32SL415U 1019273614

User Manual: 32SL415U

Open the PDF directly: View PDF .
Page Count: 92

For an overview of steps for setting up your new TV, see page 12.

Note: To display a High Deﬁnition picture, the TV must be receiving

a High Deﬁnition signal (such as an over-the-air High Deﬁnition

TV broadcast, a High Deﬁnition digital cable program, or a High

Deﬁnition digital satellite program). For details, please contact

your TV antenna installer, cable provider, or satellite provider.

Owner’s Record

The model number and serial number are on the back

and side of your TV. Record these numbers in the

spaces below. Refer to these numbers whenever you

communicate with your Toshiba dealer about this TV.

http://support.toshiba.com

Model number:

Serial number:

Owner’s Manual

Integrated High Deﬁnition

LCD Television

24SL415U

32SL415U

Dear Customer,

Thank you for purchasing this Toshiba LCD TV. This

manual will help you use the many exciting features

of your new LCD TV. Before operating your LCD TV,

please read this manual completely, and keep it

nearby for future reference.

Safety Precautions

WARNING: TO REDUCE THE RISK OF FIRE

OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

WARNING

RISK OF ELECTRIC

SHOCK DO NOT OPEN.

WARNING: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

WARNING

To prevent injury, this apparatus must be securely

attached to the floor/wall in accordance with the

installation instructions. See item 26 on page 4.

WARNING:

If you decide to wall mount this

television, always use a UL Listed wall bracket

appropriate for the size and weight of this television.

The use of any wall bracket other than a UL Listed

wall bracket appropriate for the size and weight of this

television for wall mounting this television could result

in serious bodily injury and/or property damage. See

“Removing the Pedestal Stand” ( page 6).

NOTE TO CATV INSTALLERS

This is a reminder to call the CATV system installer’s

attention to Article 820-40 of the U.S. NEC, which

provides guidelines for proper grounding and, in

particular, specifies that the cable ground shall be

connected to the grounding system of the building,

as close to the point of cable entry as practical. For

additional antenna grounding information, see items

34 and 35 on page 4.

Congratulations on your purchase! As you enjoy your

new product, please keep these safety tips in mind:

The Issue

•฀The฀home฀theater฀entertainment฀experience฀is฀a฀growing฀trend฀

and฀larger฀flat฀panel฀displays฀are฀popular฀purchases.฀However,฀

flat฀panel฀displays฀are฀not฀always฀supported฀on฀the฀proper฀stands฀

or฀installed฀according฀to฀the฀manufacturer’s฀recommendations.

•฀Flat฀panel฀displays฀that฀are฀

inappropriately฀situated฀on฀dressers,฀

bookcases,฀shelves,฀desks,฀

speakers,฀chests฀or฀carts฀may฀fall฀

over฀and฀cause฀injury.

TOSHIBA Cares!

•฀The฀consumer฀electronics฀industry฀

is฀committed฀to฀making฀home฀

entertainment฀enjoyable฀and฀safe.

Tune Into Safety

•฀

One฀size฀does฀NOT฀fit฀all.฀Follow฀the฀manufacturer’s฀recommendations฀

for฀the฀safe฀installation฀and฀use฀of฀your฀flat฀panel฀display.

•฀Carefully฀read฀and฀understand฀all฀enclosed฀instructions฀for฀

proper฀use฀of฀this฀product.

•฀Don’t฀allow฀children฀to฀climb฀on฀or฀play฀with฀furniture฀and฀

television฀sets.

•฀Don’t฀place฀flat฀panel฀displays฀on฀furniture฀

that฀can฀easily฀be฀used฀as฀steps,฀such฀

as฀a฀chest฀of฀drawers.

•฀Remember฀that฀children฀can฀

become฀excited฀while฀watching฀a฀

program,฀especially฀on฀a฀“larger฀

than฀life”฀flat฀panel฀display.฀Care฀

should฀be฀taken฀to฀place฀or฀install฀

the฀display฀where฀it฀cannot฀be฀

pushed,฀pulled฀over,฀or฀knocked฀down.

•฀Care฀should฀be฀taken฀to฀route฀all฀cords฀and฀

cables฀connected฀to฀the฀flat฀panel฀display฀so฀that฀they฀cannot฀be฀

pulled฀or฀grabbed฀by฀curious฀children.

Wall Mounting: If you decide to wall mount your

flat panel display, always:

•฀Use฀a฀mount฀that฀has฀been฀recommended฀by฀the฀display฀

manufacturer฀and/or฀listed฀by฀an฀independent฀laboratory฀(such฀

as฀UL,฀CSA,฀ETL).

•฀Follow฀all฀instructions฀supplied฀by฀the฀display฀and฀wall฀mount฀

manufacturers.

•฀If฀you฀have฀any฀doubts฀about฀your฀ability฀to฀safely฀install฀your฀

flat฀panel฀display,฀contact฀your฀retailer฀about฀professional฀

installation.

•฀Make฀sure฀that฀the฀wall฀where฀you฀are฀mounting฀the฀display฀is฀

appropriate.฀Some฀wall฀mounts฀are฀not฀designed฀to฀be฀mounted฀

to฀walls฀with฀steel฀studs฀or฀old฀cinder฀block฀construction.฀If฀you฀

are฀unsure,฀contact฀a฀professional฀installer.

•฀A฀minimum฀of฀two฀people฀are฀

required฀for฀installation.฀Flat฀panel฀

displays฀can฀be฀heavy.฀

CHILD SAFETY:

It Makes A Difference How and Where You Use Your Flat

Panel Display

broken glass or liquid from the damaged television.

The LCD panel inside the TV contains glass and a toxic

liquid. If the liquid comes in contact with your mouth

or eyes, or your skin is cut by broken glass, rinse the

affected area thoroughly with water and consult your

doctor.

•฀ ALWAYS contact a service technician to inspect the TV

any time it has been damaged or dropped.

15) CAUTION:

•฀ To reduce the risk of electric shock, do not

use the polarized plug with an extension cord,

receptacle, or other outlet unless the blades can

be inserted completely to prevent blade exposure.

•฀ To prevent electric shock, match wide blade of plug

to wide slot; fully insert.

)

CAUTION:

Do not let children swallow the product or play with

the plastic bag. Keep the product and the plastic bag

out of the reach of children.

)

CAUTION

Do not let water or other liquids come into contact

with the product, as it may result in damage.

) WARNING

•฀ To prevent the spread of fire, keep candles or other

open flames away from this product at all times.

•฀ Keep the product away from direct sunlight, fire or

a heat source such as a heater. This may reduce the

product lifetime or result in fire.

Installation, Care, and Service

Installation

Follow these recommendations and precautions and

heed all warnings when installing your TV:

)

WARNING: NEVER expose batteries

to excessive heat such as sunshine,

fire, or the like.

) ALWAYS plug the product into an outlet that is

located in such a manner that it can be easily

unplugged in case the product requires service.

) NEVER route the product’s power cord inside a wall

or similar enclosed area.

)

Never modify this equipment. Changes or

modifications may void: a) the warranty, and b) the

user’s authority to operate this equipment under the

rules of the Federal Communications Commission.

) DANGER: RISK OF SERIOUS PERSONAL

INJURY, DEATH, OR

EQUIPMENT DAMAGE!

Never place the TV on an unstable

cart, stand, or table. The TV may fall,

causing serious personal injury,

death, or serious damage to the TV.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

Do not defeat the safety purpose of the polarized

or grounding type plug. A polarized

plug has two blades with one wider

than the other. A grounding type plug

has two blades and a third grounding

prong. The wide blade or the third

prong is provided for your safety. If the provided plug

does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10) Protect the power cord from being walked on

or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use

caution when moving the cart/apparatus

combination to avoid injury from tip-

over.

13) Unplug this apparatus during lightning storms

or when unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or

plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has

been exposed to rain or moisture, does not operate

normally, or has been dropped.

Additional Safety Precautions

14a) CAUTION:

If the TV is dropped and the cabinet or

enclosure surface has been damaged or the TV does not

operate normally, take the following precautions:

•฀ ALWAYS turn off the TV and unplug the power cord to

avoid possible electric shock or fire.

•฀ NEVER allow your body to come in contact with any

Wide blade

(continued)

) To avoid damage to this product, never place or store

the TV in direct sunlight; hot, humid areas; or areas

subject to excessive dust or vibration.

25) Never place the TV in an unstabilized location such

as on a shaky table, incline or location subject to

vibration.

•฀ Only use cabinets fit for such purpose or stands

recommended by the manufacturer of the TV.

•฀ Only use furniture that can safely support the TV.

•฀ Ensure that the TV is not hanging over the edge of

the supporting furniture.

•฀ Never place the TV on tall furniture (for example,

cupboards or bookcases) without anchoring both

the furniture and the TV to a suitable support.

•฀ Never stand the TV on cloth or other material

placed between the TV and supporting furniture.

The TV may drop or fall off which may cause an injury

or damage.

26) Always place the TV on the floor or a sturdy, level,

stable surface that can support the weight of the unit.

To secure the TV, use a sturdy strap from the hook(s)

on the rear of the TV to a wall stud, pillar, or other

immovable structure. Make sure the strap is tight,

secure, and parallel to the floor.

TV side TV top

min.

Hook

Sturdy strap

(as short as possible)

Note: 24SL415U has not the hook on the rear of TV.

27) Never stand or climb on the TV.

•฀ Educate children about the dangers of climbing on

furniture to reach the TV or

its controls.

Be especially careful in

households with children to

prevent them from climbing on

top of the TV. It may move, fall

over, break, become damaged

or cause an injury.

28) The apparatus shall not be exposed to dripping or

splashing, and that no objects filled with liquids,

such as vases, shall be placed on the apparatus.

29) Never block or cover the slots or openings in the TV

cabinet back, bottom, and sides. Never place the TV:

•฀ On a bed, sofa, rug, or

similar surface;

•฀ Too close to drapes,

curtains, or walls; or

•฀ In a confined space such as

a bookcase, built-in cabinet,

or any other place with poor ventilation.

The slots and openings are provided to protect the

TV from overheating and to help maintain reliable

operation of the TV. Leave a space of at least 4 (four)

inches around the TV.

30) Always place the back of the television at least four

(4) inches away from any vertical surface (such as a

wall) to allow proper ventilation.

31) Never allow anything to rest on or roll over the power

cord, and never place the TV where the power cord is

subject to wear or abuse.

32) Never overload wall outlets and extension cords.

33) Always operate this equipment from a 120 VAC, 60

Hz power source only.

34) Always make sure the antenna system is properly

grounded to provide adequate protection against

voltage surges and built-up static charges (see

Section 810 of the National Electric Code).

Antenna lead-in wire

Antenna discharge unit

(NEC Section 810-20)

Grounding conductors

(NEC Section 810-21)

Power service grounding

electrode system

(NEC Art 250 Part-H)

Ground clamp

Electric service

equipment

Ground clamps

35) DANGER: RISK OF SERIOUS

PERSONAL INJURY OR DEATH!

•฀ Use extreme care to make sure you are never in

a position where your body (or any item you are

in contact with, such as a ladder or screwdriver)

can accidentally touch overhead power lines.

Never locate the antenna near overhead power

lines or other electrical circuits.

•฀ Never attempt to install any of the following

during lightning activity: a) an antenna system;

or b) cables, wires, or any home theater

component connected to an antenna or phone

system.

Care

For better performance and safer operation of your TOSHIBA

TV, follow these recommendations and precautions:

36) If you use the TV in a room whose temperature is

32 °F (0 °C) or below, the picture brightness may

vary until the LCD warms up. This is not a sign of

malfunction.

37) Always unplug the TV

before cleaning. When

cleaning Always unplug the

TV before cleaning. When

cleaning your TV, please

first remove any dirt or

dust from the surface. Gently wipe the cabinet and

the display panel surface (the TV screen) with a dry,

(continued)

soft cloth (cotton, flannel, etc.). Harsh rubbing or use

of a dirty or stiff cloth will scratch the TV surface.

Avoid contact with alcohol, thinner, benzene, acidic

or alkaline solvent cleaners, abrasive cleaners, or

chemical cloths, which may damage the TV surface.

Never spray volatile compounds such as insecticide

on the TV surface. Such products may damage or

discolor the TV.

38)

Never hit, press, or place anything on the back cover.

These actions will damage internal parts.

39) WARNING:

RISK OF ELECTRIC SHOCK!

Never spill liquids or push objects of any kind into

the TV cabinet slots.

40) While it is thundering, do not touch the

connecting cables or apparatus.

41) For added protection of your TV from lightning

and power surges, always unplug the power

cord and disconnect the antenna from the TV if

you leave the TV unattended or unused for long

periods of time.

42) ALWAYS unplug the TV to completely disconnect

from mains power. When the TV is turned off using

the on/off switch, it is not completely disconnected

from power and a minute amount of current is still

consumed.

43)

During normal use, the TV may make occasional

snapping or popping sounds. This is normal,

especially when the unit is being turned on or off.

If these sounds become frequent or continuous,

unplug the power cord and contact a Toshiba

Authorized Service Provider.

44) WARNING: RISK OF

SERIOUS PERSONAL

INJURY OR EQUIPMENT

DAMAGE!

Never strike the screen with a

sharp or heavy object.

45) •The฀LCD฀screen฀of฀this฀product฀can฀be฀damaged฀by฀

ultraviolet radiation from the sun. When selecting a

location for the television, avoid locations where the

screen may be exposed to direct sunlight, such as

in front of a window.

•฀

Never touch, press, or place anything on the LCD

screen. These actions will damage the LCD screen.

If you need to clean the LCD screen, follow the

instructions in item 37 on pages 4 and 5.

Service

46)

WARNING:

RISK OF ELECTRIC SHOCK!

Never attempt to service the TV yourself. Opening

and removing the covers may expose you to

dangerous voltage or other hazards. Failure to follow

this WARNING may result in death or serious injury.

Refer all servicing not specified in this manual to a

Toshiba Authorized Service Provider.

47) If you have the TV serviced:

•฀ Ask the service technician to use only replacement

parts specified by the manufacturer.

•฀ Upon completion of service, ask the service technician

to perform routine safety checks to determine that the

TV is in safe operating condition.

Choosing a location for your LCD TV

To Display your LCD TV on the included

Pedestal Stand:

Observe the following safety precautions:

1) Read and Follow the pedestal assembly instructions

included with the pedestal.

CAUTION: Before beginning pedestal assembly,

carefully lay the front of the LCD Panel face down on

a flat, cushioned surface such as a quilt or blanket.

Leave the bottom of the unit protruding over the edge

of the surface and assemble the pedestal as indicated

next page.

Note: Extreme care should always be used

when attaching the pedestal stand to avoid

damage to the LCD panel.

2) Place the TV on a sturdy, level surface that can

support the weight of the TV.

3) Be sure to secure the TV to a wall, pillar, surface, or

other immovable structure ( item 26, page 4).

To Display your LCD TV using a Wall

Bracket:

If you decide to wall mount your LCD TV, always use

a UL listed wall bracket appropriate for the size and

weight of the LCD TV ( page 2):

1) CAUTION:

Two people are required for installation.

2) Unplug and remove any cables and/or other

component connectors from the rear of the TV.

3) Always use the screws supplied or recommended

by the wall mount manufacturer.

CAUTION: Always place the TV on the floor or a sturdy,

level, stable surface that can support the weight of

the unit. To secure the TV, use a sturdy strap from

the hook(s) on the rear of the TV to a wall stud, pillar,

or other immovable structure. Make sure the strap is

tight, secure, and parallel to the floor.

4) Follow the instructions provided with your wall

bracket. Before proceeding, make sure the

appropriate bracket(s) are attached to the wall and

the back of the TV as described in the instructions

provided with the wall bracket.

5) After attaching the appropriate bracket(s) to the

wall and the back of the TV, remove the pedestal

stand from the TV as described on below.

VESA Mounting Pattern

TV Size Hole Pattern(HxV) Screw Size

24” 100x100 mm M4

32’’ 200x200 mm M6

(unit in mm)

Removing the Pedestal Stand

Carefully lay the front of the unit face down on a

flat, cushioned surface such as a quilt or blanket.

Leave the stand protruding over the edge of the

surface.

Note: Extreme care should always be used

when removing the pedestal stand to avoid

damage to the LCD panel.

2) Remove the four screws shown in the right

diagram. This will allow removal of the pedestal

stand.

3) Once you have removed all the pedestal stand

screws, remove the pedestal stand from the TV.

32” TV

Four screws

VESA Mounting Pattern

Hook

Sturdy strap

(as short as possible)

Four screws

24” TV VESA Mounting Pattern

USA - Federal Communications

Commission Statement

FCC Compliance Statement

Toshiba television models 24SL415U, and 32SL415U

comply with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received,

including interference that may cause undesired

operation.

The party responsible for compliance to these rules is:

Toshiba America Information Systems, Inc.

9740 Irvine Blvd. Irvine, CA 92618

Ph: 1-800-631-3811

Interference:

This equipment has been tested and

found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These

limits are designed to provide reasonable protection

against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there

is no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the

interference by one of the following measures:

•฀ Reorient or relocate the receiving antenna.

•฀ Increase the separation between the equipment and the

receiver.

•฀ Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

•฀ Consult the dealer or an experienced radio/TV

technician for help.

Wireless Radio

For product available in the USA/Canada market,

only channel 1–11 can be operated. Selection of other

channels is not possible.The device could automatically

discontinue transmission in case of absence of

information to transmit, or operational failure. Note that

this is not intended to prohibit transmission of control

or signaling information or the use of repetitive codes

where required by the technology. If this device is going

to be operated in 5.15–5.25GHz frequency range, then it

is restricted in indoor environment only.

Important:

Any changes or modifications not

expressly approved by the party responsible for

compliance could void the user’s authority to operate

this equipment. This device and its antenna(s) must

not be co-located or operating in conjunction with any

other antenna or transmitter.

FCC Radiation Exposure Statement: This

equipment complies with FCC radiation exposure

limits set forth for an uncontrolled environment. This

equipment should be installed and operated with

minimum distance 20cm between the radiator &

your body.

Canada - Industry Canada

Statement

This device complies with RSS-210.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received,

including interference that may cause undesired

operation of the device.

This device and its antenna(s) must not be co-located

or operating in conjunction with any other antenna or

transmitter.

Wireless Radio

For product available in the USA/Canada market,

only channel 1–11 can be operated. Selection of other

channels is not possible.

The device could automatically discontinue transmission

in case of absence of information to transmit, or

operational failure. Note that this is not intended to

prohibit transmission of control or signaling information

or the use of repetitive codes where required by the

technology.

Important: Any changes or modifications not

expressly approved by the party responsible

for compliance could void the user’s authority to

operate this equipment.

IMPORTANT NOTE:

IC Radiation Exposure Statement: This equipment

complies with IC RSS-102 radiation exposure limits

set forth for an uncontrolled environment. This

equipment should be installed and operated with

minimum distance 20cm between the radiator &

your body.

ENERGY STAR® User Information:

ENERGY STAR User Information Statement: the factory

default settings of this television meet ENERGY STAR®

requirements. Enabling or changing certain features

and functionality (e.g. Picture Settings, Auto Brightness

Sensor Setting) may increase energy consumption,

possibly beyond the limits required for ENERGY STAR

qualification.

To ensure your television is operating at optimal energy

efficiency, select [Home] mode during initial activation.

To return to [Home] mode settings, select [AutoView]

picture mode, and set Auto Brightness Sensor Setting

to [On] mode. [AutoView] mode is recommended for

normal home use.

For more information, see (



page 49).

ENERGY STAR

qualified TV.

Products that earn the ENERGY

STAR prevent green house gas

emissions by meeting strict guidelines

set by the U.S. Environmental

Protection Agency. ENERGY STAR

and the ENERGY STAR mark are

registered U.S. marks.

Important notes about your LCD TV

The following symptoms are technical limitations

of LCD Display technology and are not an

indication of malfunction; therefore, Toshiba is

not responsible for perceived issues resulting from

these symptoms.

1) An afterimage (ghost) may appear on the screen if

a fixed, nonmoving image is displayed for a long

period of time. The afterimage is not permanent

and will disappear in a short period of time.

2) The LCD panel contained in this TV is

manufactured using an extremely high level

of precision technology; however, there may

be an occasional pixel (dot of light) that does

not operate properly (does not light, remains

constantly lit, etc.). This is a structural property of

LCD technology, is not a sign of malfunction, and

is not covered under your warranty. Such pixels

are not visible when the picture is viewed from a

normal viewing distance.

Note: Interactive video games that involve

shooting a “gun” type of joystick at an on-

screen target may not work with this TV.

Trademark Information

• Manufactured under license from

Dolby Laboratories.

Dolby and the double-D symbol are

trademarks of Dolby Laboratories.

•

Audyssey Dynamic Volume controls

volume levels to eliminate loud spikes

and raise soft dialog for more enjoyable

television and movie viewing. Audyssey

EQ® provides clear, accurate and

natural sound right out of the box.

Together, these technologies ensure

you enjoy your audio experience as

much as your video.

• Manufactured under license from Audyssey

Laboratories. U.S. and foreign patents pending.

Audyssey EQ

and Audyssey Dynamic Volume are

registered trademarks of Audyssey Laboratories.

•

HDMI, the HDMI logo, and High-

Definition Multimedia Interface are trademarks

or registered trademarks of HDMI Licensing LLC

in the United States and other countries.

• Blu-ray Disc™, Blu-ray™, and the logos are

trademarks of the Blu-ray Disc Association.

• INSTAPORT™ and INSTAPORT logo are trademarks

of Silicon Image, Inc. in the United States and other

countries.

• MPEG Layer-3 audio coding technology licensed

from Fraunhofer IIS and Thomson.

• DLNA®, DLNA® Certification Logo, and DLNA

CERTIFIED™ are registered trademarks, trademarks,

service marks, or certification marks of the Digital

Living Network Alliance.

• VUDU is a trademark of VUDU, Inc.

• YouTube and the YouTube logo are trademarks of

Google Inc. in the United States and Canada.

• Netflix is a registered trademark of Netflix, Inc.

• Yahoo! is a registered trademark of Yahoo! Inc.

• CinemaNow is a registered trademark of Best Buy, Inc.

• Pandora is a registered trademark of Pandora Media, Inc.

• Blockbuster is a registered trademark of Blockbuster, Inc.

• This product contains Adobe® Flash® Player software

under license from Adobe Systems Incorporated.

are trademarks of Adobe Systems Incorporated.

• This product contains technology subject to certain

intellectual property rights of Microsoft. Use or

distribution of this technology outside of this product

is prohibited without the appropriate license(s) from

Microsoft.

• This product includes technology owned by

Microsoft Corporation and can not be used

or distributed without a license from Microsoft

Licensing, GP.

• THIS PRODUCT IS LICENSED UNDER THE AVC

PATENT PORTFOLIO LICENSE FOR THE PERSONAL

AND NON-COMMERCIAL USE OF A CONSUMER

TO (i) ENCODE VIDEO IN COMPLIANCE WITH

THE AVC STANDARD (“AVC VIDEO”) AND/OR

(ii) DECODE AVC VIDEO THAT WAS ENCODED

BY A CONSUMER ENGAGED IN A PERSONAL

AND NON-COMMERCIAL ACTIVITY AND/OR

WAS OBTAINED FROM A VIDEO PROVIDER

LICENSED TO PROVIDE AVC VIDEO. NO LICENSE

IS GRANTED OR SHALL BE IMPLIED FOR ANY

OTHER USE. ADDITIONAL INFORMATION MAY

BE OBTAINED FROM MPEG LA,LLC. SEE HTTP://

WWW.MPEGLA.COM

• THIS PRODUCT IS LICENSED UNDER THE VC-1

PATENT PORTFOLIO LICENSE FOR THE PERSONAL

AND NON-COMMERCIAL USE OF A CONSUMER

TO (i) ENCODE VIDEO IN COMPLIANCE WITH

THE VC-1 STANDARD (“VC-1 VIDEO”) AND/OR

(ii) DECODE VC-1 VIDEO THAT WAS ENCODED

BY A CONSUMER ENGAGED IN A PERSONAL

AND NON-COMMERCIAL ACTIVITY AND/OR

WAS OBTAINED FROM A VIDEO PROVIDER

LICENSED TO PROVIDE VC-1 VIDEO. NO LICENSE

IS GRANTED OR SHALL BE IMPLIED FOR ANY

OTHER USE. ADDITIONAL INFORMATION MAY

BE OBTAINED FROM MPEG LA,LLC. SEE HTTP://

WWW.MPEGLA.COM

• THIS PRODUCT IS LICENSED UNDER THE MPEG-

4 VISUAL PATENT PORTFOLIO LICENSE FOR

THE PERSONAL AND NON-COMMERCIAL USE

OF A CONSUMER FOR (i) ENCODING VIDEO

IN COMPLIANCE WITH THE MPEG-4 VISUAL

STANDARD (“MPEG-4 VIDEO”) AND/OR (ii)

DECODING MPEG-4 VIDEO THAT WAS ENCODED

BY A CONSUMER ENGAGED IN A PERSONAL

AND NON-COMMERCIAL ACTIVITY AND/OR

WAS OBTAINED FROM A VIDEO PROVIDER

LICENSED BY MPEG LA TO PROVIDE MPEG-

4 VIDEO. NO LICENSE IS GRANTED OR SHALL

BE IMPLIED FOR ANY OTHER USE. ADDITIONAL

INFORMATION INCLUDING THAT RELATING TO

PROMOTIONAL,INTERNAL AND COMMERCIAL

USES AND LICENSING MAY BE OBTAINED FROM

MPEG LA,LLC. SEE HTTP://WWW.MPEGLA.COM

Important Safety Instructions ...........................3

Installation, Care, and Service .........................3

Chapter 1: Introduction ................................ 12

Features ......................................................................................12

Overview of installation, setup, and use ....................................12

TV front and side panel controls and connections ....................13

TV back panel connections ........................................................14

Chapter 2: Connecting your TV ....................... 15

Overview of cable types .............................................................15

About the connection illustrations .............................................15

Connecting a VCR and antenna, Cable TV or Camcorder .......16

Connecting a DVD player with ColorStream®

(component video), a VCR, or a satellite receiver .............17

Connecting an HDMI® or DVI device to the HDMI input .......18

Using the TV remote and HDMI® CEC Control

to control other devices ......................................................19

Connecting an HDMI audio system ..........................................19

Connecting a digital audio system .............................................20

Connecting a personal computer (PC) .......................................20

Connecting a home network ......................................................21

Chapter 3: Using the remote control ................. 23

Controlling other devices ...........................................................23

Installing batteries ......................................................................23

Remote control effective range ..................................................23

Learning about the Remote Control ..........................................24

Chapter 4: Initial Setup and Menu ................... 25

Initial Setup ................................................................................25

Navigating the menu system ......................................................26

Main menu layout ......................................................................27

Quick menu ................................................................................28

Chapter 5: Setting up your TV ......................... 29

Changing Initial settings ............................................................29

Menu language .......................................................................29

Local Time Setting .................................................................29

Location ..................................................................................29

ANT/CABLE IN ....................................................................29

Storing channels in memory (optional) .....................................29

Auto Tuning ............................................................................29

Manual Tuning .......................................................................30

Skipping channels ......................................................................30

Skipping video inputs ................................................................30

Labeling channels ......................................................................31

Labeling video inputs .................................................................31

Configuring shared inputs ..........................................................31

Setting the Auto Input feature ....................................................32

Chapter 6: Basic features ..............................33

Tuning channels .........................................................................33

Setting the Channel Tuning Mode .........................................33

Tuning in to the next programmed channel ...........................33

Tuning in to a specific channel

(programmed or unprogrammed) ...............................33

Using the Channel Browser™ .................................................33

Using Channel Return ............................................................35

Using SurfLock™ ....................................................................35

Selecting the video input to view ...............................................35

Using closed captions ................................................................36

Analog CC mode ....................................................................36

Digital CC settings .................................................................36

Setting the PIN code ..................................................................37

Entering a new PIN code .......................................................37

Changing or deleting your PIN code .....................................37

Forgotten PIN code ................................................................37

Using parental controls ..............................................................37

Blocking TV programs and movies by rating (V-Chip) ........37

Downloading an additional rating system .............................38

Displaying ratings ..................................................................39

Unlocking programs ...............................................................39

Locking specific channels ..........................................................39

Locking video input ...............................................................39

Setting a time limit for games ................................................40

Locking the control panel ......................................................40

Using HDMI® CEC Control ......................................................40

Controlling HDMI® CEC playback devices ..........................40

HDMI® CEC Control input source selection .........................41

Adjusting the amplifier’s audio ..............................................41

Other HDMI® CEC Control functions ...................................41

Using the HDMI® settings feature .............................................42

Viewing the HDMI® signal information ....................................42

Using your PC with the TV .......................................................42

Adjusting the image ...............................................................42

Setting the PC audio ...............................................................42

Setting the timer to turn on the TV ............................................43

Setting the sleep timer ................................................................43

Setting Automatic Power Down ................................................44

Setting No Signal Power Down .................................................44

Displaying TV status information .............................................44

Viewing support information .....................................................45

Resetting to Factory Defaults ....................................................45

Power failure ..............................................................................45

Chapter 7: Picture and sound controls .............. 46

Selecting the picture size ...........................................................46

Scrolling the picture ...................................................................48

Using the Auto Aspect feature ...................................................48

Using the 4:3 Stretch ..................................................................48

Freezing the picture ....................................................................48

Adjusting the picture ..................................................................49

Selecting the picture mode .....................................................49

Adjusting the picture quality ..................................................49

Using the advanced picture settings features.............................50

Edge Enhancer........................................................................50

Dynamic Contrast...................................................................50

DynaLight™ ............................................................................50

Static Gamma .........................................................................50

MPEG NR ..............................................................................50

DNR..................................................................................... 50

Auto Brightness Sensor ..........................................................51

Backlight Adjustment Pro ......................................................51

ColorMaster™ .........................................................................51

Base Color Adjustment ..........................................................51

Color temperature ...................................................................51

Resetting to the factory default ..............................................51

Setting the Expert Picture Settings ............................................52

Test Pattern .............................................................................52

RGB Filter ..............................................................................52

White Balance ........................................................................52

Resetting to the factory default ..............................................52

Locking the picture settings .......................................................52

Adjusting the audio ....................................................................53

Muting the sound ....................................................................53

Selecting stereo/SAP broadcasts ............................................53

Adjusting the audio balance ...................................................53

Contents

Adjusting the range ................................................................53

Selecting the optical audio output format ..............................53

Using the Dolby® Digital Dynamic Range Control feature ..54

Using Audyssey Dynamic Volume®.......................................54

Using advanced sound features .................................................54

Using surround sound ............................................................54

Chapter 8: Advanced features ........................ 55

Using your home network .........................................................55

Setting up the Network ..............................................................56

Wireless Setup ........................................................................56

Advanced Network Setup ......................................................58

Network Connection Test .......................................................59

Using the software keyboard .....................................................59

Performing a Software Upgrade ................................................60

Viewing the Software Licenses .................................................60

Using the NET TV™ feature ......................................................60

NET TV menu ........................................................................60

Guided Setup ..........................................................................60

Netflix .....................................................................................61

VUDU™ ..................................................................................61

YouTube™ ...............................................................................61

CinemaNow ............................................................................62

Blockbuster .............................................................................62

Pandora ...................................................................................62

Yahoo!® TV Widgets ..............................................................62

Using the Media Player..............................................................64

Media Player Specifications...................................................64

Basic operation .......................................................................64

Viewing Movie files ...............................................................65

Playing Music files .................................................................66

Viewing Photo files ................................................................67

Using the Wallpaper feature.......................................................69

Chapter 9: Troubleshooting ........................... 70

General troubleshooting .............................................................70

LED indications .........................................................................73

Chapter 10: Appendix .................................. 74

Specifications .............................................................................74

Acceptable signal formats for PC IN and HDMI terminals ......75

PC IN signal formats ..............................................................75

HDMI signal formats .............................................................76

Remote Control functional key chart.........................................77

Operating other devices .............................................................79

Programming the remote to operate other devices ....................79

Device code setup ...................................................................79

Searching for a device code ...................................................80

Locking the volume keys .......................................................80

Clearing the remote’s programming ......................................80

Resetting to the factory default ..............................................80

Operating the TV with combination buttons .............................81

Remote control codes.................................................................82

Limited United States Warranty for LCD Televisions ..............88

Limited Canadian Warranty

for Toshiba Brand Flat Panel Televisions...........................89

Features

•฀Integrated digital tuning (8VSB ATSC and

QAM) eliminates the need for a separate digital

converter set-top box (in most cases).

•฀1366 x 768 output resolution (32SL415U),

1920 x 1080 output resolution (24SL415U).

•฀Three HDMI® digital, High-Definition Multimedia

Interfaces 1080p input support (24SL415U).

Four HDMI® digital, High-Definition Multimedia

Interfaces 1080p input support (32SL415U).

•฀HDMI capabilities

ARC (Audio Return Channel) enables the audio

signal of the TV to be sent to an AV amplifier via

an HDMI cable.

HDMI INSTAPORT™ technology reduces lag

time when switching HDMI sources.

RGB Range adjusts RGB full range signal

automatically.

•฀HDMI® CEC Control allows control of external

devices from the TV remote via HDMI connection (

page 40)

•฀ColorStream® HD high-resolution component

video inputs.

•฀Digital Audio Out optical audio connection with

Dolby® Digital optical output format ( page 54).

•฀ PC IN (Analog RGB) computer terminal ( pages 20-

21).

•฀Built-in WLAN Allows the television to access your

home wireless network without an external Dual Band

WLAN Adapter.

•฀Yahoo!® TV Widgets are Internet applications

designed to run on your TV

( page 62).

•฀ColorMaster™ lets you adjust the TV’s standard

colors

( page 51).

•฀AutoView® lets you automatically adjust picture

settings based on ambient light conditions and input

signal content

( page 49)

•฀Dynamic Volume (Audyssey Dynamic Volume®)

eliminates inconsistent TV volume when changing

channels or viewing commercials

( page 54)

•฀Media Player lets you view photo files and play

music or movie files ( page 64).

•฀ ENERGY STAR® qualified

Chapter 1: Introduction

Overview of installation, setup,

and use

Follow these steps to set up your TV and begin using

its many exciting features.

1 To choose a location for the TV:

•฀Read “Important notes about your LCD TV”

( page 8).

•฀Place the TV in an appropriate location

( page 4)

2 Do not plug in any power cords until AFTER you

have connected all cables and devices to your TV.

3 BEFORE connecting cables or devices to the TV,

learn the functions of the TV’s connections and

controls ( page 13).

4 Connect your other electronic device(s) to the TV

( pages 15–22).

5 See “Chapter 3: Using the remote control” (

page 23) for an overview of the buttons on the

remote control, install the batteries and prepare to

operate your other device(s).

6 AFTER connecting all cables and devices, plug

in the power cords for your TV and other devices.

When you turn on the TV, the Initial Setup menu

appears.

7 See “Chapter 4: Initial Setup and Menu” for a

quick overview of navigating the TV’s menu

system ( pages 25-28).

8 Program channels into the TV’s channel memory

( page 29).

9 See Chapters 6, 7 and 8, for details on using the

TV’s features.

10 For help, refer to Chapter 9: Troubleshooting.

11 See Chapter 10, for technical specifications and

warranty information.

Chapter 1: Introduction

TV front and side panel controls and connections

Models 24SL415U, and 32SL415U are used in this manual for illustration purposes.

Touch Sensor 12

1 Power On/Standby LED

2 Brightness Sensor/Remote sensor — This sensor

will detect the ambient light conditions to optimize

the backlighting levels ( page 51). Point the

remote control toward this remote sensor (

“Remote control effective range” on page 23).

3 Touch Sensor — These are available when touched.

- POWER — To turn the TV on and off.

- VOL +

— To adjust the volume level. When

a menu is onscreen, these keys function as left/

right menu navigation buttons.

- CH pq — To change the channel. When a

menu is onscreen, these keys function as up/

down menu navigation buttons.

- MENU — To access the menu. When a menu is

onscreen, the MENU key on the TV’s control

panel functions as the RETURN button.

- INPUT — To change the source you are viewing.

When a menu is onscreen, the INPUT key on the

TV’s control panel functions as the OK button.

TV front

Right side panel

Chapter 1: Introduction

1 LAN IN — LAN port is used to connect the TV to

your home network.

2 ANT/CABLE — Antenna input that supports

analog (NTSC) and digital (ATSC) off-air

antenna signals and analog and digital Cable TV

(QAM) signals.

3 AUDIO OUT — Analog audio outputs for

connecting an audio amplifier.

4 DIGITAL AUDIO OUT — Optical audio output in

Dolby Digital or PCM (pulse-code modulation)

format for connecting an external Dolby Digital

decoder, amplifier, A/V receiver, or home theater

system with optical audio input.

5 PC/HDMI-3 (AUDIO) IN — PC audio input

terminals are shared with HDMI-3 analog audio

input terminals, and their use can be configured

in the Configuring shared inputs menu ( page

31).

6 HDMI® IN — High-Definition Multimedia

Interface input receives digital audio and

uncompressed digital video from an HDMI

device or uncompressed digital video from a DVI

device. HDMI connection is necessary to receive

1080p signals.

TV back panel connections

For an explanation of cable types and connections, see pages 15–22.

7 USB port — To access photo or music files with

USB device.

8 PC IN — For use when connecting a personal

computer.

9 COLOR STREAM® HD / VIDEO IN — These

include standard A/V connections ( page 17).

Note: Component / Standard (composite)

video cables carry only video information;

separate audio cables are required for a

complete connection.

COLOR STREAM

HD / VIDEO IN

PC/HDMI 3

(AUDIO)

OUT

AUDIO

2 43

TV back

Power Cord

24SL415U

no HDMI 4

Overview of cable types

Cables can be purchased from most stores that sell audio/

video devices. Before purchasing any cables, be sure of

connector types required by your devices and the length

of each cable.

Coaxial cable (F-type)

(F-type) Coaxial cable is used for connecting your

antenna, cable TV service, and/or cable converter box

to the ANT/CABLE input on your TV.

Standard A/V cables (red/white/yellow)

Standard A/V cables (composite video) usually come

in sets of three, and are for use with video devices with

analog audio and composite video output. These cables

(and the related inputs on your TV) are typically color-

coded according to use: yellow for video, red for stereo

right audio, and white for stereo left (or mono) audio.

Component video cables (red/green/blue)

Component video cables come in sets of three and are

for use with video devices with component video output.

(ColorStream® is Toshiba’s brand of component video.)

These cables are typically color-coded red, green, and

blue. Separate audio cables are required for a complete

connection.

Note: Component video cables provide better

picture performance than a standard (composite)

video.

HDMI® cable

(with HDMI Logo “ ”)

Use it with devices built-in HDMI output. An HDMI

cable delivers digital audio and video in its native

format. Separate audio cables are not required

( pages 18-19).

Note: HDMI cables provide the best audio and

picture quality.

Optical audio cable

Optical audio cable is for connecting receivers with

Dolby Digital or PCM (pulse-code modulation) optical

audio input to the TV’s DIGITAL AUDIO OUT terminal

( page 20).

Analog RGB (15-pin) computer cable

Analog RGB (15-pin) computer cable is for connecting

a PC to the TV’s PC IN terminal ( page 20).

Note: Separate audio cables are required for a

complete connection.

3.5mm Stereo to RCA Y-cable

3.5mm Stereo to RCA Y-Cable is for connecting audio

signal from DVI device to TV.

LAN cable

Standard LAN cable is used to connect the TV to your

home network ( page 21).

Crossover LAN cable is used to connect the TV directly

to a PC ( page 21).

About the connection illustrations

You can connect different types and brands of devices to

your TV in several different configurations. The connection

illustrations in this manual are representative of typical

device connections only. The input/output terminals on

your devices may differ from those illustrated herein. For

details on connecting and using your specific devices, refer

to each device’s owner’s manual.

Chapter 2: Connecting your TV

Connecting a VCR and antenna, Cable TV or Camcorder

COLOR STREAM

HD / VIDEO IN

PC/HDMI 3

(AUDIO)

OUT

AUDIO

OUT

CH 3

CH 4

from

ANT

VIDEO AUDIO

OUT

L R

OUT

CH 3

CH 4

VIDEO

AUDIO

OUT

TV back panel

Camcorder

Stereo VCR

Cable box

From Cable TV

From Cable TV or

antenna

You will need:

•฀ Coaxial cables

•฀ Standard A/V cables

− If you have a mono VCR, connect L/MONO

on the TV to your VCR’s audio out terminal

using the white audio cable only.

•฀ Standard audio cables (If you have a mono VCR)

Note: When you use a Cable box, you may not

be able to use the remote control to program or

access certain features on the TV.

To view the antenna or Cable signal:

Select the ANT/CABLE video input source on the TV.*

To view basic and premium Cable channels:

Turn OFF the VCR. Select the ANT/CABLE video

input source on the TV.* Tune the TV to channel 3 or

4 (whichever channel the Cable box output is set to).

Use the Cable box controls to change channels.

Standard A/V cables

Coaxial cable

To view the VCR or camcorder video:

Turn ON the VCR or camcorder video. Select the

VIDEO video input source on the TV.*

*To select the video input source, press on

the remote control ( page 24). To program the

TV remote control to operate other devices, see

Chapter 3.

The unauthorized recording, use, distribution, or

revision of television programs, videotapes, DVDs,

and other materials is prohibited under the Copyright

Laws of the United States and other countries, and may

subject you to civil and criminal liability.

Chapter 2: Connecting your TV

Connecting a DVD player with ColorStream® (component video), a VCR,

or a satellite receiver

COLOR STREAM

HD / VIDEO IN

OUT

AUDIO

COLOR STREAM

HD / VIDEO IN

OUT

AUDIO

COLOR STREAM

HD / VIDEO IN

OUT

AUDIO

IN from ANT

VIDEO AUDIO

OUT to TV

L R

OUT

CH 3

CH 4

S-VIDEO

OUT

VIDEO

OUT

AUDIO

OUT

COMPONENT VIDEO

Satellite

PBPR

TV right side panel

Stereo VCR

From antenna

From satellite dish

Satellite receiver with component video or

DVD player with component video

You will need:

•฀ Coaxial cables

•฀ Standard A/V cables

− If you have a mono VCR, connect L/MONO

on the TV to your VCR’s audio out terminal

using the white audio cable only.

•฀ Standard audio cables

•฀ Component video cables

− You can connect the component video cables

(plus audio cables) from the DVD player

or satellite receiver to the ColorStream

HD terminal on the TV. The ColorStream

HD terminal can be used with Progressive

(480p, 720p) and Interlaced (480i, 1080i)

scan systems. A 1080i signal will provide

the best picture performance (1080p is not

supported).

To view antenna or Cable channels:

Select the ANT/CABLE video input source on the TV.*

To view the DVD player:

Turn ON the DVD player. Select the ColorStream HD

video input source on the TV.*

To view satellite programs using the

component video connections:

Turn on the satellite receiver. Select the ColorStream

HD video input source on the TV.*

To view the VCR or view and record

antenna channels:

Turn ON the VCR. Tune the VCR to the channel you want

to watch. Select the VIDEO video input source on the TV.*

To record a TV program while watching a DVD:

Turn ON the VCR. Tune the VCR to the channel to

record. Select the ColorStream HD video input source

on the TV* to view the DVD.

*To select the video input source, press on

the remote control ( page 24). To program the

TV remote control to operate other devices, see

Chapter 3.

The unauthorized recording, use, distribution,

or revision of television programs, videotapes,

DVDs, and other materials is prohibited under

the Copyright Laws of the United States and

other countries, and may subject you to civil and

criminal liability.

Coaxial cable

Chapter 2: Connecting your TV

To view the HDMI device video:

Select the HDMI 1, HDMI 2, HDMI 3, or HDMI 4

(except 24SL415U) video input source on the TV.

*To select the video input source, press on

the remote control ( page 24). To program the

TV remote control to operate other devices, see

Chapter 3.

To connect a DVI device, you will need:

•฀ HDMI-to-DVI adapter cable

− For proper operation, the length of an HDMI-

to-DVI adapter cable should not exceed 9.8 ft

(3m). The recommended length is 6.6 ft (2m).

•฀ 3.5mm Stereo to RCA Y-Cable

− An HDMI-to-DVI adapter cable transfers

video only. Separate analog audio cables

are required (see illustration).

PC/HDMI 3

(AUDIO)

VIDEO AUDIO

L R

OUT

DVI/ HDCP

OUT

DVI device

TV back panel

Note: To ensure that the HDMI or DVI device is reset

properly:

•When turning on your electronic components,

turn on the TV first, and then the HDMI or

DVI device.

•When turning off your electronic components,

turn off the HDMI or DVI device first, and

then the TV.

[1] EIA/CEA-861-D compliance covers the

transmission of uncompressed digital video

with high-bandwidth digital content protection,

which is being standardized for reception of

high-definition video signals. Because this is

an evolving technology, it is possible that some

devices may not operate properly with the TV.

Connecting an HDMI® or DVI

device to the HDMI input

The HDMI input on your TV receives digital audio

and uncompressed digital video from an HDMI

source device, or uncompressed digital video from a

DVI (Digital Visual Interface) source device.

This input is designed to accept HDCP (High-

Bandwidth Digital-Content Protection) program

material in digital form from EIA/CEA-861-D–

compliant[1] consumer electronic devices (such as

a set-top box or DVD player with HDMI or DVI

output).

The HDMI input can accept and display VGA,

SVGA, XGA, WXGA, SXGA, 480i (60Hz), 480p

(60Hz), 720p (60Hz), 1080i (60Hz), and 1080p

(24Hz/60Hz) signal formats. For detailed signal

specifications, see page 76.

Supported Audio format: Linear PCM, sampling rate

32/44.1/ 48 kHz

Note:

•To connect a PC to the HDMI input, see page 20.

•Some legacy HDMI sources may not work properly with

your HDMI TV due to the adoption of new standards.

Try setting the following options (INSTAPORT™ and

RGB Range) to Off (



page 42).

To connect an HDMI device, you will need:

•฀ HDMI cable (type A connector) per HDMI device

− For proper operation, it is recommended that

you use an HDMI cable with the HDMI Logo

( ).

− To display an 1080i/60Hz signal format, you

will need a High Speed HDMI cable.

A conventional HDMI/DVI cable may not

work properly.

− HDMI cables transfer both video and audio.

Separate analog audio cables are not

required (see illustration).

HDMI device

TV back panel

HDMI cable

Audio cable

24SL415U has no

HDMI 4 input

24SL415U has no

HDMI 4 input

HDMI-to

-DVI

adapter

cable

Chapter 2: Connecting your TV

HDMI cable

Using the TV remote and HDMI® CEC Control to control other devices

To control the basic functions of connected audio/video devices using the TV’s remote control, connect a

HDMI® CEC Control compatible audio receiver or playback device. The HDMI® CEC Control feature uses CEC

technology as regulated by the HDMI standard.

TV back panel

Audio receiver

Playback device

(HDMI® CEC DVD player,etc.)

Playback device

(HDMI® CEC DVD player,etc.)

To connect an audio receiver and playback devices, you will need:

•฀ HDMI cables ( page 15)

Note:

•If several devices are connected, the HDMI® CEC Control feature may not operate properly.

•For proper operation, it is recommended that you use HDMI cables with the HDMI Logo ( ).

Before controlling the devices:

•฀ For an explanation of setup and operations, see “Using HDMI® CEC Control” ( page 40).

•฀ Configure the connected devices. See each device’s operation manual.

Note:

This feature is limited to models incorporating Toshiba’s HDMI

CEC Control feature. However,

Toshiba is not liable for those operations. See the individual instruction manuals for compatibility information.

When using an external AV amplifier:

The picture and sound may not be properly synchronized. In this case, adjust the delay time of the sound on the

AV amplifier.

Note: The control range of the delay time differs according to the device you use.

Connecting an HDMI audio system

If your HDMI amplifier supports ARC, audio from the TV can be sent to the amplifier via the existing HDMI cable.

You will need:

•฀HDMI cable

HDMI’s ARC (Audio Return Channel) feature

This feature enables the audio signal of

the TV to be sent to an AV amplifier via

the HDMI cable. It will not be necessary

to connect a cable from the audio output

of the TV to the audio input of the AV

amplifier to reproduce the audio received

from the tuner of the TV through the AV

amplifier.

Note: Only HDMI 1 supports ARC.

24SL415U has no

HDMI 4 input

HDMI cable

AV amplifier that

supports ARC

24SL415U has no

HDMI 4 input

Chapter 2: Connecting your TV

Connecting a digital audio system

The TV’s DIGITAL AUDIO OUT terminal outputs a

*Dolby® Digital or 2-channel down-mixed PCM

(pulse-code modulation) signal for use with an

external Dolby® Digital decoder or other external

audio system with optical audio input.

You will need:

•฀ Optical audio cable (Use an optical audio cable

that has the larger “TosLink” connector and not

the smaller “mini-optical” connector.)

Dolby Digital decoder or

other digital audio system

TV back panel

Before controlling the audio:

See “Selecting the optical audio output format”(

page 53).

Note:

•Some audio systems may not be compatible

with Dolby Digital bitstream signals. Older

audio systems that are not compatible with

standard optical out signals may not work

properly, creating a high noise level that

may damage speakers or headphones.

THIS DAMAGE IS NOT COVERED BY YOUR

WARRANTY.

•The DIGITAL AUDIO OUT terminal may not

output some digital audio sources because

of copy restrictions.

•The Dolby Digital format is available in the

following situations:

− When tuned to a digital RF channel.

− When an HDMI input is used.

− When DLNA Certified products or Widgets are

used.

*Manufactured under license from Dolby

Laboratories. Dolby, and the double-D symbol are

trademarks of Dolby Laboratories.

(continued)

Analog

RGB

computer

cable

Optical audio

cable

Connecting a personal computer (PC)

With either the PC IN or HDMI connection, you can watch

your computer’s display on the TV and hear the sound

from the TV’s speakers.

To connect a PC to the PC IN terminal on the TV:

When connecting a PC to the PC IN terminal on the TV,

use an analog RGB (15-pin) computer cable and a PC audio

cable.

PC/HDMI 3

(AUDIO)

PC audio

cable

PC audio

output

Conversion adapter (if

necessary)

Computer

TV back panel

•฀ To use a PC, set the monitor output resolution on the

PC before connecting it to the TV. The PC IN terminal

can accept and display VGA, SVGA, XGA, WXGA and

SXGA signal formats. For detailed signal specifications

( page 75).

Other formats or non-standard signals will not be

displayed correctly.

•฀ To display the optimum picture, use the PC setting

feature ( “Using your PC with the TV” on page 42).

Note:

•The PC audio input terminals on the TV are shared

with the HDMI-3 analog audio input terminals.

•Some PC models cannot be connected to this TV.

•An adapter is not needed for computers with a

compatible mini D-sub15-pin terminal.

•Depending on the DVD’s title and the

specifications of the PC on which you are playing

the DVD-Video, some scenes may be skipped or

you may not be able to pause during multi-angle

scenes.

Chapter 2: Connecting your TV

Signal names for mini D-sub 15-pin connector

No.

Signal

name

No.

Signal

name

No.

Signal

name

1 R 6 Ground 11 NC

2 G 7 Ground 12 NC

3 B 8 Ground 13 H-sync

4 NC * 9 NC 14 V-sync

5 NC 10 Ground 15 NC

*NC=Not connected

To connect a PC to the HDMI terminal on the TV:

When connecting a PC with a DVI terminal to the

HDMI terminal on the TV, use an HDMI-to-DVI

adapter cable and analog audio cables.

When connecting a PC with an HDMI terminal, use

an HDMI cable (type A connector). Separate analog

audio cables may not be necessary, depending on PC

hardware and setup ( page 15).

PC/HDMI 3

(AUDIO)

PC audio

output

PC audio

cable

TV back panel

Computer

The HDMI input can accept and display VGA, SVGA,

XGA, WXGA, SXGA, 480i (60Hz), 480p (60Hz), 720p

(60Hz), 1080i (60Hz), and 1080p (24Hz/60Hz) signal

formats. For detailed signal specifications, see page 76.

Note:

•The edges of the images may be hidden.

•If receiving a 480i (HDMI), 480p (HDMI), 720p,

1080i, or 1080p signal program, Native mode

scales the video to display the entire picture within

the borders of the screen (i.e. no overscanning).

Connecting a home network

The LAN port allows your Toshiba TV to connect to

your home network.

You can use this home network to access photos,

movies, and music files that are stored on a DLNA

CERTIFIED™ Server and play them on your TV.

Connecting the TV directly to a PC

without an Internet connection

You will need:

•฀ Crossover LAN cable

TV back panel

Connecting the TV to a home network

without an Internet connection

You will need:

•฀ Standard LAN cables

•฀ Router with Hub

Computer

HDMI-to-

DVI

adapter

cable

TV back panel

Computer

Router with Hub

NAS

Chapter 2: Connecting your TV

Connecting the TV to a home network

with an Internet connection - Wired

You will need:

•฀ Coaxial or telephone cable (depending on your

modem type)

•฀ Standard LAN cables

•฀ Router with Hub

•฀ Modem (DSL or cable)

[1]

Coaxial or telephone cable (depending on your

modem type)

[2] Standard LAN cable

[3] Do NOT connect a phone jack directly to the TV’s

LAN port.

Connecting the TV to a home network

with an Internet connection - Wireless

You will need:

•฀ Coaxial or telephone cable (depending on your

modem type)

•฀ Standard LAN cables

•฀ Wireless LAN access point

•฀ Modem (DSL or cable)

The transmission speed over the wireless LAN and the

distance over which wireless LAN can reach may vary

depending on surrounding electromagnetic environment,

obstacles, access point design and configuration, and

client design and software/hardware configurations. The

actual transmission speed will be lower than the theoretical

maximum speed.

The Built-in WLAN Adapter is based on the

IEEE 802.11n specification and may not be fully

compatible with, or support some features (e.g.,

security) of certain Wi-Fi equipment that are based

on the draft version of IEEE 802.11n.

[1]

Coaxial or telephone cable (depending on your

modem type)

[2] Standard LAN cable

TV back panel

Cable or

phone jack

Router with Hub

Computer

Modem (DSL or cable)

[1]

[2]

[3]

[2]

Computer

Wireless LAN access point Modem (DSL or cable)

Cable or

phone jack

[1]

[2]

Built-in WLAN system:

It is not necessary to

connect an external

WLAN adapter to the TV

Controlling other devices

The TV’s remote control can operate other devices

such as cable converter boxes, satellite receivers, VCRs,

DVD players, and HTIBs (home theater in a box).

Toshiba devices:

The remote is programmed to operate a variety of

devices ( page 79).

Non-Toshiba devices or Toshiba devices that the

remote control is not programmed to operate:

Program the remote ( page 79).

Installing batteries

1 Pull up to open the cover.

2 Install two AA size carbon zinc batteries.

Note:

Use carbon zinc batteries or alkaline

batteries.

3 Slide on the cover.

Caution: Do not expose batteries to excessive

heat such as sunshine, fire, or the like.

Note:

•Every time you change the batteries, you must

reprogram the remote.

•Dispose of batteries in a designated disposal area.

•Always consider the environment when disposing

of batteries. Always follow applicable laws and

regulations.

•If the remote does not operate correctly, or if the

operating range is reduced, replace the batteries.

•Always replace both batteries with new ones.

Never mix battery types or use new and used

batteries together.

•Always remove batteries from the remote if they are

dead or if the remote control is not to be used for

an extended period of time. This prevents battery

acid from leaking into the battery compartment.

Remote control effective range

For optimum performance, aim the remote control

directly at the TV and make sure there are no

obstructions between the remote control and the TV.

24” / 32”

16.4 ft (5m)

Point remote control toward

remote sensor on front of TV.

Chapter 3: Using the remote control

Learning about the Remote Control

The buttons described in this section operate the TV only.

For the HDMI® CEC Control functions, see “Using HDMI® CEC Control” ( Page 40).

For a complete list of the remote’s functions, see “Remote control functional key chart” ( Pages 77–78).

Note: The error message “NOT AVAILABLE” may appear if you press a key for a function that is not available.

Changes the picture mode to Game

when the input mode is ColorStream

HD, PC, video, or HDMI® ( p. 49).

Sets the remote control mode to

control the device:

TV, CABLE/SAT, BD/DVD, or AUX. To

control the TV, press TV.

When the Auto Input feature is set,

you can use these keys to change

inputs on the TV ( p. 32).

Accesses the Quick menu.

Reduces or turns off the sound

( p. 53).

Adjusts the volume level.

Displays the NET TV™ menu ( p. 60).

Accesses Netflix ( p. 61).

Accesses the main TV menu system

( p. 26, 27).

Returns to the previous menu.

Displays Channel Browser™ ( p. 33).

/ Scrolls the left.

Moves to the previous / next page.

Selects the picture size ( p. 46).

Accesses the sleep timer ( p. 43)

Turns the TV on and off.

Freezes the picture ( p. 48).

Displays TV status information as well

as program details, when available (

p. 44).

Displays/hides the Yahoo! TV Widgets

user interface ( p. 62).

Displays Favorite Browser ( p. 33).

/ Scrolls the right.

Directly tune channels. The “-”

button is used to enter 2-part

channel numbers ( p. 33) or edit

the Favorites List ( p. 34).

Selects the video input source

( p. 35).

Cycles through programmed

channels.

Returns to the last viewed channel

or source ( p. 35).

Activates highlighted items in the main

menu system.

Closes onscreen menus.

Opens the closed caption selector

( p. 36).

Selects the audio mode.

When a menu is onscreen, these

buttons select or adjust programming

menus.

These buttons are used for BD/DVD,

CABLE/SAT, and VCR mode.

Initial Setup

When you first turn on or reset the TV, the Initial

Setup window will appear.

Note:

•฀ You can stop Initial Setup by pressing .

However, if you do not finish Initial Setup, the

Initial Setup screen will appear every time

you turn on your TV. To finish Initial Setup, see

“Changing Initial settings” ( page 29).

•฀ does not work until Menu Language,

Time Zone, and Location have been set.

1 Menu Language

Select a language.

2 Time Zone

Time Zone

Daylight Saving Time

Eastern

Off

Local Time Setting

Select a time zone.

3 Daylight Saving Time

Time Zone

Daylight Saving Time

Eastern

Off

Local Time Setting

Select On or Off. Press .

4 Location

To use the TV for displaying in a store showroom, please

select [Store]. [Home] mode is recommended for normal use.

(ENERGY STAR® qualiﬁed)

Home

Location

Select Home for normal home use. Press .

Chapter 4: Initial Setup and Menu

5 ANT/CABLE

To select

Antenna

Then, select

. Press .

Select

Auto

Digital

, or

Standard

( “Setting the

Channel Tuning Mode” on page 33). Press .

To select Cable:

Then, select

. Press .

Note: If you do not want to scan channels, you

do not need to make a selection for ANT/CABLE.

Select Next and press to skip this step.

First, select

Antenna

First, select

Cable

Chapter 4: Initial Setup and Menu

6 Start Scan

Start Scan

Auto Tuning

Press .

Note: If you want to stop scanning, press

while scanning.

•฀After scanning is complete, a channel list screen

(such as the one below) will appear. Press or

Note: Encrypted channels cannot be registered

though these are displayed in the above list.

If some channels are not found after scanning:

•฀Check the antenna/cable connections, and scan

again.

•฀Connect the TV to the antenna or cable box directly

and scan again.

1 > Settings > SETUP > Quick Setup > .

2 A confirmation message appears. Press

t or u

to select Yes. Press .

3 Repeat set up to Step 6.

•฀If you selected Antenna previously, select

Cable.

•฀If you selected Cable previously, select

Antenna.

4 Scan again.

7 Support Information

The Support Information screen appears. Press .

Note: Refer to this information if there is any

problem. This can be confirmed from the

following operation at any time.

> Settings > SETUP > System Information >

Navigating the menu system

•฀ To open the main menu, press on the remote

control or TV control panel.

•฀ Press p, q, t, or u on the remote control or TV

control panel to navigate and make selections.

•฀ To select a menu option, press .

•฀ To move to the next menu page, press or p.

•฀ To return to the previous menu page, press or q.

•฀ To close a menu instantly, press or

•฀ All menus will close automatically if you do not make

a selection within 60 seconds.

Chapter 4: Initial Setup and Menu

Main menu layout

To open the main menus (illustrated below), press

on the remote control or TV control panel.

1st Layer 2nd Layer 3nd Layer Page

Network NET TV 60

Network Setup 56

Wireless

Information 57

Media

Player

Photo (Device select) 67

Movie (Device select) 65

Music (Device select) 66

WallPaper 69

Timer On Timer 43

Sleep Timer 43

Game Timer 40

Settings PICTURE Picture Mode 49

Reset 49

Backlight 49

Contrast 49

Brightness 49

Color 49

Tint 49

Sharpness 49

Advanced


Settings

Expert Picture

Settings 52

TheaterLock 52

SOUND MTS 53

Balance 53

Bass 53

Treble 53

Advanced

Sound

Settings

Dynamic

Volume

(Audyssey

Dynamic

Volume

)

Dynamic

Range Control

1st Layer 2nd Layer 3nd Layer Page

Settings

APPLICATIONS

Widgets 62

NET TV 60

Media Player 64

Channel

Browser

Favorites

Browser 34

On Timer 43

Sleep Timer 43

PREFERENCES

HDMI-CEC

Control Setup 40

Network Setup 56

Netflix Setup 61

VUDU

Deactivation 61

Wallpaper

Setup 69

Channel

Browser Setup 33

PIN Setting 37

Parental

Control and

Locks

Display

Settings

42,

Connection

30,

31,

42,

Auto Input 32

Energy

Saving

Settings

HDMI

Information

Display

Chapter 4: Initial Setup and Menu

1st Layer 2nd Layer 3nd Layer Page

Settings SETUP Menu

Language 29

ANT/CABLE

In 29

Auto Tuning 29

Manual

Tuning 30

TV Settings

29,

30,

31,

33,

36,

Quick Setup 29

Location 29

Software

Upgrade 60

Software

Licences 60

System

Information 45

Reset TV 45

Quick menu

Quick menu helps you access some options more

quickly.

Press to display the Quick menu and press p or

q to select the option.

Note: Quick menu items differ depending on

the current mode.

Quick menu Item Page

PICTURE 46-52

Picture Mode 49

Picture Size 46

Repeat 66, 67, 68

SOUND 53-54

Background Music 68

Speakers 40

HDMI-CEC Player Control 41

Interval Time 68

How to navigate the menu:

> Settings > Main menu > Submenu > .

Format Description

Press the MENU button.

Settings Press t or u to select Settings.

Main menu

Press t or u to select a menu

icon (PICTURE, SOUND,

APPLICATIONS, PREFERENCES,

SETUP)

Submenu Press

p or q

to select a menu.

Press the OK button

Changing Initial settings

From Quick Setup:

1 > Settings > SETUP > Quick Setup > .

2 A confirmation message appears. Press t or u to

select Yes. Press .

3 For changing settings, see “Initial Setup” ( page

25).

From individual settings:

Menu language

You can choose from three different language settings

(English, Français, and Español) for menus and

messages.

1 > Settings > SETUP > Menu Language.

2 Press t or u to select your preferred language.

Press .

Local Time Setting

This setting allows you to specify the correct time

zone for your region.

1 > Settings > SETUP > TV Settings > .

2 Press p or q to select Local Time Setting. Press .

3 Select an option:

•฀ Time Zone

•฀ Daylight Saving Time

4 Press t or u to select your time zone or to select

On to activate Daylight Saving Time. Press .

Chapter 5: Setting up your TV

Location

You can select Home or Store for the TV location. For

normal home use, select Home.

1 > Settings > SETUP > Location.

2 Press t or u to select Home. Press .

ANT/CABLE IN

This setting configures the antenna input source for

the ANT/CABLE terminal.

1 > Settings > SETUP > ANT/CABLE In.

2 Press t or u to select the input source (Antenna

or Cable) for the ANT/CABLE input. Press .

Storing channels in memory

(optional)

To make sure your TV stop only on the channels you

want when you press or on the remote control

or the control panel, store those channels in the TV’s

memory.

Auto Tuning

Note: You must set up the antenna/cable input

source first. See “Initial Setup” (  page 25 ).

You can set up the TV to detect all active channels

in your area and store them in its memory. Then you

can manually store or skip individual channels from

memory.

Option Description

Cable

Note

: If you select Cable, auto

tuning deletes previously stored

channels from memory.

This setup requires some time, but you

do not need to repeat the setup unless

your cable TV service’s lineup changes

significantly.

Antenna

Auto tuning retains stored channels

and stores newly found channels into

memory.

To skip an antenna source channel from

memory, set the channel to be skipped.

See “Skipping channels”.

Note: To tune channels not stored in memory, use

buttons 0–9 and

on the remote control.

Chapter 5: Setting up your TV

1 > Settings > SETUP > Auto Tuning > .

A confirmation screen appears.

2 Press to start Auto Tuning or to abort.

The TV cycles through all the channels, and stores

all active channels in memory.

To view the programmed channels, press or .

Manual Tuning

After storing channels in memory, you can manually

enter channels if the channel number is known.

1 > Settings > SETUP > Manual Tuning > .

2 Use buttons 0–9 on the remote control to enter the

channel number (for example, 56). Press .

3 Press to start Manual Tuning.

The channels found are listed at the bottom of the

screen.

Type Description

ATV Analog channel

DTV Digital channel

Skipping channels

To prevent a channel from being viewed, you can set

it to be skipped.

1 > Settings > SETUP > TV Settings > .

2 Press

p or q

to select Channel Options. Press .

The list of channels appears.

3 Move to the column. Press

p or q

to select a

channel to skip. Press . The box is selected. To

clear the selection, press .

Note: You cannot tune skipped channels using

. Use buttons 0–9 and on the remote control.

Skipping video inputs

You can set video inputs to be skipped when selecting

inputs in the Input selection window.

To turn on skip:

1 > Settings > PREFERENCES > AV Connection

> .

2 Press

p or q

to select Input Labeling. Press .

3 Press

p or q

to select the item you want to be

skipped. Press the RED button to turn on Skip.

To turn off skip:

Press again the RED button to turn off Skip.

Chapter 5: Setting up your TV

Labeling channels

You can label analog TV channels.

1 > Settings > SETUP > TV Settings > .

2 Press

p or q

to select Channel Options. Press .

The list of channels appears.

3 Press

p or q

to select a channel to label.

4 Press . The Software Keyboard window appears.

5 Input a name using the Software Keyboard (

page 59).

6 Press the BLUE button.

Note: Input the desire analog channel up to 7

characters.

Labeling video inputs

The input labels are shown in the input selector, and

in the Channel Browser and banner displays. You can

label video inputs according to the devices you have

connected to the TV.

1 > Settings > PREFERENCES > AV Connection

> .

2 Press

p or q

to select Input Labeling. Press .

3 Press

p or q

to select the item you want to label.

Press t or u to select --, Amplifier, Cable, DVD,

Game, PC, Recorder, Satellite, or VCR, or press the

GREEN button to select User Input.

Note: When User Input is selected by pressing

the GREEN button, the Software Keyboard

window will appear. Input the desired characters

(up to 10 characters) using the Software

Keyboard ( page 59) or the number buttons

for a number input. To save your settings, press

the BLUE button.

4 Repeat Step 3 for other video inputs.

Configuring shared inputs

Shared AV Audio

1 > Settings > PREFERENCES > AV Connection

> .

2 Press

p or q

to select Video 1/ColorStream HD1

Audio.

3 Press t or u to select ColorStream HD1, or Video 1.

Shared PC Audio

1 > Settings > PREFERENCES > AV Connection

> .

2 Press

p or q

to select PC/HDMI 3 Audio.

3 Press t or u to select PC, or HDMI 3.

Chapter 5: Setting up your TV

Setting the Auto Input feature

You can change TV inputs using the MODE SELECT

buttons on the remote control: TV, CABLE/SAT, BD/

DVD, AUX. After setting an input for a specific MODE

SELECT button, the TV automatically switches to the

input when you press and hold the MODE SELECT

button for 3 seconds and release it.

Auto Input settings options for each MODE SELECT

button:

Mode Inputs

TV ANT/CABLE

CABLE/SAT

ANT/CABLE, Video 1,

ColorStream HD1, HDMI 1,

HDMI 2, HDMI 3, HDMI 4

(except 24SL415U), PC

BD/DVD

Video 1, ColorStream HD1,

HDMI 1, HDMI 2, HDMI 3,

HDMI 4 (except 24SL415U), PC

AUX

ANT/CABLE, Video 1,

ColorStream HD1, HDMI 1,

HDMI 2, HDMI 3, HDMI 4

(except 24SL415U), PC

Note: The TV mode select button will be restricted

to the ANT/CABLE input.

To set Auto Input:

1 > Settings > PREFERENCES > Auto Input > .

2 Set Enable Auto Input to On.

3 Press

p or q

to select the mode you want to set.

4 Press t or u to select an input source for that mode.

5 Repeat the procedure for other modes.

To turn off Auto Input:

Select Off in Step 2.

To reset Auto Input:

Select Reset. Press .

Tuning channels

Setting the Channel Tuning Mode

You can select how tuning is handled for analog and

digital channels when the TV is in Antenna mode.

Note: To use this feature, ANT/CABLE In must

be set to Antenna ( page 29).

1 > Settings > SETUP > TV Settings > .

2 Press

p or q

to highlight Channel Tuning Mode.

Mode Description

Standard You can tune both analog and

digital channels normally.

Auto

(default)

Digital channels have priority

when manually entering a channel

number using the 0-9 buttons

on the remote. To tune analog

channels, use / if available.

Digital You can only tune digital

channels.

3 Press t or u to select a mode. Press .

Note: The Channel Options screen and the Channel

Browser ANT/CABLE List are updated when you

change the mode. The History List is cleared, but the

Favorites List is saved.

Tuning in to the next programmed

channel

Press or on the remote control or TV control

panel.

Note: This feature does not work unless you store

channels in the TV’s channel memory ( page 29).

Tuning in to a specific channel

(programmed or unprogrammed)

Channel Description

Analog

Use the 0–9 buttons on the remote

control. (For example, to select

channel 125, press 1, 2, 5.) Press .

Digital

Use the 0–9 buttons on the remote

control to enter the major channel

number. Press the dash ( ) button.

Enter the sub-channel number. (For

example, to select digital channel

125- 1, press 1, 2, 5, –, 1.) Press .

Chapter 6: Basic features

Using the Channel Browser™

The Channel Browser™ is a helpful navigational

interface for all of your channels and inputs.

Features:

•฀ Navigate the contents of all of your inputs.

•฀ Keep a list of your favorite channels.

•฀ Keep a history of the last 32 channels or inputs

viewed.

•฀ Quickly surf and tune to your recently viewed

channels/inputs from the Channel Browser™

History List.

•฀ Surf via Browse mode (to immediately tune to

channels as you highlight them in the Channel

Browser™) or Select mode (to surf channels in the

Channel Browser™ before you select one to tune to).

•฀ Quickly change inputs from the Inputs List.

•฀ Quickly select HDMI® CEC devices from the

HDMI-CEC List.

To set up the Channel Browser™:

1 > Settings > PREFERENCES > Channel

Browser Setup > .

2 Press

p or q

to highlight Navigation.

3 Press t or u to select Select Mode or Browse

Mode.

4 Select a list.

•฀ History List

•฀ ANT/CABLE List

•฀ Inputs List

•฀ Favorites List

•฀ HDMI-CEC List

Note:

•฀ The History List will be cleared every time the

TV is powered off.

•฀ The HDMI-CEC Control List is not available

when Enable HDMI-CEC Control is set to

Off ( page 40).

5 Select On or Off.

6 To return to factory defaults, highlight Reset and

press .

To open the Channel Browser™:

•฀ > APPLICATIONS > Channel Browser > .

•฀ Press or .

Chapter 6: Basic features

Elements of the Channel Browser™

1 Channels stored in the current list.

2 Channel or input that is currently highlighted in

the browser.

3 Inputs or channels labels.

4 Input type.

5 Current list (History, ANT/CABLE, Inputs, Favorites,

or HDMI-CEC).

6 Channel or input currently being viewed.

To cycle through the available lists:

1 Open the Channel Browser™.

2 Press

p or q

Note:

•฀ The History List opens by default. After

selecting another list, the Channel Browser™

will open in the last selected list.

•฀ If all lists are turned off, or will not

display the Channel Browser™. If Favorites

List is turned off, pressing will not

display the Favorites Browser.

•฀ Pressing opens the Channel Browser™

Favorites list regardless of the last selected

list in the Channel Browser™.

To tune to a channel or input in Browse mode:

1 Highlight an item. The TV tunes to the channel or

input.

2 Press to close the Channel Browser™.

To tune to a channel or input in Select mode:

1 Highlight the item you want to tune to.

2 Press .

3 Press to close the Channel Browser™.

Favorites Browser

You can quickly create a favorite channels/inputs list

that is integrated into the Channel Browser™.

To add a favorite channel or input:

1 Tune to the channel or input.

2 Press and hold for 3 seconds.

Note: Additions are added to the beginning of

the Favorites list on the left side of the Channel

Browser™.

To delete a favorite channel or input:

1 Press . The Favorites Browser list appears.

2 Select a channel or input by pressing t or u.

3 Press and hold for 3 seconds.

Adding and clearing channels and inputs

in the History List

Adding channels to the History List:

As a channel or input is tuned, the Channel Browser™

adds it to the History List and displays it on the right

side of the Channel Browser™.

Previously tuned channels and inputs shift to the left.

Press t to surf back through the previously tuned

channels and inputs.

The Channel Browser™ stores these channels:

•฀ Channels that are tuned using the numeric buttons

on the remote control.

•฀ Channels that are tuned for at least 5 seconds using

or .

To clear channels from the History List:

•฀ Reconfigure the ANT/CABLE input.

•฀ Turn off the TV.

Chapter 6: Basic features

Using Channel Return

You can switch between two channels without

entering a channel number each time. This feature

also works for external inputs.

1 Select the first channel you want to view.

2 Select a second channel using the Channel Number

buttons (and the dash ( ) button if needed).

3 Each time you press , the TV switches back

and forth between the last two channels that were

tuned.

Using SurfLock™

The SurfLock™ feature temporarily memorizes one

channel to the button so it can be quickly

returned to from any other channel. This feature also

works for external inputs.

To memorize a channel to the button:

1 Tune the channel you want to program to the

button.

2 Press and hold for about 2 seconds until the

message “Memorized” appears. The channel has

been programmed to the button.

3 You can then change channels repeatedly, and

when you press , the memorized channel will

be tuned.

After pressing and then changing channels

again, the memory is cleared and the button functions

as Channel Return.

Selecting the video input to view

To select the video input to view:

1 Press on the remote control or TV control

panel.

2 Change the input:

•฀ Press 0–6 (for 24”), 0-7 (for 32”).

•฀ Repeatedly press

p or q

. Press .

•฀ Repeatedly press .

HDMI CEC

(for 24”) (for 32”)

Note:

•฀ You can label the video input sources according

to the specific devices you have connected to

the TV ( “Labeling video inputs” on page 31).

•฀ You can skip sources ( “Skipping video

inputs” on page 30).

•฀ Inputs that are set to be skipped will not be

available and will be skipped when selecting

inputs by repeatedly pressing or

•฀ If one or more HDMI® CEC devices are

connected to an HDMI input, the icon appears

in the input selector. In this case, the label (

page 31) will not appear on the input selector.

•฀ When the Auto Input feature is set, you

can select a video input source with the

remote control by pressing and holding the

corresponding MODE SELECT button for 2

seconds ( page 32).

To select a HDMI® CEC device:

1 Press

p or q

to select an HDMI input.

2 Press u. The list of HDMI® CEC devices for that

input appears.

3 If the input has multiple HDM

I®

CEC devices, use

p or q

to select a device.

4 Press .

Chapter 6: Basic features

Using closed captions

To turn on the closed caption mode:

1 > Settings > SETUP > TV Settings > .

2 Press

p or q

to select Closed Captions Settings.

Press .

3 Press

p or q

to select Closed Captions.

4 Press t or u to select On.

Note: If Closed Captions is set to Off, Analog CC

Mode and Digital CC Settings will be not available.

Analog CC mode

The closed caption mode has two options:

Mode Description

Captions

Displays the dialogue, narration, and sound

effects of TV programs and videos that are

closed captioned (usually marked “CC” in

program guides).

Text

Displays information not related to the current

program, such as weather or stock data (when

provided by individual stations).

To view captions or text:

1 > Settings > SETUP > TV Settings > .

2 Press

p or q

to select Closed Captions Settings.

Press .

3 Press

p or q

to select Analog CC Mode.

•฀ To view captions:

Press t or u to highlight CC1, CC2, CC3, or CC4.

Note: If the program or video you have selected

is not closed captioned, no captions will be

displayed.

•฀ To view text:

Press t or u to highlight T1, T2, T3, or T4.

Note: If text is not available in your area, a

black rectangle may appear on the screen. You

can set Closed Captions Settings to Off.

Note: A closed caption signal may not display

when a videotape is dubbed, signal reception is

weak, or signal reception is non-standard.

Digital CC settings

You can customize the closed caption display

characteristics.

Note:

•฀ These settings are available for digital channels

only.

•฀ You cannot set Caption Text and Background

as the same color.

Mode Description

Caption Size Auto, Small, Standard, Large

Caption Text

Type

Auto, Mono w. Serif, Prop. w. Serif,

Mono w/o Serif, Prop. w/o Serif,

Casual, Cursive, Small Capitals

Caption Text

Edge

Auto, None, Raised, Depressed,

Uniform, Left Drop Shadow, Right

Drop shadow

Caption Text

Color

Auto, Black, White, Red, Green,

Blue, Yellow, Magenta, Cyan

Text Foreground

Opacity

Auto, Transparent, Translucent,

Flashing, Solid

Background

Color

Auto, Black, White, Red, Green,

Blue, Yellow, Magenta, Cyan

Text

Background

Opacity

Auto, Transparent, Translucent,

Flashing, Solid

Caption Text

Edge Color

Auto, Black, White, Red, Green,

Blue, Yellow, Magenta, Cyan

To customize the closed captions:

1 > Settings > SETUP > TV Settings > .

2 Press

p or q

to select Closed Captions Settings.

Press .

3 Press p or q to select Digital CC Settings. Press .

4 Press

p or q

to select a characteristic. Press t or

u to select the format for that characteristic.

Using the Closed Caption button

If you press when an analog channel is tuned or from

an external input (480i signal from the video input):

•฀ The CC bar will appear and will display CC1-4, T1-

4, and Off as the options.

If you press when a digital channel is tuned:

•฀ The CC bar will appear and will display the

available caption options (available languages) for

that channel or service.

Chapter 6: Basic features

Setting the PIN code

A PIN code is necessary for some menus.

Note: The Parental Control and Locks menu is

grayed out if no PIN has been set.

Entering a new PIN code

1 > Settings > PREFERENCES > PIN Setting >

2 Use the number buttons to enter a 4-digit number.

Confirm the code.

Note: The PIN code cannot be set to “0000”.

Changing or deleting your PIN code

1 > Settings > PREFERENCES > PIN Setting >

2 Use the number buttons to enter your 4-digit PIN

code.

3 Select Change PIN or Delete PIN. Press .

Note:

•฀ The PIN code cannot be set to “0000”.

•฀ If you delete the PIN code, the settings of

Parental Controls and Locks are reset.

Forgotten PIN code

1 > Settings > PREFERENCES > PIN Setting >

2 Press 4 times within 5 seconds. The code is

cleared.

3 Enter a new PIN code.

Using parental controls

Blocking TV programs and movies by

rating (V-Chip)

Some TV programs and movies include signals that

classify the content of the program as unsuitable for

younger viewers. The V-Chip feature in this TVdetects

the signals and blocks the programs according to the

ratings you select.

Note: The V-Chip feature in this TV supports the

U.S. V-Chip system only.

1 > Settings > PREFERENCES > Parental

Control and Locks > .

2 Enter your 4-digit PIN code.

3 Press

p or q

to highlight Enable Rating Blocking.

4 Press t or u to select On.

5 Press

to select Edit Rating Limits. Press .

The Edit Rating Limits screen appears.

6 Press

, t or u.

7 Press to select a level of blocking.

A box with an “X” indicates a rating that will be

blocked. As you highlight a rating, the rating’s

definition appears at the bottom of the screen.

Note: This feature will be not available if no PIN

code is set.

Chapter 6: Basic features

Downloading an additional rating

system

In the future, an additional rating system may become

available for use in selectively blocking TV programs

and movies.

Note: The currently tuned station must be

receiving a digital signal before an additional

rating system can be downloaded.

1 > Settings > PREFERENCES > Parental

Control and Locks > .

2 Enter your 4-digit PIN code. The Parental Control

and Locks screen appears.

3 Press

p or q

to highlight Enable Rating Blocking.

4 Press t or u to select On.

5 Press

to select Edit Rating Limits. Press . The

Edit Rating Limits screen appears.

6 Select Alt RS. Press . The Edit Alternate Ratings

screen appears.

Note:

•฀ The Alt RS button is only available if

an additional rating system is currently

available.

•฀ The download may take several minutes.

•฀ The information displayed on the

Alternate Ratings screen depends on

the configuration of the additional rating

system available at the time of download.

7 Press

, t, or u.

8 Press to select the desired level of blocking. A

box with an “X” indicates the rating that will be

blocked.

Note:

•฀ You can only download the additional rating

system once. You cannot download updates if

they become available.

•฀ The additional rating system is not designed,

transmitted, or controlled by the TV or

Toshiba, nor is the availability of an additional

rating system determined or controlled by

Toshiba. Similarly, the rating of programs in

an additional rating system is not determined,

transmitted, or controlled by the TV or Toshiba.

•฀ The additional rating system is an evolving

technology; therefore, availability, content, and

format may vary.

Rating system

Independent rating system for broadcasters

Ratings Description and Content themes

TV-MA

Mature Audience Only (This program is

specifically designed to be viewed by

adults and therefore may be unsuitable

for children under 17.

L) Crude or indecent language S) Explicit

sexual activity V) Graphic violence

TV-14

Parents Strongly Cautioned (This

program contains some material that

many parents would find unsuitable for

children under 14 years of age.)

D) Intensely suggestive dialogue L)

Strong, coarse language S) Intense

sexual situations V) Intense violence

TV-PG

Parental Guidance Suggested (This

program contains material parents may

find unsuitable for younger children.)

D) Some suggestive dialogue L)

Infrequent coarse language S) Some

sexual situations V) Moderate violence

TV-G

General Audience (Most parents would

find this program suitable for all ages.)

TV-Y7,

TV-Y7FV

Directed to Older Children (This program

is designed for children age 7 and above.

Note: Programs in which fantasy

violence may be more intense or more

combative than other programs in this

category are designated TV-Y7FV.)

TV-Y All Children (This program is designed

to be appropriate for all children.)

Independent rating system for movies

Ratings Description and Content themes

X-rated (For adults only)

NC-17

Not intended for anyone 17 and under

Restricted (Under 17 requires

accompanying parent or adult)

PG-13

Parents Strongly Cautioned (Some

material may be inappropriate for children

under 13)

Parental Guidance Suggested (Some

material may not be suitable for children)

General Audience (Appropriate for all

ages)

Chapter 6: Basic features

Indication other than rating system

Display Description

NONE

The program is rated None.

(No rating appears) No rating information is

provided.

Note:

•฀If฀you฀place฀an฀“X” in the box next to “Rated “None””,

programs rated “None” or “Not Rated” will be blocked;

Programs that do not provide any rating information will

not be blocked.

Displaying ratings

To display the rating of the program you are watching,

press on the remote control.

Unlocking programs

If you try to tune to a program that exceeds the rating

limits you have set, the TV will enter program lock

mode and a warning message will appear onscreen.

Follow the instructions to temporarily unlock the

program.

Locking specific channels

A channel that is configured as Locked cannot be

viewed unless the PIN code is entered first ( “Setting

the PIN code” on page 37).

1 > Settings > SETUP > TV Settings > .

2 Press

p or q

to select Channel Options. Press .

The list of channels appears.

3 Press u and then

p or q

to select a channel in the

lock column, then press .

4 You must enter your PIN code to be able to lock

channels.

Note: If no PIN code has been set, a warning

appears.

5 The box is selected. To clear the selection, press .

Locking video input

You can lock video inputs and channels 3 and 4. You

cannot view the input sources or channels until you

unlock the inputs by entering the PIN code.

1 > Settings > PREFERENCES > Parental

Control and Locks > .

2 Enter your 4-digit PIN code.

3 Press

p or q

to highlight Input Lock.

4 Press t or u to select Video, Video+, or Off.

Mode Description

Video

Locks Video 1, ColorStream HD1, HDMI

1, HDMI 2, HDMI 3, HDMI 4 (except

24SL415U), and PC.

Video+

Locks Video 1, ColorStream HD1, HDMI

1, HDMI 2, HDMI 3, HDMI 4 (except

24SL415U), PC, and channels 3 and 4.

•฀Select฀Video+ if you want to play

video tapes via the ANT/CABLE input.

Off Unlocks all video inputs and channels 3

and 4.

Chapter 6: Basic features

Setting a time limit for games

You can use the GameTimer® to set a time limit for

playing a video game. When the time expires, the TV

locks all external inputs.

1 > Settings > PREFERENCES > Parental

Control and Locks > .

(Another: > Timer > GameTimer > .)

2 Enter your 4-digit PIN code.

3 Press

p or q

to select GameTimer.

4 Press t or u to select 30, 60, 90, or 120 minutes.

5 To cancel the timer, select Off.

To deactivate the Input Lock once the GameTimer®

has activated it:

Set the Input Lock to Off ( “Locking video input” on

page 39).

Note:

•฀ A message appears when 10 minutes, 3

minutes, and 1 minute remaining.

•฀ If the TV loses power with time remaining, the

TV will enter Input Lock mode when power

is restored (as if the GameTimer had been

activated). You must deactivate the Input Lock

( “Locking video input”).

Locking the control panel

You can lock the control panel to prevent your settings

from being changed accidentally (by children, for

example). When Panel Lock is set to On, none of the

controls on the control panel operate except POWER.

1 > Settings > PREFERENCES > Parental

Control and Locks > .

2 Enter your 4-digit PIN code.

3 Press

p or q

to select Panel Lock.

4 Press t or u to select On.

Note: When Panel Lock is set to On, “Panel

Lock” appears onscreen when the buttons on

the TV control panel are pressed. If the POWER

button is pressed, the TV turns off and you must

use the remote control to turn it on.

To unlock the control panel:

Select Off in Step 4 above.

Using HDMI® CEC Control

This feature uses CEC technology and allows you to

control Toshiba HDMI® CEC compatible devices from

the TV remote control via HDMI connection.

When Enable HDMI-CEC Control in the HDMI-CEC

Control Setup menu is set to On, the following HDMI®

CEC Control functions are enabled.

To set HDMI® CEC Control Setup:

1 > Settings > PREFERENCES > HDMI-CEC Control

Setup > .

2 Press p or q to highlight Enable HDMI-CEC Control.

3 Press t or u to select On.

Note: If you set Enable HDMI-CEC Control to Off,

the other items under HDMI-CEC Control Setup

will be grayed out.

4 Press p or q to select a item. Press t or u to select On

or the desired mode.

•฀ TV Auto Power: On/Off

•฀ Auto Standby: On/Off

•฀ Amplifier Control: On/Off

•฀ Speaker Preference: TV Speakers/Amplifier

Note: These functions depend on the connected

devices.

Controlling HDMI® CEC playback devices

With your TV’s remote control, you can control

the connected HDMI® CEC playback device (DVD

player, etc.) you are watching.

Available remote control key functions:

Before using these key functions, set the MODE

SELECT switch on the remote control to TV.

Button Description

Begins playback.

Stops playback.

Pauses the picture during play or record mode.

Skips forward.

Skips backward.

Fast-forwards.

Rewinds/reverses.

u Navigates contents menu, etc.

Enters contents menu, etc.

Closes the menu.

RED,

GREEN,

YELLOW,

BLUE

Controls various operations

Note: These functions depend on the connected devices.

Chapter 6: Basic features

HDMI® CEC Player Control menu functions:

1 Press to open the Quick menu.

2 Select HDMI-CEC Player Control. Press .

3 Press

p or q

to select the item you want to control

and press .

Item Description

Power Turns the selected device on and off.

Root Menu Accesses the selected device’s top

menu.

Contents

Accesses the contents list when you

press .

Setup

Menu Accesses the device’s setup menu.

Note:

•฀ These functions depend on the connected devices.

•฀ The HDMI-CEC Player Control item is not available

under these conditions:

- A non-HDMI input is selected.

- The Enable HDMI-CEC Control item is set to Off.

- The connected HDMI® CEC device is not a playback

or recording device.

HDMI® CEC Control input source

selection

If an HDMI® CEC device with HDMI switching

capability (e.g. an amplifier) is connected to the

HDMI input, you can select another HDMI® CEC

device that is connected to the master HDMI device.

Use on the remote control or the control panel

( page 35).

Adjusting the amplifier’s audio

Using the TV’s remote control, you can adjust or

mute the sound volume of your amplifier. First, set the

MODE SELECT switch on the remote control to TV.

•฀ adjust the volume level.

•฀ turns off the sound.

1 > Settings > PREFERENCES > HDMI-CEC

Control Setup > .

2 Press

p or q

to highlight Speaker Preference.

3 Press t or u to select Amplifier.

Note: Confirm that a connected HDMI

CEC

device (such as DVD player, etc.) is selected

for the Amplifier input source.

Note:

•฀ You can also use this function when the amplifier

is connected to the TV’s DIGITAL AUDIO OUT

terminal (not HDMI connection). Select a digital

audio input mode on the amplifier.

•฀ These functions depend on the device

connected.

Other HDMI® CEC Control functions

When Enable HDMI-CEC Control and all items in

the HDMI-CEC Control Setup menu are set to On, the

following functions will be enabled.

Item Description

TV Auto

Power

If a HDMI® CEC device is turned on,

the TV turns on automatically.

Auto

Standby

If the TV is turned off, it will send a

message to turn off all of the HDMI®

CEC devices connected to the TV.

Amplifier

Control

If Amplifier Control is set to On, you

can adjust the sound volume or turn off

the sound using the remote control.

Speaker

Preference

From this item, you can set your audio

output preference to the TV speakers

or the amplifier. When this item is set

to Amplifier, the remote control can be

used to adjust or mute the volume of the

audio. This item will not be available

and set to TV Speakers automatically

unless a HDMI® CEC compatible audio

receiver is connected.

Note: When you turn on the amplifier, change

its input source, or adjust the sound volume, the

sound will be output from the amplifier’s speakers

even if TV Speakers has been selected. Turn the

TV off and on again to output the sound from the

TV speakers.

Chapter 6: Basic features

Using the HDMI® settings feature

Note: If some HDMI legacy sources do not work

properly with your HDMI TV, set INSTAPORT™ to

Off. Adjusting this setting should allow your HDMI

legacy source to operate properly with your TV.

Mode

(default setting) Description

INSTAPORT™: On Reduces the lag time when

switching HDMI sources.

RGB Range: Auto

Adjusts the RGB full range signal

automatically.

When Limited is selected, the

RGB output signal is output in

the range of 16 to 235. When Full

is selected, the RGB output signal

is output in the range of 0 to 255.

The RGB Range setting requires appropriate HDMI

source devices. If your HDMI source device does not

support this feature, the TV may not work properly

when it is enabled.

Note:

If your HDMI connection is capable of 1080p

and/or your TV is capable of refresh rates greater

than 60 Hz, you will need a High Speed HDMI® cable.

Conventional HDMI/DVI cables may not work properly

with this mode.

1 Select the appropriate HDMI input mode (HDMI 1,

HDMI 2, HDMI 3, or HDMI 4 (except 24SL415U)).

2 > Settings > PREFERENCES > AV Connection > .

3 Press p or q to select HDMI Settings. Press .

4 Press p or q to select an item.

5 Press t or u to select a setting.

Viewing the HDMI® signal

information

1 > Settings > PREFERENCES > HDMI

Information Display.

2 Press t or u to select On. Press . The normal

banner and signal information banner appear.

Note:

•฀ The signal information banner will appear when this

feature is set to On and you watch HDMI input.

•฀ If you press when this feature is set to Off, only

the normal banner will appear.

Using your PC with the TV

Adjusting the image

If the edges of the picture are hidden, readjust

Horizontal Position and Vertical Position. If the picture

is affected by interference, readjust Clock Phase and

Sampling Clock.

1 Select PC input mode ( “Selecting the video

input to view” on page 35).

2 > Settings > PREFERENCES > Display

Settings > .

3 Press

p or q

to select PC Settings. Press .

Note: If a PC is not connected or there is no PC

input signal, this menu will not be available.

4 Press

p or q

to select an item.

5 Press t or u to make adjustments.

Note: The screen is disrupted momentarily when

adjusting the PC settings. This is not a sign of

malfunction.

Mode Description

Adjustment range

Horizontal

Position

Moves the picture

left/right.

within ±10 from

center.*

Vertical

Position

Moves the picture up/

down.

within ±10 from

center.*

Clock Phase

Helps to reduce noise

and sharpen the picture.

within ±15 from

center.

Sampling

Clock

Helps to reduce

noise and minimize

periodic vertical

stripes on the screen.

within ±5 from

center.

* The default settings and /or adjustment ranges vary

depending on the input signal format.

To reset PC Settings:

Select Reset. Press .

Setting the PC audio

You can output sound from your PC when connecting

it to your TV, using the AUDIO IN terminal and PC

audio cable.

1 > Settings > PREFERENCES > AV Connection

> .

2 Press

p or q

to select PC/HDMI 3 Audio.

3 Press t or u to select PC.

Note: To select PC, set Shared PC Audio to PC.

Chapter 6: Basic features

Setting the timer to turn on the TV

You can set the on timer to turn on the TV to a preset

channel or input at a preset time.

To activate the timer:

1 > Settings > APPLICATIONS > On Timer > .

(Another: > Timer > On Timer > .)

2 Press

p or q

to select Enable On Timer.

3 Press t or u to select On.

Note: If the Enable On Timer is set to Off, other menus

under On Timer cannot be changed.

To set the timer:

1 > Settings > APPLICATIONS > On Timer > .

2 Set these options to your preference:

Item Description

Input Video input source.

Channel Channel to view.

Volume Volume level.

Time until

Power On

Desired length of time until the TV

turns on.

minimum= 00:10, maximum= 12:00

•฀Press t or u.

•฀Use฀the฀number฀buttons.

3 Select Done. Press .

Note: If you do not operate the TV for 1 hour after it is

powered on by the On Timer feature, it turns off.

To cancel the timer:

1 > Settings > APPLICATIONS > On Timer > .

2 Press

p or q

to select Enable On Timer.

3 Press t or u to select Off.

Setting the sleep timer

You can set the TV to turn off after a specific amount

of time (maximum = 12 hours).

Using the remote control:

1 Press

2 Set the time until the TV turns off.

•฀ Repeatedly press to increase the time.

•฀ Press

p or q

to increase or decrease the time.

Using the onscreen menus:

1 > Settings > APPLICATIONS > Sleep Timer.

(Another: > Timer > Sleep Timer > .)

2 Enter the time until the TV turns off.

•฀ Use the number buttons.

•฀ Press t or u

to increase or decrease the time.

Note: If a power failure occurs, the sleep timer

setting may be cleared.

To display the time remaining until the TV turns off:

Press .

To cancel the sleep timer:

Press repeatedly or press

p or q

until it is set to 0

minutes.

Chapter 6: Basic features

Setting Automatic Power Down

The TV can be configured to automatically turn itself

off after 4 hours if you do not operate the TV either

from the remote control or the TV control panel.

1 > Settings > PREFERENCES > Energy Saving

Settings > .

2 Press

p or q

to select Automatic Power Down.

3 Press t or u to select On. Press .

Note:

•฀ 1 minute before switching to standby, a

warning message will appear.

•฀ When the following features are set, the feature

that is set for the nearest time will function.

−Automatic Power Down

−Sleep Timer

−Wallpaper/Auto Power Off

−Auto shutdown after 1 hour of inactivity (after

powering on by On Timer)

−No signal auto power off (after 14 minutes of

no signal)

Setting No Signal Power Down

When an input’s setting in this feature is set to On,

The TV will automatically turn itself off after 14

minutes if no signal is detected.You can change each

input’s setting to Off: ANT/CABLE, Video 1, Video

2, ColorStream HD1, ColorStream HD2, HDMI 1,

HDMI 2, HDMI 3, HDMI 4 (except 24SL415U), PC.

1 > Settings > PREFERENCES > Energy Saving

Settings. Press .

2 Press

p or q

to select No Signal Power Down.

Press .

3 Press

p or q

to highlight the item you want to

change.

4 Press t or u to select Off or On. Press .

Note:

•฀ Default setting for each input is On.

•฀ A warning message will appear 1 minute before

turning off.

Displaying TV status information

To display TV status information:

Press .

The following information will be displayed

(if applicable):

•฀ Current input (ANT/CABLE, Video, etc.)

•฀ If ANT/CABLE is the current input, either

“CABLE” (for cable TV) or “ANT” (for over-the-air

broadcasts).

•฀ Channel number (if in ANT/CABLE mode)

•฀ Input label (if set)

•฀ Digital signal strength indicator (bar graph in lower

right corner of box; for ATSC signals only)

•฀ Stereo, Mono, or SAP audio status (when in HDMI

input mode, PCM)

•฀ Video resolution

•฀ Aspect ratio of incoming video signal (4:3 or 16:9)

•฀ V-Chip rating status (if applicable)

•฀ GameTimer (if set)

•฀ Channel Label (If set or received)

To close the screen:

Press again.

The following additional information (only available

for ANT/CABLE input) will display for off-air digital

channels (if applicable):

•฀ Title

•฀ Duration

•฀ Detailed description

To display the next program’s information for digital

channels, press again. Pressing a third time

will remove the entire banner.

2-2

ANT

Nashville WX Channel

Nash ville WX Channel pr ovides Middle Tenes see and Southern Ke ntucky

weather.

8:59am - 4:59pm EST

480i

4:3

NONE

Chapter 6: Basic features

Viewing support information

1 > Settings > SETUP > System Information.

2 Press to display support information containing

Web/Customer service numbers for US, Canada,

and Mexico.

Resetting to Factory Defaults

You can reset all settings and channels.

1 > Settings > SETUP > Reset TV > .

2 Enter your PIN code (if a PIN code has been set).

3 A confirmation screen appears. Select Yes, and

press . The TV will turn off automatically.

To cancel the reset:

Press t or u to select No. Press .

Power failure

If power is lost while you are watching the TV, the

Last Mode Memory feature automatically turns on

the TV when power is restored.

Selecting the picture size

You can view many program formats in several picture

sizes—Native, 4:3, Full, TheaterWide 1, TheaterWide 2,

TheaterWide 3, Normal, and Dot by Dot.

Note: The picture size illustrations are examples only.

The format of the image (in any of the picture sizes)

depends on the format of the signal you are currently

watching. Select the picture size that displays the

current program in the way that looks best to you.

You can save separate picture size preferences for

each input on your TV.

To select the picture size:

1 Press PIC SIZE.

2 While the Picture Size screen is open, do one of the

following:

•฀Repeatedly press PIC SIZE.

•฀Press the corresponding number button.

•฀Press p or q and .

Note: Some picture sizes may not be available

depending on the format of the signal being received.

Using these functions to change the picture size

(i.e., changing the height/width ratio) for any

purpose other than your private viewing may be

prohibited under the Copyright Laws of the United

States and other countries, and may subject you to

civil and criminal liability.

Note: If you select a TheaterWide® picture size,

the top and bottom edges of the picture (including

subtitles or captions) may be hidden. To view these

edges, adjust the Picture Position ( ”Scrolling

the picture” on page 48) or try viewing the program

in 4:3 or Full.

Chapter 7: Picture and sound controls

Picture Size

Native

(for 480i (HDMI), 480p (HDMI), 720p, 1080i, and

1080p signal programs)

•฀ If receiving a 1080i, 1080p, 720p, 480i (HDMI),

or 480p (HDMI) signal program, the video is

scaled to display the entire picture within the

borders of the screen (i.e. no overscanning).

•฀ This is especially useful for external HD sources

such as DVHS movies, Video Games, or PC

graphics.

•฀ None of the picture is hidden.

Note:

•฀ This mode is supported only for HDMI (1080i,

1080p, 720p, 480i, and 480p), ColorStream® (1080i

and 720p), and ANT/CABLE (digital) inputs (1080i,

1080p, and 720p).

•฀ Depending on the input signal, the picture’s border

may be hidden, displayed in black, or noisy.

4:3

Some program formats will display with sidebars

and/or bars at the top and bottom.

Full

(for 16:9 [480i, 480p] source programs only)

If receiving a squeezed 4:3 format program, the

picture is stretched horizontally to fill the width of

the screen but not stretched vertically.

(for 1080i, 1080p, and 720p program sources)

The edges of the picture may be hidden.

Picture Size

TheaterWide 1

(for 4:3 format programs)

The center of the picture remains close to its original

proportions, but the left and right edges are stretched

horizontally to fill the screen.

TheaterWide 2

(for letter box programs)

A B C D E F G - - - - - - - - - - - - - - - -

The picture’s top and bottom edges may be hidden*.

TheaterWide 3

(for letter box programs with subtitles)

A B C D E F G - - - - - - - - - - - - - - - -

A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -

The picture’s top and bottom edges are hidden*.

Normal

(for SVGA, XGA, WXGA, and SXGA sources)

This size is a non-stretched display. Some input signal

formats will display with sidebars and/or bars at the top

and bottom.

Dot by Dot

(for SVGA, XGA, WXGA, and SXGA sources)

“Dot by Dot” is a non-scaling display. Depending on

the input signal format, the picture is displayed with

sidebars and/or bars at the top and bottom. (Example:

SVGA input source)

*To view the hidden areas (such as subtitles or

captions), see “Scrolling the picture”.

Chapter 7: Picture and sound controls

Scrolling the picture

If the edges of the picture are hidden, you can adjust the

image’s position.

Note:

•฀ You can adjust the picture position when the picture

size is set to TheaterWide 2 or TheaterWide 3.

•฀ When viewing DTV, NET TV. or Media Player,

this feature is not available.

1 > Settings > PREFERENCES > Display

Settings > .

2 Press

p or q

to select Picture Position. Press .

3 Press

p or q

to select Vertical Position.

4 Press t or u to make the appropriate adjustments.

The adjustment range is from -5 to +10. Press .

Using the Auto Aspect feature

When this feature is set to On, the TV will automatically

select the picture size when one of the following input

sources is received:

•฀ A 480i, 480p, 720p, 1080i digital signal from the

ANT/CABLE input

•฀ A 480i signal from the ColorStream HD or VIDEO

input

•฀ A 480i, 480p, 720p, 1080i, 1080p, or VGA

(60/72/75 Hz) signal from the HDMI 1/2/3/4 (except

24SL415U) input

Note:

The auto aspect ratio feature is not applicable

to the PC input.

1 > Settings > PREFERENCES > Display

Settings > .

2 Press

p or q

to select Auto Aspect.

3 Press t or u to select On. Press .

Using the 4:3 Stretch

When 4:3 Stretch is activated, the TV displays 4:3

programs as a full-screen picture.

Note: This feature is available when Auto Aspect

is set to On.

1 > Settings > PREFERENCES > Display

Settings > .

2 Press

p or q

to select 4:3 Stretch.

3 Press t or u to select On. Press .

Freezing the picture

1 When watching the TV, press to freeze the

picture.

2 To unfreeze the picture, press again.

Note: After 15 minutes, the picture will unfreeze

automatically.

Using the FREEZE function for any purpose other

than your private viewing may be prohibited under

the Copyright Laws of the United States and

other countries, and may subject you to civil and

criminal liability.

Chapter 7: Picture and sound controls

Adjusting the picture

Selecting the picture mode

You can select your desired picture settings from the

modes described below.

Mode Description

AutoView®

Automatically adjusts picture settings

based on ambient light conditions

and input signal content.

Sports Bright and dynamic picture.

Standard Standard picture settings.

Movie 1 Lower contrast for darkened room.

Movie 2

Game

Designed for playing a video game

requiring split-second timing

between the screen display and input

from the controller.

PC Designed for the viewing of PC

tables and documents.

Note:

•฀ PC mode is available for HDMI and PC inputs

only (not displayed for other input sources).

•฀ Game mode cannot be turned on when the

ANT/CABLE input is selected.

1 > Settings > PICTURE > Picture Mode.

2 Press t or u to select a mode. Press .

Note:

•฀ The picture mode you select affects the

current input only. You can select a different

picture mode for each input.

•฀ The pictuire mode can be changed to Game

mode by pressing when the input mode

is ColorStream HD, PC, VIDEO, or HDMI.

Adjusting the picture quality

The adjustments you make to picture quality under a

picture mode are saved to that picture mode.

Selection Pressing tPressing u

Backlight* darker lighter

Contrast lower higher

Brightness darker lighter

Color paler deeper

Tint reddish greenish

Sharpness softer sharper

*Backlight: Adjusts the brightness of the entire screen.

When in video mode and no signal is input, this

selection is set to 0. (Settings are stored in memory.)

Note: Some settings cannot be adjusted in any

of the following cases.

•฀ AutoView is selected.

•฀ TheaterLock is set to On.

To adjust the picture quality:

1 > Settings > PICTURE > the setting you

would like to adjust (Backlight, Contrast,

Brightness, Color, Tint, or Sharpness).

2 Press t or u to adjust the setting. Press .

Note:

•฀ Any picture settings that you adjust affect the

current input only. You can adjust the picture

quality separately for each input.

•฀ Depending on a Sharpness value, the Edge

Enhancer effect may be reduced.

To reset to the factory defaults:

1 Select the picture mode you want to reset.

2 > Settings > PICTURE > Reset > .

A confirmation screen appears.

3 Press t or u to select Yes. Press .

Chapter 7: Picture and sound controls

Using the advanced picture

settings features

Note: Some of the Advanced Picture Settings

features will not be available for adjustment

when the Picture Mode is set to

AutoView

Edge Enhancer

The Edge Enhancer feature lets you adjust the levels

for your desired picture settings and achieve a sharper

picture.

To set Edge Enhancer:

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select Edge Enhancer. Press .

3 Press

t or u to select On.

4 Press

p or q

to highlight Level. Press

t or u to

select either 1, 2, 3, 4, or 5 and press .

Note:

•฀ When the Picture Mode is set to

AutoView

the level range is from -2 to +2.

•฀ If the Picture Mode is set to

Game

Edge Enhancer is not available.

•฀ This feature may not work properly

depending on the content.

•฀ Noise may appear on the image depending

on the device connected to the TV (e.g. a

device with a specific enhancer function).

Dynamic Contrast

Dynamic Contrast detects changes in picture quality

that affect the appearance of your contrast settings

and then automatically adjusts the video.

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select Dynamic Contrast.

3 Press

t or u to adjust the level. The adjustment

range is from 0 to 10. Press .

Note: When the Picture Mode is set to AutoView,

the level range is from -5 to +5.

DynaLight™

The DynaLight™ feature automatically strengthens the

black coloring of dark areas in the video according to

the level of darkness.

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select DynaLight.

3 Press

t or u to select On or Off. Press .

Static Gamma

The static gamma feature lets you adjust the levels of

black in the picture.

To adjust the static gamma settings:

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select Static Gamma.

3 Press

t or u to adjust the level. The adjustment

range is within ±15 from center. Press .

MPEG NR

The MPEG noise reduction feature allows you to reduce

visible interference caused by MPEG compression.

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select Noise Reduction. Press .

3 Press

p or q

to highlight MPEG NR.

4 Press

t or u to select either Low, Middle, High, or

Off. Press .

Note: If the Picture Mode is set to Game or PC,

this feature is not available.

DNR

DNR lets you soften the screen representation of a

weak signal to reduce the noise effect.

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select Noise Reduction. Press .

3 Press

p or q

to select DNR.

4 Press

t or u to select Low, Middle, High, Auto, or

Off. Press .

Note:

•฀ If the Picture Mode is set to Game or PC, this

feature is not available.

Chapter 7: Picture and sound controls

•฀ The differences may not always be noticeable.

For the best results, use lower settings, as

picture quality may be greatly reduced if the

setting is too high.

Auto Brightness Sensor

When the Auto Brightness function of Auto Brightness

Sensor Settings is set to On, the TV optimizes the

backlighting levels to suit ambient light conditions.

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select Auto Brightness Sensor

Settings. Press .

3 Press

p or q

to select Auto Brightness Sensor.

4 Press

t or u to select On

Off. Press .

Note: When the Picture Mode is set to AutoView,

this feature is automatically set to On and will not

be available.

Backlight Adjustment Pro

This feature adjusts the backlight so that it can change

to match the ambient light conditions.

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select Auto Brightness Sensor

Settings. Press .

3 Press

p or q

to select Backlight Adjustment Pro.

Press . The Backlight Control Level screen

appears.

4 Press to display the adjustment window. Press

or u to select the point. Press

p or q

to adjust the

level. The adjustment range is from 0

100.

5 Press to fix the adjustment.

To cancel the adjustment when selecting a point,

select Cancel on the screen.

To reset the adjustments of all points to the factory

defaults, select Reset on the screen. Press .

Note: If the Auto Brightness Sensor is set to

Off, this feature will not be available.

ColorMaster™

The ColorMaster™ feature allows you to adjust

standard colors.

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select ColorMaster, press

t or u to

select On. Press .

Base Color Adjustment

When ColorMaster™ is set to On, the list of base

colors appears. You can select a base color to adjust.

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select Base Color Adjustment.

Press . The Base Color Adjustment screen appears.

3 Press

p or q

to select a color. Press u.

4 Press t or u to select Hue, Saturation, or

Brightness.

5 Press

p or q

to adjust the setting.

6 Repeat Steps 3 through 5 to adjust other colors.

To reset the adjustments to the factory defaults,

select Reset on the screen. Press .

Color temperature

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select Color Temperature. Press .

3 Press

p or q

to select Color Temperature.

4 Press t or u to adjust the level. The adjustment

range is 0 (warm) to 10 (cool). Press .

Note: When the Picture Mode is set to AutoView,

the adjustment range is -5 to +5.

Resetting to the factory default

1 > Settings > PICTURE > Advanced Picture

Settings > .

2 Press

p or q

to select Reset. Press .

A confirmation screen appears.

3 Select Yes. Press .

Chapter 7: Picture and sound controls

Setting the Expert Picture Settings

Test Pattern

When the test pattern is on screen, you can navigate

the Picture submenus without removing the image.

When you move to a non-Picture menu, or close the

menus, regular video will be restored.

1 > Settings > PICTURE > Expert Picture

Settings > .

2 Select Test Pattern.

3 Press t or u to select On.

4 Adjust picture settings.

RGB Filter

This feature individually enables or disables the red,

green, and blue components of the picture to allow

for more accurate adjustment of each color.

1 > Settings > PICTURE > Expert Picture

Settings > .

2 Press

p or q

to select RGB Filter. Press .

3 Press

p or q

to select Red, Green, or Blue to adjust.

4 Press t or u to select On.

5 Press

to select Color or Tint, press t or u to

adjust. Press .

Note: It is not possible to turn off all three colors

simultaneously.

White Balance

Window Display

This feature displays the Window Pattern to adjust

the white balance with a measuring device.

1 > Settings > PICTURE > Expert Picture

Settings > .

2 Press

p or q

to select White Balance. Press .

3 Press

p or q

to select Window Display.

4 Press t or u to select On.

5 Adjust picture settings.

Setting Type

You can adjust the white balance setting.

1 > Settings > PICTURE > Expert Picture

Settings > .

2 Press

p or q

to select White Balance. Press .

3 Press

p or q

to select 2P White Balance.

4 Press

p or q

to select Red-Offset, Green-Offset,

Blue-Offset, Red-Gain, Green-Gain, or Blue- Gain.

Press t or u to adjust. Press .

Copy to All Inputs

This feature copies White Balance on the current

input to all other inputs. Individual settings that are

not allowed for a specific input will not be copied.

1 > Settings > PICTURE > Expert Picture

Settings > .

2 Press

p or q

to select White Balance. Press .

3 Press

p or q

to select Copy to All Inputs. Press .

A confirmation screen appears.

4 Select Yes. Press .

Resetting to the factory default

1 > Settings > PICTURE > Expert Picture

Settings > .

2 Press

p or q

to select Reset. Press .

A confirmation screen appears.

3 Select Yes. Press .

Locking the picture settings

The TheaterLock™ feature lets you lock items in the

PICTURE menu that affect the picture’s display. These

items cannot be modified when TheaterLock is set to

On.

1 > Settings > PICTURE > TheaterLock.

2 Press t or u to select On. Press .

Chapter 7: Picture and sound controls

Adjusting the audio

Muting the sound

Press to partially reduce (1/2 Mute) or turn off

(Mute) the sound. Each time you press , the

mute mode changes in the following order:

1/2 Mute Mute Volume

If the closed caption mode is set to Off when you

select MUTE mode, the closed caption feature

becomes active if the TV program is closed-captioned.

To mute the audio without activating the closed

captioning, press to set the volume to 0.

Note: If you modify items in the SOUND menu

while Mute is active, Mute is cancelled.

Selecting stereo/SAP broadcasts

The MTS (multi-channel TV sound) feature is only

available for analog signals on the ANT/CABLE input.

When the TV receives a stereo or SAP (second audio

program) broadcast, the word STEREO or SAP

appears onscreen when is pressed.

To listen in stereo sound:

1 > Settings > SOUND > MTS.

2 Press

t or u to select Stereo. Press

Note:

•฀ You can typically leave the TV in

Stereo

mode

because it outputs the type of sound being

broadcast (stereo or monaural).

•฀ If the sound is noisy, select

Mono

To listen to a second audio program on an

analog station (if available):

If provided by individual analog stations, you can

listen to a second audio program containing another

language, music, or other audio information.

For example, you will hear the other language instead

of the program’s normal audio.

1 > Settings > SOUND > MTS.

2 Press

t or u to select SAP. Press

Note: If there is no sound in

SAP

mode, select

Stereo

Using the MTS button

If you press when an analog channel is

tuned:

•฀ The Analog Audio bar will appear and display

Stereo, SAP, Mono as the options.

If you press when a digital channel is

tuned:

•฀ The Digital Audio bar will appear and offer

different audio choices for the digital channel.

If you press when an external input is

selected:

•฀ No Audio bar is displayed.

Adjusting the audio balance

You can adjust the audio balance.

1 > Settings > SOUND > Balance.

2 Press

t or u to adjust. Press

Adjusting the range

You can adjust bass and treble.

1 > Settings > SOUND > Bass or Treble.

2 Press

t or u to adjust. Press

Selecting the optical audio output

format

You can select the optical audio output format when

you connect a Dolby Digital decoder or other digital

audio systems to the TV’s DIGITAL AUDIO OUT

terminal.

1 Tune to a digital source on the ANT/CABLE input.

2 > Settings > PREFERENCES > AV Connection

> .

3 Press

p or q

to select Digital Audio Output.

4 Press t or u to select Auto

PCM. Press

Option Description

Auto

Outputs Dolby Digital to the digital

audio output if it is being broadcast;

otherwise, it outputs PCM.

PCM Outputs PCM format to the digital audio

output socket.

Chapter 7: Picture and sound controls

Using the Dolby® Digital Dynamic

Range Control feature

You can further compress Dolby Digital and Dolby

Digital Plus dynamic range so you can switch from

digital to analog broadcasts at the same dynamic range.

1 > Settings > SOUND > Dynamic Range

Control.

2 Press

t or u to select On.

Note:

•฀ This feature is available when Dolby Digital

or Dolby Digital Plus is input to the TV in the

following situations:

-When tuned to a digital RF channel.

-When an HDMI input is used.

-When DLNA Certified products or widgets

are used.

•฀ This feature is automatically set to Off when

Dynamic Volume (Audyssey Dynamic

Volume®) is set to Low or High.

•฀ This feature will also affect Digital Audio

Output when the optical audio output format

is set to PCM.

Using Audyssey Dynamic Volume®

This feature provides a consistent sound volume

between television programs, commercials, and

between the loud and soft passages of movies.

1 > Settings > SOUND > Dynamic Volume.

2 Press

t or u to select Low, High, or Off.

Note:

•฀ If Dynamic Range Control is set to On, this

feature will be not available.

•฀ This feature does not affect the audio

signal output from the DIGITAL AUDIO OUT

terminal.

Using advanced sound features

Using surround sound

Voice Enhancement and Dynamic Bass Boost help

to create a thrilling surround sound experience with

deep, rich bass from stereo sound sources. Your TV’s

audio will sound fuller, richer, and wider.

Note: Surround features are only available

for Stereo mode ( “Selecting stereo/SAP

broadcasts” on page 53).

1 > Settings > SOUND > Advanced Sound

Settings > .

2 Press

p or q

highlight the feature to adjust. Press

t or u to adjust the item.

Mode Description

Voice

Enhancement

Turns the vocal emphasis effect

On or Off.

Dynamic Bass

Boost

Selects a bass expansion level

(Off, Low, or High).

Using your home network

•฀ This TV is a DLNA CERTIFIED™ Player.

It can play digital content stored on a DLNA

CERTIFIED™ product with server functions. If

you want to use this TV as a DLNA CERTIFIED™

Player, you will have to configure the network

settings on your TV ( page 21).

•฀ If you want to use your home network with an

Internet connection, you will have to configure the

network settings on your TV ( page 21).

Change the network settings if necessary ( “Setting

up the Network” on page 56).

If you use Internet services, see the following note

before use.

Third party Internet services are not provided by

Toshiba, may change or be discontinued at any time,

and may be subject to third party restrictions. Toshiba

makes no warranties, representations, or assurances

about the content, availability, or functionality of third

party content or services. Third party internet services

may require the creation of a separate account through

a computer with internet access, and payment of one-

time and/or recurring charges.

Certain features currently not available in Canada/

Mexico.

When using a Wireless network connection:

Wireless LAN and your Health:

Wireless LAN products, like other radio devices, emit

radio frequency electromagnetic energy. However, the

level of energy emitted by Wireless LAN devices is

much less than the electromagnetic energy emitted by

wireless devices like mobile phones.

Because Wireless LAN products operate within the

guidelines found in radio frequency safety standards

and recommendations, TOSHIBA believes Wireless

LAN is safe for use by consumers. These standards

and recommendations reflect the consensus of the

scientific community and result from deliberations of

panels and committees of scientists who continually

review and interpret the extensive research literature.

In some situations or environments, the use of Wireless

LAN may be restricted by the proprietor of the building

or responsible representatives of the organization.

Such restrictions may apply in environments where

the risk of interference to other devices or services is

perceived or identified as harmful.

If you are uncertain of the policy that applies on the

use of wireless devices in a specific organization

or environment, you are encouraged to ask for

authorization to use the Wireless LAN device prior to

turning on the equipment.

Chapter 8: Advanced features

Using in a wireless LAN environment:

•฀ It is recommended to use IEEE 802.11a or

IEEE 802.11n on 5 GHz for audio and SD video

streaming.

•฀ It is recommended to use IEEE 802.11n on 5 GHz

for HD video streaming.

•฀ It is recommended that the encoding rate of video

content be 20 Mbps or less.

•฀ It is not recommended to use 2.4 GHz for audio and

video streaming.

•฀ Content playback may be interrupted by surrounding

interference.

Chapter 8: Advanced features

Setting up the Network

You can select the Network Type.

1 > Settings > PREFERENCES > Network

Setup > .

(Another: > Network > Network Setup > .)

2 Press

p or q

to highlight Network Type.

3 Press t or u to select Wired or Wireless.

4 If you select Wired, see “Advanced Network

Setup” ( page 58).

If you select Wireless, see the next section.

Wireless Setup

Note:

•฀ Continued AP (Access Point) connection is

not guaranteed. Connection may be lost while

watching TV.

There are 3 methods for wireless setup:

•฀ Easy Setup (WPS)

If the AP supports WPS, this can be used.

−WPS is a standard designed to simplify the

connection of wireless LAN equipment and

the setup of network security features.

•฀ Assisted Setup (setup using the AP’s notification

information)

Network Name, Authentication, and Encryption are

decided based on information from the AP. You need

to manually set the Security Key.

•฀ Manual Setup (to input all settings)

Easy Setup using PBC (Push Button Configuration)

1 > Settings > PREFERENCES > Network Setup

> .

2 Press

p or q

to select Wireless Setup. Press .

3 Press

p or q

to select Easy Setup. Press .

4 Press t or u to select PBC.

5 Press

to select Start Scan. Press .

6 Following the onscreen instructions, push the

appropriate button on your AP.

7 When a screen reporting that the setup has

succeeded appears, press .

To cancel searching for the AP:

Press while searching for the AP. A message

will appear. Press t or u to select Yes. Press .

Easy Setup using a PIN (Personal Identification

Number)

1 > Settings > PREFERENCES > Network Setup

> .

2 Press

p or q

to select Wireless Setup. Press .

3 Press

p or q

to select Easy Setup. Press .

4 Press t or u to select PIN.

5 Press

to select Start Scan. Press .

6 Scan screen appears. Enter the PIN displayed on

this screen into your PC or AP.

7 Press

p or q

to select the desired AP. Press .

Note: Check the MAC address on the label

or in the manual of the AP and select an AP.

8 When a screen reporting that the setup has

succeeded appears, press .

To cancel searching for the AP:

Press while searching for the AP. A message

will appear. Press t or u to select Yes. Press .

Assisted Setup

1 > Settings > PREFERENCES > Network Setup

> .

2 Press

p or q

to select Wireless Setup. Press .

3 Press

p or q

to select Assisted Setup. Press .

4 Press

p or q

to select the desired AP. Press .

Note: Check the MAC address on the label

or in the manual of the AP and select an AP.

5 Select Security Key. Press . The Software

Keyboard appears.

6 Input the Security Key using the Software

Keyboard ( page 59). To save your settings,

press the BLUE button.

Note: The Security Key must adhere to these

conditions:

− TKIP/AES: 8-63 ASCII or 64 Hex characters

− WEP: 5 or 13 ASCII or 10 or 26 Hex characters

7 Select Done. Press .

Note: Settings are not saved if is pressed

before Done is selected.

Chapter 8: Advanced features

Manual Setup

1 > Settings > PREFERENCES > Network Setup

> .

2 Press

p or q

to select Wireless Setup. Press .

3 Press

p or q

to select Manual Setup. Press .

4 Press

p or q

to select Network Name. Press .

The Software Keyboard window appears.

5 Input the Network Name using the Software

Keyboard ( page 59). To save your settings,

press the BLUE button.

6 Press

p or q

to highlight Authentication. Press t

or u to select Open/Shared, WPA-PSK, or WPA2-

PSK.

7 Press

p or q

to highlight Encryption. Press t or

u to select None, WEP, TKIP, or AES.

Note:

•฀ Certain encryption types are only compatible

with specific authentication types.

−When Authentication is Open/Shared, only

WEP or None are compatible.

−When Authentication is WPA-PSK or WPA2-

PSK, only TKIP or AES are compatible.

•฀ When incompatible Authentication/Encryption

pairings are attempted, a warning message will

be displayed, and no connection attempt will

be made until the incompatibility is resolved.

8 Press

p or q

to select Security Key. Press . The

Software Keyboard window appears.

9 Input the Security Key using the Software Keyboard

( page 59). To save your settings, press the BLUE

button.

Note: This item is grayed out when

Encryption

None

10Select Done. Press .

Note: When Encryption is None, a message

will appear. Press t or u to select Yes. Press

Note: Settings are not saved if is pressed

before Done is selected.

Wireless Information

The settings configured in Wireless Setup can be

confirmed.

1 > Network > Wireless Information > .

2 When the AP connection succeeds, a Wireless

Information screen will appear.

Note: Press the RED button to check the

availability of surrounding APs.

Item Description

Status

Connected is displayed when the

TV is connected to the AP.

Disconnected is displayed when the

TV is disconnected from the AP.

Signal Connection signal strength with the

AP (STRONG/MEDIUM/WEAK)

Speed The link speed with the AP

Mode Working mode (11a, 11b, 11g, 11n)

Channel The channel in use (1-165)

Network Name SSID set

Authentication Authentication set

Encryption Encryption set

Security Key Security Key set

AP MAC

Address

The AP’s MAC address is displayed

when the TV is connected to the

AP.

TV MAC

Address The TV’s MAC address

DHCP

Enabled is displayed when you use

DHCP.

Disabled is displayed when you do

not use DHCP.

IP Address The TV’s IP address

Subnet Mask Value of the Subnet Mask

Default

Gateway Default GATEWAY’s address

DNS DNS’s address

Note: Even if an AP for IEEE 802.11n is used

when Encryption is set to WEP or TKIP, the

Speed value might be low. We recommend that

the Encryption setting be changed to AES

(Under manual setup).

Chapter 8: Advanced features

Advanced Network Setup

Note:

•฀ When the DHCP function of the router connected

to this TV is On, you can set Auto Setup to On or

Off. (Usually set it to On.)

•฀ When the DHCP function of the router is Off,

set Auto Setup to Off, and manually set the IP

Address or DNS Address.

IP Address Setup

Note: Auto Setup is linked to DNS Setup’s Auto

Setup. If Auto Setup is set to On, DNS Setup’s

Auto Setup is set to On.

Auto Setup:

1 > Settings > PREFERENCES > Network Setup

> .

2 Press

p or q

to select Advanced Network Setup.

Press .

3 Press

p or q

to select IP Address Setup. Press .

4 Select Auto Setup. Press t or u to select On.

Note: Other items will be grayed out when Auto

Setup is set to On.

Manual Setup:

1 > Settings > PREFERENCES > Network Setup

> .

2 Press

p or q

to select Advanced Network Setup.

Press .

3 Press

p or q

to select IP Address Setup. Press .

4 Select Auto Setup. Pres t or u to select Off.

5 Press

p or q

to highlight IP Address.

6 Pres t or u to highlight the field you want to

change and use the number buttons to input the IP

address. To save the setting, press .

Note:

•฀ IP address field numbers must be between

0 and 255. If you input an incompatible

number and press , the field number will

be reset to the previous value.

7 Press

p or q

to highlight Subnet Mask, and edit

in the same way as IP Address.

8 Press

p or q

to highlight Default Gateway, and

edit in the same way as IP Address.

Note: If you manually set the IP address, you

must not use the same IP address for any other

device. The IP address you use should be a private

address. If you do not know the correct values to

use, please contact your network administrator or

internet service provider.

DNS Setup

Note:

•฀ When the DHCP function of the router

connected to this TV is Off, set Auto Setup to

Off, and manually set the DNS address(es).

Your internet service provider should have

provided these to you.

•฀ Auto Setup is linked to IP Address Setup’s Auto

Setup. If Auto Setup is set to On, IP Address

Setup’s Auto Setup is set to On.

Auto setup:

1 > Settings > PREFERENCES > Network Setup

> .

2 Press

p or q

to select Advanced Network Setup.

Press .

3 Press

p or q

to select DNS Setup. Press .

4 Select Auto Setup. Press t or u to select On.

Note: Other items will be grayed out when Auto

Setup is set to On.

Manual setup:

1 > Settings > PREFERENCES > Network Setup

> .

2 Press

p or q

to select Advanced Network Setup.

Press .

3 Press

p or q

to select DNS Setup. Press .

4 Select Auto Setup. Press t or u to select Off.

5 Press

p or q

to highlight Primary DNS Address.

6 Press t or u to highlight the field you want to

change, and then use the number buttons to input

the Primary DNS Address. To save the setting, press

Note:

•฀ DNS address field numbers must be between

0 and 255. If you input an incompatible

number and press , the field number will

be reset to the previous value.

7 Press

p or q

to highlight Secondary DNS Address,

and edit in the same way as Primary DNS Address.

MAC Address

You can view the fixed MAC address for the TV.

1 > Settings > PREFERENCES > Network Setup

> .

2 Press

p or q

to select Advanced Network Setup.

Press .

3 Press

p or q

to select MAC Address. Press .

Chapter 8: Advanced features

Network Connection Test

This function checks Internet connectivity.

1 > Settings > PREFERENCES > Network Setup

> .

2 Press

p or q

to select Network Connection Test.

Press .

Note: A message will appear to indicate

whether the connection was successful or not.

Note: Favorable Network Connection Test

results do not guarantee an Internet Connection.

Depending on the situation, some Internet

features may not be available.

To cancel Network Connection Test:

Press while searching for the Internet connection.

Using the software keyboard

You can enter text using the Software Keyboard. The

Software Keyboard window will appear when you press

on a field that accepts character input.

Note: When using the NET TV feature, software

keyboard availability depends on the internet

service being accessed.

To enter text using the software keyboard:

1 Highlight the desired character on the onscreen

software keyboard.

2 Press .

3 Repeat Steps 1 and 2 until you have entered all

desired text.

4 Press the BLUE button to save your settings and

return to the previous screen.

Note: If is pressed, changes are not saved

and the software keyboard window is closed.

H I JK L M

UTSRQPO

V W X Y Z

C D E F G

Aa 1 @

AAA|

Input operation on the remote control:

Button Description

Inputs the selected character.

0-9 Inputs the number directly.

t u

Moves the character highlight.

Moves the cursor.

Moves the cursor to the head of a

character string.

Moves the cursor to the end of a

character string.

RED Deletes 1 character to the left of the

cursor.

GREEN Cycles through upper case, lower case,

numbers, and symbols, if available.

YELLOW Chooses an accented version of the

current letter, if applicable.

BLUE Saves changes and closes the Software

Keyboard window.

Closes the Software Keyboard window

without saving changes.

Chapter 8: Advanced features

Performing a Software Upgrade

TOSHIBA may offer upgrades for the TV’s software

in the future. The TV’s software is upgraded via the

Network.

Before downloading software:

Configure your TV to connect to the Internet.

Note:

•฀ You will not be able to use the TV set while the

upgrade is being performed.

•฀ Do not turn off the TV during the upgrade.

•฀ By upgrading, the factory default values may

be changed.

1 > Settings > SETUP > Software Upgrade >

2 Network Upgrade is displayed. Press .

Note: If the network is not available, a warning

message will appear.

3 After a successful download, the TV software

upgrade will start automatically.

Viewing the Software Licenses

The Licenses for the software used in this TV are

available for viewing.

1 > Settings > SETUP > Software Licenses >

A screen will appear displaying all the licensing

information required for the television’s software.

Using the NET TV™ feature

Note:

•฀ You need to connect to the Internet before using this

feature ( page 21).

•฀ Services may not be currently available in your area.

•฀ User registration or login may be required to use

some services.

NET TV menu

1 Press .

(From the Menu: > Network > NET TV > .)

2 Press t or u to select an icon. Press .

Note:

•฀ When you access the NET TV menu for the

first time, a welcome screen appears (

“Guided Setup” below).

After setup is complete, this feature is

available.

•฀ If the display of the date and time is wrong,

turn off the TV, and turn it on again.

•฀ NET TV menu items may change in the

upgrade process.

Guided Setup

The first time you use Yahoo! TV Widgets this step-

by-step wizard begins with the Welcome Screen.

1 Select Let’s get started!

If you select Exit Setup now, this step will resume

the next time you press .

2 Follow the onscreen instructions.

After completing the Guided Setup:

•฀ When you press or select NET TV from the

Menu, the NET TV menu is displayed.

•฀ When you press or select Widgets from the

Menu, the TV Widgets user interface is displayed.

Chapter 8: Advanced features

Netflix

Watching movies with Netflix

1 Press (→ Step 3) or press .

(From the Menu: > Network > NET TV > .)

2 Press t or u to select Netflix icon. Press .

3 Follow the onscreen instructions.

After having activated Netflix player and prepared

Instant Queue, movies and TV episodes in your

Instant Queue appear on the TV screen. Select the

desired content using the remote control.

Note:

•฀ The resolution of video content streamed from Netflix

varies depending on the communication speed and

bit-rate.

•฀ Future upgrades can change the screens and

messages displayed in the Netflix feature.

To close Netflix:

Press .

To confirm the Netflix ESN (Electronic Serial Number):

1 > Settings > PREFERENCES > Netflix Setup

> .

2 Press

p or q

to select ESN. Press .

Netflix ESN is displayed.

To deactivate your device:

1 > PREFERENCES > Netflix Setup > .

2 Press

p or q

to select Deactivation. Press .

3 Press t or u to select Yes. Press .

VUDU™

VUDU™ is an on-demand service that offers high-

definition movies on the Web.

1 Press .

(From the Menu: > Network > NET TV > .)

2 Press t or u to select VUDU. Press .

Note: Use of VUDU requires a working

broadband internet connection (1 to 2 Mbps for

SD video, 2.25 to 4.5 Mbps for HD video, and 4.5

to 9 Mbps for HDX video).

To close VUDU:

Press .

To deactivate your device:

1 > PREFERENCES > VUDU Deactivation > .

2 Press t or u to select Yes. Press .

YouTube™

YouTube is a video-sharing service managed by

YouTube, LLC.

This TV allows you to view YouTube content.

1 Press .

(From the Menu: > Network > NET TV > .)

2 Press t or u to select YouTube. Press .

3 Press p, q, t or u to select the file you want to view.

Press .

To close YouTube:

Press .

Note:

•฀ YouTube contents have been independently

managed by YouTube, LLC.

•฀ Not all YouTube contents that can be

accessed by computer may be viewed with

this TV.

•฀ This TV may not be able to do some

operations that computer can do.

•฀ Depending on network environment and the

use situation, content may be difficult to view.

•฀ Though the same volume value, an actual

volume might be greatly different depending

on contents.

•฀ This TV might take time during start-up and

the playback of contents.

•฀ Content that the user may feel is improper or

offensive may be included in the contents of

YouTube.

•฀ We do not assume any responsibility for

contents that YouTube offers.

•฀ If you have any questions about YouTube

contents, please contact YouTube, LLC.

•฀ The content of service and the screen that can

be used may be changed without notice.

•฀ You cannot post videos to YouTube from this

TV. Please use a PC to post videos.

•฀ Not all contents can be viewed normally when

you access websites other than YouTube

Leanback through this TV.

Chapter 8: Advanced features

CinemaNow

CinemaNow is an on-demand service that offers high

definition movies on the Web.

1 Press .

(From the Menu: > Network > NET TV > .)

2 Press t or u to select CinemaNow. Press .

To close CinemaNow:

Press .

Blockbuster

Blockbuster is an on-demand service that offers high

definition movies on the Web.

1 Press .

(From the Menu: > Network > NET TV > .)

2 Press t or u to select Blockbuster. Press .

To close Blockbuster:

Press .

Pandora

Pandora is an on-demand service that offers music on

the Web.

1 Press .

(From the Menu: > Network > NET TV > .)

2 Press t or u to select Pandora. Press .

To close Pandora:

Press .

Yahoo!® TV Widgets

Yahoo!® TV Widgets provide an integrated Internet

and TV experience powered by the Yahoo! Connected

TV platform. Yahoo!® TV Widgets allow you to:

•฀ Track your stocks and stay current with financial

news.

•฀ Share photos with friends and family.

•฀ Watch your favorite web videos.

1 Press .

(From the Menu: > Settings >

APPLICATIONS > Widgets > .)

The Dock is the horizontal list of snippets

appearing at the bottom of your TV screen.

A snippet is a shortcut which launches

a TV Widget.

2 Focus is located in the leftmost region (the

highlighted snippet). The dock scrolls snippets

under this focal point. Press t or u to focus on a

snippet. Press to select a snippet.

3 The TV Widget sidebar appears. Press

p or q

select a menu item. Press .

The TV Widget logo and

Home button

The currently focused

button is highlighted.

The sidebar’s bottom

toolbar includes four

color-coded buttons that

map to the colored keys

on the remote control.

Chapter 8: Advanced features

Button Description

RED Closes the widget.

GREEN Changes the widget’s settings.

YELLOW Adds or deletes a snippet.

BLUE Resizes the video to fit onscreen,

or to make it fullscreen.

To close Yahoo!® TV Widgets:

Press .

Note: To use Yahoo!® TV Widgets you must first

complete the “Guided Setup” ( page 60).

Using the Profile Widget

•฀ The Profile Widget

configures your user

profile.

•฀ You can set up multiple

profiles for multiple users.

•฀ Each profile maintains its

own list of TV Widgets.

•฀ The Switch Profile menu

allows you to switch to a

different user profile.

•฀ The Profile Settings menu

allows you to customize

and protect your profile.

•฀ The System Settings

menu allows you to

change your Location,

Repeat the Tutorial, and Restore Factory Settings,

which deletes all profiles and TV Widget settings (not

TV settings).

•฀ The Administrative Controls menu allows you to set

the Screen Saver timeout, create the Owner PIN, and

Create a Profile.

•฀ The Sign in to Yahoo! menu allows you to

personalize your experience using your Yahoo! ID.

•฀ Visit http://www.yahoo.com to create a Yahoo! ID.

Using the Widget Gallery

•฀ The Widget Gallery allows you to browse and discover

new TV Widgets.

•฀ The featured TV Widgets are highlighted in the display

case at the top of the sidebar.

•฀ You can also browse available TV Widgets by category.

•฀ To install a widget, select Add Widget to My Profile and

press .

•฀ The Owner PIN is needed to install widgets for profiles

that have been protected through the Limit Profile

indicator under the Profile Widget → Profile Settings

menu.

•฀ Refer to the Profile Widget → Administrative Controls

menu to set the Owner PIN.

Using other Yahoo! Widgets

•฀ The Yahoo! News Widget provides the latest

headline news for business, entertainment, politics,

sports, top stories, and many other categories.

•฀ The Yahoo! Weather Widget provides updates on

your local and favorite weather locations.

•฀ View the latest stock news with the Yahoo! Finance

Widget.

•฀ The flickr Widget enables slideshows of family and

friends’ photos on your TV.

Chapter 8: Advanced features

Using the Media Player

This TV allows you to access photos, movies, and

music files stored on a USB device.

Moreover, you can also access photos, movies, and

music files from your PC by connecting the TV to

your home network. There are two ways to play

content.

Term meaning:

DMP: DLNA CERTIFIED™ Player

DMS: DLNA CERTIFIED™ Server

•฀ DMP: The TV can control and play content on a DMS.

− DMS is a device with server functions that

stores media content for playback on a DMP.

Note:

•฀ Do not insert/remove USB device while in use.

•฀ is not available while using the Media Player.

Media Player Specifications

Device

USB device:

USB Mass Storage Class devices (MSC)

Note:

•฀ Connectivity is not guaranteed for all

devices.

•฀ Incorrect behavior may occur with a USB

HUB connection.

DLNA CERTIFIED™ Server:

NAS, your PC (for example)

Supported file system

FAT12, FAT16 and FAT32

You must obtain any required permission from copyright

owners to download or use copyrighted content.

Toshiba cannot and does not grant such permission.

Basic operation

Using Media Player with USB

When Auto Start is enabled, you will be asked if

you want to start the Media Player whenever a USB

device is inserted. If Auto Start is disabled (or if you

want to connect to a DMS on the network), you must

manually start the Media Player from the menu.

To change the Auto Start setting:

1 > Settings > APPLICATIONS > Media Player

> .

2 Press

p or q

to select Setup. Press .

3 Press

p or q

to highlight USB Auto Start. Press

t or u to select On or Off.

Auto Start:

1 Insert a USB device into the USB terminal.

A prompt appears.

2 Press t or u to select Yes. Press .

3 Press

p or q

to select Photo, Movie, or Music.

Press . The thumbnail (for Photo) or list of files

(for Movie and Music) appears.

4 Press

p or q

to select the USB device if the

selection screen appears.

Note: If Auto Start is set to Off, you can start the

Media Player manually.

Manual Start:

1 Insert a USB device into the USB terminal.

2 > Settings > APPLICATIONS > Media Player

> .

(Another: > Media Player > .)

3 Press

p or q

to select Photo, Movie, or Music.

(When Another in Step 2, press t or u to select

Photo, Movie, or Music.)

Press . The thumbnail (for Photo) or list of files

(for Movie and Music) appears.

4 Press

p or q

to select the USB device if the

selection screen appears.

To select a file in the list of contents:

1 Press

, t or u to select a file or folder.

2 Press to move to the next layer, or press

to return to the previous layer.

To close the Media Player:

Press . The TV will return to the last-viewed

channel or video input.

Chapter 8: Advanced features

Using Media Player with DLNA CERTIFIED™ Server

You need to configure a home network before using

this feature ( page 21).

1 > Settings > APPLICATIONS > Media Player

> .

(Another: > Media Player > .)

2 Press

p or q

to select Photo, Movie, or Music.

(When Another in Step 1, press t or u to select

Photo, Movie, or Music.)

Press . The thumbnail (for Photo) or list of files

(for Movie and Music) appears.

3 Press

p or q

to select the server you want to use

if a server list is displayed, and press .

To select a file in the list of contents:

1 Press

, t or u to select a file or folder.

2 Press to move to the next layer, or press

to return to the previous layer.

To close the Media Player:

Press . The TV will return to the last-viewed

channel or video input.

Viewing Movie files

Basic Playback:

1 Select a file ( “To select a file in the list of

contents” on page 64). Press or to begin

playback.

Note:

Depending on the file size, it may take

some time to start playback.

2 Press to stop playback.

3 If playback finishes before is pressed, the

screen returns to the list.

Note: When the repeat mode is set to All, the

next file will start playing automatically.

To pause playback:

Press during playback.

To resume normal playback, press .

Note: PAUSE or operations during PAUSE may not be

operable depending on the content or DMS.

To play in fast reverse or fast forward:

Press or during playback. Each time you

press or , the playback speed changes.

•฀ : Fast reverse playback

•฀ : Fast forward playback

To locate a specific file:

Press or repeatedly to access the desired file.

•฀

: Playback starts from the beginning of the

previous file.

•฀ : To locate subsequent files.

Note:

•฀ If the previous or next file is not compatible, it

is skipped automatically.

•฀ These features may not be operable

depending on the content or DMS.

To select a language:

If subtitles or audio information is available in the

video file, you can select it.

1 Press during playback.

2 Press

p or q

to select Subtitle or Audio.

3 Press t or u to select your preferred language.

Chapter 8: Advanced features

To set the repeat mode:

1 Press . The current repeat setting appears.

2 Press t or u to select Off, All, or 1.

3 Press . The setting is effective until the TV is

turned off.

Mode Description

Off

The content is played back only once.

All

Contents in the same folder are repeatedly

played back.

The same content is repeatedly played back.

To display the file status information:

1 Press during playback. The information will

be displayed at the bottom of the screen.

2 Press again to hide the information.

Note: The information may not be correctly displayed

depending on the content or DMS.

File specifications:

USB use

File format: MPEG2 PS, MPEG2 TS, MP4

Video: MPEG2, MPEG4, H.264

Audio: MPEG1-Layer2 / MPEG1-Layer3 /

Dolby Digital (AC3) / LPCM

Maximum number of files: 1000 per folder

Content on DLNA CERTIFIED™ Server

File format: MPEG2 PS, MPEG2 TS, MP4*, WMV*

Video: MPEG2(PS) PAL, MPEG2(TS) PAL,

MPEG2(PS) NTSC, MPEG2(TS) NTSC,

H.264*

Audio: LPCM / MPEG1-Layer1 / MPEG1-

Layer2 / MPEG2-Layer2 /

Dolby Digital (AC3) / AAC

Maximum number of files: 1000 per folder

Note: Some files may not be played.

Playing Music files

Basic Playback:

1 Select a file ( page 64). Press or to

begin playback.

Note: Depending on the file size, it may take

some time to start playback.

2 Press to stop playback.

If playback finishes before is pressed, the

next file will start playing automatically.

To pause playback:

Press during playback.

To resume normal playback, press .

Note: PAUSE or operations during PAUSE may

not be operable depending on the content or

DMS.

To play in fast reverse or fast forward:

Press or during playback. Each time you

press or , the playback speed changes.

•฀ : Fast reverse playback

•฀ : Fast forward playback

Note: These features may not be operable depending

on the content or DMS.

To locate a specific file:

Press or repeatedly to access the desired file.

•฀ : ese features may not be operable depending on

the content or DMS.

•฀ : To locate subsequent files.

Note: If the previous or next file is not compatible,

it is skipped automatically.

Chapter 8: Advanced features

To set the repeat mode:

1 Press . The current repeat setting appears.

2 Press t or u to select Off, All, or 1.

3 Press . The setting is effective until the TV is

turned off.

Mode Description

Off Contents in the same folder are played

back once.

All Contents in the same folder are repeatedly

played back.

1The same content is repeatedly played

back.

To display the file status information:

1 Press during playback. The information will

be displayed at the bottom of the screen.

2 Press again to hide the information.

Note: The information may not be correctly displayed

depending on the content or DMS.

File specifications:

USB use

File format: MP3, MP4 (AAC), LPCM

Sampling frequency: 32 kHz, 44.1 kHz, 48 kHz

Bit rate: from 32 to 320 kbps

Maximum number of files: 1000 per folder

Content on DLNA CERTIFIED™ Server

File format: MP3, LPCM, WMA*

Sampling frequency: 32 kHz, 44.1 kHz, 48 kHz

Bit rate: from 32 to 320 kbps

Maximum number of files: 1000 per folder

Note: Some files may not be played.

Viewing Photo files

Multi View mode:

This view mode allows you to search for photos in a

grid format.

These pictures are displayed using thumbnail data in

each image file.

1 Press

, t or u to move the highlight by one

window.

•฀ If all of the photos will not fit in one screen,

when pressing t at the top left thumbnail,

the screen will move to the previous page.

Similarly, when pressing u at the bottom

right thumbnail, the screen will move to the

next page.

2 When you select a folder, press to move to the

next layer. Press to move back to the previous

layer.

3 Press to view the selected photo in Single View

mode.

Note: Displaying thumbnail data may take time.

Single View mode:

In this view mode, only files located in the selected

directory are displayed. When moving from Multi

View mode to Single View mode, the currently

selected photo is displayed.

1 On Multi view mode, press

, t or u to

select a file. Press .

2 Press t or u to view the next or previous file.

Note:

•฀ If the previous or next file is not compatible, it will

be skipped automatically.

•฀ Single view mode is changed to Multi View mode

when is pressed.

Slideshow mode:

This view allows you to watch a slideshow of the

photos. In this mode, only files located in the selected

directory will be displayed.

1 To switch to Slideshow mode, press while in

Single View mode.

To return to Single View mode, press again.

2 Press t or u to view the next or previous file.

Note: If the previous or next file is not compatible,

it is skipped automatically.

Chapter 8: Advanced features

To set the mode settings:

1 Press to open the Quick menu while in Single

View mode or Slideshow mode.

2 Press

p or q

to select the item (PICTURE,

SOUND, Interval Time, Repeat, Background

Music, or Speakekrs).

3 Press t or u to adjust the setting.

4 Press to return to Single View mode or

Slideshow mode.

Item Description

Interval Time

Sets a time interval to view photos

at (3sec, 5sec, 10sec, 15sec, 30sec,

60sec, or 90sec).

Repeat Displays photos in the same directory

repeatedly. On/Off

To set the background Music:

1 Press to open the Quick menu while in

Slideshow mode.

2 Press p or q to select

Background Music

. Press

3 Highlight Background Music. Press t or u to

select On.

4 Press

to select Select Music. Press .

5 Select a music file.

Note:

•฀ The music must be selected from the USB or DMS

from which the picture files will be played.

•฀ This feature is not available when there is no music

that can be selected.

To rotate the image:

While viewing the image in Single View mode or

Slideshow mode, press

to rotate the image 90

degrees.

To return to the thumbnail:

Press while in Single View mode or Slide Show

mode.

To display file status information:

1 Press . The information will be displayed at the

bottom of the screen.

2 Press again to hide the information.

Note: The information may not be correctly displayed

depending on the content or DMS.

File specifications:

USB use

Data compatibility: JPEG Exif ver 2.2

File format: JPEG

Maximum viewable resolution:

4096 × 4096 (HW decode)

16384 × 16384 (SW decode)

Maximum photo size: 9 MB

Maximum number of files: 2000 per folder

Content on DLNA CERTIFIED™ Server

Data compatibility: JPEG EXIF Ver.1.x or later,

JFIF 1.02a

File format: JPEG

Maximum photo resolution: 4096 x 4096

Maximum photo size: 6 MB

Maximum number of files: 2000 per folder

Note: Some files may not be played.

Chapter 8: Advanced features

Using the Wallpaper feature

This feature allows you to display a photo file stored

on the TV.

•฀ Only one photo file can be stored on the TV.

•฀ The photo file can be overwritten with a file from an

external device (USB, DMS).

1 > Settings > PREFERENCES > Wallpaper

Setup > .

(Another: > Wallpaper > .)

The preview screen will appear.

2 Press u to select Start. Press .

To close the Wallpaper:

Press .

Photo Select

1 > Settings > PREFERENCES > Wallpaper

Setup > . The preview screen will appear.

2 Press

p or q

to select Photo Select. Press .

The device selection screen appears.

Note: This screen will not appear when there is

only one device connected.

3 Press

p or q

to select the appropriate device.

Press .

4 Press

, t or u to select the photo you want to

copy from the USB or DMS to the TV. Press .

Photo Edit

1 > Settings > PREFERENCES > Wallpaper

Setup > . The preview screen appears.

2 Press

p or q

to select Photo Edit. Press .

3 Press

p or q

to select Rotate or Delete.

4 Set the following items as required.

•฀

Rotate - Press to rotate the image 90°clockwise.

•฀

Delete - Press , A confirmation screen appears.

Select YES. Press .

Note: The Factory default image cannot be

deleted.

5 Press .

Auto Power Off

1 > Settings > PREFERENCES > Wallpaper

Setup > . The preview screen appears.

2 Press

p or q

to highlight Auto Power Off.

3 Press t or u to select Off, 00:30, 01:00, 02:00,

04:00, 06:00, or 12:00.

•฀ If the Wallpaper window is left open, the TV

will automatically turn off after the set length

of time (maximum 12 hours).

4 Press .

General troubleshooting

Before calling a service technician, please check this

chapter for a possible cause of the problem and some

solutions you can try.

Black box on-screen

•The closed caption feature is set to one of the Text

modes (T1, T2, T3, or T4). Set the closed caption

feature to Off ( page 36).

TV stops responding to controls

•If the TV stops responding to the remote control

or TV control panel and you cannot turn off the

TV, press and hold the POWER button on the TV

control panel for 5 or more seconds to reset the TV.

Other problems

•If your TV’s problem is not addressed in this

Troubleshooting section or the recommended

solution has not worked, perform the Reset

Factory Defaults procedure ( page 45).

TV will not turn on

•Ensure the power cord is plugged in. Press .

•Replace the remote control’s batteries.

•Try the control panel buttons.

Picture problems

General picture problems

•Check the antenna/cable connections ( page 15).

•Press n the remote control or on the TV and

select a valid video input source ( page 35). If no

device is connected to an input on the TV, nopicture

appears when you select that particular input source.

For device connection details, see Chapter2.

•Antenna reception may be poor. Use a highly

directional outdoor antenna (if applicable).

•The station may be having broadcast difficulties. Try

another channel.

•Adjust the picture quality ( page 49).

•If the Edge Booster does not achieve a sharper picture,

change the Sharpness value to increase the sharpness

level ( page 49).

Video Input Selection problems

•If the Input Selection window does not appear

when you press on the remote control or the

TV control panel, press a second time. The

TV displays the next video input source and the

Input Selection screen.

Cannot view external signals or channel

3 or 4

•If you cannot view signals from external devices

connected to Video 1, ColorStream® HD1, HDMI 1, HDMI 2,

HDMI 3, HDMI 4 (except 24SL415U), PC or from channel

Chapter 9: Troubleshooting

3 or 4, ensure the Input Lock is set to Off ( page 39).

Poor color or no color

•The station may be having broadcast difficulties.

Try another channel.

•Check the Input mode when you use Shared

Inputs ( page 31).

•Adjust the Tint and/or Color ( page 49).

Poor composite picture

•If the TV is connected to an external A/V device

(e.g. DVD player, video game system, set-top

box, etc.) try using a ColorStream or HDMI video

connection instead.

Picture and sound are out of sync

•As with all products that contain a digital display,

this may occur in rare instances when viewing

certain content (e.g. television broadcasts, video

games, DVDs).

Possible causes may include, without limitation,

video processing within the TV, video processing

in an attached gaming system, and video

processing or different compression rates used

by broadcasters in their programming. Try the

following procedures:

– If the TV is connected to an A/V receiver that

has a programmable audio delay feature, use

this feature to help synchronize the sound to

the picture.

– If the problem occurs only on certain TV

channels, inform your local broadcast, cable,

or satellite provider.

•The settings of Shared AV Audio and Shared PC Audio

may be not correct. Ensure the settings ( page 31).

Sound problems

•Check the antenna/cable connections ( Chapter 2).

•The station may be having broadcast difficulties.

Try another channel.

•The sound may be muted. Press VOLUME.

•If you hear no sound, try setting the MTS feature to

Stereo mode ( page 53).

•If you are not receiving a second audio program

from a known SAP source, make sure the MTS

feature is set to SAP mode ( page 53).

•If you hear audio that seems incorrect for the

program you are watching (such as music or a

foreign language), the SAP mode may be on. Set

the MTS feature to Stereo mode ( page 53).

•If you connect a PC using either the PC IN terminal

or an HDMI terminal, ensure that the

Shared PC Audio

setting is properly set ( page 42).

Remote control problems

•Ensure the remote control is set to the correct

device mode ( page 79).

Chapter 9: Troubleshooting

•Remove all obstructions between the remote

control and the TV.

•Replace the remote control’s batteries ( page 23).

•Your TV’s remote control may not operate certain

features on your external device. Refer to the

owner’s manual for your other device to determine

its available features. If your TV remote control

does not operate a specific feature on another

device, use the remote control that came with the

device ( pages 82–87).

•If the TV still does not act as expected, perform the

Reset Factory Defaults procedure ( page 45).

Channel tuning problems

•Ensure the remote control is set to the correct

device mode ( page 79).

•The Auto Tuning feature may have erased the

channel from memory. Add the channel to the

channel memory ( page 29).

•The Lock feature may have blocked the channel.

Unblock the channel ( page 39).

•If you cannot tune digital channels, check

the antenna configuration ( page 29). If

the problem persists, clear all channels from

the channel list and reprogram channels into

memory ( page 29). If the problem persists,

use the Reset Factory Defaults procedure (

page 45). See “TV stops responding to controls”

and “Other problems” ( page 70).

Closed caption problems

•If the program or video you have selected is not

closed-captioned, no captions appear.

•If text is not available, a black rectangle may

appear.

If this happens, turn off the closed-caption

feature ( page 36).

•A closed-caption signal may not display

correctly under the following circumstances: a)

the videotape is dubbed; b) the signal reception

is weak; or c) the signal reception is nonstandard

( page 36).

Rating blocking (V-Chip) problems

•If you forget your PIN code: While the PIN code

entering screen is displayed, press 4 times

within 5 seconds. The old PIN code is cleared (

page 37).

•The V-Chip feature is available for U.S. V-Chip

systems only ( page 37).

No HDMI® CEC Control operation

•The HDMI® CEC Control feature is available for

Toshiba HDMI® CEC compatible devices.

•Ensure HDMI cables with the HDMI Logo

() are used.

•When the connected HDMI® CEC device does

not work correctly after you have changed the

device’s settings, turn off your TV and unplug

the power cord, then plug in and turn on again.

•If several devices are connected, the HDMI®

CEC Control feature may not operate properly.

•Read the instruction manual of the connected

HDMI® CEC device.

HDMI problems

For HDMI cables

•Ensure HDMI cables with the HDMI Logo

() ( page 15).

For Legacy HDMI sources

•Some legacy HDMI sources may not work

properly with the latest HDMI TV products due

to new standards. Turn off INSTAPORT™ (

page 42).

Network problems

Cannot connect to the Internet

•Check the modem and its incoming cable/telephone

connections ( pages 21).

•Confirm your modem’s operation.

•Ensure your IP address is set up correctly.

No network connection

•If using a wired network connection, check to

ensure the LAN cables are connected properly (

pages 21).

•Ensure the modem and router power cords are

plugged in and the devices are operating properly.

•Ensure your IP address is set up correctly. See

Section ( “Setting up the Network”).

•Check to ensure proper operation of other network

connected devices.

Network Setup fails (Auto)

•Check to ensure the LAN cables are connected

properly ( page 21)

•DHCP is not enabled on the router, or no router

is present. Refer to your router’s documentation

for instructions on enabling DHCP. If you do not

have a router, you must manually set up the IP

address.

•Internet service is not available. Check your

cable/DSL modem or contact your ISP for

Internet service issues.

Network Setup fails (Manual)

•Ensure the TV IP address is not the same as any

other device on the network.

Example: IP address 192.168.0.100 and IP

address 192.168.0.101 are different addresses on

the same network.

Chapter 9: Troubleshooting

•Make sure the TV IP address is on the same

subnet as the networked PC.

Example of proper setup: The PC has the

IP address 192.168.0.100 with the Subnet

mask 255.255.255.0, the TV has the IP

address 192.168.0.101 with the Subnet mask

255.255.255.0; both are on the same subnet.

Example of improper setup: The PC has the

IP address 192.168.1.100 with the Subnet

mask 255.255.255.0, the TV has the IP

address 192.168.0.101 with the Subnet mask

255.255.253.0; they are on different sub-nets.

Unstable network connection

•When using a wired home-network connection,

unplug the LAN cables, and then reconnect them.

•When using a wireless home-network connection:

– Remove AC power from the router and the

television for 30 seconds.

•Reconnect AC power to the router.

•Reconnect AC power to the television and turn it

ON. After 2 minutes, check connection stability.

– Connect with LAN cables, if possible, and

check connection stability.

– Repeat the wireless network setup procedure

and check connection stability.

The DMS name is not displayed

•The LAN cables, if used, are not connected

properly ( pages 21).

•The WLAN, if used, is not configured properly.

•The network setup on the Server is incorrect.

Make sure both the DMS and TV are using the

same network type (DHCP/manual) and have

compatible network settings.

•Too many DMSs are connected. You cannot

connect more than 32 sharing devices at one time.

•The DMS is not turned ON.

•The “server” is not a DMS device.

•Check the firewall and streaming settings on the

DMS.

Wireless network problems

•Check that the router/AP (Access point) power is ON.

•After starting wireless network setup, confirm that

the network is configured properly by performing the

network connection test ( page 59).

•Check the router/AP’s connection status (

page 57).

•If the router/AP does not support PBC or WPS,

Easy Setup (PBC) will not work even if the

push-button is pressed.

•If the available router/AP list is not displayed in

Easy Setup (PIN) or Assisted Setup, the power of

the router/AP may be OFF. Check that it is ON,

and then try re-starting the scan for available

routers/APs.

•Refer to the router/AP’s instruction manual.

NET TV or Widget problems

•If the date and time display on the NET TV

menu is wrong, turn off the TV, and turn it on

again.

•NET TV or Widgets may not be available after

turning the TV on while the system is booting.

•Content delivered by NET TV or Widgets are the

responsibility of the Contents Service Provider.

Contact the Service Provider to discuss any

content issues.

Media Player problems

•Ensure that the devices (Display and Server) are

connected correctly.

•Incorrect behavior may occur when using a USB

HUB connection.

•The size of pictures stored in the DMS may be

automatically changed by the DMS and improperly

displayed. This is a result of the DMS.

•Photo files that were processed and edited using the

PC’s application software may not be viewable.

•When viewing content that supports two or

more formats the display may select one format

automatically.

•Copyright protected content stored on the DMS

may not be playable on the display.

•Content playback stability may be affected by

heavy network traffic.

•Content originally recorded on a PC may not play

correctly.

•Set the media sharing of the DMS correctly,

according to the DMS instruction manual.

•Confirm that the contents of either the DMS or

the USB storage device are in formats that are

supported by this TV ( pages 66, 67, or 68).

•Depending on the DMS, access may be limited

by the MAC address. Set the server according to

the DMS’s instruction manual. This TV’s MAC

Address can be confirmed in the Network Setup

portion of the User Menu ( page 58).

For DLNA CERTIFIED™ Player

•Depending on the DMS, it may take time to

display the list.

Chapter 9: Troubleshooting

LED indications

The POWER LED lights indicate the TV’s status, as

described below.

POWER On/Standby LED

•฀ Green

The TV is operating properly.

•฀ RED

The TV is on standby.

•฀ Green blinks

System booting. After a while, the screen appears.

•฀ Red blinks

Power-On Failure. Turn off the TV and unplug the

power cord. Then plug the power cord in again and

turn on the TV.

If the problem persists after trying the solutions:

•฀ In the U.S., visit TAIS Consumer Solutions on the

web at www.support.toshiba.com or call 1-800-

631-3811.

•฀ In Canada, locate the nearest Toshiba authorized

service depot by directing your web browser to

www.toshiba.ca; click “Home Entertainment,” and

then click “Support.”

TV front

Power LED

Specifications

Note:

•This model complies with the specifications

listed below.

•Designs and specifications are subject to

change without notice.

•This model may not be compatible with

features and/or specifications that may be

added in the future.

Television System

NTSC standard

ATSC standard (8VSB)

Digital Cable (64 QAM, 256 QAM; in-the-clear,

unencrypted)

Channel Coverage

VHF: 2 through 13

UHF: 14 through 69

Cable TV:

Mid band (A-8 through A-1, A through I)

Super band (J through W)

Hyper band (AA through ZZ, AAA, BBB)

Ultra band (65 through 94, 100 through 135)

Power Source: 120 V AC, 60 Hz

Power Consumption

24SL415U: 0.7 A (maximum current)

0.60 W in standby mode

32SL415U: 0.7 A (maximum current)

0.60 W in standby mode

Audio Power:

24SL415U: 5 W + 5 W

32SL415U: 7W + 7 W

Speaker Type:

24SL415U:

Two 3-5/8 × 1 × 7/8 inches (91 × 25 × 23 mm)

32SL415U/40SL415U:

Two 5-5/8 × 1 × 5/8 inches (142 × 25 × 16 mm)

Video/Audio Terminals

VIDEO/AUDIO INPUT:

VIDEO: 1 V(p-p), 75 ohm, negative sync.

AUDIO: 200 mV(rms) (-20dBFS)

ColorStream® (component video) HD INPUT:

VIDEO: Y: 1V(p-p), 75 ohm

PR: 0.7 V(p-p), 75 ohm

PB: 0.7 V(p-p), 75 ohm

Suggested formats: 1080i, 720p,

480p, 480i

AUDIO: 200 mV(rms), 22 k ohm or greater

Chapter 10: Appendix

HDMI® INPUT:

HDMI compliant

HDCP compliant

Suggested formats: See table on page 76.

HDMI Audio: 2-channel Linear-PCM;

32/44.1/48 kHz

sampling frequency; 16/20/24

bits per sample

DIGITAL AUDIO OUTPUT:

Optical type

PC INPUT:

15-Pin D-sub Analog RGB

Wireless connection

•฀Standard: IEEE 802.11a/b/g/n

•฀Host Interface: USB2.0 compatible

•฀Frequency Range: 5.15–5.35 GHz, 5.47–5.725

GHz, 5.725–5.850 GHz, 2.412–2.462 GHz

•฀Security: WEP64/128, TKIP, AES, WPA/WPA2-

PSK, WPS, None

Ethernet

•฀IEEE 802.3.

USB

•฀Universal Serial Bus Specification,Revison1.1.

•฀Universal Serial Bus Specification,Revison2.0.

Dimensions (include foot stand)

24SL415U:

Width: 1’11 inches (583.1mm)

Height: 1’4-1/8 inches (409.6mm)

Depth: 9-1/8 inches (233.2mm)

32SL415U:

Width: 2’6-1/2 inches (775.4mm)

Height: 1’8-1/8 inches (512.5mm)

Depth: 7-7/8 inches (200.0mm)

Mass (Weight)

24SL415U: 12.0 lbs (5.5 kg)

32SL415U: 18.7 lbs (8.5 kg)

Operating conditions

Temperature: 32ºF - 95ºF (0ºC - 35ºC)

Humidity: 20 - 80% (no moisture condensation)

Supplied Accessories

•฀Remote control with two size “AA” batteries

•฀Easy Setup Guide

•฀Stop/Quick set up guide

Chapter 10: Appendix

Acceptable signal formats for PC IN and HDMI terminals

PC IN signal formats

Note:

•The PC IN on this TV only accepts signal formats which are compliant with VESA-DMT as in the table

below. Since some PC input signals are different from the resolution and frequency described in the

table below, the following problems may occur: incorrect display, false format detection, picture position

failure, blur, or judder. In these cases, set the monitor output format on your PC to conform to any of the

signals in the table below.

•The signals whose vertical frequency is 56 Hz,70 Hz, 72 Hz, or 75 Hz are converted to a 60 Hz signal.

•When you connect a PC to this TV, it is recommended to set the refresh rate of your PC to 60 Hz.

•The PC IN on this TV does not accept the Sync on Green, Composite Sync and Interlace signals.

Format Resolution V. Frequency H. Frequency Pixel Clock Frequency VESA Standard (DMT)

VGA 640 × 480 59.940/60 Hz 31.469/31.500 kHz 25.175/25.200 MHz l

72.809 Hz 37.861 kHz 31.500 MHz l

75.000 Hz 37.500 kHz 31.500 MHz l

SVGA 800 × 600 56.250 Hz 35.156 kHz 36.000 MHz l

60.317 Hz 37.879 kHz 40.000 MHz l

72.188 Hz 48.077 kHz 50.000 MHz l

75.000 Hz 46.875 kHz 49.500 MHz l

XGA 1024 × 768 60.004 Hz 48.363 kHz 65.000 MHz l

70.069 Hz 56.476 kHz 75.000 MHz l

75.029 Hz 60.023 kHz 78.750 MHz l

WXGA 1280 × 768 59.995 Hz 47.396 kHz 68.250 MHz l

59.870 Hz 47.776 kHz 79.500 MHz l

74.893 Hz 60.289 kHz 102.250 MHz l

1360 × 768 60.015 Hz 47.712 kHz 85.500 MHz l

SXGA 1280 × 1024 60.020 Hz 63.981 kHz 108.000 MHz l

75.025 Hz 79.976 kHz 135.000 MHz l

Chapter 10: Appendix

HDMI signal formats

Note:

•The HDMI inputs on this TV only accept VGA, SVGA, XGA, WXGA, and SXGA signal formats which are

compliant with VESA-DMT as in the table below. Since some PC, HDMI, or DVI device input signals are

different from the resolution and frequency described in the table below, the following problems may

occur: incorrect display, false format detection, picture position failure, blur, or judder. In these cases,

set the monitor output format on your PC, HDMI, or DVI device to conform to any of the signals in the

table below.

•The signals whose vertical frequency is 24 Hz, 56 Hz, 70 Hz, 72 Hz, or 75 Hz are converted to a 60 Hz

signal.

•When you connect a PC to this TV, it is recommended to set the refresh rate of your PC to 60 Hz.

Format Resolution V. Frequency H. Frequency Pixel Clock Frequency VESA Standard

VGA 640 × 480 59.940 Hz 31.469 kHz 25.175 MHz l

72.809 Hz 37.861 kHz 31.500 MHz l

75.000 Hz 37.500 kHz 31.500 MHz l

SVGA 800 × 600 56.250 Hz 35.156 kHz 36.000 MHz l

60.317 Hz 37.879 kHz 40.000 MHz l

72.188 Hz 48.077 kHz 50.000 MHz l

75.000 Hz 46.875 kHz 49.500 MHz l

XGA 1024 × 768 60.004 Hz 48.363 kHz 65.000 MHz l

70.069 Hz 56.476 kHz 75.000 MHz l

75.029 Hz 60.023 kHz 78.750 MHz l

WXGA 1280 × 768 59.995 Hz 47.396 kHz 68.250 MHz l

59.870 Hz 47.776 kHz 79.500 MHz l

74.893 Hz 60.289 kHz 102.250 MHz l

1360 × 768 60.015 Hz 47.712 kHz 85.500 MHz l

SXGA 1280 × 1024 60.020 Hz 63.981 kHz 108.000 MHz l

75.000 Hz 79.976 kHz 135.000 MHz l

480i 720 × 480i 59.940/60 Hz 15.734/15.750 kHz 27.000/27.027 MHz

480p 720 × 480p 59.940/60 Hz 31.469/31.500 kHz 27.000/27.027 MHz

720p 1280 × 720p 59.940/60 Hz 44.955/45.000 kHz 74.176/74.250 MHz

1080i 1920 × 1080i 59.940/60 Hz 33.716/33.750 kHz 74.176/74.250 MHz

1080p 1920 × 1080p 23.976/24 Hz 26.973/27.000 kHz 74.176/74.250 MHz

59.940/60 Hz 67.433/67.500 kHz 148.352/148.500 MHz

Chapter 10: Appendix

Remote Control functional key chart

REMOTE

CONTROL

KEY

Toshiba TV CABLE SAT

(satellite) Blu-Ray™ DVD/

DVD-R VCR Receive CD

GAME Game --- --- --- --- --- --- ---

POWER Power Power Power Power Power Power Power Power

FREEZE (TV)Freeze

MODE

SELECT Remote control device mode selection

1 1 1 1 1 1 1 AV

input 1 1

2 2 2 2 2 2 2 AV

input 2 2

3 3 3 3 3 3 3 AV

input 3 3

4 4 4 4 4 4 4 AV

input 4 4

5 5 5 5 5 5 5 CD 5

6 6 6 6 6 6 6 Tuner 6

7 7 7 7 7 7 7 Phono 7

8 8 8 8 8 8 8 Cassette 8

9 9 9 9 9 9 9 AUX 9

0 0 0 0 0 0 0 --- 0

–– (digital

separator) --- +10 +10 +10 +100 --- ---

INPUT

(TV) Input

Input Input

VOL +/–

Volume

up/down

Volume

up/down *1

Volume

up/down *1

Volume

up/down*1

Volume

up/down*1

Volume

up/down*1

Volume

up/down

Volume

up/down

QUICK

Quick Menu

--- --- --- --- --- --- ---

MUTE Mute Mute*1 Mute*1 Mute*1 Mute*1 Mute*1 Mute Mute

CH RTN

Last channel Last

channel

Last

channel

--- --- --- --- ---

CHpq Channel up/

down

Channel

up/down

Channel

up/down

--- Channel

up/down

Channel

up/down

Channel

up/down

---

NET TV/

POPUP MENU NET TV --- ---

Popup

Menu Menu

--- --- ---

NETFLIX

Netﬂix

--- --- --- --- --- --- ---

Y! WIDGETS Yahoo! TV

Widgets --- --- --- --- --- --- ---

INFO (TV) Info

Page up/down

--- --- --- --- --- --- ---

Page left/

Channel

Browser

--- --- --- --- --- --- ---

Page right/

Favorite

Browser

--- --- --- --- --- --- ---

MENU Menu

Menu,

Cable

Menu,

Action

Top Menu Top Menu --- Menu Menu

GUIDE Guide Guide Guide --- --- --- --- ---

Chapter 10: Appendix

REMOTE

CONTROL

KEY

Toshiba TV CABLE SAT

(satellite) Blu-Ray DVD/

DVD-R VCR Receive CD

RETURN Return --- --- Return Return --- --- ---

EXIT Exit Exit Exit Clear Clear --- --- ---

p / qMenu select

up/down

Cursor

up/down

Cursor

up/down

Cursor

up/down

Cursor

up/down --- --- ---

Menu select

left/right

Cursor

left/right

Cursor

left/right

Cursor

left/right

Cursor

left/right --- --- ---

OK OK Select Select Select Select --- --- ---

REW Rewind*2 Rewind Rewind Rewind Rewind Rewind --- Rewind

PLAY Play*2 Play Play Play Play Play --- Play

FF Fast

Forward*2

Fast

Forward

Fast

Forward

Fast

Forward

Fast

Forward

Fast

Forward --- Fast

Forward

SKIP Skip REW/

DAY– *2 --- --- Skip

REW

Skip

REW --- --- Skip

REW

STOP Stop*2 Stop Stop Stop Stop Stop --- Stop

PAUSE/STEP Pause*2 Pause Pause Pause Pause Pause --- Pause

SKIP Skip FWD/

DAY+*2 --- --- Skip FWD Skip FWD --- --- Skip

FWD

RED Red --- --- Red Red --- --- ---

GREEN Green --- --- Green Green --- --- ---

YELLOW Yellow --- --- Yellow Yellow --- --- ---

BLUE/

HOME Blue/Home --- --- Blue Blue --- --- ---

SLEEP

(TV)Sleep

PIC SIZE (TV) Picture size

MTS/AUDIO MTS --- --- Audio Audio --- --- ---

CC/

SUBTITLE

C. Caption --- --- Subtitle Subtitle --- --- ---

SET UP --- --- ---

Setup Setup

--- --- ---

REC Record Record Record ---

Record*3

(Double

click)

Record

(Double

click)

--- ---

Note:

•“---” = key does not send a signal in that remote control mode.

*1 Volume affects the TV by default. When the volume is unlocked, each device has its own volume if

its ID has volume data. The AUDIO modes will have their own volume if volume lock is set on TV,

CABLE/SAT, VCR/PVR, or DVD mode. See “Locking the volume keys” (



page 80).

*2 This function is available for only HDMI CEC® (



page 40) and Media Player.

*3 DVD: REC is only for DVD Recorder, no function is selected for DVD Player.

Chapter 10: Appendix

Operating other devices

Your TV remote control has one dedicated TV mode

and three programmable multi-brand modes: CABLE/

SAT, BD/DVD, and AUX.

Note: To operate a non-Toshiba device or a Toshiba

device that the remote control is not preprogrammed

to operate, you must program the remote.

Mode select Default device mode control

(before programming)

TV Toshiba TV

CABLE/SAT Toshiba Satellite receiver

BD/DVD Toshiba Blu-ray Disc™ player

AUX Onkyo Receiver

Mode select Device mode control

(after programming)

TV Toshiba TV

CABLE/SAT

Multi-brand video/audio devicesBD/DVD

AUX

Note: If you cannot program the TV’s remote to operate

your device or some of its features, use the device’s

remote or the controls on the device.

Programming the remote to

operate other devices

Device code setup

1 Find the code for your device brand in the remote

control device code table (



page 82–87).

If multiple codes are listed, try each one

separately until you find one that works.

2 Press a mode select button (CABLE/SAT, BD/DVD,

or AUX).

3 While holding down , input the 4-digit code

for your device.

4 Point the remote at the device. Press to test the

code.

Result Meaning

The device responds.

Valid code

The device does not

respond.

Invalid code

Repeat the procedure, using

another code

5 When programming is complete, test all necessary

keys on the TV’s remote that operate your device.

If some keys are not operational, repeat the device

code setup using another code (if other codes are

listed for your device).

6 To control the TV, press TV.

7 If your VCR does not respond to the codes for

your VCR brand, and has a switch labeled VCR1/

VCR2, set the switch to the other position, then

program the remote control.

Note: Every time you change the batteries, you must

reprogram the remote.

Chapter 10: Appendix

Searching for a device code

If you do not know the device code for a particular

device, you can view each available code for that de-

vice mode and sample the functions to ﬁnd the code

that operates the target device.

1 Press a mode select button on the remote.

2 While holding down , press 8, 5, 0, 0. The

remote control enters program mode.

3 Point the remote at the target device and press

, 1, , , or , and then press

p or q

to change a code.

4 If the device responds to the remote control: Press

, to store the device code. The remote exits

program mode.

5 If the device does not respond to the remote control:

Repeat this step until the device responds to the remote.

When no code is found, exit the program mode by

the following operation:

•Press . (current state is stored)

•Press no key for 10 seconds. (current state is

not stored)

Note: When a search cycle is completed, the remote

displays each available code again. If no key is

pressed within 10 seconds, the remote exits program

mode and returns to the previous code.

Locking the volume keys

By default, the remote’s volume keys ( , , and

MUTE) are locked to the TV device mode.

State Meaning

Locked (default)

The remote operates the TV’s

volume except the AUX mode,

even when the TV is not the cur-

rent device mode.

Unlocked

The remote operates the volume

of the device associated with the

current device mode.Each device

mode has its own volume (if the

device ID has volume data).

Locked to a speciﬁc

device mode

The remote operates the volume

of the device associated with

the locked mode, even when the

locked mode is not the current

device mode.

Note: The AUX mode is not

locked to other device modes.

See “Operating other devices” (



page 79).

To lock the remote’s volume keys to a specific mode:

Example: CABLE/SAT mode

1 Press CABLE/SAT.

2 While holding down , press 8, 0, 0, 0.

3 Press . (locked).

The remote’s volume keys now operate the

volume of the device associated with the CABLE/

SAT mode, even when CABLE/SAT is not the

current device mode.

To unlock the remote’s volume keys:

1 While holding down , press 8, 0, 0, 0.

2 Press . The CABLE/SAT mode is unlocked.

Clearing the remote’s programming

You can clear all programmed remote control fea-

tures not related to “Device code setup” and reset the

volume lock to the TV device mode.

While holding down , press 8, 9, 0, 0.

Resetting to the factory default

You can clear changed manufacturing features.

While holding down , press 8, 9, 0, 1.

Chapter 10: Appendix

Operating the TV with

combination buttons

You can directly operate the TV power, input switch,

picture size switch, and picture mode switch by

pressing a combination button while holding down a

color button.

Color button Combination

button Behavior/Mode

RED

GAME Power Off

POWER Power On

1 Video 1

2 ---------

3 ColorStream HD1

4 ---------

5 HDMI 1

6 HDMI 2

7 HDMI 3

8 HDMI 4 (except 24SL415U)

9 PC

0 ANT/CABLE

MUTE Mute On

GREEN

1 Native (Picture Size)

2 4:3 (Picture Size)

3TheaterWide 1

(Picture Size)

4TheaterWide 2

(Picture Size)

5TheaterWide 3

(Picture Size)

6 Full (Picture Size)

7 Normal (Picture Size)

8Dot by Dot

(Picture Size)

MUTE 1/2 Mute On

YELLOW

1AutoView

(Picture Mode)

2 Sports (Picture Mode)

3Standard

(Picture Mode)

4Movie 1

(Picture Mode)

5Movie 2

(Picture Mode)

6 Store (Picture Mode)

Color button Combination

button Behavior/Mode

YELLOW

7 Game (Picture Mode)

8 PC (Picture Mode)

MUTE Mute Off

Chapter 10: Appendix

Remote control codes

In some cases, you may not be able

to operate your device with the TV

remote control. Your device may

use a code that is not recognized

by the TV remote control. If this

happens, use the device’s remote

control.

Satellite

Brand Code

BELL EXPRESSVU 0009, 0087

CHAPPARAL 0112

COOLSAT 0015, 0109

DIGIWAV 0019

DIRECTV 0020, 0027,

0013, 0018,

0028, 0028,

0027, 0029,

0030, 0090,

0091, 0105,

0107, 0108,

0118, 0119

DISH NETWORK 0009

DRAKE 0025, 0094,

0095

ECHOSTAR 0009, 0008,

0010, 0011,

0012

EXPRESSVU 0087

FORTEC STAR 0016, 0093,

0104, 0113

GE 0092

GENERAL

INSTRUMENT (GI)

0017, 0103

GLOBECAST 0097, 0098

HITACHI 0020, 0105,

0107, 0108

HUGHES NETWORK 0020, 0115,

0116

LG 0020

MAGNAVOX 0027, 0089

MITSUBISHI 0020, 0105,

0107, 0108

MOTOROLA 0017, 0024,

0103

NEOSAT 0009

NOVAPLEX 0101

NET 0026

PACE 0023, 0024

PANASONIC 0013, 0014,

0016

PANSAT 0016

PHILIPS 0027, 0020,

0089, 0105,

0107, 0108,

0116

PHILIPS-MAGNAVOX 0027, 0089

PRIMESTAR 0017

SAMSONIC 0114

SAMSUNG 0018

SKY NETWORK 0023, 0024,

0027, 0090,

0091

SONY 0028, 0117

STAR SIGHT 0088

STARCHOICE 0017

STS 0111

SUPER GUIDE 0110

SYLVANIA 0102

THOMSON 0027

TOSHIBA 0020, 0022,

0000, 0001,

0002, 0003,

0004, 0005,

0006, 0007,

0096, 0099,

0105, 0107,

0108

ULTIMATE TV 0028

UNIDEN 0088

VIDEO CIPHER 0025

VISIONTEC 0106

VIEWSAT 0021

ZENITH 0024, 0025,

0094, 0095,

0100

Cable

Brand Code

ABC 0081, 0078,

0065, 0079,

0123

ADELPHIA 0045

ALLEGRO 0039, 0059

AMERICAST 0052

ANTRONIX 0033, 0077,

0124

ARCHER 0033, 0077,

0082, 0124

AT&T 0068

BELL 0069

BELL SOUTH 0052

CABLETENNA 0033

CABLEVIEW 0033

CABLEVISION 0045

CENTURY 0082

CHARTER 0045

CITIZEN 0082

CLEARMAX 0042

COLOR VOICE 0040

COMCAST 0045, 0073,

0121

COMTRONICS 0036, 0083,

0122

CONTEC 0064

DIGITAL MUSIC

EXPRESS

0046

EASTERN 0061

EVERQUEST

0036

GARRARD

0082

GC ELECTRONICS

0077, 0124

0038

GEMINI

0074, 0031

GENERAL

INSTRUMENT (GI)

0072, 0081,

0079, 0081,

0046, 0065,

0078, 0123

GOLDSTAR

0041

HAMLIN

0081, 0060,

0066, 0067,

0123

HATACHI

0078

ILLICO

0045

JASCO

0082

JERROLD

0072, 0079,

0081, 0065,

0078, 0076,

0123

MAGNAVOX

0075

MEMOREX

0049

MOTOROLA

0071, 0081,

0070, 0072,

0079, 0076,

0078, 0065

MOVIE TIME

0086

NOVAPLEX

0056

NOWTV

0053

NSC

0086

OAK

0064

PANASONIC

0044

PARAGON

0049

PHILIPS

0082, 0031,

0075, 0084,

0083, 0085

PHILIPSMAGNAVOX

0054, 0055

PIONEER

0041, 0043,

0045, 0034

PULSAR

0049

QUASAR

0049

RADIO SHACK 0035, 0054,

0055, 0059

RCA 0082, 0047

REALISTIC 0077, 0124

REGAL 0067

REGENCY 0061

REMBRANDT 0078

ROGERS 0045

RUNCO 0049

SAMSUNG 0041, 0036

SCIENTIFIC ATLANTA 0045, 0063,

0045

SIGNAL 0036

SIGNATURE 0078

SL MARX 0036

STANDARD 0032

STAR SIGHT 0047

STAR TRAK 0058

STARCOM 0081, 0123

STARGATE 0036

TANDY 0080

TELEVIEW 0036

TEXSCAN 0032

TIME WARNER 0045

TOCOM 0065, 0062

TOSHIBA 0049

TV86 0086

Chapter 10: Appendix

UNIKA 0033, 0077,

0082, 0124

UNITED CABLE 0081, 0123

UNIVERSAL 0033, 0039,

0077, 0124

VERIZON 0045, 0121

VIDEO TECH 0037

VIDEOTRON 0045

VIDEOWAY 0048

VIEWSTAR 0083, 0075,

0086, 0080,

0122

VISIONTICS 0057

ZENITH 0050, 0059,

0049, 0051

ZENITH NETWORK 0052

Blu-ray Disc™

Brand Code

DENON 1019, 1029,

1030, 1081

HITACHI 1019, 1110,

1111, 1113

INTGERA 1128

JVC 1011, 1012,

1013, 1021,

1022

KENWOOD 1019

LG 1093

MARANTZ 1077, 1078

MITSUBISHI 1034, 1035

ONKYO 1128

PANASONIC 1020, 1019,

1017, 1018

PHILIPS 1133

PIONEER 1069

SAMSUNG 1134

SHARP 1026, 1027,

1028

SONY 1086, 1087,

1088, 1090

TOSHIBA 1000

YAMAHA 1065, 1122

DVD

Brand Code

AFREEY 1112

ALLEGRO 1093, 1167

AMES 1100, 1170

AMW 1059

APEX 1051, 1053,

1096, 1094,

1055, 1155

ASPIRE 1036

A-TREND 1112

BLAUPUNKT 1094

BLUESKY 1092, 1053

BLU-RAY 1025, 1137,

1016, 1093,

1069, 1086,

1134, 1145,

1160, 1166,

1167, 1181

BODYSONIC 1112

BOSE 1006

BROKSONIC 1005

CAVS 1043

CENTRIOS 1040, 1066

CHANGHONG 1155

CINEVISION 1093, 1167

CLASSIC 1100, 1155,

1170

COBY 1039, 1042,

1040, 1053,

1097, 1095,

1147

CONCEPT 1094

CONIA 1053

CONTEL 1151

CURTIS

INTERNATIONAL

1097, 1095

CYBERHOME 1063, 1112,

1064

CYTRON 1048, 1092

DAEWOO 1033, 1032

DENON 1025, 1019,

1029, 1030,

1081

DENZEL 1059

DESAY 1152

DIAMOND VISION 1047

DIGITREX 1053

DISNEY 1117

DRIVE 1153

DUAL 1103, 1048,

1059

DURABRAND 1066, 1093,

1048, 1103,

1167

DVD2000 1031

EMERSON 1093, 1117,

1167

ESA 1103

FISHER 1101

FUNAI 1117

GE 1079, 1094

GOLDSTAR 1093, 1167

GO-VIDEO 1100, 1060,

1032, 1009,

1052, 1004,

1007, 1170

GPX 1100

GRADIENTE 1092, 1103,

1040

GREENHILL 1094

HAAZ 1102, 1046

HARMAN KARDON 1114

HD-DVD 1137, 1016,

1069, 1086,

1129, 1061,

1093, 1145,

1160, 1166,

1167

HITACHI 1070, 1004,

1059, 1019,

1110, 1111,

1113, 1143

HITEKER 1053

HUMAX 1123

ILO 1015, 1094

INFINITY 1112

INITIAL 1094, 1094

INSIGNIA 1117, 1041,

1094, 1091,

1094, 1093,

1093, 1167

INTEGRA 1120

IRT 1095

JBL 1114

JVC 1061, 1014,

1130, 1010,

1011, 1012,

1013, 1021,

1022, 1139,

1140, 1141,

1142, 1158

JWIN 1053, 1047

KAWASAKI 1102, 1066

KENWOOD 1019, 1119

KISS 1059

KLH 1094, 1051,

1154

KONKA 1049, 1045

KOSS 1092, 1092

KXD 1095

LASONIC 1102

LG 1093, 1092,

1093, 1093,

1167, 1168

LINN 1076

LITEON 1109, 1118,

1015

MAGNAVOX 1061, 1130,

1117, 1131,

1158, 1177,

1178

MARANTZ 1061, 1093,

1130, 1077,

1078, 1157,

1158, 1167,

1176

MEDION 1015, 1048

MEMOREX 1005, 1048

MERIDIAN 1061

MICROSOFT 1079

MINTEK 1094

MITSUBISHI 1094, 1034,

1035

MUSTEK 1100, 1170

MYRON&DAVIS 1040

NAD 1093, 1167

NEC 1093, 1167

NESA 1094, 1040

NEXXTECH 1041, 1091,

1066, 1051,

1059, 1103,

1040, 1099,

1148, 1171

NORCENT 1039, 1109,

1041, 1097

ONKYO 1061, 1120,

1128, 1157

OPTIMUS 1070, 1162

Chapter 10: Appendix

ORION 1005

ORITRON 1092

PACIFIC 1048

PANASONIC 1016, 1020,

1019, 1024,

1023, 1143,

1144, 1145

PHILIPS 1092, 1133,

1117, 1131,

1061, 1130,

1175, 1177,

1178, 1179

PHILIPSMAGNAVOX 1061, 1130,

1131, 1178

PIONEER 1069, 1069,

1070, 1071,

1074, 1072,

1123, 1160,

1161, 1162,

1163, 1164,

1165

PIVA 1146

POLAROID 1058, 1121,

1047, 1051,

1095, 1169

POLK AUDIO 1061, 1130

PROLINE 1092

PROSCAN 1079

PROSONIC 1039

PROTRON 1041

RADIO SHACK 1066, 1116

RCA 1079, 1092,

1094, 1066,

1116, 1048

REGENT 1103

REOC 1102

RIO 1093, 1167

RJ TECHNOLOGY 1041, 1038,

1149

ROTEL 1014

SAMSUNG 1134, 1136,

1004, 1009,

1008, 1007,

1134, 1138,

1180, 1181

SAMPO 1112

SANSUI 1005

SANYO 1066, 1101

SEARS 1005

SEG 1059

SELECTRON 1037, 1040

SEMP 1092

SHARP 1137, 1044,

1026, 1027,

1028

SHERWOOD 1115

SHINCO 1094

SHINSONIC 1094

SONIC BLUE 1060

SONY 1083, 1089,

1084, 1082,

1085, 1086,

1087, 1088,

1090, 1166

SUNGALE 1041, 1040,

1147, 1150

SVA 1053, 1044

SYLVANIA 1117

SYMPHONIC 1117

TASCAM 1014

TEAC 1070, 1066,

1093, 1167

TECHNICS 1019

TECHWOOD 1130

TEVION 1092, 1048,

1103, 1102,

1046

THETA DIGITAL 1070

TIVO 1123

TOSHIBA 1129, 1005,

1104, 1061,

1108, 1001,

1002, 1003,

1105, 1106,

1107, 1156,

1172, 1173,

1174

TRUTECH 1063, 1032

UNITED 1066

VENTURER 1104, 1066,

1172

WHARFEDALE 1112

WESTINGHOUSE 1084

WHITE

WESTINGHOUSE

1117

X-BOX 1079

XENIUS 1092

YAMAHA 1130, 1122,

1131, 1158,

1159, 1178

YAMAKAWA 1056, 1059,

1065

ZENITH 1061, 1093,

1167

DVD Recorders

Brand Code

ASTAR 1050, 1095

APEX 1054

ASPIRE 1057, 1036

BROKSONIC 1067

BUSH 1068

COBY 1095

CYBERHOME 1064

EMERSON 1117

GO-VIDEO 1052, 1098,

1100, 1135

HITACHI 1018, 1113

HUGHES 1117

HUGHES NETWORK 1117, 1127

HUMAX 1126

ILO 1015

INSIGNIA 1093

JVC 1013, 1012,

1010, 1011

KXD 1095

LG 1093

LITEON 1015, 1098

MAGNAVOX 1131, 1117

MEDION 1015

MEMOREX 1048

MUSTEK 1100

PANASONIC 1018, 1017,

1019, 1020

PHILIPS 1127, 1125,

1075, 1117,

1131, 1132,

1098

PHILIPSMAGNAVOX 1131

PIONEER 1070, 1126,

1073, 1074

POLAROID 1095, 1058

RCA 1080, 1079

SAMSUNG 1135, 1004,

1136

Sansui 1068

SANYO 1101

SHARP 1137

SONY 1084, 1083,

1089

SYLVANIA 1117

SYMPHONIC 1117

TIVO 1062, 1125,

1126, 1126

TOSHIBA 1062, 1061,

1106, 1107,

1108

TRUTECH 1063

YAMAHA 1018, 1131

ZENITH 1093

VCR

Brand Code

ACCELE 2007

ADMIRAL 2062

ADVENTURA 2000

AIKO 2019

AIWA 2033, 2047,

2001, 2000

AKAI 2047, 2065,

2041, 2040,

2018, 2017,

2048

ALLEGRO 2010, 2090,

2033, 2074

AMERICAN HIGH 2046

ASHA 2007

AUDIO

DYNAMICS

2011, 2012,

2021

AUDIOVOX 2033

BEAUMARK 2007

BELL&HOWELL 2024

BROKSONIC 2003, 2051,

2052, 2005,

2002, 2049,

2081

CALIX 2033

CANDLE 2027, 2033,

2007, 2021,

2039

CANON 2060, 2004,

2046

CAPEHART 2090

CARVER 2056

CCE 2019, 2086

Chapter 10: Appendix

CINEVISION 2033, 2074

CITIZEN 2027, 2033,

2019, 2007,

2021, 2039

COLORTYME 2021

COLT 2086

CRAIG 2033, 2007,

2086, 2023

CURTIS MATHES 2060, 2056,

2047, 2019,

2007, 2021,

2020, 2046

CYBERNEX 2007

DAEWOO 2000, 2027,

2051, 2019,

2039

DBX 2011, 2012,

2021

DENON 2043

DIMENSIA 2060

DURABRAND 2033, 2074

DYNATECH 2047, 2000

ELECTROHOME 2033, 2018

ELECTROPHONIC 2033

EMERSON 2051, 2033,

2019, 2003,

2052, 2015,

2005, 2073,

2007, 2027,

2084, 2047,

2082, 2075,

2024, 2001,

2087, 2088,

2040, 2049,

2020, 2000,

2018, 2035,

2038, 2036,

2091, 2081,

2046, 2034,

2083

FISHER 2022, 2024,

2056, 2021,

2023, 2031,

2032, 2078

FUJI 2065, 2046

FUNAI 2047, 2088,

2087, 2000

GARRARD 2000

GE 2007, 2060,

2061, 2029,

2046

GOLDSTAR 2047, 2033,

2076, 2090,

2021

GO-VIDEO 2019, 2085,

2007

GRADIENTE 2000, 2033

HARLEY DAVIDSON 2000

HARMAN KARDON 2021, 2018

HARWOOD 2086

HEADQUARTER 2024

HI-Q 2023

HITACHI 2030, 2047,

2079, 2017,

2077, 2080

INFINITY 2056

INSIGNIA 2033, 2074

INSTANT REPLAY 2047, 2046

INTEO 2033

JC PENNEY 2060, 2033,

2024, 2007,

2030, 2011,

2012, 2046,

2017, 2077,

2044, 2021

JCL 2046

JENSEN 2030, 2017

JVC 2011, 2012,

2024, 2010,

2013, 2021,

2017

KENWOOD 2024, 2011,

2012, 2021,

2017

KLH 2086

KODAK 2033, 2046

LG 2047, 2090,

2076, 2074

LLOYD 2047, 2000

LOGIK 2086

LXI 2047, 2033

MAGNAVOX 2046, 2056,

2090, 2047,

2062, 2060,

2056, 2047,

2088, 2089

MAGNIN 2007

MARANTZ 2056, 2024,

2011, 2012,

2081, 2046,

2004, 2021

MARTA 2033

MATSUSHITA 2046

MEI 2046

MEMOREX 2056, 2033,

2024, 2022,

2005, 2090,

2007, 2062,

2047, 2048,

2023, 2000,

2046

MGA 2015, 2018

MGN TECHNOLOGY 2007

MIDLAND 2029

MINOLTA 2030, 2077

MITSUBISHI 2015, 2016,

2030, 2011,

2012, 2006,

2018

MONTGOMERY WARD 2062, 2092

MOTOROLA 2062, 2046

MTC 2047, 2007,

2000

MULTITECH 2047, 2007,

2000, 2029,

2086

NEC 2024, 2011,

2012, 2081,

2034, 2050,

2017, 2021,

2020

NEXXTECH 2042

NIKKO 2033

NOBLEX 2007

OLYMPUS 2046

OPTIMUS 2033, 2007,

2014, 2033,

2063, 2014,

2062

OPTONICA 2007, 2092

ORION 2003, 2005

PANASONIC 2014, 2014,

2046, 2060

PENTAX 2030, 2021,

2077

PHILCO 2056, 2060,

2047, 2046

PHILIPS 2056, 2057,

2088, 2056,

2046, 2089

PHILIPSMAGNAVOX 2056, 2062

PILOT 2033

PIONEER 2043, 2030,

2011, 2012,

2045, 2044

PORTLAND 2039

PROSCAN 2060, 2059

PROTEC 2086

PULSAR 2090

QUARTER 2024

QUARTZ 2024

QUASAR 2014, 2060,

2014, 2046

RADIO SHACK 2060, 2062,

2047, 2048,

2033, 2024,

2061, 2007,

2063, 2014,

2023, 2000,

2018, 2032,

2046, 2092

RADIX 2033

RANDEX 2033

RCA 2060, 2033,

2059, 2054,

2060, 2053,

2055, 2061,

2007, 2030,

2041, 2029,

2046, 2077,

2058

REALISTIC 2060, 2062,

2047, 2033,

2024, 2007,

2063, 2014,

2023, 2000,

2018, 2032,

2046, 2092,

2048

RICOH 2067

RIO 2033, 2074

Chapter 10: Appendix

KRELL

3043

LUXMAN

3031, 3059,

3063, 3066

LXI 3000

MAGNAVOX 3043, 3041

MARANTZ 3043, 3061,

3057, 3038

MCS 3033, 3000

MGA 3013

MISSION 3043

MITSUBISHI 3013, 3012

NAD 3067

NEC 3033

NEXXTECH 3050

NIKKO 3022, 3004,

3071

NSM 3043

ONKYO 3032, 3068,

3070, 3069

OPTIMUS 3016, 3017,

3037, 3046,

3064, 3056,

3062, 3058,

3036, 3036,

3035

PANASONIC 3039, 3009,

3010, 3039,

3011

PHILIPS 3043, 3041,

3042

PIONEER 3036, 3037,

3036, 3037,

3053, 3036,

3034, 3036

PROTON 3043

QUASAR 3039

RADIO SHACK 3017, 3062,

3055, 3036,

3050, 0868,

3044, 3036

RCA 3018, 3016,

3040, 3003,

3036, 3044,

3044, 3044,

3044, 3036

REALISTIC 3018, 3016,

3004, 3037,

3057, 0697,

3062

ROTEL 3043

SAE 3043

SAMSUNG 3077

SANSUI 3043, 3038,

3003, 3006

SANYO 3016, 3016,

3016, 3015,

3030

SCOTT 3018, 3004

SEARS 3046, 3057,

3000

SHARP 3046, 3057

SHERWOOD 3005, 3057,

3056, 3055

SHURE 3033

SONY 3075, 3076

SYLVANIA 3043

RUNCO 2090

SAMSUNG 2008, 2048,

2027, 2030,

2007, 2009

SAMTRON 2007

SANKY 2062, 2090

SANSUI 2005, 2011,

2012, 2002,

2003, 2017

SANYO 2025, 2022,

2024, 2007,

2023, 2078

SCOTT 2027, 2051,

2052, 2015,

2075, 2049,

2036

SEARS 2014, 2033,

2024, 2056,

2030, 2002,

2088, 2023,

2031, 2032,

2046, 2077,

2044, 2039

SHARP 2063, 2062,

2047, 2082,

2018, 2092

SHINTOM 2065, 2067,

2030, 2086,

2037

SHOGUN 2007

SIGNATURE 2047

SINGER 2046, 2086

SONY 2064, 2068,

2065, 2066,

2067, 2070,

2069, 2071,

2072

STS 2030, 2046,

2077

SUPERSCAN 2088

SYLVANIA 2000, 2047,

2056, 2015,

2060, 2088,

2046, 2047,

2087

SYMPHONIC 2047, 2047,

2088, 2000,

2087

TANDY 2047, 2024

TASHIKO 2033

TATUNG 2017

TEAC 2047, 2000,

2017

TECHNICS 2046

TEKNIKA 2047, 2033,

2073, 2000,

2046

TMK 2007, 2020,

2034

TOSHIBA 2027, 2028,

2026, 2056,

2015, 2007,

2030, 2032,

2075

TOTEVISION 2033, 2007

TRUTECH 2019

UNITECH 2007

VECTOR RESEARCH 2027, 2011,

2012, 2021

VICTOR 011, 2012

VIDEO CONCEPTS 2027, 2011,

2012, 2021,

2018

VIDEOSONIC 2007

WARDS 2060, 2062,

2047, 2027,

2033, 2007,

2030, 2023,

2000, 2018,

2046, 2092,

2077, 2075,

2086

WHITE WESTINGHOUSE 2047, 2019,

2087

XR-1000 2000, 2046,

2086

YAMAHA 2021, 2017,

2011, 2012

ZENITH 2090, 2010,

2019, 2082,

2067, 2007,

2033, 2065,

2005, 2025,

2011, 2085,

2090, 2074,

2056, 2062,

2047, 2076,

2079

Brand

Code

ADCOM

3018

AIWA

3002, 3047,

3001

AKAI

3025, 3024,

3025

AUDIO TECHNICA

3022

CALIFORNIA AUDIO

LABS

3039

CARVER

3043, 3016,

3017, 3042

CASIO

3000

CITIZEN

3052

CURTIS MATHES

3000

DENON

3045

EMERSON

3018, 3004

FISHER

3016, 3014,

3071, 3073,

3016

GENEXXA

3004, 3037,

3053

HARMAN KARDON

3013

HITACHI

3037

INSIGNIA

3078

JC PENNEY

3033, 3000

JVC

3008, 3007

KENWOOD

3046, 3028,

3027, 3026,

3029, 3028

Chapter 10: Appendix

TEAC 3071, 3057,

3062, 3048,

3065, 3054,

3060

TECHNICS 3039, 3009,

3039, 3011

THETA GIGITAL 3041

TOSHIBA 3067

VICTOR 3008

YAMAHA 3022, 3020,

3021, 3023,

3019

ZENITH 3071, 3049,

3072, 3074,

3051

Receiver & amp

Brand Code

AIWA 4001, 4003

APEX 4020

APPLE IPOD 4080

BOSE 4007, 4081,

4082

CARVER 4042

CENTRIOS 4021, 4020,

4019

CITIZEN 4069

DELPHI 4044

DENON 4049, 4051,

4050, 4090,

4091

FISHER 4068, 4067

GOLDSTAR 4018

HARMAN KARDON 4072, 4005

IPOD 4066

JVC 4011, 4010,

4009

KENWOOD 4077, 4032

KOSS 4061

MAGNAVOX 4069, 4068,

4042

MARANTZ 4074, 4042

NAD 4076

NELSON 4019

NEO

4044

NEXXTECH 4020, 4019,

4004

ONKYO 4078, 4079

OPTIMUS 4024, 4035,

4002, 4012,

4034, 4036,

4037

PANASONIC 4093, 4092,

4014, 4043,

4014, 4015,

4016, 4013,

4017

PHILIPS 4061, 4068,

4043, 4042,

4042, 4042,

4083

PIONEER 4036, 4040,

4034, 4041,

4033, 4038,

4037, 4036,

4039

RADIO SHACK 4036, 4037,

4038, 4075,

4073

RCA 4031, 4046,

4023, 4036,

4037, 4038,

4048, 4045,

4047, 4073,

4075

RIO 4063, 4025

SAMSUNG 4008

SANYO 4024

SHARP 4053, 4022,

4052

SHERWOOD 4006

SIRIUS 4022

SKYFI 4044

SONY 4088, 4054,

4055, 4087,

4057, 4058,

4056, 4060,

4089, 4059

TAO 4044

TECHNICS 4093, 4092,

4014, 4043,

4014, 4015

TOSHIBA 4000

WONDER 4021

XM RADIO 4044, 4044

YAMAHA 4030, 4028,

4026, 4027,

4029, 4070,

4071

ZENITH 4084, 4062,

4012, 4085,

4064, 4018,

4086, 4068,

4025, 4065

Chapter 10: Appendix

Limited United States Warranty

for LCD Televisions

Toshiba America Information Systems, Inc. (“TAIS”) makes

the following limited warranties to original consumers in

the United States.

THESE LIMITED WARRANTIES EXTEND TO THE

ORIGINAL CONSUMER PURCHASER OR ANY PERSON

RECEIVING THIS LCD TELEVISION AS A GIFT FROM THE

ORIGINAL CONSUMER PURCHASER AND TO NO OTHER

PURCHASER OR TRANSFEREE. LCD TELEVISIONS

PURCHASED IN THE U.S.A. OR PUERTO RICO AND

USED ANYWHERE OUTSIDE OF THE U.S.A. OR PUERTO

RICO, INCLUDING, WITHOUT LIMITATION, CANADA AND

MEXICO, ARE NOT COVERED BY THESE WARRANTIES.

LCD TELEVISIONS PURCHASED ANYWHERE OUTSIDE

OF THE U.S.A. OR PUERTO RICO, INCLUDING, WITHOUT

LIMITATION, CANADA AND MEXICO, AND USED IN THE

U.S.A., ARE NOT COVERED BY THESE WARRANTIES.

Limited One (1) Year Warranty on Parts and Labor

TAIS WARRANTS THIS LCD TELEVISION AND ITS PARTS

AGAINST DEFECTS IN MATERIALS OR WORKMANSHIP

FOR A PERIOD OF ONE (1) YEAR FROM THE DATE OF

ORIGINAL RETAIL PURCHASE. DURING THIS PERIOD,

TAIS WILL, AT TAIS’ SOLE DESCRETION, REPAIR OR

REPLACE A DEFECTIVE PART/PRODUCT WITH A

NEW OR REFURBISHED PART/PRODUCT WITHOUT

CHARGE TO YOU FOR PARTS OR LABOR. ANY PART

OR PRODUCT REPLACED UNDER THIS LIMITED

WARRANTY BECOMES THE PROPERTY OF TAIS.

IN SOME CASES, YOU MAY BE RESPONSIBLE FOR

DELIVERING THE PRODUCT TO A SERVICE PROVIDER.

Rental Units

The limited warranty period begins on the date of the

ﬁrst rental or thirty (30) days after the date of shipment

to the rental ﬁrm, whichever comes ﬁrst.

Your Responsibility

Read the owner’s manual thoroughly before installing

or operating this LCD Television. Complete and mail

the enclosed product registration card (if provided) or

http://support.toshiba.com. Registration of your LCD

Television will enable TAIS to contact you in the unlikely

event a safety notiﬁcation is required under the U.S.

Consumer Product Safety Act. Failure to complete and

return the product registration card does not diminish

your warranty rights.

THE ABOVE WARRANTIES ARE SUBJECT TO THE

FOLLOWING CONDITIONS:

(1) This Limited Warranty is extended only to the original

purchaser and only covers product purchased as

new.

(2) A purchase receipt or other proof of the original

purchase date is required for warranty service.

(3) All warranty servicing of this LCD Television must be

performed by an Authorized TAIS Service Provider.

(4) The warranties from TAIS are effective only if this

LCD Television is purchased and operated in the

U.S.A. or Puerto Rico.

(5) Removal and reinstallation of product that is

mounted in such a manner as to impede normal

service is not covered under these warranties. This

includes wall mounts, custom cabinets and other

installation methods that do not provide for direct

and immediate access to the product for service

purposes. Labor service charges for set installation,

setup, adjustment of customer controls, and

installation or repair of antenna, satellite or cable

systems are not covered by this limited warranty.

(6) Reception or other problems caused by inadequate

antenna systems, misaligned satellite dishes,

improperly installed cable drops or use with non-

standard signals or sources are your responsibility

and are not covered by this limited warranty.

(7) This limited warranty is void if the product is used

outside the range of the temperature (heat/cold)

and/or moisture operating conditions as outlined

in the product’s speciﬁcation listed in the Owner’s

manual, or if the product is exposed to excessive

smoke, dust, or other airborne contaminants or

environmental conditions.

(8) Warranties extend only to defects in materials

or workmanship as limited above, and do not

extend to any LCD Television or parts that have

been lost or discarded by you or to damage to the

LCD Television or parts caused by ﬁres, misuse,

abuse, accident, Acts of God (such as lightning or

ﬂuctuations in electric power), improper installation,

improper maintenance, or use in violation of

instructions furnished by TAIS; use or malfunction

through simultaneous use of this LCD Television and

connected equipment; or to units that have been

modiﬁed or had the serial number removed, altered,

defaced, or rendered illegible.

(9) Product purchased “AS-IS” or “With known faults,

defects or problems” are not covered by this limited

warranty.

(10)

Product previously owned or registered by a consumer

and resold is not covered by this limited warranty.

(11) Product that is refurbished and resold is not

covered under this limited warranty.

How to Obtain Warranty Service

After following all of the operating instructions in the

Owner’s manual, review the section entitled “Concierge”

located on our Customer Support Web site at

http://support.toshiba.com. If you ﬁnd that service is

needed, follow the instructions provided on the web

site or please contact TAIS’ Consumer Solution Center

toll free at 1-800-631-3811. You must present upon

request your original bill of sale or other proof of

purchase including the serial number for in warranty

service.

ALL WARRANTIES IMPLIED BY THE LAW OF ANY

STATE OF THE U.S.A., INCLUDING THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE, ARE EXPRESSLY

LIMITED TO THE DURATION OF THE LIMITED

WARRANTIES SET FORTH ABOVE. WITH THE

EXCEPTION OF ANY WARRANTIES IMPLIED BY

THE LAW OF ANY STATE OF THE U.S.A. AS HEREBY

LIMITED, THE FOREGOING LIMITED WARRANTY

IS EXCLUSIVE AND IN LIEU OF ALL OTHER

WARRANTIES, GUARANTEES, AGREEMENTS, AND

SIMILAR OBLIGATIONS OF TAIS WITH RESPECT

TO THE REPAIR OR REPLACEMENT OF ANY

Chapter 10: Appendix

PARTS. IN NO EVENT SHALL TAIS BE LIABLE FOR

CONSEQUENTIAL OR INCIDENTAL DAMAGES

(INCLUDING, BUT NOT LIMITED TO, LOST PROFITS,

BUSINESS INTERRUPTION, OR MODIFICATION

OR ERASURE OF RECORDED DATA CAUSED BY

USE, MISUSE OR INABILITY TO USE THIS LCD

TELEVISION).

No person, agent, distributor, dealer or company is

authorized to change, modify or extend the terms of

these warranties in any manner whatsoever. The time

within which an action must be commenced to enforce

any obligation of TAIS arising under this limited warranty

or under any statute, or law of the United States or

any state thereof, is hereby limited to ninety (90) days

from the date you discover or should have discovered,

the defect. This limitation does not apply to implied

warranties arising under the law of any state of the U.S.A.

THIS LIMITED WARRANTY GIVES YOU SPECIFIC

LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER

RIGHTS WHICH MAY VARY FROM STATE TO STATE

IN THE U.S.A. SOME STATES OF THE U.S.A. DO

NOT ALLOW LIMITATIONS ON THE DURATION OF

AN IMPLIED WARRANTY, WHEN AN ACTION MAY

BE BROUGHT, OR THE EXCLUSION OR LIMITATION

OF INCIDENTAL OR CONSEQUENTIAL DAMAGES.

THEREFORE, THE ABOVE PROVISIONS MAY NOT

APPLY TO YOU UNDER SUCH CIRCUMSTANCES.

Limited Canadian Warranty

for Toshiba Brand Flat Panel Televisions

Toshiba of Canada Limited (“TCL”) makes the following

limited warranties to original consumers in Canada.

THESE LIMITED WARRANTIES EXTEND TO THE

ORIGINAL CONSUMER PURCHASER OR ANY

PERSON RECEIVING THIS TOSHIBA BRAND

FLAT PANEL TELEVISION (the “TELEVISION(S)” or

“Television(s)”) AS A GIFT FROM THE ORIGINAL

CONSUMER PURCHASER AND TO NO OTHER

PURCHASER OR TRANSFEREE.

TELEVISIONS PURCHASED IN CANADA, AND USED

ANYWHERE OUTSIDE OF CANADA INCLUDING,

WITHOUT LIMITATION, THE UNITED STATES

AND MEXICO, ARE NOT COVERED BY THESE

WARRANTIES.

TELEVISIONS PURCHASED ANYWHERE OUTSIDE

OF CANADA, INCLUDING, WITHOUT LIMITATION,

THE UNITED STATES AND MEXICO, AND USED

IN CANADA, ARE NOT COVERED BY THESE

WARRANTIES.

Limited One (1) Year Warranty on Parts and Labour

TCL warrants the Television and its parts against

material defects in materials or workmanship that result

in the Television failing for a period of one (1) year after

the date of original retail purchase. DURING THIS

PERIOD, TCL WILL, AT TCL’S OPTION, REPAIR OR

REPLACE A DEFECTIVE PART WITH A NEW OR

RECERTIFIED PART WITHOUT CHARGE TO YOU

FOR PARTS OR LABOUR.

Rental Units

The warranty for Television rental units begins with the

date of ﬁrst rental or thirty (30) days from the date of

shipment to the rental ﬁrm, whichever comes ﬁrst.

Your Responsibility

Read the owner’s manual thoroughly before operating

this LCD Television. Complete and mail the enclosed

product registration card or register your LCD Television

online at http://support.toshiba.ca/warranty/. Registration

of your LCD Television will enable TCL to contact you in

the unlikely event of a product safety notice. Failure to

complete the product registration does not diminish your

warranty rights.

THE ABOVE WARRANTIES ARE SUBJECT TO THE

FOLLOWING CONDITIONS:

(1) You must provide your bill of sale or other proof of

purchase.

(2) All warranty servicing of this Television must

be performed by a Toshiba Authorized Service

Provider (ASP).

(3) The warranties from TCL are effective only if the

Television is (i) purchased as new and unopened

from TCL or from TCL’s authorized distributors,

dealers or resellers (“ADR’s”) and (ii) located/

operated in Canada.

(4) Removal and reinstallation of product that is

mounted in such a manner as to impede normal

service is not covered under these warranties. This

includes wall mounts, custom cabinets and other

installation methods that do not provide for direct

and immediate access to the product for service

purposes. Labour charges for set installation,

setup, adjustment of customer controls, and

installation or repair of antenna systems are not

covered by these warranties. Reception problems

caused by inadequate antenna systems are your

responsibility.

(5) Warranties extend only to material defects in

materials or workmanship as limited above, and do

not extend to:

a. Service, repairs or replacement made

necessary by accident, misuse, abuse,

moisture, liquids, dust, dirt, neglect, accident,

damage, 24/7 applications, improper

installation, improper operation, improper

cleaning, improper maintenance, normal

wear and tear, screen burn or image retention

caused by prolonged display of static images

and/or phosphor aging, or any other external

cause or event, act or omission outside

the control of TCL, including ﬁre, theft, acts

of God, alteration, power failures, power

surges or power shortages, lightning, other

electrical faults, or repairs, modiﬁcations or

replacements by persons other than those

authorized by TCL to service the Television;

b. Replacement of missing, discarded or lost

parts, the provision of retroﬁts, or preventive

maintenance;

c. Repair of damage that is cosmetic only or

does not affect the Television functionality,

such as wear and tear, scratches and dents;

d. Service on Toshiba-branded accessory items

(such accessory items may be covered by

their own warranty);

e. Service on third party products or service

made necessary by use of incompatible third

party products;

f. Service made necessary by the simultaneous

use of this Television and connected

equipment;

g. Modiﬁcations to the Television not approved in

writing by TCL, and service made necessary

by the use or installation of non-Toshiba

modiﬁcations to the Television;

h. Service of a Television on which the TOSHIBA

Chapter 10: Appendix

label or logo, rating label or serial number

have been defaced or removed;

i. Damage to the Television caused by failure

to follow the speciﬁcations, User manuals or

guides as to usage and/or storage.

Disclaimer and Limitation of Remedy

TO THE EXTENT NOT PRECLUDED BY LAW, ALL

OTHER EXPRESS AND IMPLIED WARRANTIES,

CONDITIONS AND REPRESENTATIONS

FOR THIS TELEVISION, INCLUDING THE

IMPLIED WARRANTIES, CONDITIONS AND

REPRESENTATIONS OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE,

ARE HEREBY DISCLAIMED AND EXCLUDED.

IF THE APPLICABLE LAW, STATUTORY OR

OTHERWISE, PRECLUDES THE EXCLUSION

OF ANY IMPLIED WARRANTIES, CONDITIONS

AND REPRESENTATIONS THEN SUCH

IMPLIED WARRANTIES, CONDITIONS AND

REPRESENTATIONS ARE OTHERWISE LIMITED

IN DURATION TO THE TERM OF THIS EXPRESS

WRITTEN LIMITED WARRANTY. TO THE EXTENT

NOT PRECLUDED BY LAW, STATUTORY OR

OTHERWISE, THIS WRITTEN WARRANTY

SUPERCEDES AND SPECIFICALLY DISCLAIMS

ANY OTHER WARRANTY, CONDITION OR

REPRESENTATION NOT STATED IN THIS WARRANTY,

WHETHER MADE BY TCL, TOSHIBA CORPORATION,

THEIR AFFILIATES, ADRs AND ASPs AND WHETHER

MADE ORALLY OR IN WRITING (INCLUDING ANY

STATEMENT IN ANY BROCHURE, PRESS RELEASE,

ANNOUNCEMENT, ADVERTISEMENT, POINT OF

SALE DISPLAY, ETC.).

YOU MUST READ AND FOLLOW ALL SET-UP AND

USAGE INSTRUCTIONS IN THE APPLICABLE USER

GUIDES AND/OR MANUALS. IF YOU FAIL TO DO SO,

THIS TELEVISION MAY NOT FUNCTION PROPERLY

AND MAY SUFFER DAMAGE. THIS WARRANTY WILL

NOT COVER ANY SERVICE THAT IS REQUIRED,

IN PART OR IN WHOLE, AS A RESULT OF ANY

FAILURE TO FOLLOW THE SET-UP AND USAGE

INSTRUCTIONS. THIS WARRANTY DOES NOT APPLY

AND SHALL BE VOID AND UNENFORCEABLE IF THE

TELEVISION IS OPENED, SERVICED, OR REPAIRED

BY PERSONS OTHER THAN THOSE AUTHORIZED BY

TCL TO SERVICE OR REPAIR THE TELEVISION.

IF THE TELEVISION FAILS TO WORK AS WARRANTED

ABOVE, YOUR SOLE AND EXCLUSIVE REMEDY

SHALL BE REPAIR OR REPLACEMENT OF THE

DEFECTIVE PART. IN NO EVENT WILL TCL, TOSHIBA

CORPORATION, THEIR AFFILIATES, ADRs OR ASPs

(THE “RELATED PARTIES”) BE LIABLE TO YOU OR

ANY THIRD PARTY FOR ANY DAMAGES, MONEY,

REIMBURSEMENT, COSTS OR EXPENSES.

THIS LIMITATION APPLIES TO DAMAGES, MONEY,

REIMBURSEMENT, COSTS OR EXPENSES OF ANY

KIND WHATSOEVER INCLUDING ANY DIRECT OR

INDIRECT DAMAGES, DAMAGE TO PROPERTY

OR PERSON, LOST PROFITS, LOST SAVINGS,

INCONVENIENCE OR OTHER SPECIAL, INCIDENTAL,

EXEMPLARY OR CONSEQUENTIAL DAMAGES,

WHETHER FOR BREACH OF WARRANTY, BREACH

OF CONTRACT, TORT (INCLUDING NEGLIGENCE),

UNDER A STATUTE OR UNDER ANY OTHER LAW OR

FORM OR ACTION, OR WHETHER ARISING OUT OF

THE USE OF OR INABILITY TO USE THE TELEVISION,

EVEN IF ANY OF THE RELATED PARTIES HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES

OR OF ANY CLAIM BY ANY OTHER PARTY.

No person, agent, distributor, dealer or company is

authorized to change, modify or extend the terms of

these warranties in any manner whatsoever.

Arbitration and Dispute Resolution

To the extent not precluded by law, any claim, dispute,

controversy or disagreement (whether for breach of

warranty, breach of contract, tort (including negligence),

under a statute or under any other law or form of action)

against any of the Related Parties arising out of, or

otherwise relating to: (i) this warranty; (ii) the Television;

(iii) any oral or written representations, statements,

brochures, press releases, advertising, announcement,

point of sale display, or promotional material relating to

the Television; (iv) the relationships that result from this

warranty, (the foregoing claims, disputes controversies

and disagreements are collectively referred to as the

“Dispute”), shall be referred to and resolved by ﬁnal

and binding arbitration (to the exclusion of the courts).

To the extent not precluded by law, you agree to waive

any right that you may have to commence or participate

in any representative or class proceeding against the

Related Parties relating to any Dispute. If and where

applicable and to the extent not precluded by law, you

further agree to opt out of any such representative or

class proceedings. Arbitration of any Dispute will be

conducted in the forum and in the manner as agreed

to between you and TCL. Failing such agreement, the

arbitration will be conducted by one arbitrator pursuant

to the laws and rules relating to arbitration generally in

force in the jurisdiction in which you reside at the time

that the Dispute arises. To the extent not precluded by

law, no claim, dispute, controversy or disagreement of

any other person may be joined or combined with any

Dispute by you, without the prior written consent of TCL.

Critical Applications

The Television you have purchased is not designed

for any “critical applications.” “Critical applications”

means life support systems, medical applications,

connections to implanted medical devices, commercial

transportation, nuclear facilities or systems or any other

applications where Television failure could lead to

injury to persons or loss of life or catastrophic property

damage.

IF THE CUSTOMER USES THE TELEVISION IN ANY

CRITICAL APPLICATION, THE CUSTOMER AND

NOT TCL, ITS AFFILIATES, ADRs OR ASPs – ASSUME

SOLE AND FULL RESPONSIBILITY FOR SUCH USE.

TCL RESERVES THE RIGHT TO REFUSE TO SERVICE

ANY TELEVISION USED IN A CRITICAL APPLICATION.

TCL, ITS AFFILIATES, ADRs AND ASPs HEREBY

DISCLAIM ANY AND ALL LIABILITY, DAMAGES AND

CONSEQUENCES ARISING OUT OF THE SERVICE

OR REFUSAL TO SERVICE SUCH TELEVISION

AND FURTHER DISCLAIM ANY AND ALL LIABILITY,

CONSEQUENCES AND DAMAGES THAT MAY ARISE

OR RESULT FROM THE USE OF THE TELEVISION IN

ANY CRITICAL APPLICATIONS.

General Provisions

If and to the extent that any provision of this limited

warranty should generally be found to be unenforceable,

the unenforceable provision shall be severed from

the warranty and deemed not to form part of the

warranty. The remaining provisions of this warranty

shall be and remain valid and enforceable. If and to

the extent that any provision of this limited warranty as

it relates to any of the Related Parties is found to be

invalid or unenforceable in respect of that party (the

“Excluded Party”), the Excluded Party shall be deemed

Chapter 10: Appendix

to be severed or excluded from the provision, and the

provision shall remain valid, enforceable and applicable

in respect of the other or remaining Related Parties.

To the extent permitted by law, this limited warranty shall

be governed and construed in accordance with the

laws of Ontario.

If there is any inconsistency between this limited

warranty, on the one hand, and any statement in the

packaging of the Television or in any other document

enclosed with, or used in the context of the promotion or

sale of, the Television, on the other hand, the provisions

of this limited warranty shall prevail.

How to Obtain Warranty Services

If, after following all of the operating instructions in

this manual, checked the “Troubleshooting” section,

and have visited www.toshiba.ca/support for additional

information, you ﬁnd that service is needed, please

contact TCL Customer Support toll free at 1 800 268-

3404.

Note

If you want to view the advanced functions available for

your TV, you can do so by visiting following web page.

For USA, www.support.toshiba.com

For Canada, www.toshiba.ca/support

You may obtain the complete Corresponding GPL

and LGPL Source code from Toshiba for a period of

three (3) years after our last shipment of this product

by contacting Toshiba Consumer Solutions at (800)

631-3811. There will be a charge of no more than the

cost of physically performing source distribution of

the GPL and LGPL code that we distributed to you in

this product.

WMDRM End User Notice

Content owners use Windows Media digital rights

management technology (WMDRM) to protect their

intellectual property, including copyrights. This

device uses WMDRM software to access WMDRM-

protected content. If the WMDRM software fails to

protect the content, content owners may ask Microsoft

to revoke the software’s ability to use WMDRM

to play or copy protected content. Revocation

does not affect unprotected content. When you

download licenses for protected content, you agree

that Microsoft may include a revocation list with the

licenses. Content owners may require you to upgrade

WMDRM to access their content. If you decline an

upgrade, you will not be able to access content that

requires the upgrade.

TOSHIBA AMERICA INFORMATION

SYSTEMS, INC.

Corporate Headquarters: 9740 IRVINE BLVD. IRVINE, CA 92618

VISUAL PRODUCTS SERVICE AND SUPPORT: 1420-B TOSHIBA DRIVE, LEBANON, TN

37087, U.S.A.

TOSHIBA OF CANADA LTD.

HEAD OFFICE: 191 McNABB STREET, MARKHAM, ONTARIO, L3R 8H2, CANADA

AutoView, ColorStream, GameTimer and TheaterWide are registered trademarks of Toshiba

America Information Systems, Inc.

Channel Browser, DynaLight, ColorMaster, NET TV, SurfLock and TheaterLock are trademarks

of Toshiba America Information Systems, Inc.

32SL415U 1019273614

Navigation menu

Versions of this User Manual:

Views

Navigation
