036300 314 Cosy Time Sleeper Grey_IMWEB Grey IMWEB

User Manual: 036300-314 Cosy Time Sleeper - Grey_IMWEB

Open the PDF directly: View PDF PDF.
Page Count: 16

IMPORTANT:
RETAIN FOR FUTURE REFERENCE,
READ CAREFULLY
Cosy Time
Co-Sleeper “Grey”
#036300-314
Read all instructions before assembly and use of the co-sleeper. Keep
instructions for future use.
SAFETY PRECAUTIONS
WARNING
2
NEVER LEAVE THE CHILD UNATTENDED IN THE CO-SLEEPER.
IT IS DANGEROUS TO PLACE THE PRODUCT ON A RAISED SURFACE SUCH AS A TABLE.
DO NOT USE THE PRODUCT IF ANY PART IS BROKEN, TORN, OR MISSING.
ONLY AN ADULT SHOULD ASSEMBLE, FOLD AND UNFOLD THE CO-SLEEPER.
BEFORE ASSEMBLY, CHECK THAT THE PRODUCT AND ALL OF IT’S COMPONENTS HAVE NOT BEEN
DAMAGED DURING TRANSPORTATION. SHOULD ANY PART BE DAMAGED, DO NOT USE AND KEEP OUT
OF REACH OF CHILDREN.
ENSURE USERS OF THIS PRODUCT ARE KNOWLEDGEABLE ON IT’S CORRECT OPERATION.
DO NOT POSITION THE COT NEAR WALLS AND OBSTACLES TO PREVENT ENTRAPMENT.
DO NOT ADJUST THE PRODUCT WITH THE CHILD INSIDE.
DO NOT MOVE THE PRODUCT WITH THE CHILD INSIDE.
DO NOT USE THE PRODUCT WITH MORE THAN ONE CHILD AT A TIME.
This product is intended for use for babies aged between 0 and 5 months, weighing up to a maximum of 9kg.
When a child is able to sit, kneel or to pull itself up, the product should not be used anymore for this child.
Before use in ‘co-sleep’ mode ( xed to the bed), make sure the product is securely anchored and positioned.
When the product is used in ‘co-sleep’ mode ( xed to the bed), make sure the connection belts are hooked and
tensioned properly, before laying child in the sleeper. The product must be secured to the parent’s mattress and
no gaps between the product and the adult’s mattress must be present.
DO NOT use the sleeper without the support frame. Keep the fastening belts out of reach of children.
The thickness of the uncompressed mattress shall not exceed 25mm. The upper surface of the non compressed
mattress must be at least 191mm lower than the upper surface of the lowest side of the bedside sleeper.
If you purchase a mattress separately, ensure that it is suitable for the product.
DO NOT leave any object inside the product that could reduce it’s depth.
Be aware of the risk of open  res and other sources of strong heat, such as electric bar heaters, gas  res etc.
The product is ready for use only when all locking mechanisms are engaged. Check carefully that these are
engaged before use.
Failure to follow these warnings and instructions could result in serious injury or death.
NEVER use the snuggle time co-sleeper bassinet in co-sleeper position without the anchor plate attached and
locked as shown. Failure to use this anchoring system could result in serious injury or death to the infant. Make
sure all straps are secured and tight. Check straps before each use.
SUFFOCATION HAZARD: Discard all packing materials immediately after opening. Plastic bags and ties may
cause suffocation or choking.
FALL HAZARD: To help prevent falls, do not use this product when infant begins to push up on hands and knees
or has reached manufacturer’s recommended maximum weight of 9kgs, whichever comes  rst.
SAFETY PRECAUTIONS
WARNING
WARNING
3
SUFFOCATION HAZARD - INFANTS HAVE SUFFOCATED IN GAPS BETWEEN EXTRA PADDING AND SIDE
OF BASSINET/CRADLE AND ON SOFT BEDDING.
USE ONLY THE PAD PROVIDED BY MANUFACTURER.
NEVER ADD A PILLOW, COMFORTER OR ANOTHER MATTRESS FOR PADDING.
ENTRAPMENT HAZARD - TO PREVENT DEATH FROM ENTRAPMENT, BEDSIDE SLEEPER MUST BE
PROPERLY SECURED TO ADULT BED USING THE ATTACHMENT SYSTEM
If a sheet is used with the pad, use only the one provided by CNP Brands.
To reduce the risk of SIDS, paediatricians recommend healthy infants be placed on their backs to sleep, unless
otherwise advised by your physician.
A bedside sleeper is designed to provide a sleeping area for an infant until he or she begins to push up on
hands and knees or approximately 5 months of age. Move your child to another sleeping product when your
child reaches this stage.
STRANGULATION/SUFFOCATION HAZARD: The top edge of the lowering bar must be level with or below the top of
the adult mattress when used as the bedside sleeper. The level of the bedside sleeper bassinet mattress must
be a minimum of 10cm below the top edge of the lowering bar. NEVER raise the level of the cosy time sleeper
bassinet mattress.
NEVER use plastic shipping bags or other plastic  lm as mattress covers not sold and intended for that purpose.
They can cause suffocation.
Make sure all straps are secured and tight when used in the bedside sleeper position. Tighten straps periodically.
There must be no more than 1/2 inch (13mm) gap between bedside sleeper and adult bed.
Check tightness before each use by pulling bedside sleeper in a direction away from adult bed.
If gap exceeds 1/2 inch (13mm) DO NOT use product. DO NOT ll the gap with pillows, blankets or other items
that are suffocation hazards.
Always read and follow assembly instructions for each product use mode (bedside sleeper, bassinet, play yard).
Always use ALL required parts for each use mode. Check instruction manual for a list of required parts.
Periodically check product for loose, damaged, or missing parts.
The anchor plate and straps assembly must always be used in bedside sleeper mode.
NEVER use this product if there are any loose or missing fasteners, loose joints, broken parts, or torn mesh/
fabric. Check before assembly and periodically during use. Contact CNP Brands for replacement parts. Never
substitute parts.
Assemble product according to manufacturer’s instructions for ANY use mode - bedside sleeper as well as the
bassinet.
To avoid death from the infant’s neck being caught on the top rail on the side that is next to the adult bed, the
top rail must be no higher than the adult bed mattress.
NEVER permit bedding from the adult bed to extend into the bedtime sleeper.
4
SAFETY PRECAUTIONS
NEVER leave your infant in the product without the TOP HORIZONTAL RAIL installed in the upper most position,
unless securely attached to the adult bed.
Failure to use this securing system will allow the cosy time sleeper to move away from the adult bed and could
result in the infant falling out of the bedside sleeper bedside bassinet.
STRANGULATION HAZARD: When anchor plate and strap assembly are not in use, store in a safe place not
accessible to children.
DO NOT place product near a window where cords from blinds or drapes may strangle a child.
Keep the bassinet away from stoves, heaters, camp res and other hazards.
DO NOT allow children to climb or play on or under unit in any con guration.
FALL HAZARD: Remove infant from the cosy time sleeper before starting any conversions.
Always make sure all top and bottom rails are securely locked, in all con gurations, before putting an infant
child into the unit.
To prevent serious or fatal injury from falls always keep child within arm’s reach. Never leave your child
unattended.
Strings can cause strangulation! Do not place items with a string around a child’s neck, such as hood strings
over a bassinet or cradle or attach strings to toys.
The bedside sleeper is designed for use only with adult beds that are between 18.5 and 24 inches (45cm to
55cm) from  oor to top of adult mattress.
Due to variations in the style and design of our products, the photographs and illustrations shown in this
instruction manual are generic, therefore product fabrics, colour and design may vary from images shown.
CNP Brands reserves the right to alter product speci cations without notice as a result of our ongoing
policy of product improvement.
Contents
Assembly contents list
Assembly / Operating instructions
How to care for your Cosy Time Co-Sleeper
Congratulations on your purchase of the Cosy Time
Co-Sleeper.
This product has been designed and developed with safety,
comfort and functionality in mind. Please take the time to read
this manual carefully before using this product and keep it in a
safe place for future reference.
CONGRATULATIONS
5
ASSEMBLY CONTENTS
Check what you have received...
You have received 1 box. Please check the contents of the
box against the list below. If anything is missing, please contact
Customer Service.
In Australia, contact CNP Brands on 1300 667 137, in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
Supplied loose in box:
Sleeper Frame Mattress with
removable cover
x 1 x 1
x 1 x 1
Middle support
frame Outer Travel bag
There are no accessories recommended for use with this Childcare Cosy TIme Co-Sleeper.
6
ASSEMBLY CONTENTS
7
Fully assembled product:
A: Sleeper Frame
B: Middle Support Frame
C: Fixing Belts
D: Mattress with removable cover
A
B
D
C
ASSEMBLY / OPERATING INSTRUCTIONS
To assemble Frame and Bassinet Liner...
1
3
4
2
Unzip the carry bag and remove the sleeper.
Lay the sleeper frame face down on a  at surface.
Holding the central supporting structure, turn both of
the legs outward.
You will hear the frame click into position once it is in
place.
Make sure both sides are securely locked into place.
Once the frame is secure, turn the unit onto it’s feet.
Place the mattress into the sleeper with the curved
edges of the mattress re ecting the curved edges of
the sleeper.
Select the middle support frame and gently push it
into the side slots as per image.
1a.
1b.
1c.
3a.
3b.
4a.
4b.
2a.
8
Your Cosy Time Co-Sleeper is now ready for use.
ASSEMBLY / OPERATING INSTRUCTIONS
To adjust height of Co-Sleeper...
To  x to bed in Co-Sleeper mode...
1
1
2
2
The sleeper can be adjusted to different height
positions.
To adjust the height, push the adjuster button then
turn the cap clockwise to lower the sleeper or anti
clockwise to raise the sleeper.
Turn the cap to the desired height.
Unzip the sides of the sleeper until they are completely
unzipped.
Push in the pop pin located on the top of the bar.
Slide the bar away from the pop pin.
The bar on both ends will slide out freely.
Roll up the unzipped side and secure with velcro.
Repeat this operation on the opposite side.
1a.
1b.
1c.
1a.
1b.
2a.
2b.
2c.
2a.
10
ASSEMBLY / OPERATING INSTRUCTIONS
To  x to bed in Co-Sleeper mode (continued)...
11
3
4
5
6
Move the sleeper close to the parent’s bed and check
the height of the sleeper compared with the mattress
on the bed.
The side support of the sleeper should always be
placed close to the parent’s mattress and the mattress
should always be aligned with the height of the side
support for restraint of the sleeper.
In order to  x the co-sleeper to the parent’s bed in co-
sleeping mode, use the attached pair of  xing belts
provided.
Slide the straps between the top mattress and the
base using a back and forth ‘sawing’ motion and at
the same time pulling downward until the straps and
anchor plates are in the desired position.
Tighten the loop by pulling the belts  rmly.
Adjust the belts separately until the sleeper is  rmly in
contact with the parent’s mattress.
Store any excess of belts between the mattress and
the bed base.
3a.
3b.
4a.
5a.
7a.
7b.
7c.
CAUTION! Ensure the  xing belts are straight
To  x to bed in Co-Sleeper mode (continued)...
ASSEMBLY / OPERATING INSTRUCTIONS
13
Before every use always check to make sure there is no space between the parent’s
mattress and the side of the sleeper.
If there is, pull the belts  rmly to tighten until there’s no space and the permitted condition of
use has been restored.
Use of product is only permitted with beds and/or mattresses with straight sides, use of the
product with round mattress and or water bed is not permitted.
When the product is used in the co-sleeping mode, it should always be  tted to the long
side of access to the bed, do not  x the product to the bed or bottom of the bed.
Never use the Cosy Time Sleeper in co-sleeping position without
the anchor plate. Ensure the plate is securely attached to the
adult bed.
ASSEMBLY / OPERATING INSTRUCTIONS
To assemble freestanding Bassinet...
1
2
Release the rolled up velcro fastening and zip up both
sides of sleeper.
Re-insert bar into top of side panel.
Line up the bar of the support frame as shown in the
image.
Gently push the bar until it ‘clicks’ into position.
Repeat for the other side.
1a.
1b.
2a.
2b.
2c.
14
To remove Lining...
1
2
Remove the mattress and release the velcro tabs from
the middle support frame.
Release the velcro straps from the sides of the sleeper
as per image.
Locate the zip underneath the fabric lip of the
structure and unzip.
1a.
2a.
2b.
ASSEMBLY / OPERATING INSTRUCTIONS
3Gently remove the lining from the upper tubular
structure, making sure not to damage the internal
part of the lining.
3a.
15
To remove Lining (continued)...
To disassemble Co-Sleeper...
1Follow the steps ‘To remove Lining...’ on page 14 to remove the sleeper lining from
the structure.
Repeat the steps ‘To assemble Frame’ in reverse to collapse the co-sleeper.
Remove the middle support frame by pressing the fastening pins on both side of
the sleeper.
1a.
1b.
1c.
This method is only possible with bed types that comply with all of the conditions described
in this paragraph.
In particular, the side support of the crib should always be put close to the parent’s mattress
and the mattress should always be aligned with the height of the side support for restraint of
the crib. Furthermore, the crib should be  rmly  xed to the structure of the parent’s bed or to
the mattress support.
Check to make sure that the crib in the co-sleeping mode does not interfere with the
parent’s bed.
During use, make sure that the parent’s bed sheets, blankets etc, do not enter and cover the
interior of the sleeper.
HOW TO CARE FOR YOUR CHILDCARE CO-SLEEPER
Cleaning
Maintenance
This product has been designed and developed with safety, comfort and
functionality in mind. Please take the time to read this manual carefully
before using this product and keep it in a safe place for future reference.
To ensure the long-lasting use of your co-sleeper, do not use solvents,
abrasives or aggressive cleaning products. After each wash check the
resistance of the fabric and the stitching. For washing of the fabric, carefully
comply with instructions indicated on the label (listed below).
Always check parts regularly for tightness of screws, nuts and other fasteners
– tighten or replace if required. The co-sleeper and the mattress have a
resistant fabric cover which is completely removable and washable. The
removal of the fabric should be carried out by an adult only. On a regular
basis check the condition of the product and presence of any possible
damage. In the case of damage do not use and keep it out of the reach
of children. To maintain the safety of your co-sleeper seek prompt repairs
for bent, torn, worn or broken parts. Use only those parts and accessories
approved by CNP Brands.
If you have any dif culties in assembling the co-sleeper, please contact
our Service Department.
In Australia, contact CNP Brands on 1300 667 137, in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
16
Hand wash in cold water DO NOT iron
DO NOT dry clean
DO NOT bleach
DO NOT tumble dry
ABOUT US
About CNP Brands
Currently, CNP Brands boasts one of the most diverse brand portfolios
with a combination of company owned brands and distribution
agreements. These include distribution lines for 4moms, Brica, Cybex,
Even o, Good Baby, Lascal, Maclaren, Motorola, Munchkin, OiOi
and Summer Infant.
Our own brands, including Childcare, have gone from strength to
strength in recent years. Childcare, and our premium brand bebe
care, demonstrate our commitment to quality and continuing
investment in product development.
17
Distributed in Australia by CNP Brands
20 Calarco Drive,
Derrimut, VIC, 3030
Customer Service 1300 667 137
W: www.cnpbrands.com.au
E: info@cnpbrands.com.au
F: www.facebook.com/CNPBrands
I: @cnp_baby
Distributed in New Zealand by Wainhouse
Distribution
2-6 Argyle St, Morningside,
PO Box 41-014,
St Lukes, Auckland, New Zealand
Customer Service: 0800 567 5000
E: helpline@wainhousedist.co.nz

Navigation menu
