1 Overview
This document describes how to build Android Oreo 8.0
platform for the i.MX 6 and i.MX 7 series devices. It provides
instructions for:
• Configuring a Linux® OS build machine.
• Downloading, patching, and building the software
components that create the Android™ system image.
• Building from sources and using pre-built images.
• Copying the images to boot media.
• Hardware/software configurations for programming the
boot media and running the images.
For more information about building the Android platform,
see source.android.com/source/building.html.
2Preparation
The minimum recommended system requirements are as
follows:
• 16 GB RAM
• 300 GB hard disk
For any problems on the building process related to the jack
server, see the Android website source.android.com/source/
jack.html.
NXP Semiconductors Document Number: AUG
User's Guide Rev. O8.0.0_1.0.0, 02/2018
Android™ User's Guide
Contents
1 Overview....................................................................1
2 Preparation................................ ................................ 1
3 Building the Android platform for i.MX...................2
4 Running the Android Platform with a
Prebuilt Image......................................................... 10
5 Programming Images.............................................. 13
6 Booting................................ ................................... 15
7 Revision History......................... ............................ 23
2.1 Setting up your computer
To build the Android source files, use a computer running the Linux OS. The Ubuntu 14.04 64bit version and openjdk-8-jdk
is the most tested environment for the Android Oreo 8.0 build.
After installing the computer running Linux OS, check whether all the necessary packages are installed for an Android build.
See "Setting up your machine" on the Android website source.android.com/source/initializing.html.
In addition to the packages requested on the Android website, the following packages are also needed:
$ sudo apt-get install uuid uuid-dev
$ sudo apt-get install zlib1g-dev liblz-dev
$ sudo apt-get install liblzo2-2 liblzo2-dev
$ sudo apt-get install lzop
$ sudo apt-get install git-core curl
$ sudo apt-get install u-boot-tools
$ sudo apt-get install mtd-utils
$ sudo apt-get install android-tools-fsutils
$ sudo apt-get install openjdk-8-jdk
$ sudo apt-get install device-tree-compiler
$ sudo apt-get install gdisk
NOTE
If you have trouble installing the JDK in Ubuntu, see How to install misc JDK in Ubuntu
for Android build.
Configure git before use. Set the name and email as follows:
• git config --global user.name "First Last"
• git config --global user.email "first.last@company.com"
2.2 Unpacking the Android release package
After you set up a computer running Linux OS, unpack the Android release package by using the following commands:
$ cd ~ (or any other directory you like)
$ tar xzvf mx-o8.0.0_1.0.0_ga.tar.gz
3Building the Android platform for i.MX
3.1 Getting Android source code (Android/kernel/U-Boot)
The i.MX Android release source code consists of three parts:
• NXP i.MX public source code, which is maintained in CodeAurora Forum repository.
• AOSP Android public source code, which is maintained in android.googlesource.com.
• NXP i.MX Android proprietary source code package, which is maintained in www.NXP.com.
To generate the i.MX Android release source code build environment, follow the steps below. Assume you had i.MX
Android proprietary source code package imx-o8.0.0_1.0.0.tar.gz under the ~/. directory.
$ mkdir ~/bin
$ curl https://storage.googleapis.com/git-repo-downloads/repo > ~/bin/repo
$ chmod a+x ~/bin/repo
$ export PATH=${PATH}:~/bin
Building the Android platform for i.MX
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
2 NXP Semiconductors
$ source ~/imx-o8.0.0_1.0.0_ga/imx_android_setup.sh
# By default, the imx_android_setup.sh script will create the source code build environment
in the folder ~/android_build
# ${MY_ANDROID} will be refered as the i.MX Android source code root directory in all i.MX
Andorid release documentation.
$ export MY_ANDROID=~/android_build
3.2 Building Android images
Building the Android image is performed when the source code has been downloaded (Section 3.1) and patched (Section
3.2).
Commands lunch <buildName-buildType> to set up the build configuration and make to start the build process are
executed.
The build configuration command lunch can be issued with an argument <Build name>-<Build type> string, such as lunch
sabresd_6dq-userdebug, or can be issued without the argument presenting a menu of selection.
The Build Name is the Android device name found in the directory ${MY_ANDROID}/device/fsl/. The following table lists
the i.MX build names.
Table 1. Build names
Build name Description
evk_6sl i.MX 6SoloLite Evaluation Kit
sabreauto_6q i.MX 6Quad/6DualLite/6QuadPlus SABRE-AI Board
sabresd_6dq i.MX 6Quad/6DualLite/6QuadPlus SABRE-SD Board and SABRE Platform
sabresd_6sx i.MX 6SoloX SABRE-SD Board
sabreauto_6sx i.MX 6SoloX SABRE-AI Board
sabresd_7d i.MX 7Dual SABRE-SD Board
The build type is used to specify what debug options are provided in the final image. The following table lists the build types.
Table 2. Build types
Build type Description
user Production ready image, no debug
userdebug Production ready image similar with "user" but with root access and debug
tools
eng Development image with debug tools
Android build steps are as follows:
1. Change to the top level build directory.
$ cd ${MY_ANDROID}
2. Set up the environment for building. This only configures the current terminal.
$ source build/envsetup.sh
3. Execute the Android lunch command. In this example, the setup is for the production image of i.MX 6DualQuad
SABRE Board/Platform device with user type.
$ lunch sabresd_6dq-userdebug
Building the Android platform for i.MX
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 3
4. Execute the make command to generate the image.
$ make 2>&1 | tee build-log.txt
When the make command is complete, the build-log.txt file contains the execution output. Check for any errors.
For BUILD_ID & BUILD_NUMBER changing, update build_id.mk in your ${MY_ANDROID} directory. For details, see
the Android™ Frequently Asked Questions (AFAQ).
For i.MX 6DualLite SABRE-SD, i.MX 6Dual/6Quad SABRE-SD, and i.MX 6QuadPlus SABRE-SD boards, the same build
configuration is used. These two boards share the same kernel/system/recovery images with the exception of the U-Boot
image. The following outputs are generated by default in ${MY_ANDROID}/out/target/product/sabresd_6dq:
• root/: root file system (including init, init.rc). Mounted at /.
• system/: Android system binary/libraries. Mounted at /system.
• data/: Android data area. Mounted at /data.
• recovery/: root file system when booting in "recovery" mode. Not used directly.
• boot-imx6q.img: composite image for i.MX 6Dual/6Quad SABRE-SD, which includes the kernel zImage, ramdisk,
board's device tree binary, and boot parameters.
• boot-imx6qp.img: composite image for i.MX 6QuadPlus SABRE-SD, which includes the kernel zImage, ramdisk,
board's device tree binary, and boot parameters.
• boot-imx6dl.img: composite image for i.MX 6DualLite SABRE-SD, which includes the kernel zImage, ramdisk,
board's device tree binary, and boot parameters.
• boot-imx6q-ldo.img: a composite image for i.MX 6Dual/6Quad 1.2 G Hz SABRE-SD, which includes the kernel
zImage, ramdisk, board's device tree binary, and boot parameters.
• ramdisk.img: ramdisk image generated from "root/". Not used directly.
• system.img: EXT4 image generated from "system/". It can be programmed to "SYSTEM" partition on SD/eMMC card
with "dd".
• recovery-imx6q.img: EXT4 image for i.MX 6Dual/6Quad SABRE-SD, which is generated from "recovery/". Can be
programmed to the "RECOVERY" partition on SD/eMMC card with "dd".
• recovery-imx6qp.img: EXT4 image for i.MX 6QuadPlus SABRE-SD, which is generated from "recovery/". Can be
programmed to the "RECOVERY" partition on SD/eMMC card with "dd".
• recovery-imx6q-ldo.img: EXT4 image for i.MX 6Dual/6Quad 1.2 G Hz SABRE-SD, which is generated from
"recovery/". Can be programmed to "RECOVERY" partition on SD/eMMC card with "dd".
• recovery-imx6dl.img: EXT4 image for i.MX 6DualLite SABRE-SD, which is generated from "recovery/". Can be
programmed to the "RECOVERY" partition on SD/eMMC card with "dd".
• partition-table.img: GPT partition table image, used for 8 GB SD card.
• partition-table-14GB.img: GPT partition table image, used for 16 GB SD card.
• partition-table-28GB.img: GPT partition table image, used for 32 GB SD card.
• u-boot-imx6q.imx: U-Boot image with no padding for i.MX 6Dual/6Quad SABRE-SD.
• u-boot-imx6qpimx: U-Boot image with no padding for i.MX 6QuadPlus SABRE-SD.
• u-boot-imx6dl.imx: U-Boot image with no padding for i.MX 6DualLite SABRE-SD.
• vendor.img: vendor image, which holds platform binaries, mounted at /vendor.
NOTE
• To build the U-Boot image separately, see Building U-Boot images.
• To build the kernel uImage separately, see Building a kernel image.
• To build boot.img, see Building boot.img.
The default build is configured for internal eMMC boot storage. See Building Android
image for the SD card on the SABRE-SD Board for the configuration steps to make SD
card in Slot 3 as the boot storage.
Building the Android platform for i.MX
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
4 NXP Semiconductors
3.2.1 Configuration examples of building i.MX devices
The following table shows examples of using the lunch command to set up different i.MX devices. After the desired i.MX
device is set up, the make command is used to start the build.
Table 3. i.MX device lunch examples
Build name Description
i.MX 6DualLite/Quad/QuadPlus SABRE-SD Board and
Platform
$ lunch sabresd_6dq-userdebug
i.MX 6Quad/DualLite/QuadPlus SABRE-AI Board $ lunch sabreauto_6q-userdebug
i.MX 6SoloLite EVK Board $ lunch evk_6sl-userdebug
i.MX 6SoloX SABRE-SD Board $ lunch sabresd_6sx-userdebug
i.MX 6SoloX SABRE-AI Board $ lunch sabreauto_6sx-userdebug
i.MX 7Dual SABRE-SD Board $ lunch sabresd_7d-userdebug
After the lunch command is executed, the make command is issued:
$ make 2>&1 | tee build-log.txt
3.2.2 User build mode
A production release Android system image is created by using the user Build Type. For configuration options, see Table
"Build types" in Section Building Android images.
The notable differences between the user and eng build types are as follows:
• Limited Android System image access for security reasons.
• Lack of debugging tools.
• Installation modules tagged with user.
• APKs and tools according to product definition files, which are found in PRODUCT_PACKAGES in the sources
folder ${MY_ANDROID}/device/fsl/imx6/imx6.mk. To add customized packages, add the package
MODULE_NAME or PACKAGE_NAME to this list.
• The properties are set as: ro.secure=1 and ro.debuggable=0.
•adb is disabled by default.
The i.MX development tool options are shown below from: IMX6_SW: i.MX 6 Series Software and Development Tool
Resources.
Table 4. Development tool options
i.MX
6Quad
i.MX 6Dual i.MX
6DualLite
i.MX 6Solo i.MX
6SoloX
i.MX
6SoloLite
i.MX 7Dual i.MX
6QuadPlus
SABRE
Board for
Smart
Devices
* Uses i.MX
6Quad
--*--*
SABRE
Platform for
Smart
Devices
* Uses i.MX
6Quad
* Uses i.MX
6DualLite
- - * -
Table continues on the next page...
Building the Android platform for i.MX
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 5
Table 4. Development tool options (continued)
i.MX
6Quad
i.MX 6Dual i.MX
6DualLite
i.MX 6Solo i.MX
6SoloX
i.MX
6SoloLite
i.MX 7Dual i.MX
6QuadPlus
SABRE for
Automotive
Infotainment
* Uses i.MX
6Quad
* Uses i.MX
6DualLite
---*
Evaluation
Kit
-----*--
* Supported through the superset device (i.MX 6Quad is superset to i.MX 6Dual, i.MX 6DualLite is superset to i.MX 6Solo)
Table 5. Android system image production build method 1
i.MX development tool Description Image build command
SABRE Board/Platform for
Smart Devices
i.MX 6QuadPlus/6Quad, i.MX
6DualLite
$ make PRODUCT-sabresd_6dq-userdebug 2>&1 |
tee build-log.txt
i.MX 6SoloX $ make PRODUCT-sabresd_6sx-userdebug 2>&1 |
tee build-log.txt
i.MX 7Dual $ make PRODUCT-sabresd_7d-userdebug 2>&1 | tee
build-log.txt
SABRE Board for Automotive
Infotainment
i.MX 6Dual/6Quad/6QuadPlus, i.MX
6DualLite
$ make PRODUCT-sabreauto_6q-userdebug 2>&1 |
tee build-log.txt
i.MX 6SoloX $ make PRODUCT-sabreauto_6sx-userdebug 2>&1 |
tee build-log.txt
Evaluation Kit i.MX 6SoloLite $ make PRODUCT-evk_6sl-userdebug 2>&1 | tee
build-log.txt
Another method to create Android System Images is setting the environment and then issuing the make command. To set up
the environment, execute the script ${MY_ANDROID}/build/envsetup.sh. The lunch command and configuration
argument for the Development Tool is then executed. To start the build, use the make command. The following table lists the
lunch configuration values.
Table 6. Android system image production build method 2
i.MX development tool Description Lunch configuration
SABRE Board/Platform for Smart
Devices
i.MX 6QuadPlus/6Quad, i.MX 6DualLite sabresd_6dq-userdebug
i.MX 6SoloX sabresd_6sx-userdebug
i.MX 7Dual sabresd_7d-userdebug
SABRE for Automotive Infotainment i.MX 6Dual/6Quad , i.MX 6DualLite sabreauto_6q-userdebug
i.MX 6SoloX sabreauto_6sx-userdebug
Evaluation Kit i.MX 6SoloLite evk_6sl-userdebug
An example for the SABRE Board for Smart Devices i.MX 6Dual/Quad is:
$ cd ${MY_ANDROID}
$ source build/envsetup.sh
$ lunch sabresd_6dq-userdebug
$ make
Building the Android platform for i.MX
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
6 NXP Semiconductors
To create Android platform over-the-air, OTA, and package, the following make target is specified:
$ make otapackage
For more Android platform building information, see source.android.com/source/building.html.
All the output files to create a bootable Android image should be all created in {MY_ANDROID}/out/target/product/
<board>.
3.3 Building U-Boot images
After you set up U-Boot using the steps outlined above, you can find the tool (mkimage) under tools/.
$ cd ${MY_ANDROID}/vendor/nxp-opensource/uboot-imx
$ export ARCH=arm
$ export CROSS_COMPILE=${MY_ANDROID}/prebuilts/gcc/linux-x86/arm/arm-linux-
androideabi-4.9/bin/arm-linux-androideabi-
$ make distclean
For i.MX 6Quad/6QuadPlus SABRE-SD:
# To build uboot.imx that is used in Android platform
$ make mx6qpsabresdandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6qpsabresd_config
$ make
For i.MX 6Quad SABRE-SD:
# To build uboot.imx that is used in Android platform
$ make mx6qsabresdandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6qsabresd_config
$ make
For i.MX 6DualLite SABRE-SD:
# To build uboot.imx that is used in Android platform
$ make mx6dlsabresdandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6dlsabresd_config
$ make
For i.MX 6Solo SABRE-SD:
# To build uboot.imx that is used in Android platform
$ make mx6solosabresdandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6solosabresd_config
$ make
For i.MX 6Quad SABRE-AI SD:
# To build uboot.imx that is used in Android platform
$ make mx6qsabreautoandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6qsabreauto_config
$ make
For i.MX 6QuadPlus SABRE-AI SD:
Building the Android platform for i.MX
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 7
# To build uboot.imx that is used in Android platform
$ make mx6qpsabreautoandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6qpsabreauto_config
$ make
For i.MX 6DualLite SABRE-AI SD:
# To build uboot.imx that is used in Android platform
$ make mx6dlsabreautoandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6dlsabreauto_config
$ make
For i.MX 6Solo SABRE-AI SD:
# To build uboot.imx that is used in Android platform
$ make mx6solosabreautoandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6solosabreauto_config
$ make
For i.MX 6SoloLite EVK SD:
# To build uboot.imx that is used in Android platform
$ make mx6slevkandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6slevk_config
$ make
For i.MX 6SoloX SABRE-SD SD:
# To build uboot.imx that is used in Android platform
$ make mx6sxsabresdandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6sxsabresd_config
$ make
For i.MX 6SoloX SABRE-AI SD:
# To build uboot.imx that is used in Android platform
$ make mx6sxsabreautoandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx6sxsabreauto_config
$ make
For i.MX 7Dual SABRE-SD SD:
# To build uboot.imx that is used in Android platform
$ make mx7dsabresdandroid_config
# To build uboot.img that is used in MFGTOOL
$ make mx7dsabresd_config
$ make
"u-boot.imx" is generated if you have a successful build.
NOTE
Any image that should be loaded by U-Boot must have an unique image head. For
example, data must be added at the head of the loaded image to tell U-Boot about the
image (in other words, whether it's a kernel or ramfs) and how to load the image (in other
words, load/execute address). Before loading any image into RAM by U-Boot, you need
a tool to add this information and generate a new image which can be recognized by U-
Boot. The tool is delivered together with U-Boot. After you set up U-Boot using the steps
outlined above, find the tool (mkimage) under tools/. The process of using mkimage to
generate an image (for example, kernel image and ramfs image), which is to be loaded by
U-Boot, is outlined in the subsequent sections of this document.
Building the Android platform for i.MX
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
8 NXP Semiconductors
3.4 Building a kernel image
Kernel image is automatically built when building the Android root file system.
The following are the default Android build commands to build the kernel image:
$ export PATH=${MY_ANDROID}/bootable/bootloader/uboot-imx/tools:$PATH
$ cd ${MY_ANDROID}/vendor/nxp-opensource/kernel_imx
$ echo $ARCH && echo $CROSS_COMPILE
Make sure that you have those two environment variables set. If the two variables are not set, set them as follows:
$ export ARCH=arm
$ export CROSS_COMPILE=${MY_ANDROID}/prebuilts/gcc/linux-x86/arm/arm-linux-
androideabi-4.9/bin/arm-linux-androideabi-
# Generate ".config" according to default config file under arch/arm/configs.
# To build the kernel image for i.MX 6Dual/Quad, 6QuadPlus, 6DualLite, 6Solo, 6SoloLite,
6SoloX, and 7Dual
$ make imx_v7_android_defconfig
$ make KCFLAGS=-mno-android
# To build the kernel uImage for i.MX 6Dual/Quad, 6QuadPlus, 6DualLite, and 6Solo
$ make uImage LOADADDR=0x10008000 KCFLAGS=-mno-android
# To build the kernel uImage for i.MX 6SoloLite
$ make uImage LOADADDR=0x80008000 KCFLAGS=-mno-android
# To build the kernel uImage for i.MX 6SoloX
$ make uImage LOADADDR=0x80008000 KCFLAGS=-mno-android
# To build the kernel uImage for i.MX 7Dual
$ make uImage LOADADDR=0x80008000 KCFLAGS=-mno-android
# To build the zImage that is used in MFGTOOL
# zImage is under mfgtools\Profiles\Linux\OS Firmware\firmware\
$ make imx_v7_mfg_defconfig
$ make KCFLAGS=-mno-android -j4
The kernel images are found in the folders: ${MY_ANDROID}/vendor/nxp-opensource/kernel_imx/arch/arm/boot/zImage
and ${MY_ANDROID}/vendor/nxp-opensource/kernel_imx/arch/arm/boot/uImage.
3.5 Building boot.img
boot.img and boota are default booting command and image.
As outlined in Running the Android Platform with a Prebuilt Image, we use boota as the default image to boot, not the
uramdisk and uImage we used before.
Use this command to generate boot.img under Android environment:
# Boot image for the i.MX 6Dual/6Quad SABRE-SD board
$ cd ${MY_ANDROID}
$ source build/envsetup.sh
$ lunch sabresd_6dq-userdebug
$ make bootimage
# Boot image for the i.MX 6Dual/6Quad/6QuadPlus SABRE-AI board
$ source build/envsetup.sh
$ lunch sabreauto_6q-userdebug
$ make bootimage
Building the Android platform for i.MX
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 9
# Boot image for the i.MX 6SoloLite EVK board
$ source build/envsetup.sh
$ lunch evk_6sl-userdebug
$ make bootimage
# Boot image for the i.MX 6SoloX SABRE-SD board
$ source build/envsetup.sh
$ lunch sabresd_6sx-userdebug
$ make bootimage
# Boot image for the i.MX 6SoloX SABRE-AI board
$ source build/envsetup.sh
$ lunch sabreauto_6sx-userdebug
$ make bootimage
# Boot image for i.MX 7Dual SABRE-SD board
$ source build/envsetup.sh
$ lunch sabresd_7d-userdebug
$ make bootimage
4Running the Android Platform with a Prebuilt Image
To test the Android platform before building any code, use the prebuilt images from the following packages and go to
"Download Images" and "Boot".
Table 7. Image packages
Image package Description
android_O8.0.0_1.0.0_image_6qsabresd.tar.gz Prebuilt image for i.MX 6Dual/6Quad, i.MX 6QuadPlus, and i.MX 6DualLite
SABRE-SD board, which includes extended features.
android_O8.0.0_1.0.0_image_6qsabreauto.tar.
gz
Prebuilt image for i.MX 6Dual/6Quad, i.MX 6QuadPlus, and i.MX 6DualLite/
Solo SABRE-AI board, which includes extended features.
android_O8.0.0_1.0.0_image_6slevk.tar.gz Prebuilt image for the i.MX 6SoloLite EVK board, which includes extended
features.
android_O8.0.0_1.0.0_image_6sxsabresd.tar.g
z
Prebuilt image for the i.MX 6SoloX SABRE-SD board, which includes
extended features.
android_O8.0.0_1.0.0_image_6sxsabreauto.tar
.gz
Prebuilt image for i.MX 6SoloX SABRE-AI board, which includes extended
features.
android_O8.0.0_1.0.0_image_7dsabresd.tar.gz Prebuilt image for i.MX 7Dual SABRE-SD board, which includes extended
features.
The following tables list the detailed contents of android_O8.0.0_1.0.0_image_6qsabresd.tar.gz image packages.
The table below shows the prebuilt images to support the system boot from eMMC and SD cards on the i.MX 6Dual/6Quad
SABRE-SD board and platform and i.MX 6Solo/6DualLite SABRE-SD platform.
Table 8. Images for i.MX 6 SABRE-SD board and platform eMMC boot
SABRE-SD eMMC image Description
/u-boot-imx6q.imx The bootloader (with padding) for 800 MHz or 1 GHz i.MX
6Dual/6Quad SABRE-SD board
/u-boot-imx6dl.imx The bootloader (with padding) for i.MX 6Solo/6DualLite
SABRE-SD board
Table continues on the next page...
Running the Android Platform with a Prebuilt Image
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
10 NXP Semiconductors
Table 8. Images for i.MX 6 SABRE-SD board and platform eMMC boot (continued)
/u-boot-imx6q-ldo.imx The bootloader (with padding) for 1.2 GHZ i.MX6Dual/6Quad
SABRE-SD board
/u-boot-imx6qp.imx The bootloader (with padding) for i.MX 6Solo/6DualLite
SABRE-SD board
/u-boot-imx6qp-ldo.imx The bootloader (with padding) for 1.2 GHZ i.MX6QuadPlus
SABRE-SD board
/partition-table.img GPT table Image for 8 GB SD card
/partition-table-14GB.img GPT table Image for 16 GB SD card
/partition-table-28GB.img GPT table Image for 32 GB SD card
/boot-imx6dl.img Boot Image for i.MX 6QuadPlus SABRE-SD board
/boot-imx6q.img Boot Image for 800 MHz or 1 GHz i.MX 6Dual/6Quad
SABRE-SD board
/boot-imx6q-ldo.img Boot Image for 1.2 GHZ i.MX 6Dual/6Quad SABRE-SD board
/boot-imx6qp.img Boot Image for i.MX 6QuadPlus SABRE-SD board
/boot-imx6qp-ldo.img Boot Image for 1.2 GHZ i.MX 6QuadPlus SABRE-SD board
/system.img System Boot Image
/recovery-imx6dl.img Recovery Image for i.MX 6Solo/6DualLite SABRE-SD board
/recovery-imx6q.img Recovery Image for 800 MHz or 1 GHz i.MX 6Dual/6Quad
SABRE-SD board
/recovery-imx6q-ldo.img Recovery Image for 1.2 GHZ i.MX 6Dual/6Quad SABRE-SD
board
/recovery-imx6qp.img Recovery Image for i.MX 6QuadPlus SABRE-SD board
/recovery-imx6qp-ldo.img Recovery Image for 1.2 G Hz i.MX 6QuadPlus SABRE-SD
board
/vendor.img Vendor Image
The following tables list the detailed contents of android_O8.0.0_1.0.0_image_6qsabreauto.tar.gz image packages.
The table below shows the prebuilt images to support the system boot from SD on the i.MX 6Dual/6Quad, i.MX 6QuadPlus,
and i.MX 6Solo/6DualLite SABRE-AI boards.
Table 9. Images for i.MX 6 SABRE-AI SD boot
SABRE-AI SD image Description
/u-boot-imx6q.imx Bootloader (with padding) for i.MX 6Dual/6Quad SABRE-AI
SD boot
/u-boot-imx6dl.imx Bootloader (with padding) for i.MX 6Solo/6DualLite SABRE-AI
SD boot
/u-boot-imx6qp.imx Bootloader (with padding) for i.MX 6QuadPlus SABRE-AI SD
boot
/partition-table.img GPT table image for 8 GB SD card
/partition-table-14GB.img GPT table Image for 16 GB SD card
/partition-table-28GB.img GPT table Image for 32 GB SD card
/boot-imx6q.img
/boot-imx6dl.img
Boot Image for SD
Table continues on the next page...
Running the Android Platform with a Prebuilt Image
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 11
Table 9. Images for i.MX 6 SABRE-AI SD boot (continued)
/boot-imx6qp.img
/system.img System Boot Image
/recovery-imx6q.img
/recovery-imx6dl.img
/recovery-imx6qp.img
Recovery Image
/vendor.img Vendor Image
The following tables list the detailed contents of android_O8.0.0_1.0.0_image_6slevk.tar.gz image package.
The table below shows the prebuilt images to support the system boot from SD on the i.MX 6SoloLite EVK board.
Table 10. Images for i.MX 6SoloLite EVK SD boot
EVK SD image Description
/u-boot-imx6sl.imx Bootloader (with padding) for the i.MX 6SoloLite EVK board
/partition-table.img GPT table image for 8 GB SD card
/partition-table-14GB.img GPT table Image for 16 GB SD card
/partition-table-28GB.img GPT table Image for 32 GB SD card
/boot-imx6sl.img Boot image for SD
/system.img System boot image
/recovery-imx6sl.img Recovery image
/vendor.img Vendor Image
The following tables list the detailed contents of the android_O8.0.0_1.0.0_image_6sxsabresd.tar.gz image package.
The table below shows the prebuilt images to support the system boot from SD on the i.MX 6SoloX SABRE-SD board.
Table 11. Images for i.MX 6SoloX SABRE-SD SD boot
i.MX 6SoloX SABRE-SD SD image Description
/u-boot-imx6sx.imx Bootloader (with padding) for the i.MX 6SoloX SABRE-SD
board
/partition-table.img GPT table image for 8 GB SD card
/partition-table-14GB.img GPT table Image for 16 GB SD card
/partition-table-28GB.img GPT table Image for 32 GB SD card
/boot-imx6sx.img Boot image for the i.MX 6SoloX SABRE-SD board
/system.img System boot image
/recovery-imx6sx.img Recovery image for the i.MX 6SoloX SABRE-SD board
/vendor.img Vendor Image
The following tables list the detailed contents of android_O8.0.0_1.0.0_image_6sxsabreauto.tar.gz image packages.
Running the Android Platform with a Prebuilt Image
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
12 NXP Semiconductors
The table below shows the prebuilt images to support the system boot from SD on the i.MX 6SoloX SABRE-AI boards.
Table 12. Images for i.MX 6SoloX SABRE-AI SD
i.MX 6SoloX SABRE-AI SD image Description
/u-boot-imx6sx.imx Bootloader (with padding) for i.MX 6SoloX SABRE-AI SD
boot.
/partition-table.img GPT table image for 8 GB SD card
/partition-table-14GB.img GPT table Image for 16 GB SD card
/partition-table-28GB.img GPT table Image for 32 GB SD card
/boot-imx6sx.img Boot image for SD.
/system.img System boot Image.
/recovery-imx6sx.img Recovery image.
/vendor.img Vendor Image
The following table lists the detailed contents of android_O8.0.0_1.0.0_image_7dsabresd.tar.gz image package.
The table below shows the prebuilt images to support the system boot from SD on i.MX 7Daul SABRE-SD boards.
Table 13. Images for i.MX 7Dual SABRE-SD SD boot
i.MX 7Dual SABRE-SD SD image Description
/u-boot-imx7d.imx Bootloader (with padding) for the i.MX 7Dual SABRE-SD board
/partition-table.img GPT table image for 8 GB SD card
/partition-table-14GB.img GPT table Image for 16 GB SD card
/partition-table-28GB.img GPT table Image for 32 GB SD card
/boot-imx7d.img Boot image for the i.MX 7Dual SABRE-SD board
/system.img System boot image
/recovery-imx7d.img Recovery image for the i.MX 7Dual SABRE-SD board
/vendor.img Vendor Image
NOTE
boot.img is an Android image that stores zImage and ramdisk together. It also stores
other information such as the kernel boot command line, machine name.
This information can be configured in android.mk. It is used to override any bootloader
default boot arguments without changing it in the bootloader source code.
5Programming Images
The images from the prebuilt release package or created from source code contain the U-Boot boot loader, system image, and
recovery image. At a minium, the storage devices on the development system (MMC/SD or NAND) must be programmed
with the U-Boot boot loader. The i.MX 6 series boot process determines what storage device to access based on the switch
settings. When the boot loader is loaded and begins execution, the U-Boot environment space is then read to determine how
to proceed with the boot process. For U-Boot environment settings, see Section Booting.
The following download methods can be used to write the Android System Image:
• MFGTool or fsl-sdcard-partition.sh to download all images to MMC/SD card.
Programming Images
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 13
5.1 System on MMC/SD
The images needed to create an Android system on MMC/SD can either be obtained from the release package or be built
from source.
The images needed to create an Android system on MMC/SD are listed below:
• U-Boot image: u-boot.imx
• boot image: boot.img
• Android system image: system.img
• Recovery image: recovery.img
• GPT table image: partition-table.img
• Vendor image: vendor.img
5.1.1 Storage partitions
To create storage partitions, use MFGTool as described in the Android Quick Start Guide (AQSUG), or use format tools in
the prebuild directory.
The layout of the MMC/SD/TF card for Android system is shown below:
• [Partition type/index] which is defined in the MBR.
• [Name] is only meaningful in the Android platform. Ignore it when creating these partitions.
• [Start Offset] shows where partition is started, unit in MB.
The SYSTEM partition is used to put the built Android system image. The DATA is used to put applications' unpacked
codes/data, system configuration database, etc. In normal boot mode, the root file system is mounted from uramdisk. In
recovery mode, the root file system is mounted from the RECOVERY partition.
Table 14. Storage partitions
Partition type/index Name Start offset Size File system Content
N/A BOOT Loader 1 KB 1 MB - 1K N/A bootloader
1 Boot 1 MB 32 MB boot.img format,
kernel + ramdisk
boot.img
2 Recovery Follow Boot 32 MB boot.img format,
kernel + ramdisk
recovery.img
3 SYSTEM Follow
Recovery
1536 MB EXT4. Mount as /
system
Android system files under /
system/ dir
4 CACHE Follow
SYSTEM.
512 MB EXT4. Mount as /
cache.
Android cache for image
store of OTA
5 Misc Follow
CACHE
4 MB N/A For recovery store
bootloader message, reserve
6 DATAFOOTE
R
Follow Misc 2 MB N/A For crypto footer of DATA
partition encryption
7 METADATA Follow
Dtafootor
2 MB N/A For system slide show
8 PRESISTER Follow
Metadata
1 MB N/A Option to operate unlock
\unlock
Table continues on the next page...
Programming Images
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
14 NXP Semiconductors
Table 14. Storage partitions (continued)
Partition type/index Name Start offset Size File system Content
9 VENDOR Follow
PRESISTER
112 MB EXT4. Mount as /
vendor
vendor.img
10 DATA Follow
VENDOR
Total - Other
images
EXT4. Mount at /data Application data storage for
system application, and for
internal media partition,
in /mnt/sdcard/ dir
11 FBMISC Follow Data 1 MB N/A To store the state of lock
\unlock
To create these partitions, use MFGTool described in the Android Quick Start Guide (AQSUG), or use script fsl-sdcard-
partition.sh in the source code directory.
The script below can be used to partition an SD card as shown in the partition table above:
$ cd ${MY_ANDROID}/
$ sudo ./device/fsl/common/tools/fsl-sdcard-partition.sh -f <soc_name> /dev/sdX
# <soc_name> can be as imx6qp, imx6q, imx6dl, imx6sl, imx6sx and imx7d.
NOTE
• The minimum size of the SD card is 8 GB.
• If the SD card is 8 GB, use sudo ./device/fsl/common/tools/fsl-
sdcard-partition.sh -f <soc_name> /dev/sdX to flash images.
• If the SD card is 16 GB, use sudo ./device/fsl/common/tools/fsl-
sdcard-partition.sh -f <soc_name> -c 14 /dev/sdX to flash images.
• If the SD card is 32 GB, use sudo ./device/fsl/common/tools/fsl-
sdcard-partition.sh -f <soc_name> -c 28 /dev/sdX to flash images.
• /dev/sdX, the X is the disk index from 'a' to 'z'. That may be different on each
computer running Linux OS.
• Unmount all the SD card partitions before running the script.
• Put the related bootloader, boot image, system image, recovery image, GPT table
image, and vendor image in your current directory. This script requires to install the
simg2img tool on the computer. simg2img is a tool that converts the sparse system
image to raw system image on the Linux OS host computer. The android-tools-
fsutils package includes the simg2img command for Ubuntu Linux OS.
5.1.2 Downloading images with MFGTool
MFGTool can be used to download all images into a target device. It is a quick and easy tool for downloading images. See
Android™ Quick Start Guide (AQSUG) for a detailed description of MFGTool.
6Booting
This chapter describes booting from MMC/SD, TFTP and NFS.
Booting
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 15
6.1 Booting from MMC/SD
This section describes how to boot from MMC/SD on the SABRE and EVK development tool devices:
• i.MX 6DualQuad/6DualLite/6QuadPlus SABRE-SD board/platform
• i.MX 6DualQuad/6DualLite/6QuadPlus SABRE-AI board
• i.MX 6SoloLite EVK board
• i.MX 6SoloX SABRE-SD board
• i.MX 6SoloX SABRE-AI board
• i.MX 7Dual SABRE-SD board
6.1.1 Booting from MMC/SD on the i.MX 6QuadPlus/6Quad/6DualLite
SABRE-SD board
This section contains boot switch information and steps needed to bootup from MMC/SD.
The following table lists the boot switch settings for different boot methods.
Table 15. Boot switch settings
Download mode (MFGTool mode) (SW6) 00001100 (from 1-8 bit)
eMMC 4-bit (MMC2) boot (SW6) 11100110 (from 1-8 bit)
eMMC 8-bit (MMC2) boot (SW6) 11010110 (from 1-8 bit)
SD2 boot (SW6) 10000010 (from 1-8 bit)
SD3 boot (SW6) 01000010 (from 1-8 bit)
To boot from eMMC, perform the following operations:
Change the board boot switch to eMMC 4-bit mode and make (SW6) 11100110 (from 1-8 bit). Or change (SW6) 11100110
(from 1-8 bit) for 8-bit boot mode.
The default environment in boot.img is booting from eMMC. To use the default environment in boot.img, use the following
command:
U-Boot > setenv bootargs
To clear the bootargs environment, use the following commands:
U-Boot > setenv fastboot_dev mmc2 [eMMC as fastboot deivce]
U-Boot > setenv bootcmd boota mmc2 [Load the boot.img from eMMC]
U-Boot > setenv bootargs console=ttymxc0,115200 init=/init video=mxcfb0:dev=ldb,bpp=32
video=mxcfb1:off video=mxcfb2:off video=mxcfb3:off vmalloc=128M androidboot.console=ttymxc0
consoleblank=0 androidboot.hardware=freescale cma=448M galcore.contiguousSize=33554432
[Optional]
U-Boot > saveenv #[Save the environments]
NOTE
The mmcX value changes depending on the boot mode. These are the correct values:
Hardware port U-Boot device in
software
eMMC mmc2
SD2 mmc3
SD3 mmc1
Booting
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
16 NXP Semiconductors
bootargs env is an optional setting for boota. The boot.img includes a default bootargs,
which is used if there is no definition of the bootargs environment.
Some SoCs on SABRE-SD boards do not have MAC address fused. Therefore, to use
FEC in U-Boot, set the following environment:
U-Boot > setenv ethaddr 00:04:9f:00:ea:d3 #[setup the
MAC address]
U-Boot > setenv fec_addr 00:04:9f:00:ea:d3 $[setup the
MAC address]
To boot from the SD card, perform the following operations:
Change the board boot switch to SD3 boot: (SW6) 01000010 (from 1-8 bit). To clear the bootargs env and set up the booting
from SD card in SD slot 3, use the following command:
U-Boot > setenv fastboot_dev mmc1 [eMMC as fastboot deivce]
U-Boot > setenv bootcmd boota mmc1 [Load the boot.img from SD card]
U-Boot > setenv bootargs console=ttymxc0,115200 init=/init video=mxcfb0:dev=ldb,bpp=32
video=mxcfb1:off video=mxcfb2:off video=mxcfb3:off vmalloc=128M androidboot.console=ttymxc0
consoleblank=0 androidboot.hardware=freescale cma=448M galcore.contiguousSize=33554432
#[Optional]
U-Boot > saveenv #[Save the environments]
NOTE
bootargs env is an optional setting for booti. The boot.img includes a default bootargs,
which is used if there is no definition of the bootargs environment.
Some SoCs on SABRE-SD boards do not have MAC address fused.
Therefore, to use FEC in U-Boot, set the following environment:
U-Boot > setenv ethaddr 00:04:9f:00:ea:d3 #[setup the
MAC address]
U-Boot > setenv fec_addr 00:04:9f:00:ea:d3 $[setup the
MAC address]
6.1.2 Booting from MMC/SD on the the i.MX 6Dual/Quad/DualLite/
QuadPlus SABRE-AI board
This section contains boot switch information and steps needed to bootup from MMC/SD.
The following table lists the boot switch settings for different boot methods on i.MX 6 series SABRE-AI boards.
Table 16. Boot switch settings
Download mode (MFGTool mode) (S3) 0101 (from 1-4 bit)
SD on CPU Board (S1) 0100100000 (from 1-10 bit)
(S2) 0010 (from 1-4 bit)
(S3) 0010 (from 1-4 bit)
To boot from SD, perform the following operations:
Change the board boot switch to (S3, S2, S1) 0010, 0010,0100100000 (from 1 bit).
The default environment in boot.img is booting from SD. To use the default environment in boot.img, use the following
command:
U-Boot > setenv bootargs
Booting
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 17
To clear the bootargs environment, use the following command:
U-Boot > setenv bootcmd boota mmc1 #[Load the boot.img from SD]
U-Boot > setenv bootargs console=ttymxc3,115200 init=/init video=mxcfb0:dev=ldb,bpp=32
video=mxcfb1:off video=mxcfb2:off video=mxcfb3:off vmalloc=128M androidboot.console=ttymxc3
consoleblank=0 androidboot.hardware=freescale cma=512M #[Optional]
U-Boot > saveenv #[Save the environments]
NOTE
bootargs environment is an optional setting for Android boot. The boot.img includes a
default bootargs, which is used if there is no definition of the bootargs environment.
Some SoCs on SABRE-AI boards do not have MAC address fused. Therefore, to use
FEC in U-Boot, set the following environment:
U-Boot > setenv ethaddr 00:04:9f:00:ea:d3 #[setup the
MAC address]
U-Boot > setenv fec_addr 00:04:9f:00:ea:d3 $[setup the
MAC address]
6.1.3 Booting from SD on the i.MX 6SoloLite EVK board
The following table lists the Boot switch settings used to control the boot storage.
Table 17. Boot switch settings
Download mode (MFGTool mode) SW3: 01000000(from 1-8 bit) SW4: 00101100 (from 1-8 bit)
SW5: 00000000(from 1-8 bit) Boot_Mode: 10 (from 1-2 bit)
SD boot SW3: 01000000(from 1-8 bit) SW4: 00101100 (from 1-8 bit)
SW5: 00000000(from 1-8 bit) Boot_Mode: 01 (from 1-2 bit)
To boot from SD, perform the following operations:
Change the board Boot_Mode switch to 01 (from 1-2 bit) and (SW3,4,5) 01000000 0010110000000000 (from 1-8 bit).
The default environment in boot.img is booting from SD. To use default enviroment in boot.img, use the following
command:
U-Boot > setenv bootargs
To clear the bootargs environment, use the following command:
U-Boot > setenv bootcmd boota mmc1
U-Boot > setenv bootargs console=ttymxc0,115200 init=/init androidboot.console=ttymxc0
consoleblank=0 androidboot.hardware=freescale #[Optional]
U-Boot > saveenv [Save the environments]
NOTE
bootargs environment is an optional setting for Android boot. The boot.img file includes
a default bootargs, which is used if there is no definition about the bootargs env.
Due to some SoCs on the EVK boards, do not fuse MAC address. Set the following
environment to use FEC in U-Boot:
U-Boot > setenv ethaddr 00:04:9f:00:ea:d3 [setup the MAC
address]
U-Boot > setenv fec_addr 00:04:9f:00:ea:d3 [setup the MAC
address]
Booting
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
18 NXP Semiconductors
6.1.4 Booting from SD on the i.MX 6SoloX SABRE-SD board
This section contains boot switch information and steps needed to bootup from SD.
The following table lists the boot switch settings used to control the boot storage.
Table 18. Boot switch settings
Download mode (MFGTool mode) SW10: 00000000 (from 1-8 bit)
SW11: 00111000 (from 1-8 bit)
SW12: 01000000 (from 1-8 bit)
Boot_Mode: 10 (from 1-2 bit)
SD boot SW3: 00000000 (from 1-8 bit)
SW4: 00111000 (from 1-8 bit)
SW5: 01000000 (from 1-8 bit)
Boot_Mode: 01 (from 1-2 bit)
To boot from SD, perform the following operations:
Change the board Boot_Mode switch to 01 (from 1-2 bit) and (SW10, 11, 12) 00000000 00111000 01000000 (from 1-8 bit).
The default environment in boot.img is booting from SD. To use the default environment in boot.img, use the following
command:
U-Boot > setenv bootargs
To clear the bootargs environment, use the following command:
U-Boot > setenv bootcmd boota mmc2
U-Boot > setenv bootargs console=ttymxc0,115200 init=/init androidboot.console=ttymxc0
consoleblank=0 androidboot.hardware=freescale vmalloc=128M cma=448M
galcore.contiguousSize=33554432 [Optional]
U-Boot > saveenv [Save the environments]
NOTE
bootargs environment is an optional setting for Android boot. The boot.img file includes
a default bootargs, which is used if there is no definition about the bootargs env.
Due to some SoCs on the SABRE-SD boards, do not fuse MAC addres. Set the following
environment to use FEC in U-Boot:
U-Boot > setenv ethaddr 00:04:9f:00:ea:d3 [setup the MAC
address]
U-Boot > setenv fec_addr 00:04:9f:00:ea:d3 [setup the MAC
address]
6.1.5 Booting from SD on the i.MX 6SoloX SABRE-AI board
The following table lists the boot switch settings used to control the boot storage.
Table 19. Boot switch settings
Download mode (MFGTool mode) SW3: 00001100 (from 1-8 bit)
Table continues on the next page...
Booting
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 19
Table 19. Boot switch settings (continued)
SW4: 01000010 (from 1-8 bit)
S1 (Boot_Mode): 0101 (from 1-4bit)
SD boot SW3: 00001100 (from 1-8 bit)
SW4: 01000010 (from 1-8 bit)
S1 (Boot_Mode): 0010 (from 1-4bit)
To boot from SD, perform the following operations:
Change the board S1 (Boot_Mode) switch to 0010 (from 1-4bit) and (SW3, SW4) 00001100 01000010 (from 1-8 bit).
The default environment in boot.img is booting from SD. To use default env in boot.img, use the following command:
U-Boot > setenv bootargs
To clear the bootargs environment, use the following command:
U-Boot > setenv bootcmd boota mmc0
U-Boot > setenv bootargs console=ttymxc0,115200 init=/init androidboot.console=ttymxc0
consoleblank=0 androidboot.hardware=freescale vmalloc=128M cma=448M
galcore.contiguousSize=33554432 [Optional
U-Boot > saveenv [Save the environments]
NOTE
bootargs environment is an optional setting for Android boot. The boot.img file includes
a default bootargs, which is used if there is no definition about the bootargs env.
Due to some SoCs on the SABRE-SD boards, do not fuse MAC addres. Set the following
environment to use FEC in U-Boot:
U-Boot > setenv ethaddr 00:04:9f:00:ea:d3 [setup the MAC
address]
U-Boot > setenv fec_addr 00:04:9f:00:ea:d3 [setup the MAC
address]
6.1.6 Booting from SD on the i.MX 7Dual SABRE-SD board
The following table lists the boot switch settings used to control the boot storage.
Table 20. Boot switch settings
Download mode (MFGTool mode) SW4: 00100000 (from 1-8 bit)
Boot_Mode: 01 (from 1-2 bit)
SD boot SW4: 00111000 (from 1-8 bit)
Boot_Mode: 10 (from 1-2 bit)
To boot from SD, perform the following operations:
Change the board Boot_Mode switch to 10 (from 1-2 bit) and SW4 00100000 (from 1-8 bit).
The default environment in boot.img is booting from SD. To use the default environment in boot.img, use the following
command:
U-Boot > setenv bootargs
Booting
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
20 NXP Semiconductors
To clear the bootargs environment, use the following command:
U-Boot > setenv bootcmd boota mmc0
U-Boot > setenv bootargs console=ttymxc0,115200 init=/init androidboot.console=ttymxc0
consoleblank=0 androidboot.hardware=freescale [Optional]
U-Boot > saveenv [Save the environments]
NOTE
bootargs environment is an optional setting for Android boot. The boot.img file includes
a default bootargs, which is used if there is no definition about the bootargs env.
Due to some SoCs on the SABRE-SD boards, do not fuse MAC addres. Set the following
environment to use FEC in U-Boot:
U-Boot > setenv ethaddr 00:04:9f:00:ea:d3 [setup the MAC
address]
U-Boot > setenv fec_addr 00:04:9f:00:ea:d3 [setup the MAC
address]
6.2 Boot-up configurations
This section explains the common U-Boot environments used for NFS, MMC/SD boot, and kernel command line.
6.2.1 U-Boot environment
If you do not define the bootargs environment, it uses the default bootargs inside the image.
• bootcmd is the first variable to run after U-Boot boot.
• bootargs is the kernel command line, which the bootloader passes to the kernel. As described in Kernel command line
(bootargs), bootargs environment is optional for booti. boot.img already has bootargs. If you do not define the bootargs
environment, it uses the default bootargs inside the image.
To use the default environment in boot.img, use the following command to clear the bootargs environment.
> setenv bootargs
• dhcp: get the IP address by BOOTP protocol, and load the kernel image ($bootfile env) from the TFTP server.
• booti:
booti command parses the boot.img header to get the zImage and ramdisk. It also passes the bootargs as needed (it only
passes bootargs in boot.img when it cannot find "bootargs" var in your U-Boot environment). To boot from mmcX, do
the following:
> booti mmcX
To read the boot partition (the partition store boot.img, in this instance, mmcblk0p1), the X is the MMC bus number,
which is the hardware MMC bus number, in i.MX 6Dual/6Quad SABRE-SD and i.MX 6Solo/6DualLite SABRE-SD
boards. eMMC is mmc3.
Add partition ID after mmcX.
> boota mmcX boot # boot is default
> boota mmcX recovery # boot from the recovery partition
If you have read the boot.img into memory, use this command to boot from
> boota 0xXXXXXXXX
• bootm (only works in for the NFS) starts running the kernel. For other use cases, use booti command.
Booting
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 21
6.2.2 Kernel command line (bootargs)
Depending on the different booting/usage scenarios, you may need different kernel boot parameters set for bootargs.
Table 21. Kernel boot parameters
Kernel parameter Description Typical value Used when
console Where to output
kernel log by
printk.
console=ttymxc0,115200 All use cases.
init Tells kernel where
the init file is
located.
init=/init All use cases. "init" in the Android platform
is located in "/" instead of in "/sbin".
androidboot.hardware Specifies
hardware name
for this product.
Android init
process loads the
configuration file
init.$
(androidboot.hard
ware).rc in the root
directory.
androidboot.hardware=freescal
e
All use cases.
video Tells kernel/driver
which resolution/
depth and refresh
rate should be
used, or tells
kernel/driver not to
register a
framebuffer device
for a display
device.
video=mxcfb0:dev=ldb,LDB-
XGA,if=RGB666,bpp=32
or
video=mxcfb1:dev=hdmi,
1920x1080M@60,if=RGB24,bp
p=32
or
video=mxcfb2:off
To specify a display framebuffer with:
video=mxcfb<0,1,2>:dev=<ldb,hdmi>,<LDB
-XGA,xres x
yresM@fps>,if=<RGB666,RGB24>,bpp=<1
6,32>
or
To disable a display device's framebuffer
register with:
video=mxcfb<0,1,2>:off
vmalloc vmalloc virtual
range size for
kernel.
vmalloc=256M vmalloc=<size>
androidboot.console The Android shell
console. It should
be the same as
console=.
androidboot.console=ttymxc0 To use the default shell job control, such as
Ctrl+C to terminate a running process, set
this for the kernel.
fec_mac Sets up the FEC
MAC address.
fec_mac=00:04:9f:00:ea:d3 On SABRE-SD board, the SoC does not
have a MAC address fused in. To use FEC,
assign this parameter to the kernel.
cma CMA memory size
for GPU/VPU
physical memory
allocation.
cma=448M
galcore.contiguousSize=33554
432
It is 448 MB by default.
androidboot.selinux Argument to
disable selinux
check and enable
serial input when
connecting a host
androidboot.selinux=permissiv
e
Android Oreo 8.0 CTS requirement: The
serial input should be disabled by default.
Setting this argument enables console
serial input, which violates the CTS
requirement.
Booting
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
22 NXP Semiconductors
Table 21. Kernel boot parameters
Kernel parameter Description Typical value Used when
computer to the
target board’s
USB UART port.
For details about
selinux, see
Security-
Enhanced Linux in
Android.
7 Revision History Table 22. Revision history
Revision number Date Substantive changes
O8.0.0_1.0.0 02/2018 Initial release
Revision History
Android™ User's Guide, Rev. O8.0.0_1.0.0, 02/2018
NXP Semiconductors 23
Information in this document is provided solely to enable system and software
implementers to use NXP products. There are no express or implied copyright licenses
granted hereunder to design or fabricate any integrated circuits based on the
information in this document. NXP reserves the right to make changes without further
notice to any products herein.
NXP makes no warranty, representation, or guarantee regarding the suitability of its
products for any particular purpose, nor does NXP assume any liability arising out of
the application or use of any product or circuit, and specifically disclaims any and all
liability, including without limitation consequential or incidental damages. “Typical”
parameters that may be provided in NXP data sheets and/or specifications can and do
vary in different applications, and actual performance may vary over time. All operating
parameters, including “typicals”, must be validated for each customer application by
customerís technical experts. NXP does not convey any license under its patent rights
nor the rights of others. NXP sells products pursuant to standard terms and conditions
of sale, which can be found at the following address:
nxp.com/SalesTermsandConditions.
How to Reach Us:
Home Page:
nxp.com
Web Support:
nxp.com/support
NXP, the NXP logo, Freescale, and the Freescale logo are trademarks of NXP B.V.
Arm, the Arm logo, and Cortex are registered trademarks of Arm Limited (or its
subsidiaries) in the EU and/or elsewhere. All other product or service names are the
property of their respective owners. All rights reserved.
© 2018 NXP B.V.
Document Number: AUG
Rev. O8.0.0_1.0.0
02/2018

Navigation menu
