Dirt Devil Service Manual UD40235HD 205496 1
User Manual: UD40235HD
Open the PDF directly: View PDF
.
Page Count: 3
MODEL NO.
2
18
21
19
17
28
29
33
35
1
2
3
4
5
8
13
16
20
22
23
24
25
26 27
30
31
32
34
2
7
11 10
9
2
11
10
12
2
14
2
2
6
15
085800
085805
085806
085807HD
085810
085830(T)
085840HD
UD40235
UD40235HD
ASSEMBLY
S
CHEMATIC
MODEL NO.
Item
Part Number
Models To Fit
Part Description
1 2881250000
ALL
HANDLE SCREW ASSEMBLY
2 1720430000
ALL
SCREW 8-10 X 5/8 - COMBO
3 1250100000
ALL
SCREW 8-10 X 1 - BODY
4 2881005600
ALL
HOSE ASSEMBLY
5 2881015600
ALL
LOWER HOSE ASSEMBLY
6
2JF1041600
ALL
NOZZLE COVER / BASE ASSEMBLY
BLACK ONLY
7
1JE1044G00
ALL
HANDLE RELEASE PEDAL
8
1881050B00
ALL
BUMPER
9
1JE1056600
ALL
NOZZLE GUARD
10
1912370000
ALL
CASTER
11
1912420000
ALL
WHEEL RETAINER / PAL NUT
12
1720380000
ALL
BELT GUIDE CLIP
13
1540310001
ALL
BELT - STYLE 5
14**
2881080000
SEE NOTES
ALL
BRUSH ROLL ASSEMBLY
ORDER
2881020000
AND
1881020600
OR
1JE1056600
DEPENDING ON MODEL
/
CLEANER TYPE
2881020000
ALL
BRUSH ROLL ASSEMBLY
15
2JE1110600
ALL
ROLLER LIFTER ASSEMBLY
16
1881110600
ALL
FRONT ROLLER -
ORDER
#15
17
1JE1120000
ALL
MOTOR ASSEMBLY
18
1881130000
ALL
GROMMET
19
1881135G00
ALL
SWITCH PEDAL
20
1881140600
ALL
POWER CORD
21
1920906000
ALL
BULB #906
22
1881201600
ALL
HANDLE CAP
23
1881205600
ALL
TOOL CADDY
24
2JC0360000
ALL
F-1 / HEPA FILTER ASSEMBLY
25
2881235000
ALL
DIRT CUP ASSEMBLY
26
1881250000
ALL
DIRT CUP LATCH
27
1881255000
ALL
DIRT CUP LATCH SPRING
28
1790655600
ALL
CORD HOOK
29
1860081000
ALL
SWITCH
30
1863365600
ALL
EXTENSION WAND
31
1920035600
ALL
CREVICE TOOL
PART
L
ISTING
085800
085805
085806
085807HD
085810
085830(T)
085840HD
UD40235
UD40235HD
MODEL NO.
Item
Part Number
Models To Fit
Part Description
Net Cost
List Cost
32
2920215600
085800, 085805
085806, 085807HD,
UD40235, UH40235HD
2
IN 1 BRUSH ASSEMBLY
4.99
8.32
2JC0255600
085810, 085830,
085840HD
DUSTING BRUSH ASSEMBLY
1.25
2.08
33
1881160000
ALL
LOWER MOTOR HOUSING
3.50
5.83
34
1881048600
ALL
DIRT PASSAGE DOOR
.62
1.03
35
1881060600
ALL
PIVOT SEAL
.62
1.03
PART
L
ISTING
/ P
RICE
L
IST
WIRING
S
CHEMATIC
085800
085805
085806
085807HD
085810
085830(T)
085840HD
UD40235
UD40235HD
