CBUS Library for Arduino

Introduction

This set of libraries implements a complete CBUS module using the Arduino environment. A

minimum of additional code is required to create a fully-functional FLiM-compliant module.

CBUS - an abstract base class containing the commom methods

CBUS2515 - an implementation of CBUS specifically for the MCP2515/25625 controller

CBUSLED - non-blocking LED management

CBUSswitch - non-blocking pushbutton switch management

CBUSconfig - event and node variable storage in on-chip or external EEPROM

No additional code need be written to integrate with FCU or JMRI or to learn events.

Features include:

• CBUS switch and FLiM/SLiM LEDs

• transition to and from FLiM/SLiM, tested with FCU and JMRI Node Manager

• event learning and storage, with configurable number of event variables

• node variable (NV) configuration and storage

• storage can use the on-chip 1K EEPROM or external I2C EEPROM up to 64K

• reset capability to return the module to an empty configuration

• a user-assignable function to be called when a learned event is received

• power-on reset capability to empty any stored events and NVs

All four libraries a required although the LED and switch libraries can be used standalone in

other projects if you find them useful. The download links are:

CBUS - https://github.com/obdevel/CBUS

CBUS2515 - https://github.com/obdevel/CBUS2515

CBUSLED - https://github.com/obdevel/CBUSLED

CBUSswitch - https://github.com/obdevel/CBUSswitch

CBUSconfig - https://github.com/obdevel/CBUSconfig

You will also need to install the following two 3rd party libraries:

ACAN2515 - https://github.com/pierremolinaro/acan2515

Streaming - https://github.com/janelia-arduino/Streaming

For people who may have used other CAN bus libraries (e.g. MCP_CAN), note that the

ACAN2515 library implements interrupt handling and configurable send/receive buffers, so

there is no need to code this yourself.

Hardware

The minimum hardware requirement to create a CBUS module is:

• an Arduino processor board, e.g. Uno, Nano, Mega, Pro Mini, etc

• a CAN bus module based on the MCP2515 chip (available from multiple eBay sellers)

• two LEDs (green and yellow/amber) with 1K resistors

• a pushbutton switch

As an alternative, I have designed a generic through-hole PCB containing all the above. It has

no module-specific components, but all spare IO pins are brought out to headers. The design

files are available on the MERG wiki at:

https://www.merg.org.uk/merg_wiki/doku.php?id=projects:canxmas

If using separate components, connect up as follows:

Arduino Uno pin

Module pin

Vcc

GND

10 (SS)

12 (MISO)

11 (MOSI)

13 (SCK)

SCK

2 (INT0)

INT

Connect the green LED with its current-limiting resistor between Arduino pin 4 and GND

Connect the yellow LED with its current-limiting resistor between Arduino pin 5 and GND

Connect the pushbutton switch between Arduino pin 6 and GND

You may find a breadboard handy for the connections.

Using the library

The CBUS library includes a starter sketch in the example folder. This creates a complete but

‘empty’ module with no specific personality.

Here is a commentary on the example code:

1. include the required libraries

// 3rd party libraries

#include <Streaming.h>

// CBUS library header files

#include <CBUS2515.h> // CAN controller and CBUS class

#include <CBUSswitch.h> // pushbutton switch

#include <CBUSLED.h> // CBUS LEDs

#include <CBUSconfig.h> // module configuration

#include <cbusdefs.h> // MERG CBUS constants

// local header

#include "defs.h"

2. create the CBUS objects

CBUS2515 CBUS; // CBUS object

CBUSConfig config; // configuration object

CBUSLED ledGrn, ledYlw; // LED objects

CBUSSwitch pb_switch; // switch object

3. create the module parameter variables and set the module’s name:

// CBUS module parameters

unsigned char params[21];

// module name, e.g. CANEMPTY J

unsigned char mname[7] = { 'E', 'M', 'P', 'T', 'Y', ' ', ' ' };

4. in the setup() function:

(a) set the module’s event and NV storage configuration:

// set config layout parameters

config.EE_NVS_START = 10;

config.EE_NUM_NVS = 10;

config.EE_EVENTS_START = 50;

config.EE_MAX_EVENTS = 64;

config.EE_NUM_EVS = 1;

config.EE_BYTES_PER_EVENT = (config.EE_NUM_EVS + 4);

// initialise and load configuration

config.setEEPROMtype(EEPROM_INTERNAL);

config.begin();

(b) set the module’s parameters:

// set module parameters

params[0] = 20; // 0 num params

params[1] = 0xa5; // 1 manf = MERG, 165

params[2] = VER_MIN; // 2 code minor version

params[3] = MODULE_ID; // 3 module id, 99 = undefined

params[4] = config.EE_MAX_EVENTS; // 4 num events

params[5] = config.EE_NUM_EVS; // 5 num evs per event

params[6] = config.EE_NUM_NVS; // 6 num NVs

params[7] = VER_MAJ; // 7 code major version

params[8] = 0x05; // 8 flags = 5, FLiM, consumer

params[9] = 0x32; // 9 processor id = 50

params[10] = PB_CAN; // 10 interface protocol = CAN, 1

params[11] = 0x00;

params[12] = 0x00;

params[13] = 0x00;

params[14] = 0x00;

params[15] = '3';

params[16] = '2';

params[17] = '8';

params[18] = 'P';

params[19] = CPUM_ATMEL;

params[20] = VER_BETA;

// assign to CBUS

CBUS.setParams(params);

CBUS.setName(mname);

// initialise CBUS switch

pb_switch.setPin(SWITCH0, LOW);

// module reset - if switch is depressed at startup and module is in SLiM mode

pb_switch.run();

if (pb_switch.isPressed() && !config.FLiM) {

Serial << F("> switch was pressed at startup in SLiM mode") << endl;

config.resetModule(ledGrn, ledYlw, pb_switch);

}

(d) register the user-defined function to be called when a learned event is received:

// register our CBUS event handler, to receive event messages of learned events

CBUS.setEventHandler(eventhandler);

(e) configure the LED pins and indicate the current module mode (FLiM or SLiM):

// set LED and switch pins and assign to CBUS

ledGrn.setPin(LED_GRN);

ledYlw.setPin(LED_YLW);

CBUS.setLEDs(ledGrn, ledYlw);

CBUS.setSwitch(pb_switch);

// set CBUS LEDs to indicate the current mode

CBUS.indicateMode(config.FLiM);

(f) configure the CAN bus parameters and start CBUS message processing:

// configure and start CAN bus and CBUS message processing

CBUS.setNumBuffers(4);

CBUS.setPins(10, 2);

CBUS.begin();

4. implement a simple loop() function:

void loop() {

/// do CBUS message, switch and LED processing

CBUS.process();

}

5. implement a simple user-defined function to handle received events (note that EVs and

NVs number from one, not zero):

void eventhandler(byte index, CANFrame *msg) {

// as an example, display the opcode and first EV of this event

Serial << F("> event handler: index = ") << index << F(", opcode = 0x") << _HEX(msg-

>data[0]) << endl;

byte ev = 1;

byte eeaddress = config.EE_EVENTS_START + (index * config.EE_BYTES_PER_EVENT) + 4 + (ev -

1);

Serial << F("> EV1 = ") << config.readEEPROM(eeaddress) << endl;

return;

}

Header File

The example sketch includes a module-specific header file (defs.h) which defines some local

constants, as follows:

#include <Arduino.h> // for definition of byte datatype

// constants

static const byte VER_MAJ = 1; // code major version

static const char VER_MIN = 'a'; // code minor version

static const byte VER_BETA = 0; // code beta sub-version

static const byte MODULE_ID = 99; // CBUS module type

static const byte LED_GRN = 4; // CBUS green SLiM LED pin

static const byte LED_YLW = 5; // CBUS yellow FLiM LED pin

static const byte SWITCH0 = 6; // CBUS push button switch pin

Adding the module’s personality

The foregoing implements a module that has no useful functionality.

Consumer Modules

The user-defined function is called whenever a message that matches a learned event is

received; this is the entry point for implementing a Consumer module. It goes without saying

that this function will not be called until the module has been taught at least one event.

The following useful data is passed to this function when it is called:

byte index;

This is the index into the module’s event table. The Event Variables (EVs) can then be

located.

CANFrame *msg;

A pointer to a CANFrame object containing the following:

msg->id // the CANID of the sending node

msg->len // the number of data bytes in the frame’s payload

msg->data[0] // the opcode of the received message

msg->data[1] and [2] // the Node Number (NN) of the sending module

msg->data[3] and [4] // the Event Number (EN) of the received message

Bytes 5-7 are additional data bytes that are send by some opcodes. See the CBUS

Developers’ Guide for more information on opcodes.

Producer Modules

A Producer module will need to send CBUS messages when something of interest happens,

e.g. a switch is pressed, a loco is detected, etc. It is up to you to define the following items

for any CBUS messages you wish to send:

• the opcode, depending on whether it is a simple on/off event (e.g. ACON/ACOF) or

something more complex with additional data bytes (e.g. ACON3/ACOF3)

• the Event Number (EN)

This example shows how to send a simple ON event message with event number 1 and no

additional data bytes:

// create and initialise a message object

CANFrame msg;

memset(&msg, 0, sizeof(msg));

// populate the object’s parameters

// the CANID

msg.id = config.CANID;

// the size of the data payload

msg.len = 5;

// the opcode

msg.data[0] = OPC_ACON;

// the module’s node number (NN)

msg.data[1] = highByte(config.nodeNum);

msg.data[2] = lowByte(config.nodeNum);

// the event number (EN)

msg.data[3] = 0;

msg.data[4] = 1;

// send the message

bool sent_ok = CBUS.sendMessage(&msg);

This function returns true if the message was successfully sent or false if not.

Note that the NN and EN are both 16-bit integers and each occupy two bytes of the

message. The Arduino macros highByte() and lowByte() return the appropriate (8-bit) byte

from a 16-bit integer. See the CBUS Developers’ Guide for a full discussion of short and long

events and the meaning of NN and EN.

Module Reset

The Arduino environment provides no easy way to program the microcontroller’s on-chip

EEPROM. To ensure that the contents of the EEPROM are cleared and set to sensible

defaults, the CBUSconfig library provides a simple method for resetting the module. This is

shown in the example program included with the library.

Hold down the pushbutton switch as you power-on the module. Then, as a safety

precaution, press and hold the switch for a further 5 seconds. The module will then reset the

EEPROM contents and reboot. The Node Number and CANID will both be set to zero.

The module can only be reset whilst in SLiM mode (with the green LED illuminated). If, due

to random EEPROM data, the module starts up in FLiM mode (with the yellow LED

illuminated) or you want to reset the module at any time in the future, hold the switch down

for 6 seconds to revert to SLiM mode. You can then proceed to reset the module.

CBUS SLiM Mode

The library does not currently support SLiM mode; that is, there is no provision for setting

the node number or learning events by hardware switches. Therefore, you must use FCU or

JMRI to configure your module in FLiM mode. This is in common with most newer MERG CBUS

modules.

Support for SLiM configuration and event learning may be added as a future enhancement if

demand exists.

Arduino Serial Port

The library prints every received event to the module’s serial port (115200 baud, 8N1). This

is useful for testing the bus connection or simply for monitoring the CBUS traffic.

The library also prints copious debug information but by default this code is commented out.

Selected lines can be uncommented to help with code debugging and development.
