AT commands interface
This document is the property of WAVECOM, and is transferred to
______________________________ under the conditions of the active Non-Disclosure
Agreement dated __________. Use of this document is subject to the terms of this NDA. This
document will be returned to WAVECOM under request.
Version : 8.4
Date : Oct,1999
Reference : WCOM/GSM/SW/SII015
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission i
DOCUMENT AMENDMENTS
COMMENTS
1.0 29-02-1996 PN. Higelin Creation
2.0 18-03-1996 PR. Madec Add of new commands
3.0 10-06-1996 PR. Madec Add of new commands
4.0 08-07-1996 PR. Madec Add of new commands
5.0 29-07-1996 PR. Madec Add of new commands
5.1 25-09-1996 PR. Madec Modification of commands
5.2 03-10-1996 PR. Madec Add of new commands
5.3 21-10-1996 PR. Madec Add of V25 ter commands
6.0 16-01-1997 PR. Madec Add of new commands
6.1 10-02-1997 PR. Madec Modifications of +CBST, +CRLP, +SIDET
7.0 29-05-1997 PR. Madec Add of new commands
7.1 24-07-1997 PR. Madec Modifications for error codes
7.2 16-10-1997 PF. Desnoues Network & SIM lock (+CLCK, +CPWD)
7.3 21-12-1997 PF. Desnoues SIM Phonebook management
(+CPBS, +CPBR, +CPBF, +CPBW)
FAX management document
7.4 10-02-1998 PF. Desnoues Advice Of Charge management (+CAOC,
+CACM, +CAMM, +CPUC)
7.5 31-03-1998 PF. Desnoues ATV and ATQ commands
7.6 30-04-1998 PF. Desnoues Cell Broadcast Msg management (+CSCB,
+WCBM) and Incoming bearer (+CICB)
7.7 30-06-1998 PO.Capron New commands +CPINC,+CCID,+CNUM,
+WAIP , +CPBP, +CPBN (phonebook)
7.8 29-10-1998 PO.Capron
F.Desnoues
R.Dorey
SMS commands (+CMGW, +CMSS)
New formats of Suppl Serv commands
(+CLCK,+CCWA,+CCFC)
Add comments pertaining to
+IPR,+CBST,+ICF and fax setup.
7.9 10-02-1999 PO.Capron
F.Desnoues New +CPIN2, +CIMI, +WIND, +CPOL,
+WOPN (Operator Name), +WLPR,
+WLPW, +WIOR, +WIOW (GPIO), AT&T
Extension: +CCED (RxLev auto), +CPBS
(Own Nb), +CLCK (FDN), ATD (Temporary
CLIR)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission ii
8.0 15-04-1999
04-05-1999
P
P
F.Desnoues
C.Amiens
New: +CHLD, +CLCC, +CSSN, +CUSD,
+WMGO, +WMSC
Extension: ATD, ATH, ATA, +CCWA,
+CLIP, +COLP, +WIND, +COPS
Modification: +VGR levels
New format of +ECHO?.command.
8.1 16-06-1999 PC.Foratier New: +CCUG, AT&V, ATI, +DOPT
Extension: ATD (Temporary CUG)
Modification:+CRLP, +ILRR, +FCLASS,
add fax class 1 commands,
21-06-1999 PC. Amiens New: %D, +VIP, +WAC.
8.3 27-09-1999 PC.Foratier New: +WTONE,+WDTMF,+CKPD
Extension: "EN" phonebook
Extension: ATD (GSM sequences)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission iii
CONTENTS
1. INTRODUCTION ..................................................................................................................... 1
1.1. SCOPE OF THIS DOCUMENT.................................................................................................. 1
1.2. RELATED DOCUMENTS ......................................................................................................... 1
1.3. ETSI SECRETARIAT.............................................................................................................. 2
1.4. DEFINITIONS......................................................................................................................... 2
2. AT COMMANDS FEATURES ................................................................................................. 3
2.1. WAVECOM LINE SETTINGS................................................................................................... 3
2.2. COMMAND LINE.................................................................................................................... 3
2.3. INFORMATION RESPONSES AND RESULT CODES .................................................................. 3
3. GENERAL BEHAVIORS ......................................................................................................... 4
3.1. SIM INSERTION, SIM REMOVAL......................................................................................... 4
3.2. BACKGROUNG INITIALISATION............................................................................................ 5
4. GENERAL COMMANDS ......................................................................................................... 6
4.1. MANUFACTURER IDENTIFICATION +CGMI......................................................................... 6
4.2. REQUEST MODEL IDENTIFICATION +CGMM...................................................................... 6
4.3. REQUEST REVISION IDENTIFICATION +CGMR ................................................................... 6
4.4. PRODUCT SERIAL NUMBER +CGSN .................................................................................... 7
4.5. SELECT TE CHARACTER SET +CSCS................................................................................... 7
4.6. REQUEST IMSI +CIMI ........................................................................................................ 7
4.7. CARD IDENTIFICATION +CCID........................................................................................... 8
4.8. CAPABILITIES LIST +GCAP................................................................................................. 8
4.9. REPEAT LAST COMMAND A/................................................................................................. 8
4.10. POWER OFF +CPOF ........................................................................................................... 9
4.11. SET PHONE FUNCTIONALITY +CFUN................................................................................. 9
4.12. PHONE ACTIVITY STATUS +CPAS .................................................................................... 10
4.13. REPORT MOBILE EQUIPEMENT ERRORS +CMEE........................................................... 10
4.14. KEYPAD CONTROL +CKPD.............................................................................................. 11
5. CALL CONTROL COMMANDS ........................................................................................... 12
5.1. DIAL COMMAND D.............................................................................................................. 12
5.2. HANG-UP COMMAND H...................................................................................................... 15
5.3. ANSWER A CALL A.............................................................................................................. 15
5.4. REMOTE DISCONNECTION.................................................................................................. 16
5.5. EXTENDED ERROR REPORT +CEER .................................................................................. 16
5.6. DTMF SIGNALS +VTD, +VTS ........................................................................................... 16
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission iv
5.7. REDIAL LAST NUMBER ATDL............................................................................................ 17
5.8. AUTOMATIC DIALING WITH DTR AT%DN...................................................................... 17
5.9. AUTOMATIC ANSWER ATS0............................................................................................... 19
5.10. INCOMING CALL BEARER +CICB................................................................................... 20
5.11. GAIN CONTROL +VGR, +VGT......................................................................................... 21
5.12. MICROPHONE MUTE CONTROL +CMUT........................................................................ 22
5.13. SPEAKER & MICROPHONE SELECTION +SPEAKER....................................................... 23
5.14. ECHO CANCELATION +ECHO ......................................................................................... 23
5.15. SIDETONE MODIFICATION +SIDET................................................................................. 25
5.16. INITIALISE VOICE PARAMETERS +VIP ............................................................................ 26
6. NETWORK SERVICE COMMANDS ................................................................................... 27
6.1. SIGNAL QUALITY +CSQ..................................................................................................... 27
6.2. OPERATOR SELECTION +COPS ......................................................................................... 28
6.3. NETWORK REGISTRATION +CREG ................................................................................... 31
6.4. READ OPERATOR NAME +WOPN....................................................................................... 32
6.5. PREFERRED OPERATOR LIST +CPOL ................................................................................ 32
7. SECURITY COMMANDS ...................................................................................................... 35
7.1. ENTER PIN +CPIN............................................................................................................ 35
7.2. ENTER PIN2 +CPIN2 ......................................................................................................... 37
7.3. PIN REMAINING ATTEMPT NUMBER +CPINC .................................................................. 39
7.4. FACILITY LOCK +CLCK.................................................................................................... 39
7.5. CHANGE PASSWORD +CPWD ............................................................................................ 41
8. PHONEBOOK COMMANDS ................................................................................................. 43
8.1. SELECT PHONEBOOK MEMORY STORAGE +CPBS ............................................................ 43
8.2. READ PHONEBOOK ENTRIES +CPBR................................................................................. 43
8.3. FIND PHONEBOOK ENTRIES +CPBF................................................................................... 44
8.4. WRITE PHONEBOOK ENTRY +CPBW ................................................................................ 44
8.5. PHONEBOOK PHONE SEARCH +CPBP................................................................................ 47
8.6. MOVE ACTION IN PHONEBOOK +CPBN............................................................................. 47
8.7. SUBSCRIBER NUMBER +CNUM.......................................................................................... 49
8.8. AVOID PHONEBOOK INIT +WAIP ...................................................................................... 50
9. SHORT MESSAGES COMMANDS ...................................................................................... 51
9.1. PARAMETERS DEFINITION.................................................................................................. 51
9.2. SELECT MESSAGE SERVICE +CSMS................................................................................... 52
9.3. PREFERRED MESSAGE STORAGE +CPMS ......................................................................... 53
9.4. PREFERRED MESSAGE FORMAT +CMGF.......................................................................... 54
9.5. SAVE SETTINGS +CSAS ..................................................................................................... 55
9.6. RESTORE SETTINGS +CRES............................................................................................... 55
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission v
9.7. SHOW TEXT MODE PARAMETERS +CSDH......................................................................... 56
9.8. NEW MESSAGE INDICATION +CNMI.................................................................................. 56
9.9. READ MESSAGE +CMGR ................................................................................................... 58
9.10. LIST MESSAGE +CMGL ................................................................................................... 59
9.11. SEND MESSAGE +CMGS................................................................................................... 61
9.12. WRITE MESSAGE TO MEMORY +CMGW........................................................................ 62
9.13. SEND MESSAGE FROM STORAGE +CMSS........................................................................ 63
9.14. SET TEXT MODE PARAMETERS +CSMP.......................................................................... 64
9.15. DELETE MESSAGE +CMGD.............................................................................................. 66
9.16. SERVICE CENTER ADDRESS +CSCA ................................................................................. 66
9.17. SELECT CELL BROADCAST MESSAGE TYPES +CSCB..................................................... 67
9.18. CELL BROADCAST MESSAGE IDENTIFIERS +WCBM...................................................... 67
9.19. MESSAGE STATUS MODIFICATION +WMSC .................................................................... 68
9.20. MESSAGE OVERWRITING +WMGO ................................................................................ 68
10. SUPPLEMENTARY SERVICES COMMANDS ................................................................. 70
10.1. CALL FORWARDING +CCFC............................................................................................ 70
10.2. CALL BARRING +CLCK ................................................................................................... 72
10.3. MODIFY SS PASSWORD +CPWD...................................................................................... 73
10.4. CALL WAITING +CCWA .................................................................................................. 73
10.5. CALLING LINE IDENTIFICATION RESTRICTION +CLIR ................................................... 75
10.6. CALLING LINE IDENTIFICATION PRESENTATION +CLIP................................................. 76
10.7. CONNECTED LINE IDENTIFICATION PRESENTATION +COLP ......................................... 77
10.8. ADVICE OF CHARGE +CAOC ........................................................................................... 78
10.9. ACCUMULATED CALL METER +CACM............................................................................ 79
10.10. ACCUMULATED CALL METER MAXIMUM +CAMM........................................................ 80
10.11. PRICE PER UNIT AND CURRENCY TABLE +CPUC ........................................................... 81
10.12. CALL RELATED SUPPLEMENTARY SERVICES +CHLD.................................................... 81
10.13. LIST CURRENT CALLS +CLCC........................................................................................ 82
10.14. SUPPLEMENTARY SERVICE NOTIFICATIONS +CSSN...................................................... 83
10.15. UNSTRUCTURED SUPPLEMENTARY SERVICE DATA +CUSD........................................... 85
10.16. CLOSED USER GROUP +CCUG ....................................................................................... 86
11. DATA COMMANDS ............................................................................................................. 88
11.1. BEARER TYPE SELECTION +CBST ................................................................................... 88
11.2. SELECT MODE +FCLASS ................................................................................................. 89
11.3. SERVICE REPORTING CONTROL +CR............................................................................... 90
11.4. CELLULAR RESULT CODES +CRC .................................................................................... 90
11.5. DTE-DCE LOCAL RATE REPORTING ++ILRR................................................................... 91
11.6. RADIO LINK PROTOCOL PARAMETERS +CRLP ............................................................... 91
11.7. OTHERS RADIO LINK PARAMETERS +DOPT.................................................................... 92
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission vi
12. FAX COMMANDS ................................................................................................................ 93
12.1. TRANSMIT SPEED +FTM .................................................................................................. 93
12.2. RECEIVE SPEED +FRM..................................................................................................... 93
12.3. HDLC TRANSMIT SPEED +FTH ....................................................................................... 94
12.4. HDLC RECEIVE SPEED +FRH.......................................................................................... 94
12.5. STOP TRANSMISSION AND WAIT +FTS ............................................................................. 94
12.6. RECEIVE SILENCE +FRS................................................................................................... 95
12.7. SETTING UP THE PC FAX APPLICATION:.......................................................................... 95
13. V24-V25 COMMANDS .......................................................................................................... 96
13.1. FIXED DTE RATE +IPR .................................................................................................... 96
13.2. DTE-DCE CHARACTER FRAMING +ICF.......................................................................... 97
13.3. DTE-DCE LOCAL FLOW CONTROL +IFC........................................................................ 98
13.4. SET DCD SIGNAL &C....................................................................................................... 99
13.5. SET DTR SIGNAL &D ....................................................................................................... 99
13.6. SET DSR SIGNAL &S ...................................................................................................... 100
13.7. BACK TO ONLINE MODE O.............................................................................................. 100
13.8. RESULT CODE SUPPRESSION Q....................................................................................... 100
13.9. DCE RESPONSE FORMAT V............................................................................................ 100
13.10. DEFAULT CONFIGURATION Z....................................................................................... 101
13.11. SAVE CONFIGURATION &W.......................................................................................... 101
13.12. AUTO-TESTS &T ........................................................................................................... 101
13.13. ECHO E......................................................................................................................... 102
13.14. RESTORE FACTORY SETTINGS &F................................................................................ 102
13.15. DISPLAY CONFIGURATION &V..................................................................................... 102
13.16. REQUEST IDENTIFICATION INFORMATION I................................................................ 103
14. SPECIFIC AT COMMANDS .............................................................................................. 105
14.1. CELL ENVIRONMENT DESCRIPTION +CCED................................................................. 105
14.2. AUTOMATIC RXLEV INDICATION +CCED..................................................................... 107
14.3. GENERAL INDICATIONS +WIND.................................................................................... 108
14.4. DATA CIPHERING MODE BETWEEN ME AND MSC +ALEA ......................................... 110
14.5. DATA CIPHERING MODE +CRYPT ................................................................................ 110
14.6. KEY MANAGEMENT +EXPKEY ..................................................................................... 111
14.7. INFORMATIONS ON PLMN +CPLMN............................................................................ 111
14.8. ANALOG DIGITAL CONVERTERS MEASUREMENTS +ADC............................................. 111
14.9. MOBILE EQUIPMENT EVENT REPORTING +CMER........................................................ 111
14.10. READ LANGUAGE PREFERENCE +WLPR..................................................................... 112
14.11. WRITE LANGUAGE PREFERENCE +WLPW.................................................................. 112
14.12. READ GPIO VALUE +WIOR......................................................................................... 113
14.13. WRITE GPIO VALUE +WIOW ..................................................................................... 113
14.14. ABORT COMMAND +WAC............................................................................................ 113
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission vii
14.15. PLAY TONE +WTONE.................................................................................................. 114
14.16. PLAY DTMF TONE +WDTMF...................................................................................... 116
15. OTHER AT COMMANDS .................................................................................................. 117
15.1. V.25 TER RECOMMANDATION ........................................................................................ 117
15.2. GSM 07.05 RECOMMANDATION..................................................................................... 117
15.3. GSM 07.07 RECOMMANDATION..................................................................................... 117
16. APPENDICES ...................................................................................................................... 118
16.1. ME ERROR RESULT CODE : +CME ERROR: <ERROR>................................................ 118
16.2. MESSAGE SERVICE FAILURE RESULT CODE: +CMS ERROR : <ER>............................ 119
16.3. SPECIFIC ERROR RESULT CODES.................................................................................... 119
16.4. FAILURE CAUSE FROM GSM 04.08 RECOMMANDATION (+CEER)............................... 120
16.5. SPECIFIC FAILURE CAUSE FOR +CEER......................................................................... 121
16.6. GSM 04.11 ANNEX E-2: MOBILE ORIGINATING SM-TRANSFER.................................. 121
16.7. UNSOLICITED RESULT CODES......................................................................................... 124
16.8. FINAL RESULT CODES ..................................................................................................... 124
16.9. INTERMEDIATE RESULT CODES ...................................................................................... 125
16.10. PARAMETERS STORAGE................................................................................................ 125
16.11. GSM SEQUENCES LIST.................................................................................................. 127
16.11.1. SECURITY................................................................................................................. 127
16.11.2. CALL FORWARDING .................................................................................................. 127
16.11.3. CALL BARRING ......................................................................................................... 128
16.11.4. CALL WAITING.......................................................................................................... 129
16.11.5. NUMBER PRESENTATION........................................................................................... 129
16.12. OPERATOR NAMES........................................................................................................ 130
17. ANNEX A (INFORMATIVE) ............................................................................................. 138
INFORMATIVE EXAMPLE ABOUT THE PIN REQUIRED ................................................................. 138
1.1.1. EXAMPLE 1 : IN THE START THE ME IS POWERED OFF. ................................................. 138
1.1.2. EXAMPLE 2: IN THE START THE ME HAS ALREADY BEEN POWERED ON......................... 139
INFORMATIVE EXAMPLE WHERE A VOICE CALL IS ORIGINATED................................................ 140
INFORMATIVE EXAMPLE ABOUT AN INCOMING CALL................................................................. 141
INFORMATIVE EXAMPLE ABOUT A CALL FORWARDING.............................................................. 142
INFORMATIVE EXAMPLE ABOUT A MULTIPARTY......................................................................... 143
INFORMATIVE EXAMPLE ABOUT PHONEBOOKS .......................................................................... 144
1.6.1. EXAMPLE 1 : THE WHOLE PHONEBOOK OF THE ME IS READ ......................................... 144
1.6.2. EXAMPLE 2 : ERASE OR WRITE A PHONEBOOK ENTRY .................................................. 145
1.6.3. EXAMPLE 3 : FIND PHONEBOOK ENTRIES...................................................................... 146
INFORMATIVE EXAMPLE ABOUT SHORT MESSAGES .................................................................... 147
1.6.4. EXAMPLE 4 : SEND A SHORT MESSAGE......................................................................... 147
1.6.5. EXAMPLE 5: READ SHORT MESSAGES........................................................................... 148
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission viii
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 1
1. Introduction
1.1. Scope of this document
This document describes the messages exchanged between an external
application module and the WAVECOM GSM mobile station, based on AT
commands in order to control incoming and outgoing calls.
This document presents the AT-commands implemented for the voice
call teleservice, the data teleservice and the short message teleservice.
1.2. Related documents
This interface specification is based on the following recommandations :
[1] ETSI GSM 07.05 : Digital cellular telecommunications system
(Phase 2) ; Use of DTE-DCE interface for Short Message
Service (SMS) and Cell Broadcast Service (CBS)
[2] ETSI GSM 07.07 : Digital cellular telecommunications system
(phase 2) ; AT command set for GSM Mobile Equipment (ME)
[3] ITU-T Recommandation V.25 ter : Serial asynchronous
automatic dialling and control
[4] ETSI GSM 03.40 : Digital cellular telecommunications system
(phase 2) ; Technical realization of the Short Message Service
(SMS) Point-to-Point (PP)
[5] ETSI GSM 03.38 : Digital cellular telecommunications system
(phase 2) ; Alphabets and language-specific information
[6] ETSI GSM 04.80 : Digital cellular telecommunications system
(Phase 2): Mobile radio interface layer 3, Supplementary
services specification, Formats and coding
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 2
1.3. ETSI secretariat
The following addresses can be useful to get the latest GSM
recommendations.
Postal address : F-06921 Sophia Antipolis CEDEX - FRANCE
Office address : 650 Route des Lucioles - Sophia Antipolis –
Valbonne - FRANCE
Internet : secretariat@etsi.fr
Tel : +33 4 92 94 42 00
Fax : +33 4 93 65 47 16
1.4. Definitions
In the GSM vocabulary, a call from GSM mobile to the PSTN is named
"mobile originated call" (MOC) or "outgoing call", and a call from fixed network
to a GSM mobile is called "mobile terminated call" (MTC) or "incoming call".
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 3
2. AT commands features
2.1. Wavecom line settings
Serial link handler is set to default values (factory settings) :
autobaud, 8 bits data, 1 bit stop, no parity, RTS/CTS flow control.
Please use the commands +IPR, +IFC, +ICF to change these settings.
2.2. Command line
Commands always start with AT (means ATtention !) and finish with a
<CR> character.
2.3. Information responses and result codes
Responses start and end with <CR><LF>, except with the ATV0 (DCE
response format) and ATQ1 (result code suppression) commands.
• If the syntax of the command is wrong, the string ERROR is sent.
• If the syntax command is correct but with some incorrect parameters,
the string +CME ERROR : <Err> or +CMS ERROR : <SmsErr> is sent with
different error codes.
• If the command line has been performed successfully, the string OK is
sent.
In some cases like "AT+CPIN?", "AT+EXPKEY?", or incoming events
(unsolicited) the module does not finish its response with the string OK.
In the following examples <CR> and <CR><LF> will be intentionally
omitted.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 4
3. General behaviors
3.1. SIM Insertion, SIM Removal
The SIM card Insertion and Removal procedures are supported. These
are software functions based on the reading of the hardware SIM presence
pin. This pin state (open / closed) is watched continuously.
When the SIM presence pin indicates a presence of a card in the SIM
connector, the module tries to establish a logical SIM session. Depending if
the somewhat is a SIM Card or not, the logical SIM session will be
established or not. The AT+CPIN? delivers the following answers :
- If SIM presence pin indicates “Nothing”, the answer to AT+CPIN? is
“+CME ERROR 10” (SIM not inserted)
- If SIM presence pin indicates “something”, and the inserted Card is a
SIM Card, the answer to AT+CPIN? is “+CPIN: xxx” depending of the
SIM PIN state.
- If SIM presence pin indicates “something’, and the inserted Card is
not a SIM Card, the answer to AT+CPIN? is CME ERROR 10
- These both last status are not immediately available due to
background initialisation. Between the hardware SIM presence pin
indication of “something” and the previous results the AT+CPIN?
sends “+CME ERROR: 515” (Please wait, init in progress)
When the SIM presence pin indicates an absence, if a SIM Card was
inserted before, an IMSI detach procedure is done, and all the user data are
removed from the module (Phonebooks, SMS etc.). The module is then in
emergency mode.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 5
3.2. Backgroung initialisation
After PIN entry, some SIM user data files are loaded in the module
(Phonebooks, SMS status …), but it can take a long time for huge
phonebooks reading. The AT+CPIN? command answers just after verification
of the PIN. User Datas are loaded after the answer in background.
This mean, that some datas may not be available just after the OK from
PIN Entry. Reading of phonebooks will then be refused by the following
“+CME ERROR: 515” or “+CMS ERROR: 515” meaning “please wait, service
is not available, init in progress”.
That kind of answer may be sent by the module at several steps :
- When trying to execute another AT command before the end
(response) of the previous one.
- when swapping from (or to) ADN to (or from) FDN and trying to read
immediately the concerned phonebook ;
- when asking for +CPIN? Status just after a SIM insertion when the
module has not determined that the inserted card is a valid SIM Card.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 6
4. General commands
4.1. Manufacturer identification +CGMI
This command gives the manufacturer identification.
Application to GSM AT+CGMI Get manufacturer
identification
GSM to application WAVECOM MODEM
OK Command valid, Wavecom
modem
4.2. Request model identification +CGMM
This command is used to get the supported bands (GSM 900, DCS 1800
or PCS 1900). The answer could be a combination of different bands in the
case of multiband modules.
Application to GSM AT+CGMM Get hardware version
GSM to application 900P
OK GSM 900 MHz primary band, or
"900E
" (extended band), "1800"
(DCS), "1900" (PCS) or "MULTIBAND"
4.3. Request revision identification +CGMR
This command is used to get the software version.
Application to GSM AT+CGMR get software version
GSM to application 310_G250.51 806216
032199 17:04
OK
Software release 3.10 ,révision
51 generated on the 21
st
of
March 1999
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 7
4.4. Product Serial Number +CGSN
This command allows the user application to know the IMEI of the GSM
module. The application sends :
Application to GSM AT+CGSN Request IMEI
GSM to application 135790248939
OK IMEI present in EEPROM
Application to GSM AT+CGSN Request IMEI
GSM to application +CME ERROR: 22 IMEI not found in EEPROM
4.5. Select TE character set +CSCS
This commands informs the ME which character set is used by the TE.
ME is then able to convert each character of entered or displayed string. This
is used to send, read or write short messages.
Application to GSM AT+CSCS="GSM" GSM default alphabet
GSM to application OK Command valid
Application to GSM AT+CSCS="PCCP437" PC character set Code Page
437
GSM to application OK Command valid
4.6. Request IMSI +CIMI
This command is used to read the IMSI (International Mobile Subscriber
Identity) of the SIM card. The PIN should be entered if needed before reading
the IMSI.
Command syntax: AT+CIMI
Response syntax: <IMSI>
Application to GSM AT+CIMI Read the IMSI
GSM to application 208200120320598 IMSI value (15 digits), starting
with MCC (3 digits) / MNC (2
digits, 3 for PCS 1900)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 8
See appendice 16.12 for MCC / MNC description.
4.7. Card Identification +CCID
This command instructs the module to read the EF-CCID file on the SIM
card.
Command syntax : AT+CCID
Response syntax : +CCID : <id>
In case of absent EF-CCID file on the SIM, the +CCID will not be sent.
But the OK will be present.
Application to GSM AT+CCID get card id
GSM to application +CCID : "123456789AB111213141"
OK EF-CCID is present, hexadecimal
format
Application to GSM AT+CCID ? get current value
GSM to application +CCID : "123456789AB111213141" Same result as +CCID
Application to GSM AT+CCID= ? get possible value
GSM to application OK no parameter but this command is
valid
4.8. Capabilities list +GCAP
This command gives the complete capabilities list.
Application to GSM AT+GCAP get capabilities list
GSM to application +GCAP: +CGSM +FCLASS
OK supports GSM commands and FAX
4.9. Repeat last command A/
Only A/ command can not be repeated. This command repeats the last
command executed.
Application to GSM A/ Repeat last command
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 9
4.10. Power off +CPOF
This specific command stops the GSM software stack and then the
hardware layer. The AT+CFUN=0 command is equivalent to +CPOF
Application to GSM AT+CPOF stop GSM stack
GSM to application OK Command valid
4.11. Set phone functionality +CFUN
This command selects the level of functionality in the mobile station.
• When the application wants to stop the module for making a power off,
or if the application wants to force the module for executing a IMSI DETACH
procedure, then it has to send :
AT+CFUN=0 (same as AT+CPOF)
This command executes a IMSI DETACH and makes a backup of some
internal parameters in the SIM and the EEPROM. Then no access to the SIM
card is possible.
If the mobile is not powered off after this command, it shall received
another command to re-start the whole GSM process.
If the mobile is turned off after this command, then the power on will
automatically execute the start of the whole GSM process.
When the application wants to re-start the module (after having done a
AT+CFUN=0 command, and without having cut the power supply), it has to
send :
AT+CFUN=1
This command starts again all the GSM stack and GSM functionality, a
complete software reset is done. All parameters are reset to their previous
E2P value if AT&W was not used.
If you write entries in phonebook (+CPBW) and then reset the module
directly (AT+CFUN=1, without any AT+CFUN=0 before), some entries may
not be written (SIM task does not have the time to write entries in SIM card)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 10
Also, the OK response will be sent at the last defined baud rate defined
by +IPR command. With autobauding the response can be at a different
baud rate, so it is better to save the defined baud rate with AT&W before
directly send the AT+CFUN=1 command.
Application to GSM AT+CFUN? Ask for current functionality level
GSM to application +CFUN: 1
OK Full functionality
Application to GSM AT+CFUN=0 Set minimum functionality, IMSI
detach procedure
GSM to application OK Command valid
Application to GSM AT+CFUN=1 Set the full functionality mode with
a complete software reset
GSM to application OK Command valid
4.12. Phone activity status +CPAS
This command returns the activity status of the mobile.
Application to GSM AT+CPAS Current activity status
GSM to application +CPAS: <pas>
OK <pas> can have the following values :
0 : ready (allow commands from TA/TE)
1 : unavailable (does not allow cmds)
2 : unknown
3 : ringing (ringer is active)
4 : call in progress
5 : asleep (low functionality)
4.13. Report Mobile Equipement errors +CMEE
This command disables or enables the use of result code
"+CME ERROR : <xxx>" or "+CMS ERROR :<xxx>" instead of simply
"ERROR". See appendice 16.1 for +CME ERROR result codes description
and appendice 16.2 for +CMS ERROR result codes.
Application to GSM AT+CMEE=0 Disable ME error reports, use only
« ERROR »
GSM to application OK
Application to GSM AT+CMEE=1 Enable « +CME ERROR : <xxx> »
Or « +CMS ERROR : <xxx> »
GSM to application OK
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 11
4.14. Keypad control +CKPD
Command syntax: +CKPD=<keys>
Execution command emulates ME keypad by giving each keystroke as a
character in a string <keys>.
The supported GSM sequences are listed in 16.11.
If emulating fails in an ME error, +CME ERROR: <err> is returned.
If emulating succeeds, the result is dependent of the GSM sequence.
<keys>: string of following characters (0-9,*,#)
Application to GSM AT+CKPD="*#21#" Check all call forwarding status
GSM to application +CCFC: 0,7
Application to GSM AT+CKPD="1234" Sequence not allowed
GSM to application +CME ERROR 3
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 12
5. Call Control commands
5.1. Dial command D
Command syntax: ATD <Numb> [I / i] [G/g] [;]
ATD> <PhbStr> [I / i] [G/g] [;]
ATD> mem <n> [I / i] [G/g] [;]
ATD> <PhbIndex> [I / i] [G/g] [;]
ATD <GSM sequence>
The ATD command is used to establish a speech, data or fax call.
According to GSM 02.30, dial command also controls supplementary
services.
For a data or fax call, the application sends to the GSM module the
following ASCII string : (the bearer has to be selected before with the +CBST
command)
ATD<nb> where <nb> is the called phone number.
For a voice call, the application sends to the GSM module the following
ASCII string : (the bearer may be selected before, if not a default bearer is
used)
ATD<nb>; where <nb> is the called phone number.
Please, notice that in case of international number, the local
international prefix has not to be set (usually 00) but need to be replaced by
the '+' character.
Example : to establish a voice call to Wavecom from another country,
the AT command shall be :
ATD+33146290800;
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 13
Notice that some country can have particular numbering rules for their
GSM handset numbering.
The answer to the ATD command can be one of the following ones:
Verbose result code Numeric (V0 set) Description
OK 0if the call succeeds, for voice call
only
CONNECT <speed> 10,11,12,13,14,15
if the call succeeds, for data calls
only, <speed> takes the value
negotiated by the GSM module.
BUSY 7If the called party is already in
communication
NO ANSWER 8If no hang up is detected after a fixed
network time-out
NO CARRIER 3Call setup failed or remote user
release. Use the AT+CEER
command to know the failure cause
See paragraph 16.8 for the description of all numeric result codes
(ATV0)
Direct dialling from a phonebook location (stored in SIM card) can be
done with the following command :
ATD> <index>; for calling <index> from the selected phonebook (by
+CPBS command)
ATD> "BILL"; for calling "BILL" from the the selected phonebook
ATD> mem <index> (mem is “SM”, “FD” or “ON”, see +CPBS
command) is a way to directly dial from a phonebook number.
Application to GSM AT+CPBS? Which phonebook is
selected ?
GSM to application +CPBS:”FD”,5,10 FDN phonebook is
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 14
selected, 5 locations are
used and 10 locations are
available.
Application to GSM ATD>SM6; Call index 6 from ADN
phonebook
GSM to application OK Call succeeds
When FDN phonebook has been locked only the numbers beginning
with the digits of FDN phonebook entries can be called.
For example, if “014629” is written in the FDN phonebook all the phone
numbers beginning with these 6 digits can be called.
It’s allowed to override the CLIR supplementary service subscription for
this call only.
“I” means “invocation” (restrict CLI presentation)
“i” means “suppression” (allow CLI presentation).
It's allowed to control the CUG supplementary service information by
“G” or “g” for this call only. The index and info values set with command
+CCUG are used.
An outgoing call attempt could be refused if the AOC service is active
and the credit is expired (NO CARRIER)
When trying to make an outgoing call while there is an active call, the
active call is first put on hold, then the call setup is made.
According to GSM 02.30, GSM sequences may be controlled using dial
command. These sequences can contain “*”, “#”. But “;” is forbidden.
If the sequence is not supported or fails, +CME ERROR: <err> is
returned.
See paragraph 16.11 to have the list of supported sequences.
Application to GSM ATD*#21# Check all call forwarding status
GSM to application +CCFC: 0,7 No call forwarding
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 15
Application to GSM ATD**61*+33146290800**25# Register call forwarding on no
reply, with no reply timer fixed at
25 s.
GSM to application OK Done
Application to GSM ATD*2# Bad sequence
GSM to application +CME ERROR 3
5.2. Hang-Up command H
The command ATH (or ATH0) is used by the application to disconnect
the remote user. In case of multiple calls, all calls are released (active, held
and waiting calls).
The specific Wavecom command ATH1 has been appended to
disconnect only the outgoing call. It can be useful in case of multi
communication.
Application to GSM ATH ask for disconnection
GSM to application OK All calls, if any, are
released
Application to GSM ATH1 ask for outgoing call
disconnection
GSM to application OK Outgoing call, if any, is
released
5.3. Answer a call A
When the GSM module receives a call, it set the RingInd signal and
sends to the application the ASCII string “RING” or “+CRING: <type>” if
cellular result code (+CRC) is enabled. Then it waits for the application to
accept the call.
GSM to application RING Incoming call
Application to GSM ATA Answer to this incoming call
GSM to application OK Call accepted
Application to GSM ATH Disconnect call
GSM to application NO CARRIER Call disconnected
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 16
5.4. Remote disconnection
This message is used by the GSM module to indicate to the application
that an active call has been released by the remote user.
The GSM module sends "NO CARRIER" to the application, and set the
DCD signal.
Also, in case AOC, the module can stop the communication if the credit
is over (release cause 68 with +CEER command)
5.5. Extended error report +CEER
If the last call setup (originating or answering) fails, this command gives
the reason of the call release.
Application to GSM ATD123456789 ; outgoing voice call
GSM to application NO CARRIER Call setup failure
Application to GSM AT+CEER ask for reason of release
GSM to application +CEER : Error <xxx>
OK <xxx> is the cause information
element values from GSM
recommandation 04.08 or specific
The cause information element from GSM 04.08 is given below in
chapter 16.4, or in chapter 16.5 for specific failure causes.
The “NO CARRIER” indicates that the AT+CEER information is available
for a failure diagnostic.
5.6. DTMF signals +VTD, +VTS
The GSM module offers the user application to send DTMF tones on the
GSM network. One command shall be used for defining the duration of the
tones (default value is 300 ms), the other for sending the Tones.
For defining the duration, the application uses :
AT+VTD=<n> where <n>*100 gives the duration in ms.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 17
If n < 4 the tone duration is 300 ms.
Application to GSM AT+VTD=6 for defining 600 ms tone duration
GSM to application OK command valid
Application to GSM AT+VTD=0 for setting the manufacturer default value
GSM to application OK
For sending DTMF tones (only when an active call exists), the
application uses :
AT+VTS=<Tone> where <Tone> is in {0-9,*,#,A,B,C,D}
Application to GSM AT+VTS=A
GSM to application OK command valid
Application to GSM AT+VTS=11
GSM to application +CME ERROR: 4 if the <Tone> is wrong
Application to GSM AT+VTS=4
GSM to application +CME ERROR: 3 if there is no communication
Example : to send the Tone sequence 13#, the application shall send :
AT+VTS=1;+VTS=3;+VTS=#
OK
5.7. Redial last number ATDL
This command is used by the application to redial the last number used
in the ATD command. The last dialled number is displayed followed by “;” for
speech calls only
Application to GSM ATDL redial last number
GSM to application 0146290800;
OK last call was a speech call
command valid
5.8. Automatic dialing with DTR AT%Dn
This command allows to activate and deactivate automatic dialing of the
phone number stored in the ifirst location of ADN phonebook. The number is
dialed on DTR OFF to ON transition.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 18
Sets commands : AT%D<n>[;]
Options : n(0-1) for activate or deactivate the
automatic dialing.
;Informs the module that the
number is a voice rather than
a fax or data number.
AT%D0 Deactivates automatic DTR dialing.
AT%D1; Activates automatic DTR dialing if DTR switches from OFF to ON;
Dials the phone number in the first location of ADN phonebook.
Speech call
AT%D1 Activates automatic DTR dialing if DTR switches from OFF to ON;
Dials the phone number in the first location of ADN phonebook.
Data or Fax call.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 19
Example :
Application to GSM AT%D1; Activates DTR dialing.
GSM to application OK Command has been
executed.
DTR is OFF
DTR switches ON
DTR switches OFF
The number in the first
location of the ADN
phonebook is dialed
automatically.
The module goes on-hook.
5.9. Automatic answer ATS0
This S0-parameter controls the automatic answering feature of the
mobile.
Application to GSM ATS0=2 Automatic answer after 2 rings
GSM to application OK
Application to GSM ATS0? Current value
GSM to application 002
OK always 3 characters with leading zeros
Application to GSM ATS0=0 no automatic answer
GSM to application OK command valid
All others S-parameters (S6,S7,S8 ...) are not implemented.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 20
5.10. Incoming Call Bearer +CICB
Command syntax : AT+CICB= <mode>
This specific command is used for incoming call type when no incoming
bearer is given (single numbering scheme, see +CSNS).
<mode> values :
0: Data
1: Fax
2: Speech
Application to GSM AT+CICB=1 If no incoming bearer, force a fax call
GSM to Application OK Command accepted
Application to GSM AT+CICB=2 If no incoming bearer, force a speech call
GSM to Application OK Command accepted
Application to GSM AT+CICB? Interrogate value
GSM to Application +CICB: 2 Default incoming bearer: speech call
Application to GSM AT+CICB=? Test command
GSM to Application +CICB: (0-2) Speech, data or fax default incoming
bearer
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 21
5.11. Gain control +VGR, +VGT
This command shall be used by the application to tune the receive gain
of the speaker and transmit gain of the microphone. The application shall
send
AT+VGR=<val> for the receive gain AT+VGT=<val> for the transmit gain
0 to 15 +12 db 0 to 31 +14 db
16 to 31 +8.9 db 32 to 63 +17 db
32 to 47 +7.5 db 64 to 95 +20 db
48 to 63 +5.1 db 96 to 127 +23 db
64 to 79 +2.9 db 128 to 159 +26 db
80 to 95 +0.5 db 160 to 191 +29 db
96 to 111 -1.8 db 192 to 223 +32 db
112 to 127 -3.7 db 224 to 255 +35 db
128 to 143 -6.5 db
144 to 159 -8.9 db
160 to 175 -11.2 db
176 to 191 -13.6 db
192 to 207 -16 db
208 to 223 -18.5 db
224 to 239 -21 db
240 to 255 -23.5 db
16 levels for receive gain are provided and 8 levels for transmit gain.
Application to GSM AT+VGR=25
GSM to application OK Command valid
Application to GSM AT+VGT=45
GSM to application OK Command valid
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 22
5.12. Microphone Mute Control +CMUT
Command syntax: AT+CMUT = <mode>
This command instructs the module to set the microphone mute or not
for the active microphone (defined with+SPEAKER command). This
command is only allowed during a call.
<mode> takes the following values :
0 : microphone mute off (default value).
1 : microphone mute on.
Application to GSM AT+CMUT=? Test command
GSM to application +CMUT : (0,1)
OK Enable/disable mute
Application to GSM AT+CMUT? Ask for current value
GSM to application +CMUT : 0
OK Current value is OFF
Application to GSM AT+CMUT=1 Mute ON (call active)
GSM to application OK Command valid
Application to GSM AT+CMUT? Ask for current value
GSM to application +CMUT : 1
OK Mute is active (call
active)
Application to GSM AT+CMUT=0 Mute OFF (call not
active)
GSM to application +CME ERROR: 3 Command not valid
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 23
5.13. Speaker & Microphone selection +SPEAKER
This specific command is used to choose the speaker and the
microphone. The application shall send
AT+SPEAKER=<ActiveSpkMic>
<ActiveSpkMic>
0SPEAKER ONE, MICRO ONE
1SPEAKER TWO, MICRO TWO
Application to GSM AT+SPEAKER=0 SPEAKER ONE and MICRO one
GSM to application OK Command valid
Application to GSM AT+SPEAKER?
GSM to application +SPEAKER: 0
OK SPEAKER ONE and MICRO ONE
are active
5.14. Echo Cancelation +ECHO
Command syntax: AT+ECHO= <mode>, [<Taps>,<ConvTh>,<DbtS>,
<FarS>, <EcDelay> ]
This specific command is used to activate, deactivate or configure
the Echo Cancelation function (for voice calls, in small rooms, cars…)
Defined Values
<mode>:
0: Deactivate Echo
1: Activate Echo
2: Configure the echo cancelation (automatically stored in E2P)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 24
<Taps> : Number of taps of the adaptive filter. This value is directly
related to the length of the longest echo path (240 words = 30 ms echo path
delay). Values from 1 to 192, default is 160
<ConvTh> : Threshold for convergence parameter. This specifies the
level of energy computed on <EcDelay> samples needed to assume
algorithm convergence. A low value provides a high convergence and a high
value a high stability. Values from 0 to 45, default is 12.
<DbtS> : Double talk sensitivity. This reflect the ratio between received
and sent energy to assume double talk occured. A low value provides a high
sensibility and a high value a low one. Values from 0 to 10, default is 5.
<FarS> : Far end speaker detection - algorithm adaptation. This is
related to then energy level needed on the receive path to allow filter taps
adaptation. If <FarS> = 0 the algorithm will always adjust the filter. Values
from 0 to 1000, default is 512.
<EcDelay> : Number of samples used to compute energy for algorithm
convergence evaluation. Values from 1 to 30, default is 10
Read Command: AT+ECHO?
This command returns the current settings of the Echo cancelation.
Returns:+ECHO:<Status>,<Taps>,<ConvTh>,<DbtS>,<FarS>, <EcDelay>
<Status> 0 Echo Desactivate.
1Echo Activate for Mic/Speak one.
2Echo Activate for Mic/Speak two.
Example:
Application to GSM AT+SPEAKER?
GSM to application +SPEAKER: 0
OK SPEAKER ONE and MICRO ONE
are active
Application to GSM AT+ECHO=1 Active Echocancelation for
Mic/Speak one.
GSM to application OK
Application to GSM AT+ECHO? Read current settings
GSM to application +ECHO: 1,160,12,5,512,10
OK
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 25
Application to GSM AT+ECHO=2 Configure the Echo cancelation
GSM to application +CME ERROR: 3 The parameters are missing.
Application to GSM AT+ECHO=2,0,12,5,512,10 Configure the Echo cancelation
GSM to application +CME ERROR: 3 The <Taps> parameter is wrong.
Values from 1 to 192
5.15. SideTone modification +SIDET
Command syntax : AT+SIDET=<val1>,<val2>
This specific command is used to get an echo of the voice in the
speaker (to have a microphone feedback in the speaker)
<val2>Level <val1> Presence
00 db 0SideTone is disabled
1- 6 db 1SideTone is enabled
2-12 db
3-18 db
Application to GSM AT+SIDET=1,0
GSM to application OK Command valid
Application to GSM AT+SIDET? Current value
GSM to application +SIDET: 1,0
OK Command valid
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 26
5.16. Initialise Voice Parameters +VIP
This command allows to restore the factory settings about the voice
parameters from EEPROM.
These voice parameters include :
• Gain control,
• Microphone mute control,
• Speaker & Microphone selection,
• Echo cancelation,
• Side tone modification.
Command Return
AT+VIP=<n>
AT+VIP=? +VIP: 1
AT+VIP? +VIP: (1)
Example :
Application to GSM AT+VIP?
GSM to application +VIP: 1
OK
Application to GSM AT+VIP=2 Syntax error
GSM to application +CME ERROR: 3
Application to GSM AT+VIP=1 Restore the factory settings in
EEPROM.
GSM to application OK The command has been executed
Application to GSM AT+VIP=? List of supported <n>s
GSM to application +VIP: (1)
OK
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 27
6. Network service commands
6.1. Signal Quality +CSQ
This command shall be used to know the received signal strength
indication (<rssi>) and the channel bit error rate (<ber>) with or without any
SIM card inserted.
<rssi> :
0 : -113 dBm or less
1 : -111 dBm
2...30 : -109 to -53 dBm
31 : -51dBm or greater
99 : not known or not detectable
<ber> :
0...7 : as RXQUAL values in the table GSM 05.08
99 : not known or not detectable
Application to GSM AT+CSQ
GSM to application +CSQ: <rssi>,<ber>
OK <rssi> and <ber> as defined before
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 28
6.2. Operator selection +COPS
To select the operator, three possibilities exist :
1- The mobile enters the manual mode, and then try to find an operator
which is indicated by the application. If it finds and registers correctly, then
the mobile stays in idle mode.
2- The mobile enters the automatic mode, and then try to find the home
operator. If it finds and registers correctly, then the mobile stays in idle mode ;
if not, the mobile search automatically another network.
3- The mobile enters the manual/automatic mode, and then try to find
an operator which is indicated by the application (like in manual mode) . If this
attempt fails the automatic mode is entered.
Read command returns the current mode and the currently selected
operator. Just notice that in manual mode, this PLMN could not be the one
the mobile has to register (searching phase).
To force an attempt to select and register a network operator, the
application must send the following command :
Command syntax:
AT+COPS=<mode>, [<format> [ , <oper> ] ]
Possible responses for AT+COPS=<mode>:
OK (Network is selected in full service)
+CME ERROR: 30 (No network service),
+CME ERROR: 32 (Network not allowed – emergency calls only)
+CME ERROR: 3 (During a call not allowed)
+CME ERROR: 4 (Wrong parameters)
Response syntax for AT+COPS?:
+COPS: <mode> [, <format>, <oper> ]
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 29
Response syntax for AT+COPS=?:
+COPS: [list of supported (<stat>, long alphanumeric <oper>,
short alphanumeric <oper>s, numeric <oper>) s]
The parameters values are the following ones:
<mode>:
0: automatic (default value)
1: manual
3: set only <format> (for read command AT+COPS?)
4: manual / automatic (<oper> shall be present), if manual
selection fails, automatic mode is entered.
<format>: format of <oper> field
0: long format alphanumeric <oper>
1: short format alphanumeric <oper>
2: numeric <oper> (default value)
<stat>: status of <oper>
0: unknown
1: available
2: current
3: forbidden
<oper>: operator identifier (MCC/MNC in numeric format only for
operator selection).,
Long alphanumeric format can be up to 16 characters long (see
appendice 16.12 for operator names description, field is “Name”)
Short alphanumeric format can be up to 8 characters long.
Application to GSM AT+COPS? Ask for current plmn
GSM to application +COPS: 0,2,20801
OK Home PLMN is France telecom
Itineris
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 30
Application to GSM AT+COPS=? Ask for PLMN list
GSM to application +COPS: (2,”F Itineris”,
“Itine”,”20801”), (3,”F SFR”,
“SFR”,”20810”)
OK
Home PLMN is France Telecom
SFR network has been seen
Application to GSM AT+COPS=1,2,20810 Ask for registration on SFR network
GSM to application +CME ERROR: 32 Network not allowed – emergency
calls only
Application to GSM AT+COPS=1,1,20810 Ask for registration on SFR network
GSM to application +CME ERROR: 3 Operation not allowed
Application to GSM AT+COPS=0,2 Ask for registration on home
network
GSM to application OK Succeed
Application to GSM AT+COPS=3,0 Ask for setting alphanumeric format
GSM to application OK Succeed
Application to GSM AT+COPS? Ask for current plmn
GSM to application +COPS: 0,0,”F Itineris”
OK Home PLMN is France telecom
Itineris
Application to GSM AT+COPS=1,0,”F SFR” Ask for registration on SFR network
GSM to application +CME ERROR: 32 Network not allowed – emergency
calls only
Application to GSM AT+COPS=4,0,”F SFR” Ask for registration on SFR network
in manual/automatic mode
GSM to application OK Command succeed
Application to GSM AT+COPS? Ask for current plmn
GSM to application +COPS: 0,0,”F Itineris”
OK Home PLMN is France telecom
Itineris !
So the attempt to register on SFR
Network has failed but the
automatic selection on Home
PLMN has succeed.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 31
6.3. Network registration +CREG
This command is used by the application to know the registration status
of the mobile.
Command syntax : AT+CREG= <mode>
Response syntax : +CREG: <mode>, <stat> [ ,<lac>,<ci> ]
for AT+CREG? command only
<mode>
0: Disable network registration unsolicited result code (default)
1: Enable network registration code result code +CREG : <stat>
2: Enable network registration and location information unsolicited
result code +CREG: <stat>,<lac>,<ci> if there is a change of the network cell.
<stat>
0 : not registered, ME is not currently searching a new operator
1 : registered, home network
2 : not registered, ME currently searching a new operator to register to
3 : registration denied
4 : unknown
5 : registered, roaming
<lac>: string type; two byte location area code in hexadecimal format
(e.g. “00C3” equals 193 in decimal)
<ci>: string type; two byte cell ID in hexadecimal format
Application to GSM AT+CREG?
GSM to application +CREG: <mode>,<stat>
OK as defined before
Application to GSM AT+CREG=<mode> disable/enable network registration
unsolicited result code
GSM to application OK command valid
Application to GSM AT+CREG=?
GSM to application +CREG: (0-2) 0,1,2 <mode> values are supported
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 32
6.4. Read operator name +WOPN
This specific command returns the operator name in alphanumeric
format when given the numeric format.
Command syntax: AT+WOPN=<format>,<NumOper>
Response syntax: +WOPN: <format>,<AlphaOper>
<format> is the required format. Only long (0) and short (1) alphanumeric
formats are supported.
<NumOper> is the operator in numeric format.
<AlphaOper> is the operator in long or short alphanumeric format (see
appendice 16.12 for operator names description)
Application to GSM AT+WOPN=? Test command
GSM to application OK
Application to GSM AT+WOPN=0,20801 Give an operator in numeric format
GSM to application +WOPN: 0,"F Itineris"
OK Alphanumeric answer
Application to GSM AT+WOPN=0,99999 Give a wrong operator
GSM to application +CME ERROR : 22 Not Found
6.5. Preferred operator list +CPOL
This command is used to edit the SIM preferred list of networks.
Command syntax: AT+CPOL= [ <index> ][ , <format> [ , <oper> ] ]
The different possibilities are:
AT+CPOL = <index> to delete an entry.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 33
AT+CPOL = , <format> to set the format used by the read command
(AT+CPOL?).
AT+CPOL = , <format>, <oper> to put <oper> in the next free location.
AT+CPOL = <index> , <format> , <oper> to write <oper> in the <format>
at the <index> .
The supported format are those of the +COPS command.
The length of this list is limited to 8 entries .
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 34
Application to GSM AT+CPOL? Ask for preferred list of networks
GSM to application +CPOL: 1,2,26201
+CPOL: 6,2,20810
OK
Preferred list of networks in
numeric format
Application to GSM AT+CPOL=,0 Select long alphanumeric format
GSM to application OK
Application to GSM AT+CPOL? Ask for preferred list of networks
GSM to application +CPOL: 1,0,”D1-TELEKOM”
+CPOL: 6,0,”F SFR”
OK
Preferred list of networks in long
alphanumeric format
Application to GSM AT+CPOL=7,2,20801 Add a network to the list
GSM to application OK
Application to GSM AT+CPOL? Ask for preferred list of networks
GSM to application +CPOL: 1,0,”D1-TELEKOM”
+CPOL: 6,0,”F SFR”
+CPOL: 7,0,”F Itineris”
OK
Preferred list of networks in long
alphanumeric format
Application to GSM AT+CPOL=7 Delete 7th location
GSM to application OK
Application to GSM AT+CPOL? Ask for preferred list of networks
GSM to application +CPOL: 1,0,”D1-TELEKOM”
+CPOL: 6,0,”F SFR”
OK
Preferred list of networks in long
alphanumeric format
Application to GSM AT+CPOL=8,2,77777 Add an inexistent network to the list
GSM to application OK
Application to GSM AT+CPOL? Ask for preferred list of networks
GSM to application +CPOL: 1,0,”D1-TELEKOM”
+CPOL: 6,0,”F SFR”
+CPOL: 8,2,77777
OK
Preferred list of networks in long
alphanumeric format but 8
th
entry is
unknown so the module edits it in
the numeric format.
Application to GSM AT+CPOL=9,0,”F Itineris” Add an inexistent network to the list
Format text
Application to GSM AT+CPOL? Ask for preferred list of networks
GSM to application +CPOL: 1,0,”D1-TELEKOM”
+CPOL: 6,0,”F SFR”
+CPOL: 8,2,77777
+CPOL: 9,0,”F Itineris”
OK
Preferred list of netwoks in long
alphanumeric format.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 35
7. Security commands
7.1. Enter PIN +CPIN
This command is used to enter ME passwords (CHV1 / CHV2 / PUK1 /
PUK2…) which are needed before any other functionality of the ME can be
used. The CHV1/CHV2 length is between 4 and 8 digits, the PUK1/PUK2
length is 8 digits only.
If the user application try to establish an outgoing call before having
validated the SIM PIN code (CHV1), then the GSM module will refuse the
"ATD" command with a "+CME ERROR: 11" (SIM PIN required).
It's up to the application to validate the PIN after each reset or power on
if the PIN was enabled. The application shall therefore use the command :
AT+CPIN=<pin>
Application to GSM AT+CPIN=1234 enter PIN
GSM to application OK PIN code is correct
Application to GSM AT+CPIN=5678 enter PIN
GSM to application +CME ERROR: 3 operation not allowed, PIN previously entered
After 3 unsuccessful codes, the PUK will then be required. The PUK
validation forces the user to enter as a second parameter a new PIN code
which will be the new PIN code if the PUK validation succeeds. The CHV1 is
then enabled if the PUK1 is correct. The application shall therefore use the
command :
AT+CPIN=<Puk>,<NewPin>
Application to GSM AT+CPIN=00000000,1234 enter PUK and new PIN
GSM to application +CME ERROR: 16 Incorrect PUK
Application to GSM AT+CPIN=12345678,1234 enter PUK and new PIN, 2nd attempt
GSM to application OK PUK correct, new PIN stored
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 36
To know which code has to be entered (or not), the following
interrogation command can be used :
AT+CPIN?
The possible responses are :
+CPIN: READY ME is not pending for any password
+CPIN: SIM PIN CHV1 is required
+CPIN: SIM PUK PUK1 is required
+CPIN: SIM PIN2 CHV2 is required
+CPIN: SIM PUK2 PUK2 is required
+CPIN: PH-SIM PIN SIM lock (phone-to-SIM) is required
+CPIN: PH-NET PIN Network personnalisation is required
+CME ERROR: <err> SIM failure (13) absent (10) etc...
Please note that in this case the mobile does not finish its response with
the OK string.
The response +CME ERROR : 13 (SIM failure) is returned after 10
unsuccessful PUK presentations. The SIM card is then out of order and shall
be replaced by a new one.
Example : 3 failed PIN validations + 1 successful PUK validation
AT+CPIN?
+CPIN: SIM PIN Read the PIN status
The GSM module requires SIM PIN
AT+CPIN=1235
+CME ERROR: 16 First attempt to enter a SIM PIN
Bad PIN
AT+CPIN=1236
+CME ERROR: 16 Second attempt
Bad PIN
AT+CPIN=1237
+CME ERROR: 16 Third attempt
Bad PIN
AT+CPIN?
+CPIN: SIM PUK Read PIN state
The GSM module requires PUK
AT+CPIN=99999999,5678
OK The PUK is entered, the new PIN shall be
5678 PUK validation is OK. New Pin is 5678
AT+CPIN?
+CPIN: READY Read PIN state
GSM module is ready
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 37
If the user try to do something which requires PIN2 (CHV2) the GSM
module will refuse his action with a “+CME ERROR: 17” (SIM PIN2 required).
Then the GSM module is waiting SIM PIN2 to be given.
Of course if SIM PIN2 is blocked , SIM PUK2 is required instead of SIM
PIN2.
For instance, the GSM module needs PIN2 to write in the fixed dialling
phonebook (FDN) , so if SIM PIN2 authentification has not been done during
the current cession the SIM PIN2 is required:
Application to GSM AT+CPBS=”FD” Choose FDN
GSM to application OK
Application to GSM AT+CPBW=5,"01290917",129,"Jacky"
write in FDN at location 5
GSM to application +CME ERROR:17 SIM PIN2 is required
Application to GSM AT+CPIN?
GSM to application SIM PIN2 SIM PIN2 is required
Application to GSM AT+CPIN=5678 Enter SIM PIN2
GSM to application OK
Application to GSM AT+CPBW=5,"01290917",129,"Jacky"
write in FDN at location 5
GSM to application OK Now writing in FDN is
allowed
Please note that the GSM module ask only once PIN2 or PUK2, so if
they aren’t entered right, the next +CPIN? command will return “+CPIN:
READY”.
Remark
In the way Application to GSM, an "h" character shall be added before
the PIN value if cyphering mode (with D.E.S algorithm ) is on. See +EXPKEY
command.
Same remark for +CLCK and +CPWD commands.
7.2. Enter PIN2 +CPIN2
This specific command is used to validate the PIN2 code (CHV2), or to
validate the PUK2 code (UNBLOCK CHV2) and to define a new PIN2 code.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 38
Of course +CPIN command allows to validate PIN2 or PUK2 codes but
only when the last executed command resulted in PIN2 authentification
failure.
The PIN2 length is between 4 and 8 digits, the PUK2 length is 8 digits
only.
AT+CPIN2=<pin2>
Application to GSM AT+CPIN2=1234 enter PIN2
GSM to application OK PIN2 code is correct
Application to GSM AT+CPIN2=5678 enter PIN2
GSM to application +CME ERROR: 3 operation not allowed, PIN2
previously entered
After 3 unsuccessful codes, the PUK2 will then be required. The PUK2
validation forces the user to enter as a second parameter a new PIN2 code
which will be the new PIN2 code if the PUK1 validation succeeds. The
application shall therefore use the command :
AT+CPIN2=<puk2>,<NewPin2>
Application to GSM AT+CPIN2=00000000,1234 enter PUK2 and new PIN2
GSM to application +CME ERROR: 16 Incorrect Password (PUK2)
Application to GSM AT+CPIN2=12345678,1234 enter PUK2 and new PIN1, 2
nd
attempt
GSM to application OK PUK2 correct, new PIN2 stored
To know which code has to be entered (or not), the following
interrogation command can be used :
AT+CPIN2?
The possible responses are :
+CPIN2: READY No PIN2 is needed
+CPIN2: SIM PIN2 PIN2 is required
+CPIN2: SIM PUK2 PUK2 is required
+CME ERROR: <err> Absent (10) etc...
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 39
7.3. PIN remaining attempt number +CPINC
This specific command instructs the module to display the number of valid tries for PIN1
(CHV1), PIN2 (CHV2), PUK1 (UNBLOCK CHV1) and PUK2 (UNBLOCK CHV2) identifiers.
Command syntax : AT+CPINC
Response syntax : +CPINC : <n1>,<n2>,<k1>,<k2>
<n1>, <n2> are the remaining tries of PIN1, PIN2 (0 = blocked, 3 max)
<k1>, <k2> are the remaining tries of PUK1, PUK2 (0 = blocked, 10 max)
To make it running, the card should be present at the initialisation time,
in the opposite case, an error will be sent (+CME ERROR : 10).
Application to GSM AT+CPINC Ask remaining tries
GSM to application +CPINC : 2,3,10,10 First CHV1 attempt was a failure
Application to GSM AT+CPINC? Ask current values
GSM to application +CPINC : 2,3,10,10 First attempt was a failure
Application to GSM AT+CPINC=? Ask possible values
GSM to application OK
7.4. Facility lock +CLCK
This command shall be used by the application to lock, unlock or
interrogate a ME or network facility <fac>.
Command syntax: AT+CLCK= <fac>,<mode>[,<passwd>[,<class>] ]
Response syntax: +CLCK: <status> [ ,<class1> ]
<CR><LF>+CLCK: <status>,<class2>
[ … ] ]
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 40
The following <fac> values are supported:
"PS" : SIM lock facility with a 8 digits password.
"SC" : PIN enable (<mode> = 1) / disable (<mode> = 0)
"AO" : BAOC (Barr All Outgoing Calls)
"OI" : BOIC (Barr Outgoing International Calls)
"OX" : BOIC-exHC (Barr Outg. Internat Calls except to Home Country)
"AI" : BAIC (Barr All Incoming Calls)
"IR" : BIC-Roam (Barr Inc. when Roaming outside Home Country)
"AB" : All Barring services
"AG" : All outGoing barring services
"AC" : All inComing barring services
"PN" : Network lock with a 8 digits password (NCK).
“FD”: SIM Fixed Dialling Numbers (FDN) memory feature
(PIN2 is required as <password>)
<mode>
0 : unlock the facility
1 : lock the facility
2 : query status
<class> : A facility status can be changed for only one class, or for all
classes (7 or omitted).
1 : Voice (telephony)
2 : Data (refer to all bearer services)
4 : Fax (facsimile services)
8 : Short Message service
7 : equal to all classes (Default value)
Any attempt to combine different classes will result in activation /
desactivation / interrogation of all classes.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 41
The password maximum length is given with the AT+CPWD=?
command.
Application to GSM AT+CLCK="SC",1,1234 enable PIN
GSM to application OK PIN was right
Application to GSM AT+CLCK? Read PIN status
GSM to application +CLCK: ("PS", 0),("SC", 1), ("PN",0),
(“FD”,0)
OK
(no longer supported in GSM 07.07)
PIN is enabled, no SIM
lock, no network lock, no
information on Call barring
Application to GSM AT+CLCK="SC",0,5555 disable PIN
GSM to application +CME ERROR: 16 PIN was wrong
Application to GSM AT+CPIN=1234 Enter PIN
GSM to application OK PIN was good
Application to GSM AT+CLCK= ? request supported facilities
GSM to application +CLCK : ("PS","SC","AO","OI", "OX",
"AI", "IR","AB", "AG","AC", “FD”, "PN")
OK
supported facilities
Application to GSM AT+CLCK="PN",1,12345678 Activate network lock
GSM to application OK Network lock activated
Application to GSM AT+CLCK="AO",1,1234,2 Activate All Outgoing Calls
Barring for Data Calls
GSM to application OK Call Barring is activate
Application to GSM AT+CLCK="AO",2 Query BAOC status
GSM to application <CR><LF> +CLCK : 1,2
OK BAOC activate for Data
calls only
7.5. Change password +CPWD
Command syntax : AT+CPWD= <fac>, <oldpwd>, <newpwd>
This command shall be used by the application to change a password
(PIN, call barring, NCK...). The facility values (<fac>) are the same as for
+CLCK command, with a “P2” facility to manage SIM PIN2.
For the network lock ("PN"), the unlock is forbidden after 10 failed
attempts to disable (unlock) the network lock with an incorrect password.
Application to GSM AT+CPWD=? Possible values
GSM to application +CPWD: ("PS", 8),("SC", 8),("AO", 4),
("OI", 4), ("OX", 4),("AI", 4),("IR", 4), CHV1/CHV2 must be on 8
digits maximum (4 min)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 42
("AB", 4), ("AG", 4), ("AC", 4),
("P2", 8), ("FD", 8), ("PN", 8)
OK
For Call Barring, 4 digits
maximum
Application to GSM AT+CPWD="SC",1234,5555 change PIN
GSM to application OK PIN iwas good
Application to GSM AT+CPWD="SC",1234,5555 Change PIN
GSM to application +CME ERROR: 16 PIN was wrong
Application to GSM AT+CPIN=5555 Enter PIN
GSM to application OK PIN was good
Application to GSM AT+CPWD="PN",12345678,00000000 change NCK
GSM to application OK NCK changed for net lock
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 43
8. Phonebook commands
8.1. Select phonebook memory storage +CPBS
This command selects phonebook memory storage. The available
phonebooks are the ADN (SIM), FDN (SIM fixdialling, restricted phonebook),
MSISDN (SIM own numbers) and EN (SIM emergency number) phonebooks.
Application to GSM AT+CPBS= "SM" Select ADN phonebook
GSM to application OK ADN phonebook is
selected
Application to GSM AT+CPBS=? Possible values
GSM to application +CPBS: ("SM",”FD”,”ON”,"EN")
OK ADN, FDN, MSISDN
phonebooks supported
Application to GSM AT+CPBS ? Status
GSM to application +CPBS : "SM",10,20
OK ADN phonebook selected,
10 used locations, 20
locations available
The ADN phonebook could not be selected is FDN is active.
8.2. Read phonebook entries +CPBR
This command returns phonebook entries for a location range from the
current phonebook memory storage selected with +CPBS.
Application to GSM AT+CPBR=? Test command
GSM to application +CPBR: (1-50), 20,10
OK 50 locations (from 1 to 50),
max length of 20 for phone
10 characters max for the
associated text
Application to GSM AT+CPBR=12,14 Read entries from 12 to 14
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 44
GSM to application +CPBR : 12,"112",129,"Emergency"
+CPBR : 13,"+331290909",145, "Fred"
+CPBR :
14, "0146290808",129, "Zazi"
OK
Display locations 12,13,14
with Location, Number,
Type (TON/NPI), Text
Application to GSM AT+CPBR=10 Read entry 10
GSM to application +CPBR :10,"0146290921",129,"Rob"
OK Display location 10
Application to GSM AT+CPBR=52 Read entry 52 (wrong)
GSM to application +CME ERROR: 21 Invalid index
8.3. Find phonebook entries +CPBF
This command returns phonebook entries which alphanumeric field start
with a given string. The AT+CPBF= "" command can be used to display all
phonebook entries sorted in alphabetical order.
This command is not allowed for "EN" phonebook, which does not
contain alphanumeric field.
Application to GSM AT+CPBF=? Test command
GSM to application +CPBF: 20,10
OK max length of 20 for phone
10 characters for the text
Application to GSM AT+CPBF= "E" Read entries with "E"
GSM to application +CPBF : 12,"112",129,"Emergency"
+CPBF : 15,"+331290101",145, "Eric"
OK
Display locations with text
field starting with "E"
Application to GSM AT+CPBF="H" Read entries with "H"
GSM to application +CME ERROR: 22 Entry not found
8.4. Write phonebook entry +CPBW
This command writes phonebook entry in location number <index> in the
current phonebook memory storage.
This command is not allowed for "EN" phonebook, which is not writable.
Application to GSM AT+CPBW=? Test command
GSM to application +CPBW: (1-50),20,(129,145),10 50 locations, phone
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 45
OK length=20, TON/NPI of
129 or 145, text length=10
Application to GSM AT+CPBW=3 Erase location 3
GSM to application OK Location 3 erased
Application to GSM AT+CPBW=5,"112",129 ,"SOS" Write at location 5
GSM to application OK Location 5 written
Application to GSM AT+CPBW=5,"01290917",129,"Jacky"
Overwrite location 5
GSM to application OK Location 5 is overwritten
Application to GSM AT+CPBW=,"+33145221100",145,
"SOS" Write at the first free
location
GSM to application OK Free location is written
Application to GSM AT+CPBW=,"0345221100",129,"SOS"
Write at the first free
location
GSM to application +CME ERROR: 20 Phonebook full
Application to GSM AT+CPBW=57,"112",129 ,"WM" Write at loc 57 (wrong)
GSM to application +CME ERROR: 21 Invalid index
Application to GSM AT+CPBW=7,"012345678901234567
890",129 ,"WAVE" Write at loc 7 a long Phone
number (21 digits)
GSM to application +CME ERROR: 26 Phone too long
Application to GSM AT+CPBW=7,"0122334455",129 ,
"WAVECOM TEL" Write at loc 7 a long Text
(11 characters)
GSM to application +CME ERROR: 24 Text too long
When the fixed dialling phonebook (FDN) is locked , this command is not
allowed. Moreover , when FDN is unlocked , PIN2 is required to write in the
FDN phonebook.
But if PIN2 authentification has been done during the current cession ,
+CPBW command with FDN is allowed .
Application to GSM AT+CPBS=”FD” Choose FDN
GSM to application OK
Application to GSM AT+CPBW=5,"01290917",129,"Jacky"
write in FDN at location 5
GSM to application +CME ERROR:17 SIM PIN2 is required
Application to GSM AT+CPIN?
GSM to application SIM PIN2 SIM PIN2 is required
Application to GSM AT+CPIN=5678 Enter SIM PIN2
GSM to application OK
Application to GSM AT+CPBW=5,"01290917",129,"Jacky" write in FDN at location 5
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 46
GSM to application OK Now writing in FDN is
allowed
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 47
8.5. Phonebook phone search +CPBP
This specific command instructs the module to look in the phonebook
for an item having the same phone number that defined in parameter.
Command syntax : AT+CPBP=<PhoneNumber>
<PhoneNumber> is coded like all phone numbers in GSM 07.07 or GSM
07.05 .
Application to GSM AT+CPBP= "+331290101" Read entries with this
phone number
GSM to application +CPBP : 15,"+331290101",145, "Eric"
OK Display location with this
phone number
Application to GSM AT+CPBP= "+331290101" Read entries with this
phone number
GSM to application +CPBP : 15,"+331290101",145, "Eric"
OK Display location with this
phone number
Application to GSM AT+CPBP= "+331290101" Read entries with this
phone number
GSM to application +CPBP : 15,"+331290101",145, "Eric"
OK Display location with this
phone number
Application to GSM AT+CPBP= "01290101" Read entries with this
phone number
GSM to application +CPBP : 15,"+331290101",145, "Eric"
OK Display location with this
phone number
Application to GSM AT+CPBP= "0129" Read entries with "H"
GSM to application +CME ERROR: 22 Entry not found
8.6. Move action in phonebook +CPBN
Command syntax: AT+CPBN = <mode>
This specific command instructs the module to make a forward or a
backward move in the phonebook (in alphabetical order).
This command is not allowed for "EN" phonebook, which does not
contain alphanumeric field.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 48
<mode> may take the following values : 0 for First item, 1 for Last item, 2
for Next valid item in alphabetical order, 3 for Previous valid item in
alphabetical order, 4 for Last read item and 5 for Last written item.
Application to GSM AT+CPBN= ? Test Command
GSM to application +CPBN=<0-3> Possible Modes
Application to GSM AT+CPBN= 0 Read the first location
GSM to application +CPBN : 15,"+331290101",145, "Eric"
OK Display the first location
Application to GSM AT+CPBN=2 Read the next location
GSM to application +CPBN :5,"+33147658987",145, "Fran
k"
OK
Display the second
location
Application to GSM AT+CPBN=2 Read the next location
GSM to application +CPBN : 6,"+331290302",145, "Marc"
OK Display the third location
Application to GSM AT+CPBN=3 Read the previous location
GSM to application +CPBN :5,"+33147658987",145, "Fran
k"
OK
Display the second
location
Application to GSM AT+CPBN=1 Read the last location
GSM to application +CPBN : 6,"+331290302",145, "Marc"
OK Display the last location
Application to GSM AT+CPBN=2 Read the next location
GSM to application +CPBN : 15,"+331290101",145, "Eric"
OK Display the first location
Using mode 4 and 5 with +CPBF command and CPBW :
Application to GSM AT+CPBF=”Er” Find “Er” in phonebook
GSM to application +CPBF : 15,"+331290101",145, "Eric"
OK Display this location
Application to GSM AT+CPBN=2 Read the next location
GSM to application +CPBN :5,"+33147658987",145, "Fran
k"
OK
Display the following
location
Application to GSM AT+CPBF=”Er” Find “Er” in phonebook
GSM to application +CPBF : 15,"+331290101",145, "Eric"
OK Display this location
Application to GSM AT+CPBN=4 Read the Last read
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 49
location
GSM to application +CPBN :15,"+331290101",145, "Eric" Display the Last read
location
Application to GSM AT+CPBW=,"0146290800",129, "WM" Write an item at the first
free location
GSM to application OK No information about this
location …
Application to GSM AT+CPBN=4 Read the Last read
location
GSM to application +CPBN :15,"+331290101",145, "Eric" Display the Last read
location
GSM to application +CPBN : 38,"0146290800",129, "WM" Display the Last writen
item with its location.
Application to GSM AT+CPBN=4 Read the Last read item
GSM to application +CPBN : 38,"0146290800",129, "WM" Now the last read item is
the last writen item too
Please note that the AT+CPBN=5 command is useful after an
AT+CPBW command used without a location.
8.7. Subscriber number +CNUM
This command returns the MSISDN(s) related to the subscriber.
If subscriber has different MSISDNs for different services, each MSISDN
is returned in a separate line.
Command syntax : AT+CNUM
Response syntax ;
+CNUM : <alpha1>, <number1>, <type1>
<CR><LF> +CNUM : <alpha2>, <number2>, <type2> ....
Defined values
<alphax> : optional alphanumeric string associated with <numberx>
<numberx> : string type phone number of format specified by <typex>
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 50
<typex> : type of adress octet in integer format
Application to GSM AT+CNUM Get MSISDN(s)
GSM to application +CNUM : "Phone" , "0612345678", 129
+CNUM : "Fax", "0687654321",129 MSISDNs
Application to GSM AT+CNUM= ?
GSM to application OK
8.8. Avoid phonebook init +WAIP
This specific command allows to inhibit the initialization of SIM
phonebooks (loading of the ADNs and FDNs only) during the next boots.
Command syntax : AT+WAIP=<mode>
<mode> Action
0Normal initialization (with phonebooks)
1No phonebook initialization for ADN and FDN
Application to GSM AT+WAIP? current values ?
GSM to application +WAIP : 0
OK Default value (init
phonebooks)
Application to GSM AT+WAIP= ? possible values ?
GSM to application +WAIP : (0,1)
OK disable / enable
Application to GSM AT+WAIP=1 Inhibit initialization of
phonebooks (next boot)
GSM to application OK no answer
Application to GSM AT&W Save modifications in
EEPROM
Be careful: The given value should be stored in EEPROM, so the
command AT&W must be used to save the new <mode> value.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 51
9. Short Messages commands
9.1. Parameters definition
<da> Destination Address, coded like GSM 03.40 TP-DA
<dcs> Data Coding Scheme, coded like in document [5].
<dt> Discharge Time in string format : "yy/MM/dd,hh :mm :ss±zz"
(Year [00-99], Month [01-12], Day [01-31], Hour, Minute,
Second and Time Zone [quarters of an hour] )
<fo> First Octet, coded like SMS-SUBMIT first octet in document [4],
default value is 17 for SMS-SUBMIT
<index> Place of storage in memory.
<length> Text mode (+CMGF=1): number of characters
PDU mode (+CMGF=0): length of the TP data unit in octets
<mem1> Memory used to list, read and delete messages
(+CMGL, +CMGR and +CMGD).
<mem2> Memory used to write and send messages
(+CMGW, +CMSS).
<mid> CBM Message Identifier.
<mr> Message Reference.
<oa> Originator Address.
<pid> Protocol Identifier.
<pdu> For SMS : GSM 04.11 SC address followed by GSM 03.40
TPDU in hexadecimal format, coded as specified in doc [4]
For CBS : GSM 03.41 TPDU in hexadecimal format
<ra> Recipient Address.
<sca> Service Center Address
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 52
<scts> Service Center Time Stamp in string format :
"yy/MM/dd,hh :mm :ss±zz"
(Year/Month/Day,Hour:Min:Seconds±TimeZone)
<sn> CBM Serial Number
<st> Status of a SMS-STATUS-REPORT
<stat> status of message in memory.
<tooa> Type-of-Address of <oa>.
<tora> Type-of-Address of <ra>.
<tosca> Type-of-Address of <sca>.
<total1> Number of message locations in <mem1>.
<total2> Number of messages locations in <mem2.
<used1> Total number of messages locations in <mem1>.
<used2> Total number of messages locations in <mem2.
<vp> Validity Period of the short message, default value is 167
9.2. Select message service +CSMS
The supported services are GSM originated (SMS-MO) and terminated
short message (SMS-MT), Cell Broadcast Message (SMS-CB) services.
The syntax is : AT+CSMS=<service>
<service> :
0 : SMS AT commands are compatible with GSM 07.05 Phase 2
version 4.7.0.
1 : SMS AT commands are compatible with GSM 07.05 Phase 2 +
version .
Application to GSM AT+CSMS=0 SMS AT command Phase 2 version 4.7.0
GSM to application +CSMS: 1, 1, 1
OK SMS-MO,SMS-MT and SMS-CB supported
Application to GSM AT+CSMS=1 SMS AT command Phase 2 +
GSM to application +CMS ERROR: 301 SMS service Phase 2+ not supported
GSM to application +CSMS: 0, 1, 1, 1
OK GSM 03.40 et 03.41 (SMS AT command
Phase 2 version 4.7.0),
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 53
SMS-MO,SMS-MT and SMS-CB supported
Application to GSM AT+CSMS=? Possible service
GSM to application +CSMS: (0)
OK Only GSM 03.40 et 03.41 is possible (SMS
AT command Phase 2 version 4.7.0)
9.3. Preferred Message Storage +CPMS
This command allows to define the message storage area to be used for
reading, writing…
Command syntax : AT+CPMS=<mem1>, [<mem2>]
<mem1>: Memory used to list, read and delete messages. It can be:
- “SM”: SMS message storage (in SIM) (default)
- “BM”: CBM message storage (in volatile memory).
<mem2>: Memory used to write and send messages
- “SM”: SMS message storage (in SIM) (default).
If the command is correct, the following indication message is sent:
+CPMS: <used1>,<total1>,<used2>,<total2>
When <mem1> is selected, all following +CMGL, +CMGR and
+CMGD commands are related to the type of SMS stored in this memory.
Application to GSM AT+CPMS=? Possible message storages
GSM to application +CPMS: (("SM","BM"),("SM"))
OK Read, list, delete: SMS or CBM
Write,send: SMS
Application to GSM AT+CPMS? Read it
GSM to application +CPMS: "SM", 3, 10,"SM",3,10
OK Read, write…SMS from/to SIM
3 SMS are stored in SIM. 10 is the
total available SIM memory.
Application to GSM AT+CPMS="AM" Select false message storage
GSM to application +CMS ERROR: 302
Application to GSM AT+CPMS="BM" Select CBM message storage
GSM to application +CPMS: 2, 20,3,10
OK Read, list,delete CBM from RAM
2 CBM are stored in RAM
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 54
Application to GSM AT+CPMS? Read it
GSM to application +CPMS: "BM", 2, 20,"SM",3,10
OK Read, list,delete CBM from RAM
Write SMS to SIM.
9.4. Preferred Message Format +CMGF
The formats implemented are the text mode and the PDU mode.
In PDU mode, a complete SMS Message including all header information
is passed as a binary string (in hexadecimal format, so only this set of
characters is allowed : {‘0’,’1’,’2’,’3’,’4’,’5’,’6’,’7’,’8’,’9’, ‘A’, ‘B’,’C’,’D’,’E’,’F’} ).
Each pair or characters is converted to a byte (ex : ‘41’ is converted to the
ASCII character ‘A’, whoes ASCII code is 0x41 or 65).
In Text mode, every commands and responses are in ASCII characters.
The chosen format is stored in EEPROM by the command +CSAS.
Application to GSM AT+CMGF ? current message format
GSM to application +CMGF: 1
OK Text mode
Application to GSM AT+CMGF=? Possible message format
GSM to application +CMGF: (0-1)
OK Text or PDU modes are
available
Example to send a SMS Message in PDU mode
Application to GSM AT+CMGF=0 PDU message format
GSM to application OK PDU mode valid
Application to GSM AT+CMGS=14<CR>
0001030691214365000004C9E9340B Send complete MSG in
PDU mode, no SC address
GSM to application +CMGS: 4
OK MSG correctly sent, <mr>
is returned
The message <pdu> is composed of the SC address (« 00 means no SC
address given, use default SC address read with +CSCA command) and the
TPDU message.
The length of octets of the TPDU buffer is 14, coded as GSM 03.40
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 55
In this case the TPDU is : 0x01 0x03 0x06 0x91 0x21 0x43 0x65 0x00
0x00 0x04 0xC9 0xE9 0x34 0x0B, which means regarding GSM 03.40 :
<fo> : 0x01 (SMS-SUBMIT, no validity period)
<mr> (TP-MR): 0x03 (Message Reference)
<da> (TP-DA) : 0x06 0x91 0x21 0x43 0x65
(destination address +123456)
<pid> (TP-PID): 0x00 (Protocol Identifier)
<dcs> (TP-DCS): 0x00 (Data Coding Scheme : 7 bits alphabet)
<length> (TP-UDL): 0x04 (User Data Length, 4 characters of text)
TP-UD : 0xC9 0xE9 0x34 0x0B (User Data : ISSY)
TPDU in hexadecimal format must be converted into two ASCII
characters, e.g. octet with hexadecimal value 0x2A is presented to the mobile
as two characters ‘2’ (ASCII 50) and ‘A’ (ASCII 65).
9.5. Save Settings +CSAS
All settings specified in command +CSCA and +CSMP are stored in
EEPROM if the SIM card is a phase 1 card or in the SIM card if it is phase 2.
Application to GSM AT+CSAS Store +CSCA and +CSMP parameters
GSM to application OK Parameters are saved
9.6. Restore settings +CRES
All settings specified in command +CSCA and +CSMP are restored from
EEPROM if the SIM card is phase 1 or from the SIM card if it is a phase 2
SIM card.
Application to GSM AT+CRES Restore +CSCA and +CSMP parameters
GSM to application OK Parameters are restored
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 56
9.7. Show text mode parameters +CSDH
This commands gives more informations in text mode result codes.
These informations are in brackets in commands +CMTI, +CMT, +CDS,
+CMGR, +CMGL.
Application to GSM AT+CSDH? current value
GSM to application +CSDH: 0
OK do not show header values
9.8. New message indication +CNMI
This command selects the procedure how receiving the message from
the network.The application must send the following command :
Command syntax : AT+CNMI=<mode>,<mt>,<bm>,<ds>,<bfr>
<mode> : controls the processing of unsolicited result codes
Only <mode>=2 is supported.
Any other value for <mode> (0,1 or 3) is accepted (return code will be
OK), but the processing of unsollicited result codes will be the same than for
<mode>=2.
0Buffer unsolicited result codes in the TA. If TA result code buffer is full,
indications can be buffered in some other place or the oldest indications
may be discarded and replaced with the new received indications.
1Discard indication and reject new received message unsolicited result
codes when TA-TE link is reserved. Otherwise forward them directly to
the TE.
2Buffer unsolicited result codes in the TA when TA-TE link is reserved
and flush them to the TE after reservation. Otherwise forward them
directly to the TE
3Forward unsolicited result codes directly to the TE. TA-TE link specific
inband used to embed result codes and data when TA is in on-line data
mode.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 57
<mt> : sets the result code indication routing for SMS-DELIVERs. Default
is 0.
0No SMS-DELIVER indications are routed.
1SMS-DELIVERs are routed using unsolicited code :
+CMTI : « SM », <index>
2SMS-DELIVERs (except class 2 messages) are routed using unsollicited
code :
+CMT : [<alpha>,] <length> <CR> <LF> <pdu> (PDU mode)
or
+CMT : <oa>,[<alpha>,] <scts> [,<tooa>, <fo>, <pid>, <dcs>, <sca>,
<tosca>, <length>] <CR><LF><data> (text mode)
3Class 3 SMS-DELIVERS are routed directly using code in <mt>=2 ;
Message of other classes result in indication <mt>=1
<bm> : set the rules for storing received CBMs (Cell Broadcast Message)
types depend on its coding scheme, the setting of Select CBM Types
(+CSCB command) and <bm>. Default is 0.
0No CBM indications are routed to the TE. The CBMs are stored.
1The CBM is stored and an indication of the memory location is routed to
the customer application using unsolicited result code:
+CBMI: “BM”, <index>
2New CBMs are routed directly to the TE using unsolicited result code.
+CBM : <length><CR><LF><pdu> (PDU mode)
or
+CBM :<sn>,<mid>, <dcs>,<page>,<pages> (Text mode)
<CR><LF> <data>
3Class 3 CBMs : as <bm>=2.
Other classes CBMs : as <bm>=1.
<ds> for SMS-STATUS-REPORTs. Default is 0.
0No SMS-STATUS-REPORTs are routed.
1SMS-STATUS-REPORTs are routed using unsolicited code :
+CDS : <length> <CR> <LF> <pdu> (PDU mode)
or
+CDS : <fo>,<mr>, [<ra>] , [<tora>], <scts>,<dt>,<st> (Text mode)
<bfr> Default is 0.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 58
0TA buffer of unsolicited result codes defined within this command is
flushed to the TE when <mode> 1...3 is entered (OK response shall be
given before flushing the codes)
1TA buffer of unsolicited result codes defined within this command is
cleared when <mode> 1...3 is entered.
Application to GSM AT+CNMI=2,1,0,0,0 <mt>=1
GSM to application OK
GSM to application +CMTI : "SM", 1 Message received
Application to GSM AT+CNMI=2,2,0,0,0 <mt>=2
GSM to application OK
GSM to application +CMT :"123456","98/10/01,12 :30 :00+00",
129, 4, 32, 240, "15379", 129,5<CR><LF>
Received Message
Message received
Application to GSM AT+CNMI=2,0,0,1,0 <ds>=1
GSM to application OK
Application to GSM AT+CMGS="+33146290800"<CR>
Message to send <ctrl-Z> Send a message in
text mode
GSM to application +CMGS : 7
OK Successful
transmission
GSM to application +CDS : 2, 116, "+33146290800",145,
"98/10/01,12 :30 :07+04",
"98/10/01 12 :30 :08+04", 0
Message was
delivered correctly
9.9. Read message +CMGR
This command allows the application to read stored messages.
Command syntax : AT+CMGR=<index>
Response syntax for text mode:
+CMGR :<stat>,<oa>,[<alpha>,] <scts> [,<tooa>,<fo>,
<pid>,<dcs>,<sca>,<tosca>,<length>] <CR><LF> <data>
(for SMS-DELIVER only)
+CMGR :<stat>,<da>,[<alpha>,] [,<toda>,<fo>,<pid>,<dcs>, [<vp>],
<sca>, <tosca>,<length>]<CR><LF> <data>
(for SMS-SUBMIT only)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 59
Response syntax for PDU mode:
+CMGR: <stat>, [<alpha>] ,<length> <CR><LF> <pdu>
A message read with status "REC UNREAD" will be updated in memory
with the status "REC READ" because it has been read.
Example :
GSM to application +CMTI: "SM",1 New message received
Application to GSM AT+CMGR=1 read the message
GSM to application +CMGR: "REC UNREAD",
"0146290800","98/10/01,18 :22 :11+0
0" , <CR><LF>
ABCdefGHI
OK
Application to GSM AT+CMGR=1 read again the message
GSM to application +CMGR: "REC READ",
"0146290800","98/10/01,18 :22 :11+0
0", <CR><LF>
ABCdefGHI
OK
message is read now,
Application to GSM AT+CMGR=2 Read a bad index
GSM to application +CMS ERROR: 321 error : invalid index
Application to GSM AT+CMGF=0 ;+CMGR=1 in PDU mode
GSM to application +CMGR: 2,,<length> <CR><LF>
<pdu>
OK
Message is stored but
unsent,
no <alpha> field
9.10. List message +CMGL
This command allows the application to read stored messages, by
indicating the type of the message to read.
Command syntax : AT+CMGL=<stat>
Response syntax for text mode:
+CMGL : <index>,<stat>,<da/oa>[,<alpha>], [<scts>, <tooa/toda>,
<length>] <CR><LF><data> (for SMS-DELIVER and SMS-SUBMIT,
may be followed by other <CR><LF>+CMGL:<index>…)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 60
Response syntax for PDU mode:
+CMGL : <index>,<stat>, [<alpha>], <length> <CR><LF> <pdu>
(for SMS-DELIVER and SMS-SUBMIT,
may be followed by other <CR><LF>+CMGL:<index>…)
<stat> possible values (status of message in memory) :
PDU mode Text mode
0"REC UNREAD" ( received unread message )
1"REC READ" ( received read message )
2"STO UNSENT" ( stored unsent message )
3"STO SENT" ( stored sent message )
4"ALL" ( all messages )
Application to GSM AT+CMGL=”REC UNREAD” List unread messages in
text mode
GSM to application +CMGL: 1, "REC UNREAD",
"0146290800", <CR><LF>
Unread Message!
+CMGL: 3, "REC UNREAD",
"46290800", <CR><LF>
Another Unread Message!
OK
2 messages are unread,
these messages will then
have their status changed
to “REC READ”.
(+CSDH: 0)
Application to GSM AT+CMGL=”REC READ” List read messages in text
mode
GSM to application +CMGL: 2, "REC READ",
"0146290800", <CR><LF>
Keep cool
OK
Application to GSM AT+CMGL="STO SENT" read stored and sent
messages
GSM to application +CMS ERROR: 322 No message found
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 61
9.11. Send message +CMGS
Command syntax in text mode :
AT+CMGS= <da> [ ,<toda> ] <CR>
text is entered <ctrl-Z / ESC >
Command syntax in PDU mode :
AT+CMGS= <length> <CR>
PDU is entered <ctrl-Z / ESC >
The <address> field is the address of the terminal network to whom the
message is sent. To send the message, simply type <ctrl-Z> character
(ASCII 26). The text can contain all existing character except <ctrl-Z> and
<ESC> (ASCII 27).
This command is abortable using the <ESC> character when entering
text.
In PDU mode, only hexadecimal characters are used (‘0’...’9’,’A’...’F’).
Example of use :
Application to GSM AT+CMGS="+33146290800"<CR>
Please Call me soon, Fred.<ctrl-Z> Send a message in text
mode
GSM to application +CMGS : <mr>
OK Successful transmission
Application to GSM AT+CMGS=<length><CR>
<pdu><ctrl-Z> Send a message in PDU
mode
GSM to application +CMGS : <mr>
OK Successful transmission
The message reference <mr> which is returned back to the application is
allocated by the GSM module. This number begins with 0 and is incremented
by one for each outgoing message (successful and failure case) ; it is cyclic
on one byte (0 follows 255).
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 62
Note : this number is not a storage number - outgoing messages are not
stored.
9.12. Write Message to Memory +CMGW
This command stores a message to memory storage (either SMS-
SUBMIT or SMS-DELIVERS). The memory location <index> is returned (no
choice possible as with phonebooks +CPBW).
The entering of text or PDU is done similarly as specified in command
Send Message +CMGS.
Command syntax in text mode : (<index> is returned in both
cases)
AT+CMGW= <oa/da> [,<tooa/toda> [,<stat> ] ] <CR>
enter text <ctrl-Z / ESC>
Command syntax in PDU mode :
AT+CMGW= <length> [,<stat>] <CR>
give PDU <ctrl-Z / ESC>
Response syntax: +CMGW: <index>
or +CMS ERROR: <err> if writing fails
Parameter Definition :
<oa/da> : Originating or Destination Adress Value in string format.
<tooa/toda> : Type of Originating / Destination Adress.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 63
<stat> : Integer type in PDU mode (default 2 for +CMGW), or string type
in text mode (default "STO UNSENT" for +CMGW). It indicates the status of
message in memory. If <stat> is omitted , the stored message is considered
like a message to be send.
Defined <stat> values :
PDU mode Text mode
0"REC UNREAD"
1"REC READ"
2"STO UNSENT"
3"STO SENT"
<length> : The length of the actual data unit in octets
Example:
Application to GSM AT+CMGW="+33146290800"<CR>
Hello, how are you ?<ctrl-Z> Write a message in text
mode
GSM to application +CMGW : 4
OK Message stored in index 4
Application to GSM AT+CMGW=<length><CR>
<pdu><ctrl-Z> Write a message in PDU
mode
GSM to application +CMGW : <index>
OK Message stored in <index>
9.13. Send Message From Storage +CMSS
This command sends message with location value <index> from storage
to the network.
Command syntax: AT+CMSS=<index>[,<da> [,<toda>] ]
Response syntax: +CMSS : <mr>
or +CMS ERROR: <err> if sending fails
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 64
If new recipient address <da> is given, it will be used instead of the one
stored with the message.
Example of use in Text Mode:
Application to GSM AT+CMGW=0660123456<CR>
Today is my birthday<ctrl-Z> Write a message in text
mode
GSM to application +CMGW : 5
OK Message stored in index 5
Application to GSM AT+CMSS=5 Send the message 5
GSM to application +CMSS : <mr>
OK Successful Transmission
Application to GSM AT+CMSS=5, 0680654321 Send the message 5 to a
different GSM
GSM to application +CMSS : <mr>
OK Successful Transmission
9.14. Set Text Mode Parameters +CSMP
This command shall be used to select value for the <vp>, <pid>, the
<dcs>. The application must send the following command :
Command syntax : AT+CSMP=<fo>, <vp>, <pid>,<dcs>
<fo> byte is composed of 6 differents fields :
b7 b6 B5 b4 b3 b2 b1 b0
RP UDHI SRR VPF RD MTI
RP : Reply Path, not used in text mode.
UDHI : User Data Header Information, b6=1 if the beginning of the User
Data field contains a Header in addition to the short message. This option is
not supported in +CSMP command, but can be used in PDU mode (+CMGS).
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 65
SRR : Status Report Request, b5=1 if a status report is requested. This
mode is supported.
VPF : Validity Period Format
b4=0 & b3=0 -> <vp> field is not present
b4=1 & b3=0 -> <vp> field is present in relative format
Others formats (absolute & enhanced) are not supported.
RD : Reject Duplicates, b2=1 to instruct the SC to reject an SMS-
SUBMIT for an SM still held in the SC which has the same <mr> and the
same <da> as the previously submitted SM from the same <oa>.
MTI : Message Type Indicator
b1=0 & b0=0 -> SMS-DELIVER (in the direction SC to MS)
b1=0 & b0=1 -> SMS-SUBMIT (in the direction MS to SC)
In text mode <vp> is only coded in "relative" format. The default value is
167 (24 hours). This means that one octet can describe different values :
VP value Validity period value
0 to 143 (VP + 1) x 5 minutes (up to 12 hours)
144 to 167 12 hours + ( (VP - 143) x 30 minutes )
168 to 196 (VP - 166) x 1 day
197 to 255 (VP - 192) x 1 week
<pid> is used to indicate the higher layer protocol being used or
indicates interworking with a certain type of telematic device. For example,
0x22 is for group 3 telefax, 0x24 is for voice telephone, 0x25 is for ERMES.
<dcs> is used to determine the way the information is encoded. UCS2
alphabet and compressed text are not supported. Only GSM default alphabet
and 8 bit data are supported.
Application to GSM AT+CSMP? current values
GSM to application +CSMP: 0,0,0,0
OK no validity period
<dcs>= PCCP437 alphabet (8 bits -> 7
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 66
bits )
Application to GSM AT+CSMP=17,23,64,244 <vp> = 23 (2 hours, relative format)
<dcs> = GSM 8 bits alphabet
GSM to application OK command correct
9.15. Delete message +CMGD
This command shall be used after a read-command in order to delete the
any stored message.
For example :
GSM to application +CMTI: "SM",3 New message received
Application to GSM AT+CMGR=3 Read it
GSM to application +CMGR: "REC UNREAD",
"0146290800",,"98/10/01,18 :19 :20+0
0" <CR><LF>
Received Message!
OK
Unread message
received from 0146290800
on the 01/10/1998 at 18H
19m 20s
Application to GSM AT+CMGD=3 Delete it
GSM to application OK Message deleted
9.16. Service center address +CSCA
This command shall be used to indicate to which service center the
message has to be sent.
The GSM module has no default value for this address. If the application
tries to send a message without having indicated the service center address,
an error will be generated.
So, the application has to indicate this address at initialization. This
address is then valid all the time. The application may change it if needed.
Application to GSM AT+CMGS="+33146290800"<CR>
Hello, how are you ?<ctrl-Z> Send a message
GSM to Application +CMS ERROR : 330 Service center unknown
Application to GSM AT+CSCA="0696741234" Service center initialization
GSM to application OK
Application to GSM AT+CMGS="+33146290800"<CR> Send again the same
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 67
Happy Birthday !<ctrl-Z> message
GSM to application : +CMGS : 1
OK Successful transmission
9.17. Select Cell Broadcast Message Types +CSCB
Command syntax: AT+CSCB= <mode>, [ <mids>, [ <dcss> ] ]
Set command selects which types of CBMs are to be received by the
ME, This command is allowed in both PDU and text modes.
The <bm> parameter of +CNMI command controls the message
indication.
Test read command (AT+CSCB ?) is not supported.
The activation of CBM reception (<mode>=0) can select only specific
Message Identifiers (list in <mids>) for specific Languages (list in <dcss>), but
the deactivation stops any reception of CBMs (only AT+CSCB=1 is allowed)
Message Identifiers (<mids> parameter) indicates which type of
message identifiers the ME should listen to.
Supported languages (<dcss> parameter) are : 0 for German, 1 for
English, 2 for Italian, 3 for French, 4 for Spanish, 5 for Dutch, 6 for Swedish,
7 for Danish, 8 for Portugese, 9 for Finnish, 10 for Norwegian, 11 for Greek,
12 for Turkish, 13 for Hungarian, 14 for Polish and 32 for Czech.
Application to GSM AT+CSCB=0,"15-17,50,86", "" Accept SMS-CB types 15,16,17,50
and 86 in any language
GSM to Application OK CBMs can be received
Application to GSM +CBM : 10<CR><LF>
00112233445566778899 CBM length of a received Cell
Broadcast message (SMS-CB),
CBM bytes in PDU mode
GSM to application AT+CSCB=1 Deactivate the reception of CBMs
Application to GSM OK CBM reception is completely
stopped
9.18. Cell Broadcast Message Identifiers +WCBM
Command syntax : AT+WCBM= <mode> [, <mids>, <dcss> ]
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 68
This specific command is used to read the SIM file EF-CBMI.
This file is not used with +CSCB command, the application should read
this file (AT+WCBM ?) and combine the Message Identifiers with those
required for the application.
Application to GSM AT+WCBM="10,100,1000,100
00" Write 4 message identifiers in EF-
CBMI
GSM to Application OK CBMIs are stored if EF-CBMI
Application to GSM AT+WCBM ? Read the CBMIs in EF-CBMI
GSM to application +WCBM="10,100,1000,10000" 4 CBMIs are stored if EF-CBMI
9.19. Message status modification +WMSC
Command syntax : AT+WMSC= <loc>, <status>
<loc> location number of the stored message (integer)
<status> new status to be stored, as for +CMGL command
Possible responses:
OK if the location is valid
+CMS ERROR: 321 if <loc> is invalid or free
+CMS ERROR: 302 if the new <status> and the previous one are
incompatible (1)
Note 1 : The accepted status changes are from READ to NOT READ
and vice versa, and from SENT to NOT SENT and vice versa.
If all the parameters are correct, the module overwrites the whole SMS in
the SIM. Only the first byte (Status byte) is changed.
9.20. Message overwriting +WMGO
The +CMGW writes a SMS to the first free location. To write a SMS to a
specified location, the +WMGO specific command forces the module to write
a SMS (with +CMGW command) to the location specified with +WMGO, but
just for one +CMGW command.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 69
Command syntax : AT+WMGO= <loc>
<loc> location number of the SIM record to write or overwrite
Possible responses:
OK if <loc> is a valid SMS location, for AT+WMGO=? and
for AT+WMGO?
+CMS ERROR: 321 if <loc> is out of the SIM capacity range.
+WMGO: <loc> for AT+WMGO?
Then on the next AT+CMGW commnand, the used record number will
be that one specifed by AT+WMGO command. The location is then forgotten,
and to make a second overwrting, the +WMGO shall be used again.
If the external application specifies a free location, and if an incoming
message is received before the AT+CMGW command, the module may store
the incoming message in a free location, which could be unfortunately the
one specified by +WMGO (the module does not prevent this case). Then if
the user issues a AT+CMGW command, without changing the AT+WMGO
location, the new message will be overwritten !
Be aware that this location number is not kept over a software reset.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 70
10. Supplementary Services commands
10.1. Call forwarding +CCFC
This commands allows control of the call forwarding supplementary
service.
Command syntax:
AT+CCFC= <reason>, <mode> [, <number> [,<type> [,<class>
[,<subaddr> [, <satype> [,<time> ] ] ] ] ] ]
Response syntax:
+CCFC: <status>, <class1> [, <number>, <type> [,<subaddr>,
<satype> [,<time> ] ] ]
[ <CR><LF>+CCFC: <status>, <class2> [, <number>, <type>
[,<subaddr>, <satype> [,<time> ] ] ]
[ … ] ]
* <reason> :
0Unconditional
1Mobile busy
2No reply (<time> is used)
3Not reachable
4All call forwarding
5All conditionnal call forwarding
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 71
* <mode> :
0Disable
1Enable
2Interrogate
3Registration
4Erasure
* <class> :
1Voice
2Data
4Fax
8Short Messages
7All classes
The combination of different classes in not supported, it will only result in
the activation / deactivation / status request of all classes (7).
* <subaddr>, <satype> : not managed
* <time> : For Call Forwarding on No Reply, time to wait (1 to 30) in
seconds before call is forwarded, default value is 20 seconds.
Application to GSM AT+CCFC=0,3, "0146290800" register call forwarding unconditional
GSM to application OK Command valid
Application to GSM AT+CCFC=0,2 Interrogate call forwarding unconditional
GSM to application +CCFC:1,1, "0146290800" ,129
<CR><LF>+CCFC:1,2, "014629
0802",129
<CR><LF>+CCFC:1,4, "014629
0804" ,129
OK
call forwarding active for voice
call forwarding active for data
call forwarding active for fax
Application to GSM AT+CCFC=0,4 erase call forwarding unconditional
GSM to application OK Command valid
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 72
The +CCFC responses are not sorted depending of the <class>
parameter, it only depends of the order of the network response.
10.2. Call barring +CLCK
This commands allows control of the call barring supplementary service.
Locking, unlocking or querying the status of a call barring is possible for
all or a specific class.
Command Syntax:
AT+CLCK= <fac>, <mode> [, <password> [, <class> ] ]
Response Syntax:(for <mode>=2 and command successful)
+CLCK: <status> [, <class1>
[ <CR><LF>+CLCK: <status>, <class2>
[ … ] ]
* <fac> :
"AO", "OI", "OX" for outgoing calls barring
"AI", "IR" for incoming calls barring
"AG", "AC", "AB" for all calls barring (<mode>=0 only)
*<mode>
0unlocks the facility
1locks the facility
2query status
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 73
* <class> : see description for +CLCK command (Call Barring)
The combination of different classes in not supported, it will only result in
the activation / deactivation / status request of all classes (7).
Password code must be on 4 digits maximum.
Application to GSM AT+CLCK="AO",1,1234
GSM to application OK Command valid
Application to GSM AT+CLCK="AO",0,5555
GSM to application +CME ERROR: 16 Wrong password
Application to GSM AT+CLCK="AO",0,1234
GSM to application OK Command valid
10.3. Modify SS password +CPWD
This command shall be used by the application to change the
supplementary service password. The command to manage this functionality
is :
Command Syntax:
AT+CPWD=<fac>,<OldPassword>, <NewPassword>
for <fac> see +CLCK command with only “P2” facility added (SIM PIN2).
Application to GSM AT+CPWD="AO",1234,5555 change Call Barring
password
GSM to application OK password changed
Application to GSM AT+CPWD="AO",1234,5555 Change password
GSM to application +CME ERROR: 16 wrong password
Application to GSM AT+CPWD="AO",5555,1234 change password
GSM to application OK password changed
Whatever the facility, the change of password is performed for all calls barring.
10.4. Call waiting +CCWA
This command allows control of the call waiting supplementary service.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 74
The module will send an unsolicited result code +CCWA when call
waiting service is enabled.
Command Syntax:AT+CCWA=<n>, [ <mode> [, <class> ] ]
Response Syntax:(for <mode>=2 and command successful)
+CCWA: <status> [, <class1>
[ <CR><LF>+CCWA: <status>, <class2>
[ … ] ]
Unsolicited result: +CCWA: <number>, <type>, <class> [ ,<alpha>]
(when waiting service is enabled)
* <n> : result code presentation status in the TA
0Disable
1Enable
* <mode> :
0Disable
1Enable
2Query status
* <class> :
1Voice
2Data
4Fax
8Short Messages
7All classes
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 75
The combination of different classes is not supported, it will only result
in the activation / deactivation / status request of all classes (7).
* <alpha> : optionnal string type alphanumeric representation of
<number> corresponding to the entry found in the ADN or FDN phonebook.
Application to GSM AT+CCWA=1,1,1 Enable call waiting for speech
GSM to application OK Command valid
Application to GSM AT+CCWA=1,2 Interrogate call waiting
GSM to application +CCWA:1,1
OK Call waiting active for speech calls
Application to GSM +CCWA:"0146290800",145,1,
”FREDDY” Number and name of the waiting
voice call
Application to GSM AT+CCWA=1,0,7 erase call waiting for all classes
GSM to application OK command valid
Application to GSM +CCWA: ,,1 Waiting voice call without number
10.5. Calling line identification restriction +CLIR
This command allows control of the calling line identification restriction
supplementary service.
Command syntax: AT+CLIR=<n>
Response syntax: +CLIR:<n>,<m> (for AT+CLIR?)
• <n> : parameter sets the adjustment for outgoing calls
0Presentation indicator is used according to the
subscription of the CLIR service
1CLIR invocation
2CLIR suppression
* <m> : parameter shows the subscriber CLIR status in the network
0CLIR not provisioned
1CLIR provisioned in permanent mode
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 76
2Unknown (no network...)
3CLIR temporary mode presentation restricted
4CLIR temporary mode presentation allowed
Application to GSM AT+CLIR=2
GSM to application OK command valid
Application to GSM AT+CLIR? Ask for current functionality
GSM to application +CLIR: <n>,<y>
OK <n> and <m> defined as above
10.6. Calling line identification presentation +CLIP
This command allows control of the calling line identification presentation
supplementary service. When the presentation of the CLI (Calling Line
Identification) is enabled (and calling subcriber allows), +CLIP response is
returned after every RING (or +CRING) result code.
Command syntax:
AT+CLIP=<n>
Response syntax:
+CLIP: <n>,<m> for AT+CLIP?
+CLIP: <number>, <type>[ ,<subaddr>, <satype>, <alpha> ]
for an incoming call, after each RING or +CRING indication
* <n> : parameter sets/shows the result code presentation in the TA
0Disable
1Enable
• <m> : parameter shows the subscriber CLIP service status in the
network
0CLIP not provisioned
1CLIP provisioned
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 77
2Unknown (no network...)
Application to GSM AT+CLIP=1 Enable CLIP
GSM to application OK CLIP is enabled
Application to GSM AT+CLIP? Ask for current functionality
GSM to application +CLIP: <n>,<m>
OK <n> and <m> defined as above
GSM to application RING
+CLIP:
"0146290800",129,1,,,
“FRED”
Incoming call
Incoming call with number and
name presentation
Application to GSM AT+CLIP=0 Disable CLIP presentation
GSM to application OK Command valid
10.7. Connected line identification presentation +COLP
This command allows control of the connected line identification
presentation supplementary service, useful in case of call forwarding of the
connected line.
Command syntax:
AT+COLP=<n>
Response syntax:
+COLP: <n>,<m> for AT+COLP?
+COLP: <number>,<type> [ ,<subaddr>, <satype>, <alpha> ]
after ATD command, before OK or CONNECT <speed>
<n> : parameter sets/shows the result code presentation status in the TA
0Disable
1Enable
<m> : parameter shows the subscriber COLP service status in the
network
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 78
0COLP not provisioned
1COLP provisioned
2Unknown (no network...)
Application to GSM AT+COLP=1 Activate COLP
GSM to application OK Command valid
Application to GSM AT+COLP? Ask for current functionality
GSM to application +COLP: 1,1
OK COLP is enabled and provisioned
Application to GSM ATD146290800; Outgoing call
GSM to application +COLP:
"0146290928",129,,,”JOE”
OK
Connected outgoing line number and
name presentation
Application to GSM AT+COLP=0 desactivate COLP
GSM to application OK command valid
10.8. Advice of charge +CAOC
Command syntax: AT+CAOC= <mode>
This refers to Advice of Charge supplementary service (GSM 02.24 []
and GSM 02.86 []) that enables subscriber to get information about the cost
of calls. With <mode>=0, the execute command returns the current call meter
value (CCM) from the ME.
If AOC is supported, the command also includes the possibility to enable
an unsolicited event reporting of the CCM information.
The unsolicited result code +CCCM: <ccm> is sent when the CCM value
changes. Deactivation of the unsolicited event reporting is made with the
same command.
If AOC is supported, the Read command indicates whether the
unsolicited reporting is activated or not.
Defined values
<mode>:
0query CCM value
1deactivate the unsolicited reporting of CCM value
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 79
2activate the unsolicited reporting of CCM value
<ccm>:
string type; three bytes of the current call meter value in hexadecimal
format
(e.g. "00001E" indicates decimal value 30); value is in home units and
bytes are similarly coded as ACMmax value in the SIM
Application to GSM AT+CAOC=0 Query CCM value
GSM to application +CAOC : "000A08"
OK Display Current Call Meter
value (CCM = 2568)
Application to GSM AT+CAOC=1 Deactivate unsolicited
report of CCM value
GSM to application OK CCM report deactivated
Application to GSM AT+CAOC=2 Activate unsolicited report
of CCM value
GSM to application OK CCM report activated
Application to GSM AT+CAOC ? Request mode
GSM to application +CAOC : <mode>
OK Display unsolicited report
mode (1 or 2)
Application to GSM AT+CAOC= ? Request supported modes
GSM to application +CAOC : (0-2)
OK 0,1,2 modes supported
10.9. Accumulated call meter +CACM
Set command resets the Advice of Charge related accumulated call
meter value in SIM file EFACM. ACM contains the total number of home units
for both the current and preceding calls. SIM PIN2 is required to reset the
value. If setting fails in an ME error, +CME ERROR: <err> is returned.
Read command returns the current value of ACM.
Then ACM value (entered or displayed) is in hexadecimal format with 6
digits.
Application to GSM AT+CACM ? Request ACM value
GSM to application +CACM : "000400" Display ACM value
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 80
OK (ACM = 1024)
Application to GSM AT+CACM= 1234 Request ACM reset, real
PIN2 is "1234"
GSM to application OK ACM value is reset
Application to GSM AT+CACM= 0000 Request ACM reset with
wrong PIN2 value
GSM to application +CME ERROR : 17 SIM PIN2 required
Application to GSM AT+CACM ? Request ACM value
GSM to application +CACM : "000000"
OK Display ACM value
(ACM = 0)
10.10. Accumulated call meter maximum +CAMM
Set command sets the Advice of Charge related accumulated call meter
maximum value in SIM file EFACMmax. ACMmax contains the maximum number
of home units allowed to be consumed by the subscriber. When ACM (refer
+CACM) reaches ACMmax, then calls are prohibited. SIM PIN2 is required to
set the value. If setting fails in an ME error, +CME ERROR: <err> is
returned.
Read command returns the current value of ACMmax.
Them ACMmax value (entered or displayed) is in hexadecimal format
with 6 digits.
Application to GSM AT+CAMM= "000400", 1234 Request ACMmax update,
real PIN2 is "1234"
GSM to application OK ACMmax updated to 1024
Application to GSM AT+CAMM= "000400",0000 Request ACMmax update,
real PIN2 is "1234"
GSM to application +CME ERROR : 17 SIM PIN2 required
Application to GSM AT+CAMM ? Request ACMmax value
GSM to application +CAMM : "000400"
OK ACMmax=1024
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 81
10.11. Price per unit and currency table +CPUC
Description
Set command sets the parameters of Advice of Charge related price per
unit and currency table in SIM file EFPUCT. PUCT information can be used to
convert the home units (as used in +CAOC, +CACM and +CAMM) into currency
units. SIM PIN2 is required to set the parameters. If setting fails in an ME
error, +CME ERROR: <err> is returned.
Application to GSM AT+CPUC= "FFR", "0.82", 1234 Request Currency and
Price per unit update
GSM to application OK
Application to GSM AT+CPUC= "FFR", "0.82", 1111 Request Currency and
PPU update (wrong PIN2)
GSM to application +CME ERROR : 17 SIM PIN2 required
Application to GSM AT+CPUC? Request Currency & Price
GSM to application +CPUC: "FFR", "0.82"
OK Currency= "FFR"
Price per unit= "0.82"
10.12. Call related supplementary services +CHLD
This command is used to manage call hold and multiparty conversation
(conference call).
Calls can be put on hold, recovered, released or added to conversation.
Command syntax: AT+CHLD= < n >
Response syntax: +CHLD: (0-3, 11-17, 21-27) for AT+CHLD=?
<n> 0Release all held calls or set User Determined User Busy
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 82
(UDUB) for a waiting call.
1Release all active calls (if any exist) and accepts the other
(held or waiting) call.
1X Release a specific call X (active, held or waiting)
2 Place all active calls (if any exist) on hold and accepts the
other
(held or waiting) call.
2X Place all active calls on hold except call X with
which communication is supported.
3 Adds a held call to the conversation
10.13. List current calls +CLCC
This command is used to return the list of current calls.
Command syntax:
AT+CLCC
Response syntax:
OK if no calls are available
+CLCC: <id1>, <dir>, <stat>, <mode>, <mpty>
[ ,<number>, <type> [ <alpha> ] ]
[ <CR><LF> +CLCC: <id2>, <dir>, <stat>, <mode>, <mpty>
[ ,<number>, <type> [ <alpha> ] ]
[. . . ] ] ]
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 83
<idx>: integer type, call identification as described in GSM 02.30
<dir>:
0mobile originated (MO) call
1mobile terminated (MT) call
<stat> (state of the call):
0active
1held
2dialing (MO call)
3alerting (MO call)
4incoming (MT call)
5waiting (MT call)
<mode> (teleservice):
0voice
1data
2fax
9unknown
<mpty>:
0call is not one of multiparty (conference) call parties
1call is one of multiparty (conference) call parties
<number>: string type phone number in format specified by <type>
<type>: type of address octet in integer format
<alpha>: optional string type alphanumeric representation of <number>
corresponding to the entry found in phonebook.
10.14. Supplementary service notifications +CSSN
Command syntax: AT+CSSN= <n>, <m>
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 84
This command refers to supplementary service related network initiated
notifications.
When <n>=1 and a supplementary service notification is received after a
mobile originated call setup, intermediate result code +CSSI:<code1> is sent
before any other MO call setup result codes.
When <m>=1 and a supplementary service notification is received during
a call, unsolicited result code +CSSU:<code2> is sent.
Command syntax:
AT+CSSN= <n>, <m>
Response syntax:
+CSSN: <n>, <m> for AT+CSSN?
+CSSN: (0-1), (0-1) for AT+CSSN=?
Defined values
<n> (parameter sets/shows the +CSSI result code presentation status):
0disable
1enable
<m> (parameter sets/shows the +CSSU result code presentation status):
0disable
1enable
<code1>
5 outgoing calls are barred
6 incoming calls are barred
7 CLIR suppresssion rejected
<code2>
2call has been put on hold (during a voice call)
3call has been retrieved (during a voice call)
4multiparty call entered (during a voice call)
5call on hold has been released (during a voice call)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 85
10.15. Unstructured supplementary service data +CUSD
The USSD supplementary service is described by the GSM 02.90.
It is based on digit sequences which may be entered by mobile user with
an handset. An entered sequence is sent to the network which answers back
with a alphanumerical string, only for display, or to display and to ask for a
next sequence.
This command is used for :
-enabling or disabling the CUSD indication sent to the
application by the module when a incomming USSD is
received
-send and receive USSD strings.
For the first behavior, the syntax is :
Command syntax:
AT+CUSD = <n> [ ,<str> [ <dcs> ] ]
<n>
0 : Disable the result code presentation
1 : Enable the result code presentation
2 : Cancel session (not applicable to read command response)
In case of presentation enabled, a +CUSD (as direct answer to a send
USSD) is then indicated with :
+CUSD: <m> [,<str>,<dcs> ]
- <m> :
0no further user action required (network initiated
USSD-Notify, or no further information needed after mobile
initiated operation)
1further user action required (network initiated
USSD-Request, or further information needed after mobile
initiated operation)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 86
2 USSD terminated by network
4Operation not supported
- <str> is network string, converted in the selected character set
(HEX mode is not supported).
-<dcs> is the data coding sheme received (GSM TS 03.38).
To send and receive USSD
Command syntax: AT+CUSD= <n> [,<str> [,<dcs>]]
Note : Please, be aware that the send command asks the user to re-
enter the enable/disable (<n>) parameter !
<str> is the USSD string to be sent.
<dcs> : only the default alphabet value is supported (which is the
default value when the parameter is absent).
When the module sends an USSD, an OK response is first returned. The
intermediate +CUSD indication comes after. In case of error, a +CUSD: 4
indication is returned back.
10.16. Closed user group +CCUG
The Closed User Group Supplementary Service enables subscribers to
form closed user groups to and from which access is restricted.
The CUG supplementary service is described by the GSM 02.85. This
service shall be provided after prior arrangement with the service provider. At
provision subscription options should be selected.
+CCUG command is used for :
- activating/deactivating the control of the CUG information for all
following outgoing calls.
- selecting a CUG index,
- suppressing the outgoing access (OA). The OA allows a member of
a CUG to place calls outside the CUG.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 87
- suppressing the preferential CUG. The preferential is the default
CUG used by the network when it does not receive explicit CUG
index.
Command syntax:
AT+CCUG = <n> [ ,<index> [ <info> ] ]
<n>
0 : Disable CUG mode (default)
1 : Enable CUG mode
<index>
0-9: CUG index (0 default),
10: preferred CUG
<info>
0: no information (default)
1: suppress OA
2: suppress preferential CUG
3: suppress OA and preferential CUG
For activating the control of the CUG information by call, add [G] or [g] to
the ATD command. Index and info values will be used.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 88
11. Data commands
11.1. Bearer type selection +CBST
Command syntax: AT+CBST= <speed>, <name>, <ce>
No data compression is provided and only asynchronous modem is
supported (<name> = 0).
<speed> Description Modem type
0 (default) Autobauding None
1300 bps V.21
21200 bps V.22
31200/75 bps V.23
4 2400 bps V.22bis
5 2400 bps V.26ter
6 4800 bps V.32
7 9600 bps V.32
8Specific
65 300 bps V.110
66 1200 bps V.110
68 2400 bps V.110
70 4800 bps V.110
71 9600 bps V.110
<ce> Connection element
0Transparent only
1(default) Non transparent only
2Transparent preferred
3Non transparent preferred
Application to GSM AT+CBST=7,0,1 ask for a bearer
GSM to application OK bearer supported
Application to GSM AT+CBST=81,0,0 ask for a bearer
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 89
GSM to application +CME ERROR : 3 bearer not supported
This command applies to both outgoing and incoming data calls but in
a different way. For outgoing call the two parameters (e.g. <speed> and
<ce>) apply, whereas for incoming call only the <ce> parameter applies.
Note 1) as far as incoming calls are concerned, if <ce> is set to T only
and the network proposes NT only or vice versa then the call is released.
Note 2) older values 100 and 101 for <ce> are retained for compatibility
purpose but shallnot be used anymore, values 2 and 3 shall be used instead.
11.2. Select mode +FCLASS
This command puts the module into a particular mode of operation (data
or fax).
Command syntax: AT+FCLASS= <n>
<n> Description
0 Data
1Fax class 1
Application to GSM AT+FCLASS=? Test command
GSM to application +FCLASS: (0,1)
OK Done
Application to GSM AT+FCLASS=0 Data mode asked
GSM to application OK Command valid
Application to GSM AT+FCLASS=1 Fax class 1 mode asked
GSM to application OK Command valid
Application to GSM AT+FCLASS? Current value
GSM to application +FCLASS: 1
OK Command valid
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 90
11.3. Service reporting control +CR
This command enables a more detailed service reporting, in case of data
incoming or outgoing call. Before sending the CONNECT response to the
application, the GSM module will precise the type of data connection that
have been established.
These report types are :
+CR: ASYNC For asynchronous transparent
+CR: REL ASYNC For asynchronous non-transparent
Application to GSM AT+CR=0 Extended reports disabled
GSM to application OK Command valid
Application to GSM AT+CR=1 Extended reports enabled
GSM to application OK Command valid
11.4. Cellular result codes +CRC
This command enables a more detailed ring indication, in case of
incoming call (voice or data). Instead of the string "RING", an extended
string is used to indicate which type of call is ringing (e.g. +CRING: VOICE).
These extended indications are :
+CRING: ASYNC for asynchronous transparent
+CRING: REL ASYNC for asynchronous non-transparent
+CRING: VOICE for normal speech.
+CRING : FAX for fax calls
Application to GSM AT+CRC=0 Extended reports disabled
GSM to application OK Command valid
Application to GSM AT+CRC=1 Extended reports enabled
GSM to application OK Command valid
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 91
11.5. DTE-DCE local rate reporting ++ILRR
This parameter controls whether or not the extended-format
"+ILRR:<rate>" information text is transmitted from the DCE to the DTE. The
<rate> reported shall represent the current (negotiated or renegotiated) DTE-
DCE rate.
If enabled, the intermediate result code is transmitted in a data incoming
or outgoing call, after any data compression report, and before any final
result code (CONNECT).
<rate> can take the following values: 300, 600, 1200, 2400, 4800, 9600,
19200, 38400, 57600, 115200.
Application to GSM AT+ILRR=0 Local port rate report disabled
GSM to application OK Command valid
Application to GSM AT+ILRR=1 Local port rate report enabled
GSM to application OK Command valid
11.6. Radio link protocol parameters +CRLP
This command allows to change the radio link protocol parameters used
for non transparent data transmission.
Command syntax:
AT+CRLP=<iws>,<mws>,<T1>,<N2>, <ver>
This command accepts 5 parameters.
<iws>: (0-61) Down window size, (default is 61),
<mws>: (0-61) Up window size, (default is 61),
<T1> : (40-255) Acknowledgement timer in units of 10ms, (default is
48),
<N2>: (1-255) Retransmission attempts, (default is 6),
<ver>: (0) Version number. Only 0 is supported.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 92
Application to GSM AT+CRLP=? Test command
GSM to application +CRLP: (0-61),(0-61),(40-255),(1,255),(0)
OK Done.
Application to GSM AT+CRLP=61,61,48,6,0 Set new parameters
GSM to application OK Command valid
Application to GSM AT+CRLP? Current values
GSM to application AT+CRLP: 61,61,48,6,0
OK Command valid
11.7. Others radio link parameters +DOPT
This Wavecom specific command allows to change some supplementary
radio link protocol parameters
Command syntax: AT+DOPT=<reset_allowed>,<dtx_allowed>
<reset_allowed> Description
0 Data communication is hung up in case of bad
radio link.
1 (default) Data communication goes on in case of bad radio
link (possible loose of data)
The second parameter is reserved for future use.
Application to GSM AT+DOPT=? Test command
GSM to application (0,1),(0)
OK
Application to GSM AT+DOPT=1 Set new parameters
GSM to application OK Command valid
Application to GSM AT+DOPT? Current values
GSM to application 1,0
OK Command valid
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 93
12. Fax commands
The fax service provided by the module is class 1 compatible. However
only the core commands defined by ITU T.31 are supported. It means that
commands like AT+FAR, +FCC,... are not supported.
Autobauding has to be enabled to set up the module for fax.
All set commands below return an ERROR response code if they are
not issued during the communication.
12.1. Transmit speed +FTM
This command sets the fax transmit speed.
Command syntax: AT+FTM=<speed>
<speed> Description Modem type
24 2400 bps V.27ter
48 4800 bps V.27ter
72 7200 bps V.29
96 9600 bps V.29
Application to GSM AT+FTM=? Test command
GSM to application (24,48,72,96)
OK Done
12.2. Receive speed +FRM
This command sets the fax receive speed.
Command syntax: AT+FRM=<speed>
The speeds are the same as these of +FTM command.
Application to GSM AT+FRM=? Test command
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 94
GSM to application (24,48,72,96)
OK Done
12.3. HDLC transmit speed +FTH
This command sets the fax transmit speed, using the HDLC protocol.
Command syntax: AT+FTH=<speed>
<speed> can only take 3 value which corresponds to V.21 channels 300
bps.
Application to GSM AT+FTH=? Test command
GSM to application (3)
OK
12.4. HDLC receive speed +FRH
This command sets the fax receive speed, using the HDLC protocol.
Command syntax: AT+FRH=<speed>
<speed> can only take 3 value which corresponds to V.21 channels 300
bps.
Application to GSM AT+FRH=? Test command
GSM to application (3)
OK
12.5. Stop transmission and wait +FTS
This command stops the transmission for the specified period.
Command syntax: AT+FTS=<n>
<n>: silence period (units of 10 ms).
Application to GSM AT+FTS=? Test command
GSM to application (0-255)
OK
Application to GSM AT+FTS=50 Stops transmission and waits
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 95
0.5 s
GSM to application OK Command valid
12.6. Receive silence +FRS
This command causes the modem to report back to the DTE after the
specified period.
It is aborted if any character is received.
Command syntax: AT+FRS=<n>
<n>is in units of 10 ms.
Application to GSM AT+FRS=? Test command
GSM to application (0-255)
OK
Application to GSM AT+FRS=50 Waits for 0.5 s silence
GSM to application OK Command valid
12.7. Setting up the PC fax application:
The recommended fax application is Delrina WinFax v8.0.
It should be configured as follows (menu Setup/Fax Modem Setup) :
♦ Port: any com
♦ Model: Generic Class 1 (hardware flow control). A generic class 1
with software flow control can be also selected.
♦ Init: default string is suitable for the module
♦ Reset: default string is suitable for the module
♦ Maximum Transmit Rate: 9600 baud (if higher then rate will be
automatically cut back to 9600 baud).
Others settings are of no relevance for the GSM unit: they can be
modified.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 96
13. V24-V25 commands
13.1. Fixed DTE rate +IPR
This commands specifies the data rate at which the DCE will accept
commands.
Application to GSM AT+IPR?
GSM to application +IPR: 9600
OK current rate is 9600 bps
Application to GSM AT+IPR=?
GSM to application +IPR:(0,2400, 4800, 9600, 19200) ,
(300,600,1200,38400,57600,115200)
OK
possible values (1)
Application to GSM AT+IPR=38400
GSM to application OK disable autobauding and set
rate to 38400 bps
Application to GSM AT+IPR=0
GSM to application OK enable autobauding
Note (1) : first set of values indicates the range of autodetectable
speeds. The second set of values indicates all the possible speeds which can
be used by DCE.
An autobauding is provided which operates from 2400 to 19200 baud.
However some constraints have to be dealt with :
• any AT command issued by DTE must start with a capital ‘A’ and ‘T’
(or ‘\’). If not, DCE may send back some garbagge characters and get
de-synchronized. Shoud it happen, DTE shall just issue once or twice
‘AT\r’ (at 2400 or 4800 baud) or just ‘AT’ (at 9600 baud) to get the
modem re-synchronized.
• the DTE shall wait for 1ms after receipt of the last character of the AT
response (which is always ‘\n’ or 0x0A) to send a new AT command at
either the same rate or a new rate. Shoud this delay ignored, DCE
can get de-synchronised. Once again, sending once or twice ‘AT\r’ or
just ‘AT’ causes the DCE to recover.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 97
Be careful : at start-up if autobauding is enabled and no AT command
has been received yet, the module sends all unsolicited responses (like
RING) at 9600 baud.
13.2. DTE-DCE character framing +ICF
This command is used to determine the local serial port start-stop
(asynchronous) character framing that the DCE shall use.
Command syntax: AT+ICF= <format>, <parity>
* <format> :
0Autodetect not supported
18 Data 2 Stop supported
28 Data 1 Parity 1 Stop supported
38 Data 1 Stop supported
47 Data 2 Stop supported
57 Data 1 Parity 1 Stop supported
67 Data 1 Stop supported
* <parity> :
0Odd supported
1Even supported
2Mark supported
3Space supported
4None supported
Note 1) setting a character framing different from 8N1 will disable
autobauding (in the case it was activated). However setting it back to 8N1 will
not re-enable autobaud.
Note 2) setting the framing to 8N1 will let the autobauding enabled, if it
was already enabled (implying framing was already 8N1).
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 98
Application to GSM AT+ICF?
GSM to application +ICF: 3,4
OK current values
Application to GSM AT+ICF=?
GSM to application +ICF: (1-6),(0-4)
OK possible values.
Application to GSM AT+ICF=0,0
GSM to application OK new values
13.3. DTE-DCE local flow control +IFC
This command is used to control the operation of local flow control
between the DTE and DCE.
AT+IFC=<DCE_by_DTE>,<DTE_by_DCE>
* < DCE_by_DTE > :
0 none Supported
1Xon/Xoff local circuit 103 not supported
2RTS Supported
3Xon/Xoff global on circuit 103 not supported
Important note : when this parameter is set to 2 (DTE invokes flow
control through RTS) the behavior of the DCE is the following :
If the DCE has never detected RTS in high (or ON) condition since
startup then it ignores RTS, assuming this signal is not connected.
As soon as DCE detects RTS high, then this signal acts upon it.
Therefore subsequent RTS transition to OFF will prevent DCE from sending
any further data in online and in offline as well.
This behavior allows the user to use the default settings (hardware flow
control) and let RTS disconnected. In the case RTS is connected and is high
at least once then it acts upon DCE.
* < DTE_by_DCE > :
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 99
0 none Supported
1Xon/Xoff circuit 104 not supported
2CTS Supported
When this parameter is set to 0 (none) then CTS is kept high all the time.
Application to GSM AT+IFC?
GSM to application +IFC: 2,2
OK current values
Application to GSM AT+IFC=?
GSM to application +IFC: (0,2),(0,2)
OK possible values.
Application to GSM AT+IFC=0,0
GSM to application OK new values
13.4. Set DCD signal &C
This commands controls the Data Carrier Detect (DCD) signal.
Application to GSM AT&C0 DCD always on
GSM to application OK command valid
Application to GSM AT&C1 DCD matches state of the
remote modem's data carrier
GSM to application OK command valid
13.5. Set DTR signal &D
This commands controls the Data Terminal Ready (DTR) signal.
Application to GSM AT&D0 the DTR signal is ignored
GSM to application OK command valid
Application to GSM AT&D1 Modem switches from data to command mode
when DTR switches from ON to OFF
GSM to application OK command valid
Application to GSM AT&D2 Upon DTR switch from ON to OFF, the call is
cleardown
GSM to application OK command valid
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 100
13.6. Set DSR signal &S
This commands controls the Data Set Ready (DSR) signal.
Application to GSM AT&S0 DSR always on
GSM to application OK command valid
Application to GSM AT&S1 DSR off in command mode, DSR on in data
mode
GSM to application OK command valid
13.7. Back to online mode O
If you have established a connection and the mobile is in online
command mode, this command allows to return to online data mode.
Application to GSM ATO
GSM to application OK Command valid
13.8. Result code suppression Q
Determines whether the mobile sends result codes or not
Application to GSM ATQ0 DCE transmits result codes
GSM to application OK Command valid
Application to GSM ATQ1 Result codes are suppressed and not transmitted
GSM to application (none) no response
13.9. DCE response format V
Determines the DCE response format, with or without header characters
<CR><LF>, and with the use of numeric result codes.
V0 V1
Information
responses <text><CR><LF> <CR><LF>
<text><CR><LF>
Result codes <numeric code><CR> <CR><LF>
<verbose code><CR><LF>
Application to GSM ATV0 DCE transmits limited headers and trailers and
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 101
numeric result codes
GSM to application 0command is valid (0 means OK)
Application to GSM ATV1 DCE transmits full headers and trailers and
verbose response text
GSM to application OK command is valid
13.10. Default configuration Z
Restores the configuration profile. Any call is released.
Application to GSM ATZ
GSM to application OK Command valid
13.11. Save configuration &W
This commands writes the active configuration to a non-volatile memory
(EEPROM). Description of the stored parameters is in appendice 16.10
Application to GSM AT&W Writes current configuration to EEPROM
GSM to application OK command valid
13.12. Auto-tests &T
AT&T0 is used to perform auto-tests. The response will be OK if no
software problem is detected (EEPROM, RAM and ROM checksums),
otherwise a simple ERROR response is sent.
AT&T1 is used to close the audio loop, and AT&T2 is used to open the
audio loop. This is used to validate the audio loop (microphone to speaker).
Application to GSM AT&T0 Perform software auto-tests
GSM to application OK No software problem detected, all checksums
are correct
Application to GSM AT&T1 Do the audio loop test (close)
GSM to application OK command valid
Application to GSM AT&T2 Stop the audio loop test (open)
GSM to application OK command valid
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 102
13.13. Echo E
This command is used to determines whether or not the modem echoes
characters received by an external application (DTE).
Application to GSM ATE0 Characters are not echoed
GSM to application OK Done
Application to GSM ATE1 Characters are echoed
GSM to application OK Done
13.14. Restore factory settings &F
This command is used to restore the factory settings from EEPROM.
The settings which are restored are listed in appendice 16.10.
Application to GSM AT&F Ask for restoring the factory settings
GSM to application OK Done
Application to GSM AT&F0 Ask for restoring the factory settings
GSM to application OK Done
13.15. Display configuration &V
This command is used to display modem configuration
&V0 : Display the modem configuration in RAM.
&V1 : Display the modem configuration in EEPROM.
&V2 : Display the factory modem configuration.
The parameters which are displayed are the following:
Q, V, S0, S2, S3, S4, S5, +CR, +CRC, +CMEE, +CBST,
+SPEAKER,+ECHO
Application to GSM AT&V0 RAM modem parameters
GSM to application Q:0 V:1 S0:000 S2:043 S3:013 S4:010 S5:008
+CR:0 +CRC:0 +CMEE:0 +CBST:0,0,1
+SPEAKER:0 +ECHO:0
Done
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 103
OK
13.16. Request identification information I
This command causes the GSM module to transmit one or more lines of
specific information text.
I0 : Display the manufacturer followed by model identifications.
This command is equivalent to +CGMI and +CGMM.
I3 : Display the revision identification (equivalent to +CGMR).
I4 : Display the modem configuration in RAM (equivalent to &V0).
I5 : Display the modem configuration in EEPROM (equivalent to
&V1).
I6 : Display the modem data features. This command enumerates
the supported data rates, data modes, and fax classes.
I7 : Display the modem voice features.
If the value is different, an “OK” string will be sent back.
Application to GSM ATI0 Manufacturer and model
identifications
GSM to application WAVECOM MODEM
900P
OK
GSM 900 MHz
primary band
Application to GSM ATI3 Revision identification
GSM to application 310_G250.51 806216 032199 17:04
OK Software release 3.10
,révision 51 generated on
the 21st of March 1999
Application to GSM ATI6 Modem data features
GSM to application DATA RATES:
AUTOBAUD,300,1200,1200/75,2400,4800,9600
DATA MODES: T/NT,ASYNCHRONOUS
FAX CLASS 1
OK
Done
Application to GSM ATI7 Modem voice features
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 104
GSM to application SPEECH CODINGS: FR,EFR
OK Done
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 105
14. Specific AT commands
14.1. Cell environment description +CCED
This command can be used by the application to retrieve the cell
parameters of the main cell and of up to six neighbour cells.
Two ways may exist for the external application to know these cell
parameters : on request of the application, or automatically by the module
every 5 seconds.
The automatic mode is not supported during communication or
registration.
The command to manage this functionality is :
Command syntax: AT+CCED=<mode>[, <requested
dump>]
* <mode> :
0One shot requested
1Automatic shots requested
2Stop automatic shots
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 106
* <requested dump> :
1Main Cell :
if the Cell Identity is available
MCC, MNC, LAC, CI, BSIC, BCCH Freq (absolute), RxLev,
RxLev Full, RxLev Sub, RxQual, RxQual Full, RxQual
Sub,Idle TS
if the Cell Identity is not available
MCC, MNC, LAC,, BSIC, BCCH Freq (absolute), RxLev,
RxLev Full, RxLev Sub, RxQual, RxQual Full, RxQual
Sub,Idle TS
2Neighbour1 to Neighbour6 :
if the Cell Identity is available
MCC, MNC, LAC, CI, BSIC, BCCH Freq (absolute), RxLev
if the Cell Identity is not available
MCC, MNC, LAC,, BSIC, BCCH Freq (absolute), RxLev
4Timing Advance
Combination (addition of the values) of the requested dumped are
supported.
Notice that in idle mode, only RxLev measures (one the main cell and on
the neighbour cells) are done. The value of these RxLev is set in the RxLev
Full field for the main cell.
The response will be :
+CCED :<value>, ... , <value>
OK
Where <value> is the ASCII string of the values (in decimal except LAC
and CI values are in hexadecimal) of the parameters. If a field can not be
measured - or has no sense - the parameter is not filled (two consecutive
commas are then found).
If the <requested dump> parameter is absent, this of the last +CCED
command (or 15 by default) will be taken.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 107
Values of MCC/MNC are set to 0 in case of “No service”
14.2. Automatic RxLev indication +CCED
The CCED command has been extended to indicate the the received
signal strength indication (rssi) of the main cell. The principle of the command
is not changed :
Command Syntax: AT+CCED=<mode>[, <requested
dump>]
* <mode> :
0One shot requested
1Automatic shots requested
2Stop automatic shots
* <requested dump> :
8Main cell RSSI indications (RxLev) from 0 to 31
The response will be a +CSQ answer and not a +CCED answer. The
07.07 format for the +CSQ is respected. The <ber> is not evaluated by this
command, so the <ber> value will always be 99.
+CSQ :<rssi>, 99
OK
This +CSQ answer, when automatic shots are selected, is sent every
time the <rssi> measured by the module changes. This automatic shots are
supported in idle mode and during communication.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 108
Combination (addition of the values) of the requested dumped (1,2,4,8)
are supported. Both answer +CCED and +CSQ may be then generated.
If the <requested dump> parameter is absent, this of the last +CCED
command (or 15 by default) will be taken.
14.3. General Indications +WIND
Wavecom introduced a general mechanism to send unsollicited non
standardized indication to the customer application. The yet identified
unsollicited non standardized indications are :
- indication of a physical change on the SIM presence pin from
connector (meaning SIM inserted, SIM removed)
- indication during a mobile originated call establishement, that the
calling party is ringing.
- Indication of the availability of the module, after boot, to receive AT
commands
For each of these indications, a “bit flow” has to be indicated. The syntax
of the command is :
Command syntax: AT+WIND= <IndLevel >
<IndLevel> Indication
1 (bit-0) Hardware SIM Insert / Remove indications (Rack open/close)
2 (bit-1) Calling party alert indication
4 (bit-2) Module is ready to treat AT commands (except phonebooks,
AOC, SMS), but still in emergency mode.
8 (bit-3) Indication that the module is ready to treat all AT commands,
at te end of init, or after ADN / FDN swap
16 (bit-4) Indication that a new call identifier has been created ( after an
ATD command, +CCWA indication)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 109
32 (bit-5) Indication that an active, held or waiting call has been released,
If <IndLevel> is equal to 0 (default value), no unsolicited
“+WIND: <IndNb>” will occur.
Combination (addition of the values) shall be used to allow more
than one indication flow.
0 W IndLevel W 63
The answer is OK if the value are in the previous range.
The unsolicited answer will then be :
+WIND : <event> [ ,<idx> ]
<idx>: Call identifier, defined in +CLCC command.
The supported events are:
<event> Meaning
0The SIM presence pin has been detected as “SIM removed”
(depending from the 0 bit flow)
1The SIM presence pin has been detected as “SIM inserted”
2Calling party is alerting
3Module is ready to treat AT commands (except phonebooks, AOC,
SMS), at init or after AT+CFUN=1
4Module is ready to treat all AT commands, end of phonebook init
or swap (FDN to ADN)
5Call <idx> has been created (after ATD, RING or +CCWA…)
6Call <idx> has been released, after a NO CARRIER, a +CSSU: 5
indication, or after the release of a call waiting
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 110
AT+WIND? Command is supported and indicates the <allowed bit
flows>. AT+WIND is automatically stored in e2p. This means the &W
commands has not to be used. And the selected flows are always activated
after boot.
Default value is 0 : No flow activated. No indication.
AT+WIND=? Indicates the posibbles values. (0-63)
14.4. Data ciphering mode between ME and MSC +ALEA
This command is used to get a random value from the mobile station and
to reenter it codes by the DES algorithm. In the way Application to GSM, an
"h" character shall be added before the value.
Application to GSM AT+ALEA? get random value
GSM to Application AT+ALEA=1234567890123456
OK command valid
Application to GSM AT+ALEA=hA125B348ABCDEF9 value coded
GSM to Application +ALEA=9876543210FBCADE0
OK value coded valid
new random value sent
Application to GSM AT+ALEA=h12335678902234AB new coded value
GSM to Application NO CARRIER coded value false
communication hang up
14.5. Data ciphering mode +CRYPT
This command enables or disables the data ciphering (D.E.S algorithm)
of the PIN and a random value sent periodically in order to insure a more
secure communication.
Application to GSM AT+CRYPT=0 Ciphering off
GSM to Application OK command valid
Application to GSM AT+CRYPT=1 Ciphering on
GSM to Application OK command valid
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 111
14.6. Key management +EXPKEY
This command is used to enter the key used in the D.E.S algorithm to
cipher the data (PIN ). In the way Application to GSM, an "h" character shall
be added before the value.
Application to GSM AT+EXPKEY? Is a key stored in EEPROM?
GSM to Application +EXPKEY: NO KEY key is absent
Application to GSM AT+EXPKEY=h0111011101110111 new key entered
GSM to Application OK command valid
Application to GSM AT+EXPKEY? Is a key stored in EEPROM?
GSM to Application +EXPKEY: READY key is present
14.7. Informations on PLMN +CPLMN
This command returns the status and the number of all PLMNs seen by
the mobile. It also indicates the BCCH frequency number (absolute) of the
strongest cell and its RxLev
Application to GSM AT+CPLMN=?
GSM to application +CPLMN: (2,20810,122,50),
(0,20801,64,53)
OK
as defined as AT+COPS=? in
the GSM TS 07 07
14.8. Analog digital converters measurements +ADC
This command allows to get the DC level of ADC A and ADC B (those
voltages are coded on 8 bits, see hardware specifications). Those values are
updated every 10 seconds.
Application to GSM AT+ADC?
GSM to application +ADC: 5,4
OK ADC A , ADC B
14.9. Mobile Equipment event reporting +CMER
This command enabled or disables sending of unsolicited result codes in
the case of key pressing.
Command Syntax: AT+CMER=<mode>,<keyp>,<disp>,<ind>,<bfr>
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 112
<keyp> (keypad) :
0No keypad event reporting.
1Keypad event reporting are routed using unsolicited code :
+CKEV : <key>, <press>
<press>
1: key press
0: key release
<key> : Keyboard map is (5,5)
01234
56789
10 11 12 13 14
15 16 17 18 19
20 21 22 23 24
14.10. Read Language Preference +WLPR
Command syntax: AT+WLPR= <index >
Response syntax: +WLPR: <value>
Read a Language Preference value of EF-LP. The first indexes should
have the highest priority.
Application to GSM AT+WLPR? Read command
GSM to application +WLPR: 4
OK Four language preference are
available in EF-LP
Application to GSM AT+WLPR=1 Read first EF-LP index value
GSM to application +WLPR: 5
OK Language preference is 5
14.11. Write Language Preference +WLPW
Command syntax: AT+WLPW=<index >,<value>
Response syntax: OK or +CME ERROR: <err>
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 113
Write a Language Preference value in EF-LP
Application to GSM AT+WLPW=1,5 Write Lang Pref equal to 5 in EF-LP
with index 1
GSM to application OK EF-LP correctly updated
14.12. Read GPIO value +WIOR
Command syntax: AT+WIOR=<index >
Response syntax: +WIOR: <value>
Set the I/O port as an input and read the I/O pin, 0 if the pin is reset, 1 if
the pin is set. Eight I/O ports are available, so the <index> value is between 0
and 7.
Application to GSM AT+WIOR=4 Read I/O (number 4) value
GSM to application +WIOR: 0
OK GPIO number 4 is reset
14.13. Write GPIO value +WIOW
Command syntax: AT+WIOW=<index >,<value>
Response syntax: OK
Set the I/O port as an output with a I/O pin value, 0 for reset, 1 for set
Application to GSM AT+WIOW=4,0 Reset I/O (number 4)
GSM to application OK GPIO value is written
14.14. Abort command +WAC
This specific command allows to abort SMS, SS and PLMN selection.
Command syntax:
Command Return
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 114
AT+WAC
AT+WAC=? OK
AT+WAC? OK
Example:
Application to GSM AT+COPS=? PLMN Selection.
Application to GSM AT+WAC Abort the ask of PLMN list
GSM to application OK
14.15. Play tone +WTONE
This specific command allows to play a tone on the current speaker or
on the buzzer. The frequency, gain and duration can be settled.
Command syntax:
AT+WTONE=<mode>[,<dest>,<freq>,<gain>,<duration>]
Response syntax: OK or +CME ERROR: <err>
<mode>:
0: Stop playing.
1: Play a tone
<dest>
This parameter settles the destination (mandatory if <mode>=1)
1: Speaker
2: Buzzer
<freq>
This parameter settles the frequency (in Hz) of the tone (mandatory if
<mode>=1).
If <dest> is the speaker, the range is between 1Hz and 3999Hz. If
<dest> is the buzzer, the range is between 1Hz and 50000Hz.
<gain> (0-15)
This parameter settles the gain of the tone. By default, the value is 9.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 115
<gain> Speaker (db) Buzzer (db)
0 0 -0.25
1-0.5 -0.5
2-1 -1
3-1.5 -1.5
4-2 -2
5-3 -3
6-6 -6
7-9 -9
8-12 -12
9-15 -15
10 -18 -18
11 -24 -24
12 -30 -30
13 -36 -40
14 -42 -infinite
15 -infinite -infinite
<duration> (0-255)
This parameter settles the duration of the tone (unit of 20 ms). When
this parameter is equal to 0 (default value), the duration is infinite, and
the tone can be stopped by AT+WTONE=0.
Application to GSM AT+WTONE=1,1,330,9,100 Play a tone
GSM to application OK Done
Application to GSM AT+WTONE=0 Stop playing
GSM to application OK Done
Application to GSM AT+WTONE=? Test command
GSM to application OK Done
Application to GSM AT+WTONE? Current value
GSM to application ERROR
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 116
14.16. Play DTMF tone +WDTMF
This specific command allows to play a DTMF tone on the current
speaker. The DTMF, gain and duration can be settled.
This command is only used to play a DTMF tone. To send a DTMF on
the GSM network, use the command +VTS.
Command syntax:
AT+WDTMF=<mode>[,<dtmf>,<gain>,<duration>]
Response syntax: OK or +CME ERROR: <err>
<mode>:
0: Stop playing.
1: Play a DTMF tone
<dtmf>
This parameter settles the DTMF to play in {0-9,*,#,A,B,C,D}
(mandatory if <mode>=1)
<gain> (0-15)
This parameter settles the gain of the tone. The values are the same
as these of +WTONE (speaker) command. By default, the value is 9.
<duration> (0-255)
This parameter settles the duration of the tone (unit of 20 ms). When
this parameter is equal to 0 (default value), the duration is infinite, and
the DTMF tone can be stopped by AT+WDTMF=0.
Application to GSM AT+WDTMF=1,"*",9,100 Play a DTMF tone
GSM to application OK Done
Application to GSM AT+WDTMF=0 Stop playing
GSM to application OK Done
Application to GSM AT+WDTMF=? Test command
GSM to application +WDTMF: (0-1),(0-9,*,#,A,B,C,D),(0-15),(0-255)
OK Done
Application to GSM AT+WDTMF? Current value
GSM to application ERROR
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 117
15. Other AT commands
15.1. V.25 ter recommandation
Other remaining basic commands are not implemented, so an "ERROR"
string will be sent back.
All commands about modulation control, error control and data
compression are not recognized. An "ERROR" string will be sent back.
15.2. GSM 07.05 recommandation
All the remaining commands are not implemented, so an "ERROR"
string will be sent back.
15.3. GSM 07.07 recommandation
All the remaining commands are not implemented, so an "ERROR"
string will be sent back.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 118
16. Appendices
16.1. ME error result code : +CME ERROR: <error>
<error> Meaning Resulting from the following commands
3Operation not allowed All GSM 07.07 commands (+CME ERROR: 3)
4Operation not supported All GSM 07.07 commands (+CME ERROR: 4)
5PH-SIM PIN required (SIM lock) All GSM 07.07 commands (+CME ERROR: 5)
10 SIM not inserted All GSM 07.07 commands (+CME ERROR: 10)
11 SIM PIN required All GSM 07.07 commands (+CME ERROR: 11)
12 SIM PUK required All GSM 07.07 commands (+CME ERROR: 12)
13 SIM failure All GSM 07.07 commands (+CME ERROR: 13)
16 Incorrect password +CACM, +CAMM, +CPUC, +CLCK, +CPWD,
+CPIN, +CPIN2 (+CME ERROR: 16)
17 SIM PIN2 required +CPBW (FDN), +CLCK (FDN),
18 SIM PUK2 required +CACM, +CAMM, +CPUC, +CPBW (FDN),
+CPIN, +CPIN2, +CLCK (FDN), +CPWD
20 Memory full +CPBW
21 Invalid index +CPBR, +CPBW, ATD>index, +WMGO
22 Not found +CPBF, +CPBP, +CPBN, +CGSN, +WOPN
24 Text string too long +CPBW, +CPIN, +CPIN2, +CLCK, +CPWD, +
26 Dial string too long +CPBW, ATD, +CCFC
30 No network service +VTS, +COPS=?, +CLCK, +CCFC, +CCWA
32 Network not allowed –
emergency calls only +COPS
40 Network personalisation PIN
required (Network lock) All GSM 07.07 commands (+CME ERROR: 40)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 119
16.2. Message service failure result code: +CMS ERROR : <er>
<er> is defined as below :
<er> Meaning Resulting from the following commands
1 to
127 Error cause values from the
GSM recommendation
04.11 Annex E-2
+CMGS, +CMSS
301 SMS service of ME reserved +CSMS (with +CMS: ERROR 301)
302 Operation not allowed All SMS commands (+CMSS, +CMGL, +CPMS,
+CSMP…
303 Operation not supported All SMS commands
304 Invalid PDU mode
parameter +CMGS, +CMGW
305 Invalid text mode parameter +CMGS, +CMGW, +CMSS
310 SIM not inserted All SMS commands
311 SIM PIN required All SMS commands
312 PH-SIM PIN required All SMS commands
313 SIM failure All SMS commands
316 SIM PUK required All SMS commands
317 SIM PIN2 required All SMS commands
318 SIM PUK2 required All SMS commands
321 Invalid memory index +CMGR, +CMSS, +CMGD
322 SIM memory full +CMGW
330 SC address unknown +CSCA?, +CMSS, +CMGS
16.3. Specific error result codes
<error> Meaning Resulting from the following commands
512 MM establishment failure
(for SMS) +CMGS, +CMSS (+CMS ERROR: 512)
513 Lower layer failure (for SMS) +CMGS, +CMSS
514 CP error (for SMS) +CMGS, +CMSS
515 Please wait, init or
command processing in
progress
All commands ( “+CME ERROR: 515” or “+CMS
ERROR: 515”)
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 120
16.4. Failure Cause from GSM 04.08 recommandation (+CEER)
Cause value
Diagnostic
1
Unassigned (unallocated) number
3
No route to destination
6
Channel unacceptable
8
Operator determined barring
16
Normal call clearing
17
User busy
18
No user responding
19
User alerting, no answer
21
Call rejected
22
Number changed
26
Non selected user clearing
27
Destination out of order
28
Invalid number format (incomplete number)
29
Facility rejected
30
Response to STATUS ENQUIRY
31
Normal, unspecified
34
No circuit/channel available
38
Network out of order
41
Temporary failure
42
Switching equipment congestion
43
Access information discarded
44
Requested circuit/channel not available
47
Resources unavailable, unspecified
49
Quality of service unavailable
50
Requested facility not subscribed
55
Incoming calls barred with in the CUG
57
Bearer capability not authorized
58
Bearer capability not presently available
63
Service or option not available, unspecified
65
Bearer service not implemented
68
ACM equal to or greater than ACMmax
69
Requested facility not implemented
70
Only restricted digital information bearer capability is
79
Service or option not implemented, unspecified
81
Invalid transaction identifier value
87
User not member of CUG
88
Incompatible destination
91
Invalid transit network selection
95
Semantically incorrect message
96
Invalid mandatory information
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 121
97
Message type non-existent or not implemented
98
Message type not compatible with protocol state
99
Information element non-existent or not implemented
100
Conditional IE error
101
Message not compatible with protocol state
102
Recovery on timer expiry
111
Protocol error, unspecified
127
Interworking, unspecified
All other values in the range 0 to 31 shall be treated as cause 31.
All other values in the range 32 to 47 shall be treated as cause 47.
All other values in the range 48 to 63 shall be treated as cause 63.
All other values in the range 64 to 79 shall be treated as cause 79.
All other values in the range 80 to 95 shall be treated as cause 95.
All other values in the range 96 to 111 shall be treated as cause 111.
All other values in the range 112 to 127 shall be treated as cause 127.
16.5. Specific Failure Cause for +CEER
240
FDN is active and number is not in FDN
241
Call operation not allowed
252
Call barring on outgoing calls
253
Call barring on incoming calls
254
Call impossible
255
Lower layer failure
16.6. GSM 04.11 Annex E-2: Mobile originating SM-transfer
These error causes could appear for SMS commands (+CMGS, +CMSS, +CMGD…)
Cause no 1: "Unassigned (unallocated) number"
This cause indicates that the destination requested by the Mobile Station cannot be
reached because, although the number is in a valid format, it is not currently assigned
(allocated).
Cause no 8: "Operator determined barring"
This cause indicates that the MS has tried to send a mobile originating short message
when the MS's network operator or service provider has forbidden such transactions.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 122
Cause no 10: "Call barred"
This cause indicates that the outgoing call barred service applies to the short
message service for the called destination.
Cause no 21: "Short message transfer rejected"
This cause indicates that the equipment sending this cause does not wish to accept
this short message, although it could have accepted the short message since the equipment
sending this cause is neither busy nor incompatible.
Cause no 27: "Destination out of service"
This cause indicates that the destination indicated by the Mobile Station cannot be
reached because the interface to the destination is not functioning correctly. The term "not
functioning correctly" indicates that a signalling message was unable to be delivered to the
remote user; e.g., a physical layer or data link layer failure at the remote user, user equipment
off-line, etc.
Cause no 28: "Unidentified subscriber"
This cause indicates that the subscriber is not registered in the PLMN (i.e. IMSI not
known)
Cause no 29: "Facility rejected"
This cause indicates that the facility requested by the Mobile Station is not supported
by the PLMN.
Cause no 30: "Unknown subscriber"
This cause indicates that the subscriber is not registered in the HLR (i.e. IMSI or
directory number is not allocated to a subscriber).
Cause no 38: "Network out of order"
This cause indicates that the network is not functioning correctly and that the
condition is likely to last a relatively long period of time; e.g., immediately reattempting the
short message transfer is not likely to be successful.
Cause no 41: "Temporary failure"
This cause indicates that the network is not functioning correctly and that the
condition is not likely to last a long period of time; e.g., the Mobile Station may wish to try
another short message transfer attempt almost immediately.
Cause no 42: "Congestion"
This cause indicates that the short message service cannot be serviced because of
high traffic.
Cause no 47: "Resources unavailable, unspecified"
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 123
This cause is used to report a resource unavailable event only when no other cause
applies.
Cause no 69: "Requested facility not implemented"
This cause indicates that the network is unable to provide the requested short
message service.
Cause no 81: "Invalid short message transfer reference value"
This cause indicates that the equipment sending this cause has received a message
with a short message reference which is not currently in use on the MS-network interface.
Cause no 95: "Invalid message, unspecified"
This cause is used to report an invalid message event only when no other cause in
the invalid message class applies.
Cause no 96: "Invalid mandatory information"
This cause indicates that the equipment sending this cause has received a message
where a mandatory information element is missing and/or has a content error (the two cases
are undistinguishable).
Cause no 97: "Message type non-existent or not implemented"
This cause indicates that the equipment sending this cause has received a message
with a message type it does not recognize either because this is a message not defined or
defined but not implemented by the equipment sending this cause.
Cause no 98: "Message not compatible with short message protocol state"
This cause indicates that the equipment sending this cause has received a message
such that the procedures do not indicate that this is a permissible message to receive while in
the short message transfer state.
Cause no 99: "Information element non-existent or not implemented"
This cause indicates that the equipment sending this cause has received a message
which includes information elements not recognized because the information element identifier
is not defined or it is defined but not implemented by the equipment sending the cause.
However, the information element is not required to be present in the message in
order for the equipment sending the cause to process the message.
Cause no 111: "Protocol error, unspecified"
This cause is used to report a protocol error event only when no other cause applies.
Cause no 127: "Interworking, unspecified"
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 124
This cause indicates that there has been interworking with a network which does not
provide causes for actions it takes; thus, the precise cause for a message which is being send
cannot be ascertained.
All values other than specified should be treated as error Cause No 41
16.7. Unsolicited result codes
Verbose result code Numeric (V0 set) Description
RING 2Incoming call signal from network
+CMTI: <mem>,<index> as verbose Incoming message stored in
<mem> (“SM”) at location <index>
+CMT: <oa>… (text mode)
or +CMT: [<alpha>,]… (PDU) as verbose Incoming message directly
displayed
+CDS: <fo>, <mr>… (text mode)
or +CDS: <length>,… (PDU) As verbose SMS status report after sending a
SMS
+CCCM : <ccm> As verbose Current Call Meter value
+CKEV: <keynb> As verbose Key press or release
+CCWA :<number>,<type>,
<class> [,<alpha>] As verbose Call Waiting number
+CLIP : <number>, <type>
[,,,<alpha>] As verbose Incoming Call Presentation
+CREG : <stat> [,<lac>,<ci>] As verbose Network registration indication
+CRING : <type> As verbose Incoming call type (VOICE, FAX ...)
+WIND: <IndicationNb> [,<CallId>] As verbose
(specific) Specific unsolicited indication (SIM
Insert/Remove, End of init, Reset,
Alerting, Call creation/release)
+CSQ: <RxLev>,99 As verbose
(specific) Automatic RxLev indication with
AT+CCED=1,8 command
+CSSI: <code1> As verbose
(specific) Supplementary service notification
during a call setup
16.8. Final result codes
Verbose result code Numeric (V0 set) Description
+CME ERROR: <err> As verbose Error from GSM 07.05 commands
+CMS ERROR: <err> As verbose Error from SMS commands (07.07)
BUSY 7Busy signal detected
ERROR 4Command not accepted
NO ANSWER 8Connection completion timeout
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 125
NO CARRIER 3Connection terminated
OK 0Acknowledges correct execution of
a command line
RING 2Incoming call signal from network
16.9. Intermediate result codes
Verbose result code Numeric (V0 set) Description
+COLP :<number>,<type> as verbose Outgoing Call Presentation
+CR : <type> as verbose Outgoing Call report control
+ILRR: <rate> as verbose Local TA-TE data rate
CONNECT 300 10 Data connection at 300 bauds
CONNECT 1200 11 Data connection at 1200 bauds
CONNECT 1200/75 12 Data connection at 1200/75 bauds
CONNECT 2400 13 Data connection at 2400 bauds
CONNECT 4800 14 Data connection at 4800 bauds
CONNECT 9600 15 Data connection at 9600 bauds
+CSSU: <code2> as verbose
(specific) Supplementary service notification
during a call
16.10. Parameters storage
Command AT&W
(E2P)
AT+CSAS AT&F
(SIM, E2P)
Initial values
+CMEE X X 0
+CSCS X X “PCCP437”
ATS0 X X 0 (no auto-answer)
+CICB X X 2 (speech)
+VGR X X 64 (all speakers)
+VGT X X 64 (all microphones)
+SPEAKER X X 0 (Spk 0 & Mic 0)
+SIDET X X 1,1
+CREG X X 0
+WAIP X X 0
+CMGF X X 1 (text)
+CSDH X X 0
+CNMI X X 0,1,0, 0, 0
+CSMP X X 1, 167, 0, 0
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 126
+CSCA XSIM dependant (phase 2)
+CCWA X X 0
+CLIP X X 0
+COLP X X 0
+CBST X X 0, 0, 1
+CRLP X X 61, 61, 48, 6, 0
+CR X X 0
+CRC X X 0
+IPR X0 (autobaud)
+IFC X2,2
+ICF X3,4
E X 1
&C X1
&D X1
&S X 1
QX X 0
V X X 1
+DOPT X X 1,1
+ECHO Command X0,160,12,5,512,10
+WIND Command X0
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 127
16.11. GSM sequences list
In accordance with GSM 02.30, the module implements the following
GSM sequences, which can be acceded by the ATD and the +CKPD
commands.
16.11.1. Security
**04*OLDPIN*NEWPIN*NEWPIN# Change PIN code
**042*OLDPIN2*NEWPIN2*NEWPIN2# Change PIN2 code
**05*PUK*NEWPIN*NEWPIN# Unlock PIN code
**052*PUK2*NEWPIN2*NEWPIN2# Unlock PIN2 code
*#06# Show the IMEI number
16.11.2. Call forwarding
*SC# Activate
**SC*PhoneNumber# or Register and activate
**SC*PhoneNumber*BS# or
**SC*PhoneNumber*[BS]*T#
*#SC# or *#SC**BS# Check status
#SC# Deactivate
##SC# or ##SC**BS# Unregister and deactivate
The Service codes (SC) are the followings:
002 all call forwarding
004 all conditional call forwarding
21 call forwarding unconditional
61 call forwarding on no answer
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 128
62 call forwarding on not reachable
67 call busy
The Network service codes (BS) are the followings:
No code All tele and bearer services
10 All teleservices
11 Telephony
12 All data teleservices
13 Fax services
16 Short Message Services
19 All teleservices except SMS
20 All bearer services
21 All asynchronous services
22 All synchronous services
24 All data circuit synchronous
25 All data circuit asynchronous
26 All dedicated packet access
27 All dedicated PAD access
The no reply condition timer (T), is only used for SC=61.
16.11.3. Call barring
*SC*Password# or *SC*Password*BS# Activate
*#SC# or *#SC**BS# Check status
#SC*Password# or #SC*Password*BS# Deactivate
**03*330*OLDPWD*NEWPWD*NEWPWD# Change password for call barring
**03**OLDPWD*NEWPWD*NEWPWD#
*03*330*OLDPWD*NEWPWD*NEWPWD#
*03**OLDPWD*NEWPWD*NEWPWD#
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 129
The Service codes (SC) are the followings:
33 call barring of outgoing call
330 all barring service
331 call barring of outgoing international call
332 call barring of outgoing international calls except to HPLMN
333 all outgoing barring service
35 call barring of incoming calls
351 call barring of incoming calls if roaming
353 all incoming barring service
The Network service codes (BS) are the same as these of the call
forwarding sequences.
16.11.4. Call waiting
*43# Activate
*#43# Check status
#43# Deactivate
16.11.5. Number presentation
*#30# CLIP check status
*#31# CLIR check status
*31#PhoneNumber Invoke CLIR for a voice call
#31#PhoneNumber Suppress CLIR for a voice call
*#76# COLP check status
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 130
16.12. Operator names
Country
Initials MCC MNC Preferred Presentation of
Country Initials and Mobile
Network Name
Abbreviated
Mobile Network
Name
Type of
network
A232 01 AUSTRALIA A1. A1 GSM900
A232 03 A max. max. GSM900
AL 276 01 AMC - AL A M C GSM900
ALG 603 01 ALGERIAN MOBILE NETWORK AMN GSM900
AND 213 03 STA-MOBILAND M-AND GSM900
AUS 505 01 Telstra MobileNet Telstra GSM900
AUS 505 02 YES OPTUS AUS Optus GSM900
AUS 505 03 VODAFONE AUS VFONE GSM900
AZE 400 01 AZE - AZERCELL GSM ACELL GSM900
AZE 400 02 BAKCELL GSM 2000 BKCELL GSM900
B206 10 B mobistar mobi* GSM900
BD 470 03 BD ShebaWorld SHEBA GSM900
BEL 206 01 BEL PROXIMUS PROXI GSM900
BG 284 01 M-TEL GSM BG M-TEL GSM900
BGD 470 01 BGD-GP GP GSM900
BHR 426 01 BHR MOBILE PLUS M.PLUS GSM900
BIH 218 90 PTT-GSMBIH BHGSM GSM900
BRU 528 11 BRU-DSTCom DSTCom GSM900
CAN 302 037 CAN-MCELL MCELL PCS1900
CH 228 01 SWISS GSM SWISS GSM900
CH 228 01 SWISS GSM SWISS GSM1800
CH 228 02 diAx Swiss diAx GSM900
CH 228 03 orange CH orange GSM1800
CHN 460 00 CHINA TELECOM CT-GSM GSM900
CHN 460 01 CHN-CUGSM CU-GSM GSM900
CI 612 03 CI Ivoiris Ivoir GSM900
CI 612 05 TELECEL-CI TELCEL GSM900
CL 730 001 CL ENTEL PCS ENTEL GSM900
CL 730 010 CL ENTEL PCS ENTEL PCS1900
CPV 625 01 CPV MOVEL CMOVEL GSM900
CY 280 01 CY CYTAGSM CY-GSM GSM900
CZ 230 01 PAEGAS- CZ PAEGAS GSM900
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 131
CZ 230 02 EUROTEL - CZ ET - CZ GSM900
D262 01 D1-TELEKOM D1 GSM900
D262 02 D2 PRIVAT D2 GSM900
D262 03 E-Plus E-Plus GSM1800
D262 07 D Interkom Ik GSM1800
DK 238 01 DK TDK-MOBIL TD MOB GSM900
DK 238 02 DK SONOFON SONO GSM900
DK 238 20 TELIA DK TELIA GSM1800
DK 238 30 DK mobilix #mbix GSM1800
E214 01 E AIRTEL AIRTL GSM900
E214 03 E AMENA AMENA GSM1800
E214 07 MOVISTAR MSTAR GSM900
EE 248 01 EE EMT GSM EMT GSM900
EE 248 02 EE RLE RLE GSM900
EE 248 03 EE Q GSM Q GSM GSM900
EGY 602 01 EGY MobiNiL MobiNiL GSM900
EGY 602 02 EGY CLICK GSM CLICK GSM900
ETH 636 01 ETH-MTN ET-MTN GSM900
F208 01 F Itineris Itine GSM900
F208 10 F SFR SFR GSM900
F208 20 F - BOUYGUES TELECOM BYTEL GSM1800
F340 01 F AMERIS AMERIS GSM900
F547 20 F-VINI VINI GSM900
F647 10 SFR REUNION SFR RU GSM900
FI 244 03 FI TELIA TELIA GSM1800
FI 244 05 FI RADIOLINJA RL GSM900
FI 244 09 FI FINNET FINNET GSM1800
FI 244 91 FI SONERA SONERA GSM900
FIJ 542 01 VODAFONE FIJ VODAFJ GSM900
GEO 282 01 GEO-GEOCELL GCELL GSM900
GEO 282 02 MAGTI-GSM-GEO MAGTI GSM900
GH 620 01 GH SPACEFON SPACE GSM900
GIB 266 01 GIBTEL GSM GIBTEL GSM900
GN 611 02 GN LAGUI LAGUI GSM900
GR 202 01 GR COSMOTE C-OTE GSM1800
GR 202 05 GR PANAFON PAN GSM900
GR 202 10 GR TELESTET TLSTET GSM900
H216 01 H PANNON GSM PANNON GSM900
H216 30 H-WESTEL 900 W-900 GSM900
HK 454 00 HK TELECOM TELCO GSM900
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 132
HK 454 04 HK HTCLGSM HTCL GSM900
HK 454 06 HK SMARTONE HKSMC GSM900
HK 454 10 HK NEW WORLD NWPCS GSM1800
HK 454 12 HK PEOPLES PTC GSM1800
HK 454 16 HK SUNDAY SUNDAY GSM1800
HR 219 01 HR - CRONET CRON GSM900
HR 219 10 HR-VIPNET VIP GSM900
I222 01 I TELECOM TIM GSM900
I222 10 I -OMNITEL OMNI GSM900
I222 88 I WIND I WIND GSM900
I222 88 I WIND I WIND GSM1800
IL 425 01 IL ORANGE ORANGE GSM900
INA 404 01 INA ESSAR CELLPHONE ESSARH GSM900
INA 404 07 INA - TATA CELLULAR TATA GSM900
INA 404 10 INA-AIRTL AIRTL GSM900
INA 404 11 INA ESSAR CELLPHONE ESSAR GSM900
INA 404 12 INA - ESCOTEL ESCOTL GSM900
INA 404 14 MODICOM INA MODICO GSM900
INA 404 15 INA ESSAR CELLPHONE ESSARU GSM900
INA 404 20 INA MaxTouch MAXTCH GSM900
INA 404 21 BPL MOBILE BPL MOBILE GSM900
INA 404 27 BPL MOBILE BPL MOBILE GSM900
INA 404 30 INA COMMAND COMMND GSM900
INA 404 41 INA RPG RPG GSM900
INA 404 42 INA AIRCEL AIRCEL GSM900
INA 404 43 BPL MOBILE BPL MOB GSM900
INA 404 46 BPL MOBILE BPL MOB GSM900
INA 404 60 INA ESSAR CELLPHONE ESSARR GSM900
IND 510 01 IND SATELINDOCEL SAT-C GSM900
IND 510 10 IND TELKOMSEL T-SEL GSM900
IND 510 11 IND GSM-XL EXCEL GSM900
IRL 272 01 IRL Eircell Eircell GSM900
IRL 272 02 IRL DIGIFONE DIGI GSM900
IS 274 01 IS SIMINN SIMINN GSM900
IS 274 02 IS TAL TAL GSM900
JOR 416 01 Fastlink FSTLNK GSM900
KGZ 437 01 BITEL KGZ BITEL GSM900
KHM 456 01 MOBITEL - KHM MT-KHM GSM900
KHM 456 02 KHM-SAMART-GSM KHM-SM GSM900
KSA 420 01 ALJAWWAL KSA GSM900
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 133
KSA 420 07 EAE-ALJAWWAL EAE GSM900
KT 419 02 KT MTCNet MTC GSM900
KZ 401 01 KZ K-MOBILE K-MOBILE GSM900
L 270 01 L LUXGSM LUXGSM GSM900
L 270 77 L TANGO TANGO GSM900
L 270 77 L TANGO TANGO GSM1800
LBR 618 01 LBR OMEGA OMEGA GSM900
LSO 651 01 VCL COMMS VCLCOM GSM900
LT 246 02 LT BITE GSM BITE GSM900
LTU 246 01 OMNITEL LT OMT GSM900
LV 247 01 LV LMT GSM LMT GSM900
LV 247 02 LV BALTCOM B-COM GSM900
M278 01 VODAFONE MLA VODA M GSM900
MAC 455 01 MAC-CTMGSM CTMGSM GSM900
MD 259 01 MD VOXTEL VOXTEL GSM900
MDG 642 02 MDG ANTARIS ANTARI GSM900
MKD 294 01 MKD-MOBIMAK MOBI-M GSM900
MOR 604 01 MOR IAM IAM GSM900
MOZ 643 01 MOZ - mCel mCel GSM900
MRU 617 01 CELLPLUS-MRU CELL + GSM900
MW 650 01 MW CP 900 CP 900 GSM900
MY 502 12 MY maxis mobile maxis GSM900
MY 502 13 MY EMARTEL MRTEL GSM1800
MY 502 16 MY DIGI 1800 MT18 GSM1800
MY 502 17 MY - ADAM 017 ADAM GSM1800
MY 502 19 MY CELCOM GSM CELCOM GSM900
N242 01 N Telenor TELENOR GSM900
N242 02 N NetCom GSM N COM GSM900
NCL 546 01 NCL MOBILIS MOBNCL GSM900
NL 204 04 NL LIBERTEL LIBTEL GSM900
NL 204 08 NL KPN TELECOM NL KPN GSM900
NL 204 12 NL TELFORT TELFORT GSM1800
NL 204 16 Ben NL Ben NL GSM900
NL 204 20 dutchtone Dtone GSM900
NZ 530 01 VODAFONE NZ VODA GSM900
OMN 422 02 OMAN MOBILE OMAN GSM900
P268 01 P TELECEL TLCL GSM900
P268 03 P OPTIMUS OPTIM GSM900
P268 06 P TMN TMN GSM900
PGY 744 01 HOLA PARAGUAY S.A. HPGYSA GSM900
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 134
PH 515 01 ISLACOM ISLA GSM900
PH 515 02 Globe Telecom-PH GLOBE GSM900
PH 515 03 PH SMART SMART GSM900
PH 515 03 PH SMART SMART GSM1800
PL 260 01 PL-PLUS PLUS GSM900
PL 260 02 PL-ERA GSM ERAGSM GSM900
PL 260 03 PL IDEA IDEA GSM1800
QAT 427 01 QAT-QATARNET Q-NET GSM900
R635 10 R-CELL RCELL GSM900
RA 283 01 RA-ARMGSM ARMMO1 GSM900
RL 415 01 RL Cellis CLLIS GSM900
RL 415 03 RL LibanCell LibCL GSM900
RO 226 01 RO CONNEX CONNEX GSM900
RO 226 10 RO dialog dialog GSM900
ROC 466 92 ROC LDTA GSM LDGSM GSM900
RUS 250 01 MTS-RUS MTS GSM900
RUS 250 02 North-West GSM RUS NWGSM GSM900
RUS 250 05 SCS RUS SCS GSM900
RUS 250 07 RUS BMT BMT GSM900
RUS 250 07 RUS SMARTS SMARTS GSM900
RUS 250 12 Far East RUS FEast GSM900
RUS 250 13 Kuban-GSM RUS KUGSM GSM900
RUS 250 28 EXTEL RUS EXTEL GSM900
RUS 250 39 Uraltel UTL GSM900
RUS 250 44 RUS North Caucasian GSM NC-GSM GSM900
S240 01 TELIA S TELIA GSM900
S240 07 S COMVIQ IQ GSM900
S240 08 S EUROPOLITAN EURO GSM900
SA 655 01 VodaCom-SA VODA GSM900
SA 655 10 MTN-SA MTN GSM900
SDN 634 01 SDN MobiTel SD-MOB GSM900
SEZ 633 01 SEZ CELLULAR SERVICES SEYCEL GSM900
SEZ 633 10 SEZ AIRTEL AIRTEL GSM900
SGP 525 01 ST-GSM-SGP STGSM GSM900
SGP 525 02 ST-GSM1800-SGP GSM1800 GSM1800
SGP 525 03 M1-GSM-SGP M1-GSM GSM900
SGP 525 05 STARHUB-SGP STARHUB GSM900
SI 293 40 SI.MOBIL SI.MOBIL GSM900
SI 293 41 SI MOBITEL GSM SI-GSM GSM900
SK 231 01 SVK GT SVK GT GSM900
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 135
SK 231 02 EUROTEL-SK ET-SK GSM900
SN 608 01 SN ALIZE ALIZE GSM900
SRI 413 02 SRI DIALOG DALOG GSM900
SYR 417 09 SYR MOBILE SYR MOBILE GSM900
TG 615 01 TG-TOGO CELL TGCELL GSM900
TH 520 01 TH AIS GSM TH AIS GSM900
TH 520 10 TH WCS TH WCS GSM1800
TH 520 23 TH-HELLO HELLO GSM1800
TR 286 01 TR PTT/TURKCELL GSM TCELL GSM900
TR 286 02 TR TELSIM TELSIM GSM900
TWN 466 01 Far EasTone FET GSM900
TWN 466 06 TWN Tuntex GSM 1800 TUNTEX GSM1900
TWN 466 88 KGT-Online KGT GSM1900
TWN 466 93 TWN MOBITAI TW MOB GSM900
TWN 466 97 TWN GSM 1800 PCC GSM1900
TZ 640 01 Tritel - TZ TRITEL GSM900
UA 255 01 UA UMC UMC GSM900
UA 255 03 UA-KYIVSTAR UA-KS GSM900
UA 255 05 UA - GOLDEN TELECOM GT-BCS GSM1800
UAE 424 02 UAE ETISALAT ETSLT GSM900
UG 641 01 UG CelTel CELTEL GSM900
UG 641 10 MTN-UGANDA MTN-UG GSM900
UK 234 10 UK CELLNET CLNET GSM900
UK 234 15 UK VODAFONE VODA GSM900
UK 234 30 ONE 2 ONE ONE2ONE GSM1800
UK 234 33 ORANGE ORANGE GSM1800
UK 234 50 JERSEY TELECOMS GSM UK JT GSM GSM900
UK 234 55 GUERNSEY TEL UK GSY-TEL GSM900
UK 234 58 MANX TELECOM PRONTO GSM MANX GSM900
UKR 255 02 FLASH-UKR FLASH GSM900
USA 310 010 USA MCI PCS1900
USA 310 011 USA WTTCKy PCS1900
USA 310 012 USA D&E Com PCS1900
USA 310 013 USA MobileTel PCS1900
USA 310 020 USA Sprint PCS1900
USA 310 030 USA PCS PRIME PCS1900
USA 310 031 USA-AERIAL PCS1900
USA 310 040 USA PCS PRIME PCS1900
USA 310 050 USA PCS PRIME PCS1900
USA 310 060 USA PCS PRIME PCS1900
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 136
USA 310 070 USA PCS PRIME PCS1900
USA 310 080 USA PCS PRIME PCS1900
USA 310 090 USA PCS PRIME PCS1900
USA 310 100 USA PCS PRIME PCS1900
USA 310 110 USA PCS PRIME PCS1900
USA 310 120 USA PCS PRIME PCS1900
USA 310 130 USA PCS PRIME PCS1900
USA 310 140 USA PCS PRIME PCS1900
USA 310 150 USA BellSouth BSMDCS PCS1900
USA 310 160 USA OMNIPOINT PCS1900
USA 310 170 USA PAC BELL PCS1900
USA 310 180 USA PAC BELL PCS1900
USA 310 190 USA COX PCS1900
USA 310 200 Voice STREAM USA WWC PCS1900
USA 310 210 Voice STREAM USA WWC PCS1900
USA 310 220 Voice STREAM USA WWC PCS1900
USA 310 230 Voice STREAM USA WWC PCS1900
USA 310 240 Voice STREAM USA WWC PCS1900
USA 310 250 Voice STREAM USA WWC PCS1900
USA 310 260 Voice STREAM USA WWC PCS1900
USA 310 270 USA PowerTel USA 27 PCS1900
USA 310 280 USA PowerTel PCS1900
USA 310 290 USA PowerTel PCS1900
USA 310 300 USA Aerial PCS1900
USA 310 310 USA-AERIAL AERIAL PCS1900
USA 310 320 USA Aerial PCS1900
USA 310 330 USA Aerial PCS1900
USA 310 340 USA Aerial PCS1900
USA 310 350 USA Aerial PCS1900
USA 310 380 USA Pocket PCS1900
USA 310 390 USA Pocket PCS1900
USA 310 400 USA Pocket PCS1900
USA 310 410 USA Pocket PCS1900
USA 310 420 USA Pocket PCS1900
USA 310 430 USA Pocket PCS1900
USA 310 440 USA Pocket PCS1900
USA 310 450 USA Pocket PCS1900
USA 310 460 USA OMNIPOINT PCS1900
USA 310 470 USA OMNIPOINT PCS1900
USA 310 480 USA OMNIPOINT PCS1900
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 137
USA 310 490 USA OMNIPOINT PCS1900
USA 310 500 USA OMNIPOINT PCS1900
USA 310 510 USA OMNIPOINT PCS1900
USA 310 520 USA OMNIPOINT PCS1900
USA 310 530 USA OMNIPOINT PCS1900
USA 310 540 USA OMNIPOINT PCS1900
USA 310 550 USA OMNIPOINT PCS1900
USA 310 560 USA OMNIPOINT PCS1900
USA 310 570 USA OMNIPOINT PCS1900
USA 310 580 USA OMNIPOINT PCS1900
USA 310 610 USA OMNIPOINT PCS1900
USA 310 620 USA OMNIPOINT PCS1900
USA 310 630 USA OMNIPOINT PCS1900
USA 310 640 USA Einstein PCS1900
USA 310 660 USA DiGiPH PCS1900
USA 310 670 USA WTTCKy PCS1900
USA 310 680 USA NPI PCS1900
USA 310 690 USA Conestoga PCS1900
VZ 734 01 VZ INFO INFONT
YU 220 01 YU MOBTEL MOBTEL
ZW 648 01 ZW NET*ONE NET*1
ZW 648 03 TELECEL ZW TELECEL
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 138
17. Annex A (informative)
This chapter illustrates informative examples about the general AT
commands used for a communication.
Informative example about the PIN required
1.1.1. Example 1 : In the start the ME is powered off.
AT+CMEE=1 Enable the report mobile equipment errors
OK
AT+CREG=1 Report registration
OK
AT+CPAS Query ME Status
+CPAS: 5 (ME is asleep)
OK
AT+CFUN=1 Set ME to full functionality
OK
AT+COPS=0 Ask for automatic operator selection and registration.
+CME ERROR: 11 SIM PIN required.
AT+CPIN=1234 User entered a wrong PIN
+CME ERROR: 16 Incorrect password.
AT+CPIN=0000
OK PIN Ok
AT+COPS=0 Ask for automatic operator selection and registration.
OK
+CREG:1 Registered in the network
AT+COPS=3,0 Select the long name format alphanumeric.
OK
AT+COPS? Get the operator name
+COPS: 0,0,”I OMNITEL”
OK
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 139
1.1.2. Example 2: In the start the ME has already been powered on.
AT+CMEE=1 Enable the report mobile equipment errors
OK
AT+CPAS Query ME Status
+CPAS: 0 ME is already to receive commands
OK
AT+CPIN? Is ME asking password?
+CPIN: SIM PIN Yes, SIM PIN required
AT+CPIN=0000
OK PIN Ok
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 140
Informative example where a voice call is originated.
In the start the ME is powered on and the SIM PIN has been entered.
AT+CMEE=1 Enable the report mobile equipment errors
OK
AT+WIND=63 Ask to display the general indications.
OK
AT+CPIN? Is ME asking password?
+CPIN: READY GSM module is ready
ATD0607103543; Originate a voice call
+WIND: 5,1 Indication about a call creation.
+WIND: 2 Remote party is ringing.
OK Call setup was successful
Conversation…
ATH Release the call
OK
When a voice call is attempted from a phonebook :
ATD>”John Pamborn”;
+CME ERROR: 22 Entry “John Pamborn” is not found.
ATD>”Joel Guerry”;
+WIND: 5,1 Indication about a of call creation.
+WIND: 2 Remote party is ringing.
OK Call setup was successful
Conversation…
ATH Release the call
OK
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 141
Informative example about an incoming call.
In the start the ME is powered on and the SIM PIN has been entered.
AT+CMEE=1 Enable the report mobile equipment errors
OK
AT+WIND=63 Ask to display the general indications.
OK
AT+CLIP=1 Enable the calling line identification presentation.
OK
AT+CRC=1 Enable extended format of incoming indication.
OK
AT+CNUM Query own number (voice number) or MSISDN.
+CNUM: “Speech”,”+33608971019”,145
OK
Originate the number on another ME.
+WIND: 5, 1 Indication about a call creation. (Ring)
+CRING: VOICE Type of call is VOICE.
+CLIP: "+33607103543",145,,,"John Panborn" Identification about the remote user.
+CRING: VOICE
ATA Answer the call.
OK
…Conversation…
NO CARRIER The call has been released by the remote user.
+WIND: 6,1 Indication about call release.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 142
Informative example about a call forwarding
In the start the ME is powered on and the SIM PIN has been entered.
AT+CMEE=1 Enable the report mobile equipment errors
OK
AT+CFCC=1,3,”0607492638” Registered a call forwarding when mobile is busy.
OK
AT+CCFC=2,3,”0149293031”,129 Registered a call forwarding when it does answer.
+CME ERROR: 30 No network service
AT+CCFC=1,2 Interrogate
+CCFC: 1,1,”+33607492638”,145 Call forwarding active for a voice call.
AT+CFCC=1,4 Delete call forwarding Mobile busy
OK
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 143
Informative example about a multiparty
In the start the ME is powered on and the SIM PIN has been entered.
AT+CMEE=1 Enable the report mobile equipment errors
OK
AT+WIND=63 Ask to display the general indications.
OK
AT+CCWA=1,1 Enable call waiting.
OK
ATD>”John Panborn”;
+WIND: 5,1 Indication about a of call creation.
+WIND: 2 Remote ring.
OK Call setup was successful
…Conversation…
+WIND: 5,2 Indication about another call creation.
+CCWA: “+33595984834”,145,”Dolores Claiborne” Another call is waiting.
AT+CHLD=2 Put first call on hold and answer the second one.
OK
…Conversation…
AT+CHLD=3 Every calls are into a multiparty.
OK
AT+CHLD=11 Release the first call (with John Panborn) and recover
the second call (with Dolores Claiborne)
…Conversation …
ATH Release the second call.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 144
Informative example about phonebooks
For each example illustrates in this section: in the start the ME is
powered on and the SIM PIN has been entered.
1.6.1. Example 1 : The whole phonebook of the ME is read
AT+CPBS=? Query supported phonebook memories
+CPBS: (“SM”,”FD”,”ON”) ADN, FDN, and MSISDN phonebooks supported.
AT+CPBS=”SM” Select ADN phonebook..
OK
AT+CPBR=? Read index range and element lengths.
+CPBR: (1-80),20,14 80 locations (from 1 to 80), max length of 20
for phone 14 characters max for associated text.
AT+CPBR=1,80 Read all entries but only the ones set are returned.
+CPBR: 1,“0346572834”,129,”Dolores Claiborne”
+CPBR: 2,”1284374523”,129,”Thad Beaumont”
+CPBR: 3, “1243657845”,129,”John Panborn”
OK
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 145
1.6.2. Example 2 : Erase or Write a phonebook entry
AT+CPBW=? Query version of the write phonebook entry.
+CPBW: (1-80),20,(129,145),14 80 locations, max length of 20 for phone,
TON/NPI of 129 or 145 and 14 characteers max
For length of text.
AT+CPBW=3 Erase location 3
OK
AT+CPBW=3,”4356729012”,129,”Carry” Write at location 3.
Ok
AT+CPBR=1,80 Read all entries but only the ones set are returned.
+CPBR: 1,“0346572834”,129,”Dolores Claiborne”
+CPBR: 2,”1284374523”,129,”Thad Beaumont”
+CPBR: 3,”4356729012”,129,”Carry”
OK
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 146
1.6.3. Example 3 : Find phonebook entries
AT+CPBF=? Query version of the write phonebook entry.
+CPBF: 20,14 Max length of 20 for phone,
10 characters for the text.
AT+CPBF=”D” Read entry with “D”.
+CPBF: 1,“0346572834”,129,”Dolores Claiborne”
OK
AT+CPBF=”W” Read entrie with “D”.
+CME ERROR: 22 Entry not found.
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 147
Informative example about short messages
1.6.4. Example 4 : Send a short message
AT+CNMI=0,1,1,1,0 SMS-DELIVERs are directly stored, SMS-STATUS-REPORTs are displayed
OK
AT+CSMP=17,169,0,0 ” SMS-SUBMIT message with a validity period (one day)
OK
AT+CMGF=1 ” ” Text mode to send a Short Message
OK
AT+CSCA=”+33608080706” Set Service Center Address to +33608080706
OK
AT+CMGS=0601290800Send a SMS-SUBMIT to mobile phone
Ø Module sends a 4 characters sequence: 0x0D 0x0A 0x3E 0x20
This is the first text line Edit first line and press carriage return (<CR>, 0x0D)
This is the last text line Edit last line and send message by pressing <ctrl-Z> (0x1A)
+CMGS: 5 Success: message reference 5 is returned from the SMS Service Center
+CDS: 2,5,”0601290800”,129,”99/05/01 14:15:10+04
” ” ” ” Success: report of successful message delivery received
AT commands interface
This confidential document is the property of WAVECOM and may not be copied or circulated without permission 148
1.6.5. Example 5: Read short messages
AT+CMGF=1 Text mode to read Short Messages
AT+CMGL=”ALL” List all stored messages
+CMGL: 1,”REC READ”,”+336290918”,,”99/05/01 14:15:10+04”
This is the first message
+CMGL: 2,”REC UNREAD”,”+336290918”,,”99/05/01 14:19:44+04”
This is the second message
OK
AT+CMGR=1 ” ” Read the first message
+CMGR: ”REC READ”,”+336290918”,,”99/05/01 14:19:44+04”
OK
