Pool Skimmers and Skim Filters / Renegade Gunite In-Ground Skimmers
Waterway’s Renegade
Gunite Skimmer
is designed for
better and easier
installations while
maximizing ow. e
large skimmer basket
locks into place. High
ow rate of 75 gallons
per minute.
FEATURES:
• NSF Approved with Flow Rate of 75 GPM
• PVC sockets for better glue joints
• 2" socket is 2 ½" spigot for more ow
• 1 ½" socket is 2" spigot for easier plumbing
• ½" socket for overow hose
• Large locking skimmer basket
• Easy access spring-loaded weir door
simplies replacement
• Optional oat valve
• Optional skimmer test kit
10.5" 10.5"
Square Lid
Two Port
Side-By-Side
Two Port Two Port
542-6200 519-6480 540-6500
Round Lid Square Lid
For replacement parts, see page 266.
118
Pool Skimmers and Skim Filters / Renegade Gunite In-Ground Skimmers
Renegade Gunite Skimmers - 2-Port - Round Lid
Renegade Gunite Skimmers - 2-Port - Square Lid
Renegade Gunite Skimmers - Single Port - Round Lid
Renegade Gunite Skimmers - Single Port - Square Lid
Accessories
Part No. Description Color Weight (lbs.) List (US $)
540-6430 1 ½" Socket (2" Spigot) White 8 115.23
540-6630 1 ½" Socket with Float Valve White 9 142.33
540-6410 2" Socket (2 ½" Spigot) White 8 115.23
540-6410-9B 2" Socket (2 ½" Spigot) White/Beige Lid 8 115.23
540-6411 2" Socket (2 ½" Spigot) Black 8 127.42
540-6411-9B 2" Socket (2 ½" Spigot) Black/Beige Lid 8 127.42
540-6417 2" Socket (2 ½" Spigot) Gray 8 127.42
540-6417-9B 2" Socket (2 ½" Spigot) Gray/Beige Lid 8 127.42
540-6419-BEI 2" Socket (2 ½" Spigot) Beige 8 127.42
540-6410G 2" Socket (2 ½" Spigot) - Side-by-Side White 8 118.69
540-6610 2" Socket (2 ½" Spigot) with Float Valve White 9 142.33
540-6610-9B 2" Socket (2 ½" Spigot) with Float Valve White/Beige Lid 9 142.33
540-6611 2" Socket (2 ½" Spigot) with Float Valve Black 9 159.98
540-6617 2" Socket (2 ½" Spigot) with Float Valve Gray 9 159.98
540-6617-9B 2" Socket (2 ½" Spigot) with Float Valve Gray/Beige Lid 9 142.33
540-6619-BEI 2" Socket (2 ½" Spigot) with Float Valve Beige 9 159.98
540-6619-DKG 2" Socket (2 ½" Spigot) with Float Valve Dark Gray 9 159.98
Part No. Description Color Weight (lbs.) List (US $)
540-6410-9SB 2" Socket (2 ½" Spigot) White/Beige Lid 8 119.85
540-6411-S 2" Socket (2 ½" Spigot) Black 8 119.85
540-6411-9SB 2" Socket (2 ½" Spigot) Black/Beige Lid 8 119.85
540-6417-S 2" Socket (2 ½" Spigot) Gray 8 119.85
540-6417-9SB 2" Socket (2 ½" Spigot) Gray/Beige Lid 8 119.85
Part No. Description Color Weight (lbs.) List (US $)
540-6510 2" Socket (2 ½" Spigot) White 9 115.23
540-6510-9B 2" Socket (2 ½" Spigot) White/Beige Lid 9 115.23
540-6511 2" Socket (2 ½" Spigot) Black 9 127.42
540-6511-9B 2" Socket (2 ½" Spigot) Black/Beige Lid 9 127.42
540-6517 2" Socket (2 ½" Spigot) Gray 9 127.42
540-6517-9B 2" Socket (2 ½" Spigot) Gray/Beige Lid 9 127.42
540-6519-BEI 2" Socket (2 ½" Spigot) Beige 9 127.42
540-6519-DKG 2" Socket (2 ½" Spigot) Dark Gray 9 127.42
Part No. Description Color Weight (lbs.) List (US $)
540-6510-S 2" Socket (2 ½" Spigot) White 9 119.85
540-6510-9SB 2" Socket (2 ½" Spigot) White/Beige Lid 9 119.85
Part No. Description Color Weight (lbs.) Case Quantity List (US $)
540-6010 Equalizer Valve White 0.13 120 15.37
542-6200 Float Valve White 0.8 25 27.11
519-6480 Vacuum Plate White 0.6 25 17.17
519-6560 Mounting Extension Ring White 0.4 14 11.12
519-6561 Mounting Extension Ring Black 0.4 14 11.12
519-6567 Mounting Extension Ring Gray 0.4 14 11.12
519-6569-BEI Mounting Extension Ring Beige 0.4 14 11.12
519-6569-DKG Mounting Extension Ring Dark Gray 0.4 14 11.12
540-6500 Skimmer Test Loop Kit -- 0.4 30 13.29
119
Renegade Vinyl Liner Skimmers - 2-Port - Square Lid
Renegade Vinyl Liner Skimmers - 2-Port - Round Lid
Part No. Description Throat Color List (US $)
540-8400 Standard Vinyl Liner In-Ground Skimmer - 2" Socket -- White 186.17
540-8407 Standard Vinyl Liner In-Ground Skimmer - 2" Socket -- Gray 199.27
540-8430 Standard Vinyl Liner In-Ground Skimmer - 1 ½" Socket -- White 186.71
540-8437 Standard Vinyl Liner In-Ground Skimmer - 1 ½" Socket -- Gray 199.27
540-8500 Wide-Mouth Vinyl Liner In-Ground Skimmer - 2" Socket 9" White 232.71
540-8507 Wide-Mouth Vinyl Liner In-Ground Skimmer - 2" Socket 9" Gray 240.15
540-8530 Wide-Mouth Vinyl Liner In-Ground Skimmer - 1 ½" Socket 9" White 232.71
540-8537 Wide-Mouth Vinyl Liner In-Ground Skimmer - 1 ½" Socket 9" Gray 240.15
540-8550 Wide-Mouth Vinyl Liner In-Ground Skimmer - 2" Socket 13" White 241.31
540-8557 Wide-Mouth Vinyl Liner In-Ground Skimmer - 2" Socket 13" Gray 248.93
540-8580 Wide-Mouth Vinyl Liner In-Ground Skimmer - 1 ½" Socket 13" White 241.31
540-8587 Wide-Mouth Vinyl Liner In-Ground Skimmer - 1 ½" Socket 13" Gray 248.93
Part No. Description Color List (US $)
540-8460 Standard Vinyl Liner In-Ground Skimmer - 1 ½" Socket White 186.17
Pool Skimmers and Skim Filters / Renegade Vinyl Liner and Fiberglass In-Ground Skimmers
e Renegade
skimmer from
Waterway is the
only choice you’ll
need to make for
your vinyl liner pool
installations. e
Renegade In-Ground
Vinyl Pool Skimmer
is designed to work
with all existing vinyl
liner steel, polymer
or berglass pool
walls. Available
in a wide variety
of models – either
standard or wide-
mouth in your choice
of white or gray, the
Renegade includes a
lock-down vacuum
plate, extension
collar and one of
the largest skimmer
baskets available. It
twist-locks to prevent
oating and easy-
access. Renegade’s
spring-loaded
weir door makes
replacements a snap.
FEATURES:
• PVC sockets for better glue joints
• 2" socket is 2 ½" spigot for more ow
• 1 ½" socket is 2" spigot for easier plumbing
• ½" socket for overow hose
• Large locking skimmer basket
• Easy access spring-loaded weir door
simplies replacement and installation
• High ow rate of 75 GPM
• Optional oat valve
• Optional skimmer test kit
• Lock-Down vacuum plate and an extension
collar are included
STANDARD WIDE MOUTH WIDE MOUTH
9" THROAT
WIDE MOUTH
13" THROAT
11.7" 19.3"
19.25" 22.25"
10.5"
10.5"
20.3" 20.3"
10.5" 10.5"
17.3"
9.7"
7.5" 6.3" 6.3"
10" 13"
8.5" 8.5"
7.7"
For replacement parts, see page 267.
Fits all currently manufactured
steel and polymer walls!
120
Pool Skimmers and Skim Filters / Renegade Vinyl Liner and Fiberglass In-Ground Skimmers
Renegade Vinyl Liner Skimmers - Single Port - Square Lid
Accessories
Renegade Fiberglass Only Skimmers
Part No. Description Color Case Weight (lbs.) Case Quantity List (US $)
519-9520 Standard Vinyl Liner Trim Plate White 11.03 25 10.31
519-9521 Standard Vinyl Liner Trim Plate Black 11.03 25 10.71
519-9527 Standard Vinyl Liner Trim Plate Gray 11.03 25 10.71
519-9540 Wide-Mouth Vinyl Liner Trim Plate White 16.59 20 12.48
519-9547 Wide-Mouth Vinyl Liner Trim Plate Gray 16.59 20 13.02
519-6560 Mounting Extension Ring White 7.24 14 11.12
519-6567 Mounting Extension Ring Gray 7.24 14 11.12
519-6550 Mounting Extension Ring - New Style White 10.15 10 11.12
519-9510 Vinyl Liner Square Collar White 10.15 10 17.80
519-9490 Vinyl Liner Square Collar - New Style White 10.15 10 17.80
542-6200 Float Valve White 28.25 25 27.11
519-6480 Lock-Down Vacuum Plate White -- -- 17.17
540-6500 Skimmer Test Loop Kit White 24.29 70 13.29
542-3240 Basket Assembly White 9.87 25 12.11
550-0020 Additional Mounting Tabs - Composite Wall Vinyl Liner White 9.87 25 10.50
Part No. Description Color List (US $)
540-8700 Standard Vinyl Liner In-Ground Skimmer - 2" Socket White 180.75
540-8730 Standard Vinyl Liner In-Ground Skimmer - 1 ½" Socket White 180.75
540-8800 Wide-Mouth Vinyl Liner In-Ground Skimmer - 2" Socket White 225.93
540-8830 Wide-Mouth Vinyl Liner In-Ground Skimmer - 1 ½" Socket White 225.93
FEATURES:
• PVC sockets for better glue joints
• Longer screws for one-piece berglass pools
• 2" socket is 2 ½" spigot for more ow
• 1 ½" socket is 2" spigot for easier plumbing
• ½" socket for overow hose
• Large locking skimmer basket
• Easy access spring-loaded weir door
simplies replacement and installation
• High ow rate of 75 GPM
• Optional oat valve
• Optional skimmer test kit
• Lock-Down vacuum plate and 2 extension
collars are included
For replacement parts, see page 268.
Part No. Description Color List (US $)
540-8630 Standard 1-Piece Fiberglass Only In-Ground Skimmer - 1 ½" S White 142.55
540-8610 Standard 1-Piece Fiberglass Only In-Ground Skimmer - 2" S White 142.55
121
Pool Skimmers and Skim Filters / Renegade Venturi In-Ground Skimmers
e skimmer is a very
important part of
the ltration system
on a swimming
pool. e skimmer is
permanently installed
to skim the top of the
pool to collect dirt
and debris before they
have a chance to sink
to the bottom of the
pool.
e Waterway
Renegade Venturi
Skimmer has the
latest in high tech
features and “Service-
Ease” design making
this the ultimate pool
skimmer!
FEATURES:
• By using a venturi, this skimmer doubles the cleaning
power without increasing energy costs
• Massive 9" deep basket (twice the size of standard
skimmer baskets), can hold 289 cubic inches of debris
• Basket and vacuum plate lock into place instead of oating
up when the pump is o
• Weir door is spring-loaded for easy removal- no screws
• NSF approved for 75 GPM – highest in the industry
The Waterway Venturi Skimmer pulls as much water as the pump, doubling the skimming action while NOT increasing energy costs.
24.1"
15.45"
For replacement parts, see page 266.
122
Pool Skimmers and Skim Filters / Renegade Venturi In-Ground Skimmers
Renegade Gunite Venturi In-Ground Skimmer
Renegade Vinyl Liner Venturi In-Ground Skimmer
Renegade Gunite In-Ground Skimmer - Deep Basket without Venturi
Renegade Vinyl Liner In-Ground Skimmer - Deep Basket without Venturi
Part No. Description Color List (US $)
540-5300* 2" Socket White 219.72
540-5301 2" Socket Black 230.71
540-5307 2" Socket Gray 230.71
540-5309-BEI 2" Socket Beige 230.71
540-5300-9B 2" Socket White/Beige Lid 219.72
Part No. Description Color List (US $)
540-5700* 2" Socket White 255.56
540-5710* 2" Socket with Wide Mouth White 292.07
540-5717 2" Socket with Wide Mouth Gray 299.37
Part No. Description Color List (US $)
540-5310* 2" Socket White 171.21
540-5311 2" Socket Black 181.28
540-5317 2" Socket Gray 181.28
540-5319-BEI 2" Socket Beige 181.28
540-5310-9B 2" Socket White/Beige Lid 171.21
540-5320 2" Socket with Float Valve White 192.87
Part No. Description Color List (US $)
540-5720* 2" Socket White 198.26
540-5730* 2" Socket with Wide Mouth White 229.12
540-5737 2" Socket with Wide Mouth Gray 237.94
The basket for the Venturi Skimmer and the Deep
Basket Skimmer is 9” deep, making the Waterway
basket the largest in the industry for extra leaf and
debris holding capacity.
Deep Basket Standard Basket
* NSF
* NSF
* NSF
* NSF
123
Pool Skimmers and Skim Filters / Commercial Renegade Skimmers & TWM Skim Filters
FEATURES:
• 25 or 50 sq. ft. Flo-Pro Skim Filter
• Pool return
• Center discharge pool pump
• 6 ft. NEMA (3-prong - grounded) or 3 ft. twist-lock cord (NEC/UL)
• Two 6 ft. hoses with connectors
• Equipment pad
• Optional trap
TWM Skim Filter Equipment Packs
Economical ltration
system for the
above ground pool.
Waterway’s TWM
Skim Filter (Total
Water Management)
package includes the
pump, skimmer, lter,
hoses, return, and
equipment pad.
Part No. Description HP Volts Weight (lbs.) Cord List (US $)
520-2990 25 sq. ft. Skim Filter - 1-Speed Pump 1.0 115 34 6 ft. 672.85
520-2760 50 sq. ft. Skim Filter - 1-Speed Pump 1.0 115 35 6 ft. 687.56
520-2750 50 sq. ft. Skim Filter - 1-Speed Pump 1.0 115 35 3 ft. 687.56
For replacement parts, see page 271.
Commercial Renegade Gunite In-Ground Skimmers
Waterway’s
Commercial
Renegade Gunite
Skimmer is designed
for commercial
or public pool
installations. e
large skimmer basket
locks into place. High
ow rate of 75 gallons
per minute.
FEATURES:
• NSF Approved with Flow Rate of 75 GPM
• PVC sockets for better glue joints
• 2" socket is 2 ½" spigot for more ow
• ½" socket for overow line
• Large locking skimmer basket
• Easy access spring-loaded weir door
simplies replacement
• Equalizer line for NSF commercial compliance
• Optional skimmer test kit
Part No. Description Color Weight (lbs.) List (US $)
540-6200 Gunite Skimmer with Equalizer - 2 ½" Spigot x 2" S x 2" NPT White 9.78 130.62
540-6350 Gunite Skimmer with Equalizer - 2 ½" Spigot x 2" NPT x 2" NPT -- -- 138.23
124
Pool Skimmers and Skim Filters / Renegade Vinyl Liner Builder's Packs
Renegade Vinyl Liner Skimmer - Builder's Packs
Part No. Included Parts (Quantity) Color List (US $)
545-5700 Standard Vinyl Liner Venturi In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S White 360.79
545-5707 Standard Vinyl Liner Venturi In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S Gray 374.88
545-5710 Wide Mouth Vinyl Liner Venturi In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S White 393.86
545-5717 Wide Mouth Vinyl Liner Venturi In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S Gray 408.83
545-5750 Wide Mouth Long Throat Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S White 401.22
545-5757 Wide Mouth Long Throat Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S Gray 416.35
545-8400 Standard Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S White 303.28
545-8407 Standard Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S Gray 323.23
545-8410 Standard Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S White 356.28
545-8417 Standard Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S Gray 378.26
545-8430 Standard Vinyl Liner In-Ground Skimmer Builder's Pack - 1 ½" S White 309.35
545-8437 Standard Vinyl Liner In-Ground Skimmer Builder's Pack - 1 ½" S Gray 329.70
545-8500 Wide Mouth Short Throat Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S White 349.92
545-8507 Wide Mouth Short Throat Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S Gray 365.34
545-8510 Wide Mouth Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S White 397.57
545-8517 Wide Mouth Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S Gray 415.17
545-8530 Wide Mouth Short Throat Vinyl Liner In-Ground Skimmer Builder's Pack - 1 ½" S White 349.92
545-8537 Wide Mouth Short Throat Vinyl Liner In-Ground Skimmer Builder's Pack - 1 ½" S Gray 365.36
545-8550 Wide Mouth Long Throat Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S White 350.42
545-8557 Wide Mouth Long Throat Vinyl Liner In-Ground Skimmer Builder's Pack - 2 ½" Spigot / 2" S Gray 365.69
545-8580 Wide Mouth Long Throat Vinyl Liner In-Ground Skimmer Builder's Pack - 1 ½" S White 350.42
545-8587 Wide Mouth Long Throat Vinyl Liner In-Ground Skimmer Builder's Pack - 1 ½" S Gray 365.69
540-8507540-8400
ALL BUILDER'S PACKS COME WITH THE FOLLOWING:
• Skimmer (1 qty.)
• Trim Plate (1 qty.)
• 2" S Vinyl Main Drain (2 qty.)
• 1 ½" S Vinyl Liner Wall Fitting Assembly with Combo Locknut (3 or 6 qty.)
• 1" Eyeball Opening (3 or 6 qty.)
• Wall Fitting Escutcheon (3 or 6 qty.)
125
FEATURES:
• Deep body, larger locking basket
• Long or short throat
• Basket accessible from top or front
• Durable one-piece ABS (wide mouth is two piece)
• 1 ½" FPT
• 1 ½" hose adapter included
STANDARD MOUTH
WIDE MOUTH
7.47" 8.93" 11.22"
15.875"
5.62"
7.18"
7.18" 7.18"
11.5" 11.5"
11.5"
12.51"
11.5"
11.9"
7.56"
13.65"
5.25"
6.15"
SHORT
THROAT
LONG
THROAT
SHORT
THROAT
LONG
THROAT
Flo-Pro II Above-Ground Skimmers
Flo-Pro II Wide Mouth Above-Ground Skimmers
Accessories
Part No. Description Color Weight (lbs.) List (US $)
560-COA60S Short Throat White 2.5 53.52
560-COA67S Short Throat Gray 2.5 53.52
560-C0C60S Short Throat with Return White 3.5 57.04
560-C0C67S Short Throat with Return Gray 3.5 57.04
560-D0A60S Long Throat White 4.0 54.70
560-D0A61S Long Throat Black 4.0 61.30
560-D0A67S Long Throat Gray 4.0 54.70
560-D0C60S Long Throat with Return White 5.0 58.23
560-D0C67S Long Throat with Return Gray 5.0 58.23
560-D0C60SF Long Throat with Return - 90° Eye White 5.0 58.86
Part No. Description Color Weight (lbs.) List (US $)
560-C3A60L Short Throat White 6.0 84.93
560-C3A67L Short Throat Gray 6.0 84.93
560-C3C60L Short Throat with Return White 7.0 88.44
560-C3C67L Short Throat with Return Gray 7.0 88.44
560-C3C60LF Short Throat with Return - 90° Eye White 7.0 89.10
560-D3C60L Long Throat with Return White 7.0 95.30
560-D3C67L Long Throat with Return Gray 7.0 95.30
Part No. Description Color Weight (lbs.) List (US $)
519-3090 Standard Trim Plate White 0.25 12.59
519-3091 Standard Trim Plate Black 0.25 12.59
519-3097 Standard Trim Plate Gray 0.25 12.59
500-3020 Winterize Plate - Standard Mouth White 0.25 13.57
Short Throat
Wide Mouth/Short Throat
Pool Skimmers and Skim Filters / Flo-Pro II Above Ground Skimmers
For replacement parts, see page 269.
126
Pool Skimmers and Skim Filters / Flo-Pro Above Ground Skim Filters
Flo-Pro Skim Filters
Flo-Pro Wide Mouth Skim Filters
Accessories
27" 7"
7.5"
11.375"
26.5" 26.5"
7"
12.8"
WIDE MOUTH
SHORT
15"
WIDE MOUTH
LONG
SKIM FILTER
Flo-Pro Skim Filters
combine the Flo-Pro
Skimmer with a
cartridge lter for
25 and 50 sq. .
ltration.
Part No. Description Color Filtration Area Weight (lbs.) List (US $)
560-l0C50T Long Throat with Return White 25 sq. ft. 9.0 274.47
560-l0C57T Long Throat with Return Gray 25 sq. ft. 9.0 302.25
560-J0C50T Long Throat with Return White 50 sq. ft. 9.5 293.41
560-J0C57T Long Throat with Return Gray 50 sq. ft. 9.5 322.74
Part No. Description Color Filtration Area Weight (lbs.) List (US $)
560-F3C50W Short Throat with Return White 50 sq. ft. 12.5 339.94
560-J3C50T Long Throat with Return White 50 sq. ft. 12.5 346.46
Part No. Description Case Quantity List (US $)
519-3020 Winterizing Trim Plate - White 1 12.85
916-1000 Trim Plate - Stainless Steel 1 19.54
1 ½" Hose Adapter Union Tailpiece included Support Extender included
916-1000
For replacement parts, see page 270.
127
Spa Skimmers and Filters / Deluxe Strip Skimmer and Strip Skim Filter
Deluxe Strip Skimmer and Strip Skim Filter
Part No. Description Case Quantity List (US $)
510-6900 Deluxe Strip Skimmer - 1 ½" S 50 80.68
510-6910 Deluxe Strip Skim Filter - 1 ½" S 50 123.60
FEATURES:
• Floating guillotine-style weir
• Easy through-wall installation
(requires only one round hole to mount)
• Easily accessible basket
• Skim Filter has easily accessible cartridge
11.62"
7.00"
8.30"
2.38"
HOLE SAW
2.59" 1.09"
128
Spa Skimmers and Filters / Strip Skimmers
Strip Skimmers
Part No. Description Case Quantity List (US $)
640-6920 Strip Skimmer - 1 ½" x Standard Nut 35 25.61
640-6940 Strip Skimmer - 1 ½" x 90° Ell 25 29.68
640-6960 Strip Skimmer - 1 ½" x Straight Adapter Nut 25 29.66
640-6600 Adjustable Strip Skimmer with Lint Basket - ½" S Ell 20 45.17
640-6920 640-6940
640-6961 640-6607
129
Spa Skimmers and Filters / Front Access Skim Filters
Front Access Skimmers and Skim Filters
Part No. Description Case Quantity List (US $)
510-1500 Square Spa Skimmer – 1 ½" S / 2" Spigot - Flow Control with Trim Plate 4 78.04
510-1600 Square Spa Skim Filter – 1 ½" / 2" Spigot - 10 sq. ft. 4 120.81
510-1650T Square Spa Skim Filter – 1 ½" / 2" Spigot - 20 sq. ft. 2 154.37
INCLUDES:
• 10 sq. ft. Cartridge
• EZ Flow Basket
• Flow Control Diverter Plate
• Trim Plate - White
• Mounting Gasket
INCLUDES:
• 10 sq. ft. Cartridges (2)
• EZ Flow Basket
• Flow Control Diverter Plate
• Trim Plate - White
• Mounting Gasket
Weir Door
7.375"4.9375"
2" Spigot
1.5" S 5.25"
9.625"
Basket
7.375"
2" Spigot
1.5" S
4.9375"
10 sq. ft.
Filter
Weir Door
13.75"
15.0625"
7.375"
2" Spigot
1.5" S
10 sq. ft.
Filter
Weir Door
4.9375"
18.125"
19.4375"
510-1500
510-1600
510-1650T
130
Spa Skimmers and Filters / Front Access Skim Filters
Front Access Skim Filters
Part No. Description Case Quantity List (US $)
510-9000 50 sq. ft. Front Access Skim Filter - Single Port 2 208.89
510-9020 50 sq. ft. Front Access Skim Filter - Single Port - Oval Style 2 215.71
510-9100 100 sq. ft. Front Access Skim Filter - Single Port -- 270.85
510-6600 100 sq. ft. Front Access Skim Filter - Dual Port 2 273.67
510-6620 100 sq. ft. Front Access Skim Filter - Dual Port - Oval Style 2 284.84
510-6700 200 sq. ft. Front Access Skim Filter - Dual Port -- 400.71
672-5090 100 sq. ft. Skim Filter Manifold Tee with Plug 20 20.34
FEATURES:
• 50 sq. ft. Cartridges (2) (100 sq. ft. total)
• 2" Spigot Output Ports (2)
• Extra Large 5 ½" x 14" Weir Area
• Extra Large 8" x 14" Basket
• Easy Access to Basket and Cartridges
• Easy Through-Wall Installation
FEATURES:
• 50 sq. ft. Cartridge
• 2" Spigot Output Port
• Easy access to basket and cartridges
• Easy Through-Wall Installation
FEATURES:
• 50 sq. ft. Cartridges (4) (200 sq. ft. total)
• 2" Spigot Outlet Ports (2)
FEATURES:
• 50 sq. ft. Cartridges (2) (100 sq. ft. total)
17.125"
9.125"
10.25"
18.75"
Hole Size 8.75" x 15.5"
17.125"
Hole Size 8.75" x 15.5"
9.125"
10.25"
18.5"
9.125"
10.25"
18.5"
9.75"
510-6600
510-9000 510-9020 510-6620
672-5090
510-9100510-6700
131
Spa Skimmers and Filters / 100 sq. ft. Roadster Skim Filter
100 sq. ft. Front Access Roadster Skim Filter
Part No. Description Case Quantity List (US $)
510-6680 100 sq. ft. Front Access Roadster Skim Filter -- 296.84
FEATURES:
• New Roadster grill design
• 50 sq. ft. Cartridges (2) (100 sq. ft. total)
• 2" Spigot Output Ports (2)
• Extra Large 5 ½" x 14" Weir Area
• Extra Large 8" x 14" Basket
• Easy Access to Basket and Cartridges
• Easy Through-Wall Installation
17.125"
9.125"
10.25"
18.75"
Hole Size 8.75" x 15.5"
510-6689DSG-PS
Hole Size: 8.75" x 15.5"
132
Spa Skimmers and Filters / Teleweir Skim Filters
Teleweir Skim Filters
Part No. Description "A" Dimension Case Quantity List (US $)
510-4630 25 sq. ft. Teleweir Skim Filer 20.25 in. 20 193.58
510-4620 35 sq. ft. Teleweir Skim Filter 16.00 in. 20 203.25
510-4600 50 sq. ft. Teleweir Skim Filter 20.25 in. 20 206.75
510-4590 75 sq. ft. Teleweir Skim Filter 26.38 in. 20 217.26
FEATURES:
• Cage-style tower eliminates unwanted vortexing
• Safety orientated
• Easily accessible basket for eortless cleaning
• Available in several dierent lter sizes
• 2" Socket IN/OUT plumbing
• Built in Check Valve
• Hole Saw Size: Ø 6.88"
• Custom logo plate available for volume orders
510-4600
Ø 6.88"
(HOLE SAW)
" A "
For replacement parts, see page 259.
133
Spa Skimmers and Filters / Dyna-Flo Top-Mount Skim Filters
Dyna-Flo Top-Mount Skim Filters
FEATURES:
• Improved exclusive vent system for added safety
• Exclusive bayonet lock retains the basket and weir
• PVC upper threaded, middle and bottom body components are compatible with PVC
glues and most silicones
• New compact sizes
• Traditional 4-scallop escutcheons to match the decor of the spa
• Telescoping weir has 6" of travel
• Built-in restriction valve for improved ltration with low volume
• Two basket sizes
• Dyna-Flo replacement parts t all existing Dyna-Flo Top-Mount Filters
• Retrots Dynamic Series Rainbow Skim Filters
Part No. Size Description Height List (US $)
510-4520 2" Socket - 25 sq. ft. Dyna-Flo Plus - Low Volume - 8 GPM Minimum 21 ⁄" 202.12
510-4540 2" Socket - 40 sq. ft. Dyna-Flo Plus - Low Volume - 8 GPM Minimum 17 ¼" 208.50
510-4550 2" Socket - 50 sq. ft. Dyna-Flo Plus - Low Volume - 8 GPM Minimum 21 ⁄" 215.25
510-9520 2" Socket - 25 sq. ft. Dyna-Flo Plus - Hi Volume - 15 GPM Minimum 21 ⁄" 202.12
510-9540 2" Socket - 40 sq. ft. Dyna-Flo Plus - Hi Volume - 15 GPM Minimum 17 ¼" 208.50
510-9550 2" Socket - 50 sq. ft. Dyna-Flo Plus - Hi Volume - 15 GPM Minimum 21 ⁄" 215.25
510-3520 2" Socket - 25 sq. ft. Low Prole Dyna-Flo - Low Volume - 8 GPM Minimum 19 ⁄" 193.58
510-3540 2" Socket - 40 sq. ft. Low Prole Dyna-Flo - Low Volume - 8 GPM Minimum 15 ¾" 199.97
510-3550 2" Socket - 50 sq. ft. Low Prole Dyna-Flo - Low Volume - 8 GPM Minimum 19 ⁄" 206.75
510-6520 2" Socket - 25 sq. ft. Low Prole Dyna-Flo - Hi Volume - 15 GPM Minimum 19 ⁄" 193.58
510-6540 2" Socket - 40 sq. ft. Low Prole Dyna-Flo - Hi Volume - 15 GPM Minimum 15 ¾" 199.97
510-6550 2" Socket - 50 sq. ft. Low Prole Dyna-Flo - Hi Volume - 15 GPM Minimum 19 ⁄" 206.75
ø 7.75"
For
Height
See
Chart
Below
Hole Saw Size 6.875"
(All Sizes)
DYNA-FLO PLUS
LOW PROFILE DYNA-FLO
Low Volume
8 GPM Minimum
Low Volume
8 GPM Minimum
Hi Volume
15 GPM Minimum
Hi Volume
15 GPM Minimum
For replacement parts, see page 263.
134
Spa Skimmers and Filters / Dyna-Flo XL Skim Filters and Ultra Skim Filter
Dyna-Flo XL Skim Filters
Ultra Skim Filter
FEATURES:
• Extra-large 10" diameter body for improved ltration
• Extra-large 6 ½" diameter cartridge for larger cartridge sizes
• Exclusive “Vent System” for added safety
• PVC upper, middle and bottom sections are compatible
with PVC glues and most silicones
• Available in 50, 75 and 100 sq. ft.
• Adjustable restrictor valve for variable ow control
• Extra-large basket
• Removable bypass valve for easy servicing
• Optional chemical feeder
• Available in 2" or 2 ½" Socket In/Out
Part No. Socket Size Filter Size Filter Length List (US $)
512-0270 2" 75 sq. ft. 21 ¾" 282.97
512-0210 2" 100 sq. ft. 26 ¼" 303.23
512-2550 2 ½" 50 sq. ft. 21 ¾" 268.79
512-2570 2 ½" 75 sq. ft. 21 ¾" 282.97
512-2510 2 ½" 100 sq. ft. 26 ¼" 303.23
FEATURES:
• Skims water without the use of a weir
• No moving parts
• Uses the same size hole pattern as our standard Dyna-Flo
• Allows for a larger variance of water levels
Part No. Filter Size Filter Length List (US $)
514-6550 50 sq. ft. 19 ⁄" 223.13
7.75"
5.5"
For
Height
See
Chart
Below
Hole Saw Size 6.875"
(All Sizes)
ø 9.75"
For
Height
See
Chart
Below
Hole Saw Size 8.5"
(All Sizes)
For replacement parts, see page 264.
For replacement parts, see page 265.
135
Spa Skimmers and Filters / Top-Load Filters
1 ½" and 2" Top-Load Filters
Part No. Description List (US $)
500-2500 1 ½" - 25 sq. ft. Cartridge with Plug 123.18
500-2510 1 ½" - 25 sq. ft. Cartridge with Bypass Valve 145.52
500-2540 1 ½" - 25 sq. ft. Cartridge with Plug and 10-Tablet Brominator 169.50
500-2550 1 ½" - 25 sq. ft. Cartridge with Bypass Valve and 10-Tablet Brominator 169.50
500-5000 1 ½" - 50 sq. ft. Cartridge with Plug 168.20
500-5010 1 ½" - 50 sq. ft. Cartridge with Bypass Valve 168.20
500-5050 1 ½" - 50 sq. ft. Cartridge with Bypass Valve and 10-Tablet Brominator 192.12
500-6010 1 ½" - without Cartridge - with Bypass Valve 137.49
500-6050 1 ½" - without Cartridge - with Bypass Valve and 10-Tablet Brominator 161.41
502-2500 2" - 25 sq. ft. Cartridge with Plug 155.72
502-2510 2" - 25 sq. ft. Cartridge with Bypass Valve 155.72
502-2530 2" - 25 sq. ft. Cartridge with Bypass Valve and Flow Restriction Tube 166.44
502-2550 2" - 25 sq. ft. Cartridge with Bypass Valve and 10-Tablet Brominator 169.50
502-5000 2" - 50 sq. ft. Cartridge with Plug 168.20
502-5010 2" - 50 sq. ft. Cartridge with Bypass Valve 168.20
502-5030 2" - 50 sq. ft. Cartridge with Bypass Valve and Flow Restriction Tube 179.00
502-5050 2" - 50 sq. ft. Cartridge with Bypass Valve and 10-Tablet Brominator 192.12
500-2500
7.5"
18"
2.76"
6"
12.55"
5.45"
For replacement parts, see page 261.
136
Spa Skimmers and Filters / Top-Load Extended Filters
1 ½" Top-Load Extended Filters
Part No. Description List (US $)
500-7500 75 sq. ft. Cartridge with Plug 201.35
500-7510 75 sq. ft. Cartridge with Bypass Valve 201.35
500-7550 75 sq. ft. Cartridge with Bypass Valve and 10 Tablet Brominator 225.24
500-9900 100 sq. ft. Cartridge with Plug 211.41
500-9910 100 sq. ft. Cartridge with Bypass Valve 211.41
500-9950 100 sq. ft. Cartridge with Bypass Valve and 10 Tablet Brominator 245.39
5.38"
2.5"
7.5" dia.
6" dia.
for 1.5" or 2"
2.76"
28.25"
500-7500
2" Top-Load Extended Filters
Part No. Description List (US $)
502-7500 75 sq. ft. Cartridge with Plug 201.34
502-7510 75 sq. ft. Cartridge with Bypass Valve 201.34
502-7550 75 sq. ft. Cartridge with Bypass Valve and 10 Tablet Brominator 218.70
502-9900 100 sq. ft. Cartridge with Plug 211.41
502-9910 100 sq. ft. Cartridge with Bypass Valve 211.25
137
Spa Skimmers and Filters / Filter Accessories
Filter Accessories
Part No. Description Case Quantity List (US $)
500-1021 Filter Niche with 2-Cup Holder Lid and Screws - Black 6 27.94
400-9140 Cartridge Mounting Assembly - 1 ½" NPT - with Grate 150 7.34
212-1810 Thru Wall Fitting Assembly - ½" S x ½" S 150 10.80
400-9030 Cartridge Mounting Assembly with Grate - 2" S x 1 ½" Acme 100 13.14
212-1820 Bulkhead Wall Fitting Assembly - ¾" RB 150 10.80
400-9220 Vent Wall Fitting Assembly with Grate (color matching available) 50 6.74
500-1070 10-Tablet Brominator Assembly 70 23.91
640-3170 Suction Wall Fitting Assembly with Bypass Valve 40 15.10
400-9120 Cartridge Mounting Assembly - 1 ½" NPT 150 6.74
400-9130 Cartridge Mounting Assembly - 2" NPT 100 13.14
670-2000 Water Nozzle Wall Fitting Assembly 200 6.06
640-4220 Lo-Pro ¾" SB 90° Return Fitting Assembly 40 17.20
640-4240 Lo-Pro ¾" S 90° Return Fitting Assembly 40 17.20
640-4230 Lo-Pro 1" S 90° Return Fitting Assembly 40 17.20
400-9150 Return Wall Fitting Assembly - 1 ½" FPT x 1 ½" S 50 8.38
500-1021 400-9140
212-1820 400-9220 500-1070 640-3170
400-9130
212-1810 400-9030
640-4220 / 640-4240 / 640-4230
670-2000 400-9150
138
Spa Skimmers and Filters / Skimmer and Skim Filter Options & Weirs
Skim Filter Gaskets
Spa Mounting Plate
Weirs
Filter Extensions
Part No. Description Case Quantity List (US $)
711-3280 Double-Seal Gasket 100 5.91
711-8010 Grommet Gasket -- 4.19
711-3280
680-2000 550-5617550-7760
550-1600
510-1150
Part No. Description Case Quantity List (US $)
550-1600 Spa Skimmer Mounting Plate with Screws 50 12.55
Part No. Description Case Quantity List (US $)
510-1150 Filter Extension Assembly 1 26.96
519-2041 Filter Extension - Cover 1 9.43
519-2031 Filter Extension - Body 1 14.82
Part No. Description Case Quantity List (US $)
680-2000 Custom Weir Assembly - 13 ⁄" H x 23 ¼" W (customized logo & color with quantity order) 25 150.99
550-7760 Skimmer Frame & Weir Assembly with Waterfall -- 150.99
550-5610 Curved Weir Frame Assembly - 13" H x 20 ¾" W -- 57.33
550-0120 Tiered Weir Frame Assembly -- 77.04
Pat. Pend.
550-0127
139
Spa Skimmers and Filters / Skimmer and Skim Filter Options
Replacement Cartridges for In-Line and Top-Load Filters
Part No. Description Dimensions Case Quantity List (US $)
817-2500 Cartridge - 25 sq. ft. 4 ⁄" OD x 13 ⁄" L -- 46.61
817-5000 Cartridge - 50 sq. ft. 4 ⁄" OD x 13 ⁄" L 16 67.02
817-7500 Cartridge - 75 sq. ft. 4 ⁄" OD x 23 ⁄" L -- 92.32
817-1000 Cartridge - 100 sq. ft. 4 ⁄" OD x 23 ⁄" L -- 101.31
817-2500 817-7500
Skim Filter Replacement Cartridges
Part No. Size Dimensions Top Load Front Access List (US $)
817-0010 10 sq. ft. 4 ¼" outer diameter x 4" L x 29.32
817-3501 35 sq. ft. 4 ⁄" outer diameter x 9 ¼" L (1 piece) x 44.22
817-3510 35 sq. ft. 4 ⁄" outer diameter x 4 ⁄" L (2 pieces) x 59.08
817-5010 50 sq. ft. 4 ⁄" outer diameter x 6 ⁄" L (2 pieces) x 68.73
817-0050 50 sq. ft. 6" outer diameter x 8 ¼" L x 66.65
817-0011 50 sq. ft. 6" outer diameter x 8 ¼" L (2 pieces upper) x 66.65
817-0012 50 sq. ft. 6" outer diameter x 8 ¼" L (2 pieces lower) x 66.65
817-2500 25 sq. ft. 5" outer diameter x 13 ¼" L x 46.61
817-5000 50 sq. ft. 5" outer diameter x 13 ¼" L (1 piece) x 67.02
817-0014 50 sq. ft. 5 ⁄" outer diameter x 10 ⁄" L x 73.59
817-0015 75 sq. ft. 5 ⁄" outer diameter x 14 ⁄" L x 92.08
817-7500 75 sq. ft. 5" outer diameter x 23 ⁄" L (2 pieces) x 92.32
817-0016 100 sq. ft. 5 ⁄" outer diameter x 17 ⁄" L x 107.31
817-1000 100 sq. ft. 5" outer diameter x 23 ⁄" L x 101.31
Skim Filter Replacement Cartridge

Navigation menu
