A-level Computer Science (7517)
Non-exam assessment (NEA) guidance
(Version 2 – June 2016)
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
Contents
Introduction ................................................................................................................................... 3
1 Selecting and approaching a project ...................................................................................... 4
1.1 Selecting a project ................................................................................................................ 4
1.2 Approaching the Project ....................................................................................................... 5
2 The Project Report ................................................................................................................... 6
2.1 Analysis (9 marks) ............................................................................................................... 6
2.2 Documented design (12 marks) ........................................................................................... 8
2.3 Technical solution (42 marks) .............................................................................................. 9
2.3.1 Completeness of solution (15 marks) .......................................................................... 10
2.3.2 Techniques used (27 marks) ....................................................................................... 10
2.4 Testing (8 marks) ............................................................................................................... 12
2.5 Evaluation (4 marks) .......................................................................................................... 13
3 Documentation requirements ............................................................................................... 14
3.1 Analysis .............................................................................................................................. 14
3.2 Documented design ............................................................................................................ 15
3.3 Technical Solution .............................................................................................................. 16
3.4 Testing ............................................................................................................................... 16
3.5 Evaluation........................................................................................................................... 16
4 Applying the marking scheme ............................................................................................... 17
4.1 Analysis .............................................................................................................................. 17
4.2 Documented design ............................................................................................................ 17
4.3 Technical Solution .............................................................................................................. 17
4.4 Testing ............................................................................................................................... 18
4.5 Evaluation........................................................................................................................... 18
Appendix A .................................................................................................................................. 19
Key changes from AQA A-level Computing Project (COMP4) ................................................... 19
Appendix B .................................................................................................................................. 20
Is a project (7517/C) of A-level standard? .................................................................................. 20
Appendix C .................................................................................................................................. 22
Example lists of objectives ........................................................................................................ 22
Activity for defining objectives .................................................................................................... 23
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
3 of 23
Introduction
The non-exam assessment (NEA) counts towards 20% of the A-level qualification.
The NEA allows students to develop their practical skills in the context of solving a realistic
problem or carrying out an investigation. The NEA is intended to be as much a learning
experience as a method of assessment; students have the opportunity to work independently on a
problem of interest over an extended period, during which they can extend their programming skills
and deepen their understanding of computer science.
The most important skill that should be assessed through the NEA is a student's ability to create a
programmed solution to a problem or investigation. This is recognised by allocating 42 of the 75
available marks to the technical solution and a lower proportion of marks for supporting
documentation to reflect the expectation that reporting of the problem, its analysis, the design of
solution or plan of an investigation and testing and evaluation will be concise.
It is recommended that approximately 50 hours of lesson time are allocated to the completion of
NEA.
This resource offers some advice on how to tackle the NEA and what to include in the
documentation.
You should also refer to the A-level Computer Science specification sections relating to NEA
• 4.13 Systematic approach to problem solving
• 4.14 Non-exam assessment – the computing practical project
o 4.14.3 Marking Criteria
• 5 Scheme of Assessment
• 6 Non-exam assessment administration
For centres currently following the AQA Computing specification (2510), a summary of the most
significant differences between the NEA for the new A-level Computer Science specification and
the coursework (COMP4) for the outgoing A-level Computing specification is in Appendix A.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
4 of 23
1 Selecting and approaching a project
1.1 Selecting a project
The project will take a significant amount of time to complete and contributes 20% to the overall
A-level grade. It is important that a student selects an appropriate subject for the project that:
• can maintain their interest over a long time period
• is suitably challenging so that it will enable them to fulfil their learning potential
• will enable them to access the full mark range
• can be supported and assessed by the teacher.
It is the student who must decide upon the project subject, but it is expected that the teacher
should also be involved. Students can choose between:
• Solution to a problem
The student selects a problem and develops a system to solve it. Typically, the solution
would be developed for a third party. There is no requirement for there to be an end user,
but having one is likely to be useful. Examples of this type of project include:
o a simulation, eg of a business or scientific nature, or a well-known problem such as
Conway's Game of Life (see
https://en.wikipedia.org/wiki/Conway%27s_Game_of_Life)
o a solution to data processing problem for a business, eg stock control, membership
systems
o the solution of an optimisation problem, eg production of a rota, shortest-path
problems, route finding
o a computer game with a dynamically created maze
o an application of artificial intelligence
o a control system, operated using a device such as an Arduino board
o a website with dynamic content, driven by a database back-end
o an app for a mobile phone or tablet to remotely control a server.
• Investigation
The student selects an area of the subject that they are interested in and conducts an
investigation of this area, with the focus being on programming. For an investigation, the
student would need a supervisor with some knowledge of the area being investigated.
Examples of this type of project include:
o machine learning algorithms
o 3D graphics rendering
o analysis of live data feeds, eg Twitter feeds
o investigation into the use of neural networks, eg as a noughts and crosses player
o exploring large datasets for correlations, eg the World Bank’s datasets (see
http://data.worldbank.org), and creating useful visualisations of these correlations to
answer interesting questions
o scientific investigations, eg where an analytic solution is not possible.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
5 of 23
For both types of project, the structure of the documentation required is essentially the same, with
minor differences where necessary.
In individual centres the problem chosen by a student to solve or investigate should be sufficiently
different to that of other students to avoid the work of one student informing the work of another
because they are working on the same problem or investigation. Teachers are required to record
on the Candidate Record Form for each student that they have followed this guideline. If in any
doubt on whether problems chosen by students have the potential to raise this issue, please
contact your AQA advisor.
It is expected that a task that is selected will be of A-level standard. See Appendix B for
examples of what this means, and how to deal with projects that are not of A-level standard.
Selecting the subject for the project could be done at the end of the first year of the A-level or at
the start of the second year. At this point, it may be that some of the techniques required to
complete the project (eg SQL, some data structures) have not been taught, so the teacher will
need to ensure that the project is realistically achievable.
1.2 Approaching the Project
It is not expected that a student will follow any particular formal software engineering methodology,
such as the waterfall model, when working on their project. The different sections of the project
report indicate the order that work should be presented for marking, not the order that it must be
completed in.
Research
Student’s need to research the problem they are going to tackle at the start of the project, which
will involve some analysis. It is important that at this stage a well-defined set of measurable
objectives are written so that the student and teacher have a common understanding of what the
student hopes to achieve and so that the student can gauge their progress.
Critical Path
Once a student has a thorough understanding of the problem, they should be encouraged to
identify what the critical path to be followed to produce a solution is, ie what are the key tasks that
need to be completed to produce a solution. A student should be encouraged to focus on
achieving these before working on more ancillary aspects of the problem such as a user
registration and login system.
Designing
It is unlikely to be a good idea for a student to try to design all aspects of a solution before starting
to code it. This methodology is outdated and inappropriate, particularly in the context of a project
during which a student is likely to be learning new programming techniques as the project
develops. Therefore, an agile approach should be adopted where students design, code and test
one aspect of their system before moving on to the next, iteratively using experience from testing
(and feedback from users where appropriate) to improve their design and coding. Evidence does
not need to be gathered to show this development process taking place.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
6 of 23
2 The Project Report
The project report should be presented in the following order.
1. Analysis
2. Documented design
3. Technical solution
4. Testing
5. Evaluation
This does not mean that the evidence must be produced in this order. Further detail on what
should be included in each section is included below.
The project documentation should be clearly organised, including appropriate titles, page
numbering and a contents page so that evidence can be easily found and referred to.
You should also refer to the NEA marking criteria in the A-level specification, section 4.14.3
2.1 Analysis (9 marks)
Analysis enables student’s to gain a deep understanding of the problem. This in turn allows the
student to identify the objectives for the project, giving a clear purpose and direction for their
design and solution development.
• Methods and sources: Students should be encouraged to use a range of appropriate methods
and sources to research and investigate the problem, including websites, existing software,
books, interviews, questionnaires, prototyping.
Relevant and genuine evidence should be presented in the report (most likely in an appendix,
but referenced in the main report) but students should be discouraged from generating evidence
unnecessarily or artificially.
• Identifying a third party: It will be useful if a third party (that is someone other than the
student) is involved in the analysis process. The third party might be a potential end-user of the
software, such as a friend, relative, employee or teacher or somebody with knowledge, interest
or expertise in the problem area. Their role is to support the student in investigating the
problem, deciding upon the objectives and to give feedback, particularly at the end of the
project.
For an investigative project, the third party is most likely to be the person who has agreed to act
as the student’s supervisor. The objectives should be established early on and fixed at a point
in time agreed with the third party and the teacher responsible for monitoring the student’s
project.
• Further research: It is accepted that the student’s depth of understanding of the problem will
grow and develop as the project progresses. They should be encouraged to carry out further
relevant research and after consultation with their teacher, refine and reassess their initial
objectives as appropriate. The teacher should be the final arbiter and base their judgement on
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
7 of 23
the initially agreed set of objectives and the scope appropriate for the abilities of the student and
the nature of the project.
• Prototyping and critical path: Prototyping the critical path at the analysis stage, early in the
project development period, is encouraged so that changing objectives later on occurs only in
exceptional circumstances, and with the agreement of the teacher. The achievement of the
objectives will have an effect on determining the mark awarded for the coding of the project.
A point in time should be reached when the agreed set of objectives is frozen. This cut-off point
should be early in the project development period once the critical path has been established
and assessed as achievable.
We recommend that students are given time to carry out prototyping early in the project
development period, eg the first term of Year 13, in order to investigate and test key algorithms,
data structures and data stores and most importantly demonstrate that the critical path of the
problem can be solved in the available time.
This is valuable in enabling students to assess the feasibility and scope of their objectives.
However, the initial objectives and the involvement of the third party are important in providing a
reference point and structure for the project.
• Required documentation for ‘Analysis’: this section of the report should include:
o a clear statement that describes the problem area and the specific problem being solved /
investigated
o an outline of how the problem was researched
o a statement indicating who the problem is being solved / investigated for
o background in sufficient detail for a third party to understand the problem being solved /
investigated
o a numbered list of measurable, "appropriate" specific objectives, covering all required
functionality of the solution or areas of investigation (‘appropriate’ means the specific
objectives are single purpose and at a level of detail that is without ambiguity)
o any modelling of the problem that will inform the Design stage, for example a graph /
network model of Facebook connections or an E-R model, state diagrams, scientific /
mathematical models or formulae, data flow diagrams.
The setting of well-defined, appropriate objectives is the most important part of the analysis, as
these objectives will eventually be used to assess the success of the project and award marks to
the solution produced. See Appendix C for examples of objectives.
There are three mark levels that can be awarded for ‘Analysis’. Section 4.14.3.1 of the A-level
specification gives details of the level descriptors.
If a student sets objectives that go beyond the scope of what is required at A-level, these should be
indicated as extension objectives by the student, in consultation with the teacher responsible for
the student’s project. If the objectives were not achieved, this would not prevent a student from
achieving the highest available marks for the final developed system.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
8 of 23
2.2 Documented design (12 marks)
The importance of design is to assist a student to produce a working, efficient solution to a problem
and to enable maintenance of the system at a later date. Evidence for this section of the project
report can be produced before, after or during the coding of the system.
• Sequencing: It is often useful to complete some elements of the design, such as planning data
structures, before coding takes place. This helps students avoid making mistakes which may
result in unnecessary work and recoding at a later stage. Other elements of the design that
would be useful for maintenance could have their design documented after they have been
coded.
For students, design is also an opportunity to convey the level of technical sophistication of their
solution.
We recognise that design, coding and testing are inherently iterative processes, and not three
distinct stages, carried out, one after another. After designing some parts of a system, a
student might then go on and code these before other parts of the system are designed in
detail. After coding part of a solution it is likely that this part will be tested, which may result in
possible recoding and / or redesign.
• Required documentation for ‘Documented design’: The type of system that a student is
developing will determine the aspects of the system that need to be covered in the documented
design. It is anticipated that for all systems, a high-level overview of how different parts of the
system interact would be useful. This may be a:
o structure / hierarchy chart
o a system flowchart
o a data flow diagram, or object / class diagrams, accompanied by any further explanation
that is helpful
o non-standard diagrams that combine elements of data flow and program control flow are
acceptable, as long as the two can be clearly distinguished.
Students should also document how the important parts of their system work. Possible
items that might be present in design could be:
o Algorithms: Processing of data should be at the heart of all projects. Students need to
show and explain sample algorithm(s) that their project uses. These could be user-defined
or standard algorithms, but should be chosen to demonstrate the sophistication of the
system and should be key algorithms that are essential to the success of the project.
Pseudo-code, Structured English or any other appropriate methodology could be used.
o Data structures: If a project makes use of data structures in memory, these should be
explained. Simple structures, such as arrays of records, might only require a short
explanation, while a more complex structure, such as a queue, linked list or hash table
could be explained in more detail.
o File structure and organisation: If a project stores data directly in files, the structure of
the records in these files should be described, together with how the records are organised
for access and inter-relationships between files.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
9 of 23
o Database design: If a project stores data in a database, the structure of the tables should
be described and an entity-relationship diagram could be used to show how the tables are
related.
o Queries: If a project uses a database, samples of the queries that are used, together with
explanations should be provided. The samples chosen should illustrate the sophistication
of the system.
o HCI: In almost all cases, it is expected that there will be on-screen interaction between the
student's system and the user. A small number of samples of screen / hard copy, with
explanations and reasons should be presented. We recognise that most students will
design their HCI on screen, using the features of their chosen programming environment.
Therefore, evidence of HCI can be presented as explained screenshots rather than
hand-drawn or package-drawn plans.
o Hardware selection/design: For most projects, students are unlikely to have a choice of
hardware to use, so this section will not need to be addressed. However, some projects
are more focussed on the use of hardware, such as Arduino boards. For these projects, it
would be appropriate to explain the suitability of the hardware and to present, by any
appropriate method, information about the design of the hardware or how the hardware is
used by the project.
• Evidence required: Students should provide evidence of those things that are relevant to their
own project; the list above is not intended as a checklist, on which every item needs to be ticked
off. If a project focuses particularly heavily on certain technical areas, then we would expect
more evidence for these areas to demonstrate that although other areas may not be covered at
all, the project is of suitable difficulty.
The list above is not intended to be exhaustive; students are free to present other types of
evidence that are relevant and useful to their project. For example, a student producing a
simulation project might decide to include lifecycle diagrams for entities.
There are four mark levels that can be awarded for ‘Documented design’. Section 4.14.3.2 of the
A-level specification gives details of the level descriptors.
2.3 Technical solution (42 marks)
Credit for the technical solution is awarded based upon two distinct aspects (see illustration on
page 11):
• Completeness of solution (15 marks) (see below, section 2.3.1)
• Techniques used (27 marks) (see below, section 2.3.2)
The key evidence that a student needs to provide for this section is their commented program
code. Good commenting and the use of self-documenting techniques for programming, such as
meaningful identifiers, will make this section easier to assess.
When including the program code, it would be helpful if it were broken down into titled sections and
perhaps indexed to aid the identification of evidence.
Students are free to include any other evidence that might highlight the technical quality of the
work completed.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
10 of 23
2.3.1 Completeness of solution (15 marks)
Marks are awarded based upon how much of the proposed system the student has created. To
enable this section to be assessed, it is of vital importance that a student has produced a sound
and detailed set of objectives in the analysis and that appropriate testing has been carried out to
evidence the achievement of the objectives.
If a student has not produced a suitable set of objectives in the analysis, then this mark should be
awarded on the basis of what the assessor believes a reasonable set of objectives for the project
would have been. Similarly, if a student has attempted to define the objectives in such a way as to
make it unjustifiably easy to achieve the marking criteria, then the assessor should consider what
they believe a reasonable set of objectives to be.
There are three mark levels that can be awarded for ‘Completeness of solution’. Section
4.14.3.3.1 of the A-level specification gives details of the level descriptors.
It is possible that a student might have identified in the analysis extension objectives that go
beyond A-level standard. A failure to achieve any of these objectives should not prevent the
student from being awarded a mark for having achieved "all or almost all" of the objectives
assuming that the objectives which were not classified as being extension objectives have been
achieved.
2.3.2 Techniques used (27 marks)
This section assesses the technical skills demonstrated in the solution the student has created.
Analysis of the program code written should be the main route through which the technical skills
demonstrated by the student are identified. However, this judgement could be assisted by other
evidence:
a) The documented design should include evidence of the data structures and algorithms the
student intended to use.
b) Comments should be included in the program code to highlight where techniques have
been used.
c) The teacher could look at the program code with a student present and ask the student to
explain what they have done and how.
d) The teacher could ask students to write notes to point out where in their program code they
have used particular techniques.
(a) to (d) can be used to assist in deciding on a mark, but the mark must be determined by what is
seen in the program code as, for example, the student might plan a sophisticated algorithm but not
fully implement it, or exaggerate what they have done in a discussion.
There are three mark levels that can be awarded for ‘Techniques used’. Sections 4.14.3.3.2 and
4.14.3.4 of the A-level specification provide detailed guidance about the types of technical skills
that need to be demonstrated for each level.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
11 of 23
Within a level, the specific mark to award is determined by:
• the extent to which the criteria for the mark level have been achieved
• the quality of the coding style that the student has demonstrated
• the effectiveness of the solution.
Section 4.14.3.4.2 of the A-level specification illustrates the qualities that should be looked for
when determining the quality of the coding style.
Summary of how to award the mark for the ‘Technical solution’
Add two marks together
(Max 42 marks in total)
Programmed
solution
Look at how many
objectives have been
achieved (completeness)
and the importance of
these to select a level
from 1 to 3 and the mark
to award within this level.
(Max 15 marks)
Look at the programming
techniques used to
determine a level from 1 to 3.
Consider extent to which
level criteria met, quality
of coding style and
effectiveness, to arrive at an
exact mark within the level.
(Max 27 marks)
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
12 of 23
2.4 Testing (8 marks)
Testing demonstrates that the student has, or has not, achieved the objectives identified in the
analysis. It is not necessary to provide evidence of testing, or planning to test all aspects of the
operation of the system, and the candidate should select and provide evidence of testing those
aspects which most clearly demonstrate that the project fulfils its purpose.
There is no simple answer to the question of how many tests need to be carried out. Ideally, the
tests completed should show that the system developed has fulfilled its purpose and demonstrates
to the assessor the scope of the final system.
Testing does not all need to be carried out on the final version of the system. It is acceptable for
testing evidence to be gathered during earlier stages in the development of the system. Informal
testing during development has a higher chance of failing and this should not cause a student to
fail to document this but rather provides an opportunity to discuss, fix and retest.
• Investigative type projects: It is possible that a student might choose an investigative type of
problem for their project, where the detailed outcome of runs of the system on input data is
unknown. For example, if a simulation is produced, the whole purpose of the system might be
to see what happens under certain conditions and testing the core processing functions of the
project would involve experimentation.
With such projects, there might be some tests with known correct outcomes that could be
conducted on the parts of the system that can be predicted. The test evidence could also
include examples of runs of the system where the outcome is unknown, and so cannot be
specified in a test plan other than as a goal, eg the effect of income on life expectancy, together
with explanations of what they show. Students attempting such projects should not be
penalised for being unable to specify expected outcomes for tests.
Required documentation for ‘Testing’: Evidence showing that the system works must be
presented to enable the assessor to understand how many of the objectives have been achieved
when marking the programmed solution section. It is expected that the assessor will have seen
the system running when coming to a judgement about this, but the testing evidence can provide
further evidence of this and also helps to confirm the assessor's judgements to a moderator.
For each test carried out, it is expected that the student will describe and comment on the outcome
of the test. This could be achieved by a test plan or by writing a commentary alongside the
screenshots obtained that show test evidence. A suitable explanation of a test would include:
o its purpose if not self-evident
o the test data used
o the expected test outcome
o the actual outcome with a sample of the evidence, for example screen shots of before and
after the test, etc, sampled in order to limit volume.
There are four mark levels that can be awarded for ‘Testing’. Section 4.14.3.5 of the A-level
specification gives details of the level descriptors.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
13 of 23
2.5 Evaluation (4 marks)
Evaluation allows the student to reflect on the success of the project in meeting the objectives
identified in Analysis. The student should also reflect on feedback from the third party and discuss
potential improvements and extensions to the solution.
Required documentation for ‘Evaluation’: This section of the report should include:
o an explanation of how well the objectives have been met and how this was achieved
o a discussion of how the solution could be improved
o analysis of feedback from the third party who was involved at the analysis stage.
A sensible approach would be to copy the objectives from the analysis into the evaluation so that
each can be easily commented on. For each objective, the student could judge how effectively it
has been met and also comment (if appropriate) on how the solution might be improved in this
area.
The student should aim to explain, in outline, how they might go about implementing the possible
improvements. It is important that any third party feedback obtained is analysed by the students,
not simply included as, for example, an email from the person.
In addition to commenting on the individual objectives, students should also give an overview of
the effectiveness of their solution, as it may be that some points would not be covered by
commenting on the objectives alone. For example, some ideas for improving the system might be
outside of the selected objectives.
The actual feedback obtained from the third party should be included in an appendix. If feedback
was also obtained at an earlier stage in the production of the project, for example based upon a
prototype, then this could be referenced to in this evaluation so that it could be considered for
credit.
There are four mark levels that can be awarded for ‘Evaluation. Section 4.14.3.6 of the A-level
specification gives details of the level descriptors.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
14 of 23
3 Documentation requirements
In this section we provide an overview as to the requirements for each section of the
documentation.
Whilst each project is different and therefore a check list of requirements is not appropriate we
have tried in this section to identify what we feel are core, desirable and supplementary elements
that could appear in each section of a project.
A high scoring project might not have all of the supplementary elements and some will be more
appropriate to a problem solving project compared to an investigation.
3.1 Analysis
Proposed solution details (hardware/software)
Acceptable limitations (limitations agreed with the end-user / supervisor)
Data volumes
Log / diary of research collection
Current System (if appropriate)
Identification of end-user / supervisor
Prospective users
Modelling of the problem (initial DFD, data dictionary)
Research around the investigation area (if appropriate)
Background to project
Evidence of analysis
Set of objectives
C
O
R
E
E
S
I
R
A
B
L
E
S
U
P
P
L
E
M
E
N
T
A
R
Y
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
15 of 23
3.2 Documented design
It is important for a student to design how the important parts of their system work.
If, for example, the project is based around simulating the orbits of planets then the equations and
algorithms required for calculating these orbits and updating any display would be an important
part of the design. A focus on just the user interface with limited discussion of algorithms would
not be a fully articulated design.
System security and integrity of data:
If a student has decided to encrypt data in a database or when transmitting data between a client
and server you would expect this to be discussed in the design section.
It also might be appropriate for a student to recognise the need for deleting related data when a
user is deleted to keep referential integrity.
These sorts of considerations tend to surface more in sophisticated systems where a student also
has a good understanding as to issues such as security and integrity of data.
High-level overview
Description of algorithms
Description of data structures
Database design
Design of user interface
System security and integrity of data
For an investigative project; a log of stages taken during
the investigation and how this affected the coding
Hardware selection/design (if appropriate)
High-level overview
Description of algorithms
Description of data structures
Database design
Design of user interface
C
O
R
E
D
E
S
I
R
A
B
L
E
S
U
P
P
L
E
M
E
N
T
A
R
Y
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
16 of 23
3.3 Technical Solution
The technical solution is usually presented in the form of annotated program listings but these can
be provided in a way that makes the marking of the project easier.
The listing could be organised in way that makes it easier to locate certain parts of the solution.
For a web-based project, for example, an initial contents table listing the individual web-pages and
the page where the code can be found would be helpful.
In a similar way for a project based around C# a contents table listing the main objects / sub-
routines and the page where the code can be found would be helpful.
Overview guide:
An overview guide could contain elements to help the marker including:
• directing the marker to the particularly more sophisticated algorithms
• directing the marker to the code that meets the requirements of particularly challenging
objectives.
3.4 Testing
Testing may occur during different parts of the project and when this has happened it is important
that a student clearly reflects this in their project. As part of the testing section it may be
appropriate to contain a table of tests performed at different stages of the project and a link to any
evidence of this.
It would also be appropriate for a student to perform more traditional testing of the solution at the
end of coding where the robustness and completeness of the solution are tested.
The requirement is to provide a representative sample of the testing that has happened across the
project and not record and evidence every individual test.
3.5 Evaluation
The evaluation should contain the following sections:
• a reflection on the overall effectiveness as to how their final outcome meets the original
problem requirements
• an evaluation against each of the objectives set in the analysis section
• independent feedback on their final outcome given by the end-user, supervisor or other
third party of the project
• a discussion reflecting on the feedback received and consideration as to how any changes
could be made
• a consideration as to how the outcome could be improved if the problem / investigation
were to be revisited.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
17 of 23
4 Applying the marking scheme
4.1 Analysis
Having read the analysis section of a project the following questions could be considered when
marking a project:
• Do you have a clear understanding as to the problem that is to be solved (or investigation
to be followed)?
• Has the student undertaken appropriate research into the problem area?
• Is there evidence of dialogue between the student and the end-user / supervisor / third
party?
• Are the objectives defined in such a way that the requirements of the problem will actually
be met?
• Can you identify the core objectives that will underpin whether the technical solution is
complete in terms of the problem requirements?
Objectives
When marking a project consideration must be applied as to whether the objectives set by the
student are of an A-level standard. A project that fully meets a set of unsuitable objectives will not
be considered complete in terms of the technical solution. A selection of objectives taken from
projects are included in Appendix C.
4.2 Documented design
Having read the design section of a project the following questions could be considered when
marking a project:
• Do you have a clear understanding as to how, in principle, the technical solution will work?
• Having identified the key requirements from the analysis are these sufficiently designed to a
good level of detail?
• When comparing to the technical solution do they match up well, eg class methods match
those given in the design model?
4.3 Technical Solution
With a greater focus on the technical solution it is important for the marker to have a good
understanding as to the sophistication of the solution. One method of applying this is to identify the
more challenging objectives and looking for how these have been tackled in the technical solution.
A good project would also have clear testing of these objectives which would provide evidence as
to the completeness of the project.
Hopefully the marker will have seen the technical solution develop over a period of time and
already have an understanding as to the sophistication and quality of the coding.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
18 of 23
Completeness of solution
The measure of completeness is to take into account what would be expected of an A-level project.
In terms of considering the requirements of a solution a focus should be placed on making sure
those that are the most challenging are considered carefully.
Take, for example, a system that is set up to control a stage lighting system using a specific
protocol. If this project had 10 objectives which included aspects of user interface design, ease of
use and one based around the control of the lights then if the technical solution did not control the
lights the project would not be seen as meeting the core requirement.
4.4 Testing
Testing is an opportunity for the student to demonstrate that their solution works and is robust but it
can also provide evidence about the sophistication of the solution.
The testing should focus on the more technically challenging parts of the solution.
Demonstrating that a login system works with a variety of usernames and passwords is good at
showing robustness. However, if the main focus is on scheduling parent evening slots and this is
not tested then the section would not be showing that all of the core requirements have been
achieved.
Having read the testing section of a project the following questions could be considered when
marking a project:
• Does the section demonstrate that thorough testing has been carried out?
• Have the core requirements been tested?
• Is there evidence that the more technically challenging parts of the project have been
tested?
4.5 Evaluation
The evaluation section is an opportunity for the student to reflect on their work and consider how
well they have met the requirements of the problem to be solved.
Having read the evaluation section of a project the following questions could be considered when
marking a project:
• Has the student given consideration as to how well the outcome meets the initial
requirement?
• Has the student reflected on the objectives originally set and considered how their solution
measures up to those objectives?
• Has the student obtained independent feedback and reflected upon this?
The evaluation should be an honest appraisal by the student. It might be, for example, that as the
project has progressed that another way of solving the solution has become apparent but there
was no time to change to this. An honest appraisal would consider this and highlight how this
other way of solving the problem might have been of benefit.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
19 of 23
Appendix A
Key changes from AQA A-level Computing Project (COMP4)
1. The requirement to judge the overall level of complexity of a project has been removed.
2. The proportion of marks allocated to the technical solution has been significantly
increased to 42/75 (56%). COMP4 was 20/75 (27%).
3. In addition to the traditional type of project that requires the production of a solution to a
problem, there is now an alternative type of investigative project.
4. The documentation requirements have been significantly reduced:
a. The following sections are no longer required:
i. System Maintenance
ii. User Guide
b. The following subsections are no longer a core requirement:
i. Analysis: Realistic appraisal of the feasibility of potential solutions
ii. Analysis: Justification of chosen solution
iii. Design: Identification of storage media
iv. Design: Description of measures planned for security and integrity of data
v. Design: Description of measures planned for system security
vi. Design: Overall test strategy
5. There is greater flexibility over the content of the analysis and design sections, to reflect the
wider range of projects that students produce.
6. It has been made explicit that we do not expect students to follow a traditional systems
lifecycle approach when developing their projects.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
20 of 23
Appendix B
Is a project (7517/C) of A-level standard?
If the problem (or investigation) selected for a project is not of A-level standard, mark the project
against the standard marking criteria, but adjust the mark awarded downwards by two marking
levels (two marks in the case of evaluation) in each section for all but the technical solution. For
technical solution, you should have already taken the standard into account for this, by directly
applying the criteria. For example, if a student had produced a 'fully or nearly fully articulated
design of a real problem describing how solution is to be structured/is structured' this would, for an
A-level standard project, achieve a mark in Level Four for Documented Design (10-12 marks). If
the problem selected was too simple to be of A-level standard but the same criteria had been
fulfilled, shift the mark awarded down by two levels, into Level Two, an award of 4-6 marks. If a
downward shift by two levels is not possible, then a mark in the lowest level should be awarded.
The examples below are illustrative of tasks that are not of A-level standard.
Noughts and Crosses
An implementation of noughts and crosses, in which the computer validated the legality of moves
and checked for a winner, would not be of A-level standard. However, the implementation of some
good AI such as the use of a game tree / minimax so that the computer acted as one of the players
would turn the game into a project that is of A-level standard. The range of marks that were
accessible for the technical solution would depend upon the sophistication of the algorithms used
for the AI. A more secure way of ensuring that a project was of A-level standard would be to
choose a more sophisticated game which could include more advanced AI, advanced graphics or
perhaps network communications.
Rota System
A system that stores information about employee availability and shifts that employees are needed
for at a business and matches these two together would be of A-level standard, presuming that it
was the program that carried out the matching process and not the user. If the matching was
completed by an algorithm them the range of marks available for the technical solution would
depend upon the sophistication of the matching algorithm, for example the number of factors taken
into account by it (eg staff holidays, qualifications, desired working hours). If the matching was
carried out by the user then it is unlikely that the project would be of A-level standard.
Encryption
A program that demonstrates the use of a simple encryption method such as the Caesar Cipher is
unlikely to be of A-level standard due to the limited amount of processing done. However, if this
were developed into a more complete system, for example with the option to use alternative types
of cipher, a graphical display of the Caesar Cipher wheels, the ability to load/save data then this
would be of A-level standard but unlikely to achieve a high mark for the technical solution. The
incorporation of a code-cracking option that used techniques such as frequency analysis or
comparing potential solutions to dictionary text to crack a code would offer access to higher marks
for the technical solution, as a result of more sophisticated algorithms being used.
Quiz
A simple quiz program that stored multiple choice questions and answers in a single table or file
and scored a user based upon their answers to the questions would not be of A-level standard.
The additional of functionality for a user to login and for their scores to be saved, and for questions
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
21 of 23
to be edited within the program would make the system of A-level standard. The implementation of
a more sophisticated technique to analyse responses and tailor future quizzes based upon these
has the potential to enable the awarding of a higher mark for the technical solution, as would
making the quiz work across a network using TCP/IP so that players could compete against each
other.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
22 of 23
Appendix C
Example lists of objectives
Project A
These are the full set of objectives from a supermarket product recommendation system:
1. Show confirmation message when changes made to data
2. Users must find it easy to work through the system
3. Pictures should be stored within the database as long binary data
4. The system should be readable to all users
5. The system should not cause any perplexity
6. Random product ID generator should create a random and unique Product ID
7. The system should show any recommendation of the products, depending on the data
produced by the algorithm
8. Secure logging in procedure
It is hard from the set of objectives above to actually understand what the project is intended to do.
For example, it does not identify that the system is to have a checkout system and recommend
products based on what the customer had in their basket. Issues such as calculating the total for a
basket and being able to produce a receipt are not covered but were expected requirements from
reading the problem background section.
Objectives 1, 2, 4 and 5 are not really objectives to measure the technical solution against for
completeness.
Objectives 6 and 7 are beginning to look like suitable objectives but 'the algorithm' was not
discussed in the analysis stage of this project and this is where it should have been defined. Due
to the student not performing enough analysis into how the recommendation system was to work it
can be seen why the student struggled to set a well-defined objective.
Project B
These are a subset of the objectives from a quiz based on puzzles:
3. In order to help the user if they are unable to answer the question, a puzzle must be shown
below the question.
3.1 The answer must be calculated based on the randomly generated question and
displayed on a grid of 16 squares.
3.2 The first 15 of the aforementioned squares must be saved as JPEG images and the
16th should be replaced with an empty square.
3.3 The order of the 16 squares must then be randomised and presented to the user,
below the exam question.
3.4 If it is next to an empty square, the user must be able to move a tile by clicking on it.
3.5 The user must be able to submit an answer, even if the puzzle has not been solved.
4. The questions should be from four different COMP 3 topics: real numbers, regular
expressions, reverse Polish notation and finite state machines.
4.1 For the real numbers topic, the user must be shown a mantissa and exponent, and
asked to convert them to a fraction.
AQA A-level Computer Science - NEA Guidance V2 (June 16)
AQA Education (AQA) is a registered charity (number 1073334) and a company limited by guarantee registered in
England and Wales (number 3644723). Our registered address is AQA, Devas Street, Manchester M15 6EX.
23 of 23
4.2 The regular expressions questions should describe a string and request for the user
to write a regular expression that matches this.
4.3 An input string will be shown to the user, along with a finite state machine and the
user must input the output string for the finite state machines topic.
4.4 For the reverse Polish notation questions, a statement in the form of reverse Polish
notation will be shown and the user will have to convert it to a denary value.
The objectives above are more detailed and clearly give well defined criteria that will help with the
design of the solution, provide measures to test the technical solution against and to finally
appraise against in the evaluation.
Activity for defining objectives
An idea for an activity for defining objectives is to take a known application and ask students to
come up with a list of objectives for that program.
So, for example, for a simple text editor:
• Allow the user to create, save, load and print simple text documents with no formatting
• Word wrap option that be turned on or off
• Font can be changed but only a single font
• Line and column position of cursor displayed in status bar
• Areas of text can be selected and cut, copied, pasted
• Text can be typed at end of existing text or 'inside' the text, causing existing text to move to
the right and down
• Insert/overwrite mode can be toggled
• Documents longer than the screen can be created/handled so scrolling must be
implemented
• Search and Replace facility.

Navigation menu
