Remove cap from catheter.

6

1

Close the roller clamp on the drain line tubing so

that it is completely closed.

2

Attach the White Adaptor to the drain line by

pushing the ends together and turning the locking

collar clockwise.

Open clamp on bottle and drain line.

Adjust ow as necessary.

4

Attach drain line to bottle.

To disconnect the drain line; close all clamps,

separate the adaptor from the catheter, attach new

sterile cap to catheter tip.

If a second bottle is needed to complete the

drainage, open a second sterile Safety Drain Line

Adapter and a second Sterile Bottle.

Do Not Connect to a Drain Line Adapter that

has already been used.

Adapter & Cap Instructions

7

3

5

Press t the adaptor end of the drain line into the

catheter tip.

2585 Millennium Dr., Suite C, Elgin, IL 60124

Tel: 630-587-0019 | Fax: 630-524-9088

Email: Fax@jigsawmed.com

TM

slide clamp

back to open

slide wheel

back to open
