(A2LA Cert. No. 2955.11) 01/05/2018 Page 1 of 12
SCOPE OF ACCREDITATION TO ISO/IEC 17025:2005
TUV SUD AMERICA INC.1
1775 Old Highway 8 NW, Suite 104
New Brighton, MN 55112
Mr. Barry Quinlan bquinlan@tuvam.com
Phone: 978-573-2528
ELECTRICAL
Valid To: September 30, 2019 Certificate Number: 2955.11
In recognition of the successful completion of the A2LA evaluation process, accreditation is granted to
this laboratory at the location listed above, as well as the satellite laboratory location listed below, to
perform the following EMC (electromagnetic compatibility) and Telecommunications tests:
Test Technology:
Test Method(s) 2,3:
Emissions
Conducted FCC 47 CFR, Part 15, Subpart B (using ANSI C63.4:2014);
ANSI C63.4:2014;
CISPR 14-1 (2005+A1:2008+A2:2011, 2016+C1:2016);
EN 55014-1 (2006+A1:2009+A2:2011, 2017); KN 14-1;
AS/NZS CISPR 14.1 (2013); SANS 214-1:2009;
CISPR 22 (2005, 2008); EN 55022 (2010+AC:2011, 2014);
AS/NZS CISPR 22 (2009+A1:2010);
VCCI-V3; CNS 13438 (2006) (up to 6 GHz); KN 22;
TCVN 7189:2009 (CISPR 22:2006); SANS 222:2009;
CISPR 32/AC:2013, 2015; EN55032/AC:2013, 2015; KN 32;
AS/NZS CISPR 32 (2013, 2015); VCCI-CISPR 32:2016;
CISPR 11 (2009+A1:2010, 2016); SANS 211:2010;
EN 55011 (2009+A1:2010, 2016+A1:2017);
KN 11; AS/NZS CISPR 11 (2011)
Radiated & Conducted
(ESA only)
CISPR 25 (2002, 2008+C1:2009, 2016);
EN 55025
Automotive
(excluding complete vehicle
tests)
EN 12895 (2000, 2015); EN 13309 (2010);
ISO 13766 (2006); ISO 14982 (1998, 2009);
ISO 7637-1 (2002+A1:2008, 2015);
ISO 7637-2 (1990, 2004, 2008, 2011);
ISO 7637-3 (1995, 2007, 2016);
EN 50498 (2010);
ANSI/ASAE EP455 (section 5.16);
97/24/EC; 2015/208/EC;
UN ECE R10.04; UN ECE R10.05; KN 41;
SAE J1113-41 (2006); SAE J1113-42 (2006, 2010);
SAE J1455 (2006, 2011, 2012, 2017);
(A2LA Cert. No. 2955.11) 01/05/2018 Page 2 of 12
Test Technology:
Test Method(s) 2,3:
Emissions (cont.)
Automotive (cont.)
(excluding complete vehicle
tests)
JDQ 53.3 (sections 8 & 9); JDQ 202; JDQ 203;
CLAAS CN 050215;
Harley Davidson EG812-22613;
Harley Davidson EG812-22614;
NHTSA-2013-0058 (section D test, RFI/EMI Tests);
CSTT-HVC-TR-114, CSTT-HVC-TR-150, CSA Z627-16;
EN 50436-1; Volvo STD 515-0003;
CAT EC-42;
Daimler MBN 10284-4;
PACCAR CPP0191; PACCAR CPP0193
Avionic RTCA/DO-160D (section 21);
RTCA/DO-160E (sections 21.3 & 21.4);
RTCA/DO-160F (sections 21.4 & 21.5);
RTCA/DO-160G (sections 21.4 & 21.5);
Boeing D6-16050-4; Boeing D6-16050-5;
Boeing 787B3-0147
Harmonics IEC/EN 61000-3-2; IEC/EN 61000-3-12;
SANS 61000-3-2:2009
Voltage Flicker / Fluctuations IEC/EN 61000-3-3; IEC/EN 61000-3-11;
SANS 61000-3-3:2009
Immunity
ESD IEC 61000-4-2 (2008); EN 61000-4-2; KN 61000-4-2;
SANS 61000-4-2:2009
Radiated Immunity IEC 61000-4-3 (2006+A1:2007+A2:2010);
EN 61000-4-3; KN 61000-4-3; SANS 61000-4-3:2008
EFT/Burst IEC 61000-4-4 (2004+A1:2010, 2012);
EN 61000-4-4; KN 61000-4-4; SANS 61000-4-4:2011
Surge IEC 61000-4-5 (2005+AC:2009, 2014+A1:2017, 2017);
EN 61000-4-5; KN 61000-4-5; SANS 61000-4-5:2006
Conducted Immunity IEC 61000-4-6 (2008, 2013+AC:2015);
EN 61000-4-6; KN 61000-4-6; SANS 61000-4-6:2008
Magnetic Field Immunity IEC 61000-4-8 (2009);
EN 61000-4-8; KN 61000-4-8; SANS 61000-4-8:2009
Pulse Magnetic Field
Immunity IEC 61000-4-9 (2001, 2016);
EN 61000-4-9; KN 61000-4-9
Damped Oscillatory
Magnetic Field Immunity
IEC 61000-4-10; EN 61000-4-10
Voltage Dips, Shorts, Variations IEC 61000-4-11 (2004+A1:2017, 2017);
EN 61000-4-11; KN 61000-4-11; SANS 61000-4-11:2004
(A2LA Cert. No. 2955.11) 01/05/2018 Page 3 of 12
Test Technology:
Test Method(s) 2,3:
Immunity (cont.)
Ring Wave Immunity
IEC 61000-4-12 (2006); EN 61000-4-12
Harmonics and Interharmonics
IEC 61000-4-13; EN 61000-4-13
Voltage Fluctuation Immunity
IEC 61000-4-14; EN 61000-4-14
Common Mode Disturbance –
Conducted Immunity from
0 to 150 kHz
IEC 61000-4-16 (2011); EN 61000-4-16
Ripple on D.C Input Ports
Immunity
IEC 61000-4-17; EN 61000-4-17
Damped Oscillatory Wave IEC 61000-4-18; EN 61000-4-18
Power Frequency Variation
Immunity IEC 61000-4-28; EN 61000-4-28
Voltage Dips, Shorts,
Variations on D.C. Input Ports IEC 61000-4-29; EN 61000-4-29
Automotive
ISO 10605 (2001, 2008+AC:2010+A1:2014);
ISO 11452-1 (2005+A1:2008; 2015); ISO 11452-2 (2004);
ISO 11452-4 (2005, 2011); ISO 11452-5 (2002);
ISO 11452-7 (2003+A1:2013); ISO 11452-8 (2007, 2015);
ISO 11452-10;
ISO 16750-1; ISO 16750-2;
EN 12895 (2000, 2015);
EN 13309 (2010);
ISO 13766 (2006);
ISO 14982 (1998, 2009); EN ISO 14982 (2009);
ISO 7637-1 (2002+A1:2008, 2015);
ISO 7637-2 (1990, 2004+A1:2008, 2011);
ISO 7637-3 (1995, 2007, 2016);
EN 50498 (2010);
SAE J1113-1 (2006, 2012, 2013) (excluding aircraft);
SAE J1113-2 (2004, 2010) (excluding aircraft);
SAE J1113-3 (2006, 2010); SAE J1113-4 (2004, 2014);
SAE J1113-11 (2006, 2007, 2012);
SAE J1113-12 (2006); SAE J1113-13 (2004, 2015);
SAE J1113-21 (2005, 2013); SAE J1113-22 (2003, 2010);
SAE J1113-26; SAE J1113-41 (2006);
SAE J1113-42 (2006, 2010);
SAE J1455 (2006, 2011, 2012, 2017);
ANSI/ASAE EP455 (sections 5.10, 5.11, 5.12, & 5.16);
97/24/EC; 2015/208/EC;
UN ECE R10.04; UN ECE R10.05; KN 41;
JDQ 53.3 (sections 8 & 9); JDQ 202; JDQ 203;
CLAAS CN 050215;
Harley Davidson EG812-22613;
Harley Davidson EG812-22614;
(A2LA Cert. No. 2955.11) 01/05/2018 Page 4 of 12
Test Technology:
Test Method(s) 2,3:
Immunity (cont.)
Automotive
NHTSA-2013-0058 (section D test RFI/EMI Tests);
CSTT-HVC-TR-114; CSTT-HVC-TR-150; CSA Z627-16;
EN 50436-1;
Volvo STD 515-0003;
CAT EC-42;
Daimler MBN 10284-4;
PACCAR CPP0016; PACCAR CPP0190;
PACCAR CS0013; PACCAR CTS0019
Medical AAMI Pacemaker Standard: Labelling Requirements,
Performance Requirements, and Terminology for Implantable
Artificial Cardiac Pacemakers, August 1975
(FDA Contract No. 223-74-5083);
EMCU_W09.30E; EMCU_W09.31E;
EMCU_W09.32E; EMCU_W09.33E;
EMCU_W09.34E; EMCU_W09.35E
Avionic 4 RTCA/DO-160D (sections 15, 16, 17, 18, 19, 20, 22, & 25);
RTCA/DO-160E (sections 15, 16, 17, 18, 19, 20, 22, & 25);
RTCA/DO-160F (sections 15, 16, 17, 18, 19, 20, 22, & 25);
RTCA/DO-160G (sections 15, 16, 17, 18, 19, 20, 22, & 25);
Boeing D6-16050-4; Boeing D6-16050-5; Boeing 787B3-0147
Generic/Product Family Standards
and Industry Standards
(excluding Radiated Emissions)
IEC 61000-6-1 (2005, 2016); EN 61000-6-1 (2007);
KN 61000-6-1;
IEC 61000-6-2 (2005, 2016); EN 61000-6-2 (2005);
KN 61000-6-2;
IEC 61000-6-3 (2006+A1:2010, 2011);
EN 61000-6-3 (2007/A1:2011/AC:2012); KN 61000-6-3;
AS/NZS 61000.6.3 (2007); AS/NZS 61000.6.3 (2012);
IEC 61000-6-4; EN 61000-6-4;
KN 61000-6-4;
AS/NZS 61000.6.4 (2007); AS/NZS 61000.6.4 (2012);
EN 50130-4 (2011);
EN 55103-2 (2009);
EN 50270 (2006, 2015);
EN 50293 (2012);
IEC 61326-1 (2012);
EN 61326-1 (2013);
IEC/EN 61326-2-1; IEC/EN 61326-2-6;
IEC/EN 60730-1 (sections 23 & 26);
IEC/EN 60730-2-9 (sections 23 & 26);
IEC/EN 60730-2-13 (sections 23 & 26);
IEC/EN 60730-2-14 (sections 23 & 26);
IEC/EN/KN 60601-1-2 (2007+AC:2010);
IEC 60601-1-2 (2014); EN 60601-1-2 (2015);
EN 60601-2-24 (1998, 2015) (section 36);
IEC 61131-2 (2007, 2017) (sections 8 & 9);
EN 61131-2 (2007) (sections 8 & 9);
IEC 60118-13 (2011, 2016);
EN 60118-13 (2011);
EN ISO 11608-1 (section 11);
(A2LA Cert. No. 2955.11) 01/05/2018 Page 5 of 12
Test Technology:
Test Method(s) 2,3:
Generic/Product Family Standards
and Industry Standards (cont.)
(excluding Radiated Emissions)
IEC/EN/KN 60945 (section 10);
EN 55014-2;
CISPR 14-2 (2015); KN 14-2; SANS 214-2:2009;
CISPR 24 (2010+C1:2011+A1:2015, 2015);
EN 55024 (2010+A1:2015); KN 24; SANS 224:2010;
IEC CISPR 35 (2016); KN 35;
EN 50121-1; EN 50121-3-1; EN 50121-3-2;
IEC/EN 60947-1; IEC/EN 60947-2; IEC/EN 60947-4-1;
IEC/EN 60947-4-3; IEC/EN 60947-5-2;
ANSI/AAMI PC69 (2000, 2007) (sections 4.8 & 4.9);
TCVN 7317:2003 (CISPR 24:1997);
ETSI EN 301 489-1; ETSI EN 301 489-3;
ETSI EN 301 489-7; ETSI EN 301 489-17;
ETSI EN 301 489-24; ETSI EN 301 489-27;
ETSI EN 301 489-31;
ANSI C63.19;
ANSI C12.1 (2008, 2014) (section 4.7.3.12.1);
EN 45502-1 (section 27); EN 45502-2-1 (section 27);
EN 45502-2-3 (section 27);
ISO 14708-3 (section 27);
IEC/EN/KN 61800-3;
IEC/EN 60947-4-3;
NEMA TS2 (sections 2.1.6, 2.1.7, & 2.1.8);
KN 301 489-1, -3, -7, -17, -24, -27, -31;
CAN/CSA-C22.2 NO. 60601-1-2:08 (R2014);
CAN/CSA-C22.2 NO. 60601-1-2:16
Collateral Standard: Electromagnetic compatibility
Radio Tests
(RF Conducted Measurements only)
ETSI EN 300 220-3; ETSI EN 300 330-2; ETSI EN 300 440-2;
ETSI EN 300 328 (V1.8.1, V1.9.1, V2.1.1 - excluding
adaptivity testing);
ETSI EN 301 511 (V9.0.2, V12.1.1, V12.5.1 - clauses 4.2.16
and 4.2.17);
ETSI EN 301 839-2 (V1.3.1); ETSI EN 302 195-2 (V1.1.1);
ETSI EN 301 908-1 (V6.2.1, V7.1.1, V11.1.1; clause 4.2.2);
ARIB STD-T66 (V2.1, V3.7);
HKCA 1002, Issue 6; HKCA 1003, Issue 4;
HKCA 1007, Issue 5; HKCA 1008, Issue 4;
HKCA 1033, Issue 7; HKCA 1035, Issue 7;
HKCA 1039, Issue 6; HKCA 1042, Issue 2;
HKCA 1043, Issue 4; HKCA 1044, Issue 1;
HKCA 1048, Issue 2; HKCA 1049, Issue 1;
HKCA 1052, Issue 2; HKCA 1054, Issue 1;
HKCA 1057, Issue 1; HKCA 1061, Issue 1;
IMDA TS LMR, Issue 1, (2016);
IMDA TS SRD, Issue 1, (2016);
IMDA TS CMT, Issue 1 Rev 1 (2017);
IMDA TS UWB, Issue 1, (2016);
IMDA TS WBA, Issue 1, (2016);
LP0002 (2011, 2016);
(A2LA Cert. No. 2955.11) 01/05/2018 Page 6 of 12
Test Technology:
Test Method(s) 2,3:
Radio Tests (cont.)
(RF Conducted Measurements only)
QCVN 11:2010/BTTTT; QCVN 12:2015/BTTTT;
QCVN 13:2010/BTTTT; QCVN 15:2015/BTTTT;
QCVN 18:2014/BTTTT; QCVN 54:2011/BTTTT;
QCVN 55:2011/BTTTT;
PLMN01 (2007, 2012); RTTE01 (2007);
AS/NZS 4268 (2012+A1:2013, 2017);
RSS-210 (Issue 8) (excluding DFS testing);
RSS-210 (Issue 9) (excluding DFS testing);
RSS-GEN; RSS-247;
FCC 47 CFR, Part 15, Subpart C (using ANSI C63.10:2013)
Military
Emissions & Immunity
MIL-STD-462 (methods CE01, CE02, CE03, CE04, CE07,
CS01, CS02, CS06, CS09, RE01, RE02, RS01, RS02,
RS032, RS06);
MIL-STD-462D (methods CE101, CE102, CE106, CS101,
CS109, CS114, CS115, CS116, RE101, RE102, RS101,
RS103);
MIL-STD-461E (methods CE101, CE102, CE106, CS101,
CS103, CS104, CS109, CS114, CS115, CS116, RE101,
RE102, RE103, RS101, RS103);
MIL-STD-461F (methods CE101, CE102, CE106, CS101,
CS103, CS104, CS109, CS114, CS115, CS116, RE101,
RE102, RS101, RS103);
MIL-STD-461G (methods CE101, CE102, CE106, CS101,
CS103, CS104, CS109, CS114, CS115, CS116, CS117,
CS118, RE101, RE102, RS101, RS103);
MIL-STD-1275D
(A2LA Cert. No. 2955.11) 01/05/2018 Page 7 of 12
Test Technology:
Test Method(s) 2,3:
Product Safety Tests 5
EXCLUDED MEASUREMENTS in Product Safety:
Abrasion Resistance Test
Bottom Fire Enclosure (Hot Flaming Oil)
Cathode Ray Tubes
Concentration of Flammable Vapors
CRT Strength
Hand-Transmitted Vibration
High Vacuum Devices
Human Exposure to UV Radiation
Integrated Circuit (IC) Current Limiters
Ionizing Radiation
Laser (including laser diodes)
Light Emitting Diodes (LEDs)
Mandrel Test
Materials Group Classification
Microwave Radiation
Partial Discharge Test
Pressure Vessels
Prevention of Electrostatic Charges
Resistance to Environmental Stress
Softening Temperature (ISO 306)
Tracking Index CTI
Ultrasonic Pressure
UV Radiation
Oscillating Hoop IP Test
Dust Test
Shock and Vibration Test
Oxygen Bomb Test
Altitude Test
Measurement Equipment IEC 61010-1; EN 61010-1; UL 61010-1;
CAN/CSA C22.2 No. 61010-1;
IEC 61010-2-010; EN 61010-2-010; UL 61010-2-010;
CAN/CSA C22.2 No. 61010-2-010;
IEC 61010-2-030; EN 61010-2-030; UL 61010-2-010;
CAN/CSA C22.2 No. 61010-2-030;
IEC 61010-2-081; EN 61010-2-081; UL 61010-2-081;
CAN/CSA C22.2 No. 61010.2.081;
IEC 61010-2-101; EN 61010-2-101; UL 61010-2-101;
CAN/CSA C22.2 No. 61010.2.101
Office Equipment IEC 60950-1; EN 60950-1; UL 60950-1;
CAN/CSA C22.2 No. 60950-1; AS/NZS 60950.1;
IEC 62368-1; EN 62368-1; UL 62368-1;
CAN/CSA C22.2 No. 62368-1
Audio Visual Equipment IEC 60065; EN 60065; UL 60065;
CAN/CSA C22.2 60065; AS/NZS 60065
(A2LA Cert. No. 2955.11) 01/05/2018 Page 8 of 12
Test Technology:
Test Method(s) 2,3:
Product Safety Tests 5 (cont.)
Household Appliances IEC 60335-1; EN 60335-1; UL 60335-1;
CAN/CSA C22.2 No. 60335-1; AS/NZS 60335-1;
IEC 60335-2-3; EN 60335-2-3; UL 60335-2-3;
CAN/CSA-E60335-2-3; AS/NZS 60335-2-3;
IEC 60335-2-8; EN 60335-2-8; UL 60335-2-8;
CAN/CSA-E60335-2-8; AS/NZS 60335-2-8
Medical Equipment
IEC/EN/CSA/AAMI 60601-1 (ed.3.1);
IEC/EN/CSA/AAMI/JIS 60601-1 (ed.3);
IEC/EN/CSA/UL 60601-1 (ed.2);
IEC/EN/CSA/UL 60601-1 (ed.2), Amd.1;
IEC/EN/CSA/UL 60601-1 (ed.2), Amd.2;
IEC/EN/CSA 60601-1-1 (ed.2);
IEC/EN/CSA 60601-1-4 (ed.1);
IEC/EN/CSA 60601-1-4 (ed.1), Amd.1;
IEC/EN/CSA 60601-1-6 (ed.1);
IEC/EN/CSA 60601-1-6 (ed.2);
IEC/EN/CSA 60601-1-6 (ed.3);
IEC/EN/CSA 60601-1-6 (ed.3), Amd.1;
IEC/EN/CSA 60601-1-8 (ed.1), Amd.1;
IEC/EN/CSA 60601-1-8 (ed.2);
IEC/EN/CSA 60601-1-8 (ed.2), Amd.1;
IEC/EN/CSA 60601-1-10 (ed.1)
IEC/EN/CSA 60601-1-10 (ed.1), Amd.1:
IEC/EN/CSA 60601-1-11 (ed.1);
IEC/EN/CSA/AAMI 60601-1-11 (ed.2);
IEC/EN/CSA 60601-1-12 (ed.1);
IEC/EN/CSA 60601-2-10 (ed.2);
IEC/EN/CSA 60601-2-10 (ed.2), Amd.1;
IEC/EN/CSA 60601-2-18 (ed.2);
IEC/EN/CSA 60601-2-18 (ed.2), Amd.1;
IEC/EN/CSA 60601-2-18 (ed.3);
IEC/EN/CSA 60601-2-31 (ed.2);
IEC/EN/CSA 60601-2-31 (ed.2), Amd.1;
IEC/EN/CSA 60601-2-34 (ed.2);
IEC/EN/CSA 60601-2-34 (ed.3);
IEC/EN/CSA/AAMI 62304 (ed.1);
IEC/EN/CSA/AAMI 62366 (ed.1);
IEC/EN/CSA/AAMI 62366 (ed.1), Amd.1
Industry Standards UL 22; UL 73; UL 197; UL 250; UL 291; UL 325; UL 399;
UL 471; UL 499; UL 507; UL 508; UL 508A; UL 508C;
UL 588; UL 751; UL 763; UL 778; UL 859; UL 873; UL 935;
UL 963; UL 979; UL 982; UL 987; UL 998; UL 1004-1;
UL 1004-2; UL 1004-4; UL 1012; UL 1017; UL 1026;
UL 1082; UL 1236;; UL 1278; UL 1310; UL 1431; UL 1450;
UL 1563; UL 1573; UL 1598; UL 1647; UL 1740; UL 1741;
UL 1778; UL 1838; UL 1993; UL 1995; UL 2111; UL 2200;
UL 5085-1; UL 5085-3
(A2LA Cert. No. 2955.11) 01/05/2018 Page 9 of 12
1 This accreditation covers testing performed at the main laboratory listed above, and the satellite
laboratory listed below:
19333 Wild Mountain Road
Taylors Falls, MN 55084
Mr. Barry Quinlan bquinlan@tuvam.com
Phone: 978-573-2528
Test Technology:
Test Method(s) 2,3:
Emissions
Radiated & Conducted
FCC 47 CFR, Part 15, Subpart B (using ANSI C63.4:2014);
ANSI C63.4:2014;
CISPR 22 (2005, 2008); EN 55022 (2010+AC:2011, 2014);
KN 22; AS/NZS CISPR 22 (2009+A1:2010); SANS 222:2009;
VCCI-V3 (up to 6 GHz); CNS 13438 (2006) (up to 6 GHz);
CISPR 32 (2012+AC:2012+AC:2013, 2015);
EN55032 (2012+AC:2012+AC:2013, 2015); KN 32;
AS/NZS CISPR 32 (2013, 2015); VCCI-CISPR 32:2016;
CISPR 14-1 (2005+A1:2008+A2:2011, 2016+C1:2016);
EN 55014-1 (2006+A1:2009+A2:2011, 2017); KN 14-1;
AS/NZS CISPR 14.1 (2013); SANS 214-1;
CISPR 12 (2007+A1:2009); EN 55012 (2007+A1:2009);
AS/NZS CISPR 12 (2013); SANS 212:2009;
TCVN 7189:2009 (CISPR 22:2006);
FCC 47 CFR, Part 18 (using OST-MP:1986);
CISPR 11 (2009+A1:2010, 2016);
EN 55011 (2009+A1:2010, 2016+A1:2017);
KN 11; AS/NZS CISPR 11 (2011); SANS 211:2010;
EN 61326-1 (2013); IEC 61326-1 (2012);
EN 61326-2-1 (2013); IEC 61326-2-1 (2012);
ICES-001 (Issue 4); ICES-002 (Issue 6); ICES-003 (Issue 6)
Harmonics IEC/EN 61000-3-2; IEC/EN 61000-3-12; SANS 61000-3-2:2009
Voltage Flicker / Fluctuations IEC/EN 61000-3-3; IEC/EN 61000-3-11; SANS 61000-3-3:2009
Immunity
ESD IEC 61000-4-2 (2001, 2008); EN 61000-4-2;
KN 61000-4-2; SANS 61000-4-2:2009
Radiated Immunity IEC 61000-4-3 (2002, 2006+A1:2007+A2:2010, 2010);
EN 61000-4-3; KN 61000-4-3; SANS 61000-4-3:2008
EFT/Burst IEC 61000-4-4
(1995+A1:2000+A2:2001, 2004+A1:2010, 2012);
EN 61000-4-4; KN 61000-4-4; SANS 61000-4-4:2011
Surge
IEC 61000-4-5 (2001, 2005+AC:2009, 2014+A1:2017, 2017);
EN 61000-4-5; KN 61000-4-5; SANS 61000-4-5:2006
(A2LA Cert. No. 2955.11) 01/05/2018 Page 10 of 12
Test Technology:
Test Method(s) 2,3:
Immunity (cont.)
Conducted Immunity IEC 61000-4-6 (2003, 2006, 2008, 2013+AC:2015);
EN 61000-4-6; KN 61000-4-6; SANS 61000-4-6:2008
Magnetic Field Immunity IEC 61000-4-8 (2001, 2009); EN 61000-4-8; KN 61000-4-8;
SANS 61000-4-8:2009
Pulse Magnetic Field Immunity IEC 61000-4-9 (2001, 2016); KN 61000-4-9
Voltage Dips, Shorts, Variations IEC 61000-4-11 (2001, 2004+A1:2017, 2017); EN 61000-4-11;
KN 61000-4-11; IEC/EN/KN 61000-4-34;
SANS 61000-4-11:2004
Generic/Product Family Standards
and Industry Standards
IEC 61000-6-1 (2005, 2016); EN 61000-6-1 (2001, 2007);
KN 61000-6-1; AS/NZS 61000.6.1 (2006);
IEC 61000-6-2 (2005, 2016); EN 61000-6-2 (2005);
KN 61000-6-2; AS/NZS 61000.6.2 (2006);
IEC 61000-6-3 (2006+A1:2010, 2011);
EN 61000-6-3 (2007+A1:2011+AC:2012); KN 61000-6-3;
AS/NZS 61000.6.3 (2007); AS/NZS 61000.6.3 (2012);
IEC 61000-6-4; EN 61000-6-4;
KN 61000-6-4;
AS/NZS 61000.6.4 (2007); AS/NZS 61000.6.4 (2012);
EN 50130-4 (2011); EN 55103-2 (2009);
EN 50270 (2006, 2015); EN 50293 (2012);
EN 61326-1 (2013); IEC 61326-1 (2012);
IEC/EN 61326-2-1;
IEC/EN 61326-2-6;
IEC/EN 60730-1 (sections 23 & 26);
IEC/EN 60730-2-9 (sections 23 & 26);
IEC/EN 60730-2-13 (sections 23 & 26);
IEC/EN 60730-2-14 (sections 23 & 26);
IEC/EN/KN 60601-1-2 (2007+AC:2010);
IEC 60601-1-2 (2014); EN 60601-1-2 (2015);
EN 60601-2-24 (1998, 2015) (section 36);
IEC 61131-2 (2007, 2017) (sections 8 & 9);
EN 61131-2 (2007) (sections 8 & 9);
IEC 60118-13 (2005, 2011, 2016); EN 60118-13 (2011);
EN ISO 11608-1 (section 11);
IEC/EN/KN 60945 (section 10);
EN 55014-2;
CISPR 14-2 (2008, 2015); KN 14-2; SANS 214-2:2009;
CISPR 24 (2010+C1:2011+A1:2015, 2015);
EN 55024 (2010+A1:2015); KN 24; SANS 224:2010;
IEC CISPR 35 (2016); KN 35;
EN 50121-1; EN 50121-3-1; EN 50121-3-2;
IEC/EN 60947-1; IEC/EN 60947-2; IEC/EN 60947-4-1;
IEC/EN 60947-4-3; IEC/EN 60947-5-2;
TCVN 7317:2003 (CISPR 24:1997);
ETSI EN 301 489-1; ETSI EN 301 489-3; ETSI EN 301 489-7;
ETSI EN 301 489-17; ETSI EN 301 489-24;
ETSI EN 301 489-27; ETSI EN 301 489-31;
(A2LA Cert. No. 2955.11) 01/05/2018 Page 11 of 12
Test Technology:
Test Method(s) 2,3:
Generic/Product Family Standards
and Industry Standards (cont.)
KN 301 489-1, -3, -7, -17, -24, -27, -31;
CAN/CSA-C22.2 NO. 60601-1-2:08 (R2014);
CAN/CSA-C22.2 NO. 60601-1-2:16
Collateral standard: Electromagnetic compatibility
Automotive ISO 10605 (2001, 2008+AC:2010+A1:2014);
ISO 11451-1; ISO 11451-2; ISO 11451-4;
EN 12895 (2000; 2015);
EN 13309 (2010);
ISO 13766 (2006);
ISO 14982 (2009); EN ISO 14982 (2009);
ISO 7637-1 (2002+A1:2008, 2015);
ISO 7637-2 (1990, 2004+A1:2008, 2011);
97/24/EC; 2015/208/EC; 2009/64/EC;
UN ECE R10.04; UN ECE R10.05; KN 41
Radio Tests
EN 300 220-1; EN 300 220-2; EN 300 220-3-1; EN 300 220-3-2;
EN 300 220-4; EN 300 328 (Limited to RSE); EN 300 330;
EN 300 440; EN 303 417; EN 301 893 (Limited to RSE);
EN 301 839; EN 302 502 (Limited to RSE);
EN 301 908-1 (clause 4.2.2);
EN 301 511 (clauses 4.2.16 and 4.2.17);
ARIB STD-T66 (V2.1, V3.7);
IMDA TS SRD, Issue 1 (2016);
LP0002 (2011, 2016);
AS/NZS 4268 (2012+A1:2013, 2017);
RSS-Gen; RSS-102 (excluding SAR); RSS-210; RSS-216;
RSS-243; RSS-244; RSS-247; RSS-310;
47 CFR, FCC Part 15, Subparts C and E
(using ANSI C63.10:2013);
47 CFR FCC Part 22, 24, 95, 97, and 101
(using ANSI/TIA-603-D; TIA-102.CAAA-D);
ANSI C63.4:2014;
ANSI C63.26:2015
2 When the date, revision or edition of a test method standard is not identified on the scope of
accreditation, the laboratory is expected to be competent in the use of the current version within one year
of the date of publication of the standard test method., per part C., Section 1 of A2LA R101 - General
Requirements- Accreditation of ISO-IEC 17025 Laboratories.
3 The laboratory is only accredited for testing activities outlined within the test methods listed
above. Reference to any other activity within these standards, such as risk management or risk
assessment, does not fall within the laboratory’s accredited capabilities.
4 Laboratory utilizes RADHAZ procedures for high level testing.
5 Field testing services are available for this test and this laboratory meets A2LA R104 – General
Requirements: Accreditation of Field Testing and Field Calibration Laboratories for this test.
(A2LA Cert. No. 2955.11) 01/05/2018 Page 12 of 12
Testing Activities Performed in Support of FCC Declaration of Conformity and Certification in
Accordance with 47 Code of Federal Regulations and FCC KDB 974614, Appendix A, Table A.1 6:
Unintentional Radiators
Part 15B
ANSI C63.4:2014 40000 MHz
Industrial, Scientific, and Medical Equipmen
t
Part 18
FCC MP-5 (February 1986) 40000 MHz
Intentional Radiators
Part 15C
ANSI C63.10:2013 40000 MHz
U-NIII without DFS Intentional Radiators
Part 15E
ANSI C63.10:2013 40000 MHz
General Mobile Radio Services (FCC
Licensed Radio Service Equipment)
Parts 22 (non-cellular), 90 (non-microwave),
95, 97, and 101 (non-microwave)
ANSI/TIA-603-D; TIA-102.CAAA-D 40000 MHz
6 Accreditation does not imply acceptance to the FCC equipment authorization program. Please see the
FCC website (https://apps.fcc.gov/oetcf/eas/) for a listing of FCC approved laboratories.
For the tests to which this accreditation applies, please refer to the laboratory’s Electrical Scope of Accreditation.
Accredited Laboratory
A2LA has accredited
TUV SUD AMERICA INC.
New Brighton, MN
for technical competence in the field of
Electrical Testing
This laboratory is accredited in accordance with the recognized International Standard ISO/IEC 17025:2005
General requirements for the competence of testing and calibration laboratories. This accreditation demonstrates
technical competence for a defined scope and the operation of a laboratory quality management system
(refer to joint ISO-ILAC-IAF Communiqué dated 8 January 2009).
Presented this 5
th
day of January 2018.
_______________________
President and CEO
For the Accreditation Council
Certificate Number 2955.11
Valid to September 30, 2019
