Philips 5000 series
LCD TV with Pixel Plus
HD
37"
Full HD 1080p digital TV
37PFL5604H
Brilliant design, powerful performance.
With superb picture and sound
Experience brilliant performance with a full HD 1080p display. Combined with a powerful
Pixel Plus HD Engine and fantastic invisible sound, this Flat TV will never let you down.
Vivid and razor sharp pictures
• Pixel Plus HD for better details, depth and clarity
• Full HD LCD display, with a 1920 x 1080p resolution
• 28.9 billion colours for brilliant natural images
• Dynamic contrast 50000:1 for incredible rich black details
Pure and lifelike sound
• 2 x 10 W RMS audio power
• Invisible speakers with incredible surround
Easy to connect and enjoy
• USB for fantastic multimedia playback
• 3 HDMI inputs with Easylink for a full HD connection
• PC-input allows you to use your TV as a PC monitor
Ready for digital
• MPEG4 HDTV reception via DVB-T and DVB-C tuner with CI+*
37PFL5604H/12
Highlights
LCD TV with Pixel Plus HD
37" Full HD 1080p digital TV
Pixel Plus HD
Pixel Plus HD is a picture processing
technology that enables viewers to watch
content that is vivid, natural and real. The
result is superbly razor sharp pictures with
incredible details and depth from any HD
source.
Full HD LCD display 1920 x 1080p
The Full HD screen has the widescreen
resolution of 1920 x 1080p. This is the highest
resolution of HD sources for the best possible
picture quality. It is fully future-proof as it
supports 1080p signals from all sources,
including the most recent sources such as Blu-
ray and advanced HD game consoles. The
signal processing is extensively upgraded to
support this much higher signal quality and
resolution. It produces brilliant flicker-free
progressive scan pictures with superb
brightness and colours.
28.9 billion colours
Vibrant and natural images from the most
advanced colour processing. The 3 colour
channels (RGB) are optimised using 10-bit
resolution, a total processing power of 28.9
billion colours. It produces vibrant colours
while retaining excellent sharpness. The
advanced algorithms detect subtle colour
shades and skin tones and process them to give
the most natural colours.
Dynamic contrast ratio 50000:1
You want the LCD flat display with the highest
contrast and most vibrant images. Philips
advanced video processing combined with
unique extreme dimming and backlight-
boosting technology results in vibrant images.
Dynamic Contrast will increase the contrast
with excellent black level and accurate
rendition of dark shades and colours. It gives a
bright, lifelike picture with high contrast and
vibrant colours.
USB (multimedia)
The USB connector allows access to jpeg
photos, MP3 music and video files on most
USB sticks (USB memory-class device). Plug
the USB into the slot on the side of the TV and
access the multimedia content using the easy
on-screen content browser. You can now view
and share your videos, photos and music.
PC input (VGA)
With PC input you can connect your TV to a
computer by a VGA cable and use the TV as a
PC monitor.
Invisible speakers
An invisible sound system that blends perfectly
with the design of the cabinet. The Incredible
Surround allows you to experience total
surround with greater depth and width of
sound. It gives a clear and spacious sound stage
complementary to the rich viewing experience.
MPEG4 DVB-T/C tuner with CI+*
HDTV allows you to watch TV in the best
possible picture and sound quality, without an
additional set-top box. Thanks to the built-in
tuner that supports DVB-Terrestrial and DVB-
Cable signals for both MPEG-2 and MPEG-4
formats, you receive high definition TV
programmes in exceptional quality. Moreover,
with Common Interface Plus (CI+) you benefit
from premium high definition content directly
on your TV.
with
EXT 2
(RGB/CVBS)
EXT 1
(RGB/CVBS)
SPDIF
OUT
AUDIO
VGA
TV ANTENNA
AUDIO IN:
LEFT / RIGHT
HDMI 1 / DVI
HDMI 2 / DVI
VGA
EXT 3 HDMI 2 HDMI 1
OUT
37PFL5604H/12
Specifications
LCD TV with Pixel Plus HD
37" Full HD 1080p digital TV
Picture/Display
• Aspect ratio: Widescreen
• Brightness: 500 cd/m²
• Response time (typical): 5 ms
• Viewing angle: 178º (H)/178º (V)
• Diagonal screen size: 37 inch / 94 cm
• Display screen type: LCD Full HD W-UXGA Act.
matrix
• Panel resolution: 1920 x 1080p
• Picture enhancement: Pixel Plus HD, 3/2 - 2/2
motion pull down, 3D Combfilter, Active Control
+ Light sensor, Colour Enhancement, Colour
Transient Improvement, Digital Noise Reduction,
Dynamic contrast enhancement, Luminance
Transient Improver
• Screen enhancement: Anti-Reflection coated
screen
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60 Hz
800 x 600 60 Hz
1024 x 768 60 Hz
1280 x 1024 60 Hz
1360 x 768 60 Hz
1600 x 1200 60 Hz
1920 x 1080 60 Hz
•Video formats
Resolution Refresh rate
480i 60 Hz
480p 60 Hz
576i 50 Hz
576p 50 Hz
720p 50, 60 Hz
1080i 50, 60 Hz
1080p 24, 50, 60 Hz
1080p 24, 25, 30 Hz
Sound
• Output power (RMS): 2 x 10 W
• Sound Enhancement: Incredible Surround, Treble
and Bass Control
• Sound System: Nicam Stereo
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Sleep Timer
• Connection Enhancement: Easy link
• Ease of Installation: Auto Programme Naming,
Automatic Channel Install (ACI), Automatic
Tuning System (ATS), Autostore, Fine Tuning, PLL
Digital Tuning, Plug and Play
• Ease of Use: Auto Volume Leveller (AVL), Delta
Volume per preset, Programme List, Settings
assistant Wizard, One-stop Home button,
Favourite programme selection
• Electronic Programme Guide: Now + Next EPG,
8-day Electronic Programme Guide*
• Remote Control: TV
• Remote control type: RCPF02E09B
• Screen Format Adjustments: Auto Format, Movie
expand 16:9, Super Zoom, Widescreen
• Teletext: 1000-page Smart Text
• Teletext enhancements: 4 favourite pages
• Smart mode: Game, Cinema, Personal, Energy
saving, Standard, Vivid
Multimedia Applications
• Multimedia connections: USB
• Playback Formats: MP3, LPCM, JPEG Still pictures,
MPEG1, MPEG2, H.264/MPEG-4 AVC
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G,
SECAM D/K, SECAM L/L', DVB COFDM 2K/8K
• Video Playback: NTSC, SECAM, PAL
• DVB: DVB-T MPEG4*, DVB-C MPEG4*
• Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Ext 1 Scart: Audio L/R, CVBS in, RGB
• Ext 2 Scart: Audio L/R, CVBS in, RGB
• Ext 3: YPbPr, Audio L/R in
• Front/Side connections: HDMI v1.3, S-video in,
CVBS in, Audio L/R in, Headphone out, USB 2.0
• Other connections: Audio constant level out, PC
Audio in, PC-In VGA, S/PDIF out (coaxial),
Common Interface
•HDMI 1: HDMI v1.3
•HDMI 2: HDMI v1.3
• EasyLink (HDMI-CEC): One touch play, System
info (menu language), Remote control pass-
through, System audio control, System standby
Power
• Ambient temperature: 5°C to 35°C
• Mains power: 220–240 V, 50 Hz
• Power consumption: 170 W
• Standby power consumption: 0.15 W
Dimensions
•Set dimensions (W x H x D):
927.5 x 587.4 x 99.6 mm
• Set dimensions with stand (W x H x D):
927.5 x 634 x 270 mm
• Weight incl. Packaging: 20.7 kg
• Product weight: 13.5 kg
• Product weight (+stand): 16.7 kg
•Box dimensions (W x H x D):
1139 x 672 x 265 mm
• Colour cabinet: High gloss black deco front with
black cabinet
• VESA wall mount compatible: 200 x 200 mm
Accessories
• Included Accessories: Tabletop swivel stand,
Power cord, Quick start guide, CD-ROM with
software + manual, User Manual, Warranty
certificate, Remote Control, 2 x AAA Batteries
•
Issue date 2009-06-30
Version: 6.10.7
12 NC: 8670 000 49615
EAN: 87 12581 46439 4
© 2009 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
* 8 days EPG, service not available in all countries
* DVB-T, supported in selected countries only
* DVB-C in selected countries and for selected operators only. Most
up to date information is available on the type plate of the TV.
