1 Introduction

1.1 Purpose

This document describes how to configure and operate the Qualcomm® WCNSS host

device driver on the Android platform and the Qualcomm MSM8960/8974 solution.

1.2 Scope

This document is intended for customers who use or who plan to use the WCNSS

solution in their Android phone designs.

1.3 Conventions

Function declarations, function names, type declarations, and code samples appear in a different

font, e.g., .

1.4 References

Reference documents, which may include Qualcomm documents, standards, and resources, are

listed in Table 1-1. Reference documents that are no longer applicable are deleted from this table;

therefore, reference numbers may not be sequential.

Table 1-1 Reference documents and standards

Ref.

Document

Qualcomm

Application Note: Software Glossary for Customers

CL93-V3077-1

WCNSS Android Configuration Guide

80-N8140-1

WCN36X0(A) Training WLAN Tx CLPC Characterization

Using QSPR Tools

80-WL300-25

QCA WCN36x0 WLAN Power Optimization Guide

80-Y0513-3

QCA WCN36x0 Software Architecture

80-Y0513-1

Standards

Part 11: Wireless LAN Medium Access Control (MAC) and

Physical Layer (PHY) Specifications Amendment 4:

Enhancements for Higher Throughput

IEEE P802.11n/D7.0, Sep 2008

Codes for the Representation of Names of Countries and

Their Subdivisions – Part 1: Country Codes

ISO/IEC 3166-1

WCNSS Android Parameters Configuration Guide Introduction

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 6

Confidential and Proprietary – Qualcomm Atheros, Inc.

1.5 Technical assistance

For assistance or clarification on information in this guide, submit a case to Qualcomm CDMA

Technologies at https://support.cdmatech.com/.

If you do not have access to the CDMATech Support Service website, register for access or send

email to support.cdmatech@qualcomm.com.

1.6 Acronyms

For definitions of terms and abbreviations, see Q1.

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 7

Confidential and Proprietary – Qualcomm Atheros, Inc.

2 System Configuration

2.1 STA

Config. Param.

Description

Min

Max

Default

gTxBFEnable

Enable/disable Tx beam forming

gTxBFCsnValue

Certain TxBF capability APs have an issue: When pronto

advertises the CSN value as 3, it uses the 2 antenna in the

NDPA packet, but is supposed to use the 3 antenna in the NDPA

packet. If the CSN value is advertised as 2, it uses 3 antennas in

the NDPA packet. INI configuration is needed for setting the CSN

value.

gVhtChannelWidth

Channel width for VHT mode:

1 − 20 MHz and 40 MHz

2 – 80 MHz

gVhtRxMCS

VHT Rx MCS values:

Valid values are 0, 1, 2. If commented out, the default value is 0.

0=MCS0-7

1=MCS0-8

2=MCS0-9

gVhtTxMCS

VHT Tx MCS values:

Valid values are 0, 1, 2. If commented out, the default value is 0.

0=MCS0-7

1=MCS0-8

2=MCS0-9

gDisableLDPCWithTxbfAP

Disable the LDPC when the AP is TxBF-capable. This is a

workaround for a throughput issue from the AP test firmware.

gPNOScanSupport

Advertise PNO driver capability:

0 − Disable driver PNO capability

1 − Enable driver PNO capability

gPNOScanTimerRepeatValue

The driver gets only one timer interval, which is hard-coded in the

supplicant for 10000 ms. Until the PNO is disabled, the firmware

repeats the PNO scan every 10 sec.

Taking power consumption into account, 6 timers will be used;

the timer value is increased exponentially, i.e., to 10, 20, 40,

80,160, 320 sec. The number of scan cycles for each timer is

configurable through INI parameter

gPNOScanTimerRepeatValue. If it is set to 0, only one timer will

be used and the PNO scan cycle will be repeated after each

interval specified by the supplicant until PNO is disabled.

0xffffffff

gRoamingTime

CSR roaming enable (1), disable (0)

4294967

gEnableFastRoamIn

Concurrency

Enable legacy fast roaming (LFR) on the STA link during

concurrent sessions.

gRssiFilterPeriod

Increased this value for the non-CCX AP. This is caused by

firmware RSSI monitoring the consumer of this value that is on

by default. To impact power numbers this is set to a high value.

255

gImmediateRoamRssiDiff

RSSI delta to allow STA to immediately roam to a qualified AP

without registering for the reassociation threshold. A value of 0

means to do an immediate roam if any qualified AP is found from

scanning.

125

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 8

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

gSelect5GHzMargin

Prefer connecting to 5G AP even if the RSSI is lower by

gSelect5GHzMargin dBm than 2.4G AP. This feature requires the

dependent cfg.ini gRoamPrefer5GHz to be set to 1

gNeighborScanTimerPeriod

CCX support and fast transition, the time between individual

channels in scan.

300

200

gNeighborLookupThreshold

0 indicates the host is to calculate the adaptive threshold based

on the minimum supported data rate, and the RSSI threshold

triggers a background scan to find potential roam candidates.

120

gNeighborScanChannelMaxTim

Minimum dwell time for scan.

300

gNeighborReassocThreshold

RSSI threshold to trigger roam (this threshold is registered only if

there are candidates found after the scan)→obsolete from

LFR2.0

125

gNeighborScanChannelMinTime

Minimum dwell time for scan.

gMaxNeighborReqTries

Maximum retrial counter for reassociating REQ during roaming.

gNeighborScanRefreshPeriod

Refresh interval between background scans [ms]

1000

60000

20000

gEmptyScanRefreshPeriod

Periodic background scanning interval if no candidate is found

[ms].

60000

gRrmEnable

This flag controls the capabilities (11 k) included in the

capabilities field.

This field controls whether the station supports 11 k.

gRrmOperChanMax

Section 11.10.3 IEEE std. 802.11k-2008 Maxduration =

2^(maxDuration - 4) * bcnIntvl, max duration = 2^-1 * bcnIntvl

(50% of bcn intvl)

gRrmNonOperChanMax

Section 11.10.3 IEEE std. 802.11k-2008 max duration = 2^(max

duration - 4) * bcnIntvl, max duration = 2^-1 * bcnIntvl (50% of

bcn intvl).

gRrmRandnIntvl

If defined, WLAN_FEATURE_VOWIFI.

100

gRoamPrefer5GHz

When both APs (2.4 GHz and 5 GHz) are reported on the same

bucket, 5 GHz is selected first when gRoamPrefer5GHz=1 is set

in the INI file.

gRoamIntraBand

To disable, set gRoamIntraBand=0 (roaming across band, if

defined (WLAN_FEATURE_VOWIFI_11R) || defined

(FEATURE_WLAN_CCX) || defined (FEATURE_WLAN_LFR)/.

To enable, set gRoamIntraBand=1 (roaming within band).

FastTransitionEnabled

This flag controls fast transition in case of 11r and CCX. With this

the whole neighbor roam, pre-authorization, reassociation can be

turned on or off. With this turned off, 11r will not work. For 11r,

this flag has to be on. For CCX, fast roam will not work.

RoamRssiDiff

This parameter is used to decide whether to roam. AP1 is the

currently associated AP and AP2 is chosen for roaming. The

roaming will occur only if AP2 has a better signal quality and it

has an RSSI better than AP1 in terms of RoamRssiDiff and

RoamRssiDiff is the number of units (typically measured in dB),

and AP2 is better than AP1. This check is not done if the value is

zero. Check whether the AP to which you are roaming is better

than current AP in terms of RSSI. Checking is disabled if set to

zero. Otherwise, it will use this value to determine to how much

better the RSSI of the new/roamable AP should be for roaming.

gWESModeEnabled

This parameter is used to set Wireless Extended Security Mode,

if defined as (WLAN_FEATURE_VOWIFI_11R) || defined

(FEATURE_WLAN_CCX) || defined (FEATURE_WLAN_LFR).

gRoamScanNProbes

If defined as (WLAN_FEATURE_VOWIFI_11R) || defined

(FEATURE_WLAN_CCX) || defined (FEATURE_WLAN_LFR).

gRoamScanHomeAwayTime

To determine the time between consecutive channel scans, if

defined as (WLAN_FEATURE_VOWIFI_11R) || defined

(FEATURE_WLAN_CCX) || defined (FEATURE_WLAN_LFR).

300

FastRoamEnabled

Enable/disable legacy (non-CCX, non-802.11r) Fast Roaming

Support.

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 9

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

MAWCEnabled

Enable/disable MAWC (Motion Added Wi-Fi Connectivity)

feature.

gRoamScanOffloadEnabled

Enable/disable Roam Scan Offload.

CcxEnabled

Enable/disable CCX feature.

InfraInactivityInterval

Setting inactivity interval for AddTspec communication

42949672

95UL

ImplicitQosIsEnabled

Enable/disable the driver to initiate ADDTS REQ/RSP to get the

traffic stream admitted to AP in case the phone is trying to

transmit an AC frame that has ACM set by the AP.

gOperatingChannel

IBSS operating channel

gEnforce11dChannel

Whether to limit the channels to the ones set in Csr11dInfo. If

true, the operational channels are limited to the default channel

list. It is an "AND" operation between the default channels and

the channels in the 802.11d IE.

gEnforceCountryCodeMatch

When true, an AP with an unknown country code will not be

seen. "Unknown country code" means either the AP does not

have 11d IE or a domain for the country code in its 11d IE cannot

be found.

gEnforceDefaultDomain

When true, only APs in the default domain can be seen. If the AP

has "unknown country code", or the domain of the country code

doesn't match the default domain, the AP is not acceptable.

gHeartbeat24

The number of beacon misses that the connected AP would

consider as out of range.

65535

gPowerUsage

Determine the profile to use for IMPS sleep time and BMPS listen

interval values.

Min

Max

Mod

gImpsMinSleepTime,

gImpsModSleepTime,

gImpsMaxSleepTime

Sleep time when the device is in idle state. An increase in the

sleep duration (seconds) during IMPS 0 implies no periodic wake

up from IMPS. Periodic wakeup is unnecessary if idle scan is

disabled.

65535

5, 10, 15

gBmpsMinListenInterval,

gBmpsModListenInterval,

gBmpsMaxListenInterval

The listen interval of the STA for each power usage profile.

65535

gAutoBmpsTimerValue

Traffic measure period for BMPS timer.

1000

42949672

95UL

1000

gMaxRxAmpduFactor

Maximum value of Rx AMPDU factory defined in HT Capability

IE.

gScanResultAgeCount

Aging count for BSS entry maintained in the driver scan result

table. If the driver cannot find the BSS for the amount of scans, it

would remove the entry from the scan result table

100

gScanResultAgeNCNPS,

gScanResultAgeNCPS,

gScanResultAgeCNPS,

gScanResultAgeCPS

Scan result aging time thresholds in different states:

(i) Not connect, no power save

(ii ) Not connect, power save

(iii) Connect, no power save

(iv) Connect, power save

10000

50, 300, 150,

600

gRssiCatGap

Configure bin size to categorize candidates found from scan into

RSSI bin group.

100

gShortPreamble

Enable/disable short preamble capability.

gAutoIbssBssid

BSSID in IBSS.

80211eIsEnabled

Enable/disable 802.11e support.

UapsdMask

The ACs to set up U-APSD for at association.

0x00

0xFF

0x00

PktClassificationBasis

0 − DSCP

1 − 802.1Q

InfraDirAcVo

WMM parameters for VO,

WLAN_QCT_CUST_WMM_TSDIR_BOTH

InfraNomMsduSizeAcVo

WMM parameters for VO

0x0

0xFFFF

0x80D0

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 10

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

InfraMeanDataRateAcVo

WMM parameters for VO

0x0

0xFFFFFF

0x14500

InfraMinPhyRateAcVo

WMM parameters for VO

0x0

0xFFFFFF

0x5B8D80

InfraSbaAcVo

WMM parameters for VO

0x2001

0xFFFF

0x2001

InfraDirAcVi

WMM parameters for VI,

WLAN_QCT_CUST_WMM_TSDIR_BOTH

InfraNomMsduSizeAcVi

WMM parameters for VI

0x0

0xFFFF

0x85DC

InfraMeanDataRateAcVi

WMM parameters for VI

0x0

0xFFFFFF

0x57E40

InfraMinPhyRateAcVi

WMM parameters for VI

0x0

0xFFFFFF

0x5B8D80

InfraSbaAcVi

WMM parameters for VI

0x0

0xFFFF

0x2001

InfraDirAcBe

WMM parameters for BE,

WLAN_QCT_CUST_WMM_TSDIR_BOTH

InfraNomMsduSizeAcBe

WMM parameters for BE

0x0

0xFFFF

0x85DC

InfraMeanDataRateAcBe

WMM parameters for BE

0x0

0xFFFFFF

0x493E0

InfraMinPhyRateAcBe

WMM parameters for BE

0x0

0xFFFFFF

0x5B8D80

InfraSbaAcBe

WMM parameters for BE

0x2001

0xFFFF

0x2001

InfraDirAcBk

WMM parameters for BK,

WLAN_QCT_CUST_WMM_TSDIR_BOTH

InfraNomMsduSizeAcBk

WMM parameters for BK

0x0

0xFFFF

0x85DC

InfraMeanDataRateAcBk

WMM parameters for BK

0x0

0xFFFFFF

0x493E0

InfraMinPhyRateAcBk

WMM parameters for BK

0x0

0xFFFFFF

0x5B8D80

InfraSbaAcBk

WMM parameters for BK

0x2001

0xFFFF

0x2001

InfraDirAcBe

WMM parameters for BE,

WLAN_QCT_CUST_WMM_TSDIR_BOTH

InfraNomMsduSizeAcBe

WMM parameters for BE

0x0

0xFFFF

0x85DC

InfraMeanDataRateAcBe

WMM parameters for BE

0x0

0xFFFFFF

0x493E0

InfraMinPhyRateAcBe

WMM parameters for BE

0x0

0xFFFFFF

0x5B8D80

InfraSbaAcBe

WMM parameters for BE

0x2001

0xFFFF

0x2001

InfraDirAcBk

WMM parameters for BK,

WLAN_QCT_CUST_WMM_TSDIR_BOTH

InfraNomMsduSizeAcBk

WMM parameters for BK

0x0

0xFFFF

0x85DC

InfraMeanDataRateAcBk

WMM parameters for BK

0x0

0xFFFFFF

0x493E0

InfraMinPhyRateAcBk

WMM parameters for BK

0x0

0xFFFFFF

0x5B8D80

InfraSbaAcBk

WMM parameters for BK

0x2001

0xFFFF

0x2001

WfqBkWeight, WfqBeWeight,

WfqViWeight, WfqVoWeight

AC weights

0xFF

1, 3, 5, 7

burstSizeDefinition

WMM TSPEC burst size

tsInfoAckPolicy

WMM info ACK policy

0x00

0x01

0x00

SingleTIDRC

Single RC for all TID:

0 − Separate replay counter for all TID

1 − Single replay counter for all TID

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 11

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

gAddTSWhenACMIsOff

Flag to allow STA to send AddTspec even when ACM is Off

instead of reassoc; to send ADDTS/DELTS even when ACM is

off for that AC 1; and to send AddTs even when ACM is not set

for the AC.

gValidateScanList

channelPowerInfoList24 has been corrupted. Set this flag to true

while trying to detect when it happens. This is being added into

the code because it cannot be reproduced easily. It is not known

when it happens.

gReportMaxLinkSpeed

Indicates whether actual (0) or max (1) or max scaled (2) RSSI is

to be reported.

gLinkSpeedRssiHigh

Threshold value to report the maximum possible speed with

RSSI scaling.

-127

-55

gLinkSpeedRssiMed

Threshold value to report the moderate possible speed with RSSI

scaling.

-127

-65

gLinkSpeedRssiLow

Threshold value to report the least possible speed with RSSI

scaling.

-127

-80

gEnableFirstScan2GOnly

Enable/disable the first scan for 2.4G channels only after Wi-Fi is

turned on.

gNumBuffAdvert

Number of buffers to be advertised during ADDBA negotiation.

128

gEnableLpwrImgTransition

Enable/disable LPWR image (cMEM uBSP) transition.

gFragmentationThreshold

Fragmentation threshold

256

8000

RTSThreshold

RTS threshold (depends on maximum frame size)

2347

WmmIsEnabled

WMM is enabled:

1 – Enable, QoS only

2 – Enable, but not QoS

0 – Auto, join any AP

gThermalMitigationEnable

Enable thermal mitigation

gPassiveMaxChannelTime

Maximum dwell time on each channel for passive scanning

10000

110

gPassiveMinChannelTime

Minimum dwell time on each channel for passive scanning

10000

gActiveMaxChannelTime

Maximum dwell time on each channel for active scanning

10000

gActiveMinChannelTime

Minimum dwell time on each channel for active scanning

10000

g11dSupportEnabled

Enable/disable 11d support.

g11hSupportEnabled

Enable/disable 11h support.

gCountryCodePriority

Driver can retrieve the runtime country code from either the AP

11d IE or from the framework over a private IOCTL command.

This flag gives priority to one of them.

0 − Country code from AP 11d IE has higher priority.

1 − Country code from framework over private IOCTL command

has higher priority.

gEnableSuspend

Enable suspend or not:

1 − Enable standby

2 − Enable deep sleep

3 − Enable Multicast/Broadcast filter

gEnableDriverStop

0 − No support for suspend

2 − Map to deep sleep

gWowlPattern

set Wowl pattern as format of

gWowlPattern=<pattern>[;<pattern>]. each pattern is "hex ascii"

of the form: PP:QQ:RR:SS

PP: pattern size -- 2 hex ascii digits, 01-80 (i.e. 1-128)

QQ: mask size -- 2 hex ascii digits, 01-80 (i.e. 1-128)

RR: pattern -- 2*PP hex ascii digits

SS: mask -- 2*QQ hex ascii digits

gEnableImps

Enable IMPS or not. See Q4 for details.

gEnableBmps

Enable BMPS or not. See Q4 for details.

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 12

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

gEnableAdaptRxDrain

Configuration added to enable/disable CTS2SELF in adaptive Rx

drain feature.

gEnableOxygenNwk

Configuration to enable/disable oxygen feature. SS-specific only.

No need to mention in document.

gDot11Mode

Phy Mode (auto, b, g, n, etc/) Valid values are 0-9, with 0 = Auto,

4 = 11n, 9 = 11ac

7(without

11ac),

9(with

11ac)

4(without 11ac),

9(with 11ac)

gChannelBondingMode24GHz

2.4 GHz channel bonding

gChannelBondingMode5GHz

5 GHz channel bonding

gFixedRate

Fix transmit data rate; 0 means automatic rate adaptation.

gIbssBssid

BSSID to be used when creating IBSS.

000000

ffffffffffff

000AF5040506

Intf0MacAddress

Assigned MAC addresses − Used until NV items are in place.

Each byte of the MAC address is represented in the hex format

as XX.

000000

ffffffffffff

000AF5898980

Intf1MacAddress

Assigned MAC addresses − Used until NV items are in place.

Each byte of the MAC address is represented in the hex format

as XX.

000000

ffffffffffff

000AF5898981

Intf2MacAddress

Assigned MAC addresses − Used until NV items are in place.

Each byte of the MAC address is represented in hex format as

XX.

000000

00000

ffffffffffff

000AF5898982

Intf3MacAddress

Assigned MAC addresses − Used until NV items are in place.

Each byte of the MAC address is represented in hex format as

XX.

000000

ffffffffffff

000AF5898983

gAPCntryCode

Set country code in SoftAP mode.

USI

FFF

gEnableApProt

Enable/disable 802.11n protection.

gApProtection

With gEnableApProt enabled:

bit 0 − 11b

bit 1 − 11g

bit 2 − ht20

bit 3 − Green field

bit 4 − L-SIG

bit 5 – RIFS

bit 6 – Reserved

bit 7 − Reserved

0x0

0xFFFF

0xBFFF

gEnableApOBSSProt

Enable/disable OBSS protection.

gDisableIntraBssFwd

Intra-BSS forward

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 13

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

gEnablePhyAgcListenMode

Listen Energy Detect Mode configuration

Valid values: 0-128

128 means disable Energy Detect feature

0-9 are threshold codes and 7 is the recommended value from

the system if the feature is to be enabled.

10-128 are reserved.

The EDET threshold mapping is as follows in 3 dB steps:

0 = -60 dBm

1 = -63 dBm

2 = -66 dBm

...

7 = -81 dBm

8 = -84 dBm

9 = -87 dBm

Note: Any of these settings are valid. Setting 0 yields the highest

power saving (in a noisy environment) at the cost of more range.

The range impact is approximately calculated as: Range loss

(dB) = EDET threshold level (dBm) + 97 dBm.

128

gAPAutoShutOff

Enable/disable Auto Shutdown Value in seconds.

42949672

95UL

gMinFramesProcThres

N/A

gDisablePacketFilter

Enable/disable the packet filter feature:

0 – Enable

1 – Disable

0x1

gApKeepAlivePeriod

For a certain period of seconds, if there is no activity from the

connected STA, the SAP will disconnect the STA. Applies what

WCN is running as SAP.

255

gGoKeepAlivePeriod

gGoKeepAlivePeriod/gApKeepAlivePeriod is the time spent

checking whether the frames are sending or not. Hence, the total

effective detection time is gGoLinkMonitorPeriod+

gGoKeepAlivePeriod/gApLinkMonitorPeriod+

gApKeepAlivePeriod.

gGoLinkMonitorPeriod

gGoLinkMonitorPeriod is the period during which the link is idle

and where the NULL frame is sent.

gEnableIdleScan

Enable/disable Idle Scan.

gTxPowerCap

Do not use CFG default; if there is no registry setting, this is

ignored by SME.

128

gIgnoreDtim

Setting the enforced Listen Interval. See Q4 for details.

gMaxLIModulatedDTIM

Maximum LI value for modulated DTIM. See Q4 for details.

gNumRxAnt

Make 1x1 the default antenna configuration.

gDataInactivityTimeout

Data Inactivity Timeout when in power save (in milliseconds).

255

gNthBeaconFilter

Beacon filtering frequency (unit in beacon intervals). Every Nth

beacon is checked for change in content of the beacon frame. If

there are changes in the beacon frame, the frame is forwarded to

the host.

255

gStaKeepAlivePeriod

Enable Keep Alive with nonzero period value.

65535

InfraUapsdVoSrvIntv

UAPSD service interval for VO(Voice) traffic

Unscheduled Automatic Power Save Delivery is applicable only

when the station is connected to the AP. It is primarily driven by

QoS-aware applications, e.g., VoIP. Applicable abbreviations are:

¨ BK – Background

¨ BE – Best Effort

¨ VI – Video

42949672

95UL

InfraUapsdVoSuspIntv

UAPSD service interval for VO,VI, BE, BK traffic

42949672

95UL

2000

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 14

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

InfraUapsdViSrvIntv

UAPSD service interval for VO,VI, BE, BK traffic

42949672

95UL

300

InfraUapsdBkSuspIntv

UAPSD service interval for VO,VI, BE, BK traffic

42949672

95UL

2000

telescopicBeaconTransListen

Interval

Parameter for Telescopic DTIM feature. See Q4 for details.

telescopicBeaconTransListen

IntervalNumIdleBcns

Parameter for Telescopic DTIM feature. See Q4 for details.

255

telescopicBeaconMaxListen

Interval

Parameter for Telescopic DTIM feature. See Q4 for details.

telescopicBeaconMaxListen

IntervalNumIdleBcns

Parameter for Telescopic DTIM feature. See Q4 for details.

255

beaconEarlyTerminationWake

Interval

Parameter for Beacon Early Termination feature. See Q4 for

details. With BET, since no FCS check is done when TIM is seen

as being clear, RXP does not update the TSF using the

timestamp from the beacon. This can lead to drift over time when

no traffic for STA. This configuration periodically and temporarily

suspends BET in order to allow a TSF re-sync by allowing a full

beacon to be received with FCS check and RXP update of TSF.

255

McastBcastFilter

Flags to filter Multicast and Broadcast Rx packets

Values:

0 − No filtering

1 − Filter all Multicast

2 − Filter all Broadcast

3 − Filter all Multicast and Broadcast

gTelescopicBeaconWakeupEn

Enable/disable Telescopic DTIM feature. See Q4 for details.

hostArpOffload

Enable/disable HostARPOffload feature to offload ARP reply to

firmware. See Q4 for details.

hostNSOffload

Enable/disable offload handling Neighbor Solicitation to firmware.

gEnableBtAmp

Enable/disable Bluetooth Alternate MAC Phy (BT AMP).

BandCapability

Preferred band (0: Both or 1: 2.4G only or 2: 5G only)

enableBeaconEarlyTermination

Enable/disable Beacon Early Termination

BET allows us to power down as soon as the TIM bit is seen as

being clear without waiting for entire beacon to be received and

FCS checked. The actual power savings depends on beacon

size and placement of the TIM IE within the beacon. For a

specific use case (150-byte beacon and Cisco 1252 AP), the

active receive duration shrinks from 1.3 ms to 800 µs with BET

enabled.

gEnableCloseLoop

0 – OLPC

1 − CLPC/SCPC

gEnableDFSChnlScan

Enable/disable DFS channel scan.

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 15

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

vosTraceEnableBAP,

vosTraceEnableTL,

vosTraceEnableWDI,

vosTraceEnableHDD,

vosTraceEnableSME,

vosTraceEnablePE,

vosTraceEnablePMC,

vosTraceEnableWDA,

vosTraceEnableSYS,

vosTraceEnableVOSS,

vosTraceEnableSAP,

vosTraceEnableHDDSAP

VOS Trace Enable Control

Note: The MIN/MAX/DEFAULT values apply for all modules; the

DEFAULT value is outside the valid range. If the DEFAULT value

is not overridden, no change will be made to the "built-in" default

values compiled into the code values that are bitmaps indicating

which log levels are to be enabled (must match order of

vos_trace_level enumerations).

00000001 FATAL

00000010 ERROR

00000100 WARN

00001000 INFO

00010000 INFO HIGH

00100000 INFO MED

01000000 INFO LOW

10000000 DEBUG

Hence, a value of 0xFF would set all bits (enable all logs).

0xff

0xffff

wdiTraceEnableDAL,

wdiTraceEnableCTL,

wdiTraceEnableDAT,

wdiTraceEnablePAL

WDI Trace Enable Control

Note: The MIN/MAX/DEFAULT values apply for all modules. The

DEFAULT value is outside the valid range. If the DEFAULT value

is not overridden, no change will be made to the "built in" default

values compiled into the code values that are bitmaps indicating

which log levels are to be enabled (must match order of

wpt_tracelevel enumerations).

00000001 FATAL

00000010 ERROR

00000100 WARN

00001000 INFO

00010000 INFO HIGH

00100000 INFO MED

01000000 INFO LOW

Hence, a value of 0x7F would set all bits (enable all logs).

0x7f

0xffffffff

isAndroidPsEn

BMPS Logic:

1 − Then Host driver and above layers control the PS mechanism

0 − Diver/Core Stack internally controls the power-saving

mechanism

gEnableDynamicDTIM

Enable Dynamic DTIM

0 − Disable DynamicDTIM

1 to 5 − SLM will switch to DTIM specified here when host

suspends and switch DTIM1 when the host resumes.

gEnableFirstScan2GOnly

Enable First Scan 2G only:

0 − Disable first scan 2G option.

1 − Enable first scan 2G option.

gEnableAutomaticTxPower

Control

Enable/disable Automatic Tx Power Control.

gShortGI20Mhz

Enable Short Guard Interval for HT40 in 5 GHz.

gShortGI40Mhz

Enable/disable Short Guard Interval.

gEnableModulatedDTIM

Enable/disable Modulated DTIM feature

gMCAddrListEnable

Enable/disable Multicast MAC Address List feature

gEnableRXSTBC

Enable/disable Rx STBC feature. See Q4 for details.

gEnableVhtFor24GHzBand

Parameter to control VHT support in 2.4 GHz band.

gMaxMediumTime

Valid values are 2048, 4096, 8192, etc. Do not use other values.

65525

2048

gEnableDirectedScanOffload

Enable/disable SCAN Offload.

gFlexConnectPowerFactor

Enable/disable FlexConnectPowerFactor parameter.

gEnableIbssHeartBeatOffload

Enable heart beat monitoring offload to firmware.

gAntennaDiversity

Enable/disable Antenna Diversity feature.

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 16

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

gEnableDynSplitScan

Macro to enable/disable dynamic timer.

gSplitScanTxRxThreshold

Macro to monitor the packet count.

100

gSplitScanTxRxTimer

Macro to handle the monitor timer value in milliseconds.

1000

10000

5000

gAmsduSupportInAMPDU

Enable/disable AMSDU in AMPDU. Keep this disabled until this

feature is supported.

gScanAgingTime

Scan Aging Timeout value in seconds.

200

gTxLdpcEnable

Config parameter to enable the txLdpc capability:

0 – Disable

1 − HT LDPC enable

2 − VHT LDPC enable

3 − HT and VHT LDPC enable */

See Q5 for details.

gAthDisable

Enable/disable Qualcomm proprietary algorithm for improving

throughput in short range in a noisy environment.

gEnableMemoryDebug

Enable Memory Debug.

BtAmpPreferredChannel

Preferred channel to start BT AMP AP mode (0 means, any

channel).

OkcEnabled

Enable/disable OKC feature.

2.2 P2P and Concurrency

Config Param

Description

Min

Max

Default

gPassiveMaxChannelTimeConc

Maximum channel time for passive scan, ifdef

WLAN_AP_STA_CONCURRENCY

10000

110

gPassiveMinChannelTimeConc

Minimum channel time for passive scan, ifdef

WLAN_AP_STA_CONCURRENCY

10000

gActiveMaxChannelTimeConc

Maximum channel time for active scan, ifdef

WLAN_AP_STA_CONCURRENCY

10000

gActiveMinChannelTimeConc

Maximum channel time for passive scan, ifdef

WLAN_AP_STA_CONCURRENCY

10000

gNumStaChanCombinedConc

Number of STA scanning channel perf gRestTimeConc, ifdef

WLAN_AP_STA_CONCURRENCY

255

gNumP2PChanCombinedConc

Number of P2P scanning channel perf gRestTimeConc, ifdef

WLAN_AP_STA_CONCURRENCY

255

gRestTimeConc

Time in milliseconds. In a concurrency session, the split scan is

performed (refer to the description on

gNumChanCombinedConc) and takes longer to finish a scan on

all channels as WCN needs to come back home from time to

time. There is a chance that before the WCN completes the full

set of channel scans using split scan, a new scan request comes

in. Rest time is added here to avoid triggering another split scan

right after the previous set of split scan completes to provide

better data performance.

https://www.codeaurora.org/gitweb/external/wlan/?p=prima.git;a=

commit;h=4ff9cd6939eb76dcbfbd8fef943d4717498a9a59

1000

100

gEnableMCCAdaptiveScheduler

Enable/disable the MCC adaptive scheduler feature.

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 17

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config Param

Description

Min

Max

Default

gAllowMCCGODiffBI

Allow GO in MCC mode to accept different beacon intervals than

STAs.

Added for Wi-Fi Cert. 5.1.12

Default: gAllowMCCGODiffBI = 2

gAllowMCCGODiffBI = 1 // Set to 1 for WFA certification. GO

Beacon interval is not changed. MCC-GO does not work well in

an optimized way. In a worst-case scenario, it may invite STA

disconnection.

gAllowMCCGODiffBI = 2 //If set to 2, workaround 1

disassociates all the clients and updates the beacon interval.

gAllowMCCGODiffBI = 3 //If set to 3, tear down the P2P link in

auto/nonautonomous-GO case.

gAllowMCCGODiffBI = 4 //If set to 4, do not disconnect the

P2P client in autonomous/non-autonomous-GO case; update the

BI dynamically.

gMccAllowCfgModif

Allow MCC to modify the configuration.

0x0000

0x01ff

0x000C

gEnableMCCMode

Enable MCC mode.

gDebugP2pRemainOnChannel

Enable debug for remaining on channel issues. Setting this flag

triggers marker frames in air at start and end of remain on

channel.

gSkipDfsChannelInP2pSearch

Skip the DFS Channel in case of P2P search:

0 – Do not skip DFS channel in case of P2P search.

1 − Skip DFS channel in case of P2P search.

gIgnoreDynamicDtimInP2pMode

Ignore Dynamic DTIM in case of P2P:

0 − Consider Dynamic DTIM in case of P2P.

1 − Ignore Dynamic DTIM in case of P2P.

isP2pDeviceAddrAdministrated

Derive the P2P MAC address from the primary MAC address.

gSapAllowAllChannel

The driver allows all Wi-Fi channels as operating channels in

SAP and P2P-GO mode. It is the responsibility of the user space

application not to violate regulatory domain settings.

gEnableTrafficMonitor

SAP/P2P-GO mode traffic monitor

gTrafficIdleTimeout

SAP/P2P-GO mode traffic monitor

3000

10000

5000

gPassiveMaxChannelTimeConc

Maximum channel time for passive scan, ifdef

WLAN_AP_STA_CONCURRENCY

10000

110

2.3 TDLS

Config. Param.

Description

Min

Max

Default

gEnableTDLSSupport

Enable/disable the TDLS feature.

gEnableTDLSImplicitTrigger

Enable/disable the implicit trigger; for implicit trigger to work,

both gEnableTDLSSupport and gEnableTDLSImplicitTrigger

must be enabled.

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 18

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

gTDLSTxStatsPeriod

Time period (in milliseconds) to evaluate whether the number of

Tx packets exceeds the TDLSTxPacketThreshold and triggers a

TDLS setup request.

429496729

5UL

5000

gTDLSTxPacketThreshold

Number of Tx packets during the period of gTDLSTxStatsPeriod;

when exceeded, a TDLS setup request is triggered.

429496729

5UL

100

gTDLSDiscoveryPeriod

Time period (in milliseconds) to initiate a TDLS discover request

for a peer.

5000

429496729

5UL

2000

gTDLSMaxDiscoveryAttempt

Number of failures of discover request; when exceeded, the

peer is assumed not to be TDLS-capable, and no further request

will be made.

100

gTDLSIdleTimeout

Time period (in milliseconds) for which the TDLS link is idle;

when exceeded, a TDLS teardown is triggered.

2000

40000

5000

gTDLSIdlePacketThreshold

Number of Tx/Rx packets, below which within the last

gTDLSTimeout period is considered an idle condition.

40000

gTDLSRssiHysteresis

Difference (in dB) between the AP RSSI and the peer RSSI;

when exceeded, a TDLS teardown is triggered.

100

gTDLSRSSITriggerThreshold

Absolute value (in dB) of the peer RSSI, below which a TDLS

setup request will be triggered.

-120

-75

gTDLSRSSITeardownThreshold

Absolute value (in dB) of the peer RSSI; when exceeded, a

TDLS teardown will be triggered.

-120

-75

gTDLSUapsdMask

ACs to set up U-APSD for TDLS STA.

gEnableTDLSBufferSta

Enable buffer STA capability of the TDLS DUT.

gTDLSPuapsdInactivityTime

Criteria for entering into power save:

As soon as the TDLS link is established, the host will send a

TDLS_LINK_ESTABLISHED message to the firmware. As part

of handling this message the firmware starts a timer with the

interval configured from cfg.ini (gTDLSPuapsdInactivityTime).

The firmware maintains the Tx and Rx packet count, per STA.

When the inactivity timer expires the firmware checks whether

the previous TxRx packet count is the same as the current TxRx

packet count, then sends the PM1 frame to the TDLS peers.

If there is a change in the previous TxRx packet count, restart

the timer.

gTDLSPuapsdRxFrameThreshol

Criteria for exiting from power save:

If sleep STA receives the frame more than a value configured

from cfg.ini (gTDLSPuapsdRxFrameThreshold) in a single

service period, then the sleep STA comes out of the power save

because there is more traffic coming from the buffer STA.

gTDLSExternalControl

Dictates the driver to initiate the TDLS setup requests for only

configured TDLS MAC entries.

2.4 BTC and CoEx

Config. Param.

Description

Min

Max

Default

btcActiveWlanLen

WLAN interval length during BT OPP

250000

60000

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 19

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

btcActiveBtLen

BT interval length during BT OPP

250000

90000

btcSapActiveWlanLen

SAP WLAN interval length during BT OPP

250000

60000

btcSapActiveBtLen

SAP BT interval length during BT OPP

250000

90000

BtcExecutionMode

Parameter to adjust BT vs WLAN preference:

 [Balanced] value: 0 − Optimized for best BT and WLAN

performance.

 [A2DP] value: 5 − Optimized for best BT audio quality (A2DP)

in heavy interference at the cost of WLAN throughput.

 The BTC execution modes are:

 0 – BTC_SMART_COEXISTENCE – BTC mapping layer

decides what is best

 1 – BTC_WLAN_ONLY – WLAN takes all modes

 2 – BTC_PTA_ONLY – Allow only 3-wire protocol in

hardware

 3 – BTC_SMART_MAX_WLAN – BTC mapping layer

decides what is best; WLAN weighted

 4 – BTC_SMART_MAX_BT – BTC mapping layer

decides what is best; Bluetooth-weighted

 5 – BTC_SMART_BT_A2DP – BTC mapping layer

decides what is best; balanced + Bluetooth A2DP weight

 6 – BT_BT_EXEC_MODE_MAX – This and beyond are

invalid values.

BtcConsBtSlotToBlockDuringDh

Ensure WLAN IP address delivery via DHCP in which SCO is

active:

 [0]: No protection (default)

 [1]: Best WLAN DHCP protection

 [255]: Least protection for DHCP

 [8]: Default

 SCO-specific parameter, introduced to improve Wi-Fi DHCP

connection timing when a BT SCO call is ongoing, e.g.,

consider the following case:

 When the flag is set to value 2 – Every alternate

Bluetooth SCO reserved slot will be blocked for WLAN,

i.e., ½ * 100 = 50% Bluetooth blockage. This improves

Wi-Fi DHCP connection timings but impacts SCO voice

quality.

 When the flag is set to value 4 – Every alternate 4th

Bluetooth SCO reserved slot will be blocked for WLAN,

i.e., ¼ * 100 = 25% Bluetooth blockage.

 Lowering the value is better for WLAN connection time,

but Bluetooth audio quality is impacted.

 The ideal value of this flag is 8, i.e., 1/8 * 100 = 12.5%

Bluetooth blockage.

0xFF

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 20

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

BtcA2DPDhcpProtectLevel

Ensure WLAN IP address delivery via DHCP while A2DP is

active:

 [0]: Protect WLAN DHCP best to [15]: Protect A2DP best

 [7]: Default

 A2DP-specific parameter; improves Wi-Fi DHCP connection

timing when a Bluetooth A2DP call is ongoing. The valid

value of the flag is in the range of 0 to 7.

 When the flag is 0, no Bluetooth A2DP intervals will be

blocked for Wi-Fi DHCP completion.

 When the flag is 7, the WLAN DHCP connection time will

be fastest, but there is an impact on A2DP audio quality.

 The ideal value of the flag is 3.

0xFF

btcStaticLenInqBt

BT interval length during BT inquiry [5 ms/

500 ms/120 ms]

5000

500000

120000

btcStaticLenPageBt

BT interval length during BT paging

5000

500000

120000

btcStaticLenConnBt

BT interval length during BT connection setup

5000

500000

120000

btcStaticLenLeBt

BT interval length during BT LE scan

5000

500000

120000

btcStaticLenInqWlan

WLAN interval length during BT inquiry

500000

30000

btcStaticLenPageWlan

WLAN interval length during BT paging

500000

30000

btcStaticLenConnWlan

WLAN interval length during BT connection setup

500000

30000

btcStaticLenLeWlan

WLAN interval length during BT LE scan

500000

30000

btcDynMaxLenBt

Dynamically adjusts BT interval during ACL active (A2DP/OPP).

25000

500000

250000

btcDynMaxLenWlan

Dynamically adjusts WLAN interval during ACL active

(A2DP/OPP).

15000

500000

45000

btcMaxScoBlockPerc

Maximum SCO skipping percentage

100

btcDhcpProtOnA2dp

Ensure DHCP reliability during A2DP

btcDhcpProtOnSco

Ensure DHCP reliability during SCO

mwsCoexVictim1WANFreq

LTE Coex victim table (up to 10): LTE frequency:

 [15 : 0] WAN start center frequency in MHz

 [31 : 16] WAN end center frequency in MHz

Start freq < center freq <= end freq

0xFFFFFFFF

mwsCoexVictim1WLANFreq

LTE Coex victim table (up to 10): WLAN frequency

 [31] 1: 5 GHz, 0: 2.4 GHz

 [13 : 0] For 2.4 GHz, maps to channel 1-14. Bit 0 is ch 1.

 [13 : 0] For 5 GHz, start WLAN frequency in MHz

 [29 : 16] For 5 GHz, end WLAN frequency in MHz.

0xFFFFFFFF

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 21

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

mwsCoexVictim1Config,

mwsCoexVictim1Config2

LTE power limit, Rx protect enable/disable (up to 10 victim table)

 [28:0] Must be set to 0

 [29] LTE power limit

 [30] LTE Rx protect

0xFFFFFFFF

mwsCoexModemBackoff

LTE power backoff value in dBm

0xFFFFFFFF

mwsCoexConfig1

Enable/disable LTE Coex configuration:

 Default: 0

 Disable TDM: 1

 Disable WLAN backoff: 2

 Disable modem backoff: 4

 TDM always on: 8

 Disable SAR: 16

 Disable Rel AB: 32

 Disable QMI Lite: 64

0xFFFFFFFF

gActiveMaxChannelTimeBtc

 Maximum channel dwell time when WLAN is in scan mode

during coex.

10000

120

gActiveMinChannelTimeBtc

 Minimum channel dwell time when WLAN is in scan mode

during coex.

10000

2.5 SoftAP (SAP)

Config Param

Description

Min

Max

Default

gEnableApRandomBssid

To create a random BSSID in SoftAP mode to meet the Android

requirement.

gBeaconInterval

Beacon interval for SoftAP

65535

100

gEnableApUapsd

Enable/disable UAPSD for SoftAP

gAPChannelSelectStartChannel

SoftAP channel range selection

0xFF

gAPChannelSelectEndChannel

SoftAP channel range selection

0xFF

gAPChannelSelectOperatingBan

SoftAP channel range selection operating band:

 0 − 2.4 GHz

 1 − Low-5 GHz

 2 − Mid-5 GHz

 3 − High-5 GHz

 4 − 4.9 GHz band

0x4

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 22

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config Param

Description

Min

Max

Default

gApAutoChannelSelection

SAP auto channel enable

Note: Auto channel selection for SAP configuration:

 0 − Disable auto channel

 1 − Enable auto channel selection in auto mode.

When auto channel is enabled, the channel provided by the

supplicant will be ignored.

Default configuration: Auto channel is disabled.

gEnableVSTASupport

Enable/disable VSTA based on max assoc limit. Enable to have

maximum 32 STA (P2P GC) on DUT as P2P GO or SAP.

2.6 11ac and PNO

Config Param

Description

Min

Max

Default

gTxBFEnable

Enable/Disable Tx beamforming

ifdef WLAN_FEATURE_11AC

gTxBFCsnValue

Certain TxBF capability AP has an issue that when pronto

advertise the csn value as 3 it uses the 2 antenna in the NDPA

packet but it is supposed to use the 3 antenna in the NDPA

packet. If we advertise the csn value as 2 then it uses 3

antennas in the NDPA packet. We need to have ini configuration

for setting the csn value.

gVhtChannelWidth

Channel width for VHT mode.

1 - 20 and 40MHz, 2 - 80MHz

gVhtRxMCS

VHT Rx MCS values

Valid values are 0,1,2. If commented out, the default value is 0.

0=MCS0-7, 1=MCS0-8, 2=MCS0-9

gVhtTxMCS

VHT Tx MCS values

Valid values are 0,1,2. If commented out, the default value is 0.

0=MCS0-7, 1=MCS0-8, 2=MCS0-9

gDisableLDPCWithTxbfAP

Disable LDPC when AP is TXBF capable. This is a workaround

for Throughput issue from AP's test firmware. ifdef

WLAN_FEATURE_11AC

gPNOScanSupport

Advertise PNO driver capability.

0 - disable driver PNO capability. 1 - enable driver PNO

capability

ifdef FEATURE_WLAN_SCAN_PNO

gPNOScanTimerRepeatValue

Driver gets only one timer interval which is hardcoded in

supplicant for 10000ms. So until PNO is disabled, firmware

repeats PNO scan for every 10 secs.

Taking power consumption into account 6 timers will be used,

Timervalue is increased exponentially i.e 10,20,40, 80,160,320

secs. And number of scan cycle for each timer is configurable

through INI param gPNOScanTimerRepeatValue. If it is set to 0

only one timer will be used and PNO scan cycle will be repeated

after each interval specified by supplicant till PNO is disabled.

0xffffffff

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 23

Confidential and Proprietary – Qualcomm Atheros, Inc.

2.7 Roam, LFR, VOICE, 11r and CCX

Config. Param.

Description

Min

Max

Default

gRoamingTime

CSR Roaming Enable(1) Disable(0)

4294967UL

gEnableFastRoamInConcurrency

Enable legacy fast roaming (LFR) on STA link during

concurrent sessions

gRssiFilterPeriod

Increased this value for Non-CCX AP. This is cause FW RSSI

Monitoring the consumer of this value is ON by default. So to

impact power numbers we are setting this to a high value.

255

gImmediateRoamRssiDiff

RSSI delta to allow STA to immediately roam to a qualified AP

without registering for reassoc threshold. Value of 0 means to

do immediate roam if there is any qualified AP found from

scanning. Following a scan and if potential roam candidate(s)

are found, then determine whether to register for reassoc

threshold or roam immediately based on this configuration

parameter. If the RSSI of any available candidate is better

than the currently associated AP by at least

gImmediateRoamRssiDiff, then being to roam immediately.

NOTE: Value of 0 means that immediate roaming is enabled

by default

125

gSelect5GHzMargin

Prefer connecting to 5G AP even if its RSSI is lower by

gSelect5GHzMargin dBm than 2.4G AP. This feature requires

the dependent cfg.ini "gRoamPrefer5GHz" set to 1

gNeighborScanTimerPeriod

CCX Support and fast transition, Time between individual

channels in scan.

300

200

gNeighborLookupThreshold

0 indicates the host to calculate

Adaptive threshold based on the minimum supported data

rate, RSSI threshold to trigger background scan to find

potential roam candidates.

120

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 24

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

gNeighborScanChannelList

Channel list provided by user to scan to perform background

scan after the RSSI of current AP falls below

gNeighborLookupThreshold for non-11r associations. For 11r

associations, roaming algorithm sends neighbor report request

and based on the neighbor report from AP, algorithm

dynamically generates the channel list. If there is no suitable

candidates in the neighbor report from AP, algorithm falls back

to background scan with this channel list., ifdef

WLAN_FEATURE_NEIGHBOR_ROAMING

gNeighborScanChannelMaxTime

Minimum dwell time for scan, ifdef

WLAN_FEATURE_NEIGHBOR_ROAMING

300

gNeighborReassocThreshold

RSSI threshold to trigger roam (this threshold is registered

only if there are candidates found after the scan) -> obsolete

from LFR2.0 ifdef WLAN_FEATURE_NEIGHBOR_ROAMING

125

gNeighborScanChannelMinTime

Minimum dwell time for scan, ifdef

WLAN_FEATURE_NEIGHBOR_ROAMING

gMaxNeighborReqTries

Max retrial counter for Reassoc REQ during roaming, ifdef

WLAN_FEATURE_NEIGHBOR_ROAMING

gNeighborScanRefreshPeriod

Refresh interval between background scans [ms], ifdef

WLAN_FEATURE_NEIGHBOR_ROAMING

1000

60000

20000

gEmptyScanRefreshPeriod

Periodic background scanning interval if no candidate is found

[ms], ifdef WLAN_FEATURE_NEIGHBOR_ROAMING

60000

gRrmEnable

This flag controls the capabilities(11k) included in capabilities

field.

Basically, this field controls if station supports 11k or not.

if defined WLAN_FEATURE_VOWIF

gRrmOperChanMax

section 11.10.3 IEEE std. 802.11k-2008 Maxduration =

2^(maxDuration - 4) * bcnIntvl, max duration = 2^-1 * bcnIntvl

(50% of bcn intvl)

gRrmNonOperChanMax

section 11.10.3 IEEE std. 802.11k-2008 Maxduration =

2^(maxDuration - 4) * bcnIntvl, max duration = 2^-1 * bcnIntvl

(50% of bcn intvl)

gRrmRandnIntvl

if defined WLAN_FEATURE_VOWIFI

100

gRoamPrefer5GHz

When both APs(2.4GHz and 5Ghz) are reported on same

bucket, 5Ghz is selected first when gRoamPrefer5GHz=1 set

in INI file.

if defined (WLAN_FEATURE_VOWIFI_11R) || defined

(FEATURE_WLAN_CCX) || defined(FEATURE_WLAN_LFR)

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 25

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

gRoamIntraBand

To disable, set gRoamIntraBand=0 (Roaming across band, if

defined (WLAN_FEATURE_VOWIFI_11R) || defined

(FEATURE_WLAN_CCX) || defined(FEATURE_WLAN_LFR)

To enable, set gRoamIntraBand=1 (Roaming within band)

FastTransitionEnabled

This flag will control fasttransition in case of 11r and ccx.

Basically with this the whole neighbor roam, pre-auth, reassoc

can be turned ON/OFF. With this turned OFF 11r will

completely not work. For 11r this flag has to be ON. For CCX

fastroam will not work.

RoamRssiDiff

This parameter is used to decide whether to Roam or not. AP1

is the currently associated AP and AP2 is chosen for roaming.

The Roaming will happen only if AP2 has better Signal Quality

and it has a RSSI better than AP1 in terms of

RoamRssiDiff,and RoamRssiDiff is the number of units

(typically measured in dB) AP2 is better than AP1. This check

is not done if the value is Zero. Check if the AP to which we

are roaming is better than current AP in terms of RSSI.

Checking is disabled if set to Zero.Otherwise it will use this

value as to how better the RSSI of the new/roamable AP

should be for roaming.

gWESModeEnabled

This parameter is used to set Wireless Extended Security

Mode, if defined (WLAN_FEATURE_VOWIFI_11R) || defined

(FEATURE_WLAN_CCX) || defined(FEATURE_WLAN_LFR)

gRoamScanNProbes

if defined (WLAN_FEATURE_VOWIFI_11R) || defined

(FEATURE_WLAN_CCX) || defined(FEATURE_WLAN_LFR)

gRoamScanHomeAwayTime

To determine the time between consecutive channel scans, if

defined (WLAN_FEATURE_VOWIFI_11R) || defined

(FEATURE_WLAN_CCX) || defined(FEATURE_WLAN_LFR)

300

FastRoamEnabled

Enable/Disable Legacy (non-CCX, non-802.11r) Fast Roaming

Support

ifdef FEATURE_WLAN_LFR

MAWCEnabled

Enable/Disable MAWC (Motion Added Wi-Fi Connectivity)

feature

gRoamScanOffloadEnabled

Enable/Disable Roam Scan Offload

ifdef WLAN_FEATURE_ROAM_SCAN_OFFLOAD

CcxEnabled

Enable/Disable CCX feature

InfraInactivityInterval

Setting inactivity interval for AddTspec communication

429496729

5UL

ImplicitQosIsEnabled

Enable/Disable driver to initiate ADDTS REQ/RSP to get traffic

stream admitted to AP in case phone is trying to transmit an

AC frame which has ACM set by AP

gRetryLimitZero

Primary rate of maximum retransmission number

gRetryLimitOne

Secondary rate of maximum retransmission number

WCNSS Android Parameters Configuration Guide System Configuration

80-Y0476-5 Rev. D MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 26

Confidential and Proprietary – Qualcomm Atheros, Inc.

Config. Param.

Description

Min

Max

Default

gRetryLimitTwo

Tertiary rate of maximum retransmission number

80 Y0476 5 D WCNSS Android Parameters Config Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
