BDApps API Guide
Document Version1.1.1
Robi Corporate Centre
53 Gulshan South Avenue
Gulshan 1
phone:+88 02 9887146-52
fax:+88 02 9885463
Dhaka-1212
Bangladesh
Document Code ROB-API-DGD v1.1.1 Last edited: 13 May 2015
Copyright © 1997-2015 hSenid Mobile Solutions (Pvt) Ltd. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, in any form
or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written
permission from hSenid Mobile. All copyright, confidential information, patents, design rights and all other
intellectual property rights of whatsoever nature in and to any source code contained herein (including any
header files and demonstration code that may be included), are and shall remain the sole and exclusive
property of hSenid Mobile. The information furnished herein is believed to be accurate and reliable. However,
no responsibility is assumed by hSenid Mobile for its use, or for any infringements of patents or other rights of
third parties resulting from its use.
All other trademarks in this publication are the property of their respective owners.
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 3 of 45
Table of contents
1 Overview .....................................................................................................................................6
1.1 SMS Service ..........................................................................................................................6
1.2 USSD .....................................................................................................................................6
1.3 CAAS .....................................................................................................................................6
2 HTTP REST ...................................................................................................................................8
2.1 JSON Objects ........................................................................................................................8
3 SMS .............................................................................................................................................9
3.1 Send Service .........................................................................................................................9
3.1.1 Request ..........................................................................................................................9
3.1.2 Response...................................................................................................................... 13
3.2 Receive Service ................................................................................................................... 16
3.2.1 Request ........................................................................................................................ 16
3.2.2 Response...................................................................................................................... 17
3.3 Delivery Status Report ........................................................................................................ 18
3.3.1 Request ........................................................................................................................ 18
3.3.2 Response...................................................................................................................... 20
4 USSD.......................................................................................................................................... 22
4.1 Send Service ....................................................................................................................... 22
4.1.1 Request ........................................................................................................................ 22
4.1.2 Response...................................................................................................................... 25
4.2 Receive Service ................................................................................................................... 26
4.2.1 Request ........................................................................................................................ 26
4.2.2 Response...................................................................................................................... 28
5 CAAS .......................................................................................................................................... 30
5.1 Query Balance..................................................................................................................... 30
5.1.1 Request ........................................................................................................................ 30
5.1.2 Response...................................................................................................................... 33
5.2 Get Payment Instrument List............................................................................................... 35
5.2.1 Request ........................................................................................................................ 35
5.2.2 Response...................................................................................................................... 36
5.3 Direct Debit ........................................................................................................................ 38
5.3.1 Request ........................................................................................................................ 38
5.3.2 Response...................................................................................................................... 40
Status Codes (Non Retry-able) .................................................................................................... 42
Error Codes (Non Retry-able) ...................................................................................................... 42
Error Codes (Retry-able) ............................................................................................................. 44
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 5 of 45
About This Document
The purpose of this document is to provide developing information on BDApps API for SMS and USSD
services.
The intended audience for this document is the Application Developers.
The document is divided into the following chapters:
Chapter
Description
1 Overview
This chapter gives a brief description of document content.
2 HTTP Rest
This chapter gives a brief description of involvement of HTTP REST in
the context.
3 SMS
This chapter gives a brief description of SMS REST Service.
4 USSD
This chapter gives a brief description of USSD Service.
5 CAAS
This chapter gives a brief description of CAAS Service.
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 6 of 45
1 Overview
This chapter describes how the Service Providers can use HTTP-based Interfaces from BDApps API for
SMS, and USSD services. For more details on each service please refer the relevant chapter.
1.1 SMS Service
The SMS Interface allows applications to send and receive SMS messages using a HTTP-based API.
Supported services are as follows:
Send Service – An application wishing to initiate an MT (Mobile Terminated) SMS
message should use this operation type.
Receive Service – This retrieves the SMS sent to the application.
Status Report Service – If an application when performing a Send service Operation had
requested for a status report from BDApps API, then the BDApps API will initiate the
status report service to hand over the status report to the application.
1.2 USSD
The USSD Interface allows applications to initiate USSD sessions using a HTTP-based API. Supported
services are as follows:
Send Service – An application wishing to send response to MO USSD session should call
this method.
Deliver Service – Deliver Service can be either a user initiated session or a response to
an existing USSD session.
1.3 CAAS
Applications have CAAS NCS access if charging as a service requests are required by the application.
Query Balance – This service retrieves the account balance and other related
information of a given subscriber MSISDN.
Direct Debit – This service charges a specific amount from a subscriber’s account.
Get Payment Instrument List - Get Payment Instrument List is to get a list of all the
available payment instruments for a particular subscriber.
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 7 of 45
MO (Mobile Originated) flow:
In MO, first the MO request will be sent to application from the BDApps API. There will be a response
sent from the application to BDApps API subsequently.
MT (Mobile Terminated) flow:
In MT, a MT request is sent from application to the BDApps API. The MT request response will be
from the BDApps API to application subsequently.
BDApps API
Application
1. MT request
2. MT Request Response
BDApps API
Application
1. MO request
2. Response from Application
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 8 of 45
2 HTTP REST
In this context, both requests/responses used to exchange information are with content type
"application/json".
2.1 JSON Objects
JSON objects are used as content type to communicate between application and BDApps API. JSON is
an open, text-based data exchange format; it is human-readable, independent, and supports a wide
availability of implementations.
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 9 of 45
3 SMS
The SMS REST Service provides operations for sending SMS to BDApps API and to receive the SMS.
E.g., A user sending a text message to a mobile phone from an application and receiving SMS from a
mobile phone to an application.
3.1 Send Service
This service let the user send SMS to one or more terminals (phones or any SMS-enabled device)
from their application.
Send service supports only POST HTTP requests. This is used when sending SMS to a mobile phone
from an application.
An application wishing to initiate an MT SMS message should use this operation type.
The URL for SMS Send service is as follows:
https://developer.bdapps.com/sms/send
3.1.1 Request
Following is a sample request of send service.
{
"applicationId":"APP_000027",
"password":"10d8769c825f4aad0c511dfe3de3f121",
"message":"Sample Message",
"destinationAddresses":["tel:8801812345678"]
}
Following are the Request parameters of Send service.
Parameter Name
Description
Type
Mandatory /
Optional
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 10 of 45
applicationId
Application ID as given when
provisioned
String
Mandatory
password
Password given when
provisioned
String
Mandatory
version
API version
shall be numbered as 1.0, 2.0
etc
String
Optional
If not specified
shall be validated
against the latest
version
destinationAddresses
List of destination addresses
should be telephone numbers
tel - for MSISDN
tel: 8801812345678,
tel: 8801812345678
Address can also have the
value - tel: all
which will in turn be a message
to the subscribed base of the
application
Note: tel might be a masked
number depending on the type
of application.
String
at least one need
to be specified
message
The message that need to be
sent, Messages over the limit
shall be broken up by the and
messaged.
String
Mandatory
sourceAddress
The sender address to be
shown - can be one of the
provisioned values in alias list
String
Optional
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 11 of 45
deliveryStatusRequest
To indicate the need of
Delivery Status Report for the
message.
Enumerator
0 - Delivery
Report not
required
1 - Delivery
Report Required
Optional
If not specified
shall be assumed
to be a request
without the need
for Delivery Report
encoding
Encoding scheme used in the
message
Enumerated
0 – Text
16- Bengali
240 - Flash SMS
245 - Binary SMS
Optional
If not specified
taken as Text
If the encoding
type is “Binary”
then the message
content will be
represented as hex
encoded.
chargingAmount
Charging amount specified for
variable charging applications
only
Number to 2
decimal places -
shall be
considered only
in system
currency Eg.
78.05
Optional
binaryHeader
For advanced type messages
where the binary header shall
be sent from the application
Hexadecimal
String
Optional (‘Binary
Header’ is
Mandatory if
message
‘encoding’ is ‘Flash’
or ‘Binary’ )
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 12 of 45
Comprehensive sample request:
{
"password":"c609a16c0b01aac11396cea484f8e535",
"message":"Sample Message",
"destinationAddresses":["tel:8801812345678"],
"applicationId":"APP_000006",
"deliveryStatusRequest":”0”,
"version":”1.0”,
"sourceAddress":”<shortcode_appname>”,
"encoding":”16”,
"binary-header":”7663697479”,
"chargingAmount": ”8.252342”
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 13 of 45
3.1.2 Response
Following is a sample response of send service.
{
"statusCode":"S1000",
"requestId":"101307311109540017",
"statusDetail":"Request was successfully processed",
"destinationResponses":[{"statusCode":"S1000",
"timeStamp":"20130731110954",
"address":"tel: 8801812345677",
"statusDetail":"Request was successfully processed",
"messageId":"101307311109540017"}],
"version":"1.0"
}
Following are the Response parameters of Send service.
Parameter Name
Description
Type
Mandatory
/ Optional
version
API version
shall be numbered as 1.0, 2.0 etc
If version was specified in request, same
version must be sent in response.
If version was not specified in request, then
latest version will be specified in response.
String
Mandatory
requestId
requestId to uniquely Identify the request
within the BDApps API
String
Mandatory
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 14 of 45
statusCode
The status code for the entire request
String
Mandatory
statusDetail
The status detail for the entire request
String
Mandatory
destinationResponses
The list of Responses for the full list of
Addresses It will be a collection with
individual entry for each element in the
Address list of the request.
Address
TimeStamp - Processed Time stamp
MessageId - Message Identifier
StatusCode - Error Code
StatusDetail - Error detail
Eg:
{"DesinationResponses" : {
"DestinationResponse" : [ { "Address": "tel:
+880183216345490", "TimeStamp":
"yyyymmddhhmmss", "MessageId":
"dfsfs1213", "StatusCode": "SBL-SMS-MT-
2000", "StatusDetail": "Success" } {
"Address": "tel: 8801832165490",
"TimeStamp": "yyyymmddhhmmss",
"MessageId": "dfsfs12232", "StatusCode":
"SBL-SMS-MT-2000", "StatusDetail":
"Success" } ] },
String
Mandatory
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 15 of 45
Sample Destination Response:
"destinationResponses":[{"statusCode":"S1000",
"timeStamp":"20130731114407",
"address":"tel : 8801812345677",
"statusDetail":"Request was successfully processed",
"messageId":"101307311144070043"}],
Comprehensive sample response:
{
"statusCode":"S1000",
"requestId":"101307311144070043",
"statusDetail":"Request was successfully processed",
"destinationResponses":[{"statusCode":"S1000",
"timeStamp":"20130731114407",
"address":"8801812345677",
"statusDetail":"Request was successfully processed",
"messageId":"101307311144070043"}],
"version":"1.0"
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 16 of 45
3.2 Receive Service
This retrieves the SMS sent to the web application. Receive service returns only a list of SMS
messages received since the previous invocation of the method to receive SMSs.
3.2.1 Request
Following is a sample request of receive service.
{
"message":"Test Message",
"requestId":"51307311302350037",
"applicationId":"APP_000006",
"sourceAddress":"tel: 8801832160987",
"version":”1.0”,
"encoding":”16”
}
Following are the Request parameters of receive service.
Parameter Name
Description
Type
Mandatory
/ Optional
version
API version
shall be numbered as 1.0, 2.0 etc
String
Mandatory
applicationId
Application ID as given when
provisioned
String
Mandatory
sourceAddress
source address
sourceAddress: tel: +8801832160987
String
at least one
will be
specified
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 17 of 45
message
Message as sent from the user
String
Mandatory
requestId
Request Identifier in the BDApps API.
String
Mandatory
encoding
Encoding scheme used in the
message
If the encoding type is “Binary” then
the message content will be
represented as hex encoded.
Enumerated
0 – Text
16- Bengali
240 - Flash SMS
245 - Binary SMS
Mandatory
3.2.2 Response
Following is a sample response of receive service.
{
"statusCode":"S1000",
"statusDetail":"Success"
}
Following are the Response parameters of receive service.
Parameter
Name
Description
Type
Mandatory
/ Optional
statusCode
The error code for the entire request
String
Mandatory
statusDetail
The error detail for the entire request
String
Mandatory
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 18 of 45
Comprehensive sample response:
{
"statusCode":"S1000",
"statusDetail":"Success"
}
3.3 Delivery Status Report
When performing a SendSms Operation if an application had requested for a Delivery Response
message from the Message Centre, then the BDApps API will initiate the Delivery Report service to
hand over the Delivery Response message to the application. The messageId should be used to
match the MT response with the Delivery Report.
3.3.1 Request
Following is a sample request of delivery status report service.
{
"destinationAddress":"tel:8801832160987",
"timeStamp":"20120113082110",
"requestId":"51307311302350037",
"deliveryStatus":"DELIVERED"
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 19 of 45
Following are the request parameters of delivery status report service.
Parameter Name
Description
Type
Mandatory
/ Optional
destinationAddress
Address of the subscriber
E.g., tel: 8801832160987
String
Mandatory
timeStamp
The timestamp sent from the SMS
"yyMMddHHmm"
yy – last two digits of the year (00-99)
MM – month (01-12)
dd – day (01-31)
HH – hour (00-23)
mm- minute (00-59)
String
Mandatory
requestId
requestId to uniquely Identify the
request within the BDApps API
String
Mandatory
deliveryStatus
Enum From SMPP Gateway : DELIVRD,
EXPIRED, DELETED, UNDELIV, ACCEPTD,
UNKNOWN, REJECTD
Enum from bd-apps to Application:
DELIVERED, EXPIRED, DELETED,
UNDELIVERABLE, ACCEPTED,
UNKNOWN, REJECTED
Mandatory
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 20 of 45
Comprehensive sample request:
{
"destinationAddress":"tel: 8801832160987",
"timeStamp":"20120113082110",
"requestId":"51307311302350037",
"deliveryStatus":"DELIVERED"
}
3.3.2 Response
Following is a sample request of delivery status report service.
{
"statusCode":"S1000",
"statusDetail":"Success"
}
Following are the response parameters of delivery status report service.
Parameter
Name
Description
Type
Mandatory
/ Optional
statusCode
The status code for the entire request
String
Mandatory
statusDetail
The status detail for the entire request
String
Mandatory
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 21 of 45
Comprehensive sample response:
{
"statusCode":"S1000",
"statusDetail":"Success"
}
Note: Sample status and error codes are listed in the Appendix A
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 22 of 45
4 USSD
USSD (Unstructured Supplementary Service Data) is a capability built into SMS-based mobile devices.
USSD information is directly sent from the sender’s device to an application which is with USSD . A
USSD service can be invoked either by the mobile user or by a USSD .
4.1 Send Service
This service lets the user send USSD to one or more terminals from the application.
Send service supports only POST HTTP requests. This is used when sending USSD messages to a
mobile phone from an application.
The URL for USSD Send service is as follows:
https://developer.bdapps.com/ussd/send
4.1.1 Request
Following is a sample request for send service.
{
"applicationId":"APP_003117",
"password":"18b834673a1eed3913ce72fec6d91df4",
"message": "1. Press One
2. Press two
3. Press three
4. Exit",
"sessionId": "1330929317043",
"ussdOperation": "mt-cont",
"destinationAddress": "tel: 8801812345678"
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 23 of 45
Following are the Request parameters of send service.
Parameter Name
Description
Type
M / O
applicationId
Application ID as given when provisioned
String
M
password
Password given when provisioned
String
M
version
API version (shall be numbered as 1.0 etc)
If not specified shall be validated against
the latest version
O
sessionId
Unique number that USSD Gateway
assigns to the application for the duration
of the session. This number will be
maintained in all messages throughout a
single session.
String
M
ussdOperation
mo-init : BDApps API to assign when a
USSD session is initiated by subscriber
mo-cont : BDApps API to assign for any
USSD message originated from subscriber,
that comes after a init
mt-init : App to assign when a USSD
session is initiated by an application
mt-cont : App to assign for any USSD
message originated from application, that
comes after a init
mt-fin : App to assign when session ends
in final message
Enumerator
Data type will be
string where the
operation name
itself will be used in
the parameter
value.
M
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 24 of 45
destinationAddress
Destination address
should be a telephone number
tel - for MSISDN
tel: 8801812345678
Note : tel might be a masked number
depending on the type of application
String
M
encoding
Encoding scheme used in the message
440 - Plain ASCII characters
16- Bengali
Enumerated
O
message
Message as sent to the user
String
M
chargingAmount
Charging amount specified for variable
charging applications only
number to 2
decimal places -
shall be considered
only in system
currency Eg. 78.05
O
Comprehensive sample request:
{
"applicationId": "APP_000001",
"password": "18b834673a1eed3913ce72fec6d91df4",
"message": "1. Press One
2. Press two
3. Press three
4. Exit",
"sessionId": "1330929317043",
"ussdOperation": "mt-cont",
"destinationAddress": "tel: 8801812345678",
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 25 of 45
"version":”1.0”,
"encoding":”16”,
"chargingAmount":”8.252342”
}
4.1.2 Response
USSD-Send-Response is a response from the BDApps API to the application, which will be sent as a
response to the USSD-Send-Request message.
Following are the response parameters of send service.
Parameter Name
Description
Type
M / O
version
API version (shall be numbered as 1.0 etc)
String
M
requestId
requestId to uniquely Identify the request
within the BDApps API
String
M
statusCode
The status code for the entire request
String
M
statusDetail
The status detail for the entire request
String
M
Comprehensive sample response:
{
"statusCode":"S1000",
"requestId":"101308060614220956",
"statusDetail":"Success",
"version":"1.0"
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 26 of 45
4.2 Receive Service
The ReceiveUssd service allows BDApps API to deliver MO messages to the application using HTTP –
based API. The flow of messages is initiated by a MO request sent to an application, the BDApps API
will deliver the message to the application as an acknowledgement. Hence it could be either request-
response exchange or a request-exception exchange.
Receive USSD request is a MO message which will be sent to the application through the BDApps API
as a delivery request.
4.2.1 Request
Following is a sample request for receive service.
{
"message":"010",
"ussdOperation":"mo-init",
"requestId":"071308060343170263",
"sessionId":"1209992331266121",
"encoding":"16",
"applicationId":"APP_003117",
"sourceAddress":"tel: 8801812345678",
"version":"1.0"
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 27 of 45
Following are the request parameters of receive service.
Parameter
Name
Description
Type
M / O
version
API version (shall be numbered as 1.0 etc)
String
M
applicationId
Application ID as given when provisioned
String
M
sessionId
Unique number that USSD GW assigns to the
application for the duration of the session
String
M
ussdOperation
mo-init : BDApps API to assign when a USSD
session is initiated by subscriber
mo-cont : BDApps API to assign for any USSD
message originated from subscriber, that comes
after a init
mt-init : App to assign when a USSD session is
initiated by an application
mt-cont : App to assign for any USSD message
originated from application, that comes after a init
mt-fin : App to assign when session ends in final
message
Integer
M
sourceAddress
sender address
sourceAddress: tel: 8801832165490
String
M
message
Message as sent from the user
String
M
encoding
Encoding scheme used in the message
440 - Plain ASCII characters
16- Bengali
Enumerated
M
requestId
Request ID to uniquely Identify the request within
the BDApps API
String
M
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 28 of 45
Comprehensive sample request:
{
"message":"010",
"ussdOperation":"mo-init",
"requestId":"071308060343170263",
"sessionId":"1209992331266121",
"encoding":"16",
"applicationId":"APP_003117",
"sourceAddress":"tel: 8801812345678",
"version":"1.0"
}
4.2.2 Response
Deliver-USSD-Response should be the response given by the Application to the BDApps API as an
acknowledgement on the receipt of a MO message submitted by BDApps API.
Following are the response parameters of receive service.
Parameter Name
Description
Type
M / O
statusCode
The status code for the entire request
String
M
statusDetail
The status detail for the entire request
String
M
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 29 of 45
Comprehensive sample response:
{
"statusCode": "S1000",
"statusDetail": "Success"
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 30 of 45
5 CAAS
Applications have Caas NCS access if charging as a service requests are required by the application.
5.1 Query Balance
This service retrieves the account balance and other related information of a given subscriber
MSISDN. Account information comprises of Account type (Pre paid or Post paid) and Account’s status
(Activate or Disable).
The URL for Query Balance service is as follows:
https://developer.bdapps.com/caas/balance/query
5.1.1 Request
Following is a sample request for query balance service.
{
"applicationId":"APP_000010",
"password":"8f57d2e8de06e6f2d6ee5da6107d0a4f",
"subscriberId":"tel: 8801812345678"
"paymentInstrumentName":"Mobile Account"
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 31 of 45
Following are the Request parameters of query balance service.
Parameter Name
Description
Type
M / O
applicationId
Used to identify the application. This is a
unique identifier generated while provisioning
an application.
Only a single value can be sent per request.
String (32)
M
password
Used to authenticate the application
originated message against the service
provider’s credentials.
Encoded, single value.
String(32)
M
subscriberId
This can be the MSISDN of the subscriber
whose account balance is being queried.
Note: tel: number might be a masked number
depending on the type of the application.
Only a single value can be sent per request.
String
M
paymentInstrumentName
The name of the payment instrument.
Only a single value can be sent per request.
Enumerator
M
accountId
The account of the payment instrument.
Only a single value can be sent per request.
String
O
currency
The currency of the amount.
Only a single value can be sent per request.
Only ‘BDT’ is allowed.
String
O
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 32 of 45
Comprehensive sample request:
{
"applicationId":"APP_000010",
"password":"8f57d2e8de06e6f2d6ee5da6107d0a4f",
"subscriberId":"tel: 8801812345678",
"currency":"BDT",
"accountId":"8801812345678",
"paymentInstrumentName":"Mobile Account"
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 33 of 45
5.1.2 Response
Following are the response parameters of query balance service.
Parameter Name
Description
Type
M / O
accountType
Account type of the subscriber id.
E.g. Prepaid/Post paid for GSM domain.
Only a single set of elements can be sent per
request.
String
M
accountStatus
Account status of the subscriber ID
Only a single set of elements can be sent per
request
String
M
statusCode
Status of the operation.
Only a single set of elements can be sent per
request.
String
M
statusDetail
The textual description of the operation's
status.
Only a single set of elements can be sent per
request.
String
M
chargeableBalanc
e
Available chargeable balance of the subscriber.
Refers to either remaining account balance
(prepaid user) or the difference between credit
limit and outstanding bill (postpaid user).
Only a single value can be sent per request.
String
(rounded up to
two decimal
points)
M
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 34 of 45
Comprehensive sample response:
{
"statusCode":"S1000",
"chargeableBalance":"100",
"statusDetail":"Request was successfully processed",
"accountStatus":"0",
"accountType":"PREPAID"
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 35 of 45
5.2 Get Payment Instrument List
Get Payment Instrument List is to get a list of all the available payment instruments for a particular
subscriber. In the request, the payment instrument list can be specified; either asynchronous or
synchronous.
If the payment instrument type is not specified, the entire available payment instrument list will be
sent.
The URL for 'Get Payment Instrument List' service is as follows:
https://developer.bdapps.com/caas/list/pi
5.2.1 Request
Following are the request parameters of Get Payment Instrument List.
Parameter
Name
Description
Type
M / O
applicationId
appId of the application
String
M
password
Password of the application
String
M
subscriberId
This can be the MSISDN of the subscriber. This is a
unique identifier.
Tel: is for MSISDN
Subscriber: tel: 8801812345678
Note: tel might be a masked number depending
on the type of the application
String
M
type
Payment instrument type
Possible values:
- sync
- async
- all
(by default: all)
Enumerated
O
Comprehensive sample request:
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 36 of 45
{
"applicationId":"APP_000010",
"password":"8f57d2e8de06e6f2d6ee5da6107d0a4f",
"subscriberId":"tel: 8801812345678",
"type":"all"
}
5.2.2 Response
Following are the response parameters of Get Payment Instrument List.
Parameter Name
Description
Type
M / O
paymentInstrumentList
This is the list of payment instruments
configured to the subscriber. It should be as
follows.
E.g.,
[
{"name":"Mobile Account",
"type":"sync"},
]
- name : payment instrument name
- type: payment instrument type
String
M
(if the
request is
successful)
statusCode
Status of the operation
String
M
statusDetail
The textual description of the operation's
status
String
M
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 37 of 45
Comprehensive sample response:
{
"statusCode": "S1000",
"statusDetail": "Success",
"paymentInstrumentList": [
{
"name": "Mobile Account",
"type": "sync"
}
]
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 38 of 45
5.3 Direct Debit
This service charges a specific amount from a subscriber’s account.
The URL for Direct Debit service is as follows:
https://developer.bdapps.com/caas/direct/debit
5.3.1 Request
Following is a sample request for direct debit service.
{
"externalTrxId":"25609",
"amount":"5",
"applicationId":"APP_000010",
"password":"8f57d2e8de06e6f2d6ee5da6107d0a4f",
"subscriberId":"tel: 8801812345678",
"paymentInstrumentName":"Mobile Account"
}
Following are the request parameters of direct debit service.
Parameter Name
Description
Type
M /
O
applicationId
Used to identify the application. This is a
unique identifier generated by bd-apps when
provisioning an application.
Only a single value can be sent per request.
String(32)
M
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 39 of 45
password
Used to authenticate the application
originated message against the service
providers credentials.
Encoded, single value.
String(32)
M
externalTrxId
This is the transaction ID generated by the
application to map the request with the
response.
This is needed to avoid any conflicts when SP
inquires about a transaction.
Only a single value can be sent per request.
String(32)
M
subscriberId
This can be the MSISDN the subscriber to be
charged. This is a unique identifier.
Tel: is for MSISDN
Subscriber: tel: 8801812345678
Note: tel might be a masked number
depending on the type of the application
Only a single value can be sent per request.
String
M
paymentInstrumentName
The name of the payment instrument.
Only a single value can be sent per request.
Enumerator
M
accountId
The account of the payment instrument.
Only a single value can be sent per request.
String
O
amount
Amount to be reserved for charging.
Only a single value can be sent per request.
String
(rounded up
to two
decimal
points)
M
currency
The currency of the amount.
Only a single value can be sent per request.
Only ‘BDT’ is allowed.
String
O
Comprehensive sample request for direct debit service:
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 40 of 45
{
"externalTrxId":"25609",
"amount":"5",
"applicationId":"APP_000010",
"password":"8f57d2e8de06e6f2d6ee5da6107d0a4f",
"subscriberId":"tel: 8801812345678",
"currency":"BDT",
"accountId":"8801812345678",
"paymentInstrumentName":"Mobile Account"
}
5.3.2 Response
Following are the response parameters of direct debit service.
Parameter Name
Description
Type
M / O
externalTrxId
The transaction ID generated by the
application to map the request with the
response.
Only a single value can be sent per request.
String
M
internalTrxId
Internal Transaction ID generated by the
Payment Gateway for the transaction. This
is unique per transaction.
Only a single value can be sent per request.
String(32)
M
referenceId
Unique number generated by the system for
the payment request. This is required to be
entered in the external charging
system/menu.
8 digits
O
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 41 of 45
timeStamp
System date and time of success or failed
transaction.
Only a single value can be sent per request.
Date/Time string
in ISO-8601
format
e.g.'2011-08-
23T16:50:31.418
+05:30'
statusCode
Status of the operation.
Only a single set of elements can be sent
per request.
String
M
statusDetail
The textual description of the operation's
status.
Only a single set of elements can be sent
per request.
String
M
Comprehensive sample response:
{
"statusCode":"S1000",
"timeStamp":"2013-08-01T08:43:34.344+05:30",
"externalTrxId":"25609",
"statusDetail":"Request was successfully processed",
"internalTrxId":"913080108430074"
}
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 42 of 45
Appendix A
Status Codes and Error Codes
Status Codes (Non Retry-able)
Code
Description
S1000
Process completed successfully for all the available destination
numbers.
Error Codes (Non Retry-able)
Code
Description
E1313
Authentication failed. No such active application with applicationId
<application-id>, or no active service provider or the given password
in the request is invalid.
E1303
IP address from which this request originated is not provisioned to
send request to application <application-id>. Please use a
provisioned system to send request or contact system admin to
provision the new IP.
E1312
Request is Invalid. <specify_the_reason> Refer the BDApps API NBL
API Developer Guide for the mandatory fields and correct format of
the request.
E1309
Requested SMS service is not allowed for this Application. Please
check the issue with BDApps API system administrator.
E1311
Mobile terminated SMS messages have not enabled. Check your NCS
configuration in provisioning.
E1315
Cannot find the requested service SMS or it is not active.
E1317
<MSISDN> in request is invalid or not allowed.
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 43 of 45
E1328
Charging operation {operation} not allowed. Please check the NCS
configuration.
E1341
Request failed. Errors occurred while sending the request for all the
destinations.
E1334
SMS sent to <application name> application could not be processed
as the message length is too long. Maximum message length allowed
is <specify_max_limit>
E1335
SMS sent to <application name> application could not be processed
as the advertisement message length is too long. Maximum message
length allowed for advertisements is <specify_max_adv_limit>
E1337
Duplicate request.
E1601
System experienced an unexpected error.
E1342
MSISDN is black listed. Not authorized to use the application
<application_name>
E1343
MSISDN is not white listed. Only white list numbers are allowed to
send messages at this state.
E1325
Format of the address is invalid. Expected format is "tel:
8801812345678"
E1331
<sourceAddress> is not allowed. Please use one of the values
configured in alias configuration in the SLAs or send the request
without <sourceAddress>, so BDApps API will use the default source
address to send the message to subscriber.
E1308
Permanent charging error due <specify_reason E.g., Insufficient
Balance>.
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 44 of 45
Error Codes (Retry-able)
Code
Description
E1318
Transaction limit per second has exceeded. Please throttle requests
not to exceed the transaction limit. Contact BDApps API admin to
increase the traffic limit.
E1319
Transaction limit for today is exceeded. Please try again tomorrow or
contact BDApps API admin to increase the transaction per day limit
E1326
Insufficient balance.
E1602
Message delivery failed. Please retry
E1603
Temporary System Error occurred while delivering your request.
BDApps API Guide
© 2015 hSenid Mobile. All rights reserved Page 45 of 45
Appendix B
What follows is a list of definitions of all terms, acronyms and abbreviations required to properly
interpret this document.
NCS – Network Capability Service
SMS –Simple Message Service
HTTP – Hyper Text Transfer Protocol
MO – Mobile Originated
MT – Mobile Terminated
MSISDN – Mobile Station Integrated Services Digital Network
SLA – Service Level Agreement
