J SERIES
WALK BEHIND
MOWERS
JS28 I JS38 I JS48
John Deere Walk-Behind Mowers
• The JS28, JS38 and JS48 all feature durable Briggs & Stratton
engines with a “Fresh Start” cap that automatically drips fuel
stabilizer to help prevent stale gas.
• MowMentum™ Drive System features a pivoting handle, allowing
you to comfortably mow at precisely the right speed with less effort
• JS48 has an electric start for added convenience and a
spin-on oil filter for extended life
• The JS38 and JS48 offer a convenient single lever height-
of-cut adjuster
• Rugged 22-inch steel decks include 3-in-1 blades
Meet the mowers that go easy on you...and your budget.
Engine:
Gross Torque Power** 7.25 7.25 8.75
Displacement 190cc 190cc 190cc
Valves Side Side Overhead
Starting Pull Cord Pull Cord Electric Start with
Pull Cord backup
Choke / Primer Fresh Start & Ready Start Fresh Start & Ready Start Fresh Start & Ready Start
Deck 22” 14 gauge steel 22” 14 gauge steel 22” 14 gauge steel
Blades 3-in-1 for use in all
applications (mulching,
side discharge
and bagging)
3-in-1 for use in all
applications (mulching,
side discharge
and bagging)
3-in-1 for use in all
applications (mulching,
side discharge
and bagging)
Single lever height of cut 4-point Yes Yes
Height of Cut 9 settings
from 1.2” to 4.2”
9 settings
from 1.2” to 4.2”
9 settings
from 1.2” to 4.2”
Discharge Rear/Side Rear/Side Rear/Side
Drive System MowMentum
Drive System™
MowMentum
Drive System™
MowMentum
Drive System™
Transmission Variable drive
transmission;
front wheel
Variable drive
transmission;
rear wheel
Variable drive
transmission;
rear wheel
Variable Speed 0-4 mph 0-4 mph 0-4 mph
Adjustable Handle Standard 3 position Standard 3 position Standard 3 position
Front Wheels Stationary 8 inch Stationary 8 inch Stationary 8 inch
Rear Wheels Stationary 8 inch Stationary 9 inch Stationary 9 inch
Bag; Side Discharge and
Mulch Ready
Standard Standard Standard
Bagger Capacity 2.5 bushel Standard Standard Standard
Total Weight 95 lbs 95 lbs 100 lbs
** Gross Torque Power: a direct way to measure the turning force an engine can produce.
JS38JS28 JS48
SPECIFICATIONS
Single lever height adjuster
makes it convenient to change
the height of cut in nine set-
tings from 1.2" to 4.2".
MowMentum Drive™ allows
the customer to choose the
speed to follow the mower by
pivoting the drive handle.
DSTE50810 (12-01) Litho in USA. Job # 50810
When you buy a John Deere, you’re getting more than just a machine: you’re getting the knowledge and expertise that only comes from a
John Deere dealer. Ask about the variety of service plans available or visit www.readytomow.com to find out how you can get “Service
Delivered” without ever leaving your home.
Behind you all season long: your John Deere dealer
All power levels are stated ft-lbs per SAE J1940 as rated by the engine manufacturer.
The engine horsepower and torque information are provided by the engine manufacturer to be used for comparison purposes only. Actual operating horsepower
and torque will be less. Refer to the engine manufacturer's website for additional information.
This literature has been compiled for worldwide circulation. While general information, pictures and descriptions are provided, some illustrations and text may include
finance, credit, insurance, product options and accessories NOT AVAILABLE in all regions. PLEASE CONTACT YOUR LOCAL DEALER FOR DETAILS. John Deere reserves
the right to change specification, design and price of products described in this literature without notice. John Deere’s green and yellow color scheme, the leaping
deer symbol, and JOHN DEERE are trademarks of Deere & Company.
