SIMnet 2016: Access 2016 Capstone Project Level 3
Access 2016 capstone project AC-3
Working with a Sales Database
In this project, you will work with a sales database from Top’t Corn, a popcorn company with a multiple food trucks
and two retail stores. Previously, Top’t Corn kept their data in multiple Excel workbooks. Recently, they decided to
expand their product offerings at different price points, and they realized they needed a more robust database to track
sales. You will help them create new database tables and clean up data imported from Excel.
You will begin by creating new tables to track sales and sale details. You will use the Form Wizard to create a form
based on the new tables. Next, you will modify the existing Items table and create forms based on that table. You will
create a new form from scratch in Layout view to display records from the Locations table. Next, you will clean up
the imported data in the Sales_Archive table, import additional records from an Excel worksheet, and create a
relationship between the data in the Sales_Archive and the Items tables. You will create a series of queries using text,
numeric, and date criteria. Finally, you will create a report using the Report Wizard and another report from scratch
in Layout view.
Skills needed to complete this project:
• Create and save a new table
• Add a new field to a table
• Create a lookup field using values from another
table
• Apply an input mask to a field in a table
• Apply date formatting to a field by modifying
the field Format property
• Create a lookup field using list values
• Create a new record in a table
• Adjust table column widths
• Set a default value for a field in a table
• Use the Form Wizard to create a new form
• Change the data type of a field
• Create a Single Record form based on a table
• Create a Split form based on a table
• Create a new blank form in Layout view
• Add fields to a blank form from Layout view
• Resize controls in a form
• Move controls in a form
• Add a logo to a form header
• Delete a field from a table
• Delete a record from a table
• Find and replace data in a table
• Rename a field in a table
• Import records from an Excel worksheet
• Create a one-to-many relationship between two
tables
• Enforce referential integrity in a one-to-many
relationship
• Create a simple select query to combine fields
from multiple tables
• Add text criteria to a query
• Hide a field in a query
• Use OR in a query
• Add numeric criteria to a query
• Specify the sort order in a query
• Use AND in a query
• Add date criteria to a query
• Add a calculated field to a query
• Create a parameter query
• Use the Report Wizard to create a new report
• Group records in a report
• Add totals to a report
• Create a new blank report
• Add fields to a blank report from Layout view
• Resize controls in a report
• Arrange controls in a report
• Add the date to a report header
• Add page numbers to a report footer
1 | P ag e Last Modified: 12/5/17
SIMnet 2016: Access 2016 Capstone Project Level 3
IMPORTANT: Download the resource file needed for this project from the Resources link. Be sure to
extract the file after downloading the resources zipped folder. Please visit SIMnet Instant Help for
step-by-step instructions.
Step 1
Download
start file
1. Open the start file AC2016-Capstone-Level3. NOTE: If necessary, enable active content by
clicking the Enable Content button in the Message Bar.
2. The file will be renamed automatically to include your name. Change the project file name if
directed to do so by your instructor, and save it.
3. Create a new table from scratch to track sales.
a. The first field should be an AutoNumber field named: SaleID
b. The second field should be a Date & Time field named: SaleDate
c. The third field should be a lookup field. (Hint: Use the Lookup Wizard to create the new field.)
It should display the LocationDescription field from the Locations table. Values in the lookup
should be sorted by values in the LocationDescription field. Include the LocationID field in
the lookup, but do not display it. (Hint: Hide the key column.) Enable data integrity by restricting
deletions. Name this field: SaleLocation
d. Save the table with the name: Sales
4. Switch to Design view and modify field properties.
a. Add an input mask to the SaleDate field. Use the Short Date input mask. Do not change any
other input mask options.
b. Apply the Long Date format to the SaleDate field.
5. Add a new lookup field as the last field in the Sales table to track payment type. (Hint: Use the
Lookup Wizard to create the new field.)
a. Name the field: PaymentType
b. The lookup field should display these values in this order:
Cash
Credit Card
Gift Card
Store Credit
c. Limit data entry to values in the list. Do not allow multiple values.
d. Save the table.
6. Switch back to Datasheet view to add sample records to the Sales table.
a. Add three records to the table with the following data. (Hint: Remember, the first field in the
table, SaleID, is an AutoNumber field, so there is nothing to enter for each record.)
SaleDate
SaleLocation
PaymentType
10/01/2016
Georgetown
Credit Card
10/01/2016
George Washington University
Cash
10/01/2016
George Washington University
Cash
b. Adjust the width of the SaleDate field so the entire long date is visible.
c. Save and close the table.
7. Create a new table to capture the details for each sale.
2 | P ag e Last Modified: 12/5/17
SIMnet 2016: Access 2016 Capstone Project Level 3
a. The first field should be an AutoNumber field named: SaleDetailID
b. The second field should be a lookup field named: SaleID The lookup field should be limited
to values in the SaleID field of the Sales table. Include only the SaleID in the lookup field.
Enable data integrity by restricting deletions.
c. Save the table as: SaleDetails
d. Add a third field to the far right of the table. Name this field: Item This is another lookup field.
Include all the fields from the Items table. Sort the lookup items by values in the ItemName
field. Hide the primary key field. Enable data integrity by restricting deletions.
e. Add a Number field to the right of the Item field. Name the field: Quantity
f. Set the default value for the Quantity field to: 1
g. Add three records to the table with the following data. (Hint: Remember, the first field in the
table, SaleDetailID, is an AutoNumber field, so there is nothing to enter for each record.)
SaleID
Item
Quantity
1
Chocolate
4
1
Sea Salt and Caramel
2
2
Sea Salt and Caramel
4
h. Close the table.
8. Use the Form Wizard to create a new form for inputting sales data.
a. Include all the fields from the Sales table.
b. Include the Item and Quantity fields from the SaleDetails table.
c. View the form data by records in the Sales table with related records in the SaleDetails table
displayed in a subform.
d. The subform should be displayed as a Datasheet.
e. Name the main form: SalesForm and name the subform: SaleDetailsSubform
(Hint: Be sure to remove the space between SaleDetails and Subform in the subform name
suggested by Access.)
f. Open the form in Form view to review your work.
g. Navigate to the record in the main form for SaleID 3 and enter sale details in the subform as
follows:
Item: Original Blend, Quantity: 3
Item: Old Bay, Quantity: 2
h. Close the form.
9. Open the Items table and modify the table fields as follows:
a. Set the Default Value property for the Price field to: 6
b. Change the data type for the Price field to: Currency
c. Autofit the width of the ItemName field.
3 | P ag e Last Modified: 12/5/17
SIMnet 2016: Access 2016 Capstone Project Level 3
d. Save the changes and close the Items table.
10. Create a Single Record form using the Items table as the record source. Save the form with the
name: SingleRecordForm
11. Create a form to display records from the Items table in two formats with the Single Record form at
the top and a Datasheet form at the bottom.
a. Create a Split Form based on the Items table.
b. Name the form: SplitForm
12. Begin a new blank form in Layout view.
a. From the Locations table, add the LocationID, LocationDescription, and Comments fields
in that order, at the left side of the form.
b. Widen the labels so that they are just wide enough for LocationDescription to be completely
visible.
c. From the Locations table, add the OpenTime field to the right of the LocationID controls.
d. Reduce the width of the OpenTime bound control so the control is just wide enough to display
the time data.
e. From the Locations table, add the CloseTime field to the right of the OpenTime controls.
f. Reduce the width of the CloseTime bound control so the control is just wide enough to display
the time data.
g. Move the OpenTime and CloseTime controls so they are next to the LocationDescription
controls instead.
h. From the Locations table, add the Days field to the form layout in the empty space to the right
of the LocationID controls, above the OpenTime controls.
Download
Resources i. Add a logo to the form header. Use this file, located with the resources for this project:
j. Save the form with the name: LocationsForm
13. Close the forms.
14. Open the Sales_Archive table.
a. Delete the Total field.
b. Find the record with the ID 500 and delete it. (Hint: It is the last record in the table.)
c. Find and replace each ItemID value OLDB with OLDB005.
d. Rename the TotalSal field to: TotalSale
e. Save and close the table.
15. Import records from the Excel file NewSalesData (downloaded from the Resources link) and
append a copy of the records to the Sales_Archive table.
16. Use the Relationships window to create a relationship between the Items and Sales_Archive tables.
a. Show the Sales_Archive table in the Relationships window.
Download
Resources
4 | P ag e Last Modified: 12/5/17
SIMnet 2016: Access 2016 Capstone Project Level 3
b. Create a one-to-many relationship between the ItemID field in the Items table and the ItemID
field in the Sales_Archive table. You may rearrange the tables in the Relationships window if
you want.
c. Enforce referential integrity so a record cannot be deleted or altered in the Items table if it would
cause a conflict with the data in the Sales_Archive table.
d. Close the Relationships window and save the changes.
17. Create a query to display sales of Truffle flavored popcorn from the Sales_Archive table.
a. Include the following fields in this order: the SaleDate, Quantity, and TotalSale fields from the
Sales_Archive table and the ItemName field from the Items table.
b. Add the criteria Truffle to the ItemName field.
c. Hide the ItemName field in the query results. Run the query to check your work. (Hint: There
should be 46 records in the query results.)
d. Save the query as TruffleQry and then close the query.
18. Create a query to display sales of Old Bay
or
Truffle flavored popcorn from the Sales_Archive table
a. Include the following fields in this order: the SaleDate, Quantity, and TotalSale fields from the
Sales_Archive table and the ItemName field from the Items table.
b. Add the criteria Old Bay or Truffle to the ItemName field. Run the query to check your work.
(Hint: There should be 110 records in the query results.)
c. Save the query as NewFlavorsQry and then close the query.
19. Create a query to display sales for more than $100.00 from the Sales_Archive table.
a. Include the following fields in this order: the SaleDate from the Sales_Archive table,
ItemName field from the Items table, and TotalSale from the Sales_Archive table.
b. Add criteria to the TotalSale field to return only sales greater than 100.
c. Specify the sort order in the query, so the results always display the records with the highest
values in the TotalSale field first. Run the query to check your work. (Hint: There should be 17
records in the query results.)
d. Save the query as HighDollarSalesQry and close it.
20. Create a query to display sales for more than $100 of Old Bay flavored popcorn from the
Sales_Archive table
a. Include the following fields in this order: the ItemName field from the Items table and the
SaleDate, Quantity, and TotalSale fields from the Sales_Archive table.
b. Add the criteria to the query to return only records where the ItemName is Old Bay and the
TotalSale is greater than 100. Run the query to check your work. (Hint: There should be 3
records in the query results.)
c. Save the query as HighDollarOldBayQry and then close the query.
21. Create a query to display sales of Original Blend popcorn on July 4, 2016 from the Sales_Archive table.
a. Include the following fields in this order: the ItemName field from the Items table and the
SaleDate and Quantity fields from the Sales_Archive table.
5 | P ag e Last Modified: 12/5/17
SIMnet 2016: Access 2016 Capstone Project Level 3
b. Add the criteria to the query to return only records where the ItemName is Original Blend
and the Date is July 4, 2016. Run the query to check your work. (Hint: There should be 3
records in the query results.)
c. Save the query as July4OriginalBlendQry and then close the query.
22. Create a query to calculate the per unit price of the archived sales.
a. Include the following fields in this order: the ItemName field from the Items table and the
Quantity and TotalSale fields from the Sales_Archive table.
b. Add a calculated field to the far right of the query to calculate the value of the TotalSale
divided by Quantity. Name the field: CostPerUnit Run the query to check your work.
(Hint: There should be 234 records in the query results.)
c. Save the query as CostPerUnitQry and then close the query.
23. Create a parameter query to display sales from a specific date.
a. Include these fields in this order: the SaleDate field from the Sales_Archive table, the
ItemName field from the Items table, the Quantity and TotalSale fields from the
Sales_Archive table.
b. Use the prompt: Enter the sale date:
c. Run the query to check your work. Enter the date 7/4/2016 when prompted. (Hint: There
should be 9 records in the query results.)
d. Save the query as ByDateParameterQry and close it.
24. Use the Report Wizard to create a report based on the NewFlavorsQry query.
a. Include the fields from the NewFlavorsQry query in this order: ItemName, SaleDate,
Quantity, and TotalSale.
b. View the data by the Items table.
c. Do not add any additional grouping.
d. Sort the detail records by sale date.
e. Use the Stepped layout in Portrait orientation.
f. Name the report NewFlavorRpt and then view the report to check your work.
25. Switch to Layout view and add more grouping and totals to the NewFlavorRpt report.
a. Display the Group, Sort, and Total pane and add new grouping by values in the SaleDate field by
Month.
b. Add totals to each group to calculate the Sum of values in the TotalSale field.
c. Save and close the report.
26. Create a new report from scratch in Layout view.
a. From the Sales_Archive table, add the SaleDate field to the report. Add these fields in order to
the right of the SaleDate controls: ItemName from the Items table, and Quantity and
TotalSale from the Sales_Archive table.
b. Resize the ItemName controls so all the item names are visible. (Hint: Widen the ItemName
column so the entire Sea Salt and Caramel name is visible.)
6 | P ag e Last Modified: 12/5/17
SIMnet 2016: Access 2016 Capstone Project Level 3
c. Add the ItemID field from the Items table. Move the ItemID controls so they appear to the
left of the ItemName controls.
d. Add the current date to the report header. Use this date format: Thursday, February 25, 2016
Do not include the time.
e. Add page numbers centered in the report footer. Use this page number format: Page N of M
f. Save the report as: SalesArchiveRpt
Step 2
Upload &
Save
Step 3
Grade my
Project
27. Save and close any open database objects and then close the database.
28. Upload and save your project file.
29. Submit project for grading.
7 | P ag e Last Modified: 12/5/17

Navigation menu
