C-TPAT Training Seminar

March 2010

C-TPAT

5 Step Risk Assessment

Process

Guide

C-TPAT Training Seminar

March 2010

Table of Contents

Page

5 Step Risk Assessment Process - Introduction 3

Definition of Terms 4

Security Risk Rating 6

5 Step Risk Assessment Process Overview 8

Attachments

Step 1 - Attachment A 9

Example of Mapping Cargo Flow and Business Partners

Step 2 – Conducting a Threat Assessment

Attachment B Sample Risk Assessment Resource List 10

Attachment C Sample Threat Assessment 12

Step 3 - Attachment D 13

Sample Vulnerability Assessment

Step 4 – Attachment E 19

Sample Risk Assessment Action Plan/Follow-up

Step 5 - Attachment F 20

Documenting Risk Assessment Process

C-TPAT Training Seminar

March 2010

5 Step Risk Assessment Process

Introduction

In order to assist C-TPAT Partners with conducting a risk assessment of their

international supply chain(s) in accordance with C-TPAT minimum security criteria, the

5 Step Risk Assessment Process is recommended.

This reference guide contains some of the basic tools, resources, and examples C-TPAT

partners should consider using when conducting a risk assessment on their international

supply chain(s). The information contained herein is intended to serve as a guide, and is

not “all inclusive” of what should be included in an international supply chain security

risk assessment.

The 5 Step Risk Assessment Process includes:

1. Mapping Cargo Flow and Identifying Business Partners (directly or indirectly

contracted)

2. Conducting a Threat Assessment focusing on: Terrorism, Contraband Smuggling,

Human Smuggling, Organized Crime, and conditions in a country/region which

may foster such threats and rate threat – High, Medium, Low

3. Conducting a Vulnerability Assessment in accordance with C-TPAT Minimum

Security Criteria and rate vulnerability – High, Medium, Low

4. Preparing an Action Plan

5. Documenting How Risk Assessments are Conducted

It is understood that some C-TPAT members may have numerous supply chains which

may present a monumental task when conducting a comprehensive security risk

assessment of their international supply chains. Therefore, it is recommended for

C-TPAT members to identify their “High Risk” supply chains by conducting a threat

assessment at the point of origin/region and where the cargo is routed/transshipped, and

then conduct a comprehensive security vulnerability assessment of those supply chains.

Conversely, if supply chains involve a limited number of business partners or related

business partners, their supply chain security risk assessment may not require such

extensive efforts.

C-TPAT Training Seminar

March 2010

Risk Assessment Process

Definition of Terms

The definition of terms below is intended as a guide when examining the roles of parties

involved in the international supply chain.

Instruments of International Traffic (IIT): Containers, trailers, flatbeds, unit load

devices (ULDs), lift vans, cargo vans, shipping tanks, bins, skids, pallets, caul boards,

cores for textile fabrics, or other specialized containers arriving (loaded or empty) in use

or to be used in the shipment of merchandise in international trade.

International Supply Chain Security: Encompasses securing all of the following

processes from the cargo’s point of origin (factory/farm) until its arrival and distribution

in the United States: Procurement, Production, Packing, Staging/Storing,

Loading/Unloading, Transportation, and Document Preparation.

International Supply Chain Security Risk Assessment: Process of identifying the

security threats, vulnerabilities, and weaknesses throughout the international supply chain

and prescribing corrective actions with follow-up procedures to ensure weaknesses have

been mitigated.

Loading/Unloading: Placing cargo in/on or taking cargo out/off of an IIT, including

containers, trailers, vessels, planes etc.

Mapping Cargo Flow/Parties Involved: Method of identifying all parties involved and

their prospective roles in the following processes throughout the international supply

chain: Procurement, Production, Packing, Staging/Storing, Loading/Unloading, and

Document Preparation of cargo destined for the United States. All partners involved both

directly and indirectly in exportation/movement of the goods from the point of origin to

the importer’s distribution center must be included. Some examples of parties involved

in the international flow of cargo include, but are not limited to, the following:

 factories

 farms

 suppliers

 export packing facilities

 buying/selling agents

 trading companies

 freight forwarders

 non-vessel operated common carriers (NVOCCs)

 inland truck/rail carriers

 warehouse/consolidation/deconsolidation facilities

 feeder vessels

 rail depots

 trailer/container yards

 shipyards

C-TPAT Training Seminar

March 2010

 local drayage companies

 international air/rail/sea/truck carriers

 Customs brokers.

Packing: Encompasses both packing the goods for export into non-reusable containers

and reusable instruments of international traffic (IIT). It includes but is not limited to

placing goods in/on pallets, cartons, cardboard boxes, crates, bins, or other specialized

containers. It also entails bundling, wrapping, shrink-wrapping, and other types of

packaging.

Procurement: Ordering products or services from business partners in the international

supply chain. Raw materials that go into making the exported products are excluded

from this process. These products only pertain to finished cargo/raw material that will be

exported to the United States. Services include indirect procurement methods for goods

shipped to the United States such as buying agents and trading companies.

Production: Making, growing/harvesting, or assembling products to be exported to the

United States.

Risk Rating: Assigning numerical values to threats and vulnerabilities identified during

a supply chain security risk assessment (e.g. 1-Low, 2-Medium, and 3-High).

Staging/Storing: Placing products and/or IITs at a location of “rest” prior to or during

movement to the United States. This includes any warehousing/consolidation/deconsolidation of

goods and/or facilities where goods wait to be loaded onto another transit mode such as a rail

depot or shipyard in the country of origin or other countries the goods may transit through on the

way to the United States.

Supply Chain Security Action Plan: Identifies security weaknesses and vulnerabilities

found during the risk assessment process for a business partner. The plan assigns

responsibility for corrective actions/mitigation strategies (internal and external),

establishes deadlines/timeframes, documents evidence of actions taken, outlines

processes used to verify actions have been taken, and delineates the final outcome.

Transportation: Movement of cargo throughout the international supply chain.

Transporting the goods for export to the United States includes any domestic legs of the

goods’ journey in the country of origin to the Port of Export, from the Port of Export to

any countries that the goods may transit through, to the US Port of Entry, and to the US

domestic distribution center.

C-TPAT Training Seminar

March 2010

Security Risk Rating

Each C-TPAT partner is responsible for establishing its own overall Security Risk Rating

System based on its business model. It is understood that businesses use various

methodologies for rating risk within their international supply chains. However, the

following “Risk Ratings” are recommended when examining security threats and

vulnerabilities within the international supply chain.

Threat Assessment

There are many “Open Sources” which provide information on threats within the

international supply chain. After conducting research, it is recommended to assign a

threat risk rating based on the following.

1 - Low Risk - No recent incidents/intelligence/information

2 - Medium Risk – No recent incidents/some intelligence/information on possible activity

3 - High Risk – Recent incidents and intelligence/information

A Score of 3 in any of the following areas would deem the supply chain “High Risk”

1) Terrorism

2) Contraband Smuggling

3) Human Smuggling

4) Organized Crime

Vulnerability Assessment

One method that may be used to conduct a vulnerability assessment is sending security

surveys to Business Partners who are not eligible or do not participate in the C-TPAT

program. Security surveys should be based on the process performed by the business

partner in the international supply chain (e.g. Procurement, Production, Packing, Storage,

Loading/Unloading, Transportation, and Document Preparation). Questions should ask

the business partner to describe security measures used, and not only be “Yes/No”

questions. The survey should address whether or not a system of checks, balances, and

accountability are in place, particularly in areas of Securing Instruments of International

Traffic, Tracking and Monitoring Cargo, Seal Security, and Business Partner Screening

(sub-contracted).

The following is a recommended risk rating of vulnerabilities for C-TPAT minimum-

security criteria categories: Business Partner Requirements, Securing Instruments of

International Traffic, Procedural Security, Physical Security, Physical Access Controls,

Personnel Security, Security and Threat Awareness Training, and Information

Technology Security.

C-TPAT Training Seminar

March 2010

1 - Low Risk - Meets all applicable Minimum Security Criteria (Musts and Shoulds)

2 - Medium Risk - Meets all applicable “Musts” Minimum Security Criteria, but does not

meet all “Shoulds”

3 - High Risk – Does not meet all “Must” Minimum Security Criteria

For example,

1) If all “Musts” for Procedural Security were met, the risk rating for that category

would be “1-Low risk.”

2) If all “Musts” were met for Procedural Security and “Shoulds” were not met, the

rating would be “2-Medium Risk.”

3) If one “Must” is not met for Procedural Security, then it would be rated a “3-High

Risk,” because a supply chain security measure is only as strong as its weakest

link.

Post Incident Analysis and Risk Rating

Based on a study conducted by the C-TPAT Program in June 2009 on factors which

contributed to Security Breaches, the following data should be taken into consideration

when conducting a Security Vulnerability Assessment.

34% Conveyance Security: Conveyances not inspected

35% Business Partner Requirements: Failure to Screen Business Partners

41% Instruments of International Traffic (containers, trailers, pallets, etc.

not secured/properly inspected prior to loading

44% Seal Controls: Lack of Seal Procedures

53% Transportation Monitoring: Inadequate Transportation Monitoring

68% Security Procedures not followed (lack of checks, balances, accountability)

90% - Involved “trucks” as the mode of transportation for breached cargo

5 Step Risk Assessment Process

Step Process Description Methods Resources

1 Map Cargo Flow and

Business Partners

Identify ALL parties involved in the following

processes:

1) Procurement

2) Production

3) Packing

4) Storage

5) Loading/Unloading

6) Transportation

7) Document Preparation

1) Request information from supply chain partners

2) Review documentation (BOLs, manifests,

invoices, etc.) to determine routing

3) On site visits/audits of the supply chain

See Attachment A:

Example of Mapping Cargo Flow,

Identifying Business Partners, and

Processes

2 Conduct Threat Assessment

Identify and rate the risk of threat (High, Medium,

Low) for the country and region for each

international supply chain, using the following (at a

minimum):

1) Terrorism (political, bio, agro, cyber)

2) Contraband Smuggling

3) Human Smuggling

4) Organized Crime

5) Conditions fostering above threats

1) Open source internet information (government

and private organizations)

2) Representative/Contacts “on the ground” at

origin

3) Law enforcement (foreign/domestic), local state,

federal/national

4) Trade and security organizations

5) Assigned C-TPAT SCSS

See Attachments B:

Threat Assessment Resource List

Attachment C:

Threat Assessment Example

3 Conduct Vulnerability

Assessment

For all business partners in the international supply

chain (directly contracted or sub-contracted):

1) Identify the process they perform

2) Verify partners meet applicable minimum

security criteria

3) Rate their compliance within each

applicable minimum-security criteria

category (High, Medium, Low)

1) SVI Number/C-TPAT Membership

2) Membership in “Mutual Recognition Program”

3) Security Surveys

4) Site visits by company representative

5) Site visits by overseas personnel/agents

6) Business reports

7) Security certifications covering C-TPAT

minimum-security criteria

8) 3rd party supply chain security assessments

See Attachment D:

Vulnerability Assessment

Using C-TPAT

Minimum-Security Criteria

4 Prepare Action Plan

Establish a corrective action plan to address gaps or

vulnerabilities found in business partner’s security

programs.

1) Word Document

2) Excel Spreadsheet

3) Project Management Software

See Attachment E:

Action Plan and Follow-Up

5 Document How Risk

Assessments are Conducted

A description of the company’s approach, policies,

and procedures for conducting an international

supply chain security risk assessment.

1) Document company’s Policy for conducting

International Supply Chain Security Risk

Assessment

2) Document Procedures used to conduct

International Supply Chain Security Risk

Assessments

See Attachment F – Documenting

Risk Assessment Process, Policies,

and Procedures

Attachment A - Example of Cargo Flow and Partners - Ocean Cargo - LCL

Step 1 - Sample - Map Cargo Flow, Identify Partners, and Processes

Notes: Ensure partners map out all variations of a supply chain - For example, FCL vs. LCL; From one factory to various ports of export; From one factory using different modes of

transportation (Air vs. Sea); Any other potential variations that would alter the movement of cargo or the individuals involved in the process. Always remember - "Freight at Rest is

Freight at Risk".

Sub-contracting increases risk within a supply chain, particularly where security requirements have not been conveyed or verified.

Partner

Process

Cargo Movement - if applicable

Known Details About Provider

Days Cargo

is "At

Rest" at

this stage

Transport

Mode

If entity physically

handles cargo, who

selects them as a

provider?

XYZ Manufacturer Production, Packing,

Document Preparation Point of Departure Location: City 123, Country Origin; Years doing

business with - 22; Family Owned and Operated 0 N/A

Export Broker/FF Prepares Documentation

for Export N/A Unknown NA N/A

Foreign Inland

Carrier ABC Inland Transporation Picks up cargo from factory and

Consolidator EFG

Location: City 123, Country Origin; Contracted by

factory -

in Business 22 years; Parent Company

C-TPAT in USA

0 Truck

Consolidator

LMNOP

Unloading, Storage,

Unloads cargo from inland truck carrier,

stores LCL, loads with other customers'

cargo

Location City 123, Country Origin; Contracted by

factory - in business 2 years 2 N/A

Inland Carrier JKL Inland Transporation Picks up cargo from consolidator and

transports to Port of Export

Location: City 123, Country Origin; Contracted by

factory; in business 22 years; Parent Company

C-TPAT in USA

0 Truck

Port Terminal -

Origin Storage Receives and stores container in container

yard until ready to go on vessel

Location: City 456, Country Origin; operated by

government body; MTSA/ISPS Compliant 4 N/A

Sea Carrier Transportation Transports cargo from port of lading

Location: City 456; Country Origin;

Parent Company C-TPAT in USA 3 Vessel

Port Terminal -

Transit Country Storage Receives offloaded container at country of

transshipment

Location: City 183, Transit Country; unknown;

Unknown MTSA/ISPS Compliant 10 N/A

Sea Carrier Transportation Transports cargo from country of

transshipment Location: City, New Country; unknown 10 Vessel

Port Terminal - USA Storage Unloads cargo from Sea Carrier's vessel

and stores until domestic transport picks up Location: City 42, USA ; MTSA/ISPS Compliant 2 N/A

Domestic Drayage

Carrier Picks up Transportation Picks up cargo from terminal Unknown 0 Truck

Consolidator/

Deconsolidator

Unloading, Storage,

Receives LCL Cargo, consolidates, ships to

destination Location: City 42, USA - Cross dock facility 1 N/A

Long Haul Carrier Transportation Transports cargo to distribution center Location: City, USA - Unknown 0 Truck

U.S. Distribution

Center/Consignee Unloading Receives cargo Location: City 53, USA 2 N/A

Attachment B

RISK ASSESSMENT RESOURCE LIST*

Customs & Border Protection: www.cbp.gov

CIA – The World Fact Book:

https://www.cia.gov/library/publications/the-world-

factbook/

Information Technology Security: http://www.us-cert.gov/nav//nt01/

Federal Trade Commission – Identity Theft/Data Breach:

http://www.ftc.gov/bcp/edu/microsites/idtheft/

Licensed Freight Forwarders/NVOCC/OTI/Terminal Operators:

http://www.fmc.gov/

U.S. Department of State - Terrorist Threats/Country Information:

http://travel.state.gov/travel/cis_pa_tw/pa/pa_1161.html

Federal Motor Carrier Safety Administration – Check Carriers:

http://www.fmcsa.dot.gov/safety-security/safety-security.htm

Manufacturer Seal Requirements – U.S./Mexico FAST:

http://www.customs.gov/xp/cgov/trade/cargo_security/ctpat/fast/us_mexico/mexico_

manuf/manuf_seal_requirements.xml

Global Security Newswire is now available: http://gsn.nti.org/gsn/

7 Signs of Terrorism: http://www.homelandresponder.org/pages/7signs.html

State Dept. Overseas Security Advisory Council: www.osac.gov

National Cargo Security Association:

www.tncsa.org

FBI Infrastructure Security: www.infragard.net

International Chamber of Commerce:

www.icc-ccs.org

Cargo Security Alliance: www.securecargo.org

U.S. Department of Commerce: www.commerce.gov

International Maritime Organization:

www.imo.org

Department of Transportation:

www.phmsa.dot.gov

ASIS International: www.asisonline.org

World Bank:

Web.worldbank.org

Transported Asset Protection Association: www.tapaonline.org

Business Alliance for Secure Commerce:

www.wbasco.org

Department of Homeland Security Crisis Management Planning:

www.ready.gov

Information Systems Audit and Control Association:

www.isaca.org

Department of Homeland Security:

www.dhs.gov

International Container Owners Association:

www.containerownersassociation.org

U.S. Postal Service:

www.usps.com/communications/news/security/mailcenter

Supply Chain Information Sharing and Analysis:

https://secure.sc-investigate.net/SC-ISAC/

*Note: C-TPAT partners should also consult with local law enforcement when

conducting threat assessments. In addition, there are many private for profit

organizations who offer security risk assessment services.

This list is not all inclusive and is not meant to be an endorsement of any organization

or service.

Attachment C

Step 2: Sample Threat Assessment

1 - Low Risk - No recent activity/intelligence/information

2 - Medium Risk – No recent incidents/some intelligence/information on possible activity

3 - High Risk – Recent incidents and intelligence/information

Note: For C-TPAT Purposes a "3" for any of the Threat Risk Factors below would result in a "High Risk" rating for the supply chain

Partner: Factory-Supplier ABC

Location: Country X, Y, Z

Region: Region J-K

Threat Risk Factor

Risk Rating:

1-Low - - NA/No

Medium

3-High –

Incidents/Information

Activity

Source

Terrorism (Political, Bio, Agro, Cyber) 3

2009, 2010 - Recent domestic bombings

and violence against U.S. based interests

Name of news publication, government site, open

source information, intel service, etc.

Contraband Smuggling

2005-Present - location known for

narcotics exports and weapons smuggling

Name of news publication, government site, open

source information, intel service, etc.

Human Smuggling

2000-2005 - numerous incidents of

human smuggling; none since 2005

Name of news publication, government site, open

source information, intel service, etc.

Organized Crime 1

1998-2003 - Drug cartels operating

throughout country/ region

Name of news publication, government site, open

source information, intel service, etc.

Conditions within a country which may foster any

of the aforementioned threats (e.g. poverty, social

unrest, political instability).

Demographics - 35% population lives in

poverty; a few social movements

underway with anti-western sentiments

Name of news publication, government site, open

source information, intel service, etc.

Other: Theft, Pilferage, Hijacking, Piracy, IPR,

Piracy 2

2007 – Incidents of piracy along shipping

route; none reported since late 2007

Name of news publication, government site, open

source information, intel service, etc.

Overall Threat Risk Rating = 3

Vulnerability Assessment

Attachment D

Partner Name: Supply Chain Process: Transportation

Security Point Of Contact: Phone Number: E-mail Address:

Country Location: Region: Instruments of International Traffic Used:

Sample Risk Ratings: 1 - Low Meets/Exceeds all Minimum Security Criteria (MSC - Musts and Shoulds) 2-Medium Meets "Musts" not all "Shoulds" 3 - Does not meet all "Musts" criteria N/A - Not applicable. Note:

If a "Must" criterion is not met in a category, the score for the entire category should be "3".

Processes/Roles Performed (including responsibility for sub-contracting) - Note: 1 business partner may perform multiple roles: For example, the factory may not only produce, but they may pack, load, and transport

cargo. The key is to ensure that each process is secured in the supply chain.

Effective Security System = Meeting all MSC + Oversight + Accountability + Checks and Balances

Supply Chain Process

C-TPAT Security

Criteria -

Determine as

applicable to

process

C-TPAT Sub-Criteria

(Note-Some applicable sub-

criteria may not be listed -

must be tailored for each

supply chain)

M-

ust

S-

Should

Method to Verify

Adherence

Vulnerabilities

Identified

Sub-

Table Of Contents Point 5 System C.5 5Step Risk Assessment Process

Navigation menu

Versions of this User Manual:

Views

Navigation
