B&C Speakers 15PS76
User Manual: 15PS76
Open the PDF directly: View PDF
.
Page Count: 2
1100 W continuous program power capacity
76 mm (3 in) copper voice coil
40 - 2000 Hz response
99 dB sensitivity
Double silicone spider with optimized
compliance
15PS76
LF Drivers - 15.0 Inches
8Ω
B&C Speakers s.p.a.
Via Poggiomoro, 1 - Loc. Vallina, 50012 Bagno a Ripoli (FI) - ITALY - Tel. +39 055 65721 - Fax +39 055 6572312 - mail@bcspeakers.com
15PS76
LF Drivers- 15.0 Inc hes
380 mm (15.0 in)
8 Ω
6.3 Ω
550 W
1100 W
99.0 dB
40 - 2000 Hz
76 mm (3.0 in)
Copper
Glass Fibre
19.0 mm (0.75 in)
11.0 mm (0.4 in)
1.15 T
SPECIFICATIONS
Nominal Diameter
Nominal Impedance
Minimum Impedance
Nominal Power Handling1
Continuous Power Handling2
Sensitivity3
Frequency Range
Voice Coil Diameter
Winding Material
Former Material
Winding Depth
Magnetic Gap Depth
Flux Density
Triple Roll
Exponential
Ferrite
Double Silicone
T-Pole
None
110.0 dm3 (3.88 ft3)
45 Hz
DESIGN
Surround Shape
Cone Shape
Magnet Material
Spider
Pole Design
Woofer Cone Treatment
Recommended Enclosure
Recommended Tuning
38 Hz
5.0 Ω
0.28
5.2
0.26
164.0 dm3 (5.7 ft3)
855.0 cm2 (132.5 in2)
3.3 %
7.5 mm
8.5 mm
106.0 g
22.1 Txm
1.3 mH
135 Hz
PARAMETERS4
Resonance Frequency
Re
Qes
Qms
Qts
Vas
Sd
η ₀
Xmax
Xvar
Mms
Bl
Le
EBP
393 mm (15.5 in)
374 mm (14.7 in)
354.0 mm (13.9 in)
171 mm (6.7 in)
16 mm (0.62 in)
0.0 dm3 (0.0 ft3)
8.7 kg (19.1 lb)
1
10.0 kg (22.05 lb)
425x425x224 mm (16.73x16.73x8.82 in)
MOUNTING AND SHIPPING INFO
Overall Diameter
Bolt Circle Diameter
Baffle Cutout Diameter
Depth
Flange and Gasket Thickness
Air Volume Occupied by Driver
Net Weight
Shipping Units
Shipping Weight
Shipping Box
RCK15PS768
SERVICE KIT
1. 2 hours test made with continuous pink noise signal within the range Fs-10Fs. Power calculated on rated nominal impedance. Loudspeaker in free air.
2. Power on Continuous Program is defined as 3 dB greater than the Nominal rating.
3. Applied RMS Voltage is set to 2.83 V for 8 ohms Nominal Impedance.
4. Thiele-Small parameters are measured after a high level 20 Hz sine wave preconditioning test.
