Total Access 1424S-CE/1448S-CE

Carrier Ethernet Network Termination and Aggregation

Product Features

■ 24/48-port EFM bonded

e.SHDSL

■ Up to 125/250 Mbps of resilient

Carrier Ethernet service

■ Certified MEF9, 14 Traffic

Management Compliant

■ 1 RMU stackable

with wallmount or

rackmount options

■ Rapid deployment via

AOE ServiceDesigner,

ServiceActivator tools

■ Standards based

OAM supported

■ Monitoring, fault detection,

and loopback functions

■ TScan™ advanced

loop diagnostics

■ Flexible Bandwidth

management

■ Performance monitoring

with threshold alarms

■ Configurable Queuing for

CoS support

■ Command Line Interface (CLI)

■ Traffic storm protection to

prevent service interruptions

due to broadcast, multicast,

unicast or L2CP traffic

■ Small Form-factor Pluggable

(SFP) 1000Base-X Ethernet

■ Autosensing 10/100 Base-T

Ethernet connections

■ Industry-leading warranty

Ethernet is the undisputed, global choice for

Metro Access Networks (MANs) and Local

Access Networks (LANs). However, existing

copper access networks do not facilitate an

end-to-end high-bandwidth connection,

creating a bottleneck. This bottleneck is the

first mile of access. This refers to the access

link (most often a TDM-based copper circuit)

from the business customer’s office LAN

to their service provider’s MAN. ADTRAN®

affords service providers the ability to remove

this bottleneck through the utilization of an

improved data transmission standard. This

standard, ITU-T G.998.2, is known as Ethernet

in the First Mile (EFM). ADTRAN EFM over

Copper (EoCu) defines a way to effectively and

universally bond together, lower bandwidth

copper loops or pairs of wires creating

a Carrier Ethernet access connection.

The solution is an alternative to costly

fibre and microwave build-outs or expensive

SONET/SDH access tariffs by leveraging

existing infrastructure which speeds the

deployment time of the most sought after

Ethernet service segment (100 Mbps). In

addition, IT applications from email to

streaming video have access connections

trending to a downstream dominant usage

pattern. High-Performance Ethernet is opti-

mised for delivering high-capacity downstream

bandwidth over an extended service reach to

better align with the traffic demands associ-

ated with cloud computing as well as 4G

mobile and DSLAM infrastructure backhaul.

Quality of Service Flexibility and Assurance

The NetVanta 800 Series deliver packet flow

capabilities certified compliant per the

Metro Ethernet Forum. These packet flow

capabilities offer the traffic classification and

bandwidth profiling capabilities required

to offer customers a flexible, tiered service

offer. In addition to this highly configurable,

granular bandwidth selection toolset enabling

Quality of Service (QoS) options, these same

network termination points support the stan-

dards-based measurement and monitoring

capabilities required to maintain a carrier-

grade Ethernet network. All of this allows

providers to create and meet customer

SLA agreements.

Reliable Service Connection Mechanisms

In the event a single loop fails, the NetVanta

800 offers resiliency, maintaining traffic over

the remaining active loops in order to main-

tain service. Once the failed loop is operational

again, the NetVanta will automatically detect

its availability and return the loop to the

bonded group, providing the original provi-

sioned customer bandwidth. When deployed

through the Total Access 5000, these NTUs

tap into an unparalleled array of copper loop

diagnostic tools that afford an even greater

service assurance level.

Simplified Service Delivery

In order to improve service time to market

and reduce deployment costs, the NetVanta

800 Series delivers a feature set designed to

simplify service deployment and mainte-

nance. ADTRAN Total Access EMS employs

EZ-Ethernet Provisioning, minimizing the

number of steps to provision a new service.

The EIA-232 craft port enables local access

for configuration and status information.

A management VLAN is used to remotely

configure and collect status information.

Specifications subject to change

without notice. ADTRAN and Total Access

are registered trademarks of ADTRAN, Inc.

All registered trademarks and trademarks

mentioned in this publication are the

property of their respective owners.

Total Access 1424S-CE/1448S-CE

100 Mbps Ethernet services over Copper

Product Specifications

Physical Interface

■ Network Interface: e.SHDSL – RJ21

■ Customer: Four autosensing

10/100/1000Base-T Ethernet

 •RJ-45

 •AutoMDI/MDIX

 •Auto-Rate

 •Auto-Duplex

■ Gigabit Ethernet Interface (Quantity 5)

 •Interface Type: 1000 Base-X

 •Connector: Single SFP

 •Compliance: 802.3, 802.1D, 802.1Q

■ Management: Console port

 •DB-9

 •EIA-232

Diagnostic LEDs

■ Power/Alarm LED

■ SHDSL loop status for each loop

■ Ethernet LED

Features

■ Software selectable for LTU or NTU mode

of operation

■ E-Line support

■ Mini jumbo frame support (2,000 Bytes)

■ Efficient EFM bonding

■ Q in Q

■ Flexible bandwidth profiles for rate limiting

■ Traffic classification options include CE-VLAN,

port, p-bit, DSCP

■ SNMP support

Standards Compliant

■ ITU-T Y.1731 performance monitoring

■ IEEE 802.1ag fault management

■ IEEE 802.1p priority marking

■ IEEE 802.1d dynamic/transparent bridging

■ IEEE 802.1q VLAN tagging

■ IEEE 802.3 ah EFM standard

■ IEEE 802.3u Ethernet

■ MEF 9,14

Management & Administration

■ Craft interface (local, EIA-232)

■ Remote firmware upgrades

■ Local: YMODEM through craft port

■ Remote: Managed through Total Access 5000

■ Flow through provisioning via ADTRAN’s

Advanced Operational Environment (AOE)

■ Supports OAM management status and

loopback messaging

■ Configuration script download

■ Three auxiliary alarm inputs

■ Three alarm relay outputs

Environment

■ Operating Temperature: -40 C to +65 C (32 to 122 F)

■ Storage Temperature: -40 C to + 85 C (-4 to 158 F)

■ Relative Humidity: Up to 95%, noncondensing

Physical

■ Dimensions: 44 mm (1.7 in.) H, 437 mm

(17.2 in.) W, 254 mm (10.0 in.) D

■ Weight: 3.4 kg

■ DC Power: -48 VDC

Agency Approvals

■ FCC Part 15 Class A

■ FCC Part 68

■ UL 60950, CAN/CSA C22.2 No. 60950

■ EN 60950, IEC 60950, AS 3260/ AS NZS60950

■ NEBS Level 3

■ S043.2

■ ITU-T K21:2000 Basic

Ordering Information

Equipment Part #

Total Access 1424S-CE 1172656G1

Total Access 1444S-CE 1172657G1

Replacement Fan Module 1179675G1

6117265xG1-8A June 2012
