A beginner’s guide to Java Persistence locking
JANUARY 12, 2015 ⁄VLADMIHALCEA
(Last Updated On: January 29, 2018)
Implicit locking
In concurrency theory, locking is used for protecting mutable shared data against hazardous data integrity anomalies. Because lock
management is a very complex problem, most applications rely on their data provider implicit locking techniques.
Delegating the whole locking responsibility to the database system can both simplify application development and prevent concurrency
issues, such as deadlocking. Deadlocks can still occur, but the database can detect and take safety measures (arbitrarily releasing one of the
two competing locks).
Want to run your data access layer at warp speed?
Your email address..
Subscribe
Physical locks
Most database systems use shared (read) and exclusive (write) locks, attributed to specic locking elements (rows, tables). While physical
locking is demanded by the SQL standard, the pessimistic approach might hinder scalability.
Modern databases have implemented lightweight locking techniques, such as MVCC.
The implicit database locking is hidden behind the transaction isolation level conguration. Each isolation level comes with a predened
locking scheme, aimed at preventing a certain set of data integrity anomalies.
READ COMMITTED uses query-level shared locks and exclusive locks for the current transaction modied data. REPEATABLE READ and
SERIALIZABLE use transaction-level shared locks when reading and exclusive locks when writing.
Logical locks
If database locking is sufcient for batch processing systems, a multi-request web ow spans over several database transactions. For long
conversations, a logical (optimistic) locking mechanism is much more appropriate.
Paired with a conversation-level repeatable read storage, optimistic locking can ensure data integrity without trading scalability.
JPA supports both optimistic locking and persistence context repeatable reads, making it ideal for implementing logical transactions.
Explicit locking
While implicit locking is probably the best choice for most applications concurrency control requirements, there might be times when you
want a ner-grained locking strategy.
Most database systems support query-time exclusive locking directives, such as SELECT FOR UPDATE or SELECT FOR SHARE. We can,
therefore, use lower level default isolation levels (READ COMMITTED), while requesting share or exclusive locks for specic transaction
scenarios.
Most optimistic locking implementations verify modied data only, but JPA allows explicit optimistic locking as well.
JPA locking
As a database abstraction layer, JPA can benet from the implicit locking mechanisms offered by the underlying RDBMS. For logical locking,
JPA offers an optional automated entity version control mechanism as well.
JPA supports explicit locking for the following operations:
nding an entity
locking an existing persistence context entity
refreshing an entity
querying through JPQL, Criteria or native queries
Explicit lock types
The LockModeType contains the following optimistic and pessimistic locking modes:
Lock Mode Type Description
NONE In the absence of explicit locking, the application will use implicit locking (optimistic or
pessimistic)
OPTIMISTIC Always issues a version check upon transaction commit, therefore ensuring optimistic locking
repeatable reads.
READ Same as OPTIMISTIC.
OPTIMISTIC_FORCE_INCREMENT Always increases the entity version (even when the entity doesn’t change) and issues a version
check upon transaction commit, therefore ensuring optimistic locking repeatable reads.
WRITE Same as OPTIMISTIC_FORCE_INCREMENT.
PESSIMISTIC_READ A shared lock is acquired to prevent any other transaction from acquiring a
PESSIMISTIC_WRITE lock.
PESSIMISTIC_WRITE An exclusive lock is acquired to prevent any other transaction from acquiring a
PESSIMISTIC_READ or a PESSIMISTIC_WRITE lock.
PESSIMISTIC_FORCE_INCREMENT A database lock is acquired to prevent any other transaction from acquiring a
PESSIMISTIC_READ or a PESSIMISTIC_WRITE lock and the entity version is incremented upon
transaction commit.
Lock scope and timeouts
JPA 2.0 dened the javax.persistence.lock.scope property, taking one of the following values:
NORMAL
Because object graphs can span to multiple tables, an explicit locking request might propagate to more than one table (e.g. joined
inheritance, secondary tables).
Because the entire entity associated row(s) are locked, many-to-one and one-to-one foreign keys will be locked as well but without locking
the other side parent associations. This scope doesn’t propagate to children collections.
EXTENDED
The explicit lock is propagated to element collections and junction tables, but it doesn’t lock the actual children entities. The lock is only
useful for protecting against removing existing children, while permitting phantom reads or changes to the actual children entity states.
JPA 2.0 also introduced the javax.persistence.lock.timeout property, allowing us to congure the amount of time (milliseconds) a lock request
will wait before throwing a PessimisticLockException.
Hibernate locking
Hibernate supports all JPA locking modes and some additional specic locking options. As with JPA, explicit locking can be congured for the
following operations:
locking an entity using various LockOptions settings.
getting an entity
loading an entity
refreshing an entity
creating an entity or a native Query
creating a Criteria query
The LockModeConverter takes care of mapping JPA and Hibernate lock modes as follows:
Hibernate LockMode JPA LockModeType
NONE NONE
OPTIMISTIC
READ
OPTIMISTIC
OPTIMISTIC_FORCE_INCREMENT
WRITE
OPTIMISTIC_FORCE_INCREMENT
PESSIMISTIC_READ PESSIMISTIC_READ
PESSIMISTIC_WRITE
UPGRADE
UPGRADE_NOWAIT
UPGRADE_SKIPLOCKED
PESSIMISTIC_WRITE
PESSIMISTIC_FORCE_INCREMENT
FORCE
PESSIMISTIC_FORCE_INCREMENT
The UPGRADE and FORCE lock modes are deprecated in favor of PESSIMISTIC_WRITE.
UPGRADE_NOWAIT and UPGRADE_SKIPLOCKED use an Oracle-style select for update nowait or select for update skip locked syntax
respectively.
