NOMADIX AG 5800 ACCESS GATEWAY

The AG 5800 is a next generation, high-performance Internet access

gateway that extends a wired or WiFi network to create a public

Internet access network. Designed for medium- to large-sized venues,

from hotels to airports to convention centers, the AG 5800 features

the ﬂexibility to support 300 devices and scale to 4,000 simultaneous

devices. Unlike server-based solutions, the AG 5800 is a fast, reliable,

dedicated network appliance designed to keep trafﬁc ﬂowing.

NEXT GENERATION PLATFORM FOR SPEED AND DURABILITY

The AG 5800 hardware platform is built upon Intel’s high-performance processors and sports built-in ﬂash

memory. The AG 5800 is designed for intensive usage while supporting a Gbit WAN port and four LAN ports.

Top-speed is delivered regardless of user load. The durability of the AG 5800 is achieved due to its reliable and

quality platform, ensuring optimum uptime.

Based on the VxWorks real-time multi-tasking operating system, the AG 5800 is architected to use less

processing power and run faster. Combined with the proven Nomadix Service Engine™ (NSE) Core Software,

the AG 5800 is an ultra high-performance appliance with unparalleled reliability.

BANDWIDTH MANAGEMENT

The AG 5800 comes equipped with a range of bandwidth management tools, ensuring that the quality of the

connection is optimum and that each user gets fair access to bandwidth. Bandwidth can be managed by group,

subscriber or device, or a combination of all three, and includes data ofﬂoading. The AG 5800 is equipped to

operate at near wire speed and also offers new NSE features with increased computational intensity.

HIGHLY SCALABLE

From medium-sized businesses to large public settings, the AG 5800 is scalable from 300 up to 4,000

simultaneous devices. No change of hardware or software design is required to upgrade to the desired device

count. The AG 5800 ﬁts in any environment that uses a rack mount.

ADVANCED SECURITY FOR NETWORK PROTECTION

The AG 5800 offers advanced security for network protection with ICMP packet blocking. Enhanced by

utilizing Session Rate Limiting (SRL) to manage Denial of Service (DOS) attacks, the AG 5800 includes

URL ﬁltering, centralized RADIUS authentication, and iNAT technology that allows multiple VPN tunnels

to provide users with a seamless connection at higher levels of security. Additionally, the AG 5800 provides

the ability to centrally monitor responsible usage, and set policies to securely manage user access.

HIGH-PERFORMANCE,

SCALABLE ACCESS GATEWAY

ADDRESSES FLUCTUATING

BANDWIDTH DEMANDS

MODEL AG 5800 SPECIFICATIONS

User True Plug and Play Dynamic Address Translation (DAT) Dynamic Transparent Proxy

Service Provisioning Home Page Redirect

HTTP - Redirect

HTTPS -Redirect

Portal Page Redirect

Session Termination Redirect Information

and Control console

Pop-up (Explicit) Logout Button

International Language Support

External Web Server Mode

Internal Web Server Mode

Secure XML API over SSL

Billing Plan Enablement RADIUS Client

RADIUS (AAA) Proxy

Port Based Policies

Port Mapping

Local Database

Credit Card Interface

PMS Advanced XML Interface

Bill Mirroring

Access Control and

Authentication

Authorization, Authentication and

Accounting (AAA)

Walled Garden

Group Accounts

Tri Mode Authentication

Universal Access Method over SSL

IEEE 802.1x

Smart Client Support (Boingo, iPass)

MAC Authentication

Remember Me Log-in

Advanced Security iNAT

IPSec Support

PPTP Support

Session Rate Limiting (SRL)

User Agent Filtering

Mac Address Filtering

URL Filtering

ICMP Blocking

Proxy ARP for device to

device communication

Policy Based Trafﬁc

Shaping

Bandwidth Management QoS Tagging

Group Bandwidth Management

IP Address Management IEEE 802.3/ 3ul/3ab

IEEE 802.1d

DHCP Server

DHCP Relay

Multiple Subnet Support

IP UPsell

DHCP Client

PPPoE Client

Intelligent Roaming Realm Based Routing Zone Migration

Branding Parameter Passing enabling branding

Network Management Web Management Interface (WMI)

Command Line Interface (CLI)

Integrated VPN Client for Management

RADIUS-Driven Conﬁguration

Multi-level Admin Support

Centralized Radius Authentication

SMTP Redirection

Access Control

Bridge Mode

SNMPv2c

Syslog/AAALog

Media Access Control CSMA/CA

Ports 10/100/1000 Base-T Ethernet, RJ-45 (UTP):

WAN 5 – 10/100/1000 Base-T Ethernet,

RJ-45 (UTP): LAN

Front access RJ-45 port for serial

System Console

DB9 serial port: Property Management

Interface

Power 100 to 240 VAC 50/60 Hz 220 watts

Environment Operating temp 0 to 40C

Operating humidity: 5% to 90% RH

Storage: -20 to 70C

Storage humidity: 5% to 95% RH

(non condensing)

Regulatory FCC Class A

UL, UL (US and Canada) CE

EN 55022: 2010 Class A, EN 61000-3-

2:2006/A1:2009/A2:2009, EN 61000-3-

3:2008

EN55024:2010 (IEC 61000-4-2:2008, IEC

61000-4-3:2006/A1:2007/A2:2010, IEC

6100-4-4:2004/A1:2010, IEC 6100-4-

5:2006, IEC 61000-4-6:2008, IEC 61000-

4-8:2009, IEC 6100-4-11:2004),

Australian Standard AZ/NZS CISPR

22:2009 Class A

CB Scheme

Physical 1U rack mountable

431mm wide x 305mm deep x 44.4mm high

17”x 12” x 1.75”

Weight 10.2 lbs.

Weight: 4.6 kg

LEDs Power Indicator

Status Indicator

10/100/1000 ACT/LINK for each

Ethernet port

Performance 4000 Concurrent Users and or Devices Throughput: Up to 970 Mbps as deﬁned

by RFC1242, Section 3.17

As deﬁned by RFC1242, Section 3.17 - Nomadix Service Engine, Dynamic Address Translation and iNAT are trademarks or registered trademarks of Nomadix, Inc.

Other names and brands may be claimed as the property of others
