Class 150 • Outside Screw & Yoke • Flexible Wedge Disc

November 2008

Description Material

Body A216 WCB

Bonnet A216 WCB

Seat Rings Hardfaced

Disc 13% CR Overlay

Stem 410 SS

Packing Graphite

Bonnet Gasket Soft Iron

Back Seat 410 SS

Yoke Sleeve D2 Ni-Resist

Retaining Nut Malleable or Steel

Gland Steel

Gland Flange Steel

Eye Bolt Steel

Eye Bolt Nuts Steel

Pins Steel

Bonnet Studs A193 Gr. B7

Bonnet Nuts A194 Gr. 2H

Handwheel Malleable, Ductile, or Steel

Handwheel Nut Ductile or Steel

I.D. Tags SS

I.D. Pins Steel

Spacer Steel

Grease Fittings Steel

Materials of Construction

Figure 47XU-F

Flanged

Size Range:

2 - 24 inches

Pressure Temperature Rating

Carbon Steel

ASTM A216 Grade WCB

285 psi @ -20°F to 100°F

Industry Standards

Dimensions and Weights

Steel Valves ANSI B16.34

Face-to-Face/End-to-End ANSI B16.10

Flange Dimensions ANSI B16.5

Basic Design API 600

Testing API 598

Acceptance API RP591

Valve Dimensions (inches)

Size Weight (pounds) AB C

Valve Open

2 46 7.00 16.50 8.00

21/270 7.50 18.00 8.00

3 76 8.00 21.00 9.00

4 110 9.00 23.00 10.00

6 175 10.50 31.00 12.00

8 310 11.50 39.00 14.00

10 455 13.00 46.75 16.00

12 650 14.00 55.00 18.00

14 860 15.00 60.50 20.00

16 1120 16.00 68.50 20.00

18 1400 17.00 77.50 23.62

20 2125 18.00 84.00 23.62

24 3120 20.00 99.00 28.35

Cast Steel Gate Valves Figure 47XU-F
