2008 Car Audio & Multimedia Catalogue
Clarion H.M.I. is both dream and reality. A dream, in the sense
that it is an ideal that we will always strive for. A reality,
since it is already present in its most up-to-date form in our products.
Interfacing people with music and information in mobile environments.
Futuristic technology for people living in the real world.
That’s the Clarion H.M.I. concept.
A dream comes true
2-DIN DVD MULTIMEDIA STATION WITH 7″ TOUCH PANEL
CONTROL, USB AND BUILT-IN BLUETOOTH
MAX686BT
Remote Control
Remote Control
DVD MULTIMEDIA STATION WITH 7″ TOUCH PANEL
CONTROL, USB AND BUILT-IN BLUETOOTH
VRX786BT
• DVD-Video/DVD±R/DVD±RW/CD-DA/CD-R/RW ready • MP3/WMA/AAC Compatible • Official DivX® Certified product • Plays
all versions of DivX® video (including DivX® 6) with standard playback of DivX® media files • 18 FM, 6 AM station presets • Rear
USB connector • WMDRM 10 playback for Digital Media Streaming (rear USB) • Fully motorized 7-inch QVGA colour LCD monitor
(VRX786BT) • Motorised sloping control panel with 7-inch QVGA colour LCD monitor (MAX686BT) • Built-in Bluetooth® Handsfree
(HFP & OPP) and Audio Streaming(A2DP & AVRCP) • iPod® direct control via USB • 3-band parametric equaliser • MAGNA BASS
EX dynamic bass enhancement • Built-in LPF/HPF • Subwoofer volume control • 24-bit D/A converter • 6 ch audio pre-out • 2-Zone
entertainment • 1 AUX AV input • 4-channel × 50 watts MOS-FET amplification • OEM Steering Wheel remote interface capability
DVD MULTIMEDIA STATION WITH
3.5″ MONITOR
VRX386USB
• DVD±R/DVD±RW ready • CD-R/RW ready • MP3 and WMA and iTunes® AAC (only USB) compatible • Official DivX® Certified product
• Plays all versions of DivX® video (including DivX®
6) with standard playback of DivX® media files • Rear USB connector • 18 FM,
12 AM
station presets • iPod direct connection and control (optional cable CCA691) • Shock proof memory • 24-bit D/A converter
• Subwoofer volume control • 2-Zone entertainment • Z-Enhancer Plus • 2-band parametric equaliser • MAGNA BASS EX dynamic
bass enhancement • Built-in High pass filter & Low pass filter • Built-in amplifier canceller • 4-channel × 50 watts MOS-FET amplification
• Fully motorised 7-inch TFT colour LCD monitor (VRX586USB) • Motorized sloping control panel with 3.5-inch TFT colour LCD monitor
(VRX386USB) • Touch panel control (VRX586USB) • Adjustable display brightness • Phone mute • 1 AUX AV input • 6-channel audio
pre-out • AUX Bluetooth audio/mobile-phone transceiver BLT370 ready • OEM steering wheel remote interface capability • CCD camera
input via video line-in with reverse gear connection
DVD MULTIMEDIA STATION WITH 7″ TOUCH PANEL CONTROL
VRX586USB Remote Control
Remote Control
DCP
DCP
ITALDESIGN-GIUGIARO
Jay Kay (Jamiroquai)
“Jay Kay”, vocalist for the
world-famous jazz funk band
Jamiroquai.
“VAD.HO”, the Clarion H.M.I.
concept car created by Italian
designer GIUGIARO, one
of the world’s top industrial
design firms.
*VRX786BT/MAX686BT is compatible with MP3/WMA/AAC/DivX on DVD±R/
DVD±RW/CD-R/RW media formats. Maximum track capacity: 999 tracks (255
folders with max. 255 tracks per folder) *VRX786BT/MAX686BT is compatible with
MP3/WMA/AAC on USB. Maximum track capacity:130,560 tracks (512 folders with
max. 255 tracks per folder) *The units of iPod video compatible are not playable the
PLAY LIST that is mixed music files and movie files.
Multimedia station
Clarion knows connectivity and so do the VRX586USB
and VRX386USB. They are equipped with a USB slot
for easy access to your music collection, an OEM
Steering Wheel control interface input and a rear
view camera input. Combine this with MP3/WMA and
iTunes
®
AAC file format decoding, iPod
®
audio and
video connectivity and 2-Zone entertainment. Clarion
offers everything you ever wanted. All Clarion in-dash
multimedia products also offer seamless connection
to our full range of rearview CCD camera systems.
Simply shifting your vehicle into reverse automatically
starts the on-screen image display.
Handsfree communication
and wireless music
playback thanks to
Bluetooth
®
technology
Direct USB iPod
®
control
* To connect iPod, please use the USB cable attached to iPod. * For video playback , optional CCA723 cable required * Please see the Clarion website for iPod models that can be connected
DCP
microphone
DVD / CD
MP3 / WMA / DivX
MPEG4 / JPEG
AM / FM
VRX586USB
VRX386USB
Multimedia
station
Rear-View
Camera
Video Camera
(AUX) iPod
Audio & Video
USB
MP3 / WMA /
AAC
Amplifier
2-Zone
02 www.clarion.com
VB476 VS755
DVD/CD/VCD/MP3/WMA RECEIVER
• DVD±R/ DVD±RW Ready • NTSC/PAL Formatted DVD
Compatible • CD-R/RW and JPEG Image Disc Ready
• MP3 Compatible with ID3 TAG • On-screen Display
• 2 Audio/Video Inputs (Includes Front Panel A/V Input)
• Plug-in Infrared Remote Receiver • Infrared Remote
Control • Parental Level Settings
DVD/CD/VCD/MP3 PLAYER
• MP3/WMA compatible • DVD±R/DVD±RW/CD-R/CD-
RW ready • 18 FM,12 AM station presets • 24-bit D/A
converter • 6-channel audio pre-out with subwoofer
volume control • 4-channel × 45 watts of amplification
• DVD video and audio/video CD compatible • Flip-down
console • 2 video line-outs • 2-channel auxiliary input
• Remote control included • Detachable control panel
Multimedia
• DVD-Video/DVD±R/DVD±RW/CD-DA/CD-R/RW ready • MP3/WMA Compatible with ID3-
TAG display • 18 FM, 6 AM station presets • Seek manual up/down • Fully motorised 7-inch
QVGA colour LCD monitor • Adjustable display brightness • Tilt angle 5 Positions Display
• Touch Panel Control • 24-bit D/A converter • RCA visual input • 6ch RCA output
• 4-channel × 40 watts built-in amplifier • iPod® audio control (optional cable CCUiPod)
• Built-in IR eye and remote included
DVD MULTIMEDIA STATION WITH 7-INCH TOUCH PANEL CONTROL
VRX486VD
• DVD-Video/DVD±R/DVD±RW/CD-R/RW Ready • MP3/WMA Compatible with ID3-TAG
display • 18 FM, 6 AM station presets • 6.5-inch QVGA colour LCD monitor • Touch panel control
• Phone mute • 24-bit D/A converter • 6 ch RCA output (front + rear + subwoofer) • 4-channel
× 40 watts built-in amplifier • Rotary volume control • iPod® audio control (optional cable
CCUiPod) • Built-in IR eye and remote included • Rear audio and visual input • Rear AV output
2-DIN DVD MULTIMEDIA STATION WITH 6.5-INCH TOUCH PANEL CONTROL
MAX386VD
5.6"/16:9 HEADREST/STAND-
ALONE MONITOR
VMA573
VMA773
7"/16:9 HEADREST/STAND-
ALONE MONITOR
CENTRE SPEAKER SYSTEM
WITH POWER AMPLIFIER
SRK604
8″ OVERHEAD ENTERTAINMENT
DIGITAL MONITOR
OHM875VD
OHM107VD
10.2″ OVERHEAD ENTERTAINMENT
DIGITAL MONITOR
OHM1575VD
15″ OVERHEAD ENTERTAINMENT
DIGITAL MONITOR
5.6"/16:9 HEADREST/STAND-
ALONE MONITOR
VMA5096
VMA7196
7"/16:9 HEADREST/STAND-
ALONE MONITOR
OHM Series Monitor Features
• Universal Slim Profile • MPEG 1/2/4, MP3 and WMA playback • Adjustable Display Modes: Wide/Normal • Infrared
Remote control with On Screen Display • 2 Audio/Video Inputs for external devices • 1 Audio/Video Output for multiple
monitor applications • Built-in LED Dome lights • Includes 2 Headphones
• 16:9/4:3 Adjustable Screen Format • On-screen Display • 2 AV Inputs • Built-in
Dual IR Output for Headphone (Optional IRH602A) • Built-in Receiver for compatible
Devices • Easy-fit Universal Mounting Bracket Included • Supports NTSC and PAL
With Clarion multimedia
loaded in your vehicle,
your back seat might
become your home away
from home.
“Are we there yet?” That sentence is
now extinct thanks to Clarion’s rear seat
entertainment systems. Featuring a line-
up of overhead monitors ranging from
8-inch to 15-inch which include a built
in DVD player and wireless headphone
transmitters as well as a selection of
5-inch & 7-inch headrest monitors - now
peace of mind is only a press of a button
away. Our TFT active matrix LCD
monitors reproduce vivid colors and pro-
vide crisp clear viewing of your favorite
DVD. Now the problem will be getting
your kids out of the car when you reach
your destination.
• 16:9/4:3 Adjustable Screen Format • On-screen Display • 2 AV Inputs • Built-in
Dual IR Output for Headphone (Optional IRH602A) • Built-in Receiver for compatible
Devices • Easy-fit Universal Mounting Bracket Included • Supports NTSC and PAL
Remote Control
CeNET TV TUNER
TTX754 PAL
DOLBY DIGITAL/dts CeNET
PROCESSOR
DVH940
www.clarion.com 03
• CD-R/RW ready • MP3, WMA and iTunes® AAC compatible • Rear USB
connector with maximum track capacity: 130,560 (255 tracks in 512 folders)
• WMDRM 10 playback for Digital Media Streaming
• 18 FM, 6 AM station
presets • iPod® direct control via USB • 6V / 6ch audio preout • Subwoofer level
control • 24-bit D/A converter • Sound Restorer • Digital Z-Enhancer • Digital time
alignment • 3-way active crossover • 3-band parametric equaliser • Built-in High
pass filter & Low pass filter • Built-in amplifier canceller • 4-channel × 53 watts
MOS-FET amplification • Motorised sloping console • 728-variable colour display
and illuminated keys • Full dot display with Screensavers • "SLIDETRAK" for
dynamic operation • Mobile phone mute • Auxilliary input with level control
•
CeNET control of
6-disc CD changer • AUX Bluetooth transceiver BLT370 ready
• OEM steering wheel remote wired interface capability
HIGH END CD/USB/MP3/WMA/AAC RECEIVER
WITH CeNET CONTROL
DXZ786USB
Remote control
DCP
Remote control
DCP
• CD-R/RW ready • MP3, WMA and iTunes
®
AAC compatible • Front USB slot with
maximum track capacity: 130,560 (255 tracks in 512 folders) • WMDRM 10 playback
•
18 FM, 6 AM station presets
• iPod
®
direct control via USB
• 6ch RCA output • Built-in High pass filter & Low pass filter • Z-Enhancer
Plus • MAGNA BASS EX dynamic bass enhancement •
4-channel × 50
watts
• High visibility single line display with Screensavers • Rotary volume
control • Phone mute • Front-panel auxilliary input with level control
• CeNET control of 6-disc CD changer • AUX Bluetooth transceiver
BLT370 ready • OEM steering wheel remote wired interface capability
Remote control
DCP
CD/USB/MP3/WMA/AAC
RECEIVER WITH
CeNET CONTROL
DXZ386USB
• CD-R/RW ready • Front USB slot with maximum track capacity: 65,535 (supports 999
folders and max. 256 files in the folders) • MP3 and WMA compatible • 18 FM, 6 AM
station presets • 13 × 8 digits High visibility LCD • Z-Enhancer Plus
• MAGNA BASS EX dynamic bass enhancement
•
4-channel × 50
watts • High visibility single line display with Screensavers • Rotary
volume control • Non Fader volume control • Front-panel auxilliary
input with level control • 4-channel audio pre-out (front+non fader)
• AUX Bluetooth transceiver BLT370 ready • OEM steering wheel
remote wired interface capability
CD/USB/MP3/WMA RECEIVER
DB286USB
CD/MP3/WMA RECEIVER
DB186MP
DCP
• SD slot for music playback • MP3 compatible with ID3-TAG display • Built-in Bluetooth
wireless technology for handsfree / audio streaming and remote control • 18 FM station
presets • 4-channel × 50 watts • Flip-down control panel • 728-variable colour illuminated
face panel • Auxiliary input • 2-channel audio pre-out • External microphone included
BLUETOOTH SD/
MP3 RECEIVER
FB276BT
The next-generation source unit
• Built-in Bluetooth audio streaming
(A2DP & AVRCP)
• Built-in Bluetooth Handsfree (HFP)
• MP3 playback via SD card slot
DCP
Rear USB connector
with iPod control
Clarion takes HMI
to the next level
with SLIDETRAK
for precise control
of key features
on the main unit.
Simply swipe your
fingertip to easily adjust the volume. Preset radio
stations and CD track controls are also incorpo-
rated into the multifunctional display, so you can
navigate through preset stations or select your
favourite music track by sliding your finger to a
side of the display. SLIDETRAK also maxim-
ises available space on the main unit to create a
large, easy-to-read display.
6 volts / 6 channels
SR off SR on
Hear your music the way it was
meant to be heard. Clarion’s Sound
Restorer recreates the high fre-
quency information that is lost dur-
ing compression. The result is clear
and detailed sound.
SOUND RESTORER
SLIDETRAK Sideways Control
Front USB
connector with
iPod control
USB Slot
Front panel
auxiliary input
Bluetooth system
FB286BTB
FB276BT
Mobile phone
FB286BTB
CD/USB/MP3/WMA/AAC
RECEIVER WITH CeNET
CONTROL
DXZ586USB
• CD-R/RW ready • MP3, WMA and iTunes
®
AAC compatible • Front USB slot with
maximum track capacity: 130,560 (255 tracks in 512 folders) • WMDRM 10 playback for
USB Digital Media Streaming •
18 FM, 6 AM station presets
• iPod
®
direct control via USB
• Subwoofer level control • 24-bit D/A converter • Sound Restorer • Digital Z-Enhancer • 2-
band parametric equaliser • Built-in High pass filter & Low pass filter •
4-channel × 53 watts
MOS-FET amplification • Flip-down console • High visibility 2-line display with Screensavers
• "SLIDETRAK" for dynamic operation • Cellular input and Phone mute • Auxilliary input
with level control • 6-channel audio pre-out • CeNET control of 6-disc CD changer • AUX
Bluetooth transceiver BLT370 ready • OEM steering wheel remote wired interface capability
SLIDETRAK Sideways
Control
Front USB connector
with iPod control 24 bit D/A converter
microphone
* Use the USB cable supplied to connect the iPod on models feat. iPod control
* Please visit the Clarion website for iPod models that can be connected.
Remote control
(Optional)
Remote control
(Optional)
• CD-R/RW ready • MP3 and WMA compatible
• 18 FM, 6 AM station
presets
• Z-Enhancer Plus • MAGNA BASS EX dynamic bass enhancement
• 4-channel × 50 watts • High visibility single line display with Screensavers
• Rotary volume control • Phone mute • Mobile phone input through minijack
• Front-panel auxilliary input with level control • 4ch/2v audio pre-out
• AUX Bluetooth transceiver BLT370 ready • OEM steering wheel remote
interface capability
DCP
X-over and Time Alignment
Source units
04 www.clarion.com
• CD-R/RW ready • MP3 and WMA compatible • Front USB slot (supports max. 255 folders and
max. 15,000 files in the folders) •
18 FM, 6 AM station presets
• Z-Enhancer • MAGNA BASS EX
dynamic bass enhancement • 4-channel × 50 watts MOS-FET amplification • High visibility single
line display with Screensavers • 728-variable colour display and illuminated keys • Front-panel audio
input with level control • 4-channel audio pre-out • AUX Bluetooth transceiver BLT370 ready • OEM
steering wheel remote wired interface capability
• CD-R/RW ready • MP3 and WMA compatible with ID3-
TAG display • 18FM, 6AM station presets • 4-channel × 50
watts of MOS-FET amplification • VF display with Spectrum
analyser and Screensavers • CATS: Theft prevention sys-
tem with personal code • CeNET Control of: DVD changer,
TV tuner, 6-disc CD changer and iPod • 4-channel audio
pre-out • Auxiliary input with level control • CeNET iPod
interface compatible
(EA1251 is required)
Source units
• CD-R/RW ready • MP3, WMA and iTunes
®
AAC compatible • Rear USB connector
• WMDRM 10 playback via supported USB Digital Media streaming
•
18 FM, 6 AM station
presets
• iPod
®
direct control via USB • Z-Enhancer Plus • MAGNA BASS EX dynamic bass
enhancement •
4-channel × 50 watts
• High visibility 2-line display with Screensavers • Rotary
volume control • Phone mute • CeNET control of 6-disc CD changer • Front AUX input
• 4-channel audio pre-out • AUX Bluetooth transceiver BLT370 ready • OEM steering wheel
remote wired interface capability
2-DIN CD/USB/MP3/
WMA/AAC RECEIVER
WITH CeNET CONTROL
DUZ386MP
2-DIN 6-DISC CD/MP3/WMA
RECEIVER / CeNET CONTROL
WXZ466MP
Remote control
• Dual 24-bit / 96kHz sampling digital to analogue burr-
brown converters and DSP • Built-in 4-way crossovers
• 5-band parametric equaliser • Digital time alignment
for each line level output • 8-channel/4-volt gold plate
oxygen-free RCA output • 0.5dB-step electronic
volume adjustment circuit • Copper plated chassis
• External DC/DC converter • CeNET control of: DVD
changer, 6-disc CD changer, TV tuner and iPod
®
• 2 x
2-channel auxiliary inputs • Zinc die-cast faceplate
• Fiber optic input/output • Vacuum florescent display
• 18FM, 6AM station presets
CD RECEVER/CeNET CONTROL
HX-D2
DUB276MP
DUB276MPW
Remote control
(Optional)
2-DIN CD/USB/MP3/WMA
RECEIVER
Built-in 6-discs
CD changer
Silver-Coated SK:6N
(99.9999% Oxygen-Free)
Copper RCA
96kHz Sampling D/A
Converter
96kHz Sampling D/A Converter
96kHz sampling enables reproduction of sounds faithful to the original source.
The 96kHz Sampling D/A converter samples at a much higher rate than the usual
44.1kHz to offer reproduction frequencies as high as 48kHz (half the sampling
frequency of 96kHz), surpassing the format specifications for CD as the first such D/A
Converter for car audio use. By broadening the sampling range, it becomes possible
to reproduce the subtle nuances and depth contained in harmonic elements while
reducing phase distortion in the high frequency range, delivering the full expressive-
ness and natural resonation that is inherently present in sound.
Conceptual Diagram of Frequency/
Phase Characteristics
<Phase Characteristics>
<Frequency Characteristics>
Phase
shift occurs
Reproduction
of high-range
spectrum
Conventional audio
Audio with 96kHz sampling
100k(Hz)96k70k40k20k10k
0
0
-40
-80
(dB)
0˚
Remote control
Front USB input
728-variable colour illumination
Front auxiliary
input
Direct USB iPod®
Control
Rear USB connector
compatible with WMDRM 10
Front auxiliary
input
Remote control
Bluetooth® & Mobile-phone
With Clarion’s Bluetooth® technology, talk hands-free through your car’s audio system with a Bluetooth®
compatible mobile phone. If your mobile phone (or other audio device) is compatible with Bluetooth audio
profiles (A2DP or AVRCP), you can stream music stored on the phone or other audio device wirelessly to
the car’s audio system for playback.
Hands-free
communication and
wireless music playback
thanks to Bluetooth
®
technology
Bluetooth Profile : Headset Profile
(HSP), Hands-free Profile (HFP),
Advanced Audio Distribution Profile
(A2DP), Audio Video Remote
Control Profile (AVRCP)
Bluetooth audio/mobile-
PHONE TRANSCEIVER fOR
AUX INPUT
BLT370
DXZ786USB
DXZ586USB
DB286USB
VRX586USB
DXZ386USB
DB186MP
VRX486VD
MAX386USB
VRX386USB
Keep your mobile phone or Bluetooth® Audio enabled playback
device safe and sound in your pocket or purse while enjoying
crystal-clear sound through the BLT370 Bluetooth® audio/mobile
phone transceiver.
Bluetooth® Audio Interface
www.clarion.com 05
680W 4/3/2 CHANNEL
POWER AMPLIFIER
APX4361
1550W MONO POWER
AMPLIFIER
DPX11551
38 CM [15″] DUAL 4-OHM VOICE
COIL SUBWOOFER
PXW1552
30 CM [12″] DUAL 4-OHM VOICE
COIL SUBWOOFER
PXW1252
30 CM [12″] DUAL 2-OHM VOICE
COIL SUBWOOFER
PXW1251
25 CM [10″] SINGLE 4-OHM VOICE
COIL SHALLOW SUBWOOFER
PFW1051
850W MONO POWER
AMPLIFIER
DPX1851
650W 2/1 CHANNEL
POWER AMPLIFIER
DPX2251
400W 4/3/2 CHANNEL
POWER AMPLIFIER
APX4241
200W 2/1 CHANNEL
POWER AMPLIFIER
APX2121
340W 2/1 CHANNEL POWER
APX2181
420W MONO
POWER AMPLIFIER
APX1301
APX SERIES
SLIM DESIGN 17 CM [6-3/4″]
COUNTER DRIVE ACTIVE SUBWOOFER
SRV313
ACTIVE SUBWOOFER
ACCESSORIES
IRH602A
DUAL CHANNEL
WIRELESS
HEAD-PHONE
SYSTEMS
(FOR VMA SERIES HEAD-
REST MONITORS))
VA700
VIDEO DISTRIBUTION
AMPLIFIER
CC2011E
ULTRA COMPACT
COLOUR CCD CAMERA
(MIRROR IMAGE)
CAMERA CABLES FOR
CC2011E
• Connecting cables for
compact camera
CCA532 (7m)
CCA533 (10m)
CCA534 (15m)
DCZ625
6-DISC CD CeNET CHANGER
DC625
6-DISC CD C-BUS CHANGER
FMC250
CD CHANGER
CONTROLLER WITH
FM MODULATOR
FM200
FM MODULATOR
CAA188
POWER BOX FOR
CCD CAMERA
(FOR MAX676VD)
CAA185
POWER BOX FOR
CCD CAMERA
(FOR MAX686BT/VRX786BT/
VRX586USB/VRX386USB)
12″ SINGLE 4-OHM VOICE COIL
SUBWOOFER
SRW1251
10″ SINGLE 4-OHM VOICE COIL
SUBWOOFER
SRW1051
SRW SERIES SUBWOOFERS
Stick wired remote control
PXW SERIES SUBWOOFERS
Harness the power,
love your music!
15″ & 12″ SINGLE 4-OHM VOICE
COIL SUBWOOFERS
SB15XB & SB12XB
SB SERIES
IR700
WIRELESS
HEAD-PHONE
SYSTEMS
(FOR OHM1575VD/
OHM107VD &
OHM875VD))
SH1575/SH1075
SHROUD
(FOR OHM1575VD/
OHM107VD)
APX ILLUMINATION
SERIES DPX HYBRID SERIES : DIGITAL AMPLIFIERS
06 www.clarion.com
Amplifiers / Subwoofers / Speakers
13 CM × 18 CM (5″ × 7″)
CUSTOM-FIT COAXIAL 2WAY
SRG5720C
10 CM × 15 CM (4″ × 6″)
CUSTOM-FIT COAXIAL 2WAY
SRG4620C
9 CM (3-1/2″) CUSTOM-FIT
COAXIAL 2WAY
SRG920C
CUSTOM-FIT SERIES
13 CM (
5-1/4
″)
/ 12 CM
×
18 CM
(5″ × 7″
)
MULTIFIT SPEAKER SYSTEM
SRU1320M
16.5 CM (6-3/4″) /
15 CM × 20 CM
(6″ × 8″)
MULTIFIT SPEAKER
SYSTEM
SRU1720M
2.5 CM (1
″
)
DOME TWEETER
SRU310H
16 CM (6-1/2″) /
15 CM × 20 CM (6″ × 8″)
MULTIFIT SPEAKER
SYSTEM
SRP1620M
13 CM (5-1/4″) / 12 CM × 18 CM (5″ × 7″)
MULTIFIT SPEAKER SYSTEM
SRP1320M
10 CM (4″) / 10 CM × 15 CM (4″ × 6″)
MULTIFIT SPEAKER SYSTEM
SRP4620M
15 CM × 23 CM (6″ × 9″) MULTIFIT
SPEAKER SYSTEM
SRP6920M
16 CM (6-1/2
″
) 2WAY
COMPONENT SYSTEM
SRQ1620S
16 CM (6-1/2″)
MULTIAXIAL 3WAY
SRQ1630R
13 CM (5-1/4″)
MULTIAXIAL 3-WAY
SRQ1330R
ULTRA SERIES
PLATINUM SERIES
“Q” SERIES
2 CM (3/4″)
DOME TWEETER
SRQ210H
10 CM (4″)
COAXIAL 2-WAY
SRQ1020R
15 CM × 23 CM (6″ × 9″)
COAXIAL 2WAY
SRG6920R
16 CM (6-1/2″)
COAXIAL 2WAY
SRG1620R
13 CM (5-1/4″)
COAXIAL 2WAY
SRG1320R
10 CM (4″)
COAXIAL 2WAY
SRG1020R
“G” SERIES
“Q” SERIES
Passion for performance,
innovative by design
Clarion is proud to present its premier line of multi-
speakers for a new generation of vehicles. Offering
a specific fit adaptor for vehicles with more difficult
fitment requirements, and allowing for a seamless
and effort-free installation. Other features include
die-cast frames for advanced rigidity, soft silk
dome tweeters, and Spider Exhaust Technology
S.E.T. Cooling for improved power handling.
MultiFit
The multi-fit construction of the Ultra and Platinum series
allows the tweeter and woofer to be separated during instal-
lation. This grants the user the ability to install the speakers
in the most focally correct location for specific vehicles.
Tweeter
Phase
Plug
Speakers
Spider Exhaust Technology Cooling S.E.T.
Heat is the number one enemy of speakers. All of Clarion’s Ultra and
Platinum woofer drivers feature S.E.T. (Spider Exhaust Technology)
Cooling, to allow hot air to escape the speaker’s internal motor assembly
via computer designed porting.
13 CM (5-1/4″) 2WAY
COMPONENT SYSTEM
SRQ1320S
15 CM ×
23 CM (6″
×
9″)
MULTIAXIAL 3-WAY
SRQ6931R
www.clarion.com 07
Printed in Australia
Authorised Dealership
WARNING: Driver is prohibited by law from viewing a video signal on any in-dash monitor
while the vehicle is in motion.
Clarion Australia Pty. Ltd.
30 Corporate Drive, Moorabbin, Victoria, Australia, 3189
Tel: (03)8558-1115 Fax: (03)9551-0366
http://www.clarion.com.au
Clarion Co., Ltd.
5-35-2 Hakusan, Bunkyo-ku, Tokyo 112-8608, Japan
Tel: (81) 3-3815-1121
http://www.clarion.com
ACCESSORIES
CCA-519
CeNET Branch Cable: 1 m
CCA-389
Mini 8-pin (DIN) to RCA
Transfer Cable
CCA-521
CeNET Extension Cable: 0.6
m
CCA-520
CeNET Extension Cable: 2.5 m
CCA-623
RCA transfer cable for TB851P
• 1 AUX AV (L/R/V) input,
1 video line-out
CABLES
CAA-397-900
Spare 6-CD Magazine
• For DCZ625/DC625
CD MAGAZINE
Terminal Shape
Length
Out In
DCA-005
VRX776VD DVH940
5 m
DCA-006
DCZ625 DVH940
5 m
DCA-008
VRX776VD DVH940
1.5 m
OPTIONAL CABLES
Notes
• Specifications and design are subject to change without notice.
• Photos are non-binding. The manufacturer and importer do not take
responsibility for any printing errors.
• Photographs in this catalogue may appear slightly different in colour than
the actual object due to printing ink properties.
• iPod and iTunes are for legal or right holder authorised copying only.
Don't steal music.
• iPod® and iTunes® are a trademark of Apple Inc. registered in the U.S.
and other countries.
• The Bluetooth trademark and logo are owned by Bluetooth SIG, Inc.,
and use of these trademarks by Clarion is carried out under license.
• DivX, DivX Certified, and associated logos are trademarks of DivX, Inc.
and are used under license.
• All other trademarks are the property of their respective owners.
• All units in this catalogue are primarily intended for installation in passenger
cars. Use in lorries, tractors, off-road vehicles, construction machinery,
boats (except marine products), and other special-purpose vehicles or on
motorcycles is not recommended.
• There is no guarantee that all units in this catalogue can play CCCD (Copy
Control CD), Hybrid SACD (Super Audio CD), CD-R/RW and DVD±R/RW
• The driver should be aware and abide by the laws of the country when
operating any multimedia/navigational equipment
• LCD panels use the latest high-tech components and boast an effective pixel
rate of 99.99%. However, be aware that 0.01% or less of the pixels may be
defective.
• USB digital media streaming-compatible. This product is protected by certain
intellectual property rights of Microsoft Corporation. Use or distribution of
such technology outside of this product is prohibited without a license from
Microsoft Corporation.
• Windows Media and the Windows logo are trademarks or registered trade
marks of Microsoft Corporation in the United States and/or other countries.
• See the Clarion website for iPod models that can be connected
CeNET - iPod Interface
iPod CONNECTING UNIT
• For WXZ466MP/HX-D2
iPod CONNECTING UNIT
*Compatible with ’06 or older CeNET Models
Interfaces to enjoy iPods
with full operation
Interfaces to enjoy iPods with
simple operation as with
CD Auto-changers
EA1276
• Compatible with ’07 CeNET
Models
EA1251
Direct iPod connection
• For MAX676VD/VRX776VD
CCA673
iPod AUDIO/VIDEO
CONNECTING CABLE
• For VRX586USB/VRX386USB
CCA691
iPod AUDIO/VIDEO
CONNECTING CABLE
• For MAX686BT/VRX786BT
CCA723
iPod AUDIO/VIDEO
CONNECTING CABLE
• For MAX386VD/VRX486VD
CCUiPod
iPod AUDIO
CONNECTING CABLE
RCB-147-600
Infrared joystick remote control
RCB-177
Remote Control
For MAX686BT/VRX786BT
RCB-176
Remote Control
REMOTES
ZCP-100
Whip and Window Type
4-Way Diversity Antenna
ZCP104
4-Way Amplified Diversity
Inside Window Film TV Antenna
for TTX754
TV ANTENNAS
FLA250S
4-Way Diversity Inside
Window Film TV Antenna for
TTX754
CeNET - iPod Interface
CeNET iPod INTERFACE
CCA iPod
•
iPod® Audio Transfer Through CeNET
Busing • Sort Music by Song Title, Album,
Artist, Composer, Genre and Playlist.
• Track Information on CD Text
Compatible Source Units • Recharges
iPod® Battery
