CD Receivers Brochure
Circle Surround II
Digital circuits benefit from signals staying in
the digital domain as long as possible, helping
to minimize distortion and noise. All signal
processing in the CD Receivers remains
entirely in the digital domain until the last stage
prior to power amplification. The final level of
audio performance also relies on high-
performance digital to analog conversion. As
this process greatly influences final sound
quality, a proprietary DAC is utilized so
distortion is minimized and S/N ratio stays
high.
High-performance DSP
Parametric EQ
This sophisticated equalization method is the
best for achieving a smooth, well-balanced in-
car system frequency response that
overcomes the frequency peaks and dips often
encountered in automobile environments due
to the combination of hard, reflective surfaces
and soft, absorbing surfaces. Parametric EQ
allows selecting a frequency band as well as
bandwidth for an even system response.
3-band Graphic EQ
An additional EQ method to
adjust the tonal characteristics
of program material to suit
user preferences.
High voltage and low impedance output
Focus
Generates virtual speakers that create a
front-firing, higher-positioned soundfield.
TruBass
Generates a virtual subwoofer for
satisfying low frequency
reinforcement.
Circle Surround
Multichannel surround
sound is generated from
any audio source.
Analog AM/FM signal is sent to a A/D converter before entering the DSP.
CD
CD-R/RW
MP3
DSP AMP
SP
D/A
converter
DigitalDigital AnalogAnalog
Conversion
CD Receiver Amp
Speaker
Normal Voltage Because the amplitude ratio is high,
the amplitude of the noise carried in the signal
is also high.
VoltageVoltage
Signal Noise
+Noise
+Noise
Signal Noise
Amplitude
ratio XL
High Voltage Because the amplitude ratio is low,
the amplitude of the noise carried in the signal
is also low.
Amplitude
ratio S
This technology enhances in-car listening
enjoyment with a powerful combination of
three functions. Circle Surround generates
surround sound from any audio source such
as CDs, MP3 files and radio broadcasts with
just four speakers. Focus raises the stereo
soundfield, making the sound appear to be
coming from directly in front at ear level.
Its use complements surround sound to
create a rich, enveloping soundfield. TruBass
is technology based on psychoacoustics and
scientific knowledge of the human hearing
system to generate bass sounds extending
lower than a small speaker’s response so that
a subwoofer is not required.
The new CD Receiver line delivers outstanding audio performance across the board for each model. By adhering
to ECLIPSE’s time-proven audio philosophy and incorporating advancements where possible by combining the
best of digital and analog, the new CD Receivers provide significantly better audio quality that greatly enhances
the enjoyment of music.
Featured in the CD8455 and CD8445, this single
sophisticated chip contains the Parametric EQ,
Multi-Harmonizer, Time Alignment and
Crossover functions as well as level.
Audio
Highend audio products usually are
engineered to have preamp outputs that have
high voltages along with low impedances.
These characteristics are desirable from an
audio electronics point of view as they enable
driving downstream amplifiers optimally to
reap other benefits such as a higher signal-
to-noise ratio and increased dynamics. Each
CD receiver ensures any connected external
amplifier will deliver optimal performance.
CD8455/8445: 8V at 55Ω
CD5435/5425/5415/5405: 5V at 55Ω
2
CD8455 (Pro off), CD8445 (Adv. on)
CD8455/8445
CD8455/8445
CD8455/8445 (Adv. on)
CD5435/5425/5415/5405
High-performance 24-bit ∆∑
D/A converter
AUX Input
When connecting external sources, the
AUX input has adjustable sensitivity for
perfect matching to cut extraneous noise
and improve S/N ratios.
MOSFET 50W × 4
power amplification
MOSFET devices are used for power
amplification due to their desirable
characteristics — drawing less current
and requiring less power — as well as
providing a more natural sound.
Multi-Harmonizer
Digital music files in formats such as
MP3, WMA and ATRAC3 lose harmonic
data during the encoding process because
of the compression that is applied. Multi-
Harmonizer restores the lost harmonic
data, allowing files to sound much better.
Crossover
To create a smoother, system response in
a multi speaker unit system the frequency
point and slope can be tweaked for
optimal crossover settings .
Area Shot
New E-iSERV advances
At home
In the Car
Access E-iSERV from a
personal computer.
Input start point and destination
information — street address, city,
state, and zip code.
Start Area Shot to display first map.
View the map(s) and confirm
the route.
As the first mapped area (Area Shot)
is approached, an indication in the
display will activate.
After the required number of Area
Shots, the destination will be reached.
Download the completed route
data onto:
Memory Stick: CD8455, CD8445
CD-R: CD8455, CD8445
CD5435, CD5425
Load the data (on MS or CD-R)
into the CD Receiver.
Can set up to 3 “on-the-way”
stopping locations.
User’s PC
User’s vehicle
Customized audio data for the user’s very own
car as well as basic map data for use in Area
Shot can be downloaded from the E-iSERV
server and transferred to Memory Stick or a
CD-R for inputting into the head unit to enable
customized optimization.
or
Internet
connection
Data from the user’s vehicle such
as system frequency response can
be downloaded onto a Memory
Stick then taken to the user’s PC to
access the internet-based E-iSERV
database.
Motion Picture
Customization for the display panel in the CD8455
and CD8445 is possible. The proprietary “cutting
board” application can be downloaded and up to
100 favorite images can be put together to create
an up to 10 sec. animated sequence.
Original music file
MP3 file
Lost harmonic data
Restored harmonic data
E-iSERV
Notes : Areas Shot is convenient for reviewing the route. However, the car must not be in motion when using Area Shot.
GPS option for CD8455 and CD8445 allows current position to be displayed.
ECLIPSE’s E-iSERV has raised user
customization to a new level that many thought
could not be done. By using the internet and a
personal computer, the user can access
functions and features that can optimize in-car
system response and provide map guidance,
along with customizing displays and
enhanced control abilities.
Adding value to CD Receivers with map viewing
and route assistance, this feature allows
searching for a destination and downloading the
route to get there. Once the data has been
input into the CD Receiver, it can be viewed to
confirm the route.
www.eclipse-web.com
Time Alignment
Electronic delay lines make sure the
sounds from all the speaker units arrive at
the listener’s ears simultaneously for a
much more natural sound with improved
imaging. CD8455/8445 (Adv. on)
CD8455/8445/5435/5425
CD8455/8445
All units
CD8455/8445/5435,CD5425 (optional)
This is where E-iSERV starts!
E-iSERV
Original database
Audio Customize
Area Shot Motion Picture
Other Content
3
Audio Customize
CD8455
3WAY Multi (6 Speakers) 4SP + Subwoofer (5 Speakers) 4SP + Subwoofer (5 Speakers)
CD8445
Time Alignment Optimizes system response by manipulating the arrival times of sounds from various speakers positioned in different
locations to arrive at a listener’s ears simultaneously, creating better imaging. Initial adjustment starts with selecting a mode.
Access E-iSERV from a personal computer to start audio customization with 3 independent processes.
Crossover
The data from the two
customization procedures above
can then be downloaded to the
user’s computer where it can be put
on a Memory Stick which can then
be inserted into the CD Receiver.
Allows selecting the frequency points where one speaker component’s response crosses over to another driver.
The goal is to achieve a smooth, natural response across the entire frequency spectrum, without speaker discontinuities.
Parametric EQ
In the Time Alignment Pro
mode window, follow the
directions and input values to
set time delay and speaker
level for each of the system’s
speakers one by one. Each
speaker is highlighted in the
display so adjustment is
simple and all data is input
into the E-iSERV server.
In the Time Alignment
Easy mode window, the
process is simpler, with
vehicle type such as
sedan, compact, SUV
etc., tweeter and rear
speaker positions to
select.
In the Crossover Pro mode
window, speaker cutoff
frequencies and slope
settings can be selected for a
system comprising full 3-way
multi component speakers as
well a 4-speaker plus
subwoofer system.
Allows selecting the
subwoofer and the
frequency at which it
comes into operation.
In the Parametric EQ Pro
mode window, the
amplitude, center frequency
and bandwidth for each of
ten frequency bands can be
adjusted: 5 bands each for
the front and rear speakers
and 5 bands each for the low
and high frequencies can be
selected for each channel.
In the Parametric EQ
Easy mode window,
7 frequency bands
across the entire
frequency spectrum
for each channel can
be adjusted.
Defeats a car’s interior acoustic anomalies that cause significant peaks and dips in the overall
frequency response with precise equalization control that can pinpoint problem frequencies.
The optimized parametric EQ settings can now be downloaded onto a Memory Stick which
again can be inserted into the CD Receiver that automatically makes the necessary changes.
Now the user’s car optimization process is complete.
Easy
Professional Professional
Once the CD Receiver has
received the data it will run a
frequency analysis. This data
is then downloaded to an MS
so that it can be sent to
E-iSERV via a PC.
4
Others
Catering to dedicated audio-only requirements, ECLIPSE’s CD Receivers have been redesigned to offer a significantly
higher level of performance along with new and upgraded features.
The CD8455 and CD8445 have all the features and performance to satisfy the most discerning music lover. Able to extract
the best performance from CD, CD-R/RW, WMA and MP3 music files, both units demonstrate exceptional audio quality
and user convenience. ECLIPSE's innovative interactive E-iSERV can be accessed to achieve results that previously
required trained technicians with test equipment.
CD8455
ESN E8 High-Power “Pro Customize” CD/MS Receiver
with MP3/WMA Decoder and Remote
CD8445
ESN E8 High-Power “Customize” CD/MS Receiver
with MP3/WMA Decoder and Remote
MOSFET 50W × 4 (max.) MOSFET 50W × 4 (max.)
•CD, CD-R/RW, WMA and MP3
compatibility
•Circle Surround II (pro mode off)
•E-iSERV connectivity
•Area Shot (basic map, arrow and text)
•GPS unit-ready
•Motion Picture
•Advanced 2-mode Sound Control DSP:
•Parametric EQ
10 band (pro mode on)
17 band (pro mode off)
•Multi-Harmonizer
•Time Alignment
•Crossover
•Listening Position Selector
•Source Volume Control
•Memory Stick-ready for
recording/playback (ATRAC3)
•All digital circuitry with advanced 24-bit
∆∑ D/A converter
•High 8V preamp output with low 55Ω
impedance
•HD Radio-ready
•SIRIUS Satellite Radio-ready
•FM/AM tuner
•MOSFET power amplification
•8-step full dot VF display
•5-pattern illumination
•MS and CD ESN security
•Digital input
•3 prs. pre outputs
•Aux input
•Remote control
•CD, CD-R/RW, WMA and MP3
compatibility
•Circle Surround II (advanced mode on)
•E-iSERV connectivity
•Area Shot (basic map, arrow and text)
•GPS unit-ready
•Motion Picture
•Advanced 2-mode Sound Control DSP:
•7-band Parametric EQ
(advanced mode on)
•Multi-Harmonizer
•Time Alignment
•Crossover
•Listening Position Selector
•Source Volume Control
• Memory Stick-ready for
recording/playback (ATRAC 3)
•All digital circuitry with advanced 24-bit
∆∑ D/A converter
•High 8V preamp output with low 55Ω
impedance
•HD Radio-ready
•SIRIUS Satellite Radio-ready
•FM/AM tuner
•MOSFET power amplification
•8-step full dot VF display
•5-pattern illumination
•MS and CD ESN security
•3 prs. pre outputs
•Aux input
•Remote control
5-pattern illumination
ECLIPSE has added the ability to
change a CD Receiver's illuminated
colors, allowing the user to select a
color combination that
complements the car interior or just
to vary the color as desired.
Illumination can be instantly
switched between Blue+Red,
Blue+Amber, Blue+Green, All Green
and All Red.
Blue+Red Blue+Amber Blue+Green
All Green All Red
CD Receivers
5
Vary the CD Receiver’s illumination color to
enhance the car’s interior appearance.
CD8455/8445/5435
The difficult task of providing the most in-demand features of a head unit in terms of performance and convenience has
been met in a spectacular manner with the CD5435 and CD5425 units. Well ahead of any other head units in their class,
the CD5435 and CD5425 offer superior performance for handling just about any form of audio optical disc. The CD5435
will also accommodate WMA files.
CD5435
ESN E5 High-Power “Full-Face” CD Receiver
with MP3/WMA Decoder and Remote
CD5425
ESN E5 High-Power “Full-Face” CD Receiver with MP3 Decoder
MOSFET 50W × 4 (max.) MOSFET 50W × 4 (max.)
•CD, CD-R/RW, WMA and MP3
compatibility
•E-iSERV connectivity
•Area Shot (arrow and text)
•1-bit DAC
•3-band Graphic EQ
•Crossover
•Source Volume Control
•5V preamp output with low 55Ω
impedance
•Bright and clear LCD display
•5-pattern illumination
•HD Radio-ready
•SIRIUS Satellite Radio-ready
•FM/AM tuner
•MOSFET power amplification
•ESN security
•3 prs. pre outputs
•Aux input
•Remote control
•CD, CD-R/RW and MP3 compatibility
•E-iSERV connectivity
•Area Shot (arrow and text)
•1-bit DAC
•3-band Graphic EQ
•Crossover
•Source Volume Control
•5V preamp output with low 55Ω
impedance
•Bright and clear LCD display
•HD Radio-ready
•SIRIUS Satellite Radio-ready
•FM/AM tuner
•MOSFET power amplification
•ESN security
•3 prs. pre outputs
•Aux input-ready
•Remote control-ready
8-step full dot VF display
The top models in the CD Receivers line
incorporate full dot vacuum fluorescent
displays with highly legible alphanumeric
characters. There are also eight levels of
adjustment to suit user preferences as well as
a Bright & Dimmer control for more
adjustment. E-LAN data link system
ECLIPSE's E-LAN only requires a single cable
that carries control signals as well as
transmission signals to connect components
of a mobile entertainment system. E-LAN
also ensures upstream compatibility with
future ECLIPSE products.
SVC (Source Volume Control)
The fully digital circuitry featured in the new
CD Receivers makes it possible to offer
functions such as Source Volume Control that
can automatically level the volume settings of
all sources, eliminating the annoying
differences in volume experienced when
switching from radio to CD or DVD.
6
ECLIPSE's proven theft-deterrent measure
uses a user-designated CD or a Memory Stick
depending on the CD receiver model to
control system activation. The selected media
can be set to be a key device that the system
must "see" before it will activate. Without the
key device, the system remains locked and
will not operate.
CD8455/8445
CD8455/8445/5435/5425/5415
CD8455/8445/5435/5425
All units
These two CD Receivers overturn preconceived ideas of entry level receivers. Designed to deliver the best from the two
most popular sources of music today, CDs and MP3s, the CD5415 will please anyone who enjoys listening to music. The
CD5405 is more focused on CDs.
CD5415
ESN E5 High-Power CD Receiver with MP3 Decoder
CD5405
ESN E5 High-Power CD Receiver
MOSFET 50W × 4 (max.) MOSFET 50W × 4 (max.)
•CD, CD-R/RW and MP3 compatibility
•3-band Graphic EQ
•1-bit DAC
•5V preamp output with low 55Ω
impedance
•Bright and clear LCD display
•HD Radio-ready
•SIRIUS Satellite Radio-ready
•FM/AM tuner
•MOSFET power amplification
•ESN security
•3 prs. pre outputs
•Remote control-ready
•CD and CD-R/RW compatibility
•3-band Graphic EQ
•1-bit DAC
•5V preamp output with low 55Ω
impedance
•Bright and clear LCD display
•FM/AM tuner
•MOSFET power amplification
•ESN security
•Dual pre outputs
(rear/non-fader selectable)
•Remote control-ready
7
Options
CH3083
8-Disc CD Changer with Magazine Unit
AUX 105
Optional CD5425-dedicated AUX IN cable
Functioning as an immense mobile
jukebox with storage for 8 CDs, the
CH3083 is ideal for increasing
music content as it is also
compatible with CD-R/RW discs.
•CD and CD-R/RW discs
•8 disc magazine
•Coaxial digital output
•Multiple unit connectivity (2 units)
•Precision optical pickup
•“No disc contact” transport
•Reinforced high-rigidity chassis
RMC 105
New ergonomic design remote enhances operation.
Included with CD8455, CD8445 and CD5435,
optional with CD5425, CD5415 and CD5405
Wireless Remote
AUX Cord
Options
14.4V Power Supply CD8455 CD8445 CD5435 CD5425 CD5415 CD5405
Max. Power Output 50W × 4
RMS Power Output* 14W × 4 (20Hz ~ 20kHz, 1% THD, 4Ω)
Lineout Output Level/Impedance 8V(0dB)/55Ω 5V(0dB)/55Ω
Tone Bass/Mid/Treble ±12dB at 80Hz/±12dB at 630Hz/±12dB at 10kHz
Control Loudness +10dB at 100Hz/+6.5dB at 10kHz
FM Frequency Range USA: 87.75 ~ 107.9 MHz (0.2MHz step) Latin America: 87.75 ~ 107.9 MHz (0.1MHz step)
Usable Sensitivity 13dBf
50dB Quieting Sensitivity 14dBf
Frequency Response 30 ~ 15.000Hz ±3dB
Stereo Separation 38dB (1kHz)
AM Frequency Range USA: 530 ~ 1,710kHz (10kHz step) Latin America: 530 ~ 1,710kHz (10kHz step)
Usable Sensitivity 20µV
CD Frequency Response 20 Hz ~ 20,000Hz, ±3dB
S/N Ratio (A-weighted) 100dB 95dB
Total Harmonic Distortion 0.008%
Stereo Separation 85dB 80dB
Memory Frequency Response 20 Hz ~ 20,000Hz, ±3dB —
Stick S/N Ratio (A-weighted) 100dB —
Total Harmonic Distortion 0.008% —
Dimensions (W × H × D) 7˝ × 2˝ × 6-1/8˝ (178 × 50 × 155mm)
Specifications * Meets CEA2006 guidelines
SIR-ECL1
ECLIPSE COMPATIBLE SIRIUS SATELLITE RADIO TUNER
Optional for: CD8455, CD8445, CD5435,
CD5425, CD5415
Dimensions (W × H × D)
4-9/64˝ × 1-3/8˝ × 4-59/64˝
105 × 35 × 125mm
Optional for: CD8455, CD8445, CD5435,
CD5425, CD5415
Dimensions (W × H × D)
6-19/64˝ × 1-7/16˝ × 6-29/32˝
160 × 36.5 × 175mm
GPS105
GPS Unit
Connects to compatible CD Receiver units for use with Area Shot to
enhance its features.
Optional for: CD8455, CD8445
Digital Radio Options
HDR105
HD Radio Tuner Unit
8
Feature List
CD8455 CD8445 CD5435 CD5425 CD5415 CD5405
CONTROL
Remote Control ●●●Optional Optional Optional
CD Changer Control ●●●●●—
CD-R/CD-RW ●●●●●●
WMA ●●●———
MP3 ●●●●●—
Digital Servo System (DSS) ●●●●●●
TUNER
FM / AM ●●●●●●
Station Name Input ●●————
HD Radio / SIRIUS Satellite Radio-ready ●●●●●—
AUDIO
Output Voltage and Impedance 8V/55Ω 8V/55Ω 5V/55Ω5V/55Ω5V/55Ω5V/55Ω
MOSFET Amplification ●●●●●●
All Digital circuitry 24-Bit ∆∑ DAC ●●————
Source Volume Control (SVC) ●●●●——
Sound Control Mode Professional Advanced — — — —
On Off On Off — — — —
3-band Graphic EQ ———— ●●●●
Circle Surround II —●●—————
Bass/Mid/Treble Control ●——●●●●●
Time Alignment ●●●—————
Parametric EQ 10-band 7-band 7-band — — — — —
Multi-Harmonizer (MP3/WMA/ATRAC3) ●●●● ————
Listening Position Selector ●●●● ————
Crossover ●●●● ● ● ——
Non Fader Level / Phase Control ●●●● ● ● ——
SFC ———●————
Frequency Response Analysis ●●● —————
Non Fader PreOut ●●●●●Selectable (Rear)
3 Prs. Pre Outputs ●●●●●Selectable (Rear)
Digital Input ● —————
AUX In ●●●Optional — —
GENERAL
ATRAC3 Decoder/Encoder ●●————
E-iSERV Connection MS or CD-R MS or CD-R CD-R CD-R — —
ESN MS or CD MS or CD CD CD CD CD
Display 8-step VF 8-step VF LCD LCD LCD LCD
Full Face Tilt ●●●●——
E-LAN data link system ●●●●●—
• To ensure safe operation of products, please read the
owner’s manuals carefully prior to use.
• ECLIPSE is not responsible for accident or damage due
to improper connections or products modified in any
way.
Warning
• All products are intended for DC 12-Volt operation in
negative grounded vehicles only. Never use them in 24-
Volt vehicles such as heavy trucks or diesel cars with
cold-region specification.
• Do not adjust controls while driving. To adjust the
controls, stop the car in a safe location.
Caution
• Installation of products requires experience and
knowledge. Ask your ECLIPSE retailer for proper
installation.
• E-iSERV graphic examples are from pre-release software
and may slightly vary from the finalized version.
General
• Product design and specifications are subject to change
without prior notice as ECLIPSE constantly seeks to
improve its products.
• Due to characteristics and properties of various
photography and printing processes, the color(s) of the
actual product may slightly differ from those shown on
these pages.
• Some screen images shown are simulated.
Operation notes
• Area Shot operations cannot be accessed during driving.
• Map data created for use with Area Shot based on
information provided by Tele Atlas and Geographic Data
Technology.
• Use map data while being aware of actual road conditions
and obeying traffic rules.
• Copying, publishing and the use of maps in electronic
media or form are only possible when express written
consent has been obtained prior to usage.
Others
• It may not be possible to install all products in some
vehicles. In this event please consult your ECLIPSE
retailer.
• Some recent audio discs may resemble conventional
music CDs but are technically not Compact Discs (CD
Red Book format) because of the copy protection
technology employed. ECLIPSE cannot guarantee
operation and performance if these discs are used.
• CD-R/RW playback quality may be affected by disc
surface condition and disc format initialization process.
• It may be necessary to purchase additional connecting
cables for the products.
• Due to the effects of photography and printing processes,
the color of the actual product may differ somewhat from
that shown here.
• Memory Stick is a registered trademark of Sony Corp.
• Circle Surround II and the SRS logo are trademarks or
registered trademarks of SRS Labs, Inc.
• HD Radio is a trademark of iBiquity Digital Corporation.
• SIRIUS SATELLITE RADIO is a trademark of SIRIUS
Satellite Radio Inc.
• ATRAC3 is an efficient compression codec for digital
music files, allowing files to take up just 1/10 their
uncompressed size without degrading audio quality.
• Recording/playback of song data is only possible on
Magic Gate-compatible memory stick devices.
Product safety notice
9
FUJITSU TEN LIMITED
Contact: FUJITSU TEN CORP. OF AMERICA
19600 So. Vermont Avenue, Torrance, CA 90502
Call: 1-800-55-ECLIPSE (Dealer Locator)
1-800-233-2216 (Information)
www.eclipse-web.com
