17CD RECEIVERS16 CD RECEIVERS

CD Receiver with Multi-Color LCD Display, iPod®Adapter Ready, MP3/WMA Playback, MOSFET50, XM-Ready,

SIRIUS-Ready, Supertuner®III

D

™, IP-Bus System Control, Slim Remote, Pop-up Rotary Volume Control, Flap Face,

and Detachable Face Security™

CD Receiver with Multi-Color LCD Display, 45W x 4 high power, Supertuner®III

D

™, Rotary Volume Control,

and Detachable Face Security™

CD Receiver with Multi-Color LCD Display, iPod®Adapter Ready, MP3/WMA Playback, MOSFET50, XM-Ready,

SIRIUS-Ready, Supertuner®III

D

™, IP-Bus System Control, Slim Remote, Rotary Volume Control,

and Detachable Face Security™

CD Receiver with Blue Background LCD Display, 45W x 4 high power, Supertuner®III

D

™, and Detachable Face Security™

DEH-P9600MP DEH-P8600MP DEH-P80MP DEH-P7700MP DEH-P6700MP DEH-P4700MP DEH-P3700MP DEH-2700 DEH-1700

*1Burr-Brown

*2iTunes®AAC Playback: AAC player can decode only AAC files ripped and encoded using iTunes®; they cannot decode AAC DRM files downloaded from iTunes music store®.

*3AAC: AAC is a short for Advanced Audio Coding and refers to audio compression technology standard used with MPEG 4.

*4iPod is for legal or rightholder-authorized copying only. Don't steal music. iPod and iTunes are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.

High Performance Digital

Supertuner

®

Pioneer's Supertuner®has long set the standard for tuners and Supertuner®III

D

™

continues the proud lineage. Digital processing works with analog

technology to reduce distortion and improve signal-to-noise ratio, stereo

separation and sensitivity. In areas where reception is weak, it

automatically adjusts to boost the signal and reduce multi-path noise

caused by tall buildings. A digital filter achieves high selectivity in career

frequency areas, while an analog block works to supreme advantage where

reception is strong. Supertuner®III

D

™, the legend lives on.

MOSFET50

In recent years, MOSFET has become the buzzword

of the car electronics industry. And for good

reasons. It's a highly efficient way to power your

sound system and even drives a subwoofer.

MOSFET50 by Pioneer is the real thing. It may not

look like much, but this little chip pumps a solid 50 watts to all four speaker

channels. Of course, its true beauty is its musical clarity. With MOSFET50,

sound is far more detailed than what the average stereo pumps out with a

bipolar circuit.

DEH-P3700MP

DEH-2700

DEH-1700 NEW FOR 2005

NEW FOR 2005

NEW FOR 2005

DEH-P4700MP NEW FOR 2005 SUPERTUNER SECTION

Supertuner III

D

III

D

III

D

III

D

+III

D

III

D

III

D

III

D

III

D

XM Radio Ready x x x xxxx

SIRIUS-Ready x x x xxxx

24-Station/6-Button (18FM/6AM) Presets

xxxxxxxxx

BSM (Best Stations Memory) x x x xxxxxx

CD PLAYER

1-bit D/A Converter 8fs/24-bit*18fs/24-bit*18fs/16-bit 8fs/16-bit 8fs/16-bit 8fs/16-bit 8fs/16-bit 8fs/16-bit 8fs/16-bit

CD-R/CD-RW Compatible x x x xxxxxx

MP3 Compatible x x x xxxx

WMA (Windows Media®Audio) x x x xxxx

Wave (.wav) Compatible x x x xxxx

iTunes®*2AAC*3Playback x

AGC (Automatic Gain Control) x x x xxxxxx

Disc Title Memory x x x xxxx

Disc List x x x x x

CD Text xxxxxxx

IP-Bus (Changer Control) x x x xxxx

BMX Digital Compression (SCD) x x x xxxx

DBE (MCD) x x x xxxx

AUDIO SECTION

MOSFET60 (60Wx4-Channel High Power)

x

MOSFET50 (50Wx4-Channel High Power)

xx xxxx

45W x 4-Channel Power xx

Equalizer 13-Band 13-Band

3-Band Parametric 3-Band Parametric 3-Band Parametric 3-Band Parametric 3-Band Parametric 3-Band Parametric

Bass/Treble

SFEQ (Sound Focus EQ) x

EQ-EX x x x

Selectable FIE (Front Image Enhancer)

xxx

DSP x x

Auto-EQ (with Mic Included) x x

Auto Time Alignment x x

BBE x x

Source Level Adjuster (SLA) x x x xxxxxx

Automatic Sound Levelizer (ASL) x x x x

Loudness x x x 3 Mode 3 Mode 3 Mode 3 Mode 3 Mode 2 Mode

Listening Position Selector x x

Selectable Fader x x x xxxxxx

HPF Crossover x x x x x

Subwoofer (LPF) Crossover x x x x x

Hi-Volt RCA Preouts 3 (4.0V) 3 (4.0V) 3 (4.0V)

RCA Preouts 3 (2.2V) 2 (2.2V) 2 (2.2V) 2 (2.2V) 1 (2.2V) 1 (2.2V)

GENERAL

iPod®Adapter Ready*4xxxxxxx

DVD Control Ext x x x x Ext Ext

Customizable Display CD-R CD-R CD-R

Detachable Face Security™ x x x xxxxxx

Flap Face Motorized Auto Slide Auto Slide x x x

Organic EL Display Multi-Color Multi-Color Blue Blue Blue

LCD Display with LED Backlight Multi-Color Multi-Color Multi-Color x

Spectrum Analyzer x x Level Ind. Level Ind. Level Ind.

Soft-Key Operation x x

Remote Control 10-key 10-key 10-key 10-key Card Card Card

Rotary Volume Control x x

Rotary Commander Rotary Commander

Pop-up Pop-up x x

Wired Remote Input x x x xxxxx

Display Output x x x xxxx

Cellular Mute x x x x x

Face Case (Included) x x x x

Warranty 1 Year 1 Year 1 Year 1 Year 1 Year 1 Year 1 Year 1 Year 1 Year

19CASSETTE PLAYERS & AUDIO PROCESSORS18 2-DIN SPECIAL FIT & CASSETTE PLAYERS

FH-P4200MP NEW FOR 2005

Double-DIN CD/Cassette Receiver with LCD

Display, iPod®Adapter Ready, iTunes®AAC

Playback, MP3/WMA Playback, BMX Digital

Compression, MOSFET50, XM-Ready,

SIRIUS-Ready, Supertuner®III

D

™, Rotary

Volume Control, IP-Bus System Control and

Slim Remote

DEH-P77DH

GM/Chrysler-Fit CD Receiver with

Multi-Color LCD Display, iPod®Adapter

Ready, EEQ™, MOSFET45, XM-Ready,

SIRIUS-Ready, Supertuner®III™, IP-Bus

System Control, Slim Remote, DFS™ Alarm,

Pop-up Rotary Volume Control, Detachable

Face Security™, and Hi-Volt Preouts

DEH-P47DH

GM/Chrysler-Fit CD Receiver with

Multi-Color LCD Display, iPod®Adapter

Ready, EEQ™, MOSFET45, XM-Ready,

SIRIUS-Ready, Supertuner®III™, IP-Bus

System Control, Pop-up Rotary Volume

Control, and Detachable Face Security™

FEATURES:

• 3-Band Parametric Equalizer:

Presets (6 Factory, 4 User),

Nuance Control

• Auto-EQ: 3 Curves

(Dynamic/Natural/Mild), Omni-

Directional Microphone

(Included)

• 8x Oversampling 1-Bit Legato

Link™ D/A Converter

• Multi-Color Display with EL

Backlighting

• RCA Input

•

RCA Outputs (x3 Pair) (Front/Rear

+

Subwoofer or High/Mid/Low)

• DSP Mode: 5-Mode Digital Sound

Field Control (SFC), Listening

Position Selector, Front & Rear

HPF, Subwoofer LPF

• Pro Mode: Time Alignment,

Listening Position Selector, High-

HPF, Mid-LPF, Mid-HPF, Low-LPF

• Dimensions (WxHxD): 7-3/8" x

2-1/4" x 1-1/4"

Universal Add-On Digital Signal Processor with Auto-EQ, Digital

Crossover Network, Legato Link™ Conversion, and Detachable Face

Security™

DEH-P77DH

FH-P4200MP

KEH-P4020

DEH-P47DH KEH-P2030

FEATURES:

• Electronic 15-Band Digital

Graphic Equalizer: Presets

(5 Factory, 3 User), Nuance

Control, 15 Center Frequencies,

±12dB Gain

• 5-Mode Digital Sound Field

Control (SFC)

• Listening Position Selector

• Hi-Bit Legato Link™ Digital

Processing with 20-Bit Accuracy

• RCA Input

•

RCA Outputs (x3 Pair) (Front/Rear

+

Subwoofer)

• Sub-Out Crossover (50/80/125Hz,

-18dB/Oct.)

• Multi-Color EL Display

• Remote Control Sensor

• Dimensions (WxHxD): 7" x 2" x

5-1/4"

Universal Add-On Digital Processing Equalizer with DSP and

Subwoofer Output

DEQ-7600

DEQ-9200

Full-Logic Cassette Receiver with

Multi-Color Display, EEQ™, 45Wx4-Channel

High Power, XM-Ready, Supertuner®,

IP-Bus System Control, and Detachable

Face Security™

Cassette Receiver with 40Wx4-Channel High Power,

XM-Ready, Supertuner®, IP-Bus System Control, and

Detachable Face Security™

KEH-P2030

KEH-P4020

SUPERTUNER SECTION

Supertuner III

D

III III x x

XM Radio Ready x x x x x

SIRIUS-Ready x x x

24-Station/6-Button (18FM/6AM) Presets x x x x x

BSM (Best Stations Memory) x x x x x

CD PLAYER/CD FUNCTIONS

1-bit D/A Converter x x x

CD-R/CD-RW Compatible x x (CD-R) x (CD-R)

MP3 Compatible x

WMA (Windows Media®Audio) x

Wave (.wav) Compatible x

iTunes®* AAC** Playback x

AGC (Automatic Gain Control) x x x

Disc Title Memory x x x

Disc List x x

CD Text x x (MCD) x (MCD)

IP-BUS (Changer Control) x x x x x

BMX Digital Compression (SCD) x

DBE (MCD) x

CASSETTE PLAYER

Auto Reverse x x x

Full Logic Control x x

SHC Dual-Groove Tape Head x x x

Dolby®B Noise Reduction x

Music Search & Repeat x x

Radio Intercept xx

AUDIO SECTION

MOSFET50 (50Wx4-Channel High Power) x

MOSFET45 (45Wx4-Channel High Power) x x

45Wx4-Channel High Power x

40Wx4-Channel High Power x

BTB (Bass/Treble Booster) x

Equalizer 9-Band

3-Band Parametric 3-Band Parametric

3-Band

Selectable FIE (Front Image Enhancer) x x x

Source Level Adjuster (SLA) x

DSP x

BBE x

Loudness x Variable Variable 3 Mode 2 Mode

HPF Crossover x x x

Selectable Fader x x x

Subwoofer (LPF) Crossover x x x

Hi-Volt RCA Preouts 3 (4V)

RCA Preouts 2 (2V) 1 (2V) 1 (2V) 1 (2V)

GENERAL

iPod®Adapter Ready*** x x x

LCD Display with LED Backlight x Multi-Color Multi-Color Multi-Color

Spectrum Analyzer x

Detachable Face Security™ x x x x

Flap Face x

Face Case (Included) x

Remote Control Slim Slim

Rotary Volume Control x Pop-up Pop-up

Cellular Mute x x x

Warranty 1 Year 1 Year 1 Year 1 Year 1 Year

*iTunes®AAC Playback: AAC player can decode only AAC files ripped and encoded using iTunes®; they cannot decode AAC DRM files

downloaded from iTunes music store®.

** AAC: AAC is a short for Advanced Audio Coding and refers to audio compression technology standard used with MPEG 4.

*** iPod is for legal or rightholder-authorized copying only. Don't steal music. iPod and iTunes are trademarks of Apple Computer, Inc.,

registered in the U.S. and other countries.

SPECIFICATIONS

Peak Music Power

500W (4Ω)120W x 4 (4Ω)250W x 2 (4Ω)120W x 2 (4Ω)600W (4Ω)

800W (2Ω)

300W x 2 (Bridge, 4Ω)

760W x 1 (Bridge) 300W x 1 (Bridge)

1000W (2Ω)

Number of Channels 14221

Continuous Power (4Ω)250W x 1 60W x 4 125W x 2 60W x 2 300W x 1

Continuous Power (2Ω)360W x 1 75W x 4 190W x 2 75W x 2 500W x 1

Continuous Power Bridged (4

Ω

)

150W x 2 380W x 1 150W x 1

Frequency Response (0, -1dB) 10Hz - 240Hz 10Hz - 50kHz 10Hz-50kHz 10Hz-50kHz 5Hz - 240Hz

(+0dB, -3dB)

(+0.5dB, -3dB)

Total Harmonic Distortion (1kHz, 4Ω)

<0.03% (120Hz) <0.01% <0.015% <0.008%

<0.1% (100Hz, 4Ω)

Signal-to-Noise Ratio (IHF-A Weighted, at 1kHz)

>100dB >95dB >95dB >100dB >100dB

Dimensions (WxHxD)

11-13/16" x 2-3/8" 11-13/16" x 2-3/8" 11-13/16" x 2-3/8" 11-13/16" x 2-3/8" 10-9/16" x 2-1/16"

x 12-7/8" x 12-7/8" x 12-7/8" x 7-5/16" x 9-13/16"

FEATURES

Bridgeable 1/2/3-Channel Capability X X

Bridgeable 2/3/4-Channel Capability X

Class D Amplifier X

PWM Regulated MOSFET Power Supply

XXX X

DMOSFET Output Section X

Balanced Isolator Input Circuit XXXX

Oversized Screw-Type Power/Ground Terminals

XXXXX

RCA Inputs 2 Ch 4 Ch 2 Ch 2 Ch 2 Ch

RCA Outputs (Pass Thru) X

Speaker Level Input XXXX

Screw-Type Speaker Terminals XXXXX

Hi-Volt Input Level Control (200mV-6.5V)

XXXX

Variable Crossover (40-240Hz, -24dB/Oct. [LPF])

X

Variable LPF (40-240Hz, -12dB/Oct.) X

Selectable Crossover (80Hz, -12dB/Oct.) X

Bass Boost (50Hz, 0/6/12dB) X X

Selectable LPF (80Hz, -12dB/Oct.) X X

21AMPLIFIERS20 MULTI-PLAY CD PLAYERS & ADD-ON CD PLAYER

CDX-P680

This 6-disc changer is compatible with Pioneer's IP-Bus headunits. Disc title memory

allows you to program the names of up to 100 CDs. Mount it anywhere and control it via your headunit.

6-Disc IP-Bus Multi-CD Player

CDX-FM687

Yes, you can add a CD changer onto your factory stereo. The CDX-FM687 works off an

FM signal. Load in six of your favorite discs and control everything with a wireless remote and a

control/display unit.

Universal FM-Modulated 6-Disc Multi-CD System with Wireless Remote Control

CDS-P4000

If all you need is a single disc player to add onto your Pioneer IP-Bus headunit or AV

receiver, this is it. It seamlessly connects to your system and provides an illuminated LCD display.

Single-Disc IP-Bus Add-On CD Player with LCD Level Indicator

CDX-P1280

Ready to step up to a 12-disc CD changer? The CDX-P1280 works with a Pioneer system

IP-Bus headunit and can be mounted vertically or horizontally and has CD Text capability.

12-Disc IP-Bus Multi-CD Player

CDX-FM1287

Want a 12-disc changer that goes with your factory stereo? No problem.

The CDX-FM1287 uses your FM signal to reproduce CD audio, giving you hours of CD, CD-R, and

CD-RW play. It mounts easily, and includes a remote and control/display unit.

Universal FM-Modulated 12-Disc Multi-CD System with Wireless Remote Control

GM-7100M NEW FOR 2005

Get harder-hitting bass with 800 watts of high power at a 2-ohm load. This amp

delivers powerful sound with a low distortion rating of less than 0.03%.

GM-6100F NEW FOR 2005

Upgrade your in-car audio system with 600 watts of high power and variable LPF

and HPF. Dynamic power can be yours whether the amp is configured for 2- or 4-channel.

GM-5100T NEW FOR 2005

Give your system clean, high power. This amp has two channels to enhance your front/rear

sound. Bridge the channels together to drive a power-hungry subwoofer for harder-hitting bass.

GM-D510M

CLASS D AMPLIFIER

Big, efficient power. Operating

in Class D, the space-saving

GM-D510M gives you massive

power with less heat – and

less distortion—than with a

conventional amp.

GM-3100T

Add power with clarity to your system and experience the excitement of an

on-board live performance. It's a smart, simple solution to improving your in-car sound.

GM-6100F GM-5100TGM-7100M

GM-3100T

GM-D510M

600W MAX.800W MAX.

300W MAX.

760W MAX.

1000W MAX.

NEW FOR 2005

Push an explosive 1000 watts of power into a hard-driving 2-ohm load. Class D design

means high efficiency, cool operation and high decibel sound without taking too much space in your

trunk—perfect for driving a sub or two.

RCA Input RCA Input and Output

CDX-P680 CDS-P4000

CDX-P1280

CDX-FM1287

CDX-FM687

CD PLAYER

Disc Capacity 12 6 1 12 6

AGC (Automatic Gain Control) x x x x x

CD-R/CD-RW Compatible x x x x x

1-bit D/A Converter x x x x x

8x Oversampling Filter x x x x x

“Double-Floating” Anti-Vibration System

xxxxx

CD-Text Decoder x x x x

Disc Title Memory 100 Discs 100 Discs 100 Discs 100 Discs

ITS Memory 100 Discs 100 Discs 100 Discs 100 Discs

IP-Bus Control Output x x x x x

IP-Bus Control Input (Pass-thru)

x

Built-in FM Modulator x x

Selectable FM Frequencies 12 12

GENERAL

Multiple Mounting Angles x x In-Dash x x

Wired Control/Display x x

Wireless Remote Slim Slim

Magazine JD1212S JD612V JD1212S JD612V

Warranty 1 Year 1 Year 1 Year 1 Year 1 Year

125 Watts x 2, at 4Ω<= 1% THD+N

380 Watts x 1, at 4ΩBRIDGE <= 1% THD+N

75 dBA Signal-to-Noise Ratio

(Reference: 1 Watt Output)

60 Watts x 4, at 4Ω<= 1% THD+N

150 Watts x 2, at 4ΩBRIDGE <= 1% THD+N

80 dBA Signal-to-Noise Ratio

(Reference: 1 Watt Output)

60 Watts x 2, at 4Ω<= 1% THD+N

150 Watts x 1, at 4ΩBRIDGE <= 1% THD+N

80 dBA Signal-to-Noise Ratio

(Reference: 1 Watt Output)

250 Watts x 1, at 4Ω<= 1% THD+N

360 Watts x 1, at 2Ω<= 1% THD+N, at 100Hz

80 dBA Signal-to-Noise Ratio

(Reference: 1 Watt Output)

23ENCLOSED SPEAKERS, COMPONENT SPEAKERS & TRUCK RIDERS

®

3-Layer Fiber Woven Radial Surround and Newly

Designed Cone

To reduce distortion and flexing that can occur

during extreme performance, we've created a

surround construction similar in concept to a

radial tire. It consists of two layers of urethane

sandwiching one layer of interwoven fiber that

evenly distributes strength through the surround

material, eliminating potential weak points.

Additionally, the new TS-W subwoofers

come with a newly designed cone applying Pioneer patent-pending

technology. It is divided into a parabolic-shaped main cone and a flexible

drive cone that can be curved or straight, which enables even deeper bass.

Dual Voice Coil. In search of perfect bass

DVC subwoofers have two voice coils of 4-ohms each, which may be

connected in parallel to create a 2-ohm sub, or in a series, an 8-ohm sub.

Thanks to advanced Dual Voice Coil (DVC) design you can use a low

impedance amplifier to create exceptionally impressive sound

reproduction with one or two more subs. When used in combination with a

low load impedance compatible amp, DVC can give your subwoofers even

more powerful bass reproduction capability. This flexibility gives you the

power to create truly superior sound with hard driving bass.

Dual-Mass Magnet Assembly

Simply glance at our sub and you'll see our big idea. The Dual-Mass

Magnet Assembly is nearly twice the size of a conventional subwoofer. It

combines with the Extended Pole Yoke to create a significantly more

powerful and focused magnetic force. It's this force that controls the voice

coil and drives the woofer cone, bringing powerful, clean bass to

thunderous life.

Cross Section of TS-W306DVC Subwoofer

22 SUBWOOFERS

TS-WX121

12" Bass-Reflex Enclosed Subwoofer

TS-WX101

FEATURES:

• 10" Foamed IMPP Composite Cone

(Silver Grey)

• One-Piece Construction for Reduced

Distortion

• Dual-Layer Urethane Surround

• Integrated Direct Voice Coil Mounting Ring

• Conex Damper with Damper Ring

• Lead Wires Integrated into Damper for High

Reliability and Improved Power Transfer

• Glass-Imide Voice Coil Bobbin

• Projected Pole Yoke with Vented Pole

• Bass-Reflex Design with Side Port

• Thick Wood Enclosure for Richer Bass

Response

• Ideal Design for Sport-Utility Vehicles (SUV's)

and Hatchbacks

SPECIFICATIONS:

• 350 Watts Max. Music Power (80 Watts

Nominal)

• Frequency Response: 20 - 1,800Hz

• Sensitivity: 104dB (In-car)

• 4ΩRated

• Dimensions: 18-7/8" x 12" x 16"

10" Bass-Reflex Enclosed Subwoofer

TS-C1653

FEATURES:

• 6-1/2" Foamed IMPP Composite Cone Woofer

(Titanium Grey)

• Butyl Rubber Surround

• 7/8" Soft Dome Tweeter with Neodymium

Magnet and Magnetic Fluid

• Surface (Angled) or Flush Swivel Mounting

• Outboard Crossover Network Included

with -18dB/Oct. HPF and -6dB/Oct. LPF Filters

and Tweeter Protection Circuit

• Full-Depth Basket for Rich Bass Response

• New Basket Provides Improved Fit on GM

Oversized 6-1/2" Applications

SPECIFICATIONS:

• 150 Watts Max. Music Power (50 Watts

Nominal) (with 80Hz, -12dB/Oct. HPF);

120 Watts (40 Watts) without Crossover

• Frequency Response: 30Hz - 32kHz

• Sensitivity: 90dB

• 4ΩRated

FEATURES:

• 5-1/4" Foamed IMPP Composite Cone

(Titanium Grey)

• Butyl Rubber Surround

• 7/8" Soft Dome Tweeter with Neodymium

Magnet and Magnetic Fluid

• Surface (Angled) or Flush Swivel Mounting

• Outboard Crossover Network Included

with -18dB/Oct. HPF and -6dB/Oct. LPF Filters

and Tweeter Protection Circuit

SPECIFICATIONS:

• 150 Watts Max. Music Power (50 Watts

Nominal) (with 80Hz, -12dB/Oct. HPF);

90 Watts (30 Watts) without Crossover

• Sensitivity: 90dB

• Frequency Response: 40Hz - 32kHz

• 4ΩRated

6-1/2" Component Speaker Package

TS-C1353

5-1/4" Component Speaker Package

TS-W306C/TS-W306DVC

12" Component Subwoofers

TS-W256C/TS-W256DVC

10" Component Subwoofers

TS-W300R

SPECIFICATIONS:

• 600 Watts Max. Music Power

• 150 Watts Nominal Power Handling

• Frequency Response: 20 - 4,000Hz

• Sensitivity: 91dB

• 4ΩRated

• Accessory Grille (UD-G306) Available

• Recommended Enclosure: 1.5 Cubic Feet

SPECIFICATIONS:

• 1000 Watts Max. Music Power

• 400 Watts Nominal Power Handling

• Frequency Response: 18 - 500Hz

• Sensitivity: 89dB

• Accessory Grille (UD-G306) Available

•

Recommended Enclosure: 0.85 - 1.75 Cubic Feet

TS-W306C

• 4ΩRated

TS-W306DVC

• Dual-Voice Coil Design (4Ω)

SPECIFICATIONS:

• 800 Watts Max. Music Power

• 350 Watts Nominal Power Handling

• Frequency Response: 18 - 600Hz

• Sensitivity: 87dB

• Accessory Grille (UD-G256) Available

• Recommended Enclosure: 0.65-1.25 Cubic Feet

TS-W256C

• 4ΩRated

TS-W256DVC

• Dual-Voice Coil Design (4Ω)

SPECIFICATIONS:

• 500 Watts Max. Music Power

• 120 Watts Nominal Power Handling

• Frequency Response: 20 - 4,500Hz

• Sensitivity: 90dB

• 4ΩRated

• Accessory Grille (UD-G256) Available

• Recommended Enclosure: 1.0 Cubic Foot

• IMPP Composite Cone Woofer

• Dual-Layer Urethane Surround

• 4-Layer, Long Voice Coil

• Aluminum Voice Coil Bobbin

• Conex Damper with Damper Ring

• Extended and Vented Pole Yoke

• Bumped Backplate

• Molded Gasket

SHARED FEATURES (TS-W300R/TS-W250R):

• Composite IMPP Cone Using Interlaced Dual

Aramid Fiber

• 3-Layer Fiber Woven Radial Surround

• 4-Layer, Long Voice Coil

• 12-Slit Aluminum Voice Coil Bobbin

• Dual Mass High-Power Magnet

• Conex Damper with Damper Ring

• Extended and Vented Pole Yoke

• Molded Gasket

• Magnet Cover

SHARED FEATURES (TS-W306C/TS-W306DVC/TS-W256C/TS-W256DVC):

12" IMPP Component Subwoofer

TS-W250R

10" IMPP Component Subwoofer

TS-TRX40

FEATURES:

• 5" IMPP Composite Cone

Woofer

• 2-1/4" PPS (Polyphenylene

Sulfide) Dome Tweeter

• Water Resistant Diaphragms

for Woofer and Tweeter

• Versatile Mounting Bracket

enables Top or Bottom

Mounting

SPECIFICATIONS:

• 100 Watts Max. Music Power

(35 Watts Nominal)

• Frequency Response:

75Hz - 23kHz

• Sensitivity: 90dB

• 4ΩRated

• Dimensions: 11-1/4" x 7-1/2" x

4-5/8"

Truck Riders®Series 2-Way Speaker System

TS-TRX800

FEATURES:

• 8" IMPP Composite Cone

Woofer

• 2-1/4" Horn Tweeter

• Optimized Bass-Reflex Design

to Ensure Rich and Powerful

Bass Reproduction

• Mounting Belts and Plates

Included

SPECIFICATIONS:

• 200 Watts Max. Music Power

(75 Watts Nominal)

• Frequency Response:

45Hz - 24kHz

• Sensitivity: 92dB

• 4ΩRated

• Dimensions:

17-1/2" x 13-1/2" x 4"

Truck Riders®Series 2-Way Speaker System

TS-TRX1000

FEATURES:

• 10" IMPP Composite Cone

Woofer

• 2-5/8" Horn Midrange

• 2-1/4" Horn Tweeter

• Optimized Bass-Reflex Design

to Ensure Rich and Powerful

Bass Reproduction

• Mounting Belts and Plates

Included

SPECIFICATIONS:

• 250 Watts Max. Music Power

(100 Watts Nominal)

• Frequency Response:

35Hz - 24kHz

• Sensitivity: 94dB

• 4ΩRated

• Dimensions: 24" x 15" x 4-3/8"

Truck Riders®Series 3-Way Speaker System

TS-T15

FEATURES:

• Small-Sized (3/4") Polyester Fiber Soft Dome

Tweeter with Neodymium Magnet and Magnet

Fluid

• -6dB/Oct. Capacitor for Tweeter Protection

(Included)

• Flush and Surface Mounting Capabilities

SPECIFICATIONS:

• 120 Watts Max. Music Power (40 Watts

Nominal) (with Network)

• Frequency Response: 2,500Hz - 30kHz

• Sensitivity: 90dB

• 4ΩRated

3/4" Component Soft Dome Tweeter

TS-T110

FEATURES:

• 7/8" PPTA Hard Dome Tweeter with Strontium

Magnet and Magnetic Fluid

• In-Line -6dB/Oct. Capacitor for Tweeter

Protection

• Surface or Flush Mounting Capabilities

SPECIFICATIONS:

• 120 Watts Max. Music Power (40 Watts

Nominal) (with Included Crossover)

• Frequency Response: 2,500Hz - 30kHz

• Sensitivity: 90dB

• 4ΩRated

7/8" Component Hard Dome Tweeter

150W MAX.

100W MAX.

350W MAX.400W MAX.600W MAX.

500W MAX.

1000W MAX.

800W MAX.

200W MAX.250W MAX.

150W MAX.

120W MAX.120W MAX.

FEATURES:

• 12" Foamed IMPP Composite Cone

(Silver Grey)

• One-Piece Construction for Reduced

Distortion

• Dual-Layer Urethane Surround

• Integrated Direct Voice Coil Mounting Ring

• Conex Damper with Damper Ring

• Lead Wires Integrated into Damper for High

Reliability and Improved Power Transfer

• Glass-Imide Voice Coil Bobbin

• Projected Pole Yoke with Vented Pole

• Bass-Reflex Design with Side Port

• Thick Wood Enclosure for Richer Bass

Response

• Ideal Design for Sport-Utility Vehicles (SUV's)

and Hatchbacks

SPECIFICATIONS:

• 400 Watts Max. Music Power (100 Watts

Nominal)

• Frequency Response: 20 - 1,500Hz

• Sensitivity: 106dB (In-car)

• 4ΩRated

• Dimensions: 18-7/8" x 13-1/2" x 14-1/8"

Fiber Woven Radial Surround

(Patent Pending)

Composite IMPP Cone

Using Interlaced Aramid

Fiber (Patent Pending)

Dual-Mass Magnet Assembly

Wide Roll Surround

Oversized Voice Coil

Extended and Vented Pole Yoke

Fiber Woven Radial Surround

(Patent Pending)

Fiber

Urethane

UD-G306 Spoke Grille.

UD-G256 Spoke Grille.

NEW FOR 2005

NEW FOR 2005

25REV SERIES

TS-D161R NEW FOR 2005

TS-C160R

REV Series Evolution — for Even More Excitement

The new REV (TS-D) Series speakers boost the impact of sound with high

power and smooth, accurate sound reproduction. The composite IMPP

cones now feature 2nd generation KEVLAR®Brand Fiber composite cone

with ceramic coating, which enables high spec in sound-propagation

speed, internal loss, and rigidity. The result is more detailed, high-fidelity

sound with lower resonance and better transient response in low and mid

ranges.

And the true beauty of REV Series speakers is the science built into

their soft-dome tweeters. Ordinary speaker woofers play frequencies that

extend into the higher ranges. REV Series speakers direct those crisp

sounds exclusively to the tweeters, thanks to a diaphragm and rear

chamber that controls damping and improves imaging and staging. The

domes themselves are made of newly-applied lightweight material, and the

gentle shape of the domes improves sound by preventing sharp, top-end

peaks.

Also contributing to better sound is the newly designed basket with

thicker steel — more than 1.4 times thicker than previous models — which

results in more than three-times higher compressive strength and better

dumping.

Cross Section of REV Speaker

Wave Guides

To help control the dips in frequency response, REV Series tweeters rely on

an innovation called wave guides. They affect the dispersion patterns of

sound waves and provide a sound image that is clear and focused. Wave

guides also enhance localization, depth in soundstage and generate a

wider sweet spot than normal tweeters.

The new REV Series comes with an

updated version of wave guides,

which boasts even higher performance.

DuPont and/or DU PONT-TORAY CO., LTD. produce KEVLAR®brand fiber. DuPont™ and KEVLAR®are trademarks and registered trademarks of DuPont or its affiliates and are used under license by Pioneer.

24 REV SERIES

FEATURES:

• 6-1/2" KEVLAR®Brand Fiber Composite Cone Woofer

• Butyl Rubber Surround for Smoother Response

• CCAW (Copper-Clad Aluminum Wire) Voice Coil

• Glass-Imide/Copper Voice Coil Bobbin

• Conex Damper

• VCCS™ (Voice Coil Cooling System) with Aluminum Dust Cap

• Projected Pole Yoke

• 1" Lightweight Soft Dome Tweeter with Magnetic Fluid and Neodymium Magnet

• Surface (Angled) or Flush Swivel Mounting

• Outboard Crossover Network Included with -12dB/Oct. HPF and -12dB/Oct. LPF,

Tweeter Protection Circuit and Tweeter Level Adjustment (0, -3dB)

• Aluminum Die-Cast Full-Depth Basket for Rich Bass Response

• Gold-Plated Binding Posts

• Fits GM Oversized 6-1/2" Applications

SPECIFICATIONS:

• 250 Watts Max. Music Power (60 Watts Nominal)

• Frequency Response: 25Hz - 32kHz

• Sensitivity: 90dB

• 4ΩRated

6-1/2" REV Component Speaker Package

TS-C130R

FEATURES:

• 5-1/4" KEVLAR®Brand Fiber Composite Cone Woofer

• Butyl Rubber Surround for Smoother Response

• Glass-Imide/Copper Voice Coil Bobbin

• Conex Damper

• VCCS™ (Voice Coil Cooling System) with Aluminum Dust Cap

• Projected Pole Yoke

• 1" Lightweight Soft Dome Tweeter with Magnetic Fluid and Neodymium Magnet

• Surface (Angled) or Flush Swivel Mounting

• Outboard Crossover Network Included with -12dB/Oct. HPF and -12dB/Oct. LPF,

Tweeter Protection Circuit and Tweeter Level Adjustment (0, -3dB)

• Aluminum Die-Cast Full-Depth Basket for Rich Bass Response

• Gold-Plated Binding Posts

SPECIFICATIONS:

• 180 Watts Max. Music Power (40 Watts Nominal)

• Frequency Response: 35Hz - 32kHz

• Sensitivity: 90dB

• 4ΩRated

5-1/4" REV Component Speaker Package

FEATURES:

• Dual-Layer KEVLAR®Brand Fiber with Rigilite™ IMPP™ Composite Cone

• Butyl Rubber Surround for Smoother Response

• Glass-Imide Voice Coil Bobbin

• Conex Damper

• 1-1/8" Lightweight Soft Dome Tweeter with Neodymium Magnet and Rear Chamber

• Newly-Designed Wave Guides for Even Better Dispersion Control

• Built-in LC Network (-12dB/Oct. LPF & HPF)

• Newly-Designed Basket Boasting Much Higher Compressive Strength and Better

Damping

SPECIFICATIONS:

• 260 Watts Max. Music Power (60 Watts Nominal)

• Frequency Response: 27Hz - 32kHz

• Sensitivity: 90dB

• 4ΩRated

6-1/2" REV 2-Way Speaker

TS-D691R NEW FOR 2005

FEATURES:

• Dual-Layer KEVLAR®Brand Fiber with Rigilite™ IMPP™ Composite Cone

• Butyl Rubber Surround for Smoother Response

• Glass-Imide Voice Coil Bobbin

• Conex Damper

• 1-1/8" Lightweight Soft Dome Tweeter with Neodymium Magnet and Rear Chamber

• Newly-Designed Wave Guides for Even Better Dispersion Control

• Built-in LC Network (-12dB/Oct. LPF & HPF)

• Newly-Designed Full-Depth Basket Boasting Much Higher Compressive Strength

and Better Damping

SPECIFICATIONS:

• 350 Watts Max. Music Power (80 Watts Nominal)

• Frequency Response: 22Hz - 32kHz

• Sensitivity: 91dB

• 4ΩRated

6" X 9" REV 2-Way Speaker

TS-D681R NEW FOR 2005

FEATURES:

• Dual-Layer KEVLAR®Brand Fiber with Rigilite™ IMPP™ Composite Cone

• Butyl Rubber Surround for Smoother Response

• Glass-Imide Voice Coil Bobbin

• Conex Damper

• 1-1/8" Lightweight Soft Dome Tweeter with Neodymium Magnet and Rear Chamber

• Newly-Designed Wave Guides for Even Better Dispersion Control

• Built-in LC Network (-12dB/Oct. LPF & HPF)

• Newly-Designed Basket Boasting Much Higher Compressive Strength and Better

Damping

SPECIFICATIONS:

• 260 Watts Max. Music Power (60 Watts Nominal)

• Frequency Response: 27Hz - 32kHz

• Sensitivity: 91dB

• 4ΩRated

6" X 8" REV 2-Way Speaker

260W MAX.

250W MAX.

180W MAX.

350W MAX.

260W MAX.

Dual-Layer KEVLAR®Brand Fiber with Rigilite™

IMPP™ Composite Cone (Patent Pending) Magnified Cross Section View

KEVLAR®Brand Fiber

Wave Guides

Ceramic

Coating

Composite Foamed IMPP

Kevlar®Fiber Skin Layer

Dual-Layer KEVLAR®Brand Fiber with Rigilite™

IMPP™ Composite Cone (Patent Pending)

Rear Chamber

Newly Designed Basket

with Thicker Steel

Neodymium Magnet

1-1/8" Lightweight

Soft Dome Tweeter

Speaker Specifications located on Page 30.

Speaker Specifications located on Page 30.

27SPEAKERS

New Materials, New Shape — Better Sound

The new TS-A series speakers feature a composite IMPP cone woofer that

uses two kinds of interlaced aramid fiber for even higher sound quality —

one for sufficient volume in low frequency levels and the other for creating

a smooth, natural, stereoscopic sound field with minute details. Use of the

two materials also increases the rigidity and durability of the woofer, and

the voice coil ring with reduced thickness permits better linearity.

The lightweight balanced dome midrange enables improved

sensitivity and better transient. Its overall shape has been optimized

through repeated simulations. The result is reduced sound-wave

interference between the dome and the surrounding area.

New Basket Design

Behind the TS-A series speakers' cool-looking face — featuring metallic sub

grill and new spoke grills — is the newly designed basket, which ensures

higher sound quality and easy installation on a wider variety of vehicles.

The new basket design boasts higher compressive strength, while the

wider installation coverage is enabled by smaller cutout holes that

maintain the vibration area.

Cross Section of TS-A6991R Speaker

26 SPEAKERS

6" x 8" Perfect Fit Speakers

There are a few things in life we'll never understand. Like why do stereo

companies keep trying to force people to put 5" x 7" speakers in 6" x 8"

holes? It doesn't look or sound right. That's why we've researched exactly

what dimension speakers would work best with what cars. If it doesn't fit

perfect, it's not gonna sound perfect. Trust us on this.

TS-A6991R

FEATURES:

• Composite IMPP Cone Woofer Using

Interlaced Dual Aramid Fiber

• Butyl Rubber Surround for Smoother

Response

• Glass-Imide Voice Coil Bobbin

• Latex-Treated Conex Damper

• 2-1/4" Lightweight Balanced Dome Midrange

with Magnetic Fluid

• 1-1/2" Film Cone Tweeter with Neodymium

Magnet

• 3/4" Dome Supertweeter

• Full-Depth Basket for Rich Bass Response

6" x 9" 5-Way Speaker

TS-A6981R

FEATURES:

• Composite IMPP Cone Woofer Using

Interlaced Dual Aramid Fiber

• Butyl Rubber Surround for Smoother

Response

• Glass-Imide Voice Coil Bobbin

• Latex-Treated Conex Damper

• 2-1/4" Lightweight Balanced Dome Midrange

with Magnetic Fluid

• 1-1/2" Film Cone Tweeter

• 3/4" Dome Supertweeter

• Full-Depth Basket for Rich Bass Response

6" x 9" 4-Way Speaker

TS-A6880R

FEATURES:

• Composite IMPP Cone Woofer Using

Interlaced Aramid Fiber

• Butyl Rubber Surround for Smoother

Response

• High-Energy Strontium Magnet (Woofer)

• Glass-Imide Voice Coil Bobbin

• Latex-Treated Conex Damper

• 1-5/8" Foamed PPC (Pearl Poly-Carbon)

Balanced Dome Midrange with Magnetic Fluid

and Strontium Magnet

• 5/8" Dome Tweeter

• 3/8" Dome Supertweeter

• Custom-Fit for Ford and Mazda Vehicles

FEATURES:

• Composite IMPP Cone Woofer Using

Interlaced Aramid Fiber

• Butyl Rubber Surround for Smoother

Response

• High-Energy Strontium Magnet (Woofer)

• Glass-Imide Voice Coil Bobbin

• Latex-Treated Conex Damper

• 1-5/8" Foamed PPC (Pearl Poly-Carbon)

Balanced Dome Midrange with Magnetic Fluid

and Strontium Magnet

• 3/8" Dome Tweeter

• Custom-Fit for Ford and Mazda Vehicles

6" x 8" Custom-Fit 4-Way Speaker

TS-A6870R

6" x 8" Custom-Fit 3-Way Speaker

TS-G6840R

FEATURES:

• IMPP Composite Cone Woofer

• High-Energy Strontium Magnet

• Kapton Voice Coil Bobbin

• Conex Damper

• 1-1/2" Film Cone Tweeter

• New Custom-Fit for Ford and Mazda Vehicles

FEATURES:

• Foamed IMPP Composite Cone Woofer

• Urethane Surround for High Efficiency

• High-Energy Strontium Magnet

• 1-5/8" Cone Tweeter

• Custom-designed Speaker Basket Fits Ford,

Chrysler and Toyota (6" x 8" or 5" x 7") Factory

Provisions

6" x 8" Custom-Fit 2-Way Speaker

TS-A5713

5" x 7" Custom-Fit 2-Way Speaker

TS-A1780R

FEATURES:

• Composite IMPP Cone Woofer Using

Interlaced Aramid Fiber

• Butyl Rubber Surround for Smoother

Response

• High-Energy Strontium Magnet (Woofer)

• Glass-Imide Voice Coil Bobbin

• Conex Damper

• 1-5/8" Foamed PPC (Pearl Poly-Carbon)

Balanced Dome Midrange with Magnetic Fluid

and Strontium Magnet

• 3/8" Dome Tweeter

• 3/8" Dome Supertweeter

6-3/4" 4-Way Speaker

3-Hole Adapter

TS-A6971R

FEATURES:

• Composite IMPP Cone Woofer Using

Interlaced Dual Aramid Fiber

• Glass-Imide Voice Coil Bobbin

• 2-1/4" Lightweight Balanced Dome Midrange

with Magnetic Fluid

• 3/4" Cone Tweeter

• Shallow Basket for Increased Installation

Versatility

6" x 9" 3-Way Speaker

TS-A6961R

FEATURES:

• Composite IMPP Cone Woofer Using

Interlaced Dual Aramid Fiber

• Glass-Imide Voice Coil Bobbin

• 2-1/4" Film Cone Midrange

• 3/4" Cone Tweeter

• Shallow Basket for Increased Installation

Versatility

6" x 9" 3-Way Speaker

6" x 8" Factory Opening

5" x 7" Speaker

6" x 8" Factory Opening

6" x 8" Speaker

460W MAX. 420W MAX.

NEW FOR 2005 NEW FOR 2005

230W MAX.

NEW FOR 2005

300W MAX.

NEW FOR 2005

220W MAX.240W MAX.

120W MAX.150W MAX.

240W MAX.

Composite IMPP Cone Using

Interlaced Dual Aramid Fiber

(Patent Pending)

Voice Coil Ring in a New Shape

Large-Diameter

Conex Spider

Lightweight Balanced

Dome Midrange

“B” Type Aramid

Fiber Pellets

Master Badge

Pellets

“A” Type Aramid

Fiber Pellets

Polypropylene

Pellets

The IMPP cones of new TS-A series are made from

two types of aramid fibers, polypropylene,

and master badge pellets.

The new cone boasts even

higher rigidity and durability.

Microscopic Cross

Section View

Newly Designed Basket

Speaker Specifications located on Page 30. Speaker Specifications located on Page 30.

28 SPEAKERS

TS-A1681R

6-1/2" 4-Way Speaker

29SPEAKERS

TS-G1640R

FEATURES:

• IMPP Composite Cone Woofer

• High-Energy Strontium Magnet (Woofer)

• Kapton Voice Coil Bobbin

• Conex Damper

• CCAW (Copper-Clad Aluminum Wire) Voice

Coil

• 1-5/8" Film Cone Tweeter

• 6-3/4" Compatibility (GM Tabs)

6-1/2" 2-Way Speaker

TS-A1671R

FEATURES:

• Composite IMPP Cone Woofer Using

Interlaced Dual Aramid Fiber

• Butyl Rubber Surround for Smoother Response

• Glass-Imide Voice Coil Bobbin

• Latex-Treated Conex Damper

• 1-5/8" Lightweight Balanced Dome Midrange

with Magnetic Fluid

• 5/8" Dome Tweeter

• 3/8" Dome Supertweeter

• Full-Depth Basket for Rich Bass Response

FEATURES:

• Composite IMPP Cone Woofer Using

Interlaced Dual Aramid Fiber

• Butyl Rubber Surround for Smoother Response

• Glass-Imide Voice Coil Bobbin

• Latex-Treated Conex Damper

• 1-5/8" Lightweight Balanced Dome Midrange

with Magnetic Fluid and Neodymium Magnet

• 3/8" Dome Tweeter

• Shallow Mounting Depth for Increased

Installation Versatility

6-1/2" 3-Way Speaker

TS-A1370R

FEATURES:

• Composite IMPP Cone Woofer Using

Interlaced Aramid Fiber

• Butyl Rubber Surround for Smoother Response

• High-Energy Strontium Magnet (Woofer)

• Glass-Imide Voice Coil Bobbin

• Conex Damper

• 1-5/8" Foamed PPC (Pearl Poly-Carbon) Cone

Midrange with Magnetic Fluid and Strontium

Magnet

• 3/8" Dome Tweeter

5-1/4" 3-Way Speaker

TS-A4103

FEATURES:

• IMPP Composite Cone Woofer

• Urethane Surround for High Efficiency

• High-Energy Strontium Magnet (Woofer/Tweeter)

• Aluminum Voice Coil Bobbin

• Conex Damper

• 1-5/8" Cone Tweeter

4" x 10" 2-Way Speaker

TS-G1340R

FEATURES:

• IMPP Composite Cone Woofer

• High-Energy Strontium Magnet (Woofer)

• Kapton Voice Coil Bobbin

• Conex Damper

• 1-3/8" Film Cone Tweeter

• Shallow Mounting Depth for Wider Installation

Coverage

5-1/4" 2-Way Speaker

TS-P462

FEATURES:

• 4" Foamed IMPP Composite Cone

• Butyl Rubber Surround for Smoother Response

• High-Energy Strontium Magnet (Woofer)

• Latex-Treated Conex Damper

• Kapton Voice Coil Bobbin

• 1" Soft-Dome Tweeter with Neodymium Magnet

• Built-In Passive Crossover (-6dB/Oct. LPF, -12dB/Oct. HPF)

4" x 6" 2-Way Component Plate Speaker

TS-G4640R

FEATURES:

• IMPP Composite Cone Woofer

• High-Energy Strontium Magnet

• Kapton Voice Coil Bobbin

• Conex Damper

• 1-3/8" Film Cone Tweeter

• New Custom-Fit US/European Compatible Basket Design

4" x 6" 2-Way Speaker

TS-A4670R

FEATURES:

• Composite IMPP Cone Using Interlaced Aramid Brand Fiber

• High-Energy Strontium Magnet (Woofer)

• Glass-Imide Voice Coil Bobbin

• Conex Damper

• 1-1/8" Foamed PPC (Pearl Poly-Carbon) Balanced Dome

Midrange with Magnetic Fluid and Neodymium Magnet

• 3/8" Film Dome Tweeter

• Custom-Fit US/European Compatible Basket Design

4" x 6" 3-Way Speaker

TS-A1057

FEATURES:

• Foamed IMPP Composite Cone Woofer

• High-Compliance Urethane Surround for High Efficiency

• High-Energy Strontium Magnet (Woofer)

• Glass-Imide Voice Coil Bobbin

• Latex-Treated Conex Damper

• 1" Foamed PPC (Pearl Poly-Carbon) Balanced Dome Tweeter

with Neodymium Magnet and Magnetic Fluid

• 4 & 2-Hole Compatibility with Removable Screw Holes

4" 2-Way Speaker

TS-A878

FEATURES:

• 3-1/2" Carbon-Graphite Blended IMPP

Composite Cone Woofer

• High-Energy Strontium Magnet (Woofer)

• Glass-Imide Voice Coil Bobbin

• Conex Damper

• 1" PEI (Poly-Ether Imide) Dome Tweeter

• Ultra-Slim Neodymium Magnet (Tweeter)

• Custom-Fit for GM, Ford and Volkswagen

Vehicles

3-1/2" Dash-Mount 2-Way Speaker

TS-G1040R

FEATURES:

• IMPP Composite Cone Woofer

• Kapton Voice Coil Bobbin

• Cotton/Conex Damper

• 1-1/8" Film Cone Tweeter

• 4 & 2-Hole Compatibility with Removable Screw Holes

4" 2-Way Speaker

TS-877

FEATURES:

• 3-1/2" Cone Woofer

• Custom-Fit for GM, Ford and Volkswagen

Vehicles

3-1/2" Dash-Mount Dual-Cone Speaker

TS-X150

FEATURES:

• 5-1/4" IMPP Composite Cone Woofer

• 1-1/8" Horn Midrange

• 3/4" Horn Tweeter

• Top-Mounting Bracket

SPECIFICATIONS:

• 60 Watts Max. Music Power (20 Watts

Nominal)

• Frequency Response: 75Hz - 20kHz

• Sensitivity: 89dB

• 4ΩRated

Surface-Mount 3-Way Speaker

TS-X200

FEATURES:

• 4" IMPP Composite Cone Woofer

• 2-1/4" Cone Midrange

• 3/4" Horn Tweeter

• Top-Mounting Bracket

• Bass-Reflex Cabinet

SPECIFICATIONS:

• 80 Watts Max. Music Power (20 Watts

Nominal)

• Frequency Response: 65Hz - 30kHz

• Sensitivity: 89dB

• 4ΩRated

Surface-Mount 3-Way Speaker

NEW FOR 2005

260W MAX.

NEW FOR 2005

220W MAX.

160W MAX. 160W MAX.

130W MAX.

120W MAX. 150W MAX. 120W MAX.

100W MAX. 100W MAX. 100W MAX.

60W MAX. 40W MAX. 80W MAX. 60W MAX.

Foamed PPC

PPC (or Pearl Poly-Carbon to us

engineers) is a lightweight material

that delivers high sensitivity, open

sound character and smooth

extended frequency response in

tweeters. Not only that, but it has a

high inner loss that reduces

distortion. It's also blended with

special carbon fiber for UV resistance and protection against the harsh

environment of your car. Think of it as the perfect soundstage for the

crisp highs you demand.

Speaker Specifications located on Page 30. Speaker Specifications located on Page 30.

Nautica Series

To us, “mobile audio” extends out onto water, and our high-grade Nautica Series marine speakers are designed

specifically for this application. They are water- and corrosion-resistant, with magnets that are sealed away from

moisture. Even the parts and terminals are marinized, for long life and great music.

TS-MR2040

FEATURES:

• White Water-Resistant IMPP Cone Woofer

• Water-Resistant Elastomer Surround

• Glass-Imide Voice Coil Bobbin

• Conex Damper

• 3/4" PI (Poly Imide) Reflex Horn Tweeter Design

• High-Quality Corrosion-Resistant Hardware

• Gold-Plated Tinsel Leadwire and Terminals

• Weather-Proof and Heat-Resistant Resin

Nautica®Series

8" Marine-Use 2-Way Speaker

TS-MR1640

FEATURES:

• White Water-Resistant IMPP Cone Woofer

• Water-Resistant Elastomer Surround

• Glass-Imide Voice Coil Bobbin

• Conex Damper

•

1-1/8" PEI (Poly-Ether Imide) Dome Tweeter with Magnetic Fluid and Equalizer

• High-Quality Corrosion-Resistant Hardware

• Gold-Plated Leadwire and Terminals

• Weather-Proof and Heat-Resistant Resin

Nautica®Series

6-1/2" Marine-Use 2-Way Speaker

200W MAX. 160W MAX.

CD-MR70 AD-MR92

FEATURES:

• Fully Weatherproof Cover Designed Exclusively for Marine

Environment

• Exclusive “Vertical Opening Locking Bubble”

• Stainless Steel Mounting Hardware (Included)

Nautica®Series Waterproof Marine Stereo Cover

FEATURES:

• Compatible with all Pioneer Wired Remote Ready Headunits

• Weatherproof Sealed Design

• Mini Plug Cable Supplied (7m Length)

• Dimensions (W x H x D): 4" x 2-5/8" x 1-13/16" (102 x 67 x 46mm)

Wired Marine Remote Control

TS-MR1600

FEATURES:

• White Water-Resistant IMPP Cone Woofer

• Water-Resistant Elastomer Surround

• Glass-Imide Voice Coil Bobbin

• Conex Damper

• High-Quality Corrosion-Resistant Hardware

• Gold-Plated Tinsel Leadwire and Terminals

• Weather-Proof and Heat-Resistant Resin

Nautica®Series

6-1/2" Marine-Use Dual-Cone Speaker

100W MAX.

CD-MR80D

FEATURES:

• Compatible with Pioneer 1-DIN CD Receivers*

•

The display indicates channel number, track number, operation status, etc.

• Satellite Radio Tuner Indications**

• ATT (Volume Attenuator) Button

•

Dimensions (W x H x D): 3-7/8" x 2-13/16" x 1-13/16" (98 x 72 x 46mm)

*For details about compatible units and available controls, contact

your dealer or nearest Pioneer Service Center.

**Available in conjunction with DEH-P7700MP, DEH-P6700MP,

DEH-P4700MP, and DEH-P3700MP.

Wired Marine Remote Control

NEW FOR 2005

TS-D691R 6" x 9" 350W (80W) 22Hz - 32kHz 91dB 4Ω3-1/2" (88.8mm) 6" x 8-7/8" (153mm x 225mm)

TS-D681R 6" x 8" 260W (60W) 27Hz - 32kHz 91dB 4Ω2-9/16" (65.5mm) 5-1/4" x 7-1/2" (133mm x 191mm)

TS-D161R 6-1/2" 260W (60W) 27Hz - 32kHz 90dB 4Ω2-5/16" (59mm) 5-1/16" (128mm)

TS-C160R 6-1/2" 250W (60W) 25Hz - 32kHz 90dB 4Ω2-3/8" (60.5mm) 5-1/16" (128mm)†

TS-C130R 5-1/4" 180W (40W) 35Hz - 32kHz 90dB 4Ω2-1/4" (56.5mm) 4-3/4" (121mm)†

TS-A6991R 6" x 9" 460W (80W) 25Hz - 35kHz 93dB 4Ω3-7/16" (87mm) 6" x 8-7/8" (153mm x 225mm)

TS-A6981R 6" x 9" 420W (80W) 25Hz - 33kHz 93dB 4Ω3-3/8" (86mm) 6" x 8-7/8" (153mm x 225mm)

TS-A6971R 6" x 9" 300W (40W) 28Hz - 33kHz 93dB 4Ω2-7/8" (73mm) 6" x 8-7/8" (153mm x 225mm)

TS-A6961R 6" x 9" 230W (40W) 28Hz - 28kHz 93dB 4Ω2-7/8" (73mm) 6" x 8-7/8" (153mm x 225mm)

TS-A6880R 6" x 8" 240W (50W) 30Hz - 30kHz 91dB 4Ω2-1/2" (62mm) 7-1/2" x 5-1/4" (191mm x 133mm)

TS-A6870R 6" x 8" 220W (50W) 30Hz - 28kHz 91dB 4Ω2-1/2" (62mm) 7-1/2" x 5-1/4" (191mm x 133mm)

TS-G6840R 6" x 8" 150W (30W) 35Hz - 22kHz 90dB 4Ω2-3/8" (59mm) 7-1/2" x 5-1/2" (191mm x 139mm)

TS-A5713 5" x 7" 120W (40W) 35Hz - 24kHz 92dB 4Ω2-1/4" (58.5mm) 7-1/4" x 5" (183mm x 126mm)

TS-A1780R 6-3/4" 240W (50W) 28Hz - 30kHz 91dB 4Ω2-1/2" (62.5mm) 5-1/2" (139mm)

TS-A1681R 6-1/2" 260W (50W) 30Hz - 33kHz 91dB 4Ω2-1/4" (57mm) 5-1/16" (128mm)

TS-A1671R 6-1/2" 220W (35W) 30Hz - 33kHz 90dB 4Ω1-3/4" (44mm) 5-1/16" (128mm)

TS-G1640R 6-1/2" 160W (30W) 35Hz - 22kHz 92dB 4Ω1-5/8" (42mm) 5-1/16" (128mm)

TS-A1370R 5-1/4" 160W (35W) 40Hz - 30kHz 91dB 4Ω2-1/16" (53mm) 4-3/4" (121mm)

TS-G1340R 5-1/4" 130W (25W) 40Hz - 22kHz 91dB 4Ω1-7/8" (46mm) 4-3/4" (121mm)

TS-A4103 4" x 10" 120W (35W) 38Hz - 23kHz 91dB 4Ω2-1/2" (64mm) 6-7/8" x 3-3/8" (175mm x 85mm)

TS-P462 4" x 6" 150W (50W)* 70Hz - 32kHz 89dB 4Ω1-5/8" (42mm) 4" x 6" (100mm x 153mm)

80W (20W)** 45Hz - 32kHz**

TS-A4670R 4" x 6" 120W (20W) 45Hz - 30kHz 90dB 4Ω1-3/4" (45mm) 3-3/4" x 6" (95mm x 153mm)

TS-G4640R 4" x 6" 100W (20W) 45Hz - 22kHz 90dB 4Ω1-3/4" (45mm) 4-7/8" x 2-7/8" (123 x 73mm)

TS-A1057 4" 100W (20W) 45Hz - 30kHz 90dB 4Ω1-11/16" (42.8mm) 4" (102mm)

TS-G1040R 4" 100W (20W) 45Hz - 22kHz 90dB 4Ω1-5/8" (43mm) 4-1/8" (106mm)

TS-A878 3-1/2" 60W (15W) 60Hz - 28kHz 88dB 4Ω1-3/8" (36mm) 3" (77mm)

TS-877 3-1/2" 40W (10W) 90Hz - 20kHz 88dB 4Ω1-1/2" (37mm) 3" (77mm)

TS-MR2040 8" 200W (40W) 25Hz - 30kHz 92dB 4Ω2-15/16" (75mm) 7-5/16" (186mm)

TS-MR1640 6-1/2" 160W (30W) 30Hz - 30kHz 91dB 4Ω2-3/16" (56mm) 5-1/8" (130mm)

TS-MR1600 6-1/2" 100W (25W) 30Hz - 20kHz 90dB 4Ω2-3/16" (56mm) 5-1/8" (130mm)

31ACCESSORIES30 NAUTICA

®

SERIES

Max. Music Power

(Nominal) Frequency ResponseSizeSpeakers Sensitivity Impedance Mounting Depth Cut-Out Dimensions

* With 400Hz, -6dB/Oct. HPF; ** Without Crossover †Woofer dimensions

AUDIO VIDEO ACCESSORIES

AD-GA10

Offset Installation Kit

For use with AVIC-N2, AVH-P7600DVD and AVH-P5700DVD.

CD-V61FM

Add-on FM Modulator

Compatible with any 2ch Audio Source.

CD-VS33

Video Switcher

Universal switcher with 3 A/V inputs, 3 video

inputs, 2 headphone outputs with volume

control and independent AV selector.

TS-CX7

Center Channel Speaker

Combine the high quality TS-CX7 with

the AVH-P7600DVD for true surround sound.

NAVIGATIONAL ACCESSORIES

ND-BC1

Universal Rear View Camera

Features include high resolution,

compact size and reversed-image capability.

CD-VC1

Voice Command Pack

Package includes voice recognition mic and steering wheel

remote. For use only with AVIC-N2.

CD-TS37GP

Navigation Guidance Speaker

Optional guidance speaker for use when the AVIC-N2 is con-

nected to a multi-channel processor.

CD-SR11

Steering Remote for Pioneer Navigation Systems

Compatible with AVIC-D1, AVIC-N1, and AVIC-N2.

CD-RV1

Rear Seat Mini Remote

Allows rear seat passenger to control AVIC-N2's

DVD playback functions. For use only with AVIC-N2.

CNDV-50MTP

Touch Panel Navigation Upgrade Discs

Upgrade discs for Pioneer Touch Panel Navigation Systems.

Include database and feature upgrade equivalent to AVIC-N2 and

AVIC-D1 (XM NavTraffic™ capability only available with AVIC-N1).

Compatible with AVIC-N1, and AVIC-88DVD, AVIC-80DVD,

AVIC-90DVD, and AVIC-9DVD when used with Touch Panel Display

only (AVD-W6210, AVH-P7600DVD, AVH-P7500DVD, AVH-P6600DVD,

AVH-P6500DVD, AVH-P5700DVD).

CNDV-40R

Remote Control Navigation Upgrade Discs

Upgrade discs for Pioneer Remote Control Navigation Systems.

Include database and feature upgrade equivalent to AVIC-N1

and AVIC-88DVD. Compatible with AVIC-80DVD, AVIC-90DVD

and AVIC-9DVD when used with Remote Control Displays only

(AVD-W6010, AVH-P6400CD, AVH-P6400, AVX-P7300DVD).

CD-SC300E

Trunk-Mount Extension System Cable (3 meter)

Extension between main unit and the hideaway box.

CD-600DC

Data Communication Cable (6 meter)

For Connecting AVIC-D1/AVIC-N2 with GEX-P10XMT.

CD-TS37GP

Navigation Guidance Speaker

Optional guidance speaker for use when the AVIC-N2 is

connected to a multi-channel processor.

CD-RGB26P

26-Pin RGB Connection Box

Required when connecting the AVIC-880DVD to 20-pin RGB

components.

CD-TS36

Voice Guidance Speaker with IR Sensor for

AVIC-9DVD, AVIC-90DVD, AVIC-80DVD and AVIC-880DVD

For use with Non-Pioneer Displays (CD-RGB26P is also required

for Non-Pioneer Displays.)

AUDIO VIDEO/NAVIGATION CABLES

CD-AB300

AV-Bus Cable (3 meter)

Male-to-Male. For use with AVH-P7600DVD and AVH-P5700DVD

when connecting to XDV-P90.

CD-AB301E

AV-Bus Extension Cable (3 meter)

Female-to-Male Extension Cable. For use with AV products.

CD-AB50

AV-Bus Cable (0.5 meter)

Male-to-Male. For use with AVH-P7600DVD and AVH-P5700DVD

when connecting to XDV-P90.

CD-IP601E

IP-Bus Extension Cable (6 meter)

Female-to-Male Extension Cable. For use with AV products.

CD-RGB31E

20-pin RGB Extension Cable (3 meter)

Female-to-Male RGB Extension Cable. All 20-pin RGB Cables

can be extended with this cable.

REMOTE CONTROL

CD-R5

Remote Control

Required for stand-alone control and functionality when using

AVH-P5700DVD.

CD-R11

Full Function Audio Video and Navi Remote

Necessary when using AVIC-880DVD with non-Pioneer or

non-touch monitors.

CD-R600

Full Function Smart Remote Control

For use with remote ready IP-Bus Headunits and

AVM-P7000R. (No Video Control)

CD-R7

DVD Remote with IR Sensor

For use with XDV-P90 when used in stand-alone mode.

CD-R99

DVD/TV Tuner Remote Control

Works with all Pioneer DVD sources. Main use for rear seat

passengers.

CD-SR100

Steering Wheel Remote Control

For use with AVH-P6400CD, AVH-P6400, AVH-P6500DVD,

AVH-P6600DVD, AVM-P7000R, and all IP-Bus source units.

With DVD NAVI Voice Controller.

CELLULAR ACCESSORIES

CD-CM1

Add-on Cellular Mute Kit

For use with all cellular mute compatible headunits.

(Analog phones only)

SPEAKER GRILLES

UD-G306

12" Spoke Grille

For use with TS-W306C, TS-W306DVC and TS-W300R.

UD-G256

10" Spoke Grille

For use with TS-W256C, TS-W256DVC and TS-W250R.

IP-BUS EXTENSION CABLES

CD-IP600

IP-Bus Cable (6 meter)

Male-to-Male Extension Cable.

CD-IP150

IP-Bus Extension Cable (1.5 meter)

Female-to-Male Extension Cable.

MCD MAGAZINES

JD-1212S

12 Disc Magazine

For use with FM and Straight 12 Disc Changers, 1996 to current.

JD-612V

6 Disc Magazine

For use with XDV-P90, FM and Straight 6 Disc Changers, 1996 to

current.

JD-T1212

12 Disc Magazine

For use with FM and Straight 12 Disc Changers, 1995 and earlier.

JD-T612

6 Disc Magazine

For use with FM and Straight 6 Disc Changers, 1995 and earlier.

JD-M3000CEEA

6 Disc Magazine

For use with CDX-M30 only.

AUXILIARY INPUT ADAPTERS

CD-RB20

IP-Bus-to-RCA Adapter

Allows connection of external audio source and MCD player to

IP-Bus headunit.

CD-RB10

IP-Bus-to-RCA Adapter

Allows connection of external audio source to IP-Bus headunit.

NEW FOR 2005

NEW FOR 2005

NEW FOR 2005

NEW FOR 2005

NEW FOR 2005

are registered trademarks of Dolby Laboratories. is

a registered trademark of Digital Theater Systems, Inc. The XM name and

related logos are trademarks of XM Satellite Radio Inc. “Sirius” and

related marks are trademarks of Sirius Satellite Radio Inc.

Pioneer Electronics (USA) Inc. proudly supports and encourages you to

support the Consumer Electronics Association (CEA), Mobile Electronics

Certification Program (MECP) for installers and the Mobile Electronics

Retailers Association (MERA).

PIONEER SERVICE FACILITIES

For the name and address of your nearest service center or for other

service-related information, contact :

The Innovations Design and Engineering Award is based upon descriptive

materials submitted to the judges. CEA did not verify the accuracy of any

submission or of any claims made and did not test the item to which the

award was given.

Pioneer Customer Service Department

Post Office Box 1760 Long Beach, California 90810

Telephone: 1-800-PIONEER

Published 2005 by Pioneer Corporation.

Copyright by Pioneer Corporation and Pioneer Electronics (USA) Inc.

All Rights Reserved.

Note: Specifications and design subject to modification without notice.

Product colors and illumination may differ in photographs from actual

appearance, due to effects of printing and photography.

NEW FOR 2005

NEW FOR 2005
