© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public. Page 1 of 2
Packet Tracer – Troubleshooting Single-Area OSPFv2
Topology
Addressing Table
Device
Interface
IP Address
Subnet Mask
Default Gateway
R1
G0/0
172.16.1.1
255.255.255.0
N/A
S0/0/0
172.16.3.1
255.255.255.252
N/A
S0/0/1
192.168.10.5
255.255.255.252
N/A
R2
G0/0
172.16.2.1
255.255.255.0
N/A
S0/0/0
172.16.3.2
255.255.255.252
N/A
S0/0/1
192.168.10.9
255.255.255.252
N/A
S0/1/0
209.165.200.225
255.255.255.224
N/A
R3
G0/0
192.168.1.1
255.255.255.0
N/A
S0/0/0
192.168.10.6
255.255.255.252
N/A
S0/0/1
192.168.10.10
255.255.255.252
N/A
PC1
NIC
172.16.1.2
255.255.255.0
172.16.1.1
PC2
NIC
172.16.2.2
255.255.255.0
172.16.2.1
PC3
NIC
192.168.1.2
255.255.255.0
192.168.1.1
Scenario
In this activity, you will troubleshoot OSPF routing issues using ping and show commands to identify errors in
the network configuration. Then, you will document the errors you discover and implement an appropriate
solution. Finally, you will verify end-to-end connectivity is restored.
Packet Tracer – Troubleshooting Single-Area OSPFv2
© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public. Page 2 of 2
Troubleshooting Process
1. Use testing commands to discover connectivity problems in the network and document the problem in
the Documentation Table.
2. Use verification commands to discover the source of the problem and devise an appropriate solution
to implement. Document the proposed solution in the Documentation Table.
3. Implement each solution one at a time and verify if the problem is resolved. Indicate the resolution
status in the Documentation Table.
4. If the problem is not resolved, it may be necessary to first remove the implemented solution before
returning to Step 2.
5. Once all identified problems are resolved, test for end-to-end connectivity.
Documentation Table
Device
Identified Problem
Resolved?
