Technical Data
1756 ControlLogix and GuardLogix Controllers
ControlLogix Controller Catalog Numbers 1756-L61, 1756-L62, 1756-L63, 1756-L63XT, 1756-L64, 1756-L65
1756-L71, 1756-L72, 1756-L73, 1756-L73XT, 1756-L74, 1756-L75
1756-L71K, 1756-L72K, 1756-L73K, 1756-L74K, 1756-L75K
1756-L81E, 1756-L82E, 1756-L83E, 1756-L84E, 1756-L85E,
1756-L81EK, 1756-L82EK, 1756-L83EK, 1756-L84EK, 1756-L85EK
GuardLogix Controller Catalog Numbers 1756-L61S, 1756-L62S, 1756-L63S, 1756-LSP
1756-L71S, 1756-L71SK, 1756-L72S, 1756-L72SK, 1756-L73S, 1756-L73SK, 1756-L7SP,
1756-L7SPK, 1756-L73SXT, 1756-L7SPXT
1756-L81ES, 1756-L81ESK, 1756-L82ES,1756-L82ESK, 1756-L83ES, 1756-L83ESK,
1756-L84ES, 1756-L84ESK, 1756-L8SP, 1756-L8SPK
Armor ControlLogix Catalog Numbers 1756-L72EROM, 1756-L73EROM
Armor GuardLogix Catalog Numbers 1756-L72EROMS, 1756-L73EROMS
ControlLogix Redundancy Catalog Numbers 1756-RM2, 1756-RM2XT
Topic Page
1756 ControlLogix Controllers 2
1756 ControlLogix-XT Controllers 13
1756 GuardLogix Controllers 17
1756 GuardLogix-XT Controllers 29
1756 Armor ControlLogix and Armor GuardLogix Controllers 32
Controller Compatibility 36
ControlLogix Redundancy 39
ControlLogix Controller Accessories 42
2Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
1756 ControlLogix Controllers
The ControlLogix® controller provides a scalable controller solution that is capable of addressing many I/O points. You
can place the ControlLogix controller into any slot of a ControlLogix I/O chassis, and install multiple controllers in the
same chassis.
ControlLogix controllers can monitor and control I/O across the ControlLogix backplane, and over network links. The
ControlLogix 5580 controllers have an embedded Ethernet port for a direct connection to Ethernet-enabled devices and
networks, and also support communication interface modules in the local chassis. To provide communication for
ControlLogix 5570 or ControlLogix 5560 controllers, install the appropriate communication interface module into the
local chassis.
ControlLogix 5580 and ControlLogix 5570 controllers are available with a conformal coating. A conformal coating
provides a layer of protection against contaminants and humidity to help protect the assembly and extend product life in
harsh, corrosive environments. Products with a conformal coating have a ‘K’ suffix at the end of the catalog number.
1756 ControlLogix Controller Page
ControlLogix 5580 Controllers Features and Specifications 3
ControlLogix 5570 Controllers Features and Specifications 7
ControlLogix 5560 Controllers Features and Specifications 10
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 3
1756 ControlLogix and GuardLogix Controllers
ControlLogix 5580 Controllers Features and Specifications
Feature 1756-L81E,
1756-L81EK
1756-L82E,
1756-L82EK
1756-L83E,
1756-L83EK
1756-L84E,
1756-L84EK
1756-L85E,
1756-L85EK
Controller tasks
32 tasks
1000 programs/task
Local I/O event triggers: No limit
Built-in communication ports 1 port USB(3)
Embedded Ethernet port
(3) The USB port is intended for temporary local programming purposes only and not intended for permanent connection. Do not use the USB port in hazardous locations.
USB port communication
USB 2.0
Full speed (12 Mbps)
Programming, configuration, firmware update, and on-line edits only
Ethernet performance 10/100/1000 Mbps
Packet Rate Capacity (packets/second)(1)
(1) I/O numbers are maximums; they assume no HMI/MSG. HMI/MSG numbers are maximums, they assume no I/O. Packet rates vary depending on packet size. For more details, see Troubleshoot EtherNet/IP Application Technique,
publication ENET-AT003, and the EDS file for a specific catalog number.
I/O: 128,000
HMI/MSG: 1000
Communication options
•EtherNet/IP™
•ControlNet™
•DeviceNet™
•Data Highway Plus™
•Remote I/O
•SynchLink™
•Third-party process and device networks
EtherNet/IP nodes supported, max(2)
(2) A node is an EtherNet/IP device that you add directly to the I/O configuration, and counts toward the node limits of the controller. For more information on EtherNet/IP nodes, see the ControlLogix 5580 Controllers User Manual,
publication1756-UM543.
60 nodes(5)
100 nodes(6) 80 nodes(5)
175 nodes(6) 100 nodes(4)
250 nodes(6)
(4) With Studio 5000 Logix Designer® Application Version 28 and Version 29.
150 nodes(5)
250 nodes(6)
(5) With Studio 5000 Logix Designer Application Version 29.
(6) With Studio 5000 Logix Designer Application Version 30 or greater.
300 nodes(7)
(7) With Studio 5000 Logix Designer Application Version 28 or greater.
Network connections, per network module located
in the local chassis
•ControlLogix 5580 Controllers front EtherNet/IP port. See ‘EtherNet/IP nodes supported, max’ in this table.
•256 EtherNet/IP; 128 TCP (1756-EN2x)
•128 EtherNet/IP; 64 TCP (1756-ENBT)
•100 ControlNet (1756-CN2/A)
•40 ControlNet (1756-CNB/D, 1756-CNB/E)
•128 ControlNet (1756-CN2/B)
Controller redundancy —
Integrated motion •Integrated Motion on the EtherNet/IP network
Programming languages
•Relay Ladder Logic (RLL)
•Structured Text
•Function Block Diagram
•Sequential Function Chart (SFC)
4Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Technical Specifications - ControlLogix 5580 Controllers
Attribute 1756-L81E,
1756-L81EK
1756-L82E,
1756-L82EK
1756-L83E,
1756-L83EK
1756-L84E,
1756-L84EK
1756-L85E,
1756-L85EK
User memory 3 MB 5 MB 10 MB 20 MB 40 MB
Digital I/O, max 128,000
Analog I/O, max 4000
Total I/O, max 128,000
Optional nonvolatile memory storage 2 GB Secure Digital Card (1784-SD2), ships pre-installed in the controller
Energy storage module Embedded in controller, nonremovable
Current draw @ 1.2V DC 5.0 mA
Current draw @ 5.1V DC 1.20 A
Power dissipation 6.2 W
Thermal dissipation 21.2 BTU/hr
Isolation voltage 50V (continuous), Basic Insulation type, USB port to backplane, Ethernet port to backplane, and USB port to Ethernet port
Type tested at 1000V AC for 60 seconds
Weight, approx 0.394 kg (.868 lb)
Slot width 1
Module location Chassis-based, any slot
Chassis 1756-A4, 1756-A4K, 1756-A7, 1756-A7K, 1756-A10, 1756-A10K, 1756-A13, 1756-A13K,1756-A17, 1756-A17 K Series B, Series C
Power supply, standard 1756-PA50, 1756-PA72, 1756-PA72K, 1756-PA75, 1756-PA75K, 1756-PB50, 1756-PB72, 1756-PB72K, 1756-PB75, 1756-PB75K,
1756-PH75, 1756-PC75
Power supply, redundant 1756-PA75R, 1756-PA75RK, 1756-PB75R, 1756-PB75RK, 1756-PSCA2, 1756-PSCA2K
Wire category(1)
(1) Use this conductor category information to plan conductor routing. See Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
3 - on USB port
2 - on Ethernet ports
Wire size Ethernet connections:
Ethernet cabling and installation according to IEC 61918 and IEC 61784-5-2
North American temperature code T4
ATEX temperature code T4
IECEx temperature code T4
Enclosure type rating None (open-style)
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 5
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - ControlLogix 5580 Controllers
Attribute 1756-L81E, 1756-L82E, 1756-L83E, 1756-L84E, 1756-L85E, 1756-L81EK, 1756-L82EK,
1756-L83EK, 1756-L84EK, 1756-L85EK
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
Chassis series C: 0 °C < Ta < +60 °C (+32 °F < Ta < +140 °F)
Chassis series B: 0 °C < Ta < +50 °C (+32 °F < Ta < +122 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
Chassis series B and C: -40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max Chassis series C: 60 °C (140 °F)
Chassis series B: 50 °C (122 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
EFT/B Immunity
IEC 61000-4-4 ±2 kV at 5 kHz on Ethernet ports
Surge Transient Immunity
IEC 61000-4-5 ±2 kV line-earth (CM) on Ethernet ports
Conducted RF Immunity
IEC 61000-4-6 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
6Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Certifications - ControlLogix 5580 Controllers
Certification(1)
(1) See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-L81E, 1756-L81EK, 1756-L82E, 1756-L82EK, 1756-L83E, 1756-L83EK, 1756-L84E, 1756-L84EK, 1756-L85E, 1756-L85EK
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
CSA CSA Certified Process Control Equipment. See CSA File LR54689C.
CSA Certified Process Control Equipment for Class I, Division 2 Group A,B,C,D Hazardous Locations. See CSA File LR69960C.
FM FM Approved Equipment for use in Class I Division 2 Group A,B,C,D Hazardous Locations
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-15; Potentially Explosive Atmospheres, Protection ”n”
•EN 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•DEMKO13ATEX1325026X
IECEx
IECEx System, compliant with:
•IEC 60079-15; Potentially Explosive Atmospheres, Protection “n”
•IEC 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•IECEx UL 14.0008X
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
EtherNet/IP ODVA conformance tested to EtherNet/IP specifications
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 7
1756 ControlLogix and GuardLogix Controllers
ControlLogix 5570 Controllers Features and Specifications
Feature 1756-L71, 1756-L71K, 1756-L72, 1756-L72K, 1756-L73, 1756-L73K, 1756-L74, 1756-L74K, 1756-L75, 1756-L75K
Controller tasks •32 tasks
•100 programs/task
•Event tasks: all event triggers
Built-in communication ports 1 port USB(2)
(2) The USB port is intended for temporary local programming purposes only and not intended for permanent connection. Do not use the USB port in hazardous locations.
Communication options
•EtherNet/IP
•ControlNet
•DeviceNet
•Data Highway Plus
•Remote I/O
•SynchLink
•Third-party process and device networks
USB port communication Programming, configuration, firmware update, and on-line edits only
Controller connections supported, max(1)
(1) ControlLogix 5570 controllers use connections to establish communication links between devices. For more information on how to use and calculate connections, see the ControlLogix System User Manual, publication
1756-UM001.
500
Network connections, per network module
•100 ControlNet (1756-CN2/A)
•40 ControlNet (1756-CNB/D, 1756-CNB/E)
•128 ControlNet (1756-CN2/B)
•256 EtherNet/IP; 128 TCP (1756-EN2x)
•128 EtherNet/IP; 64 TCP (1756-ENBT)
Controller redundancy Full support
Integrated motion •SERCOS interface
•Analog options (encoder input, LDT input, SSI input)
•Integrated Motion on the EtherNet/IP network
Programming languages
•Relay Ladder
•Structured Text
•Function Block Diagram
•Sequential Function Chart (SFC)
8Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Technical Specifications - ControlLogix 5570 Controllers
Attribute 1756-L71, 1756-L71K 1756-L72, 1756-L72K 1756-L73, 1756-L73K 1756-L74, 1756-L74K 1756-L75, 1756-L75K
User memory 2 MB 4 MB 8 MB 16 MB 32 MB
I/O memory 0.98 MB
Optional nonvolatile memory storage 1 GB (1784-SD1 ships with every controller)
2 GB (1784-SD2)
Digital I/O, max 128,000
Analog I/O, max 4000
Total I/O, max 128,000
Energy storage module
•1756-ESMCAP, 1756-ESMCAPK capacitor energy storage module (removable, ships installed with every controller)
•1756-ESMNSE, 1756-ESMNSEK capacitor energy storage module (removable, no residual WallClockTime power backup)
•1756-ESMNRM, 1756-ESMNRMK capacitor energy storage module (nonremovable, helps prevent USB connection and SD card use to
help secure the controller)
Current draw @ 1.2V DC 5 mA
Current draw @ 5.1V DC 800 mA
Power dissipation 2.5 W
Thermal dissipation 8.5 BTU/hr
Isolation voltage 30V (continuous), basic insulation type, USB port-to-system
Type tested at 500V AC for 60 s
USB port(1)
(1) The USB port is intended for temporary local programming purposes only and not intended for permanent connection. Do not use the USB port in hazardous locations.
USB 2.0, full speed (12 Mbps)
Weight, approx 0.25 kg (0.55 lb)
Slot width 1
Module location Chassis-based, any slot
Chassis 1756-A4, 1756-A4K, 1756-A7, 1756-A7K, 1756-A10, 1756-A10K, 1756-A13, 1756-A13K,1756-A17, 1756-A17 K
Power supply, standard 1756-PA50, 1756-PA72, 1756-PA72K, 1756-PA75, 1756-PA75K, 1756-PB50, 1756-PB72, 1756-PB72K, 1756-PB75, 1756-PB75K,
1756-PH75
Power supply, redundant 1756-PA75R, 1756-PA75RK, 1756-PB75R, 1756-PB75RK,1756-PSCA2, 1756-PSCA2K
Wire category(2)
(2) Use this conductor category information to plan conductor routing. See Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
3 - on USB port
North American temperature code T4A
ATEX temperature code T4
IECEx temperature code T4
Enclosure type rating None (open-style)
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 9
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - ControlLogix 5570 Controllers
Attribute 1756-L71, 1756-L71K, 1756-L72, 1756-L72K, 1756-L73, 1756-L73K, 1756-L74K, 1756-L74,
1756-L75, 1756-L75K
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0 °C < Ta < +60 °C (+32 °F < Ta < +140 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g (45 g with SD card installed)
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Conducted RF Immunity
IEC 61000-4-6 Not applicable: USB is a temporary programming port.
Certifications - ControlLogix 5570 Controllers
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-L71, 1756-L71K, 1756-L72, 1756-L72K, 1756-L73, 1756-L73K, 1756-L74, 1756-L74K, 1756-L75, 1756-L75K
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
CE
European Union 2004/108/EC EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
EN 60079-0; General Requirements
EN 60079-15; Potentially Explosive Atmospheres, Protection “n”
II 3 G Ex nA IIC T4 Gc
DEMKO13ATEX1325026X
IECEx
IECEx System, compliant with:
IEC 60079-0; General Requirements
IEC 60079-15; Potentially Explosive Atmospheres, Protection “n”
II 3 G Ex nA IIC T4 Gc
IECEx UL 14.0008X
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
10 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
ControlLogix 5560 Controllers Features and Specifications
Feature 1756-L61, 1756-L62, 1756-L63, 1756-L63XT, 1756-L64, 1756-L65
Controller tasks •32 tasks
•100 programs/task
•Event tasks: all event triggers
Built-in communication ports 1 port RS-232 serial
Communication options
•EtherNet/IP
•ControlNet
•DeviceNet
•Data Highway Plus
•Remote I/O
•SynchLink
•Third-party process and device networks
Serial port communication
•ASCII
•DF1 full/half-duplex
•DF1 radio modem
•DH-485
•Modbus via logic
Controller connections supported, max(1)
(1) ControlLogix 5560 controllers use connections to establish communication links between devices. For more information on connections, see the ControlLogix System User Manual, publication 1756-UM001.
250
Network connections, per network module
•100 ControlNet (1756-CN2/A)
•40 ControlNet (1756-CNB/D, 1756-CNB/E)
•128 ControlNet (1756-CN2/B)
•256 EtherNet/IP; 128 TCP (1756-EN2x)
•128 EtherNet/IP; 64 TCP (1756-ENBT)
Controller redundancy Full support
Integrated motion •SERCOS interface
•Analog options (encoder input, LDT input, SSI input)
•Integrated Motion on the EtherNet/IP network
Programming languages
•Relay Ladder
•Structured Text
•Function Block Diagram
•Sequential Function Chart (SFC)
IMPORTANT Scan time for a project that is loaded in a 1756-L64 or 1756-L65 controller can be slower than for the same project loaded in one
of the other 1756-L6x controllers. For instruction execution times, see the Logix5000 Controllers Instruction Execution Time and
Memory Use Reference Manual, publication 1756-RM087.
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 11
1756 ControlLogix and GuardLogix Controllers
Technical Specifications - ControlLogix 5560 Controllers
Attribute 1756-L61 1756-L62 1756-L63 1756-L64 1756-L65
User memory 2 MB 4 MB 8 MB 16 MB 32 MB
I/O memory 478 KB
Optional nonvolatile memory storage 128 MB (1784-CF128)
Digital I/O, max 128,000
Analog I/O, max 4000
Total I/O, max 128,000
Replacement battery(1)
(1) For Australian Mining certification applications, only a series A controller and a 1756-BA1 battery can be used. For more information, contact your local distributor or sales office.
Series A: 1756-BA1, 1756-BATM, 1756-BATA
Series B: 1756-BA2 1756-BA2 (0.50 g Lithium)
Current draw @ 5.1V DC 1200 mA
Current draw @ 24V DC 14 mA
Power dissipation 3.5 W
Thermal dissipation 11.9 BTU/hr
Isolation voltage 30V (continuous), basic insulation type, RS-232 port to system
Type tested at 720V DC for 60 s
Serial cables 1756-CP3 or 1747-CP3, right angle connector to controller, straight to serial port, 3 m (9.84 ft)
Weight, approx Series A: 0.32 kg (0.71 lb)
Series B: 0.35 kg (0.78 lb)
Slot width 1
Module location Chassis-based, any slot
Chassis 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17
Power supply, standard 1756-PA50, 1756-PA72, 1756-PA75, 1756-PB50, 1756-PB72, 1756-PB75
Power supply, redundant 1756-PA75R, 1756-PB75R, 1756-PSCA2
Wire category(2)
(2) Use this conductor category information to plan conductor routing as described in the system level installation manual. See the Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
2 - on RS-232 port
North American temperature code T4A
IEC temperature code T4
Enclosure type rating None (open-style)
12 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - ControlLogix 5560 Controllers
Attribute 1756-L61, 1756-L62, 1756-L63, 1756-L64, 1756-L65
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0…60 °C (32 …140 °F)
Temperature, storage
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
Emissions
CISPR 11
IEC 61000-6-4
Class A
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
EFT/B immunity
IEC 61000-4-4 ±4 kV at 5 kHz on RS-232 port
Surge transient immunity
IEC 61000-4-5 ±2 kV line-earth (CM) on RS-232 port
Conducted RF immunity
IEC 61000-4-6 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Certifications - ControlLogix 5560 Controllers
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-L61, 1756-L62, 1756-L63, 1756-L64, 1756-L65
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
CSA CSA Certified Process Control Equipment. See CSA File LR54689C.
CSA Certified Process Control Equipment for Class I, Division 2 Group A,B,C,D Hazardous Locations. See CSA File LR69960C.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-15; Potentially Explosive Atmospheres, Protection “n”
•EN60079-0; General Requirements
•II 3 G Ex nA IIC T4 X
•LCIE01ATEX6020X
IMPORTANT: The 1756-L64 and 1756-L65 controllers do not have this certification.
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
FM FM Approved Equipment for use in Class I Division 2 Group A,B,C,D Hazardous Locations
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 13
1756 ControlLogix and GuardLogix Controllers
1756 ControlLogix-XT Controllers
The ControlLogix-XT™ controllers function in the same way as the traditional ControlLogix controllers.
The ControlLogix-XT products include control and communication system components that are conformally coated
for extended protection in harsh, corrosive environments:
•When used with FLEX I/O-XT™ products, the ControlLogix-XT system can withstand temperature ranges of -
20…+70 °C (-4…+158 °F).
•When used independently, the ControlLogix-XT system can withstand temperature ranges of -25…+70 °C (-
13…+158 °F).
•Customers who previously used the LXT chassis should now migrate to the K version of the chassis.
1756-L73XT ControlLogix Controller Specifications
Technical Specifications - 1756-L73XT ControlLogix Controller
Attribute 1756-L73XT
User memory 8 MB
I/O memory 0.98 MB
Optional nonvolatile memory 1 GB (1784-SD1 ships with every controller)
2 GB (1784-SD2)
Digital I/O, max 128,000
Analog I/O, max 4000
Total I/O, max 128,000
Replacement battery —
Energy storage modules
•1756-ESMCAPXT capacitor energy storage module (removable, ships installed with every controller)
•1756-ESMNSEXT capacitor energy storage module (removable, no residual WallClockTime power backup)
•1756-ESMNRMXT capacitor energy storage module (nonremovable, helps prevent USB connection and SD card use to help secure the
controller)
Current draw @ 5.1V DC 800 mA
Current draw @ 1.2V DC 5 mA
Power dissipation 2.5 W
Thermal dissipation 8.5 BTU/hr
Isolation voltage 30V (continuous), basic insulation type, USB port to backplane
Type tested at 500V AC for 60 s
USB port(1)
(1) The USB port is intended for temporary local programming purposes only and not intended for permanent connection. Do not use the USB port in hazardous locations.
USB 2.0, full speed (12 Mbps)
Weight, approx 0.25 kg (0.55 lb)
Slot width 1
Module location Chassis-based, any slot
Chassis 1756-A7XT, 1756-A10XT
For low temperature applications only, use 1756-A4K, 1756-A7K, 1756-A10K, 1756-A13K, 1756-A17K
Power supply, standard 1756-PAXT, 1756-PA30XT, 1756-PBXT, 1756-PB30XT
Power supply, redundant None
Wire category(2)
(2) Use this conductor category information to plan conductor routing. See the Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
3 - on USB ports
North American temperature code T4A
IECEx temperature code T4
ATEX temperature code T4
Enclosure type rating None (open-style)
14 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - 1756-L73XT ControlLogix Controller
Attribute 1756-L73XT
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-25 °C < Ta < +70 °C (-13 °F < Ta < +158 °F)
When using a 1756-A7LXT chassis, surrounding air temperature range is
-25 °C < Ta < +60 °C (-13 °F < Ta < +140 °F) even when using an ‘XT’ controller.
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 70 °C (158 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
(45 g with SD card installed)
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Conducted RF Immunity
IEC 61000-4-6 Not applicable: USB is a temporary programming port.
Certifications - 1756-L73XT ControlLogix Controller
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-L73XT
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61000-6-4; Industrial Emissions
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-15; Potentially Explosive Atmospheres, Protection ”n”
•EN 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•DEMKO13ATEX1325026X
IECEx
IECEx System, compliant with:
•IEC 60079-0; General Requirements
•IEC 60079-15; Potentially Explosive Atmospheres, Protection ”n”
•II 3 G Ex nA IIC T4 Gc
•IECEx UL 14.0008X
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 15
1756 ControlLogix and GuardLogix Controllers
1756-L63XT ControlLogix Controller Specifications
Technical Specifications - 1756-L63XT Controller
Attribute 1756-L63XT
User memory 8 MB
I/O memory 478 KB
Optional nonvolatile memory storage 128 MB (1784-CF128)
Digital I/O, max 128,000
Analog I/O, max 4000
Total I/O, max 128,000
Replacement battery 1756-BA2
Current draw @ 5.1V DC 1200 mA
Current draw @ 24V DC 14 mA
Power dissipation 3.5 W
Thermal dissipation 11.9 BTU/hr
Isolation voltage 30V (continuous), basic insulation type, RS-232 port to system
Type tested at 720V DC for 60 s
Serial cables 1756-CP3 or 1747-CP3, right angle connector to controller, straight to serial port, 3 m (9.84 ft)
Weight, approx 0.35 kg (0.78 lb)
Slot width 1
Module location Chassis-based, any slot
Chassis 1756-A7XT, 1756-A10XT
For low temperature applications only, use 1756-A4K, 1756-A7K, 1756-A10K, 1756-A13K, 1756-A17K
Power supply, standard 1756-PAXT, 1756-PA30XT, 1756-PBXT, 1756-PB30XT
Power supply, redundant None
Wire category(1)
(1) Use this conductor category information to plan conductor routing as described in the system level installation manual. See the Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
2 - on RS-232 port
North American temperature code T4A
IEC temperature code T4
Enclosure type rating None (open-style)
16 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - 1756-L63XT Controller
Attribute 1756-L63XT
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-25…+70 °C (-13…+158 °F)
When using a 1756-A7LXT chassis, surrounding air temperature range is -25…+60 °C (-13…+140 °F)
even when using an ‘XT’ controller
Temperature, storage
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 70 °C (158 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
Emissions
CISPR 11 Group 1, Class A
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
EFT/B immunity
IEC 61000-4-4 ±4 kV at 5 kHz on RS-232 port
Surge transient immunity
IEC 61000-4-5 ±2 kV line-earth (CM) on communication ports
Conducted RF immunity
IEC 61000-4-6 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Certifications - 1756-L63XT Controller
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-L63XT
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61000-6-4; Industrial Emissions
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-15; Potentially Explosive Atmospheres, Protection ’n’
•EN 60079-0; General Requirements
• II 3 G Ex nA IIC T4 X
•LCIE01ATEX6020X
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 17
1756 ControlLogix and GuardLogix Controllers
1756 GuardLogix Controllers
A GuardLogix® controller is a ControlLogix controller that also provides the ability to perform safety functions. You
must use a primary safety controller and a safety partner to achieve up to SIL CL 3/PLe/Cat. 4. A major benefit of this
system is that it is still one project, safety and standard together. The safety partner is a part of the system, is automatically
configured, and requires no user setup.
With the introduction of the GuardLogix 5580 controller, users can achieve up to SIL 2/PLd (Category 3) with a single
controller and the use of the safety task and safety I/O.
During development, safety and standard have the same rules; multiple programmers, online editing, and forcing are all
allowed. Once the safety system is validated and the safety signature applied, safety memory is protected, the safety logic
cannot be modified, and all safety functions operate with SIL integrity. If the safety partner is present, the safety integrity
will be SIL3. If no safety partner is present, the safety integrity will be SIL2.
On the standard side of the GuardLogix controller, all functions operate like a regular Logix controller. Thus, online
editing, forcing, and other activities are all allowed.
With this level of integration, safety memory can be read by standard logic and external devices, like HMIs or other
controllers, minimizing the need to condition safety memory for use elsewhere. The result is easy system-wide
integration and the ability to display safety status on displays or marquees. Use Guard I/O™ modules for field device
connectivity on Ethernet or DeviceNet networks, and for safety interlocking between GuardLogix controllers use
Ethernet or ControlNet networks. Multiple GuardLogix controllers can share safety data for zone to zone interlocking,
or one GuardLogix controller can use remote distributed safety I/O between different cells/areas.
1756 GuardLogix controllers are available with a conformal coating. The conformal coating provides a layer of
protection against contaminants and humidity to help protect the assembly and extend product life in harsh, corrosive
environments. Products with a conformal coating have a ‘K’ suffix at the end of the catalog number.
GuardLogix 5580 Controller with Safety Partner GuardLogix 5570 Controller with Safety Partner
18 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
In addition to the standard features of a ControlLogix controller, the GuardLogix controller has these safety-related
features.
Features - GuardLogix Controllers
Feature
1756-L61S, 1756-L62S, 1756-L63S, 1756-L71S, 1756-L72S,
1756-L73S, 1756-L73SXT, 1756-L71SK, 1756-L72SK,
1756-L73SK
1756-L81ES, 1756-L82ES, 1756-L83ES, 1756-L84ES,
1756-L81ESK, 1756-L82ESK, 1756-L83ESK, 1756-L84ESK
Safety communication options
Standard and safety
•EtherNet/IP
•ControlNet
•DeviceNet
Network connections, per
network module
•100 ControlNet (1756-CN2/A)
•40 ControlNet (1756-CNB/D, 1756-CNB/E)
•128 ControlNet (1756-CN2/B)
•256 EtherNet/IP; 128 TCP (1756-EN2x)
•128 EtherNet/IP; 64 TCP (1756-ENBT)
•GuardLogix 5580 Controllers front EtherNet/IP port. See ‘EtherNet/IP
nodes supported, max’ in this table.
•256 EtherNet/IP; 128 TCP (1756-EN2x)
•128 EtherNet/IP; 64 TCP (1756-ENBT)
•100 ControlNet (1756-CN2/A)
•40 ControlNet (1756-CNB/D, 1756-CNB/E)
•128 ControlNet (1756-CN2/B)
EtherNet/IP nodes supported,
max(1)
(1) A node is an EtherNet/IP device that you add directly to the I/O configuration, and counts toward the node limits of the controller. For more information on EtherNet/IP nodes, see the ControlLogix 5580 Controllers and
GuardLogix 5580 Controllers User Manual, publication1756-UM543.
—
1756-L81ES, 1756-L81ESK: 100 nodes
1756-L82ES, 1756-L82ESK: 175 nodes
1756-L83ES, 1756-L83ESK: 250 nodes
1756-L84ES, 1756-L84ESK: 250 nodes
Controller redundancy Not supported
Programming languages
•Relay Ladder Logic (RLL)
•Structured Text
•Function Block Diagram
•Sequential Function Chart (SFC)
•Safety Task supports only RLL and the additional safety application instructions
Safety Partners
Primary Controller Safety Partner
1756-L61S, 1756-L62S, 1756-L63S 1756-LSP
1756-L71S, 1756-L71SK, 1756-L72S,1756-L72SK, 1756-L73S,1756-L73SK 1756-L7SP, 1756-L7SPK
1756-L73SXT 1756-L7SPXT
1756-L81ES, 1756-L81ESK, 1756-L82ES, 1756-L82ESK, 1756-L83ES, 1756-L83ESK, 1756-L84ES, 1756-L84ESK 1756-L8SP, 1756-L8SPK
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 19
1756 ControlLogix and GuardLogix Controllers
GuardLogix 5580 Controllers Features and Specifications
Feature 1756-L81ES,
1756-L81ESK
1756-L82ES,
1756-L82ESK
1756-L83ES,
1756-L83ESK
1756-L84ES,
1756-L84ESK
1756-L8SP,
1756-L8SPK
Controller tasks
31 standard tasks, 1 safety task
1000 programs/task
Local I/O event triggers: No limit
—
Built-in communication ports 1 port USB(3)
Embedded Ethernet port
(3) The USB port is intended for temporary local programming purposes only and not intended for permanent connection. Do not use the USB port in hazardous locations.
—
USB port communication
USB 2.0
Full speed (12 Mbps)
Programming, configuration, firmware update, and on-line edits only
—
Ethernet performance 10/100/1000 Mbps —
Packet Rate Capacity (packets/second)(1)
(1) I/O numbers are maximums; they assume no HMI/MSG. HMI/MSG numbers are maximums, they assume no I/O. Packet rates vary depending on packet size. For more details, see Troubleshoot EtherNet/IP Application Technique,
publication ENET-AT003, and the EDS file for a specific catalog number.
I/O: 128,000
HMI/MSG: 1000 —
Communication options
•EtherNet/IP™
•ControlNet™
•DeviceNet™
•Data Highway Plus
•Remote I/O
•SynchLink
•Third-party process and device networks
—
EtherNet/IP nodes supported, max(2)
(2) A node is an EtherNet/IP device that you add directly to the I/O configuration, and counts toward the node limits of the controller. For more information on EtherNet/IP nodes, see the ControlLogix 5580 Controllers and GuardLogix
5580 Controllers User Manual, publication1756-UM543.
100 nodes 175 nodes 250 nodes 250 nodes —
Network connections, per network module located
in the local chassis
•GuardLogix 5580 Controllers front EtherNet/IP port. See ‘EtherNet/IP nodes supported,
max’ in this table.
•256 EtherNet/IP; 128 TCP (1756-EN2x)
•128 EtherNet/IP; 64 TCP (1756-ENBT)
•100 ControlNet (1756-CN2/A)
•40 ControlNet (1756-CNB/D, 1756-CNB/E)
•128 ControlNet (1756-CN2/B)
—
Controller redundancy — —
Integrated motion •Integrated Motion on the EtherNet/IP network —
Programming languages
•For the safety task, GuardLogix controllers support Ladder Diagram only.
•For standard tasks, GuardLogix controllers support:
–Ladder Diagram (LD)
–Structured Text (ST)
–Function Block Diagram (FBD)
–Sequential Function Chart (SFC)
—
20 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Technical Specifications - GuardLogix 5580 Controllers
Attribute 1756-L81ES,
1756-L81ESK
1756-L82ES,
1756-L82ESK
1756-L83ES,
1756-L83ESK
1756-L84ES,
1756-L84ESK
1756-L8SP,
1756-L8SPK
User memory 3 MB 5 MB 10 MB 20 MB —
Safety memory 1.5 MB 2.5 MB 5 MB 6 MB (2)
(2) Same as corresponding primary controller.
Digital I/O, max 128,000 —
Analog I/O, max 4000 —
Total I/O, max 128,000 —
Optional nonvolatile memory storage 2 GB Secure Digital Card (1784-SD2), ships pre-installed in the controller —
Energy storage module Embedded in controller, nonremovable Embedded in safety
partner, nonremovable
Current draw @ 1.2V DC 5.0 mA
Current draw @ 5.1V DC 1.20 A
Power dissipation 6.2 W
Thermal dissipation 21.2 BTU/hr
Isolation voltage 50V (continuous), Basic Insulation type, Ethernet to backplane, USB to backplane, and USB to Ethernet
Type tested at 1000V AC for 60 seconds
Weight, approx 0.394 kg (.868 lb)
Slot width 1
Module location Chassis-based, any slot (the safety partner must be installed in the slot to the immediate right of the primary controller)
Chassis 1756-A4, 1756-A4K, 1756-A7, 1756-A7K, 1756-A10, 1756-A10K, 1756-A13, 1756-A13K,1756-A17, 1756-A17 K Series B, Series C
Power supply, standard 1756-PA50, 1756-PA72, 1756-PA72K, 1756-PA75, 1756-PA75K, 1756-PB50, 1756-PB72, 1756-PB72K, 1756-PB75, 1756-PB75K,
1756-PH75, 1756-PC75
Power supply, redundant 1756-PA75R, 1756-PA75RK, 1756-PB75R, 1756-PB75RK, 1756-PSCA2, 1756-PSCA2K
Wire category(1)
(1) Use this conductor category information to plan conductor routing. See Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
3 - on USB port
2 - on Ethernet ports
Wire size Ethernet connections:
Ethernet cabling and installation according to IEC 61918 and IEC 61784-5-2
North American temperature code T4
ATEX temperature code T4
IECEx temperature code T4
Enclosure type rating None (open-style)
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 21
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications -GuardLogix 5580 Controllers
Attribute 1756-L81ES, 1756-L82ES, 1756-L83ES, 1756-L84ES
1756-L81ESK, 1756-L82ESK, 1756-L83ESK, 1756-L84ESK, 1756-L8SP, 1756-L8SPK
Temperature, operating (SIL 2/PLd)
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0 °C < Ta < +60 °C (+32 °F < Ta < +140 °F) for Series C Chassis
Note: If operating above +55 °C (+131 °F), modules greater than 6.2W shall not be installed in slots
adjacent to the controller.
Temperature, operating (SIL 3/PLe)
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0 °C < Ta < +60 °C (+32 °F < Ta < +140 °F) for Series C Chassis
0 °C < Ta < +50 °C (+32 °F < Ta < +122 °F) for Series B Chassis
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
Chassis series B and C: -40…+85 °C (-40…+185 °F)
Temperature, Surrounding Air, max (SIL 2/PLd)
60 °C (140 °F) for Series C Chassis
Note: If operating above +55 °C (+131 °F), modules greater than 6.2W shall not be installed in slots
adjacent to the controller.
Temperature, Surrounding Air, max (SIL 3/PLe) 60 °C (140 °F) for Series C Chassis
50 °C (122 °F) for Series B Chassis
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
3V/m with 1 kHz sine-wave 80% AM from 2700…6000 MHz
EFT/B Immunity
IEC 61000-4-4 ±2 kV at 5 kHz on Ethernet ports
Surge Transient Immunity
IEC 61000-4-5 ±2 kV line-earth (CM) on Ethernet ports
Conducted RF Immunity
IEC 61000-4-6 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
22 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Certifications - GuardLogix 5580 Controllers
Certification(1)
(1) See the Product Certification link at http://www.rockwellautomation.com/global/certification/overview.page for Declarations of Conformity, Certificates, and other certification details.
1756-L81ES, 1756-L82ES, 1756-L83ES, 1756-L84ES, 1756-L81ESK, 1756-L82ESK, 1756-L83ESK, 1756-L84ESK,
1756-L8SP, 1756-L8SPK
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
CSA CSA Certified Process Control Equipment. See CSA File 150115.
CSA Certified Process Control Equipment for Class I, Division 2 Group A,B,C,D Hazardous Locations. See CSA File 150115.
FM FM Approved Equipment for use in Class I Division 2 Group A,B,C,D Hazardous Locations
CE
European Union 2014/30/EU EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
European Union 2006/42/EC MD, compliant with:
•EN ISO 13849-1; Safety-related parts of control systems
•EN 62061; Functional safety of safety-related control systems
•Up to Cat. 4/PL e according to EN ISO 13849-1 and SIL CL 3 according to EN/IEC 62061 when used in combination with the 1756-L8SP
safety partner
•Up to Cat. 3/PL d according to EN ISO 13849-1, and SIL CL 2 according to EN/IEC 62061 when not used in combination with the 1756-L8SP
safety partner
•TÜV 01/205/5611
European Union 2011/65/EU RoHS, compliant with:
•EN 50581; Technical documentation
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 2014/34/EU ATEX Directive, compliant with:
•EN 60079-0; General Requirements
•EN 60079-15; Potentially Explosive Atmospheres, Protection ”n”
•II 3 G Ex nA IIC T4 Gc
•DEMKO13ATEX1325026X
IECEx
IECEx System, compliant with:
•IEC 60079-0; General Requirements
•IEC 60079-15; Potentially Explosive Atmospheres, Protection “n”
•II 3 G Ex nA IIC T4 Gc
•IECEx UL 14.0008X
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
TÜV certified for functional safety(2)
(2) When used with specified firmware revisions. See the Product Safety Certificate at http://www.rockwellautomation.com/global/certification/overview.page for a full list of safety-related certifications.
Capable of SIL 3, CAT. 4/PLe
EtherNet/IP ODVA conformance tested to CIP Safety EtherNet/IP specifications
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 23
1756 ControlLogix and GuardLogix Controllers
1756-L7S GuardLogix Controllers Specifications
Technical Specifications - 1756-L7S GuardLogix Controllers
Attribute 1756-L71S, 1756-L71SK 1756-L72S, 1756-L72SK 1756-L73S, 1756-L73SK 1756-L7SP, 1756-L7SPK
User memory 2 MB 4 MB 8 MB —
Safety memory 1 MB 2 MB 4 MB (2)
(2) Same as corresponding primary controller.
I/O memory 0.98 MB —
Optional nonvolatile memory storage 1 GB (1756-SD1 ships with every controller)
2 GB (1756-SD2) —
Digital I/O, max 128,000 —
Analog I/O, max 4000 —
Total I/O, max 128,000 —
Replacement battery —
Energy storage modules
•1756-ESMCAP capacitor energy storage module (removable, ships installed with
every controller)
•1756-ESMNSE capacitor energy storage module (removable, no residual
WallClockTime power backup)
•1756-ESMNRM capacitor energy storage module (nonremovable, helps prevent USB
connection and SD card use to help secure the controller)
•1756-SPESMNSE capacitor energy storage
module for the safety partner (removable,
no residual WallClockTime power backup)
•1756-SPESMNRM capacitor energy storage
module for the safety partner
(nonremovable, helps prevent USB
connection and SD card use to help secure
the controller)
Current draw @ 1.2V DC 5 mA
Current draw @ 5.1V DC 800 mA
Power dissipation 2.5 W
Thermal dissipation 8.5 BTU/hr
Isolation voltage 30V (continuous), basic insulation, USB port-to-system, type tested at 980V AC for 60 s
Weight, approx 0.25 kg (0.55 lb)
Slot width 2 (both modules needed; each is one slot)
Module location Chassis-based, any slot (the safety partner must be installed in the slot to the immediate right of the primary controller)
Chassis 1756-A4, 1756-A4K, 1756-A7, 1756-A7K, 1756-A10, 1756-A10K, 1756-A13, 1756-A13K,1756-A17, 1756-A17K
Power supply, standard 1756-PA50, 1756-PA72, 1756-PA72K, 1756-PA75, 1756-PA75K, 1756-PB50, 1756-PB72, 1756-PB72K, 1756-PB75, 1756-PB75K
Wire category(1)
(1) Use this Conductor Category information to plan conductor routing. See Industrial Wiring and Grounding Guidelines, publication 1770-4.1.
3 - on USB ports
North American temperature code T4A
ATEX temperature code T4
IECEx temperature code T4
Enclosure type rating None (open-style)
24 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - 1756-L7S GuardLogix Controllers
Attribute 1756-L71S, 1756-L72S, 1756-L73S, 1756-L7SP 1756-L71SK, 1756-L72SK, 1756-L73SK,
1756-L7SPK
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0 °C < Ta < +60 °C (+32 °F < Ta < +140 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Temperature, surrounding air, max 60 °C (140 °F)
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
(45 g with SD card installed)
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Conducted RF Immunity
IEC 61000-4-6 Not applicable: USB is a temporary programming port.
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 25
1756 ControlLogix and GuardLogix Controllers
Certifications - 1756-L7S GuardLogix Controllers
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-L71S, 1756-L72S, 1756-L73S, 1756-L7SP 1756-L71SK, 1756-L72SK, 1756-L73SK, 1756-L7SPK
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
European Union 2006/42/EC MD, compliant with:
•EN 60204-1; Electrical equipment of machines
•EN ISO 13849-1; Safety-related parts of control systems
•EN 62061; Functional safety of safety-related control systems
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-0; General Requirements
•EN 60079-15; Potentially Explosive Atmospheres, Protection ”n”
•Ex nA IIC T4 Gc
•DEMKO15 ATEX 1593X
IECEx
IECEx System, compliant with:
•EN 60079-0; General Requirements
•EN 60079-15; Potentially Explosive Atmospheres, Protection ”n”
•II 3 G Ex nA IIC T4 Gc
•IECEx UL 15.0125X
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
TÜV certified for functional safety(2)
(2) When used with specified firmware revisions. See the Product Safety Certificate at the Product Certification link ( http://www.ab.com) for a full list of safety-related certifications.
Capable of SIL CL 3 according to IEC 61508, capable of Category 4 according to EN954-1, and capable of PL(e) according to ISO 13849-1
when used as described in the GuardLogix 5570 and Compact GuardLogix 5370 Controller Systems Safety Reference Manual, publication
1756-RM099.
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
26 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
1756-L6S GuardLogix Controllers Specifications
Technical Specifications - 1756-L6S GuardLogix Controllers
Attribute 1756-L61S 1756-L62S 1756-L63S 1756-LSP
User memory 2 MB 4 MB 8 MB —
Safety memory 1 MB 1 MB 3.75 MB Same as corresponding primary
controller
I/O memory 478 KB —
Optional nonvolatile memory storage
128 MB (1784-CF128)(2)
1 GB (1784-SD1, ships with every controller)
2 GB (1784-SD2)
(2) RSLogix 5000® programming software, version 18 or later.
—
Digital I/O, max 128,000 —
—
—
Analog I/O, max 4000
Total I/O, max 128,000
Replacement battery 1756-BA2 (0.50 g lithium)
Energy storage modules —
Current draw @ 1.2V DC —
Current draw @ 5.1V DC 1200 mA
Current draw @ 24V DC 14 mA
Power dissipation 3.5 W
Thermal dissipation 11.9 BTU/hr
Isolation voltage 30V (continuous), Basic Insulation Type, RS-232 to system
Type tested at 720V DC for 60 s
Serial cables 1756-CP3 or 1747-CP3, right angle connector to controller, straight to serial port, 3 m (9.84 ft)
Weight, approx 0.32 kg
(0.70 lb)
Slot width 2 (both modules needed; each is one slot)
Module location Chassis-based, any slot (the safety partner must be installed in the slot to the immediate right of the primary controller)
Chassis 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17
Power supply standard 1756-PA50, 1756-PA72, 1756-PA75, 1756-PB50, 1756-PB72, 1756-PB75
Wire category(1)
(1) Use this conductor category information for to plan conductor routing as described in the system level installation manual. See the Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
2 - on RS-232 port
North American temperature code T4A
Enclosure type rating None (open-style)
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 27
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - 1756-L6S GuardLogix Controllers
Attribute 1756-L61S, 1756-L62S, 1756-L63S, 1756-LSP
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0 °C…+60 °C (+32…+140 °F) on 1756-L61S, 1756-L62S, 1756-L63S, 1756-LSP
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
Emissions
CISPR 11
IEC 61000-6-4
Class A
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
EFT/B immunity
IEC 61000-4-4 ±4 kV at 5 kHz on RS-232 port
Surge transient immunity
IEC 61000-4-5 ±2 kV line-earth (CM) on RS-232 port
Conducted RF immunity
IEC 61000-4-6 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
28 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Certifications - 1756-L6S GuardLogix Controllers
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-L61S, 1756-L62S, 1756-L63S, 1756-LSP
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
CSA CSA Certified Process Control Equipment. See CSA File LR54689C.
CSA Certified Process Control Equipment for Class I, Division 2 Group A,B,C,D Hazardous Locations. See CSA File LR69960C.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61000-6-4; Industrial Emissions
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
European Union 2006/42/EC MD, compliant with:
•EN 60204-1; Electrical equipment of machines
•EN ISO 13849-1; Safety-related parts of control systems
•EN 62061; Functional safety of safety-related control systems
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
FM FM Approved Equipment for use in Class I, Division 2 Group A, B, C, D Hazardous Locations
KC Korean Registration of Broadcasting and Communication Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
TÜV certified for functional safety(2)
(2) When used with specified firmware revisions.
Capable of Cat. 4/PL e according to EN ISO 13849-1 and SIL 3 according to EN 62061/IEC 61508 when used as described in the
GuardLogix Controller Systems Safety Reference Manual, publication 1756-RM093.
UL certified for functional safety(2) Capable of SIL CL 3, see UL File E256621.
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 29
1756 ControlLogix and GuardLogix Controllers
1756 GuardLogix-XT Controllers
The GuardLogix-XT™ controllers function the same way as the traditional GuardLogix controllers. The GuardLogix-XT
controllers are conformally coated for extended protection in harsh, corrosive environments. The GuardLogix-XT
system can withstand temperature ranges from -25…+70 °C (-13…+158 °F). You must use a 1756-L73SXT primary
controller with a 1756-L7SPXT safety partner.
Customers who previously used the LXT chassis should now migrate to the K version of the chassis.
Attribute 1756-L73SXT 1756-L7SPXT
User memory 8 MB —
Safety memory 4 MB Same as corresponding primary controller
I/O memory 0.98 MB
Digital I/O, max 128,000
Analog I/O, max 4,000
Total I/O, max 128,000
Energy storage modules
•1756-ESMCAPXT capacitor energy storage module extreme
temperature (removable, ships installed with every controller)
•1756-ESMNSEXT capacitor energy storage module extreme
temperature (removable, no residual WallClockTime power backup)
•1756-ESMNRMXT capacitor energy storage module extreme
temperature (nonremovable, helps prevent USB connection and SD
card use to help secure the controller)
•1756-SPESMNSEXT capacitor energy storage module for the
safety partner extreme temperature (removable, no residual
WallClockTime power backup)
•1756-SPESMNRMXT capacitor energy storage module for the
safety partner extreme temperature (nonremovable, helps
prevent USB connection and SD card use to help secure the
controller)
Current draw @ 1.2V DC 5 mA
Current draw @ 5.1V DC 800 mA
Power dissipation 2.5 W
Thermal dissipation 8.5 BTU/hr
Isolation voltage 30V (continuous), Basic Insulation, USB port to backplane
Type tested at 980V AC for 60 s
Weight, approx 0.25 kg (0.55 lb)
Slot width 2 (need 2 modules; each uses a slot)
Module location Chassis-based, any slot (the safety partner must be in a slot to the right of the primary)
Chassis 1756-A7XT, 1756-A10XT
For low temperature applications only, use 1756-A4K, 1756-A7K, 1756-A10K, 1756-A13K, 1756-A17K
Power supply 1756-PAXT, 1756-PA30XT, 1756-PBXT, 1756-PB30XT
Wire category(1)
(1) Use this conductor category information to plan conductor routing as described in the system level installation manual. See the Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
3 - on USB ports
North American temperature code T4A
ATEX temperature code T4
IECEx temperature code T4
Enclosure type rating None (open-style)
30 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - 1756 GuardLogix-XT Controllers
Attribute 1756-L73SXT, 1756-L7SPXT
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-25 °C< Ta < +70 °C (-13 °F < Ta < +158 °F)
When using a 1756-A7LXT chassis, surrounding air temperature range is -25…+60 °C (-13…+140 °F)
even when using an XT controller
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 70 °C (158 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g (45 g with SD card installed)
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Conducted RF Immunity
IEC 61000-4-6. Not applicable: USB is a temporary programming port.
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 31
1756 ControlLogix and GuardLogix Controllers
Certifications - 1756 GuardLogix-XT Controllers
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-L73SXT, 1756-L7SPXT
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
European Union 2006/42/EC MD, compliant with:
•EN 60204-1; Electrical equipment of machines
•EN ISO 13849-1; Safety-related parts of control systems
•EN 62061; Functional safety of safety-related control systems
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-0; General Requirements
•EN 60079-15; Potentially Explosive Atmospheres, Protection ”n”
•II 3 G Ex nA IIC T4 Gc
•DEMKO15 ATEX 1593X
IECEx
IECEx System, compliant with:
•EN 60079-0; General Requirements
•EN 60079-15; Potentially Explosive Atmospheres, Protection ”n”
•II 3 G Ex nA IIC T4 Gc
•IECEx UL 15.0125X
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
TÜV certified for functional safety(2)
(2) When used with specified firmware revision.
Capable of SIL CL 3 according to IEC 61508, capable of Category 4 according to EN954-1, and capable of PL(e) according to ISO 13849-1
when used as described in the GuardLogix Controller Systems Safety Reference Manual, publication 1756-RM093.
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
32 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
1756 Armor ControlLogix and Armor GuardLogix Controllers
The Armor™ ControlLogix® and Armor™ GuardLogix® controllers extend the ControlLogix platform to the
On-Machine™ space to put industrial control closer to the application, and sometimes onto the machine itself.
The Armor GuardLogix controllers are certified for use in safety applications up to Safety Integrity Level (SIL) 3 and
Performance Level PLe (Category 4), where the de-energized state is the safe state.
Dual independent EtherNet/IP ports and Device Level Ring (DLR) capabilities provide resiliency from loss of network
connections due to one connection failure.
The controllers support the same environmental ratings and global certifications as the ControlLogix and GuardLogix
controllers, but now provide Ingress Protection (IP67 and UL Type 4/4x) for dust and washdown protection.
With so many hardware functions in one device, these controllers minimize cabinet hardware and simplify wiring
layouts. The controllers do not require specialty tools or specialty personnel for component replacement. These features
can help improve Mean Time to Repair (MTTR), simplify troubleshooting, and make system status readily available
without having to open a cabinet or visit a control room.
Features - Armor ControlLogix and Armor GuardLogix Controllers
Feature 1756-L72EROM, 1756-L73EROM 1756-L72EROMS, 1756-L73EROMS
Communication options Standard on EtherNet/IP networks Standard and safety on EtherNet/IP networks
Network connections 256 EtherNet/IP; 128 TCP
Controller redundancy Not supported
Programming languages
•Relay Ladder Logic (RLL)
•Structured Text
•Function Block Diagram
•Sequential Function Chart (SFC)
•Relay Ladder Logic (RLL)
•Structured Text
•Function Block Diagram
•Sequential Function Chart (SFC)
•Safety Task supports only RLL and the additional safety
application instructions
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 33
1756 ControlLogix and GuardLogix Controllers
Armor ControlLogix and Armor GuardLogix Controller Specifications
Technical Specifications - Armor ControlLogix and Armor GuardLogix Controllers
Attribute 1756-L72EROM 1756-L72EROMS 1756-L73EROM 1756-L73EROMS
Standard memory 4 MB 4 MB 8 MB 8 MB
Safety memory — 2 MB — 4 MB
I/O memory 0.98 MB
Optional nonvolatile memory storage 1 GB (1756-SD1 ships with every controller)
2 GB (1756-SD2)
Digital I/O, max 128,000
Analog I/O, max 4000
Total I/O, max 128,000
Input voltage range 18…32V DC
Input voltage, nom 24V DC
Input system power, pins 2 and 3 18…32V DC @ 8 A
Input pass through power, pins 1 and 4 SELV 18…32V DC @ 8 A
Output external power, pins 2 and 3 18…32V DC @ 6 A
Output pass through power, pins 1 and 4 SELV 18…32V DC @ 8 A
Fusing Non-replaceable fuse is soldered in place(3)
(3) This fuse is intended to guard against fire hazard due to short circuit conditions.
Isolation voltage
30V (continuous), Basic Insulation Type, Power to enclosure, Ethernet channels to Power, and non-redundant
Ethernet channels to non-redundant Ethernet channels.
No isolation between redundant Ethernet channels
Type tested at 707V DC for 60 seconds
Weight, approx 7.04 kg (15.50 lb) 7.15 kg (15.725 lb) 7.04 kg (15.50 lb) 7.15 kg (15.725 lb)
Dimensions 240.0 x 292.0 x 164.52 mm (9.4 x 11.5 x 6.5 in.)
Ethernet ports 4 Ethernet M12 Category 5E
Ethernet cable 802.3 compliant shielded or unshielded twisted pair
USB port(1)
(1) The USB port is intended for temporary local programming purposes only and not intended for permanent connection.
USB 1.1, full speed (12 Mbps)
Wire Size PE Ground: 1.3…5.2 mm2 (16…0 AWG)
Terminal block torque specifications PE Ground: 2 N•m (17.7 lb•in)
Wire category(2)
(2) Use this Conductor Category information to plan conductor routing. See Industrial Wiring and Grounding Guidelines, publication 1770-4.1.
3 - on USB ports
2 - on power ports
2 - on Ethernet ports
Enclosure type rating UL Type 4/4x
Meets IP67 (when marked) with receptacle dust caps or cable termination
34 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - Armor ControlLogix and Armor GuardLogix Controllers
Attribute 1756-L72EROM, 1756-L72EROMS, 1756-L73EROM, 1756-L73EROMS
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0…60 °C (32…140 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Temperature, ambient, max 60 °C (140 °F)
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
3V/m with 1 kHz sine-wave 80% AM from 2700…6000 MHz
EFT/B immunity
IEC 61000-4-4
±3 kV at 5 kHz and 100 kHz on Power Ports
±3 kV at 5 kHz and 100 kHz on Ethernet Ports
Surge transient immunity
IEC 61000-4-5
±1 kV line-line (DM) and ±2 kV line-earth (CM) on power ports
±2 kV line-earth (CM) on Ethernet ports
Conducted RF immunity
IEC 61000-4-6 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Voltage variation
IEC 61000-4-29 10 ms interruption on DC supply ports
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 35
1756 ControlLogix and GuardLogix Controllers
Certifications - Armor ControlLogix and Armor GuardLogix Controllers
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-L72EROM, 1756-L73EROM 1756-L72EROMS, 1756-L73EROMS
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
European Union 2006/42/EC MD, compliant with:
•EN 60204-1; Electrical equipment of machines
•EN ISO 13849-1; Safety-related parts of control systems
•EN 62061; Functional safety of safety-related control systems
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
TÜV certified for functional safety(2)
(2) When used with specified firmware revisions.
—
Capable of Cat. 4/PL e according to EN ISO 13849-1 and SIL 3 according
to EN 62061/IEC 61508 when used as described in the GuardLogix 5570
and Compact GuardLogix 5370 Controller Systems Safety Reference
Manual, publication 1756-RM099.
36 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Controller Compatibility
The following tables provide compatibility with I/O modules, display devices, and other controllers and communication
devices.
Control Distributed I/O Modules
The controller can control these distributed I/O modules via the I/O Configuration tree in the programming software.
Control Safety Distributed I/O Modules
The GuardLogix controller can control these safety distributed I/O modules in a safety system.
I/O Modules EtherNet/IP ControlNet DeviceNet Remote I/O
Chassis-based I/O
1715 Redundant I/O Yes No No Yes
1746 SLC™ I/O No No No Yes
1756 ControlLogix I/O Yes Yes No No
1769 Compact I/O™ No No Yes Yes(2)
(2) With a third-party module.
1771 Universal I/O No Ye s No Yes
In-cabinet I/O
1734 POINT I/O™ Yes Yes Yes No
1734D POINTBlock I/O No No Yes No
1790, 1790D, 1790P CompactBlock™ LDX I/O No No Yes No
1791D, 1791P, 1791R CompactBlock I/O No No Ye s No
1794 FLEX™ I/O Yes Yes Ye s Yes
1797 FLEX Ex™ I/O No Ye s No No
5069 Compact I/O™ (1)
(1) Compatible with ControlLogix 5580 Controllers only.
Yes No No No
On-Machine™ I/O
1732 ArmorBlock® I/O Yes No Yes No
1738 ArmorPOINT® I/O Yes Yes Ye s No
1792D ArmorBlock® MaXum™ I/O No No Ye s No
1799 Embedded I/O No No Yes No
I/O Modules EtherNet/IP ControlNet DeviceNet
In-cabinet I/O
1791DS CompactBlock™ Guard I/O™ No No Yes
1791ES CompactBlock Guard I/O Yes No No
1734 POINT Guard I/O™ Yes No Yes
On-Machine I/O
1732DS ArmorBlock® Guard I/O™ No No Yes
1732ES ArmorBlock Guard I/O Yes No No
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 37
1756 ControlLogix and GuardLogix Controllers
Communicate with Display Devices
The controller can communicate with these display devices.
Communicate with Other Controllers
The controller can communicate with these programmable controllers.
Display Devices EtherNet/IP ControlNet DeviceNet DH+™ Remote I/O RS-232 (DF1)
Industrial Computers
Allen-Bradley® industrial computers (all)(1)
(1) Includes Allen-Bradley integrated display rotating media (HDD) and solid state (SSD) computers, Rockwell Automation® non-display computers, and Allen-Bradley integrated display computers with keypad.
Yes Yes Yes Yes Ye s Yes
Graphic Terminals
PanelView™ Plus and PanelView e terminals Yes Yes Yes Yes Ye s Yes
PanelView Standard terminals Yes Ye s Yes Yes Ye s Yes
PanelView e terminals No Ye s No Yes Ye s No
Message Displays
InView™ message displays Yes Ye s Yes Yes Ye s Yes
Controller EtherNet/IP ControlNet DeviceNet DH+ RS-232 (DF1) DH-485(5)
(5) The 1756-DH485 module supports full DH-485 functionality.
1756 ControlLogix
1756 GuardLogix Yes Yes Yes Yes Ye s Ye s
5069 CompactLogix™ Yes No No No No No
1768, 1769 CompactLogix
1768, 1769 Compact GuardLogix Yes Ye s Yes No Yes Ye s
1789 SoftLogix™5800 Ye s Yes Yes No Ye s No
1794 FlexLogix™ Yes Ye s Yes No Yes Ye s
PowerFlex® with DriveLogix™ Ye s Ye s Yes No Ye s Yes
1785 PLC-5®(1) (2)(3)
(1) The Ethernet PLC-5 controller must be series C, firmware revision N.1 or later; series D, firmware revision E.1 or later; or series E, firmware revision D.1 or later.
(2) The 1785-ENET Ethernet communication interface module must be series A, firmware revision D or later.
(3) The PLC-5, SLC, and MicroLogix processors appear as I/O points to the Logix controller. Use the appropriate DeviceNet interface for the controller.
Yes Yes Yes Ye s Ye s No
1747 SLC™(4)
(4) Use a 1747-L55x controller with OS501 or later.
Yes Yes Yes Ye s Ye s Yes
1761 MicroLogix™(4) Yes No Yes No Yes Ye s
1762 MicroLogix(4) Yes No Yes No Yes Ye s
1763 MicroLogix (4) Yes No Yes No Yes Ye s
1764 MicroLogix (4) Yes No Yes No Yes Ye s
1772 PLC-2® No No No Yes Yes No
1775 PLC-3® No No No Yes Ye s No
5250 PLC-5/250 No No No Yes Yes No
38 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Communicate with Other Communication Devices
The controller can communicate with these communication devices.
Communication Device EtherNet/IP ControlNet DeviceNet DH+
Linking device 1788-EN2DNROM 1788-CN2DN
1788-CN2FF
1788-EN2DNR
1788-EN2DNROM
(On-Machine version)
1788-CN2DN
—
PCMCIA card — 1784-PCC 1784-PCD 1784-PCMK
PCI card — 1784-PCIC
1784-PCICS
1784-PCID
1784-PCIDS
1784-CPCIDS —
Drives SCANport™ module (1)
(1) Use a CIP generic MSG instruction to communicate with the 1203-FM1 SCANport™ module on a DIN rail that is remote to the controller. The remote DIN rail also requires a 1794-ACN15 or 1794-ACNR15 ControlNet adapter.
— 1203-FM1
1203-FB1 — —
Communication module (2)
(2) Use the generic module configuration to configure the 1203-CN1 module and a CIP generic MSG instruction to communicate with the module.
—
1203-CN
1770-KFC15
1770-KFCD15
1747-KFC15
1770-KFD
1770-KFG 1770-KF2
Communication card — 1784-PKTCS
1784-KTCS
1784-KTCX15
1784-PKTX
1784-PKTXD —
USB communication device — 1784-U2CN 1784-U2DN 1784-U2DHP
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 39
1756 ControlLogix and GuardLogix Controllers
ControlLogix Redundancy
The ControlLogix 5560 and ControlLogix 5570 controllers support controller redundancy. In a redundant controller
system, you need these components:
•Two 1756 chassis, each with the same of the following:
–Number of slots
–Compatible modules in the same slots
–Redundancy firmware revisions in each module
–Two additional ControlNet nodes outside the redundant chassis pair if the application uses ControlNet networks
•One 1756-RM2 or 1756-RM2XT redundancy module per chassis that is connected by a 1756-RMCx cable
•One or two ControlLogix 5560 or ControlLogix 5570 controllers
•As many as seven enhanced communication modules, that is, 1756-CN2/B, 1756-CN2R/B, 1756-CN2RXT
modules, or 1756-EN2T, 1756-EN2TR, 1756-EN2TXT modules
1756-RM2, 1756-RM2XT Redundancy Modules
Technical Specifications - 1756-RM2, 1756-RM2XT Redundancy Modules
Attribute 1756-RM2, 1756-RM2K 1756-RM2XT
Current draw @ 5.1V DC 1.16 A
Current draw @ 24V DC 3.4 mA
Power dissipation 6 W, max
Thermal dissipation 21 BTU/hr
Connector cables 1756-RMC1, 1 m (3.28 ft)
1756-RMC3, 3 m (9.84 ft)
1756-RMC10, 10 m (32.81 ft)
Slot width 1 slot
Module location Chassis-based, any slot
Chassis 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17 1756-A7XT, 1756-A10XT,
1756-A4LXT, 1756-A5LXT, 1756-A7LXT
Controller families, supported ControlLogix 5560, ControlLogix 5570
Power supply, standard 1756-PA72, 1756-PA75, 1756-PB72, 1756-PB75 1756-PAXT, 1756-PBXT
Power supply, redundant 1756-PA75R, 1756-PB75R, 1756-PSCA2 None
North American temperature code T4
IECEx temperature code T4
ATEX temperature code T4
Enclosure type None (open-style)
Weight, approx 0.29 kg (0.64 lb)
Mounting ControlLogix-XT chassis, single-slot module
40 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - 1756-RM2, 1756-RM2XT Redundancy Modules
Attribute 1756-RM2, 1756-RM2K 1756-RM2XT
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0…60 °C (32…140 °F) -25…+70 °C (-13…+158 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 60 °C (140 °F) 70 °C (158 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 41
1756 ControlLogix and GuardLogix Controllers
Certifications - 1756-RM2, 1756-RM2XT Redundancy Modules
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-RM2, 1756-RM2K 1756-RM2XT
CSA CSA Certified Process Control Equipment. See CSA File LR54689C.
CSA Certified Process Control Equipment for Class I, Division 2 Group A,B,C,D Hazardous Locations. See CSA File LR69960C. —
CE
European Union 2004/108/IEC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
c-UL-us UL Listed Industrial Control Equipment, certified for U.S. and Canada. See UL file E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
Ex
European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-15; Potentially Explosive Atmospheres, Protection “n”
•EN 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•DEMKO13ATEX1325026X
IECEx
IECEx System, compliant with:
•EN 60079-15; Potentially Explosive Atmospheres, Protection “n”
•EN 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•IECEx UL 14.0008X
FM FM Approved Equipment for use in Class I Division 2 Group A,B,C,D Hazardous Locations —
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
42 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
ControlLogix Controller Accessories
You can use these accessories with ControlLogix controllers.
Memory Cards
Memory cards offer nonvolatile memory to store a user program and tag data on a controller.
•The ControlLogix 5560 controllers support optional 1784-CF128 CompactFlash cards purchased separately.
•The ControlLogix 5570 controllers come with the 1784-SD1 Secure Digital (SD) card installed.
•The ControlLogix 5580 controllers come with the 1784-SD2 Secure Digital (SD) card installed.
The memory cards are installed in a socket on the controller. Through the programming software, you can manually
trigger the controller to save to, or load from, nonvolatile memory or configure the controller to load from nonvolatile
memory on powerup.
Accessory Page
Memory Cards 42
1756 Energy Storage Modules 44
1756 ControlLogix Batteries 50
Serial Communication Cables 51
Technical Specifications - 1784 Memory Cards
Attribute 1784-CF128 1784-SD1 1784-SD2
Memory 128 MB 1 GB 2 GB
Supported controllers 1756-L6, 1756-L6S(1)
(1) For safety controllers using RSLogix 5000 programming software version 18 or later.
1756-L71, 1756-L71K, 1756-L71S, 1756-L71SK, 1756-L72, 1756-L72K, 1756-L72S, 1756-L72SK,
1756-L72EROM, 1756-L72EROMS, 1756-L73, 1756-L73K, 1756-L73S, 1756-L73SK, 1756-L73EROM,
1756-L73EROMS, 1756-L73XT, 1756-L73SXT, 1756-L74, 1756-L74K, 1756-L75, 1756-L75K
1756-L81E, 1756-L81EK, 1756-L81ES, 1756-L81ESK,1756-L82E, 1756-L82EK, 1756-L82ES, 1756-L82ESK,
1756-L83E, 1756-L83EK, 1756-L83ES, 1756-L83ESK, 1756-L84E, 1756-L84EK, 1756-L84ES, 1756-L84ESK,
1756-L85E, 1756-L85EK
Weight, approx 14.20 g (0.50 oz) 1.76 g (0.06 oz)
Environmental Specifications - 1784 Memory Cards
Attribute 1784-CF128 1784-SD1, 1784-SD2
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-25…+70 °C (-13…+158 °F)
Temperature, storage
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 43
1756 ControlLogix and GuardLogix Controllers
Emissions
CISPR 11 Group 1, Class A
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Certifications - 1784 Memory Cards
Certification(1)
(1) See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1784-CF128, 1784-SD1 1784-SD2
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61000-6-4; Industrial Emissions
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
Environmental Specifications - 1784 Memory Cards
Attribute 1784-CF128 1784-SD1, 1784-SD2
44 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
1756 Energy Storage Modules
These energy storage modules are available for ControlLogix 1756 controllers.
1756-L7 and 1756-L7S Energy Storage Modules
Instead of a battery, the 1756-L7 and 1756-L7S controllers are shipped with a 1756-ESMCAP energy storage module
(ESM) already installed.
Energy Storage Modules Page
1756-L7 and 1756-L7S Energy Storage Modules 44
Extreme Temperature Energy Storage Modules 46
GuardLogix Safety Partner Energy Storage Modules 47
GuardLogix Extreme-temperature Safety Partner Energy-storage Modules 49
Technical Specifications - 1756-L7 and 1756-L7S Energy Storage Modules(1)
(1) The energy storage modules for the On-Machine controllers are not field-accessible and must be returned to Rockwell Automaton for maintenance or replacement.
Attribute 1756-ESMCAP, 1756-ESMCAPK 1756-ESMNSE, 1756-ESMNSEK 1756-ESMNRM, 1756-ESMNRMK
Description Capacitor energy storage module (removable,
ships installed with every controller).
Capacitor energy storage module (removable,
no residual WallClockTime power backup).
Use this ESM if your application requires that
the installed ESM deplete its residual energy
to 40 μJ or less before transporting it into or
out of your application. Additionally, you can
use this ESM with a 1756-L73 (8 MB) or
smaller memory-sized controller only.
Wait at least 20 minutes for the residual
stored energy to decrease to 40 μJ or less
before you remove the ESM.
Capacitor energy storage module
(nonremovable, helps prevent USB
connection and SD card use to help secure
the controller).
If the SD card is installed prior to insertion
of the 1756-ESMNRM module, the SD card
remains functional, but not removable.
This ESM provides your application an
enhanced degree of security.
Current draw @ 5.1V DC 330 mA 300 mA 330 mA
North American temperature code T4A
ATEX temperature code T4
IECEx temperature code T4
Enclosure type rating None (open-style)
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 45
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - 1756-L7 and 1756-L7S Energy Storage Modules
Attribute 1756-ESMCAP, 1756-ESMCAPK, 1756-ESMNSE, 1756-ESMNSEK, 1756-ESMNRM, 1756-ESMNRMK
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0 °C < Ta < +60 °C (+32 °F < Ta < +140 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10 …500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2
6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Certifications - 1756-L7 and 1756-L7S Energy Storage Modules
Certification(1)
(1) See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-ESMCAP, 1756-ESMCAPK, 1756-ESMNSE, 1756-ESMNSEK, 1756-ESMNRM, 1756-ESMNRMK
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for US and Canada. See UL File E194810.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
•European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-15; Potentially Explosive Atmospheres, Protection ”n”
•EN 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•DEMKO13 ATEX 1325026X
IECEx
IECEx System, compliant with:
•EN 60079-0; General Requirements
•EN 60079-15; Potentially Explosive Atmospheres, Protection ”n”
•II 3 G Ex nA IIC T4 Gc
•IECEx UL 14.0008X
KC Korean Registration of Broadcasting and Communication Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
46 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Extreme Temperature Energy Storage Modules
The 1756-L7 XT and the 1756-L7 SXT extreme temperature controllers are shipped with a 1756-ESMCAPXT
installed.
Technical Specifications - 1756 Extreme Temperature Energy Storage Modules
Attribute 1756-ESMCAPXT 1756-ESMNSEXT 1756-ESMNRMXT
Description
Extreme-temperature capacitor energy
storage module (removable, ships installed
with every extreme-temperature
controller).
Extreme-temperature capacitor energy
storage module (removable, no residual
WallClockTime power backup).
Use this ESM if your application requires
that the installed ESM deplete its residual
energy to 40 μJ or less before
transporting it into or out of your
application. Additionally, you can use this
ESM with a 1756-L73 (8 MB) or smaller
memory-sized controller only.
Wait at least 20 minutes for the residual
stored energy to decrease to 40 μJ or less
before you remove the ESM.
Extreme-temperature capacitor energy
storage module (nonremovable, helps prevent
USB connection and SD card use to help secure
the controller).
If the SD card is installed before insertion of
the 1756-ESMNRM module, the SD card
remains functional, but not removable.
This ESM provides your application an
enhanced degree of security.
Current draw @ 5.1V DC 330 mA 300 mA 330 mA
North American temperature code T4A
ATEX Temp Code T4
IECEx temperature code T4
Enclosure type rating None (open-style)
Environmental Specifications - 1756 Extreme Temperature Energy Storage Modules
Attribute 1756-ESMCAPXT 1756-ESMNSEXT 1756-ESMNRMXT
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-25°C < Ta < +70 °C (-13°F < Ta < +158 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 70 °C (158 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10 …500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2
6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 47
1756 ControlLogix and GuardLogix Controllers
GuardLogix Safety Partner Energy Storage Modules
The 1756-L7SP safety partner for a GuardLogix system has these energy storage modules available.
Certifications - 1756 Extreme Temperature Energy Storage Modules
Certification(1)
(1) See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-ESMCAPXT, 1756-ESMNSEXT, 1756-ESMNRMXT
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for US and Canada. See UL File E194810.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-15; Potentially Explosive Atmospheres, Protection “n”
•EN 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•DEMKO13 ATEX 1325026X
IECEx
IECEx System, compliant with:
•IEC 60079-15; Potentially Explosive Atmospheres, Protection “n”
•IEC 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•IECEx UL 14.0008X
KC Korean Certification of Broadcasting and Communication Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
Technical Specifications - 1756-L7SP Safety Partner Energy Storage Modules(1)
(1) The energy storage modules for the On-Machine controllers are not field-accessible and must be returned to Rockwell Automaton for maintenance or replacement.
Attribute 1756-SPESMNSE, 1756-SPESMNSEK 1756-SPESMNRM
Description
Capacitor energy storage module for the safety partner
(removable, no residual WallClockTime power backup).
Use this ESM if your application requires that the installed ESM deplete
its residual energy to 40 μJ or less before transporting it into or out of
your application. Additionally, you can use this ESM with a 1756-L73
(8 MB) or smaller memory-sized controller only.
Wait at least 20 minutes for the residual stored energy to decrease to
40 μJ or less before you remove the ESM.
Capacitor energy storage module for the safety partner
(nonremovable, helps prevent USB connection and SD card use to
help secure the controller).
If the SD card is installed before insertion of the 1756-ESMNRM
module, the SD card remains functional, but not removable.
This ESM provides your application an enhanced degree of security.
Current draw @ 5.1V DC 300 mA 330 mA
North American temperature code T4A
ATEX temperature code T4
IECEx temperature code T4
Enclosure type rating None (open-style)
48 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
Environmental Specifications - 1756-L7SP Safety Partner Energy Storage Modules
Attribute 1756-SPESMNSE, 1756-SPESMNSEK 1756-SPESMNRM
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0 °C < Ta < +60 °C (+32 °F < Ta < +140 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Certifications - 1756-L7SP Safety Partner Energy Storage Modules
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-SPESMNSE, 1756-SPESMNSEK, 1756-SPESMNRM
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for US and Canada. See UL File E194810.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-15; Potentially Explosive Atmospheres, Protection “n”
•EN 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•DEMKO15 ATEX 1593X
IECEx
IECEx System, compliant with:
•IEC 60079-15; Potentially Explosive Atmospheres, Protection “n”
•IEC 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•IECEx UL 15.0125X
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 49
1756 ControlLogix and GuardLogix Controllers
GuardLogix Extreme-temperature Safety Partner Energy-storage Modules
The 1756-L7SPXT extreme-temperature safety partner is shipped with a 1756-SPESMNSEXT energy storage module
installed.
Technical Specifications - 1756-L7SPXT Extreme-temperature Safety Partner Energy-storage Modules
Attribute 1756-SPESMNSEXT 1756-SPESMNRMXT
Description
Capacitor energy storage module for the extreme-temperature
safety partner (removable, no residual WallClockTime power
backup).
Use this ESM if your application requires that the installed ESM
deplete its residual energy to 40 μJ or less before transporting it into
or out of your application. Additionally, you can use this ESM with a
1756-L73 (8 MB) or smaller memory-sized controller only.
Wait at least 20 minutes for the residual stored energy to decrease
to 40 μJ or less before you remove the ESM.
Capacitor energy storage module for the safety extreme-
temperature partner (helps prevent USB connection and SD card use
to help secure the controller).
If the SD card is installed before insertion of the 1756-ESMNRM
module, the SD card remains functional, but not removable.
This ESM provides your application an enhanced degree of security.
Current draw @ 5.1V DC 300 mA 330 mA
North American temperature code T4A
ATEX Temp Code T4
IECEx temperature code T4
Enclosure type rating None (open-style)
Environmental Specifications - 1756-L7SPXT Extreme-temperature Safety Partner Energy Storage Modules
Attribute 1756-SPESMNSEXT 1756-SPESMNRMXT
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-25 °C < Ta < +70 °C (-13 °F < Ta <+158 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
-40…+85 °C (-40…+185 °F)
Temperature, surrounding air, max 70 °C (158 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat) 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock) 50 g
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2 6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
50 Rockwell Automation Publication 1756-TD001O-EN-P - February 2018
1756 ControlLogix and GuardLogix Controllers
1756 ControlLogix Batteries
Each ControlLogix 5560 controller ships with a battery. The ControlLogix 5560 controllers have nonvolatile memory if
you install a 1784-CF128 industrial CompactFlash card. With nonvolatile memory, the controller can be used without a
battery. If you do not use a battery, current tag data remains in the state it was when the nonvolatile memory was saved.
These tables summarize battery life, replacement battery compatibility, and recommendations for use of an
externally-mounted battery assembly.
Certifications - 1756-L7SPXT Extreme-temperature Safety Partner Energy-storage Modules
Certification(1)
(1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1756-SPESMNSEXT, 1756-SPESMNRMXT
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for US and Canada. See UL File E194810.
CE
European Union 2004/108/EC EMC Directive, compliant with:
•EN 61326-1; Meas./Control/Lab., Industrial Requirements
•EN 61000-6-2; Industrial Immunity
•EN 61000-6-4; Industrial Emissions
•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with EN 61000-6-4; Industrial Emissions
Ex
European Union 94/9/EC ATEX Directive, compliant with:
•EN 60079-15; Potentially Explosive Atmospheres, Protection “n”
•EN 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•DEMKO15 ATEX 1593X
IECEx
IECEx System, compliant with:
•IEC 60079-15; Potentially Explosive Atmospheres, Protection “n”
•IEC 60079-0; General Requirements
•II 3 G Ex nA IIC T4 Gc
•IECEx UL 15.0125X
KC Korean Registration of Broadcasting and Communications Equipment, compliant with Article 58-2 of Radio Waves Act, Clause 3
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
Technical Specifications - 1756 ControlLogix Batteries (1)
(1) To ship lithium batteries globally, there can be specific restrictions and special packaging requirements. Contact the shipping company for packaging and shipping guidelines and restrictions.
Attribute 1756-BA1 1756-BA2 1756-BATM(3)
(3) The 1756-BATM externally mounted battery assembly is recommended for use with all 1756-L55x controllers, and is highly recommended for use with all series A 1756-L6x controllers, and provides longer battery life than the
1756-BA1 battery. The 1756-BATM assembly includes one 1756-BATA lithium battery assembly and a 1 m (3.28 ft) cable to connect housing to the controller.
1756-BATA
Description Lithium battery (0.59 g) Lithium battery (0.59 g) Externally mounted battery
assembly
Replacement lithium battery for
1756-BATM (5 g max lithium per
each D cell; contains 2 D cells)
ControlLogix controllers 1756-L61, 1756-L62, 1756-L63
controllers, series A
1756-L61, 1756-L62, 1756-L63
controllers, series B
1756-L64, 1756-L65 controllers
1756-L61, 1756-L62, 1756-L63
controllers, series A 1756-BATM battery module
GuardLogix controllers — 1756-L61S, 1756-L62S, 1756-L63S — —
Supported legacy controllers 1756-L55M controllers(2)
1756-L60M03SE controller
(2) The 1756-L55M22, 1756-L55M23, and 1756-L55M24 controllers have nonvolatile memory and can be used without a battery.
—1756-L55M controllers(3)
1756-L60M03SE controller 1756-BATM battery module
Rockwell Automation Publication 1756-TD001O-EN-P - February 2018 51
1756 ControlLogix and GuardLogix Controllers
Serial Communication Cables
The 1756-L6 and 1756-L6S controllers have a built-in serial port.
Technical Specifications - 1756 Serial Cables
Attribute 1756-CP3 1747-CP3
Connector type Female 9-pin D-shell
Connector angle Right-angle connector to controller, straight to serial port
Length 3 m (9.84 ft)
Allen-Bradley, Armor, ArmorBlock, ArmorBlock MaXum, ArmorPOINT, CompactBlock, Compact I/O, CompactLogix, ControlLogix, ControlLogix-XT, Data Highway Plus, DH+, DriveLogix, FLEX, FLEX Ex, FLEX I/O-XT, FlexLogix,
Guard I/O, GuardLogix, GuardLogix-XT, InView, LISTEN.THINK.SOLVE., MicroLogix, On-Machine, PanelView, PLC-2, PLC-3, PLC-5, POINT I/O, POINT Guard I/O, PowerFlex, Rockwell Automation, Rockwell Software, RSLogix 5000, SCANport,
SLC, SoftLogix, and SynchLink are trademarks of Rockwell Automation, Inc.
ControlNet, DeviceNet, and EtherNet/IP are trademarks of ODVA, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Publication 1756-TD001O-EN-P - February 2018
Supersedes Publication 1756-TD001N-EN-P - May 2017 Copyright © 2018 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
Rockwell Automation Support
Use the following resources to access support information.
Documentation Feedback
Your comments will help us serve your documentation needs better. If you have any suggestions on how to improve this document, complete the
How Are We Doing? form at http://literature.rockwellautomation.com/idc/groups/literature/documents/du/ra-du002_-en-e.pdf.
Technical Support Center Knowledgebase Articles, How-to Videos, FAQs, Chat,
User Forums, and Product Notification Updates. www.rockwellautomation.com/knowledgebase
Local Technical Support Phone Numbers Locate the phone number for your country. www.rockwellautomation.com/global/support/get-support-
now.page
Direct Dial Codes
Find the Direct Dial Code for your product. Use the
code to route your call directly to a technical support
engineer.
www.rockwellautomation.com/global/support/direct-
dial.page
Literature Library Installation Instructions, Manuals, Brochures, and
Technical Data. www.rockwellautomation.com/literature
Product Compatibility and Download Center
(PCDC)
Get help determining how products interact, check
features and capabilities, and find associated
firmware. www.rockwellautomation.com/global/support/pcdc.page
Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: +90 (216) 5698400
Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page.
