Friginox RC50 26 2009 SPL

User Manual: Friginox RC50-26

Open the PDF directly: View PDF PDF.
Page Count: 2

Warranty: 1 yEar parts and labor – sErvicE on sitE
Accommodates trollies 30” x 37” x 73” (WxDxH); Blast chilling capacity RR2FS160:
353 lbs. from 145°F to 40°F “to core” within 1 hr. 50 mins. Blast chilling capacity
SR2FS160: 485 lbs. 145°F to 40°F “to core” within 1 hr. 50 mins. Blast freezing
capacity RRSR2FS 353lbs. from 145°F to 0°F “to core” within 4 hrs. 30 mins.
Roll-in Model RR2FS160 Blast Chiller, no compressor/condensor .....................
$ 53,710
Roll-in Model SR2FS160 Blast Chiller/Blast Freezer, no compressor/condensor ...........
$ 54,250
Roll-in Model RRSR2FS Blast Chiller/Blast Freezer, pass through option ...................
$ 2,715
Printer Option ..............................................................
$ 2,630
10 levels to accommodate 12” x 20” hotel pans or a maximum of 26 levels (levels at
1-1/2” increments); Blast chilling capacity: 110 lbs. from 145°F, to 40°F, “to core”
within 1 hr. 50 mins. Blast freezing capacity: 55 lbs. from 145°F, to 0°F, “to core”
within 4 hrs. 30 mins.
Reach-in Model RC50-26A ...................................................
$ 23,445
To Order Call 336 / 661-0257 • Fax 336 / 661-9546 • www.friginoxusa.com
Accommodates trollies 30” x 24” x 73” (WxDxH); Blast chilling capacity
RR1, RR1S & SR1S: 176 lbs. from 145°F to 40°F “to core” within 1 hr. 50 mins.
Blast freezing capacity SR1S: 242 lbs. from 145°F to 0°F “to core” within 4 hrs. 30 mins.
Roll-in Model RR1 Blast Chiller ................................................
$ 45,095
Roll-in Model RR1S Blast Chiller, no compressor ..................................
$ 36,835
Roll-in Model SR1S Blast Chiller/Blast Freezer, no compressor ........................
$ 40,255
Chillers for Cooked Dishes and Pastries / Combined Blast Freezers
Reach-in
Model
RC50-26A
Roll-in
Models
RR1, RR1S,
SR1S
Friginox Blast Chillers/
Blast Freezers Price List
Effective April 1, 2009
FOB Winston-Salem, NC
External Dimensions (inches) Packed Wt. Volume
Wide High Deep (Lbs) (Ft.3)
303/8 75 311/8 367 41.0
External Dimensions (inches) Packed Wt. Volume
Wide High Deep (Lbs) (Ft.3)
313/8 591/2 235/8 541 25.5
Reach-in
Model
RC30-15A
External Dimensions (inches) Packed Wt. Volume
Wide High Deep (Lbs) (Ft.3)
303/8 607/8 317/8 340 34.1
6 levels accommodates 12” x 20” hotel pans or a maximum of 15 levels (levels at 1-1/2” increments);
Blast chilling capacity: 66 lbs. from 145°F, to 40°F, “to core” within 1 hr. 50 mins.;
Blast freezing capacity: 33 lbs. from 145°F, to 0°F, “to core” within 4 hrs. 30 mins.
Reach-in Model RC30-15A ...................................................
$ 22,815
Roll-in
Models
RR-SR
2FS-160
External Dimensions (inches) Packed Wt. Volume
Wide High Deep (Lbs) (Ft.3)
313/8 591/2 235/8 541 25.5
3 levels accommodates 12” x 20” hotel pans or a maximum of 7 levels. Blast chilling
capacity: 33 lbs. from 145°F to 40°F, “to core”, within 1 hr. 50 mins. Blast freezing
capacity: 16 lbs. from 145°F to 0°F, “to core”, within 4 hrs. 30 mins.
Reach-in Model RC15-7A ....................................................
$ 14,900
Reach-in
Model
RC15-7A
External Dimensions (inches) Packed Wt. Volume
Wide High Deep (Lbs) (Ft.3)
303/8 375/8 311/8 254 20.6
(3M) 3/09
To Order Call 336 / 661-0257 • Fax 336 / 661-9546 • www.friginoxusa.com
Chillers and Combined Blast Freezers Options
Friginox Blast Chillers/
Blast Freezers Price List
Effective April 1, 2009
FOB Winston-Salem, NC
Options With Order Part # Price
Rolls of thermal paper for printer (6 rolls) FX39269394 $45.00
SST wall mount support for core temperature printer FX39269386 $42.00
Sound alarm (in case of error) FX39289681 $72.00
Double access on RR2FS-160/ SR 2FS-160 models (without unit only) FX39261516 $1,235.00
Board with HACCP output
(RS 232 C type serial output and parallel output) for connection to a PC, computer network or
to a printer. For RC-15-7A/ 30-15A/ 50-26A/ reach-in models.
FX39269147 $417.00
5” SST casters
Set of 4 (two locking) (15-7A/ 30-15A/ 50-26A models with housed unit)
FX39268206 $258.00
Trolleys: SST, 4 pivoting zinc plated wheels 5" (2 with brakes) 4 protection stops.
Hotel Pans, 20 levels
Containers (21x13) 18(L)x25(D)x71(H), 3" space between levels
FX39267042 $898.00
Hotel Pans, 22 levels
Containers (21x13) 18(L)x25(D)x71(H), 2" space between levels
FX39284237 $981.00
Hotel Pans, 20 levels
Containers (25x21) 26(L)x30(D)x71(H), 3" space between levels
FX39267059 $991.00
Hotel Pans, 22 levels
Containers (25x21) 26(L)x30’(D)x71(H), 2" space between levels
FX39284245 $1,069.00
Pans, 23/16 20 levels
for pans and pastry plates (23x16) 21(L)x27(D)x71(H), 3" space between levels
FX39267067 $962.00
Pans, 23/16, 22 levels
for pans and pastry plates (26x16) 21(L)x27(D)x71(H), 2" space between levels
FX39284260 $1,126.00
23/31, 20 levels (23x31) 29(L)x35(D)x71(H), 3" space between levels FX39267075 $1,249.00
23/31, 22 levels (23x31) 29(L)x35(D)x71(H), 2" space between levels FX39284252 $1,308.00
SST casters FX39267091 $131.00
SST Runners , Pair (length 15")
“U” type for Hotel pans and containers FX39284955 $35.00
“J” type for Hotel pans FX39285002 $32.00
USA
P.O. Box 4129,Winston-Salem, NC 27115
336/661-0257 • Fax 336/661-9546
CANADA
P.O. Box 301, Jordan Station, Ontario L0R 1S0
905/562-4195 • Fax: 905/562-4618
In line with policy to continually develop and improve its products, Friginox reserves the right to change specifications and designs wtihout notice.
