1 Introduction

This document describes the usage of the binlog.dll provided with CANoe/CANalyzer.

The BL package is installed in the folder Programming\BLF_Logging of the

CANoe/CANalyzer installation.

Besides the binlog header file in the Include folder, a sample VisualStudio project is

provided in the subfolder VS_Project, which demonstrates the usage of the

binlog.dll. The resulting sample program bl.exe creates the BL file test.blf.

In the subfolder Demo CANoe/CANalyzer configurations are provided, which make

use of the generated sample BL file.

2

Version 1.5 BINLOG DLL Manual © Vector Informatik GmbH

2 BL Functions

2.1 Overview

BLAPI( HANDLE) BLCreateFile( LPCTSTR lpFileName,

DWORD dwDesiredAccess);

BLAPI( BOOL) BLCloseHandle( HANDLE hFile);

BLAPI( BOOL) BLWriteObject( HANDLE hFile,

VBLObjectHeaderBase* pBase);

BLAPI( BOOL) BLPeekObject( HANDLE hFile,

VBLObjectHeaderBase* pBase);

BLAPI( BOOL) BLSkipObject( HANDLE hFile,

VBLObjectHeaderBase* pBase);

BLAPI( BOOL) BLReadObject( HANDLE hFile,

VBLObjectHeaderBase* pBase);

BLAPI( BOOL) BLReadObjectSecure( HANDLE hFile,

VBLObjectHeaderBase* pBase

,

size_t expectedSize);

BLAPI( BOOL) BLFreeObject( HANDLE hFile,

VBLObjectHeaderBase* pBase);

BLAPI( BOOL) BLSetApplication( HANDLE hFile, BYTE appID,

BYTE appMajor,

BYTE appMinor,

BYTE appBuild);

BLAPI( BOOL) BLSetWriteOptions( HANDLE hFile,

DWORD dwCompression,

DWORD dwReserved);

3

BLAPI( BOOL) BLSetMeasurementStartTime

( HANDLE hFile,

const LPSYSTEMTIME lpStartTime);

BLAPI( BOOL) BLGetFileStatistics

( HANDLE hFile,

VBLFileStatistics* pStatistics);

BLAPI( BOOL) BLGetFileStatisticsEx

( HANDLE hFile,

VBLFileStatisticsEx* pStatistics);

BLAPI( BOOL) BLFlushFileBuffers( HANDLE hFile,

DWORD dwFlags);

4

Version 1.5 BINLOG DLL Manual © Vector Informatik GmbH

2.2 BLCreateFile

Syntax BLAPI( HANDLE) BLCreateFile( LPCTSTR lpFileName,

DWORD dwDesiredAccess)

Description Use this function to open a BL file with the desired access.

Parameters LPCTSTR lpFileName

Pointer to a null-terminated string that specifies the name

of the file to create or open.

DWORD dwDesiredAccess

Specifies the type of access to the file. An application can

obtain read access or write access. This parameter can be

GENERIC_READ or GENERIC_WRITE.

Return values If the function succeeds, the return value is an open handle to the

specified file. If the function fails, the return value is INVA-

LID_HANDLE_VALUE.

2.3 BLCloseHandle

Syntax BLAPI( BOOL) BLCloseHandle( HANDLE hFile)

Description Use this function to close a BL file opened with BLCreateFile.

Parameters HANDLE hFile

The file handle returned by BLCreateFile.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

2.4 BLWriteObject

Syntax BLAPI( BOOL) BLWriteObject( HANDLE hFile,

VBLObjectHeaderBase* pBase)

Description Use this function to write a BL object to the file.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_WRITE access to

the file.

VBLObjectHeaderBase* pBase

Pointer to a BL object structure containing the data to be

5

written to the file.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

2.5 BLPeekObject

Syntax BLAPI( BOOL) BLPeekObject( HANDLE hFile,

VBLObjectHeaderBase* pBase)

Description Use this function to read the base header part of a BL object.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_READ access to

the file.

VBLObjectHeaderBase* pBase

Pointer to a BL object structure that receives the object

header description.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

2.6 BLSkipObject

Syntax BLAPI( BOOL) BLSkipObject( HANDLE hFile,

VBLObjectHeader Base* pBase)

Description Use this function to skip a BL object.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_READ access to

the file.

VBLObjectHeaderBase* pBase

Pointer to a BL object structure that describes the object to

be skipped.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

6

Version 1.5 BINLOG DLL Manual © Vector Informatik GmbH

2.7 BLReadObject (Obsolete)

Obsolete: This function has been replaced by BLReadObjectSecure.

Syntax BLAPI( BOOL) BLReadObject( HANDLE hFile,

VBLObjectHeaderBase* pBase)

Description Use this function to read a BL object.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_READ access to

the file.

VBLObjectHeaderBase* pBase

Pointer to a BL object structure that describes the object

to be read.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

2.8 BLReadObjectSecure

Syntax BLAPI( BOOL) BLReadObjectSecure( HANDLE hFile,

VBLObjectHeaderBase* pBase,

size_t expectedSize)

Description Use this function to read a BL object.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_READ access to

the file.

VBLObjectHeaderBase* pBase

Pointer to a BL object structure that describes the object

to be read

size_t expectedSize

Size of BL object structure which is provided by pointer

pBase.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

2.9 BLFreeObject

Syntax BLAPI( BOOL) BLFreeObject( HANDLE hFile,

VBLObjectHeaderBase* pBase)

Description Use this function to free the memory which has been allocated for

a previously read BL object. Altough this is only required for dy-

7

namic sized objects such as environment variables it doesn't harm

to call this method for fixed sized objects like CAN messages as

well.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_READ access to

the file.

VBLObjectHeaderBase* pBase

Pointer to a BL object structure that describes the object

to be freed.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

2.10 BLSetApplication

Syntax BLAPI( BOOL) BLSetApplication( HANDLE hFile,

BYTE appID,

BYTE appMajor,

BYTE appMinor,

BYTE appBuild)

Description Use this function to specify the application which writes the file.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_WRITE access to

the file.

BYTE appID

The application identifier.

BYTE appMajor

The application major version number.

BYTE appMinor

The application minor version number.

BYTE appBuild

The application build version number.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

8

Version 1.5 BINLOG DLL Manual © Vector Informatik GmbH

2.11 BLSetWriteOptions

Syntax BLAPI( BOOL) BLSetWriteOptions( HANDLE hFile,

DWORD dwCompres

sion,

DWORD dwReserved)

Description Use this function to set the compression.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_WRITE access to

the file.

DWORD dwCompression

The compression to be used during write. Valid values

range from 0 (no compression) to 10 (maximum compres

sion).

DWORD dwReserved

Reserved. Must be zero.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

2.12 BLSetMeasurementStartTime

Syntax BLAPI( BOOL) BLSetMeasurementStartTime

( HANDLE hFile,

const LPSYSTEMTIME lpStartTime);

Description Use this function to set the measurement start time

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_WRITE access to

the file.

LPSYSTEMTIME lpStartTime

The pointer to the windows system time structure

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

9

2.13 BLGetFileStatistics

Syntax BLAPI( BOOL) BLGetFileStatistics( HANDLE hFile,

VBLFileStatistics* pStatistics)

Description Use this function to retrieve the file statistics.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_READ access to

the file.

VBLFileStatistics* pStatistics

The pointer to the file statistics structure.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

2.14 BLGetFileStatisticsEx

Syntax BLAPI( BOOL) BLGetFileStatisticsEx

( HANDLE hFile,

VBLFileStatisticsEx* pStatistics)

Description Use this function to retrieve the extended file statistics.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_READ access to

the file.

VBLFileStatisticsEx* pStatistics

The pointer to the extended file statistics structure.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

2.15 BLFlushFileBuffers

Syntax BLAPI( BOOL) BLFlushFileBuffers( HANDLE hFile,

DWORD dwFlags)

Description

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_WRITE access to

the file.

DWORD dwFlags

10

Flag indicating how to flush. Valid values are:

BL_FLUSH_STREAM - flushes all internal streams

BL_FLUSH_FILE - flushes the file and combinations

thereof.

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

2.16 BLSeekTime

Syntax BLAPI( BOOL) BLSeekTime ( HANDLE hFile,

ULONGLONG timeStamp,

void* arg,

BOOL (*pProgressCallback)(void*, FLOAT),

WORD callbackRate)

Description Use this function to seek forward in a BLF file to the first object

with a certain time stamp.

Parameters HANDLE hFile

The file handle returned by BLCreateFile. The file handle

must have been created with GENERIC_READ access to

the file.

ULONGLONG timestamp

The time stamp value you are searching for.

void* arg

Argument which is passed back to the pProgressCallback

call. It can be used as a bridge between the C-Style binlog

interface and C++ (by passing the class this pointer).

BOOL (*pProgressCallback) (void*, FLOAT)

Callback function, which passes back the arg pointer and

the progress value (between 0 and 1.0).

WORD callbackRate

Rate how often pProgressCallback is called (in ms).

Return values If the function succeeds, the return value is nonzero.

If the function fails, the return value is zero.

11

3 BL structures

3.1 Overview

VBLObjectHeaderBase

VBLFileStatistics

3.2 VBLObjectHeaderBase

typedef struct VBLObjectHeaderBase_t

{

DWORD mSignature; /* signature (BL_OBJ_SIGNATURE) */

WORD mHeaderSize; /* sizeof object header */

WORD mHeaderVersion; /* header version (1) */

DWORD mObjectSize; /* object size */

DWORD mObjectType; /* object type (BL_OBJ_TYPE_XXX) */

} VBLObjectHeaderBase;

3.3 VBLFileStatistics

typedef struct VBLFileStatistics_t

{

DWORD mStatisticsSize; /* sizeof (VBLFileStatistics) */

BYTE mApplicationID; /* application ID */

BYTE mApplicationMajor; /* application major number */

BYTE mApplicationMinor; /* application minor number */

BYTE mApplicationBuild; /* application build number */

ULONGLONG mFileSize; /* file size in bytes */

ULONGLONG mUncompressedFileSize;

/* uncompressed file size in bytes */

DWORD mObjectCount; /* number of objects */

DWORD mObjectsRead; /* number of objects read */

} VBLFileStatistics;

12

3.4 VBLFileStatisticsEx

typedef struct VBLFileStatisticsEx_t

{

DWORD mStatisticsSize; /* sizeof (VBLFileStatisticsEx) */

BYTE mApplicationID; /* application ID */

BYTE mApplicationMajor; /* application major number */

BYTE mApplicationMinor; /* application minor number */

BYTE mApplicationBuild; /* application build number */

ULONGLONG mFileSize; /* file size in bytes */

ULONGLONG mUncompressedFileSize;

/* uncompressed file size in bytes */

DWORD mObjectCount; /* number of objects */

DWORD mObjectsRead; /* number of objects read */

SYSTEMTIME mMeasurementStartTime;

/* measurement start time */

SYSTEMTIME mLastObjectTime; /* last object time */

DWORD mReserved[18]; /* reserved */

} VBLFileStatisticsEx;

13

4 Additional informations

4.1 Extended CAN identifiers

The following structure is used to write CAN frames:

typedef struct VBLCANMessage_t

{

VBLObjectHeader mHeader; /* object header */

WORD mChannel; /* application channel */

BYTE mFlags; /* CAN dir & rtr */

BYTE mDLC; /* CAN dlc */

DWORD mID; /* CAN ID */

BYTE mData[8]; /* CAN data */

} VBLCANMessage;

The member mID is used for the numeric identifier of the frame. If you want to write

an extended frame identifier, you have to set the highest bit of the mID field. E.g. if

you want to write a frame with the extended identifier 0x100, you have to do the fol-

lowing:

message.mID = 0x80000100

For the same frame with a standard identifier you would use the field mID in the fol-

lowing way:

message.mID = 0x00000100

14

5 License

5.1 Acknowledgement

The compression routines used in the BL library derive from the zlib library.

5.2 The zlib Software License

Adler

This software is provided 'as-is', without any express or implied warranty. In no event

will the authors be held liable for any damages arising from the use of this software.

Permission is granted to anyone to use this software for any purpose, including

commercial applications, and to alter it and redistribute it freely, subject to the

following restrictions:

• The origin of this software must not be misrepresented; you must not claim that

you wrote the original software. If you use this software in a product, an ac-

knowledgment in the product documentation would be appreciated but is not

required.

• Altered source versions must be plainly marked as such, and must not be mis-

represented as being the original software.

• This notice may not be removed or altered from any source distribution.

Jean-loup Gailly (jloup@gzip.org) Mark Adler (madler@alumni.caltech.edu)

The data format used by the zlib library is described by RFCs (Request for Com-

ments) 1950 to 1952 in the files ftp://ds.internic.net/rfc/rfc1950.txt (zlib format),

rfc1951.txt (deflate format) and rfc1952.txt (gzip format).

BINLOG DLL Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
