© 2012–2013 Dell Inc.

Dell™, the DELL logo, and Inspiron™ are trademarks of Dell Inc. Microsoft® and Windows® are either trademarks

or registered trademarks of Microsoft Corporation in the United States and/or other countries. Intel® and

Pentium® are registered trademark and Core™ is a trademark of Intel Corporation in the U.S.

and/or other countries. Bluetooth® is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell

under license. Blu-ray Disc™ is a trademark owned by the Blu-ray Disc Association (BDA) and licensed for use

on discs and players.

2013 - 10 A01

Regulatory Model: W05C | Type: W05C001

Computer Model: Inspiron One 2330

Specifications

One 2330

Dimensions

Height 442.40 mm (17.40 inches)

Width 574.0 mm (22.60 inches)

Depth

Computer 72.40 mm (2.85 inches)

Stand 220.0 mm (8.66 inches)

Weight

Without stand 7.34 kg – 10.20 kg (16.18 lb – 22.44 lb)

With stand 9.34 kg – 12.20 kg (20.59 lb – 26.84 lb)

NOTE: The weight of your computer may vary

depending on the configuration ordered and

the manufacturing variability.

System information

Computer Model Inspiron One 2330

Processor • Intel Dual Core

• Intel Core i3 (2nd generation)

• Intel Core i5 (2nd and 3rd generation)

• Intel Core i7 (3rd generation)

System chipset Intel B75 Express chipset

Graphics bus PCIe x16 Gen3

Memory

Connectors two internally-accessible DDR3 SO-DIMM

sockets

Capacities 2 GB, 4 GB, and 8 GB

Memory type up to 1600 MHz, unbuffered non-ECC,

dual-channel DDR3 configuration

Memory configurations

supported

2 GB, 4 GB, 6 GB, and 8 GB

Power ratings

Input voltage 100–240 VAC

Input frequency 50 Hz–60 Hz

Output current 2.9 A

Communications

Network adapter 10/100/1000 Mbps Ethernet LAN on

Motherboard (LOM)

Wireless • half mini-card (Wi-Fi b/g/n supporting Wi-Fi

display)

• combo half mini-card (Bluetooth 4.0 and

Wi-Fi b/g/n supporting Wi-Fi display)

Ports and connectors

Network adapter one RJ45 port

USB four 9-pin USB 3.0-compliant ports

two 4-pin USB 2.0-compliant ports

Media-card reader one 8-in-1 slot

Audio one audio input/microphone port

one headphone port

one audio output port

one S/P DIF port

HDMI one 19-pin input port

VGA one 15-pin input port

one 15-hole output port

Composite one composite port

Audio

Controller Intel High Definition Audio with Waves

MaxxAudio3

Speaker single 8-ohms speakers in both the left and

right speaker assembly (5 W average per

channel)

Internal speaker amplifier up to 15 W per channel

Internal microphone support dual digital microphone in camera assembly

Volume controls Volume up/down buttons and program menus

Video

Video controller

Integrated Intel HD Graphics 2000/2500/4000

Discrete AMD Radeon HD 7650A

Video memory

Integrated shared memory

Discrete 1 GB GDDR3

External display support VGA, composite, and Wi-Fi Display

Hard-Drive Storage

Interface SATA

Number of drives one

Dimension 3.5 inch

Camera

Image resolution 1.3 megapixel

Video resolution 720p HD

Diagonal viewing angle 60 degrees

Display

Type 23-inch full-HD WLED

Maximum resolution 1920 x 1080

Refresh rate 60 Hz

Operating angle 0 degree (closed) to 140 degrees

Pixel pitch 0.2652 mm

Controls on-screen controls

Optical drive

Interface SATA

Type Tray-load

Drives supported • DVD±RW

• Blu-ray reader and DVD±RW combo

• Blu-ray writer

Plays or records only standard-size (12 cm) CDs, DVDs, and

Blu-ray discs (optional)

Stand

Tilt –5 degrees to 30 degrees

Media Card Reader

Cards supported • Secure Digital (SD)

• SDXC

• Hi Speed-SD

• Hi Capacity-SD

• Multi Media Card (MMC)

• xD-Picture Card

• Memory Stick (MS)

• Memory Stick PRO

Computer environment

Temperature range

Operating 0 °C to 35 °C (32 °F to 95 °F)

Storage –40 °C to 65 °C (–40 °F to 149 °F)

Relative humidity (maximum)

Operating 10 % to 90 % (non-condensing)

Storage 10 % to 95 % (non-condensing)

Maximum vibration (using a random vibration spectrum that simulates user

environment)

Operating 0.66 GRMS

Storage 1.3 GRMS

Maximum shock (Measured with hard drive in operating status and a 2-ms

half-sine pulse for operating. Also measured with hard drive in head-parked

position and a 2-ms half-sine pulse for storage)

Operating 110 G

Storage 160 G

Altitude (maximum)

Operating –15.2 m to 3048 m (–50 ft to 10,000 ft)

Storage –15.2 m to 10,668 m (–50 ft to 35,000 ft)

Airborne contaminant level G2 or lower as defined by ISA-S71.04-1985
