Replacement
Parts Guide
(Effective April 2014)
Model Page
Index
Model Page Model Page Model Page
325ILS (BEST) 36
326 (BEST) 36
326 REV A (BEST) 37
326 REV B (BEST) 37
340 (BEST) 37
341ILS (BEST) 38
40 (BEST) 35
41 (BEST) 36
94KE222 (BEST) 11
94ISE222 (BEST) 30
ACR3 40
AEIP 40
ALP 40
ALP REV B 40
ANKCP4536 39
ANKCP4742 39
ANKCP4748 39
ANKCP4760 39
ANKCP55 39
ANKIC34 39
ANKIF6 40
ANKU10 39
ANKUP 39
ANKUPXX2RSB 40
ANKWC23 39
ANKWC26 39
ANKWC345 40
ANKWC46 40
ANKWM24 39
ANKWPP9 40
ANKWPXX6RSB 40
ANKWPXX6SB 39
ANKWT32 39
ANKWTT320 40
ANKWTT326 40
ATDIP 40
B01IS (BEST) 23
B01K (BEST) 2
B02IS (BEST) 23
BER01IS (BEST) 24
BER01K (BEST) 2
BER02IS REV A (BEST) 24
BER02IS REV B (BEST) 24
Blower Wheels 41
Bulbs 41
CC34E6SB REV A (BEST) 2
CC34ESB REV A (BEST) 2
CC34IQSB (BEST) 2
CC34ISB REV A (BEST) 2
Charcoal Filters 40
CP34 (VENMAR) 22
CP35 (VENMAR) 22
CP37 REV A (VENMAR) 22
CP45I (VENMAR) 22
CP47I REV A (VENMAR) 22
CP47E REV A (VENMAR) 22
CP55IQ (VENMAR) 23
CP57E (VENMAR) 23
CP57IQT (VENMAR) 23
CPD (CHINA) 22
DD01 (HTF) 18
DDEX (HTF) 18
DD2M (BEST) 1
DD6 (BEST) 18
DD61 (BEST) 18
DD97 (BEST) 18
DDB5 1
DDM (BEST) 1
EB6 (HTF) 2
EB9 (HTF) 2
EB12 (HTF) 2
EB15 (HTF) 2
IBF4I (BEST @ ATLAN) 24
IC34E (BEST) 31
IC34IQ (BEST) 31
IC35I (BEST) 24
ICF6IQ (BEST) 31
IEX102 REV A (BEST) 25
IEX102 REV B (BEST) 25
IEX170 REV A (BEST) 25
IEX170 REV B (BEST) 25
IEX170 REV C (BEST) 25
IEX222 REV A (BEST) 25
IEX222 REV B (BEST) 26
IEX42 REV A (BEST) 24
IEX42 REV B (BEST) 25
ILB3 (HTF) 1
ILB6 (HTF) 1
ILB9 (HTF) 1
ILB11 (HTF) 1
IM32I (BEST) 26
IM33I REV A (BEST) 26
IM33I REV B (BEST) 26
IM42I (BEST) 26
IP29M REV A (VENMAR) 26
IP29M REV B (VENMAR) 26
IPB9E (BEST) 31
IPB9IQ (BEST) 31
IPP9E (BEST) 30
IPP9IQT (BEST) 30
IS1 (BEST) 27
IS2 (BEST) 27
IS4 (BEST) 27
IS102 REV A (BEST) 28
IS102 REV B (BEST) 28
IS11 (BEST) 27
IS170 REV A (BEST) 29
IS170 REV B (BEST) 29
IS170 REV C (BEST) 29
IS23 REV A (BEST) 27
IS23 REV B (BEST) 27
IS2304 (BEST) 30
IS32 (BEST) 27
IS41 (BEST) 27
IS41.1 (BEST) 27
IS42 (BEST) 28
IS42.1 REV A (BEST) 28
IS42.1 REV B (BEST) 28
IS502 REV A & B (BEST) 29
IS502 REV C (BEST) 29
ISE222 (BEST) 30
ISER222 REV A (BEST) 30
ISER222 REV B (BEST) 30
K1 (BEST) 3
K2 (BEST) 3
K11 (BEST) 3
K13 (BEST) 3
K142 (BEST) 8
K15 REV A (BEST) 3
K15 REV B (BEST) 3
K15 REV C (BEST) 3
K15 REV D (BEST) 4
K186L (BEST) 8
K21 (BEST) 4
K210A (VENMAR) 31
K210A REV B (VENMAR) 31
K210A REV C (VENMAR) 32
K210A REV D & E (VENMAR) 32
K23 (BEST) 4
K260 A-A (BEST) 32
K260 A-B (VENMAR) 32
K260 A-C (VENMAR) 32
K260 (Best) 32
K260A REV D (VENMAR) 33
K260A REV E (VENMAR) 33
K260A REV F (VENMAR) 33
K260D (VENMAR) 33
K271 (BEST) 8
K273 REV A (BEST) 9
K273 REV B (BEST) 9
K29 REV A (BEST) 4
K29 REV B (BEST) 4
K29 REV C (BEST) 4
K29 48” REV B (BEST) 4
K30 REV A (BEST) 5
K30 REV B (BEST) 5
K30 REV C (BEST) 5
K31 (BEST) 5
K3139 REV A (BEST) 9
K3139 REV B (BEST) 9
K3139 REV C (BEST) 9
K3139 REV D (BEST) 9
K34 REV A (BEST) 5
K34 REV B (BEST) 6
K34 REV C (BEST) 6
K34 REV D (BEST) 6
K3500 REV A & B (BEST) 10
K3500 REV C & D (BEST) 10
K4 (BEST) 3
K41 (BEST) 6
K41.1 REV A (BEST) 6
K41.1 REV B (BEST) 7
K41.1 REV C (BEST) 7
K42 (BEST) 7
K42.1 REV A (BEST) 7
K42.1 REV B (BEST) 8
K42.1 REV C (BEST) 8
K6 (BEST) 3
K61 (BEST) 3
K7388 REV A (BEST) 10
K7388 REV B (BEST) 10
K7788 (BEST) 10
K8087 (BEST) 10
K92 (BEST) 8
KE222 (BEST) 11
KER222 REV A (BEST) 11
KER222 REV B (BEST) 11
KEX222 REV A (BEST) 12
KEX222 REV B (BEST) 13
KEX273 REV A (BEST) 13
KEX273 REV B (BEST) 13
KEX30 REV A (BEST) 11
KEX30 REV B (BEST) 12
KEX30 REV C (BEST) 12
KEX3500 REV A (BEST) 13
KEX3500 REV B & C (BEST) 13
KEX42 REV A (BEST) 12
KEX42 REV B (BEST) 12
KEX42 REV C (BEST) 12
KEX7788 (BEST) 13
KEX8087 (BEST) 13
Light Lenses 41
Liners 40
Miscellaneous Parts 40
Motor Cross Reference 42
NDIS170 39
NDK3139 39
NDK7388 39
NDK7780 39
Outdoor hood covers 40
P1 (BEST) 1
P2 (BEST) 1
P12 (HTF) 1
P12D (HTF) 1
P191 (BEST) 18
P195 REV A (BEST) 18
P195 REV B (BEST) 19
P195 REV C (BEST) 19
P195ES (BEST Poland) 19
P195P REV A (BEST Poland) 19
P195P REV B 19
P195P1M52SB6 19
P195P1M70SB6 REV C 19
P5 (VENMAR) 1
P510 (BEST) 23
P511 (BEST) 20
P6 (HTF) 1
P8 (VENMAR) 1
P8D OUTDOOR (VENMAR) 1
PIK33 (VENMAR) 20
PIK33 REV B (VENMAR) 20
PIK33 REV C (VENMAR) 20
PIK33 REV D (VENMAR) 20
PIK33D (VENMAR) 20
PIK33D REV B (VENMAR) 20
PIK45 (VENMAR) 20
PIK45 REV B (VENMAR) 20
PIK45 REV C (VENMAR) 20
PIK45 REV D (VENMAR) 20
PK22 REV A (BEST) 21
PK22 REV B (BEST) 21
PK22 REV C (BEST) 21
PK22 REV D (BEST) 21
PK2230 (VENMAR) 23
PK2239 (VENMAR) 23
PK2245 (VENMAR) 23
PKEX22 REV A (BEST) 21
PKEX22 REV B (BEST) 21
PKEX22 REV C (BEST) 21
PKEX22 REV D (BEST) 22
PKEX2239 (VENMAR) 23
PKEX2245 (VENMAR) 23
REKIT41F 39
U102E (BEST) 38
U102I (BEST) 38
UP26M (VENMAR) 35
UP27E (VENMAR) 34
UP27I (VENMAR) 33
UP27M (VENMAR) 35
WBF4I (ATLAN) 16
WC23E (BEST) 13
WC23I (BEST) 14
WC26E (BEST) 14
WC26I (BEST) 14
WC33I REV A & B (BEST) 14
WC34E (BEST) 17
WC34I (BEST) 15
WC34IQ (BEST) 17
WC35E (BEST) 17
WC35I (BEST) 15
WC35IQ (BEST) 17
WC43I (BEST) 15
WC44E (BEST) 17
WC44IQ (BEST) 17
WC45E (BEST) 17
WC45IQ (BEST) 17
WC46E (BEST) 16
WC46IQ (BEST) 17
WCPI 40
WM24E (BEST) 14
WM24I (BEST) 15
WM33I (BEST) 15
WM34I REV A & B (BEST) 15
WM43I (BEST) 15
WM45I (BEST) 16
WP28M (VENMAR) 35
WP29M REV A (VENMAR) 34
WP29M REV B (VENMAR) 34
WPD28I (VENMAR) 34
WPD28I (VENMAR) 34
WPD29M (VENMAR) 35
WPD38I (VENMAR) 34
WPD39M (VENMAR) 35
WPP9E (BEST) 16
WPP9IQ (BEST) 16
WPP9IQT (BEST) 16
WT32I (VENMAR) 16
WTT32I (PACIFIC) 16
Model Page
Index
Model Page Model Page Model Page
NLA = no longer available; OBS = obsolete
DDB5
motor w/capacitor S99080362
motor mounting bracket S99100484
blower wheel S99020247
capacitor S99271000
DDM (BEST)
motor S02310044 (11-2012 NLA)
rubber motor mount SB03202007
(Rpl by SB03204177)
motor mounting bracket SE3400166 (NLA)
blower wheel SB02011091
capacitor S02300671
plastic gasket SB03202430
P1 & P2 (BEST)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor bracket SB02000314
rubber mounts SB03202007 (Rpl by SB03204177)
capacitor SB02300653
damper assembly/P1 SB080810111
damper assembly/P2 metal SB080810199
P5 (VENMAR)
motor SV01766
blower wheel SV03400
blower wheel ring SV01810
capacitor SV02160
motor grommet SV02001
motor mounting bracket SV11705
36” blower power cord SV03494
power cord SV03496
air deflector SV03500
damper SV13296
rough in plate SV12997
P6 (HTF)
redesign of this blower in August 2012. Below parts
are NLA. They need to order this kit: S97018851
complete blower assembly S97014156
motor S97011214
blower wheel S99020145
power cord S99440033
outlet box cover S98003370
complete rough in assembly S97014155
damper S97010792
P8 (VENMAR)
motor CW SV01766
motor CCW SV03457
blower wheel CW SV03400
blower wheel CCW SV03399
blower wheel ring SV01810
capacitor SV02160
motor grommet SV02001
motor mounting bracket SV11705
36” blower power cord SV03494
power cord SV03496
air deflector SV03500
damper 3 1/4 x 10 SV13296
damper 3 1/4 x 14 SV14971
rough in plate SV14975
U-clip part bag SV05805
P8D OUTDOOR (VENMAR)
capacitor--2 SV02160
motor CW SV06338
blower wheel CW SV03400
motor CCW SV06339
blower wheel CCW SV03399
cord SV06369
rough-in plate SV15443
air deflector SV03500
P12 (HTF)
new blower design starting in Jan. 2012. Below parts
are NLA. They need to order this kit: S97018834
motor S97011215
blower wheel CCW S99020121
blower wheel CW S99020122
scroll right S97002320
scroll left S97002321
power cord S99440033
outlet box cover S98003370
rough in assembly S97014161
P12D OUTDOOR BLOWER (HTF)
motor S99080572
blower wheel CCW S99020121
blower wheel CW S99020122
barrel nut S97016751
ILB3 (HTF)
mounting bracket (2 req) S97014728
damper assembly 8” S97014761
duct connector 8” S99390099
screw 8-18 x 1/4 (12 req) S99150415
wire box cover S98005513
strain relief bushing S99400035
wiring plate S98005512
ground screw 10-32 x 1/2 (2 req) S99150471
inlet ring S98009399
blower wheel S99020273
motor S99080485
lock nut 8-32 (4 req) S99260558
washer (4 req) S99250959
grommet (4 req) S99100491
blower assembly S97016792
nut 1/4-20 (6 req) S99260477
wire harness S97006039
access panel S98009417
cover nut (2 req) S99420470
cover mounting screw (2 req) S99150472
screw 10-16 x 7/8 (4 req) S99150591
hanger kit S97016791
transition 8-10” round S414
rough-in kit S97014597
ILB6 (HTF)
mounting bracket (2 req) S97014728
duct connector (2 req) S98009449
damper flap assembly (2 req) S97014822
screw 8-18 x 1/4 (18 req) S99150415
wiring plate S98005512
ground screw 10-32 x 1/2 (2 req) S99150471
wire box cover S98005513
strain relief bushing S99400035
wire harness S97006039
nut 1/4-20 (12 req) S99260477
blower wheel (2 req) S99020273
inlet ring (2 req) S98009399
motor S99080488
motor mounting bracket S97014794
rubber isolator (4 req) S99100497
screw 10-24 x 78 (4 req) S99160380
washer (4 req) S99250399
hex nut 10-24 (4 req) S99260306 (OBS)
washer (4 req) S99250254
hex flange nut 3/8-16 S93260456
blower assembly S97016793
assess panel S98009464
access panel nut (4 req) S99420470
access panel mounting screw (4 req) S99150472
screw 10-16 x 7/8 (4 req) S99150591
hanger kit S97016791
transition 4.5 x 18” to 10” round S423
rough-in kit S97014597
ILB9 & ILB11 (HTF)
damper flap S97014853
screw #8B x 1/4 (16 req) S99150415
duct connector (2 req) S98009520
mounting bracket (2 req) S97014728
mounting screw (4 req) S99150591
wiring harness S97006142
ground screw #10-32 x 1/2 (2 req) S99150471
wiring adapter plate S98005512
access panel nut (4 req) S99420470
screw #10-24 x .375 (8 req) S93150487
outlet box cover S98005513
strain relief bushing S99400035
motor bracket S97014788
whiz nut 1/4-20 (11 req) S99260477
screw 1/4-20 x 1/2 (5 req) S99200202
motor----ILB9 S99080490
motor----ILB11 S99080491
hex flange nut 5/16-18 (5 req) S93260447
blower wheel S99020286
inlet ring S98009514
screw #8-18 x 1/4 (5 req) S99150417
blower assembly ILB9 S97016794
blower assembly ILB11 S97016795
access cover S98009532
access cover screw (4 req) S99150472
hanger kit S97016791
transition 8” x 12” to 10” rnd male (1 req) S99610015
transition 8” x 12” to 10” rnd female (1 req) S99610028
rough-in kit S97014597
DD2M (BEST)
motor S02310046
wheel SB02011091
motor bracket SE3400166 (NLA)
capacitor S02300671
rubber mounts SB03202007 (Rpl by SB03204177)
damper SBE3400161
Blowers
1
NLA = no longer available; OBS = obsolete
EB6 & EB9 (HTF)
motor w/capacitor EB6 S99080397
motor w/capacitor EB9 S99080396
blower wheel EB6 S99020264
blower wheel EB9 S99020263
capacitor S99271110
damper spring S99140145
damper S98008507
rubber motor isolator (qty 3) S99100484
bird screen S98008511
rough-in kit S97014597
EB12 & EB15 (HTF)
motor & wheel assembly EB12* S99080478
motor & wheel assembly EB15* S99080479
(rpl by S97017160)
wire assembly EB12 S99271222
wire assembly EB15 S99271221 (rpl by S99271222)
capacitor S97015531
terminal rubber boot S99100530
motor support EB12 S98009430
motor support EB15 S98009539
bird screen/grille EB12 S97016229
bird screen/grille EB15 S98009537
damper flap EB12 (qty 2) S98009497
damper flap EB15 (qty 2) S98009541
damper spring (qty 2) S99140145
foam seal EB12 S99100532
foam seal EB15 S99100531
top cover EB12 S98009429
top cover EB15 S98009538
rough-in kit S97014597
* wheel is not available as a separate part. Must order
motor & wheel assembly
CC34ESB REV A (BEST)
OBSOLETE UNIT
frame SB08092793
grease filter SB08087804
wires SB02300995
wires SB02300999
lower support frame SBE3404989
upper support frame SB08092997
control board SB08080864
ring nut SB02011389
main switch SB02300907
display visor spring SB02011421
LED bulb SB02300885
switch assembly SB06103842
remote control SB08999140
damper/duct connector SB08092501
hardware package SB080810962
CC34E6SB REV A (BEST)
frame SB08092793
grease filter SB08087804
wires SB02300995
wires SB02300999
lower support frame SBE3404989
upper support frame SB08092997
control board SB08080869
ring nut SB02011389
main switch SB02300907
display visor spring SB02011421
LED bulb SB02300885
switch assembly SB06103842
remote control SB08999140
damper/duct connector SB08092501
hardware package SB080810962
CC34ISB REV A (BEST)
OBSOLETE UNIT
frame SB080892793
grease filter SB08087804
capacitor with wires SB06102535
transformer SB02300998
wires SB02300995
damper duct connector SB08088378
lower support frame SB08092796
upper support frame SB08092797
control board SB08080865
ring nut SB02011389
display visor spring SB02011421
LED light SB02300885
blower assembly SB06002080
motor SB02310260
blower wheel SB03295071
switch assembly SB06103842
remote control SB08999140
hardware package SB080810962
CC34IQSB (BEST)
blower assembly SB06002259
BLDC driver S97019431
wires SB06102601
electrical installation assembly SB06145222
wires SB06102598
upper skeleton SB08092797
bottom skeleton SBE3404965
calibration button assembly SB06102584
LED light SB02300885
light ring nut SB02011389
switch assembly SB06102585
door SB08093076
hinge SB02011378
display visor spring SB02011421
grease filter SB08087804
damper/duct connector SB08092501
remote control SB08999166
hardware package SB080810994
B01K (BEST) OBSOLETE UNIT
blower assembly NLA
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
capacitor SB02300653
resistor S02300654
control board S08086109
switch assembly S06104602 (NLA)
knob (cylindrical) S03202183 (NLA)
knob (conical) S03202223 (NLA 12-31-13)
knob cover grey S03202224
indicator lens S03200793
micro switch SB02300620
transformer SB02300670
lamp socket S02300667
socket insulator S03202164
lamp protector SB03292296
bulb MR16 20 Watt---qty 2 SB02300774
grille spring---qty 2 SB020002340
grille/filter 11”x15-3/4” SB08088750
damper duct connector SB080810111
flue gasket black--qty 2 SB03202430
glass gasket clear SB03204094
wall gasket clear SB03204095
logo silver S03202159
logo black SB03202436
logo white SB03202437
Flues
upper SS SBE3338711
lower SS S003181767
fuse SB02300782
BER01K (BEST) OBS 11-2002
grille/filter 11” x 15-3/4” SB08088750
charcoal filter SB03300424
capacitor SB06106272
bulb MR16 20 Watt---qty 2 SB02300774
motor SB02310094
blower wheel SB03295076
rubber washer SB03202007 (Rpl by SB03204177)
damper/duct connector SB080810111
blower protection SE3334545
plastic gasket (qty 2) SB03202430
glass gasket SB03204094
logo (adhesive black w/silver letters)** SB08091852
logo black SB03202436
logo white SB03202437
Flues
lower SS SB003182144
upper SS SBE3338711
flue mounting bracket SBE3334555
glass bracket front SBE3334547
glass bracket left SBE3334553 (NLA)
glass bracket right SE3334552 (NLA)
control board SB08080602 (11-2012 NLA)
light socket SB02300727
bulb protection SB03292296
transformer SB02300739
switch button SB03202296
bulb support SBE3342289
blower assembly SB06001801
switch assembly SB06106380
parts bag/glass mtg hardware SB080810236
(includes: protection SB03204095, front glass bracket
SBE3334547, right glass bracket SE3334552, left
glass bracket SBE3334553, ceiling flue bracket
SBE3334555)
recirculating kit* SB08820164 (NLA)
*special order--contains vented upper flue & charcoal
filters. 16-20 week lead time
**new logo can replace old style
Blowers / Ceiling Hoods / Chimney Hoods
2
NLA = no longer available; OBS = obsolete
K1 & K2 (BEST) OBSOLETE UNIT
motor S02310010
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
capacitor S02300581
resistor S02300631
switch assembly white S06109822
switch assembly black SB06109827
control board S08086092 (NLA)
lamp holder S02300627
light lens S03200725
filter 9-3/16” x 12-1/2” plastic finger well S08087390
logo S03202159
K4 (BEST) OBSOLETE UNIT
motor S02310010 (NLA)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314 (NLA)
capacitor S02300581 (NLA)
resistor S02300631 (NLA)
switch assembly white S06104191 (NLA)
switch assembly black S06104162 (NLA)
switch assembly high temperature black SB06106502
RPL BY SB06107552
control board S08086092 (NLA)
lamp holder S02300627 (NLA)
light lens S03200725
filter 9-3/16”x12-1/2” plastic finger well S08087390
logo S03202159
K6 & K61 (BEST) OBSOLETE UNIT
blower assembly NLA
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB023000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
capacitor SB02300653
resistor S02300654
switch assembly white S06104118 (NLA)
switch assembly black OBS
control board S08086096 (OBS 11-2013)
logo S03202159
tube holder K61 S02300521
starter/tube holder K61 S02300522
starter K61 S02300659
ballast K61 S02300657
fluorescent tube K61 S02300500
light lens S03200725
right grille latch S05000050
left grille latch S05000051
filter S08087716
filter retainer S02000276
damper/duct connector SB080810111
K11 (BEST) OBSOLETE UNIT
blower assembly NLA
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
damper/duct connector SB080810111
capacitor SB02300653
resistor S02300654
switch assembly white S06109994 (NLA)
switch assembly black S06109998
control board S08086096 (OBS 11-2013)
lamp holder S02300521
lamp/starter holder S02300522
starter S02300659
ballast S02300657
fluorescent lamp S02300500
light lens S03200725
filter (req 3) 9-3/16”x12-1/2” plastic finger well
S08087390
logo S03202159
upper flue SS SE3338285 (NLA)
upper flue Brass SE3338183
lower flue SS SE3338280 (NLA)
lower flue Brass SE3337994
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws &
drywall anchors)
K13 (BEST) OBSOLETE UNIT
blower assembly S06001534 (NLA 9-2012)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mounts SB03202007 (Rpl by
SB03204177)
damper/duct connector SB080810111
switch assembly white S06104465
switch assembly black S06104498
control board S08086096 (OBS 11-2013)
capacitor SB02300653
resistor S02300654
ballast S02300657
fluorescent tube holder S02300521
fluorescent tube/starter holder S02300522
fluorescent tube S02300500
lens S03200725
starter S02300659
logo white SB03202437
logo black SB03202436
ceiling bracket SE3334416
upper flue SS SE3407417
upper flue BL SB03108747 (NLA)
lower flue SS SE33383310 (NLA)
lower flue BL SB03108606 (NLA)
filter spring SB02000191
filter left filter is 5 sided S08087376
filter center 11-3/4”x11-3/4” plastic finger well
S08087399
filter right filter is 5 sided S08087377
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws &
drywall anchors)
K15 REV A (BEST)
logo SB03202436
blower assembly SB06001768
motor SB02310094
blower wheel SB03295076
switch assembly SB06106381
control board SB08080101
transformer SB02300739
capacitor SB06106272
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
damper/duct connector SB080810111
halogen bulb Type JC 12 volt 20 watt G4 base
SB02300891
rail SB02009106
filter (req 2) 9-3/16” x 12-13/16” slide latch
SB08087248
upper flue SBE3341071
lower flue SBE3341061
flue mounting bracket SE3334416
hardware package S080810054
(includes flue mounting bracket, wall mtg brackets,
installation screws, drywall anchors)
K15 REV B Heat Sentry Oct 2002
(BEST)
blower assembly SB06002017
motor SB02310201
blower wheel SB03295071
switch assembly SB06107642
control board SB08086668
transformer SB02300783
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
capacitor SB06107677
damper/duct connector SB080810111
halogen bulb Type JC 12 volt 20 watt G4 base
SB02300891
rail SB02009106
filter (req 2) flip latch 9-1/4”x12-3/4” SB08087163
upper flue SBE3341071
lower flue SBE3341061
heat sentry SB02300787
flue mtg bracket SE3334416
fuse SB02300782
hardware package S080810054
(includes flue mounting bracket, wall mtg brackets,
installation screws, drywall anchors)
K15 REV C Flue change April 2005
(BEST)
filter (req 2) flip latch 9-1/4” x 12-3/4” SB08087163
capacitor SB02300233
halogen bulb Type JC 12 volt 20 watt G4 base
SB02300891
heat sentry SB02300787
motor SB02310201
blower wheel SB03295071
damper/duct connector SB080810111
lower flue SBE3348119
upper flue SBE3348120
flue mtg bracket SE3334416
rail SB02009106
control board SB08086668
transformer SB02300783
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
switch assembly SB06107642
blower assembly SB06002017
fuse SB02300782
hardware package SB080810712
(ceiling flue bracket (solid metal), wall mtg brackets,
installation screws & drywall anchors)
Chimney Hoods
3
NLA = no longer available; OBS = obsolete
K15 REV D (BEST) Changed Trans-
former Nov 2008 OBS 9-2012
filter (req 2) flip latch 9-1/4” x 12-3/4” SB08087163
capacitor SB02300233
halogen bulb Type JC 12 volt 20 watt G4 base
SB02300891
heat sentry SB02300787
motor SB02310201
blower wheel SB03295071
damper/duct connector SB080810111
lower flue SBE3348119
upper flue SBE3348120
flue mtg bracket SE3334416
rail SB02009106
control board SB08086668
transformer SB02300861
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
switch assembly SB06107642
blower assembly SB06002017
fuse SB02300782
hardware package SB080810712
(ceiling flue bracket (solid metal), wall mtg brackets,
installation screws & drywall anchors)
K21 (BEST) OBSOLETE UNIT
same as K11 for all functional parts
K23 (BEST) OBS 11-2002
blower assembly SB06001333 (NLA) 3-2012
motor S02310010
blower wheel SB03295089 (NLA 7-2012)
motor bracket SB02000314
rubber mounts SB03202007 (Rpl by SB03204177)
duct connector (no flaps) SB03292283
damper flaps SB02000756
ductfree diverter SB08089123
switch assembly S06104943 (NLA--6-27-13)
switch button (one per pack) SB03200361
button extender SB03292301
capacitor S02300581
resistor S02300631
control board SB08080101
ballast/lamp holder S02300701
fluorescent tube S02300700
light lens (3 1/8” x 11 7/8”) SB03201016
light lens (1 7/8” x 15 3/16”) SB03200797
red indicator lens SB03201014
logo white SB03202437
logo black SB03202436
filter spring SB02000191
Flues:
upper SS SE3341627
upper WH S031170342 (NLA)
upper BL SB03114034
lower SS SE3341001
lower WH S31170062 (NLA)
lower BL SB03114006
Filters: finger well
30” (requires 2) 9 1/4” x 12 1/2” S08087490
30” (requires 1) 6 5/8” x 12 1/2” S08087444
42” (requires 3) 11 1/8” 12 1/2” S08087394
90 cm (requires 3) 9 1/4” x 12 1/2” S08087490
ductfree filter SB03300498
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws &
drywall anchors)
ceiling bracket SB03292293
(customer may have ceiling bracket part #BE3292118
--just order the one I have listed)
K29 REV A (BEST)
filter spring SB02000191
Filters finger well
90cm (req 3) 9-3/16”x12-9/16” SB08087303
(RPL By S08087490)
48” (req 4) 9-3/16”x12-9/16” SB08087303
(RPL By S08087490)
filter finger tab grey round front SB03292425
filter finger tab grey round back SB03292426
Charcoal filter for 90cm SB08999740
Charcoal filter for 48” SB08999741
capacitor SB06106247
halogen bulb Type JC 12 volt 20 watt G4 base
SB02300891
motor SB02310094
blower wheel SB03295076
rubber washer SB03202007 (Rpl by SB03204177)
damper/duct connector SB080810111
black logo SB03202436
white logo SB03202437
lower flue SS SBE3342581
lower flue BL SB03114357 (NLA)
lower flue WH SB03117682 (NLA)
upper flue SS SBE3342582
upper flue BL SB03114358
upper flue WH SB03117683 (NLA)
flue mounting bracket SB03202118 (RPL By
SB03292293)
control board SB08080101
Transformer for 90cm SB02300717
Transformer for 48” SB02300729
switch button SB03200351
red indicator lens SB03201014
button extender SB03292301
light housing/socket (includes lens) SB02300719
blower assembly SB06001763
Switch assembly
90cm SB06106259 (3-4-13 NLA)
48” SB06106255 (3-11-14 NLA)
hardware package SB08081189
(ceiling flue bracket (solid plastic), wall mtg brackets,
installation screws & drywall anchors
K29 REV B Heat Sentry Nov 2002
(BEST)
Filter flip latch
90cm (req 3) 9-1/4”X12-3/4” SB08087163
48” (req 4) 9-1/4”X12-3/4” SB08087163
Charcoal filter for 90cm SB08999740
Charcoal filter for 48” SB08999741
capacitor SB02300233
halogen bulb Type JC 12v 20 watt G4 SB02300891
motor SB02310201
blower wheel SB03295071
rubber washer SB03202007 (Rpl by SB03204177)
damper/duct connector (plastic) SB080810111
damper/duct connector (metal) Sept 2007
SB08092518
logo (adhesive silver) SB02011284 (RPL by SV05869)
lower flue SS SBE3342581
lower flue BL SB03114357 (NLA)
lower flue WH SB03117682 (NLA)
upper flue SS SBE3342582
upper flue BL SB03114358
upper flue WH SB03117683 (NLA)
flue mounting bracket SB03292293
control board SB08086668
Transformer for 90cm SB02300783
Transformer for 48” SB02300792
heat sentry SB02300787
fuse SB02300782
fuse holder SB02300674
switch button SB03200351
red indicator light SB03201014
button extender SB03292301
light housing/socket (includes lens) SB02300719
blower assembly SB06002017
Switch assembly for 90cm SB06107657
Switch assembly for 48” SB06107657
hardware package SB08081189
(ceiling flue bracket (solid plastic), wall mtg brackets,
installation screws & drywall anchors
K29 REV C (BEST) Changed Trans-
former Nov 2008 (Note: K29 48” is
still at REV B) OBS 9-2012
Filter flip latch
90cm (requires 3) 9-1/4”X12-3/4” SB08087163
48” (requires 4) 9-1/4”X12-3/4” SB08087163
Charcoal filter
90cm SB08999740
48” SB08999741
capacitor SB02300233
halogen bulb Type JC 12v 20 watt G4 SB02300891
motor SB02310201
blower wheel SB03295071
rubber washer SB03202007 (Rpl by SB03204177)
damper/duct connector (plastic) SB080810111
damper/duct connector (metal) Sept 2007
SB08092518
logo (adhesive silver) SB02011284 (RPL by SV05869)
lower flue SS SBE3342581
lower flue BL SB03114357 (NLA)
lower flue WH SB03117682 (NLA)
upper flue SS SBE3342582
upper flue BL SB03114358
upper flue WH SB03117683 (NLA)
flue mounting bracket SB03292293
control board SB08086668
Transformer
90cm (changed 11-16-2008) SB02300861
48” (changed 9-30-2010) SB02300729
heat sentry SB02300787
fuse SB02300782
fuse holder SB02300674
switch button SB03200351
red indicator light SB03201014
button extender SB03292301
Chimney Hoods
4
NLA = no longer available; OBS = obsolete
light housing/socket (includes lens) SB02300719
blower assembly SB06002017
Switch assembly for 90cm SB06107657
Switch assembly for 48” SB06107657
hardware package SB08081189
(ceiling flue bracket (solid plastic), wall mtg brackets,
installation screws & drywall anchors
K30 REV A (BEST)
logo SB03202436
damper/duct connector SB080810111
blower assembly SB06001987
motor SB02310186
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
capacitor SB02300233
transformer SB02300783
transformer 48” SB02300792
socket support SB02009103
socket base SB02300688
socket reflector SB02009193
switch assembly SB06107333
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
Filters finger well
90cm (req 2) 11-11/16”x11-11/16” SB08087296
48” (req 3) 11-11/16”x11-11/16” SB08087296
upper flue SS SBE3345044
lower flue SS SBE3333768
control board SB08086661
fuse SB02300782
fuse holder SB02300674
power cord SB02300249
flue mounting bracket SB08091367
filter spring SB02000191
hardware package SB080810495
(ceiling flue bracket, wall mtg bracket, installation
screws & drywall anchors)
K30 REV B Heat Sentry April 2003
(BEST)
logo (adhesive black w/silver letters) SB08091852
damper/duct connector SB080810111
blower assembly SB06002019
motor SB02310201
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
capacitor SB02300233
transformer SB02300783
transformer SB02300792
socket support SB02009103
socket base SB02300688
socket reflector SB02009193
switch assembly SB06107333
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
Filters finger well
90cm (req 2) 11-11/16”x11-11/16” SB08087296
48” (req 3) 11-11/16”x11-11/16” SB08087296
upper flue SS SBE3345044
lower flue SS SBE3333768
heat sentry SB02300787
control board SB08086662
fuse SB02300782
fuse holder SB02300674
power cord SB02300249
flue mounting bracket SB08091367
filter spring SB02000191
hardware package SB080810495
(ceiling flue bracket, wall mtg bracket, installation screws
& drywall anchors)
K30 REV C Flip Latch Filter Sept
2004 (BEST) OBS JAN 2014
logo (adhesive silver) SB02011284 (RPL by SV05869)
damper/duct connector (plastic) SB080810111
damper/duct connector (metal) Sept 2007
SB08092518
blower assembly SB06002019
motor SB02310184
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
capacitor SB02300233
transformer 90 cm SB02300783
after Oct-11-2010 use SB02300739
transformer 48” 48” SB02300792
after Sept-30-2010 use SB02300729
socket support SB02009103
socket base SB02300688
socket reflector SB02009193
switch assembly SB06107333
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
Filters flip latch
90cm (req 2) 11-3/4”x12-1/8” SB08087018
48” (req 3) 11-3/4”x12-1/8” SB08087018
upper flue SS SBE3347629
lower flue SS SBE3347628
heat sentry SB02300787
control board SB08086662
fuse SB02300782
fuse holder SB02300674
power cord SB02300249
flue mounting bracket SB08091367
hardware package SB080810495
(ceiling flue bracket, wall mtg bracket, installation screws
& drywall anchors)
K31 (BEST) OBSOLETE UNIT
blower assembly S06001534 (NLA 9-2012)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
rubber motor mount SB03202007
(Rpl by SB03204177)
motor mounting bracket SB02000314
logo S03202159
capacitor SB02300653
resistor S02300654
control board S08086096 (OBS 11-2013)
switch assembly white S06104161
switch assembly black S06109998
switch assembly high temperature black SB06106502
RPL BY SB06107552
tube holder S02300521
starter/tube holder S02300522
starter S02300659
ballast S02300657
filter spring SB02000191
fluorescent tube S02300500
light lens S03200725
filter 30” (req 2) finger well 11-1/8”x12-1/2” S08087394
filter 90 cm (req 3) finger well 9-3/16”x12-1/2”
S08087390
filter 42” (req 4) finger well 9-3/16”x12-1/2” S08087390
filter 48” (req 4) finger well 9-3/16”x12-1/2”
S08087390
upper flue SS SE3495301 (NLA)
lower flue SS SE3338211 (NLA)
K34 REV A (BEST)
blower assembly SB06001761
motor SB02310094
wheel SB03295076
motor mounting rubber SB03202007 (Rpl by
SB03204177)
capacitor SB02300730
damper/duct connector SB080810111
control board SB08080101
Switch assembly
90 cm SB06106257 OBS 5-3-13
48” SB06106257 OBS 5-3-13
switch button (one per pack) SB03200361 (flat)
button extender SB03292301
red indicator lens SB03201014
Transformer for 90 cm SB02300717
Transformer for 48” SB02300729
lamp housing/socket (includes lens) Customer could
have any one of the four part numbers listed. Best made
changes without notifying us. See four choices below:
(rectangular) SB02300719
(round shiny raised bezel w/bulb) SB02300736
(bezel, lens & bulb) SB02300790
(round flat bezel brushed finish) SB02300791
halogen bulb Type JC 12v 20 watt G4 SB02300891
black Logo SB03202436
white Logo SB03202437
upper SS Flue SBE3342449
lower SS Flue SB003181790
upper WH Flue SB03117361
lower WH Flue SB003181793
upper BL Flue SB03114353
lower BL Flue SB003181794
flue mounting bracket SBE3333698
filter spring SB02000191
filter (req 3) 9-3/16”x12-9/16” finger well SB08087303
(RPL By S08087490)
filter (req 3) slide latch 9-3/16”x12-13/16” SB08087248
filter finger tab grey round front SB03292425
filter finger tab grey round back SB03292426
ductfree diverter SB08091211
Charcoal filter for 90 cm SB08999740
Charcoal filter for 48” SB08999741
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws & drywall
anchors)
Chimney Hoods
5
NLA = no longer available; OBS = obsolete
K34 REV B Heat Sentry Nov 2002
(BEST)
blower assembly SB06002017
motor SB02310201
wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
capacitor SB02300233
damper/duct connector SB080810111
control board SB08086668
Switch assembly for 90 cm SB06107665**
Switch assembly 48” SB06107668
heat sentry SB02300787
switch button SB03200376
button extender SB03292301
red indicator lens SB03201014
Transformer for 90 cm SB02300783
Transformer for 48” SB02300792
fuse SB02300782
fuse holder SB02300674
lamp housing/socket (includes lens) SB02300791
(round)
halogen bulb Type JC 12v 20 watt G4 SB02300891
black Logo SB03202436
white Logo SB03202437
upper SS Flue SBE3342449
lower SS Flue SB003181790
upper WH Flue SB03117361
lower WH Flue SB003181793
upper BL Flue SB03114353
lower BL Flue SB003181794
flue mounting bracket SBE3333698
filter (req 3) flip latch 9-1/4”x12-3/4” SB08087163
ductfree diverter SB08091211
Charcoal filter for 90 cm SB08999740
Charcoal filter for 48” SB08999741
hardware package SB080810533
(ceiling flue bracket (solid metal), damper duct con-
nector, wall mtg brackets, installation screws & drywall
anchors)
** For 90 cm unit you can use the switch assembly
from the 48” unit. Part number SB06107668
K34 REV C Flue redesign Sept
2004 (BEST)
blower assembly SB06002017
motor SB02310201
blower wheel SB03295071
motor mounting bracket SB03202007 (Rpl by
SB03204177)
capacitor SB02300233
damper/duct connector (plastic) SB080810111
damper/duct connector (metal) Sept 2007
SB08092518
control board SB08086668
Switch assembly
90 cm SB06107665**
48” SB06107668
heat sentry SB02300787
switch button SB03200376
button extender SB03292301
red indicator lens SB03201014
Transformer for 90 cm SB02300783
Transformer for 48” SB02300792
fuse SB02300782
fuse holder SB02300674
lamp housing/socket - round (incl lens) SB02300791
halogen bulb Type JC 12v 12 watt G4 SB02300891
logo (adhesive silver) SB02011284 (RPL by SV05869)
Flues
upper SS SBE3347625
lower SS (no logo---order separately) SBE3347624
upper WH SB03118874
lower WH (no logo---order separately) SB03118873
upper BL SB03114958
lower BL (no logo---order separately) SB03114957
flue mounting bracket SBE3333698
filter (req 3) flip latch 9-1/4”x12-3/4” SB08087163
ductfree diverter SB08091211
Charcoal filter for 90 cm SB08999740
Charcoal filter for 48” SB08999741
hardware package SB080810533
(ceiling flue bracket (solid metal), damper duct con-
nector, wall mtg brackets, installation screws & drywall
anchors)
** For 90 cm unit you can use the switch assembly
from the 48” unit. Part number SB06107668
K34 REV D (BEST) Changed Trans-
former Nov 2008
blower assembly SB06002017
motor SB02310201
blower wheel SB03295071
motor mounting bracket SB03202007 (Rpl by
SB03204177)
capacitor SB02300233
damper/duct connector (plastic) SB080810111
damper/duct connector (metal) Sept 2007
SB08092518
control board SB08086668
Switch assembly for 90 cm SB06107665
heat sentry SB02300787
switch button SB03200376
button extender SB03292301
red indicator lens SB03201014
Transformer
90 cm changed Nov-16-2008 SB02300861
fuse SB02300782
fuse holder SB02300674
lamp housing/socket - round (incl lens) SB02300791
halogen bulb Type JC 12v 12 watt G4 SB02300891
logo (adhesive silver) SB02011284 (RPL by SV05869)
Flues
upper SS SBE3347625
lower SS (no logo---order separately) SBE3347624
upper WH SB03118874
lower WH (no logo---order separately) SB03118873
upper BL SB03114958
lower BL (no logo---order separately) SB03114957
flue mounting bracket SBE3333698
filter (req 3) flip latch 9-1/4”x12-3/4” SB08087163
ductfree diverter SB08091211
Charcoal filter for 90 cm SB08999740
hardware package (ceiling flue bracket (solid metal),
damper duct connector, wall mtg brackets, installation
screws & drywall anchors) SB080810533
K41 (Fluorescent bulb) (BEST)
OBSOLETE UNIT
damper/duct connector SB080810111
blower assembly S06001523 (NLA 2-2012)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295076
motor mtg rubber SB03202007 (Rpl by SB03204177)
capacitor SB02300653
resistor S02300654
fluorescent bulb holder S02300521
fluorescent bulb holder w/starter S02300522
fluorescent starter S02300659
ballast S02300657
control board S08086096 (OBS 11-2013)
switch assembly SB06105067
logo (adhesive black w/silver letters) SB08091852
filter spring SB02000191
fluorescent bulb S02300500
light lens S03200725
lower flue SE3338410 (NLA)
upper flue SE3338411 (NLA)
Filters finger well
30” (req. 2) 9-3/16”x12-1/2” S08087390
36” (req. 3) 9-3/16”x12-1/2” S08087390
42” (req. 4) 9-3/16” x 12-1/2” S08087390
48” (req. 4) 9-3/16” x 12-1/2” S08087390
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws & drywall
anchors)
K41.1 REV A (BEST)
damper/duct connector SB080810111
blower assembly S06001523 (NLA 2-2012)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295076
motor mounting rubber SB03202007 (Rpl by
SB03204177)
capacitor SB02300653
resistor S02300654
socket support SB02009103
socket base SB02300688
transformer SB02300670
control board S08086096 (OBS 11-2013)
Switch assembly white SB06105067
Switch assembly black SB06105117
logo SB03202436
filter spring SB02000191
halogen bulb SB02300774
bezel SB02009102
SS Lower flue SBE3341301
WH Lower flue S031170302
BL Lower flue S03114035
BRASS Lower flue SE3341312
COPPER Lower flue SB03159000
SS Upper flue SBE3341311
WH Upper flue S031170312
BL Upper flue S03114036
BRASS Upper flue SE3341313
COPPER Upper flue SB03159001
Filter finger well
30” (qty 2) 11-1/8”x12-1/2” S08087394
36” (qty 3) 9-3/16”x12-1/2” S08087390
upper flue mtg bracket SBE3300517
Chimney Hoods
6
NLA = no longer available; OBS = obsolete
fuse SB02300782
fuse holder SB02300674
charcoal filter SB03300498
30” SS Front trim SB003180331
36” SS Front trim SB003180037
48” SS Front trim SB003180101 (NLA)
90cm SS Front trim SB003181964 (NLA)
30” WH Front trim SB003180332
36” WH Front trim SB003180038
90cm WH Front trim SB003181965 (NLA)
30” BL Front trim SB003180333 (NLA)
36” BL Front trim SB003180036 (NLA)
90cm BL Front trim SB003181966 (NLA)
30” COPPER Front trim SB003180474 (NLA)
36” COPPER Front trim SB03159003 (NLA)
90cm COPPER Front trim SB003181968 (NLA)
30” BRASS Front trim SB003180360 (NLA)
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws & drywall
anchors) NOTE: Front trims not listed can be ordered
from Best. Contact Technical Support.
K41.1 REV B Heat Sentry Sept 2002
(BEST)
damper/duct connector (plastic) SB080810111
damper/duct connector (metal) Sept 2007
SB08092518
blower assembly SB06002012
motor SB02310201
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
capacitor SB02300233
socket support SB02009103
socket base SB02300688
transformer SB02300783
control board SB08086668
Switch assembly black SB06107628
logo (adhesive silver) SB02011284 (RPL by SV05869)
halogen bulb SB02300774
bezel SB02009102
heat sentry SB02300787
SS Lower flue SBE3341301
BL Lower flue S03114035
WH Lower flue S031170302
CP Lower flue SB03159000
BR Lower flue SE3341312
SS Upper flue SBE3341311
BL Upper flue S03114036
WH Upper flue S031170312
CP Upper flue SB03159001
BR Upper flue SE3341313
Filter flip latch
30” (qty 2) 9-1/4”x12-3/4” SB08087163
36” (qty 3) 9-1/4”x12-3/4” SB08087163
upper flue mtg bracket SBE3300517
fuse SB02300782
fuse holder SB02300674
charcoal filter SB03300498
30” SS Front trim SB003180331
36” SS Front trim SB003180037
30” BL Front trim SB003180333 (NLA)
36” BL Front trim SB003180036 (NLA)
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws & drywall
anchors)
NOTE: Front trims not listed can be ordered from Best.
Contact Technical Support.
K41.1 REV C (BEST) Changed
Transformer Nov 2008 - OBS 01/14
damper/duct connector (plastic) SB080810111
damper/duct connector (metal) Sept 2007
SB08092518
blower assembly SB06002012
motor SB02310201
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
capacitor SB02300233
socket support SB02009103
socket base SB02300688
transformer SB02300861
control board SB08086668
Switch assemly black SB06107628
logo (adhesive silver) SB02011284 (RPL by SV05869)
halogen bulb SB02300774
bezel SB02009102
heat sentry SB02300787
SS Lower flue SBE3341301
BL Lower flue S03114035
WH Lower flue S031170302
CP Lower flue SB03159000
BR Lower flue SE3341312
SS Upper flue SBE3341311
BL Upper flue S03114036
WH Upper flue S031170312
CP Upper flue SB03159001
BR Upper flue SE3341313
Filter flip latch
30” (qty 2) 9-1/4”x12-3/4” SB08087163
36” (qty 3) 9-1/4”x12-3/4” SB08087163
upper flue mtg bracket SBE3300517
fuse SB02300782
fuse holder SB02300674
charcoal filter SB03300498
30” SS Front trim SB003180331
36” SS Front trim SB003180037
30” BL Front trim SB003180333 (NLA)
36” BL Front trim SB003180036 (NLA)
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws & drywall
anchors)
NOTE: Front trims not listed can be ordered from Best.
Contact Technical Support.
K42 FLUORESCENT LIGHT UNIT
(BEST) OBSOLETE UNIT
damper/duct connector plastic SB08085018
damper/duct connector metal SB080810199
blower assembly SB06001898 (NLA) 2-2012
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting rubber SB03202007 (Rpl by
SB03204177)
resistor - qty 2 S02300654
(need to replace both at the same time)
capacitor w/wires SB06104132 (NLA)
capacitor SB02300653
bulb holder S02300521
bulb holder with starter S02300522
starter S02300659
ballast S02300657
reflector cover S03292288
switch assembly white SB06105067
control board S08086096 (OBS 11-2013)
logo (adhesive black w/silver letters) SB08091852
filter spring SB02000191
fluorescent bulb S02300500
light lens S03200725
lower flue SE3338410 (NLA)
upper flue SE3338411 (NLA)
Filters finger well
36” & 90cm requires 3 9-1/4”x12-1/2” S08087390
42” requires 3 9-1/4”x12-1/2” S08087390
48” requires 4 9-1/4”x12-1/2” S08087390
54” requires 5 9-1/4”x12-1/2” S08087390
upper flue bracket SBE3300517
Front trim 19 7/16” deep
SS 36” SB003180037
SS 42” SB003180068
SS 48” SB003180101 (NLA)
SS 54” SB003180681
SS 90 cm SB003180072
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws & drywall
anchors)
K42.1 REV A (BEST)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295076
motor mounting rubber SB03202007 (Rpl by
SB03204177)
blower assembly SB06001898 (NLA) 2-2012
control board S08086096 (OBS 11-2013)
switch assembly
black (same as B06105498) SB06105117
white SB06105067
high temperature SB06106502 RPL BY SB06107552
capacitor SB02300653
resistor - qty 2 S02300654
(need to replace both at the same time)
transformer SB02300670
light socket SB02300688
socket support SB02009103
bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
fuse SB02300782
fuse holder SB02300674
filter spring SB02000191
Filter finger well
36” (requires 3) 9-1/4”x16-1/2” S08087341
90 cm (requires 3) 9-1/4”x16-1/2” S08087341
42” (requires 3) 9-1/4”x16-1/2” S08087341
48” (requires 4) 9-1/4”x16-1/2” S08087341
54” (requires 5) 9-1/4”x16-1/2” S08087341
logo white/silver SB03202437
logo black/silver SB03202436
Chimney Hoods
7
NLA = no longer available; OBS = obsolete
damper/duct connector SB080810265 OBS RPL BY
SB08085018
flue mounting bracket SBE3300517
upper SS Flue SBE3341311
lower SS Flue SBE3341301
36” SS Front trim (24” deep) S003180564
42” SS Front trim (24” deep) SB003180557
48” SS Front trim (24” deep) S003180555
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws & drywall
anchors)
K42.1 REV B Heat Sentry July 2002
(BEST)
motor SB02310201
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
blower assembly SB06002008
control board SB08086668
switch assembly SB06107571
capacitor SB02300233
heat sentry SB02300787
transformer SB02300783
light socket SB02300688
socket support SB02009103
bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
fuse SB02300782
fuse holder SB02300674
Filter flip latch
36” (requires 3) 9-1/4”x12-3/4” SB08087163
90 cm (requires 3) 9-1/4”x12-3/4” SB08087163
42” (requires 3) 9-1/4”x12-3/4” SB08087163
48” (requires 4) 9-1/4”x12-3/4” SB08087163
54” (requires 4) 9-1/4”x12-3/4” SB08087163
logo (adhesive silver) SB02011284 (RPL by SV05869)
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) Sept 2007
SB08092501
flue mounting bracket SBE3300517
Flues
upper SS SBE3341311
lower SS SBE3341301
Front trim (24” deep)
36” SS S003180564
42” SS SB003180557
48” SS S003180555
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws & drywall
anchors)
K42.1 REV C (BEST) Changed
Transformer Nov 2008 - OBS 01/14
motor SB02310201
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
blower assembly SB06002008
control board SB08086668
switch assembly SB06107571
capacitor SB02300233
heat sentry SB02300787
transformer SB02300861
light socket SB02300688
socket support SB02009103
bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
fuse SB02300782
fuse holder SB02300674
Filter flip latch
36” (requires 3) 9-1/4”x12-3/4” SB08087163
90 cm (requires 3) 9-1/4”x12-3/4” SB08087163
42” (requires 3) 9-1/4”x12-3/4” SB08087163
48” (requires 4) 9-1/4”x12-3/4” SB08087163
54” (requires 4) 9-1/4”x12-3/4” SB08087163
logo (adhesive silver) SB02011284 (RPL by SV05869)
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) Sept 2007
SB08092501
flue mounting bracket SBE3300517
upper SS Flue SBE3341311
lower SS Flue SBE3341301
36” SS Front trim (24” deep) S003180564
42” SS Front trim (24” deep) SB003180557
48” SS Front trim (24” deep) S003180555
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws & drywall
anchors)
K92 (BEST) OBSOLETE UNIT
blower assembly S06001527 (OBS)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
capacitor SB02300653
resistor - qty 2 S02300654
(need to replace both at the same time)
switch assembly S06104280
knob S03202163
control board S08086096 (OBS 11-2013)
tube holder S02300521
starter/tube holder S02300522
ballast S02300657
fluorescent tube S02300500
light lens S03200725
drawer track S02000588 (NLA)
filter spring SB02000191
front panel 90cm black S03108719 (NLA)
upper filter 90cm (requires 3) S08087371
upper filter 42” (req 4) S08087368
9-1/4”x9-5/8” plastic finger well
upper filter 48” (req 3) S08087368
9-11/16”x14-5/16” plastic finger well
lower filter 90cm (req 3) S08087370
7-1/8”x9-3/4” plastic finger well
lower filter 42” (req 4) S08087369 (NLA)
lower filter 48” (req 3) SB08087367
7-3/16”x13-7/8” plastic finger well
upper flue SS SE3338386 (NLA)
upper flue BL S03108738 (NLA)
lower flue SS SE3338385 (NLA)
lower flue BL S03108739 (NLA)
K142 (BEST) OBSOLETE UNIT
blower assembly S06001527 (OBS)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
capacitor SB02300653
resistor - qty 2 S02300654
(need to replace both at the same time)
control board SB08080101
switch assembly S06105104 (NLA)
warning lamp lens SB03201014
switch button (one per pack) SB03200361
micro switch SB02300620
transformer SB02300670
light socket SB02300688
socket support SB02009103
bulb MR16 12 volt 20 watt SB02300774
lamp bezel SB02009102
upper filter S08087371
lower filter 7-1/8”x9-3/4” plastic finger well S08087370
filter spring SB02000191
damper/duct connector (metal) SB080810199
flue sections NLA
K186L (BEST) OBSOLETE UNIT
motor SB02300040 (11-2012 NLA)
switch board SB08086015
K271 (BEST) OBS 11/02
filter spring SB02000191
grease filter - 9-3/16”x14-7/16” SB08087212
metal finger well 90 cm - qty 3; 48” qty 4
capacitor SB06106261 (NLA)
halogen bulb Type JC 12 volt 20 watt G4 SB02300891
motor SB082300519 (NLA)
blower wheel SB03295076
rubber washer SB03202007 (Rpl by SB03204177)
damper/duct connector 90 cm SB080810111
damper/duct connector 48” SB080810265 OBS RPL
BY SB08085018
switch mounting bracket SB08091173
rear filter channel 48” SBE3342469
rear filter channel 90 cm SBE3335533
logo black SB03202436
logo white SB03202437
lower flue 48” SB003181822
lower flue 90 cm SB003181795 (NLA)
upper flue 48” SBE3342476
upper flue 90 cm SBE3342455 (NLA)
flue mounting bracket SBE3342477
utensil rail & mounting pins 48” SB080810296
utensil rail & mounting pins 90 cm SB080810294
control board SB08080602 (11-2012 NLA)
transformer 48” SB02300729
transformer 90 cm SB02300717
switch button SB03292256
lamp housing (includes lens) SB02300719
blower assembly 48” SB06001764
switch box assembly SB06106264
Chimney Hoods
8
NLA = no longer available; OBS = obsolete
K273 REV A (BEST)
logo SB03202436
duct connector (no flaps) SB03292283
damper flaps SB02000756
blower assembly SB06001989
motor SB02310185
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
switch assembly SB06107359
socket protection SB02009103
socket base SB02300688
socket reflector SB02009193
control board SB08086661
capacitor SB02300233
transformer SB02300783
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
Utensil rail for 90 cm SB02009208
Utensil rail for 42” SB02009340
filter - finger well (req 3) 8-1/2”x11-1/8” SB08087299
filter - flip latch (req 3) 8-1/2”x11-1/4” SB08087165
upper flue SBE3341841
lower flue SBE3341840
fuse SB02300782
fuse holder SB02300674
flue mounting bracket SB03292293
filter spring SB02000191
hardware package SB080810502
(ceiling flue bracket (solid white plastic), wall mtg brack-
ets, installation screws & drywall anchors)
K273 REV B Heat Sentry 04-03 (BEST)
logo (adhesive silver) SB02011284 (RPL by SV05869)
duct connector (plastic, no flaps) SB03292283
damper flaps SB02000756
damper/duct connector (metal) 09/07 SB08092518
blower assembly SB06002019
motor SB02310184
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
switch assembly SB06107359
socket protection SB02009103
socket base SB02300688
socket reflector SB02009193
control board SB08086662
capacitor SB02300233
transformer SB02300783
transformer after Oct-11-2010 SB02300739
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
heat sentry SB02300787
Utensil rail for 90 cm SB02009208
Utensil rail for 42” SB02009340
filter (req 3) flip latch 8-1/2”x11-1/4” SB08087165
upper flue SBE3341841
lower flue SBE3341840
fuse SB02300782
fuse holder SB02300674
flue mounting bracket SB03292293
hardware package SB080810502
(ceiling flue bracket (solid white plastic), wall mtg
brackets, installation screws & drywall anchors)
K3139 REV A (BEST)
charcoal filter (set of two) SB03300495
Filters slide latch
30” (req 2) 9-3/8”x11-3/4” SB08087151
36” & 42” (req 3) 9-3/8”x11-3/4” SB08087151
capacitor SB02300233
bulb Type JC 12 volt 20 watt SB02300891
motor SB02310175 (Rpl by SB02300411) 3-19-14
blower wheel SB03295076
rubber washer SB03202007 (Rpl by SB03204177)
damper/duct connector (plastic) SB08088378
logo SB03202436
lower flue SS SBE3343376
lower flue WH SB03117804
lower flue BL SB03114485
upper flue SS SBE3343377
upper flue WH SB03117805
upper flue BL SB03114486
upper flue bracket SB08091367
transformer SB02300783
switch circuit board SB08086240
switch button SB03200351
button extender SB03292301
red indicator lens SB03201014
fuse SB02300782
light housing/socket (includes lens) SB02300791
blower assembly SB06001978
hardware package SB080810471
(damper duct connector, air deflector SB03295016,
wall mtg bracket, ceiling flue bracket, mtg screws and
wall anchors)
K3139 REV B Heat Sentry
Sept 2003 (BEST)
charcoal filter (set of two) SB03300495
Filter slide latch
30” (req 2) 9-3/8”x11-3/4” SB08087151
36” & 42” (req 3) 9-3/8”x11-3/4” SB08087151
capacitor SB02300233
bulb Type JC 12 volt 20 watt SB02300891
motor SB02310203
blower wheel SB03295076
rubber washer SB03202007 (Rpl by SB03204177)
damper/duct connector (plastic) SB08088378
logo (adhesive black w/silver letters) SB08091852
lower flue SS SBE3343376
lower flue WH SB03117804
lower flue BL SB03114485
upper flue SS SBE3343377
upper flue WH SB03117805
upper flue BL SB03114486
upper flue bracket SB08091367
transformer SB02300783
control board SB08086668
switch circuit board SB08086286
switch button SB03200351
button extender SB03292301
red indicator lens SB03201014
fuse SB02300782
light housing/socket (includes lens) SB02300791
blower assembly SB06002013
heat sentry SB02300787
hardware package SB080810480
(damper duct connector, ceiling flue bracket, wall mtg
bracket, mtg screws & wall anchors)
K3139 REV C Transformer location
May 2004 (BEST)
charcoal filter (set of two) SB03300495
Filter slide latch
30” (req 2) 9-3/8”x11-3/4” SB08087151
36” & 42” (req 3) 9-3/8”x11-3/4” SB08087151
capacitor SB02300233
bulb Type JC 12 volt 20 watt SB02300891
motor SB02310203
blower wheel SB03295076
rubber washer SB03202007 (Rpl by SB03204177)
damper/duct connector (plastic) SB08088378
logo (adhesive black w/silver letters) SB08091852
lower flue SS SBE3343376
lower flue WH SB03117804
lower flue BL SB03114485
upper flue SS SBE3343377
upper flue WH SB03117805
upper flue BL SB03114486
upper flue bracket SB08091367
transformer SB02300783
control board SB08086668
switch circuit board SB08086286
switch button SB03200351
button extender SB03292301
red indicator lens SB03201014
fuse SB02300782
light housing/socket (includes lens) SB02300791
blower assembly SB06002013
heat sentry SB02300787
hardware package SB080810480
(damper duct connector, ceiling flue bracket, wall mtg
bracket, mtg screws & wall anchors)
K3139 REV D 120 volt lighting Oct
2005 (BEST)
charcoal filter (set of two) SB03300495
Filter slide latch
30” (req 2) 9-3/8”x11-3/4” SB08087151
36” & 42” (req 3) 9-3/8”x11-3/4” SB08087151
capacitor SB02300233
bulb 120 volt 50 watt GU10 SB02300899 (RPL by
SV05921)
motor SB02310203
blower wheel SB03295076
rubber washer SB03202007 (Rpl by SB03204177)
damper/duct connector (plastic) SB08088378
logo (adhesive silver) SB02011284 (RPL by SV05869)
lower flue SS SBE3343376
lower flue WH SB03117804
lower flue BL SB03114485
upper flue SS SBE3343377
upper flue WH SB03117805
upper flue BL SB03114486
upper flue bracket SB08091367
control board SB08086668
switch circuit board SB08086286
switch button SB03200351
button extender SB03292301
red indicator lens SB03201014
Chimney Hoods
9
NLA = no longer available; OBS = obsolete
light housing/socket SB06108800
bezel SB02009102
blower assembly SB06002013
heat sentry SB02300787
hardware package SB080810480
(damper duct connector, ceiling flue bracket, wall mtg
bracket, mtg screws & wall anchors)
K3500 REV A and B (REV B changed
bulb supplier in 3-2002) (BEST)
blower assembly SB06001988
motor SB02310184
rubber motor mounts SB03202007 (Rpl by
SB03204177)
blower wheel SB03295071
capacitor SB02300233
damper/duct connector (plastic) SB08088378
switch assembly SB06107351
control board SB08086661
transformer SB02300783
fuse SB02300782
fuse holder SB02300674
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
halogen bulb Type JC 12v 20 watt G4 SB02300891
power cord SB02300249
logo SB03202436
flue mounting bracket SB08091367
lower flue SS SBE3347082
upper flue SS SBE3347083
glass SB02005032
rubber gasket glass SB03202430
rubber gasket flue SB03202129
filter (req 1) slide latch filter is arched SB08087150
filter spring SB02000191
hardware package SB080810498
(damper duct connector, ceiling flue bracket, wall mtg
bracket, installation screws & drywall anchors)
K3500 REV C and D (REV C Heat
Sentry 4-2003) (REV D Flue length
change 3-2004 ) (BEST) OBS JAN
2014
blower assembly SB06001988
motor SB02310184
rubber motor mounts SB03202007 (Rpl by
SB03204177)
blower wheel SB03295071
capacitor SB02300233
damper/duct connector (plastic) SB08088378
switch assembly SB06107351
control board SB08086662
transformer SB02300783
transformer after Oct-11-2010 SB02300739
fuse SB02300782
fuse holder SB02300674
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
halogen bulb Type JC 12v 20 watt G4 SB02300891
power cord SB02300249
logo (adhesive silver) SB02011284 (RPL by SV05869)
flue mounting bracket SB08091367
lower flue SS SBE3347082
upper flue SS SBE3347083
glass SB02005032
rubber gasket glass SB03202430
rubber gasket flue SB03202129
filter (req 1) slide latch filter is arched SB08087150
filter spring SB02000191
heat sentry SB02300787
hardware package SB080810498
(damper duct connector, ceiling flue bracket, wall mtg
bracket, installation screws & drywall anchors)
K7388 REV A (BEST) OBS 9-2012
blower assembly SB06001988
motor SB02310184
rubber motor mounts SB03202007 (Rpl by
SB03204177)
blower wheel SB03295071
capacitor SB02300233
damper/duct connector (plastic) SB08088378
switch assembly SB06107336
control board SB08086661
transformer SB02300783
fuse SB02300782
fuse holder SB02300674
light housing/socket (includes lens) SB02300741
halogen bulb Type JC 12v 20 watt G4 SB02300891
power cord SB02300249
logo SB03202436
hood mounting bracket SBE3343340
flue mounting bracket SB08091367
lower flue SS SBE3343563
upper flue SS SBE3343560
glass canopy SB02005036
filter (req 2) slide latch 9-3/8”x11-3/4” SB08087294
charcoal filter SB03300488
flue gasket SB03202430
hardware package SB080810498
(damper duct connector, ceiling flue bracket, wall mtg
bracket, installation screws & drywall anchors)
K7388 REV B Heat Sentry April
2003 (BEST)-- OBS 9-2012
blower assembly SB06001988
motor SB02310184
rubber motor mounts SB03202007 (Rpl by
SB03204177)
blower wheel SB03295071
capacitor SB02300233
damper/duct connector (plastic) SB08088378
switch assembly SB06107336
control board SB08086662
transformer SB02300783
transformer after Oct-11-2010 SB020300739
fuse SB02300782
fuse holder SB02300674
light housing/socket (includes lens) SB02300741
halogen bulb Type JC 12v 20 watt G4 SB02300891
power cord SB02300249
logo (adhesive silver) SB02011284 (RPL by SV05869)
hood mounting bracket SBE3343340
flue mounting bracket SB08091367
lower flue SS SBE3343563
upper flue SS SBE3343560
glass canopy SB02005036
filter (req 2) slide latch 9-3/8”x11-3/4” SB08087294
charcoal filter SB03300488
heat sentry SB02300787
flue gasket SB03202430
ribbon cable from switch to control board SB02300277
hardware package SB080810604
(damper duct connector, ceiling flue bracket, wall mtg
bracket, installation screws & drywall anchors)
K7788 (BEST) OBS 9-2012
blower assembly SB06001988
motor SB02310184
rubber motor mounts SB03202007 (Rpl by
SB03204177)
blower wheel SB03295071
capacitor SB02300233
damper/duct connector (plastic) SB08088378
switch assembly SB06107782
control board SB08086662
transformer SB02300783
transformer after Oct-11-2010 SB020300739
fuse SB02300782
fuse holder SB02300674
light housing/socket (includes lens) SB02300733
halogen bulb Type JC 12 volt 20 watt SB02300891
power cord SB02300249
flue mounting bracket SB08091367
lower flue SS SBE3344803
upper flue SS SBE3346646
Glass
black SB002090225
sage green SB002090246
garnet red SB002090247
cobalt blue SB002090245
filter requires 3 flip latch 9-3/8”x11-3/4” SB08087131
charcoal filter SB03300488
heat sentry SB02300787
ribbon cable from switch to control board SB02300277
hardware package SB080810498
(damper duct connector, ceiling flue bracket, wall mtg
bracket, installation screws & drywall anchors)
K8087 (BEST)
blower assembly SB06001988
motor SB02310184
rubber motor mounts SB03202007 (Rpl by
SB03204177)
blower wheel SB03295071
capacitor SB02300233
damper/duct connector (plastic) SB08088378
switch assembly SB06107786
control board SB08086662
transformer SB02300783
transformer after Oct-11-2010 SB020300739
fuse SB02300782
fuse holder SB02300674
light housing/socket (includes lens) SB02300733
halogen bulb Type JC 12v 20 watt G4 SB02300891
power cord SB02300249
flue mounting bracket SB08091367
lower flue SS SB003100591
upper flue SS SBE3346644
Chimney Hoods
10
NLA = no longer available; OBS = obsolete
Chimney Hoods
11
filter (req 1) flip latch 12”x14-1/2” SB08087169
charcoal filter SB03300488
heat sentry SB02300787
ribbon cable from switch to control board SB02300275
hardware package SB080810498
(damper duct connector, ceiling flue bracket, wall mtg
bracket, installation screws & drywall anchors)
KE222 & 94KE222 (BEST) OBS
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting rubber SB03202007 (Rpl by
SB03204177)
capacitor SB02300653
resistor -- qty 2 (replace both) S02300654
control board S08086112 (11-2012 NLA)
Switch assembly
KE222 (round grey buttons) S06104675 (OBS 8-24-12)
94KE222 (square black buttons) S06105406 (NLA)
Switch membrane
KE222 (round grey buttons) S03204101
94KE222 (square black buttons) S03292281
fuse SB02300782
transformer SB02300670
light socket SB02300688
socket support SB02009103
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
damper/duct connector (metal) SB080810199
Front rail
90cm brass SB02009118 (NLA)
42” brass SB02009132 (NLA)
48” brass S02009133
side rail set--chrome SB080810076
side rail set--brass SB080810077
rail coupling chrome S02009124
rail coupling brass S02009134
rail spacer brass S02009131
rail stub end chrome S02009120
Filters plastic finger well
42” (req 3) 10-3/4”x16-7/16” S08087340
48” (req 4) 9-1/4”x16-1/2” S08087341
90cm (req 3) 9-1/4”x16-1/2” S08087341
upper flue SS SBE3341311
lower flue SS SBE3341301
upper flue WH S031170312
lower flue WH S031170302
upper flue BL S03114036
lower flue BL S03114035
upper flue CP SB03159001
lower flue CP SB03159000
lower flue BR SE3338418 (NLA)
logo silver S03202159
logo white SB03202437
logo black SB03202436
upper flue mounting bracket SBE3300517
hardware package S08081196 Rpl by SB080810578
(includes wall mtg brackets, installation screws &
drywall anchors)
KER222 REV A (BEST)
black logo SB03202436
white logo SB03202437
blower assembly SB06001805
motor SB082300530
blower wheel SB03295076
motor mounting rubber SB03202007 (Rpl by
SB03204177)
switch assembly SB06106790
capacitor SB02300730
transformer 90 cm SB02300739
transformer 42” & 48” SB02300729
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
control board SB08080602 (11-2012 NLA)
Front utensil rail
90cm chrome SB02009293
90cm brass SB02009321 (NLA)
42” chrome SB02009292
42” brass SB02009336
48” chrome SB02009290
48” brass SB02009319
rail support w/screws chrome SB02009186
rail support w/screws brass SB02009177
decorative end for front rail CH SB02009187
decorative end for front rail BR SB02009178
side utensil rail chrome SB02009291
side utensil rail brass SB02009322
Frame
90cm SBE3401920*
42” SBE3401918
48” SBE3401902*
halogen bulb Type JC 12 volt 20 watt SB02300891
Filter slide latch
90cm & 42” (req 3) 9-1/4”x12-3/4” SB08087079 (rpl
with SB08087163 flip latch 12-2012)
48” (req 4) 9-1/4”x12-3/4” SB08087079 (rpl with
SB08087163 flip latch 12-2012)
NOTE---the latch on the replacement filter looks
different---please advise customer.
damper/duct connector plastic SB08085018
lower flue SS SBE3341301
lower flue WH S031170302
lower flue BL S03114035
upper flue SS SBE3341311
upper flue WH S031170312
upper flue BL S03114036
upper flue mtg bracket SBE3300517
fuse SB02300782
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws &
drywall anchors)
*These parts have not been loaded into the AS400
system. They can be ordered from Best if needed.
KER222 REV B Heat Sentry Sept
2002 (BEST) OBS JAN 2014
logo (adhesive silver) SB02011284 (RPL by SV05869)
blower assembly SB06002008
motor SB02310201
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
switch assembly SB06103249
capacitor SB02300233
transformer 90 cm SB02300783
transformer 90cm after 10/11/10 SB02300739
transformer 42” & 48” SB02300792
transformer 42” & 48” after 9/30/10 SB02300729
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
control board SB08086662
front utensil rail 90cm chrome SB02009293
front utensil rail 90cm brass SB02009321 (NLA)
front utensil rail 42” chrome SB02009292
front utensil rail 42” brass SB02009336
front utensil rail 48” chrome SB02009290
front utensil rail 48” brass SB02009319
rail support w/screws chrome SB02009186
rail support w/screws brass SB02009177
decorative end for front rail CH SB02009187
decorative end for front rail BR SB02009178
side utensil rail chrome SB02009291
side utensil rail brass SB02009322
frame - 90cm SBE3403606*
frame - 42” SBE3403608*
frame - 48” SBE3403610
halogen bulb Type JC 12 volt 20 watt SB02300891
Filter flip latch
90cm & 42” (req 3) 9-1/4”x12-3/4” SB08087163
48” (req 4) 9-1/4”x12-3/4” SB08087163
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) 09- 2007 SB08092501
lower flue SS SBE3341301
lower flue WH SB031099312 (NLA)
lower flue BL SB03108750 (NLA)
upper flue SS SBE3338411
upper flue WH SB031099322
upper flue BL SB03108751 (NLA)
upper flue mtg bracket SBE3300517
fuse SB02300782
heat sentry SB02300787
hardware package SB080810601
(wall mtg brackets, installation screws & drywall
anchors)
*These parts have not been loaded into the AS400
system. They can be ordered from Best if needed.
KEX30 REV A (BEST)
logo SB03202436
filter spring SB02000191
damper/duct connector (metal) SB080810199
transformer SB02300783
transformer for 48” SB02300792
socket support SB02009103
socket base SB02300688
socket reflector SB02009193
fuse SB02300782
fuse holder SB02300674
control board SB08086670
switch assembly SB06107333
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
Filter finger well
90cm (req 2) 11-11/16”x11-11/16” SB08087296
48” (req 3) 11-11/16”x11-11/16” SB08087296
NLA = no longer available; OBS = obsolete
Chimney Hoods
12
upper flue mounting bracket SB08091367
lower flue SBE3333768
upper flue SBE3345044
hardware package SB080810495
(ceiling flue bracket, wall mtg bracket, installation
screws & drywall anchors)
KEX30 REV B Heat Sentry April
2003 (BEST)
logo (adhesive black w/silver letters) SB08091852
filter spring SB02000191
damper/duct connector (metal) SB080810199
transformer SB02300783
transformer for 48” SB02300792
socket support SB02009103
socket base SB02300688
socket reflector SB02009193
fuse SB02300782
fuse holder SB02300674
control board SB08086670
switch assembly SB06107333
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
Filter finger well
90cm (req 2) 11-11/16”x11-11/16” SB08087296
48” (req 3)11-11/16”x11-11/16” SB08087296
upper flue mounting bracket SB08091367
lower flue SBE3333768
upper flue SBE3345044
heat sentry SB02300787
hardware package SB080810495
(ceiling flue bracket, wall mtg bracket, installation
screws & drywall anchors)
KEX30 REV C Flip Latch Filter June
2004 (BEST) OBS JAN 2014
logo (adhesive silver) SB02011284 (RPL by SV05869)
damper/duct connector (metal) SB080810199
transformer 90 cm SB02300783
transformer 90 cm after Oct-11-2010 SB02300739
transformer 48” SB02300792
transformer 48” after Sept-30-2010 SB02300729
socket support SB02300792
socket base SB02300688
socket reflector SB02009193
fuse SB02300782
fuse holder SB02300674
control board SB08086670
switch assembly SB06107333
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
Filter flip latch
90cm requires 2 11-3/4”x12-1/8” SB08087018
48” requires 3 11-3/4”x12-1/8” SB08087018
upper flue mounting bracket SB08091367
lower flue SBE3347628
upper flue SBE3347629
heat sentry SB02300787
hardware package SB080810495
(ceiling flue bracket, wall mtg bracket, installation
screws & drywall anchors)
KEX42 REV A (BEST)
control board SB08080141 (RPL by SB08086141)
switch assembly black SB06107390 (OBS 6-28-13)
power cord SB02300249
transformer SB02300783
light socket SB02300688
socket support SB02009103
bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
fuse SB02300782
fuse holder SB02300674
upper flue SS SBE3341311
lower flue SS SBE3341301
Filter slide latch
36” & 42” 9-1/4”x12-3/4” SB08087079 (rpl with
SB08087163 flip latch 12-2012)
48” & 54” 9-1/4”x12-3/4” SB08087079 (rpl with
SB08087163 flip latch 12-2012)
NOTE---the latch on the replacement filter looks
different---please advise customer.
Front trim
36” SS S003180564
42” SS SB003180557
48” SS S003180555
damper/duct connector plastic SB08085018
KEX42 REV B Heat Sentry Sept
2003 (BEST)
control board w/triac for motor speeds SB08080141
(RPL by SB08086141)
logo (adhesive silver) SB02011284 (RPL by SV05869)
control board SB08086668
switch assembly black SB06108086
power cord SB02300249
transformer SB02300783
light socket SB02300688
socket support SB02009103
bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
heat sentry SB02300787
fuse SB02300782
fuse holder SB02300674
upper flue SS SBE3341311
lower flue SS SBE3341301
Filter flip latch
36” & 42” 9-1/4”x12-3/4” SB08087163
48” & 54” 9-1/4”x12-3/4” SB08087163
Front trim
36” SS S003180564
42” SS SB003180557
48” SS S003180555
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) 9/07 SB08092501
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws &
drywall anchors)
KEX42 REV C Changed transform-
er Nov 2008 (BEST) OBS JAN 2014
control board w/triac for motor speeds SB08080141
(RPL by SB08086141)
logo (adhesive silver) SB02011284 (RPL by SV05869)
control board SB08086668
switch assembly black SB06108086
power cord SB02300249
transformer SB02300861
light socket SB02300688
socket support SB02009103
bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
heat sentry SB02300787
fuse SB02300782
fuse holder SB02300674
upper flue mounting bracket SBE3300517
upper flue SS SBE3341311
lower flue SS SBE3341301
Filter flip latch
36” & 42” 9-1/4”x12-3/4” SB08087163
48” & 54” 9-1/4”x12-3/4” SB08087163
Front trim
36” SS S003180564
42” SS SB003180557
48” SS S003180555
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) 9/07 SB08092501
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws &
drywall anchors)
KEX222 REV A (BEST)
control board SB08086670
switch assembly SB06107500
power cord SB02300249
Transformer
90cm SB02300783
42” & 48” SB02300729 (before 6-1-2002)
SB02300792 (after 6-1-2002)
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
halogen bulb Type JC 12 volt 20 watt SB02300891
damper/duct connector plastic SB08085018
logo SB03202436
upper flue mounting bracket SBE3300517
Front utensil rail
90cm SB02009293
42” SB02009292
48” SB02009290
side utensil rail SB02009291
rail support w/screws chrome SB02009186
decorative end for front rail chrome SB02009187
Filter slide latch
90cm & 42” (req 3) 9-1/4”x12-3/4” SB08087079 (rpl
with SB08087163 flip latch 12-2012)
48” (req 4) 9-1/4”x12-3/4” SB08087079 (rpl with
SB08087163 flip latch 12-2012)
NOTE---the latch on the replacement filter looks
different---please advise customer.
lower flue SBE3341301
upper flue SBE3341311
fuse SB02300782
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws &
drywall anchors)
NLA = no longer available; OBS = obsolete
Chimney Hoods
13
KEX222 REV B Heat Sentry April
2003 (BEST) OBS JAN 2014
control board SB08086670
switch assembly SB06107500
power cord SB02300249
Transformer
90cm SB02300783
90cm after Oct-11-2010 SB02300739
42” & 48” SB02300792
42” & 48” after Sept-30-2010 SB02300729
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
halogen bulb Type JC 12 volt 20 watt G4 SB02300891
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) 9/07 SB08092501
logo (adhesive silver) SB02011284 (RPL by SV05869)
upper flue mounting bracket SBE3300517
Front utensil rail
90cm SB02009293
42” SB02009292
48” SB02009290
side utensil rail SB02009291
rail support w/screws chrome SB02009186
decorative end for front rail chrome SB02009187
Filter (flip latch)
90cm & 42” (req 3) 9-1/4”x12-3/4” SB08087163
48” (req 4) 9-1/4”x12-3/4” SB08087163
lower flue SBE3341301
upper flue SBE3338411
heat sentry SB02300787
fuse SB02300782
hardware package SB080810601
(wall mtg brackets, installation screws & drywall
anchors)
KEX273 REV A (BEST)
filter spring SB02000191
logo SB03202436
damper/duct connector (metal) SB080810199
switch assembly SB06107359
socket support SB02009103
socket base SB02300688
socket reflector SB02009193
control board SB08086670
transformer SB02300783
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
Utensil rail
90 cm SB02009208
42” SB02009340
filter (req 3) 8-1/2”x11-1/8” B08087299
NOTE: REV level or BOL number did not change
when the filter style changed. SB08087299 (round
finger well) SB08087165 (flip latch)
fuse SB02300782
fuse holder SB02300674
upper flue SBE3345404
lower flue SBE3345403
upper flue mounting bracket SB08091367
hardware package SB080810517
(ceiling flue bracket, wall mtg bracket, installation
screws & dry wall anchors)
KEX273 REV B Heat Sentry April
2003 (BEST)
logo (adhesive silver) SB02011284 (RPL by SV05869)
damper/duct connector (metal) SB080810199
switch assembly SB06107359
socket support SB02009103
socket base SB02300688
socket reflector SB02009193
control board SB08086670
transformer SB02300783
transformer after Oct-11-2010 SB02300739
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
Utensil rail
90 cm SB02009208
42” SB02009340
filter (req 3) flip latch 8-1/2”x11-1/4” SB08087165
fuse SB02300782
fuse holder SB02300674
heat sentry SB02300787
upper flue SBE3345404
lower flue SBE3345403
upper flue mounting bracket SB08091367
hardware package SB080810517
(ceiling flue bracket, wall mtg bracket, installation
screws & dry wall anchors)
KEX3500 REV A (BEST)
damper/duct connector (metal) SB080810199
switch assembly SB06107351
control board SB08086670
transformer SB02300739
fuse SB02300782
fuse holder SB02300674
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
halogen bulb Type JC 12v 20 watt G4 SB02300891
logo SB03202436
flue mounting bracket SB08091367
lower flue SS SBE3344185 (RPL by SBE3347082)
upper flue SS SBE3345043 (RPL by SBE3347083)
glass SB02005032
rubber gasket glass SB03202430
rubber gasket flue SB03202129
filter (req 1) slide latch filter is arched SB08087150
filter spring SB02000191
hardware package SB080810482
(ceiling flue bracket, wall mtg bracket, installation
screws & drywall anchors)
KEX3500 REV B and C (REV B Heat
Sentry 4- 2003) (REV C Flue length
change 3-2004) (BEST) OBS JAN
2014
damper/duct connector (metal) SB080810199
switch assembly SB06107351
control board SB08086670
transformer SB02300739
fuse SB02300782
fuse holder SB02300674
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
halogen bulb Type JC 12v 20 watt G4 SB02300891
logo (adhesive silver) SB02011284 (RPL by SV05869)
flue mounting bracket SB08091367
glass SB02005032
rubber gasket glass SB03202430
rubber gasket flue SB03202129
lower flue SS SBE3344185 (RPL by SBE3347082)
upper flue SS SBE3345043 (RPL by SBE3347083)
filter (req 1) slide latch filter is arched SB08087150
filter spring SB02000191
heat sentry SB02300787
hardware package SB080810482
(ceiling flue bracket, wall mtg bracket, installation
screws & drywall anchors)
KEX7788 (BEST)---OBS OCT 2012
damper/duct connector (metal) SB080810199
switch assembly SB06107782
control board SB08086670
transformer SB02300739
fuse SB02300782
fuse holder SB02300674
light housing/socket (includes lens) SB02300733
halogen bulb Type JC 12V 20 watt SB02300891
flue mounting bracket SB08091367
lower flue SS SBE3344803
upper flue SS SBE3346838
filter (req 3) flip latch 9-3/8”x11-3/4” SB08087131
heat sentry SB02300787
glass SB002090225
ribbon cable from switch to control board SB02300277
hardware package SB080810482
(ceiling flue bracket, wall mtg bracket, installation
screws & drywall anchors)
KEX8087 (BEST)
damper/duct connector (metal) SB080810199
switch assembly SB06107786
control board SB08086670
transformer SB02300739
fuse SB02300782
fuse holder SB02300674
light housing/socket (includes lens) SB02300733
halogen bulb Type JC 12v 20 watt G4 SB02300891
flue mounting bracket SB08091367
lower flue SS SB003100591
upper flue SS SBE3346837
filter (requires 1) flip latch 12”x14-1/2” SB08087169
heat sentry SB02300787
ribbon cable from switch to control board SB02300275
hardware package SB080810482
(ceiling flue bracket, wall mtg bracket, installation
screws & drywall anchors)
WC23E (BEST) OBS 9-2012
spring SB02000191
grease filter (req 1) slide latch 9-1/16”x7-1/8”
SB08087194
electrical box support SBE3345329
bulb Type JC 12 volt 20 watt G4 base SB02300891
heat sentry SB02300787
glass flip down door SB08092278
hinge for flip down door SB02011247
latch for flip down glass door SB02011262
NLA = no longer available; OBS = obsolete
Chimney Hoods
14
top glass SB02005078
damper duct connector (metal) SB080810199
lower flue SS SBE3348093
lower flue copper SB03159021
upper flue SS SBE3348686
upper flue copper SB03159022
upper flue bracket SB08091851
control board SB08086701
transformer SB02300783
transformer after Oct-11-2010 SB02300739
light socket w/lens SB02300733
switch assembly (includes ribbon cable) SB06108494
switch and light housing SB003102171
fuse SB02300782
fuse holder SB02300674
hardware package SB080810779
(ceiling flue bracket, wall mtg bracket, installation
screws & drywall anchors)
WC26E (BEST)
grease filter flip latch 12”x14-1/2” SB08087169
bulb Type JC 12 volt 20 watt G4 SB02300891
heat sentry SB02300804
damper duct connector (metal) SB080810199
top glass 36” SB02005084
top glass 42” SB02005095
top glass 48” SB02005096
plastic gasket SB02000509
logo SB02011284 (RPL by SV05869)
lower flue SS SBE3348104
lower flue copper SB03159012
upper flue SS SBE3348345
upper flue copper SB03159018
upper flue mounting bracket SB08091367
control board SB08086718
reflector SB03294811
transformer SB02300783
transformer after Oct-11-2010 SB02300739
cover SBE3345328
bracket SB03118136
light socket with lens SB02300802
switch assembly (does not include blue lens cover key
229) SB06108502
blue lens cover on switch SB03294173
fuse SB02300782
fuse holder SB02300674
led bulbs and wire harness assembly SB06108498
hardware package SB080810747
(ceiling flue bracket, wall mtg bracket, installation
screws & drywall anchors)
WM24E (BEST) OBS 9-2012
screen/gas sentry SB08087198
filter spring SB02000191
attachment bracket SB08092170
grease filter flip latch 8-1/2”x11-1/4” SB08087165
halogen bulb Type JC 12 volt 20 watt G4 base
SB02300891
heat sentry SB02300804
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) 9/07 SB08092501
control board SB08086720
control cable SB02300384
sentry cable SB02300388
gas sentry board SB08086673
transformer SB02300729
sentry ring SB03292847
micro-switch SB02300620
blower cover aluminum SB08092132
blower cover red SB08092290 (NLA 7-27-13)
blower cover blue SB08092297
blower cover black SB08092333
side vent covers (requires 2) SB03114979
cover SBE3248026
socket/lens assembly SB02300733
9’ flue aluminum SB080810742
9’ flue red SB080812419
9’ flue blue SB080812422
9’ flue black SB080812426
switch assembly SB06108512
fuse SB02300782
fuse holder SB02300674
hardware package SB080810765
(cover, 2-brackets, 4 screws 4.8 x 38mm pan head, 4
screws 3.9 x 6mm flat head)
hardware package SB080810621
(damper-duct connector, 2 small brackets, 4 screws
3.9 x 9.5mm pan head, 4 screws 3.9 x 9.5mm pan
head black)
WC23I (BEST) OBS 9-2012
filter spring SB02000191
grease filter slide latch 9-1/16”x7-1/8” SB08087194
capacitor SB02300233
heat sentry SB02300787
motor SB02310260
blower wheel SB03295071
motor mtg rubber SB03202007 (Rpl by SB03204177)
duct reducer SB03295018
glass support SB08092014
glass SB02005078
glass flip down door SB08092278
hinge for flip down door SB02011247
latch for flip down glass door SB02011262
damper/duct connector (plastic) SB08088378
lower flue SBE3348093
upper flue SBE3348094
flue mtg bracket SB08091851
non-duct air plenum SB08999028
control board SB08086700
transformer SB02300783
transformer after Oct-11-2010 SB02300739
socket/lens assembly SB02300733
blower assembly SB06002080
switch assembly (includes ribbon cable) SB06108494
switch and light housing SB003102171
non-ducted filter SB03300501
fuse SB02300782
fuse holder SB02300674
bulb Type JC 12 volt 20 watt G-4 base SB02300891
hardware package SB080810699
(damper duct connector, ceiling flue bracket, wall mtg
bracket, installation screws & drywall anchors)
WC26I (BEST)
grease filter flip latch 12”x14-1/2” SB08087169
capacitor SB02300233
halogen bulb Type JC 12 volt 20 watt G4 SB02300891
heat sentry SB02300804
motor SB02310272
blower wheel SB03295071
motor mtg rubber SB03202007 (Rpl by SB03204177)
glass 36” SB02005084
glass 42” SB02005095
glass 48” SB02005096
damper/duct connector (plastic) SB08088378
gasket SB02000509
logo SB02011284 (RPL by SV05869)
lower flue SS SBE3348104
lower flue CP SB03159012
upper flue SS SBE3346876
upper flue CP SB03159014
flue mounting bracket SB08091367
control board SB08086717
transformer SB02300783
transformer after Oct-11-2010 SB02300739
socket/lens assembly SB02300802
blower assembly SB06002096
switch assembly (does not include blue lens cover key
229) SB06108502
blue lens cover on switch SB03294173
non-ducted filter SB03300488
fuse SB02300782
fuse holder SB02300674
led bulbs and wire harness assembly SB06108498
hardware package SB080810707
(damper duct connector, ceiling flue bracket, wall mtg
bracket, installation screws & drywall anchors)
WC33I Modulare (SPRING of 2011)
BEST REV A & B
REV B had changes so blade guard would fit. No
changes to parts.
grease filter SB08087824
duct-free filter SB03300495
capacitor SB02300233
bulb (Type T4 120 volt 25 watt G9 base) SB02300890
heat sentry SB02300804
motor SB02310260
6” to 5” reducer SB03295018
blower wheel SB03295071
wires SB02300958
damper/duct connector SB08088378
lower flue SBE3350073
upper flue SBE3350074
upper flue bracket SB08091367
duct-free plenum SB03295016
control board SB08080852
light socket SB02300918
flexible duct SB02011452
blower assembly SB06002080
switch assembly SB06103881
hardware pkg SB080810954
NLA = no longer available; OBS = obsolete
Chimney Hoods
15
WC34I Eclisse (SPRING of 2011)
BEST OBS JAN 2014
spring SB02000191
grease filter SB08087825
duct-free filter SB08087828
capacitor SB02300233
bulb (Type T4 120 volt 25 watt G9 base) SB02300890
heat sentry SB02300804
motor SB02310260
blower wheel SB03295071
6” to 5” reducer SB03295018
wires SB02300959
top glass SB003102748
damper-duct connector SB08088378
lower flue SBE3345965
upper flue SBE3345966
upper flue bracket SB08091367
duct-free plenum SB08088369
control board SB08080852
light socket SB02300918
flexible duct SB02011452
blower assembly SB06002080
switch assembly SB06103883
hardware pkg SB080810501
WC35I Dune (Spring of 2011) BEST
OBS JAN 2014
spring SB02000191
grease filter SB08087823
duct free filter SB08087828
capacitor SB02300233
bulb (Type T4 120 volt 25 watt G9 base) SB02300890
heat sentry SB02300804
motor SB02310260
blower wheel SB03295071
6” to 5” reducer SB03295018
wires SB02300957
damper/duct connector SB08088378
lower flue SBE3345965
upper flue SBE3345966
upper flue bracket SB08091367
non-ducted plenum SB08088369
control board SB08080853
light socket SB02300918
flexible duct SB02011452
switch assembly SB06103882
blower assembly SB06002080
hardware pkg SB080810501
WC43I Sun BEST (JUNE 2012)
blade guard SB03115314
grease filter qty-1 SB08087827
capacitor SB02300233
bulb-Type T4 -- 120 volt -- 25 watt -- G9 base
SB02300890
heat sentry SB02300804
motor SB02310260
blower wheel SB03295071
rubber washer SB03204177
cord SB02300983
wires SB02300961
top glass black SB08092853
top glass white SB08092929
control board SB08080852
light socket SB02300918
switch assembly SB06103891
flip door assembly SB08092852
blower assembly SB06002157
charcoal filters SB03300495
hardware package SB080810973
WM24I (BEST) OBS 9-2012
screen/gas sentry SB08087198
filter spring SB02000191
attachment bracket SB08092170
grease filter flip latch 8-1/2”x11-1/4” SB08087165
capacitor SB02300233
halogen bulb Type JC 12 volt 20 watt G4 base
SB02300891
heat sentry SB02300804
charcoal filter support SB03295001 (NLA)
motor SB02310272
blower wheel SB03295071
motor mtg rubber SB03202007 (Rpl by SB03204177)
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) 9/07 SB08092501
control board SB08086753
control cable SB02300384
sentry cable SB02300388
gas sentry board SB08086673
transformer SB02300729
sentry ring SB03292847
micro-switch SB02300620
blower cover aluminum SB08092132
blower cover red SB08092290 (NLA 7-27-13)
blower cover blue SB08092297
blower cover black SB08092333
side vent covers (requires 2) SB03114979
cover SBE3248026
socket/lens assembly SB02300733
9’ flue aluminum SB080810742
9’ flue red SB080812419
9’ flue blue SB080812422
9’ flue black SB080812426
blower assembly SB06002102
switch assembly SB06108512
non-ducted filter SB03300502
fuse SB02300782
fuse holder SB02300674
hardware package SB080810765
(cover, 2-brackets, 4 screws 4.8 x 38mm pan head, 4
screws 3.9 x 6mm flat head)
hardware package SB080810621
(damper-duct connector, 2 small brackets, 4 screws
3.9 x 9.5mm pan head, 4 screws 3.9 x 9.5mm pan
head black)
WM33I Lipstick (Spring of 2011) BEST
spring SB02000191
grease filter SB08087165
duct free filter SB03300502
capacitor SB02300233
bulb (Type JC 12 volt 20 watt G4 base) SB02300891
heat sentry SB02300804
motor SB02310260
blower wheel SB03295071
wires SB02300970
wires SB02300971
damper/duct connector SB08088378
upper flue SB03145724
lower flue SB003102614
non-ducted plenum SB080810955
ladle hanger hook SB02011262
control board SB08080854
transformer SB02300861
inside panel SBE3250198
light socket SB02300834
blower assembly SB06002157
switch assembly SB06103990
hardware pkg SB080810888
WM34I Surf (Spring of 2011) BEST
REV A & B
REV B changes made so blade guard would fit. No
change in parts.
grease filter SB08087827
duct-free filter SB03300495
capacitor SB02300233
bulb (Type T4 120 volt 25 watt G9 base) SB02300890
heat sentry SB02300804
motor SB02310260
blower wheel SB032965071
6” to 5” reducer SB03295018
wires SB02300961
top glass SB08093024
damper/duct connector SB08088378
duct connector to plenum SB03292300
lower flue SBE3350842
upper flue SBE3350841
upper flue bracket SBE3349246
non-ducted plenum SB08093104
control board SB08080852
light socket SB02300918
flexible duct SB02011452
switch assembly SB06103891
blower assembly SB06002157
hardware pkg SB080810939
WM43I Fusion BEST (JUNE 2012)
grease filter--qty 1 SB08807684
capacitor SB02300233
bulb -- Type T4 -- 120 volt --25 watt -- G9 base
SB02300890
heat sentry SB02300804
motor SB02310260
blower wheel SB03295071
rubber washer SB03204177
cord SB02300983
wires SB02300961
top glass SB08093211
control board SB08080852
light socket SB02300918
blower guard SB03115309
switch assembly SB06103891
blower assembly SB06002157
charcoal filters SB03300495
hardware package SB080810959
NLA = no longer available; OBS = obsolete
Chimney Hoods
16
WM45I Intrigue BEST (JUNE 2012)
grease filter --qty 1 SB08087189
capacitor SB02300233
bulb Type T4, 120 volt, 25 watt, G9 base SB02300890
heat sentry SB02300804
motor SB02310260
blower wheel SB03295071
rubber washer SB03204177
cord SB02300249
wires SB02300980
damper/duct connector SB08088378
lower flue SBE3351433
upper flue SBE3351434
flue mounting bracket SB08091367
control board SB08080852
light socket SB02300918
switch assembly SB06103825
blower assembly SB06002080
charcoal filter SB03300541
mounting template---hood SB04302156
mounting template---flue SB04302154
hardware package SB080810501
WT32I (VENMAR) JAN 2010 OBS
upper flue mounting bracket 30”, 36”, & 42” SV18504
upper flue mounting bracket 48” SV18505
upper flue 30”, 36”, & 42” SV18496
upper flue 48” SV18497
lower flue 30”, 36”, & 42” SV18494
lower flue 48” SV18495
10” round in-line damper (48” unit only) S421
10” round adapter (48” unit only) SV08541
hood mounting bracket SV09014
lamp shell, socket & trim SV16569
(2 for 30” & 36”; 3 for 42” & 48”)
halogen bulb 120V, 50W GU10 SV05921
transformer SV09022
blower w/capacitor (48” req 2) S97017924
capacitor (48” unit req 2) S99271379
filter 30” (req 2), 48” (req 3) (13.83” x 13.83”) SV09012
filter 36” (req 2), 42” (req 2) (16.83” x 13.83”) SV09013
controls with chrome buttons and blue LEDS SV08964
logo SV05869
8” round damper/adapter (not used on 48”) SV08543
hardware package SV09027
3 #8 x 1 1/4” countersunk screws, 8 #8 x 3/4” screws
WBF4I Brick Chimney (ATLAN)
NOVEMBER 2012
upper and lower flue S99528393
blower assembly S99526974
light socket assembly S99526975
light trim ring S99527010
switch assembly S99527660
control board S99527665
filter 30” (pair) S97018027
filter 36” (set of three) S97018028
duct free filters (pair) S99528030
damper/duct connector S99526983
6” flexible duct S99526984
non-duct plenum S99526985
capacitor S99527012
transformer S99527011
hardware package S99526994
WTT32I (PACIFIC) JAN 2013
upper and lower flues 30”, 36” & 42” S99528405
upper and lower flues 48” S99528406
blower assembly (2 used on 48” hood) S99528407
light socket S99528408
light socket mounting bracket S99528409
switch assembly S99528410
switch wire harness S99528411
control board 30”, 36” & 42” S99528412
control board 48” S99528413
grease filter 30” (req 2) & 48” (req 3) S99528414
grease filter 36” & 42” (each size req 2) S99528415
ductfree filter 30” (pack of 2) S97018968
ductfree filter 36” & 42” (pack of 2) S97019039
8” damper/duct connector S99528418
8” flexible duct S99528429
non-duct plenum S99528421
10” damper/duct connector S99528419
diverter S99528420
upper flue mounting bracket for 30, 36 & 42”
S99528422
upper flue mounting bracket for 48” S99528438
bulb 50 watt MR16 GU10 SV05921
capacitor ( 2 used on 48” hood) S99528423
hardware package 30”, 36” & 42” S99528425
hardware package 48” S99528430
WPP9E (BEST) JAN 2014
grease filter 36”, 42”, 48” qty 3 54” qty 4 SB08087951
36” light support panel SBE3351882
42” light support panel SBE3351898
48” light support panel SBE3351906
54” light support panel SBE3351915
heat sentry SB02300804
wire assembly 36 & 42” SB06102604
wire assembly 48 & 54” SB06102614
wiring box SBE3350233
wiring box cover SBE3334252
36” front trim SBE3405180
42” front trim SBE3405184
48” front trim SBE3405187
54” front trim SBE3405190
filter spacers 42 & 54” only SBE3351870
bulb 25 watt, 120 volt, T4, G9 base SB02300918
flue assembly (both upper and lower) SB08016379
switch assembly SB06102605
10” damper/duct connector SBE3405192
electrical assembly SB06145226
36” grease rail SBE3405182
42” grease rail SBE34051085
48” grease rail SBE3405188
54” grease rail SBE3405191
hardware package SB080810995
(includes upper flue mounting bracket)
WPP9IQ (BEST) JAN 2014
grease filters requires qty 3 SB08087951
duct-free filter (set of 2) S97017930
36” light support panel SBE3351882
42” light support panel SBE3351898
heat sentry SB02300804
wire assembly SB06102602
wiring box SBE3350233
wiring box cover SBE3334252
36” front trim SBE3405180
42” front trim SBE3405184
fitler spacers 42” only SBE3351870
bulb SB02300918
flue assembly (includes upper and lower) SB08016372
BLDC driver S97019432
calibration button SB06102584
switch assembly SB06102596
8” damper/duct connector SB08092501
electrical assembly SB06145225
blower assembly SB06002259
duct reducer SB03294170
plenum duct collar SB03292300
plenum SB08093448
flex ducting SB02011557
non-duct filter supports S99111455
36” grease rail SBE3405182
42” grease rail SBE3405185
hardware package SB080810995
(includes upper flue mounting bracket)
WPP9IQT (BEST) JAN 2014
grease filters 36” & 42” qty 3 48” & 54” qty 4
SB08087951
36” light support panel SBE3351882
42” light support panel SBE3351898
48” light support panel SBE3351906
54” light support panel SBE3351915
heat sentry SB02300804
wire assembly 36 & 42” SB06102603
wire assembly 48 & 54” SB06102606
wiring box SBE3350233
wiring box cover SBE3334252
36” front trim SBE3405180
42” front trim SBE3405184
48” front trim SBE3405187
54” front trim SBE3405190
filter spacers 42 & 54” only SBE3351870
bulb SB02300918
flue assembly (includes upper and lower) SB08016379
BLDC driver S97019434
calibration button assembly SB06102584
switch assembly SB06102596
10” damper/duct connector SBE3405192
electrical assembly SB06145225
blower assembly SB06002259
36” grease rail SBE3405182
42” grease rail SBE3405185
48” grease rail SBE3405188
54” grease rail SBE3405191
hardware package SB080810995
(includes upper flue mounting bracket)
WC46E (BEST) JAN 2014
grease filters---requires 2 SB08087955
90cm light support panel SBE3351924
42” light support panel SBE3351922
heat sentry SB02300804
wire assembly SB06102593
wiring box SBE3350233
wirng box cover SBE3334252
latch assembly SB02011262
90cm closure panel SBE3352013
NLA = no longer available; OBS = obsolete
Chimney Hoods
17
42” closure panel SBE3351923
LED bulb SB08093413
hinge SB02011376
flue assembly (includes upper and lower) SB08016368
switch assembly SB06102610
8” damper/duct connector SB080810849
electrical assembly SB06145223
hardware package SB080810993
(includes upper flue mounting bracket)
WC46IQ (BEST) JAN 2014
grease filters---requires 2 SB08087955
90cm light support panel SBE3351924
42” light support panel SBE3351922
heat sentry SB02300804
wire assembly SB06102592
latch assembly SB02011262
90cm closure panel SBE3352013
42” closure panel SBE3351923
LED bulb SB08093413
hinge SB02011376
flue assembly (includes upper and lower) SB08016368
BLDC driver S97019430
calibration button assembly SB06102584
switch assembly SB06102609
8” damper/duct connector SB080810849
electrical assembly SB06145222
blower assembly SB06002259
duct reducer SB03294170
plenum duct connector SB03292300
plenum SB08093478
flex ducting SB02011557
non-ducted filter SB08999182
(pair of square that attach to aluminum filters)
hardware package SB080810993
(included upper flue mounting bracket)
WC34E (BEST) JAN 2014
top glass SB02300804
electrical assembly SB08093413
control board SB08080877
wires SB06102593
heat sentry SB02300804
LED bulb SB08093413
switch assembly SB06102595
light support panel SBE3351891
grease filter---requires 3 SB08087825
damper/duct connector SB080810849
flue assembly (includes upper and lower) SB08016368
upper flue mounting bracket SB08091851
hardware bag
WC34IQ (BEST) JAN 2014
top glass SB003102748
blower assembly SB06002259
blower wheel SB03295071
electrical assembly SB06145222
BLDC driver S97019431
wires SB06102592
calibration button SB06102584
calibration button holder SB02320034
heat sentry SB02300804
LED bulb SB08093413
switch assembly SB06102594
light support panel SBE3351891
grease filter---requires 3 SB08087825
duct free filter (one piece square) SB08999176
damper/duct connector SB080810849
flue assembly (includes upper and lower) SB08016368
upper flue mounting bracket SB08091851
8” to 6” reducer SB03294170
flex ducting 6” SB02011557
plenum duct collar SB032292300
plenum SB08093478
duct free filter support SB08093447
hardware package
WC35E (BEST) JAN 2014
electrical assembly SB06145223
control board SB08080877
wires SB06102593
heat sentry SB02300804
LED bulb SB08093413
switch assembly SB06102591
grease filter---requires 2 SB08087823
damper/duct connector SB080810849
flue assembly (includes upper and lower) SB08016368
upper flue mounting bracket SB08091851
center filter support bracket SBE3351078
hardware package
WC35IQ (BEST) JAN 2014
blower assembly SB06002259
blower wheel SB03295071
electrical assembly SB06145222
BLDC driver S97019431
wires SB06102592
heat sentry SB02300804
LED bulb SB08093413
switch assembly SB06102590
calibration button holder SB02320034
calibration button SB06102584
grease filter---requires 2 SB08087823
duct free filter (one piece square) SB08999176
damper/duct connector SB080810849
flue kit (includes upper and lower) SB08016368
upper flue mounting bracket SB08091851
center filter support bracket SBE3351078
plenum SB08093478
6” plenum duct connector SB032292300
flex ducting 6” SB02011557
8” to 6” reducer SB03294170
hardware package
WC44E (BEST) JAN 2014
grease filter---requires 2 SB08087958
heat sentry SB02300804
wire assembly SB06102616
glass SB02005322
wiring box SBE3350233
wiring box cover SBE3334252
LED bulb SB08093413
flue assembly (includes upper and lower) SB08016375
switch assembly SB06102633
8” damper/duct connector SB080810849
electrical assembly SB06145223
hardware package SB080810993
WC44IQ (BEST) JAN 2014
grease filters---requires 2 SB08087958
heat sentry SB02300804
wire assembly SB06102615
glass SB02005322
LED bulb SB08093413
flue assembly (includes upper and lower) SB08016375
BLDC driver S97019430
calibration button SB06102584
switch assembly SB06102632
8” duct connector SB080810849
electrical assembly SB06145222
blower assembly SB096002259
reducer SB03294170
duct free filter support SB08093447
plenum duct connector SBSB03292300
plenum SB08093478
flex ducting SB02011557
duct free filter (one piece square) SB08999176
hardware package SB080810993
WC45E (BEST) FEB 2014
grease filter---requires 2 SB08087806
heat sentry SB02300804
power cord SB02300249
wire assembly SB06102616
glass SB002090377
LED bulb SB08093413
upper and lower flue assembly SB08016368
switch assembly SB06102622
8” damper/duct connector SB080810849
electrical installation assembly SB06145223
hardware package SB080810993
WC45IQ (BEST) FEB 2014
grease filter---requires 2 SB08087806
heat sentry SB02300804
power cord SB02300249
wire assembly SB06102615
glass SB002090377
LED bulb SB08093413
upper and lower flue assembly SB08016368
BLDC driver S97019431
calibration button assembly SB06102584
switch assembly SB06102621
8” damper/duct connector SB080810849
electrical installation assembly SB06145222
blower assembly SB06002259
8” to 6” reducer SB03294170
non-ducted filter frame SB08093447
plenum duct connector SB03292300
non-duct plenum SB08093478
flexible duct SB02011557
duct-free filter (one piece square) SB08999176
hardware package SB080810993
NLA = no longer available; OBS = obsolete
Downdrafts / Hood Inserts and Power Packs
18
DD01 & DDEX (HTF)
top cover 30” S97015866
top cover 36” S97015867
top cover 48” S97015868
filter spring S99140195
rivet for spring S99230345
chimney weldment 30” S97015970
chimney weldment 36” S97015971
chimney weldment 48” S97015972
end cap RH S98009357
end cap LH S98009358
chimney slide S97015973
airbox slide S98010013
filter 30” (req 2) metal finger well 4-9/16”x12-11/16”
S97015753
filter 36” (req 2) metal finger well 4-1/2”x15-5/8”
S97015754
filter 48” 4-1/2” x 12-11/16” S97015755
spacer S99710032
slide strips S99111184
cord set S99271210
strain relief S99400060
wire harness S99271303
heat sensor harness S99271294
control board S99271289
crank assembly S97015674
gear motor bracket S97015977
gear motor DD01 30” S97017051
gear motor DD01 36” S97017047
gear motor DD01 48” S97017049
gear motor DDEX 30” S97017052
gear motor DDEX 36” S97017048
gear motor DDEX 48” S97017050
remote control assembly S97015692
airbox clamp S98009773
motor w/capacitor S99080362
blower wheel S99020247
motor mount isolator S99100484
microswitch (set of 2) S99271234
heat sensor S99271293
switch assembly S97015983
DDEX wire harness S99271304
hardware package S97011305
DD6 (BEST) OBSOLETE UNIT
blower assembly** see below
lift motor S02310043 (OBS)
microswitch SB02300620
switch assembly (does not include membrane)
S06104631 (NLA 9-2012)
switch membrane S03204100
control board S08086121 (NLA) 3-12-12
transformer S02300672
resistor S02300673
capacitor*** (not loaded in our system) S02300675
slide rails S020003530
Filters
24” (requires 2) S08087425
30” (requires 2) S08087426 (NLA 6-27-13)
36” (requires 2) S08087427 (OBS)
42” (requires 3)**** S08087420 (OBS)
48” (requires 3) S08087421
90cm (requires 2) S08087427 (OBS)
** Uses DDM or DD2M blower (listed separately)
*** Special order 8 week lead time
**** Coded OBS in AS400 can still order as a special
with an 8-week lead time
DD61 (BEST) OBSOLETE UNIT
blower assembly** see below
lift motor w/flat OBS
lift motor w/pin hole OBS S02310052
display visor pivot SB08088698
4 x 22 mm roll pin SB02000089 (NLA)
microswitch SB02300620
switch assembly S06104631 (NLA 9-2012)
switch membrane S03204100
control board S08086121 (NLA) 3-12-12
transformer S02300672
resistor S02300673
slide rails S020003530
Filters
24” (requires 2) S08087425
30” (requires 2) S08087426 (NLA 6-27-13)
36” (requires 2) S08087427
42” (requires 3)**** S08087420 (OBS)
48” (requires 3) S08087421
90cm (requires 2) S08087427 (OBS)
** Uses DDM DD2M blower listed separately
*** Use 02310052 & B08088698
**** Coded OBS in AS400 can still order as a special
with an 8-week lead time
DD97 (BEST) OBSOLETE UNIT
blower assembly **
lift motor SB082300528
switch assembly SB06106378
control board SB08086625
slide rails S020003530
display visor 36” SB08091293
top trim 36” SBE3401888
top cover 36” SB003182128
grille 36” SBE3342985
top cover end cap SB03292844
Filters
30” SB08087250***
36” SB08087249***
48” SB08087253***
**Uses DDB5 or EB9 blower (listed separately)
***Special order 8 week lead time
P191 (BEST) OBSOLETE UNIT
blower assembly NLA
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
damper/duct connector SB080810111
capacitor SB02300653
resistor S02300654
control board S08086096 (OBS 11-2013)
switch assembly white S06104844
switch assembly black S06105182 (OBS 6-28-13)
ballast S02300657
tube holder S02300521
starter/tube holder S02300522
starter S02300659
fluorescent tube S02300542
light lens SB03200797
filter 52cm (req 1) 7-3/8”x16-11/16” plastic finger well
S08087357
filter 70cm (req 2) 7-3/8”x11-7/8” plastic finger well
S08087356
round charcoal filter (set of 2) SB03300498
filter spring SB02000191
P195 REV A (BEST)
SILVER PUSH BUTTONS ON RIGHT SIDE
blower assembly P1951M 52 & 70CM SB06001802
blower assembly P1952M 70CM SB06001804
motor SB02310094
blower wheel SB03295076
rubber washer SB03202007 (Rpl by SB03204177)
switch assembly (includes push buttons) SB06106781
(3-4-13 NLA)
switch button (4 required) SB03200376
button extender (4 required) SB03292301
rectangular light housing SB02300719
(includes flip down door & glass lens)
transformer SB02300739
control board SB08080101
capacitor with wires P1951M SB06106272
capacitor with wires P1952M (contains two capacitors)
SB06106787
mounting spring SB02011013
red indicator light cover SB03200793
bulb---qty 2 Type JC 12 volt 20 watt SB02300891
Grilles
52cm SS SB08091196
52cm WH SB08091265
52cm BL SB08091266
70cm SS SB08091198 (OBS rpl by SB08092165)
70cm WH SB08091240
70cm BL SB08091239
grease filter 52cm (req 1) 5-13/16”x15-5/8”
SB08087232
grease filter 70cm (req 2) 5-13/16”x11-5/16”
SB08087233
filter stop SB032940130
damper/duct connector P1951M SB080810111
damper/duct connector P1952M SB080810265 OBS
RPL BY SB08085018
Frames
52cm SS SB003182146
52cm WH SB003182343
52cm BL SB003182344
70cm SS SB003182147
70cm WH SB003182341
70cm BL SB003182342
charcoal filter P1951M only (set of 2) SB03300498
charcoal filter bracket P1951M only (2 req)
SB03290377
hardware package SB080810286
(mounting screws for hood & damper)
NLA = no longer available; OBS = obsolete
Hood Inserts and Power Packs
19
P195 REV B Heat Sentry April 2003
(BEST)
SILVER PUSH BUTTONS ON RIGHT SIDE
blower assembly P1951M SB06002036
blower assembly P1952M SB06002008
motor SB02310201
blower wheel SB03295071
rubber washer SB03202007 (Rpl by SB03204177)
switch assembly (no buttons) SB06107819
switch button (4 required) SB03200376
button extender (4 required) SB03292301
rectangular light housing SB02300719
(includes flip down door & glass lens)
transformer SB02300783
control board SB08086668
capacitor SB06107821
heat sentry SB02300787
mounting spring SB02011013
red indicator light cover SB03200793
bulb----qty 2 Type JC 12 volt 20 watt SB02300891
Grilles
52cm SS SB08091196
52cm WH SB08091265
52cm BL SB08091266
70cm SS SB08091198 (OBS rpl by SB08092165)
70cm WH SB08091240
70cm BL SB08091239
filter 52cm (req 1) 5-13/16”x15-5/8” SB08087232
filter 70cm (req 2) 5-13/16”x11-5/16” SB08087233
filter stop SB032940130
damper/duct connector P1951M SB080810111
damper/duct connector P1952M SB080810265 OBS
RPL BY SB08085018
Frames
52cm SS SB003100622
52cm WH SB003100623
52cm BL SB003100624
70cm SS SB003100626
70cm WH SB003100627
70cm BL SB003100625
charcoal filter P1951M only (pair of 2) SB03300498
charcoal filter bracket P1951M only (2 req)
SB03290377
fuse SB02300782
hardware package SB080810286
(mounting screws for hood & damper)
P195 REV C 120 volt lighting Oct
2005 (BEST) OBS 8-2012
SILVER PUSH BUTTONS ON RIGHT SIDE
blower assembly P1951M SB06002036
blower assembly P1952M SB06002008
motor SB02310201
blower wheel SB03295071
rubber washer SB03202007 (Rpl by SB03204177)
switch assembly (no buttons) SB06108584
switch button (4 required) SB03200376
button extender (4 required) SB03292301
light socket SB06108800
round light bezel SB02009102
control board SB08086668
capacitor SB06107821 OR SB02300233 (no wires)
heat sentry SB02300787
mounting spring SB02011013
red indicator light cover SB03200793
bulb----qty 2 120 volt 50 watt GU10 SB02300899
(RPL by SV05921)
Grilles
52cm SS SB08092167
52cm WH SB08092187
52cm BL SB08092188
70cm SS SB08092165
70cm WH SB08092208
70cm BL SB08092189
filter 52cm (req 1) 5-13/16”x15-5/8” SB08087232
filter 70cm (req 2) 5-13/16”x11-5/16” SB08087233
filter stop SB032940130
damper/duct connector P1951M (plastic) SB08088240
(RPL by SB080810111)
damper/duct connector P1951M (metal) Sept 2007
SB08092518
damper/duct connector P1952M (plastic) SB08085018
damper/duct connector P1952M (metal) Sept 2007
SB08092501
Frames
52cm SS SB003102230
52cm WH SB003102247
52cm BL SB003102255
70cm SS SB003102220
70cm WH SB003102251
70cm BL SB003102256
charcoal filter P1951M only (pair of 2) SB03300498
charcoal filter bracket P1951M only (2 req)
SB03290377
hardware package SB080810286
(mounting screws for hood & damper)
P195ES (BEST Poland) Nov 2012
frame 52cm SB08093943
frame 70cm SB08093944
side fastner SB03295083
spring SB02011013
filter 52cm SB08087694
filter 70cm SB08087527
capacitor SB02300985
fluorescent bulb SB02320351
light lens SB03293051
heat sentry SB02300787
intake grid 70cm only SB03290377
power cord SB02300983
grid latch SB03295084
control board SB08086668
bulb holder SB02300987
ballast SB02320352
indicator lens SB03201014
blower assembly 52cm SB06002195
blower assembly 70cm SB06002203
damper/duct connector 52cm SB08088378
damper/duct connector 70cm SB08092501
switch assembly SB06108783
hardware package SB08084044
P195P REV A (BEST POLAND)
SEPT 2012
GRAY SWITCHES IN FRONT CENTER
frame 52 cm SB03100145
frame 70 cm SB03100146
spring SB02011013
grease filter 52 cm SB08087694
grease filter 70 cm SB08087527
capacitor S99271379
bulb Type T3 12 volt 20 watt G4 base halogen
SB02300891
heat sensor SB02300804
control board SB08080865
transformer SB02300861
bottom panel 52cm SBE3403940
bottom panel 70cm SBE3403941
light socket/housing SB02300798
panel hinge SB02011376
switch assembly SB06108780
8” damper/duct connector SB080810849
blower assembly S97017924
hardware package--mounting screws SB08084041
hardware package---junction boxes SB08084042
P195P REV B (First serial number
43-13-0055)
Two light levels, New control board, New frame, Inter-
face lens changed from red to blue.
frame 52 cm SB003100148
frame 70 cm SB003100147
spring SB02011013
grease filter 52 cm SB08087694
grease filter 70 cm SB08087527
capacitor S99271379
bulb Type T3 12 volt 20 watt G4 base halogen
SB02300891
heat sensor SB02300804
control board SB08080872
transformer SB02300861
bottom panel 52cm SBE3403940
bottom panel 70cm SBE3403941
light socket/housing SB02300798
panel hinge SB02011376
switch assembly SB06108780
8” damper/duct connector SB080810849
blower assembly S97017924
hardware package--mounting screws SB08084041
hardware package---junction boxes SB08084042
P195P1M52SB6 & P195P1M70SB6
REV C New Model Number
Changed 8” to 6” duct connector
frame 52 cm SB003100148
frame 70 cm SB003100147
spring SB02011013
grease filter 52 cm SB08087694
grease filter 70 cm SB08087527
capacitor S99271379
bulb Type T3 12 volt 20 watt G4 base halogen
SB02300891
heat sensor SB02300804
control board SB08080872
NLA = no longer available; OBS = obsolete
Hood Inserts and Power Packs
20
transformer SB02300861
bottom panel 52cm SBE3403940
bottom panel 70cm SBE3403941
light socket/housing SB02300798
panel hinge SB02011376
switch assembly SB06108780
6” damper/duct connector SB080814501
blower assembly S97017924
hardware package--mounting screws SB08084041
hardware package---junction boxes SB08084042
P511 (BEST) OBSOLETE UNIT
blower assembly SB06001571 (NLA)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
damper/duct connector SB080810111
capacitor SB02300653
resistor S02300654
control board S08086096 (OBS 11-2013)
switch assembly white S06104709 (NLA)
indicator lens S03200793
lamp holder S02300627
light lens S03202061
filter 51cm 8-11/16”x16-5/16” S08087720 (OBS)
filter 81cm 8-3/4”x28-1/8” S08087721
charcoal filter---round---set of 2 SB03300498
filter retaining wire S02000277
grille assembly 51cm white S083110330 (NLA)
grille assembly 81cm white SB083110333 (NLA)
grille assembly 81cm black SB083110334
right grille latch white SB05000028
left grille latch white SB05000029
right grille latch black SB05000048 (NLA)
left grille latch black SB05000049 (NLA)
PIK33 & PIK45 (VENMAR)
control board w/switches SV03255
switch knobs SV12969
light bezel/chrome ring (PIK33-2 PIK45-3) SV03241
light socket (PIK33-2 PIK45-3) SV03685
bulb PAR20 50 Watt (PIK33-2 PIK45-3) SV02544
wire harness SV05870
male power connector SV02773
female power connector SV02772
logo SV05869
filter clip (PIK33-3 PIK45-4) SV05528
baffle filter 9 1/4 x 12 1/2 (PIK33-3 PIK45-2) SV13431
baffle filter 11 1/8 x 12 1/2 (PIK45-2) SV13432
heat sentry SV03435
grease rail 33” SV15085
grease rail 45” SV15086
hardware package (installation screws, nuts, washers,
wire nuts, drywall anchors & wire clamp) SV03888
PIK33 & PIK45 REV B (VENMAR)
CHANGED TO GU10 BULB JAN 2007
SERIAL 0201070101530
control board w/switches SV03255
switch knobs SV12969
lamp housing, socket and trim (PIK33-2 PIK45-3)
SV16555
halogen bulb 50 Watt GU10 (PIK33-2 PIK45-3)
SV05921
wire harness SV07399
splitting harness (PIK45 only) SV07400
male power connector SV02773
female power connector SV02772
logo SV05869
filter clip SV05528
baffle filter 9 1/4 x 12 1/2 (PIK33-3 PIK45-2) SV13431
baffle filter 11 1/8 x 12 1/2 (PIK45-2) SV13432
heat sentry SV03435
hardware package SV03888
(4-lock nuts no. 10-32, 1-wire clamp, 2-wire connec-
tors, 8 - 8 x 3/4” screws, 8 - 8 x 3/8” screws, 2 - 6 x
1/2” screws)
PIK33 & PIK45 REV C (VENMAR)
March 2009
CHANGED LIGHT TRIM TO GRAY & REDESIGN OF
BAFFLE FILTERS SERIAL 0203090301395
logo SV05869
filter spacer (requires 2) SV12515
heat sentry SV03435
control board SV03255
male power connector SV02773
female power connector SV02772
lamp housing, socket and gray trim SV16569
(PIK33-2, PIK45-3)
halogen bulb 50 Watt GU10 SV05921
(PIK33-2, PIK45-3)
baffle filters 8.4” x 12.5” SV18264
baffle filters 12” x 12.5” SV18267
Baffle Filter Quantities
PIK33- 2 - small, 1 - large
PIK45- 2 - small, 2 - large
switch slide knobs SV12969
filter springs (set of 6) SV08337
wire harness SV07399
splitting harness SV07400
hardware package SV03888
(4-lock nuts no. 10-32, 1-wire clamp, 2-wire connectors, 8
- 8 x 3/4” screws, 8 - 8 x 3/8” screws, 2 - 6 x 1/2” screws)
PIK33 & PIK45 REV D (VENMAR)
May 2011
ADDED HANDLES TO BAFFLE FILTERS
SERIAL 0204110500243. REV E was just a logo
change
logo SV05869
filter spacer (requires 2) SV12515
heat sentry SV03435
control board SV03255
male power connector SV02773
female power connector SV02772
lamp housing, socket and gray trim (PIK33-2, PIK45-3)
SV16569
halogen bulb 50 Watt GU10 (PIK33-2, PIK45-3)
SV05921
baffle filters w/handles 8.4” x 12.5” SV18264
baffle filters w/handles 12” x 12.5” SV18267
Baffle Filter Quantities
PIK33- 2 - small, 1 - large
PIK45- 2 - small, 2 - large
filter handle w/screws (1 pack) SV07680
switch slide knobs SV12969
filter springs (set of 6) SV08337
wire harness SV07399
splitting harness for PIK45 only SV07400
hardware package SV03888
(4-lock nuts no. 10-32, 1-wire clamp, 2-wire connec-
tors, 8 - 8 x 3/4” screws, 8 - 8 x 3/8” screws, 2 - 6 x
1/2” screws)
PIK33D OUTDOOR UNIT (VENMAR)
OBS Sept. 2012
light switch SV06495
fan switch SV06496
speed control SV06364
speed control knob SV03504
light bezel/chrome ring (qty 2) SB02009102
light socket (qty 2) SV06498
bulb 120V 50W GU10 (requires 2) SV05921
logo SV05869
filters (req 3) baffle filters 9-1/4” x 12-1/2” SV15422
(does not have handles)
filter clips (req 3) SV15432
heat sentry SV06497
transition SV03428
hardware package SV04216
(installation screws, washers, wire nuts, drywall
anchors & 2 wire clamps)
PIK33D REV B OUTDOOR UNIT
(VENMAR) JULY 2010; OBS Sept.
2012
CHANGED LIGHT TRIM TO GRAY.
SERIAL 0201100700034
light switch SV06495
fan switch SV06496
speed control SV06364
speed control knob SV03504
lamp shell, socket & trim assembly SV16765
bulb 120V 50W GU10 (requires 2) SV05921
logo SV05869
filters (req 3) baffle filters 9-1/4” x 12-1/2” SV15422
(does not have handles)
filter clips (req 3) SV15432
heat sentry SV06497
transition SV03428
hardware package SV04216
(installation screws, washers, wire nuts, drywall
anchors & 2 wire clamps)
NLA = no longer available; OBS = obsolete
Hood Inserts and Power Packs
21
PK22 REV A (BEST) BLACK SLIDE
SWITCHES
blower assembly SB06001882/OBS NLA
motor (req 2) SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting rubber SB03202007 (Rpl by
SB03204177)
damper duct connector metal SB080810199
damper duct connector plastic SB080810265 OBS
RPL BY SB08085018
capacitor with wires SB06107068
control board SB08080141 (RPL by SB08086141)
switch assembly black w/knobs SB06105580
transformer 29” (qty 1) SB02300670
transformer 38” (qty 2) SB02300670
light socket SB02300688
socket support SB02009103
bulb MR16 12v 20 Watt SB02300774
bezel SB02009102
filter spring SB02000191
filter PK2229 plastic finger well (req 3) 8-9/16”x11-3/8”
SB08087305
filter PK2238 plastic finger well (req 4) 8-9/16”x11-3/8”
SB08087305
frame PK2229 SBE3401300
frame PK2238 SE3401303
fuse SB02300782
fuse holder SB02300674
filter finger tab grey round front SB03292425
filter finger tab grey round back SB03292426
hardware package SB080810511
(4 screws 4.2 x 15mm pan head & 2 screws M4 x
30mm pan head)
PK22 REV B Heat Sentry July 2002
(BEST) BLACK SLIDE SWITCHES
blower assembly SB06002008
motor (req 2) SB02310201
blower wheel SB03295071
motor mounting bracket SB03202007 (Rpl by
SB03204177)
damper duct connector SB080810265 OBS RPL BY
SB08085018
capacitor SB02300233
control board SB08086668
switch assembly black w/knobs SB06107567
transformer 29” qty 1 SB02300783
transformer 38” qty 1 SB02300792
light socket SB02300688
socket support SB02009103
bulb MR16 12v 20 Watt SB02300774
bezel SB02009102
filter spring SB02000191
filter 29” metal finger well (req 3) 8-9/16”x11-3/8”
SB08087156
filter 38” metal finger well (req 4) 8-9/16”x11-3/8”
SB08087156
frame 29” SBE3402992
frame 38” SBE3402996
fuse SB02300782
fuse holder SB02300674
heat sentry SB02300787
hardware package SB080810511
(4 screws 4.2 x 15mm pan head & 2 screws M4 x
30mm pan head)
PK22 REV C Flip latch style
filters April 2004 (BEST)
BLACK SLIDE SWITCHES
blower assembly SB06002008
motor (requires 2) SB02310201
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
damper duct connector SB080810265 OBS RPL BY
SB08085018
capacitor SB02300233
control board SB08086668
switch assembly black w/knobs SB06107567
transformer 29” qty 1 SB02300783
transformer 38” qty 1 SB02300792
light socket SB02300688
socket support SB02009103
bulb MR16 12v 20 Watt SB02300774
bezel SB02009102
filter 29” flip latch (req 3) 8-5/8”x11-3/4” SB08087189
filter 38” flip latch (req 4) 8-5/8”x11-3/4” SB08087189
frame 29” SBE3403649
frame 38” SBE3403651
fuse SB02300782
fuse holder SB02300674
heat sentry SB02300787
hardware package SB080810511
(4 screws 4.2 x 15mm pan head & 2 screws M4 x
30mm pan head)
PK22 REV D 120 volt lighting
Oct 2005 (BEST) BLACK SLIDE
SWITCHES OBSOLETE UNIT
blower assembly SB06002008
motor (requires 2) SB02310201
blower wheel SB03295071
motor mounting rubber SB03202007 (Rpl by
SB03204177)
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) 9/07 SB08092501
capacitor SB02300233
control board SB08086668
switch assembly black w/knobs SB06107567
light socket SB06108800
bulb 120 volt 50 watt GU10 SB02300899
(RPL by SV05921)
bezel SB02009102
filter 29” flip latch (req 3) 8-5/8”x11-3/4” SB08087189
filter 38” flip latch (req 4) 8-5/8”x11-3/4” SB08087189
heat sentry SB02300787
light support bar 29” SBE3404074
light support bar 38” SBE3404076
bottom frame 29” SBE3404073
bottom frame 38” SBE3404075
hardware package SB080810511
(4 screws 4.2 x 15mm pan head & 2 screws M4 x
30mm pan head)
PKEX22 REV A (BEST) BLACK
SLIDE SWITCHES
control board SB08080141 (RPL by SB08086141)
switch assembly w/knobs SB06107378
transformer SB02300729
fuse (5 amp) SB02300781
fuse holder SB02300674
light socket SB02300688
socket support SB02009103
bulb MR16 12v 20 Watt SB02300774
bezel SB02009102
filter spring SB02000191
filter--- metal finger well (req 4) 8-9/16”x11-3/8”
SB08087156
frame SE3401303
damper/duct connector SB080810265 OBS RPL BY
SB08085018
hardware package SB080810511
(4 screws 4.2 x 15mm pan head & 2 screws M4 x
30mm pan head)
PKEX22 REV B Heat Sentry
Sept 2003 (BEST) BLACK SLIDE
SWITCHES
control board w/triac for motor speeds SB08080141
(RPL by SB08086141)
control board SB08086668
switch assembly w/knobs SB06108090
transformer SB02300729
fuse (5 amp) SB02300781
fuse holder SB02300674
light socket SB02300688
socket support SB02009103
bulb MR16 12v 20 Watt SB02300774
bezel SB02009102
filter spring SB02000191
filter - metal finger well (req 4) 8-9/16”x11-3/8”
SB08087156
frame SE3401303
heat sentry SB02300787
damper/duct connector SB080810265 OBS RPL BY
SB08085018
hardware package SB080810511
(4 screws 4.2 x 15mm pan head & 2 screws M4 x
30mm pan head)
PKEX22 REV C Flip latch
style filters April 2004 (BEST)
BLACK SLIDE SWITCHES
control board w/triac for motor speeds SB08080141
(RPL by SB08086141)
control board SB08086668
switch assembly w/knobs SB06108090
transformer SB02300729
fuse (5 amp) SB02300781
fuse holder SB02300674
light socket SB02300688
socket support SB02009103
bulb MR16 12v 20 Watt SB02300774
bezel SB02009102
filter---metal flip latch (req 4) 8-5/8”x11-3/4”
SB08087189
NLA = no longer available; OBS = obsolete
Hood Inserts and Power Packs
22
frame SBE3403651
heat sentry SB02300787
damper/duct connector SB080810265 OBS RPL BY
SB08085018
hardware package SB080810511
(4 screws 4.2 x 15mm pan head & 2 screws M4 x
30mm pan head)
PKEX22 REV D 120 volt lighting
Oct 2005 (BEST) BLACK SLIDE
SWITCHES OBSOLETE UNIT
damper duct connector (plastic) SB08085018
damper/duct connector (metal) 9/07 SB08092501
control board SB08086668
control board w/triac for motor speeds SB08080141
(RPL by SB08086141)
switch assembly black w/knobs SB06108571
light socket SB06108800
bulb 120 volt 50 watt GU10 SB02300899
(RPL by SV05921)
bezel SB02009102
filter 38” flip latch (req 4) 8-5/8”x11-3/4” SB08087189
heat sentry SB02300787
bottom frame 38” SBE3404075
light support bar 38” SBE3404076
hardware package SB080810511
(4 screws 4.2 x 15mm pan head & 2 screws M4 x
30mm pan head)
CP34, CP35 & CP37 REV A (VENMAR)
8” round damper/duct connector SV08543
(30”, 36” & 42” units only)
10” round duct adapter (48” unit only) SV08541
10” round vertical in-line damper SV08542
(CP37 unit only) (book as S421)
blower assembly (48” requires 2) SV08097
lamp housing, socket & trim ring (2 req) SV16569
halogen bulb 120 volt MR16 GU10 50 watt SV05921
heat sentry SV03435
light switch SV08338
speed control SV03501
blower and light knobs (contains 2) SV08578
blower rocker switch SV08548
filter side bars for 42” units only (pair) SV17852
grease rail 30” SV17870
grease rail 36” SV17871
grease rail 42” SV17872
grease rail 48” SV17873
logo SV05869
filter spring (set of six) SV08337
baffle filter 8.84” x 9.80”
30” (req 3) SV17600
36” (req 1 plus 2ea baffle filter listed below) SV17600
42” (req 4) SV17600
48” (req 5) SV17600
baffle filter 11.84” x 9.80”
36” (req 2) SV17603
baffle filter handle w/screws (one per pack) SV07680
wire harness SV60622
hardware package SV08545
(2-wire connectors, 1-wire clamp, 4 screws 8 x 3/8”,
9 chrome plated screws 8 x 1/2”, 10 mechanical screws
8-32 x 1/4”)
CP45I & CP47I REV A (VENMAR)
OBS JAN 2014
8” round damper/duct connector (CP45 units only)
SV08543
10” round duct adapter (CP47 units only) SV08541
10” round vertical in-line damper SV08542
(CP47 units only) (book as S421)
logo SV05869
grease rail 36” SV17871
grease rail 42” SV17872
grease rail 48” SV17873
grease rail 54” SV17874
grease rail 60” SV17875
grease rail 66” SV17876
blower assembly (CP47 units req 2) SV08582
(book as S97017924)
capacitor (CP47 units req 2) SV08783
(RPL BY S99271379)
heat sentry SV06138
control processor board (incl PLM board) SV08581
linklogic control board SV06628
(RPL BY S97017737)
switch assembly SV08583
lamp housing, socket & trim ring SV16569
(36” has 2 all other sizes have 4)
halogen bulb 120 volt MR16 GU10 50 watt SV05921
micro-mesh filter 8.84” x 9.80” SV08695
micro-mesh filter 11.84” x 9.80” SV08694
Micro-mesh filter quantities
36” one small & two large
42” four small
48” five small
54” three small & two large
60” one small & four large
66” five large
filter filler (one pair) used on 42” & 66” units only
SV17852
baffle filter 8.84” x 9.80” SV17600
baffle filter 11.84” x 9.80” SV17603
baffle filter 8.84” x 9.80” (includes micro-mesh filter)
SV17917
baffle filter 11.84” x 9.80” (includes micro-mesh filter)
SV17918
Baffle filter quantities
36” one small & two large
42” four small
48” five small
54” three small & two large
60” one small & four large
66” five large
Duct-free filters
36” S99010357-1 & S99010358-2
42” S99010357-4
48” S99010357-5
60” S99010357-1 & S99010358-4
filter spring (set of 6) SV08337
baffle filter handle with screws SV07680
wire harness CP45 SV08698
wire harness CP47 SV08699
hardware package SV08545
(2-wire connectors, 1-wire clamp, 4 screws 8 x 3/8”, 9
chrome plated screws 8 x 1/2”, 10 mechanical screws
8-32 x 1/4”)
CP47E REV A (VENMAR) OBS JAN
2014
logo SV05869
grease rail 36” SV17871
grease rail 48” SV17873
grease rail 60” SV17875
male connector SV13924
female connector SV13923
heat sentry SV06138
lamp housing, socket and trim ring SV16569
(36” has 2 other sizes have 4)
control processor board SV08701
(includes PLM board S97017737)
linklogic control board (PLM board) SV06628
(RPL BY S97017737)
switch assembly SV08583
halogen bulb 120 volt MR16 GU10 50 watt SV05921
micro-mesh filter 8.84” x 9.80” SV08695
micro-mesh filter 11.84” x 9.80” SV08694
Micro-mesh filter quantities
36” one small & two large; 48” five small; 60” one
small & four large
baffle filter 8.84” x 9.80” SV17600
baffle filter 11.84” x 9.80” SV17603
baffle filter 8.84” x 9.80” (includes micro-mesh filter)
SV17917
baffle filter 11.84” x 9.80” (includes micro-mesh filter)
SV17918
Baffle filter quantities
36” one small & two large; 48” five small; 60” one
small & four large
filter spring (set of 6) SV08337
baffle filter handle with screws SV07680
10” round vertical in-line damper SV08542
(book as S421)
wire harness SV08702
hardware package SV08545
(2-wire connectors, 1-wire clamp, 4 screws
8 x 3/8”, 9 chrome plated screws 8 x 1/2”,
10 mechanical screws 8-32 x 1/4”)
CPD OUTDOOR HOOD INSERT
(CHINA) July 2012
10” round duct connector (does not include damper)
S97018874
grease rail 36” S98010930
grease rail 48” S98010931
grease rail 60” S98010932
blower (requires 2) S97018875
capacitor (requires 2) S99271454
heat sentry S99271455
halogen bulbs--120 volt, 50 watt, GU10 SV05921
(2 on 30” ---4 on 48” & 60”)
filter filler 36” (one pair) S98010933
fitler filler 60” (one pair) S98010936
baffle filter (includes knob) S97018876
(2 on 30”----3 on 48” & 60”)
filter spring (set of six) S98010934
filter knob with screws (one pair) S99840023
light socket S97018879
rotary switch S99271456
suction cup tool S99526707
hardware package S97018878
NLA = no longer available; OBS = obsolete
Hood Inserts and Power Packs / Island Hoods
23
PK2230, PK2239, PK2245 JAN 2013
(VENMAR) GRAY SWITCHES
10” round adapter SV08541
10” round damper SV08542
blower requires 2 S97018985
electronic drive for blower SV20818
calibration button SV20817
black rocker switch SV08548
light socket SV05917
socket holder SV09435
light bezel stainless steel SV09434
bulb, GU10, PAR16, 120 volt, 50 watt SV05921
filter filler, 45” only (2 req) SV61044
baffle filter w/handle for 30”, 12” x 10” SV61045
baffle filter w/handle for 39” & 45”, 17” x 10” SV61046
control board SV20816
switch assembly SV20814
transformer 9 volts DC SV09022
logo SV05869
hardware package SV20830
PKEX2239 & PKEX2245 JAN 2013
(VENMAR) GRAY SWITCHES
auto-transformer and fuse kit--includes metal support
SV61049
control board SV20816
light socket SV05917
socket holder SV09435
light bezel stainless steel SV09434
bulb---GU10, PAR16, 120 volt, 50 watt SV05921
filter filler----45” only--2 required SV61044
baffle filter w/handle----17” x 10” SV61046
male power connector SV13924
female power connector SV13923
switch assembly SV20815
logo SV05869
hardware package SV20830
CP55IQ & CP57IQT (VENMAR)
DEC 2013
10” round adapter (CP57IQ only) SV08541
8” round adapter/damper (CP55IQ only) SV08543
logo SV05869
36” grease rail SV17871
42” grease rail SV17872
48” grease rail SV17873
54” grease rail SV17874
60” grease rail SV17875
66” grease rail SV17876
calibration button SV20817
BLDC blower CP57IQT requires qty 2 S97018985
LED driver and LED light harness extension SV21414
(qty 2 for 54, 60 & 66”)
LED module SV21413
(Two on 36, 42 & 48” Four on 54, 60 & 66”)
filter filler (comes as pair) only used on 42 & 66” units
SV61691
duct-free filter--one pair (for model CP55IQ only)
S97017930
baffle filter with micromesh & handle 8.84” x 8.61” x 1”
SV61639
baffle filter with micromesh & handle 11.84” x 8.61” x 1”
SV61640
FILTER QTYS
36”----1 small, 2 large
42”----4 small
48”----5 small
54”----3 small, 2 large
60”----1 small, 4 large
66”----5 large
control interface PCB for internal blowers SV21411
remote control PCB SV20816
electronic drive for CP55IQ SV21416
electronic drive for CP57IQT SV20818
black rocker switch SV08548
wire harness for CP55IQ SV21418
wire harness for CP57IQT SV20824
transformer 9 volts DC SV09022
10” round in-line damper SV08542
hardware package SV08545
(2 wire connectors, 1 wire clamp, 4 screws 8 x 3/8”, 9
chrome plated screws 8 x 1/2”, 10 mechanical screws
8-32 x 1/4”)
CP57E (VENMAR) DEC 2013
logo SV05869
36” grease rail SV17871
48” grease rail SV17873
60” grease rail SV17875
autotransformer and fuse kit (includes metal support)
SV61659
LED driver and LED light harness extension SV21414
LED module SV21413
baffle fiter with micromesh & handle 8.84 x 8.61 x 1”
SV61639
baffle filter with micromesh & handle 11.84 x 8.61 x 1”
SV61640
FILTER QTYS
36”----1 small, 2 large
48”----5 small
60”----1 small, 4 large
control interface PCB for external blower SV21412
remote control PCB SV20816
female connector SV13923
male connector SV13924
wire harness SV20825
hardware package SV08545
(2 wire connectors, 1 wire clamp, 4 screws 8 x 3/8”, 9
chrome plated screws 8 x 1/2”, 10 mechanical screws
8-32 x 1/4”)
P510 (BEST)
Parts no longer available
B01IS (BEST) OBSOLETE UNIT
blower assembly NLA
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
capacitor SB02300653
resistor S02300654
control board S08086109
switch assembly S06104602 (obsolete NLA)
knob (cylindrical) S03202183 (NLA)
knob (conical) S03202223 (NLA 12-31-13)
knob cover grey S03202224
indicator lens S03200793
micro switch SB02300620
transformer SB02300670
lamp socket S02300667
socket insulator S03202164
lamp protector SB03292296
bulb MR16 20 Watt---qty 2 SB02300774
grille spring---qty 2 SB020002340
grille/filter 11 x 15 3/4” S08088749 (OBS 12-2012)
damper/duct connector SB080810111
flue gasket black--qty 4 SB03202430
glass gasket clear--qty 4 S03204093
logo silver S03202159
logo black SB03202436
logo white SB03202437
Flues
upper SS SE3495581 (NLA)
upper WH SB031097982
lower SS SB003181960 (NLA)
lower WH SB003181961 (NLA)
upper skeleton bracket S031094742
upper skeleton SB031093082
lower skeleton SB031094732 (NLA)
fuse SB02300782
hardware package SB080810120
(3 glass brackets front SBE3334547, sides SE3334548,
glass gasket, installation screws & drywall anchors)
B02IS (BEST) OBSOLETE UNIT
blower assembly NLA
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
capacitor SB02300653
resistor S02300654
control board S08086112 (11-2012 NLA)
switch assembly S06104960
switch membrane S03204101
transformer SB02300670
lamp socket S02300667
socket insulator S03202164
lamp protector SB03292296
bulb MR16 12 volt 20 Watt---qty 2 SB02300774
grille spring---qty 2 SB020002340
grille/filter 17 3/4” round S08088744
damper duct connector SB080810111
flue gasket--qty 4 SB03202430
NLA = no longer available; OBS = obsolete
Island Hoods
24
glass gasket clear--qty 2 S03204093
logo silver S03202159
logo black SB03202436
logo white SB03202437
indicator lens SB03201014
Flues
upper SS SE3400435
lower SS SE3400436
upper BL SB03114397 (NLA)
lower BL SB03114398 (NLA)
fuse SB02300782
hardware package SB080810120
(3 glass brackets front SBE3334547, sides SE3334548,
glass gasket, installation screws & drywall anchors)
BER01IS (BEST) OBS 11-2002
spring SB020002340
blower assembly SB06001801
motor SB02310094
blower wheel SB03295076
rubber washer SB03202007 (Rpl by SB03204177)
switch assembly SB06106380
switch buttons SB03202296
capacitor SB06106272
light socket SB02300727
control board SB08080602 (11-2012 NLA)
transformer SB02300739
damper/duct connector SB080810111
lower skeleton SB031094732 (NLA)
upper skeleton SB03117526 (NLA)
bulb protection SB03292296
bulb MR16 12 volt 20 Watt---qty 2 SB02300774
grille/filter 11 x 15 3/4” S08088749 (OBS 12-2012)
charcoal filter SB03300424
logo (adhesive black w/silver letters) SB08091852
logo old style black order new style
logo old style white SB03202437
Flues
lower SS SB003182145
upper SS SBE3495597 (NLA)
plastic gasket/lower flue--qty 4 SB03202430
glass gasket S03204093
glass bracket sides SE3334548
glass bracket front SBE3334547
recirculating kit* SB08820163
hardware package SB080810237
(includes: glass gasket S032044093, front glass
bracket SBE3334547, side glass bracket SE3334548)
*recirculation kit is a special order. It includes vented
upper flue and charcoal filters. 16-20 week lead time.
BER02IS REV A (BEST)
filter spring SB020002340
blower assembly SB06001801
motor SB02310094
blower wheel SB03295076
rubber washer SB03202007 (Rpl by SB03204177)
switch assembly SB06106383
switch button SB03202296
capacitor SB06106272
light socket SB02300727
control board SB08080602 (11-2012 NLA)
transformer SB02300739
damper duct connector SB080810111
lower skeleton SB031094732 (NLA)
upper skeleton SB031094722
blower protection SE3334545
lamp protection SB03292296
bulb MR16 12 volt 20 Watt---qty 2 SB02300774
grille 17 3/4” round S08088744
Flues
upper SS SE3400435
lower SS SE3400436
plastic gasket (qty 4) SB03202430
glass gasket S03204093
glass front bracket SBE3334547
glass bracket sides SE3334548
logo (adhesive black w/silver letters) SB08091852
logo old style (black) order new style
logo old style (white) SB03202437
fuse SB02300782
hardware pkg (ceiling bracket w/screws) SB080810114
hardware pkg SB080810590
(glass mtg hdw) (includes two bulbs, glass gasket, 2
glass mtg brackets, mtg screws, washers and bolts,
adhesive foam strip and adhesive tape)
hardware pkg SB080810320
(switch box top SBE3335756, switch box bottom (in-
cludes logo & labeled holes for switches)SB003182151,
4 mounting screws and two washers)
BER02IS REV B Heat Sentry Nov
2002 (BEST) OBS 9-2012
filter spring SB020002340
blower assembly SB06002019
motor SB02310184
blower wheel SB03295071
rubber washer SB03202007 (Rpl by SB03204177)
switch assembly (includes part number SBE3343007
key #92 ) SB06107676
switch button SB03202296
capacitor w/wires SB06107677
light socket SB02300727
control board SB08086662
transformer SB02300783
transformer after Oct-11-2010 SB02300739
damper duct connector (plastic) SB080810111
damper/duct connector (metal) 9/07 SB08092518
lower skeleton SB031094732 (NLA)
upper skeleton SB031094722
blower protection SBE3403023
lamp protection SB03292296
bulb MR16 12 volt 20 watt SB02300774
grille 17 3/4” round S08088744
upper flue SE3400435
lower flue SE3400436
plastic gasket (qty 4) SB03202430
glass gasket S03204093
glass front bracket SBE3334547
glass bracket sides SE3334548
logo (adhesive silver) SB02011284
(RPL by SV05869)
fuse SB02300782
heat sentry SB02300787
hardware pkg SB080810590
(glass mtg hdw) (includes two bulbs, glass gasket, 2
glass mtg brackets, mtg screws, washers and bolts,
adhesive foam strip and adhesive tape)
hardware pkg (ceiling bracket w/screws) SB080810114
hardware pkg SB080810320
(switch box top SBE3335756, switch box bottom (in-
cludes logo & labeled holes for switches) SB003182151,
4 mounting screws and two washers)
IBF4I (BEST MFG @ ATLAN)
upper & lower flue S99528360
blower assembly S99528361
light socket assembly---uses 4 S99526975
light trim ring/lens---uses 4 S99527010
halogen bulb --Type JC, 12V, 20 watt G4 base
SB02300891
switch assembly S99527660
control board S99527665
transformer S99527011
grease filters---uses 3 S97018908
duct-free filter S99527023
damper/duct connector S99526983
6” expandable flexible aluminum duct S99526984
duct-free plenum S99528362
angel mounting bracket---uses 8 S99528363
ceiling mounting bracket w/outlet box S99528364
capacitor S99527662
duct free filter clips S99528459
hardware package S99527132
IC35I Secret (BEST) SPRING 2011
grill SB08087677
grease filter SB08087826
duct-free filter SB03300495
capacitor SB02300233
bulb (Type T4 120 volt 25 watt G9 base) SB02300890
heat sentry SB02300804
motor SB02310260
blower wheel SB03295071
6” to 5” reducer SB03295018
wires SB02300961
top glass/IC35I90B SB002090356
top glass/IC35I90W SB002090357
duct connector duct-free SB03292300
damper/duct connector SB08088378
upper duct extension SB08092915
upper duct extension SBE3404968
lower duct extension SB08092980
duct-free plenum SB08092981
lower skeleton SB08093107
control board SB08080852
light socket SB02300918
flexible duct SB02011452
switch assembly SB06103891
blower assembly SB06002157
hardware pkg SB080810938
IEX42 REV A (BEST)
control board SB08080141 (RPL by SB08086141)
switch assembly SB06107515
fuse SB02300782
fuse holder SB02300674
transformer SB02300729
bulb MR16 12 volt 20 watt SB02300774
light socket SB02300688
NLA = no longer available; OBS = obsolete
Island Hoods
25
socket support SB02009103
socket protector SB02009193
bezel SB02009102
logo SB03202436
damper/duct connector (metal) SB080810199
lower skeleton SB03109013
upper skeleton SB03109014
lower flue SS SBE3403622
upper flue SS SBE3403623
bottom trim SS 70 x 100cm SB003181955
filter (req 6) 9-3/8”x11-3/4” slide latch SB08087151
hardware package SB080810004
(includes screws, nuts and washers)
IEX42 REV B Heat Sentry Sept
2003 (BEST) OBS JAN 2014
control board w/triac for motor speeds SB08080141
(RPL by SB08086141)
control board SB08086668
switch assembly SB06108101
fuse SB02300782
fuse holder SB02300674
transformer SB02300729
heat sentry SB02300787
bulb MR16 12 volt 20 watt SB02300774
light socket SB02300688
socket support SB02009103
socket protector SB02009193
bezel SB02009102
logo (adhesive silver) SB02011284
(RPL by SV05869)
damper/duct connector (metal) SB080810199
lower skeleton SB03109013
upper skeleton SB03109014
lower flue SS SBE3403622
upper flue SS SBE3403623
bottom trim SS 70 x 100cm SB003181955
filter (req 6) 9-3/8”x11-3/4” flip latch SB08087131
hardware package SB080810004
(includes screws, nuts and washers)
IEX102 REV A (BEST)
control board w/triac SB08080141
(RPL by SB08086141)
switch assembly SB06107455
fuse SB02300782
fuse holder SB02300674
transformer SB02300729
halogen bulb Type JC 12v 20 watt G4 SB02300891
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
logo SB003183758
damper/duct connector (metal) SB080810199
lower skeleton SB03109013
upper skeleton SB03109033
lower flue SS SE3495392
upper flue SS SBE3402898
side trim rod SB02009091
utensil rail chrome S02000556
center filter (req 2) 11-11/16”x14-1/4” flip latch
SB08087161
right filter (req 2) flip latch SB08087159
(filter has trapezoidal shape)
left filter (req 2) flip latch SB08087160
(filter has trapezoidal shape)
hardware package SB080810526
(installation screws, washers & nuts)
IEX102 REV B Heat Sentry Sept
2003 (BEST) OBS JAN 2014
control board SB08086668
control board/triac SB08080141
(RPL by SB08086141)
switch assembly SB06108098
fuse SB02300782
fuse holder SB02300674
transformer SB02300729
halogen bulb Type JC 12v 20 watt G4 SB02300891
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
logo (adhesive silver) SB02011284
(RPL by SV05869)
damper/duct connector (metal) SB080810199
lower skeleton SB03109013
upper skeleton SB03109033
lower flue SS SE3495392
upper flue SS SBE3402898
side trim rod SB02009091
utensil rail chrome S02000556
center filter (req 2) 11-11/16”x14-1/4” flip latch
SB08087161
right filter (req 2) flip latch SB08087159
(filter has trapezoidal shape)
left filter (req 2) flip latch SB08087160
(filter has trapezoidal shape)
heat sentry SB02300787
hardware package SB080810526
(installation screws, washers & nuts)
IEX170 REV A (BEST)
control board SB08086670
transformer SB02300729 before June 2002
SB02300792 after June 2002
socket support SB02009103
light socket SB02300688
switch assembly SB06107370
logo SB03202436
spring SB02000191
bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
damper/duct connector (metal) SB080810199
grease filter (req 4) 9-5/8”x10-1/8” metal finger well
SB08087152
upper flue SBE3402818
lower flue SBE3400447
upper skeleton SB03109011
lower skeleton SB03109019
fuse SB02300782
hardware package SB080810504
(installation screws, glass mtg brackets (qty 3), glass
pads & drywall anchors)
IEX170 REV B Heat Sentry April
2003 (BEST)
control board SB08086670
transformer SB02300792
socket support SB02009103
light socket SB02300688
switch assembly SB06107370
logo SB03202436
spring SB02000191
bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
damper/duct connector (metal) SB080810199
grease filter (req 4) 9-5/8”x10-1/8” metal finger well
SB08087152
heat sentry SB02300787
upper flue SBE3402818
lower flue SBE3400447
upper skeleton SB03109011
lower skeleton SB03109019
fuse SB02300782
hardware package SB080810504
(installation screws, glass mtg brackets (qty 3), glass
pads & drywall anchors)
IEX170 REV C Flip Latch Filter May
2004 (BEST) OBS JAN 2014
control board SB08086670
transformer SB02300792
transformer after Sept-30-2010 SB02300729
socket support SB02009103
light socket SB02300688
switch assembly SB06107370
logo (adhesive silver) SB02011284
(RPL by SV05869)
spring SB02000191
bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
damper/duct connector (metal) SB080810199
grease filter (req 4) 10-1/8”x10” flip latch SB08087078
heat sentry SB02300787
upper flue SBE3402818
lower flue SBE3400447
upper skeleton SB03109011
lower skeleton SB03109019
fuse SB02300782
hardware package SB080810504
(installation screws, glass mtg brackets (qty 3), glass
pads & drywall anchors)
IEX222 REV A (BEST)
logo (adhesive black w/silver letters) SB08091852
switch assembly SB06103241
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
transformer before June 2002 SB02300729
transformer after June 2002 SB02300792
control board (contains fuses) SB08086670
utensil rail front SB02009290
coupling (set of 2) SB02009186
utensil rail side SB02009301
halogen bulb Type JC 12 volt 20 watt SB02300891
filter 9-3/16”x15-5/16” slide latch SB08087599
damper/duct connector plastic SB08085018
NLA = no longer available; OBS = obsolete
Island Hoods
26
lower flue SBE3403622
upper flue SBE3403623
lower skeleton SB03120185
upper skeleton SB03120186
fuse (located on control board) SB02300782
hardware package SB080810004
(includes screws, nuts and washers)
IEX222 REV B Heat Sentry April
2003 (BEST)
logo (adhesive silver) SB02011284
(RPL by SV05869)
switch assembly SB06103241
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
transformer SB02300792
transformer after Sept-30-2010 SB02300729
control board (contains fuses) SB08086670
utensil rail front SB02009290
coupling (set of 2) SB02009186
utensil rail side SB02009301
halogen bulb Type JC 12 volt 20 watt SB02300891
filter 9-3/16”x15-5/16” flip latch SB08087141
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) 9/07 SB08092501
lower flue SBE3403622
upper flue SBE3403623
lower skeleton SB03120185
upper skeleton SB03120186
heat sentry SB02300787
fuse (located on control board) SB02300782
hardware package SB080810004
(includes screws, nuts and washers)
IM32I Double Vertigo (BEST) Spring
2011
frame SB08092783
grill SB03115221
grease filter SB08087691
duct-free filter SB08087695
capacitor SB02300976
bulb (Type JC 12 volt 20 watt G4 base) SB02300891
control board SB08080852
heat sentry SB02300804
motor SB02310731
top glass SB02005214
lower flue SBE3350690
upper flue SBE3350691
lower skeleton SB02011387
upper skeleton SB08093200
transformer SB02300861
light socket SB02300798
switch assembly SB06108625
hardware package SB080810953
IM33I GLOSS REV A (BEST) Spring
2011
frame SB03115266
spring SB02000191
grease filter SB08087027
duct-free filter SB03300300
capacitor SB02300233
heat sentry SB02300804
motor SB02310260
blower wheel SB03295071
6” to 5” reducer SB03295018
wires SB02300878
wires SB02300974
duct connector/duct free SB03294535
damper duct connector SB08088378
lower flue SB003102729
upper flue SB08092897
non-duct plenum SB08092898
lower skeleton SBE3403881
upper skeleton SB08092895
control board SB08080855
LED light qty 3 SB02300885
driver/feeder for LEDs SB02300973
(Do not send driver/feeder for LEDs out for REV A
hoods. See note below.*)
flex ducting SB02011452
blower assembly SB06002157
switch assembly SB06103825
hardware package SB080810952
*The original driver/feeder was discontinued. The new
driver/feeder has the same part number but the hood
now has 4 LEDS instead of 3. If someone is in need
of this part we will need to send them a kit containing
a new frame with 4 LEDS. It will include wiring instruc-
tions as well as a sticker for them to place on their
spec label to change the REV of the hood from A to B
Contact Technical Support for kit.
IM33I GLOSS REV B (BEST)
SERIAL 39-11-0001, 4 LED lights
frame SB03115266
spring SB02000191
grease filter SB08087027
duct-free filter SB03300300
capacitor SB02300233
heat sentry SB02300804
motor SB02310260
blower wheel SB03295071
6” to 5” reducer SB03295018
wires SB02300878
wires SB02300974
duct connector/duct free SB03294535
damper duct connector SB08088378
lower flue SB003102729
upper flue SB08092897
non-duct plenum SB08092898
lower skeleton SBE3403881
upper skeleton SB08092895
control board SB08080855
LED light qty 4 SB02300885
driver/feeder for LEDs SB02300998
flex ducting SB02011452
blower assembly SB06002157
switch assembly SB06103825
hardware package SB080810952
IM42I Sphera (BEST) JUNE 2012
frame white SB03102790
frame black SB03102797
grease filter---qty 1 SB08087696
bulb (req 2) MR11, 12 volt, 20 watt, G4 , 2 pin
SB02300882
heat sentry SB02300804
motor SB02310219
blower wheel SB03295076
rubber washer SB03204177
wires SB02301006
bottom duct extension SB08093038
upper duct extension SB08093285
control board SB08080865
light socket SB02320348
transformer SB02300861
cover SB08093286
capacitor w/wires SB06102235
switch assembly white SB06103984
switch assembly black SB06103891
blower assembly SB06002013
charcoal filter SB08087829
mounting template SB04302155
hardware package SB080810974
IP29M REV A (VENMAR) 2008 OBS
JAN 2014
control processor unit SV08069
particulates sensor SV08073
male connector SV13924
female connector SV13923
control interface SV08074
lamp shell, socket and trim assembly SV16569
(42” qty 4, 54” qty 6)
bulb 50 watt 120 volt PAR16 GU10 SV05921
baffle filter 8.95 x 8.61 x 1 SV16967
(includes micromesh filter) 42” qty 2
baffle filter 14.95 x 8.61 x 1 SV16968
(includes micromesh filter) 42” qty 1, 54” qty 3
baffle filter handle w/screws (one handle per pack)
SV07680
filter spring (qty 3 for all sizes) SV05528
micromesh filter 8.84 x 8.50 42” qty 2 SV07694
micromesh filter 14.84 x 8.50 42” qty 1, 54” qty 3
SV07695
grease rail 42” (rail is 36” long) SV16794
grease rail 54” (rail is 48” long) SV16796
inside frame 42” (includes filter springs) SV17448
inside frame 54” (includes filter springs) SV17449
heat sentry SV03435
logo SV05869
internal wire harness SV06631
hardware package SV08068
(steel wood screw 10 x 1.5 qty 10, screws 8 x 3/8 qty
6, washers #10 qty 10)
IP29M REV B (VENMAR) JAN 2013
control processor unit SV08069
particulates sensor SV08073
male connector SV13924
female connector SV13923
control interface SV08074
light socket SV05917
NLA = no longer available; OBS = obsolete
Island Hoods
27
socket holder SV09435
light trim SV09434
bulb 50 watt. 120 volt, PAR 16, GU10 SV05921
baffle filter 8.84” x 8.61” x 1” SV61639
baffle filter 11.84” x 8.61” x 1” SV61640
Filter quantities
42”----SV61639--qty 1, SV61640--qty 2
54”----SV61639--qty 5
42” grease rail SV61934
54” grease rail SV61935
heat sentry SV03435
logo SV05859
accessory hardware package SV06927
(5 lock nuts, 14 screws 8 x 3/8”, 10 steel washers #10,
wood screws 10 x 1.5” qty 10)
hardware package SV08068
(10 wood screws 10 x 1.5”, 6 screws 8 x 3/8”, washers
#10 qty 10)
IS1, IS2 & IS4 (BEST) OBSOLETE
UNITS
motor S02310010
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
capacitor S02300581
resistor S02300631
switch assembly white S06109822
switch assembly black SB06109827
control board S08086092 (NLA)
lamp holder S02300627
light lens S03200725
logo S03202159
filter 70 x 100 cm 9-3/16”x12-1/2” plastic finger well
S08087390
IS11 (BEST) OBSOLETE UNIT
blower assembly NLA
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
capacitor SB02300653
resistor S02300654
control board S08086096 (OBS 11-2013)
switch assembly white S06104127 (NLA)
switch assembly black SB06105065 (NLA)
ballast S02300657
tube holder S02300521
starter/tube holder S02300522
starter S02300659
fluorescent tube S02300500
light lens S03200725
logo silver S03202159
filter spring SB02000191
filter (requires 3) 9-3/16”x12-1/2” plastic finger well
S08087390
flues NLA
skeletons NLA
IS23 REV A (BEST)
logo SB03202436
spring SB02000191
blower assembly NLA
motor (prior to 1996) S02310010
motor SB02310036 (NLA 5-2012)
rubber washer SB03202007 (Rpl by SB03204177)
blower wheel (prior to 1996) SB03295089
(NLA 7-2012)
blower wheel SB03295076
control board SB08080101
switch assembly S06105055 (OBS 6-28-13)
resistor (prior to 1996) S02300631
resistor S02300654
capacitor (prior to 1996) S02300581
capacitor SB02300653
ballast/light socket S02300701
bulb 9 watt Fluorescent S02300700
light lens S03201016
upper flue ducted only SS SE3400403
upper flue w/non-duct vents SS SBE3400402
lower flue SS SE3400401
upper skeleton S03109066
lower skeleton S03109065
non-duct air deflector S080810001
duct connector SB03292300
damper flaps SB02000756
duct-free filter (set of 2) SB03300498
grease filter (req 3) 9-1/4”x16-1/2” plastic finger well
S08087401
hardware package SB080810126
(includes electrical wiring box & cover, damper duct
connector, installation screws & drywall anchors)
IS23 REV B (BEST) Heat Sentry Oct
2002
logo (adhesive silver) SB02011284
(RPL by SV05869)
blower assembly SB06002012
motor SB02310201
rubber washer SB03202007 (Rpl by SB03204177)
blower wheel SB03295071
control board SB08086668
switch assembly SB06107646
switch button (one per pack) SB03200361
switch push button extender SB03292301
capacitor SB02300233
ballast/light socket S02300701
bulb 9 watt Fluorescent S02300700
light lens S03201016
heat sentry SB02300787
upper flue ducted only SS SE3400403
upper flue w/non-duct vents SS SBE3400402
lower flue SS SE3400401
upper skeleton S03109066
lower skeleton S03109065
non-duct air deflector S080810001
duct connector SB03292300
damper flaps SB02000756
duct-free filter (set of 2) SB03300498
grease filter (req 3) 9-3/16”x15-5/16” flip latch
SB08087141
hardware package SB080810532
(damper duct connector, wiring box & cover, installa-
tion screws, nuts & washers)
IS32 (BEST) OBSOLETE UNIT
blower assembly SB06001898 (NLA) 2-2012
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007
(Rpl by SB03204177)
capacitor SB02300653
resistor - qty 2 (replace both - same time) S02300654
control board S08086096 (OBS 11-2013)
switch assembly S06104268 (NLA)
ballast S02300657
tube holder S02300521
starter/tube holder S02300522
starter S02300659
fluorescent tube 15 watt S02300500
light lens S03200725
logo silver S03202159
filter spring SB02000191
filter (requires 3) S08087388
upper flue SE3495450 (NLA)
lower flue SE3495451 (NLA)
IS41 Fluorescent light (BEST) OB-
SOLETE UNIT
blower assembly S06001534 (NLA 9-2012)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mtg rubber SB03202007 (Rpl by SB03204177)
resistor S02300654
control board S08086096 (OBS 11-2013)
switch assembly SB06105117
bulb holder S02300521
bulb holder/starter S02300522
starter S02300659
ballast S02300657
capacitor SB02300653
logo S03202159
filter spring SB02000191
light lens S03200725
fluorescent tube 15 watt S02300500
lower flue SBE3403622
upper flue SBE3403623
lower skeleton round S03109072
upper skeleton round S03109073
grease filter (6 req) 9-3/16”x12-1/2” plastic finger well
S08087390
charcoal filter SB03300498
hardware package SB080810004
(includes screws, nuts and washers)
IS41.1 (BEST) OBSOLETE UNIT
blower assembly S06001534 (NLA 9-2012)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mtg rubber SB03202007 (Rpl by SB03204177)
capacitor SB02300653
resistor S02300654
control board S08086096 (OBS 11-2013)
switch assembly SB06105117
transformer SB02300670
light socket SB02300688
socket support SB02009103
NLA = no longer available; OBS = obsolete
Island Hoods
28
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
logo S03202159
filter spring SB02000191
lower flue SBE3403622
upper flue SBE3403623
lower skeleton square SB03109013
upper skeleton square SB03109014
grease filter (6 req) 9-3/16”x12-1/2” plastic finger well
S08087390
charcoal filter SB03300498
hardware package SB080810004
(includes screws, nuts and washers)
IS42 Fluorescent light (BEST) OB-
SOLETE UNIT
blower assembly SB06001898 (NLA) 2-2012
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mtg rubber SB03202007 (Rpl by SB03204177)
resistor--qty 2 (replace both - same time) S02300654
capacitor SB02300653
tube holder S02300521
tube holder/starter S02300522
starter S02300659
ballast S02300657
switch assembly white SB06105067
switch assembly black SB06105117
control board S08086096 (OBS 11-2013)
logo S03202159
frame S03143105
filter spring SB02000191
fluorescent bulb 15 watt S02300500
light lens S03200725
lower flue SBE3403622
upper flue SE3407478 (NLA)
lower skeleton S03109072
upper skeleton S03109073
filter 70 x 100cm (req 6) S08087390
(9-3/16”x12-1/2” plastic finger well)
filter 90 x 130cm (req 8) SB08087322
(11-11/16”x14-1/4” metal finger well)
damper/duct connector (metal) SB080810199
hardware package SB080810004
(includes screws, nuts and washers)
IS42.1 REV A (BEST)
blower assembly SB06001539 OBS
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mtg rubber SB03202007 (Rpl by SB03204177)
damper/duct connector (metal) SB080810199
capacitor SB02300653
resistor--qty 2 (both need to be replaced at the same
time) S02300654
control board S08086096 (OBS 11-2013)
switch assembly white SB06105067
switch assembly black SB06105117
transformer SB02300670
light socket SB02300688
socket support SB02009103
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
logo SB03202436
filter spring SB02000191
filter 70 x 100cm (req 6) 9-3/16”x12-1/2” plastic finger
well S08087390
filter 90 x 130cm (req 8) 11-11/16”x14-1/4” metal finger
well SB08087322
upper flue SS SBE3403623
lower flue SS SBE3403622
upper flue CP SBE3407503 (NLA)
lower flue CP SBE3407502 (NLA)
upper flue BR SBE3407501
lower flue BR SBE3407500
lower skeleton square SB03109013
upper skeleton square SB03109014
hardware package SB080810004
(includes screws, nuts and washers)
IS42.1 REV B Heat Sentry July
2002 (BEST) OBS JAN 2014
blower assembly SB06002007
motor SB02310183
blower wheel SB03295071
motor mtg rubber SB03202007 (Rpl by SB03204177)
damper/duct connector (metal) SB080810199
capacitor SB02300233
heat sentry SB02300787
control board SB08086668
switch assembly black SB06107575
transformer SB02300792
transformer after Sept-30-2010 SB02300729
light socket SB02300688
socket support SB02009103
halogen bulb MR16 12 volt 20 watt SB02300774
bezel SB02009102
logo (adhesive silver) SB02011284
(RPL by SV05869)
filter 70 x 100cm (req 6) 9-3/8”x11-3/4” flip latch
SB08087131
filter 90 x 130cm (req 8) 9-3/16”x15-5/16” flip latch
SB08087141
upper flue SS SBE3403623
lower flue SS SBE3403622
upper flue CP SBE3407503 (NLA)
lower flue CP SBE3407502 (NLA)
upper flue BR SBE3407501
lower flue BR SBE3407500
lower skeleton square SB03109013
upper skeleton square SB03109014
hardware package SB080810004
(includes screws, nuts and washers)
IS102 REV A (BEST)
blower assembly SB06001898 (NLA) 2-2012
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
damper flaps SE3300528 (NLA)
capacitor SB02300653
resistor --qty 2 (replace both - same time) S02300654
control board S08086096 (OBS 11-2013)
switch assembly white SB06105067
switch assembly black SB06105117
ballast S02300657
tube holder S02300521
starter/tube holder S02300522
starter S02300659
fluorescent tube 15 watt S02300500
light lens S03200725
logo silver SB003180269
logo black SB003180252
logo white SB003180251
filter spring SB02000191
filter left (req 2) SB08087321
(filter has trapezoidal shape)
filter center (req 2) 11-11/16”x14-1/4” metal finger well
SB08087322
filter right (req 2) SB08087320
(filter has trapezoidal shape)
Flues
upper SS SE3495393
lower SS SE3495392
upper black SB03108611
lower black S03108610
lower skeleton S03109072
upper skeleton S03109073
Trim rod
SS SB02009091
WH SB031096022
Utensil rails
SS S02000556
Brass S02000557 OBS
Black S033108757 (NLA)
White S031099282 (NLA)
hardware package SB080810526
(installation screws, washers & nuts)
IS102 REV B Heat Sentry (BEST)
June 2002 OBS JAN 2014
blower assembly SB06002007
motor SB02310183
blower wheel SB03295071
damper flaps SBE3300527 (NLA)
damper/duct connector (metal) SB080810199
capacitor SB02300233
control board SB08086668
switch assembly black SB06107563
heat sentry SB02300787
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
halogen bulb Type JC 12 volt 20 watt G4 SB02300891
transformer SB02300792
transformer after Sept-30-2010 SB02300729
fuse SB02300782
fuse holder SB02300674
logo silver on silver (adhesive) SB02011284
(RPL by SV05869)
filter spring SB02000191
filter left (req 2) flip latch SB08087160
(filter has trapezoidal shape)
filter center (req 2) 11-11/16”x14-1/4” flip latch
SB08087161
filter right (req 2) flip latch SB08087159
(filter has trapezoidal shape)
Flues
upper SS SBE3402898
lower SS SE3495392
upper Black SB03108611
NLA = no longer available; OBS = obsolete
Island Hoods
29
lower Black S03108610
lower skeleton SB03109013
upper skeleton SB03109033
Trim rod
SS SB02009091
White SB031096022
Utensil rails
SS S02000556
Brass S02000557 OBS
Black S03108757 (NLA)
White S031099282 (NLA)
hardware package SB080810526
(installation screws, washers & nuts)
IS170 REV A (BEST)
blower assembly SB06001993
motor SB02310183
rubber motor mounts SB03202007 (Rpl by
SB03204177)
blower wheel SB03295071
capacitor SB02300233
damper/duct connector SB080810111
switch assembly SB06107370
control board SB08086661
transformer (qty 1) SB02300729 after
5-31-2002 use SB02300792
fuse SB02300782
fuse holder SB02300674
light socket (qty 4) SB02300688
socket support (qty 4) SB02009103
halogen bulb MR16 12 volt 20 watt (qty 4)
SB02300774
light bezel (qty 4) SB02009102
logo white SB03202437
logo SB03202436
lower skeleton SB03109019
upper skeleton SB03109011
lower flue SBE3400447
upper flue SBE3402818
grease filter (req 4) 9-5/8x10-1/8” metal finger well
SB08087152
filter spring SB02000191
charcoal filter SB03300488
hardware package SB080810504
(installation screws, glass mtg brackets (qty 3), glass
pads & drywall anchors)
IS170 REV B Heat Sentry April 2003
(BEST)
blower assembly SB06002019
motor SB02310201
rubber motor mounts SB03202007 (Rpl by
SB03204177)
blower wheel SB03295071
capacitor SB02300233
damper/duct connector SB080810111
switch assembly SB06107370
control board SB08086662
transformer (qty 1) SB02300792
fuse SB02300782
fuse holder SB02300674
light socket (qty 4) SB02300688
socket support (qty 4) SB02009103
halogen bulb MR16 12 volt 20 watt (qty 4)
SB02300774
light bezel (qty 4) SB02009102
logo white SB03202437
logo SB03202436
lower skeleton SB03109019
upper skeleton SB03109011
lower flue SBE3400447
upper flue SBE3402818
heat sentry SB02300787
grease filter (req 4) 9-5/8x10-1/8” metal finger well
SB08087152
filter spring SB02000191
charcoal filter SB03300488
hardware package SB080810504
(installation screws, glass mtg brackets (qty 3), glass
pads & drywall anchors)
IS170 REV C Flip Latch Filter May
2004 (BEST) OBS JAN 2014
blower assembly SB06002019
motor SB02310184
rubber motor mounts SB03202007 (Rpl by
SB03204177)
blower wheel SB03295071
capacitor SB02300233
capacitor w/wires SB06107368
damper/duct connector (plastic) SB080810111
damper/duct connector (metal) 9/07 SB08092518
switch assembly SB06107370
control board SB08086662
transformer (qty 1) SB02300792
transformer after Sept-30-2010 SB02300729
fuse SB02300782
fuse holder SB02300674
light socket (qty 4) SB02300688
socket support (qty 4) SB02009103
halogen bulb MR16 12 volt 20 watt (qty 4)
SB02300774
light bezel (qty 4) SB02009102
logo (adhesive silver) SB02011284
(RPL by SV05869)
lower skeleton SB03109019
upper skeleton SB03109011
lower flue SBE3400447
upper flue SBE3402818
heat sentry SB02300787
grease filter (req 4) 10-1/8”x10” flip latch SB08087078
filter spring SB02000191
charcoal filter SB03300488
hardware package SB080810504
(installation screws, glass mtg brackets (qty 3), glass
pads & drywall anchors)
IS502 REV A & B (REV B Flue rede-
sign) DEC 2002 (BEST)
logo (adhesive black w/silver letters) SB08091852
blower assembly SB06001992
motor SB02310183
blower wheel SB03295071
motor mtg rubber SB03202007 (Rpl by SB03204177)
control board SB08086661
switch assembly SB06107364
switch mounting bracket SBE3343134
transformer SB02300783
capacitor SB02300233
halogen bulb Type JC 12 volt 20 watt SB02300891
grille/filter 11”x11” SBE3402214
lower flue SB03183609
upper flue SBE3402799
lower skeleton SB03117867
upper skeleton SB03117868
light hardware kit SB080810506
(light housings SB08091547, light support rods
SB08091377, lamp holder supports SB02009346, rod
isolators SB03295078)
light housing (includes lens) SB08091547
light housing clamps SB08091377
light support rods SB02009318
(RPL by SB02009346)
support rod insulators (on flue) SB03295078
support rod clamps (on glass trim includes isolators)
SB08091429
upper flue mtg bracket SB08091550
grille/filter screws SB02000690
damper/duct connector SB080810111
fuse 4 amp SB02300782
fuse holder SB02300674
hardware package SB080810507
(support frame bracket assembled, mtg washers,
screws, nuts & filter knobs)
IS502 REV C Heat Sentry May 2003
(BEST) OBS JAN 2014
logo (adhesive silver) SB02011284
(RPL by SV05869)
blower assembly SB06002019
motor SB02310184
blower wheel SB03295071
motor mtg rubber SB03202007 (Rpl by SB03204177)
control board SB08086662
switch assembly SB06107364
switch mounting bracket SBE3343134
transformer SB02300783
transformer after Oct-11-2010 SB02300739
capacitor SB02300233
halogen bulb Type JC 12 volt 20 watt SB02300891
grille/filter 11”x11” SBE3402214
lower flue SB03183609
upper flue SBE3402799
lower skeleton SB03117867
upper skeleton SB03117868
light hardware kit SB080810506
(light housings SB08091547, light support rods
SB08091377, lamp holder supports SB02009346, rod
isolators SB03295078)
light housing (includes lens) SB08091547
light housing clamps SB08091377
light support rods SB02009346
support rod insulators (on flue) SB03295078
support rod clamps (on glass trim includes isolators)
SB08091429
upper flue mtg bracket SB08091550
grille/filter screws SB02000690
damper/duct connector (plastic) SB080810111
damper/duct connector (metal) 9/07 SB08092518
NLA = no longer available; OBS = obsolete
Island Hoods
30
fuse 4 amp SB02300782
fuse holder SB02300674
heat sentry SB02300787
hardware package SB080810507
(support frame bracket assembled (includes wiring
box and cover), mtg washers, screws, nuts & filter
knobs)
IS2304 (BEST) Discontinued 12-9-11
grease filter (qty 3) 9-3/16”x15-5/16” flip latch
SB08087141
capacitor SB02300233
fluorescent bulb S02300700
ballast S02300701
light lens S03201016
heat sentry SB02300787
non-duct filter support SB03290377
motor SB02310201
blower wheel SB03295071
rubber washer SB03204177
damper flap SB02000756
duct connector SB03292300
logo (adhesive silver) SB02011284
(RPL by SV05869)
lower flue SBE3402692
upper flue SBE3402691
duct free plenum S080810001
lower skeleton S03109065
upper skeleton S03109066
control board SB08086668
switch button (one per pack) SB03200361
switch push button extender SB03292301
switch assembly SB06107646
blower assembly SB06002012
duct free filter (set of two) SB03300498
terminal block SBR2300135
hardware package SB080810532
(damper duct connector, wiring box & cover, installa-
tion screws, nuts & washers)
ISE222 & 94ISE222 (BEST) OBSO-
LETE UNIT
blower assembly SB06001539 OBS
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
damper/duct connector (metal) SB080810199
capacitor SB02300653
resistor - qty 2 (replace both - same time) S02300654
control board S08086112 (11-2012 NLA)
switch assembly ISE222 (round grey buttons)
S06104675 (OBS 8-24-12)
switch assembly 94ISE222 (square black buttons)
SB06105462 (OBS 8-24-12)
switch membrane ISE222 (round grey buttons)
S03204101
switch membrane 94ISE222 (square black buttons)
S03292281
transformer (qty 2) SB02300670
light socket SB02300688
socket support SB02009103
bulb MR16 12 volt 20 Watt---qty 4 SB02300774
bezel SB02009102
logo silver S03202159
logo black SB03202436
logo white SB03202437
filter spring SB02000191
filter (req 4) 9-1/4”x16-1/2” plastic finger well
S08087341
brass front rail S02009133
brass side rail S02009137 OBS
brass coupling S02009134
brass spacer S02009131
chrome front rail OBS
chrome side rail OBS
chrome coupling S02009124
chrome spacer OBS
Flues
upper SS SBE3403623
lower SS SBE3403622
upper WH SB031099422 (NLA)
lower WH SB031099412 (NLA)
upper BL S03108728
lower BL OBS
upper copper SBE3407503 (NLA)
lower copper SBE3407502 (NLA)
upper brass SBE3407501
lower brass SBE3407500
lower skeleton round S03109072
upper skeleton round S03109073
lower skeleton square SB03109013
upper skeleton square SB03109014
hardware package SB080810004
(includes screws, nuts and washers)
ISER222 REV A (BEST)
filter (req 4) 9-3/16”x15-5/16” slide latch SB08087599
capacitor SB06106272
bulb Type JC 12 volt 20 watt SB02300891
motor SB082300530
blower wheel SB03295076
blower assembly SB06001805
motor mtg rubber SB03202007 (Rpl by SB03204177)
damper/duct connector SB080810265 OBS RPL BY
SB08085018
logo black SB03202436
logo white SB03202437
lower flue SS SBE3403622
upper flue SS SBE3407816 OBS RPL BY
SBE3403623
lower skeleton SB03120185
upper skeleton SB03120186
front utensil rail chrome SB02009290
front utensil rail brass SB02009319
side rail chrome SB02009301
side rail brass SB02009320
coupling chrome (set of 2) SB02009186
coupling brass (set of 2) SB02009177
control board SB08080602 (11-2012 NLA)
transformer SB02300729
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
switch assembly SB06106790
hardware package SB080810004
(includes screws, nuts and washers)
ISER222 REV B Heat Sentry Sept
2002 (BEST)
filter (req 4) 9-3/16”x15-5/16” flip latch SB08087141
capacitor SB02300233
bulb Type JC 12 volt 20 watt SB02300891
motor SB02310201
blower wheel SB03295071
blower assembly SB06002008
motor mtg rubber SB03202007 (Rpl by SB03204177)
damper/duct connector plastic SB08085018
damper/duct connector (metal) SB08092501
logo (adhesive silver) SB02011284
(RPL by SV05869)
lower flue SS SBE3403622
upper flue SS SBE3407816 (OBS RPL BY
SBE3403623)
lower skeleton SB03120185
upper skeleton SB03120186
front utensil rail chrome SB02009290
front utensil rail brass SB02009319
side rail chrome SB02009301
side rail brass SB02009320
coupling chrome (set of 2) SB02009186
coupling brass (set of 2) SB02009177
control board SB08086662
transformer SB02300792
transformer after Sept-30-2010 SB02300729
lamp housing/socket (includes bezel, glass & bulb)
SB02300790
switch assembly SB06103249
heat sentry SB02300787
fuse SB02300782
hardware package SB080810004
(includes screws, nuts and washers)
IPP9E (BEST) JAN 2014
grease filter (req 3) SB08087951
front light support panel SBE3351864
heat sentry SB02300804
wire assembly SB06102608
wiring box SBE3350233
wiring box cover SBE3334252
lower skeleton SB08093422
upper skeleton SB08093456
front trim SBE3405184
back trim SBE3405178
filter spacers SBE3351870
bulb 25 watt, 120 volt, T4, G9 base SB02300918
back light support panel SBE3351866
flue assembly (includes upper and lower) SB08016370
switch assembly SB06102607
10” damper/duct connector SBE3405192
electrical assembly SB06145226
42” grease rail SBE3405185
hardware package SB080810996
IPP9IQT (BEST) JAN 2014
grease filter---requires 3 SB08087951
front light support panel SBE3351864
heat sentry SB02300804
wire assembly SB06102599
wiring box SBE3350233
wiring box cover SBE3334252
NLA = no longer available; OBS = obsolete
Island Hoods / Professional Series
31
bottom skeleton SB08093422
upper skeleton SB08093456
front trim SBE3405184
back trim SBE3405178
filter spacers SBE3351870
bulb 25 watt, 120 volt, T4, G9 base SB02300918
back light support panel SBE3351866
flue assembly (includes upper and lower) SB08016370
BLDC driver S97019432
calibration button SB06102584
switch assembly SB06102600
10” damper/duct connector SBE3405192
electrical assembly SB06145225
blower assembly SB06002259
42” grease rail SBE3405185
hardware package SB080810996
ICF6IQ (BEST) JAN 2014
grease filter---requires 1 SB08087675
charcoal filter SB08999179
heat sentry SB02300804
wire assembly SB06102620
glass SB08092902
wiring box SB03292499
wiring box cover SBE3350233
lower flue SBE3334252
upper flue SB08092906
lower skeleton SB08092909
upper skeleton SB08092904
light trim SBE3405258
inside panel SB03115336
panel SB08092900
magnet SB02011377
LED bulb SB02300885
BLDC driver S97019432
calibration button SB06102584
switch assembly SB06102594
8” damper/duct connector SB080810849
electrical installation SB06145222
blower assembly SB06002259
hardware package SB080811005
IPB9E (BEST) FEB 2014
grease filter---requires 3 SB08087951
front light support panel SBE3351928
back light support panel SBE3351945
heat sentry SB02300804
wire assembly SB06102612
runner wires SB03292499
lower skeleton SB08093422
upper skeleton SB08093456
halogen bulb type T4, 120 volt, 25 watt, G9 base
SB02300918
upper and lower flue assembly SB08016373
switch assembly SB06102605
10” damper/duct connector SBE3405192
electrical installation assembly SB06145226
hardware package SB080811011
(includes 10” damper/duct connector)
IPB9IQ (BEST) FEB 2014
grease filter---requires 3 SB08087951
front light support panel SBE3351928
back light support panel SBE3351945
heat sentry SB02300804
wire assembly SB06102611
runner wires SB03292499
lower skeleton SB08093422
upper skeleton SB08093456
halogen bulb type T4, 120 volt, 25 watt, G9 base
SB02300918
upper and lower flue assembly SB08016373
BLDC driver S97019434
calibration button assembly SB06102584
switch assembly SB06102596
10” damper/duct connector SBE3405192
electrical installation assembly SB06145225
blower assembly SB06002259
hardware package SB080811011
(includes 10” damper/duct connector)
IC34E (BEST) FEB 2014
grease filter ---requires 3 SB08087679
front light support panel SBE3351998
back light support panel SBE3352074
heat sentry SB02300804
wire assembly SB06102628
front glass trim SB003102891
back glass trim SB08092983
runner wires SB03292499
lower skeleton SB08092904
upper skeleton SB08093457
LED bulb SB08093413
upper and lower flue assembly SB08016376
switch assembly SB06102595
10” damper/duct connector SB080810849
electrical installation assembly SB06145226
hardware package SB080811002
IC34IQ (BEST) FEB 2014
grease filter---requires 3 SB08087679
duct-free filter (one piece square) SB08999176
front light support panel SBE3351998
back light support panel SBE3352074
heat sentry SB02300804
wire assembly SB06102619
front glass trim SB003102891
back glass trim SB08092983
runner wires SB03292499
lower skeleton SB08092904
upper skeleton SB08093457
LED bulb SB08093413
upper and lower flue assembly SB08016376
switch assembly SB06102594
10” damper/duct connector SB080810849
BLDC driver S97019431
calibration button assembly SB06102584
electrical installation assembly SB06145225
blower assembly SB06002259
hardware package SB080811002
K210A (VENMAR)
switch faceplate Black SV12969
lamp bezel SV03241
light socket SV03685
control board with switches SV03255
heat sentry SV03435
heat sentry bracket SV03436
male connector SV02773
female connector SV02772
side liners 30” SV12514
side liners 36” SV12515
side liners 42” SV13113
side liners 48” SV12516
grease channel 30” 22-3/8” long SV13220
grease channel 36” 27-3/4” long SV13221
grease channel 42” SV13112
grease channel 48” 37” long SV13222
logo white SB03202437
logo black SB03202436
halogen bulb PAR 20 120 volt 50 watt SV02544
wiring harness SV03240
filter clips SV05528
Filters Metal Finger Well
30” (req 2) 11 1/8 x 12 1/2 SV03461
36” (req 3) 9 1/4 x 12 1/2 SV03462
42” (req 3) 11 1/8 x 12 1/2 SV03461
48” (req 4) 9 1/4 x 12 1/2 SV03462
Optional baffle filters
30” (req 2) 11 1/8 x 12 1/2 SV13432
36” (req 3) 9-1/4”x12-1/2” SV13431
42” (req 3) 11 1/8 x 12 1/2 SV13432
48” (req 4) 9 1/4 x 12 1/2 SV13431
hardware package SV13278
(installation screws, nuts, wire nuts & wire clamp)
K210A REV B (VENMAR)
Changed to GU10 bulb Jan 2007 SERIAL
0202070101586
switch faceplate/knobs black SV12969
lamp housing, socket & trim (silver) SV16555
(30” & 36” QTY 2 -- 42” & 48” QTY 3)
halogen bulb GU10 50 Watt SV05921
(30” & 36” QTY 2 -- 42” & 48” QTY 3)
control board SV03255
heat sentry SV03435
heat sentry bracket SV03436
male connector SV02773
female connector SV02772
Filters
30” (requires 2) 11 1/8 x 12 1/2 SV03461
36” (requires 3) 9 1/4 x 12 1/2 SV03462
42” (requires 3) 11 1/8 x 12 1/2 SV03461
48” (requires 4) 9 1/4 x 12 1/2 SV03462
Optional baffle filters
30” (requires 2) 11 1/8 x 12 1/2 SV13432
36” (requires 3) 9 1/4 x 12 1/2 SV13431
42” (requires 3) 11 1/8 x 12 1/2 SV13432
48” (requires 4) 9 1/4 x 12 1/2 SV13431
grease rail 30” 22-3/8” long SV13220
grease rail 36” 27-3/4” long SV13221
grease rail 42” SV13112
grease rail 48” 37” long SV13222
logo (silver adhesive) SV05869
NLA = no longer available; OBS = obsolete
Professional Series
filter spring (30” & 36” req 3 - 42” & 48” req 4) SV05528
wire harness SV07398
splitting harness (42” & 48” units only) SV07400
hardware package SV13278
(installation screws, nuts, wire nuts & wire clamp)
K210A REV C (VENMAR)
Changed lamp housing trim to gray. Serial Number
0204090900491
switch faceplate/knobs black SV12969
lamp housing, socket & trim (gray) SV16569
(30” & 36” QTY 2 42” & 48” QTY 3)
halogen bulb GU10 50 Watt SV05921
(30” & 36” QTY 2 -- 42” & 48” QTY 3)
control board SV03255
heat sentry SV03435
heat sentry bracket SV03436
male connector SV02773
female connector SV02772
Filters
30” (requires 2) 11 1/8 x 12 1/2 SV03461
36” (requires 3) 9 1/4 x 12 1/2 SV03462
42” (requires 3) 11 1/8 x 12 1/2 SV03461
48” (requires 4) 9 1/4 x 12 1/2 SV03462
Optional baffle filters
30” (requires 2) 11 1/8 x 12 1/2 SV13432
36” (requires 3) 9 1/4 x 12 1/2 SV13431
42” (requires 3) 11 1/8 x 12 1/2 SV13432
48” (requires 4) 9 1/4 x 12 1/2 SV13431
grease rail 30” 22-3/8” long SV13220
grease rail 36” 27-3/4” long SV13221
grease rail 42” SV13112
grease rail 48” 37” long SV13222
side filler bar 30” SV12514
side filler bar 36” SV12515
side filler bar 42” SV13113
side filler bar 48” SV12516
logo (silver adhesive) SV05869
filter spring
(30” & 36” QTY 3 --- 42” & 48” QTY 4) SV05528
wire harness SV07398
splitting harness (42” & 48” units only) SV07400
hardware package SV13278
(installation screws, nuts, wire nuts & wire clamp)
K210A REV D & E (VENMAR) OBS
JAN 2014
D Changed to baffle filters w/handles
E Changed the Logo. Serial Number 0205110301358
switch faceplate/knobs black SV12969
lamp housing, socket & trim (gray) SV16569
(30” & 36” QTY 2 42” & 48” QTY 3)
halogen bulb GU10 50 Watt SV05921
(30” & 36” QTY 2 42” & 48” QTY 3)
control board SV03255
heat sentry SV03435
heat sentry bracket SV03436
male connector SV02773
female connector SV02772
Baffle filters (includes handle & screws)
30” (requires 2) 11 1/8 x 12 1/2 SV13432
36” (requires 3) 9 1/4 x 12 1/2 SV13431
42” (requires 3) 11 1/8 x 12 1/2 SV13432
48” (requires 4) 9 1/4 x 12 1/2 SV13431
filter handle w/screws (1 pack) SV07680
grease rail 30” 22-3/8” long SV13220
grease rail 36” 27-3/4” long SV13221
grease rail 42” SV13112
grease rail 48” 37” long SV13222
side filler bar 30” SV12514
side filler bar 36” SV12515
side filler bar 42” SV13113
side filler bar 48” SV12516
logo (silver adhesive) SV05869
filter spring SV05528
(30” & 36” QTY 3 42” & 48” QTY 4)
wire harness SV07398
splitting harness (42” & 48” units only) SV07400
hardware package SV13278
(installation screws, nuts, wire nuts & wire clamp)
K260 Original (Best)
Used with P1, P2 or DD2M blowers
control board SB08080141 (RPL by SB08086141)
switch assembly white SB06105509
switch assembly black SB06105515
switch assembly black high temperature SB06106500
transformer SB02300670
fuse 5 x 20mm 4 amp SB02300782
halogen bulb MR16 12 volt 20 watt SB02300774
light socket SB02300688
light bezel ring SB02009102
logo white SB03202437
logo black SB03202436
filter spring SB02000191
Filters
30” (requires 2) 11-1/8”x12-1/2” S08087418
36” (requires 3) 9-1/4”x12-1/2” S08087419
42” (requires 4) 9-1/4”x12-1/2” S08087419
48” (requires 4) 9-1/4”x12-1/2” S08087419
54” (requires 4) 11-1/8”x12-1/2” S08087418
60” (requires 5) 9-1/4”x12-1/2” S08087419
90cm (requires 3) 9-1/4”x12-1/2” S08087419
hardware package S08081196 RPL BY SB080810578
(includes wall mtg brackets, installation screws &
drywall anchors)
K260 A-A (BEST)
control board SB08080141 (RPL by SB08086141)
switch assembly (high temperature) SB06106500
switch assembly white SB06105509
switch assembly black SB06105515
heat sentry SV03435
transformer SB02300670
fuse SB02300782
fuse holder SB02300674
halogen bulbs MR16 12 volt 20 watt SB02300774
male receptacle SV02773
female receptacle SV02772
logo white/silver SB03202437
logo black/silver SB03202436
bezel SB02009102
socket SB02300688
Filters
30” (requires 2) 11-1/8”x12-1/2” S08087418
36” (requires 3) 9-1/4”x12-1/2” S08087419
42” (requires 4) 9-1/4”x12-1/2” S08087419
48” (requires 4) 9-1/4”x12-1/2” S08087419
54” (requires 4) 11-1/8”x12-1/2” S08087418
60” (requires 5) 9-1/4”x12-1/2” S08087419
90 cm (requires 3) 9-1/4”x12-1/2” S08087419
filter spring SV05528
hardware package SV12971
(installation screws, nuts, washers & drywall anchors)
K260 A-B (VENMAR)
control board w/slide switches (no faceplate) SV03255
switch faceplate black SV12969
heat sentry SV03435
wiring harness SV03240
halogen bulbs PAR 20 120 volt 50 watt SV02544
male receptacle SV02773
female receptacle SV02772
logo white/silver SB03202437
logo black/silver SB03202436
bezel SV03241
socket SV03685
Filters
30” (requires 2) 11-1/8”x12-1/2” S08087418
36” (requires 3) 9-1/4”x12-1/2” S08087419
42” (requires 4) 9-1/4”x12-1/2” S08087419
48” (requires 4) 9-1/4”x12-1/2” S08087419
54” (requires 4) 11-1/8”x12-1/2” S08087418
60” (requires 5) 9-1/4”x12-1/2” S08087419
90 cm (requires 3) 9-1/4”x12-1/2” S08087419
filter spring SV05528
hardware package SV12971
(installation screws, nuts, washers & drywall anchors)
K260 A-C October 1998 (VENMAR)
control board SV03255
switch faceplate white (with knobs) SV12970
(RPL BY SV12969)
switch faceplate black (with knobs) SV12969
heat sentry SV03435
wiring harness SV03240
halogen bulbs PAR 20 120 volt 50 watt SV02544
male receptacle SV02773
female receptacle SV02772
logo white/silver SB03202437
logo black/silver SB03202436
bezel SV03241
socket SV03685
Filters Metal Finger Well
30” (requires 2) 11-1/8”x12-1/2” SV03461
36” (requires 3) 9-1/4”x12-1/2” SV03462
42” (requires 3) 11-1/8”x12-1/2” SV03461
48” (requires 4) 9-1/4”x12-1/2” SV03462
54” (requires 4) 11-1/8”x12-1/2” SV03461
60” (requires 5) 9-1/4”x12-1/2” SV03462
90 cm (requires 3) 11-1/8”x12-1/2” SV03461
Baffle filters
9 1/4 x 12 1/2 SV13431
11 1/8 x 12 1/2 SV13432
filter spring (plastic) SV03686
filter spring (metal) SV05528
hardware package SV12971
(installation screws, nuts, washers & drywall anchors)
32
NLA = no longer available; OBS = obsolete
Professional Series
K260A REV D (VENMAR)
Changed to GU10 bulbs Jan 2007. Serial Number
0202070101443.
switch faceplate w/knob black SV12969
halogen bulb 50 Watt GU10 SV05921
lamp housing, socket & trim SV16555
control board SV03255
female receptacle SV02772
male receptacle SV02773
Filters Metal Finger Well
30” (requires 2) 11 1/8 X 12 1/2 SV03461
36” (requires 3) 9 1/4 X 12 1/2 SV03462
42” (requires 3) 11 1/8 X 12 1/2 SV03461
48” (requires 4) 9 1/4 X 12 1/2 SV03462
54” (requires 4) 11 1/8 X 12 1/2 SV03461
60” (requires 5) 9 1/4 X 12 1/2 SV03462
90 cm (requires 3) 11 1/8 X 12 1/2 SV03461
Baffle filters
9 1/4 x 12 1/2 SV13431
11 1/8 x 12 1/2 SV13432
grease rail 30” SV13220
grease rail 36” SV13221
grease rail 42” SV13112
grease rail 48” SV13222
grease rail 54” SV13322
grease rail 60” SV13323
logo (adhesive silver) SV05869
heat sentry bracket SV03436
heat sentry SV03435
filter spring SV05528
wire harness SV07398
splitting harness (42” to 60” units only) SV07400
hardware package SV12971
(installation screws, nuts, washers & drywall anchors)
K260A REV E (VENMAR)
Changed lamp housing trim to gray. Serial Number
0203090801694.
switch faceplate w/knob black SV12969
halogen bulb 50 Watt GU10 SV05921
lamp housing, socket & trim (gray) SV16569
control board SV03255
female receptacle SV02772
male receptacle SV02773
Filters Metal Finger Well
30” (requires 2) 11 1/8 X 12 1/2 SV03461
36” (requires 3) 9 1/4 X 12 1/2 SV03462
42” (requires 3) 11 1/8 X 12 1/2 SV03461
48” (requires 4) 9 1/4 X 12 1/2 SV03462
54” (requires 4) 11 1/8 X 12 1/2 SV03461
60” (requires 5) 9 1/4 X 12 1/2 SV03462
90 cm (requires 3) 11 1/8 X 12 1/2 SV03461
Baffle filters
9 1/4 x 12 1/2 SV13431
11 1/8 x 12 1/2 SV13432
grease rail 30” SV13220
grease rail 36” SV13221
grease rail 42” SV13112
grease rail 48” SV13222
grease rail 54” SV13322
grease rail 60” SV13323
side filler bar 30” SV12514
33
side filler bar 36” SV12515
side filler bar 42” SV13113
side filler bar 48” SV12516
side filler bar 54” SV12517
side filler bar 60” SV12518
exhaust plate SV13321
logo (adhesive silver) SV05869
heat sentry bracket SV03436
heat sentry SV03435
filter spring SV05528
wire harness SV07398
splitting harness (42” to 60” units only) SV07400
hardware package SV12971
(installation screws, nuts, washers & drywall anchors)
K260A REV F (VENMAR) OBS JAN
2014
Changed to baffle filters w/handles. Serial Number
0204110301384. March 2011.
switch faceplate w/knob black SV12969
halogen bulb 50 Watt GU10 SV05921
lamp housing, socket & trim (gray) SV16569
control board SV03255
female receptacle SV02772
male receptacle SV02773
Baffle filters (includes handle & screws)
30” (requires 2) 11 1/8 X 12 1/2 SV13432
36” (requires 3) 9 1/4 X 12 1/2 SV13431
42” (requires 3) 11 1/8 X 12 1/2 SV13432
48” (requires 4) 9 1/4 X 12 1/2 SV13431
54” (requires 4) 11 1/8 X 12 1/2 SV13432
60” (requires 5) 9 1/4 X 12 1/2 SV13431
filter handle w/screws (1 pack) SV07680
grease rail 30” SV13220
grease rail 36” SV13221
grease rail 42” SV13112
grease rail 48” SV13222
grease rail 54” SV13322
grease rail 60” SV13323
side filler bar 30” SV12514
side filler bar 36” SV12515
side filler bar 42” SV13113
side filler bar 48” SV12516
side filler bar 54” SV12517
side filler bar 60” SV12518
exhaust plate SV13321
logo (adhesive silver) SV05869
heat sentry bracket SV03436
heat sentry SV03435
filter spring SV05528
wire harness SV07398
splitting harness (42” to 60” units only) SV07400
hardware package (installation screws, nuts, washers
& drywall anchors) SV12971
K260D OUTDOOR UNIT (VENMAR)
OBS Spring 2005
blower assembly **
** Uses P12D blower
control board SV03255***
switch faceplate black SV12969***
***You can offer the customer a complete new control
panel which contains upgraded marine type switches.
Part number for 36” SV15924
Part number for 48” SV16248
Part number 36” SV15924
Part number 48” SV16248
heat sentry SV03435
light socket SV03685
halogen lamp PAR 20 120 volt 50 watt SV02544
warming shelves SV03172
bezel SV03241
female receptacle SV02772
logo SB03202436
10” round transition SV03428
filter spring SB02000191
Filters
36” (req 3) 9 1/4 X 12 1/2 SV03462****
48” (req 4) 9 1/4 X 12 1/2 SV03462****
****SV03462 aluminum micro-mesh filters. Customer
can upgrade the filter to part number SV07124 which
is constructed of 316 stainless steel.
wire harness SV03240
hardware package SV12971
(installation screws, nuts, washers & drywall anchors)
UP27I (VENMAR) OBS JAN 2014
damper 3 1/4” x 14” SV14971
adapter 3 1/4” x 14” to 3 1/4” x 10” ST461
heat sentry SV03435
rotary control SV03501
toggle switch SV07689
plastic control frame and knob assembly SV16966
knob SV07688
light shell, socket and trim assembly SV16569
halogen bulbs (50 watt 120V PAR 16 GU10) SV05921
capacitor SV02160
wire cover SV01857
motor clockwise SV01766
motor counterclockwise SV03457
blower wheel counterclockwise SV03399
blower wheel clockwise SV03400
secondary micromesh filter 8.84” x 13.35” SV08070
secondary micromesh filter 14.84” x 13.35” SV08071
baffle filter 8.95” x 13.5” SV17025
(includes micromesh filter)
baffle filter 14.95” x 13.5” SV17026
(includes micromesh filter)
baffle filter handle w/screws (one handle per pack)
SV07680
grease rail 30” SV16793
grease rail 36” SV16794
grease rail 42” SV16795
grease rail 48” SV16796
logo SV05869
internal frame 30” (includes logo) SV15457
internal frame 36” (includes logo) SV15458
internal frame 42” (includes logo) SV15459
internal frame 48” (includes logo) SV15460
back plate SV15512
left flow deviator SV06242
right flow deviator SV06243
main power switch SV03503
motor grommet SV02001
charcoal filter kit 30” (includes 3 filters) SV17020
NLA = no longer available; OBS = obsolete
charcoal filter kit 36” (includes 3 filters) SV17021
charcoal filter kit 42” (includes 3 filters) SV17022
charcoal filter kit 48” (includes 3 filters) SV17023
hardware package SV13278
(installation screws, nuts, wire nuts & wire clamp)
UP27E (VENMAR) OBS JAN 2014
female connector SV13923
male connector SV13924
heat sentry SV03435
knob SV07688
plastic control frame and knob assembly SV16966
toggle switch SV07689
rotary control SV03501
light shell, socket and trim assembly SV16569
halogen bulb 50 watt 120V PAR16 GU10 SV05921
micromesh filter 8.84” x 13.35” SV08070
micromesh filter 14.84” x 13.35” SV08071
baffle filter 8.95” x 13.5” SV17025
(includes micromesh filter)
baffle filter 14.95” x 13.5” SV17026
(includes micromesh filter)
baffle filter handle w/screws (one handle per pack)
SV07680
grease rail 30” SV16793
grease rail 36” SV16794
grease rail 42” SV16795
grease rail 48” SV16796
logo SV05869
internal frame 30” (includes logo) SV15461
internal frame 36” (includes logo) SV15462
internal frame 42” (includes logo) SV15463
internal frame 48” (includes logo) SV15464
hardware package SV13278
(installation screws, nuts, wire nuts & wire clamp)
WP29M REV A (VENMAR) OBS
JAN 2014
lamp housing, socket & trim SV16569
(30”, 36”, 42” QTY 4; 48”, 54”, 60” QTY 6)
halogen bulbs 50 Watt GU10 SV05921
(30”, 36”, 42” QTY 4; 48”, 54”, 60” QTY 6)
rotary speed control SV03501
toggle switch (includes lock nut) SV07689
plastic control frame and knobs SV16966
knob SV07688
male receptacle SV13924
female receptacle SV13923
grease rail 30” SV16793
grease rail 36” SV16794
grease rail 42” SV16794
grease rail 48” SV16796
grease rail 54” SV16796
grease rail 60” (qty 2 required) SV16793
heat sentry SV03435
Inside frame 24” deep units
30” SV17115
36” SV17116
42” SV17117
48” SV17118
54” SV17119
60” SV17120
Professional Series
34
Inside frame 27” deep units
36” SV17121
42” SV17122
48” SV17123
54” SV17124
60” SV17125
filter spring (60” QTY 6; all other sizes QTY 3)
SV05528
secondary micro-mesh filter 8.84” x 8.50” SV07694
(30” QTY 3, 36” & 42” QTY 2, 60” QTY 6)
secondary micro-mesh filter 14.84” x 8.50” SV07695
(36” & 42” QTY 1, 48” & 54” QTY 3)
hybrid baffle filter 8.95” x 8.61” SV16967
(includes micro-mesh filter) (30” QTY 3, 36” & 42”
QTY 2, 60” QTY 6)
hybrid baffle filter 14.95” x 8.61” SV16968
(includes micro-mesh filter) (36” & 42” QTY 1, 48” &
54” QTY 3)
baffle filter handle w/screws (one handle per pack)
SV07680
logo SV05869
charcoal filter kit 30” units (includes 3 pcs.) SV16998
charcoal filter kit 36” & 42” units (includes 3 pcs.)
SV16999
charcoal filter kit 48” units (includes 3 pcs.) SV17000
hardware package SV12971
(installation screws, nuts, washers & drywall anchors)
WP29M REV B (VENMAR) JAN 2014
light socket SV05917
socket holder SV09435
light trim SV09434
bulb 50 watt, 120 volt, PAR 16, GU10 SV05921
rotary control SV03501
toggle switch SV07689
male connector SV13924
female connector SV13923
plastic frame and knob assembly SV16966
knob (requires 2) SV07688
heat sentry SV03435
filter fillers w/screw (pair) only for 42” unit SV61691
30” & 60” grease rail (60” requires 2) SV61932
36” grease rail SV61933
42” grease rail SV61934
48” & 54” grease rail SV61935
baffle filter 8.84 x 8.61 x 1 SV61639
baffle filter 11.84 x 8.61 x 1 SV61640
Filter quantities
30”---SV61639---QTY 3
36”---SV61639---QTY 1------SV61640---QTY 2
42”---SV61639---QTY 4
48”---SV61639---QTY 5
54”---SV61639---QTY 5
60”---SV61639---QTY 6
duct-free filter (set of 2) for hoods 30” thru 48”
S97017930
logo SV05869
hardware package SV12971
(4 #10 x 2” flat head screws, 8 #8 x 3/4” screws. 4 #10-
32 nuts, 2 wall anchors, washers 3/16” ID x 3/4” OD)
WPD28I OUTDOOR UNIT (VENMAR)
transition 9” x 18” to 10” round SV03428
logo (adhesive silver) SV05869
filter clip (includes rivet) SV15432
(36” requires 3 ; 48” requires 4)
potentiometer (speed control) SV06364
thermostat SV06497
lamp socket SV06498
(36” requires 2; 48” requires 4)
bezel SV02775 (RPL by SB02009102)
(36” requires 2; 48” requires 4)
knob speed control SV03504
blower switch SV06496
light switch SV06495
baffle filters 9.25” x 12.5” SV15422
(36” requires 3; 48” requires 4)
wire harness 36” SV06332
wire harness 48” SV06933
bulb 50W 120 volt GU10 type SV05921
(36” requires 2; 48” requires 4)
hardware package SV04216
(installation screws, washers, wire nuts, drywall
anchors & 2 wire clamps)
WPD28I OUTDOOR UNIT REV B
(VENMAR) (OBS SEPT 2012)
CHANGED LIGHT TRIM TO GRAY. SERIAL NUMBER
0202100800763
transition 9” x 18” to 10” round SV03428
logo (adhesive silver) SV05869
filter clip (includes rivet) SV15432
(36” requires 3; 48” requires 4)
potentiometer (speed control) SV06364
thermostat SV06497
lamp shell, socket & trim assembly SV16765
(36” requires 2; 48” requires 4)
knob speed control SV03504
blower switch SV06496
light switch SV06495
baffle filters 9.25” x 12.5” SV15422
(36” requires 3; 48” requires 4) (handles not available
as separate part)
wire harness 36” SV06332
wire harness 48” SV06933
bulb 50W 120 volt GU10 type SV05921
(36” requires 2; 48” requires 4)
hardware package SV04216
(installation screws, washers, wire nuts, drywall
anchors & 2 wire clamps)
WPD38I OUTDOOR (VENMAR)
MAY 2012
10” round duct adapter SV08541
light socket and trim assembly SV16569
(2 on 36”; 3 on 48 & 60”)
halogen bulb 120 volt, 50 watt, GU10 base SV05921
blower assembly---requires 2 S97017924
filter spring SV08337
baffle filter (includes spring) 11.84 x 15.125 SV60675
(3 on 30”, 4 on 48”; 5 on 60”)
grease rail 36” SV60695
grease rail 48” SV60696
NLA = no longer available; OBS = obsolete
Professional Series / Pull Outs
35
grease rail 60” SV60697
light switch SV02563
blower switch SV03503
fan knob SV08549
heat sentry SV03435
speed control SV08968
main power switch SV08548
logo SV05869
hardware package SV04216
(3 waterproof wire connectors, 2 wire clamps LP16-
AP, 8ea 8 x 5/8” screws, 4ea 10 x 2” flat head screws,
10ea 8-32 x 3/8” screws, 2 wall anchors, 2 washers
3/16” ID x 3/4” OD)
WPD29M OUTDOOR UNIT (VEN-
MAR) (OBS SEPT 2012)
transition 9” x 18” to 10” round SV03428
lamp housing, socket & trim SV16765
(42” QTY 4, 54” QTY 6)
halogen bulbs 50 Watt GU10 SV05921
(42” QTY 4, 54” QTY 6)
heat sentry SV06497
rotary speed control SV06364
speed control knob SV03504
light switch SV06495
blower switch SV06496
Note: handles for filters not available
baffle filter 8.95” x 8.61” (42” QTY 2) SV16939
baffle filter 14.95” x 8.61” SV16940
(42” QTY 1, 54” QTY 3)
filter spring (42” & 54” 3 req) SV15432
grease rail 42” SV16958
grease rail 54” SV16964
inside frame assembly 42” SV16996
inside frame assembly 54” SV16997
logo (adhesive silver) SV05869
light wire harness SV06933
light splitter wire harness SV07838
(for 54” unit only requires two. This part is not in our
system. Need to get directly from Venmar)
hardware package SV04216
(installation screws, washers, wire nuts, drywall
anchors & 2 wire clamps)
WPD39M OUTDOOR (VENMAR)
JULY 2012
Note 2-13-2013 this unit went to revision 01 (3rd & 4th
digit in serial number) added bracket with mounting
studs for the blowers in the hood. No service part
changes.
light socket assembly SV06887
halogen bulb (120 v, 50 watt, GU10 base) SV05921
heat sentry SV03435
fan knob SV08549
speed control SV03501
male connector SV13924
female connector SV13923
grease tray SV60879
baffle filter 11.84 x 15.125 (spring included) SV60675
baffle filter 8.84 x 15.125 (spring included) SV60716
filter spring SV08337
light rocker switch SV02563
blower rocker switch SV03503
logo SV05869
hardware package SV04216
UP26M (VENMAR) JAN 2014
logo SV05869
baffle filter 8.84 x 8.61 includes handle SV13431
baffle filter 11.84 x 8.61 includes handle SV13432
Filter quantities
30” ----SV13432----qty 2
36” ----SV13431-----qty 3
42” ----SV13431----qty 1 & SV13432----qty 2
48” ----SV13432----qty 3
filter filler 1.6” (contains 1 pair) for 36 & 42” SV61691
(30” hood doesn’t use any)
filter filler 3” (contains 1 pair) for 48” hood SV61679
30” grease rail SV61742
36” grease rail SV61743
42” grease rail SV61744
48” grease rail SV61745
light socket SV05917
socket holder SV09435
light trim SV09434
bulb 50 watt 120 volt PAR 16 GU10 SV05921
knobs for blower and light (contains 2) SV08578
heat sentry SV03435
light switch SV08338
speed control SV03501
blower rocker switch SV08548
female connector SV12516
male connector SV07398
heat sentry bracket SV17645
hardware package SV13278
(4 lock nuts 10-32, 1 wire clamp, 2 no. 6 x 1/2” screws.
2 wire connectors, 6 no. 8 x 3/8”, 8 double threaded
screws 6-12 x 1/2”)
UP27M (VENMAR) JAN 2014
logo SV05869
30” grease rail SV61932
36” grease rail SV61933
42” grease rail SV61934
48” grease rail SV61935
Filter quantities
30”----SV61639--- qty 3
36”----SV61639---qty 1 & SV16140---qty 2
42”----SV61639 ----qty 4
48”----SV61639----qty 5
filter fillers (pair) SV61691
baffle filter 8.84 x 13.5 x 1 SV61639
baffle filter 11.84 x 13.5 x 1 SV61640
duct-free filter (pair) S97017930
heat sentry SV03435
female connector SV13923
male connector SV13924
knobs (pair) SV07688
plastic control frame & knob assembly SV16966
rotary control SV06501
toggle switch SV07689
light socket SV05917
socket holder SV09435
light trim SV09434
bulb 50 watt, 120 volt, PAR 16, GU10 SV05921
hardware package SV13278
(1 electrical clamp, wire connectors, 6 double thread-
ed screws 6-12 x .5”, 6 screws 8 x 3/8”, 4 nuts 10-32, 2
screws 6 x 1/2”)
WP28M (VENMAR) JAN 2014
logo SV05869
exhaust plate SV13321
light socket SV05917
socket holder SV09435
light trim SV09434
bulb 50 watt, 120 volt, PAR16, GU10 SV05921
light switch SV08338
speed control SV03501
blower rocker switch SV08548
heat sentry SV03435
blower and light knobs (pair) SV08578
filter fillers with screw (pair) 1.6” x 11.86” SV61680
filter fillers with screw (pair) 3.04” x 11.86” SV61681
baffle filter 8.84 x 12 x 1 SV61683
baffle filter 11.84 x 12 x 1 SV61684
Baffle Filter Quantities
30”-----SV61684----qty 2
36”----SV61683----qty 3
42”---SV61683---qty 1 & SV61684---qty----2
48”----SV61684---qty 3
54”----SV61683----qty 2 & SV61684---qty ----2
60”----SV61684----qty 4
electrical harness SV21520
splitting harness SV07400
hardware package SV12971
(4 #10 x 2” flat head screw, 8 #8 x 3/4” screws, 4 #10-
32 nuts, 2 wall anchors, washers 3/16” ID x 3/4” OD)
40 (BEST) OBSOLETE UNIT
microswitch SB02300620
light lens 24” S03200725
light lens all other sizes S03200755
top right runner S03292308 (NLA)
top left runner S03292310 NLA
top right support S03292311 NLA
top left support S03292312 NLA
front bottom runner (requires 2) S03292309 (NLA)
panel stop SB03292313
panel stop handle SB03292314
runner pin support SB03292306
runner pin SB03292307
runner pin spring SB02000744
Filters*
60cm SB08087706
90cm SB08087707
30” SB08087701 (NLA)
36” (6.5” on one side---9” on the other) SB08087702
If your model has a control board utilizing spade
connectors for each wire, we believe that the following
parts are usable. If however, your unit uses plugs with
multiple wires in each, these parts will not work and
we are unable to obtain these types of
blower assembly S06001316 (NLA)
motor S02300070
blower wheel, CCW S03292008 (NLA)
blower wheel, CW S03292009 (NLA)
NLA = no longer available; OBS = obsolete
Pull Outs
36
41 (BEST) OBSOLETE UNIT
blower assembly NLA
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mounting bracket SB02000314
rubber motor mount SB03202007 (Rpl by
SB03204177)
damper/duct connector SB080810111
capacitor SB02300653
resistor S02300654
control board S08086096 (OBS 11-2013)
switch assembly, white S06104190
switch assembly, black S06104353
microswitch SB02300620
ballast S02300657
tube holder S02300521
starter/tube holder S02300522
starter S02300659
fluorescent tube 15 watt S02300500
light lens 24” (flat lens 17 1/4 x 2 3/4) S03200725
light lens all others sizes (L shaped lens 19 3/8” long)
S03200755
Filters*
60cm SB08087706
90cm SB08087707
30” SB08087701 (NLA)
36” (6.5” on one side; 9” on the other) SB08087702
top right runner S03292308 (NLA)
top left runner S03292310 (NLA)
top right support S03292311 (NLA)
top left support S03292312 (NLA)
front bottom runner (requires 2) S03292309 (NLA)
panel stop SB03292313
panel top handle SB03292314
runner pin support SB03292306
runner pin SB03292307
runner pin spring SB02000744
*Note: filters for 24” & 42” are obsolete
325ILS (BEST) OBSOLETE UNIT
blower assembly S06001316 (NLA)
motor S02300070
blower wheel CCW S03292008 (NLA)
blower wheel CW S03292009 (NLA)
rubber motor mount SB03202007 (Rpl by
SB03204177)
damper/duct connector S08088029 (NLA)
capacitor S02300581
resistor S02300631
control board S08086092 (NLA)
switch assembly white S06104931 (NLA)
switch assembly black SB06109515 (NLA)
microswitch SB02300620
drawer slides S02000311
track mounting screws SB02000164
lamp holder S02300627
light lens 24” S03202076
light lens all other sizes S03200755
glass support pads S02000715
Lens extensions
36” (1 set) 6.375” SB080810474
30” & 42” (1 set) 3.313” SB080810473 (OBS 8-24-12)
90 cm (1 set) 6.063 SB080810475 (NLA 3-6-13)
Grease filters:
60 cm & 24” (req 1) 6-9/16”x17-5/8” S08087727
30” (req 2) 6-1/2”x11-13/16” S08087731
90 cm & 36” (req 2) 6-1/2”x14-3/4” S08087728
42” (req 2) 6-9/16”x17-5/8” S08087727
Charcoal filter sets:
60 cm & 24” (req 1) 16-1/2” x 6-15/16” filter pad
SB08999729
30” (kit contains 4 filters) SB08999737
90 cm & 36” (kit contains 6 filters) SB08999745 (OBS
1-2014)
42” (kit contains 8 filters) SB08999746
filter retaining wires S02000276
grille latch right ----white S05000050
grille latch left----white S05000051
grille latch right-----black S05000052
grille latch left----black S05000053
Front trim:
60 cm white SB003150208
60 cm black SB003150210
90 cm white SB003150209
24” white SB003150200
24” black SB003150204
30” white SB003150201
30” black S003150205
36” white SB003150202
36” black S003150206
42” black SB003150207
right side trim white S03292315
left side trim white S03292316 (OBS 8-24-12)
right side trim black S03294345
left side trim black S03294346 (NLA)
glass support pad S02000715
Glass panel*
90 cm (30.67” x 5.6”) S02000962
24” (19.21” x 5.6”) S02000965
30” (25.24” x 5.6”) S02000966
36” (31.22” x 5.6”) S02000967
42” (37.2” x 5.6”) S02000968 (11-12-12--NLA)
Grille assembly**
60 cm black SB083110211
(part number not loaded in ASI)
90 cm white SB083110219
90 cm black SB083110226
24” black SB083110222
30” white SB083110216
30” black S083110223
36” white S083110217
36” black SB083110224
42” black SB083110225
* Note: 60 cm glass panel is no longer available
** Note: 60 cm white, 24” white and 42” white grille
assemblies are no longer available.
326 (1995 or earlier) (BEST)
blower assembly S06001519 (NLA 5-2012)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mtg rubber SB03202007 (Rpl by SB03204177)
damper/duct connector SB080810111
capacitor SB02300653
resistor S02300654
control board S08086096 (OBS 11-2013)
switch assembly white S06109988 (3-4-13 NLA)
switch assembly black S06109990 (NLA 12-31-13)
microswitch SB02300620
drawer slides S02000311
track mounting screws SB02000164
ballast S02300657
tube holder S02300521
tube holder/starter S02300522
starter S02300659
fluorescent tube S02300500
light lens 24” units S03202076
light lens all other sizes S03200755
Light lens extension sets
30” (3.313”) SB080810473 (OBS 8-24-12)
36” (6.375”) SB080810474
90cm (6.063”) SB080810475 (NLA 3-6-13)
42” (req 2 sets) SB080810473 & SB080810475
(OBS 8-24-12)
Filters
60 cm & 24” (req1) 6-9/16”x17-5/8” S08087727
30” (req 2) 6-1/2”x11-13/16” S08087731
90cm & 36” (req 2) 6-1/2”x14-3/4” S08087728
42” (req 2) 6-9/16”x17-5/8” S08087727
Charcoal filter sets
60cm & 24” (req 1) 16-1/2” x 6-15/16” filter pad
SB08999729
30” (kit contains 4 filters) SB08999737
90cm & 36” (kit contains 6 filters) SB08999745
(OBS 1-2014)
42” (kit contains 8 filters) SB08999746
filter retaining wires S02000276
Grille latch right
white S05000050
black S05000052
Grille latch left
white S05000051
black S05000053
glass support pad S02000715
Glass panel
60cm OBS
90 cm (30.67” x 5.6”) S02000962
24” (19.21” x 5.6”) S02000965
30” (25.24” x 5.6”) S02000966
36” (31.22” x 5.6”) S02000967
42” (37.2” x 5.6”) S02000968 (11-12-12--NLA)
Grille assembly
60cm WH OBS
60cm BL SB083110221
90cm WH SB083110219
90cm BL SB083110226
24” WH OBS
24” BL SB083110222
30” WH SB083110216
30” BL S083110223
36” WH S083110217
36” BL SB083110224
42” WH OBS
42” BL SB083110225
hardware package S08081098
(includes 4 mounting screws & 2 damper screws)
NLA = no longer available; OBS = obsolete
Pull Outs
37
326 REV A (1995-DEC 2002) (BEST)
blower assembly SB06001564 (NLA 5-2012)
motor SB02310036 (NLA 5-2012)
blower wheel SB03295076
motor mtg rubber SB03202007 (Rpl by SB03204177)
microswitch SB02300620
resistor S02300654
side wire cover OBS
switch assembly white S06104658
switch assembly black S06104712
tube holder S02300521
tube holder/starter S02300522
starter S02300659
ballast S02300657
capacitor SB02300653
control board S08086096 (OBS 11-2013)
drawer slide S02000311
track mounting screws SB02000164
Front trim
60cm white SB003150208
60cm black SB003150210
90cm white SB003150209
90cm black SB003150211
24” white SB003150200
24” black SB003150204
30” white SB003150201
30” black S003150205
36” white SB003150202
36” black S003150206
42” white S003150203
42” black SB003150207
Right side trim
white S03292315
black S03294345
Left side trim
white S03292316 (OBS 8-24-12)
black S03294346 (NLA)
fluorescent bulb S02300500
light lens 24” S03202076
light lens all other sizes S03200755
Lens extension sets
30” (3.313”) SB080810473 (OBS 8-24-12)
36” (6.375”) SB080810474
90cm (6.063”) SB080810475 (NLA 3-6-13)
42” (requires 2 sets) SB080810473 & SB080810475
(OBS 8-24-12)
Grille assembly
60cm white OBS
60cm black SB083110221
90cm white SB083110219
90cm black SB083110226
24” white OBS
24” black SB083110222
30” white SB083110216
30” black S083110223
36” white S083110217
36” black SB083110224
42” white OBS
42” black SB083110225
Grille latch right
white S05000050
black S05000052
Grille latch left
white S05000051
black S05000053
Filters
60 cm & 24” (req 1) 6-9/16”x17-5/8” S08087727
30” (req 2) 6-1/2”x11-13/16” S08087731
90cm & 36” (req 2) 6-1/2”x14-3/4” S08087728
42” (req 2) 6-9/16”x17-5/8” S08087727
filter retaining wires S02000276
Charcoal filter sets
60cm & 24” (req 1) 16-1/2” x 6-15/16” filter pad
SB08999729
30” (kit contains 4 filters) SB08999737
90cm & 36” (kit contains 6 filters) SB08999745
(OBS 1-2014)
42” (kit contains 8 filters) SB08999746
Charcoal filter spacer
90cm & 36” SB031171032 (NLA)
30” SB031171752
42” OBS
Glass panel
60cm OBS
90 cm (30.67” x 5.6”) S02000962
24” (19.21” x 5.6”) S02000965
30” (25.24” x 5.6”) S02000966
36” (31.22” x 5.6”) S02000967
42” (37.2” x 5.6”) S02000968 (11-12-12--NLA)
damper/duct connector SB080810111
hardware package S08081098
(includes 4 mounting screws & 2 damper screws)
326 REV B (DEC 2002) (BEST)
OBSOLETE UNIT
blower assembly SB06002020
motor SB02310205
blower wheel SB03295071
motor mtg rubber SB03202007 (Rpl by SB03204177)
microswitch SB02300620
side wire cover OBS
switch assembly white SB06107701
switch assembly black SB06107729
tube holder SB02300796
tube holder/starter SB02300797
starter S02300659
ballast S02300657
capacitor SB02300233
drawer slide S02000311
track mounting screws SB02000164
Front trim
60cm white SB003150208
60cm black SB003150210
90cm white SB003150209
90cm black SB003150211
24” white SB003150200
24” black SB003150204
30” white SB003150201
30” black S003150205
36” white SB003150202
36” black S003150206
42” white S003150203
42” black SB003150207
Right side trim
white S03292315
black S03294345
Left side trim
white S03292316 (OBS 8-24-12)
black S03294346 (NLA)
fluorescent bulb S02300500
light lens 24” S03202076
light lens all other sizes S03200755
Lens extension sets
30” (3.313”) SB080810473 (OBS 8-14-12)
36” (6.375”) SB080810474
90cm & 42” (6.063”) SB080810475 (NLA 3-6-13)
Grille assembly
60cm white OBS
60cm black SB083110221
90cm white SB083110219
90cm black SB083110226
24” white OBS
24” black SB083110222
30” white SB083110216
30” black S083110223
36” white S083110217
36” black SB083110224
42” white OBS
42” black SB083110225
Grille latch right
white S05000050
black S05000052
Grille latch left
white S05000051
black S05000053
Filters
60 cm & 24” (req 1) 6-9/16”x17-5/8” S08087727
30” (req 2) 6-1/2”x11-13/16” S08087731
90cm & 36” (req 2) 6-1/2”x14-3/4” S08087728
42” (req 2) 6-9/16”x17-5/8” S08087727
filter retaining wires S02000276
Charcoal filter sets
60cm & 24” (req 1) 16-1/2” x 6-15/16” filter pad
SB08999729
30” (kit contains 4 filters) SB08999737
90cm & 36” (kit contains 6 filters) SB08999745
(OBS 1-2014)
42” (kit contains 8 filters) SB08999746
Charcoal filter spacer
90cm & 36” SB031171032 (NLA)
30” SB031171752
42” OBS
Glass panel
60cm OBS
90 cm (30.67” x 5.6”) S02000962
24” (19.21” x 5.6”) S02000965
30” (25.24” x 5.6”) S02000966
36” (31.22” x 5.6”) S02000967
42” (37.2” x 5.6”) S02000968 (11-12-12--NLA)
damper/duct connector SB080810111
hardware package S08081098
(includes 4 mounting screws & 2 damper screws)
340 (BEST) OBSOLETE UNIT
microswitch SB02300620
drawer slides S02000311
light lens 24” S03202076
light lens for all other sizes S03200755
Lens extensions:
NLA = no longer available; OBS = obsolete
Pull Outs
38
36” set SB080810474
30” & 42” set SB080810473 (OBS 8-14-12)
90cm set SB080810475 (NLA 3-6-13)
Filters:
60cm & 24” (1 req) 6-9/16”x17-5/8” S08087727
30” (2 req) 6-1/2”x11-13/16” S08087731
90cm & 36” (2 req) 6-1/2”x14-3/4” S08087728
42” (2 req) 6-9/16”x17-5/8” S08087727
Charcoal filter sets:
60cm & 24” (req 1) 16-1/2” x 6-15/16” filter pad
SB08999729
30” (kit contains 4 filters) SB08999737
90cm & 36” (kit contains 6 filters) SB08999745
(OBS 1-2014)
42” (kit contains 8 filters) SB08999746
filter retaining wires S02000276
If your model has a control board using spade con-
nectors for each wire, we believe that the following
parts are usable. If however, your unit uses plugs with
multiple wires in each, these parts will not work and
we are unable to obtain these types of parts:
blower assembly S06001316 (NLA)
motor S02300070
blower wheel CCW S03292008 (NLA)
blower wheel CW S03292009 (NLA)
rubber motor mount SB03202007 (Rpl by
SB03204177)
damper/duct connector S08088029 (NLA)
switch assembly white S06104931 (NLA)
switch assembly black SB06109515 (NLA)
control board w/spade connectors S08086092 (NLA)
capacitor S02300581
resistor S02300631
light socket S02300627
light socket support SB02000606
341ILS (BEST) OBSOLETE UNIT
blower assembly NLA
motor SB02310036 (NLA 5-2012)
blower wheel SB03295089 (NLA 7-2012)
motor mtg rubber SB03202007 (Rpl by SB03204177)
damper/duct connector SB080810111
capacitor SB02300653
resistor S02300654
control board S08086096 (OBS 11-2013)
Switch assembly
white SB06104138
black SB06104146
microswitch SB02300620
drawer slides S02000311
track mounting screws SB02000164
ballast S02300657
tube holder S02300521
starter/tube holder S02300522
starter S02300659
fluorescent tube 15 watt S02300500
light lens (except 24”) S03200755
light lens 24” models S03202076
Lens extensions
36” set SB080810474
30” & 42” set SB080810473 (OBS 8-14-12)
90cm set SB080810475 (NLA 3-6-13)
Filters
60cm & 24” (1 req) 6-9/16”x17-5/8” S08087727
30” (2 req) 6-1/2”x11-13/16” S08087731
90cm & 36” (2 req) 6-1/2”x14-3/4” S08087728
42” (2 req) 6-9/16”x17-5/8” S08087727
Charcoal filter sets
60 cm & 24” (req 1) 16-1/2” x 6-15/16” filter pad
SB08999729
30” (kit contains 4 filters) SB08999737
90cm & 36” (kit contains 6 filters) SB08999745
(OBS 1-2014)
42” (kit contains 8 filters) SB08999746
filter retaining wires S02000276
grill latch--right--white S05000050
grill latch--left--white S05000051
grill latch--right--black S05000052
grill latch--left--black S05000053
Front trim
60cm WH SB003150208
60cm BL SB003150210
90cm WH SB003150209
24” WH SB003150200
24” BL SB003150204
30” WH SB003150201
30” BL S003150205
36” WH SB003150202
36” BL S003150206
42” BL SB003150207
right side trim white S03292315
left side trim white S03292316 (OBS 8-24-12)
right side trim black S03294345
left side trim black S03294346 (NLA)
glass support pad S02000715
Glass panel
60cm OBS
90 cm (30.67” x 5.6”) S02000962
24” (19.21” x 5.6”) S02000965
30” (25.24” x 5.6”) S02000966
36” (31.22” x 5.6”) S02000967
42” (37.2” x 5.6”) S02000968 (11-12-12--NLA)
Grille assembly
60cm WH OBS
60cm BL SB083110221
90cm WH SB083110219
90cm BL SB083110226
24” WH OBS
24” BL SB083110222
30” WH SB083110216
30” BL S083110223
36” WH S083110217
36” BL SB083110224
42” WH OBS
42” BL SB083110225
U102I (BEST)
Drawer support
30” SBE3403751
36” SBE3403713
Visor frame
30” SBE3403752
36” SBE3403714
drawer slide SB020111650
Front panel
30” SS SB003101220
36” SS SB003101208
30” WH SB003101223
36” WH SB003101217
30” BL SB003101224
36” BL SB003101218
drawer handle SB03294747
logo (adhesive silver) SB02011284
(RPL by SV05869)
switch assembly SB06108277
blower assembly SB06002066
blower wheel SB03295071
rubber washer SB03202007 (Rpl by SB03204177)
capacitor SB02300233
control board SB08086700
microswitch SB02300620
Light bar for sockets
30” SBE3347372
36” SBE3347241
transformer SB02300783
transformer after Oct-11-2010 SB02300739
heat sentry SB02300804
lamp cover spacer support SB03292203
lamp housing/socket (includes lens) SB02300733
halogen bulb 12v 20 watt Type JC G4 SB02300891
charcoal filter bracket SB03290377
Grease filter
30” (req 1) flip latch 6-1/8” x 25-7/8” SB08087016
36” (req 2) flip latch 6 x 15 15/16” SB08087077
filter frame support 36” only SBE3403716
Wall spacer
30” SB003101222
36” SB003101216
fuse SB02300782
fuse holder SB02300674
left bracket SBE3347251
right bracket SBE3347252
Glass visor
30” (25 1/4 x 3 7/8) SB02005070
36” (31 1/4 x 3 7/8) SB02005069
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) 9/07 SB08092501
mounting nuts SB02000739 (RPL by SB02011301)
hardware package SB080810599
(2 mtg brackets, installation screws & washers)
U102E (BEST)
Drawer support
30” SBE3403751
36” SBE3403713
42” SBE3403761
Visor frame
30” SBE3403752
36” SBE3403714
42” SBE3403762
drawer slide SB020111650
Front panel
30” SS SB003101220
36” SS SB003101208
42” SS SB003101227
30” WH SB003101223
36” WH SB003101217
42” WH SB003101264
NLA = no longer available; OBS = obsolete
Pull Outs / Non-Duct Kits
39
30” BL SB003101224
36” BL SB003101218
42” BL SB003101265
drawer handle SB03294747
logo (adhesive silver) SB02011284
(RPL by SV05869)
switch assembly SB06108277
control board SB08086701
microswitch SB02300620
Light bar for sockets
30” SBE3347372
36” SBE3347241
42” SBE3347378
transformer SB02300783
transformer after Oct-11-2010 SB02300739
heat sentry SB02300804
lamp cover spacer support SB03292203
light housing/socket (includes lens) SB02300733
halogen bulb 12v 20 watt Type JC G4 SB02300891
Grease filter
30” (req 1) flip latch 6-1/8”x25-7/8” SB08087016
36” (req 2) flip latch 6”x15-15/16” SB08087077
42” (req 2) flip latch 6”x18-15/16” SB08087017
Filter support frame
36” SBE3403716
42” SBE3403765
Wall spacer
30” SB003101222
36” SB003101216
42” SB003101228
left bracket SBE3347251
right bracket SBE3347252
Glass visor
30” (25 1/4 x 3 7/8) SB02005070
36” (31 1/4 x 3 7/8) SB02005069
42” (37 1/4 x 3 7/8) SB02005071
fuse SB02300782
fuse holder SB02300674
damper/duct connector (plastic) SB08085018
damper/duct connector (metal) 9/07 SB08092501
mounting nuts SB02000739
(RPL by SB02011301)
hardware package SB080810599
(2 mtg brackets, installation screws & washers)
ANKCP4536 Non-duct Kit
filter S99010357 (qty-1) & S99010358 (qty-2)
reducer 8” to 7” S99610026
transition 7” to 4 x 10 S99610027
ANKCP4742 Non-duct Kit
filter S99010357 (qty-4)
transition S424
ANKCP4748 Non-duct Kit
filter S99010357 (qty-5)
transition S424
ANKCP4760 Non-duct Kit
filter S99010357 (qty-1) & S99010358 (qty-4)
transition S424
ANKU10 Non-duct Kit
filter SB03300498
reducer 8” to 6” SB03294170
ANKUP Non-Duct Kit
charcoal filter 30” (set of three filters) SV17020
(3ea 8.95” x 13.5”)
charcoal filter 36” (set of three filters) SV17021
(2ea 8.95” x 13.5” & 1ea 14.95” x 13.5”)
charcoal filter 42” (set of three filters) SV17022
(1ea 8.95” x 13.5” & 2ea 14.95” x 13.5”)
charcoal filter 48” (set of three filters) SV17023
(3ea 14.95” x 13.5”)
wire sleeve
hardware package SV07701
(8 #8-10 x 1/2” screws, 8 #8-18 x 3/8” screws and 4
#8-18 x 3/4” screws)
ANKWC23 Non-duct Kit
OBS OCT 2012
filter SB03300501
reducer 6” to 5” SB03295018
air plenum/diverter SB08092048
5” flex duct SB02011452
hardware package SB080810714
ANKWC26 Non-duct Kit
filter SB03300488
reducer 6” to 5” SB03295018
air plenum/diverter SB08092047
plenum extension SB03295017
5” flex duct SB02011452
hardware package SB080810714
ANKWM24 Non-duct Kit
OBS OCT 2012
filter SB03300498
8” round adapter
air plenum/diverter
plenum extension
flex duct
hardware package
ANKWPXX6SB Non-Duct Kit
charcoal filter 30” (set of three filters) SV16998
(3ea 8.95” x 8.61”)
charcoal filter 36” and 42” (set of three) SV16999
(2ea 8.95” x 8.61” & 1ea 14.95” x 8.61” )
charcoal filter 48” (set of three filters) SV17000
(3ea 14.95” x 8.61”)
wire sleeve
hardware package SV07701
(8 #8-10 x 1/2” screws, 8 #8-18 x 3/8” screws and 4
#8-18 x 3/4” screws)
ANKWT32 Non-duct Kit
filter (need to order 2) S97017930
filter support (need 2) SV09016
8” round adapter SV18518
air plenum/diverter SV18509 & SV18508
flex duct SV09017
hardware package SV05803
NDIS170 Non-duct Kit
filter SB03300488
air plenum/diverter SBE3401893
connector to plenum SB03292300
5” flex duct SB02011452
NDK3139 Non-duct Kit
filter SB03300495
reducer 6” to 5” SB03295018
air plenum/diverter SB03295016
5” flex duct SB02011452
hardware package SB080810545
NDK7388 Non-duct Kit
OBS OCT 2012
filter SB03300488
reducer 6” to 5” SB03295018
air plenum/diverter SB03295016
5” flex duct SB02011452
hardware package SB080810545
NDK7780 Non-duct Kit
filter SB03300488
reducer 6” to 5” SB03295018
air plenum/diverter SB03295016
5” flex duct SB02011452
hardware package SB080810558
REKIT41F Non-duct Kit
filter SB03300498
connector to plenum SB03292300
5” flex duct SB02011452
ANKCP55
filter S97017930
filter support S99111455
transition 7” round to 4” x 10” S99610027
reducer S99610026
hardware package S99160437
NLA = no longer available; OBS = obsolete
Non-Duct Kits / Miscellaneous Parts
40
ANKIC34
filter SB08999176
filter support SB08093447
plenum SB08093496
6” flex duct SB02011557
reducer SB03294170
plenum duct connector collar SB03292300
screws need 8 SB02000166
wire clamps need 2 SB03202287
ANKIF6
filter SB08999179
plenum SB08093495
6” flex duct SB02011557
reducer SB03294170
plenum duct connector collar SB03292300
ANKWC345
filter SB08999176
filter support SB08093447
plenum SB08093478
6” flex duct SB02011557
reducer SB03294170
plenum duct connector collar SB03292300
ANKWC46
filter SB08999182
plenum SB08093478
6” flex duct SB02011557
reducer SB03294170
plenum duct connector collar SB03292300
ANKWPP9
filter S97017930
plenum SB08093448
6” flex duct SB02011557
reducer SB03294170
plenum duct connector collar SB03292300
ANKWTT320
filter (includes clips) S97018968
plenum S99528421
8” flex duct S99528429
ANKWTT326
filter (includes clips) S97019039
plenum S99528421
8” flex duct S99528429
ANKWPXX6RSB
filter (set of 2) S97017930
filter support S99111455
hardware package SV07701
(8 #8-10 x 1/2” screws, 8 #8-18 x 3/8” screws and 4
#8-18 x 3/4” screws)
ANKUPXX2RSB
filter (set of 2) S97017930
filter support S99111455
hardware package SV07701
(8 #8-10 x 1/2” screws, 8 #8-18 x 3/8” screws and 4
#8-18 x 3/4” screws)
AEIP Soffit Flue (For IP29M unit)
Hardware package SV06927
(installation screws, nuts and washers)
ALP Ambient Light Panel
light socket (30,36,42 --qty 2) (48 & 60 -- qty 3)
SV05917
bulb GU10 50 Watt 120 Volt SV05921
bezel SB02009102
rocker switch SV02563
ALP Ambient Light Panel REV B
JUNE 2010 CHANGED LIGHT TRIM TO GRAY.
SERIAL NUMBER 0500100600580.
lamp shell, socket & trim assembly SV16569
bulb GU10 50 Watt 120 Volt SV05921
rocker switch SV02563
ATDIP Drywall Kit (For IP29M unit)
Hardware package SV06927
(installation screws, nuts and washers)
Charcoal Filters
filter blocks for models 325 326 340 & 341
24” & 60cm SB08999729
30” (kit contains 4 filters) SB08999737
36” & 90cm (kit contains 6 filters) SB08999745
(OBS 1-2014)
42” (kit contains 8 filters) SB08999746
filter pads for models K29 & K34
90cm (1 pad 27 1/2 x 12 1/2) SB08999740
48” (1 pad 37 x 12 1/2) SB08999741
FILTEREB40 (set of 2) SB03300495
FILTERSQUARE (single pack) SB03300488
ROUNDFILTER (set of 2) SB03300498
mtg bracket for roundfilter motor side SB03292318
(NLA)
mtg bracket for roundfilter wheel side SB03292319
screws to mount brackets (each side takes 3)
S99150531
Liners
hardware package indoor liners SV05864
(2 pads, 10 screws)
hardware package outdoor liners SV06331
(2 pads, 10 screws)
Miscellaneous Parts
4 amp fuse 4amp fuse 5 x 20 mm SB02300782
brass trim screw SB02000011
black trim screw SB02000117
polishing stone SPFD75940248
color sample set S08869990
filter finger tab grey round front SB03292425
filter finger tab grey round back SB03292426
5” flexible duct SB02011452
Outdoor hood covers
Fits ACVWPD2836, ACVWPD2848, ACVWPD2942,
ACVWPD2954
hardware package (snaps) S97017652
WCPI Wall Control
faceplate SV15087
light/fan switch (req 1) SV05915
speed control SV03501
speed control knob SV03504
stainless steel screws #8 1/2” (req 2) SV05874
wire harnesses w/molex & spade connectors
SV05872
ACR3 Remote Control
service part for ACR3 remote control SB08999186
Light Lenses / Bulbs / Blower Wheels
Light Lenses
Part Number Width Height Length Style
S03201016 3-1/8”, 80mm 11-7/8”, 300mm Frosted Plastic
SB003260000 (repl by S03200725) 2-11/16”, 68mm 17-1/4”, 440mm Prismed Plastic, Best Logo
S03200725 2-11/16”, 68mm 17-1/4”, 440mm Prismed Plastic
SB03200797 1-7/8”, 48mm 15-3/16”, 386mm Frosted Plastic
S03200755 1-3/4”, 45mm 1-3/4”, 45mm 19-3/8”, 493mm Translucent White Plastic
S03202076 1-3/4”, 45mm 1-3/4”, 45mm 19-5/8”, 500mm Translucent White Plastic
Bulbs
Part Number Description
SB02300891 Type JC 12 volt 20 watt G4 Base small plug in bulb with two pins
SB02300774 MR16 12 volt 20 watt plug in bulb enclosed in glass
SB02300264 40 watt candelabra type bulb
SV02544 PAR 20 50 watt Halogen screw in bulb
S02300700 9 watt Fluorescent
S02300500 15 watt Fluorescent
SV05921 GU10 50 watt 120 volt push & twist (curved lens)
SB02300899 (repl by SV05921) GU10 MR16 120 volt 50 watt push & twist (flat lens)
Blower Wheels
(all dimensions in millimeters. For inches divide by 25.4)
Part Number Diameter Depth Bore Rotation Inlet Color Material
S03292008 (no longer available) 134mm 93mm 6.5 CCW Single Black Plastic
S03292009 (no longer available) 134mm 93mm 6.5 CW Single Black Plastic
SB03295000 (repl by SB03295076) 154mm 126mm 6.5 CW Double White Plastic
SB03295076 154mm 126mm 6 CW Double Grey Plastic
SB03295071 154mm 126mm 8 CW Double Grey Plastic
SB03292320 (repl by SB03295089) 154mm 137mm 6.5 CW Double White Plastic
SB03292284 (repl by SB03295089) 154mm 137mm 6.5 CW Double White Plastic
SB03295089 154mm 137mm 6.5 CW Double Grey Plastic
SB02011091 236mm 78mm 8 CW Single Silver Metal
41
Motor Cross Reference
Vender P/N Vendor BEST P/N Notes/Where Used
80624.0 CROUZET S02310052 DD6, DD61
DE2G097N Universal/Magnetek S99080357 P6
DE2J056N Magnetek S99080362 DDB5
DE3G126N Magnetek S99080397 EB6
DE3J051N Magnetek S99080396 EB9
EA27MT0301 Elektromec SB02300040 (NLA)
EB351402 Elektromec S02310010 28” 6 WIRE W MOLEX
EB35MTC1401 Elektromec S02300070
EB35MTC1402 Elektromec S02310010 7 wire, RM50000
EB35MTC1426 Elektromec S02310043 6 wire, w crimp connectors & separate ground
EB40MTA0003.1 Elektromec SB02310177 no wire leads
EB40MTA0003.1 Elektromec SB02310177 36” 6 WIRE W MOLEX
EB40MTA0003.4 Elektromec SB02310187 24” 6 wire plus ground, blue/brown 7” longer
EB40MTA0003.4 Elektromec SB02310175 23” 6 wire plus ground, no terminals
(RPL by SB02300411) 3-19-14
EP40MTC6200 Elektromec SB02310036 6 wire with separate ground
EP40MTC6200.1 Elektromec SB02310036
EP40MTC6202 Elektromec SB082300530 36” 5 wire plus ground, molex connector
EP40MTC6202 Elektromec SB02310094 4 wire, K41 etc.
EP40MTC6202 Elektromec SB082300530 4 wire
EP40MTC6202 Elektromec SB082300519 (NLA) 6 wire, K29 etc
EP40MTC6205 Elektromec SB082300521 4 wire, K23 etc
EP40R6211.6 Elektromec SB02310201 28” 6 wire plus ground, no terminals
EP40RTC6211 Elektromec SB02310184 4 wire, K23 etc
EP40RTC6211 Elektromec SB02310185 4 wire, 62000
EP40RTC6211 Elektromec SB02310183 6 wire, w crimp connectors & separate ground & 8 position molex
EP40RTC6211.4 Elektromec SB02310186 25” 6 wire plus ground, 2 mm spade connectors
EP65MTC6700.4 Elektromec S02310044 (NLA) 6 wire, with separate ground
EP65MTC6704 Elektromec S02310046 4 WIRE, DD6
HF2L026N Magnetek S97011212 P12
M4E068-DF33-54 EBM SV01766 4 WIRE, P5 & P8
M4E068-DF33-59 EBM SV03457 4 WIRE, P8
R4E355-AF13-10 EBM Papst S99080478 EB12
RH35M-4EK.4F.1R EBM Papst S99080479 EB15
(RPL by S97017160)
NLA = no longer available; OBS = obsolete
42
BEST P.O. Box 140, Hartford, WI 53027
www.BestRangeHoods.com
Toll-Free Hot Line Order Department: 1-800-558-1711 Toll Free Technical Support Group: 1-800-637-1453
In Canada: Broan-NuTone Canada 1-888-882-7626
BEST reserves the right to make changes at any time, without notice, in prices, colors, materials, equipment,
specifications and models, place of manufacture, and to discontinue models or equipment.
99850583L
