This document is a user guide for the Gstreamer version 1.0 based accelerated solution

included in NVIDIA® Tegra® Linux Driver Package for Ubuntu Linux 16.04 on platforms

including Tegra X1 devices.

This document contains the following sections:

 Gstreamer-1.0 Installation and Setup

 Decode Examples

 Encode Examples

 Camera Capture with Gstreamer-1.0

 Video Playback with Gstreamer-1.0

 Video Format Conversion with Gstreamer-1.0

 Video Scaling with Gstreamer-1.0

 Video Cropping with Gstreamer-1.0

 Video Transcode with Gstreamer-1.0

 CUDA Video Post-Processing with Gstreamer-1.0

 Video Rotation with Gstreamer-1.0

 Interpolation Methods for Video Scaling

 EGLStream Producer Example

 EGL Image Transform Example

 Gstreamer Build Instructions

 Nvgstcapture-1.0 Option Reference

 Video Encoder Features

 Supported USB Camera

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 2

GSTREAMER-1.0 INSTALLATION AND SETUP

This section describes how to install and configure Gstreamer.

To install Gstreamer-1.0

 Install Gstreamer-1.0 on the platform with the following commands:

sudo add-apt-repository universe

sudo add-apt-repository multiverse

sudo apt-get update

sudo apt-get install gstreamer1.0-tools gstreamer1.0-alsa gstreamer1.0-

plugins-base gstreamer1.0-plugins-good gstreamer1.0-plugins-bad

gstreamer1.0-plugins-ugly gstreamer1.0-libav

sudo apt-get install libgstreamer1.0-dev libgstreamer-plugins-base1.0-

dev libgstreamer-plugins-good1.0-dev libgstreamer-plugins-bad1.0-dev

To check the Gstreamer-1.0 version

 Check the Gstreamer-1.0 version with the following command:

gst-inspect-1.0 –-version

Gstreamer version 1.0 includes the following gst-omx video decoders:

Video Decoder Description

omxh265dec OpenMAX IL H.265 Video Decoder

omxh264dec OpenMAX IL H.264 Video Decoder

omxmpeg4videodec OpenMAX IL MPEG4 Video Decoder

omxvp8dec OpenMAX IL VP8 Video Decoder

omxvp9dec OpenMAX IL VP9 video decoder

Gstreamer version 1.0 includes the following gst-omx video encoders:

Video Encoders

Description

omxh264enc OpenMAX IL H.264/AVC video encoder

omxh265enc OpenMAX IL H.265/AVC video encoder

omxvp8enc OpenMAX IL VP8 video encoder

Gstreamer version 1.0 includes the following gst-omx video sinks:

Video Sink

Description

nvoverlaysink OpenMAX IL videosink element

nvhdmioverlaysink

(deprecated) OpenMAX IL HDMI videosink element

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 3

Gstreamer version 1.0 includes the following egl image video sinks:

Video Sink Description

nveglglessink EGL/GLES videosink element

Gstreamer version 1.0 includes the following proprietary NVIDIA plugins:

Video Sink

Description

nvvidconv Video format conversion & scaling

nveglstreamsrc Acts as Gstreamer Source Component, accepts

EGLStream from EGLStream producer

nvvideosink Video Sink Component. Accepts YUV-I420 format and

produces EGLStream (RGBA)

nvegltransform Video transform element for NVMM to EGLimage

(supported with nveglglessink only)

Gstreamer version 1.0 includes the following libjpeg based JPEG image video

encode/decode plugins:

Video Sink

Description

nvjpegenc JPEG encoder element

nvjpegdec JPEG decoder element



Note: Execute the following command on the target before starting the

video decode pipeline using gst-launch or nvgstplayer.

export DISPLAY=:0

Start the X server with xinit &, if it is not already running.

DECODE EXAMPLES

The examples in this section show how you can perform audio and video decode with

Gstreamer.



Note: Gstreamer version 0.10 support is deprecated in Linux for Tegra

(L4T) Release 24.2. Use of Gstreamer version 1.0 is recommended for

development.

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 4

Audio Decode Examples Using gst-launch-1.0

The following examples show how you can perform audio decode using Gstreamer-1.0.

AAC Decode (OSS software decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.audio_0 ! queue ! avdec_aac ! audioconvert ! alsasink -e

AMR-WB Decode (OSS software decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.audio_0 ! queue ! avdec_amrwb ! audioconvert ! alsasink -e

AMR-NB Decode (OSS software decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.audio_0 ! queue ! avdec_amrnb ! audioconvert ! alsasink -e

MP3 Decode (OSS software decode)

gst-launch-1.0 filesrc location=<filename.mp3> ! mpegaudioparse !

avdec_mp3 ! audioconvert ! alsasink -e



Note: To route audio over HDMI, set the alsasink property device to the

following:

hw:Tegra,3

Video Decode Examples Using gst-launch-1.0

The following examples show how you can perform video decode on Gstreamer-1.0.

H.264 Decode (NVIDIA accelerated decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.video_0 ! queue ! h264parse ! omxh264dec ! nveglglessink -e

H.265 Decode (NVIDIA accelerated decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.video_0 ! queue ! h265parse ! omxh265dec ! nvoverlaysink -e



Note: Decoding H.265 streams requires Gstreamer version 1.4.x or later,

including support for h265parse and qtdemux. See Gstreamer Build

Instructions in this guide for details.

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 5

VP8 Decode (NVIDIA accelerated decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.video_0 ! queue ! omxvp8dec ! nvoverlaysink -e



Note: When you do not use the primary display to render video, use the

display-id property of nvoverlaysink. For example, refer to the

pipeline below.

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.video_0 ! queue ! omxvp8dec ! nvoverlaysink display-id=1 -e

MPEG-4 Decode (NVIDIA accelerated decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.video_0 ! queue ! mpeg4videoparse ! omxmpeg4videodec !

nveglglessink -e

Image Decode

gst-launch-1.0 filesrc location=<filename.jpg> ! nvjpegdec !

imagefreeze ! xvimagesink -e

ENCODE EXAMPLES

The examples in this section show how you can perform audio and video encode with

Gstreamer.

Audio Encode Examples Using gst-launch-1.0

The following examples show how you can perform audio encode on Gstreamer-1.0.

AAC Encode (OSS software encode)

gst-launch-1.0 audiotestsrc ! 'audio/x-raw, format=(string)S16LE,

layout=(string)interleaved, rate=(int)44100, channels=(int)2' !

voaacenc ! qtmux ! filesink location=test.mp4 -e

AMR-WB Encode (OSS software encode)

gst-launch-1.0 audiotestsrc ! 'audio/x-raw, format=(string)S16LE,

layout=(string)interleaved, rate=(int)16000, channels=(int)1' !

voamrwbenc ! qtmux ! filesink location=test.mp4 -e

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 6

Video Encode Examples Using gst-launch-1.0

The following examples show how you can perform video encode with Gstreamer-1.0.

H.264 Encode (NVIDIA accelerated encode)

gst-launch-1.0 videotestsrc ! 'video/x-raw, format=(string)I420,

width=(int)640, height=(int)480' ! omxh264enc ! 'video/x-h264, stream-

format=(string)byte-stream' ! h264parse ! qtmux ! filesink

location=test.mp4 -e

H.265 Encode (NVIDIA accelerated encode)

gst-launch-1.0 videotestsrc ! 'video/x-raw, format=(string)I420,

width=(int)640, height=(int)480' ! omxh265enc ! filesink

location=test.h265 -e

VP8 Encode (NVIDIA accelerated encode)

gst-launch-1.0 videotestsrc ! 'video/x-raw, format=(string)I420,

width=(int)640, height=(int)480' ! omxvp8enc ! qtmux ! filesink

location=test.mp4 -e

MPEG-4 Encode (OSS software encode)

gst-launch-1.0 videotestsrc ! 'video/x-raw, format=(string)I420,

width=(int)640, height=(int)480' ! avenc_mpeg4 ! qtmux ! filesink

location=test.mp4 -e

H.263 Encode (OSS software encode)

gst-launch-1.0 videotestsrc ! 'video/x-raw, format=(string)I420,

width=(int)704, height=(int)576' ! avenc_h263 ! qtmux ! filesink

location=test.mp4 -e

Image Encode

gst-launch-1.0 videotestsrc num-buffers=1 ! 'video/x-raw,

width=(int)640, height=(int)480, format=(string)I420' ! nvjpegenc !

filesink location=test.jpg -e

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 7

Supported H.264/H.265 Encoder Features with

Gstreamer-1.0

This section describes example gst-launch-1.0 usage for features supported by the

NVIDIA accelerated H.264/H.265 encoder.



Note: Display detailed information on omxh264enc or omxh265enc encoder

properties with the gst-inspect-1.0 [omxh264enc | omxh265enc]

command.

Set I-frame interval

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

iframeinterval=100 ! qtmux ! filesink location=test.mp4 -e

Set temporal-tradeoff (the rate the encoder should drop frames)

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

temporal-tradeoff=1 ! qtmux ! filesink location=test.mp4 -e

Configuring temporal tradeoff causes the encoder to intentionally, periodically, drop

input frames. The following modes are supported:

Mode Description

0 Disable

1 Drop 1 in 5 frames

2 Drop 1 in 3 frames

3 Drop 1 in 2 frames

4 Drop 2 in 3 frames

Set rate control mode

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

control-rate=1 ! qtmux ! filesink location=test.mp4 -e

The following modes are supported:

Mode Description

0 Disable

1 Variable bit rate

2 Constant bit rate

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 8

3 Variable bit rate with frame skip. The encoder skips

frames as necessary to meet the target bit rate.

4 Constant bit rate with frame skip

Set quantization range for I, P and B frame

The format for the range is the following:

”<I_range>:<P_range>:<B_range>”

Where <I_range>, <P_range> and <B_range> are each expressed as hyphenated

values, as shown in the following example:

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc qp-

range="10,30:10,35:10,35" ! qtmux ! filesink location=test.mp4 -e

The range of B frames does not take effect if the number of B frames is 0.

Set hardware preset level

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

quality-level=0 ! qtmux ! filesink location=test.mp4 -e

The following modes are supported:

Mode

Description

0 UltraFastPreset

1

FastPreset

Only Integer Pixel (integer-pel) block motion is

estimated. For I/P macroblock mode decision, only

Intra 16 x 16 cost is compared with Inter modes costs.

Supports Intra 16 x 16 and Intra 4 x 4 modes.

2

MediumPreset

Supports up to Half Pixel (half-pel) block motion

estimation. For an I/P macroblock mode decision, only

Intra 16 x 16 cost is compared with Inter modes costs.

Supports Intra 16 x 16 and Intra 4 x 4 modes.

3

SlowPreset

Supports up to Quarter Pixel (Qpel) block motion

estimation. For an I/P macroblock mode decision, Intra

4 x 4 as well as Intra 16 x 16 cost is compared with

Inter modes costs. Supports Intra 16 x 16 and Intra 4 x

4 modes.

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 9

Set profile

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

profile=8 ! qtmux ! filesink location=test.mp4 -e

From omxh264enc, the following profiles are supported:

Profile

Description

1 Baseline profile

2 Main profile

8 High profile

Set number of B frames between two reference frames

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

num-B-Frames=2 ! qtmux ! filesink location=test.mp4 –e



Note: B-frame-encoding is not supported with omxh265enc.

Insert SPS and PPS at IDR

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

insert-sps-pps=1 ! qtmux ! filesink location=test.mp4 –e

If enabled, a sequence parameter set (SPS) and a picture parameter set (PPS) are inserted

before each IDR frame in the H.264/H.265 stream.

Enable two-pass CBR

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

EnableTwopassCBR=1 control-rate=2 ! qtmux ! filesink location=test.mp4

–e

Two-pass CBR must be enabled along with constant bit rate (control-rate=2).

Set virtual buffer size

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

vbv-size=10 ! qtmux ! filesink location=test.mp4 –e

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 10

If the buffer size of decoder or network bandwidth is limited, configuring virtual buffer

size can cause video stream generation to correspond to the limitations according to the

following formula:

virtual buffer size = vbv-size * (bitrate/fps)

Slice-header-spacing with spacing in terms of MB

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

slice-header-spacing=200 bit-packetization=0 ! qtmux ! filesink

location=test.mp4 –e

The parameter bit-packetization=0 configures the network abstraction layer

(NAL) packet as macroblock (MB)-based, and slice-header-spacing=200

configures each NAL packet as 200 MB at maximum.

Slice header spacing with spacing in terms of number of bits

gst-launch-1.0 videotestsrc num-buffers=200 ! 'video/x-raw,

width=(int)1280, height=(int)720, format=(string)I420' ! omxh264enc

slice-header-spacing=1024 bit-packetization=1 ! qtmux ! filesink

location=test1.mp4 –e

The parameter bit-packetization=1 configures the network abstraction layer

(NAL) packet as size-based, and slice-header-spacing=1024 configures each NAL

packet as 1024 bytes at maximum.

CAMERA CAPTURE WITH GSTREAMER-1.0

For nvgstcapture-1.0 usage information enter the following command:

nvgstcapture-1.0 --help

The nvgstcapture-1.0 application uses the v4l2src plugin to capture still images

and video.

The following table shows USB camera support.

USB Camera Support

Feature

YUV

Preview display

Image capture (VGA, 640 x 480)

Video capture (480p, 720p, H.264/VP8 encode)

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 11

raw-yuv Capture (I420 format) and preview display with xvimagesink

gst-launch-1.0 v4l2src device="/dev/video0" ! "video/x-raw, width=640,

height=480, format=(string)I420" ! xvimagesink -e

VIDEO PLAYBACK WITH GSTREAMER-1.0

For nvgstplayer-1.0 usage information enter the following command:

nvgstplayer-1.0 --help

Video can be output to HD displays using the HDMI connector on the platform. The

Gstreamer-1.0 application supports currently the following video sinks:

Overlay Sink (Video playback on overlay in full-screen mode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux !

h264parse ! omxh264dec ! nvoverlaysink –e

nveglglessink (Windowed video playback, NVIDIA EGL/GLES videosink)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux !

h264parse ! omxh264dec ! nveglglessink –e

This nvgstplayer-1.0 application supports specific window position and dimensions for

windowed playback:

nvgstplayer-1.0 –i <filename> --window-x=300 –window-y=300 –window-

width=500 –window-height=500

VIDEO FORMAT CONVERSION WITH GSTREAMER-1.0

The NVIDIA proprietary nvvidconv Gstreamer-1.0 plug-in allows conversion between

OSS (raw) video formats and NVIDIA video formats. The nvvidconv plug-in currently

supports the format conversions described in this section

raw-yuv Input Formats

Currently nvvidconv supports the I420, UYVY, and NV12 raw-yuv input formats.

gst-launch-1.0 videotestsrc ! 'video/x-raw, format=(string)UYVY,

width=(int)1280, height=(int)720' ! nvvidconv !

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 12

'video/x-raw(memory:NVMM), format=(string)I420’ ! omxh264enc !

'video/x-h264,

stream-format=(string)byte-stream' ! h264parse ! qtmux ! filesink

location=test.mp4 -e

raw-gray Input Formats

Currently nvvidconv supports the GRAY8 raw-gray input format.

gst-launch-1.0 videotestsrc ! 'video/x-raw, format=(string)GRAY8,

width=(int)1280, height=(int)720’ ! nvvidconv !

'video/x-raw(memory:NVMM), format=(string)I420’ ! omxh264enc !

'video/x-h264,

stream-format=(string)byte-stream' ! h264parse ! qtmux ! filesink

location=test.mp4 –e

raw-yuv Output Formats

Currently nvvidconv supports the I420 and UYVY the raw-yuv output formats.

gst-launch-1.0 filesrc location=640x480_30p.mp4 ! qtdemux ! queue !

h264parse ! omxh264dec ! nvvidconv ! 'video/x-raw, format=(string)UYVY'

! xvimagesink –e

raw-gray Output Formats

Currently nvvidconv supports the GRAY8 raw-gray output format.

gst-launch-1.0 filesrc location=640x480_30p.mp4 ! qtdemux ! queue !

h264parse ! omxh264dec ! nvvidconv ! 'video/x-raw,

format=(string)GRAY8' ! videoconvert ! xvimagesink –e

VIDEO SCALING WITH GSTREAMER-1.0

The NVIDIA proprietary nvvidconv Gstreamer-1.0 plug-in also allows you to perform

video scaling. The nvvidconv plug-in currently supports scaling with the format

conversions described in this section.

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 13

raw-yuv Input Formats

Currently nvvidconv supports the I420, UYVY, and NV12 raw-yuv input formats for

scaling.

gst-launch-1.0 videotestsrc ! 'video/x-raw, format=(string)I420,

width=(int)1280, height=(int)720' ! nvvidconv !

'video/x-raw(memory:NVMM), width=(int)640, height=(int)480,

format=(string)I420' ! omxh264enc ! 'video/x-h264, stream-

format=(string)byte-stream' ! h264parse ! qtmux ! filesink

location=test.mp4 –e

raw-gray Input Formats

Currently nvvidconv supports the GRAY8 raw-gray input format for scaling.

gst-launch-1.0 videotestsrc ! 'video/x-raw, format=(string)GRAY8,

width=(int)1280, height=(int)720’! nvvidconv !

'video/x-raw(memory:NVMM), width=(int)640, height=(int)480,

format=(string)I420' ! omxh264enc ! 'video/x-h264, stream-

format=(string)byte-stream' ! h264parse ! qtmux ! filesink

location=test.mp4 –e

raw-yuv Output Formats

Currently nvvidconv supports the I420 and UYVY raw-yuv output formats for scaling.

gst-launch-1.0 filesrc location=1280x720_30p.mp4 ! qtdemux ! queue !

h264parse ! omxh264dec ! nvvidconv ! 'video/x-raw, format=(string)I420,

width=640, height=480' ! xvimagesink –e

raw-gray Output Formats

Currently nvvidconv supports the GRAY8 raw-gray output format for scaling.

gst-launch-1.0 filesrc location=1280x720_30p.mp4 ! qtdemux ! queue !

h264parse ! omxh264dec ! nvvidconv ! 'video/x-raw,

format=(string)GRAY8, width=640, height=480' ! videoconvert !

xvimagesink –e

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 14

NVIDIA Input and Output Formats

Currently nvvidconv supports the NVIDIA input and output formats for scaling

described in the following table:

Input Format Output Format

NV12 NV12

I420 I420

RGBA

To scale between NVIDIA formats

 Scale between NVIDIA Formats with the following commands:

gst-launch-1.0 filesrc location=1280x720_30p.mp4 ! qtdemux ! h264parse

! omxh264dec ! nvvidconv ! 'video/x-raw(memory:NVMM), width=(int)640,

height=(int)480, format=(string)I420' ! omxh264enc ! qtmux ! filesink

location=test.mp4 –e

gst-launch-1.0 filesrc location=1280x720_30p.mp4 ! qtdemux ! h264parse

! omxh264dec ! nvvidconv ! 'video/x-raw(memory:NVMM), width=(int)640,

height=(int)480, format=(string)RGBA' ! nvoverlaysink –e

gst-launch-1.0 nvcamerasrc fpsRange="30 30" ! 'video/x-

raw(memory:NVMM), width=(int)1920, height=(int)1080,

format=(string)I420, framerate=(fraction)30/1' ! nvtee ! nvvidconv !

'video/x-raw(memory:NVMM), width=(int)640, height=(int)480,

format=(string)NV12’ ! omxh264enc ! qtmux ! filesink location=test.mp4

–e

VIDEO CROPPING WITH GSTREAMER-1.0

The NVIDIA proprietary nvvidconv Gstreamer-1.0 plug-in also allows you to perform

video cropping.

To crop video

 Crop video with the following commands:

gst-launch-1.0 filesrc location=<filename_1080p.mp4> ! qtdemux !

h264parse ! omxh264dec ! nvvidconv left=400 right=1520 top=200

bottom=880 ! nvoverlaysink display-id=1 –e

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 15

VIDEO TRANSCODE WITH GSTREAMER-1.0

You can perform video transcoding between the following video formats.

H.264 Decode to VP8 Encode (NVIDIA-accelerated decode to NVIDIA-

accelerated encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.video_0 ! queue ! h264parse ! omxh264dec ! nvvidconv ! 'video/x-

raw(memory:NVMM), format=(string)I420’ ! omxvp8enc ! qtmux name=mux !

filesink location=<Transcoded_filename.mp4> demux.audio_0 ! queue !

aacparse ! mux.audio_0 -e

VP8 Decode to H.264 Encode (NVIDIA-accelerated decode to NVIDIA-

accelerated encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux

name=demux demux.video_0 ! queue ! omxvp8dec ! nvvidconv ! 'video/x-

raw(memory:NVMM), format=(string)I420’ ! omxh264enc ! qtmux name=mux !

filesink location=<Transcoded_filename.mp4> demux.audio_0 ! queue !

aacparse ! mux.audio_0 -e

MPEG-4 Decode to VP8 Encode (NVIDIA-accelerated decode to NVIDIA-

accelerated encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux

name=demux demux.video_0 ! queue ! mpeg4videoparse ! omxmpeg4videodec !

nvvidconv ! 'video/x-raw(memory:NVMM), format=(string)I420’ !

omxvp8enc ! qtmux name=mux ! filesink

location=<Transcoded_filename.mp4> demux.audio_0 ! queue ! aacparse !

mux.audio_0 -e

MPEG-4 Decode to H.264 Encode (NVIDIA-accelerated decode to NVIDIA-

accelerated encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux

name=demux demux.video_0 ! queue ! mpeg4videoparse ! omxmpeg4videodec !

nvvidconv ! 'video/x-raw(memory:NVMM), format=(string)I420’ !

omxh264enc ! qtmux name=mux ! filesink

location=<Transcoded_filename.mp4> demux.audio_0 ! queue ! aacparse !

mux.audio_0 -e

H.264 Decode to MPEG-4 Encode (NVIDIA-accelerated decode to OSS

software encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux

name=demux demux.video_0 ! queue ! h264parse ! omxh264dec ! nvvidconv !

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 16

avenc_mpeg4 ! qtmux name=mux ! filesink

location=<Transcoded_filename.mp4> demux.audio_0 ! queue ! aacparse !

mux.audio_0 -e

VP8 Decode to MPEG-4 Encode (NVIDIA-accelerated decode to OSS

software encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux

name=demux demux.video_0 ! queue ! omxvp8dec ! nvvidconv !

avenc_mpeg4 ! qtmux name=mux ! filesink

location=<Transcoded_filename.mp4> demux.audio_0 ! queue ! aacparse !

mux.audio_0 -e

H.264 Decode to Theora Encode (NVIDIA-accelerated decode to OSS

software encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.video_0 ! queue ! h264parse ! omxh264dec ! nvvidconv ! theoraenc

! oggmux name=mux ! filesink location=<Transcoded_filename.ogg> -e

VP8 Decode to Theora Encode (NVIDIA-accelerated decode to OSS

software encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.video_0 ! queue ! omxvp8dec ! nvvidconv ! theoraenc ! oggmux

name=mux ! filesink location=<Transcoded_filename.ogg> -e

MPEG-4 Decode to Theora Encode (NVIDIA-accelerated decode to OSS

software encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux

demux.video_0 ! queue ! mpeg4videoparse ! omxmpeg4videodec !

nvvidconv ! theoraenc ! oggmux name=mux ! filesink

location=<Transcoded_filename.ogg> -e

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 17

CUDA VIDEO POST-PROCESSING WITH GSTREAMER-

1.0

This section describes Gstreamer-1.0 plug-ins for CUDA post-processing operations.

gst-videocuda

This GStreamer-1.0 plug-in performs CUDA post-processing operations on decoder-

provided EGL images and render video using nveglglessink.

The following are sample pipeline creation and application usage commands.

Sample decode pipeline

gst-launch-1.0 filesrc location=<filename_h264_1080p.mp4> ! qtdemux

name=demux ! h264parse ! omxh264dec ! videocuda ! nveglglessink max-

lateness=-1 -e

Sample decode command

nvgstplayer-1.0 -i <filename_h264_1080p.mp4> --svd="omxh264dec" --

svc="videocuda" --svs="nveglglessink # max-lateness=-1" --disable-

vnative --no-audio --window-x=0 --window-y=0 --window-width=960 --

window-height=540

gst-nvivafilter

This NVIDIA proprietary GStreamer-1.0 plug-in performs pre/post and CUDA post-

processing operations on CSI camera captured or decoded frames, and renders video

using overlay video sink or video encode.

Sample decode pipeline

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux ! h264parse !

omxh264dec ! nvivafilter cuda-process=true customer-lib-

name="libnvsample_cudaprocess.so" ! 'video/x-raw(memory:NVMM),

format=(string)NV12' ! nvoverlaysink -e

Sample CSI Camera pipeline

gst-launch-1.0 nvcamerasrc fpsRange="30 30" ! 'video/x-

raw(memory:NVMM), width=(int)3840, height=(int)2160,

format=(string)I420, framerate=(fraction)30/1' ! nvtee ! nvivafilter

cuda-process=true customer-lib-name="libnvsample_cudaprocess.so" !

'video/x-raw(memory:NVMM), format=(string)NV12' ! nvoverlaysink -e

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 18



Note: See nvsample_cudaprocess_src.tbz2 package for the

libnvsample_cudaprocess.so library sources. A Sample CUDA

implementation of libnvsample_cudaprocess.so can be replaced by a

custom CUDA implementation.

VIDEO ROTATION WITH GSTREAMER-1.0

The NVIDIA proprietary nvvidconv Gstreamer-1.0 plug-in also allows you to perform

video rotation operations.

The following table shows the supported values for the nvvidconv flip-method

property.

Flip Method

Property value

identity - no rotation (default) 0

counterclockwise - 90 degrees 1

rotate - 180 degrees 2

clockwise - 90 degrees 3

horizontal flip 4

upper right diagonal flip 5

vertical flip 6

upper-left diagonal 7



Note: Get information on nvvidconv flip-method property with the gst-

inspect-1.0 nvvidconv

command.

To rotate video 90 degrees counterclockwise

 To rotate video 90 degrees in a counterclockwise direction, enter the following

command.

gst-launch-1.0 filesrc location=<filename.mp4>! qtdemux name=demux !

h264parse ! omxh264dec ! nvvidconv flip-method=1 ! 'video/x-

raw(memory:NVMM), format=(string)I420' ! nvoverlaysink –e

To rotate video 90 degrees clockwise

 To rotate video 90 degrees in a clockwise direction, enter the following command:

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux !

h264parse ! omxh264dec ! nvvidconv flip-method=3 ! 'video/x-

raw(memory:NVMM), format=(string)I420’ !

omxh264enc ! qtmux ! filesink location=test.mp4 –e

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 19

Rotate 180 degrees

 To rotate video 180 degrees, enter the following command:

gst-launch-1.0 nvcamerasrc fpsRange="30.0 30.0" ! 'video/x-

raw(memory:NVMM), width=(int)1920, height=(int)1080,

format=(string)I420, framerate=(fraction)30/1' ! nvtee ! nvvidconv

flip-method=2 ! 'video/x-raw(memory:NVMM), format=(string)I420' !

nvoverlaysink -e

To scale and rotate video 90 degrees counterclockwise

 To scale and rotate video 90 degrees counterclockwise, enter the following

command:

gst-launch-1.0 filesrc location=<filename_1080p.mp4> ! qtdemux !

h264parse ! omxh264dec ! nvvidconv flip-method=1 ! 'video/x-

raw(memory:NVMM), width=(int)480, height=(int)640, format=(string)I420'

! nvoverlaysink -e

To scale and rotate video 90 degrees clockwise

 To scale and rotate video 90 degrees clockwise, enter the following command:

gst-launch-1.0 nvcamerasrc fpsRange="30.0 30.0" ! 'video/x-

raw(memory:NVMM), width=(int)1920, height=(int)1080,

format=(string)I420, framerate=(fraction)30/1' ! nvtee ! nvvidconv

flip-method=3 ! 'video/x-raw(memory:NVMM), width=(int)480,

height=(int)640, format=(string)I420' ! nvoverlaysink -e

To scale and rotate video 180 degrees

 To scale and rotate video 180 degrees, enter the following command:

gst-launch-1.0 filesrc location=<filename_1080p.mp4> ! qtdemux !

h264parse ! omxh264dec ! nvvidconv flip-method=2 ! 'video/x-

raw(memory:NVMM), width=(int)640, height=(int)480, format=(string)I420'

! nvoverlaysink -e

INTERPOLATION METHODS FOR VIDEO SCALING

The NVIDIA proprietary nvvidconv Gstreamer-1.0 plug-in allows you to choose the

interpolation method used for scaling.

The following table shows the supported values for the nvvidconv

interpolation-method property.

Accelerated GStreamer User Guide

Accelerated GStreamer User Guide DA_07303 | 20

Interpolation Method

Property Value

nearest 0

linear 1

smart (default) 2

bilinear 3



Note: Get information on nvvidconv interpolation-method property

with the gst-inspect-1.0 nvvidconv command.

To use bilinear interpolation method for scaling

 Enter the following command:

gst-launch-1.0 filesrc location=<filename_1080p.mp4>! qtdemux

name=demux ! h264parse ! omxh264dec ! nvvidconv interpolation-

method=3 ! 'video/x-raw(memory:NVMM), format=(string)I420,

width=1280, height=720' ! nvoverlaysink –e

EGLSTREAM PRODUCER EXAMPLE

The NVIDIA-proprietary nveglstreamsrc and nvvideosink Gstreamer-1.0 plug-ins allow

simulation of an EGLStream producer pipeline (for preview only.)

To simulate an EGLStream producer pipeline

 Enter the following command:

nvgstcapture-1.0 --camsrc=3 --nvvideosink-create-eglstream

EGL IMAGE TRANSFORM EXAMPLE

The NVIDIA proprietary nvegltransform Gstreamer-1.0 plug-in allows simulation of an

EGLImage transform pipeline.

To simulate an EGL Image transform pipeline

 Enter the following command:

gst-launch-1.0 filesrc location=<filename_h264_1080p.mp4> ! qtdemux

! h264parse ! omxh264dec ! nvvidconv ! 'video/x-raw(memory:NVMM),

width=(int)1280, height=(int)720, format=(string)NV12' !

nvegltransform ! nveglglessink -e

Accelerated GStreamer User Guide DA_07303| 21

GSTREAMER BUILD INSTRUCTIONS

This section provides a procedure for building current versions of gstreamer.

Using gst-install to build GStreamer

This release contains the git-install script to install a specific GStreamer version. To

install, execute:

gst-install [--prefix=<install_path>] [--version=<version>]

Where:

 <install_path> is the location where you are installing GStreamer

 <version> is the GStreamer version

For example:

gst-install --prefix=/home/ubuntu/gst-1.6.0 --version=1.6.0

To build GStreamer manually

1. Download the latest version of gstreamer available at:

http://gstreamer.freedesktop.org/src/

The following are the files you need from version 1.6.0:

● gstreamer-1.6.0.tar.xz

● gst-plugins-base-1.6.0.tar.xz

● gst-plugins-good-1.6.0.tar.xz

● gst-plugins-bad-1.6.0.tar.xz

● gst-plugins-ugly-1.6.0.tar.xz

GStreamer Build Instructions

Accelerated GStreamer User Guide DA_07303 | 22

2. Install needed packages with the following command:

sudo apt-get install build-essential dpkg-dev flex bison autotools-

dev automake liborc-dev autopoint libtool gtk-doc-tools

libgstreamer1.0-dev

3. In the ~/ directory, create a gst_<version> directory, where <version> is the

version number of gstreamer you are building.

4. Copy the downloaded tar.xz files to the gst_<version> directory.

5. Uncompress the tar.xz files in the gst_<version> directory.

6. Set the PKG_CONFIG_PATH with the following command:

export PKG_CONFIG_PATH=/home/ubuntu/gst_1.6.0/out/lib/pkgconfig

7. Build gstreamer (in this example, gstreamer-1.6.0) with the following commands:

./configure --prefix=/home/ubuntu/gst_1.6.0/out

make

make install

8. Build gst-plugins-base-1.6.0 with the following commands:

sudo apt-get install libxv-dev libasound2-dev libtheora-dev libogg-

dev libvorbis-dev

./configure --prefix=/home/ubuntu/gst_1.6.0/out

make

make install

9. Build gst-plugins-good-1.6.0 with the following commands:

sudo apt-get install libbz2-dev libv4l-dev libvpx-dev libjack-

jackd2-dev libsoup2.4-dev libpulse-dev

./configure --prefix=/home/ubuntu/gst_1.6.0/out

make

make install

10. Obtain and build gst-plugins-bad-1.6.0 with the following commands:

sudo apt-get install faad libfaad-dev libfaac-dev

./configure --prefix=/home/ubuntu/gst_1.6.0/out

make

make install

GStreamer Build Instructions

Accelerated GStreamer User Guide DA_07303 | 23

11. Obtain and build gst-plugins-ugly-1.6.0 with the following commands:

sudo apt-get install libx264-dev libmad0-dev

./configure --prefix=/home/ubuntu/gst_1.6.0/out

make

make install

12. Set the LD_LIBRARY_PATH environment variable with the following command:

export LD_LIBRARY_PATH=/home/ubuntu/gst_1.6.0/out/lib/

13. Copy the nvidia gstreamer-1.0 libraries to the gst_1.6.0 plugin directory

using the following command:

cd /usr/lib/arm-linux-gnueabihf/gstreamer-1.0/

cp libgstnv* libnvgst* libgstomx.so ~/gst_1.6.0/out/lib/gstreamer-

1.0/

The nvidia gstreamer-1.0 libraries include:

libgstnvcamera.so

libgstnveglglessink.so

libgstnveglstreamsrc.so

libgstnvegltransform.so

libgstnvivafilter.so

libgstnvvidconv.so

libgstnvvideosink.so

libnvgstjpeg.so

libgstomx.so

Accelerated GStreamer User Guide DA_07303| 24

NVGSTCAPTURE-1.0 OPTION REFERENCE

This section describes the options available in the nvgstcapture-1.0 application.

NVGSTCAPTURE APPLICATION OPTIONS

Nvgstcapture-1.0 command-line options are described in the following table.

Application Options

Option

Description

Notes

--prev_res Preview area width and height,

e.g., --prev_res=3 -

--cus-prev-res Custom preview width and height

for CSI only -

--image_res Image width and height, e.g., --

image_res=3 -

--video_res Video width and height, e.g., --

video_res=3 -

-m, --mode Capture mode. 1-Still

2-Video

-v, --video_enc Video encoder type. 0-H.264 (hardware)

1-VP8(hardware)

2-MPEG-4 (software)

3-H.263 (software)

-b, --enc-bitrate Video encoding Bit-rate(in bytes) Example:

--enc-bitrate=4000000

--enc-profile Video encoder profile (only for

H.264) 0-Baseline

1-Main

2-High

-j, --image_enc Image encoder type. 0-jpeg_SW[jpegenc]

1-jpeg_HW[nvjpegenc]

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303 | 25

-k, --file_type Container file type. 0-MP4

1-3GP

2-AVI

--cap-dev-node Video capture device node. 0=/dev/video0[default]

1=/dev/video1

2=/dev/video2

--svs Chain for video preview. -

--file-name File name for capture. “nvcamtest” is used by

default.

--camsrc Camera source. 0-v4l2

1-csi (default)

2-videotest

3-eglstream

--orientation Camera sensor orientation

value(CSI only) -

-w, --whitebalance White balance value for capture.

(CSI only) -

-s, --scene-mode Camera scene-mode value. (CSI

only) -

-c, --color-effect Camera color effect value. (CSI

only) -

--auto-exposure Camera auto-exposure value. (CSI

only) -

--flash Camera flash value. (CSI only) -

--flicker Camera flicker detection and

avoidance mode value. (CSI only) -

--contrast Camera contrast value. (CSI only) -

--saturation Camera saturation value. (CSI

only) -

--edge-enhancement Camera edge enhancement value.

(CSI only) -

--tnr_strength Camera TNR strength value. (CSI

only) -

--tnr_mode Camera TNR mode value. (CSI

only) -

--sensor-id Camera Sensor ID value. (CSI only) -

--display-id Display ID value (for nvoverlaysink

only) -

--eglstream-id Select EGLStreamProducerID value

(for CSI EGLStream). Default is 0. -

--aeRegion ROI for AE coordinates (top, left,

bottom, right) and weight, in that

order. (CSI only)

Example:

--aeRegion="30 40 200 200 1.2"

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303 | 26

--wbRegion ROI for AWB coordinates (top,

left, bottom, right) and weight in

that order. (CSI only)

Example:

--wbRegion="30 40 200 200 1.2"

--fpsRange FPS range values (low, high) (CSI

only) Example:

--fpsRange="15 30"

--wbGains White Balance (WB) gains values

(R, GR, GB, B) in that order. (CSI

only)

Example:

--wbGains="1.2 1.4 0.8 1.6"

--overlayConfig Overlay Configuration Options

index and coordinates in (index,

x_pos, y_pos, width, height)

order.

Example: --overlayConfig="0,

0, 0, 1280, 720"

--enable-meta Enables Sensor MetaData

reporting if the sensor has the

capability to provide the

embedded metadata.

-

--eglConfig EGL window Coordinates (x_pos

y_pos) in that order. Example: --eglConfig=”50 100”

--enable-exif Enable Exif data -

--dump-bayer Dump bayer data in addition to

image capture -

--exposure-time Capture exposure time value. (CSI

only) Example:

--exposure-time=0.033

Help Options

Option

Description

Notes

-h, --help Show help options. -

--help-all Show all help options. -

--help-gst Show Gstreamer options. -

CSI CAMERA SUPPORTED RESOLUTIONS

CSI camera supports the following image resolutions:

 640x480

 1280x720

 1920x1080

 2104x1560

 2592x1944

 2616x1472

 3840x2160

 3896x2192

 4208x3120

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303 | 27

CSI CAMERA RUNTIME COMMANDS

CSI camera runtime commands are described in the following table.

Command

Description

Notes

h Help -

q Quit -

mo:<value> Set capture mode 1-image

2-video

gmo Get capture mode -

sid:<value> Set sensor ID -

gsid Get sensor ID -

so:<val> Set sensor orientation (0): none

(1): Rotate counter-

clockwise 90 degrees

(2): Rotate 180 degrees

(3): Rotate clockwise 90

degrees

gso Get sensor orientation -

wb:<value> Set white balance mode 0-off

1-auto

2-incandescent

3-fluorescent

4-warm-fluorescent

5-daylight

6-cloudy-daylight

7-twilight

8-shade

gwb Get white balance mode -

scm:<value> Set scene mode 0-face-priority

1-action

2-portrait

3-landscape

4-night

5-night-portrait

6-theatre

7-beach

8-snow

9-sunset

10-steady-photo

11-fireworks

12-sports

13-party

14-candle-light

15-barcode

gcm Get scene mode -

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303 | 28

ce:<value> Set color effect mode 1-off

2-mono

3-negative

4-solarize

5-sepia

6-posterize

7-aqua

gce Get color effect mode -

ae:<value> Set auto-exposure mode 1-off

2-on

3-OnAutoFlash

4-OnAlwaysFlash

5-OnFlashRedEye

gae Get auto exposure mode -

f:<value> Set flash mode 0-off

1-on

2-torch

3-auto

gf Get flash mode -

fl:<value> Set flicker detection and

avoidance mode 0-off

1-50 Hz

2-60 Hz

3-auto

gfl Get flicker detection and

avoidance mode -

ct:<value> Set contrast 0-1, e.g., ct:0.75

gct Get contrast -

st:<value> Set saturation 0-2, e.g., st:1.25

gst Get saturation -

ext:<value> Set exposure time (in seconds) e.g., ext:0.033

gext Get exposure time -

ee:<value> Set edge enhancment 0-1, e.g., ee:0.75

gee Get edge enhancment -

aer:<value> Set ROI coordinates for AE

(top, left, bottom, right) and

weight

e.g., aer:20 20 400 400 1.2

gaer Get ROI for AE -

wbr:<value> Set ROI coordinates for AWB

(top, left, bottom, right) and

weight

e.g., wbr:20 20 400 400 1.2

gwbr Get ROI for AE -

fpsr:<value> Set FPS range (low, high) e.g., fpsr:15 30

gfpsr Get FPS range -

wbg:<value> Set WB gains (R, GR, GB, B) e.g., wbg:1.2 2.2 0.8 1.6

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303 | 29

gwbg Get WB gains -

ts:<value> Set TNR strength 0-1, e.g., ts:0.75

gts Get TNR strength -

tnr:<value> Set TNR mode 0-Original

1-Outdoor-low-light

2-Outdoor-medium-light

3-Outdoor-high-light

4-Indoor-low-light

5-Indoor-medium-light

6-Indoor-high-light

gtnr Get TNR mode -

j Capture one image. -

jx<delay> Capture after a delay of

<delay>, e.g., jx5000 to

capture after a 5-second

delay

-

j:<value> Capture <count> number of

images in succession, e.g., j:6

to capture 6 images.

-

1 Start recording video -

0 Stop recording video -

gpcr Get preview resolution -

gicr Get image capture resolution -

gvcr Get video capture resolution -

USB CAMERA RUNTIME COMMANDS

USB camera runtime commands are described in the following table.

Command

Description

Notes

h Help -

q Quit -

mo:<value> Set capture mode 1-image

2-video

gmo Get capture mode -

j Capture one image. -

jx<delay> Capture after a delay of

<delay>, e.g., jx5000 to

capture after a 5-second

delay

-

j:<value> Capture <count> number of

images in succession, e.g., j:6

to capture 6 images.

-

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303 | 30

1 Start recording video -

0 Stop recording video -

pcr:<value> Set preview resolution 0-176x144

1-320x240

2-640x480

3-1280x720

gpcr Get preview resolution -

gicr Get image capture resolution -

gvcr Get video capture resolution -

br:<value> Set encoding bit rate (in

bytes) e.g., br:4000000

gbr Get encoding bit rate -

cdn:<value> Set capture device node 0-/dev/video0

1-/dev/video1

2-/dev/video2

gcdn Get capture device node -

Runtime video encoder configuration options are described in the following table.

Command Description Notes

br:<val> Sets encoding bit-rate (in

bytes) Example: br:4000000

gbr Gets encoding bit-rate (in

bytes) -

ep:<val> Sets encoding profile (for

H.264 only) Example: ep:1

(0): Baseline

(1): Main

(2): High

gep Gets encoding profile (for

H.264 only) -

Enter+f Forces IDR frame on video

encoder (for H.264 only) -

NOTES

 The nvgstcapture-1.0 application generates image and video output files in the same

directory as the application itself.

 Filenames for image and video content are in the formats

nvcamtest<counter>.jpg and nvcamtest<counter>.mp4 respectively, where

<counter> is a counter starting from 0 every time you run the application. Rename or

move files between runs to avoid overwriting results you want to save.

 Default H.263 encode resolution is 704x576(4CIF) in AVI container formats. Use --

camsrc=2 for H.263 video encode.

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303 | 31

 The nvgstcapture-1.0 application supports native capture(video only) mode by

default.

 Advance features, like setting zoom, brightness, exposure, and whitebalance levels,

are not supported for USB camera.

Accelerated GStreamer User Guide DA_07303| 32

VIDEO ENCODER FEATURES

The Gstreamer-1.0-based gst-omx video encoders support the following features,

respectively:

Video Encoder Feature

H264enc

H265enc

Vp8enc

profile (Baseline / Main / High)  (all)  (Main) 

bitrate   

insert-spsppsatidr   

control-rate   

iframeinterval   

qp-range   

temporal-tradeoff   

bit-packetization   

quality-level   

low-latency   

slice-header spacing   -

force-IDR   

vbv-size   

sliceintrarefreshenable   -

sliceintrarefreshinterval   -

EnableTwoPassCBR   

num-B-Frames  - -

Accelerated GStreamer User Guide DA_07303| 33

SUPPORTED CAMERAS

This section describes the supported cameras.

CSI CAMERAS

 Jetson TX1 currently supports only 1 CSI RAW BAYER sensor.

 The platform has been validated with a single OV5693 sensor for capture on L4T.

 The camera module is interfaced with the Tegra platform via MIPI-CSI.

 Tested using the nvgstcapture application.

USB 2.0 CAMERAS

The following cameras have been validated on Tegra platforms for Android and L4T

with USB 2.0 ports. These cameras are UVC compliant.

 Logitech c920 (preferred)

http://www.logitech.com/en-in/product/hd-pro-webcam-c920

 Logitech c910

http://www.amazon.com/Logitech-HD-Pro-Webcam-C910/dp/B003M2YT96

 Rocketfish™ HD Webcam Pro

http://www.rocketfishproducts.com/products/computer-accessories/RF-

HDWEB10.html?supportTab=open

 Creative Live! Cam Socialize HD 1080

http://support.creative.com/Products/ProductDetails.aspx?catID=218&CatName=We

b+Cameras&subCatID=231&subCatName=MIDI+Keyboards&prodID=20165&prodN

ame=Live!+Cam+Socialize+HD+1080&bTopTwenty=1&VARSET=prodfaq:PRODFAQ

_20165,VARSET=CategoryID:218

Supported Cameras

Accelerated GStreamer User Guide DA_07303 | 34

INDUSTRIAL CAMERA DETAILS

The following USB 3.0 Industrial cameras are supported on Jetson-TX1 under L4T:

 See3CAM_CU130

http://www.e-consystems.com/UltraHD-USB-Camera.asp

● USB 3.0

● UVC compliant

● 3840 x 2160 at 30 FPS | 4224 x 3156 at 13 FPS

● Purpose - Embedded Navigation

● Test using the nvgstcapture app.

● Issues encountered:

― FPS cannot be fixed. Changes based on exposure.

― FPS cannot be changed. Needs payment to vendor to get the support added

to their firmware.

 MQ003CG-CM

http://www.ximea.com/en/products/usb3-vision-cameras-xiq-line/mq003cg-cm

● USB 3.0

● Non-UVC compliant

● 640 x 480 at 500 FPS

● Purpose - Embedded Robotics

● Installation and Verification on Jetson TX1:

1. Add the user to the plugdev group:

sudo gpasswd -a ubuntu plugdev

Re-login.

2. Install tools for the application:

apt-get install libgstreamer0.10-dev libgstreamer-plugins-

base0.10-dev libgtk2.0-dev g++"

3. Download XIMEA Linux Software Package:

wget http://www.ximea.com/downloads/recent/XIMEA_Linux_SP.tgz

Untar:

tar xzf XIMEA_Linux_SP.tgz

cd package

Supported Cameras

Accelerated GStreamer User Guide DA_07303 | 35

4. Open the install file and replace

elif [ "${arch:0:3}" == "arm" ]

with

elif [ "$arch" == "aarch64" ]

5. Start installation:

./install

Install USB3 camera:

./install -cam_usb30

Install graphical desktop:

sudo apt-get update

sudo apt-get install ubuntu-desktop

6. Reboot. The system boots to the graphical desktop.

7. To access sample applications:

• xiSample: run from /package/bin folder

• streamViewer

• make from /package/examples/streamViewer folder

• run from the /package/bin folder

www.nvidia.com

Notice

ALL NVIDIA DESIGN SPECIFICATIONS, REFERENCE BOARDS, FILES, DRAWINGS, DIAGNOSTICS, LISTS, AND OTHER

DOCUMENTS (TOGETHER AND SEPARATELY, "MATERIALS") ARE BEING PROVIDED "AS IS." NVIDIA MAKES NO

WARRANTIES, EXPRESS, IMPLIED, STATUTORY, OR OTHERWISE WITH RESPECT TO THE MATERIALS, AND ALL

EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY

OR CONDITION OF TITLE, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE

AND ON-INFRINGEMENT, ARE HEREBY EXCLUDED TO THE MAXIMUM EXTENT PERMITTED BY LAW.

Information furnished is believed to be accurate and reliable. However, NVIDIA Corporation assumes no

responsibility for the consequences of use of such information or for any infringement of patents or other

rights of third parties that may result from its use. No license is granted by implication or otherwise under

any patent or patent rights of NVIDIA Corporation. Specifications mentioned in this publication are subject to

change without notice. This publication supersedes and replaces all information previously supplied. NVIDIA

Corporation products are not authorized for use as critical components in life support devices or systems

without express written approval of NVIDIA Corporation.

Trademarks

NVIDIA and the NVIDIA logo are trademarks or registered trademarks of NVIDIA Corporation in the United

States and other countries. Other company and product names may be trademarks of the respective

companies with which they are associated.

Copyright

© 2015, 2016, 2017 NVIDIA Corporation. All rights reserved.
