Terminology
Airspeed
KIAS Knots
Indicated
Airspeed
Speed in knots as indicated on the airspeed indicator.
KCAS Knots
Calibrated
Airspeed
KIAS corrected for instrument error. Note this error is
often negligible and CAS may be omitted from
calculations.
KTAS Knots True
Airspeed
KCAS corrected for density (altitude and temperature)
error.
Va Max
Manoeuvering
Speed
The maximum speed for full or abrupt control inputs.
Vfe Maximum Flap
Extended
Speed
The highest speed permitted with flap extended.
Indicated by the top of the white arc.
Vno Maximum
structural
cruising speed
Sometimes referred to as “Normal operating range”
Should not be exceeded except in smooth conditions and
only with caution. Indicated by the green arc.
Vne Never Exceed
speed
Maximum speed permitted, exceeding will cause
structural damage. Indicated by the upper red line.
Vs Stall Speed The minimum speed before loss of control in the normal
cruise configuration. Indicated by the bottom of the
green arc. Sometimes referred to as minimum ‘steady
flight’ speed.
Vso Stall Speed
landing
configuration
The minimum speed before loss of control in the landing
configuration, at the most forward C of G*. Indicated by
the bottom of the white arc.
Vx Best angle of
climb speed
The speed which results in the maximum gain in altitude
for a given horizontal distance.
Vy Best Rate of
Climb speed
The speed which results in the maximum gain in altitude
for a given time, indicated by the maximum rate of climb
for the conditions on the VSI.
Vref Reference
speed
The minimum safe approach speed, calculated as 1.3 x
Vso.
Vr Rotation
speed
The speed which rotation should be initiated.
Vat Barrier speed The speed nominated to reach before the 50ft barrier or
on reaching 50ft above the runway.
*forward centre of gravity gives a higher stall speed and so is used for certification
Maximum
Demonstrated
Crosswind
The maximum demonstrated crosswind during testing.
Meteorological Terms
OAT Outside Air
Temperature
Free outside air temperature, or indicated outside air
temperature corrected for gauge, position and ram air
errors.
IOAT Indicated
outside air
temperature
Temperature indicated on the temperature gauge.
Standard
temperature
The temperature in the International Standard
atmosphere for the associated level, and is 15 degrees
Celsius at sea level decreased by two degrees every
1000ft.
Pressure
Altitude
The altitude in the International Standard Atmosphere
with a sea level.
pressure of 1013 and a standard reduction of 1mb per
30ft. Pressure Altitude would be observed with the
altimeter subscale set to 1013.
Density
Altitude
The altitude that the prevailing density would occur in the
International Standard Atmosphere, and can be found by
correcting Pressure Altitude for temperature deviations.
Engine Terms
BHP Brake Horse
Power
The power developed by the engine (actual power
available will have some transmission losses).
RPM Revolutions
per Minute
Engine drive and propeller speed.
Static RPM The maximum RPM obtained during stationery full
throttle operation
Weight and Balance Terms
Arm (moment
arm)
The horizontal distance in inches from reference datum
line to the centre of gravity of the item.
C of G Centre of
Gravity
The point about which an aeroplane would balance if it
were possible to suspend it at that point. It is the mass
centre of the aeroplane, or the theoretical point at which
entire weight of the aeroplane is assumed to be
concentrated. It may be expressed in percent of MAC
(mean aerodynamic chord) or in inches from the
reference datum.
Centre of
gravity limit
The specified forward and aft point beyond which the CG
must not be located. The forward limit defines the
controllability of aircraft and aft limits – stability of the
aircraft.
Datum
(reference
datum)
An imaginary vertical plane or line from which all
measurements of arm are taken. The datum is
established by the manufacturer.
Moment The product of the weight of an item multiplied by its arm
and expressed in inch-pounds. The total moment is the
weight of the aeroplane multiplied by distance between
the datum and the CG.
MZFW Maximum
Zero Fuel
Weight
The maximum permissible weight to prevent exceeding
the wing bending limits. This limit is not always
applicable for aircraft with small fuel loads.
BEW Basic empty
weight
The weight of an empty aeroplane, including permanently
installed equipment, fixed ballast, full oil and unusable
fuel, and is that specified on the aircraft mass and
balance documentation for each individual aircraft.
SEW Standard
Empty Weight
The basic empty weight of a standard aeroplane,
specified in the POH, and is an average weight given for
performance considerations and calculations.
OEW Operating
Empty Weight
The weight of the aircraft with crew, unusable fuel, and
operational items (galley etc).
Payload The weight the aircraft can carry with the pilot and fuel
on board.
MRW Maximum
Ramp Weight
The maximum weight for ramp maneouvering, the
maximum takeoff weight plus additional fuel for start taxi
and runup.
MTOW Maximum
Take off
Weight
The maximum permissible takeoff weight and sometimes
called the maximum all up weight, landing weight is
normally lower as allows for burn off and carries shock
loads on touchdown.
MLW Maximum
Landing
Weight
Maximum permissible weight for landing. Sometimes this
is the same as the takeoff weight for smaller aircraft.
