 9 X X
025-18284-000 FUHLR,#23,600V, 30A,3P R:1 FUSE 7 - 9 X X X X X X
025-18285-000 FUHLR,#24,600V, 60A,3P R:1 FUSE 1 - 6 X X X X X X
025-32733-001 FUSE,600V,30A,CLASS CC R:A 120V GFCI OUTLET XXXXXX X X X
025-27750-000 FUSE,DUAL, 600V1 1/2A, R:A FUSE 16 -17 XXXXXX X X X
025-17392-000 FUSE,DUAL,600V60A,1 1/6 X R:C FUSE 1 - 6 X X X X X X
026-25549-000 GUARD, FAN CONDENSER XXXXXX X X X
025-37487-016 HARNESS,SMOKE DETECTOR R:A 10" LENGTH XXXXXX X X X
025-37487-017 HARNESS,SMOKE DETECTOR R:A 120" LENGTH XXXXXX X X X
029-22126-000 HINGE CONT 8 X 1.5 R:A HINGED FILTER DOOR XXXXXX X X X
026-38657-000 HOOD,RAIN,FLUE *:00 GAS HEAT XXXXXX X X X
025-27709-001 HTR,ELEC,18.0KW,240/ R:A ELEC HEAT X X X
025-27709-002 HTR,ELEC,18.0KW,480/ R:A ELEC HEAT X X X
025-27709-003 HTR,ELEC,18.0KW,600/ R:A ELEC HEAT X X X
025-27709-004 HTR,ELEC,36.0KW,240 R:A ELEC HEAT X X X
025-27709-005 HTR,ELEC,36.0KW,480 R:A ELEC HEAT X X X
025-27709-006 HTR,ELEC,36.0KW,600/ R:A ELEC HEAT X X X
025-27709-007 HTR,ELEC,54.0KW,240/ R:A ELEC HEAT X X X
025-27709-008 HTR,ELEC,54.0KW,480/ R:A ELEC HEAT X X X
025-27709-009 HTR,ELEC,54.0KW,600/ R:A ELEC HEAT X X X
025-27709-010 HTR,ELEC,72.0KW,240/ R:A ELEC HEAT X X X
025-27709-011 HTR,ELEC,72.0KW,480/ R:A ELEC HEAT X X X
025-27709-012 HTR,ELEC,72.0KW,600/ R:A ELEC HEAT X X X
026-38571-000 HTX 6 TUBE SS R:A GAS HEAT XXXXXX X X X
026-38570-000 HTX 8 TUBE SS R:A GAS HEAT XXXXXX X X X
* See UNIT NAMEPLATE or TECHNICAL LITERATURE for the required breaker/max fuse size.
DM240 DM300
Part Number Description Notes or code on wiring diagram 230V 460V 575V 230V 460V 575V 230V 460V 575V
Model and Voltage
DM180
025-27731-002 IGNITOR SPARK W/O TERM R:C SPARK XXXXXX X X X
335-18936-000 INSTR. DM180/240/300 R:A INSTR. PACKET XXXXXX X X X
029-21160-000 ECON 15 TON BAS BAS Only X X X
029-22266-000 ECON 15T SINGLE ENTHALPY PE Only X X X
029-22251-000 ECON 20T BAS BAS Only X X X
029-22250-000 ECON 20T SINGLE ENTHALPY XXX
029-21172-000 ECON 25 TON BAS BAS Only X X X
029-22264-000 ECON 25T SINGLE ENTHALPY XX X
029-22252-000 ECON MOTORIZED DAMPER 20 TON XXX
029-22265-000 ECON MOTORIZED DAMPER 25 TON XX X
029-22127-000 KNOB,TEE STUD. 25 X 20 R:A TOOLESS ACCESS ONLY XXXXXX X X X
035-10176-000 LABEL,DRAIN STD TRAP R:B XXXXXX X X X
035-18919-000 LABEL,WIRING CMPNENT MAP R:A XXXXXX X X X
035-18847-000 LABEL,WIRING DM/DH180DM240R:A XXXXXX
035-18863-000 LABEL,WIRING DM300 R:A XX X
035-18541-000 LABEL,WIRING,CPC R:B BAS Only XXXXXX X X X
035-18526-000 LABEL,WIRING,E18 230V R:B X X X
035-18530-000 LABEL,WIRING,E18 460V R:B X X X
035-18534-000 LABEL,WIRING,E18 575V R:B X X X
035-18527-000 LABEL,WIRING,E36 230V R:B X X X
035-18531-000 LABEL,WIRING,E36 460V R:B X X X
035-18535-000 LABEL,WIRING,E36 575V R:B X X X
035-18528-000 LABEL,WIRING,E54 230V R:B X X X
035-18532-000 LABEL,WIRING,E54 460V R:B X X X
035-18536-000 LABEL,WIRING,E54 575V R:B X X X
035-18529-000 LABEL,WIRING,E72 230V R:B X X X
035-18533-000 LABEL,WIRING,E72 460V R:B X X X
035-18537-000 LABEL,WIRING,E72 575V R:B X X X
035-18538-000 LABEL,WIRING,HNYWLL R:B BAS Only XXXXXX X X X
035-18539-000 LABEL,WIRING,JHNSN R:B BAS Only XXXXXX X X X
035-18951-000 LABEL,WIRING,MTR DMPR 25T Motorized Damper Only X X X
035-18862-000 LABEL,WIRING,MTRZD DAMPER XXXXXX
035-18540-000 LABEL,WIRING,NOVAR R:B BAS Only XXXXXX X X X
035-13904-000 LABEL,YORK, 5.17 X 24.00 R:A XXXXXX X X X
025-19282-000 LUG,GROUND XXXXXX X X X
029-20081-000 MANIFOLD,GAS R:C GAS HEAT XXXXXX X X X
024-24104-000 MOTOR,3/4 HP 230V 3 SPEED POWER EXHAUST FAN X X X
024-24131-000 MOTOR,3/4 HP 460V 3 SPEED POWER EXHAUST FAN X X X
024-24104-001 MOTOR,3/4 HP 575V 3 SPEED POWER EXHAUST FAN X X X
024-27591-004 MOTOR,BLOWER 15HP,230/460 R:A ID FAN X X
024-27591-005 MOTOR,BLOWER 15HP,575 R:A ID FAN X
024-27591-001 MOTOR,BLOWER 5HP,230/460 R:A ID FAN X X
024-27591-002 MOTOR,BLOWER 5HP,575 R:A ID FAN X
024-27591-003 MOTOR,BLOWER 7.50HP,575 R:A ID FAN X
024-27591-006 MOTOR,BLOWER 7.5HP,230/460R:A ID FAN X X
024-31939-002 MOTOR,FAN CONDENSER R:A OD MOTOR X X X X X X
024-31939-003 MOTOR,FAN CONDENSER R:A OD MOTOR X X X
024-25005-001 MOTOR,VENTOR,208/230 V R:B DRAFT MOTOR X X X
024-25005-004 MOTOR,VENTOR,460V R:B DRAFT MOTOR X X X X X X
029-20423-030 ORIFICE,GAS,BURNER,#30 R:A GAS HEAT XXXXXX X X X
029-20422-058 ORIFICE,GAS,PILOT,#58 R:A 8 TUBE XXXXXX X X X
029-20422-065 ORIFICE,GAS,PILOT,#65 R:A 6 TUBE XXXXXX X X X
028-13222-000 O-RING, SQUARE 1.609 ID R:A McDONALDS XXXXXX X X X
025-31987-000 OUTLET, CONVENIENCE R:A 120V GFCI OUTLET XXXXXX X X X
031-01922-000 PHASE,MONITOR PHS XXXXXX X X X
024-32008-000 RELAY SS DC CONTROL R:A BAS Only, LR XXXXXX X X X
024-23972-000 RELAY,CONT 24V50/60HZDPDT R:D DMR XXXXXX X X X
024-24111-000 RELAY,CONT 24V50/60HZDPST R:B RW1 XXXXXX X X X
024-21678-000 RELAY,CONT 24V50/60HZSPDT R:C RW2 XXXXXX X X X
024-24103-000 RELAY,CONT 24V50/60HZSPST R:B HR,RWI,RW2 XXXXXX X X X
024-27552-001 RELAY,OVLD, 5.0- 8.0FLA R:A BOR X X X
024-27552-002 RELAY,OVLD, 8.0-13.0FLA R:A BOR X
024-27552-003 RELAY,OVLD,12.0-20.0FLA R:A BOR X X
024-27552-004 RELAY,OVLD,16.0-25.0FLA R:A BOR X X
024-27552-005 RELAY,OVLD,30.0-50.0FLA R:A BOR X
031-01942-000 RESISTOR,500 OHM R:A BAS Only, HONEYWELL XXXXXX X X X
026-34563-000 SCREEN 1.000X2.000 .062 R:A GAS HEAT XXXXXX X X X
025-27731-001 SENSOR FLAME W/TERM R:C GAS HEAT, SENSOR XXXXXX X X X
031-01120-000 SENSOR HE-6310-2 R:A BAS, JOHNSON XXXXXX X X X
031-00863-000 SENSOR,ENTHALPY R:B BAS, HONEYWELL XXXXXX X X X
031-01943-000 SENSOR,TEMP 20K OHM R:A BAS, HONEYWELL XXXXXX X X X
031-01945-000 SENSOR,TEMP,CPC R:A BAS, CPC XXXXXX X X X
031-01946-000 SENSOR,TEMP,JCI R:A BAS, JOHNSON XXXXXX X X X
031-01944-000 SENSOR,TEMP,NOVAR R:A BAS, NOVAR XXXXXX X X X
028-12026-000 SHEAVE,FXD, BK 90 1GRV,1.000BORE R:A STD SPEED X X X
028-10564-000 SHEAVE,FXD, BK 80 1GRV,1.000BORE R:B HIGH SPEED X X X
028-10577-000 SHEAVE,FXD, BK120 1GRV,1.188BORE R:A STD SPEED X X X
028-12012-000 SHEAVE,FXD, BK110 1GRV,1.188BORE R:A HIGH SPEED X X X
028-13330-000 SHEAVE,FXD,FIX, B5V110 1 GRV R:A STD SPEED X X X
028-04761-000 SHEAVE,VAR, 1VP56, 1GRV,1.125BORE R:C MOTOR PULLEY X X X
028-12010-000 SHEAVE,VAR, 1VP68, 1GRV,1.375BORE R:A MOTOR PULLEY X X X
* See UNIT NAMEPLATE or TECHNICAL LITERATURE for the required breaker/max fuse size.
DM240 DM300
Part Number Description Notes or code on wiring diagram 230V 460V 575V 230V 460V 575V 230V 460V 575V
Model and Voltage
DM180
028-14721-000 SHEAVE,VARIABLE, 1VP75,1 GRV R:A MOTOR PULLEY X X X
029-22196-000 SMOKE DETECTOR ACCESSORY R:A SUPPLY/ RETURN W/ECON XXXXXX X X X
029-22198-000 SMOKE DETECTOR ACCESSORY R:A RETURN WO/ECON XXXXXX X X X
026-37389-000 SUPPORT, OD MOTOR OD MOTOR XXXXXX X X X
024-26065-000 SWITCH, 120V OUTLET 120V GFCI OUTLET XXXXXX X X X
023-16881-000 SWITCH, PRESSURE TAP R:A BAS Only XXXXXX X X X
024-21215-001 SWITCH,100A 600V DS1
024-27548-000 SWITCH,150A 600V DS1
025-32677-000 SWITCH,250A 600V DS1
025-27743-001 SWITCH,LIM,HLX,170/120DEG R:A TLS ELEC HEAT (CONTROL VOLT) XXXXXX X X X
025-27743-002 SWITCH,LIM,HLX,200/150DEG R:A TLS ELEC HEAT (CONTROL VOLT) XXXXXX X X X
025-26392-007 SWITCH,LIMIT R:A TLS ELEC HEAT (CONTROL VOLT) X X
025-26392-004 SWITCH,LIMIT (60TX11) R:A TLS ELEC HEAT (CONTROL VOLT) XXXXXX X X X
025-30249-000 SWITCH,LOW PRESSURE R:A LPS XXXXXX X X X
024-32007-000 SWITCH,PRESSURE DIFF R:A DFS XXXXXX X X X
025-27755-000 TERM BLOCK, 3P,250V 20A R:B TB4 XXXXXX X X X
024-26089-000 TIME DELAY, GAS HEAT (DMC) DMC XXXXXX X X X
025-25973-000 TRANSF .075 KVA 208/230-24 R:D BAS Only X X X
025-25974-000 TRANSF .075 KVA 460PRI-24 R:D BAS Only X X X
025-25974-000 TRANSF .075 KVA 460PRI-24 R:D T2 X X X
025-27729-000 TRANSF .075 KVA 575V-24 BAS Only X X X
025-25973-000 TRANSF .075KVA 208/230-24 R:D T2 X X X
025-27729-000 TRANSF .075KVA 575V/24V T1-T3 X X X
025-17636-000 TRANSF .15KVA 240/480 R:D T2 X X X
025-32672-240 TRANSF 208/230-120V R:A 120V GFCI OUTLET X X X
025-30383-000 TRANSF 3 KVA 600 PRI R:A 120V GFCI OUTLET X X X
025-32762-000 TRANSF 3KVA 240/480 120V GFCI OUTLET X X X
025-37378-000 TRANSF.15 KVA 208/230-24 R:A T1 X X X
025-37378-002 TRANSF.15 KVA 460/575-24 R:A T1 X X X X X X
028-12479-000 TRAP,ADAPTER R:A McDONALDS XXXXXX X X X
028-13237-000 TRAP,CONDENSATE R:A McDONALDS XXXXXX X X X
029-20099-000 TUBE,CARRYOVER R:C 8 TUBE XXXXXX X X X
029-20404-000 TUBE,CARRYOVER R:C 6 TUBE XXXXXX X X X
026-32679-002 VALVE DISTR 4 TUBE # 4ORF R:A X X X
026-32679-003 VALVE DISTR 7 TUBE # 8ORF R:A XXX
026-32679-001 VALVE DISTR 8 TUBE # 8ORF R:A X X X
022-08998-000 VALVE, TXV R:00 R:A XX X
022-06848-010 VALVE,EXP,THRM 48PSI R:A X X X
025-27720-000 VALVE,GAS,36C68-466 R:B GV1&2 XXXXXX X X X
022-06852-001 VALVE,THERMAL EXPANSION R:A XXXXXX
026-25529-004 WHEEL,BLO,15DIA15W1.OBORE R:C ID BLOWER X X X
026-25529-003 WHEEL,BLO,18DIA15W1.2BORE R:C ID BLOWER X X X
026-32631-000 WHEEL,BLO,18DIA15W1.4BORE R:A ID BLOWER X X X
026-32626-000 WHEEL,BLO,4DIA2WD,375BORE R:A CCW DRAFT BLOWER XXXXXX X X X
026-32625-000 WHEEL,BLO,4DIA2WD.375BORE R:A CW DRAFT BLOWER XXXXXX X X X
025-35366-009 WIRE,HARNESS JUMPER R:A NO SMOKE DETECTOR
X
X
X
X
X
X
X
X
X
* See UNIT NAMEPLATE or TECHNICAL LITERATURE for the required breaker/max fuse size.

Navigation menu
