Agriquip

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-05889921 10 LH 3.937" / 100mm 1.85" / 47mm .157" / 4mm .826" / 21mm

For Models: ALL CM SERIES

A-05870021 10 RH 3.937" / 100mm 1.85" / 47mm .157" / 4mm .826" / 21mm

For Models: ALL CM SERIES

BUSH HOG

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-526215BH 10 RH 4.724" / 120mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: DM18, DM19, DM7, DM8, DM9, HM5, HM7, HM8

A-526216BH 10 LH 4.724" / 120mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: DM18, DM19, DM7, DM8, DM9, HM5, HM7, HM8

A-527748BH 9 RH 4.750" / 121mm 2.000" / 50.8mm .157" / 4mm .889" / 22.6mm

For Models: DM180, DM190, DM70, DM80, DM90

A-527749BH 9 LH 4.750" / 121mm 2.000" / 50.8mm .157" / 4mm .889" / 22.6mm

For Models: DM180, DM190, DM70, DM80, DM90

A-527747BH 10 RH 4.750" / 121mm 2.000" / 50.8mm .157" / 4mm .889" / 22.6mm

For Models: DM5406, DM5407, DM5408, DM5409

A-527746BH 10 LH 4.750" / 121mm 2.000" / 50.8mm .157" / 4mm .889" / 22.6mm

For Models: DM5406, DM5407, DM5408, DM5409

CASE-IH

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-700712888 9 RH 4.213" / 107mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: 8309, 8312, 8315, 8850

A-700712889 9 LH 4.213" / 107mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: 8309, 8312, 8315, 8350

A-700711857 10 RH 4.213" / 107 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 8309, 8312, 8315, 8850

A-700711858 10 LH 4.213" / 107 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 8309, 8312, 8315, 8850

A-3164894R3 3.78" / 96mm 1.57" / 40mm .14" / 3.5mm .75" / 19mm

For Models: 3104, 3106

A-ZA113384A1 9 RH 4.750" / 121MM 2.000" / 50.8 MM .157" / 4 MM .889" / 22.6 MM

For Models: (3204, 3205, 3206, 3309 ALL W/ Heavy Duty Disc)

DISC MOWER BLADES

DISC MOWER BLADES

A-ZA113385A1 9 LH 4.750" / 121 MM 2.000" / 50.8 MM .157" / 4 MM .889" / 22.6 MM

For Models: (3204, 3205, 3206, 3309 ALL W/ Heavy Duty Disc)

A-ZA526215 10 RH 4.725" / 120 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: (3204, 3205, 3206, 3209 ALL W/ Standard Disc)

A-ZA526216 10 LH 4.724" / 120 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: (3204, 3205, 3206, 3209 ALL W/ Standard Disc)

CLAAS

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-9775160 1 3.543" / 90mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

A-9781860 1 3.779" / 96mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

A-9041777 10 LH 3.7" / 94mm 1.57" / 40mm .12" / 3mm .75" / 19mm

For Models: CORTO 290F, WM165, WM185, WM210, WM31F

A-9041787 10 RH 3.7" / 94mm 1.57" / 40mm .12" / 3mm .75" / 19mm

For Models: CORTO 290F, WM165, WM185, WM210, WM31F

A-9782414 9 3.78" / 96mm 1.57" / 40mm .12" / 3mm .75" / 19mm

For Models: SEVERAL

FELLA

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-116948 1 3.35" / 85mm 1.61" / 41mm .17" / 4.3mm .77" / 19.5mm

For Models: FKM2, FKM2H, FKM80

A-116954 1 3.779" / 96mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: KM20, KM22

A-121713 10 RH 3.858" / 98mm 1.890" / 48mm .157" / 4mm .748" / 19mm

For Models: (SM165, SM240 ALL <1989)

A-121712 10 LH 3.858" / 98mm 1.890" / 48mm .157" / 4mm .748" / 19mm

For Models: (SM165, SM240 ALL <1989), SM215 <7/1990

A-122330 10 RH 4.173" / 106mm 1.890" / 48mm .157" / 4mm .748" / 19mm

For Models: (SM165, SM206, SM215, SM216, SM240 ALL 1990>)

A-122329 10 LH 4.173" / 106mm 1.890" / 48mm .157" / 4mm .748" / 19mm

For Models: (SM165, SM206, SM215, SM216, SM240 ALL 1990>)

A-111725 10 RH 4.274" / 120mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: SM240

A-111724 10 LH 4.724" / 120mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: SM240

A-477741 1 3.543" / 90mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

FAHR

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-110190102820 1 3.267" / 83mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: SEVERAL

A-1101203011500 1 3.779" / 96mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: KM2.17, KM2.19, KM2.33, KM20, KM22, KM24, KM25

A-06561542 9 3.78" / 96mm 1.57" / 40mm .12" / 3mm .75" / 19mm

For Models: KM2.17, KM2.19, KM2.33, KM20, KM22, KM24, KM25

A-1101701015300 1 3.779" / 96mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: KM20, KM22, KM24, KM25

A-1101901027120 1 3.543" / 90mm 1.575" / 40mm .118" / 3mm .748" / 149mm

For Models: KM20, KM22

A-06561547 9 LH 3.78" / 96mm 1.61" / 41mm .12" / 3mm .75" / 19mm

For Models: KM2.27

A-06561546 9 RH 3.78" / 96mm 1.61" / 41mm .12" / 3mm .75" / 19mm

For Models: KM2.27

A-1101901028200 1 3.267" / 83mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

FARENDLOSE

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-011069 1 3.897" / 99mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

Fort

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-40490006 9 LH 3.86" / 98mm 1.77" / 45mm .14" / 3.5mm .65" / 16.5mm

For Models: (DISC MOWER: SEVERAL)

A-40490005 9 RH 3.86" / 98mm 1.77" / 45mm .14" / 3.5mm .65" / 16.5mm

For Models: (DISC MOWER: SEVERAL)

Freudendahl (JF)

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-13800001 9 3.7" / 94mm 1.97" / 50mm .16" / 4mm .79"x.94" / 20x24mm

For Models: JF-245

A-13800005 1 3.7" / 94mm 1.57" / 40mm .16" / 4mm .75"/ 19mm

For Models: JF-1900

A-13800002 9 3.7" / 94mm 1.97" / 50mm .16" / 4mm .79"x.94" / 20x24mm

For Models: SEVERAL

A-13800003 9 3.7" / 94mm 1.97" / 50mm .16" / 4mm .79"x.94" / 20x24mm

For Models: SEVERAL

A-13800004 4.33" / 110mm 1.97" / 50mm .16" / 4mm .81" / 20.5mm

For Models: SEVERAL

A-13800006 9 LH 3.7" / 94mm 1.65" / 42mm .16" / 4mm .75" / 19mm

For Models: SEVERAL

A-13800007 9 RH 3.7" / 94mm 1.65" / 42mm .16" / 4mm .75" / 19mm

For Models: SEVERAL

A-13800013 1 HVDTY 3.543" / 90mm 1.772" / 45mm .157" / 4mm .807"x.946" / 20.54x24.3mm

For Models: SEVERAL

GEHL

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-125446 9 RH 4.843" / 123 MM 1.772" / 45 MM .160" / 4 MM .716" / 18.2 MM

For Models: 162 W/ HD Disc, 165, 2340, 2360

A-125447 9 LH 4.843" / 123 MM 1.772" / 45 MM .157" / 4 MM .716" / 18.2 MM

For Models: 162 W/ HD Disc, 165, 2340, 2360

A-613727 9 RH 3.740" / 95 MM 1.772" / 45 MM .139" / 3.5 MM .640" / 16.25 MM

For Models: 162 W/ Standard Disc

A-613728 9 LH 3.740" / 95 MM 1.772" / 45 MM .139" / 3.5 MM .640" / 16.25 MM

For Models: 162 W/ Standard Disc

A-113269 9 RH 4.213" / 107 MM 1.772" / 45 MM .157" / 4 MM .716" / 18.2 MM

For Models: 1162, 1165, 2345, 2365

A-113268 9 LH 4.213" / 107 Mm 1.772" / 45 MM .157" / 4 MM .728" / 18.5 MM

For Models: 1162, 1165, 2345, 2365

A-604659 10 RH 4.724" / 120mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: 2310, 2330 SN <2226, DC1080, DC2350, DM140, DM160

A-604658 10 LH 4.724" / 120mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: 2310, 2330 SN <2226, DC1080, DC2350, DM140, DM160

A-612635 10 RH 4.213" / 107 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 2330 SN 2226>

A-612634 10 LH 4.213" / 107 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 2330 SN 2226>

A-126744 N/A 5.197" / 132mm 1.968" / 50mm .157" / 4mm .718" / 18.25mm

For Models: 2340, 2360

HESSTON

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-DM304 9 RH 3.858" / 98mm 1.575" / 40mm .157" / 4mm .640" / 16.25mm

For Models: 1030, 1040, 1050, 1060

A-DM303 9 LH 3.858" / 98mm 1.575" / 40mm .157" / 4mm .640" / 16.25mm

For Models: 1030, 1040, 1050, 1060

A-6616924 1 RH 4.134" / 105mm 1.850" / 47mm .118" / 3mm .827" / 21mm

For Models: 1180

A-748095 4 LH 4.134" / 105mm 1.850" / 47mm .118" / 3mm .827" / 21mm

For Models: 1180

A-700712888 9 RH 4.213" / 107mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: 1320, 1340

DISC MOWER BLADES

DISC MOWER BLADES

A-700711857 10 RH 4.213" / 107 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 1320, 1340

A-700711858 10 LH 4.213" / 107 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 1320, 1340

A-700712889 9 LH 4.213" / 107mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: 1320, 1340, 1360, 1365, 8500

A-784095 4 4.134" / 105mm 1.850" / 47mm .118" / 3mm .827" / 21mm

For Models: (DISC MOWERS: SEVERAL)

JOHN DEERE

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-CC19333 9 RH 3.600" 1.575" .118" .639"

For Models: 1314, 1315

A-CC19336 9 LH 3.600" 1.575" .118" .639"

For Models: 1314, 1315

A-CC20501 9 RH 3.740" / 95mm 1.772" / 45mm .139" / 3.5mm .640" / 16.25mm

For Models: 1314, 1315, 1320, 1326, 1327, 240, 260

A-CC20500 9 LH 3.740" / 95mm 1.772" / 45mm .139" / 3.5mm .640" / 16.25mm

For Models: 1314, 1315, 1320, 1326, 1327, 240, 260

A-CC21781 9 RH 4.843" / 123mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: 1326, 1327, 265 S/N 150001->, 270, 275 S/N 152001->

A-CC21780 9 LH 4.843" / 123mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: 1326, 1327, 265 S/N 150001->, 270, 275 S/N 152001->

A-CC26780 9 LH 4.213" / 107mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: 1350, 1360, 1460, 1470, 910, 920, 930

A-CC26781 9 RH 4.213" / 107mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: 1350, 1360, 1460, 1470, 910, 920, 930

JF

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-2220101B 1 3.543" / 90mm 1.772" / 45mm .157" / 4mm .807" - .946" / 20.5mm - 24.3mm

For Models: SEVERAL

KRONE

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-1466900 10 3.779" / 96mm 1.890" / 48mm .157" / 4mm .748" / 19mm

For Models: 202, 242, 282, AM167

A-1466910 10 3.779" / 96mm 1.890" / 48mm .157" / 4mm .748" / 19mm

For Models: 202, 242, 282, AM167

A-41474191 10 LH 3.701" / 94mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: 240, 241, 281

A-1473025 10 3.701" / 94mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: 240, 241, 281 S/N <-5549

A-1474195 10 3.701" / 94mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: 240, 241, 281 S/N <-5549

A-13712427 1 3.779" / 96mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

A-13722427 1 3.267" / 83mm 1.575" / 40mm .118" / 3mm .748"/ 19mm

For Models: DISC MOWER - CHECK DIM.

A-41410710 1 3.543" / 90mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

A-1466911 10 RH 3.779" / 96mm 1.890" / 50.4mm .157" / 4mm .748" / 19mm

For Models: AM167, AM202, AM242, AM282

A-1466901 10 LH 3.779" / 96mm 1.890" / 50.4mm .157" / 4mm .748" / 19mm

For Models: AM167, AM202, AM242, AM282

A-139889 4.409" 1.890" .157" .748"

For Models: 323 Shaft Drive

A-139888 4.409" 1.890" .157" .748"

For Models: 323 Shaft Drive

A-1446901 10 LH 3.78" / 96mm 1.93" / 49mm .16'" / 4mm .75" / 19mm

For Models: (DISC MOWER: SEVERAL)

A-1446911 10 RH 3.78" / 96mm 1.93" / 49mm .16'" / 4mm .75" / 19mm

For Models: (DISC MOWER: SEVERAL)

A-1458691 10 LH 3.66" / 93mm 1.85" / 47mm .12" / 3mm .75" / 19mm

For Models: (DISC MOWER: SEVERAL)

A-1458681 10 RH 3.66" / 93mm 1.85" / 47mm .12" / 3mm .75" / 19mm

For Models: (DISC MOWER: SEVERAL)

KUHN

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-55903310 9 RH 4.213" / 107mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: FC250, FC300, FC350, GMD400, GMD500, GMD600, GMD700, FC200 <1988, FC240, FC280

A-55903210 9 LH 4.213" / 107mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: FC250, FC300, FC350, GMD400, GMD500, GMD600, GMD700

A-56150000 1 3.779" / 96mm 1.575" / 40mm .118" / 3mm .640" / 16.25mm

For Models: GMD44, GMD55, GMD66

A-56151310 9 RH 3.740" / 95mm 1.772" / 45mm .139" / 3.5mm .640" / 16.25mm

For Models: (GMD44, GMD55, GMD66, GMD77 ALL W/ Standard Disc)

A-56151210 9 LH 3.740" / 95mm 1.772" / 45mm .139" / 3.5mm .640" / 16.25mm

For Models: (GMD44, GMD55, GMD66, GMD77 ALL W/ Standard Disc)

A-56151100 9 3.425" / 87mm 1.575" / 40mm .118" / 3mm .640" / 16.25mm

For Models: (GMD44HD, GMD55HD, GMD77HD ALL W/ Heavy Duty Disc)

A-56151200 9 LH 3.661" / 93mm 1.575" / 40mm .118" / 3mm .640" / 16.25mm

For Models: (GMD44HD, GMD55HD, GMD77HD, GMD66HD ALL W/ Heavy Duty Disc)

A-56151300 9 RH 3.661" / 93mm 1.575" / 40mm .118" / 3mm .640" / 16.25mm

For Models: (GMD44HD, GMD55HD, GMD66HD, GMD77HD ALL W/ Heavy Duty Disc)

A-56451200 9 RH 4.843" / 123mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: (GMD44HD, GMD55HD, GMD66HD, GMD77HD ALL W/ HD Disc)

A-56451300 9 RH 4.843" / 123mm 1.772" / 45mm .157" / 4mm .716" / 18.2mm

For Models: (GMD44HD, GMD55HD, GMD66HD, GMD77HD ALL W/ HD Disc)

A-56451210 9 4.843" / 123mm 1.772" / 45mm .160" / 4mm .716" / 18.2mm

For Models: (GMD44HD, GMD55HD, GMD66HD, GMD77HD ALL W/ HD Disc)

A-56450000 6 5.039" / 128mm 1.968" / 50mm .728" - .807" / 18.5mm - 20.5mm.728" - .807" / 18.5mm - 20.5mm

For Models: DISC MOWER - CHECK DIM.

A-56110300 6 5.039" / 128mm 1.968" / 50mm .807" - .905" / 20.5mm - 23mm.807" - .905" / 20.5mm - 23mm

For Models: DISC MOWER - CHECK DIM.

A-55906000 9 LH 4.566" / 116mm 1.772" / 45mm .716" / 18.2mm .716" / 18.2mm

For Models: DISC MOWER - CHECK DIM.

A-56450002 6 5.12" / 130mm 1.97" / 50mm .16" / 4mm .73x.81" / 18.5x20.5mm

For Models: (DISC MOWER: SEVERAL)

A-55906100 9 RH 4.566" / 116mm 1.772" / 45mm .716" / 18.2mm .716" / 18.2mm

For Models: DISC MOWER - CHECK DIM.

LONG

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-AMI11103 9 LH 3.78" / 96mm 1.61" / 41mm .12" / 3mm .75" / 19mm

For Models: 2007, 2008, 2009

A-AMI11104 9 RH 3.78" / 96mm 1.61" / 41mm .12" / 3mm .75" / 19mm

For Models: 2007, 2008, 2009

A-BCS31192R 10 RH 3.71" / 94mm 1.89" / 48mm .16" / 4mm .75" / 19mm

For Models: 2084, 2096

A-BCS31193L 10 LH 3.71" / 94mm 1.89" / 48mm .16" / 4mm .75" / 19mm

For Models: 2084, 2096

LELY

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-4120114730 10 LH 4.724" / 120mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: 165, 205, 240, 280, 320

A-4120114740 10 RH 4.724" / 120mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: 165, 205, 240, 280, 320

M & W

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-3238725 10 RH 3.94" / 100mm 1.77" / 45mm .16" / 4mm .79" / 20mm

For Models: HC5, HC6, HC7

A-3238726 10 LH 3.94" / 100mm 1.77" / 45mm .16" / 4mm .79" / 20mm

For Models: HC5, HC6, HC7

DISC MOWER BLADES

DISC MOWER BLADES

Marangon

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-05869921 10 3.937" / 100mm 1.85" / 47mm .157" / 4mm .826" / 21mm

For Models: (DISC MOWER: SEVERAL)

A-05870021 10 RH 3.937" / 100mm 1.85" / 47mm .157" / 4mm .826" / 21mm

For Models: SEVERAL

MASSEY FERGUSON

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-3730224M1 10 RH 4.724" / 120 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 125

A-3730223M1 10 LH 4.213" / 107 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 125

A-3730225M1 10 LH 4.724" / 120 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 127

A-3730226M1 10 RH 4.725" / 120 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 127

Mortl

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-6553L1 9 LH 3.86" / 98mm 1.85" / 47mm .12" / 3mm .91" / 23mm

For Models: SEVERAL

A-6553R1 9 RH 3.86" / 98mm 1.85" / 47mm .12" / 3mm .91" / 23mm

For Models: SEVERAL

A-T673L 10 LH 3.86" / 98mm 1.85" / 47mm .12" / 3mm .91" / 23mm

For Models: SEVERAL

A-T673R 10 RH 3.86" / 98mm 1.85" / 47mm .12" / 3mm .91" / 23mm

For Models: SEVERAL

NEW HOLLAND

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-853819 9 RH 4.213" / 107mm 1.772" / 45mm .157" / 4mm .728" / 18.5mm

For Models: 408, 411 SN 711816>, 412, 415

A-853820 9 LH 4.213" / 107mm 1.772" / 45mm .157" / 4mm .728" / 18.5mm

For Models: 408, 411, 412, 415

A-785609 9 RH 4.566" / 116mm 1.772" / 45mm .716" / 18.2mm .716" / 18.2mm

For Models: 411 S/N <-711815

A-785608 9 LH 4.566" / 116mm 1.772" / 45mm .716" / 18.2mm .716" / 18.2mm

For Models: 411 S/N <-711815

A-274097 9 RH 3.661" / 93mm 1.575" / 40mm .120" / 3mm .640" / 16.25mm

For Models: 442 SN < Z4750, 452, 462 SN < Z1643

A-274096 9 LH 3.661" / 93mm 1.575" / 40mm .120" / 3mm .640" / 16.25mm

For Models: 442 SN < Z4750, 452, 462 SN < Z1643

A-274230 1 3.779" / 96mm 1.575" / 40mm .120" / 3mm .640" / 16.25mm

For Models: 442, 462

A-697551 6 5.039" / 128mm 1.968" / 50mm .160" / 4mm .807" - .905" / 20.5mm - 23mm

For Models: 442, 462

A-766727 9 RH 3.740" / 95mm 1.772" / 45mm .140" / 3.6mm .640" / 16.25mm

For Models: (442, 452, 462 ALL W/ Standard Disc)

A-766726 9 LH 3.740" / 95mm 1.772" / 45mm .140" / 3.6mm .640" / 16.25mm

For Models: (442, 452, 462 ALL W/ Standard Disc)

A-784221 9 RH 4.843" / 123mm 1.772" / 45mm .160" / 4mm .716" / 18.2mm

For Models: (442, 452, 462, 463, 465 ALL W/ Heavy Duty Disc)

A-784220 9 LH 4.843" / 123mm 1.772" / 45mm .160" / 4mm .716" / 18.2mm

For Models: (442, 452, 462, 463, 465 ALL W/ Heavy Duty Disc)

NEW IDEA

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-526216NI 10 LH 4.724" / 120 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: 526, 527, 528, (5209, 5212 ALL SN 9756-16012), (5406, 5407, 5408, 5409 ALL SN 1001159-1007480)

A-527746NI 10 RH 4.750" / 121mm 2.000" / 50.8mm .889" / 22.6mm .889" / 22.6mm

For Models: (5209, 5212 ALL SN 16013>), 5312, (5406, 5407, 5408, 5410 ALL SN 1007482>)

A-527747NI 10 LH 4.750" / 121mm 2.000" / 50.8mm .889" / 22.6mm .889" / 22.6mm

For Models: (5209, 5212 ALL SN 16013>), 5312, (5406, 5407, 5408, 5410 ALL SN 1007482>)

A-527748NI 9 RH 4.750" / 121 MM 2.000" / 50.8 MM .157" / 4 MM .889" / 22.6 MM

For Models: (5209, 5212 ALL SN 16013>), 5406, 5407, 5410

A-526215NI 10 RH 4.724" / 120 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: (5209, 5212 ALL SN 9756-16012), 526, 527, 528, (5406, 5407, 5408, 5409 ALL SN 1001159-1007480)

A-527749NI 9 LH 4.750" / 121 MM 2.000" / 50.8 MM .157" / 4 MM .889" / 22.6 MM

For Models: 5406, 5407, 5410, (5209, 5212 ALL SN 16013>)

NIEMEYER

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-1448261 10 RH 3.543" / 90mm 1.937" / 49mm .157" / 4mm .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

A-1448251 10 LH 3.543" / 90mm 1.937" / 49mm .157" / 4mm .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

A-41473021 10 RH 3.701" / 94mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

Reese

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-UFO141 9 4.02" / 102mm 1.77" / 45mm .16" / 4mm .68" / 17.25mm

For Models: (DISC MOWER: SEVERAL)

RHINO

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-65948 9 LH 4.343" / 110mm 1.850" / 47mm .118" / 3mm .827" / 21mm

For Models: SEVERAL

A-65947 9 RH 4.343" / 110mm 1.850" / 47mm .118" / 3mm .827" / 21mm

For Models: SEVERAL

SITREX

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-21009431 9 RH 3.740" / 95 MM 1.772" / 45 MM .139" / 3.5 MM .640" / 16.25 MM

For Models: SEVERAL Check Dimensions

A-21009432 9 LH 3.740" 1.772" .139" .640"

For Models: SEVERAL Check Dimensions

SCHMITZ

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-1002268 1 3.779" / 96 MM 1.575" / 40 MM .118" / 3 MM .748" / 19 MM

For Models: SEVERAL Check Dimensions

TAARUP

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-56110300 6 5.039" / 128mm 1.968" / 50mm .807" - .905" / 20.5mm - 23mm.807" - .905" / 20.5mm - 23mm

For Models: 204, 205, 206

A-16530208 6 5.039" / 128mm 1.968" / 50mm .157" / 4mm .728" - .807" / 18.5mm - 20.5mm

For Models: 204, 205, 206

A-58372000 1 4.291" / 107mm 1.575" / 40mm .118" / 3mm .807" / 20.5mm

For Models: DISC MOWER - CHECK DIM.

A-90261560 10 RH 4.213" / 107mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: DISC MOWER - CHECK DIM.

A-90261559 10 LH 4.213" / 107mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: SEVERAL Check Dimensions

A-56110400 9 LH 4.96" / 126mm 1.89" / 48mm .16" / 23mm .81x.91" / 20.5x23mm

For Models: (DISC MOWER: SEVERAL)

A-56110900 9 RH 4.96" / 126mm 1.89" / 48mm .16" / 23mm .81x.91" / 20.5x23mm

For Models: (DISC MOWER: SEVERAL)

TAS

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-121712 10 LH 3.858" / 98mm 1.890" / 48mm .157" / 4mm .748" / 19mm

For Models: (DISC MOWERS: SEVERAL)

A-121713 10 RH 3.858" / 98mm 1.890" / 48mm .157" / 4mm .748" / 19mm

For Models: (DISC MOWERS: SEVERAL)

DISC MOWER BLADES

VICON

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-90261560 10 RH 4.213" / 107mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: AM2800, CM216, CM217, CM2200, DMP2800, KM281 Late Model W/ 3 Blades Per Disc, GMR2800, KM216, KM391CP, OM216, OM281

A-90261559 10 LH 4.213" / 107mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: AM2800, CM216, CM217, CM2200, DMP2800, KM281 Late Model W/ 3 Blades Per Disc, GMR2800, KM391CP, OM216, OM281

A-58699 10 LH TWST 4.724" / 120mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: AM3200, CM165, CM167, CM1700, CM240, CM2400, CM247, DMP2400, DMP3200, KM240, KM241, KM281 Early Model W/ 2 Blades Per Disc, KM321

A-58700 10 RH TWST 4.724" / 120mm 1.890" / 48mm .157" / 4mm .728" / 18.5mm

For Models: AM3200, CM165, CM167, CM1700, CM240, CM2400, CM247, CMP3200, DMP2400, KM240, KM241, KM281 Early Models W/ 2 Blades Per Disc, KM321

A-90258699 10 LH 4.724" / 120 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: CM165, CM167, CM240, CM247, GMR2400, GMR3200, KM165, KM240, KM241, KM321, OM165, OM241

A-90258700 10 RH 4.724" / 120 MM 1.890" / 48 MM .157" / 4 MM .728" / 18.5 MM

For Models: CM165, CM167, CM240, CM247, GMR2400, GMR3200, KM165, KM240, KM241, KM321, OM165, OM241

VERMEER

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-CM120 4 4.134" / 105mm 1.850" / 47mm .118" / 3mm .827" / 21mm

For Models: SEVERAL Check Dimensions

A-MT452S 1 3.779" / 96 MM 1.575" / 40 MM .118" / 3 MM .748" / 19 MM

For Models: SEVERAL Check Dimensions

A-MT52 1 3.543" / 90mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: SEVERAL

WELGER

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-0982150100 1 3.543" / 90mm 1.575" / 40mm N/A .748" / 19mm

For Models: DISC MOWER - CHECK DIM.

ZWEEGER

PA R T TYPE LENGTH WIDTH THICKNESS HOLE DIA.

A-CM15 1 4.134" / 105mm 1.850" / 47mm .118" / 3mm .827" / 21mm

For Models: 135, 164, 166, 167, 168, 170, 184, 210, CM215

A-CM120 4 4.134" / 105mm 1.850" / 47mm .118" / 3mm .827" / 21mm

For Models: 212, 220, 211, 264, CM135, CM166, CM167, CM168, CM170, CM210

A-DM303 9 LH 3.858" / 98mm 1.575" / 40mm .157" / 4mm .640" / 16.25mm

For Models: 230, 265, 275, 320

A-DM304 9 RH 3.858" / 98mm 1.575" / 40mm .157" / 4mm .640" / 16.25mm

For Models: 230, 265, 275, 320

A-MT52S 1 3.543" / 90mm 1.575" / 40mm .118" / 3mm .748" / 19mm

For Models: 230, 265, 275, 320

A-TF71 10 LH 3.7" / 94mm 1.89" / 48mm .12" / 3mm .75" / 19mm

For Models: CM184, CM185, CM186, CM187, CM189, CM190, CM230, CM265, CM270

A-TF70 10 RH 3.7" / 94mm 1.89" / 48mm .12" / 3mm .75" / 19mm

For Models: CM184, CM185, CM186, CM187, CM189, CM190, CM230, CM265, CM270

A-TT97 9 3.78" / 96mm 1.58" / 40mm .12" / 19mm .75" / 19mm

For Models: CM185H

A-DM160 9 RH 3.661" / 93 MM 1.575" / 40 MM .118" / 3 MM .640" / 16.25 MM

For Models: SEVERAL Check Dimensions

A-DM155 9 LH 3.661" / 93 MM 1.575" / 40 MM .118" / 3 MM .640" / 16.25 MM

For Models: SEVERAL Check Dimensions

A-MT452S 1 3.779" / 96 MM 1.575" / 40 MM .118" / 3 MM .748" / 19 MM

For Models: SEVERAL Check Dimensions

A-M452S 9 3.78" / 96mm 1.57" / 40mm .12" / 3mm .75" / 19mm

For Models: (DISC MOWER: SEVERAL)

DISC MOWER BLADES

DISC MOWER BLADE BOLTS & NUTS

A-76N929 Blade Bolt & Nut

BUSH HOG SEVERAL

A-76N924 Blade Bolt & Nut

GEHL SEVERAL

A-76N927 Blade Bolt & Nut

NEW HOLLAND 442, 452, 462

A-76N927 Blade Bolt & Nut

JOHN DEERE CUTTER PARTS

A-76N928 Blade Bolt & Nut

JOHN DEERE CUTTER PARTS

A-76N927 Blade Bolt & Nut

KUHN SEVERAL

A-76N928 Blade Bolt & Nut

KUHN SEVERAL

A-76N929 Blade Bolt & Nut

NEW IDEA SEVERAL

A-56294000 Blade Bolt & Nut

TAARUP SEVERAL

A-76N924 Blade Bolt & Nut

VICON SEVERAL

A-475219 Blade Bolt & Nut

Used w/blade holder 121248

FELLA KM166A, KM191, KM192A

A-126287 Blade Bolt & Nut

Used w/blade holder 122181

FELLA SM215, SM216

A-477274 Blade Bolt & Nut

Used w/blade holder 477263

FELLA FKM180, FKM2, FKM2H

A-475219 Blade Bolt & Nut

Used w/blade holder 121248

FELLA KM166A, KM191, KM192A

A-124508 Bolt, Disc Mower

Used w/ 475219 nut, Fits 121248 Blade Holder

FELLA KM166A, KM191, KM192A

A-122181K Blade Bolt/Nut Kit

Consists of 122181 Bolt & 126287 Nut

FELLA SM215, SM216

A-90081160K Blade Bolt, Nut Kit

Consists of 90081160 Bolt & 30577100 Nut

FAHR SM2.17, SM2.21, SM2.24, SM3.24, SM3.28

A-06568555K Blade Bolt, Nut Kit

FAHR SEVERAL

A-478415K Blade Bolt, Nut Kit

Consists of Bolt & Nut

FELLA SEVERAL

A-01141150 Knife Bolt

FAHR SM45

A-06561225 Knife, Special Nut

Used w/ 01141150 Bolt

FAHR SM45

A-477263 Bolt, Disc Mower Blade

Uses 477274 Nut

FELLA FKM180, FKM2, FKM2H

A-477274 Nut, Blade Bolt

Used w/ 477263 Bolt

FELLA FKM180, FKM2, FKM2H

A-KBL760 Knifehead Bolts/Locknuts, 1-1/4” (25 pc./each)

1-1/4” Grade 8, Rib Neck Bolt,

Package of 25 pcs./Each of Bolts & Locknuts.

Misc. SEVERAL Knifeheads Requiring 1-1/4” Bolts

BLADE DISC

A-DC19535 Disc

JOHN DEERE 240, 260

A-56200700 Disc

KUHN GMD55, GMD66, GMD77, GMD44

A-56452100 Heavy Duty Disc

KUHN GMD55HD, GMD66HD, GMD77HD

A-56808200 Disc Mower Blade

KUHN GMD500, GMD600, GMD700

A-274117 Disc

NEW HOLLAND 442, 452, 462

A-1019894 Disc

VICON CM165 Series 14034 & 14037, CM240 Series 14039,

CM247

BLADE HOLDERS

A-1101701055000 Blade Holder

DIXIE SEVERAL

A-9210651 Blade Holder

CLAAS WM20, WM24, WM26, WM31F

A-9474271 Blade Holder

CLAAS CORTO 290F, WM165, WM185

DISC MOWER PARTS

A-9484591 Blade Holder

CLAAS CORTO 165, CORTO 185, CORTO 210, CORTO 300,

WM210

A-121248 Blade Holder

FELLA KM166A, KM191, KM192A

A-06563514 Blade Holder

FAHR KM20, KM22, KM24, KM25

A-06580109 Blade Holder

FAHR KM20, KM22, KM24, KM25

A-EU056 Blade Holder

FAHR KM3.23S, KM3.23STC

A-PZ0243 Blade Holder

FAHR KM3.21FS, KM3.21S

A-PZ116 Blade Holder

ZWEEGER 185

A-PZ0250 Blade Holder

ZWEEGER SEVERAL

SKID PLATE

A-ZA526875 Skid Plate

CASE-IH 3309

A-ZA526438 Skid Plate

CASE-IH 3204, 3205, 3206

A-56330200 Skid Plate Weld on Pad

KUHN GMD55, GMD55HD, GMD66, GMD66HD, GMD77,

GMD77HD

GUARDS

A-56205800 Inner Shoe Guard

JOHN DEERE 240, 260

A-56205802 Inner Shoe Guard

KUHN (44, 55, 66 ALL w/o adjustable bolt)

A-56205800 Inner Shoe Guard

KUHN GMD44 SN 784792>, GMD55 SN 780101>, GMD66 SN

760501>, GMD66HD, GMD77HD

A-56990603 Stone Guard

KUHN GMD44, GMD55 SN 780101>, GMD55HD, GMD66,

GMD66HD, GMD77, GMD77HD

A-56801420 Stone Guard

KUHN GMD500, (GMD600, GMD700 ALL SN 940001>)

A-781810 Inner Shoe Guard

NEW HOLLAND 442, 452, 462, 463, 465

A-781809 Stone Guard

NEW HOLLAND 442, 452, 462, 463, 465

A-781810NH Inner Shoe Guard

NEW HOLLAND 442, 462, 463

A-781809NH Stone Guard

NEW HOLLAND 442, 462, 463

DISC MOWER PARTS

STONE GUARDS

A-56190600 Stone Guard

JOHN DEERE (240, 260 ALL w/ adjustable bolt)

A-90015853 Center Stone Guard

VICON CM240 Series 14039 Except 1st & 2nd Outer Disc

A-90015923 End Stone Guard

VICON CM165 Series 14034 & 14037 On All Knife Discs, CM205

Series 14028 On All Knife Discs, CM240 Series 14039 On 1st &

2nd Outer Knife Disc

A-186-13456 Stone Gaurd

VICON (CM165, CM167, CM240, CM247 ALL new style)

A-186-13457 Stone Gaurd

VICON (CM216, CM217 ALL new style)

SKID PLATE

A-526875 Disc Mower Skid Plate

NEW IDEA 5406, 5407, 5408, 5409, 5209, 5212

A-526438 Disc Mower Skid Plate

NEW IDEA (526, 527, 528 ALL <-1989)

A-90062054 Skid Plate

VICON CM165 Series 14023, CM240 Series 14024

A-90066591 Skid Plate

VICON CM165 Series 14034 & 14037, CM205 Series 14028,

CM240 Series 14039

LOCK NUT

A-99307816 Lock Nut

TAARUP ALL MODELS

DISC MOWER PARTS

DISC MOWER CURTAINS

BUSH HOG

PART DESCRIPTION LENGTH WIDTH

A-84152 Disc Mower Curtain

93.120" 44.940"

For Models: (DISC MOWER: DM7 7 Ft. Curtain)

A-84153 Disc Mower Curtain

105.210" 44.940"

For Models: (DISC MOWER: DM8 8 Ft. Curtain)

A-84154 Disc Mower Curtain

123.120" 44.940"

For Models: (DISC MOWER: DM9 9 Ft. Curtain)

KUHN

PART DESCRIPTION LENGTH WIDTH

A-56165000 Disc Mower Curtain

56.500" 42.500"

For Models: (DISC MOWER: GMD44)

A-56221000 Disc Mower Curtain

71.880" 42.500"

For Models: (DISC MOWER: GMD55)

A-56206600 Disc Mower Curtain

86.810" 42.500"

For Models: (DISC MOWER: GMD66)

A-56224300 Disc Mower Curtain

100.000" 42.500"

For Models: (DISC MOWER: GMD77)

LELY

PART DESCRIPTION LENGTH WIDTH

A-4120114990 Disc Mower Curtain

72.880" 44.500"

For Models: (DISC MOWER: 165)

A-4120214970 Disc Mower Curtain

89.500" 44.500"

For Models: (DISC MOWER: 205)

A-4120314960 Disc Mower Curtain

103.380" 44.500"

For Models: (DISC MOWER: 240)

A-41201014990 Disc Mower Curtain

119.880" 44.500"

For Models: (DISC MOWER: 280)

A-4121901950 Disc Mower Curtain

133.380" 44.500"

For Models: (DISC MOWER: 320)

M & W

PART DESCRIPTION LENGTH WIDTH

A-772637 Disc Mower Curtain

84.300" 36.610"

For Models: (DISC MOWER: HC5)

A-772638 Disc Mower Curtain

97.240" 36.610"

For Models: (DISC MOWER: HC6)

A-772639 Disc Mower Curtain

105.120" 36.610"

For Models: (DISC MOWER: HC7)

NEW HOLLAND

PART DESCRIPTION LENGTH WIDTH

A-86622313 Disc Mower Curtain

95.330" 51.630"

For Models: (DISC MOWER: 615)

A-86622314 Disc Mower Curtain

109.500" 51.630"

For Models: (DISC MOWER: 616)

A-86622315 Disc Mower Curtain

125.250" 51.630"

For Models: (DISC MOWER: 617)

NEW IDEA

PART DESCRIPTION LENGTH WIDTH

A-526791 Disc Mower Curtain

73.100" 43.300"

For Models: (DISC MOWER: 5406)

A-526792 Disc Mower Curtain

88.810" 43.300"

For Models: (DISC MOWER: 5407)

A-526793 Disc Mower Curtain

102.630" 43.300"

For Models: (DISC MOWER: 5408)

A-526794 Disc Mower Curtain

119.000" 43.300"

For Models: (DISC MOWER: 5409)

RHINO

PART DESCRIPTION LENGTH WIDTH

A-772637 Disc Mower Curtain

84.300" 36.610"

For Models: (DISC MOWER: DM82)

A-772638 Disc Mower Curtain

97.240" 36.610"

For Models: (DISC MOWER: DM95)

A-772639 Disc Mower Curtain

105.120" 36.610"

For Models: (DISC MOWER: DM112)

VICON

PART DESCRIPTION LENGTH WIDTH

A-97884569 Disc Mower Curtain

69.500" 45.000"

For Models: (DISC MOWER: CM165 Series 14013, 20, 23, 26, 34, 54, 26, 34 & 54)

A-97884570 Disc Mower Curtain

95.500" 44.500"

For Models: (DISC MOWER: CM216 Series 14031, 14038, 14044, 14048 & 14055)

A-90083107 Disc Mower Curtain

A-90081590 Disc Mower Curtain

101.000" 44.500"

For Models: (DISC MOWER: CM240 Series 14027)

A-97884571 Disc Mower Curtain

106.000" 44.500"

For Models: (DISC MOWER: CM240 Series 14035, 14039, 14052 & 14056)

A-B1310578 Disc Mower Curtain

60.380" 45.000"

For Models: (DISC MOWER: CM144)

A-1108993 Disc Mower Curtain

74.750" 45.000"

For Models: (DISC MOWER: CM166 Series 14030)

BUSH HOG

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-67743BH CW lift 17.125" 1.500" 4.00" .500" 14.625" 2.500"

For Models: (1268, 268 ALL 8 Ft. Mowers, LH)

A-67744BH CCW lift 17.125" 1.500" 4.00" .500" 14.625" 2.500"

For Models: (1268, 268 ALL 8 Ft. Mowers, RH), SQ84 Squealer 7 Ft. Mower

A-7828BH CW lift 19.250" 1.500" 4.00" .500" 16.750" 2.500"

For Models: 109, 109 OFFSET, 1109, 1109 OFFSET, 1166, 1209, 12512, 13108, 13108 OFFSET, 160, 1600, 166, 2512, 3108, 3108 OFFSET, 3209, 3209 OFFSET

A-7829BH CW lift 19.250" 1.500" 4.00" .500" 16.750" 2.500"

For Models: 109, 1109, 1166, 1209, 12512, 13108, 160, 1600, 166, 2512, 3108, 3209

A-86664BH CCW lift 20.750" 1.500" 4.000" .500" 18.250" 2.500"

For Models: 13368, 3214, 3368

A-86665BH CW lift 20.750" 1.500" 4.000" .500" 18.250" 2.500"

For Models: 13368, 3214, 3368

A-78494BH CW lift 24.000" 1.500" 4.000" .500" 21.500" 2.500"

For Models: 13126R, 13126S, 3126R, 3126S

A-78495BH CCW lift 24.000" 1.500" 4.000" .500" 21.500" 2.500"

For Models: 13126R, 13126S, 3126R, 3126R Offset, 3126S, 3126S Offset

A-90015BH CCW lift 24.000" 1.500" 4.000" .500" 21.500" 2.500"

For Models: 3126, 3210

A-90014BH CW lift 24.000" 1.500" 4.000" .500" 21.500" 2.500"

For Models: 3126, 3210

A-81395BH CCW 24.625" 1.265" 3.000" .375" 22.125" 2.375"

For Models: RAZORBACK RZ60

A-262BH CCW 24.750" 1.500" 3.500" .500" 22.125" 2.000"

For Models: SEVERAL

A-63968BH CW/CCW 24.750" 1.500" 3.000" .500" 22.250" 2.000"

For Models: SM160, SM60

A-462BH CCW 24.750" 1.500" 3.000" .500" 22.250" 2.000"

For Models: 105, 12, 205, 255, 266, 305, 502, 600, RB60, SQ60, SQ600-3, SQ60-5

A-11150BH CW lift 24.750" 1.500" 4.000" .500" 22.250" 2.500"

For Models: 1126, 1226, 126, (12610, 12615 ALL LH), 1315, 2315, 2415, 2510, (2610, 2615 ALL LH), 315, (3610, 3615 ALL LH)

A-36ULBH CCW 24.750" 1.500" 3.000" .500" 22.250" 2.000"

For Models: 105, 12, 205, 255, 266, 305, 502, 6, 600, RB60

A-36BH 24.750" 1.500" 3.000" .500" 22.250" 2.000"

For Models: 105, 12, 205, 255, 266, 305, 502, 6, 600, RB60

A-7555BH CCW lift 24.750" 1.500" 4.000" .500" 22.250" 2.500"

For Models: 105, 1126, 1126 OFFSET, 12, 1226, 126, 126 OFFSET, 12610 RH, 12615, 1310, 1315, 205, 206, 2315, 2415, 2510, 255, 2610 RH, 2615, 266, 275, 285, 305, 310, 315,

3610 RH, 3615, 502, 600, RB60, SQ60, SQ600-3, SQ60-5

A-7278BH CCW 27.750" 2.000" 5.000" .625" 25.250" 2.625"

For Models: (1406, 406 ALL Extra Heavy Duty Blade)

A-304BH CCW 27.750" 1.500" 3.000" .500" 25.250" 2.000"

For Models: 1206, 206, 306, SQ72-4

A-463BH CCW lift 27.750" 1.500" 3.500" .500" 25.250" 2.000"

For Models: 1206, 1256, 206, 256, 306, SQ720, SQ720-3, SQ72-4

ROTARY CUTTER BLADES

A-7556BH CCW lift 27.750" 1.500" 4.000" .500" 25.250" 2.500"

For Models: 1206, 1256, (12610, 12615, 1310, 1315 ALL Center), 206, (2315, 2415 ALL Center), 256, (2610, 2615 ALL Center), 276, 286, 306, (310, 315, 3610, 3615 ALL Center),

SQ720, SQ720-3, SQ72-4

A-7557BH CCW lift 30.750" 1.500" 4.000" .500" 28.250" 2.500"

For Models: 1207, 1220 Center & RH, 1257, 1287, 1307, 207, 220 Center & RH, 257, 2620 Center & RH, 277, 287, 307, SQ7, SQ840

A-67327BH CCW 30.750" 1.500" 3.000" .500" 28.250" 2.500"

For Models: SQ72, SQ72-2, SQ72-3

A-464BH CCW 30.750" 1.500" 3.500" .500" 28.250" 2.000"

For Models: 1207, 1257, 1307, 207, 257, 307

FORD

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-220633 CCW 22.000" 1.500" 3.000" .375" 20.500" 2.000"

For Models: 22-100, 22-111, 22-112, 22-113, 22-117, 22-118, 22-119, 22-127, 22-127A, 22-140, 22-141, 22-171, 22-172, 22-176, 22-177, 22-178, 22-179, 22-194, 22-195, 22-196,

22-197, 22-198, 22-199, 22-220, 22-221, 22-222, 22-223, 22-47, 22-60, 22-70, 22-99, 505, 901, 908, 909, 910

A-221854 CCW twist 22.250" 1.500" 3.000" .375" 20.500" 2.000"

For Models: 22-111, 22-113, 22-127, 22-127A, 22-140, 22-141, 22-171, 22-172, 22-176, 22-177, 22-178, 22-179, 22-196, 22-197, 22-198, 22-199, 22-47, 22-60, 22-70, 505, 901, 908,

909, 910

FRED CAIN

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-72280 CCW lift 19.750" 1.500" 4.000" .500" 16.750" 2.500"

For Models: ROTARY MOWER - CHECK DIM.

A-360 CCW 24.750" 1.500" 3.000" .500" 22.250" 2.000"

For Models: ROTARY MOWER - CHECK DIM.

A-360UL CCW lift 24.750" 1.500" 3.000" .500" 22.250" 2.000"

For Models: ROTARY MOWER - CHECK DIM.

A-4620 CCW 24.750" 1.500" 3.500" .500" 22.250" 2.000"

For Models: ROTARY MOWER - CHECK DIM.

A-3040 CCW 27.750" 1.500" 3.000" .500" 25.250" 2.000"

For Models: ROTARY MOWER - CHECK DIM.

A-4630 CCW 27.750" 1.500" 3.500" .500" 25.250" 2.000"

For Models: ROTARY MOWER - CHECK DIM.

A-4640 CCW 30.750" 1.500" 3.500" .500" 28.250" 2.000"

For Models: ROTARY MOWER - CHECK DIM.

HICO

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-420HC CCW 24.750" 1.500" 3.500" .500" 22.125" 2.000"

For Models: 5 FT. ROTARY MOWERS

A-420UL CCW lift 24.750" 1.500" 3.500" .500" 22.125" 2.000"

For Models: 5 FT. ROTARY MOWERS

A-422HC CCW 27.750" 1.500" 3.500" .500" 25.250" 2.000"

For Models: 6 FT. ROTARY MOWER

HARDEE

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-C1256 CCW lift 18.750" 1.500" 3.500" .500" 16.500" 2.000"

For Models: T8398

A-C1257 CW lift 18.750" 1.500" 3.500" .500" 16.500" 2.000"

For Models: T8398

A-C49HDRC CCW 22.750" 1.500" 3.500" .500" 20.250" 2.750"

For Models: (H-CO, T160, T160LT, T160LTO, T166, T166LT, T166LTO, T172, T172LT, T172LTO ALL Heavy Duty, Except 66" & 72" W/ Round Blade Holder)

A-C49A CCW 23.000" 1.500" 3.000" .500" 20.500" 3.000"

For Models: 52LT, 60LT, 60LTO, 66LT, 66LTO, 72LT, H360CO, HS260CO, T160LT, T160LTO, T166LT, T166LTO, T172LT, T172LTO

A-C49RC CCW 23.000" 1.500" 3.000" .500" 20.500" 2.500"

For Models: (H-CO, T160, T160LT, T160LTO, T166, T166LT, T166LTO, T172, T172LT, T172LTO ALL Except 66" & 72" W/ Round Blade Holder)

A-C49ND CW/CCW 23.000" 1.500" 3.000" .500" 20.500" 2.500"

For Models: (H-CO, T160, T160LT, T160LTO, T166, T166LT, T166LTO, T172, T172LT, T172LTO ALL Except 66" & 72" W/ Round Blade Holder)

A-C469ND CW/CCW 26.000" 1.500" 3.500" .500" 23.500" 3.000"

For Models: (C66, H8, PW, T8215 ALL W/ Round Blade Holder)

A-C1169L CCW 26.000" 1.500" 3.500" .500" 23.500" 3.000"

For Models: (H8115AIS, T8215PTW ALL For 66" Mower W/ Round Blade Holder)

ROTARY CUTTER BLADES

A-C1169R CW 26.000" 1.500" 3.500" .500" 23.500" 3.000"

For Models: (H8115AIS, T8215PTW ALL For 66" Mower W/ Round Blade Holder)

A-C470 CCW 28.750" 1.500" 3.500" .500" 26.250" 2.500"

For Models: (772, T484LT, T484PT, T884LT, T884PT ALL W/ Round Blade Holder)

IMCO

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-10751 CCW 24.750" 1.500" 3.000" .500" 22.250" 2.000"

For Models: ROTARY MOWER - CHECK DIM.

A-10751UL CCW lift 24.750" 1.500" 3.000" .500" 22.250" 2.000"

For Models: ROTARY MOWER - CHECK DIM.

JOHN DEERE

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-W45327 CCW 21.500" 1.500" 4.000" .500" 19.500" 3.000"

For Models: (CX15, CX20 ALL Center & RH Wing), HX10, (HX15, HX20 ALL Center & RH Wing), MX10, MX5, MX6

A-W45326 CW 21.500" 1.500" 4.000" .500" 19.500" 3.000"

For Models: (CX15, CX20 ALL LH Wing), HX10, (HX15, HX20 ALL LH Wing), MX10

A-W34286 CW/ CCW 11.00" 1.250" 3.000" 9.500" 0.250" 0.250"

For Models: 205, 227, 307

A-W43048 21.750" 1.500" 4.000" 19.750" 2.750" Flat Offset

For Models: 1008, 1508, 509, 609, 709

A-80A39201 CCW 21.875" 1.500" 4.000" .500" 19.750" 2.500"

For Models: 1008, 1508, 727, 737

A-W43040 CCW 21.875" 1.500" 4.000" .500" 19.750" 2.500"

For Models: 1008, 1508, 509, 609, 709, 727, 737

A-80A39204 18.25" 1.500" 4.000" 16.25" 2.750" Flat Offset

For Models: 1408, 1418

LAND PRIDE

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-820-075C 27" 1.500" 3.000" .500"

For Models: 35120

A-820-075C 27" 1.500" 3.000" .500"

For Models: 35120

A-820-067C CW 24" 1.500" 3.000" .500" 2.000”

For Models: 1560, 2560

A-820-066C CW 30.5" 1.500" 3.000" .500" 2.000”

For Models: 1572, 2572, 2584

MONO

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-850500 CCW 25.000" 1.500" 3.000" .500" 22.500" 2.000"

For Models: 5 FT. ROTARY MOWERS

A-850500UL CCW lift 25.000" 1.500" 3.000" .500" 22.500" 2.000"

For Models: 5 FT. ROTARY MOWERS

RHINO

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-37118 CCW lift 18.750" 1.375" 3.625" .500" 17.000" flat

For Models: SEVERAL

A-681063 CW/CCW 19.125" 1.375" 4.000" .500" 17.125" 1.750"

For Models: 1310

A-0731340000 CW lift 19.750" 1.000" 3.000" .375" 18.000" 4.500"

For Models: SATURN 8

A-0731350000 CCW lift 19.750" 1.000" 3.000" .375" 18.000" 4.500"

For Models: SATURN 8

A-00753841 CW lift 19.875" 1.500" 3.500" .500" 17.375" 2.500"

For Models: TW96 RH

A-00753842 CCW lift 19.875" 1.500" 3.500" .500" 17.375" 2.500"

For Models: TW96 LH

ROTARY CUTTER BLADES

A-8589 CCW lift 20.125" 1.500" 4.000" .500" 18.125" 2.500"

For Models: A960, TW60

A-8590 CW lift 20.125" 1.500" 4.000" .500" 18.250" 2.250"

For Models: SR15, TW120

A-00759338 CW lift 21.500" 1.375" 4.000" .500" 19.500" 3.000"

For Models: SR15 LH Wing Blade

A-00759339 CCW lift 21.500" 1.375" 4.000" .500" 19.500" 3.000"

For Models: SR15 RH Wing Blade

A-652011R CW 24.500" 1.375" 4.000" .500" 22.500" 3.562"

For Models: 1008 FLEX 15

A-622013 CCW 24.500" 1.375" 4.000" .500" 22.500" 3.562"

For Models: 1008 FLEX 15, CYCLONE 60

A-0652010030 CW/CCW 24.500" 1.391" 4.000" .500" 22.500" 3.562"

For Models: CYCLONE 60, FLEX 15, GR60, S128

A-622013F CCW lift 24.750" 1.375" 4.000" .500" 22.500" 3.562"

For Models: (1008, CY60, FLEX 15, SA15 ALL LH)

A-652011RF CW lift 24.750" 1.375" 4.000" .500" 22.500" 3.562"

For Models: (1008, FLEX 15, SA15 ALL RH)

A-8588 CCW lift 26.250" 1.500" 4.000" .500" 24.250" 2.500"

For Models: A972, TW144, TW72

A-71103 CCW lift 24.500" 1.0625" 3.000" .375" 22.750" 3.000"

For Models: SEVERAL

A-582013 CCW 27.000" 1.375" 4.000" .500" 25.500" 3.250"

For Models: CYCLONE 72 Main Blade, FLEX 15 Center Blade

A-582013F CCW 27.750" 1.375" 4.000" .500" 25.500" 3.250"

For Models: 1008 Center, CY72, (FLEX 15, SA15 ALL Center)

SCHULTE

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-401-014 CCW Lift 24.750" 1.500" 4.000" .500" 22.250" 2.500"

For Models: SEVERAL Check Dimensions

A-401-015 CCW Lift 27.750" 1.500" 4.000" .500" 25.250" 2.500"

For Models: SEVERAL Check Dimensions

A-401-013 CW Lift 27.750" 1.500" 4.000" .500" 22.250" 2.500"

For Models: SEVERAL Check Dimensions

A-401-028 CW 27.750" 1.500" 4.000" .500" 2.750”

For Models: 5026 Center, Suction, 5026 RH Inner, Suction, V1280 RH

A-401-027 CW 24.750" 1.500" 4.000" .500" 2.750”

For Models: 5026 RH Outer, Suction, (S100, XH1000 All RH)

A-401-026 CCW 24.750" 1.500" 4.000" .500" 2.750”

For Models: 5026 LH Outer, Suction, (S100, XH1000 All RH)

A-401-032 CCW 27.750" 1.500" 4.500" .500" 2.750”

For Models: 5026 LH Inner, Suction, S100 Center, V1280 LH, XH1000 Center, XH600

A-401-033 24.750" 1.500" 4.000" .375"

For Models: 5026 RH Outer, Uppper & LH Outer, Upper

A-401-034 27.750" 1.500" 4.000" .375"

For Models: 5026 RH/LH Inner, Upper & Center, Upper

A-401-036 8.812" 1.000" 3.000" .500"

For Models: V1280 Center

SIDEWINDER

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-21301SW CW/CCW 17.375" 1.500" 3.000" .375" 15.375" 2.000"

For Models: GB-50, SX-50

A-15074SW CCW 20.250" 1.500" 3.500" .500" 17.750" 4.500"

For Models: GB144, GB48, RS160, RS213, SW66

A-17065SW CCW 22.375" 1.500" 3.000" .375" 20.375" 2.000"

For Models: 5X5, K-60, SX-60

A-15096SW CCW 22.750" 1.500" 3.500" .500" 20.250" 2.750"

For Models: 605, 660, GB60, GB602, SW72

A-22334SW CW/CCW 24.875" 1.500" 3.500" .500" 22.375" 3.000"

For Models: PG210

A-20013SW CW/CCW 25.437" 1.500" 3.500" .500" 22.937" 3.125"

For Models: FW215

A-15120SW CCW 28.750" 1.500" 3.500" .500" 26.250" 3.000"

For Models: 6X6, GB722, GB842, SW842

ROTARY CUTTER BLADES

TIGER

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-UTB2031A CW 17.375" 1.500" 5.000" .500" 14.687" 1.500"

For Models: BOOM MOWER

A-TB2031 CW 17.375" 1.500" 5.000" .500" 14.687" 2.500"

For Models: BOOM MOWER

A-6T1021R CW lift 20.000" 1.500" 4.000" .500" 17.500" 2.500"

For Models: BOOM MOWER

A-6T1021RS CW twist 20.000" 1.500" 4.000" .500" 17.500" 2.500"

For Models: ROTARY HIGHWAY MOWERS

TERRAIN KING

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-02761500 CW/CCW 14.500" 1.500" 5.000' .625" 12.000" flat

For Models: A1300M, A-BOOM

A-2886200 CW lift 20.125" 1.500" 4.000" .500" 17.875" 2.500"

For Models: 60" VERSA MOWER, 72" VERSA MOWER

A-750787 CW 24.750" 1.500" 3.500" .500" 22.250" 3.00"

For Models: HYDRO 15, TK15, X5

A-750788 CCW lift 24.750" 1.500" 3.500" .500" 22.250" 3.000"

For Models: HYDRO 15, TK15, X5

A-750121 CW/CCW 24.875" 1.500" 3.500" .500" 22.375" 3.000"

For Models: TK15

WOODS-COPELAND

OVERALL HOLE CENTER OFFSET

PA R T DESCRIPTION LENGTH DIAMETER WIDTH THICKNESS HOLE/END HEIGHT

A-15789 CCW 18.500" 1.500" 3.000" .375" 17.125" twist

For Models: DO80-2, MDO80-2

A-3900WD CCW twist 18.375" .875" 3.000" .375" 17.125" .750"

For Models: 80, B080, B80, B80U, C080, C80, C80U, D08, D80, K4, M80, MB80

A-3975WD CW 19.562" .875" 2.500" N/A N/A N/A

For Models: 42

A-6330WD CCW 22.000" 1.500" 3.000" .375" 20.500" 2.000"

For Models: 60-2, 60-3, 60-4, E60, M5-4, RM5-3

A-6866WD CCW twist 22.000" 1.500" 3.000" .375" 20.500' 2.375"

For Models: 60-4, E60, M5, M60

A-12892WD CCW lift 24.000" 1.500" 4.000" .375" 21.375" 2.625"

For Models: 2090, 312, D210R, D315, HD210R-2, HD210R-3, (HD210R-4, HD315-4 ALL Early), MR105, R105, S105 Early, S105-1, S105-2

A-24771WD CW lift 24.000" 1.500" 4.000" .375" 21.500" 2.625"

For Models: 2090, D210R, D315, D315-2, D315-3, (HD210R-4, HD315-4 ALL Early), HS105, HS105-1, HS105-2, HS105-3, S105 Late, S105-3

A-8825WD CW lift 30.000" 1.500" 4.000" .500" 27.375" 3.750"

For Models: 211, 213Q, 214, 214Q, 214R, 215, 315, 320, 84-1, B106, B214, B214QR, B320, CADET 72, CADET 8, M214, M84, MB106, MR107, R107, S106 Early, S214, SM214

A-8820WD CCW lift 30.000" 1.500" 4.000" .500" 27.375" 3.750"

For Models: 211, 213Q, 214, 214Q, 214R, 215, 315, 320, B214, B214QR, B320, HS106, M214, S106 Late, S106-3, S214, SM214

A-6323WD CCW lift 30.250" 1.500" 4.000" .401" 27.375" N/A

For Models: 213, 320, 72, 84, B315-4, M72, M84, MD172, MD184, XT184

A-11768WD CW lift 20.125" 1.500" 4.000" .375" 2.500”

For Models: 2080

A-11769WD CCW lift 20.125" 1.500" 4.000" .375" 2.500”

For Models: 2080

A-17130WD CW lift 24.000" 1.500" 4.000" .375" 2.625”

For Models: 121, O121

A-19160WD CCW lift 25.250" 1.500" 4.000" .500" 3.000”

For Models: 3180, HD315-5

A-19161WD CW lift 25.250" 1.500" 4.000" .500" 3.000”

For Models: 3180, HD315-5

A-4742WD CCW lift 24.000" 1.500" 4.000" .375" 2.188”

For Models: 121, MD160, O121

ROTARY CUTTER BLADES

ROTARY CUTTER BLADE BOLTS & NUTS

A-7A5000 Blade Bolt & Nut

Kit Contains 7A4997 Bolt, Nut & Lock Washer

Used with 420HC, 422HC Blades

BUSH HOG 105, 109, 1109, 1126, 12, 1209, 1226, 126, 1310, 1315, 160,

1600, 205, 206, 226, 305, 306, 307, 307R, 310, 315, 502, 6, 600

A-63607BH Bolt Kit

Contains 2 Each 7919BH Bolts, Nuts & Lock Washers

BUSH HOG 105, 109, 1109, 1126, 12, 1209, 1226, 126, 1310, 1315, 160,

1600, 205, 206, 226, 305, 306, 307, 307R, 310, 315, 502, 6, 600

A-7A5495 Blade Bolt & Nut

Kit Contains 7A5494 Bolt, Nut & Lock Washer

DIXIE SEVERAL

A-7A5495 Blade Bolt & Nut

Kit Contains 7A5494 Bolt, Nut & Lock Washer

2-7/8" LENGTH, 1-3/8" THREAD LENGTH, .562" SHOULDER LENGTH

DIXIE SEVERAL

A-7A5000 Bolt Kit

Kit Contains 7A4997 Bolt, Nut & Lock Washer

Used with 420HC, 422HC Blades

FRED CAIN SEVERAL

A-309719 Blade Bolt Kit

Includes Bolt, Nut, Spacer, & Cotter PIn

FORD 22-47, 22-60, 22-70

A-7A5495 Blade Bolt & Nut

Kit Contains 7A5494 Bolt, Nut & Lock Washer

2-7/8" LENGTH, 1-3/8" THREAD LENGTH, .562" SHOULDER LENGTH

COVINGTON SEVERAL

A-7A5575 Bolt Kit

HICO SEVERAL

A-HL418N Bolt & Nut

HICO SEVERAL w/ new square shoulder

A-7A5495 Blade Bolt & Nut

Kit Contains 7A5494 Bolt, Nut & Lock Washer

2-7/8" LENGTH, 1-3/8" THREAD LENGTH, .562" SHOULDER LENGTH

HICO SEVERAL

A-7A5000 Blade Bolt & Nut

Kit Contains 7A4997 Bolt, Nut & Lock Washer

Used with 420HC, 422HC Blades

HICO

A-7A5500 Bolt Kit

Includes 3.625" Bolt, Nut & Lock washer

1-C48 BOLT, 1-C46 NUT, 1-C47 LOCKWASHER

HARDEE SEVERAL

A-7A5495 Blade Bolt & Nut

Kit Contains 7A5494 Bolt, Nut & Lock Washer

2-7/8" LENGTH, 1-3/8" THREAD LENGTH, .562" SHOULDER LENGTH

IMCO SEVERAL

A-7A5495 Blade Bolt & Nut

Kit Contains 7A5494 Bolt, Nut & Lock Washer

2-7/8" LENGTH, 1-3/8" THREAD LENGTH, .562" SHOULDER LENGTH

MONO SEVERAL

A-7A6000 Blade Bolt Kit

For 1/2" Blades; Kit Contains Bolt, Nut, Spacer & Cotter Pin

MONO SEVERAL

A-7A6010 Blade Bolt Kit

Kit Contains Bolt, Nut, Spacer & Cotter Pin

MONO SEVERAL W/ 3/8" Blades

A-63607BH Bolt Kit

Contains 2 Each 7919BH Bolts, Nuts & Lock Washers

MARVEL SEVERAL

A-B36107A2ALH Bolt Kit

Kit Contains Bolt & Lock Nut

RHINO SEVERAL

A-B571044 Blade Bolt Kit

Kit Contains 571044 1" LH bolt, 5GL16140 LH nut

RHINO SEVERAL

A-27723SW Bolt Kit

Kit Contains Bolt, Nut & Spacer

SIDEWINDER SEVERAL W/ 1/2" Blade, 6X6

A-27722SW Bolt Kit

Kit Contains Bolt, Nut & Spacer

SIDEWINDER SEVERAL W/ 3/8" Blade, 6X6

A-7A5492 Bolt Kit

Includes Bolt & Nut

SIDEWINDER SEVERAL

A-27724SW Blade Bolt w/ Nut

Kit Contains 15060SW Bolt & Nut

SIDEWINDER FW16, FW216, GB605, GB725, GB842, RS160, RS213, SW66,

SW72, SW84, SW842

A-7A6015 Bolt Kit

Includes Bolt & Lock Nut

TIGER SEVERAL

A-7A6042 Blade Bolt Kit

For 02761500 blade (Kit Contains Bolt, Lockwasher, Nut & Roll Pin)

TERRAIN KING A1300M, A-BOOM

SLIP CLUTCH ASSEMBLY

A-80A80 Hvy Spring, 3 required (B)

BMB 2162 w/ 3 spring 60" and 72" cutters

A-7142 Front Plate (C)

BMB 2162 w/ 3 spring 60" and 72" cutters

A-8053 Facing, 2 required (D)

BMB 2162 w/ 3 spring 60" and 72" cutters

A-7143 Back Plate (F)

BMB 2162 w/ 3 spring 60" and 72" cutters

CLUTCH FACING

A-374BH Clutch Facing, Inner

6.5” O.D. 1.187” I.D.

BUSH HOG SEVERAL

ROTARY CUTTER PARTS

CLUTCH FACING

A-372-1BH Clutch Facing, Outer

For 368-1BH Slip Clutch

BUSH HOG SEVERAL

SPRING & LINING KIT

A-67303BH Spring & Lining Kit

Kit Contains 2-Linings & 8-64657BH 6MM Springs

BUSH HOG SQ60, SQ60-4 w/ spline input shaft on gearbox,

SQ72-3 pull type

A-67304BH Spring & Lining Kit

Kit Contains: 2-64644BH Linings, 8-64657BH 6MM Linings

BUSH HOG 12610, 12615, 255R, 255R-2, 256R, 256R-2, 2610,

2615, (1220R, 1220RW, 1220S, 1220SW, 1310R, 1310RW,

1310S, 1310SW, 1315R, 1315RW, 1315S, 1315SW, 220, 220R,

220RW, 220S, 220SW, 310R, 310RW, 310S, 310SW, 315R,

315RW, 315S, 315SW ALL for wing drive shaft), (SQ72-2, SQ72-

3 ALL lift models w/ input shaft on gearbox)

A-67305BH Spring & Lining Kit

Kit Contains: 4-Linings & 8-64657BH 6MM Springs

BUSH HOG 12680R, 1268R, 2680R, 268R, 277, (12620,

13615, 2620, 3615 ALL for wing and center driveline), (1256R-2,

1257R, 1257R-2 ALL pull models), (257R, 257R-2 ALL lift mod-

els), (2512-11, 2512-13, 2512-14, 2512-18 ALL w/o jackshaft)

A-67306BH Spring & Lining Kit

Kit Contains: 4-64644BH Linings & 8-64657BH 6MM Springs

BUSH HOG 13108, 13108 OFFSET, 13126, 13126 OFFSET,

13368, 13618, 3108, 3108 OFFSET, 3126, 3126 OFFSET, 3168,

3368, (2512, 12512 ALL w/ lift & semi-lift mounts), 2512 pull type,

(1220R, 1220RW, 1220S, 1220SW, 1310R, 1310RW, 1310S,

1310SW, 1315R, 1315RW, 1315S, 1315SW, 220, 220R, 220RW,

220S, 220SW, 2512-01, 2512-03, 2512-04, 2512-08, 310R,

310RW, 310S, 310SW, 315R, 315RW, 315S, 315SW ALL w/

jackshaft)

LINING

A-970-4140 Lining, (140mm) 5-1/2" OD

For 800 Series Cutters

BUSH HOG (1257R, 257R ALL lift & pull type), 40, 52, 60, RT32

A-64644BH Lining, (160mm) 6-5/16" OD

BUSH HOG 1220R, 1310R, 1315R, 220R, 310R, 315R, (255R,

256R ALL LIFT & PULL TYPE)

BUSHING

A-64828BH Bushing

BUSH HOG 1220R, 1310R, 1315R, 220R, 310R, 315R, 40, 52,

60, RT32, (1257R, 257R ALL lift & pull type)

SPRING COIL

A-351016370 Spring Coil, (5mm) 3/16", 8 required

BUSH HOG SEVERAL

A-64657BH Spring Coil, (6mm) 1/4", 8 required

BUSH HOG SEVERAL

A-64648BH Spring Coil, (7mm) 9/32", 8 required

BUSH HOG SEVERAL

WHEEL ASSEMBLY

A-12269BH Caster Wheel Assy.

A-12528BH Fork Assy. (1)

A-20123BH Bolt 3/4"-10x8" (2)

A-15591BH Lock Nut 3/4" - 10 (3)

A-80A122 Wear Washer (4)

A-VLH1722 Spacer (5)

A-12250BH Roller Brg w/Sleeve (6)

A-233BH Wheel Half (7) *not included

A-500BH 400x8 Tail Wheel Assy. (8)

A-12268BH Hub w/ Bolts (9A) *not included

A-12105BH Hub less Bolts (9B)

A-HD12X1NCBLT Bolt 1/2" - 13x1" (10)

A-HD12LW 1/2" Lock Washer (11)

A-GF1428TT Grease Fitting (12)

BUSH HOG 104, 105, 1050, 1051, 109, 1109, 1126, 12, 1209,

1226, 126, 1307, 1405, 1405HR, 1406, 1406HR, 266, 305, 306,

307, 405, 405HR, 406, 406HR, 502, 600

ROTARY CUTTER PARTS

ROTARY CUTTER PARTS

BEARING SET

A-8A911 1 Required Per Hub

BUSH HOG 104, 105, 1050, 1051, 109, 1109, 1126, 12, 1209,

1226, 126, 1307, 1405, 1405HR, 1406, 1406HR, 266, 305, 306,

307, 405, 405HR, 406, 406HR, 502, 600

ROLLER BEARING KIT

A-12250BH Roller Bearing Kit

For New Style Tail Wheel

BUSH HOG 104, 105, 1050, 1051, 109, 1109, 1126, 12, 1209,

1226, 126, 1307, 1405, 1405HR, 1406, 1406HR, 266, 305, 306,

307, 405, 405HR, 406, 406HR, 502, 600

WHEEL ASSEMBLY

A-215BH Caster Wheel Assy.

A-1317BH Axle Bolt, 1"x7", 3/4" thread (1)

A-15591BH Lock Nut 3/4" - 10 (2)

A-610335BH Bushing (3)

A-30BH Seal (4)

A-22BH Cone (5)

A-170BH Cup (6)

A-1311BH Hub w/ brg cups (7)

A-233BH Wheel Half (8)

A-500BH 400x8 Tail Wheel Assy. (9)

BUSH HOG SEVERAL

HUB KIT

A-80A311 Hub Kit

Includes Hub, 4 Lug Bolts,Bearings, Seals, Spacers, Axle Bolt &

Lock Nut

BUSH HOG SEVERAL

WHEEL HALVES

A-80A502 2 Wheel Halves w/ Bolts

BUSH HOG SEVERAL

BEARING SETS

A-8A901 Bearing Set

BUSH HOG SEVERAL

A-8A902 Bearing Set

Contains two of the following: Seal, Cone, Cup, Bushing

BUSH HOG SEVERAL

A-610335BH Bushing

BUSH HOG SEVERAL

WHEEL ASSEMBLIES

A-VPN1035 4x8 Tail Wheel Assembly

BUSH HOG SEVERAL w/1-1/2" Shaft

A-8A1035 Bearing Kit W/ Spindle Assy

BUSH HOG SEVERAL

A-VPN1038 Bearing Kit

For VPN1035 Contains 2 Each Bearing Cones, Cups & Seals

BUSH HOG SEVERAL

A-4A1035 Spindle Assembly

BUSH HOG SEVERAL

HUBS

A-60990BH Hub, 4 bolt on 5" circle, less bushings

W/Bolts, Less Bushing

BUSH HOG SEVERAL

A-63813BH Hub, 4 bolt on 5" circle, w/ .750" bushings

BUSH HOG SEVERAL

A-44090BH 3/4" x 7" Tail Wheel Hub Bolt

BUSH HOG SEVERAL

A-15591BH Lock Nut 3/4" - 10

BUSH HOG 104, 105, 1050, 1051, 109, 1109, 1126, 12, 1209,

1226, 126, 1307, 1405, 1405HR, 1406, 1406HR, 266, 305, 306,

307, 405, 405HR, 406, 406HR, 502, 600, SEVERAL

A-63811BH 3/4" ID Bushing

3/4" I.D., 2 Reqd Per Hub

BUSH HOG

A-80A616 1" ID Bushing

1" I.D., 2 Reqd Per Hub

BUSH HOG

TAIL TIRE

A-294BH 6x9 Tail Tire w/ Rims

BUSH HOG SEVERAL

SLIP CLUTCH ASSEMBLY

A-3054 Clutch Assembly, w/ 3 springs

CALDWELL SEVERAL

A-4406 Clutch Assembly, w/ 2 springs

CALDWELL SEVERAL

A-8320 Adjustable Nut, 1 Reqd (A)

CALDWELL SEVERAL

A-8319 Spring, as reqd (B)

CALDWELL SEVERAL

A-8322 Drive Plate, 1 Reqd (C)

CALDWELL SEVERAL

A-8323 Facing, 6.5" OD, 2.625" ID, 2 Reqd (D)

CALDWELL SEVERAL

A-8318 Plate, 1 Reqd (E)

CALDWELL SEVERAL

A-8324 Back Plate, 1 Reqd (F)

CALDWELL SEVERAL

A-3061 Hub, 1 Reqd (G)

CALDWELL SEVERAL

A-3059 Facing, 6.5" OD, 2" ID

CALDWELL SEVERAL

ROLLER BEARING KIT

A-8A91 Roller Bearing Kit

(Kit Contains 2 Cups, 2 Brgs, 1 Seal)

FOREST CITY SEVERAL

TAIL WHEEL

A-AC27 4x8 Tail Wheel

FRED CAIN SEVERAL

A-80A502 2 Wheel Halves w/ Bolts

FRED CAIN SEVERAL

A-80A501 1 Wheel Half

FRED CAIN SEVERAL

SLIP CLUTCH

A-7502531 Slip Clutch

FORD

A-7500438 Slip Clutch

FORD

A-7500438-H Slip Clutch Assy.

Has 2 Heavy Springs.

FORD

ROTARY CUTTER PARTS

ROTARY CUTTER PARTS

HUB KIT

A-80A350 Hub Kit

FRED CAIN SEVERAL

A-80A1311 Wheel Hub w/ Bolts & Cups

FRED CAIN SEVERAL

A-BC18 Hub Axle Bolt

FRED CAIN SEVERAL

A-HD1NCNUT Hub Axle Nut, 1"-8 HEX

FRED CAIN SEVERAL

A-452554 SEAL

FRED CAIN SEVERAL

A-AC21 Bushing

FRED CAIN SEVERAL

BEARING SET

A-8A901 Bearing Set *order seperately

FRED CAIN SEVERAL

A-8A902 Bearing Set (set of 2) *order seperately

FRED CAIN SEVERAL

HUBS

A-80A600 4 Bolt Hub (5" center), less Bushing

FRED CAIN SEVERAL

A-80A616 1" ID Bushing

FRED CAIN SEVERAL

TAIL TIRE

A-80A500 4x8 Tail Tire w/ Rims

HARDEE SEVERAL

A-80A502 2 Wheel Halves w/ Bolts

HARDEE SEVERAL

A-80A501 1 Wheel Half

HARDEE SEVERAL

TAIL WHEEL HUB

A-C37 Tail Wheel Hub

HARDEE SEVERAL

TAIL WHEEL PARTS

A-8A993 Wheel Bearing Kit

For Tail Wheel Hub C37

HARDEE SEVERAL

A-VPN1035 4x8 Tail Wheel Assembly

HARDEE SEVERAL w/1-1/2" Shaft

A-8A1035 Bearing Kit W/ Spindle Assy

HARDEE SEVERAL

A-VPN1038 Bearing Kit

For VPN1035 Contains 2 Each Bearing Cones, Cups & Seals

HARDEE SEVERAL

A-4A1035 Spindle Assembly

HARDEE SEVERAL

SLIP CLUTCH ASSEMBLY

A-80A75 Slip Clutch Assy. w/ 2 Springs

HARDEE T160LT, T160LTO, T166LT, T166LTO, T172LT,

T172LTO, T52LT

A-C61A Adjustable Nut, 1 reqd

HARDEE T160LT, T160LTO, T166LT, T166LTO, T172LT,

T172LTO, T52LT

A-C60A Spring, 2 reqd

HARDEE T160LT, T160LTO, T166LT, T166LTO, T172LT,

T172LTO, T52LT

A-C56A Front Plate

HARDEE T160LT, T160LTO, T166LT, T166LTO, T172LT,

T172LTO, T52LT

A-36F42 Facing, 2.625" hole, 6.25" OD, 2 reqd

HARDEE T160LT, T160LTO, T166LT, T166LTO, T172LT,

T172LTO, T52LT

A-80A81 Drive Plate, 1 reqd

HARDEE T160LT, T160LTO, T166LT, T166LTO, T172LT,

T172LTO, T52LT

A-C433 Back Plate

HARDEE T160LT, T160LTO, T166LT, T166LTO, T172LT,

T172LTO, T52LT

A-80A79 Hub

HARDEE T160LT, T160LTO, T166LT, T166LTO, T172LT,

T172LTO, T52LT

SLIP CLUTCH LINING

A-970-4140 Slip Clutch Lining, 5.5" OD, 3.375" ID

HARDEE 800 SERIES

FRICTION DISC

A-970-2110 Friction Disc, 6" OD

HARDEE SEVERAL

WHEEL HUB

A-80A1311 Wheel Hub w/ Bolts & Cups

IMCO SEVERAL

SLIP CLUTCH DISC

A-W39301 SLIP CL DISC

JOHN DEERE

A-DC38275 SLIP CLUTCH DISC

JOHN DEERE

WHEEL ASSEMBLY

A-VPN1035 4x8 Tail Wheel Assembly

LAND PRIDE SEVERAL w/1-1/2" Shaft

A-8A1035 Bearing Kit W/ Spindle Assy

LAND PRIDE SEVERAL

A-VPN1038 Bearing Kit

For VPN1035 Contains 2 Each Bearing Cones, Cups & Seals

LAND PRIDE SEVERAL

A-4A1035 Spindle Assembly

LAND PRIDE SEVRAL

WHEEL ASSEMBLY

A-4010048 4x8 Tail Tire w/ Rims

MODERN SEVERAL

A-80A502 2 Wheel Halves w/ Bolts

MODERN SEVERAL

A-80A501 1 Wheel Half

MODERN SEVERAL

ROTARY CUTTER PARTS

SLIP CLUTCH ASSEMBLY

A-80A75 Slip Clutch Assy. w/ 2 Springs

MONO SEVERAL

A-80A78 Adjusting Nut

MONO SEVERAL

A-80A82 Drive Plate

MONO SEVERAL

A-36F42 Facing, 2.625" hole, 6.25" OD, 2 reqd

MONO SEVERAL

A-80A81 Drive Plate, 1 reqd

MONO SEVERAL

A-80A83 Back Plate

MONO SEVERAL

A-80A79 Hub

MONO SEVERAL

TAIL TIRE

A-80A500 4x8 Tail Tire w/ Rims

MARVEL SEVERAL, MODERN SEVERAL, MONO,

HARDEE SEVERAL

A-80A502 2 Wheel Halves w/ Bolts

MARVEL SEVERAL, MODERN SEVERAL, MONO

HARDEE SEVERAL

A-80A501 1 Wheel Half

MARVEL SEVERAL, MODERN SEVERAL, MONO

HARDEE SEVERAL

A-373024H 4x8 Tail Tire w/ Rims

NEW IDEA SEVERAL

A-00025200 6X9 Tail Tire w/ Rims

NEW IDEA SEVERAL

A-373024B 2 Wheel Halves w/ Bolts

NEW IDEA SEVERAL

A-80A501 1 Wheel Half

NEW IDEA SEVERAL

A-373024C Tail Wheel Hub

NEW IDEA SEVERAL

A-8A993 Bearing Set

NEW IDEA SEVERAL

A-37302C2C Bushing

NEW IDEA SEVERAL

A-373024H 4x8 Tail Tire w/ Rims

RHINO SEVERAL

A-00025200 6X9 Tail Tire w/ Rims

RHINO SEVERAL

A-373024B 2 Wheel Halves w/ Bolts

RHINO SEVERAL

A-80A501 1 Wheel Half

RHINO SEVERAL

A-373024C Tail Wheel Hub

RHINO SEVERAL

A-8A993 Bearing Set

RHINO SEVERAL

A-37302C2C Bushing

RHINO SEVERAL

TAIL WHEEL BEARING SET

A-VLH1717 Tail Wheel Bearing Set

RHINO FL15M, SEVERAL, SR15M, TW168

4 BOLT HUB

A-VPN1004 4 Bolt Hub (5" center) w/ Brgs & Seals

RHINO SEVERAL

SLIP CLUTCH ASSEMBLY

A-0731070000 Slip Clutch Assy. w/ 3 Springs

RHINO SEVERAL

A-073-1070-007 Adjusting Nut (A)

RHINO SEVERAL

A-073-1070-006 Spring (B)

RHINO SEVERAL

A-073-1070-005 Front Plate (C)

RHINO SEVERAL

A-073-1070-003 Facing, 2.625" hole, 6.5" OD (D)

RHINO SEVERAL

A-073-1070-004 Drive Plate (E)

RHINO SEVERAL

A-073-1070-002 Back Plate (F)

RHINO SEVERAL

A-80A79 Hub (G)

RHINO SEVERAL

ROTARY CUTTER PARTS

SLIP CLUTCH DISC

A-007-54-202 Slip Clutch Disc, 3-19/32" hole, 6" OD

RHINO TW60, TW72, TW84

A-073-1070-003 Facing, 2.625" hole, 6.5" OD

RHINO TW60, TW72, TW84

A-058-1060-003 Slip Clutch Disc, 3.75" hole, 7" OD

RHINO TW60, TW72, TW84

FRICTION DISC

A-970-2110 Friction Disc, 6" OD

For Flexible Couplers

RHINO SEVERAL

TAIL WHEEL HUB

A-37-302-4C Tail Wheel Hub w/ Brg Cups

RHINO SAT5, SAT6, SAT7, SAT8, CY60, CY72, G72, RHINO

128

TAIL WHEEL HUB BUSHING

A-37-302C-2C Bushing for Tail Wheel Hub

RHINO SEVERAL

WHEEL BEARING KIT

A-8A996 Wheel Bearing Kit (6 Bolt Hub)

For Pull Type Cutters

RHINO FLEX 1310, FLEX 15

A-8A997 Wheel Bearing Kit (6 Bolt Hub)

For Pull Type Cutters

RHINO GR84

A-8A994 Wheel Bearing Kit

For Pull Type Cutters

RHINO CY60, CY72, FLEX 15 w/ 5 bolt hub, FS15 outside axle

only, G60, G72, SAT6, SAT7, SAT8

A-8A993 Wheel Bearing Kit

For Tail Wheel Hub

RHINO CY60, CY72, G72, RHINO 128, SAT5, SAT6, SAT7,

SAT8

HUB

A-80A196 Hub w/ Bolts, Cups, Cones, Seals, Bushings

SIDEWINDER

A-16952SW Hub w/ Bolts & Cups

SIDEWINDER SEVERAL

A-80A15196 Bushing

SIDEWINDER SEVERAL

A-8A993 Wheel Bearing Kit *sold separately

SIDEWINDER SEVERAL

HEAVY SPRING

A-80A80 Hvy Spring

MONO SEVERAL

ROTARY CUTTER PARTS

4 BOLT HUB

A-80A600 4 Bolt Hub (5" center), less Bushing

SIDEWINDER

A-80A612 .725" ID Bushing

SIDEWINDER

A-80A616 1" ID Bushing

SIDEWINDER

TAIL TIRE

A-15205SW Tail Tire w/ Rims

SIDEWINDER SEVERAL

A-17122SW Tail Tire w/ Rims

SIDEWINDER SEVERAL

A-80A502 2 Wheel Halves w/ Bolts

SIDEWINDER SEVERAL

A-80A501 1 Wheel Half

SIDEWINDER SEVERAL

A-80A600 4 Bolt Hub (5" center), less Bushing

SIDEWINDER SEVERAL

A-80A612 .725" ID Bushing

SIDEWINDER SEVERAL

A-80A616 1" ID Bushing

SIDEWINDER SEVERAL

A-16952SW Hub w/ Bolts & Cups

SIDEWINDER SEVERAL

A-80A196 Hub w/ Bolts, Cups, Cones, Seals, Bushings

SIDEWINDER SEVERAL

A-15196SW Bushing

SIDEWINDER SEVERAL

A-8A993 Wheel Bearing Kit

For Tail Wheel Hub

SIDEWINDER SEVERAL

SLIP CLUTCH ASSEMBLY

A-15432-03SW Slip Clutch Assy. w/ 1-3/8" 6 splines

SIDEWINDER SEVERAL

A-15440SW Adjusting Nut (A)

SIDEWINDER SEVERAL

A-18311-018SW Spring (B)

SIDEWINDER SEVERAL

A-15435SW Front Plate (C)

SIDEWINDER SEVERAL

A-15436SW Facing (D)

SIDEWINDER SEVERAL

A-15437-03SW Drive Plate (E)

SIDEWINDER SEVERAL

A-15435-02SW Back Plate (F)

SIDEWINDER SEVERAL

A-20770SW Hub (G)

SIDEWINDER SEVERAL

FRICTION DISC

A-970-2110 Friction Disc, 6" OD

For Flexible Couplers

SIDEWINDER SEVERAL

SLIP CLUTCH ASSEMBLY

A-80A75 Slip Clutch Assy. w/ 2 Springs

Used on 6' Cutters

TERRAIN KING SEVERAL

A-748830 Adjusting Nut (A)

TERRAIN KING SEVERAL

A-748831 Spring (B)

TERRAIN KING SEVERAL

A-748832 Front Plate (C)

TERRAIN KING SEVERAL

A-748833 Facing (D)

TERRAIN KING SEVERAL

A-748826 Drive Plate (E)

TERRAIN KING SEVERAL

A-748834 Back Plate (F)

TERRAIN KING SEVERAL

A-80A79 Hub (G)

TERRAIN KING SEVERAL

ROTARY CUTTER PARTS

SLIP CLUTCH DISC

A-00754202 Slip Clutch Disc, 6" OD, 3.625" ID

TERRAIN KING SEVERAL

WHEEL HUB

A-80A1311 Wheel Hub w/ Bolts & Cups

TERRAIN KING SEVERAL

BEARING SET

A-8A993 Bearing Set (for Wheel Hub 80A1311)

TERRAIN KING SEVERAL

FRICTION DISC

A-970-2110 Friction Disc, 6" OD

For Flexible Couplers

TAYLORWAY SEVERAL

SLIP CLUTCH ASSEMBLY

A-80A75 Slip Clutch Assy. w/ 2 Springs

Used on 6' Cutters

VERMEER SEVERAL

A-80A78 Adjusting Nut (A)

VERMEER SEVERAL

A-4976-005-01 Spring (B)

VERMEER SEVERAL

A-1417-013-01 Front Plate (C)

VERMEER SEVERAL

A-4976-003-1 Facing (D)

VERMEER SEVERAL

A-80A81 Drive Plate (E)

VERMEER SEVERAL

A-4976-015-1 Back Plate (F)

VERMEER SEVERAL

A-80A79 Hub (G)

VERMEER SEVERAL

SLIP CLUTCH DISC

A-106416-017 Slip Clutch Disc

VERMEER SEVERAL

BLADE PIN KIT

A-32606WD Blade Pin Kit

WOODS-COPELAND SEVERAL

A-32602WD Blade Pin (C)

WOODS-COPELAND SEVERAL

A-7A6005 Clamp Kit (A, B)

WOODS-COPELAND SEVERAL

ROTARY CUTTER PARTS

ROTARY CUTTER PARTS

SLIP CLUTCH DISC

A-7280WD Slip Clutch Disc

For Rotary Cutters

WOODS-COPELAND 0120, 0121, 120, 121, 208, 2090, 214,

60, 72, 84, B106, B214, B315, B320, D15, D210R, HD210,

HD315, M121, M208, M4, M5, M60, M72, M84, MB106, MC72,

MK105, R105, S105, S106, SM2090, SM214

FRICTION DISC

A-970-2110 Friction Disc

BUSH HOG SEVERAL

SLIP CLUTCH

A-7502531 Slip Clutch

FORD

A-7500438 Slip Clutch

FORD

A-7500438-H Slip Clutch Assy.

Has 2 Heavy Springs.

FORD

MISCELLANEOUS

A-567300 Friction Disk (6.024" O.D. X 3.583" I.D.)

For W2100, W2200, W1, W2300, W220, W230, W2400, W11,

W240, W2500, W2600 German Type PTO

MISCELLANEOUS

A-159335 Mower Deck Height Stabilizer

Kit Contains 2 Chains With Brackets

MISCELLANEOUS

A-VTE7920 FRICTION DISC (6.024" OD X 3.583" ID)

4/PACK

MISCELLANEOUS

MOWER DECK HEIGHT STABILIZER

A-159335 Mower Deck Height Stabilizer

Kit Contains 2 Chains With Brackets

MISCELLANEOUS applications

Agriquip

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1850 17.500" 15.750" 1.500" 2.000" .500"

For Models: AGRI FOUR

A-BB1870 31.750" 30.000" 1.500" 2.000" .500"

For Models: AGRI SIX

A-BB1878 15.500" 13.750" 1.500" 1.500" .500"

For Models: AGRI 42"

A-BB1885 26.750" 25.000" 1.500" 2.000" .500"

For Models: AGRI 6.6

A-BB1887 27.750" 26.000" 1.500" 2.000" .500"

For Models: AGRI SIX

A-BB1891 23.750" 22.000" 1.500" 2.000" .500"

For Models: AGRI FIVE

ALAMO

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1845 30.500" 28.750" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1854 19.750" 18.000" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1865 24.750" 23.000" 1.375" 3.000" .500"

For Models: SEVERAL

A-BB1867 25.500" 23.750" 1.500" 3.000" .500"

For Models: AG72 BOOM MOWER

A-BB1871 28.000" 26.250" 1.375" 3.000" .500"

For Models: SEVERAL

A-BB1872 24.750" 23.000" 1.375" 3.000" .500"

For Models: SEVERAL

A-BB1892 23.750" 22.000" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1893 21.750" 20.000" 1.375" 3.500" .500"

For Models: SEVERAL

A-BB1922 30.500" 28.750" 1.500" 2.000" .500"

For Models: SEVERAL

BIG BEE

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1889 29.750" 28.000" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1895 24.250" 22.500" 1.500" 2.250" .500"

For Models: SEVERAL

BUSH HOG

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1843 24.375" 22.625" 1.500" 1.500" .500"

For Models: 1126, 1226, 126, (12610, 12615 ALL LH), 1315, 2315, 2415, 2510, (2610, 2615 ALL LH), 315, (3610, 3615 ALL LH)

A-BB1845 30.500" 28.750" 1.500" 2.000" .500"

For Models: 1207, 1257, 1307, 207, 257, 307, 800

A-BB1850 17.500" 15.750" 1.500" 2.000" .500"

For Models: 104, 204

A-BB1854 19.750" 18.000" 1.500" 2.000" .500"

For Models: 13168 RH & Center, 3368 LH

BANANA BLADES

A-BB1863 24.500" 22.750" 1.500" 2.000" .500"

For Models: 1050, (SM16, SM60 ALL LH)

A-BB1864 24.500" 22.750" 1.500" 2.000" .500"

For Models: (SM16, SM60 ALL RH)

A-BB1874 18.750" 17.000" 1.500" 2.000" .500"

For Models: 109, 1109, 1209, 160, 1600

A-BB1875 18.750" 17.000" 1.500" 2.000" .500"

For Models: 109, 1109, 1209, 160, 1600

A-BB1881 20.250" 18.500" 1.500" 2.000" .500"

For Models: 13168 LH, 3368 RH & Center

A-BB1883 22.750" 21.000" 1.250" 2.000" .375"

For Models: RAZORBACK RZ60

A-BB1885 26.750" 25.000" 1.500" 2.000" .500"

For Models: 1206, 1310C, 206, 306, 310C, 315C

A-BB1887 27.750" 26.000" 1.500" 2.000" .500"

For Models: 603

A-BB1889 29.750" 28.000" 1.500" 2.000" .500"

For Models: 307, 307R, SQ72

A-BB1890 16.250" 14.500" 1.500" 2.000" .500"

For Models: 1268, 268

A-BB1891 23.750" 22.000" 1.500" 2.000" .500"

For Models: 3126 RH & Center, 3126 OFFSET, 3126R, 3126S

A-BB1892 23.750" 22.000" 1.500" 2.000" .500"

For Models: 13126R, 13126S, 3126 LH, 3126R, 3126S

A-BB1895 24.250" 22.500" 1.500" 2.250" .500"

For Models: 105, 1126LS & O, 12, 1226LS, 126LS & O, 1310RS, 1315RS, 205, 266, 305, 310, 310RS, 315RS, 502, 6, 600

A-BB1922 30.500" 28.750" 1.500" 2.000" .500"

For Models: 220, 2620

A-BB1923 16.250" 14.500" 1.500" 2.000" .500"

For Models: 1268, 268, SQ84

BMB

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1834 26.500" 24.750" 1.250" 4.000" .500"

For Models: FR7.3

A-BB1846 20.000" 18.250" 1.250" 4.000" .500"

For Models: SEVERAL

A-BB1847 20.000" 18.250" 1.250" 4.000" .500"

For Models: SEVERAL

A-BB1848 20.000" 18.250" 1.250" 4.000' .375"

For Models: SEVERAL

A-BB1849 19.500" 17.750" 1.250" 2.000" .500"

For Models: SEVERAL

A-BB1853 19.500" 17.750" 1.500" 2.000" .500"

For Models: BR5, SUPERFLEX 15, SUPERFLEX HD, XL100

A-BB1885 26.750" 25.000" 1.500" 2.000" .500"

For Models: BR6, SUPERFLEX HD

Brown

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1860 22.500" 20.750" 1.500" 2.000" .500"

For Models: 560, 572, 584

A-BB1838 29.250" 27.500" 1.625" 1.750" .375"

For Models: SEVERAL

A-BB1883 22.750" 21.000" 1.250" 2.000" .375"

For Models: 60, 66, 72

BANANA BLADES

Corsicana

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1860 22.500" 20.750" 1.500" 2.000" .500"

For Models: F, G

FORD

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1882 22.750" 21.000" 1.500" 2.000" .375"

For Models: 22-100, 22-111, 22-112, 22-113, 22-117, 22-118, 22-119, 22-127, 22-127A, 22-140, 22-141, 22-171, 22-172, 22-176, 22-177, 22-178, 22-179, 22-194, 22-195, 22-196,

22-197, 22-198, 22-199, 22-220, 22-221, 22-222, 22-223, 22-47, 22-60, 22-70, 22-99, 505, 901, 908, 909, 910

A-BB1885 26.750" 25.000" 1.500" 2.000" .500"

For Models: 6' MODEL

FRED CAIN

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1850 17.500" 15.750" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1860 22.500" 20.750" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1885 26.750" 25.000" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1863 24.500" 22.750" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1864 24.500" 22.750" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1874 18.750" 17.000" 1.500" 2.000" .500"

For Models: 8' ROTARY CUTTER

A-BB1875 18.750" 17.000" 1.500" 2.000" .500"

For Models: 8' ROTARY CUTTER

A-BB1889 29.750" 28.000" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1895 24.250" 22.500" 1.500" 2.250" .500"

For Models: SEVERAL

HICO

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1844 24.375" 22.625" 1.500" 1.500" .500"

For Models: 500S 5 Ft. Cutter

A-BB1850 17.500" 15.750" 1.500" 2.000" .500"

For Models: 400 4 Ft. Cutters

A-BB1860 22.500" 20.750" 1.500" 2.000" .500"

For Models: M SERIES 4.5

A-BB1885 26.750" 25.000" 1.500" 2.000" .500"

For Models: 6 FT. ROTARY MOWER

A-BB1863 24.500" 22.750" 1.500" 2.000" .500"

For Models: BOSS 10

A-BB1864 24.500" 22.750" 1.500" 2.000" .500"

For Models: BOSS 10

HARDEE

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1882 22.750" 21.000" 1.500" 2.000" .375"

For Models: C160LT, C60LT

BANANA BLADES

A-BB1860 22.500" 20.750" 1.500" 2.000" .500"

For Models: T160, T160LT, T160LTO, T166, T166LT, T166LTO, T172, T172LT, T172LTO, T660, T8009LT, T8009PT, T8414, TH360

A-BB1867 25.500" 23.750" 1.500" 3.000" .500"

For Models: T666, T8215PTW

A-BB1868 25.500" 23.750" 1.500" 3.000" .500"

For Models: T666, T8215PTW

A-BB1869 28.500" 26.750" 1.500" 2.000" .500"

For Models: T672LT, T872LT, T872TP, T884LTW

A-BB1873 22.500" 20.750" 1.500" 2.000" .500"

For Models: T8009LT, T8009PT, T8414

A-BB1874 18.750" 17.000" 1.500" 2.000" .500"

For Models: T8398LT, T8398PT

A-BB1875 18.750" 17.000" 1.500" 2.000" .500"

For Models: H-CO, T52LT, T52PT, T8398LT, T8398PT

A-BB1879 15.750" 14.000" 1.500" 1.500" .375"

For Models: E36LT, E48LT

A-BB1880 18.500" 16.750" 1.500" 2.000" .375"

For Models: C148LT, E52PT

A-BB1888 29.000" 27.250" 1.500" 2.000" .500"

For Models: C172LT

IMCO

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1868 25.500" 23.750" 1.500" 3.000" .500"

For Models: 5 & 6 FOOT ROTARY CUTTERS

A-BB1889 29.750" 28.000" 1.500" 2.000" .500"

For Models: 7' MODELS

JOHN DEERE

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1850 17.500" 15.750" 1.500" 2.000" .500"

For Models: (1008, 1408, 1418 ALL 4 Ft. Cutters)

A-BB1851 17.500" 15.750" 1.500" 2.000" .500"

For Models: 1008, 1408, 1418

A-BB1874 18.750" 17.000" 1.500" 2.000" .500"

For Models: 1008, 1408, 1414, 1418

A-BB1875 18.750" 17.000" 1.500" 2.000" .500"

For Models: 1008, 1408, 1418, 403

A-BB1876 18.750" 17.000" 1.500" 1.000" .500"

For Models: 1008, 1408, 1418

A-BB1877 18.750" 17.000" 1.500" 1.000" .500"

For Models: 1008, 1408, 1418

A-BB1889 29.750" 28.000" 1.500" 2.000" .500"

For Models: 603

A-BB1891 23.750" 22.000" 1.500" 2.000" .500"

For Models: 503

A-BB1896 21.750" 20.000" 1.500" 2.500" .500"

For Models: 1008, 1508, 1517, 1518, 509, 516, 616, 717, 727, 737

A-BB1897 21.750" 20.000" 1.500" 2.500" .500"

For Models: 1008, 1018, 1508, 1517, 1518

King Kutter

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1835 23.750" 22.000" 1.500" 2.375" .500"

For Models: L60-HD, P60-HD

BANANA BLADES

A-BB1836 29.500" 27.750" 1.500" 2.375" .500"

For Models: L72 HD, L72 RD, L84 HD, P72 RD, P84 HD

A-BB1889 29.750" 28.000" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1891 23.750" 22.000" 1.500" 2.000" .500"

For Models: SEVERAL

LAND PRIDE

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1885 26.750" 25.000" 1.500" 2.000" .500"

For Models: 35120, 45180

A-BB1875 18.750" 17.000" 1.500" 2.000" .500"

For Models: RC1548

A-BB1886 26.750" 25.000" 1.500" 2.000" .500"

For Models: 35120, 45180

A-BB1889 29.750" 28.000" 1.500" 2.000" .500"

For Models: 1572, 3584

A-BB1891 23.750" 22.000" 1.500" 2.000" .500"

For Models: 1560, 2560, 3560

LONG

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1878 15.500" 13.750" 1.500" 1.500" .500"

For Models: SEVERAL

A-BB1867 25.500" 23.750" 1.500" 3.000" .500"

For Models: SEVERAL

A-BB1881 20.250" 18.500" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1880 18.500" 16.750" 1.500" 2.000" .375"

For Models: SEVERAL

A-BB1882 22.750" 21.000" 1.500" 2.000" .375"

For Models: SEVERAL

A-BB1896 21.750" 20.000" 1.500" 2.500" .500"

For Models: SEVERAL

A-BB1895 24.250" 22.500" 1.500" 2.250" .500"

For Models: SEVERAL

M & W

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1842 23.750" 22.000" 1.625" 1.000" .500"

For Models: SEVERAL

MOHAWK

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1850 17.500" 15.750" 1.500" 2.000" .500"

For Models: (1360, 840 ALL 4 Ft. Cutters)

A-BB1863 24.500" 22.750" 1.500" 2.000" .500"

For Models: 15' FLEXWING

A-BB1867 25.500" 23.750" 1.500" 3.000" .500"

For Models: 720

BANANA BLADES

MODERN

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1859 22.500" 20.750" 1.500" 3.000" .375"

For Models: SEVERAL

A-BB1887 27.750" 26.000" 1.500" 2.000" .500"

For Models: 6' MODELS

MONO

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1866 25.500" 23.750" 1.500" 2.000" .500"

For Models: 5 FT. ROTARY MOWERS

MISCELLANEOUS

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1830 19.00" 17.25" .875" .375" .375"

For Models: SEVERAL Rotary Cutters / Check Dimensions

A-BB1839 24.500" 22.750" 1.500" 1.000" .500"

For Models: SEVERAL Rotary Cutters / Check Dimensions

A-BB1840 24.500" 22.750" 1.500" 1.000" .500"

For Models: SEVERAL Rotary Cutters / Check Dimensions

A-BB1841 23.750" 22.000" 1.625" 1.000" .500"

For Models: SEVERAL Rotary Cutters / Check Dimensions

A-BB1857 20.000" 18.250" 1.500" 3.000" .500"

For Models: SEVERAL Rotary Cutters / Check Dimensions

A-BB1858 20.000" 18.750" 1.500" 3.000" .500"

For Models: SEVERAL Rotary Cutters / Check Dimensions

A-BB1894 21.750" 20.000" 1.375" 3.500" .500"

For Models: SEVERAL Rotary Cutters / Check Dimensions

A-BB1925 15.750" 14.000" 1.625" .375"

For Models: SEVERAL Rotary Cutters / Check Dimensions

RHINO

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1831 24.375" 22.625" 1.000" 1.750" .375"

For Models: SE6

A-BB1832 16.000" 14.250" 1.000" .375"

For Models: SEVERAL

A-BB1845 30.500" 28.750" 1.500" 2.000" .500"

For Models: SR20

A-BB1855 20.000" 18.250" 1.000" 2.000" .500"

For Models: SATURN 8

A-BB1856 20.000" 18.250" 1.000" 2.000" .500"

For Models: SATURN 8

A-BB1865 24.750" 23.000" 1.375" 3.000" .500"

For Models: 1008 FLEX 15, FLEX 15 RH

A-BB1871 28.000" 26.250" 1.375" 3.000" .500"

For Models: CYCLONE 72, FLEX 15 Center

A-BB1872 24.750" 23.000" 1.375" 3.000" .500"

For Models: 1008 FLEX 15, CYCLONE 60, FLEX 15 LH

A-BB1922 30.500" 28.750" 1.500" 2.000" .500"

For Models: SR20

A-BB1924 24.250" 22.500" 1.000" 3.000" .375"

For Models: SATURN 5', SATURN 6'

BANANA BLADES

Rollins

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1863 24.500" 22.750" 1.500" 2.000" .500"

For Models: ECONO 6'

A-BB1891 23.750" 22.000" 1.500" 2.000" .500"

For Models: ECONO 5'

SIDEWINDER

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1853 19.500" 17.750" 1.500" 2.000" .500"

For Models: GB144, GB48, RS160, RS213, SW66

A-BB1860 22.500" 20.750" 1.500" 2.000" .500"

For Models: 605, 660, GB60, GB602, SW72

A-BB1864 24.500" 22.750" 1.500" 2.000" .500"

For Models: FW215 CW, FW215 Flex Wing (RH)

A-BB1866 25.500" 23.750" 1.500" 2.000" .500"

For Models: FW215, FW215 Flex Wing (LH)

A-BB1869 28.500" 26.750" 1.500" 2.000" .500"

For Models: 6X6, GB722, GB842, SW642

A-BB1880 18.500" 16.750" 1.500" 2.000" .375"

For Models: GB-50, SX-50

A-BB1882 22.750" 21.000" 1.500" 2.000" .375"

For Models: 5X5, K-60, SX-60

Taylor (Midland)

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1850 17.500" 15.750" 1.500" 2.000" .500"

For Models: SEVERAL

A-BB1885 26.750" 25.000" 1.500" 2.000" .500"

For Models: 240 - 66"

A-BB1889 29.750" 28.000" 1.500" 2.000" .500"

For Models: 240 - 72"

A-BB1891 23.750" 22.000" 1.500" 2.000" .500"

For Models: 240 - 60"

TIGER

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1854 19.750" 18.000" 1.500" 2.000" .500"

For Models: ROTARY HIGHWAY MOWERS

A-BB1890 16.250" 14.500" 1.500" 2.000" .500"

For Models: BOOM MOWER

TERRAIN KING

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1843 24.375" 22.625" 1.500" 1.500" .500"

For Models: HYDRO 15, TK15, X5

A-BB1854 19.750" 18.000" 1.500" 2.000" .500"

For Models: 60" VERSA MOWER, 72" VERSA MOWER

A-BB1895 24.250" 22.500" 1.500" 2.250" .500"

For Models: (HYDRO 15, TK15, X5 ALL LH)

BANANA BLADES

BANANA BLADES

WOODS-COPELAND

OVERALL HOLE BOLT

PA R T LENGTH CTR-END HOLE OFFSET THICKNESS

A-BB1852 18.625" 16.750" .875" 1.000" .375"

For Models: 80, B080, B80, B80U, C080, C80, C80U, D08, D80, K4, M80, MB80

A-BB1859 22.500" 20.750" 1.500" 3.000" .375"

For Models: 60-2, 60-3, 60-4, E60, M5-3, M5-4

A-BB1861 24.000" 22.250" 1.500" 2.000" .375"

For Models: D210R-2, D210-R3, D315-2, D315-3, MR105, R105, S105-1, S105-2, SM2090

A-BB1862 24.000" 22.250" 1.500" 2.000" .375"

For Models: 121

A-BB1863 24.500" 22.750" 1.500" 2.000" .500"

For Models: D210-3, D210R-2, D315-2, D315-3, DM2090, HD315-5, S105-3

A-BB1864 24.500" 22.750" 1.500" 2.000" .500"

For Models: 3180, HD315-5

A-BB1881 20.250" 18.500" 1.500" 2.000" .500"

For Models: 208, B315

A-BB1889 29.750" 28.000" 1.500" 2.000" .500"

For Models: 211, 213, 213Q, 214Q, 214R, 315, 320, 84-1, B106, M84, MB106, MR107, R107, SM214, SM215

A-BB1895 24.250" 22.500" 1.500" 2.250" .500"

For Models: 3180 LH

A-BB1920 29.750" 28.000" 1.500" 2.000" .375"

For Models: 211, 213, 213Q, 214Q, 214R, 215, 315, 320, HS106-1, HS106-2, HS106-3, S106-3, SM214

A-BB1921 29.750" 28.000" 1.500" 1.250" .500"

For Models: 72-1, 72-3, 84-2

A-BB1926 14.250" 12.500" .875" .250" .375"

For Models: SEVERAL

A-BB1927 18.625" 16.750" .875" 1.000" .375"

For Models: 80, B80, B80U, C080, C80, C80U, D080, D80, MB80

ALLIS-CHALMERS

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-71656144 14.562" / 370mm 2.50" / 63.5mm .170" / 4mm 1.375" / 35mm

For Models: (608, 610, 710, 7106SP, 712H, 712S, 716H ALL W/ 42" LH CUT)

A-71656143 16.687" / 424mm 2.50" / 63.5mm .170" / 4mm 1.375" / 35mm

For Models: (710, 712H, 712S, 7166SP, 716H, 718 ALL LH W/ 48" CUT)

BIG BEE

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-19B19 19" 0.531" Formed 2.50" 0.250"

For Models: SEVERAL 4 FT. FINISHING MOWERS

A-19B20 20" 0.531" Formed 2.50" 0.250"

For Models: SEVERAL 5 Ft. Finishing Mower

A-19B25 25" 0.531" Formed 2.50" 0.250

For Models: SEVERAL 6 Ft. Finishing Mower

BUSH HOG

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-82324BH 21.000" .500" 2.250" ..234" N/A N/A

For Models: 60 (Turf Hog)

CAIN

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-19FC22 16.687" N/A 2.250" N/A N/A N/A

For Models: SEVERAL

A-19FC25 25.000" N/A 2.250" N/A N/A N/A

CASE-IH

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-C24442 LH Cut 15 9/16" 1 1/4" 13/32" 2 5/8" 2 1/2"

For Models: SEVERAL

GREAT PLAINS

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-19LP457 20.937" 1.000" 2.500" .203" N/A N/A

For Models: SEVERAL

A-19LP456 24.906" 1.000" 2.500" .250" N/A N/A

For Models: SEVERAL

King Kutter

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-190124KK 24.750" 1.500" 3.000" .500" 22.250" 2.000"

For Models: SEVERAL Check Dimensions

A-190224KK 24.750" 1.500" 3.000" .500" 22.250" 2.000"

For Models: SEVERAL Check Dimensions

A-190230KK 27.750" 1.500" 3.500" .500" 25.250" 2.000"

For Models: SEVERAL Check Dimensions

LAWN MOWER BLADES

KUBOTA

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-7650099010 16.687" .718" 2.000" .187" .343" 1.500"

For Models: RC48-62A, RC48-62F, RC48-62H

A-7071299010 15.343" .718" 2.000" .187" .343" 1.500"

For Models: RC44G

A-7071234330 15.343" .718" 2.000" .187" .343" 1.500"

For Models: RC44G

A-7008000777 20.187" .625" 2.000" .187" N/A N/A

For Models: L3559, L3560, L590

A-7072234330 20.437" .718" 2.000" .203" N/A N/A

For Models: MR6000, RC60-1, RC60-27, RC60-71H, RC60-72, RC60-72H, RC60-82H

A-7650034330 16.687" .718" 2.000" .187" .343" N/A

For Models: RC48-62A, RC48-62F, RC48-62H

A-7072134330 16.687" .718" 2.000" .187" .343" 1.500"

For Models: MR4800

A-7008000234 12.000" .750" 2.500" .187" N/A N/A

For Models: B44, K44

MASSEY FERGUSON

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-517915M1 17.437" .625" 2" .155" .187” 2.134”

For Models: SEVERAL Lawn & Garden Tractors w/ 34" Cut

A-1041224M1 17.063" .855" 2" .170" .398” 2.563”

For Models: SEVERAL Lawn & Garden Tractors w/ 42" Cut High Lift

A-517308M1 14.937" .75" x 1” 2" .155" .262” 2.140”

For Models: SEVERAL Lawn & Garden Tractors w/ 42" Cut & Double D Center Hole

A-3020019M1 14.50" .524" 2" .187" .262” 2.140”

For Models: SEVERAL Lawn & Garden Tractors w/ 42" Cut

MURRAY

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-19MU107 19.437" .850" 2.25" .140" 91745HT, 91742E701

For Models: SEVERAL 36" & 38" Cut (for bagger)

SITREX

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-48007700 16.875" .750" 2.000" .250" N/A N/A

For Models: SM120

A-SM512150 20.250" .750" N/A N/A N/A N/A

For Models: SM150

A-SM612180 24.125" .750" N/A N/A N/A N/A

For Models: SM180

SIMPLICITY

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-19SIM3 14.562" 1.375" 2.50" .170" .390" 3.0625"

For Models: SEVERAL w/ 42" LH Cut

A-19SIM4 16.687" 1.375" 2.50" .170" .39" 3.0625"

For Models: (7000, 7100 ALL S/N <1987 w/ 48" LH Cut)

SNAPPER

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-19879 14.50" .524" 2.00" .187" .262" 2.140"

For Models: SEVERAL w/ 42" Cut

A-19645 20.687" .375" 2.750" .170" .375" 2.750"

For Models: SEVERAL W/ 21" Steel Deck

LAWN MOWER BLADES

A-19795 20.8125" .385" 2.750" .164" .385" 2.750" (center to center

For Models: SEVERAL w/ 41" STD. & BBC Walk-Behind Tractor

A-18069 30.00" 1.0625" 2.750" .187" .562" 7.50"

For Models: SEVERAL 30" Riders

A-19523 33.00" 1.0625" 2.750" .187" .545" 7.50"

For Models: SEVERAL 33" Riders

SEARS

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-19SE14 15.34 .375" 2.250" .187" Straight 25034R, 25034

For Models: SEVERAL 44" Cut

A-19SE15 19.375" .375" 2.250" .187" Straight 25036R, 25036

For Models: SEVERAL 38" Cut w/o bagger

WOODS-COPELAND

OVERALL HOLE OUTER HOLE

PA R T LENGTH DIAMETER WIDTH THICKNESS HOLE DIA. CTR-CTR

A-5081WD 16.750" .625" 1.750" .203" N/A N/A

For Models: SEVERAL

A-6950WD 20.187" .625" 2.000" .187" N/A N/A

For Models: SEVERAL

A-23825WD 20.187" .625" 2.000" .187" N/A N/A

For Models: SEVERAL

A-13404WD 24.437" 1.000" 2.500" .203" N/A N/A

For Models: SEVERAL

LAWN MOWER BLADES

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

ALLIS CHALMERS

A-70511506 Rake tooth

(A) 7.750" (B) 1.875" (C) 4.000"

ALLIS-CHALMERS:

A-531727 Rake tooth

DIM A (1) 7" DIM B (2) 3.750" DIM C (3) 2.250"

ALLIS-CHALMERS: SEVERAL

A-539754 Rake tooth

DIM A (1) 7" DIM B (2) 3.375" DIM C (3) 2.250"

ALLIS-CHALMERS: SEVERAL

ATLAS

A-203055 Rake tooth

DIM A (1) 15" DIM B (2) 11.5" DIM C (3) 6.5"

ATLAS: SEVERAL

CASE-IH

A-96HE2 Rake tooth

DIM A (1) A- 6.000" DIM B (2) B- 3.500" DIM C (3) C- 1.875"

CASE-IH: SEVERAL Mfg By Hesston Same

A-ZA103012 Baler Tooth

DIM A (1) 5.750" DIM B (2) 2.625" DIM C (3) 1.5"

CASE-IH: 3650

TEETH

BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-626742R1 Baler Tooth

DIM A (1) 4.125" DIM B (2) 4.375"

CASE-IH: (BALER: 2400)

A-10670P Rake Tooth

DIM A (1) 6.10" DIM B (2) 4.20" DIM C (3) 1.59"

CASE-IH: SEVERAL

A-MA74528 Baler tooth

DIM A (1) 6.125" DIM B (2) 4" DIM C (3) 1.625"

CASE-IH: 27, 37, 45, 46, 47, 55, 56, 57, 60, 70, 71, 420, 430, 440, (FORAGE

HARVESTER: 15, 16, 55, 350, 550, 650)

A-210614C1 Baler tooth

DIM A (1) 6.25" DIM B (2) 2.75" DIM C (3) 1.375"

CASE-IH: 428, 435, 445, 5420

A-T17350 Rake tooth

DIM A (1) 7.125" DIM B (2) 3.75" DIM C (3) 2.187"

CASE-IH: 281 1960->

A-R-740S Rake tooth

DIM A (1) 7.75" DIM B (2) 3.437" DIM C (3) 1.5"

CASE-IH: 169, 170, F170

A-R740S Rake tooth

DIM A (1) 7.50" DIM B (2) 4.125" DIM C (3) 2.50"

CASE-IH: (170, F170 ALL 1939 & Up)

A-455165R1 Rake tooth

DIM A (1) 7.75" DIM B (2) 3.625" DIM C (3) 1.812"

CASE-IH: 5 1952>

A-462978R1 Rake tooth

DIM A (1) 6.750" DIM B (2) 2.25" DIM C (3) 1.75"

Replaces: 457374R1

CASE-IH: (11, 15 ALL 1956>), 14, 16, 3, 30, 35, 4, 5, 8, 86, 9, 96, 97

A-R15080 Rake tooth

DIM A (1) 8.5" DIM B (2) 3.5"

CASE-IH: SEVERAL

A-540565R1 Rake/Tedder tooth

DIM A (1) 7.125" DIM B (2) 3.750" DIM C (3) 1.875"

CASE-IH: 1190, 1490, 1590, 990

A-R1044S Rake tooth

DIM A (1) 7.250" DIM B (2) 1.562" DIM C (3) 2.500"

CASE-IH: (RAKE: 200 1953>)

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

CLAAS

A-9029160 Tedder Tooth

DIM A (1) 21.000" DIM B (2) 3.540" DIM C (3) 1.575"

CLAAS: ANDEX 280, ANDEX 310, WSDS310, WSDS370

A-9020830 Tedder Tooth

DIM A (1) 18.750" DIM B (2) 3.312" DIM C (3) 1.535"

CLAAS: WS280, WS310, WSDS280, WSDS310

A-9023442 Tedder Tooth (LH)

DIM A (1) 14.960" DIM B (2) 3.858" DIM C (3) 1.650"

CLAAS: VOLTO 450, VOLTO 540, VOLTO 640, VOLTO 740, W360, W400,

W540, W600, W730, WA360, WA400, WA540, WA600, WA730

A-9024820 Tedder Tooth (RH)

DIM A (1) 15.280" DIM B (2) 15.870" DIM C (3) 3.780" DIM D (4) 1.575"

CLAAS: W360, W450, W540, WA360, WA450, WA540

A-9024830 Tedder Tooth (LH)

DIM A (1) 15.870" DIM B (2) 15.275" DIM C (3) 3.780" DIM D (4) 1.575"

CLAAS: W360, W450, W540, W600S, W730S, WA360, WA450, WA540

DAVID BRADLEY

A-DB1 Tooth

DIM A (1) 6.75" DIM B (2) 3.687" DIM C (3) 2.437"

DAVID BRADLEY:

DARF

A-L10503 Rake tooth

DIM A (1) 7.250" DIM B (2) 1.687"

DARF:

FAHR

A-6580456 Tedder Tooth

DIM A (1) 14.875" DIM B (2) 3.750" DIM C (3) 1.625"

FAHR: KH2.76DN, KH20, KH300DN, KH40, KH400DN, KH45DN, KH500DN,

KH60, KH600DN, KH700DN, KH2.36DN, KH2.44DN, KH2.52DN

A-06580647 Tedder Tooth

DIM A (1) 15.156" DIM B (2) 16.140" DIM C (3) 3.625" DIM D (4) 1.614"

FAHR: APOLLO, KU250DN, KV3500

A-06580648 Tedder Tooth

DIM A (1) 16.140" DIM B (2) 15.156" DIM C (3) 3.625" DIM D (4) 1.180"

FAHR: APOLLO, KU250DN, KV3500

A-16504333 Tedder Tooth

DIM A (1) 24.800" DIM B (2) 3.88" DIM C (3) 1.575"

FAHR: KS1.30, KS2.29, KS2.33, KS1.30DN, KS1.50DN, KS1.70DN

A-16504331 Tedder Tooth

DIM A (1) 24.800" DIM B (2) 2.952" DIM C (3) 1.575" DIM D (4) 3.88"

FAHR: KS1.50, KS1.70, KS2.37, KS2.42, KS2.60, KS1.30DN, KS1.50DN,

KS1.70DN

A-1104000150010 Tedder Tooth

DIM A (1) 14.567" DIM B (2) 13.150" DIM C (3) 4.134" DIM D (4) 1.375"

FAHR: KH2N, KH4N, KH6N

A-1104000150110 Tedder Tooth

DIM A (1) 13.150" DIM B (2) 14.567" DIM C (3) 4.134" DIM D (4) 1.375"

FAHR: KH2N, KH4N, KH6N

A-06565574 Tedder Tooth

DIM A (1) 14.760" DIM B (2) 3.780" DIM C (3) 1.650"

FAHR: SEVERAL

A-1103663011300 Tedder Tooth

DIM A (1) 17.520" DIM B (2) 3.425" DIM C (3) 1.575" DIM D (4) 3.190"

FAHR: KS80DN

A-04303010700 Rake/Tedder tooth

DIM A (1) 12.750" DIM B (2) 2.250"

FAHR: (TEDDER: SEVERAL), (RAKE: SEVERAL)

A-11043030107 Tedder tooth

DIM A (1) 14.875" DIM B (2) 1.625" DIM C (3) 2.625"

FAHR: KH4S, KH20, KH40, KH60, KH300DN, KH400, KH500DN, KH600N

FARMHAND

A-L2117R Rake tooth, RH

DIM A (1) 5" DIM B (2) 5"

FARMHAND: 76

A-96FH2L Rake tooth, LH

DIM A (1) 5.250" DIM B (2) 4.5" DIM C (3) 1.875"

FARMHAND: LR5, LR6, M5, M6, 3P black RH

FELLA

A-461110 Rake Tooth

DIM A (1) 15.350" DIM B (2) 13.780" DIM C (3) 4.840" DIM D (4) 1.535"

FELLA: TH2, TH20, TH40

A-461111 Rake Tooth

DIM A (1) 13.780" DIM B (2) 15.350" DIM C (3) 1.535" DIM D (4) 4.84"

FELLA: TH2, TH20, TH40

A-460181 Rake Tooth (RH)

DIM A (1) 13.390" DIM B (2) 14.490" DIM C (3) 1.535" DIM D (4) 4.000"

FELLA: TH330, TH380, TH4, TH460, TH6

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-460182 Rake Tooth (LH)

DIM A (1) 14.570" DIM B (2) 13.975" DIM C (3) 1.570" DIM D (4) 4.050"

FELLA: TH330, TH380, TH4, TH460, TH6

A-488072 Tedder Tooth

DIM A (1) 13.15" DIM B (2) 3.75"

FELLA: TH360, TH370, TH410, TH430, TH440

A-487922 Tedder Tooth

DIM A (1) 13.25" DIM B (2) 3.75"

FELLA: TH410, TH430, TH450H, TH520, TH540, TH680, TH700, TH800

A-491774 Tedder Tooth

DIM A (1) 22.440" DIM B (2) 3.580" DIM C (3) 1.535"

FELLA: TS250, TS280, TS290, TS310, TS320, TS330, TS335, TS385, TS415,

TS630, TS631, TS780

A-490046 Tedder Tooth

DIM A (1) 17.370" DIM B (2) 3.625" DIM C (3) 1.520"

FELLA: TS7, TS8, UH320

A-491000 Tedder Tooth

DIM A (1) 17.375" DIM B (2) 3.625" DIM C (3) 1.620"

FELLA: UH320

FARENDLOSE

A-66230000 Tedder Tooth

DIM A (1) 14.570" DIM B (2) 13.976 DIM C (3) 1.968" DIM D (4) 4.291"

FARENDLOSE: RW330C

A-66231000 Tedder Tooth

DIM A (1) 14.570" DIM B (2) 13.976" DIM C (3) 1.968" DIM D (4) 4.291"

FARENDLOSE: RW330C

FORD

A-149956 Baler Tooth

(A) 6.0" (B) 1.5" (C) 4.0"

FORD: 150, 250, 350, 504, 506, 509, 520, 530, 532, 540, 542

A-142856 Rake tooth

(A) 7.375" (B) 2.250" (C) 3.500"

FORD: 14-20 < S/N W2000 1948 & up

A-146545 Rake tooth

DIM A (1) 6.25" DIM B (2) 5" DIM C (3) 2.25"

FORD: 503

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-107058 Rake tooth

DIM A (1) 6.75" DIM B (2) 3.687" DIM C (3) 2.437"

FORD: 508

A-143049 Rake tooth

DIM A (1) 7.25" DIM B (2) 3.5" DIM C (3) 2.25"

FORD: 14-20 S/N Z1000 >, (14-40, 14-41 ALL 1949 & UP), SEVERAL

FREEMAN

A-F1226 Baler tooth

DIM A (1) 7" DIM B (2) 2.75" DIM C (3) 1.562"

FREEMAN: (BALER: SEVERAL)

FREUDENDAHL (JF)

A-14330200 Rake Tooth

DIM A (1) 14.170" DIM B (2) 10.430" DIM C (3) 4.134" DIM D (4) 2.000"

Freudendahl (JF): (RAKE: SEVERAL)

A-14330201 Rake Tooth

DIM A (1) 14.170" DIM B (2) 10.430" DIM C (3) 4.134" DIM D (4) 2.000"

Freudendahl (JF): (RAKE: SEVERAL)

GALFRE

A-GT107SV Tedder Tooth

DIM A (1) 14.960" DIM B (2) 3.940" DIM C (3) 1.535"

GALFRE: (RAKE: SEVERAL)

A-GT108SV Tedder Tooth

DIM A (1) 14.960" DIM B (2) 3.940" DIM C (3) 1.456"

GALFRE: (RAKE: SEVERAL)

A-10370000 Rake & Tedder tooth

DIM A (1) 3.5" DIM B (2) 15.250" DIM C (3) 2.787"

GALFRE: (280, GT280, GTS280 ALL <-1995)

A-GS-3 LH Rake / Tedder tooth

DIM A (1) 13.500" DIM B (2) 3.250"

GALFRE: 250 Blue Tooth

A-GS-2 RH Rake/Tedder tooth

DIM A (1) 13.500" DIM B (2) 3.250"

GALFRE: 250 White Tooth

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

GEHL

A-664491 Baler Tooth

DIM A (1) 5.125" Tine Length DIM B (2) 3.500" Width

DIM C (3) 1.625" Coil Dia.

GEHL: (BALER: 1600)

A-96HE2 Rake tooth

DIM A (1) A- 6.000" DIM B (2) B- 3.500" DIM C (3) C- 1.875"

GEHL: 2130, 2160

A-56350 Baler tooth

DIM A (1) 4.625" DIM B (2) 4" DIM C (3) 1.625"

GEHL: (BALER: SEVERAL)

A-71607 Baler tooth

DIM A (1) 5.5" DIM B (2) 3.625" DIM C (3) 1.5"

GEHL: (BALER: SEVERAL)

A-611181 Rake tooth

DIM A (1) 6" DIM B (2) 3.750" DIM C (3) 1.875"

GEHL: 2130, 2160

GRIMM

A-GT51 Tedder tooth

DIM A (1) 9.125" DIM B (2) 3.687"

GRIMM: (TEDDER: SEVERAL)

GUAPPO

A-608754 Rake tooth

DIM A (1) 12.750" DIM B (2) 7.5" DIM C (3) 5"

Guappo: SEVERAL

H & S

A-203055 Rake tooth

DIM A (1) 15" DIM B (2) 11.5" DIM C (3) 6.5"

H&S: SEVERAL tooth .262" diameter

HAY BUSTER

A-268SE Baler tooth

DIM A (1) 4.75" DIM B (2) 3.187" DIM C (3) 1.5"

HAY BUSTER: (BALER: SEVERAL)

HAWK BILT

A-186SE Rake tooth

DIM A (1) 7.5" DIM B (2) 3.687" DIM C (3) 1.75"

HAWK BILT: (RAKE: SEVERAL)

HESSTON

A-01710102 Baler tooth

DIM A (1) 5.250" DIM B (2) 2.5" DIM C (3) 1.5"

HESSTON: 530, 540, 5510, 5530, 5540, 5545, 5585

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-96HE2 Rake tooth

DIM A (1) A- 6.000" DIM B (2) B- 3.500" DIM C (3) C- 1.875"

HESSTON: (MOWER: PT7, PT10, PT12), (MOWER CONDITIONER: 1012,

1014, 1070, 1090), (WINDROWER: 420, 620, 1014, 6600)

A-7893746 Baler tooth

DIM A (1) 6.250" DIM B (2) 3.312" DIM C (3) 1.5"

HESSTON: 4800

A-1711951 Baler tooth

DIM A (1) 5.5" DIM B (2) 3.125" DIM C (3) 1.5"

HESSTON: 5510

A-7894306 Baler tooth

DIM A (1) 5.5" DIM B (2) 3.625" DIM C (3) 1.5"

HESSTON: 5500

A-7751621 Tedder tooth

DIM A (1) 4.625" DIM B (2) 3.125" DIM C (3) 1.5"

HESSTON: 5600, 5800

A-PZ107 Tedder tooth

DIM A (1) 9" DIM B (2) 5.125" DIM C (3) 4" DIM D (4) 6.750"

DIM E (5) 2.5"

HESSTON: SEVERAL LH narrow

A-PZ224 Tedder tooth

DIM A (1) 9.5" DIM B (2) 5" DIM C (3) 4" DIM D (4) 7" DIM E (5) 2.5"

HESSTON: SEVERAL RH narrow

A-PZ225 Tedder tooth

DIM A (1) 8" DIM B (2) 3" DIM C (3) 8" DIM D (4) 2.5" DIM E (5) 6.5"

DIM F (6) 2.5"

HESSTON: SEVERAL RH wide

A-PZ110 Tedder tooth

DIM A (1) 8.5" DIM B (2) .750" DIM C (3) 7.125" DIM D (4) 4.5"

DIM E (5) 6.5" DIM F (6) 2.5"

HESSTON: SEVERAL LH wide

HUME

A-481088 LH Reel tooth

Replaces: (JD: H33333) (AC: 1171800),, (IH: 167652C1), (WH: W2722907)

HUME: (REEL: SEVERAL)

A-48107 RH Reel tooth

DIM A (1) 3.00" DIM B (2) 1.50" DIM C (3) 11.50"

Replaces: (JD: H33333) (AC: 1129508),, (IH: 167652C1), (WH: W2722937)

HUME: (REEL: SEVERAL)

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-H1611 Reel tooth, large dia.

DIM A (1) .218"

HUME: (REEL: SEVERAL)

A-H31 Reel tooth, small dia.

DIM A (1) .187"

HUME: (REEL: SEVERAL)

H & S

A-HS1RT Rake Tooth (6.5 MM /.256" Wire)

DIM A (1) 6.00" DIM B (2) 11.00" DIM C (3) 15.00"

H&S: SEVERAL

A-HS1ERT Rake Tooth (7MM /.276" Wire)

DIM A (1) 6.00" DIM B (2) 11.00" DIM C (3) 15.00"

H&S: SEVERAL

JOHN DEERE

A-241SE Rake Tooth

DIM A (1) 5.50" DIM B (2) 4.00" DIM C (3) 1.75"

JOHN DEERE: SEVERAL

A-P45961 Pickup Tooth

DIM A (1) 4.750" DIM B (2) 1.500" DIM C (3) .875"

JOHN DEERE: SEVERAL Used On Pickup Belt Attachment

A-E39915 Pickup Tooth

DIM A (1) 4.750" DIM B (2) 1.625" DIM C (3) .875"

JOHN DEERE: SEVERAL Used On Pickup Belt Attachment

A-278830 Tedder Tooth

DIM A (1) 15.750" DIM B (2) 4.218" DIM C (3) 2.000"

NEW HOLLAND: SEVERAL

A-EF2888001 Rake Tooth (Single Tine)

JOHN DEERE: (RAKE: 700)

A-AE57831 Rake tooth

DIM A (1) 17.50" DIM B (2) 10.00" DIM C (3) 6.00"

JOHN DEERE: 702, 704

A-E41833 Baler tooth

DIM A (1) 6.5" DIM B (2) 2.25" DIM C (3) 1.625"

JOHN DEERE: 327, 336, 337, 346, 347, 467

A-E67036 Baler tooth

DIM A (1) 4.625" DIM B (2) 2.375" DIM C (3) 1.5"

JOHN DEERE: 410, 430, 500, 510, 530

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-276SE Baler tooth

DIM A (1) 6.75" DIM B (2) 3.812" DIM C (3) 2.25"

JOHN DEERE: 14T, 24T, 214T

A-268SE Baler tooth

DIM A (1) 4.75" DIM B (2) 3.187" DIM C (3) 1.5"

JOHN DEERE: 8F w/ pick-up attachment

A-E74678 Baler tooth

DIM A (1) 4.625" DIM B (2) 2.437" DIM C (3) 4.625"

JOHN DEERE: 330, 340, 530, (435, 535 ALL Early Models)

A-E79475 Baler tooth

DIM A (1) 5.75" DIM B (2) 2.437" DIM C (3) 1.5"

JOHN DEERE: (335, 375 ALL SN 915001->), 435 SN 921151->, 535 SN

921940->

A-AE47389 Rake Tooth (Single Tine)

DIM A (1) 1-5/8" YOKE OPENING

JOHN DEERE: (RAKE: 54, 64, 650, 660, 670, 672, 74, 652, 662)

A-186SE Rake tooth

DIM A (1) 7.5" DIM B (2) 3.687" DIM C (3) 1.75"

JOHN DEERE: 553, 594

A-257SE Rake tooth

DIM A (1) 7" DIM B (2) 3.625" DIM C (3) 2.187"

JOHN DEERE: 350, 851, 858, 894, 896

A-237SE Rake tooth

DIM A (1) 7.375" DIM B (2) 3.625" DIM C (3) 1.75"

JOHN DEERE: 14, 596, 597, 714

A-AE47389 Rubber mtd rake tooth

DIM A (1) 1-5/8" YOKE OPENING

JOHN DEERE: 700

A-E68906 Windrower teeth

DIM A (1) 7" DIM B (2) 3.5" DIM C (3) 2"

JOHN DEERE: (WINDROWER-SWATHER: 1207, 1209, 1210, 1217, 1380,

230 new models)

A-E37596 Windrower teeth

DIM A (1) 5.5" DIM B (2) 3.5" DIM C (3) 1.75"

JOHN DEERE: 1207, 1209, 1214, 385 old models, 480, 483

KRAUSE

A-76-156 Harrow Tooth

DIM A (1) A- 13 1/2" DIM B (2) B- 7" DIM C (3) C- 3"

KRAUSE: (HARROW: SEVERAL) Double tooth

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

KRONE

A-600039 LH Reel tooth (yellow)

DIM A (1) 4.125" DIM B (2) 2.250"

KRONE: (REEL: SEVERAL)

A-600038 RH tedder tooth (red)

DIM A (1) 4.125" DIM B (2) 2.250"

KRONE: (REEL: SEVERAL)

A-9379190 Baler Tooth

DIM A (1) 6.250" DIM B (2) 3.000" DIM C (3) 1.062"

KRONE: KR120, KR150, KR180

A-9380403 Baler Tooth

DIM A (1) 6.500" DIM B (2) 3.150" DIM C (3) .790"

KRONE: (ROUND BALER: KR120, KR150, KR155)

A-0280650 Rake Tooth

DIM A (1) 7.280" DIM B (2) 2.640" DIM C (3) 1.062" DIM D (4) 2.950"

KRONE: (RAKE: LM65)

KOEHN

A-203055 Rake tooth

DIM A (1) 15" DIM B (2) 11.5" DIM C (3) 6.5"

KOEHN: SEVERAL tooth .262" diameter

KUHN

A-57601673 Rake tooth

DIM A (1) 12.5" DIM B (2) 3.625" DIM C (3) 2.750"

KUHN: GF22N, GF5000, GF6001

A-57502000 Tedder Tooth

DIM A (1) 18.500" DIM B (2) 19.020" DIM C (3) 3.900" DIM D (4) 1.730"

KUHN: GA20, GA230, GA250, GA280, GA300

A-57601100 Tedder Tooth

DIM A (1) 15.200" DIM B (2) 4.370" DIM C (3) 1.812"

KUHN: GF5000H, GRS20, GRS21

A-57644010 Tedder Tooth

DIM A (1) 20.275" DIM B (2) 4.135" DIM C (3) 2.000"

KUHN: GRS25N SN 800001>

A-57701701 Tedder Tooth

DIM A (1) 17.050" DIM B (2) 16.930" DIM C (3) 3.860" DIM D (4) 1.690"

KUHN: GA280, GA300, GA301, GA402

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-57720200 Tedder Tooth

DIM A (1) 23.030" DIM B (2) 22.250" DIM C (3) 20.050" DIM D (4) .630"

KUHN: GA300, GA381, GA4101, GA682, GA7301, GA732, GA782, GM10

A-58505210 Hay tedder tooth

DIM A (1) 15.750" DIM B (2) 4.218" DIM C (3) 2"

KUHN: GF440, GF452

A-58561900 Tedder Tooth

DIM A (1) 12.750" DIM B (2) 3.625" DIM C (3) 2.750"

KUHN: GF440S, GF671, SRP, (23N, 440 ALL 1981->), GF22F, GF4000,

GF440, GF5000

A-57609000 Tedder tooth

DIM A (1) 12.5" DIM B (2) 3.625" DIM C (3) 2.75"

KUHN: GF4201, GF5000, GF5001, GF6000, GF6001, GF6301, GF7001,

GRS24

LELY

A-4100302080 Tedder Tooth (LH)

DIM A (1) 14.570" DIM B (2) 11.220" DIM C (3) 4.020" DIM D (4) 1.420"

LELY: GEMINI 300 Early Model

A-4101101390 Tedder Tooth (RH)

DIM A (1) 11.220" DIM B (2) 14.570" DIM C (3) 4.016"

LELY: GEMINI 300 Early Model

A-4101500580 Tedder Tooth

DIM A (1) 14.960" DIM B (2) 11.220" DIM C (3) 3.780" DIM D (4) 1.460"

LELY: LOTUS 230

A-4101500680 Tedder Tooth

DIM A (1) 11.220 DIM B (2) 14.960" DIM C (3) 3.780" DIM D (4) 1.460"

LELY: LOTUS 230

A-4101601490 Tedder Tooth (RH)

DIM A (1) 11.140" DIM B (2) 14.960" DIM C (3) 3.860"

DIM D (4) 1.460" DIM E (5) 4.450"

LELY: (LOTUS 300, LOTUS 600 ALL Early Model)

A-4101601590 Tedder Tooth (LH)

DIM A (1) 14.960" DIM B (2) 11.140" DIM C (3) 3.860"

DIM D (4) 1.460" DIM E (5) 4.450"

LELY: (LOTUS 300, LOTUS 600 ALL Early Model)

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-4101701260 Tedder Tooth (LH)

DIM A (1) 14.570" DIM B (2) 10.830" DIM C (3) 3.540"

DIM D (4) 1.460" DIM E (5) 3.940"

LELY: LOTUS 300, LOTUS 460, LOTUS 520, LOTUS 600 SNB, LOTUS STA-

BILO 520, LOTUS STABILO 600, LOTUS STABILO 640, LOTUS STABILO 675,

LOTUS STABILO 725, LOTUS STABILO 770

A-4101701380 Tedder Tooth (RH)

DIM A (1) 10.830" DIM B (2) 14.570" DIM C (3) 3.540"

DIM D (4) 1.460" DIM E (5) 3.940"

LELY: LOTUS 300, LOTUS 460, LOTUS 520, LOTUS 600 SNB, LOTUS STA-

BILO 520, LOTUS STABILO 600, LOTUS STABILO 640, LOTUS STABILO 675,

LOTUS STABILO 725, LOTUS STABILO 770

A-4108003910 Tedder Tooth (LH)

DIM A (1) 14.570" DIM B (2) 11.140" DIM C (3) 4.020"

DIM D (4) 1.378" DIM E (5) 3.900"

LELY: GEMINI 300, GEMINI 600

A-4108003920 Tedder Tooth (RH)

DIM A (1) 11.140" DIM B (2) 14.570" DIM C (3) 4.020"

DIM D (4) 1.378" DIM E (5) 3.900"

LELY: GEMINI 300, GEMINI 600

LONG

A-96L01 Peanut Combine Tooth

DIM A (1) 4" DIM B (2) 2.625" DIM C (3) 1.406"

LONG: curved cyl tooth .281" diameter

A-96L01A Peanut Combine Tooth

DIM A (1) 4.750" DIM B (2) 2.250" DIM C (3) 2.312"

LONG: stripper bar tooth .250" diameter

A-145351 Peanut Combine tooth

DIM A (1) 4" DIM B (2) 2.687" DIM C (3) 1.750"

LONG: straight 2nd cylinder, .281" diameter

LILLISTON

A-96LL3 Peanut Combine tooth

DIM A (1) 4.750" DIM B (2) 3.250" DIM C (3) 1.687"

LILLISTON: 1500

A-96LL2 Peanut Combine tooth

DIM A (1) 3.250" DIM B (2) 2.5" DIM C (3) 2.250"

LILLISTON:

MASSEY FERGUSON

A-TEO01236 Rake tooth

DIM A (1) A- 9.00" DIM B (2) B- 3.50" DIM C (3) C- 1.75"

MASSEY FERGUSON:

A-665930M1 Baler tooth

(A) 6.500" (B) 1.625" (C) 2.625"

MASSEY FERGUSON: 10, 12, 3, 9

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-580848M1 Rake tooth - LH

MASSEY FERGUSON: 25 SN 419009907>, 36 SN 012159>, 37

A-1023216M1 Rake teeth

DIM A (1) 17.5" DIM B (2) 12.5" DIM C (3) 6"

MASSEY FERGUSON: 29 12 1/2" Offset

A-1053394M1 Baler tooth

DIM A (1) 7" DIM B (2) 2.875" DIM C (3) 1.687"

MASSEY FERGUSON: 1560, 1655

A-665929M1 Baler tooth

DIM A (1) 6.375" DIM B (2) 4" DIM C (3) 1.625"

MASSEY FERGUSON: (3, 9, 10, 12 ALL <-1958)

A-151075M2 Baler tooth

DIM A (1) 6" DIM B (2) 2.75" DIM C (3) 1.625"

MASSEY FERGUSON: SEVERAL <-1958

A-92611 Rake tooth

DIM A (1) 17.5" DIM B (2) 10" DIM C (3) 6"

MASSEY FERGUSON: 29, 39 5 bar

A-1031118M1 Rake tooth

DIM A (1) 17.5" DIM B (2) 10" DIM C (3) 6"

MASSEY FERGUSON: 29 SN 1233000011> W/ 10" Offset, 39 SN

1411000001> W/ 10" Offset

A-667656M1 Rake tooth

DIM A (1) 7.375" DIM B (2) 2" DIM C (3) 1.875"

MASSEY FERGUSON: SEVERAL <-1958

A-668364M1 Rake tooth

DIM A (1) 7.25" DIM B (2) 1.937" DIM C (3) 3.875"

MASSEY FERGUSON: 25, 36, 37

A-585136M1 Baler tooth

DIM A (1) 6.5" DIM B (2) 2.75" DIM C (3) 1.625"

MASSEY FERGUSON: 120, 124, 126, 128, 130, 220, 224, 228

A-542397M1 Pickup Tooth

DIM A (1) 7.500"

MASSEY FERGUSON: (COMBINE: 50)

A-1052668M1 Tedder Tooth

DIM A (1) 7.750"\

MASSEY FERGUSON: (SWATHER: 775, 785, 885), (COMBINE: SEVERAL

Pickup Reels)

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-27997001 2 Prong rubber mtd tooth

MASSEY FERGUSON: 1440, 1455, 1550, 1565

A-581318M91 Tine Bar Bearing

DIM A (1) 1 7/8" Bearing O.D. DIM B (2) 2 1/8" Overall Length

DIM C (3) 1 1/2" Thread Length DIM D (4) 3/4" Thread

MASSEY FERGUSON: (RAKE: 25 SN 419012167>, 37 SN 1283005190>,

585, 588)

A-667530M1 Rake tooth

DIM A (1) 7.25" DIM B (2) 1.875"

MASSEY FERGUSON: (RAKE: 21 MH, 25 SN 14550>)

MIDWEST

A-CH113A Harrow tooth

DIM A (1) 12.750" DIM B (2) 6.5" DIM C (3) 3.250"

MIDWEST: (HARROW: SEVERAL) 1.5" ID coil

M & W

A-1437430 Baler Tooth

DIM A (1) 5.20" DIM B (2) 3.00" DIM C (3) 1.05"

M & W: SEVERAL

A-3637507 Rake Tooth

DIM A (1) 15" DIM B (2) 11.5" DIM C (3) 6.5"

M & W: SEVERAL

A-1437434 Baler Tooth

DIM A (1) 6.300" DIM B (2) 2.834" DIM C (3) 1.100"

M & W: 1500, 1800

NIEMEYER

A-600032 Tedder Tooth (LH)

DIM A (1) 13.385" DIM B (2) 14.375" DIM C (3) 4.725" DIM D (4) 1.500"

NIEMEYER: HR301, HR361, HR362, HR401, HR460.11, HR462, HR501,

HR562, HR621, HR702, HR751

A-600033 Tedder Tooth (RH)

DIM A (1) 14.375" DIM B (2) 13.385" DIM C (3) 4.725" DIM D (4) 1.500"

NIEMEYER: HR301, HR361, HR362, HR401, HR460.11, HR462, HR501,

HR562, HR621, HR702, HR751

A-600013 Tedder Tooth

DIM A (1) 21.614" DIM B (2) 3.425" DIM C (3) 1.500"

NIEMEYER: RS280, RS281, RS28D SN 1601>, RS30, RS300, RS310,

RS330, RS420D

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-600014 Tedder Tooth

DIM A (1) 22.640" DIM B (2) 3.385" DIM C (3) 1.575"

NIEMEYER: RS28DL SN <1600

A-600034 Tedder Tooth

DIM A (1) 20.080" DIM B (2) 3.580" DIM C (3) 1.500"

NIEMEYER: RS311D, RS330D SN 2450>, RS330VRF, RS430D, RS550D

A-600030 Tedder Tooth

DIM A (1) 21.250" DIM B (2) 3.465" DIM C (3) 1.500"

NIEMEYER: RS420D

A-600029 Tedder Tooth

DIM A (1) 21.250" DIM B (2) 3.390" DIM C (3) 1.535"

NIEMEYER: SEVERAL

NEW HOLLAND

A-64562 Baler tooth

DIM A (1) 7" DIM B (2) 3.875" DIM C (3) 2.375"

NEW HOLLAND: 55, 56, 57, 256, 258, 259, 260

A-40917 Baler tooth

DIM A (1) 7" DIM B (2) 3.375" DIM C (3) 2.25"

NEW HOLLAND: 55 prior to 1951

A-37762 Baler Tooth

DIM A (1) 6.00" DIM B (2) 4.00" DIM C (3) 1.50"

NEW HOLLAND: 67

A-12027 Baler Tooth

DIM A (1) 7.25" DIM B (2) 4.00" DIM C (3) 1.50"

NEW HOLLAND: 77, 80, 87, 98, SUPER 77

A-278687 Tedder Tooth

DIM A (1) 12.750" DIM B (2) 3.625" DIM C (3) 2.750"

NEW HOLLAND: 156, 158, 162 Early Models

A-279542 Tedder Tooth

DIM A (1) 12.5" DIM B (2) 3.625" DIM C (3) 2.75"

NEW HOLLAND: 162 Late Models, 163, 165

A-28286 Baler Tooth

DIM A (1) A- 6.375" DIM B (2) B- 4.250" DIM C (3) C- 1.500"

NEW HOLLAND: 166, 66, SUPER 66

A-127566 Baler tooth

DIM A (1) 5.75" DIM B (2) 4" DIM C (3) 1.5"

NEW HOLLAND: 67, SUPER 68, 69, 78, 268, 269, 270

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-241380L LH Baler tooth

DIM A (1) 6" DIM B (2) 2.5" DIM C (3) 4.437"

NEW HOLLAND: 488, 495, 499, 1495, 1499

A-241379R RH Baler tooth

DIM A (1) 6" DIM B (2) 2.5" DIM C (3) 4.437"

NEW HOLLAND: 488, 495, 499, 1495, 1499

A-29971 Pickup Tooth

DIM A (1) 4.20" DIM B (2) 5.90" DIM C (3) 1.50"

NEW HOLLAND: 626, 727, 728, 820, 821

A-210614C1 Baler tooth

DIM A (1) 6.25" DIM B (2) 2.75" DIM C (3) 1.375"

NEW HOLLAND: 555, 565, 571, 571W

A-788853 Baler tooth

DIM A (1) 5.75" DIM B (2) 2.5" DIM C (3) 1.625"

NEW HOLLAND: 565 SN 808917>, 570 SN 804880>, 575 SN 808665>, 848

SN 714629>, 853 SN 724165>, 855 SN 733140>

A-131673 Baler tooth

DIM A (1) 5.75" DIM B (2) 2.5" DIM C (3) 1.625"

NEW HOLLAND: 845, 846, 847, 850, 851, 852

A-683310 Baler tooth

DIM A (1) 5.75" DIM B (2) 2.5" DIM C (3) 1.625"

NEW HOLLAND: 2000, 848 SN <714628, 849, 853 SN <724164, 855 SN

<733139

A-850613 LH Rubber Mounted Tooth

NEW HOLLAND: 258, 259, 260

A-850614 RH Rubber Mounted Tooth

NEW HOLLAND: 258, 259, 260

A-850612 Rake Tooth (Single Tine)

DIM A (1) Yoke Opening 1-5/8" DIM B (2) Punched Hole

DIM C (3) For 3/8" Bolt

NEW HOLLAND: 256, 56, 57

A-76517 Windrower teeth

DIM A (1) 6.5" DIM B (2) 4.25" DIM C (3) 1.875"

NEW HOLLAND: 460, 461, 467, 468, 472, 474, 488, 492, 903, 907, 909, 912,

1100, 1112, 1114, 1118 self-propelled

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-128102 Baler tooth

DIM A (1) 7.25" DIM B (2) 4"

NEW HOLLAND: 1280, 1281, 1290, 280, 281, 290

NEW IDEA

A-M873 Rake Tooth

DIM A (1) 9.00" DIM B (2) 3.30" DIM C (3) 1.98"

NEW IDEA: 4, 44, 45G

A-400033 Rake Tooth

DIM A (1) 6.625" DIM B (2) 2.437" DIM C (3) 4.00"

NEW IDEA: (400, 402, 403, 49 ALL 1955>)

A-290141 Rake Tooth

DIM A (1) 7.125" DIM B (2) 3.750" DIM C (3) 1.875"

NEW IDEA: 270, 271, 299, 750, 751, 752

A-103012 Baler tooth

DIM A (1) 5.750" DIM B (2) 2.625" DIM C (3) 1.5"

NEW IDEA: 55, 465, 483, 484, 485, 486

A-048ME Rake tooth

DIM A (1) 7.5" DIM B (2) 3.375" DIM C (3) 1.750"

NEW IDEA: 4, 44, 45G

A-NE400033 Rake Tooth

DIM A (1) 6.625" DIM B (2) 3.875" DIM C (3) 2.5"

NEW IDEA: 49, 400, 402, 403 1955->

A-96R1 Rake Tooth

DIM A (1) YOKE OPENING 1-5/8" DIM B (2) PUNCHED HOLE

DIM C (3) FOR 3/8" BOLT

NEW IDEA: (RAKE: SEVERAL) single tooth for all parallel bar rakes

A-96R2 Rake Tooth

NEW IDEA: (RAKE: SEVERAL)

double tooth for all wheel rakes

A-VLH7001 Rake & Tedder tooth

DIM A (1) 3.5" DIM B (2) 15.250" DIM C (3) 2.787"

NEW IDEA: (RAKE: SEVERAL)

A-0782ME1 Rake teeth

DIM A (1) 7" DIM B (2) 3.625" DIM C (3) 2.5"

NEW IDEA: SEVERAL 1957->

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-149781 Harrow tooth

DIM A (1) 11.250" DIM B (2) 7.5" DIM C (3) 3.5"

NEW IDEA: (HARROW: SEVERAL) tooth coil 1.8125" ID

A-41410 Harrow tooth

DIM A (1) 16.5" DIM B (2) 7.5" DIM C (3) 3.5" DIM D (4) 12.5"

NEW IDEA: (HARROW: SEVERAL) tooth coil 1.8125" ID

NIEMEYER

A-600038 RH tedder tooth (red)

DIM A (1) 4.125" DIM B (2) 2.250"

NIEMEYER: HR301, HR361, HR362, HR401, HR460.11, HR462, HR501,

HR562, HR621, HR702, HR751

A-600039 LH Reel tooth (yellow)

DIM A (1) 4.125" DIM B (2) 2.250"

NIEMEYER: HR301, HR361, HR362, HR401, HR460.11, HR462, HR501,

HR562, HR621, HR702, HR751

OMC

A-11032347 Baler tooth

DIM A (1) 6.125" DIM B (2) 2.5" DIM C (3) 1.562"

OMC: 590, 595, 596

OTMA

A-OT2TT Tedder Tooth

DIM A (1) 13.40" DIM B (2) 3.75" DIM C (3) 1.95"

OTMA: SEVERAL

A-OT3RT Rake Tooth

DIM A (1) 26.380" DIM B (2) 3.780" DIM C (3) 1.770"

OTMA: SEVERAL

A-203055 Rake tooth

DIM A (1) 15" DIM B (2) 11.5" DIM C (3) 6.5"

OTMA: SEVERAL tooth .262" diameter

OWATTONA

A-11032354 Windrower teeth

DIM A (1) 6.5" DIM B (2) 4.25" DIM C (3) 1.875"

OWATTONA: 157, 207, 235, 257

PANORAMA

A-P2567920 Tedder Tooth

DIM A (1) 14.00" DIM B (2) 3.60" DIM C (3) 2.80"

Panorama: SEVERAL

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

POLLARD

A-7D265 Rake tooth

DIM A (1) 5.375" DIM B (2) 1.812"

POLLARD: (RAKE: SEVERAL)

A-2010R Rake tooth

DIM A (1) 8" DIM B (2) 3.875" DIM C (3) 1.875"

POLLARD: (RAKE: SEVERAL)

ROANOKE HUSTLER

A-19439 Peanut Combine tooth

DIM A (1) 4" DIM B (2) 2.687" DIM C (3) 1.406"

ROANOKE HUSTLER: (COMBINE: SEVERAL)

A-96L01 Peanut Combine Tooth

DIM A (1) 4" DIM B (2) 2.625" DIM C (3) 1.406"

ROANOKE HUSTLER: (COMBINE: SEVERAL)

curved cyl tooth .281" diameter

ROSSI

A-608754 Rake tooth

DIM A (1) 12.750" DIM B (2) 7.5" DIM C (3) 5"

ROSSI: SEVERAL

A-54 Rake tooth

DIM A (1) 12.750" DIM B (2) 8.5" DIM C (3) 5"

ROSSI: 2222

SITREX

A-SS1RT Rake Tooth

DIM A (1) 15.00" DIM B (2) 11.00" DIM C (3) 6.00"

SITREX: (RAKE: SEVERAL)

A-SS2TT Tedder Tooth

DIM A (1) 12.50" DIM B (2) 3.45" DIM C (3) 2.60"

SITREX: (TEDDER: SEVERAL)

A-203055 Rake tooth

DIM A (1) 15" DIM B (2) 11.5" DIM C (3) 6.5"

SITREX: (RAKE: SEVERAL) tooth .262" diameter

A-VLH7002 Rake & Tedder tooth

DIM A (1) 7.250" DIM B (2) 11" DIM C (3) 15"

SITREX: (RAKE: SEVERAL)

TONUTTI

A-0330049 Rake Tooth

DIM A (1) 18.500" DIM B (2) 3.385" DIM C (3) 1.850"

TONUTTI: SEVERAL

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-010940 Tedder Tooth

DIM A (1) 11.57" DIM B (2) 3.75" DIM C (3) 3.75"

TONUTTI: SEVERAL

A-PLO15 Rake Tooth - LH

DIM A (1) 17.250" DIM B (2) 13" DIM C (3) 5.250"

TONUTTI: P4-74, P5-79, RK90, RTP-8, RTP-10

A-PRO15 Rake Tooth - RH

DIM A (1) 17.250" DIM B (2) 13" DIM C (3) 5.250"

TONUTTI: P4-74, P5-79, RK90, RTP-8, RTP-10

UNIVERSAL

A-96UH1 Combine Reel Tooth

UNIVERSAL: (REEL: SEVERAL) snap lock finger

A-C5H Combine Reel Tooth

UNIVERSAL: (REEL: SEVERAL) hvy duty snap lock finger

VERMEER

A-96R5 Rubber mtd Baler Tooth

VERMEER:

A-48893001 Baler tooth

DIM A (1) 4.875" DIM B (2) 3.75" DIM C (3) 1.625"

VERMEER: B, C

A-29001 Baler Tooth

DIM A (1) 4.75" DIM B (2) 3" DIM C (3) 1.625"

VERMEER: D

A-4059001 Baler Tooth

DIM A (1) 7" DIM B (2) 2.875" DIM C (3) 1.687"

VERMEER: E, F, G

A-27997001 2 Prong rubber mtd tooth

VERMEER: (RAKE: SEVERAL)

A-115663001 Rake Tooth

DIM A (1) 17.5" DIM B (2) 10" DIM C (3) 6"

VERMEER: (RAKE: SEVERAL wheel)

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

VICON

A-51000856 Tedder Tooth (LH)

DIM A (1) 15.43" DIM B (2) 4.37" DIM C (3) 1.65" DIM D (4) 16.50"

VICON: (RS410, RS510, RS610, RS740 ALL Newer Model)

A-51000855 Tedder Tooth (RH)

DIM A (1) 16.50" DIM B (2) 4.37" DIM C (3) 1.65" DIM D (4) 15.43"

VICON: (RS410, RS510, RS610, RS740 ALL Newer Model)

A-96VI1 Rake Tooth

DIM A (1) 17.50" DIM B (2) 10.00" DIM C (3) 6.00"

VICON: ACROBAT Newer Model, H1020, H1050

A-51001286 Tedder Tooth

DIM A (1) 7.000" DIM B (2) 4.125" DIM C (3) 5.125"

DIM D (4) 9.250" DIM E (5) 2.500"

VICON: HAYBOB 300

A-51001289 Tedder Tooth

DIM A (1) 6.875" DIM B (2) 4.125" DIM C (3) 7.5"

DIM D (4) 9.125" DIM E (5) 2.625"

VICON: HAYBOB 300

A-51001287 Tedder Tooth

DIM A (1) 9.000" DIM B (2) 5.125" DIM C (3) 4.000"

DIM D (4) 6.750" DIM E (5) 2.500"

VICON: HAYBOB 300, HS360

A-51001288 Tedder Tooth

DIM A (1) 8.50" DIM B (2) 0.75" DIM C (3) 7.125"

DIM D (4) 4.50" DIM E (5) 6.50" DIM F (6) 2.50"

VICON: HAYBOB 300, HS360

A-51001367 Tedder Tooth

DIM A (1) 9.5" DIM B (2) 5.0" DIM C (3) 4.0"

DIM D (4) 7.0" DIM E (5) 2.5"

VICON: HS360

A-92611 Rake Tooth

DIM A (1) 17.5" DIM B (2) 10" DIM C (3) 6"

VICON: 5, ACROBAT Older Models, H1020, H820, HKM SPRINTER, HKX500

Old Style, HKX620

A-36133 Rake Tooth

DIM A (1) 17.5" DIM B (2) 10.00" DIM C (3) 6.00"

VICON: 6

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-PZ225 Tedder Tooth

DIM A (1) 8" DIM B (2) 3" DIM C (3) 8" DIM D (4) 2.5"

DIM E (5) 6.5" DIM F (6) 2.5"

VICON: HS360

WALTON

A-1407 Tedder Tooth

DIM A (1) 14.960" DIM B (2) 3.940" DIM C (3) 1.456"

Walton: WT9

A-5515L RAKE TOOTH-LH

DIM A (1) 17.250" DIM B (2) 13" DIM C (3) 5.250"

Walton: FINGER REEL RAKES

A-0946 TEDDER TOOTH

DIM A (1) 3.5" DIM B (2) 15.25" DIM C (3) 2.787"

Walton: 21046, WT16, WT19, WT21

A-1408 Tedder Tooth

DIM A (1) 14.960" DIM B (2) 3.940" DIM C (3) 1.456"

Walton: WT9

A-5515R RAKE TOOTH-RH

DIM A (1) 17.250" DIM B (2) 13.000" DIM C (3) 5.250"

Walton: FINGER REEL RAKES

WELGER

A-0940522500 Rake Tooth

DIM A (1) 6.29" DIM B (2) 2.75" DIM C (3) 2.75"

WELGER: SEVERAL

A-034312 Rake Tooth

DIM A (1) 7.08" DIM B (2) 2.90" DIM C (3) 1.18"

WELGER: SEVERAL

A-034317 Rake Tooth

DIM A (1) 7.00" DIM B (2) 2.95" DIM C (3) 1.25"

WELGER: SEVERAL

A-034338 Rake Tooth

DIM A (1) 6.61" DIM B (2) 2.95" DIM C (3) 1.25"

WELGER: SEVERAL

WHITE/OLIVER

A-500629E Rake tooth

DIM A (1) 6.625" DIM B (2) 3.25" DIM C (3) 1.812"

WHITE/OLIVER: 107 rotor bar

WILRICH

A-16429 Harrow Tooth

DIM A (1) 16" DIM B (2) 9.375" DIM C (3) 5"

WILRICH: (HARROW: SEVERAL) tooth coil 1.625" ID

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

ZWEEGER

A-PZ107 Tedder Tooth

DIM A (1) 9" DIM B (2) 5.125" DIM C (3) 4" DIM D (4) 6.750"

DIM E (5) 2.5"

ZWEEGER: (HAY BOB, HS360 ALL LH narrow)

A-PZ110 Tedder Tooth

DIM A (1) 8.5" DIM B (2) .750" DIM C (3) 7.125"

DIM D (4) 4.5" DIM E (5) 6.5" DIM F (6) 2.5"

ZWEEGER: (HAY BOB, HS360 ALL LH wide)

A-PZ106 Tedder Tooth

DIM A (1) 7" DIM B (2) 4.125" DIM C (3) 5.125"

DIM D (4) 9.250" DIM E (5) 2.5"

ZWEEGER: HAY BOB RH narrow

A-PZ111 Tedder Tooth

DIM A (1) 6.875" DIM B (2) 4.125" DIM C (3) 7.5"

DIM D (4) 9.125" DIM E (5) 2.625"

ZWEEGER: HAY BOB RH wide

A-PZ224 Tedder Tooth

DIM A (1) 9.5" DIM B (2) 5" DIM C (3) 4" DIM D (4) 7" DIM E (5) 2.5"

ZWEEGER: HS360 RH narrow

A-PZ225 Tedder Tooth

DIM A (1) 8" DIM B (2) 3" DIM C (3) 8" DIM D (4) 2.5"

DIM E (5) 6.5" DIM F (6) 2.5"

ZWEEGER: HS360 RH wide

A-PZ190 Tedder Tooth

DIM A (1) 13.312" DIM B (2) 11.650" DIM C (3) 4.370" DIM D (4) 1.650"

ZWEEGER: DS5000

A-PZ191 Tedder Tooth

DIM A (1) 13.312" DIM B (2) 11.650" DIM C (3) 4.375" DIM D (4) 1.653"

ZWEEGER: DS5000

A-PZ192 Tedder Tooth

DIM A (1) 11.650" DIM B (2) 13.312" DIM C (3) 4.370" DIM D (4) 1.650"

ZWEEGER: DS5000

A-PZ193 Tedder Tooth

DIM A (1) 11.650" DIM B (2) 13.312" DIM C (3) 4.375" DIM D (4) 1.653"

ZWEEGER: DS5000

A-PZ339 Tedder Tooth (LH)

DIM A (1) 15.43" DIM B (2) 4.37" DIM C (3) 1.65" DIM D (4) 16.50"

ZWEEGER: (FANEX 400, FANEX 500, FANEX 600, FANEX 641, FANEX 730

ALL 1987>), 400, 500

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

A-PZ340 Tedder Tooth (RH)

DIM A (1) 16.50" DIM B (2) 4.37" DIM C (3) 1.65" DIM D (4) 15.43"

ZWEEGER: (FANEX 400, FANEX 500, FANEX 600, FANEX 641, FANEX 730

ALL 1987>), 400, 500

A-11010401 Tedder Tooth

DIM A (1) 3.50" DIM B (2) 15.250" DIM C (3) 2.787"

ROSSI: G4L, G4LPE

MISCELLANEOUS

A-91C246 Combine reel flex tine

Misc.: for wood bats, includes mtg hardware

A-91C366 Combine reel flex tine

Misc.: for tear drop style bats, includes mtg hardware

COMPLETE FINGERWHEELS

A-V90095347Z RIGHT HAND WHEEL RAKE

VICON, OLDER GEHL & MASSEY RAKES: ALL WHEEL RAKES

A-V90095862Z LEFT HAND WHEEL RAKE

VICON, OLDER GEHL & MASSEY RAKES: V-RAKES ONLY

A-P20BG003 RIGHT HAND ITALIAN WHEEL RAKE (7 mm Tines)

OTMA, ROSSI, SITREX, TONUTTI, GEHL, H&S, JD, VERMEER, WALTON:

ALL WHEEL RAKES

A-P20BG004 LEFT HAND ITALIAN WHEEL RAKE (7 mm Tines)

OTMA, ROSSI, SITREX, TONUTTI, GEHL, H&S, JD, VERMEER, WALTON:

V-RAKES ONLY

TEETH: BALER, COMBINE REEL, HARROW, RAKE, TEDDER, ETC.

CAM FOLLOWER BEARINGS / PLUNGER ROLLER BEARINGS

CCAAMM FFOOLLLLOOWWEERR BBEEAARRIINNGGSS

BRG

PART DESCRIPTION TYPE (A) (B) (C) (D) (E) (F)

A-CF108S4F6 Cam Follower Bearing 3 1 1/2 5/8 1 13/32 25/32 3/8 24 UNF2A 1/2 HEX

A-CF108S7F Cam Follower Bearing 5 1 1/2 5/8 2 1/16 15/16 7/16 20 UNF2A 11/16 RND

A-CF108S10F Cam Follower Bearing 4 1 1/2 5/8 1 3/4 13/16 1/2 20 UNF2A -

A-CF110S8F10 Cam Follower Bearing 6 1 5/8 7/8 Z 3/16 3/4 5/6 18 UNF2A -

A-CF6032 Cam Follower Bearing 2 1 1/4 5/8 1 5/16 3/4 3/16 24 UNF2A 3/16

A-CF6416 Cam Follower Bearing 3 1 1/4 5/8 1 5/16 3/4 3/8 24 UNF2A 1/2 HEX

A-CF6522 Cam Follower Bearing 2 1 1/4 5/8 2 1 1/6 3/16 24 UNF2A 3/16

A-CF6888 Cam Follower Bearing 4 1 3/4 3/4 1 23/32 3/4 .375-.378-

A-CF7811E Cam Follower Bearing 3 1 1/2 5/8 2 1/32 1 1/16 1/2 20 UNF2A 5/16 HEX

A-CF7811 Cam Follower Bearing 3 1 1/2 5/8 2 1/32 1 1/16 1/2 20 UNF2A 5/16 HEX

A-CF9727 Cam Follower Bearing 7 1 3/4 3/4 2 1/8 1 1/2 20 UNF2A 5/16 HEX

PPLLUUNNGGEERR RROOLLLLEERR BBEEAARRIINNGGSS

BRG

PART DESCRIPTION TYPE (A) (B) (C) (D) (E) (F) (G)

A-6922LH Plunger Roller Bearing 1 2.0472 0.7 2 17/32 1.375 3/4 0.09 1/8

A-B74K Plunger Roller Bearing 1 5/8" X 77" 5/8" 13/32" 1955.8

A-6901P Plunger Roller Bearing 4 2.5 0.888 2.25 1.15625 13/16 1 0.75

A-6901PA Plunger Roller Bearing 4 2.5 0.888 2.25 1.15625 13/16 1 0.75

A-6901PW Plunger Roller Bearing 4 2.5 1.125 2.484375 1.15625 13/16 1 0.75

A-6901M Plunger Roller Bearing 2 2.5 0.888 2.25 1.15625 13/16 1 0.795

A-6901S Plunger Roller Bearing 2 2.5 0.888 2 1/4 1.1875 13/16 1 0.75

A-PR6956 Plunger Roller Bearing 1 2.5 0.888 2 7/32 1 1/6 15/16 0.157 0.16

ROLLER CHAINS & ATTACHMENT LINKS

CHAIN LUBE & BELT

DRESSING

PA R T DESCRIPTION SIZE PKG QTY

A-1T1475 Chain Lube 16 oz 12

ROLLER CHAIN BREAKER

TOOLS

PA R T DESCRIPTION

A-5A1 Roller Chain Breaker

notes for above: For use on chain 25 thru 60

A-5A1S Screw w/ tip & handle

ROLLER CHAIN BREAKER

TOOLS

PA R T DESCRIPTION

A-5A2 Roller Chain Breaker

notes for above: For use on chain 60 thru 100

A-5A2S Screw w/ tip

25 ROLLER CHAINS

AND ATTACHMENT

LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-CL25IMP 25 connector link

A-OL25 25 offset link

A-OL25IMP 25 offset link (Import)

35 ROLLER CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION

A-RC35 35 roller chain, 10ft 3/8" 3/16"

A-RC35IMP 35 roller chain, 10ft (Import) 3/8" 3/16"

A-RC35X50 35 Roller Chain X 50ft

A-RC35X50IMP 35 roller chain, 50ft (Import) 3/8" 3/16"

A-CL35 35 connector link

A-CL35IMP 35 connector link (Import)

A-OL35 35 offset link

A-OL35IMP 35 offset link (Import)

A-RL35 35 roller link 3/8"

CCHHAAIINNSS && CCHHAAIINN LLIINNKKSS

ROLLER CHAINS & ATTACHMENT LINKS

40 ROLLER CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC40 40 roller chain, 10ft 1/2" 5/16" 240

A-RC40IMP 40 roller chain, 10ft (Import) 1/2" 5/16" 240

A-RC40X50 40 roller chain, 50ft 1/2" 5/16" 240

A-RC40X50IMP 40 roller chain, 50ft (Import) 1/2" 5/16" 240

A-RC40X100IMP 40 roller chain, 100ft (Import) 1/2" 5/16" 240

A-CL40 40 connector link

A-CL40IMP 40 connector link (Import)

A-CL40SSIMP 40 stainless steel connector link (Import)

A-OL40 40 offset link

A-OL40IMP 40 offset link (Import)

A-OL40SSIMP 40 stainless steel offset link

A-OL40SSIMP 40 stainless steel offset link (Import)

A-RL40 40 roller link

40 DOUBLE ROLLER

CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC40DIMP 40 Double Roller Chain X 10Ft, (Import) 1/2" 5/16" 240

A-CL40D 40 Double Connector Link, USA

A-CL40DIMP 40 Double Connector Link, (Import)

A-OL40D 40 Double Offset Link, USA

A-OL40DIMP 40 Double Offset Link, (Import)

41 ROLLER CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC41 41 roller chain, 10ft 1/2" 1/4" 240

A-RC41IMP 41 roller chain, 10ft (Import) 1/2" 1/4" 240

A-RC41X50 41 roller chain, 50ft 1/2" 1/4" 240

A-RC41X50IMP 41 roller chain, 50ft (Import) 1/2" 1/4" 240

A-CL41 41 connector link

A-CL41IMP 41 connector link (Import)

A-OL41 41 offset link

A-OL41IMP 41 offset link (Import)

A-RL41 41 roller link

50 ROLLER CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC50 50 roller chain, 10ft 5/8" 3/8" 192

A-RC50IMP 50 roller chain, 10ft (Import) 5/8" 3/8" 192

A-RC50SSIMP 50 stainless steel roller chain, 10ft (Import)

A-RC50X50 50 roller chain, 50ft 5/8" 3/8" 192

A-RC50X50IMP 50 roller chain, 50ft (Import) 5/8" 3/8" 192

A-CL50 50 connector link

A-CL50IMP 50 connector link (Import)

A-CL50SSIMP 50 stainless steel connector link (Import)

A-OL50 50 offset link

A-OL50IMP 50 offset link (Import)

A-OL50SSIMP 50 stainless steel offset link (Import)

A-RL50 50 roller link

A-RC50HIMP 50 Hvy roller chain, 10ft (Import) 5/8" 3/8" 192

A-CL50HIMP 50 Hvy connector link (Import)

A-OL50HIMP 50 Hvy offset link (Import)

50 DOUBLE ROLLER

CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC50D 50 Double Roller Chain X 10Ft. 5/8" 3/8" 192

A-RC50DIMP 50 Double Roller Chain X 10Ft. (Import) 5/8" 3/8" 192

A-RC50DX50 ROLLER CHAIN, USA

A-CL50D 50 Double Connector Link

A-CL50DIMP 50 Double Connector Link, (Import)

A-OL50D 50 Double Offset Link

A-OL50DIMP 50 Double Offset Link, (Import)

60 ROLLER CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC60 60 roller chain, 10ft 3/4" 1/2" 160

A-RC60IMP 60 roller chain, 10ft (Import) 3/4" 1/2" 160

A-RC60X50 60 roller chain, 50ft 3/4" 1/2" 160

A-RC60X50IMP 60 roller chain, 50ft (Import) 3/4" 1/2" 160

A-RC60X100 60 Roller Chain X 100 Ft., USA

A-RC60X100IMP 60 roller chain, 100ft (Import) 3/4" 1/2" (width) 160 (links per 10 ft) 1/2" 160

A-CL60 60 connector link

A-CL60IMP 60 connector link (Import)

A-CL60SSIMP 60 stainless steel connector link (Import)

A-OL60 60 offset link

A-OL60IMP 60 offset link (Import)

A-OL60SSIMP 60 stainless steel offset link (Import)

A-RL60 60 roller link

A-RC60H 60 Hvy roller chain, 10ft 3/4" 1/2" 160

A-RC60HIMP 60 Hvy roller chain, 10ft (Import) 3/4" 1/2" 160

A-RC60HX50 60 Hvy roller chain, 50ft 3/4" 1/2" 160

A-RC60HX50IMP 60 Hvy roller chain, 50ft (Import) 3/4" 1/2" 160

A-CL60H 60 Hvy connector link

A-CL60HIMP 60 Hvy connector link (Import)

A-OL60H 60 Hvy offset link

A-OL60HIMP 60 Hvy offset link (Import)

A-RL60H 60 Hvy roller link

ROLLER CHAINS & ATTACHMENT LINKS

60 DOUBLE ROLLER

CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC60D 60 Double Roller Chain X 10 Ft. 3/4" 1/2" 160

A-RC60DIMP 60 Double Roller Chain X 10Ft (Import) 3/4" 1/2" 160

A-RC60DX50 60 Double Roller Chain X 50 Ft. 3/4" 1/2" 160

A-CL60D 60 Double Connector Link

A-CL60DIMP 60 Double Connector Link, (Import)

A-OL60D 60 Double Offset Link

A-OL60DIMP 60 Double Offset Link, (Import)

80 ROLLER CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC80 80 roller chain, 10ft 1" 5/8" 120

A-RC80IMP 80 roller chain, 10ft (Import) 1" 5/8" 120

A-RC80X50 80 roller chain, 50ft 1" 5/8" 120

A-RC80X50IMP 80 roller chain, 50ft (Import) 1" 5/8" 120

A-CL80 80 connector link

A-CL80IMP 80 connector link (Import)

A-OL80 80 offset link

A-OL80IMP 80 offset link (Import)

A-RL80 80 roller link

A-RC80H 80 Hvy roller chain, 10ft 1" 5/8" 120

A-RC80IMP 80 Hvy roller chain, 10ft (Import) 1" 5/8" 120

A-RC80HX50 80 Hvy roller chain, 50ft 1" 5/8" 120

A-CL80H 80 Hvy connector link

A-CL80HIMP 80 Hvy connector link (Import)

A-OL80H 80 Hvy offset link

A-OL80HIMP 80 Hvy offset link (Import)

A-RL80H 80 Hvy roller link

80 DOUBLE ROLLER

CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC80D 80 Double Roller Chain X 10Ft.1" 5/8" 120

A-RC80DIMP 80 Double Roller Chain X 10Ft. (Import) 1" 5/8" 120

A-CL80D 80 Double Connector Link

A-CL80DIMP 80 Double Connector Link, (Import)

A-OL80D 80 Double Offset Link

A-OL80DIMP 80 Double Offset Link, (Import)

100 ROLLER CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC100 100 roller chain, 10ft 1-1/4" 3/4" 96

A-RC100IMP 100 roller chain, 10ft (Import)

A-CL100 100 connector link

A-CL100IMP 100 connector link (Import)

A-OL100 100 offset link

A-OL100IMP 100 offset link (Import)

A-RL100 100 roller link

120 ROLLER CHAINS

AND ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC120 120 roller chain, 10ft

A-RC120IMP 120 roller chain, 10ft (Import) 1-1/2" 1"

A-CL120 120 connector link

A-CL120IMP 120 connector link (Import)

A-OL120 120 offset link

A-OL120IMP 120 offset link (Import)

2040 ROLLER CHAINS

AND ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10 FT

A-RC2040 2040 Extended pitch roller chain, 10ft 1" 5/16" 120

A-RC2040IMP 2040 Ext. pitch roller chain, 10ft (Import) 1" 5/16" 120

A-RC2040X50 2040 Ext. pitch roller chain, 50ft 1" 5/16" 120

A-RC2040X50IMP 2040 Ext. pitch roller chain, 50ft (Import) 1" 5/16" 120

A-CL2040 2040 Extended pitch connector link

A-CL2040IMP 2040 Extended pitch connector link (Import)

A-OL2040 2040 Extended pitch offset link

A-OL2040IMP 2040 Extended pitch offset link (Import)

A-RL2040 2040 Extended pitch roller link

2050 ROLLER CHAINS

AND ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10’

A-RC2050 2050 Extended pitch roller chain, 10ft 1-1/4" 3/8" 96

A-RC2050IMP 2050 Extended pitch roller chain, 10ft (Import)

1-1/4" 3/8" 96

A-RC2050X50 2050 Extended pitch roller chain, 50ft 1-1/4" 3/8" 96

A-RC50X50IMP 2050 Extended pitch roller chain, 50ft (Import)

5/8" 3/8" 192

A-RC2050X100IMP 2050 Extended pitch roller chain, 100ft (Import)

1-1/4" 3/8" 96

A-CL2050 2050 Extended pitch connector link

A-CL2050IMP 2050 Extended pitch connector link (Import)

A-OL2050 2050 Extended pitch offset link

A-OL2050IMP 2050 Extended pitch offset link (Import)

A-RL2050 2050 Extended pitch roller link

ROLLER CHAINS & ATTACHMENT LINKS

2060 ROLLER CHAINS

AND ATTACHMENT LINKS

PA R T DESCRIPTION PITCH WIDTH LINKS

LENGTH PER 10’

A-RC2060 2060 Extended pitch roller chain, 10ft 1-1/2" 1/2" 80

A-RC2060IMP 2060 Ext. pitch roller chain, 10ft (Import) 1-1/2" 1/2" 80

A-RC2060X50IMP 2060 Extended pitch roller chain, 50ft 1-1/2" 1/2" 80

A-CL2060 2060 Extended pitch connector link

A-CL2060IMP 2060 Extended pitch connector link (Import)

A-OL2060 2060 Extended pitch offset link

A-OL2060IMP 2060 Extended pitch offset link (Import)

A-RL2060 2060 Extended pitch roller link

A550 ROLLER CHAINS

AND ATTACHMENT LINKS

PA R T DESCRIPTION

A-A550 A550 Roller Chain, 10 ft

A-A550C A550-C Connector Link

A-A550R A550-R Roller Link

A-A550O A550-O Offset Link

ROLLER CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION

A-A620 A620 Roller Chain, 10 ft

A-A620C A620-C Connector Link

A-A620R A620-R Roller Link

A-A620O A620-O Offset Link

CA550 ROLLER

CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION

A-CA550 CA550 Conveyor Series Chain, 10 ft

A-CA550C CA550-C Connector Link

A-CA550R CA550-R Roller Link

A-CA550O CA550-O Offset Link

CA550 ROLLER

CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION

A-CA555 CA555 Conveyor Series Chain, 10 ft

A-CA555C CA555-C Connector Link

A-CA555R CA555-R Roller Link

A-CA555O CA555-O Offset Link

CA557 ROLLER

CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION

A-CA557 CA557 Conveyor Series Chain, 10 ft

A-CA557C CA557-C Connector Link

A-CA557R CA557-R Roller Link

A-CA557O CA557-O Offset Link

CA620 ROLLER

CHAINS AND

ATTACHMENT LINKS

PA R T DESCRIPTION

A-CA620 CA620 Conveyor Series Chain, 10 ft

A-CA620C CA620-C Connector Link

A-CA620R CA620-R Roller Link

A-CA620O CA620-O Offset Link

PINTLE CHAINS

PA R T DESCRIPTION

A-AL662 AL662 Pintle Chain, 10 ft

A-AL662CO AL662-CO Connector Link

A-AL667H AL667H Pintle Chain, 10 ft

A-AL667HCO AL667H-CO Connector Link

A-AL667HASCO AL667H-AS-CO Attaching Link

A-AL667X AL667X Pintle Chain, 10 ft

A-AL667XCO AL667X-CO Connector Link

A-AL667XASCO AL667X-AS-CO Attaching Link

ROUND BALER CHAINS

for New Holland models

PA R T DESCRIPTION (TOTAL LINKS) (ATT. LINKS)

A-268766 Round Baler Lower Floor Chain 71 17

A-714619 Round Baler Lower Floor Chain 61 15

A-710395 Round Baler Lower Floor Chain 78 19

A-718096 Round Baler Lower Floor Chain 65 16

ROUND BALER CHAINS

for New Holland models

PA R T DESCRIPTION

A-262268 Repair Section

notes for above: for chains: 268766, 714619

A-702378 Repair Section

notes for above: for chains: 710395, 718096

ROLLER CHAINS & ATTACHMENT LINKS

ROUND BALER

CHAINS

for New Holland models

PA R T DESCRIPTION (TOTAL LINKS) (ATT. LINKS)

A-704545 Upper Slat Chain, CA550 180 60

A-634335 Upper Slat Chain, CA550 192 64

A-795027 Upper Slat Chain, CA557 228 76

A-855594 Upper Slat Chain, CA557 228 57

A-679303 Upper Slat Chain, CA557 240 80

A-273260 Upper Slat Chain, CA550 216 72

A-679768 Upper Slat Chain, CA557 234 78

A-850096 Upper Slat Chain, CA557 248 62

ROUND BALER CHAINS

for New Holland models

PA R T DESCRIPTION

A-639219 Repair Section, CA550

notes for above: for chains: 704545, 634335, 273260, 679768, 795027

A-770522 Repair Section, CA557

notes for above: for chain 855594

T-ROD CHAIN LINK

The unique design of T-Rod Chain Links allows removing or adding links without

tools. Just turn the link 45 degrees and with a slight twist a link can be disen-

gaged.

PA R T DESCRIPTION

A-AL67R 67 T-Rod Chain Link, 10 ft (50 links)

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION DIM A (1) DIM B (2) DIM C (3)

A-25 25 Steel Detachable Chain (10 ft) 45/64 27/64 29/32

A-32 32 Steel Detachable Chain (10 ft) 15/16 19/32 1-5/32

A-32W 32W Steel Detachable Chain (10 ft) 1-1/16 19/32 1-5/32

A-33 33 Steel Detachable Chain (10 ft) 1-1/16 11/16 1-13/32

A-42 42 Steel Detachable Chain (10 ft) 1-7/32 25/32 1-3/8

A-50H 50H Steel Detachable Chain (10 ft) 1-9/32 25/32 1-3/8

A-51 51 Steel Detachable Chain (10 ft) 1-3/32 45/64 1-5/32

A-52 52 Steel Detachable Chain (10 ft) 1-13/32 27/32 1-1/2

A-55 55 Steel Detachable Chain (10 ft) 1-9/32 51/64 1-5/8

A-62 62 Steel Detachable Chain (10 ft) 1-9/16 63/64 1-21/32

A-62A 62A Steel Detachable Chain (10 ft) 1-15/16 63/64 1-43/64

A-62H 62H Steel Detachable Chain (10 ft) 1-7/8 63/64 1-21/32

A-67H 67H Steel Detachable Chain (10 ft) 1-7/8 1-3/32 2-5/16

A-67XH 67XH Steel Detachable Chain (10 ft) 1-7/8 1-3/32 2-5/16

A-70 70 Steel Detachable Chain (10 ft) 1-15/16 1-3/32 2-1/64

A-7212A 71-1/2 Steel Detachable Chain (10 ft) 2 1-5/32 1-41/64

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION

A-55CO 55CO Attachment Link

A-62CO 62CO Attachment Link

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION

A-55C1 55C1 Attachment Link

A-62C1 62C1 Attachment Link

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION

A-55A2L 55A2L Attachment Link

A-55A2R 55A2R Attachment Link

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION

A-55A1L 55A1L Attachment Link

A-55A1R 55A1R Attachment Link

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION

A-62A1L 62A1L Attachment Link

A-62A1R 62A1R Attachment Link

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION

A-55SH 55SH Attachment Link

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION

A-55SD 55SD Attachment Link

A-62SD 62SD Attachment Link

ROLLER CHAINS & ATTACHMENT LINKS

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION

A-55K1 55K1 Attachment Link

A-62K1 62K1 Attachment Link

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION

A-55G27L 55G27L Attachment Link

A-55G27R 55G27R Attachment Link

A-62G27L 62G27L Attachment Link

A-62G27R 62G27R Attachment Link

STEEL DETACHABLE

CHAINS

PA R T DESCRIPTION

A-67HASL 67HASL Attachment Link

A-67HASR 67HASR Attachment Link

A-67XHASL 67XHASL Attachment Link

A-67XHASR 67XHASR Attachment Link

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

ROUND BALER BELTING

AC

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

Roto-Baler A-1000573 Upper belting 5.5 X 72 2Ply Texture Top w/ Clipper fastener 6 3

Roto-Baler A-1000574 Lower belting 5.5 X 102 2Ply Texture Top w/ Clipper fastener 6 5

Case IH

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

241, 2400 A-1000557 Upper belting 4 X 431 2Ply Texture Top w/ Clipper fastener 9 208510C92 12

241, 2400 A-1000669 Upper belting 4 X 431 3Ply Texture Top w/ Clipper fastener 9 208510C92 14

241, 2400 A-1000588 Upper belting 10 X 431 2Ply Texture Top w/ Clipper fastener 35

241, 2400 A-1000612 Upper belting 10 X 431 3Ply Texture Top w/ Clipper fastener 39

241, 2400 A-1000660 Lower belting 60 X 120 2Ply Texture Top w/ Clipper fastener 1 210480C92 65

2400 A-1001776 Upper belting 4 X 424 2Ply Texture Top w/ Clipper fastener 9 12

2400 A-1001777 Upper belting 4 X 424 3Ply Texture Top w/ Clipper fastener 9 14

2400 A-1001778 Upper belting 10 X 424 2Ply Texture Top w/ Clipper fastener 35

2400 A-1001779 Upper belting 10 X 424 3Ply Texture Top w/ Clipper fastener 39

3440 A-1000397 Upper belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 12 6

3440 A-1000398 Upper belting 11 X 73.25 3Ply Texture Top w/ Clipper fastener 12 8

3440 A-1000399 Lower belting 11 X 103.5 2Ply Texture Top w/ Clipper fastener 4 19

3440 A-1000400 Lower belting 11 X 103.5 3Ply Texture Top w/ Clipper fastener 4 22

3450 A-1000569 Upper belting 4.75 X 73.25 2Ply Texture Top w/ Clipper fastener 30 3

3450 A-1000685 Upper belting 4.75 X 73.25 3Ply Texture Top w/ Clipper fastener 30 5

3450 A-1000397 Upper belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 15 6

3450 A-1000398 Upper belting 11 X 73.25 3Ply Texture Top w/ Clipper fastener 15 8

3450 A-1000399 Lower belting 11 X 103.5 2Ply Texture Top w/ Clipper fastener 5 19

3450 A-1000400 Lower belting 11 X 103.5 3Ply Texture Top w/ Clipper fastener 5 22

3640 A-1000397 Upper belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 20 6

3640 A-1000398 Upper belting 11 X 73.25 3Ply Texture Top w/ Clipper fastener 20 8

3640 A-1000599 Lower belting 11 X 121.25 2Ply Texture Top w/ Clipper fastener 4 10

3640 A-1000623 Lower belting 11 X 121.25 3Ply Texture Top w/ Clipper fastener 4 13

3650 A-1000569 Upper belting 4.75 X 73.25 2Ply Texture Top w/ Clipper fastener 55 3

3650 A-1000685 Upper belting 4.75 X 73.25 3Ply Texture Top w/ Clipper fastener 55 5

3650 A-1000397 Upper belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 25 6

3650 A-1000398 Upper belting 11 X 73.25 3Ply Texture Top w/ Clipper fastener 25 8

3650 A-1000599 Lower belting 11 X 121.25 2Ply Texture Top w/ Clipper fastener 5 10

3650 A-1000623 Lower belting 11 X 121.25 3Ply Texture Top w/ Clipper fastener 5 13

8420 A-1001772 Upper belting 4.8 X 364 2Ply Texture Top w/ Clipper fastener 5 700-700-802 15

8420 A-1000357 Upper belting 4.8 X 364 3Ply Mini Rough w/ Clipper fastener 5 700-700-802 19

8430 A-1002467 Upper belting 7 X 366 2Ply Texture Top w/ Clipper fastener 6 700-709-185 19

8430 A-1002860 Upper belting 7 X 366 3Ply Chevron w/ Clipper fastener 6 700-709-185 23

8430 A-1003209 Upper belting 7 X 366 3Ply Chevron w/ Titan fastener 6 23

8430 A-1002727 Upper belting 7 X 366 3Ply Mini Rough w/ Clipper fastener 6 23

8435 A-1003213 Upper belting 7 X 471.5 2Ply Texture Top w/ Clipper fastener 6 26

8435 A-1003214 Upper belting 7 X 471.5 3Ply Chevron w/ Clipper fastener 6 30

8435 A-1003210 Upper belting 7 X 471.5 3Ply Chevron w/ Titan fastener 6 30

8440 A-1000561 Upper belting 4 X 452 2Ply Texture Top w/ Clipper fastener 9 828178 13

8440 A-1002854 Upper belting 4 X 452 3Ply Chevron w/ Clipper fastener 9 828178 17

8440 A-1000355 Upper belting 4 X 452 3Ply Herringbone w/ Clipper fastener 9 17

8450 A-1002455 Upper belting 6.5 X 572.5 2Ply Texture Top w/ Clipper fastener 2 700-708-740 28

8450 A-1002859 Upper belting 6.5 X 572.5 3Ply Chevron w/ Clipper fastener 2 700-708-740 33

8450 A-1002457 Upper belting 7 X 570 2Ply Texture Top w/ Clipper fastener 4 700-707-162 30

8450 A-1002862 Upper belting 7 X 570 3Ply Chevron w/ Clipper fastener 4 700-707-162 36

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

ROUND BALER BELTING

364

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

Case IH continued

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

8450 A-1003208 Upper belting 6.5 X 572.5 3Ply Chevron w/ Titan fastener 2 33

8450 A-1003212 Upper belting 7 X 570 3Ply Chevron w/ Titan fastener 4 36

8450 A-1002456 Upper belting 6.5 X 572.5 3Ply Herringbone w/ Clipper fastener 2 33

8450 A-1002458 Upper belting 7 X 570 3Ply Herringbone w/ Clipper fastener 4 36

8455 A-1002865 Upper belting 7 X 562.5 2Ply Texture Top w/ Clipper fastener 6 29

8455 A-1002861 Upper belting 7 X 562.5 3Ply Chevron w/ Clipper fastener 6 36

8455 A-1003211 Upper belting 7 X 562.5 3Ply Chevron w/ Titan fastener 6 36

8455 A-1002867 Upper belting 7 X 562.5 3Ply Herringbone w/ Clipper fastener 6 36

8460 A-1002455 Early / upper belting 6.5 X 572.5 2Ply Texture Top w/ Clipper fastener 2 700-708-740 28

8460 A-1002859 Early / upper belting 6.5 X 572.5 3Ply Chevron w/ Clipper fastener 2 700-708-740 33

8460 A-1002457 Early / upper belting 7 X 570 2Ply Texture Top w/ Clipper fastener 6 700-707-162 30

8460 A-1002862 Early / upper belting 7 X 570 3Ply Chevron w/ Clipper fastener 6 700-707-162 36

8460 A-1003208 Upper belting 6.5 X 572.5 3Ply Chevron w/ Titan fastener 2 33

8460 A-1003212 Upper belting 7 X 570 3Ply Chevron w/ Titan fastener 6 36

8460 A-1002456 Early / upper belting 6.5 X 572.5 3Ply Herringbone w/ Clipper fastener 2 33

8460 A-1002458 Early / upper belting 7 X 570 3Ply Herringbone w/ Clipper fastener 6 36

8460 A-1002861 Upper belting 7 X 562.5 3Ply Chevron w/ Clipper fastener 8 36

8460 A-1003211 Upper belting 7 X 562.5 3Ply Chevron w/ Titan fastener 8 36

8460 A-1002867 Newer / Upper belting 7 X 562.5 3Ply Herringbone w/ Clipper fastener 8 36

8465 A-1002865 Upper belting 7 X 562.5 2Ply Texture Top w/ Clipper fastener 8 29

8465 A-1002861 Upper belting 7 X 562.5 3Ply Chevron w/ Clipper fastener 8 36

8465 A-1003211 Upper belting 7 X 562.5 3Ply Chevron w/ Titan fastener 8 36

8465 A-1002867 Upper belting 7 X 562.5 3Ply Herringbone w/ Clipper fastener 8 36

8480 A-1000397 Upper belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 25 6

8480 A-1000398 Upper belting 11 X 73.25 3Ply Texture Top w/ Clipper fastener 25 8

8480 A-1000599 Lower belting 11 X 121.25 2Ply Texture Top w/ Clipper fastener 5 10

8480 A-1000623 Lower belting 11 X 121.25 3Ply Texture Top w/ Clipper fastener 5 13

RBX441 A-1003784 Upper belting 7 X 272.5 3Ply Chevron w/ Titan fastener 6 18

RBX441 A-1003785 Upper belting 7 X 272.5 3Ply Chevron w/ Clipper fastener 6 18

RBX451 A-1003786 Upper belting 7 X 343 3Ply Chevron w/ Titan fastener 6 22

RBX451 A-1003787 Upper belting 7 X 343 3Ply Chevron w/ Clipper fastener 6 22

RBX451 A-1003786 Upper belting 7 X 343 3Ply Chevron w/ Titan fastener 6 22

RBX451 A-1003787 Upper belting 7 X 343 3Ply Chevron w/ Clipper fastener 6 22

RBX461 A-1003788 Upper belting 7 X 420.5 3Ply Chevron w/ Titan fastener 6 26

RBX461 A-1003789 Upper belting 7 X 420.5 3Ply Chevron w/ Clipper fastener 6 26

RBX561 A-1003788 Upper belting 7 X 420.5 3Ply Chevron w/ Titan fastener 8 26

RBX561 A-1003789 Upper belting 7 X 420.5 3Ply Chevron w/ Clipper fastener 8 26

RS451 A-1003638 Upper belting 7 X 475 3Ply Chevron w/ Titan fastener 6 36

RS451 A-1003335 Upper belting 7 X 475 3Ply Chevron w/ Clipper fastener 6 36

RS451 A-1003670 Upper belting 7 X 475 3Ply Chevron w/ Titan fastener 6 40

RS551 A-1003638 Upper belting 7 X 475 3Ply Chevron w/ Titan fastener 8 36

RS551 A-1003335 Upper belting 7 X 475 3Ply Chevron w/ Clipper fastener 8 36

RS551 A-1003670 Upper belting 7 X 475 .315 Mini w/ Titan fastener 8 40

RS561 A-1003621 Upper belting 7 X 547 3Ply Chevron w/ Titan fastener 8 46

RS561 A-1003620 Upper belting 7 X 547 3Ply Chevron w/ Clipper fastener 8 46

Claas

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

Rollaut 180 A-1003668 Upper belting 8.66 X 500 3Ply Mini Rough Top w/ Titan fastener 5 37

FORD / NH

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

551 A-1000575 Upper belting 6 X 450 2Ply Texture Top w/ Clipper fastener 2 GH-059802 19

551 A-1000688 Upper belting 6 X 450 3Ply Texture Top w/ Clipper fastener 2 GH-059802 24

551 A-1000571 Upper belting 5 X 450 2Ply Texture Top w/ Clipper fastener 3 GH-066548 16

551 A-1000686 Upper belting 5 X 450 3Ply Texture Top w/ Clipper fastener 3 GH-066548 22

551 A-1000652 Lower/V-Guide belting 44.25 X 69.5 2Ply Texture Top w/ Clipper fastener 1 GH-066556 26

551 A-1000651 Lower/V-Guide belting 44.25 X 56.5 2Ply Texture Top w/ Clipper fastener 1 GH-066548 26

552 A-1000577 Upper belting 6 X 466 2Ply Texture Top w/ Clipper fastener 6 GH-059800 20

552 A-1000690 Upper belting 6 X 466 3Ply Texture Top w/ Clipper fastener 6 GH-059800 25

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

365

ROUND BALER BELTING

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

FORD / NH continued

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

552 A-1000657 Lower/V-Guide belting 60 X 96 2Ply Texture Top w/ Clipper fastener 1 GH-056580 47

630, 634 A-1002459 Upper belting 7 X 272.5 2Ply Texture Top w/ Clipper fastener 6 14

630, 634 A-1002460 Upper belting 7 X 272.5 3Ply Mini Rough Top w/ Clipper fastener 6 18

638 A-1002459 Upper belting 7 X 272.5 2Ply Texture Top w/ Clipper fastener 6 14

638 A-1002460 Upper belting 7 X 272.5 3Ply Mini Rough Top w/ Clipper fastener 6 18

640, 644 A-1002864 Upper belting 7 X 343 2Ply Texture Top w/ Clipper fastener 6 9843314 18

640, 644 A-1002866 Upper belting 7 X 343 3Ply Mini Rough Top w/ Clipper fastener 6 9843314 22

640, 644 A-1002980 Upper belting 7 X 343 .315" Thick Mini Rough w/ Clipper fastener 6 28

648 A-1002864 Upper belting 7 X 343 2Ply Texture Top w/ Clipper fastener 6 18

648 A-1002866 Upper belting 7 X 343 3Ply Mini Rough Top w/ Clipper fastener 6 22

648 A-1002980 Upper belting 7 X 343 .315" Thick Mini Rough w/ Clipper fastener 6 28

650, 654 A-1002461 Upper belting 7 X 420.5 2Ply Texture Top w/ Clipper fastener 6 21

650, 654 A-1002462 Upper belting 7 X 420.5 3Ply Mini Rough Top w/ Clipper fastener 6 27

658 A-1002461 Upper belting 7 X 420.5 2Ply Texture Top w/ Clipper fastener 6 21

658 A-1002462 Upper belting 7 X 420.5 3Ply Mini Rough Top w/ Clipper fastener 6 27

658 A-1002981 Upper belting 7 X 420.5 .315" Thick Mini Rough w/ Clipper fastener 6 34

660, 664 A-1002461 Upper belting 7 X 420.5 2Ply Texture Top w/ Clipper fastener 8 21

660, 664 A-1002462 Upper belting 7 X 420.5 3Ply Mini Rough Top w/ Clipper fastener 8 27

650, 654 A-1002981 Upper belting 7 X 420.5 .315" Thick Mini Rough w/ Clipper fastener 6 34

668 A-1002461 Upper belting 7 X 420.5 2Ply Texture Top w/ Clipper fastener 8 21

668 A-1002462 Upper belting 7 X 420.5 3Ply Mini Rough Top w/ Clipper fastener 8 27

668 A-1002981 Upper belting 7 X 420.5 .315" Thick Mini Rough w/ Clipper fastener 8 34

678 A-1002864 Upper belting 7 X 343 2Ply Texture Top w/ Clipper fastener 8 18

678 A-1002866 Upper belting 7 X 343 3Ply Mini Rough Top w/ Clipper fastener 8 22

678 A-1002980 Upper belting 7 X 343 .315" Thick Mini Rough w/ Clipper fastener 8 28

688 A-1002461 Upper belting 7 X 420.5 2Ply Texture Top w/ Clipper fastener 8 21

688 A-1002462 Upper belting 7 X 420.5 3Ply Mini Rough Top w/ Clipper fastener 8 27

688 A-1002981 Upper belting 7 X 420.5 .315" Thick Mini Rough w/ Clipper fastener 8 34

Gehl

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

1400 A-1000575 Upper belting 6 X 450 2Ply Texture Top w/ Clipper fastener 2 68254 19

1400 A-1000688 Upper belting 6 X 450 3Ply Texture Top w/ Clipper fastener 2 68254 24

1400 A-1000571 Upper belting 5 X 450 2Ply Texture Top w/ Clipper fastener 3 66548 16

1400 A-1000686 Upper belting 5 X 450 3Ply Texture Top w/ Clipper fastener 3 66548 22

1400 A-1000651 Lower belting w/ "V-Guide" 44.25 X 56.5 2Ply Texture Top w/ Clipper fastener 1 69784 26

1400, 1440 A-1000652 Lower belting w/ "V-Guide" 44.25 X 69.5 2Ply Texture Top w/ Clipper fastener 1 66556 26

1450, 1460, 1465 A-1000576 Upper belting belting 6 X 468.5 2Ply Texture Top w/ Clipper fastener 5 75567 20

1450, 1460, 1465 A-1000689 Upper belting 6 X 468.5 3Ply Texture Top w/ Clipper fastener 5 75567 25

1450, 1460, 1465 A-1000651 Lower belting w/ "V-Guide" 44.25 X 56.5 2Ply Texture Top w/ Clipper fastener 1 24

1465, 1470, 1475,

1500 A-1000576 Upper belting 6 X 468.5 2Ply Texture Top w/ Clipper fastener 6 20

1465, 1470, 1475,

1500 A-1000689 Upper belting 6 X 468.5 3Ply Texture Top w/ Clipper fastener 6 25

1465, 1470, 1475,

1500 A-1002856 Optional Upper belting 6 X 468.5 3Ply Chevron w/ Clipper fastener 6 26

1465, 1470, 1475,

1500 A-1002463 Optional Upper belting 6 X 468.5 3Ply Mini Rough Top w/ Clipper fastener 6 27

1500 A-1000563 Upper belting 4 X 466 2Ply Texture Top w/ Clipper fastener 9 56479 13

1500 A-1000675 Upper belting 4 X 466 3Ply Texture Top w/ Clipper fastener 9 56479 18

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

ROUND BALER BELTING

366

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

Gehl continued

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

1500 A-1000593 Upper belting 10 X 466 2Ply Texture Top w/ Clipper fastener 35

1500 A-1000617 Upper belting 10 X 466 3Ply Texture Top w/ Clipper fastener 44

1500A, 1600 A-1000577 Upper belting 6 X 466 2Ply Texture Top w/ Clipper fastener 6 59800 20

1500A, 1600 A-1000690 Upper belting 6 X 466 3Ply Texture Top w/ Clipper fastener 6 59800 25

1500, 1500A, 1600 A-1000657 Lower belting w/ "V-Guide" 60 X 96 2Ply Texture Top w/ Clipper fastener 1 56480 47

1850, 1860 A-1000578 Upper belting 6 X 546 2Ply Texture Top w/ Clipper fastener 7 75742 23

1850, 1860 A-1000691 Upper belting 6 X 546 3Ply Texture Top w/ Clipper fastener 7 75742 29

1850, 1860 A-1000656 Lower w/ "V-Guide" 60 X 56.5 2Ply Texture Top w/ Clipper fastener 1 74727 27

1865, 1870 A-1002464 Upper belting 6 X 545.5 2Ply Texture Top w/ Clipper fastener 8 23

1865, 1870 A-1002465 Upper belting 6 X 545.5 3Ply Texture Top w/ Clipper fastener 8 29

1865, 1870 A-1002857 Optional Upper belting 6 X 545.5 3Ply Chevron w/ Clipper fastener 8 30

1865, 1870 A-1002466 Optional Upper belting 6 X 545.5 3Ply Mini Rough Top w/ Clipper fastener 8 32

1875 A-1002863 Upper belting 6 X 552 2Ply Texture Top w/ Clipper fastener 8 119477 24

1875 A-1002858 Upper belting 6 X 552 3Ply Chevron w/ Clipper fastener 8 119477 30

2480 A-1003783 Upper belting 6 X 468.5 3Ply Mini Rough Top w/ Clipper fastener 6 28

2580 A-1003780 Upper belting 6.5 X 474.5 3Ply Reg. Chevron w/ Alligator Rivet 2 29

2580 A-1003779 6.5 X 502 3Ply Reg. Chevron w/ Alligator Rivet 4 31

2680 A-1003781 Upper belting 6.5 X 556 3Ply Reg. Chevron w/ Alligator Rivet 2 34

2680 A-1003782 6.5 X 577.5 3Ply Reg. Chevron w/ Alligator Rivet 4 36

2780 A-1003783 Upper belting 6 X 468.5 3Ply Mini Rough Top w/ Clipper fastener 8 28

2880 A-1003781 Upper belting 6.5 X 556 3Ply Reg. Chevron w/ Alligator Rivet 4 34

2880 A-1003782 6.5 X 577.5 3Ply Reg. Chevron w/ Alligator Rivet 4 36

Hesston

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

514 A-1000397 Upper belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 25 6

514 A-1000398 Upper belting belting 11 X 73.25 3Ply Texture Top w/ Clipper fastener 25 8

514 A-1000599 Lowerr belting 11 X 121.25 2Ply Texture Top w/ Clipper fastener 5 10

514 A-1000623 Lowerr belting 11 X 121.25 3Ply Texture Top w/ Clipper fastener 5 13

530 A-1001772 Upper belting 4.8 X 364 2Ply Texture Top w/ Clipper fastener 5 700-700-802 15

530 A-1000357 Upper belting 4.8 X 364 3Ply Mini Rough Top w/ Clipper fastener 5 700-700-802 19

540 A-1002467 Upper belting 7 X 366 2Ply Texture Top w/ Clipper fastener 6 700-709-185 19

540 A-1002860 Upper belting 7 X 366 3Ply Chevron w/ Clipper fastener 6 700-709-185 23

540 A-1003209 Optional Upper belting 7 X 366 3Ply Chevron w/ Titan fastener 6 23

540 A-1002468 Optional Upper belting 7 X 366 3Ply Rough Herring Bone w/ Clipper fastener 6 23

545 A-1003213 Upper belting 7 X 471.5 2Ply Texture Top w/ Clipper fastener 6 700-714-815 23

545 A-1003214 Upper belting 7 X 471.5 3Ply Chevron w/ Clipper fastener 6 700-714-815 23

545 A-1003334 Upper belting/Endless 7 X 471.5 3Ply Chevron w/ Clipper fastener 6 30

545 A-1003210 Upper belting 7 X 471.5 3Ply Chevron w/ Titan fastener 6 30

550 A-1002455 Upper belting 6.5 X 572.5 2Ply Texture Top w/ Clipper fastener 2 700-708-740 29

550 A-1002859 Upper belting 6.5 X 572.5 3Ply Chevron w/ Clipper fastener 2 700-708-740 36

550 A-1003208 Optional Upper belting 6.5 X 572.5 3Ply Chevron w/ Titan fastener 2 36

550 A-1002456 Optional Upper belting 6.5 X 572.5 3Ply Rough Herring Bone w/ Clipper fastener 2 36

550 A-1002457 Upper belting 7 X 570 2Ply Texture Top w/ Clipper fastener 4 700-707-162 29

550 A-1002862 Upper belting 7 X 570 3Ply Chevron w/ Clipper fastener 4 700-707-162 36

550 A-1003212 Optional Upper belting 7 X 570 3Ply Chevron w/ Titan fastener 4 700-713-630 36

550 A-1002458 Optional Upper belting 7 X 570 3Ply Rough Herring Bone w/ Clipper fastener 4 36

555 A-1002865 Upper belting 7 X 562.5 2Ply Texture Top w/ Clipper fastener 6 700-709-999 29

555 A-1002861 Upper belting 7 X 562.5 3Ply Chevron w/ Clipper fastener 6 700-709-999 36

555 A-1003211 Upper belting 7 X 562.5 3Ply Chevron w/ Titan fastener 6 700-713-617 36

560, 565 A-1002457 Upper belting 7 X 570 2Ply Texture Top w/ Clipper fastener 8 29

560, 565 A-1002862 Upper belting 7 X 570 3Ply Chevron w/ Clipper fastener 8 36

560, 565 A-1003212 Upper belting 7 X 570 3Ply Chevron w/ Titan fastener 8 36

560, 565 A-1002458 Optional Upper belting 7 X 570 3Ply Rough Herring Bone w/ Clipper fastener 8 36

565 A-1003887 Upper belting 7 X 562.5 Mini-Rough Top w/ Clipper fastener 8 700728090

840 A-1003209 Upper belting 7 X 366 3Ply Chevron w/ Titan fastener 6 23

840 A-1002467 Optional Upper belting 7 X 366 2Ply Texture Top w/ Clipper fastener 6 19

840 A-1002860 Optional Upper belting 7 X 366 3Ply Chevron w/ Clipper fastener 6 23

846A A-1003680 Upper belting 7 X 547 3Ply .315 Mini Rough w/ Titan fastener 6 44

845 A-1003335 Upper belting 7 X 475 3Ply Chevron w/ Clipper fastener 8 700-716-049 36

845 A-1003336 Upper belting/Endless 7 X 475 3Ply Chevron w/ Clipper fastener 8 700-717-965 36

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

367

ROUND BALER BELTING

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

Hesston continued

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

855 A-1003335 Upper belting 7 X 475 3Ply Chevron w/ Clipper fastener 8 700-716-049 36

855 A-1003336 Upper belting/Endless 7 X 475 3Ply Chevron w/ Clipper fastener 8 700-717-965 36

856 A-1003335 Upper belting 7 X 547 3Ply Chevron w/ Clipper fastener 8 700-717-717 36

856 A-1003336 Upper belting/Endless 7 X 547 3Ply Chevron w/ Clipper fastener 8 700-717-966 36

856A A-1003886 Mini-Rough 7 X 547 Mini-Rough w/ Clipper fastener 8 700728088

5400 A-1000550 Upper belting 4 X 127 2Ply Texture Top w/ Clipper fastener 9 728733 3

5400 A-1000662 Upper belting 4 X 127 3Ply Texture Top w/ Clipper fastener 9 728733 5

5500, 5510 A-1000561 Upper belting 4 X 452 2Ply Texture Top w/ Clipper fastener 9 828178 13

5500, 5510 A-1002854 Upper belting 4 X 452 3Ply Chevron w/ Clipper fastener 9 828178 17

5500, 5510 A-1000355 Optional Upper belting 4 X 452 3Ply Rough Herring Bone w/ Clipper fastener 9 17

5530 A-1001772 Upper belting 4.8 X 365 2Ply Texture Top w/ Clipper fastener 5 15

5530 A-1000357 Upper belting 4.8 X 365 3Ply Mini Rough Top w/ Clipper fastener 5 19

5540 A-1000572 Upper belting 5.3 X 470 2Ply Texture Top w/ Clipper fastener 6 828335 18

5540 A-1002855 Upper belting 5.3 X 470 3Ply Chevron w/ Clipper fastener 6 828335 30

5540 A-1000358 Optional Upper belting 5.3 X 470 3Ply Rough Herring Bone w/ Clipper fastener 6 30

5545 A-1001773 Upper belting 5.3 X 465 2Ply Texture Top w/ Clipper fastener 6 15

5545 A-1003332 Upper belting 5.3 X 465 3Ply Chevron w/ Clipper fastener 6 20

5545 A-1000354 Optional Upper belting 5.3 X 465 3Ply Mini Rough Top w/ Clipper fastener 8 19

5580 A-1000572 Upper belting 5.3 X 470 2Ply Texture Top w/ Clipper fastener 8 828335 18

5580 A-1002855 Upper belting 5.3 X 470 3Ply Chevron w/ Clipper fastener 8 828335 30

5580 A-1000358 Optional Upper belting 5.3 X 470 3Ply Rough Herring Bone w/ Clipper fastener 8 30

5585 A-1001773 Upper belting 5.3 X 465 2Ply Texture Top w/ Clipper fastener 8 15

5585 A-1003332 Upper belting 5.3 X 465 3Ply Chevron w/ Clipper fastener 8 20

5585 A-1000354 Optional Upper belting 5.3 X 465 3Ply Mini Rough Top w/ Clipper fastener 8 19

5600 A-1000554 Upper belting 4 X 400 2Ply Texture Top w/ Clipper fastener 9 728832 11

5600 A-1000666 Upper belting 4 X 400 3Ply Texture Top w/ Clipper fastener 9 728832 13

5600 A-1000585 Optional Upper belting 10 X 400 2Ply Texture Top w/ Clipper fastener 30

5600 A-1000697 Optional Upper belting 10 X 400 3Ply Texture Top w/ Clipper fastener 34

5600 A-1000658 Lower belting w/ V-Guide 60 X 120 2Ply Texture Top w/ Clipper fastener 1 728931 58

5800 A-1000564 Upper belting 4 X 480 2Ply Texture Top w/ Clipper fastener 9 7827991 14

5800 A-1000363 Upper belting 4 X 480 3Ply Texture Top w/ Clipper fastener 9 7827991 18

5800 A-1000350 Optional Upper belting* 10 X 480 2Ply Texture Top w/ Clipper fastener 30

5800 A-1000618 Optional Upper belting* 10 X 480 3Ply Texture Top w/ Clipper fastener 35

JD

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

330, 335, 446,

447 A-1002599 Upper belting 7 X 402.75 3Ply Diamond Top w/ Clipper fastener 2 DC22173 38

330, 335, 446,

447 A-1003290 Upper belting 7 X 402.75 3Ply Diamond w/ Alligator fastener 2 DC22173 38

330, 335, 446,

447 A-1002600 Upper belting 7 X 410.25 3Ply Diamond Top w/ Clipper fastener 4 DC22174 38

330, 335, 446,

447 A-1003289 Upper belting 7 X 410.25 3Ply Diamond w/ Alligator fastener 4 DC22174 38

330, 335, 446,

447 A-1002942 Upper belting 7 X 402.75 3Ply Diamond w/ Titan fastener 2 38

330, 335, 446,

447 A-1003290 Upper belting 7 X 402.75 3Ply Diamond w/ Alligator fastener 2 38

330, 335, 446,

447 A-1002943 Upper belting 7 X 410.25 3Ply Diamond w/ Titan fastener 4 38

330, 335, 446,

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

ROUND BALER BELTING

368

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

JD continued

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

447 A-1003289 Upper belting 7 X 410.25 3Ply Diamond w/ Alligator fastener 4 38

375, 546, 547 A-1002599 Upper belting 7 X 402.75 3Ply Diamond Top w/ Clipper fastener 4 DC22173 38

375, 546, 547 A-1003290 Upper belting 7 X 402.75 3Ply Diamond w/ Alligator fastener 4 DC22173 38

375, 546, 547 A-1002600 Upper belting 7 X 410.25 3Ply Diamond Top w/ Clipper fastener 4 DC22174 38

375, 546, 547 A-1003289 Upper belting 7 X 410.25 3Ply Diamond w/ Alligator fastener 4 DC22174 38

375, 546, 547 A-1002942 Upper belting 7 X 402.75 3Ply Diamond w/ Titan fastener 4 38

375, 546, 547 A-1003290 Upper belting 7 X 402.75 3Ply Diamond w/ Alligator fastener 4 38

375, 546, 547 A-1002943 Upper belting 7 X 410.25 3Ply Diamond w/ Titan fastener 4 38

375, 546, 547 A-1003289 Upper belting 7 X 410.25 3Ply Diamond w/ Alligator fastener 4 38

385, 456, 457 A-1003002 Upper belting 7 X 461 3Ply Diamond Top w/ Clipper fastener 2 43

385, 456, 457 A-1003004 Upper belting 7 X 466.5 3Ply Diamond Top w/ Clipper fastener 4 44

385, 456, 457 A-1003003 Upper belting 7 X 461 3Ply Diamond w/ Titan fastener 2 43

385, 456, 457 A-1003005 Upper belting 7 X 466.5 3Ply Diamond w/ Titan fastener 4 44

556, 557 A-1003002 Upper belting 7 X 461 3Ply Diamond Top w/ Clipper fastener 4 43

556, 557 A-1003004 Upper belting 7 X 466.5 3Ply Diamond Top w/ Clipper fastener 4 44

556, 557 A-1003003 Upper belting 7 X 461 3Ply Diamond w/ Titan fastener 4 43

556, 557 A-1003005 Upper belting 7 X 466.5 3Ply Diamond w/ Titan fastener 4 44

410 A-1000555 Upper belting 4 X 415 2Ply Texture Top w/ Clipper fastener 6 AE35930 12

410 A-1000667 Upper belting 4 X 415 3Ply Texture Top w/ Clipper fastener 6 AE35930 15

410 A-1000586 Upper belting 10 X 415 2Ply Texture Top w/ Clipper fastener 28

410 A-1000698 Upper belting 10 X 415 3Ply Texture Top w/ Clipper fastener 32

410 A-1001742 Upper belting 12 X 417.5 2Ply Texture Top w/ Clipper fastener AE41723 32

410 A-1001743 Upper belting 12 X 417.5 3Ply Texture Top w/ Clipper fastener AE41723 37

410 A-1003566 Lower belting 8 X 74.5 2Ply Texture Top w/ Clipper fastener 5 AE37525 5

410 A-1003281 Lower belting 8 X 74.5 3Ply Texture Top w/ Clipper fastener 5 AE37525 37

430, 435 A-1000388 Upper belting 7 X 525 3Ply Diamond Top w/ Clipper fastener 2 AE40797 49

430, 435 A-1003288 Upper belting 7 X 525 3Ply Diamond w/ Alligator fastener 2 AE40797 49

430, 435 A-1000389 Upper belting 7 X 531 3Ply Diamond Top w/ Clipper fastener 4 AE40798 49

430, 435 A-1003287 Upper belting 7 X 531 3Ply Diamond w/ Alligator fastener 4 AE40798 49

530, 535, 566,

567 A-1000388 Upper belting 7 X 525 3Ply Diamond Top w/ Clipper fastener 4 AE40797 49

530, 535, 566,

567 A-1003288 Upper belting 7 X 525 3Ply Diamond w/ Alligator fastener 4 AE40797 49

530, 535, 566,

567 A-1000389 Upper belting 7 X 531 3Ply Diamond Top w/ Clipper fastener 4 AE40798 49

530, 535, 566,

567 A-1003287 Upper belting 7 X 531 3Ply Diamond w/ Alligator fastener 4 AE40798 49

430, 435 A-1002940 Upper belting 7 X 525 3Ply Diamond w/ Titan fastener 2 AE53295 49

430, 435 A-1003288 Upper belting 7 X 525 3Ply Diamond w/ Alligator fastener 2 AE53295 49

430, 435 A-1002941 Upper belting 7 X 531 3Ply Diamond w/ Titan fastener 4 AE53296 49

430, 435 A-1003287 Upper belting 7 X 531 3Ply Diamond w/ Alligator fastener 4 AE53296 49

530, 535, 566,

567 A-1002940 Upper belting 7 X 525 3Ply Diamond w/ Titan fastener 4 AE53295 49

530, 535, 566,

567 A-1003288 Upper belting 7 X 525 3Ply Diamond w/ Alligator fastener 4 AE53295 49

530, 535, 566,

567 A-1002941 Upper belting 7 X 531 3Ply Diamond w/ Titan fastener 4 AE53296 49

530, 535, 566,

567 A-1003287 Upper belting 7 X 531 3Ply Diamond w/ Alligator fastener 4 AE53296 49

466, 467 A-1000388 Upper belting 7 X 525 3Ply Diamond Top w/ Clipper fastener 2 AE40797 49

466, 467 A-1003288 Upper belting 7 X 525 3Ply Diamond w/ Alligator fastener 2 AE40797 49

466, 467 A-1000389 Upper belting 7 X 531 3Ply Diamond Top w/ Clipper fastener 4 AE40798 49

466, 467 A-1003287 Upper belting 7 X 531 3Ply Diamond w/ Alligator fastener 4 AE40798 49

466, 467 A-1002940 Upper belting 7 X 525 3Ply Diamond w/ Titan fastener 2 AE53295 49

466, 467 A-1003288 Upper belting 7 X 525 3Ply Diamond w/ Alligator fastener 2 AE53295 49

466, 467 A-1002941 Upper belting 7 X 531 3Ply Diamond w/ Titan fastener 4 AE53296 49

466, 467 A-1003287 Upper belting 7 X 531 3Ply Diamond w/ Alligator fastener 4 AE53296 49

500 A-1000556 Upper belting 4 X 422 2Ply Texture Top w/ Clipper fastener 9 AE3390 12

500 A-1000668 Upper belting 4 X 422 3Ply Texture Top w/ Clipper fastener 9 AE3390 16

500 A-1000587 Upper belting 10 X 422 2Ply Texture Top w/ Clipper fastener 28

500 A-1000699 Upper belting 10 X 422 3Ply Texture Top w/ Clipper fastener 16

500 A-1000661 Lower belting/V-Guide 60 X 138 2Ply Texture Top w/ Clipper fastener 1 AE58828 65

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

369

ROUND BALER BELTING

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

JD continued

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

510 A-1000565 Upper belting 4 X 484 2Ply Texture Top w/ Clipper fastener 9 AE35484 14

510 A-1000677 Upper belting 4 X 484 3Ply Texture Top w/ Clipper fastener 9 AE35484 18

510 A-1000595 Upper belting 10 X 484 2Ply Texture Top w/ Clipper fastener 31

510 A-1000619 Upper belting 10 X 484 3Ply Texture Top w/ Clipper fastener 35

510 A-1000650 Upper belting 12 X 486.5 2Ply Texture Top w/ Clipper fastener AE41724 41

510 A-1000624 Upper belting 12 X 486.5 3Ply Texture Top w/ Clipper fastener AE41724 46

510 A-1003566 Lower belting 8 X 74.5 2Ply Texture Top w/ Clipper fastener 7 AE37525 5

510 A-1003281 Lower belting 8 X 74.5 3Ply Texture Top w/ Clipper fastener 7 AE37525 13

MF

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

450 A-1000553 Upper belting 4 X 388 2Ply Texture Top w/ Clipper fastener 8 1047868M93 11

450 A-1000665 Upper belting 4 X 388 3Ply Texture Top w/ Clipper fastener 8 1047868M93 15

450 A-1000582 Upper belting 9 X 388 2Ply Texture Top w/ Clipper fastener 28

450 A-1000694 Upper belting 9 X 388 3Ply Texture Top w/ Clipper fastener 30

450 A-1000658 Lower belting 60 X 120 2Ply Texture Top w/ Clipper fastener 58

560 A-1000559 Upper belting 4 X 440 2Ply Texture Top w/ Clipper fastener 9 1045352M92 13

560 A-1000671 Upper belting 4 X 440 3Ply Texture Top w/ Clipper fastener 9 1045352M92 17

560 A-1000590 Upper belting 10 X 440 2Ply Texture Top w/ Clipper fastener 1096895M91 33

560 A-1000614 Upper belting 10 X 440 3Ply Texture Top w/ Clipper fastener 1096895M91 38

634 A-1002469 Upper belting 6 X 428 2Ply Texture Top w/ Clipper fastener 4 20

634 A-1002470 Upper belting 6 X 428 3Ply Texture Top w/ Clipper fastener 4 23

645 A-1000394 Upper belting 6.5 X 528 2Ply Texture Top w/ Clipper fastener 6 26

645 A-1000395 Upper belting 6.5 X 528 3Ply Texture Top w/ Clipper fastener 6 31

656 A-1000394 Upper belting 6.5 X 528 2Ply Texture Top w/ Clipper fastener 8 26

656 A-1000395 Upper belting 6.5 X 528 3Ply Texture Top w/ Clipper fastener 8 31

822 A-1002717 Front Upper belting 6.375 X 187.8 2Ply Texture Top w/ Clipper fastener 6 9

822 A-1002869 Front Upper belting 6.375 X 187.8 3Ply Mini Rough Top w/ Clipper fastener 6 10

822 A-1002721 Rear Upper belting 6.375 X 226.8 2Ply Texture Top w/ Clipper fastener 6 11

822 A-1002871 Rear Upper belting 6.375 X 226.8 3Ply Mini Rough Top w/ Clipper fastener 6 12

825 A-1000576 Upper belting 6 X 462.5 2Ply Texture Top w/ Clipper fastener 6 20

825 A-1002856 Upper belting 6 X 462.5 3Ply Chevron w/ Clipper fastener 6 25

828 A-1002719 Front Upper belting 6.375 X 211.42 2Ply Texture Top w/ Clipper fastener 6 10

828 A-1002870 Front Upper belting 6.375 X 211.42 3Ply Mini Rough Top w/ Clipper fastener 6 12

828 A-1002723 Rear Upper belting 6.375 X 306.3 2Ply Texture Top w/ Clipper fastener 6 15

828 A-1002872 Rear Upper belting 6.375 X 306.3 3Ply Mini Rough Top w/ Clipper fastener 6 16

834 A-1002719 Front Upper belting 6.375 X 211.42 2Ply Texture Top w/ Clipper fastener 8 10

834 A-1002870 Front Upper belting 6.375 X 211.42 3Ply Mini Rough Top w/ Clipper fastener 8 12

834 A-1002723 Rear Upper belting 6.375 X 306.3 2Ply Texture Top w/ Clipper fastener 8 15

834 A-1002872 Rear Upper belting 6.375 X 306.3 3Ply Mini Rough Top w/ Clipper fastener 8 18

835 A-1002464 Upper belting 6 X 545.5 2Ply Texture Top w/ Clipper fastener 8 24

835 A-1002857 Upper belting 6 X 545.5 3Ply Chevron w/ Clipper fastener 8 30

1440, 1450, 1455 A-1000558 Upper belting 4 X 436 2Ply Texture Top w/ Clipper fastener 8 1045352M92 13

1440, 1450, 1455 A-1000670 Upper belting 4 X 436 3Ply Texture Top w/ Clipper fastener 8 1045352M92 17

1440, 1450, 1455 A-1000390 Upper belting 9 X 436 2Ply Texture Top w/ Clipper fastener 32

1440, 1450, 1455 A-1000391 Upper belting 9 X 436 3Ply Texture Top w/ Clipper fastener 37

1440, 1450, 1455 A-1000589 Upper belting 10 X 436 2Ply Texture Top w/ Clipper fastener 1095895M91 33

1440, 1450, 1455 A-1000613 Upper belting 10 X 436 3Ply Texture Top w/ Clipper fastener 1095895M91 38

1550, 1560, 1565 A-1000567 Upper belting 4 X 512 2Ply Texture Top w/ Clipper fastener 6 1053386M91 14

1550, 1560, 1565 A-1000679 Upper belting 4 X 512 3Ply Texture Top w/ Clipper fastener 6 1053386M91 19

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

ROUND BALER BELTING

370

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

MF continued

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

1550, 1560, 1565 A-1000583 Upper/Options belting 9 X 512 2Ply Texture Top w/ Clipper fastener 3 33

1550, 1560, 1565 A-1000695 Upper/Options belting 9 X 512 3Ply Texture Top w/ Clipper fastener 3 38

1550, 1560, 1565 A-1000597 Upper/Optional belting 10 X 512 2Ply Texture Top w/ Clipper fastener 2 1053387M91 34

1550, 1560, 1565 A-1000621 Upper/Optional belting 10 X 512 3Ply Texture Top w/ Clipper fastener 2 1053387M91 39

McKee

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

875 A-1001610 Upper belting 4.75 X 64.5 2Ply Texture Top w/ Clipper fastener 45 3

875 A-1001611 Upper belting 4.75 X 64.5 3Ply Texure Top w/ Clipper fastener 45 5

875 A-1001612 Lower belting 7 X 104.5 2Ply Texture Top w/ Clipper fastener 6 5

875 A-1001613 Lower belting 7 X 104.5 3Ply Texure Top w/ Clipper fastener 6 7

1500, 1578 A-1000569 Upper belting 4.75 X 73.25 2Ply Texture Top w/ Clipper fastener 55 3

1500, 1578 A-1000685 Upper belting 4.75 X 73.25 3Ply Texure Top w/ Clipper fastener 55 5

1500, 1578 A-1000599 Lower belting 11 X 121.25 2Ply Texture Top w/ Clipper fastener 5 10

1500, 1578 A-1000623 Lower belting 11 X 121.25 3Ply Texure Top w/ Clipper fastener 5 13

1500, 1578 A-1000570 Bk-cleat belting 4.75 X 73.25 2Ply Texture Top w/ Clipper fastener N/A 3

1500, 1578 A-1001744 Bk-cleat belting 4.75 X 73.25 3Ply Texure Top w/ Clipper fastener N/A 5

New Idea

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

483 A-1000397 Lower Belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 12 6

483 A-1000398 Lower Belting 11 X 73.25 3Ply Texture Top w/ Clipper fastener 12 8

484 A-1000399 Lower Belting 11 X 103.5 2Ply Texture Top w/ Clipper fastener 4 9

484 A-1000400 Lower Belting 11 X 103.5 3Ply Texture Top w/ Clipper fastener 4 22

484 A-1000569 Upper Belting 4.75 X 73.25 2Ply Texture Top w/ Clipper fastener 30 104412 3

484 A-1000685 Upper Belting 4.75 X 73.25 3Ply Texture Top w/ Clipper fastener 30 104412 5

484 A-1000399 Lower Belting 11 X 103.5 2Ply Texture Top w/ Clipper fastener 5 9

484 A-1000400 Lower Belting 11 X 103.5 3Ply Texture Top w/ Clipper fastener 5 22

485 A-1000397 Upper Belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 20 105003 6

485 A-1000398 Upper Belting 11 X 73.25 3Ply Texture Top w/ Clipper fastener 20 105003 8

4855 A-1000599 Upper Belting 11 X 121.25 2Ply Texture Top w/ Clipper fastener 4 104108 10

4855 A-1000623 Upper Belting 11 X 121.25 3Ply Texture Top w/ Clipper fastener 4 104108 13

456, 486, 4865 A-1000569 Upper Belting 4.75 X 73.25 2Ply Texture Top w/ Clipper fastener 55 104412 3

456, 486, 4865 A-1000685 Upper Belting 4.75 X 73.25 3Ply Texture Top w/ Clipper fastener 55 104412 5

456, 486, 4865 A-1000397 Upper Belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 25 6

456, 486, 4865 A-1000398 Upper Belting 11 X 73.25 3Ply Texture Top w/ Clipper fastener 25 8

456, 486, 4865 A-1000599 Lower Belting 11 X 121.25 2Ply Texture Top w/ Clipper fastener 5 104411 10

456, 486, 4865 A-1000623 Lower Belting 11 X 121.25 3Ply Texture Top w/ Clipper fastener 5 104411 13

456, 486, 4865 A-1000570 Bk-cleat Belting 4.75 X 73.25 2Ply Texture Top w/ Clipper fastener 104104 3

456, 486, 4865 A-1001744 Bk-cleat Belting 4.75 X 73.25 3Ply Texture Top w/ Clipper fastener 104104 5

4643 A-1001772 Upper Belting 4.8 X 364 2Ply Texture Top w/ Clipper fastener 5 14

4643 A-1000357 Upper Belting 4.8 X 364 3Ply Mini Rough Top w/ Clipper fastener 5 16

4644 A-1002467 Upper Belting 7 X 366 2Ply Texture Top w/ Clipper fastener 6 20

4644 A-1002860 Upper Belting 7 X 366 3Ply Chevron w/ Clipper fastener 6 23

4644 A-1003209 Upper Belting 7 X 366 3Ply Chevron w/ Titan fastener 6 23

4664 A-1002865 Upper Belting 7 X 562.5 2Ply Texture Top w/ Clipper fastener 6 29

4664 A-1002861 Upper Belting 7 X 562.5 3Ply Chevron w/ Clipper fastener 6 36

4664 A-1003211 Upper Belting 7 X 562.5 3Ply Chevron w/ Titan fastener 6 36

4665 A-1002865 Upper Belting 7 X 562.5 2Ply Texture Top w/ Clipper fastener 8 31

4665 A-1002861 Upper Belting 7 X 562.5 3Ply Chevron w/ Clipper fastener 8 36

4665 A-1003211 Upper Belting 7 X 562.5 3Ply Chevron w/ Titan fastener 8 36

6343 A-1001772 Upper Belting 4.8 X 364 2Ply Texture Top w/ Clipper fastener 5 15

6343 A-1000357 Upper Belting 4.8 X 364 3Ply Mini Rough Top w/ Clipper fastener 5 19

6344 A-1002467 Upper Belting 7 X 366 2Ply Texture Top w/ Clipper fastener 6 19

6344 A-1002860 Upper Belting 7 X 366 3Ply Chevron w/ Clipper fastener 6 23

6364 A-1002865 Upper Belting 7 X 562.5 2Ply Texture Top w/ Clipper fastener 6 29

6364 A-1002861 Upper Belting 7 X 562.5 3Ply Chevron w/ Clipper fastener 6 36

6364 A-1003211 Upper Belting 7 X 562.5 3Ply Chevron w/ Titan fastener 6 36

6365 A-1002865 Upper Belting 7 X 562.5 2Ply Texture Top w/ Clipper fastener 6 29

6365 A-1002861 Upper Belting 7 X 562.5 3Ply Chevron w/ Clipper fastener 6 36

6365 A-1003211 Upper Belting 7 X 562.5 3Ply Chevron w/ Titan fastener 6 36

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

371

ROUND BALER BELTING

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

Renn

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

121 A-1001614 Upper Belting 4 X 465 2Ply Texture Top w/ Clipper fastener 4 13

121 A-1001615 Upper Belting 4 X 465 3Ply Texture Top w/ Clipper fastener 4 18

121 A-1001616 Upper Belting 9 X 465 2Ply Texture Top w/ Clipper fastener 2 35

121 A-1001617 Upper Belting 9 X 465 3Ply Texture Top w/ Clipper fastener 2 39

151 A-1001614 Upper Belting 4 X 465 2Ply Texture Top w/ Clipper fastener 6 13

151 A-1001615 Upper Belting 4 X 465 3Ply Texture Top w/ Clipper fastener 6 18

151 A-1001616 Upper Belting 9 X 465 2Ply Texture Top w/ Clipper fastener 2 35

151 A-1001617 Upper Belting 9 X 465 3Ply Texture Top w/ Clipper fastener 2 39

Vermeer

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

403F, 403G A-1000551 Upper Belting 4 X 358 2Ply Texture Top w/ Clipper fastener 6 10

403F, 403G A-1000663 Upper Belting 4 X 358 3Ply Texture Top w/ Clipper fastener 6 13

403F, 403G A-1000581 Upper Belting 9 X 358 2Ply Texture Top w/ Clipper fastener 23

403F, 403G A-1000693 Upper Belting 9 X 358 3Ply Texture Top w/ Clipper fastener 26

503I A-1000392 Upper Belting 6.5 X 431 2Ply Texture Top w/ Clipper fastener 4 17

503I A-1000393 Upper Belting 6.5 X 431 3Ply Texture Top w/ Clipper fastener 4 20

504C A-1000553 Upper Belting 4 X 388 2Ply Texture Top w/ Clipper fastener 8 F-685 11

504C A-1000665 Upper Belting 4 X 388 3Ply Texture Top w/ Clipper fastener 8 F-685 15

504C A-1000582 Upper Belting 9 X 388 2Ply Texture Top w/ Clipper fastener 28

504C A-1000694 Upper Belting 9 X 388 3Ply Texture Top w/ Clipper fastener 30

504F, 504G, 504H A-1000558 Upper Belting 4 X 436 2Ply Texture Top w/ Clipper fastener 8 826-003 12

504F, 504G, 504H A-1000670 Upper Belting 4 X 436 3Ply Texture Top w/ Clipper fastener 8 826-003 16

504F, 504G, 504H A-1000589 Upper Belting 10 X 436 2Ply Texture Top w/ Clipper fastener 4075-001 33

504F, 504G, 504H A-1000613 Upper Belting 10 X 436 3Ply Texture Top w/ Clipper fastener 4075-001 37

504F, 504G, 504H A-1000390 Upper Belting 9 X 436 2Ply Texture Top w/ Clipper fastener 31

504F, 504G, 504H A-1000391 Upper Belting 9 X 436 3Ply Texture Top w/ Clipper fastener 35

504I A-1002469 Upper Belting 6 X 428 2Ply Texture Top w/ Clipper fastener 6 20

504I A-1002470 Upper Belting 6 X 428 3Ply Texture Top w/ Clipper fastener 6 23

505I A-1002569 Upper Belting 6 X 424 2Ply Texture Top w/ Clipper fastener 8 20

505I A-1002570 Upper Belting 6 X 424 3Ply Texture Top w/ Clipper fastener 8 23

505I A-1002569 Upper Belting 6 X 424 2Ply Texture Top w/ Clipper fastener 2 Optional 20

505I A-1002570 Upper Belting 6 X 424 3Ply Texture Top w/ Clipper fastener 2 Optional 23

505I A-1002563 Upper Belting 14 X 424 2Ply Texture Top w/ Clipper fastener 3 Optional 47

505I A-1002564 Upper Belting 14 X 424 3Ply Texture Top w/ Clipper fastener 3 Optional 54

5400 A-1002563 Upper Belting 14 X 424 2Ply Texture Top w/ Clipper fastener 2 47

5400 A-1002564 Upper Belting 14 X 424 3Ply Texture Top w/ Clipper fastener 2 54

5400 A-1002569 Upper Belting 6 X 424 2Ply Texture Top w/ Clipper fastener 2 20

5400 A-1002570 Upper Belting 6 X 424 3Ply Texture Top w/ Clipper fastener 2 23

5500 A-1002563 Upper Belting 14 X 424 2Ply Texture Top w/ Clipper fastener 3 47

5500 A-1002564 Upper Belting 14 X 424 3Ply Texture Top w/ Clipper fastener 3 54

5500 A-1002569 Upper Belting 6 X 424 2Ply Texture Top w/ Clipper fastener 2 20

5500 A-1002570 Upper Belting 6 X 424 3Ply Texture Top w/ Clipper fastener 2 23

554XL A-1003791 Upper Belting 14 X 450 2Ply Texture Top w/ Clipper fastener 2 48

554XL A-1003794 Upper Belting 14 X 450 3Ply Texture Top w/ Clipper fastener 2 60

554XL A-1003792 Upper Belting 16 X 450 2Ply Texture Top w/ Clipper fastener 2 55

554XL A-1003795 Upper Belting 16 X 450 3Ply Texture Top w/ Clipper fastener 2 68

555XL A-1003791 Upper Belting 14 X 450 2Ply Texture Top w/ Clipper fastener 3 48

555XL A-1003794 Upper Belting 14 X 450 3Ply Texture Top w/ Clipper fastener 3 60

555XL A-1003793 Upper Belting 6 X 450 2Ply Texture Top w/ Clipper fastener 2 21

555XL A-1003796 Upper Belting 6 X 450 3Ply Texture Top w/ Clipper fastener 2 24

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

ROUND BALER BELTING

372

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

Vermeer continued

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

604XL A-1002565 Upper Belting 14 X 528 2Ply Texture Top w/ Clipper fastener 2 56

604XL A-1002566 Upper Belting 14 X 528 3Ply Texture Top w/ Clipper fastener 2 70

604XL A-1000394 Upper Belting 6.5 X 528 2Ply Texture Top w/ Clipper fastener 2 26

604XL A-1000395 Upper Belting 6.5 X 528 3Ply Texture Top w/ Clipper fastener 2 31

605A A-1000554 Upper Belting 4 X 400 2Ply Texture Top w/ Clipper fastener 9 F-158 11

605A A-1000666 Upper Belting 4 X 400 3Ply Texture Top w/ Clipper fastener 9 F-158 13

605A A-1000585 Upper Belting 10 X 400 2Ply Texture Top w/ Clipper fastener 30

605A A-1000697 Upper Belting 10 X 400 3Ply Texture Top w/ Clipper fastener 34

605B A-1000552 Upper Belting 4 X 387 2Ply Texture Top w/ Clipper fastener 9 F-1670 11

605B A-1000664 Upper Belting 4 X 387 3Ply Texture Top w/ Clipper fastener 9 F-1670 15

605B A-1000625 Upper Belting 10 X 387 2Ply Texture Top w/ Clipper fastener 24

605B A-1000626 Upper Belting 10 X 387 3Ply Texture Top w/ Clipper fastener 29

605A, 605B A-1000658 Lower Belting 60 X 120 2Ply Texture Top w/ Clipper fastener 1 58

605C A-1000559 Upper Belting 4 X 440 2Ply Texture Top w/ Clipper fastener 9 F-894 13

605C A-1000671 Upper Belting 4 X 440 3Ply Texture Top w/ Clipper fastener 9 F-894 17

605C A-1000590 Upper Belting 10 X 440 2Ply Texture Top w/ Clipper fastener 33

605C A-1000614 Upper Belting 10 X 440 3Ply Texture Top w/ Clipper fastener 38

605D A-1000560 Upper Belting 4 X 450 2Ply Texture Top w/ Clipper fastener 9 F-1447 13

605D A-1000672 Upper Belting 4 X 450 3Ply Texture Top w/ Clipper fastener 9 F-1447 17

605D A-1000591 Upper Belting 10 X 450 2Ply Texture Top w/ Clipper fastener 34

605D A-1000615 Upper Belting 10 X 450 3Ply Texture Top w/ Clipper fastener 39

605E A-1000562 Upper Belting 4 X 457 2Ply Texture Top w/ Clipper fastener 5 13

605E A-1000674 Upper Belting 4 X 457 3Ply Texture Top w/ Clipper fastener 5 17

605E A-1000592 Upper Belting 10 X 457 2Ply Texture Top w/ Clipper fastener 2 35

605E A-1000616 Upper Belting 10 X 457 3Ply Texture Top w/ Clipper fastener 2 39

605E A-1000559 Upper Belting 4 X 440 2Ply Texture Top w/ Clipper fastener 5 13

605E A-1000671 Upper Belting 4 X 440 3Ply Texture Top w/ Clipper fastener 5 17

605E A-1000590 Upper Belting 10 X 440 2Ply Texture Top w/ Clipper fastener 2 33

605E A-1000614 Upper Belting 10 X 440 3Ply Texture Top w/ Clipper fastener 2 38

605F, 605G, 605H A-1000567 Upper Belting 4 X 512 2Ply Texture Top w/ Clipper fastener 6 1826-001 14

605F, 605G, 605H A-1000679 Upper Belting 4 X 512 3Ply Texture Top w/ Clipper fastener 6 1826-001 19

605F, 605G, 605H A-1000583 Upper Belting 9 X 512 2Ply Texture Top w/ Clipper fastener 3 32

605F, 605G, 605H A-1000695 Upper Belting 9 X 512 3Ply Texture Top w/ Clipper fastener 3 37

605F, 605G, 605H A-1000597 Upper Belting 10 X 512 2Ply Texture Top w/ Clipper fastener 2 34

605F, 605G, 605H A-1000621 Upper Belting 10 X 512 3Ply Texture Top w/ Clipper fastener 2 39

605F, 605G, 605H A-1000394 Upper Belting 6.5 X 528 2Ply Texture Top w/ Clipper fastener 6 23

605F, 605G, 605H A-1000395 Upper Belting 6.5 X 528 3Ply Texture Top w/ Clipper fastener 6 28

604K A-1000394 Upper Belting 6.5 X 528 2Ply Texture Top w/ Clipper fastener 2 26

604K A-1000395 Upper Belting 6.5 X 528 3Ply Texture Top w/ Clipper fastener 2 31

604K A-1002565 Upper Belting 14 X 528 2Ply Texture Top w/ Clipper fastener 2 56

604K A-1002566 Upper Belting 14 X 528 3Ply Texture Top w/ Clipper fastener 2 70

605J A-1000394 Upper Belting 6.5 X 528 2Ply Texture Top w/ Clipper fastener 8 26

605J A-1000395 Upper Belting 6.5 X 528 3Ply Texture Top w/ Clipper fastener 8 31

605J A-1003338 Upper Belting 6.5 X 542 2Ply Texture Top w/ Clipper fastener 8 28

605J A-1003339 Upper Belting 6.5 X 542 3Ply Texture Top w/ Clipper fastener 8 32

605K A-1000394 Upper Belting 6.5 X 528 2Ply Texture Top w/ Clipper fastener 2 26

605K A-1000395 Upper Belting 6.5 X 528 3Ply Texture Top w/ Clipper fastener 2 31

605K A-1002565 Upper Belting 14 X 528 2Ply Texture Top w/ Clipper fastener 3 56

605K A-1002566 Upper Belting 14 X 528 3Ply Texture Top w/ Clipper fastener 3 70

605XL A-1002565 Upper Belting 14 X 528 2Ply Texture Top w/ Clipper fastener 3 56

605XL A-1002566 Upper Belting 14 X 528 3Ply Texture Top w/ Clipper fastener 3 70

605XL A-1000394 Upper Belting 6.5 X 528 2Ply Texture Top w/ Clipper fastener 2 26

605XL A-1000395 Upper Belting 6.5 X 528 3Ply Texture Top w/ Clipper fastener 2 31

706A A-1000566 Upper Belting 4 X 493 2Ply Texture Top w/ Clipper fastener 11 F-329 14

706A A-1000678 Upper Belting 4 X 493 3Ply Texture Top w/ Clipper fastener 11 F-329 17

706A A-1000596 Upper Belting 10 X 493 2Ply Texture Top w/ Clipper fastener 37

706A A-1000620 Upper Belting 10 X 493 3Ply Texture Top w/ Clipper fastener 43

706C A-1000568 Upper Belting 4 X 541 2Ply Texture Top w/ Clipper fastener 12 F-1037 15

706C A-1000680 Upper Belting 4 X 541 3Ply Texture Top w/ Clipper fastener 12 F-1037 20

706C A-1000598 Upper Belting 10 X 541 2Ply Texture Top w/ Clipper fastener 41

706C A-1000622 Upper Belting 10 X 541 3Ply Texture Top w/ Clipper fastener 45

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

373

ROUND BALER BELTING

A&I PRODUCTS fax: 1-800-511-0516 e-mail: sales@aiproducts.com 1-800-657-4343

Vicon

MODELS PA R T DESCRIPTION SIZE (INCH) PLY/TEXTURE #BELTS REPL WT

260 A-1001618 Upper Belting 7 X 64.5 2Ply Texture Top w/ Clipper fastener 30 6

260 A-1001619 Upper Belting 7 X 64.5 3Ply, clupper lacing w/ Clipper fastener 30 8

260 A-1001612 Lower Belting 7 X 104.5 2Ply Texture Top w/ Clipper fastener 6 9

260 A-1001613 Lower Belting 7 X 104.5 3Ply, clupper lacing w/ Clipper fastener 6 12

560 A-1000397 Upper Belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 25 6

560 A-1000398 Upper Belting 11 X 73.25 3Ply, clupper lacing w/ Clipper fastener 25 8

560 A-1000599 Lower Belting 11 X 121.25 2Ply Texture Top w/ Clipper fastener 5 10

560 A-1000623 Lower Belting 11 X 121.25 3Ply, clupper lacing w/ Clipper fastener 5 13

1200 A-1001614 Upper Belting 4 X 465 2Ply Texture Top w/ Clipper fastener 4 13

1200 A-1001615 Upper Belting 4 X 465 3Ply, clupper lacing w/ Clipper fastener 4 18

1200 A-1001616 Upper Belting 9 X 465 2Ply Texture Top w/ Clipper fastener 2 35

1200 A-1001617 Upper Belting 9 X 465 3Ply, clupper lacing w/ Clipper fastener 2 39

RP1210 A-1001610 Upper Belting 4.75 X 64.75 2Ply Texture Top w/ Clipper fastener 45 3

RP1210 A-1001611 Upper Belting 4.75 X 64.75 3Ply, clupper lacing w/ Clipper fastener 45 5

RP1210 A-1001618 Upper Belting 7 X 64.75 2Ply Texture Top w/ Clipper fastener 30 6

RP1210 A-1001619 Upper Belting 7 X 64.75 3Ply, clupper lacing w/ Clipper fastener 30 8

RP1210 A-1001612 Lower Belting 7 X 104.5 2Ply Texture Top w/ Clipper fastener 6 9

RP1210 A-1001613 Lower Belting 7 X 104.5 3Ply, clupper lacing w/ Clipper fastener 6 12

RP1211 A-1000627 Upper Belting 7.28 X 64.8 2Ply Texture Top w/ Clipper fastener 25 6

RP1211 A-1002479 Upper Belting 7.28 X 64.8 3Ply, clupper lacing w/ Clipper fastener 25 8

RP1211 A-1000631 Lower Belting 7.28 X 96.85 2Ply Texture Top w/ Clipper fastener 5 6

RP1211 A-1002480 Lower Belting 7.28 X 96.85 3Ply, clupper lacing w/ Clipper fastener 5 8

RP1510 A-1000569 Upper Belting 4.75 X 73.25 2Ply Texture Top w/ Clipper fastener 55 3

RP1510 A-1000685 Upper Belting 4.75 X 73.25 3Ply, clupper lacing w/ Clipper fastener 55 5

RP1510 A-1000599 Lower Belting 11 X 121.25 2Ply Texture Top w/ Clipper fastener 5 10

RP1510 A-1000623 Lower Belting 11 X 121.25 3Ply, clupper lacing w/ Clipper fastener 5 13

RP1510 A-1000397 Upper Belting 11 X 73.25 2Ply Texture Top w/ Clipper fastener 25 6

RP1510 A-1000398 Upper Belting 11 X 73.25 3Ply, clupper lacing w/ Clipper fastener 25 8

RP1510 A-1000599 Lower Belting 11 X 121.25 2Ply Texture Top w/ Clipper fastener 5 10

RP1510 A-1000623 Lower Belting 11 X 121.25 3Ply, clupper lacing w/ Clipper fastener 5 13

RP1511 A-1002481 Upper Belting 11 X 75.75 2Ply Texture Top w/ Clipper fastener 25 11

RP1511 A-1002482 Upper Belting 11 X 75.75 3Ply, clupper lacing w/ Clipper fastener 25 14

RP1511 A-1002483 Upper Belting 11 X 112 2Ply Texture Top w/ Clipper fastener 5 14

RP1511 A-1002484 Upper Belting 11 X 112 3Ply, clupper lacing w/ Clipper fastener 5 17

RV1501 A-1003797 Upper Belting 8.46 X 403.54 2Ply Texture Top w/ Clipper fastener 5 28

RV1501 A-1003803 Upper Belting 8.46 X 403.54 3Ply, clupper lacing w/ Clipper fastener 5 32

RV1501 A-1003800 Upper Belting 8.46 X 403.54 3Ply, clupper lacing w/ Clipper fastener 5 32

RV1601 A-1003798 Upper Belting 8.46 X 421.26 2Ply Texture Top w/ Clipper fastener 5 29

RV1601 A-1003804 Upper Belting 8.46 X 421.26 3Ply, clupper lacing w/ Clipper fastener 5 33

RV1601 A-1003801 Upper Belting 8.46 X 421.26 3Ply, clupper lacing w/ Clipper fastener 5 33

RV1901 A-1003799 Upper Belting 8.46 X 472.44 2Ply Texture Top w/ Clipper fastener 5 32

RV1901 A-1003805 Upper Belting 8.46 X 472.44 3Ply, clupper lacing w/ Clipper fastener 5 37

RV1901 A-1003802 Upper Belting 8.46 X 472.44 3Ply, clupper lacing w/ Clipper fastener 5 37

BELTING

A&I parts are not original parts, and are not sponsored affiliated or otherwise connected with any major brand.

ROUND BALER BELTING

374

|

SICKLE SECTIONS - CASE-IH

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-211-003 |black 14ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |1145

|A-212-063 |chrome 14ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |604800

|A-211-011 |black 11ga smooth |3.250" |2.062" |1" |7/32 x 5/8 |26622

|A-212-131 |chrome 11ga smooth |3.250" |2.062" |1" |7/32 x 5/8 |457605R3

|A-211-001 |black 11ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |29875

|A-212-061 |chrome 11ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |060635

|A-211-211 |black 11ga top serrated, 2 hole |3.250" |2.062" |1" |7/32 x 5/8 |9622744

|A-231-211 |black 11ga big tooth, 2 hole |3.250" |2.062" |1" |7/32 x 5/8 |124737BT

|A-231-461 |black 11ga saber tooth |3.250" |2.062" |1" |7/32 x 5/8 |9622744ST

|A-212-001 |chrome 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |700705300

|A-232-001 |chrome 11ga big tooth |3.250" |2.062" |1" |7/32 x 5/8 |700705300BT

|A-232-461 |chrome 11ga saber tooth |3.250" |2.062" |1" |7/32 x 5/8 |9826090ST

|A-612-140 |(10) RH end sections, chrm top ser |end section |||7/32 x 5/8 |148200C1

|A-612-150 |(10) RH end sections, chrm top ser |3 hole |||7/32 x 5/8 |700705463

|A-612-090 |(10) LH end sections, chrm top ser |end section |||7/32 x 5/8 |700705462

SICKLE PARTS - CASE-IH

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-012 |Sickle Head |MA999 |

|A-901-011 |Sickle Head |56692C91 |(MOWER: CUTTER PARTS balanced head)

|A-901-075 |Sickle Head |ZA502562 |(MOWER CONDITIONER: 1490, 1590)

|A-901-042 |Sickle Head |824594C91 |(WINDROWER: 4000, 5000)

|A-901-018 |Sickle Head, LH |6821078 |(WINDROWER: 8820, 8320, 8330, 8350)

|A-901-019 |Sickle Head, RH |6821136 |(WINDROWER: 8820)

|A-901-013 |Sickle Head |540607R11 |(MOWER CONDITIONER: 990)

|A-901-120 |Sickle Head, LH |700111003 |(WINDROWER: 8820, 8830, 8840, 8360, 8370, 8330, 8340)

|A-901-137 |Sickle Head, RH |700116709 |(WINDROWER: 8820, 8830, 8840)

|A-901-158 |Sickle Head |823710C1 |(WINDROWER: 375, 275)

|A-901-130 |Sickle Head, RH/LH |700114594 |(WINDROWER: 8840, 8380)

|A-920-223 |Bearing |176699C91 |(WINDROWER: 810, 820)

|A-920-130 |Bronze Bushing |458971R1 |(MOWER: SERIES 100)

|A-920-136 |Head Plug |458972R1 |(MOWER: CUTTER PARTS balanced head)

|A-920-314 |Knifehead Pin |458973R4 |(WINDROWER: 1100, 1300)

|A-725-001 |Knifehead Pin Kit |176699C91 |

|A-529-016 |Wear Plate |71116532, 71176537 |

|A-920-159 |Head Wear Plate |MB22863 |(MOWER: CUTTER PARTS)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES & PARTS

|A-920-101 |Center Guard |50HS4A, 143HSA |

|A-920-102 |Outer Guard ||

|A-920-126 |Ledger Plate |455634R1 |(MOWER: CUTTER PARTS)

|A-904-520 |(50) 7/16x1-1/2" bolts ||

|A-904-521 |(50) 7/16x1-3/4" bolts ||

|A-920-127 |Outer Shoe Plate |MA330 |(MOWER: CUTTER PARTS)

|A-920-343 |Inner Shoe Plate |458965R1 |(MOWER: CUTTER PARTS)

|A-920-146 |Inner Sole |MC465 |(MOWER: CUTTER PARTS)

|A-920-140 |Rear Guide, Upper |M22161 |(MOWER: CUTTER PARTS)

|A-M22184 |Pitman Wood 35.687" |M22184 |(MOWER: 16, 24, 32)

|A-M32119 |Pitman Wood 35.687" |M32119 |(MOWER: 25V, 27V, 27VA)

|A-920-128 |Pitman Strap, front |MA1577 |(MOWER: CUTTER PARTS)

|A-920-129 |Pitman Strap, rear |M1578 |(MOWER: CUTTER PARTS)

|A-920-182 |(10) Shims |6821052 |

|A-515-046 |Malleable Knife Clip |MA812, XL1000 |(MOWER: CUTTER PARTS for riveted sickle only)

|A-515-026 |Malleable Knife Clip |MB812, XA1000, 611759R1 |(MOWER: CUTTER PARTS for riveted sickle only)

|A-515-126 |Knifehead Clip |611759R1, 595648R1 |(MOWER: CUTTER PARTS for bolted sickle only)

|A-515-016 |Knife Clip |71176540 |(MOWER: CUTTER PARTS floating headers, Gen II & III HC)

|A-515-066 |Knife Clip |61384282 |(MOWER: CUTTER PARTS)

|A-904-022 |(1lb) 7/32 x 5/8" OH rivet |700000883 |(MOWER: CUTTER PARTS for extra heavy sections)

|A-904-500 |(50) 7/32 x 5/8" Bolt & Nut |700705296 |(MOWER: CUTTER PARTS for standard straight hole sections)

|A-904-525 |(50) 7/32 x 5/8" 60° CTSK Bolt & Nut |700002978 |(MOWER: CUTTER PARTS for J.E.Love & Hart Carter)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-800-071 |black 11ga under serrated |5 ft. |MA999 |1958205C1 |826722C2

|A-801-073 |A-800-073 |black 11ga under serrated |6 ft. |501015E |501012ESXH |501017EXH

|A-801-074 |A-800-074 |black 11ga smooth |7 ft. |501015E |501013ESXH |501016EXH

|A-801-076 |A-800-076 |black 11ga under serrated |7 ft. |MA999 |1958207C1 |826722C2

|A-801-078 |A-800-078 |black 11ga smooth |9 ft. |MA999 |463293R91 |826724C2

|A-801-079 |A-800-079 |black 11ga under serrated |9 ft. |MA999 |463294R91 |826722C2

For Models:

(MOWER: CUTTER PARTS except series 100 balanced heads)

|A-801-064 |A-800-064 |black 11ga under serrated |5 ft. |56692C91 |463408R93 |826722C2

|A-801-065 |A-800-065 |black 11ga under serrated |6 ft. |56692C91 |465112R93 |826722C2

|A-801-060 |A-800-060 |black 11ga smooth |7 ft. |56692C91 |462381R93 |826724C2

|A-801-066 |A-800-066 |black 11ga under serrated |7 ft. |56692C91 |462380R93 |826722C2

|A-801-691 |A-800-691 |black 11top serrated |7 ft. |56692C91 |1281292C92 |826720C3

|A-861-010 |N/A |black 11ga big tooth |7 ft. |56692C91 |1281292C92BT |826720C3BT

|A-801-061 |A-800-061 |black 11ga smooth |9 ft. |56692C91 |463182R93 |826724C2

|A-801-692 |A-800-692 |black 11top serrated |9 ft. |56692C91 |1281291C92 |826720C3

|A-861-527 |N/A |black 11ga big tooth |9 ft. |56692C91 |1281291C92BT |826720C3BT

For Models:

(MOWER: SERIES 100 balanced heads, 1100, 1130)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-245 |A-800-245 |chrome 14ga top serrated |7 ft. |451948 |6193510 |049213

|A-801-246 |A-800-246 |chrome 14ga top serrated |9 ft. |451948 |451955 |049213

|A-801-247 |A-800-247 |chrome 12ga top serrated |9 ft. |451948 |6566178 |049254

For Models:

(MOWER CONDITIONER: 555)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-399 |A-800-399 |black 11ga under serrated |7 ft. |540607R11 |542816R92 |826722C2

|A-801-080 |A-800-080 |black 11ga under serrated |9 ft. |540607R11 |540605R92 |826722C2

|A-831-865 |A-830-865 |black 11ga top serrated |9 ft. |540607R11 |540605R92BL |826720C3

For Models:

(MOWER CONDITIONER: 990)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-400 |A-800-400 |black 11ga under serrated |7 ft. |824594C91 |101987C95 |W501017E

|A-801-306 |A-800-306 |black 11ga under serrated |9 ft. |824594C91 |101988C95 |W501017E

|A-831-869 |A-830-869 |black 11ga under serrated |9 ft. |824594C91 |1960310C1 |W501017ETS

For Models:

(MOWER CONDITIONER: 1190)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-084 |A-800-084 |chrome 11ga under serrated |12 ft. |823710C1 |595650R93, 824427C92 |457607R3

For Models:

(MOWER CONDITIONER: 1290)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-764 |A-800-764 |chrome 11ga under serrated |12 ft. |ZA502562 |ZA502930, ZA502889 |502933

|A-801-765 |A-800-765 |chrome 11ga under serrated |14 ft. |ZA502562 |ZA502931, ZA502890 |502933

For Models:

(MOWER CONDITIONER: 1490 (12'), 1590 (14'))

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-778 |A-800-778 |chrome 11ga under serrated |7 ft. |6821078 |700111432 |700705300

|A-801-779 |A-800-779 |chrome 11ga under serrated |9 ft. |6821078 |700111430 |700705300

|A-831-904 |N/A |black 11ga under serrated |9 ft. |6821078 |700111430BL |700705299

|A-801-540 |A-800-540 |chrome 11ga under serrated |12 ft. |6821078 |700109341 |700705300

|A-831-906 |N/A |black 11ga under serrated |12 ft. |6821078 |700109341BL |700705299

For Models:

(MOWER CONDITIONER: 8320 (7'), 8330 (9'), 8350 (12'))

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-984 |N/A |chrome 11ga top serrated |9 ft. |700111003 |700118673 |700705300

For Models:

(MOWER CONDITIONER: 8340)

|A-801-742 |N/A |chrome 11ga top serrated |9 ft. |Headless |700118671 |700705300

|A-831-905 |N/A |black 11ga top serrated |9 ft. |700111003 |700118673BL |700705299

For Models:

(MOWER CONDITIONER: 8340)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-308 |A-800-308 |chrome 11ga under serrated |12-1/2 ft. |824594C91 |827813C92 |457607R3

|A-801-309 |A-800-309 |chrome 11ga under serrated |14-1/2 ft. |824594C91 |827814C92 |457607R3

|A-801-771 |A-800-771 |chrome 11ga top serrated |14-1/2 ft. |824594C91 |831607C94 |700705300

|A-861-534 |A-860-534 |black 11ga top serrated |14-1/2 ft. |824594C91 |831607C94BL |826720C3

|A-801-310 |A-800-310 |chrome 11ga under serrated |16-1/2 ft. |824594C91 |827815C92 |457607R3

|A-831-870 |A-830-870 |black 11ga top serrated |16-1/2 ft. |824594C91 |827815C92BL |826720C3

|A-861-102 |A-860-102 |chrome 11ga top serrated |16-1/2 ft. |824594C91 |827815C92TS |700705300

|A-801-535 |A-800-535 |chrome 11ga under serrated |19-1/2 ft. |824594C91 |827816C92 |457607R3

|A-831-871 |A-830-871 |black 11ga top serrated |19-1/2 ft. |824594C91 |827816C92BL |826720C3

|A-801-372 |A-800-372 |chrome 11ga under serrated |24-1/2 ft. 1 pc. |824594C91 |827830C92 |457607R3

|A-831-872 |A-830-872 |black 11ga top serrated |24-1/2 ft. 1 pc. |824594C91 |827830C92BL |826720C3

|A-861-105 |A-860-105 |chrome 11ga top serrated |24-1/2 ft. 1 pc. |824594C91 |827830C92TS |700705300

For Models:

(WINDROWER: (230, 4000, 500 ALL w/ single auger or 12' - 24' draper header), 210 SN 3700>)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-516 |A-800-516 |chrome 11ga under serrated |13 ft |STUDS |271981PLBT |457607R3

|A-831-866 |A-830-866 |black 11ga top serrated |12 ft. |824594C91 |827724C92BL |826720C3

|A-801-517 |A-800-517 |chrome 11ga under serrated |15 ft |STUDS |271981PLBT |457607R3

|A-801-848 |A-800-848 |chrome 11ga top serrated |14 ft. |824594C91 |827701C92 |700705300

|A-831-458 |A-830-458 |chrome 11ga big tooth |14 ft. |824594C91 |827701C92BT |700705300BT

|A-831-867 |A-830-867 |black 11ga top serrated |14 ft. |824594C91 |827701C92BL |826720C3

|N/A |A-800-518 |chrome 11ga under serrated |16 ft. |824594C91 |827726C92 |457607R3

|A-831-868 |A-830-868 |black 11ga top serrated |16 ft. |824594C91 |827726C92BL |826720C3

For Models:

(WINDROWER: (4000, 5000, 5500 ALL w/ dual auger headers))

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-657 |A-800-657 |chrome 14ga under serrated |15 ft. |Headless |16641PL |7253

|A-801-490 |A-800-490 |chrome 14ga under serrated |18 ft. |Headless |824874C91 |457606R3

|A-801-491 |A-800-491 |chrome 14ga under serrated |21 ft. |Headless |824875C91 |457606R3

|A-801-658 |A-800-658 |chrome 14ga under serrated |25 ft. |Headless |824699C91 |457606R3

For Models:

(WINDROWER: 75 pull)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-084 |A-800-084 |chrome 11ga under serrated |12 ft. |823710C1 |595650R93, 824427C92 |457607R3

|A-801-085 |A-800-085 |chrome 11ga under serrated |14 ft. |823710C1 |595651R93 |457607R3

For Models:

(WINDROWER: 275, 375)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-772 |A-800-772 |chrome 11ga top serrated |21 ft. |Headless |90966C91 |700705300

|A-801-773 |A-800-773 |chrome 11ga top serrated |26 ft. 1 pc. |Headless |80648C91 |700705300

|A-801-774 |A-800-774 |chrome 11ga top serrated |31 ft. 1 pc. |Headless |80650C91 |700705300

For Models:

(WINDROWER: 721, 725, 730, 736, 742, 750, 6000, 6500)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-237 |A-800-237 |chrome 14ga top serrated |12 ft. |379370 |373522 |049213

|A-801-239 |A-800-239 |chrome 14ga top serrated |14 ft. |379370 |373530 |049213

|A-801-241 |A-800-241 |chrome 12ga top serrated |14 ft. |379370 |373530H |049254

|A-801-243 |A-800-243 |chrome 14ga top serrated |16 ft. |379370 |373548 |049213

For Models:

(WINDROWER: 950, 955, 1050, 1055, 1150, 1155)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-248 |A-800-248 |chrome 14ga top serrated |10 ft. |6193577, 6497416 |6193619 |049213

|A-801-249 |A-800-249 |chrome 14ga top serrated |12 ft. |6193577, 6497416 |6193627 |049213

|A-801-250 |A-800-250 |chrome 14ga top serrated |12 ft. |Headless |6206023 |049213

|A-801-251 |A-800-251 |chrome 12ga top serrated |12 ft. |6193577, 6497416 |6272959 |049254

|A-801-252 |A-800-252 |chrome 12ga top serrated |12 ft. |Headless |6497457 |049254

|A-861-054 |N/A |chrome 11ga big tooth |12 ft. |6497416 |6196327BT |700705300BT

|A-801-253 |A-800-253 |chrome 14ga top serrated |14 ft. |6193577, 6497416 |6193635 |049213

|A-801-254 |A-800-254 |chrome 14ga top serrated |14 ft. |Headless |6206031 |049213

|A-801-255 |A-800-255 |chrome 12ga top serrated |14 ft. |6193577, 6497416 |6272967 |049254

|A-801-256 |A-800-256 |chrome 12ga top serrated |14 ft. |Headless |6497465 |049254

|A-801-706 |N/A |black 11ga top serrated |14 ft. |Headless |6497465BL |700705299

|A-861-060 |N/A |chrome 11ga big tooth |14 ft. |Headless |6497465BT |700705300BT

|A-801-728 |N/A |black 11ga top serrated |14 ft. |6497416 |6272967BL |700705299

|A-801-397 |A-800-397 |chrome 12ga top serrated |14 ft. |6497416 |6497119 |049254

|A-831-508 |N/A |chrome 11ga big tooth |14 ft. |6497416 |6497119BT |700705300BT

|A-801-388 |A-800-388 |chrome 12ga top serrated |16 ft. |6497416 |6497374 |049254

|A-801-257 |A-800-257 |chrome 12ga top serrated |16 ft. |Headless |6497473 |049254

|A-801-707 |N/A |black 11ga top serrated |16 ft. |Headless |6497473BL |700705299

|A-831-509 |N/A |chrome 11ga big tooth |16 ft. |6497416 |6497374BT |700705300BT

For Models:

(WINDROWER: 1075, 1085, 1275)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-826 |A-800-826 |chrome 11ga top serrated |12 ft. |700111003 |700110730 |700705300

|A-801-928 |A-800-928 |chrome 11ga top serrated |12 ft. |Headless |700115887 |700705300

|A-831-514 |A-830-514 |chrome 11ga big tooth |12 ft. |700111003 |700110730BT |700705300BT

|A-831-907 |N/A |black 11ga top serrated |12 ft. |700111003 |700110730BL |700705299

|A-801-780 |A-800-780 |chrome 11ga top serrated |14 ft. |700111003 |700110731 |700705300

|A-801-781 |A-800-781 |chrome 11ga top serrated |14 ft. |Headless |700115804 |700705300

|A-831-515 |A-830-515 |chrome 11ga big tooth |14 ft. |700111003 |700110731BT |700705300BT

|A-831-908 |N/A |black 11ga top serrated |14 ft. |700111003 |700110731BL |700705299

For Models:

(WINDROWER: 8360 w/ 12' enter pivot, 8370 w/ 14' enter pivot, 8830 w/ 12' & 14' enter pivot)

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-861-511 |N/A |black 11ga top serrated |8 ft. LH |700111003 |700709646BL |700705299

For Models:

(WINDROWER: (8820, 8830, 8840 ALL w/ 15', 18', 21' draper headers))

|A-861-512 |N/A |black 11ga top serrated |7 ft. RH |700116709 |700709647BL |700705299

|A-861-513 |N/A |black 11ga top serrated |9 ft. LH |700111003 |700709648BL |700705299

|A-861-514 |N/A |black 11ga top serrated |9 ft. RH |700116709 |700709649BL |700705299

|A-801-973 |A-800-973 |chrome 12ga top serrated |11 ft. LH |700116003 |700709650 |049254

|A-801-974 |A-800-974 |chrome 12ga top serrated |10 ft. RH |700116709 |700709651 |049254

|A-861-515 |N/A |black 11ga top serrated |11 ft. LH |700116003 |700709650BL |700705299

|A-861-516 |N/A |black 11ga top serrated |10 ft. RH |700116709 |700709651BL |700705299

For Models:

(WINDROWER: (8820, 8830, 8840 ALL w/ 15', 18', 21' draper headers))

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-973 |A-800-973 |chrome 12ga top serrated |11 ft. LH |700116003 |700709650 |049254

|A-801-974 |A-800-974 |chrome 12ga top serrated |10 ft. RH |700116709 |700709651 |049254

|A-861-515 |N/A |black 11ga top serrated |11 ft. LH |700116003 |700709650BL |700705299

|A-861-516 |N/A |black 11ga top serrated |10 ft. RH |700116709 |700709651BL |700705299

|A-861-517 |N/A |black 11ga top serrated |13 ft. LH |700116003 |700709652BL |700705299

|A-861-518 |N/A |black 11ga top serrated |12 ft. RH |700116709 |700709653BL |700705299

|A-861-519 |N/A |black 11ga top serrated |15 ft. LH |700116003 |700709654BL |700705299

|A-861-520 |N/A |black 11ga top serrated |15 ft. RH |700116709 |700709655BL |700705299

For Models:

(WINDROWER: 8820 shiftable draper header (21', 25', 30'))

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-175 |A-800-175 |Xchrome 12ga top serrated |7 ft. LH |6821078 |6832174 |700705300

|A-801-181 |A-800-181 |Xchrome 12ga top serrated |7 ft. RH |6821136 |6832224 |700705300

|A-831-510 |A-830-510 |chrome 11ga big tooth |7 ft. LH |6821078 |6832174BT |700705300BT

|A-831-511 |A-830-511 |chrome 11ga big tooth |7 ft. RH |6821136 |6832224BT |700705300BT

|A-801-173 |A-800-173 |Xchrome 12ga top serrated |8 ft. LH |6821078 |6832182 |700705300

|A-801-179 |A-800-179 |Xchrome 12ga top serrated |8 ft. RH |6821136 |6832232 |700705300

|A-861-630 |N/A |Xchrome 12ga top serrated |8 ft. LH |Headless |6832182 |700705300

|A-861-631 |N/A |Xchrome 12ga top serrated |8 ft. RH |Headless |6832232 |700705300

|A-831-512 |A-830-512 |chrome 11ga big tooth |8 ft. LH |6821078 |6832182BT |700705300BT

|A-831-513 |A-830-513 |chrome 11ga big tooth |8 ft. RH |6821136 |6832232BT |700705300BT

For Models:

(WINDROWER: 8820 single auger header (14', 16'))

SICKLE ASSEMBLIES - CASE-IH

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-985 |A-800-985 |chrome 11ga top serrated |7 ft. LH |700114594 |700114590 |700705300

|A-801-986 |A-800-986 |chrome 11ga top serrated |7 ft. RH |700114594 |700114591 |700705300

|A-801-797 |A-800-797 |chrome 11ga top serrated |7 ft. LH |Headless |700709581 |700705300

|A-801-796 |A-800-796 |chrome 11ga top serrated |7 ft. RH |Headless |700709582 |700705300

|A-831-459 |A-830-459 |chrome 11ga big tooth |7 ft. LH |700114594 |700114590BT |700705300BT

|A-831-460 |A-830-460 |chrome 11ga big tooth |7 ft. RH |700114594 |700114591BT |700705300BT

SICKLE ASSEMBLIES & PARTS

|A-861-956 |N/A |chrome 11ga sabertooth |7 ft. LH |700114594 |700114590ST |700705300ST

|A-861-957 |N/A |chrome 11ga sabertooth |7 ft. RH |700114594 |700114591ST |700705300ST

|A-861-958 |N/A |chrome 11ga sabertooth |7 ft. LH |Headless |700709581NHST |700705300ST

|A-861-959 |N/A |chrome 11ga sabertooth |7 ft. RH |Headless |700709582NHST |700705300ST

|A-801-979 |A-800-979 |chrome 11ga top serrated |8 ft. LH |700114594 |700114592 |700705300

|A-801-980 |A-800-980 |chrome 11ga top serrated |8 ft. RH |700114594 |700114593 |700705300

|A-801-799 |A-800-799 |chrome 11ga top serrated |8 ft. LH |Headless |700709585 |700705300

|A-801-798 |A-800-798 |chrome 11ga top serrated |8 ft. RH |Headless |700709586 |700705300

|A-831-461 |A-830-461 |chrome 11ga big tooth |8 ft. LH |700114594 |700114592BT |700705300BT

|A-831-462 |A-830-462 |chrome 11ga big tooth |8 ft. RH |700114594 |700114593BT |700705300BT

|A-861-960 |N/A |chrome 11ga sabertooth |8 ft. LH |700114594 |700114592ST |700705300ST

|A-861-961 |N/A |chrome 11ga sabertooth |8 ft. RH |700114594 |700114593ST |700705300ST

|A-861-962 |N/A |chrome 11ga sabertooth |8 ft. LH |Headless |700709585NHST |700705300ST

|A-861-963 |N/A |chrome 11ga sabertooth |8 ft. RH |Headless |700709586NHST |700705300ST

|A-881-001 |N/A |chrome 11ga top serrated |9 ft. LH |700114594 |700715778 |700705300

|A-881-002 |N/A |chrome 11ga top serrated |9 ft. RH |700114594 |700715779 |700705300

|A-881-003 |N/A |chrome 11ga top serrated |9 ft. LH |Headless |700715778NH |700705300

|A-881-004 |N/A |chrome 11ga top serrated |9 ft. RH |Headless |700715779NH |700705300

|A-881-005 |N/A |chrome 11ga big tooth |9 ft. LH |700114594 |700715778BT |700705300BT

|A-881-006 |N/A |chrome 11ga big tooth |9 ft. RH |700114594 |700715779BT |700705300BT

|A-881-007 |N/A |chrome 11ga sabertooth |9 ft. LH |700114594 |700715778ST |700705300ST

|A-881-008 |N/A |chrome 11ga sabertooth |9 ft. RH |700114594 |700715779ST |700705300ST

|A-881-009 |N/A |chrome 11ga sabertooth |9 ft. LH |Headless |700715778NHST |700705300ST

|A-881-010 |N/A |chrome 11ga sabertooth |9 ft. RH |Headless |700715779NHST |700705300ST

For Models:

(WINDROWER: (8840, 8870, 8380 ALL w/ 625 auger headers))

SICKLE SECTIONS - FORD

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-211-203 |chrome 14ga under serrated |3.250" |2" |1" |7/32 x 5/8 |Z7029H

|A-211-102 |black 12ga smooth |3.250" |2" |1" |7/32 x 5/8 |Z6451H

|A-211-022 |black 12ga under serrated |3.250" |2" |1" |7/32 x 5/8 |Z7030H

|A-211-611 |black 11ga top serrated |3.250" |2" |1" |7/32 x 5/8 |E76370BL

|A-211-001 |black 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |29875

|A-211-232 |black 12ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |340-32015

|A-211-011 |black 11ga smooth |3.250" |2.062" |1" |7/32 x 5/8 |26622

|A-211-211 |black 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |9622744

|A-231-211 |black 11ga big tooth |3.250" |2.062" |1" |7/32 x 5/8 |124737BT

|A-211-002 |black 12ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |OU557HS

SICKLE PARTS - FORD

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-011 |Sickle Head |56692C91 |(MOWER: 505 riveted)

|A-901-022 |Sickle Head |147874 |(MOWER: 501)

SICKLE ASSEMBLIES & PARTS

|A-901-047 |Sickle Head |140019 |(MOWER: 502)

|A-901-059 |Sickle Head |290271 |(MOWER CONDITIONER: 535)

|A-901-071 |Sickle Head |142670 |(MOWER: 14, 15)

|A-901-128 |Sickle Head |242063 |(MOWER: 14, 15)

|A-920-130 |Bronze Bushing |458971R1 |(MOWER: 505)

|A-920-136 |Head Plug |458972R1 |(MOWER: 505)

|A-920-314 |Knifehead Pin |458973R4 |(MOWER: 505)

|A-725-001 |Knifehead Pin Kit |176699C91 |

|A-515-126 |Knifehead clip ||

|A-515-066 |Low knifehead clip ||

|A-515-036 |Knife Clip |142726 |

|A-515-026 |Knifehead Clip |MB812, XA1000, 611759R1 |

|A-920-101 |Center Guard |50HS4A, 143HSA |

|A-920-102 |Outer Guard |15011105M1 |

|A-920-118 |Ledger Plate |142570 |

|A-904-520 |(50) 7/16x1-1/2" bolts ||

|A-904-521 |(50) 7/16x1-3/4" bolts ||

|A-529-076 |Wear Plate, 6" slotted ||

|A-149197 |Pitman Wood 37.687" |149197 |(MOWER: 501)

|A-149198 |Pitman Wood 46.437" |149198 |

|A-920-128 |Pitman Strap, front |MA1577 |

|A-920-129 |Pitman Strap, rear |M1578 |

|A-904-022 |(1lb) 7/32 x 5/8" OH rivet |700000883 |

|A-904-500 |(50) 7/32 x 5/8" Bolt & Nut |700705296 |

|A-904-525 |(50) 7/32 x 5/8" 60° CTSK Bolt & Nut |700002978 |

SICKLE ASSEMBLIES - FORD

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-465 |A-800-465 |black 12ga under serrated |7 ft |142670 |142669H |141198

For Models:

(MOWER: 14, 15, 16, 62, 63, 65, 66)

SICKLE ASSEMBLIES - FORD

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-200 |A-800-200 |black 14ga under serrated |6 ft |147874 |148122 |141113

|A-801-201 |A-800-201 |black 12ga under serrated |6 ft |147874 |240906 |141198

|A-801-203 |A-800-203 |black 14ga under serrated |7 ft |147874 |148119 |141113

|A-801-205 |A-800-205 |black 12ga under serrated |7 ft |147874 |240891 |141198

For Models:

(MOWER: 501 SERIES, 14-94, 95, 96, 97, 175, 176, 257, 258, 259, 260)

SICKLE ASSEMBLIES - FORD

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-463 |N/A |black 12ga under serrated |6 ft |140019 |148723 |141198

For Models:

(MOWER: 502)

|N/A A-860-455 |black 14ga under serrated |6 ft |140019 |140017F |141113

|A-831-275 |N/A |black 12ga under serrated |7 ft |140019 |241150 |141198

For Models:

(MOWER: 502)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - FORD

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-064 |A-800-064 |black 12ga under serrated |5 ft. |56692C91 |463408R93 |29875

|A-801-065 |A-800-065 |black 12ga under serrated |6 ft. |56692C91 |465112R93 |29875

|A-801-060 |A-800-060 |black 11ga smooth |7 ft. |56692C91 |462381R93 |26622

|A-801-066 |A-800-066 |black 12ga under serrated |7 ft. |56692C91 |462380R93 |29875

|A-801-691 |A-800-691 |black 11ga top serrated |7 ft. |56692C91 |1281292C92 |9622744

|A-861-010 |N/A |black 11ga big tooth |7 ft. |56692C91 |1281292C92BT |9622744BT

|A-801-061 |A-800-061 |black 11ga smooth |9 ft. |56692C91 |463182R93 |26622

|A-801-067 |A-800-067 |black 12ga under serrated |9 ft |56692C91 |463159R93 |29875

|A-801-692 |A-800-692 |black 11ga top serrated |9 ft. |56692C91 |1281291C92 |9622744

|A-861-527 |N/A |black 11ga big tooth |9 ft. |56692C91 |1281291C92BT |9622744BT

For Models:

(MOWER: 505 balanced head)

SICKLE ASSEMBLIES - FORD

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-697 |A-800-697 |black 12ga under serrated |7 ft |242063 |241905 |141198

|A-801-698 |A-800-698 |black 12ga under serrated |8 ft |242063 |241906 |141198

For Models:

(MOWER: 515 SERIES)

SICKLE ASSEMBLIES - FORD

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-348 |A-800-348 |black 12ga under serrated |9 ft. |Headless |290744S, 290627S |OU577HS

|A-801-419 |A-800-419 |black 12ga under serrated |9 ft. |290271 |290744, 290627 |OU577HS

For Models:

(MOWER CONDITIONER: 535)

SICKLE ASSEMBLIES - FORD

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-349 |A-800-349 |black 12ga top serrated |9 ft. |Headless |340-32016 |340-32015

For Models:

(MOWER CONDITIONER: 536)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - FORD

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-400 |A-800-400 |black 11ga under serrated |7 ft. |824594C91 |101987C95 |29875

|A-801-306 |A-800-306 |black 11ga under serrated |9 ft. |824594C91 |101988C95 |29875

|A-831-869 |A-830-869 |black 11ga top serrated |9 ft. |824594C91 |1960310C1 |9622744

For Models:

(MOWER CONDITIONER: 538)

SICKLE SECTIONS - GEHL

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-211-232 |black 12ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |340-32015

|A-211-002 |black 12ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |OU557HS

|A-211-003 |chrome 14ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |1145

|A-211-211 |black 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |9622744

|A-231-211 |black 11ga big tooth |3.250" |2.062" |1" |7/32 x 5/8 |124737BT

|A-231-211 |black 12ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |124737BT

|A-211-011 |black 11ga smooth |3.250" |2.062" |1" |7/32 x 5/8 |26622

|A-211-211 |black 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |9622744

|A-231-211 |black 11ga big tooth |3.250" |2.062" |1" |7/32 x 5/8 |124737BT

|A-211-002 |black 12ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |OU557HS

|A-212-061 |chrome 11ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |060635

|A-212-001 |chrome 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |700705300

|A-232-001 |chrome 11ga big tooth |3.250" |2.062" |1" |7/32 x 5/8 |700705300BT

|A-411-132 |black 12ga top serrated |3.250" |2.062" |1.5" |7/32 x 5/8 |340-32041

|A-212-133 |chrome 14ga smooth |3.250" |2.062" |1.5" |7/32 x 5/8 |340-16456

SICKLE PARTS - GEHL

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-018 |Sickle Head, LH |6821078 |(WINDROWER: 2262)

|A-901-019 |Sickle Head, RH |6821136 |(WINDROWER: 2262)

|A-901-028 |Sickle Head |611344 |(WINDROWER: 2230)

|A-901-029 |Sickle Head |611440 |(MOWER CONDITIONER: 2130, 2160)

|A-901-049 |Sickle Head |060320 |(MOWER CONDITIONER: 770, 1070, 880, 1090)

|A-529-016 |Wear Plate |71116532, 71176537 |

|A-515-126 |Knifehead clip ||

|A-515-066 |Knife Clip |61384282 |(MOWER: CUTTER PARTS uses 7/16" guard)

|A-515-186 |Knife Clip |110-10157, 110-10734 |(MOWER: CUTTER PARTS uses 1/2" guard)

|A-904-022 |(1lb) 7/32 x 5/8" OH rivet |700000883 |(MOWER: CUTTER PARTS for extra heavy sections)

|A-904-500 |(50) 7/32 x 5/8" Bolt & Nut |700705296 |(MOWER: CUTTER PARTS for standard straight hole sections)

|A-904-525 |(50) 7/32 x 5/8" 60° CTSK Bolt & Nut |700002978 |(MOWER: CUTTER PARTS for J.E.Love & Hart Carter)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - GEHL

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-349 |A-800-349 |black 12ga top serrated |9 ft. |Headless |340-32016 |340-32015

|A-801-766 |A-800-766 |black 12ga top serrated |9-1/2 ft. |Headless |340-32063TS |340-32015

|N/A |A-860-494 |black 12ga top serrated |9-1/2 ft. |Headless |340-32063 |340-32049

|A-801-351 |A-800-351 |black 12ga top serrated |12 ft. |Headless |340-32019 |340-32015

|A-801-352 |A-800-352 |black 12ga top serrated |14 ft. |Headless |340-32020TS |340-32015

|A-861-495 |A-860-495 |black 12ga under serrated |14 ft. |Headless |340-32020 |340-32049

For Models:

(MOWER CONDITIONER: 208, 216, 217 (9'), 235 w/ swing-tongue (12' & 14'), 229)

SICKLE ASSEMBLIES - GEHL

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-355 |A-800-355 |chrome 12ga under serrated |7 ft. |60320 |60337 |60635

|A-801-356 |A-800-356 |chrome 12ga under serrated |9 ft. |60320 |60322 |60635

|A-801-354 |A-800-354 |chrome 12ga under serrated |9 ft. |Headless |60969 |60635

|N/A A-860-493 |chrome 12ga under serrated |9 ft. |Headless |060969TS |124737

For Models:

(MOWER CONDITIONER: 770, 1070 (7'), (880, 1090 ALL (9')))

SICKLE ASSEMBLIES - GEHL

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-389 |A-800-389 |chrome 12ga top serrated |7 ft. |6584031 |700711999 |049254

|A-801-258 |A-800-258 |chrome 12ga top serrated |9 ft. |6582522 |700711999 |049254

|A-861-063 |N/A |chrome 11ga big tooth |9 ft. |611440 |611439BT |700705300BT

For Models:

(MOWER CONDITIONER: 2130 (7'), 2160 (9'))

SICKLE ASSEMBLIES - GEHL

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-831-752 |N/A |black 12ga top serrated |7 ft. |Headless |90655 |124737

For Models:

(MOWER CONDITIONER: 2140 (7'), 2170 (9'), 2240 swing frame (12'), 2270 (14'))

|A-831-753 |N/A |black 12ga top serrated |9 ft. |Headless |90692 |124737

|A-831-754 |N/A |black 11ga top serrated |12 ft. |Headless |91804 |124737

|A-861-059 |N/A |black 11ga big tooth |12 ft. |Headless |091804BT |124737BT

|A-831-755 |N/A |black 11ga top serrated |14 ft. |Headless |91805 |124737

For Models:

(MOWER CONDITIONER: 2140 (7'), 2170 (9'), 2240 swing frame (12'), 2270 (14'))

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - GEHL

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-832 |A-800-832 |black 12ga top serrated |12 ft. |Headless |340-32045 |340-32041

|A-801-840 |A-800-840 |black 12ga top serrated |14 ft. |Headless |340-32046 |340-32041

|A-801-997 |A-800-997 |black 12ga top serrated |16 ft. |Headless |340-32047 |340-32041

|A-801-904 |A-800-904 |black 12ga top serrated |20 ft. |Headless |340-32048 |340-32041

|A-801-843 |A-800-843 |black 12ga top serrated |21 ft. |Headless |340-32062 |340-32041

For Models:

(WINDROWER: 260D, 262, 265, 270D, 275, 280, 281 w/ high sholder sections)

SICKLE ASSEMBLIES - GEHL

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-350 |A-800-350 |black 12ga top serrated |10 ft. |Headless |340-32018 |340-32015

|A-801-351 |A-800-351 |black 12ga top serrated |12 ft. |Headless |340-32019 |340-32015

|A-801-352 |A-800-352 |black 12ga top serrated |14 ft. |Headless |340-32020TS |340-32015

|A-861-495 |A-860-495 |black 12ga under serrated |14 ft. |Headless |340-32020 |340-32049

|A-801-501 |A-801-501 |black 12ga top serrated |16 ft. |Headless |340-32021TS |340-32015

|A-861-496 |A-861-496 |black 12ga under serrated |16 ft. |Headless |340-32021 |340-32049

|A-801-665 |A-800-665 |black 12ga top serrated |20 ft. |Headless |340-32028 |340-32015

For Models:

(WINDROWER: 260, 265, 270, 275, 280, 281, 282, 285, 800, 900 (10' - 20'), 2650SP (14' & 16'))

SICKLE ASSEMBLIES - GEHL

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-249 |A-800-249 |chrome 14ga top serrated |12 ft. |6193577, 6497416 |6193627 |049213

|A-801-250 |A-800-250 |chrome 14ga top serrated |12 ft. |Headless |6206023 |049213

|A-801-251 |A-800-251 |chrome 12ga top serrated |12 ft. |6193577, 6497416 |6272959 |049254

|A-801-252 |A-800-252 |chrome 12ga top serrated |12 ft. |Headless |6497457 |049254

For Models:

(WINDROWER: 2230)

SICKLE ASSEMBLIES - GEHL

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-175 |A-800-175 |chrome 12ga top serrated |7 ft. LH |6821078 |6832174 |700705300

|A-801-181 |A-800-181 |chrome 12ga top serrated |7 ft. RH |6821136 |6832224 |700705300

|A-831-510 |A-830-510 |chrome 11ga big tooth |7 ft. LH |6821078 |6832174BT |700705300BT

|A-831-511 |A-830-511 |chrome 11ga big tooth |7 ft. RH |6821136 |6832224BT |700705300BT

For Models:

(WINDROWER: 2262)

SICKLE ASSEMBLIES & PARTS

SICKLE SECTIONS - HART CARTER

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-111-001 |black 11ga top serrated |2.500" |2.000" |.875" |7/32 X 5/8" ctsk |71176531 BL

|A-112-001 |chrome 11ga top serrated |2.5" |2" |.875" |7/32 x 5/8 |179736C3

|A-132-001 |chrome 11ga big tooth |2.5" |2" |.875" |7/32 x 5/8 |179736C3BT

|A-131-001 |black 11ga big tooth |3" |2" |.875" |7/32 x 5/8 CTSK |277444BLBT

SICKLE PARTS - HART CARTER

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-046 |Sickle Head |179765C1 |(MOWER: CUTTER PARTS Hart Carter Gen. I)

|A-901-016 |Sickle Head |180859C91 |(MOWER: CUTTER PARTS Hart Carter Gen. III)

|A-901-015 |Head Plate |180497C1 |(MOWER: CUTTER PARTS Hart Carter Gen. II)

|A-529-016 |Wear Plate |71116532, 71176537 |(MOWER: CUTTER PARTS all Hart Carter headers)

|A-529-056 |Wear Plate, 6" ||(MOWER: CUTTER PARTS alternative to 529-016)

|A-529-076 |Wear Plate, 6" slotted ||(MOWER: CUTTER PARTS alternative to 529-016)

|A-515-016 |Low Knife Clip |71176540 |(MOWER: CUTTER PARTS all Hart Carter headers)

|A-904-525 |(50) 7/32 x 5/8" 60° CTSK Bolt & Nut |700002978 |(MOWER: CUTTER PARTS For J.E.Love & Hart Carter)

|A-904-528 |(25) 7/32 X 1" 60" CTSK Bolt & Nut ||(MOWER: CUTTER PARTS for Hart Carter headers)

|A-904-003 |7/32 X 5/8" CTSK rivet ||(MOWER: CUTTER PARTS for HC extra hvy CTSK sections)

|A-904-022 |(1lb) 7/32 x 5/8" OH rivet |700000883 |(MOWER: CUTTER PARTS For extra heavy sections)

|A-904-500 |(50) 7/32 x 5/8" Bolt & Nut |700705296 |(MOWER: CUTTER PARTS for standard straight hole sections)

|A-904-525 |(50) 7/32 x 5/8" 60° CTSK Bolt & Nut ||(MOWER: CUTTER PARTS For J.E.Love & Hart Carter)

SICKLE SECTIONS - HESSTON

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-212-063 |chrome 14ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |604800

|A-212-133 |chrome 14ga smooth |3.250" |2.062" |1.5" |7/32 x 5/8 |340-16456

|A-212-003 |chrome 14ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |604921

SICKLE ASSEMBLIES & PARTS

|A-212-132 |chrome 12ga smooth |3.250" |2.062" |1" |7/32 x 5/8 |049262

|A-211-232 |black 12ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |340-32015

|A-212-012 |chrome 12ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |94579

|A-212-001 |chrome 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |700705300

|A-212-001 |chrome 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |700705300

|A-211-211 |black 11ga top serrated, 2 hole |3.250" |2.062" |1" |7/32 x 5/8 |9622744

|A-232-001 |chrome 11ga big tooth |3.250" |2.062" |1" |7/32 x 5/8 |700705300BT

|A-231-461 |black 11ga saber tooth |3.250" |2.062" |1" |7/32 x 5/8 |9622744ST

|A-231-211 |black 11ga big tooth, 2 hole |3.250" |2.062" |1" |7/32 x 5/8 |124737BT

|A-232-461 |chrome 11ga saber tooth |3.250" |2.062" |1" |7/32 x 5/8 |9826090ST

|A-212-262 |chrome 12ga top serrated |rivet type |||7/32 x 5/8 CTSK |706424H

|A-519-002 |chrome 11ga saw tooth |overlap |||7/32 x 5/8 CTSK |748152

|A-612-150 |(10) RH end sections, chrm top ser |3 hole |||7/32 x 5/8 |700705463

|A-612-090 |(10) LH end sections, chrm top ser |end section |||

7/32 x 5/8 |700705462

|A-711-001 |(kit) sections w/ rivets, chrm top ser |overlap section kit |||7/32 x 5/8 CTSK |

SICKLE PARTS - HESSTON

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-027 |Sickle Head |451948 |(MOWER: PT10, PT7), (MOWER CONDITIONER: 1010)

|A-901-030 |Sickle Head |433102 |(MOWER: PT12), 600

|A-901-029 |Sickle Head |611440 |(MOWER CONDITIONER: 1070, 1090, 1071, 1091)

|A-901-026 |Sickle Head |379370 |200 - 500

|A-901-055 |Sickle Head, long |6497416 |CUTTER PARTS

|A-901-028 |Sickle Head, short |611344 |CUTTER PARTS

|A-901-018 |Sickle Head, LH |6821078 |(WINDROWER: 6450, 6550, 6650), (MOWER CONDITIONER: 1110), 1120,

(MOWER CONDITIONER: 1150), LH

|A-901-019 |Sickle Head, RH |6821136 |(WINDROWER: 6450, 6550, 6650), RH

|A-901-120 |Sickle Head, RH/LH |700111003 |(WINDROWER: 8200), (MOWER CONDITIONER: 1130), (WINDROWER:

1160)

|A-901-130 |Sickle Head, RH/LH |700114594 |(MOWER CONDITIONER: 1170), (WINDROWER: 8400)

|A-920-182 |(10) Shims |6821052 |CUTTER PARTS

|A-515-126 |Knifehead Clip |611759R1, 595648R1 |CUTTER PARTS

|A-515-066 |Knife Clip, low |61384282 |CUTTER PARTS

|A-904-022 |(1lb) 7/32 x 5/8" OH rivet |700000883 |CUTTER PARTS

|A-904-003 |7/32 x 5/8" CTSK rivet |700000583 |CUTTER PARTS

|A-904-500 |(50) 7/32 x 5/8" bolt/nut |700705296 |CUTTER PARTS

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-245 |A-800-245 |chrome 14ga top serrated |7 ft. |451948 |6193510 |049213

|A-801-246 |A-800-246 |chrome 14ga top serrated |9 ft. |451948 |451955 |049213

|A-801-247 |A-800-247 |chrome 12ga top serrated |9 ft. |451948 |6566178 |049254

For Models:

(MOWER: PT10 9', PT7 7'), (MOWER CONDITIONER: 1010 9')

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-264 |A-800-264 |chrome 14ga top serrated |12 ft. |433102 |429498 |049213

For Models:

(MOWER: PT12)

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-389 |A-800-389 |chrome 12ga top serrated |7 ft. |700711999 |6584031 |049254

|A-801-258 |A-800-258 |chrome 12ga top serrated |9 ft. |700711999 |6582522 |049254

|A-831-063 |N/A |chrome 11ga big tooth |9 ft. |700711999 |658252BT |700705300BT

For Models:

(MOWER CONDITIONER: 1070 7', 1090, 1071 7', 1095 9', 1085, 1091)

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-778 |A-800-778 |chrome 12ga top serrated |7 ft. |6821078 |700111432 |700705300

|A-801-779 |A-800-779 |chrome 12ga top serrated |9 ft. |6821078 |700111430 |700705300

|A-831-904 |N/A |black 11ga top serrated |9 ft. |6821078 |700111430BL |700705299

|A-801-540 |A-800-540 |chrome 12ga top serrated |12 ft. |6821078 |700109341 |700705300

|A-831-906 |N/A |black 112ga top serrated |12 ft. |6821078 |700109341BL |700705299

For Models:

(MOWER CONDITIONER: 1110 7', 1150 12', 1290 9')

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-984 |N/A |chrome 11ga top serrated |9 ft. |700111003 |700118673 |700705300

For Models:

(MOWER CONDITIONER: 1130)

|A-801-742 |N/A |chrome 11ga top serrated |9 ft. |Headless |700118671 |700705300

|A-831-905 |N/A |black 11ga top serrated |9 ft. |700111003 |700118673BL |700705299

For Models:

(MOWER CONDITIONER: 1130)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-237 |A-800-237 |chome 14ga top serrated |12 ft. |379370 |373522 |049213

|A-801-239 |A-800-239 |chome 14ga top serrated |14 ft. |379370 |373530 |049213

|A-801-241 |A-800-241 |chrome 12ga top serrated |14 ft. |379370 |373530H |049254

|A-801-243 |A-800-243 |chome 14ga top serrated |16 ft. |379370 |373548 |049213

For Models:

(WINDROWER: 300, 200, 220, 240, 260, 280, 500)

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-248 |A-800-248 |chome 14ga top serrated |10 ft. |6193577, 6497416 |6193619 |049213

|A-801-249 |A-800-249 |chome 14ga top serrated |12 ft. |6193577, 6497416 |6193627 |049213

|A-801-250 |A-800-250 |chome 14ga top serrated |12 ft. |Headless |6206023 |049213

|A-801-251 |A-800-251 |chrome 12ga top serrated |12 ft. |6193577, 6497416 |6272959 |049254

|A-801-252 |A-800-252 |chrome 12ga top serrated |12 ft. |Headless |6497457 |049254

|A-861-054 |N/A |chrome 11ga big tooth |12 ft. |6497416 |6196327BT |700705300BT

|A-801-253 |A-800-253 |chome 14ga top serrated |14 ft. |6193577, 6497416 |6193635 |049213

|A-801-254 |A-800-254 |chome 14ga top serrated |14 ft. |Headless |6206031 |049213

|A-801-255 |A-800-255 |chrome 12ga top serrated |14 ft. |6193577, 6497416 |6272967 |049254

|A-801-256 |A-800-256 |chrome 12ga top serrated |14 ft. |Headless |6497465 |049254

|A-801-706 |N/A |black 11ga top serrated |14 ft. |Headless |6497465BL |700705299

|A-861-060 |N/A |chrome 11ga big tooth |14 ft. |Headless |6497465BT |700705300BT

|A-801-728 |N/A |black 11ga top serrated |14 ft. |6497416 |6272967BL |700705299

|A-801-397 |A-800-397 |chrome 12ga top serrated |14 ft. |6497416 |6497119 |049254

|A-831-508 |A-830-508 |chrome 11ga big tooth |14 ft. |6497416 |6497119BT |700705300BT

|A-801-388 |A-800-388 |chrome 12ga top serrated |16 ft. |6497416 |6497374 |049254

|A-801-257 |A-800-257 |chrome 12ga top serrated |16 ft. |Headless |6497473 |049254

|A-801-707 |N/A |black 11ga top serrated |16 ft. |Headless |6497473BL |700705299

|A-831-509 |A-830-509 |chrome 11ga big tooth |16 ft. |6497416 |6497374BT |700705300BT

For Models:

(WINDROWER: 520, 620, 6200, 6400, 6450, 6610, 1014 hydro-swing, 6600, 6465)

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-264 |A-800-264 |chome 14ga top serrated |12 ft. |433102 |429498 |049213

|A-801-395 |A-800-395 |chome 14ga top serrated |14 ft. |433102 |441527 |049213

For Models:

(WINDROWER: 600)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-596 |A-800-596 |chrome 12ga top serrated |7-1/2 ft. LH |6821078 |6821045 |049254

|A-801-599 |A-800-599 |chrome 12ga top serrated |7-1/2 ft. RH |6821136 |6821110 |049254

|A-861-055 |N/A |chrome 11ga big tooth |9 ft. LH |6821078 |6839146BT |700705300BT

|A-861-056 |N/A |chrome 11ga big tooth |9 ft. RH |6821136 |6839153BT |700705300BT

|A-801-597 |A-800-597 |chrome 12ga top serrated |9 ft. LH |6821078 |6839146 |049254

|A-801-600 |A-800-600 |chrome 12ga top serrated |9 ft. RH |6821136 |6839153 |049254

|A-801-598 |A-800-598 |chrome 12ga top serrated |10-1/2 ft. LH |6821078 |6839161 |049254

|A-801-601 |A-800-601 |chrome 12ga top serrated |10-1/2 ft. RH |6821136 |6839179 |049254

|A-861-057 |N/A |chrome 11ga big tooth |10-1/2 ft. LH |6821078 |6839161BT |700705300BT

|A-861-058 |N/A |chrome 11ga big tooth |10-1/2 ft. RH |6821136 |6839179BT |700705300BT

For Models:

(WINDROWER: (6450, 8200, 65 ALL draper), SPECIALTY)

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-177 |A-800-177 |chrome 11ga top serrated |6 ft. LH |6821078 |6823272 |700705300

|A-801-183 |A-800-183 |chrome 11ga top serrated |6 ft. RH |6821136 |6823280 |700705300

|A-801-175 |A-800-175 |chrome 11ga top serrated |7 ft. LH |6821078 |6832174 |700705300

|A-801-181 |A-800-181 |chrome 11ga top serrated |7 ft. RH |6821136 |6832224 |700705300

|A-831-510 |A-830-510 |chrome 11ga big tooth |7 ft. LH |6821078 |6832174BT |700705300BT

|A-831-511 |A-830-511 |chrome 11ga big tooth |7 ft. RH |6821136 |6832224BT |700705300BT

|A-801-173 |A-800-173 |chrome 11ga top serrated |8 ft. LH |6821078 |6832182 |700705300

|A-801-179 |A-800-179 |chrome 11ga top serrated |8 ft. RH |6821136 |6832232 |700705300

|A-861-630 |N/A |chrome 11ga top serrated |8 ft. LH |Headless |6832182 |700705300

|A-861-631 |N/A |chrome 11ga top serrated |8 ft. RH |Headless |6832232 |700705300

|A-831-512 |A-830-512 |chrome 11ga big tooth |8 ft. LH |6821078 |6832182BT |700705300BT

|A-831-513 |A-830-513 |chrome 11ga big tooth |8 ft. RH |6821136 |6832232BT |700705300BT

For Models:

(WINDROWER: 6550, 6650, 6666, 8100 auger header, 6566, 1014+2, 6665)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-861-511 |N/A |black 11ga top serrated |8 ft. LH |700111003 |700709646BL |700705299

For Models:

(WINDROWER: (8200, 8400, 8100 ALL draper header))

|A-861-512 |N/A |black 11ga top serrated |7 ft. RH |700116709 |700709647BL |700705299

|A-861-513 |N/A |black 11ga top serrated |9 ft. LH |700111003 |700709648BL |700705299

|A-861-514 |N/A |black 11ga top serrated |9 ft. RH |700116709 |700709649BL |700705299

|A-801-973 |A-800-973 |chrome 12ga top serrated |11 ft. LH |700116003 |700709650 |049254

|A-801-974 |A-800-974 |chrome 12ga top serrated |10 ft. RH |700116709 |700709651 |049254

|A-861-515 |N/A |black 11ga top serrated |11 ft. LH |700116003 |700709650BL |700705299

|A-861-516 |N/A |black 11ga top serrated |10 ft. RH |700116709 |700709651BL |700705299

For Models:

(WINDROWER: (8200, 8400, 8100 ALL draper header))

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-973 |A-800-973 |chrome 12ga top serrated |11 ft. LH |700116003 |700709650 |049254

|A-801-974 |A-800-974 |chrome 12ga top serrated |10 ft. RH |700116709 |700709651 |049254

|A-861-515 |N/A |black 11ga top serrated |11 ft. LH |700116003 |700709650BL |700705299

|A-861-516 |N/A |black 11ga top serrated |10 ft. RH |700116709 |700709651BL |700705299

|A-861-517 |N/A |black 11ga top serrated |13 ft. LH |700116003 |700709652BL |700705299

|A-861-518 |N/A |black 11ga top serrated |12 ft. RH |700116709 |700709653BL |700705299

|A-861-519 |N/A |black 11ga top serrated |15 ft. LH |700116003 |700709654BL |700705299

|A-861-520 |N/A |black 11ga top serrated |15 ft. RH |700116709 |700709655BL |700705299

For Models:

(WINDROWER: 8100 shiftable draper header (21', 25', 30'))

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-826 |A-800-826 |chrome 11ga top serrated |12 ft. |700111003 |700110730 |700705300

|A-801-928 |A-800-928 |chrome 11ga top serrated |12 ft. |Headless |700115887 |700705300

|A-831-514 |A-830-514 |chrome 11ga big tooth |12 ft. |700111003 |700110730BT |700705300BT

|A-831-907 |N/A |black 11ga top serrated |12 ft. |700111003 |700110730BL |700705299

|A-801-780 |A-800-780 |chrome 11ga top serrated |14 ft. |700111003 |700110731 |700705300

|A-801-781 |A-800-781 |chrome 11ga top serrated |14 ft. |Headless |700115804 |700705300

|A-831-515 |A-830-515 |chrome 11ga big tooth |14 ft. |700111003 |700110731BT |700705300BT

|A-831-908 |N/A |black 11ga top serrated |14 ft. |700111003 |700110731BL |700705299

For Models:

(WINDROWER: 8200, 1160 center pivot (14'))

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - HESSTON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-985 |A-800-985 |chrome 11ga top serrated |7 ft. LH |700114594 |700114590 |700705300

|A-801-986 |A-800-986 |chrome 11ga top serrated |7 ft. RH |700114594 |700114591 |700705300

|A-801-797 |A-800-797 |chrome 11ga top serrated |7 ft. LH |Headless |700709581 |700705300

|A-801-796 |A-800-796 |chrome 11ga top serrated |7 ft. RH |Headless |700709582 |700705300

|A-831-459 |A-830-459 |chrome 11ga big tooth |7 ft. LH |700114594 |700114590BT |700705300BT

|A-831-460 |A-830-460 |chrome 11ga big tooth |7 ft. RH |700114594 |700114591BT |700705300BT

|A-861-956 |N/A |chome 11ga sabertooth |7 ft. LH |700114594 |700114590ST |700705300ST

|A-861-957 |N/A |chome 11ga sabertooth |7 ft. RH |700114594 |700114591ST |700705300ST

|A-861-958 |N/A |chome 11ga sabertooth |7 ft. LH |Headless |700709581NHST |700705300ST

|A-861-959 |N/A |chome 11ga sabertooth |7 ft. RH |Headless |700709582NHST |700705300ST

|A-801-979 |A-800-979 |chrome 11ga top serrated |8 ft. LH |700114594 |700114592 |700705300

|A-801-980 |A-800-980 |chrome 11ga top serrated |8 ft. RH |700114594 |700114593 |700705300

|A-801-799 |A-800-799 |chrome 11ga top serrated |8 ft. LH |Headless |700709585 |700705300

|A-801-798 |A-800-798 |chrome 11ga top serrated |8 ft. RH |Headless |700709586 |700705300

|A-831-461 |A-830-461 |chrome 11ga big tooth |8 ft. LH |700114594 |700114592BT |700705300BT

|A-831-462 |A-830-462 |chrome 11ga big tooth |8 ft. RH |700114594 |700114593BT |700705300BT

|A-861-960 |N/A |chome 11ga sabertooth |8 ft. LH |700114594 |700114592ST |700705300ST

|A-861-961 |N/A |chome 11ga sabertooth |8 ft. RH |700114594 |700114593ST |700705300ST

|A-861-962 |N/A |chome 11ga sabertooth |8 ft. LH |Headless |700709585NHST |700705300ST

|A-861-963 |N/A |chome 11ga sabertooth |8 ft. RH |Headless |700709586NHST |700705300ST

|A-881-001 |N/A |chrome 11ga top serrated |9 ft. LH |700114594 |700715778 |700705300

|A-881-002 |N/A |chrome 11ga top serrated |9 ft. RH |700114594 |700715779 |700705300

|A-881-003 |N/A |chrome 11ga top serrated |9 ft. LH |Headless |700715778NH |700705300

|A-881-004 |N/A |chrome 11ga top serrated |9 ft. RH |Headless |700715779NH |700705300

|A-881-005 |N/A |chrome 11ga big tooth |9 ft. LH |700114594 |700715778BT |700705300BT

|A-881-006 |N/A |chrome 11ga big tooth |9 ft. RH |700114594 |700715779BT |700705300BT

|A-881-007 |N/A |chome 11ga sabertooth |9 ft. LH |700114594 |700715778ST |700705300ST

|A-881-008 |N/A |chome 11ga sabertooth |9 ft. RH |700114594 |700715779ST |700705300ST

|A-881-009 |N/A |chome 11ga sabertooth |9 ft. LH |Headless |700715778NHST |700705300ST

|A-881-010 |N/A |chome 11ga sabertooth |9 ft. RH |Headless |700715779NHST |700705300ST

For Models:

(WINDROWER: 8400, 8600), (MOWER CONDITIONER: 1170 w/ 625 auger header)

SICKLE SECTIONS - JOHN DEERE

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-211-203 |chrome 14ga under serrated |3.250" |2" |1" |7/32 x 5/8 |Z7029H

|A-212-073 |chrome 14ga under serrated |3.250" |2" |1" |7/32 x 5/8 |H21529

|A-211-102 |black 12ga smooth |3.250" |2" |1" |7/32 x 5/8 |Z6451H

|A-212-152 |chrome 12ga smooth |3.250" |2" |1" |7/32 x 5/8 |H21525

|A-211-022 |black 12ga under serrated |3.250" |2" |1" |7/32 x 5/8 |Z7030H

|A-212-082 |chrome 12ga under serrated |3.250" |2" |1" |7/32 x 5/8 |H21530

SICKLE ASSEMBLIES & PARTS

|A-212-242 |chrome 12ga top serrated |3.250" |2" |1" |7/32 x 5/8 |E45996

|A-211-292 |black 12ga top serrated |3.250" |2" |1" |7/32 x 5/8 |E45996BL

|A-232-242 |chrome 12ga big tooth |3.250" |2" |1" |7/32 x 5/8 |E45996BT

|A-231-292 |black 12ga big tooth |3.250" |2" |1" |7/32 x 5/8 |E45996BLBT

|A-211-631 |black 11ga smooth |3.250" |2" |1" |7/32 x 5/8 |E76372

|A-211-021 |black 11ga under serrated |3.250" |2" |1" |7/32 x 5/8 |E76373

|A-212-081 |chrome 11ga under serrated |3.250" |2" |1" |7/32 x 5/8 |E76371

|A-211-611 |black 11ga top serrated |3.250" |2" |1" |7/32 x 5/8 |E76370BL

|A-231-451 |black 11ga sabertooth |3.250" |2" |1" |7/32 x 5/8 |E76370BLST

|A-232-451 |chome 11ga sabertooth |3.250" |2" |1" |7/32 x 5/8 |E76370ST

|A-212-241 |chrome 12ga top serrated |3.250" |2" |1" |7/32 x 5/8 |E76370

|A-232-241 |chrome 11ga big tooth |3.250" |2" |1" |7/32 x 5/8 |E76370BT

|A-231-611 |black 11ga big tooth |3.250" |2" |1" |7/32 x 5/8 |E76370BLBT

|A-211-223 |black 14ga under serrated |3.250" |2.125" |1" |7/32 x 5/8 |875785L

|A-412-102 |chrome 12ga top serrated |3" wide |3.218"long |1" |7/32 x 5/8 |1055090M1

|A-711-003 |chrome 12ga top serrated |twin sect |||overlap kit

SICKLE PARTS - JOHN DEERE

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-036 |Sickle Head |H28076H |

|A-901-039 |Sickle Head |AE24247 |

|A-901-235 |Sickle Head |AE48583 |

|A-901-233 |Sickle Head, LH |AE48125 |

|A-901-234 |Sickle Head, RH |AE48126 |

|A-920-378 |Knifehead Pin |E77840 |

|A-920-379 |Needle Bearing |AE48137 |

|A-920-334 |Seal |E56795 |

|A-725-003 |Knifehead Pin Kit ||

|A-920-101 |Center Guard |50HS4A, 143HSA |

|A-920-102 |Outer Guard ||

|A-920-119 |Ledger Plate |Z5110H |

|A-904-520 |(50) 7/16x1-1/2" bolts ||

|A-904-521 |(50) 7/16x1-3/4" bolts ||

|A-920-143 |Outer Sole |AH11948H |

|A-920-144 |Inner Sole |H24076H |

|A-920-148 |Head Wear Plate |Z5870H |

|A-H28286 |Pitman Wood 36.812" |H28286 |(MOWER: 8W, 9W)

|A-Z9298H |Pitman Wood 33.875" |Z9298H |(MOWER: 5)

|A-Z9913H |Pitman Wood 26.750" |Z9913H |(MOWER: 8, 9)

|A-529-056 |Wear Plate 6" |206196M1, 231303M1 |

|A-515-066 |Knife Clip |61384282 |

|A-515-126 |Knifehead clip ||

|A-904-524 |(25) Strap Bolt & Nut |H125889 |(MOWER: CUTTER PARTS 7/8" bolt)

|A-904-549 |(25) Head Bolt & Nut |H125890 |(MOWER: CUTTER PARTS 3/4" bolt)

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-292 |A-800-292 |black 12ga smooth |7 ft. |H28076H |AZ958H |Z6451H

|A-801-294 |A-800-294 |black 12ga under serrated |7 ft. |H28076H |AZ1299H |Z7030H

|A-801-296 |A-800-296 |black 12ga smooth |9 ft. |H28076H |AZ3987H |Z6451H

|A-801-298 |A-800-298 |black 12ga under serrated |9 ft. |H28076H |AZ3988H |Z7030H

For Models:

(MOWER: 5, 8, 9, 11, 37, 38, 39, 39N)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-831-687 |A-830-687 |black 12ga smooth |7 ft. |AE48583 |AE48593BL, AE36101 |Z6451H

|A-831-686 |A-830-686 |black 12ga under serrated |7 ft. |AE48583 |AE48592, AE36097 |Z7030H

|A-831-689 |A-830-689 |black 12ga smooth |9 ft. |AE48583 |AE48595, AE69106 |Z6451H

|A-831-688 |A-830-688 |black 12ga under serrated |9 ft. |AE48583 |AE48594, AE36102 |Z7030H

|A-831-685 |A-830-685 |chome 12ga top serrated |9 ft. |AE48583 |AE48594TSPL, AE36102TSPL |E45996

|A-831-813 |A-830-813 |Xblack 12ga top serrated |9 ft. |AE48583 |AE48594TS, AE36102TS |E76370BL

For Models:

(MOWER: 47, 50, 250, 350, 450, 3700 w/ needle brg style head)

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-374 |A-800-374 |chome 12ga under serrated |9 ft. |AE24247 |AE27623 |H21530

|A-801-280 |A-800-280 |chome 12ga top serrated |9 ft. |AE24247 |AE27602 |E45996

|A-801-377 |A-800-377 |chome 12ga under serrated |12 ft. |AE24247 |AE28069 |H21530

|A-801-281 |A-800-281 |chome 12ga top serrated |12 ft. |AE24247 |AE28067 |E45996

|A-801-378 |A-800-378 |chome 12ga under serrated |14 ft. |AE24247 |AE28075 |H21530

|A-801-282 |A-800-282 |chome 12ga top serrated |14 ft. |AE24247 |AE28073 |E45996

For Models:

(MOWER CONDITIONER: 1209 SN <-285000 (9'), 480, 483, 485 (9'), 1214 (12' & 14'))

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-831-815 |A-830-815 |Xchome 12ga top serrated |7 ft. |AE48125 |AE48663 |E76370

|A-831-691 |A-830-691 |Xchome 12ga under serrated |7 ft. |AE48125 |AE48661 |E76371

|A-831-579 |A-830-579 |Xchome 12ga top serrated |9 ft. |AE48125 |AE48664 |E76370

|A-831-692 |A-830-692 |Xchome 12ga under serrated |9 ft. |AE48125 |AE48662 |E76371

|A-831-821 |A-830-821 |Xblack 12ga top serrated |9 ft. |AE48125 |AE48664BL |E76370BL

|A-861-544 |N/A |black 11ga big tooth |9 ft. |AE48125 |AE48664BLBT |E76370BLBT

|A-831-580 |A-830-580 |Xchome 12ga top serrated |12 ft. |AE48125 |AE48652 |E76370

|A-831-818 |A-830-818 |Xchome 12ga under serrated |12 ft. |AE48125 |AE48651 |E76371

|A-831-875 |A-830-875 |Xblack 12ga top serrated |12 ft. |AE48125 |AE48651BL |E76370BL

|A-861-545 |N/A |black 11ga big tooth |12 ft. |AE48125 |AE48652BLBT |E76370BLBT

|A-831-581 |A-830-581 |Xchome 12ga top serrated |14 ft. |AE48125 |AE48654 |E76370

|A-831-819 |A-830-819 |Xchome 12ga under serrated |14 ft. |AE48125 |AE48655 |E76371

|A-831-876 |A-830-876 |Xblack 12ga top serrated |14 ft. |AE48125 |AE48654BL |E76370BL

|A-861-546 |N/A |black 11ga big tooth |14 ft. |AE48125 |AE48654BLBT |E76370BLBT

For Models:

(MOWER CONDITIONER: 1209 SN 285001->, 1217 (7'), 1219 SN 710001-> (9'), 1380 mid pivot, 1424 (12' & 24'))

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-484 |A-800-484 |Xchome 12ga top serrated |6 ft. RH |AE48126 |AE48597 |E76370

|A-801-485 |A-800-485 |Xchome 12ga top serrated |6 ft. LH |AE48125 |AE48665 |E76370

|A-831-888 |A-830-888 |Xblack 12ga top serrated |6 ft. RH |AE48126 |AE48597BL |E76370BL

|A-831-887 |A-830-887 |Xblack 12ga top serrated |6 ft. LH |AE48125 |AE48665BL |E76370BL

|A-831-476 |N/A |chome 11ga big tooth |6 ft. RH |AE48126 |AE48126 |E76370BT

|A-831-477 |N/A |chome 11ga big tooth |6 ft. LH |AE48125 |AE48665BT |E76370BT

|A-801-486 |A-800-486 |Xchome 12ga top serrated |7 ft. RH |AE48126 |AE48135 |E76370

|A-801-487 |A-800-487 |Xchome 12ga top serrated |7 ft. LH |AE48125 |AE48131 |E76370

|A-831-890 |A-830-890 |Xblack 12ga top serrated |7 ft. RH |AE48126 |AE48135BL |E76370BL

|A-831-889 |A-830-889 |Xblack 12ga top serrated |7 ft. LH |AE48125 |AE48131BL |E76370BL

|A-881-056 |N/A |chrome 11ga sabertooth |7 ft. RH |AE48125 |AE48135ST |E76370ST

|A-881-057 |N/A |chrome 11ga sabertooth |7 ft. LH |AE48125 |AE48131ST |E76370ST

For Models:

(MOWER CONDITIONER: 1525 w/ 300 twin knife drive, 1600 SN <-880001, platform (12' & 14'))

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-659 |A-800-659 |black 14ga under serrated |18 ft. |Headless |899416L |875785L

|A-801-660 |A-800-660 |black 14ga under serrated |21 ft. |Headless |885194L |875785L

|A-801-661 |A-800-661 |black 14ga under serrated |25 ft. |Headless |885477 |875785L

|A-801-391 |A-800-391 |black 14ga under serrated |31 ft. 1 pc. |Headless |AW24760 |W30344

For Models:

(WINDROWER: 580, 590 (30'))

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-377 |A-800-377 |chome 12ga under serrated |12 ft. |AE24247 |AE28069 |H21530

|A-801-281 |A-800-281 |chome 12ga top serrated |12 ft. |AE24247 |AE28067 |E45996

|A-801-378 |A-800-378 |chome 12ga under serrated |14 ft. |AE24247 |AE28075 |H21530

|A-801-282 |A-800-282 |chome 12ga top serrated |14 ft. |AE24247 |AE28073 |E45996

|A-801-454 |A-800-454 |chome 12ga top serrated |15 ft. |AE24247 |AE23898 |E45996

|A-801-283 |A-800-283 |chome 12ga top serrated |16 ft. |AE24247 |AE32359 |E45996

|A-801-492 |A-800-492 |chome 12ga top serrated |18 ft. |AE24247 |AE23782 |E45996

|A-801-493 |A-800-493 |chome 12ga top serrated |21 ft. |AE24247 |AE25476 |E45996

For Models:

(WINDROWER: 2270 platforms: 88, 120, 188, 220 (12' - 21'), 830, 780, 800, 880, 2250)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-831-580 |A-830-580 |Xchome 12ga top serrated |12 ft. |AE48125 |AE48652 |E76370

|A-831-818 |A-830-818 |Xchome 12ga under serrated |12 ft. |AE48125 |AE48651 |E76371

|A-831-875 |A-830-875 |Xblack 12ga top serrated |12 ft. |AE48125 |AE48651BL |E76370BL

|A-861-545 |N/A |black 11ga big tooth |12 ft. |AE48125 |AE48652BLBT |E76370BLBT

|A-831-581 |A-830-581 |Xchome 12ga top serrated |14 ft. |AE48125 |AE48654 |E76370

|A-831-819 |A-830-819 |Xchome 12ga under serrated |14 ft. |AE48125 |AE48655 |E76371

|A-831-876 |A-830-876 |Xblack 12ga top serrated |14 ft. |AE48125 |AE48654BL |E76370BL

|A-861-546 |N/A |black 11ga big tooth |14 ft. |AE48125 |AE48654BLBT |E76370BLBT

|A-831-582 |A-830-582 |chome 12ga top serrated |15 ft. |AE48125 |AE38816 |E45996

|A-831-583 |A-830-583 |Xchome 12ga top serrated |16 ft. |AE48125 |AE48657 |E76370

|A-831-820 |A-830-820 |Xchome 12ga under serrated |16 ft. |AE48125 |AE48656 |E76371

|A-831-877 |A-830-877 |Xblack 12ga top serrated |16 ft. |AE48125 |AE48657BL |E76370BL

|A-861-547 |N/A |black 11ga big tooth |16 ft. |AE48125 |AE48657BLBT |E76370BLBT

|A-831-584 |A-830-584 |Xchome 12ga top serrated |18 ft. |AE48125 |AE48599 |E76370

|A-831-878 |A-830-878 |Xblack 12ga top serrated |18 ft. |AE48125 |AE48599BL |E76370BL

|A-861-548 |N/A |black 11ga big tooth |18 ft. |AE48125 |AE48599BLBT |E76370BLBT

|A-831-585 |A-830-585 |Xchome 12ga top serrated |21 ft. |AE48125 |AE48598 |E76370

|A-831-879 |A-830-879 |Xblack 12ga top serrated |21 ft. |AE48125 |AE48598BL |E76370BL

|A-861-549 |N/A |black 11ga big tooth |21 ft. |AE48125 |AE48598BLBT |E76370BLBT

|A-831-586 |A-830-586 |Xchome 12ga top serrated |25 ft. |AE48125 |AE39178 |E76370

|A-831-880 |A-830-880 |Xblack 12ga top serrated |25 ft. |AE48125 |AE39178BL |E76370BL

|A-861-550 |N/A |black 11ga big tooth |25 ft. |AE48125 |AE39178BLBT |E76370BLBT

For Models:

(2280, 2320, 2420 ALL auger:230,240(12',14',16'); draper:130,135(15',18',21',25'))

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-648 |A-800-648 |chome 12ga top serrated |15 ft. |Headless |1057966M91, 1057964M91 |31-7970650

|A-831-833 |A-830-833 |Xblack 12ga top serrated |15 ft. |Headless |33703 |34390

|A-801-649 |A-800-649 |chome 12ga top serrated |18 ft. |Headless |1057967M91, 1057965M91 |1055090M1

|A-831-834 |A-830-834 |Xblack 12ga top serrated |18 ft. |Headless |33704 |34390

|A-801-650 |A-800-650 |chome 12ga top serrated |21 ft. |Headless |1057508M91 |1055090M1

|A-831-835 |A-830-835 |Xblack 12ga top serrated |21 ft. |Headless |33705 |34390

|A-801-651 |A-800-651 |chome 12ga top serrated |26 ft 1 pc. |Headless |1056739M91, 1056738M91 |1055090M1

|A-831-836 |A-830-836 |Xblack 12ga top serrated |28 ft 1 pc. |Headless |33746 |34390

|A-801-652 |A-800-652 |chome 12ga top serrated |31 ft 1 pc. |Headless |1057912M91 |1055090M1

|A-831-837 |A-830-837 |Xblack 12ga top serrated |33 ft 1 pc. |Headless |33747 |34390

For Models:

(WINDROWER: 2360 w/ draper header)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-484 |A-800-484 |Xchome 12ga top serrated |6 ft. RH |AE48126 |AE48597 |E76370

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-485 |A-800-485 |Xchome 12ga top serrated |6 ft. LH |AE48125 |AE48665 |E76370

|A-831-888 |A-830-888 |Xblack 12ga top serrated |6 ft. RH |AE48126 |AE48597BL |E76370BL

|A-831-887 |A-830-887 |Xblack 12ga top serrated |6 ft. LH |AE48125 |AE48665BL |E76370BL

|A-831-476 |N/A |chome 11ga big tooth |6 ft. RH |AE48126 |AE48126 |E76370BT

|A-831-477 |N/A |chome 11ga big tooth |6 ft. LH |AE48125 |AE48665BT |E76370BT

|A-801-486 |A-800-486 |Xchome 12ga top serrated |7 ft. RH |AE48126 |AE48135 |E76370

|A-801-487 |A-800-487 |Xchome 12ga top serrated |7 ft. LH |AE48125 |AE48131 |E76370

|A-831-890 |A-830-890 |Xblack 12ga top serrated |7 ft. RH |AE48126 |AE48135BL |E76370BL

|A-831-889 |A-830-889 |Xblack 12ga top serrated |7 ft. LH |AE48125 |AE48131BL |E76370BL

|A-881-056 |N/A |chrome 11ga sabertooth |7 ft. RH |AE48125 |AE48135ST |E76370ST

|A-881-057 |N/A |chrome 11ga sabertooth |7 ft. LH |AE48125 |AE48131ST |E76370ST

|A-801-590 |A-800-590 |Xchome 12ga top serrated |8 ft. RH |AE48126 |AE48134 |E76370

|A-801-591 |A-800-591 |Xchome 12ga top serrated |8 ft. LH |AE48125 |AE48130 |E76370

|A-831-892 |A-830-892 |Xblack 12ga top serrated |8 ft. RH |AE48126 |AE48134BL |E76370BL

|A-831-891 |A-830-891 |Xblack 12ga top serrated |8 ft. LH |AE48125 |AE48130BL |E76370BL

|A-881-058 |N/A |chrome 11ga sabertooth |8 ft. RH |AE48126 |AE48134ST |E76370ST

|A-881-059 |N/A |chrome 11ga sabertooth |8 ft. LH |AE48125 |AE48130ST |E76370ST

For Models:

(WINDROWER: (3430, 3830 ALL w/ 300 & 300A twin knife drive (12'-16') SN <-880000))

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - JOHN DEERE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-861-970 |N/A |Xchome 12ga top serrated |7 ft. LH |Headless |AE55769 |E76370

For Models:

(WINDROWER: 4890 w/ 890 platform)

|A-861-971 |N/A |Xchome 12ga top serrated |7 ft. RH |Headless |AE55770 |E76370

|A-861-972 |N/A |Xchome 12ga top serrated |8 ft. LH |Headless |AE55771 |E76370

|A-861-973 |N/A |Xchome 12ga top serrated |8 ft. RH |Headless |AE55772 |E76370

|A-861-974 |N/A |Xchome 12ga top serrated |9 ft. LH |Headless |AE56459 |E76370

|A-861-975 |N/A |Xchome 12ga top serrated |9 ft. RH |Headless |AE56460 |E76370

For Models:

(WINDROWER: 4890 w/ 890 platform)

SICKLE PARTS - MAC DON

PART NO. DESCRIPTION APPLICATION

|A-515-126 |Knifehead clip ||

|A-515-066 |Low knifehead clip ||

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-861-999 |N/A |black 11ga top serrated |9 ft. |Headless |36931 |34390

For Models:

(MOWER CONDITIONER: 4000)

|A-861-980 |N/A |black 11ga sabertooth |9 ft. |Headless |36931ST |102053

For Models:

(MOWER CONDITIONER: 4000)

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-881-078 |N/A |black 11ga top serrated |12 ft. |Headless |38632 |34390

For Models:

(WINDROWER: 942 multi-crop header & 741, 941 hay conditioner w/ single drive)

|A-881-079 |N/A |black 11ga sabertooth |12 ft. |Headless |38632ST |102053

For Models:

(WINDROWER: 942 multi-crop header & 741, 941 hay conditioner w/ single drive)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-881-019 |N/A |black 11ga top serrated |8 ft. RH |Headless |47783 |34390

For Models:

(WINDROWER: 942 multi-crop header & 741, 941 hay conditioner w/ double drive)

|A-881-022 |N/A |black 11ga sabertooth |8 ft. RH |Headless |47783ST |102053

|A-881-020 |N/A |black 11ga top serrated |9 ft. LH |Headless |47788 |34390

|A-881-023 |N/A |black 11ga sabertooth |9 ft. LH |Headless |47788ST |102053

|A-881-021 |N/A |black 11ga top serrated |9 ft. RH |Headless |47793 |34390

|A-881-024 |N/A |black 11ga sabertooth |9 ft. RH |Headless |47793ST |102053

For Models:

(WINDROWER: 942 multi-crop header & 741, 941 hay conditioner w/ double drive)

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-881-025 |N/A |black 11ga top serrated |21 ft. LH |Headless |49667 |34390

For Models:

(WINDROWER: 960 double & triple delivery harvest headers, 962 (30' & 36'), double & triple delivery harvest headers)

|A-881-029 |N/A |black 11ga sabertooth |21 ft. LH |Headless |49667ST |102053

|A-881-026 |N/A |black 11ga top serrated |4 ft. RH |Headless |43076 |34390

|A-881-030 |N/A |black 11ga sabertooth |4 ft. RH |Headless |43076ST |102053

|A-881-027 |N/A |black 11ga top serrated |9 ft. RH |Headless |43077 |34390

|A-881-031 |N/A |black 11ga sabertooth |9 ft. RH |Headless |43077ST |102053

|A-881-028 |N/A |black 11ga top serrated |15 ft. RH |Headless |43078 |34390

|A-881-032 |N/A |black 11ga sabertooth |15 ft. RH |Headless |43078ST |102053

For Models:

(WINDROWER: 960 double & triple delivery harvest headers, 962 (30' & 36'), double & triple delivery harvest headers)

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-657 |A-800-657 |chrome 14ga under serrated |15 ft. |Headless |16641PL |7253

|A-801-659 |A-800-659 |black 14ga under serrated |18 ft. |Headless |899416L |875785L

|A-801-641 |A-800-641 |chrome 14ga top serrated |18 ft. |Headless |1042904M91 |1046779M1

|A-801-660 |A-800-660 |black 14ga under serrated |21 ft. |Headless |885194L |875785L

|A-801-642 |A-800-642 |chrome 14ga top serrated |21 ft. |Headless |1041471M91 |1046779M1

|A-801-661 |A-800-661 |black 14ga under serrated |25 ft. |Headless |885477 |875785L

|A-801-643 |A-800-643 |chrome 14ga top serrated |25 ft. |Headless |1050779M91 |1046779M1

For Models:

(WINDROWER: RENN 1000 Prairie-Mac pull type)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-409 |A-800-409 |chrome 12ga top serrated |12 ft. |31-7970683 |1046768M1 |31-7970650

|A-801-411 |A-800-411 |chrome 12ga top serrated |15 ft. |31-7970683 |31-7970623 |31-7970650

|A-801-413 |A-800-413 |chrome 12ga top serrated |18 ft. |31-7970683 |31-7970633 |31-7970650

|A-801-415 |A-800-415 |chrome 12ga top serrated |21 ft. |31-7970683 |31-7970643 |31-7970650

For Models:

(WINDROWER: RENN 2000 Hydro-Mac)

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-670 |A-800-670 |black 14ga under serrated |21 ft. |Headless |1043842M91 |1041472M1

|A-801-671 |A-800-671 |black 14ga under serrated |25 ft. |Headless |1065051M91 |1041472M1

|A-801-672 |A-800-672 |black 14ga under serrated |30 ft. |Headless |1065052M91 |1041472M1

|A-801-673 |A-800-673 |black 14ga under serrated |21 ft. LH |Headless |1069664M91 |1041472M1

|A-801-674 |A-800-674 |black 14ga under serrated |15 ft. RH |Headless |1069665M91 |1041472M1

For Models:

(WINDROWER: 3000 pull type swather, single & duplex)

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-881-033 |N/A |black 11ga top serrated |12 ft. |Headless |34181 |34390

For Models:

(WINDROWER: 5000 power tongue, 910, 920, 930 auger header w/ single drive)

|A-861-977 |N/A |black 11ga sabertooth |12 ft. |Headless |34181ST |102053

|A-881-034 |N/A |black 11ga top serrated |14 ft. |Headless |34182 |34390

|A-861-978 |N/A |black 11ga sabertooth |14 ft. |Headless |34182ST |102053

|A-881-035 |N/A |black 11ga top serrated |16 ft. |Headless |34183 |34390

|A-861-979 |N/A |black 11ga sabertooth |16 ft. |Headless |34183ST |102053

For Models:

(WINDROWER: 5000 power tongue, 910, 920, 930 auger header w/ single drive)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-644 |A-800-644 |black 11ga top serrated |12 ft. |Headless |1057934M91 |1071707M1

|A-801-645 |A-800-645 |black 11ga top serrated |14 ft. |1056738M91 |-|1056865M91

|A-801-646 |A-800-646 |black 11ga top serrated |14 ft. |Headless |1056866M91 |1071707M1

|A-831-530 |N/A |black 11ga big tooth |14 ft. |Headless |34393BT |34390BT

|A-801-647 |A-800-647 |black 11ga top serrated |14 ft. |Headless |1057538M91 |1071707M1

For Models:

(WINDROWER: 7000 auger header)

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-831-833 |A-830-833 |black 11ga top serrated |15 ft. |Headless |33703 |34390

|A-831-834 |A-830-834 |black 11ga top serrated |18 ft. |Headless |33704 |34390

|A-831-835 |A-830-835 |black 11ga top serrated |21 ft. |Headless |33705 |34390

|A-831-836 |A-830-836 |black 11ga top serrated |26 ft. 1 pc. |Headless |33746 |34390

|A-831-837 |A-830-837 |black 11ga top serrated |31 ft. 1 pc. |Headless |33747 |34390

For Models:

(WINDROWER: 7000 draper headere, multi-crop header, harvest header)

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-831-839 |N/A |black 11ga top serrated |7 ft. LH |Headless |33715, 34211 |34390

For Models:

(WINDROWER: 7000 w/ 910, 920, 930 auger header, double knife drive & standard)

|A-861-996 |N/A |black 11ga sabertooth |7 ft. LH |Headless |34211ST |102053

|A-831-838 |A-830-838 |black 11ga top serrated |7 ft. RH |Headless |33718, 34212 |34390

|A-861-995 |N/A |black 11ga sabertooth |7 ft. RH |Headless |34212ST |102053

|A-831-841 |A-830-841 |black 11ga top serrated |8 ft. LH |Headless |33716, 34212 |34390

|A-861-998 |N/A |black 11ga sabertooth |8 ft. LH |Headless |34212ST |102053

|A-831-840 |A-830-840 |black 11ga top serrated |8 ft. RH |Headless |33719, 34313 |34390

|A-861-997 |N/A |black 11ga sabertooth |8 ft. RH |Headless |34213ST |102053

For Models:

(WINDROWER: 7000 w/ 910, 920, 930 auger header, double knife drive & standard)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - MAC DON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-881-036 |N/A |black 11ga top serrated |6 ft. LH |Headless |34328 |34390

For Models:

(WINDROWER: 7000 w/ 910, 920, 930 auger header, double knife drive & stub gau)

|A-861-981 |N/A |black 11ga sabertooth |6 ft. LH |Headless |34328ST |102053

|A-881-039 |N/A |black 11ga top serrated |6 ft. RH |Headless |34674 |34390

|A-861-983 |N/A |black 11ga sabertooth |6 ft. RH |Headless |34674ST |102053

|A-881-037 |N/A |black 11ga top serrated |7 ft. LH |Headless |34329 |34390

|A-861-982 |N/A |black 11ga sabertooth |7 ft. LH |Headless |34329ST |102053

|A-881-038 |N/A |black 11ga top serrated |7 ft. RH |Headless |34678 |34390

|A-861-984 |N/A |black 11ga sabertooth |7 ft. RH |Headless |34678ST |102053

|A-881-040 |N/A |black 11ga top serrated |8 ft. LH |Headless |34330 |34390

|A-861-985 |N/A |black 11ga sabertooth |8 ft. LH |Headless |34330ST |102053

|A-881-041 |N/A |black 11ga top serrated |8 ft. RH |Headless |34679 |34390

|A-861-986 |N/A |black 11ga sabertooth |8 ft. RH |Headless |34679ST |102053

For Models:

(WINDROWER: 7000 w/ 910, 920, 930 auger header, double knife drive & stub gau)

SICKLE SECTIONS - MASSEY FERGUSON

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-211-002 |black 12ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |OU557HS

|A-211-201 |black 11ga under serrated |3.250" |2.125" |1" |7/32 x 5/8 |130356M1

|A-212-091 |chrome 11ga under serrated |3.250" |2.125" |1" |7/32 x 5/8 |669807M1

|A-212-181 |chrome 11ga smooth |3.250" |2.125" |1" |7/32 x 5/8 |669806M1

|A-212-403 |chrome 14ga top serrated |3.250" |2.125" |1" |7/32 x 5/8 |1046779M1

|A-211-223 |black 14ga under serrated |3.250" |2.125" |1" |7/32 x 5/8 |875785L

|A-211-162 |black 12ga smooth |3.250" |2.125" |1" |7/32 x 5/8 |130357M1

|A-212-103 |chrome 14ga under serrated |3.250" |2.125" |1" |7/32 x 5/8 |160262M1

|A-212-412 |chrome 12ga top serrated |3.250" |2.125" |1" |7/32 x 5/8 |31-7970650

|A-232-412 |chrome 12ga big tooth |3.250" |2.125" |1" |7/32 x 5/8 |1046776M1BT

|A-211-411 |black 11ga top serrated |3.250" |2.125" |1" |7/32 x 5/8 |1071707M1

|A-231-411 |black 11ga big tooth |3.250" |2.125" |1" |7/32 x 5/8 |1071707M1BT

|A-412-102 |chrome 12ga top serrated |3" wide |3.218"long ||7/32 x 5/8 |1055090M1

|A-412-032 |chrome 12ga top serrated |3.250" |2" |1.250" |7/32 x 5/8 |146503M2, 26143M1H

|A-211-273 |black 14ga under serrated |3.250" |width 3" ||1/4 x 5/8 |1146

|A-211-362 |black 14ga top serrated |3.250" |width 3" ||1/4 x 5/8 |A10081

SICKLE ASSEMBLIES & PARTS

SICKLE PARTS - MASSEY FERGUSON

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-010 |Sickle Head |683879M91 |

|A-920-229 |Bushing |683458M1 |

|A-901-056 |Sickle Head |144306M91 |

|A-920-222 |Bushing |143015M1 |

|A-901-057 |Sickle Head |31-7970683 |

|A-901-054 |Bushing |SW1740 |

|A-901-123 |Sickle Head |1049406M91 |

|A-901-109 |Sickle Head |1056738M91 |

|A-901-090 |Head |669505M3 |

|A-901-070 |Head & Strap |667200M95 |

|A-901-087 |Head only |581387M1 |

|A-901-114 |Spring, Head, Connector |581169M91 |

|A-901-097 |Connector |667015M1 |

|A-529-056 |Wear Plate |206196M1, 231303M1 |

|A-669434M1 |Pitman Wood, 34" |669434M1 |

|A-515-126 |Knifehead clip ||

|A-515-066 |Low Knife Clip |61384282 |

|A-920-277 |Guard, Center Malleable |679837M91 |

|A-920-278 |Guard, Outer Malleable |668457M92 |

|A-920-101 |Center Guard |50HS4A, 143HSA |

|A-920-102 |Outer Guard |15011105M1 |

|A-920-118 |Ledger Plate ||

|A-904-520 |(50) 7/16x1-1/2" bolts ||

|A-904-521 |(50) 7/16x1-3/4" bolts ||

|A-920-302 |Outer Shoe Plate |669099M1 |

|A-920-275 |Ledger Plate |668611M1 |

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-474 |A-800-474 |chrome 11ga under serrated |6 ft. |667200M95 |669787M93 |669807M1

|A-801-475 |A-800-475 |chrome 11ga under serrated |7 ft. |667200M95 |669791M93 |669807M1

|A-801-476 |A-800-476 |chrome 11ga under serrated |8 ft. |667200M95 |669703M93 |669807M1

For Models:

(MOWER: DYNA-BALANCE 31, DYNA-BALANCE 51, DYNA-BALANCE 71, DYNA-BALANCE 135 series FEO (cast gear box))

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-633 |A-800-633 |chrome 11ga under serrated |6 ft. |669505M3 |669818M92 |669807M1

|A-801-608 |A-800-608 |chrome 11ga under serrated |7 ft. |669505M3 |669822M92 |669807M1

For Models:

(MOWER: PITMAN 32, PITMAN 42, PITMAN 52, PITMAN 238)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-477 |A-800-477 |chrome 11ga smooth |6 ft. |581387M1 |581172M92 |669806M1

|A-801-478 |A-800-478 |chrome 11ga under serrated |6 ft. |581387M1 |581173M92 |669807M1

|A-801-479 |A-800-479 |chrome 11ga smooth |7 ft. |581387M1 |581176M92 |669806M1

|A-801-480 |A-800-480 |chrome 11ga under serrated |7 ft. |581387M1 |581177M92 |669807M1

|A-801-481 |A-800-481 |chrome 11ga under serrated |8 ft. |581387M1 |581181M92 |669807M1

For Models:

(MOWER: DYNA-BALANCE 135 SN 18100810-> (welded gear box), DYNA-BALANCE 41)

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-348 |A-800-348 |black 12ga under serrated |9 ft. |Headless |290744S, 290627S |OU577HS

For Models:

(MOWER CONDITIONER: 81 haytender)

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-056 |A-800-056 |black 12ga under serrated |7 ft. |683879M91 |683590M91 |683937M1

|A-801-053 |A-800-053 |black 12ga under serrated |9 ft. |683879M91 |683583M91 |683937M1

|A-801-694 |A-800-694 |black 12ga under serrated |9 ft. |Headless |683583M91-S |683937M1

For Models:

(MOWER CONDITIONER: 725 (7'), 925 (9'), BN1000 (7'), BN1005 (9'))

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-402 |A-800-402 |chome 12ga top serrated |12 ft. |144306M91 |146469M91 |146503M2

|A-801-403 |A-800-403 |chome 14ga top serrated |14 ft. |144306M91 |146459M91 |261431M1

|A-801-405 |A-800-405 |chome 14ga top serrated |16 ft. |144306M91 |146462M91 |261431M1

|A-801-407 |A-800-407 |chome 14ga top serrated |18 ft. |144306M91 |146465M91 |261431M1

For Models:

(WINDROWER: 36, 34, 44)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-641 |A-800-641 |chome 14ga top serrated |18 ft. |Headless |1042904M91 |1046779M1

|A-801-642 |A-800-642 |chome 14ga top serrated |21 ft. |Headless |1041471M91 |1046779M1

|N/A A-830-564 |chome 14ga top serrated |21 ft |Headless |1041471M91BT |1046779M1BT

|A-801-643 |A-800-643 |chome 14ga top serrated |25 ft. |Headless |1050779M91 |1046779M1

For Models:

(WINDROWER: 35)

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-409 |A-800-409 |chome 12ga top serrated |12 ft. |31-7970683 |1046768M1 |31-7970650

|A-801-411 |A-800-411 |chome 12ga top serrated |15 ft. |31-7970683 |31-7970623 |31-7970650

|A-801-413 |A-800-413 |chome 12ga top serrated |18 ft. |31-7970683 |31-7970633 |31-7970650

|A-801-415 |A-800-415 |chome 12ga top serrated |21 ft. |31-7970683 |31-7970643 |31-7970650

For Models:

(WINDROWER: 655, 675, 775, 785 w/ draper header)

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-786 |A-800-786 |chome 12ga top serrated |12 ft. |1049406M91 |1049402M91 |1046776M1

|A-801-787 |A-800-787 |chome 12ga top serrated |14 ft. |1049406M91 |1049403M91 |1046776M1

For Models:

(WINDROWER: 775 w/ auger header)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-831-859 |A-830-859 |black 14ga under serrated |14 ft. LH |Headless |32849 Rivet, A10127 Bolt |1146

|A-831-847 |N/A |black 12ga top serrated |14 ft. LH |Headless |48892 |A10081

|A-831-854 |A-830-854 |black 14ga under serrated |4 ft. RH |Headless |39871 Rivet, A10122 Bolt |1146

|A-831-842 |N/A |black 12ga top serrated |4 ft. RH |Headless |48896 |A10081

|A-831-855 |A-830-855 |black 14ga under serrated |8 ft. RH |Headless |39868 Rivet, A101123 Bolt |1146

|A-831-843 |N/A |black 12ga top serrated |8 ft. RH |Headless |48894 |A10081

|A-831-856 |A-830-856 |black 14ga under serrated |12 ft. RH |Headless |32850 Rivet, A10124 Bolt |1146

|A-831-844 |N/A |black 12ga top serrated |12 ft. RH |Headless |48893 |A10081

|A-831-857 |A-830-857 |black 14ga under serrated |16 ft. RH |Headless |39870 Rivet, A10125 Bolt |1146

|A-831-845 |N/A |black 12ga top serrated |16 ft. RH |Headless |48895 |A10081

|A-831-858 |A-830-858 |black 14ga under serrated |20 ft. RH |Headless |39869 Rivet, A10126 Bolt |1146

|A-831-846 |N/A |black 12ga top serrated |20 ft. RH |Headless |3729276M1TS |A10081

For Models:

(SWATHER: 200 self propelled, 210 pull type)

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-670 |A-800-670 |black 14ga under serrated |21 ft. |Headless |1043842M91 |1041472M1

|A-801-671 |A-800-671 |black 14ga under serrated |25 ft. |Headless |1065051M91 |1041472M1

|A-801-672 |A-800-672 |black 14ga under serrated |30 ft. |Headless |1065052M91 |1041472M1

|A-801-673 |A-800-673 |black 14ga under serrated |21 ft. LH |Headless |1069664M91 |1041472M1

|A-801-674 |A-800-674 |black 14ga under serrated |15 ft. RH |Headless |1069665M91 |1041472M1

For Models:

(SWATHER: 613 pull type, 625)

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-644 |A-800-644 |Xblack 12ga top serrated |12 ft. |Headless |1057934M91 |1071707M1

|A-801-645 |A-800-645 |Xblack 12ga top serrated |14 ft. |1056738M91 |1056865M91 |1071707M1

|A-801-646 |A-800-646 |Xblack 12ga top serrated |14 ft. |Headless |1056866M91 |1071707M1

|A-801-647 |A-800-647 |Xblack 12ga top serrated |14 ft. |Headless |1057538M91 |1071707M1

For Models:

(SWATHER: 885 w/ auger header)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - MASSEY FERGUSON

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-648 |A-800-648 |chome 12ga top serrated |15 ft. |Headless |1057966M91, 1057964M91 |31-7970650

|A-801-649 |A-800-649 |chome 12ga top serrated |18 ft. |Headless |1057967M91, 1057965M91 |1055090M1

|A-801-650 |A-800-650 |chome 12ga top serrated |21 ft. |Headless |1057508M91 |1055090M1

|A-801-651 |A-800-651 |chome 12ga top serrated |26 ft 1 pc. |Headless |1056739M91, 1056738M91 |1055090M1

|A-801-652 |A-800-652 |chome 12ga top serrated |31 ft 1 pc. |Headless |1057912M91 |1055090M1

For Models:

(SWATHER: 885 w/ draper header)

SICKLE SECTIONS - NEW HOLLAND

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-211-003 |black 14ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |1145

|A-212-063 |chrome 14ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |604800

|A-211-233 |black 14ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |67631

|A-212-003 |chrome 14ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |604921

|A-212-012 |chrome 12ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |94579

|A-211-211 |black 11ga top serrated, 2 hole |3.250" |2.062" |1" |7/32 x 5/8 |9622744

|A-231-211 |black 11ga big tooth, 2 hole |3.250" |2.062" |1" |7/32 x 5/8 |124737BT

|A-231-461 |black 11ga saber tooth |3.250" |2.062" |1" |7/32 x 5/8 |9622744ST

|A-212-001 |chrome 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |700705300

|A-232-001 |chrome 11ga big tooth |3.250" |2.062" |1" |7/32 x 5/8 |700705300BT

|A-232-461 |chrome 11ga saber tooth |3.250" |2.062" |1" |7/32 x 5/8 |9826090ST

|A-211-011 |black 11ga smooth |3.250" |2.062" |1" |7/32 x 5/8 |26622

|A-212-001 |chrome 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |700705300

|A-212-061 |chrome 12ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |060635

|A-212-403 |chrome 14ga top serrated |3.250" |2.125" |1" |7/32 x 5/8 |1046779M1

|A-212-412 |chrome 12ga top serrated |3.250" |2.125" |1" |7/32 x 5/8 |31-7970650

|A-611-070 |black 11ga under serrated |end sect. |3 holes |RH |7/32 x 5/8 |630555

|A-611-090 |black 11ga under serrated |end sect. |3 holes |LH |7/32 x 5/8 |634789

|A-611-130 |black 11ga top serrated |end sect. |3 slotted |RH |7/32 x 5/8 |9622715

|A-611-140 |black 11ga top serrated |end sect. |3 slotted |LH |7/32 x 5/8 |9622714

|A-212-262 |chrome 12ga top serrated |rivet type |btmCTSK |rivet type |7/32 x 5/8 CTSK |706424H

|A-212-232 |chrome 12ga top serrated |rivet type |top CTSK |rivet type |7/32 x 5/8 CTSK |706423H

|A-622-271 |chrome 11ga top serrated |overlap |btmCTSK |rivet type |7/32 x 5/8 CTSK |766758

|A-622-281 |chrome 11ga top serrated |overlap |top CTSK |rivet type |7/32 x 5/8 CTSK |766757

|A-412-161 |chrome 11ga top serrated |overlap |btmCTSK |rivet type |7/32 x 5/8 CTSK |694722

|A-212-513 |chrome 14ga top serrated |bolt type |btmCTSK |bolt type |7/32 x 5/8 CTSK |9826047

|A-212-523 |chrome 14ga top serrated |bolt type |top CTSK |bolt type |7/32 x 5/8 CTSK |9826046

|A-212-302 |chrome 12ga top serrated |bolt type |btmCTSK |bolt type |7/32 x 5/8 CTSK |9826047H

|A-212-312 |chrome 12ga top serrated |bolt type |top CTSK |bolt type |7/32 x 5/8 CTSK |9826046H

|A-211-191 |chrome 11ga top serrated |bolt type |btmCTSK |bolt type |7/32 x 5/8 CTSK |861353

|A-211-181 |chrome 11ga top serrated |bolt type |top CTSK |bolt type |7/32 x 5/8 CTSK |861354

|A-711-002 |kit: chrm 12ga top ser |rivet type |top/btm |rivet type |7/32 x 5/8 CTSK |

|A-711-004 |kit: chrm 11ga top ser |bolt type |top/btm |bolt type |7/32 x 5/8 CTSK |

|A-711-005 |kit: blk 11ga top ser |bolt type |top/btm |bolt type |7/32 x 5/8 CTSK |

|A-711-006 |kit: chrm 14ga top ser |bolt type |top/btm |bolt type |7/32 x 5/8 CTSK |

SICKLE ASSEMBLIES & PARTS

SICKLE PARTS - NEW HOLLAND

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-008 |Sickle Head |858740 |

|A-920-433 |Bushing |127610 |(MOWER: 450, 456, 499, 1496), (WINDROWER: 499, 1496, 1499)

|A-901-005 |Sickle Head |86507377 |(MOWER CONDITIONER: 460, 461, 467, 469)

|A-920-434 |Bushing |134182 |(MOWER CONDITIONER: 460, 467, 469)

|A-901-007 |Sickle Head |577868 |(MOWER CONDITIONER: 472, 477, 478)

|A-901-006 |Sickle Head |577867 |(MOWER CONDITIONER: 479, 488, 490, 1496)

|A-920-437 |Bushing |254132 |(MOWER CONDITIONER: 472, 479)

|A-901-033 |Sickle Head |289488 |(MOWER CONDITIONER: 474, 489)

|A-920-406 |Hub & Bushing |701401 |(MOWER CONDITIONER: 474, 489)

|A-901-034 |Sickle Head |86508155 |(MOWER CONDITIONER: 495, 1495)

|A-901-001 |Sickle Head, RH |137635 |(WINDROWER: 907, 912)

|A-920-436 |Bushing |76417 |(WINDROWER: 907, 912, 114, 1112, 1116, 1118)

|A-901-002 |Sickle Head, LH |135822 |(WINDROWER: 907, 912)

|A-901-003 |Sickle Head, RH |858714 |(WINDROWER: 1112, 1116)

|A-901-004 |Sickle Head, LH |858713 |(WINDROWER: 1112, 1116)

|A-901-009 |Sickle Head |76173 |(WINDROWER: 905)

|A-901-060 |Sickle Head, RH |704316, 858756 |(WINDROWER: 114)

|A-901-061 |Sickle Head, LH |575163, 858755 |(WINDROWER: 114)

|A-901-107 |Sickle Head, LH |86536346 |(WINDROWER: 499, 1496, 1499)

|A-920-433 |Bushing |127610 |(MOWER: 450, 456, 499, 1496), (WINDROWER: 499, 1496, 1499)

|A-529-016 |Wear Plate |71116532, 71176537 |

|A-515-066 |Low Knife Clip |61384282 |

|A-515-126 |Knifehead clip ||

|A-920-323 |Inner Sole |36653 |

|A-920-324 |Outer Sole |37025 |

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-049 |A-800-049 |black 11ga under serrated |7 ft |858740 |143607 |29875

|A-801-051 |A-800-051 |black 11ga under serrated |9 ft |858740 |143609 |29875

|N/A A-800-696 |black 11ga top serrated |9 ft |858740 |143609TS |9622744

For Models:

450 SN 87764->, 455 SN 88846->

|A-801-362 |A-800-362 |black 11ga under serrated |7 ft |858740 |228435 |29875

|A-861-418 |A-860-418 |black, 11ga top serrated |7 ft |858740 |228435TS, 86534626 |9622744

|A-861-013 |N/A |black, 11ga big tooth |7 ft |858740 |228435BT, 86534625BT |9622744BT

|N/A A-860-383 |black, 11ga smooth |9 ft |858740 |228432 |26622

|A-801-363 |A-800-363 |black, 11g under serrated |9 ft |858740 |228434, 858746 |29875

|A-801-756 |A-800-756 |black, 11ga top serrated |9 ft |858740 |86534626 |9622744

For Models:

451, 456

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-035 |A-800-035 |black, 11ga under serrated |7 ft |86507377 |137214 |29875

For Models:

467

|A-801-036 |A-800-036 |black, 11ga under serrated |9 ft |86507377 |127609, 134186 |29875

For Models:

460, 461

|A-801-037 |A-800-037 |black, 11ga under serrated |9 ft |86507377 |86518677, 648844 |29875

|A-801-767 |A-800-767 |black, 11ga top serrated |9 ft |86507377 |86518678 |9622744

|N/A |A-861-440 |black, 11ga big tooth |9 ft |86507377 |86518678BT |9622744BT

For Models:

469, 1469 SN <-220947

|A-801-274 |A-800-274 |black, 11ga under serrated |12 ft |86507377 |174593 |29875

For Models:

490 SN <-259714

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-040 |A-800-040 |black, 11ga under serrated |7 ft |577868 |648832, 858708 |29875

|A-831-079 |N/A |black, 11ga top serrated |7 ft |577868 |9623792, 9623571 |9622744

|N/A |A-830-079 |black, 11ga top serrated |7 ft |577868 |9623792, 9623571 |9622744

|A-801-042 |A-800-042 |black, 11ga under serrated |9 ft |577867 |648840, 858700 |29875

|A-801-768 |A-800-768 |black, 11ga top serrated |9 ft |577867 |9623793, 9623570 |9622744

|A-861-012 |N/A |black, 11ga big tooth |9 ft |577867 |9623570BT |9622744BT

|A-801-520 |A-800-520 |black, 11ga under serrated |12 ft |86512652 |579171 |29875

For Models:

472, 477, 478 7', 479, 488 9', 490 12', SN 259714->, 1469 9', SN 220947->

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-500 |A-800-500 |black, 11ga under serrated |7 ft |289488 |648831, 858748 |29875

|A-831-822 |N/A |black, 11ga top serrated |7 ft |289488 |9623560 |9622744

|A-801-270 |A-800-270 |black, 11ga under serrated |9 ft |289488 |648835, 858702 |29875

|A-801-769 |A-800-769 |black, 11ga top serrated |9 ft |289488 |86529232 |9622744

|A-861-011 |N/A |black, 11ga big tooth |9 ft |289488 |86529232BT |9622744BT

For Models:

474 7', 489, 492 9', 1465

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-271 |A-800-271 |black, 11ga under serrated |12 ft |86508155 |648003, 858706 |29875

|A-801-770 |A-800-770 |black, 11ga top serrated |12 ft |86508155 |9623797, 9623572 |9622744

|A-831-572 |A-830-572 |black, 11ga big tooth |12 ft |86508155 |9623797BT, 9623572BT |9622744BT

For Models:

495, 1495

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-482 |A-800-482 |black, 11ga under serrated |6 ft LH |86536346 |635163, 9619698 |29875

|A-801-483 |A-800-483 |black, 11ga under serrated |6 ft RH |86536345 |635279, 9619669 |29875

|A-831-823 |A-830-823 |black, 11ga top serrated |6 ft LH |86536346 |86536819, 9622712 |9622744

|A-831-824 |A-830-824 |black, 11ga top serrated |6 ft RH |86536345 |86536820, 9622713 |9622744

|A-831-495 |N/A |black, 11ga big tooth |6 ft LH |86536346 |86536819BT, 9622712BT |9622744BT

|A-831-496 |N/A |black, 11ga big tooth |6 ft RH |86536345 |86536820BT, 9622713BT |9622744BT

|A-861-562 |N/A |chome 11ga top serrated |6 ft LH |86536346 |86536819PL, 9622712PL |9826090

|A-861-565 |N/A |chome 11ga top serrated |6 ft RH |86536345 |86536820PL, 9622713PL |9826090

For Models:

499 pivot tongue, 1496, 1499

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-420 |N/A |black, 14ga under serrated |6 ft RH |858756, 704316 |858752, 708297 |67630

For Models:

114 pivot tongue

|N/A |A-800-420 |black, 14ga under serrated |6 ft RH |858756, 704317 |858752, 708298 |67630

|A-801-422 |N/A |black, 14ga under serrated |6 ft LH |858755, 575163 |858751, 708296 |67630

|N/A |A-800-422 |black, 14ga under serrated |6 ft LH |858755, 575164 |858751, 708297 |67630

|A-801-421 |N/A |black, 14ga under serrated |7 ft RH |858756, 704316 |858750, 575114 |67630

|N/A |A-800-421 |black, 14ga under serrated |7 ft RH |858756, 704317 |858750, 575115 |67630

|A-801-423 |N/A |black, 14ga under serrated |7 ft LH |858755, 575163 |858749, 575106 |67630

|N/A |A-800-423 |black, 14ga under serrated |7 ft LH |858755, 575164 |858749, 575107 |67630

|A-861-754 |N/A |black, 11ga top serrated |7 ft RH |858756 |858750TS |9622744

|A-861-755 |N/A |black, 11ga top serrated |7 ft LH |858755 |858749TS |9622744

For Models:

114 pivot tongue

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-043 |A-800-043 |chome 14ga top serrated |12 ft |76173 |67156 |604921

|A-801-044 |A-800-044 |chome 14ga top serrated |14 ft |76173 |67145 |604921

For Models:

905

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-005 |A-800-005 |chome 14ga under serrated |6 ft RH |137635 |139179 |604800

|A-801-006 |A-800-006 |chome 14ga under serrated |6 ft LH |135822 |139182 |604800

|A-801-015 |A-800-015 |chome 14ga under serrated |7 ft RH |137635 |139184 |604800

|A-801-016 |A-800-016 |chome 14ga under serrated |7 ft LH |135822 |139185 |604800

|A-801-011 |A-800-011 |chome 12ga top serrated |7 ft RH |137635 |9623845 |604921H

|A-801-012 |A-800-012 |chome 12ga top serrated |7 ft LH |135822 |9623844 |604921H

|A-881-068 |N/A |chome 11ga sabre tooth |7 ft RH |137635 |9623845ST |9826090ST

|A-881-069 |N/A |chome 11ga sabre tooth |7 ft LH |135822 |9623844ST |9826090ST

|A-801-025 |A-800-025 |chome 14ga under serrated |8 ft RH |137635 |139186 |604800

|A-801-026 |A-800-026 |chome 14ga under serrated |8 ft LH |135822 |139187 |604800

|A-801-021 |A-800-021 |chome 12ga top serrated |8 ft RH |137635 |9623843 |604921H

|A-801-022 |A-800-022 |chome 12ga top serrated |8 ft LH |135822 |9623842 |604921H

For Models:

907, 909, 910, 912

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-003 |A-800-003 |chome 12ga top serrated |6 ft RH |Headless |706420 |604921H

|A-801-004 |N/A |chome 12ga top serrated |6 ft LH |Headless |706419 |604921H

|A-801-013 |A-800-013 |chome 12ga top serrated |7 ft RH |Headless |706418 |604921H

|A-801-014 |A-800-014 |chome 12ga top serrated |7 ft LH |Headless |706417 |604921H

|A-881-072 |N/A |chome 11ga sabre tooth |7 ft RH |Headless |706418ST |9826090ST

|A-881-073 |N/A |chome 11ga sabre tooth |7 ft LH |Headless |706417ST |9826090ST

|A-801-023 |A-800-023 |chome 12ga top serrated |8 ft RH |Headless |706416 |604921H

|A-801-024 |A-800-024 |chome 12ga top serrated |8 ft LH |Headless |706415 |604921H

For Models:

(907, 909, 912, 1112, 1114, 1116, 116 ALL w/ headless sickles)

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-505 |A-800-505 |chome 12ga under serrated |10 ft |135822 |143013PL |604800

|N/A |A-800-510 |chome 12ga under serrated |12 ft |135822 |135853PL |604800

|A-801-502 |N/A |chome 12ga under serrated |14 ft |135822 |137969PL |604800

For Models:

1100 w/ auger or draper head, 903 12'

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-009 |A-800-009 |chome 14ga under serrated |6 ft RH |858714 |264984PL |604800

|A-801-010 |A-800-010 |chome 14ga under serrated |6 ft LH |858713 |264986PL |604800

|A-861-039 |N/A |black 14ga under serrated |6 ft RH |858714 |264984 |276617

|A-861-040 |N/A |black 14ga under serrated |6 ft LH |858713 |264986 |276617

|A-801-017 |A-800-017 |chome 12ga top serrated |7 ft RH |858714 |86518780H, 9826051H |604921H

|A-801-018 |A-800-018 |chome 12ga top serrated |7 ft LH |858713 |86518780H, 9826050H |604921H

|A-801-019 |A-800-019 |chome 14ga under serrated |7 ft RH |858714 |247988PL, 9619697PL |604800

|A-801-020 |A-800-020 |chome 14ga under serrated |7 ft LH |858713 |247987PL, 9619696PL |604800

|A-831-008 |A-830-008 |black 14ga under serrated |7 ft RH |858714 |247988, 9619697 |604921

|A-831-009 |A-830-009 |black 14ga under serrated |7 ft LH |858713 |247987, 9619696 |604921

|A-831-893 |A-830-893 |black 11ga top serrated |7 ft RH |858714 |247988TS, 9619697TS |9622744

|A-831-894 |A-830-894 |black 11ga top serrated |7 ft LH |858713 |247987TS, 9619696TS |9622744

|A-831-825 |N/A |black 11ga big tooth |7 ft RH |858714 |247988BT, 9619697BT |9622744BT

|A-831-826 |N/A |black 11ga big tooth |7 ft LH |858713 |247987BT, 9619696BT |9622744BT

|A-831-201 |A-830-201 |chome 11ga big tooth |7 ft RH |858714 |247988PLBT, 9619697PLBT |9826090BT

|A-831-202 |A-830-202 |chome 11ga big tooth |7 ft LH |858713 |247987PLBT, 9619696PLBT |9826090BT

|A-801-027 |A-800-027 |chome 12ga top serrated |8 ft RH |858714 |86518782H, 9826049H |604921H

|A-801-028 |A-800-028 |chome 12ga top serrated |8 ft LH |858713 |86518783H, 9826048H |604921H

|A-801-029 |A-800-029 |chome 14ga under serrated |8 ft RH |858714 |264985PL, 9619695PL |604800

|A-801-030 |A-800-030 |chome 14ga under serrated |8 ft LH |858713 |264987PL, 9619694PL |604800

|A-831-010 |A-830-010 |black 12ga under serrated |8 ft RH |858714 |264985, 9619695 |604921

|A-831-011 |A-830-011 |black 12ga under serrated |8 ft LH |858713 |264987, 9619694 |604921

|A-831-895 |A-830-895 |black 11ga top serrated |8 ft RH |858714 |264985TS, 9619695TS |9622744

|A-831-896 |A-830-896 |black 11ga top serrated |8 ft LH |858713 |264987TS, 9619694TS |9622744

|A-831-497 |N/A |black 11ga big tooth |8 ft RH |858714 |264985BT, 9619695BT |9622744BT

|A-831-498 |N/A |black 11ga big tooth |8 ft LH |858713 |264987BT, 9619694BT |9622744BT

|A-861-035 |N/A |black 11ga big tooth |8 ft RH |858714 |264985PLBT, 9619695PLBT |9826090BT

|A-861-036 |N/A |black 11ga big tooth |8 ft LH |858713 |264987PLBT, 9619694PLBT |9826090BT

For Models:

1100 high perform header, 1112, 1114, 1116, 1118, 116 14' and 16' pivot tongue

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|N/A |A-800-653 |chome 12ga top serrated |12 ft |Headless |9605373 |275521

For Models:

1090 self propelled headless

|N/A |A-800-654 |chome 12ga top serrated |15 ft |Headless |275503 |275521

|N/A |A-800-655 |chome 14ga top serrated |18 ft |Headless |275504R |275522

|N/A |A-800-656 |chome 14ga top serrated |21 ft |Headless |275505R |275522

For Models:

1090 self propelled headless

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-409 |A-800-409 |chome 12ga top serrated |12 ft. |31-7970683 |1046768M1 |31-7970650

|A-801-411 |A-800-411 |chome 12ga top serrated |15 ft. |31-7970683 |31-7970623 |31-7970650

|A-801-413 |A-800-413 |chome 12ga top serrated |18 ft. |31-7970683 |31-7970633 |31-7970650

|A-801-415 |A-800-415 |chome 12ga top serrated |21 ft. |31-7970683 |31-7970643 |31-7970650

For Models:

1090 self propelled w/ head

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-861-388 |N/A |black 11ga top serrated |6 ft LH |Headless |86528151 |9622744

For Models:

1475 dbl overlap design, 2200, 2300, 2450, 2550

|A-861-389 |N/A |black 11ga top serrated |6 ft RH |Headless |86528152 |9622744

|A-861-390 |N/A |black 11ga top serrated |7 ft LH |Headless |86528149 |9622744

|A-861-391 |N/A |black 11ga top serrated |7 ft RH |Headless |86528150 |9622744

|A-861-398 |N/A |black 11ga big tooth |7 ft LH |Headless |86544308 |9622744BT

|A-861-399 |N/A |black 11ga big tooth |7 ft RH |Headless |86544309 |9622744BT

|A-881-062 |N/A |black 11ga sabre tooth |7 ft LH |Headless |86544308ST |9622744ST

|A-881-063 |N/A |black 11ga sabre tooth |7 ft RH |Headless |86544309ST |9622744ST

|A-861-392 |N/A |black 11ga top serrated |8 ft LH |Headless |86528147 |9622744

|A-861-393 |N/A |black 11ga top serrated |8 ft RH |Headless |86528148 |9622744

|A-861-400 |N/A |black 11ga big tooth |8 ft LH |Headless |86544306 |9622744BT

|A-861-401 |N/A |black 11ga big tooth |8 ft RH |Headless |86544307 |9622744BT

|A-881-064 |N/A |black 11ga sabre tooth |8 ft LH |Headless |86544306ST |9622744ST

|A-881-065 |N/A |black 11ga sabre tooth |8 ft RH |Headless |86544307ST |9622744ST

|A-861-394 |N/A |black 11ga top serrated |9 ft LH |Headless |86528145 |9622744

|A-861-395 |N/A |black 11ga top serrated |9 ft RH |Headless |86528146 |9622744

|A-861-402 |N/A |black 11ga big tooth |9 ft LH |Headless |86544304 |9622744BT

|A-861-403 |N/A |black 11ga big tooth |9 ft RH |Headless |86544305 |9622744BT

For Models:

1475 dbl overlap design, 2200, 2300, 2450, 2550

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-146 |A-800-146 |chome 11ga top serrated |13 ft |STUDS |271979PL |271981PL

|A-801-516 |A-800-516 |chome 11ga big tooth |13 ft |STUDS |271979PLBT |271981PLBT

|A-801-148 |A-800-148 |chome 11ga top serrated |15 ft |STUDS |271980PL |271981PL

|A-801-517 |A-800-517 |chome 11ga big tooth |15 ft |STUDS |271980PLBT |271981PLBT

|A-801-150 |A-800-150 |chome 11ga top serrated |16 ft |STUDS |-|271981PL

|A-831-518 |N/A |chome 11ga big tooth |16 ft |STUDS |-|271981PLBT

SICKLE ASSEMBLIES & PARTS

|A-801-152 |A-800-152 |chome 11ga top serrated |18 ft |STUDS |-|271981PL

|A-801-154 |A-800-154 |chome 11ga top serrated |20 ft |STUDS |273847PL |271981PL

|A-831-520 |N/A |chome 11ga big tooth |20 ft |STUDS |273847PLBT |271981PLBT

|N/A |A-800-156 |chome 11ga top serrated |22 ft. |STUDS |273847PLBT |271981PL

For Models:

960 flex header

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-802-040 |N/A |chome 11ga top serrated |10 ft RH |848094 |851662 |848093

For Models:

(TR75, TR85, TR86, TR95, TR96, TX36, TX66, TX88 ALL w/ header), (970, 971, 972, 973 ALL w/ twin points)

|A-802-041 |N/A |chome 11ga top serrated |10 ft LH |848094 |851663 |848093

|A-802-043 |N/A |chome 11ga top serrated |12 ft LH |848094 |9842537 |848093

|A-802-045 |N/A |chome 11ga top serrated |15 ft LH |848094 |9820456 |848093

For Models:

(TR75, TR85, TR86, TR95, TR96, TX36, TX66, TX88 ALL w/ header), (970, 971, 972, 973 ALL w/ twin points)

SICKLE ASSEMBLIES - NEW HOLLAND

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-429 |N/A |chome 11ga top serrated |15 ft |848094 |605039, 851667 |694723

For Models:

(TR75, TR85, TR86, TR95, TR96, TX36, TX66, TX88 ALL w/ header), 970, 971, 972, 973

|N/A |A-800-431 |chome 11ga top serrated |18 ft |848094 |605663, 851654 |694723

|A-801-432 |N/A |chome 11ga top serrated |10 ft RH |848094 |605665, 851668 |694723

|A-801-433 |N/A |chome 11ga top serrated |10 ft LH |848094 |605668, 851669 |694723

For Models:

(TR75, TR85, TR86, TR95, TR96, TX36, TX66, TX88 ALL w/ header), 970, 971, 972, 973

SICKLE SECTIONS - NEW IDEA

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-211-003 |black 14ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |1145

|A-211-002 |black 12ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |OU557HS

|A-211-001 |black 11ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |29875

|A-212-001 |chrome 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |700705300

|A-212-063 |chrome 14ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |604800

|A-211-233 |black 14ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |67631

|A-212-003 |chrome 14ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |604921

|A-212-012 |chrome 12ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |94579

|A-211-211 |black 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |9622744

|A-231-211 |black 11ga big tooth |3.250" |2.062" |1" |7/32 x 5/8 |124737BT

|A-231-461 |black 11ga saber tooth |3.250" |2.062" |1" |7/32 x 5/8 |9622744ST

|A-212-001 |chrome 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |700705300

|A-232-001 |chrome 11ga big tooth |3.250" |2.062" |1" |7/32 x 5/8 |700705300BT

SICKLE ASSEMBLIES & PARTS

|A-232-461 |chrome 11ga sabertooth |3.250" |2.062" |1" |7/32 x 5/8 |9826090ST

|A-211-011 |black 11ga smooth |3.250" |2.062" |1" |7/32 x 5/8 |26622

|A-211-001 |black 11ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |29875

|A-212-061 |chrome 11ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |060635

|A-212-262 |overlap chrm 12ga top ser |rivet type |||7/32 x 5/8 CTSK |706424H

|A-212-232 |overlap chrm 12ga top ser |rivet type |||7/32 x 5/8 CTSK |706423H

|A-212-513 |overlap chrm 14ga top ser |bolt type |||7/32 x 5/8 CTSK |9826047

|A-212-523 |overlap chrm 14ga top ser |bolt type |||7/32 x 5/8 CTSK |9826046

|A-212-302 |overlap chrm 12ga top ser |bolt type |||7/32 x 5/8 CTSK |9826047H

|A-212-312 |overlap chrm 12ga top ser |bolt type |||7/32 x 5/8 CTSK |9826046H

|A-211-191 |overlap blk 11ga top ser |bolt type |||7/32 x 5/8 CTSK |861353

|A-211-181 |overlap blk 11ga top ser |bolt type |||7/32 x 5/8 CTSK |861354

|A-711-002 |ovrlap kit, chrm 12ga top ser |rivet type |||7/32 x 5/8 CTSK |

|A-711-004 |ovrlap kit, chrm 12ga top ser |bolt type |||7/32 x 5/8 CTSK |

|A-711-005 |ovrlap kit, blk 11ga top ser |bolt type |||7/32 x 5/8 CTSK |

|A-711-006 |ovrlap kit, chrm 14ga top ser |bolt type |||7/32 x 5/8 CTSK |

SICKLE PARTS - NEW IDEA

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-008 |Sickle head |858740 |

|A-901-005 |Sickle head |86507377 |(MOWER CONDITIONER: 460, 461, 467, 469)

|A-901-007 |Sickle head |577868 |(MOWER CONDITIONER: 472, 477, 478)

|A-901-006 |Sickle head |577867 |(MOWER CONDITIONER: 479, 488, 490, 1496)

|A-901-033 |Sickle head |289488 |(MOWER CONDITIONER: 474, 489)

|A-901-034 |Sickle head |86508155 |(MOWER CONDITIONER: 495, 1495)

|A-901-009 |Sickle head |76173 |(WINDROWER: 905)

|A-901-002 |Sickle head, LH |135822 |(WINDROWER: 907, 912)

|A-901-004 |Sickle head, LH |858713 |(WINDROWER: 1112, 1116)

|A-901-061 |Sickle head, LH |575163, 858755 |(WINDROWER: 114)

|A-901-107 |Sickle head, LH |86536346 |

|A-901-001 |Sickle head, RH |137635 |(WINDROWER: 907, 912)

|A-901-003 |Sickle head, RH |858714 |(WINDROWER: 1112, 1116)

|A-901-060 |Sickle head, RH |704316, 858756 |(WINDROWER: 114)

|A-901-108 |Sickle head, RH |86536345 |(MOWER CONDITIONER: 1496, 499, 1499)

|A-910-059 |Knifehead |290271 |(MOWER: 290)

|A-901-075 |Knifehead |ZA502562 |(MOWER CONDITIONER: 512, 514)

|A-901-042 |Knifehead |824594C91 |(MOWER CONDITIONER: 507, 5107, 509, 5109)

|A-901-063 |Knifehead |045HSA |

|A-920-433 |Bushing |127610 |(MOWER: 450, 456)

|A-920-434 |Bushing |134182 |(MOWER CONDITIONER: 460, 469)

|A-920-437 |Bushing |254132 |(MOWER CONDITIONER: 472, 479, 488, 495, 1495)

|A-920-436 |Bushing |76417 |(WINDROWER: 907, 114, 1118)

|A-920-323 |Inner sole |36653 |

|A-515-066 |Low knife clip |61384282 |

|A-515-126 |Knifehead clip ||

|A-920-101 |Center Guard |50HS4A, 143HSA |

|A-920-102 |Outer Guard ||

|A-920-118 |Ledger Plate ||

|A-904-520 |(50) 7/16x1-1/2" bolts ||

|A-904-521 |(50) 7/16x1-3/4" bolts ||

|A-920-324 |Outer sole |37025 |

SICKLE ASSEMBLIES & PARTS

|A-903-104 |Overlap strap |858762, 86502971 |

|A-903-105 |Overlap strap |861711, 86502821 |

|A-529-016 |Wear plate |71116532, 71176537 |

|A-W20HSA |Pitman wood 36" |W20HSA |

SICKLE ASSEMBLIES - NEW IDEA

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-442 |A-800-442 |black 12ga under serrated |7 ft. |045HSA |OU286HSA |OU577HS

For Models:

(MOWER: 10, 20, 30, 40, 41, 250, 251, 252, 253, 254, 255)

SICKLE ASSEMBLIES - NEW IDEA

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-064 |A-800-064 |Xblack 12ga under serrated |5 ft. |56692C91 |463408R93 |826722C2

|A-801-065 |A-800-065 |Xblack 12ga under serrated |6 ft. |56692C91 |465112R93 |826722C2

|A-801-060 |A-800-060 |black 11ga smooth |7 ft. |56692C91 |462381R93 |826724C2

|A-801-066 |A-800-066 |Xblack 12ga under serrated |7 ft. |56692C91 |462380R93 |826722C2

|A-801-691 |A-800-691 |black 11ga top serrated |7 ft. |56692C91 |1281292C92 |826720C3

|A-861-010 |N/A |black 11ga big tooth |7 ft. |56692C91 |1281292C92BT |826720C3BT

|A-801-061 |A-800-061 |black 11ga smooth |9 ft. |56692C91 |463182R93 |826724C2

|A-801-692 |A-800-692 |black 11ga top serrated |9 ft. |56692C91 |1281291C92 |826720C3

|A-861-527 |N/A |black 11ga big tooth |9 ft. |56692C91 |1281291C92BT |826720C3BT

For Models:

(WINDROWER: 521, 522)

SICKLE ASSEMBLIES - NEW IDEA

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-348 |A-800-348 |black 12ga under serrated |9 ft. |Headless |290744S, 290627S |OU577HS

|A-801-419 |A-800-419 |black 12ga under serrated |9 ft. |290271 |290744, 290627 |OU577HS

For Models:

(MOWER CONDITIONER: 290)

SICKLE ASSEMBLIES - NEW IDEA

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-777 |A-800-777 |black 12ga under serrated |9 ft. |Headless |290927 |OU577HS

For Models:

(MOWER CONDITIONER: 299)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - NEW IDEA

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-400 |A-800-400 |Xblack 12ga under serrated |7 ft. |824594C91 |101987C95 |W501017E

|A-801-306 |A-800-306 |Xblack 12ga under serrated |9 ft. |824594C91 |101988C95 |W501017E

|A-831-869 |A-830-869 |black 11ga top serrated |9 ft. |824594C91 |1960310C1 |W501017ETS

For Models:

(MOWER CONDITIONER: 507, 5107 (7'), 509, 5109 (9'))

SICKLE ASSEMBLIES - NEW IDEA

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-764 |A-800-764 |chrome 11ga under serrated |12 ft. |ZA502562 |ZA502930, ZA502889 |502933

|A-801-765 |A-800-765 |chrome 11ga under serrated |14 ft. |ZA502562 |ZA502931, ZA502890 |502933

For Models:

(MOWER CONDITIONER: 512 (12') pivot tongue, 514 (14') pivot tongue)

SICKLE SECTIONS - PMI

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-211-003 |black 14ga under serrated |3.250" |2.062" |1" |7/32 x 5/8 |1145

|A-211-273 |black 14ga under serrated |3.250" |width 3" ||1/4 x 5/8 |1146

|A-211-362 |black 12ga top serrated |3.250" |width 3" ||1/4 x 5/8 |A10081

SICKLE ASSEMBLIES - PMI

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|N/A |A-830-593 |black 14ga under serrated |15 ft. |Headless |1301, 40035 |1145

For Models:

(SWATHER: 500 sp)

|N/A |A-860-212 |black 14ga under serrated |18 ft. |Headless |1302, 40036 |1145

For Models:

(SWATHER: 500 sp)

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - PMI

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-662 |A-800-662 |black 14ga under serrated |15 ft. |Headless |40059,10813, 14021 |1145

|A-801-663 |A-800-663 |black 14ga under serrated |18 ft. |Headless |40060, 10816, 14022 |1145

|A-801-664 |A-800-664 |black 14ga under serrated |21 ft. |Headless |40061, 10819, 14023 |1145

For Models:

(SWATHER: 550)

SICKLE ASSEMBLIES - PMI

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|N/A |A-830-594 |black 14ga under serrated |15 ft. |Headless |1304, 40038 |1145

For Models:

(SWATHER: 601 pull type)

|N/A |A-830-595 |black 14ga under serrated |18 ft. |Headless |1305, 40039 |1145

For Models:

(SWATHER: 601 pull type)

SICKLE ASSEMBLIES - PMI

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-831-856 |A-830-856 |black 14ga under serrated |12 ft. RH |Headless |32850 Rivet, A10124 Bolt |1146

|A-831-844 |N/A |black 12ga top serrated |12 ft. RH |Headless |48893 |A10081

|A-831-859 |A-830-859 |black 14ga under serrated |14 ft. LH |Headless |32849 Rivet, A10127 Bolt |1146

|A-831-857 |N/A |black 12ga top serrated |16 ft. RH |Headless |39870 Rivet, A10125 Bolt |1146

For Models:

(SWATHER: 626 pull type)

SICKLE ASSEMBLIES - PMI

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-831-854 |A-830-854 |black 14ga under serrated |4 ft. RH |Headless |39871 Rivet, A10122 Bolt |1146

|A-831-842 |N/A |black 12ga top serrated |4 ft. RH |Headless |48896 |A10081

|A-831-855 |A-830-855 |black 14ga under serrated |8 ft. RH |Headless |39868 Rivet, A101123 Bolt |1146

|A-831-843 |N/A |black 12ga top serrated |8 ft. RH |Headless |48894 |A10081

|A-831-856 |A-830-856 |black 14ga under serrated |12 ft. RH |Headless |32850 Rivet, A10124 Bolt |1146

|A-831-844 |N/A |black 12ga top serrated |12 ft. RH |Headless |48893 |A10081

|A-831-859 |A-830-859 |black 14ga under serrated |14 ft. LH |Headless |32849 Rivet, A10127 Bolt |1146

|A-831-847 |N/A |black 12ga top serrated |14 ft. LH |Headless |48892 |A10081

|A-831-857 |A-830-857 |black 14ga under serrated |16 ft. RH |Headless |39870 Rivet, A10125 Bolt |1146

|A-831-845 |N/A |black 12ga top serrated |16 ft. RH |Headless |48895 |A10081

|A-831-858 |A-830-858 |black 14ga under serrated |20 ft. RH |Headless |39869 Rivet, A10126 Bolt |1146

|A-831-846 |N/A |black 12ga top serrated |20 ft. RH |Headless |3729276M1TS |A10081

For Models:

(SWATHER: (702, 722 ALL w/ 2pc sickle assy))

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - PMI

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|N/A |A-830-639 |black 14ga under serrated |21 ft. LH |Headless |35483 |1146

For Models:

(SWATHER: 742 sp)

|N/A |A-830-638 |black 14ga under serrated |21 ft. RH |Headless |35484 |1146

For Models:

(SWATHER: 742 sp)

SICKLE SECTIONS - VERSATILE

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-211-123 |black 14ga top serrated |3.250" |2.062" |1" |7/32 x 9/16 |93545

|A-212-362 |chrome 12ga under serrated |3.250" |2.062" |1" |7/32 x 9/16 |93544

|A-211-053 |black 14ga top serrated |3" |2.062" |.875" |7/32 x 5/8 CTSK |SW1616 CTSK

|A-231-053 |black 14ga big tooth |3" |2.062" |.875" |7/32 x 5/8 CTSK |SW1616BT CTSK

|A-212-213 |chrome 14ga top serrated |3" |2.062" |.875" |7/32 x 5/8 CTSK |SW1616PL CTSK

|A-411-083 |black 14ga top serrated |3" |2.062" |1.250" |7/32 x 5/8 CTSK |SW1776 CTSK

|A-431-083 |black 14ga big tooth |3" |2.062" |1.250" |7/32 x 5/8 CTSK |SW1776BT CTSK

|A-412-063 |chrome 14ga top serrated |3" |2.062" |1.250" |7/32 x 5/8 CTSK |SW1776PL CTSK

|A-212-012 |chrome 14ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |94579

|A-212-001 |chrome 11ga top serrated |3.250" |2.062" |1" |7/32 x 5/8 |700705300

|A-232-001 |chrome 11ga big tooth |3.250" |2.062" |1" |7/32 x 5/8 |700705300BT

SICKLE PARTS - VERSATILE

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-020 |Sickle Head |SWA28253 |(WINDROWER: 10, 103, 400)

|A-901-054 |Sickle Bushing |SW1740 |(WINDROWER: 10, 103, 400, 4400)

|A-901-078 |Sickle Head |SWA28509 |(WINDROWER: 4400)

|A-515-076 |Low Knife Clip |SW202 |

|A-904-529 |(50) 7/32 x 9/16" 60° CTSK Bolt & Nut||

|A-904-528 |(25) 7/32 x 1" 60° CTSK Bolt & Nut ||

|A-904-002 |7/32 x 5/8 CTSK rivet ||

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - VERSATILE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-186 |A-800-186 |R TS PL |12 ft. |SWA28253 |SWA1783PL, 74339 |SW1776PL

|A-801-189 |A-800-189 |R TS PL |15 ft. |SWA28253 |SWA25571PL |SW1616PL

|A-801-190 |A-800-190 |R TS BL |15 ft-. |SWA28253 |SWA1786, 74344 |SW1776

|A-831-552 |A-830-552 |R BT BL |15 ft. |SWA28253 |SWA1786BT, 74344 |SW1776BT

|A-801-191 |A-800-191 |R TS PL |15 ft. |SWA28253 |SWA1786PL, 74345 |SW1776PL

|A-801-193 |A-800-193 |R TS PL |18 ft. |SWA28253 |SWA25572PL |SW1616PL

|A-801-194 |A-800-194 |R TS BL |18 ft. |SWA28253 |SWA1789, 74350 |SW1776

|A-831-553 |A-830-553 |R BT BL |18 ft. |SWA28253 |SWA1789BT, 74350 |SW1776BT

|A-801-195 |A-800-195 |R TS PL |18 ft. |SWA28253 |SWA1789PL, 74351 |SW1776PL

|A-801-197 |A-800-197 |R TS PL |20 ft. |SWA28253 |SWA25573PL |SW1616PL

|A-801-198 |A-800-198 |R TS BL |20 ft. |SWA28253 |SWA3311, 74455 |SW1776

|A-831-554 |A-830-554 |R BT 1BL |20 ft. |SWA28253 |SWA3311BT, 74455 |SW1776BT

|A-801-199 |A-800-199 |R TS PL |20 ft. |SWA28253 |SWA3311PL, 74456 |SW1776PL

|A-801-521 |A-800-521 |R TS BL |24 ft. |SWA28253 |SWA35743 |SW1776

|A-831-555 |A-830-555 |R BT BL |24 ft. |SWA28253 |SWA35743BT |SW1776BT

|A-801-683 |A-800-683 |R TS PL |24 ft. |SWA28253 |SWA48346 |SW1776PL

For Models:

(WINDROWER: 10, 103, 400)

SICKLE ASSEMBLIES - VERSATILE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-522 |A-800-522 |R TS PL |15 ft. |SWA28509 |SWA54834 |SW1616PL

|A-831-556 |A-830-556 |R BT BL |15 ft. |SWA28509 |SWA54834BT |SW1616BT

|A-801-523 |A-800-523 |R TS PL |18 ft |SWA28509 |SWA54840 |SW1616PL

|A-831-557 |A-830-557 |R BT BL |18 ft. |SWA28509 |SWA54840BT |SW1616BT

|A-801-524 |A-800-524 |R TS PL |20 ft. |SWA28509 |SWA54846 |SW1616PL

|A-831-558 |A-830-558 |R BT BL |20 ft. |SWA28509 |SWA54846BT |SW1616BT

|A-801-525 |A-800-525 |R TS PL |22 ft. |SWA28509 |SWA54850 |SW1616PL

|A-831-559 |A-830-559 |R BT BL |22 ft. |SWA28509 |SWA54850BT |SW1616BT

For Models:

(WINDROWER: 4400)

SICKLE ASSEMBLIES - VERSATILE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-177 |A-800-177 |XH TS PL |6 ft. LH |6821078 |6823272 |700705300

|A-801-183 |A-800-183 |XH TS PL |6 ft. RH |6821136 |6823280 |700705300

|A-801-175 |A-800-175 |XH TS PL |7 ft. LH |6821078 |6832174 |700705300

|A-801-181 |A-800-181 |XH TS PL |7 ft. RH |6821136 |6832224 |700705300

|A-831-510 |A-830-510 |XH BT PL |7 ft. LH |6821078 |6832174BT |700705300BT

|A-831-511 |A-830-511 |XH BT PL |7 ft. RH |6821136 |6832224BT |700705300BT

For Models:

(WINDROWER: 4812 (12'), 4814 (14'))

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - VERSATILE

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|N/A |A-860-776 |R TS BL |9 ft. LH |Headless |103830 |93545

For Models:

(SWATHER: 4700 double drive, 4750)

|N/A |A-860-777 |R TS BL |9 ft. RH |Headless |103784 |93545

|N/A |A-860-778 |R TS BL |11 ft. LH |Headless |103832 |93545

|N/A |A-860-779 |R TS BL |11 ft. RH |Headless |103786 |93545

|N/A |A-860-108 |R TS BL |12 ft. LH |Headless |103833 |93545

|N/A |A-860-107 |R TS BL |13 ft. RH |Headless |103787 |93545

|N/A |A-860-523 |R TS BL |15 ft. LH |Headless |103834 |93545

|N/A |A-860-524 |R TS BL |15 ft. RH |Headless |103788 |93545

For Models:

(SWATHER: 4700 double drive, 4750)

SICKLE SECTIONS - WHITE/OLIVER

PART NO. DESCRIPTION DIM A (1) DIM B (2) DIM C (3) FASTENER REPL. NO.

|A-211-223 |black 14ga under serrated |3.250" |2.125" |1" |7/32 x 5/8 |875785L

|A-212-412 |chrome 14ga top serrated |3.250" |2.125" |1" |7/32 x 5/8 |31-7970650

|A-621-022 |3point blk 12ga under ser |4.5" |3.312" |3 point |1/4 x 5/8 |31-1714750

SICKLE PARTS - WHITE/OLIVER

PART NO. DESCRIPTION REPLACES APPLICATION

|A-901-057 |Sickle Head |31-7970683 |(WINDROWER: 6200)

|A-515-126 |Knifehead clip ||

|A-515-066 |Low knifehead clip ||

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - WHITE/OLIVER

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-073 |A-800-073 |black 11ga under serrated |6 ft. |501015E |501012ESXH |501017EXH

|A-801-074 |A-800-074 |black 11ga smooth |7 ft. |501015E |501013ESXH |501016EXH

For Models:

(MOWER: 57, 82, 84, 344, 355, 356, 415)

SICKLE ASSEMBLIES - WHITE/OLIVER

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-659 |A-800-659 |black 14ga under serrated |18 ft. |Headless |899416L |875785L

|A-801-660 |A-800-660 |black 14ga under serrated |21 ft. |Headless |885194L |875785L

|A-801-661 |A-800-661 |black 14ga under serrated |25 ft. |Headless |885477 |875785L

For Models:

(WINDROWER: 601 pull type)

SICKLE ASSEMBLIES - WHITE/OLIVER

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-409 |A-800-409 |chrome 12ga top serrated |12 ft. |31-7970683 |1046768M1 |31-7970650

|A-801-411 |A-800-411 |chrome 12ga top serrated |15 ft. |31-7970683 |31-7970623 |31-7970650

|A-801-413 |A-800-413 |chrome 12ga top serrated |18 ft. |31-7970683 |31-7970633 |31-7970650

|A-801-415 |A-800-415 |chrome 12ga top serrated |21 ft. |31-7970683 |31-7970643 |31-7970650

For Models:

(WINDROWER: SP6200 w/ draper header)

SICKLE ASSEMBLIES - WHITE/OLIVER

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-644 |A-800-644 |black 11ga top serrated |12 ft. |Headless |1057934M91 |1071707M1

|A-801-645 |A-800-645 |black 11ga top serrated |14 ft. |1056738M91 |1056865M91 |1071707M1

|A-801-646 |N/A |black 11ga top serrated |14 ft. |Headless |1056866M91 |1071707M1

|A-801-647 |N/A |black 11ga top serrated |14 ft. |Headless |1057538M91 |1071707M1

|N/A |A-800-647 |black 11ga top serrated |14 ft. |Headless |1057538M91 |1071707M1

For Models:

(WINDROWER: 6400 w/ auger header)

SICKLE ASSEMBLIES - WHITE/OLIVER

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-648 |N/A |chrome 12ga top serrated |15 ft. |Headless |1057966M91, 1057964M91 |31-7970650

SICKLE ASSEMBLIES & PARTS

SICKLE ASSEMBLIES - WHITE/OLIVER

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|N/A |A-800-648 |black 11ga top serrated |15 ft. |Headless |1057966M91, 1057964M91 |31-7970650

SICKLE ASSEMBLIES - WHITE/OLIVER

BOLT ON RIVETED DESCRIPTION LENGTH HEAD NO. OEM SICKLE NO. SECT. PART NO.

|A-801-649 |A-800-649 |chrome 12ga top serrated |18 ft. |Headless |1057967M91, 1057965M91 |31-7970650

|A-801-650 |A-800-650 |chrome 12ga top serrated |21 ft. |Headless |1057508M91 |31-7970650

|A-801-651 |A-800-651 |chrome 12ga top serrated |25 ft 1 pc. |Headless |1056739M91, 1056738M91 |31-7970650

|A-801-652 |A-800-652 |chrome 12ga top serrated |30 ft 1 pc. |Headless |1057912M91 |31-7970650

For Models:

(WINDROWER: 6400 w/ draper header)

OVERLAP SICKLE SECTION KITS

A-OSK615 Overlap Sickle Section Kit

2 LH, 3 RH, 10 Rivets

One Complete Set: For Left & Right Hand Sickles

CASE-IH SEVERAL Twin Sickle Hay Equipment

A-OSK616 Overlap Sickle Section Kit

3 LH, 2 RH, 10 Rivets

One Complete Set: For Left & Right Hand Sickles

NEW HOLLAND SEVERAL Twin Sickle Hay Equipment

OVAL HEAD RIVETS

A-OHR761 Oval Head Rivets, 9/16” (150 pcs.)

9/16” Oval Head, Packages of 150 pcs.

MISC. SEVERAL

A-OHR765 Oval Head Rivets, 5/8” (125 pcs.)

5/8” Oval Head, Packages of 125 pcs.

MISC. SEVERAL

A-OHR763 Oval Head Rivets, 7/8” (100 pcs.)

7/8” Oval Head, Packages of 100 pcs.

MISC. SEVERAL

A-CR762 Countersunk Rivets, 5/8” (175 pcs.)

5/8” Countersunk, Packages of 175 pcs.

MISC. SEVERAL

A-OHRA764 Oval Head Rivet Asst.

Kit Contains 70 (5/8”), 7 (5/16”), 5 (1-1/4”)

MISC. Designed for most 9’ Sickle Assemblies

SECTION BOLTS/LOCKNUTS

A-SBL757 Section Bolts/Locknuts, 5/8” (50 pcs.)

5/8” Grade 8, Rib Neck Bolt, Packages of 50 pcs. each

MISC. SEVERAL

A-SBL757 Section Bolts/Locknuts, 5/8” (50 pcs. each)

5/8” Grade 8, Rib Neck Bolt, Packages of 50 pcs. each

MISC. SEVERAL

A-KBL758 Knifehead Bolts/Locknuts, 1” (25 pcs. each)

1” Grade 8, Rib Neck Bolt, Packages of 25 pcs. each

MISC. SEVERAL

A-LN759 Locknuts, Section/Knifehead (100 pcs.)

Package of 100 pcs.

MISC. SEVERAL/Knifeheads Requiring 12-24 Locknut

UNIVERSAL KNIFE CLIP SET (2)

A-UCS750 Universal Knife Clip Set (2)

Low Clip, For Bolted or Riveted Sections, Set of 515-116 Knife

Clips Replaces: (JD) H127081, H84412, 143241M1, 206195M1;

(IH) 176722C1; (AC) 71189684, 71346158

MISC. ALL MODELS Except w/Hart-Carter & J.E. Love Headers

SICKLE ASSEMBLIES & PARTS

Badger/Northland

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-699020M1 Forged Guard Two Prong BU250

For Models:

(MOWER: ALL MODELS)

A-683994M1 FORGED GUARD Two Prong 683181M1, 683476M1 & BU215A

For Models:

ALL MODELS

A-683994M1H FORGED GUARD Two Prong Double Heat Treated 683181M1H, 683476M1 & BU215H

For Models:

ALL MODELS

CASE-IH

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-483500R3 Forged Guard Two Prong H483500R3 & BU210

For Models:

1000, 1100, 1110, 115, 1190, 1200, 1290, 1300, 1490, 1590, 200, 230, 230, 275, 3110, 375, 4000, 5000, 5500, 650, 655, 75, 816, 990, (100, 110, 120 ALL 1966>), 210

W/ Platform SN 3700>

A-633098R1 FORGED GUARD Two Prong BU265

For Models:

810 Header, 815, 915

A-613838R3 Forged Guard Two Prong 613838R1 & BU270

For Models:

100 1958-1965, 110 1960-1965, 115 <1965, 120 1961-1965, 1290, 175, 201, 210, 225, 230, 275, 375, 4000, 5000, 5500, 75, 820 Header, 1190, 1490, 1590

A-049239 Forged Guard Two Prong Plateless 748178 & BU245

For Models:

1050, 1055, 1150, 1155, 1275, 950, 955

A-823025C1 FORGED GUARD Two Prong 2 Pc. Tie Knife Guard FH049270 & BU260

For Models:

1050, 1055, 1085, 1150, 1155, 1275, 1290, 210, 225, 230, 275, 375, 820, 950, 955

CLAAS

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-6762352 Forged Guard Two Prong BU215A

For Models:

(MOWER: ALL MODELS)

A-6762352H Forged Guard Two Prong Double Heat Treated BU215H

For Models:

(MOWER: ALL MODELS)

FORD

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-483500R3 Forged Guard Two Prong H483500R3 & BU210

For Models:

538

A-290385 Forged Guard Two Prong BU280

For Models:

535

A-11032327 Forged Guard Two Prong MC11032327, 11032342 & BU206

For Models:

536, 537

Field Queen

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-049270 Forged Guard Two Prong Forged Plateless BU260

For Models:

420, 620

A-049239 Forged Guard Two Prong Plateless 748178 & BU245

For Models:

420, 620

GEHL

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-044779 Forged Guard Two Prong BU270

For Models:

HK108, KH440, MA206A

A-059827 Forged Guard Two Prong 072057 & BU220

For Models:

1070, 1090, 770, 880

HART CARTER

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-232155 Forged Guard Two Prong 234006 & BU231

For Models:

(COMBINE: ALL COMBINES W/ Floating Cutter Bar)

FORGED GUARDS

HESSTON

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-049270 Forged Guard Two Prong Forged Plateless BU260

For Models:

1010, 1014, 1070, 1085, 1090, 1095, 300, 420, 500, 520, 620, 6200, 6400, 6450, 6465, 6600, 6610, PT10, PT12, PT7

A-049239 Forged Guard Two Prong Plateless 748178 & BU245

For Models:

ALL MODELS Windrowers & Mower Conditioners

JOHN DEERE

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-H145791 Forged Guard Two Prong One Piece Construction H61954, H75386 & BU240A

For Models:

213, 215, 216, 218, 220, 222, 224, 230, 913, 915, 918, 920, 922, 924, 925, 930

A-W30341 Forged Guard Two Prong BU235

For Models:

580 Pull Type

A-E82559 Forged Guard Two Prong One Piece Construction E48093, E52667 & BU220

For Models:

120, 1214, 130, 135, 183, 250, 350, 37, 38, 39, 450, 480, 483, 485, 78

Killberry

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-K8420S Forged Guard Two Prong BU235

For Models:

(WINDROWER: ALL MODELS)

Kosch

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-K101 Forged Guard Two Prong BU270

For Models:

(MOWER: ALL MODELS)

LOVE

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-LB208 Forged Guard Two Prong LB214 & BU275

For Models:

ALL MODELS Grain Heads

LOWE

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-044779 Forged Guard Two Prong BU270

For Models:

(MOWER: ALL MODELS)

MAC DON

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-K8420S Forged Guard Two Prong BU235

For Models:

1000, 2000, 3000, 7000

MASSEY FERGUSON

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-1036339M1 Forged Guard Two Prong BU280

For Models:

MF81

A-228392M2 Forged Guard Two Prong 228392M1 & BU240A

For Models:

205, 300, 35, 405, 410, 510, 540, 550, 60, 70, 72, 750, 760, 80, 82, 850, 860, 92

A-1041468M1 Forged Guard Two Prong BU235

For Models:

35, 655, 775, 785

A-699020M1 Forged Guard Two Prong BU250

For Models:

725, 885, 925

A-683994M1 FORGED GUARD Two Prong 683181M1, 683476M1 & BU215A

For Models:

613, 625, 725, 775, 785, 885, 925

A-683994M1H FORGED GUARD Two Prong Double Heat Treated 683181M1H, 683476M1 & BU215H

For Models:

613, 625, 725, 925, 775, 785, 885

A-1053174M1 FORGED GUARD Two Prong BU231

For Models:

(540, 550, 750, 760, 850, 860 ALL W/ Floating Cutter Bar)

FORGED GUARDS

NEW HOLLAND

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-134024 FORGED GUARD Two Prong BU240A

For Models:

960, 975, 985, 995

A-273846 FORGED GUARD Two Prong 271971 & BU275

For Models:

960 W/ Love Floating Cutterbar

A-219190 FORGED GUARD Two Prong 144176 & BU218

For Models:

451, 456, 505, 507

A-65327 FORGED GUARD Two Prong BU245

For Models:

1469, 460, 461, 467, 469, 490, 827, 830, 880, 900, 903, 905, 907, 909, 910, 912

A-86617061 Forged Guard Two Prong Stub Guard 257634, 132146, 86553348, 86521592, 858764 & BU250

For Models:

1100, 1112, 1114, 1116, 114, 1465, 1469, 1495, 1496, 1499, 460, 461, 467, 469, 472, 474, 477, 478, 479, 488, 489, 490, 492, 495, 499, 536, 537, 903, 905, 907, 909,

910, 912

A-86615982 Forged Guard Two Prong 219191, 695501, 858778, 86521587, 86553340 & BU215A

For Models:

1090, 1100, 1112, 1114, 1116, 1118, 114, 116, 1465, 1469, 1475, 1495, 1496, 1499, 2450, 2550, 472, 474, 477, 478, 479, 488, 489, 490, 492, 495, 499, 903, 910, 912

A-86615982H Forged Guard Two Prong Double Heat Treated 219191, 695501, 858778, 86521587, 86553340 & BU215H

For Models:

1090, 1100, 1112, 1114, 1116, 1118, 114, 116, 1465, 1469, 1475, 1495, 1496, 1499, 2450, 2550, 472, 474, 477, 478, 479, 488, 489, 490, 492, 495, 499, 903, 910, 912

A-11010657 Forged Guard Two Prong MC11010657 & BU205

For Models:

536

NEW IDEA

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-290385 Forged Guard Two Prong BU280

For Models:

290, 7135, 7165

A-65327 FORGED GUARD Two Prong BU245

For Models:

815, 816, 817, 818, 819, 820

OWATTONA

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-11032327 Forged Guard Two Prong MC11032327, 11032342 & BU206

For Models:

ALL MODELS Windrowers & Mower Conditioners 1979>

A-11010657 Forged Guard Two Prong MC11010657 & BU205

For Models:

ALL MODELS Windrowers

VERSATILE

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-86544410 Forged Guard Two Prong V1605, SW1605, 9705050 & BU290

For Models:

103, 10V, 1400V, 1950V, 2400V, 2800V, 400V, 420V, 42V, 4400V, 440V, 5000V

WHITE/OLIVER

PA R T DESCRIPTION DIM A (1) DIM B (2) REPLACES

A-895744L Forged Guard Two Prong BU235

For Models:

100, 101, 501, 502, 503

FORGED GUARDS

DRIVELINES

Please refer to A&I’s Driveline Catalog,

Ag Supply Catalog (CT224) or A&I’s Driveline

Flyer (CT243) for more information and for an

extensive list of drivelines and driveline parts.

Friction Clutch Adjustable Friction Clutch Radial Pin Clutch Key-Type Overrunning Clutch

PTO CLUTCHES

FOR A FULL LISTING OF PTO CLUTCHES, PLEASE LOOK IN A&I’SDRIVELINE CATALOG OR AG SUPPLY CATALOG

NEAPCO

Binnacchi

METRIC REPLACEMENT DRIVELINES

FFiinniisshhiinngg MMoowweerr

Stock Overall Compressed

Number *Series Length - Dim. “A” Tractor Yoke Implement Yoke

A-14006446 BYPY 4 46” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL QD

A-14006637 BYPY 6 37” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL QD

A-14006340 BYPY 3 40" 1 3/8" x 6 Spl. QD 1 3/8" x 6 Spl. QD

RRoottaarryy CCuutttteerr

Stock Overall Compressed

Number *Series Type Length - Dim. “A” Tractor Yoke Implement Yoke

A-14006251 BYPY 2 Pull (Towed) 51” 1-3/8” x 6 SPL QD 1-3/8” RD with Pinhole

A-14006451 BYPY 4 Pull (Towed) 51” 1-3/8” x 6 SPL QD 1-3/8” RD with Pinhole

A-14006432 BYPY 4 4 ft. Lift (3-pt. Hitch) 32” 1-3/8” x 6 SPL QD 1-3/8” RD with Pinhole

A-14006436 BYPY 4 5 ft. Lift (3-pt. Hitch) 36” 1-3/8” x 6 SPL QD 1-3/8” RD with Pinhole

A-14006442 BYPY 4 6 ft. Lift / 3-pt. Hitch 42" 1 3/8" x 6 Spl. QD 1 3/8" Rd w/ Pinhole

A-14006542 BYPY 5 6 ft. Lift (3-pt. Hitch) 42” 1-3/8” x 6 SPL QD 1-3/8” RD with Pinhole

A-14006652 BYPY 6 7 ft. Lift (3-pt. Hitch) 52” 1-3/8” x 6 SPL QD 1-3/8” RD with Pinhole

Stock Overall Compressed

Number *Series Type Length - Dim. “A” Tractor Yoke Implement Yoke

A-14106438 BYPY 4 Pull (Towed) 38” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL Friction Clutch

A-14106546 BYPY 5 Pull (Towed) 46” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL Friction Clutch

A-14106654 BYPY 6 7 Ft. Lift (3-pt. Hitch) 54” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL Friction Clutch

METRIC REPLACEMENT DRIVELINES

AAllll PPuurrppoossee DDrriivveelliinnee

Stock Overall Compressed

Number *Series Length - Dim. “A” Tractor Yoke Implement Yoke

A-14006247 BYPY 2 47” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL QD

A-14006448 BYPY 4 48” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL QD

A-14006424 BYPY 4 (CATFISH POND DRIVELINE) 48” 1-3/8” x 6 SPL QD 1-1/2” RD. with 3/8” Keyway

A-14006657 BYPY 6 57” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL QD

A-14006857 BYPY 8 57” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL QD

PPoosstt HHoollee DDiiggggeerr

Stock Overall Compressed

Number *Series Type Length - Dim. “A” Tractor Yoke Implement Yoke

A-14006252 BYPY 2 Light Duty 52” 1-3/8” x 6 SPL QD 1-1/4” RD with Pinhole

A-14006453 BYPY 4 Heavy Duty 53” 1-3/8” x 6 SPL QD 1-1/4” RD with Pinhole

HHaayy TTeeddddeerr

Stock Overall Compressed

Number *Series Type Length - Dim. “A” Tractor Yoke Implement Yoke

A-14206252 BYPY 2 2 Rotor 52” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL Radial Pin Clutch

A-14206454 BYPY 4 4 Rotor 54” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL Radial Pin Clutch

FFeerrttiilliizzeerr SSpprreeaaddeerr

Stock Overall Compressed

Number *Series Length - Dim. “A” Tractor Yoke Implement Yoke

A-14006127 BYPY 1 27” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL QD

A-14006135 BYPY 1 35” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL QD

SIMPLE TO MODIFY CUT-TO-LENGTH

DDiisscc MMoowweerr

Stock Overall Compressed

Number *Series Length - Dim. “A” Tractor Yoke Implement Yoke

A-14306639 BYPY 6 39” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL w/Overrunning Clutch

A-14307645 W/S 2400 45” 1-3/8” x 6 SPL QD 1-3/8” x 6 SPL w/Overrunning Clutch

*INTERCHANGES WITH BONDIOLI &PAVESI AND WALTERSCHEID DRIVELINES

80° CV’S FOR FLEX WING CUTTERS - DOMESTIC & METRIC

Interchange with DEERE®

Model #:1517, 1518, 2018

Also fits other competitive models

Interchange with BUSH HOG®

Model #:2615, 3615

Also fits other competitive models

OOvveerraallllIImmpplleemmeenntt

CCVVPPaarrtt ##TTrraaccttoorr YYookkeeCCoommpprreesssseedd LLeennggtthhCCllaammpp YYookkeeSSeerriieess

Domestic A-14505555 1-3/8” x 6 Spline 55” 1-3/8” x 6 Spline 55

Domestic A-14605555 1-3/8” x 21 Spline 55” 1-3/8” x 6 Spline 55

Domestic A-14705555 1-3/4” x 20 Spline 55” 1-3/8” x 6 Spline 55

Metric A-14507955 1-3/8” x 6 Spline 55” 1-3/8” x 6 Spline BP 8/WS 2580*

Metric A-14607955 1-3/8” x 21 Spline 55” 1-3/8” x 6 Spline BP 8/WS 2580*

Metric A-14707955 1-3/4” x 20 Spline 55” 1-3/8” x 6 Spline BP 8/WS 2580*

OOvveerraallllIImmpplleemmeenntt

CCVVPPaarrtt ##TTrraaccttoorr YYookkeeCCoommpprreesssseedd LLeennggtthhCCllaammpp YYookkeeSSeerriieess

Domestic A-14515555 1-3/8” x 6 Spline 55” 1-3/4” x 20 Spline 55

Domestic A-14615555 1-3/8” x 21 Spline 55” 1-3/4” x 20 Spline 55

Domestic A-14715555 1-3/4” x 20 Spline 55” 1-3/4” x 20 Spline 55

Metric A-14517955 1-3/8” x 6 Spline 55” 1-3/4” x 20 Spline BP 8/WS 2580*

Metric A-14617955 1-3/8” x 21 Spline 55” 1-3/4” x 20 Spline BP 8/WS 2580*

Metric A-14717955 1-3/4” x 20 Spline 55” 1-3/4” x 20 Spline BP 8/WS 2580*

*Interchanges with either Bondioli & Pavesi or Walterscheid

METRIC

• Star profile telescoping members to better

handle thrust.

• Produced at Weasler’s European facility...

WeaslerAgdrive

• Patented Easy Lock Guard System!

• Competitively priced

DOMESTIC

• Highest capacity CV - 55 series/Cat.6...

compared to competition’s Cat.5.

• Patented features include greasing system

and guarding.

• Competitively priced - check it out through

the OEM.

METRIC / DOMESTIC

• Direct replacement with standard lengths

and series. Select tractor yoke and domestic

or metric style driveline.

• Fully assembled...

ready-to-go

• HUGE field population of

flex-wings = HUGE opportunity

• Remember - DO NOT EXCEED 80° in both

operating and non-operating modes.

OOvveerraallllIImmpplleemmeenntt

CCVVPPaarrtt ##TTrraaccttoorr YYookkeeCCoommpprreesssseedd LLeennggtthhCCllaammpp YYookkeeSSeerriieess

Domestic A-14505551 1-3/8” x 6 Spline 51” 1-3/4” x 20 Spline 55

Domestic A-14605551 1-3/8” x 21 Spline 51” 1-3/4” x 20 Spline 55

Domestic A-14705551 1-3/4” x 20 Spline 51” 1-3/4” x 20 Spline 55

Metric A-14507951 1-3/8” x 6 Spline 51” 1-3/4” x 20 Spline BP 8/WS 2580*

Metric A-14607951 1-3/8” x 21 Spline 51” 1-3/4” x 20 Spline BP 8/WS 2580*

Metric A-14707951 1-3/4” x 20 Spline 51” 1-3/4” x 20 Spline BP 8/WS 2580*

Interchange with RHINO®

Model #:SR-15, SE-15

BUSH HOG®RHINO®DEERE®

80° CV ROUND BALER DRIVELINES

DEERE - MODEL #467 AND #466

540 RPM

*A-14503558 .................................................................................Driveline

A-59018000 ...............................................................................Clutch Pak

A-817-3506...............................................................................Clutch Yoke

A-200-3500........................................................................Cross Repair Kit

1000 RPM

*A-14603558 ................................................................................Driveline

A-59018000 ...............................................................................Clutch Pak

A-817-3506...............................................................................Clutch Yoke

A-200-3500........................................................................Cross Repair Kit

DEERE - MODEL #567 AND #566

540 RPM

*A-14503558 .................................................................................Driveline

A-59010000 ...............................................................................Clutch Pak

A-817-3506...............................................................................Clutch Yoke

A-200-3500........................................................................Cross Repair Kit

1000 RPM

*A-14603558 .................................................................................Driveline

A-59010000 ...............................................................................Clutch Pak

A-817-3506...............................................................................Clutch Yoke

A-200-3500........................................................................Cross Repair Kit

GEHL DELUXE - MODEL #2880

540 RPM

*A-14503567 .................................................................................Driveline

A-57015000 ...............................................................................Clutch Pak

A-817-3521...............................................................................Clutch Yoke

A-200-3500.............................................................................Cross Repair

1000 RPM

*A-14603567 .................................................................................Driveline

A-57015000 ...............................................................................Clutch Pak

A-817-3521...............................................................................Clutch Yoke

A-200-3500.............................................................................Cross Repair

CASE - MODEL #8455S AND 8455T

540 RPM

*A-14503558 .................................................................................Driveline

A-57015000 ...............................................................................Clutch Pak

A-817-3506...............................................................................Clutch Yoke

A-200-3500........................................................................Cross Repair Kit

1000 RPM

*A-14603558 .................................................................................Driveline

A-57015000 ...............................................................................Clutch Pak

A-817-3506...............................................................................Clutch Yoke

A-200-3500........................................................................Cross Repair Kit

VERMEER - MODEL #604K

540 RPM

*A-14503558 .................................................................................Driveline

A-57015000 ...............................................................................Clutch Pak

A-817-3506...............................................................................Clutch Yoke

A-200-3500........................................................................Cross Repair Kit

1000 RPM

*A-14603558 .................................................................................Driveline

A-57015000 ...............................................................................Clutch Pak

A-817-3506...............................................................................Clutch Yoke

A-200-3500........................................................................Cross Repair Kit

HESSTON - MODEL #555S AND 555T

540 RPM

*A-14503558 .................................................................................Driveline

A-57015000 ...............................................................................Clutch Pak

A-817-3506...............................................................................Clutch Yoke

A-200-3500........................................................................Cross Repair Kit

1000 RPM

*A-14603558 .................................................................................Driveline

A-57015000 ...............................................................................Clutch Pak

A-817-3506...............................................................................Clutch Yoke

A-200-3500........................................................................Cross Repair Kit

*Implement yoke and cross must be purchased separately

PARTS FOR TORQMASTER CLUTCH

7” Clutch

A-987-9000.......................................................................Disc Spring

A-98712000 ......................................................................Disc Spring

A-98715000 ......................................................................Disc Spring

A-98718000 ......................................................................Disc Spring

Separator Plate 7” Clutch

A-990-7000 ................................................................Separator Plate

Disc 7” Clutch

A-970-7000 .....................................................................Friction Disc

9” Clutch

A-98910000 ......................................................................Disc Spring

A-98915000 ......................................................................Disc Spring

A-98918000 ......................................................................Disc Spring

Separator Plate 9” Clutch

A-990-9000 ................................................................Separator Plate

Disc 9” Clutch

A-970-9000 .....................................................................Friction Disc

Part # Description Part # Description
