Addonics Technologies Inc.
1918 Junction Avenue, San Jose, CA 95131
Phone: 408.573.8580 | Fax: 408.573.8588
HDD Duplicator PRO/ HDD Duplicator PRO-S
Simple, Fast and Easy-to-Use 1:1 Duplicator
INTRODUCTION
The Addonics HDD Duplicator PRO is one of the most powerful hard drive copying tools
that you can find in the market. Operating stand alone without any computer or special
software, any type of 2.5" or 3.5" hard drive or SSD can be duplicated onto any 2.5" or
3.5" hard drive or SSD that has either SATA or IDE interface. With the addition of an
optional Diamond Cipher drive enclosure, the exact content on any hard drive or SSD
can be quickly copied onto a 3.5" or 2.5" SATA drive with solid AES-256 bit hardware
encryption. For built-in data security, the HDD Duplicator PRO-S can duplicate and
encrypt data quickly and easily without the use of software or time consuming conversion
processes. Such flexibility makes HDD Duplicator PRO and PRO-S perfect tools for any
organization that has a wide mix of hard drives in various form factors, interfaces, need
for quick transfer of OS or data onto different type of hard drives and data security.
The HDD Duplicator PRO and PRO-S are simple to use and operate. Just open the doors
on the two drive bays, load your master hard drive into the drive bay on top and another
hard drive of equal or larger capacity into the bottom drive bay, turn the key lock to the
lock position and push the start button to start the copying process.
SPECIFICATIONS
● Writing mode: Sector to Sector
● Support up to 1.5Gbps transferring rate (actual transfer rate depends on the speed of the source and destination drive)
● Install drives into drive bay via removable drive enclosure
● Stylish clear acrylic exterior
● Light weight and sturdy aluminum construction
● Ventilated side panels for efficient air flow
● Ball bearing high CFM low noise cooling fans
● LCD display with functional control panel
● Integrated 220W 110/240 auto-sense power supply
● Compact size - 8.19 x 12.94 x 8 inch (W x D x H)
● Weight: 9.1 lb (4.13 kg)
● Operating environment: 0 - 50 degree C, 15% - 90% RH
● Storage environment: (- 20) - (65) degree C, 0% - 95% RH non-condensing
FEATURES
HDUSI325
(PRO)
HDUSI325AES
(PRO-S)
● Copy any 2.5" or 3.5" hard drive / SSD to any 2.5" or 3.5" hard drive / SSD.
● OS independent
● Copy up to 1.5Gbps depending on the performance of the hard drive
● Source and Destination drives are added or removed like tape cartridges via a removable drive enclosure.
● Add AES-256 bit encyrption capability to source or target with optional Diamond Cipher drive enclosure
● LCM control module provides a rich set of robust advanced configuration options
● Operate as a stand alone appliance. No computer or software needed
● Copy any 2.5" or 3.5" hard drive / SSD to any 2.5" or 3.5" hard drive or SSD with AES 256-bit encryption and vice versa*
● Copy any 2.5" or 3.5" SATA hard drive / SSD to 2.5" or 3.5" IDE hard drive / SSD or vice versa
● OS independent
● Copy up to 1.5Gbps depending on the performance of the hard drive
● Source and Destination drives are added or removed like tape cartridges via a removable drive enclosure.
● LCM control module provides a rich set of robust advanced configuration options
● Operate as a stand alone appliance. No computer or software needed
Addonics Technologies Inc.
1918 Junction Avenue, San Jose, CA 95131
Phone: 408.573.8580 | Fax: 408.573.8588
HDD Duplicator PRO/ HDD Duplicator PRO-S
Simple, Fast and Easy-to-Use 1:1 Duplicator
HDUSI325AESHDUSI325
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Yes
Yes
Yes
Yes
Yes
*
Yes
*
Yes
Yes
Yes
Yes
Yes
*
Yes
*
Requires Additional Diamond Cipher
Drive Enclosure (model: DCSACS256)
Requires Additional Diamond Cipher
Drive Enclosure (model: DCSACS256)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
*
Yes
*
Yes
Yes
Yes
Yes
Yes
*
Yes
*
N/A
N/A
SUPPORTED DRIVE COPYING OPTIONS
Source
3.5" SATA HDD
3.5" IDE HDD
3.5" SATA HDD
3.5" IDE HDD
2.5" SATA HDD / SSD
2.5" IDE HDD / SSD
3.5" SATA HDD with
AES 256-bit hardware encryption
3.5" SATA HDD with
AES 256-bit hardware encryption
3.5" SATA HDD with
AES 256-bit hardware encryption
3.5" SATA HDD with
AES 256-bit hardware encryption
2.5" SATA HDD/SDD with
AES 256-bit hardware encryption
2.5" SATA HDD/SDD with
AES 256-bit hardware encryption
3.5" SATA HDD
3.5" SATA HDD
3.5" SATA HDD
3.5" SATA HDD
3.5" IDE HDD
3.5" IDE HDD
3.5" IDE HDD
3.5" IDE HDD
2.5" SATA HDD/SSD
2.5" SATA HDD/SSD
2.5" SATA HDD/SSD
2.5" SATA HDD/SSD
2.5" IDE HDD/SSD
2.5" IDE HDD/SSD
2.5" IDE HDD/SSD
2.5" IDE HDD/SSD
2.5"/3.5" IDE or
SATA HDD/SSD
2.5" or 3.5" SATA
HDD/SSD with AES
256-bit encryption
Target
3.5" SATA HDD with
AES 256-bit hardware encryption
3.5" SATA HDD with
AES 256-bit hardware encryption
2.5" SATA HDD/SDD with
AES 256-bit hardware encryption
2.5" SATA HDD/SDD with
AES 256-bit hardware encryption
2.5" SATA HDD/SDD with
AES 256-bit hardware encryption
2.5" SATA HDD/SDD with
AES 256-bit hardware encryption
3.5" SATA HDD
3.5" IDE HDD
2.5" SATA HDD/SSD
2.5" IDE HDD/SSD
2.5" SATA HDD/SSD
2.5" IDE HDD/SSD
3.5" SATA HDD
3.5" IDE HDD
2.5" SATA HDD/SSD
2.5" IDE HDD/SSD
3.5" SATA HDD
3.5" IDE HDD
2.5" SATA HDD/SSD
2.5" IDE HDD/SSD
3.5" SATA HDD
3.5" IDE HDD
2.5" SATA HDD/SSD
2.5" IDE HDD/SSD
3.5" SATA HDD
3.5" IDE HDD
2.5" SATA HDD/SSD
2.5" IDE HDD/SSD
2.5" or 3.5" SATA
HDD/SSD with AES
256-bit encryption
2.5"/3.5" IDE or
SATA HDD/SSD
*Requires additional Diamond IDE drive enclosure (model: DICSB) for 3.5" IDE hard drive. For additinal support of 2.5" IDE hard drive, please also add the 2.5" - 3.5" connector converter (model: AA25IDE35)
